ENGLISH
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that
this HF-210 product is in compliance with
the essential requirements and other
relevant provisions of Directive 1999/5/EC.
The product is in conformity with the limits
defined in Directive 2004/104/EC (amending
Directive 72/245/EEC), Annex I, paragraph
6.5, 6.6, 6.8 and 6.9. A copy of the
Declaration of Conformity can be found at
http://www.nokia.com/phones/
declaration_of_conformity
© 2010 Nokia. All rights reserved.
Nokia, Nokia Connecting People and the
Nokia Original Accessories logo are
trademarks or registered trademarks of
Nokia Corporation. Nokia tune is a sound
mark of Nokia Corporation. Other product
and company names mentioned herein may
be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or
storage of part or all of the contents in this
document in any form without the prior
written permission of Nokia is prohibited.
Nokia operates a policy of continuous
development. Nokia reserves the right to
make changes and improvements to any of
the products described in this document
without prior notice.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
To the maximum extent permitted by
applicable law, under no circumstances shall
Nokia or any of its licensors be responsible
for any loss of data or income or any special,
incidental, consequential or indirect
damages howsoever caused.
The contents of this document are provided
"as is". Except as required by applicable law,
no warranties of any kind, either express or
implied, including, but not limited to, the
implied warranties of merchantability and
fitness for a particular purpose, are made in
relation to the accuracy, reliability or
contents of this document. Nokia reserves
the right to revise this document or
withdraw it at any time without prior notice.
The availability of products may vary by
region. For more information, contact your
Nokia dealer. This device may contain
commodities, technology or software
9223070_en1_KESKEN.fm Page 4 Thursday, July 8, 2010 12:23 PM
ENGLISH
subject to export laws and regulations from
the US and other countries. Diversion
contrary to law is prohibited.
For your safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
Road safety comes first
Obey all local laws. Always
keep your hands free to
operate the vehicle while driving. Your
first consideration while driving should
be road safety.
Interference
All wireless devices may be
susceptible to interference,
which could affect performance.
Introduction
With the Nokia Speakerphone
HF-210, you can make and answer
calls hands-free.
Read this user guide carefully before
using the speakerphone. Also, read the
user guide for the device that you
connect to the speakerphone.
This product may contain small parts.
Keep them out of the reach of small
children.
The surface of this device is nickel-
free.
9223070_en1_KESKEN.fm Page 5 Thursday, July 8, 2010 12:23 PM
ENGLISH
Bluetooth wireless technology
Bluetooth wireless technology allows
you to connect compatible devices
without cables. The speakerphone and
the other device do not need to be in
line of sight, but they should be within
10 metres (33 feet) of each other.
Connections may be subject to
interference from obstructions, such
as walls, or other electronic devices.
The speakerphone is compliant with
the Bluetooth Specification 2.1 + EDR
supporting the following profiles:
Handsfree Profile 1.5. Check with the
manufacturers of other devices to
determine their compatibility with
this device.
Get started
The speakerphone contains the
following parts shown on the title
page: volume down key (1),
microphone (2), answer/end key with
indicator light (3), clip (4), volume up
key (5), power key (6), release tab (7),
speaker (8), and charger connector (9).
Before using the speakerphone, you
must charge the battery and pair the
speakerphone with a compatible
device.
Parts of the device are magnetic. Metallic
materials may be attracted to the device.
Do not place credit cards or other
magnetic storage media near the device,
because information stored on them may
be erased.
Charge the battery
Before charging the battery, carefully
read “Battery information”.
1. Connect the charger cable to the
charger connector.
9223070_en1_KESKEN.fm Page 6 Thursday, July 8, 2010 12:23 PM
ENGLISH
2. Connect the charger to the power
source. The red indicator light is
displayed while charging.
If you use a charger that is
connected to the cigarette lighter
socket, power must be supplied by
a 12-volt car battery. Make sure
the charger is properly inserted in
the cigarette lighter socket and
does not interfere with the normal
operation of the car.
In some car models, the cigarette
lighter socket is powered by the car
battery, even when you remove the
ignition key. In those cases, the car
battery might be discharged, even
if the speakerphone is not used. For
more information, contact the
vehicle manufacturer.
If charging does not start,
disconnect the charger and plug it
in again. Charging the battery fully
may take up to 2 hours.
3. When the battery is fully charged,
the green indicator light is
displayed. Disconnect the charger
from the speakerphone, then from
the power source.
The fully charged battery has power
for up to 10 hours of talk time or up to
240 hours of standby time.
To check the battery charge, observe
the colour of the indicator light when
you switch on the speakerphone. If the
light is green, the charge level is
sufficient. If the light is yellow, you
may need to recharge the battery
soon. If the light is red, recharge the
battery.
When the battery charge is low, the
speakerphone beeps every 5 minutes
and the red indicator light flashes.
Switch on or off
To switch on, press the power key. The
speakerphone beeps, and the indicator
9223070_en1_KESKEN.fm Page 7 Thursday, July 8, 2010 12:23 PM
ENGLISH
light flashes slowly while the
speakerphone tries to connect to the
last used device. When the
speakerphone is connected to your
device and is ready for use, the blue
indicator light flashes slowly. If the
speakerphone has not been paired
with a device, it automatically enters
pairing mode.
To switch off, press the power key. The
speakerphone beeps, and the red
indicator light is briefly displayed. If
the speakerphone is not connected to
a device within about 30 minutes, it
switches off automatically.
Pair and connect
Before using the speakerphone, you
must pair and connect it to a
compatible device.
You can pair the speakerphone with
up to 8 devices, but connect it to only
one device at a time.
1. Make sure your mobile device is
switched on.
2. If you have not previously paired
the speakerphone with a device,
switch on the speakerphone. The
speakerphone enters pairing mode,
and the blue indicator light starts
to flash quickly.
If you have previously paired the
speakerphone with a device, make
sure the Bluetooth function is
deactivated in the current device
or the device is not within 10
metres (33 feet) of the
speakerphone. Then switch off the
speakerphone, and switch it on
again.
3. Within about 3 minutes, activate
the Bluetooth feature on your
device, and set the device to search
for Bluetooth devices. See the user
guide of your device for
instructions.
9223070_en1_KESKEN.fm Page 8 Thursday, July 8, 2010 12:23 PM
ENGLISH
4. Select the speakerphone from the
list of found devices.
5. If necessary, enter the passcode
0000 to pair and connect the
speakerphone to your device. In
some devices, you may need to
make the connection separately
after pairing.
When the speakerphone is connected
to your device and is ready for use, the
blue indicator light flashes slowly.
When you switch on the
speakerphone, it tries to connect to
the last used device. If the connection
fails, the speakerphone tries to
connect to one of the other paired
devices. To reconnect the
speakerphone when it is on, but not
connected to a device, make sure the
other device is on, and switch the
speakerphone off and back on; or
make the connection in the Bluetooth
menu of your device.
You may be able to set your mobile
device so that the speakerphone
connects to it automatically. To
activate this feature in a Nokia device,
modify the paired device settings in
the Bluetooth menu.
Installation in a car
You can attach the speakerphone to
the sunvisor of your car using the
supplied clip.
General safety instructions
When you install the speakerphone in
a car, make sure it does not interfere
with or hinder the systems used in the
operation of the vehicle (for example,
9223070_en1_KESKEN.fm Page 9 Thursday, July 8, 2010 12:23 PM
ENGLISH
airbags) or disturb your field of vision
while driving.
Check that the deployment of the
airbags is not blocked or impaired in
any way. Only operate the
speakerphone if it is safe to do so
under all driving conditions.
To use the speakerphone when it is
attached to the sunvisor, make sure
the sunvisor is folded up against the
car roof (10).
Attach the clip to the sunvisor
Slide the clip around the sunvisor from
the driver’s or passenger’s side.
Push the clip towards the sunvisor
(14), and pull the strap attached to the
clip (15 and 16). Firmly press the hook
and loop end of the strap against the
felt on the strap (17) to keep the
speakerphone securely in place. Fold
the sunvisor up against the car roof
(18).
Attach the speakerphone to the
clip
Line up the recess at the right side of
the speakerphone with the catch on
the clip (11), and press the left side
towards the clip (12) to lock the
speakerphone firmly in place. Check
that the speakerphone is in the correct
position.
To detach the speakerphone, press the
release tab, and pull the speakerphone
away from the clip (13).
9223070_en1_KESKEN.fm Page 10 Thursday, July 8, 2010 12:23 PM
ENGLISH
Basic use
Adjust volume
During a call, press either volume key.
Warning: Do not hold the
device near your ear, because
the volume may be extremely
loud.
Calls
To make a call, use your mobile device
in the normal way when the
speakerphone is connected to it.
Speak towards the speakerphone
microphone. For optimal performance,
check that there are no objects in
front of the microphone and that the
microphone is in front of you. During a
call, the blue indicator light is
displayed.
To redial the number you last called (if
your mobile device supports this
feature with the speakerphone), when
no call is in progress, press the
answer/end key twice.
To activate voice dialling (if your
mobile device supports this feature
with the speakerphone), when no call
is in progress, press and hold the
answer/end key for about 2 seconds.
Proceed as described in the user guide
of the mobile device.
To answer a call, press the answer/end
key. To reject a call, press the answer/
end key twice.
To end a call, press the answer/end
key.
To switch an active call between the
speakerphone and the connected
device, press and hold the answer/end
key for about 2 seconds.
9223070_en1_KESKEN.fm Page 11 Thursday, July 8, 2010 12:23 PM
ENGLISH
Activate or deactivate lights
By default, the indicator lights are
used in all situations. To deactivate
the lights in some situations (for
example, during a call or when the
speakerphone is connected to a
mobile device), press and hold the
answer/end key and the volume down
key for about 5 seconds when the
speakerphone is connected to a
device. The speakerphone beeps, and
the yellow indicator light flashes once.
To activate the lights, press and hold
the answer/end key and the volume up
key for about 5 seconds. The
speakerphone beeps, and the green
indicator light flashes once.
Clear settings or reset
To clear the pairing settings from the
speakerphone, switch off the
speakerphone, and press and hold the
power key and the answer/end key at
the same time for over 8 seconds.
When the settings are cleared, the red
and green indicator lights alternate.
To reset the speakerphone if it stops
functioning, even though it is charged,
connect the speakerphone to a
charger while you press and hold the
power key.
Troubleshooting
If you cannot connect the
speakerphone to your compatible
device, check that the speakerphone is
charged, switched on, and paired with
your device.
9223070_en1_KESKEN.fm Page 12 Thursday, July 8, 2010 12:23 PM
ENGLISH
Battery information
This device has an internal,
nonremovable, rechargeable battery. Do
not attempt to remove the battery from
the device as you may damage the
device. This device is intended for use
when supplied with power from the
following chargers: AC-3, AC-4, AC-5,
AC-8, AC-15, DC-4, DC-9, and DC-13.
The exact charger model number may
vary depending on the type of plug. The
plug variant is identified by one of the
following: E, X, AR, U, A, C, K, or B. The
battery can be charged and discharged
hundreds of times, but it will eventually
wear out.
Talk and standby times are estimates
only. Actual times are affected by, for
example, device settings, features being
used, battery condition, and temperature.
If the battery has not been used for a
long time, to begin charging, you may
need to connect the charger, then
disconnect and reconnect it.
If the battery is completely discharged, it
may take several minutes before the
charging indicator is displayed.
When your charger is not in use, unplug
it from the electrical plug and the device.
Do not leave a fully charged battery
connected to a charger, as overcharging
may shorten the battery's lifetime. If left
unused, a fully charged battery will lose
its charge over time.
Always keep the battery between 15°C
and 25°C (59°F and 77°F). Extreme
temperatures reduce the capacity and
lifetime of the battery. A device with a
hot or cold battery may not work
temporarily.
Do not dispose of batteries in a fire as
they may explode. Dispose of batteries
according to local regulations. Recycle
when possible. Do not dispose as
household waste.
9223070_en1_KESKEN.fm Page 13 Thursday, July 8, 2010 12:23 PM
ENGLISH
Use the charger for its intended purpose
only. Improper use or use of unapproved
chargers may present a risk of fire,
explosion, or other hazard, and may
invalidate any approval or warranty. If
you believe the charger is damaged, take
it to a service centre for inspection before
continuing to use it. Never use a
damaged charger. Only use the charger
indoors.
Take care of your device
Handle your device, charger and
accessories with care. The following
suggestions help you protect your
warranty coverage.
• Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits. If your
device does get wet, allow it to dry
completely.
• Do not use or store the device in dusty
or dirty areas. Moving parts and
electronic components can be
damaged.
• Do not store the device in high
temperatures. High temperatures can
shorten the life of the device, damage
the battery, and warp or melt plastics.
• Do not store the device in cold
temperatures. When the device
warms to its normal temperature,
moisture can form inside the device
and damage electronic circuits.
• Do not attempt to open the device.
• Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and
mechanics.
• Only use a soft, clean, dry cloth to
clean the surface of the device.
9223070_en1_KESKEN.fm Page 14 Thursday, July 8, 2010 12:23 PM
ENGLISH
• Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
Recycle
Always return your used electronic
products, batteries, and packaging
materials to dedicated collection points.
This way you help prevent uncontrolled
waste disposal and promote the recycling
of materials. Check product
environmental information and how to
recycle your Nokia products at
www.nokia.com/werecycle, or with a
mobile device, www.nokia.mobi/
werecycle.
The crossed-out wheeled-bin
symbol on your product, battery,
literature, or packaging reminds
you that all electrical and
electronic products, batteries,
and accumulators must be taken to
separate collection at the end of their
working life. This requirement applies in
the European Union. Do not dispose of
these products as unsorted municipal
waste. For more information on the
environmental attributes of your device,
see www.nokia.com/ecodeclaration.
Additional safety information
■Vehicles
Radio signals may affect improperly
installed or inadequately shielded
electronic systems in motor vehicles such
as electronic fuel injection, electronic
antilock braking, electronic speed
control, and air bag systems. For more
information, check with the
manufacturer of your vehicle or its
equipment.
9223070_en1_KESKEN.fm Page 15 Thursday, July 8, 2010 12:23 PM
ENGLISH
Faulty installation or service may be
dangerous and may invalidate your
warranty. Check regularly that all
wireless device equipment in your vehicle
is mounted and operating properly. Do
not store or carry flammable liquids,
gases, or explosive materials in the same
compartment as the device, its parts, or
accessories. Remember that air bags
inflate with great force. Do not place
your device or accessories in the air bag
deployment area.
FCC/Industry Canada notice
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: 1. This device may not cause
harmful interference; and 2. This device
must accept any interference received,
including interference that may cause
undesired operation. This equipment has
been tested and found to comply with the
limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and,
if not installed and used in accordance with
the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver. Connect the
equipment into an outlet on a circuit
different from that to which the receiver is
connected. Consult the dealer or an
experienced radio/TV technician for help.
NOTE: FCC Radiation Exposure Statement:
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be
9223070_en1_KESKEN.fm Page 16 Thursday, July 8, 2010 12:23 PM
ENGLISH
co-located or operating in conjunction with
any other antenna or transmitter. NOTE:
Changes or modifications not expressly
approved by Nokia could void the user's
authority to operate the equipment.
9223070_en1_KESKEN.fm Page 17 Thursday, July 8, 2010 12:23 PM
