GSM Tracker
Prime bolt
User Manual
Revision: 1.00
Document Title Prime bolt User manual
Version 1.00
Finale Date 2015-5-20
Status Released
Document Control ID TRACKER Prime bolt
2
Contents
1 Introduction......................................................................................................................................3
2 Product Overview............................................................................................................................ 3
2.1 Appearance............................................................................................................................3
2.2 Buttons/Micro USB Interface Description........................................................................... 3
2.3 LED Description................................................................................................................... 4
3 Getting Started................................................................................................................................. 5
3.1 Parts List................................................................................................................................5
3.2 Battery Charging...................................................................................................................5
3.3 Prime ATC Data Cable..........................................................................................................6
3.4 Power on/Power off.............................................................................................................. 6
4 Trouble shooting and Safety info.....................................................................................................7
4.1 Trouble shooting................................................................................................................... 7
4.2 Safety info.............................................................................................................................7
3
1 Introduction
Prime bolt is a powerful GPS locator which is designed for vehicle, pets and assets tracking. With
superior receiving sensitivity, fast TTFF and GSM frequencies 850/1900. Its location can be real
time or schedule tracked by backend server or specified terminals. Based on the embedded
wireless tracking protocol, Prime bolt can communicate with the backend server through
GPRS/GSM network, and transfer reports of emergency, Geo-fencing, device status and scheduled
GPS position etc… Service provider is easy to setup their tracking platform based on the
functional wireless tracking protocol.
2 Product Overview
2.1 Appearance
Figure 1-1
4
2.2 LED / Wireless Charging Center
Figure 1-2
There are one red LED light and a wireless charging center icon on PRIME BOLT front
face.
The LED description is as following.
Light Event State
Power LED Power on Solid red
Fully charged and normal Dark
In charging Slow flash red
3 Getting Started
3.1 Parts List
Name Picture Remark
Prime bolt Locater The GSM/GPRS/GPS locator.
Prime bolt
Wireless Charging
Pad
The WPC-certified Wireless charging
transmitter.
5
AC-DC Power
Adapter / Cable
It is used to connect the wireless charging pad
for power supply.
3.2 Battery Wireless Charging
The following items are suggestion for battery charge, please pay more attention.
Please connect AC-DC power adapter/cable with wireless charging pad.
Insert the AC-DC power adapter into the power socket.
Place Prime bolt on the wireless charging pad as following.
For optimal performance, Prime bolt should be placed in the proper location on the pad.
The charging pad LED light will fast flash blue if the device is not properly aligned and
slowly flash blue when a good charge alignment is acquired.
During the charging process, the Prime bolt Power LED lightwill flash red. When
the battery is fully charged, the Prime bolt Power LED light will be dark.
Charging will last about 20 hours.
4 Trouble shooting and Safety info
4.1 Trouble shooting
Trouble Possible Reason Solution
Messages can’t be
reported to the
backend server by
APN is wrong. Some
APN can not visit the
internet directly.
Ask the network operator for the right
APN.
6
4.2 Safety info
The following items are suggestion for safety use, please pay more attention.
Please do not disassemble the device by yourself.
Please do not put the device on the overheating or too humid place, avoid exposure
to direct sunlight. Too high temperature will damage the device or even cause the
battery explosion.
Please do not use Prime bolt on the airplane or near medical equipment.
FCC Caution.
§ 15.19 Labelling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
GPRS. The IP address or port of
the backend server is
wrong.
Make sure the IP address for the
backend server is an identified address
in the internet.
Prime bolt can’t fix
GPS successfully.
GPS LED flashes
slowly.
The GPS signal is weak. Please move Prime bolt to a place with
open sky.
It is better to let the top surface face to
the sky. (The same surface with
indication LED)
7
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
*RF warning for Mobile device:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
