Nokia Bluetooth Headset BH-112U User Guide
Issue 1.2
Introduction
About your headset
With the Nokia Bluetooth BH-112U headset, you can handle calls hands-free, even when
you are using two mobile devices at the same time.
The surface of this product is nickel-free.
Warning:
This product may contain small parts. Keep them out of the reach of small children.
Parts of the product are magnetic. Metallic materials may be attracted to the product.
Do not place credit cards or other magnetic storage media near the product, because
information stored on them may be erased.
Read this user guide carefully before using the product. Also, read the user guide for
the device that you connect to the product.
About Bluetooth connectivity
You can use Bluetooth to make a wireless connection to other compatible devices, such
as mobile devices.
Devices do not need to be in direct line-of-sight, but they must be within 10 metres (33
feet) of each other. The connection may be affected by obstructions such as walls or
other electronic devices.
This device is compliant with Bluetooth Specification 2.1 +EDR supporting the following
profiles: Headset Profile (HSP) 1.1, Handsfree Profile (HFP) 1.5. Check with the
manufacturers of other devices to determine their compatibility with this device.
2
Get started
Keys and parts
1Charger connector
2Indicator light
3Power key
4Microphone
5Call key
6Earpiece
7Earloop
Start using your headset
When you switch on your headset for the first time, a voice prompt helps you set up
your headset. Voice prompts are not available in all languages.
The headset comes with different sized earpads. Select the earpad that fits the best and
is the most comfortable for your ear. To change the earpad, pull the current earpad from
the earpiece, and push the new earpad into place.
1 To switch the headset on, press and hold for 2 seconds. If the headset doesn't
switch on, charge the battery.
2 Gently push the earpiece into your ear.
3 To pair the headset with a compatible phone, follow the voice prompt.
Charge the battery
Before using the headset, you must charge the battery.
3
1
2
3
7
6
5
4
Warning:
Use only chargers approved by Nokia for use with this particular model. The use of any
other types may invalidate any approval or warranty, and may be dangerous. Use of
unapproved chargers may present a risk of fire, explosion, or other hazard.
2 Connect the charger cable to the charger connector on the headset. The red indicator
light turns green when the battery is fully charged.
3 Disconnect the charger from the headset, then from the wall outlet.
When you unplug a charger, hold and pull the plug, not the cord.
The fully charged battery has power for up to 5 hours of talk time or up to 150 hours of
standby time.
When the battery charge is low, you hear a voice prompt, the headset beeps every 5
minutes, and the red indicator light flashes. When the battery is charging, the red
indicator light is on.
Check the battery charge
Make sure the headset is switched on, and press . A green light indicates a sufficient
charge level. If the light is yellow, you may need to recharge the battery soon. If the
light is red, recharge the battery.
Switch the headset on or off
Switch on
Press and hold for 2 seconds. The headset beeps, and a green indicator light flashes
once.
The headset connects to the last connected device. If you have never paired the headset
with a device, or you have cleared the device pairings, pairing mode is activated.
Switch off
Press and hold for 2 seconds. The headset beeps, and a red indicator light flashes
once. All active calls are ended.
If not connected to a device within 30 minutes, the headset switches off.
Pair and connect the headset to your phone
Before using the headset, you must pair and connect it to a compatible phone.
4
1Connect the USB cable to the USB connector of the charger. Connect the charger
to a wall outlet.
1 To switch the headset off, press and hold for 2 seconds.
2 Switch on the phone to pair with.
3 If you have never paired the headset with a phone, or you have cleared the phone
pairings, switch the headset on.
If you have previously paired your headset with another phone, press and hold
for 5 seconds.
Pairing mode is activated, and a green indicator light starts to flash quickly. Follow
the voice prompt.
4 Within 3 minutes, activate Bluetooth on the phone, and set it to search for Bluetooth
devices. For details, see the user guide of the phone.
5 Select the headset from the list of found devices.
6 If required, enter the passcode 0000.
You can pair your headset with 8 compatible phones, but you can only connect it to a
maximum of 2 phones at the same time.
With some phones, you may need to make the connection separately after pairing.
Wear the headset
If you want to use the headset with the earloop, attach the earloop to the headset. To
detach the earloop, gently pull it from the headset.
Slide the earloop behind your ear, and gently push the earpiece against your ear.
Carefully bend the earloop around your ear for the best fit. Point the headset towards
your mouth.
5
Make calls
Make and receive calls
To make and receive calls using your headset, you need to connect it to your phone.
Make a call
Make a call in the normal way.
Answer a call
Press .
End a call
Press .
Reject a call
Press twice.
Switch a call between your headset and phone
Press and hold for 2 seconds.
You can redial the last called number or use voice dialling, if your phone supports these
features with the headset.
Redial the last called number
When no call is in progress, press twice.
Use voice dialling
When no call is in progress, press and hold for 2 seconds, and follow the instructions
in the user guide of your phone.
6
Change the volume
Set the desired volume level on your connected mobile device. The selected volume level
is saved as the minimum volume level for the device that is currently connected to the
headset.
Pair and connect the headset to two phones
When you use the headset for the first time, it automatically connects to your phone.
You can also connect your headset to another phone, and manage calls from, for
example, both your personal and your work phone at the same time.
1 Make sure Bluetooth is activated on both phones.
2 To switch the headset off, press and hold for 2 seconds.
3 To activate pairing mode, press and hold for 5 seconds, and pair the headset
with the second phone.
4 Switch the headset off and back on. The headset connects to both phones.
To use your headset with just one phone again, activate pairing mode, and press and
hold and for 5 seconds.
Handle calls from two phones
If your headset is connected to two phones, you can handle calls from both at the same
time.
End an ongoing call, and answer a call on another phone
Press .
Put an ongoing call on hold, and answer a call on another phone
Press and hold for 2 seconds.
Switch between active and held calls
Press and hold for 2 seconds.
End an ongoing call, and activate a held call
Press .
If you redial or use voice dialling, the call is made on the phone you last had an active
call on with the headset.
Settings
Clear device pairings
1 To switch the headset off, press and hold for 2 seconds.
7
2Press and hold and for 9 seconds. The headset beeps twice, and the red and
green indicator lights alternate.
3 When the headset switches on, follow the voice prompt. Pairing mode is activated.
Deactivate voice prompts
1 To switch the headset off, press and hold for 2 seconds.
2 Press and hold for 5 seconds. Pairing mode is activated, and a blue indicator
light starts to flash quickly.
3 Press and hold for 5 seconds. You hear a voice prompt, and a yellow indicator
light flashes once.
Activate voice prompts
1 To switch the headset off, press and hold for 5 seconds.
2 Press and hold for 5 seconds. Pairing mode is activated, and a blue indicator
light starts to flash quickly.
3 Press and hold for 2 seconds. You hear a voice prompt, and a green indicator
light flashes once.
Troubleshooting
•Cannot connect the headset to a compatible device? Make sure the headset is
charged, switched on, and paired with the device.
•Did the headset stop functioning even though it is charged? Plug the charger into
a wall outlet, and while you press and hold the power key, connect the headset to
the charger.
Product and safety information
Battery and charger information
This device has an internal, nonremovable, rechargeable battery. Do not attempt to remove the battery from the device as you
may damage the device.
Charge your device with any Nokia micro-USB charger. Charger plug type may vary. The plug variant is identified by one
of the following: E, X, AR, U, A, C, K, or B.
The battery can be charged and discharged hundreds of times, but it will eventually wear out.
Talk and standby times are estimates only. Actual times are affected by, for example, device settings, features being used,
battery condition, and temperature.
If the battery has not been used for a long time, to begin charging, you may need to connect the charger, then disconnect and
reconnect it.
If the battery is completely discharged, it may take several minutes before the charging indicator is displayed.
8
When your charger is not in use, unplug it from the electrical plug and the device. Do not leave a fully charged battery connected
to a charger, as overcharging may shorten the battery’s lifetime. If left unused, a fully charged battery will lose its charge over
time.
Always keep the battery between 15°C and 25°C (59°F and 77°F). Extreme temperatures reduce the capacity and lifetime of the
battery. A device with a hot or cold battery may not work temporarily.
Do not dispose of batteries in a fire as they may explode. Dispose of batteries according to local regulations. Recycle when
possible. Do not dispose as household waste.
Use the charger for its intended purpose only. Improper use or use of unapproved chargers may present a risk of fire, explosion,
or other hazard, and may invalidate any approval or warranty. If you believe the charger is damaged, take it to a service centre
for inspection before continuing to use it. Never use a damaged charger. Only use the charger indoors.
Take care of your device
Handle your device, charger and accessories with care. The following suggestions help you protect your warranty coverage.
•Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that corrode
electronic circuits. If your device gets wet, allow the device to dry.
•Do not store the device in cold temperatures.
•Do not attempt to open the device.
•Unauthorised modifications may damage the device and violate regulations governing radio devices.
•Do not drop, knock, or shake the device.
•Only use a soft, clean, dry cloth to clean the surface of the device.
Recycle
Always return your used electronic products, batteries, and packaging materials to dedicated collection points. This way you
help prevent uncontrolled waste disposal and promote the recycling of materials.
Crossed-out wheeled-bin symbol
The crossed-out wheeled-bin symbol on your product, battery, literature, or packaging reminds you that all electrical and
electronic products, batteries, and accumulators must be taken to separate collection at the end of their working life. This
requirement applies in the European Union. Do not dispose of these products as unsorted municipal waste. For more
environmental information, see the product Eco profile atwww.nokia.com/ecoprofile.
Copyright and other notices
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this BH-112U product is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/
global/declaration/declaration-of-conformity/.
© 2011-2013 Nokia. All rights reserved.
9
Nokia, Nokia Connecting People, and the Nokia Original Accessories logo are trademarks or registered trademarks of Nokia
Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be
trademarks or tradenames of their respective owners.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Nokia is under license.
The availability of products may vary by region. For more information, contact your Nokia dealer. This device may contain
co mmodit ie s, tec hn olo gy or so ft ware sub je ct t o export la ws a nd regulations from the US and other countries. Diversion contrary
to law is prohibited.
/Issue 1.2 EN
10
FCC/INDUSTRY CANADA NOTICE
This device complies with Part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions: 1. This device may not cause harmful interference; and 2. This device must accept any
interference received, including interference that may cause undesired operation. This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the
equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an
experienced radio/TV technician for help. NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter. NOTE: Changes or modifications not expressly approved by Nokia could void the user's
authority to operate the equipment.
NOTICE FCC / INDUSTRY CANADA
Cet appareil est conforme à la partie 15 de la réglementation FCC et aux normes RSS exemptes de licence d'Industry Canada.
Toute opération est sujette aux deux conditions suivantes: 1. Cet appareil ne doit pas provoquer d'interférence nuisible et 2.
Cet appareil doit accepter toute interférence reçue, y compris les interférences pouvant provoquer un fonctionnement
inattendu. Le présent équipement a été testé et révélé conforme aux limites fixées pour un périphérique numérique de classe
B, conformément à la partie15 de la réglementation FCC. Ces limites sont destinées à apporter une protection raisonnable
contre les interférences nuisibles dans une installation résidentielle. Cet équipement génère, utilise et peut émettre une
énergie de fréquence radio, et en cas d'installation ou d'utilisation non conforme aux instructions, provoquer des interférences
nuisibles aux communications radio. Toutefois, il n'est nullement garanti que des interférences ne se produiront pas dans une
installation particulière. Si cet équipement provoque des interférences nuisibles à la réception radio ou télévision, pouvant être
déterminées par la mise sous tension et hors tension de l'équipement, l'utilisateur est encouragé à tenter de corriger les
interférences par l'une ou plusieurs des mesures suivantes: réorienter ou déplacer l'antenne de réception; augmenter l'espace
séparant l'équipement et le récepteur; raccorder l'équipement à une prise située sur un circuit différent de celui auquel le
récepteur est raccordé; consulter le distributeur ou un réparateur radio/TV compétent pour obtenir de l'assistance. REMARQUE:
Déclaration d'exposition aux radiations FCC: Cet équipement satisfait aux limites d'exposition aux radiations FCC définies pour
un environnement non-contrôlé. Ce transmetteur ne doit pas être situé à côté ou fonctionner en même temps que toute autre
antenne ou transmetteur. REMARQUE: Les changements ou modifications non expressément approuvés par Nokia peuvent
annuler le droit d'usage de l'utilisateur sur l'équipement.
