Microsoft MD-50W Nokia Play 360° Wireless Speaker MD-50W User Manual
Microsoft Mobile Oy Nokia Play 360° Wireless Speaker MD-50W
user manual
Nokia Play 360° Wireless
Speaker MD-50W
9227660/1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Get started
Keys and parts
1 NFC area
2 Volume keys
3 Bluetooth status indicator
4 Bluetooth key
5 Battery status indicator
6 Charger connector
7 Power key
8 Battery cover fixing screw
9 3.5 mm audio input connector
Start using your speaker
1. Charge the battery.
2. If your compatible device, such
as a phone, supports Near Field
Communication (NFC), activate
its NFC feature, and touch the
NFC area of the speaker (1) with
the NFC area of your device. The
speaker switches on, and
connects to the device
automatically.
If your compatible device does
not support NFC, to switch on
the speaker, press and hold the
power key (7). Press and hold
(4) for 3 seconds. Pairing mode
is activated, and the blue
indicator light (3) flashes
slowly. Activate Bluetooth on
your device, set your device to
search for devices, and select
the speaker from the list of
found devices.
3. On your compatible device,
select a song or album, and
start playing music.
4. To connect two speakers for
stereo sound, switch the
speakers off, and press and
hold the power key (7) on both
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
devices for 5 seconds. Connect
your phone to the speaker
which audibly identifies itself
as the left channel.
For more information, go to
www.nokia.com/support, and
search for Nokia Play 360°.
Product and safety information
Battery and charger
information
Your device is intended for use with
a BL-5C rechargeable battery. Nokia
may make additional battery models
available for this device. Always use
original Nokia batteries.
This device is intended for use when
supplied with power from the
following chargers: AC-10. The exact
Nokia charger model number may
vary depending on the plug type,
identified by E, X, AR, U, A, C, K, or B.
Battery safety
Always switch the device off and
disconnect the charger before
removing the battery. When you
unplug a charger or an accessory,
hold and pull the plug, not the cord.
When your charger is not in use,
un plug it from the electrical plug a nd
the device. Do not leave a fully
charged battery connected to a
charger, as overcharging may
shorten the battery’s lifetime. If left
unused, a fully charged battery will
lose its charge over time.
Always keep the battery between
15°C and 25°C (59°F and 77°F).
Extreme temperatures reduce the
capacity and lifetime of the battery.
A device with a hot or cold battery
may not work temporarily.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Accidental short-circuiting can
happen when a metallic object
touches the metal strips on the
battery, for example, if you carry a
spare battery in your pocket. Short-
circuiting may damage the battery
or the connecting object.
Do not dispose of batteries in a fire
as they may explode. Dispose of
batteries according to local
regulations. Recycle when possible.
Do not dispose as household waste.
Do not dismantle, cut, open, crush,
bend, puncture, or shred cells or
batteries. If a battery leaks, do not let
battery liquid touch skin or eyes. If
this happens, immediately flush the
affected areas with water, or seek
medical help.
Do not modify, remanufacture,
attempt to insert foreign objects into
the battery, or immerse or expose it
to water or other liquids. Batteries
may explode if damaged.
Use the battery and charger for their
intended purposes only. Improper
use, or use of unapproved batteries
or incompatible chargers may
present a risk of fire, explosion, or
other hazard, and may invalidate
any approval or warranty. If you
believe the battery or charger is
damaged, take it to a service centre
for inspection before continuing to
use it. Never use a damaged battery
or charger. Only use the charger
indoors.
Take care of your device
Handle your device, battery, charger
and accessories with care. The
following suggestions help you
protect your warranty coverage.
•Keep the device dry.
Precipitation, humidity, and all
types of liquids or moisture can
contain minerals that corrode
electronic circuits. If your device
gets wet, remove the battery, and
allow the device to dry.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
•Do not use or store the device in
dusty or dirty areas. Moving parts
and electronic components can
be damaged.
•Do not store the device in high
temperatures. High temperatures
can shorten the life of the device,
damage the battery, and warp or
melt plastics.
•Do not store the device in cold
temperatures. When the device
warms to its normal temperature,
moisture can form inside the
device and damage electronic
circuits.
•Do not attempt to open the
device.
•Unauthorised modifications may
damage the device and violate
regulations governing radio
devices.
•Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and
mechanics.
•Only use a soft, clean, dry cloth to
clean the surface of the device.
•Do not paint the device. Paint can
clog the moving parts and
prevent proper operation.
•Switch off the device and remove
the battery from time to time for
optimum performance.
Recycle
Always return your used electronic
products, batteries, and packaging
materials to dedicated collection
points. This way you help prevent
uncontrolled waste disposal and
promote the recycling of materials.
Check product environmental
information and how to recycle your
Nokia products at www.nokia.com/
werecycle, or with a mobile device,
http://nokia.mobi/werecycle.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Crossed-out wheeled-bin symbol
The crossed-out wheeled-bin
symbol on your product,
battery, literature, or
packaging reminds you that
all electrical and electronic
products, batteries, and
accumulators must be taken to
separate collection at the end of
their working life. This requirement
applies in the European Union. Do
not dispose of these products as
unsorted municipal waste. For more
information on the environmental
attributes of your device, see
www.nokia.com/ecodeclaration.
Copyright and other notices
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION
declares that this MD-50W product is
in compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity
can be found at www.nokia.com/
phones/declaration_of_conformity/.
© 2011 Nokia. All rights reserved.
Nokia, Nokia Connecting People, and
the Nokia Original Accessories logo
are trademarks or registered
trademarks of Nokia Corporation.
Nokia tune is a sound mark of Nokia
Corporation. Other product and
company names mentioned herein
may be trademarks or tradenames of
their respective owners.
Reproduction, transfer, distribution,
or storage of part or all of the
contents in this document in any
form without the prior written
permission of Nokia is prohibited.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Nokia operates a policy of
continuous development. Nokia
reserves the right to make changes
and improvements to any of the
products described in this document
without prior notice.
Bluetooth is a registered trademark
of Bluetooth SIG, Inc.
The contents of this document are
provided "as is". Except as required
by applicable law, no warranties of
any kind, either express or implied,
including, but not limited to, the
implied warranties of
merchantability and fitness for a
particular purpose, are made in
relation to the accuracy, reliability or
contents of this document. Nokia
reserves the right to revise this
document or withdraw it at any time
without prior notice.
To the maximum extent permitted
by applicable law, under no
circumstances shall Nokia or any of
its licensors be responsible for any
loss of data or income or any special,
incidental, consequential or indirect
damages howsoever caused.
The availability of particular
products may vary by region. Please
check with your Nokia dealer for
details. This device may contain
commodities, technology or
software subject to export laws and
regulations from the US and other
countries. Diversion contrary to law
is prohibited.
FCC/INDUSTRY CANADA NOTICE
This device complies with Part 15 of
the FCC Rules and Industry Canada
licence-exempt RSS standard(s).
Operation is subject to the following
two conditions: 1. This device may
not cause harmful interference; and
2. This device must accept any
interference received, including
interference that may cause
undesired operation. This
equipment has been tested and
found to comply with the limits for a
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful
interference in a residential
installation. This equipment
generates, uses and can radiate
radio frequency energy and, if not
installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is
no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and on,
the user is encouraged to try to
correct the interference by one or
more of the following measures:
Reorient or relocate the receiving
antenna. Increase the separation
between the equipment and
receiver. Connect the equipment
into an outlet on a circuit different
from that to which the receiver is
connected. Consult the dealer or an
experienced radio/TV technician for
help. NOTE: FCC Radiation Exposure
Statement: This equipment complies
with FCC radiation exposure limits
set forth for an uncontrolled
environment. This transmitter must
not be co-located or operating in
conjunction with any other antenna
or transmitter. NOTE: Changes or
modifications not expressly
approved by Nokia could void the
user's authority to operate the
equipment.
