Nokia Bluetooth Speakers MD-5W
9200275/1
12
13
910 11
5
88
7
14
6
432
MD-5W_en1_DRAFT_8_WITH_FFC&IC_notice.fm Page 1 Thursday, December 14, 2006 7:10 PM
ENGLISH
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that
this MD-5W product is in compliance with
the essential requirements and other
relevant provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity can be
found at http://www.nokia.com/phones/
declaration_of_conformity/.
The crossed-out wheeled bin
means that within the European
Union the product must be taken
to separate collection at the
product end-of-life. Do not dispose
of these products as unsorted municipal
waste. For more information, see product
Eco-Declaration or country specific
information at www.nokia.com.
© 2007 Nokia. All rights reserved.
Reproduction, transfer, distribution or
storage of part or all of the contents in this
document in any form without the prior
written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are
registered trademarks of Nokia Corporation.
Other product and company names
mentioned herein may be trademarks or
tradenames of their respective owners.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Nokia operates a policy of ongoing
development. Nokia reserves the right to
make changes and improvements to any of
the products described in this document
without prior notice.
Under no circumstances shall Nokia be
responsible for any loss of data or income or
any special, incidental, consequential or
indirect damages howsoever caused.
The contents of this document are provided
"as is". Except as required by applicable law,
no warranties of any kind, either express or
implied, including, but not limited to, the
implied warranties of merchantability and
fitness for a particular purpose, are made in
relation to the accuracy, reliability or
contents of this document. Nokia reserves
the right to revise this document or
withdraw it at any time without prior notice.
MD-5W_en1_DRAFT_8_WITH_FFC&IC_notice.fm Page 2 Thursday, December 14, 2006 7:10 PM
ENGLISH
The availability of particular products may
vary by region. Please check with the Nokia
dealer nearest to you.
Unauthorized changes or modifications to
this device may void the user's authority to
operate the equipment.
Export Controls
This device may contain commodities,
technology or software subject to export
laws and regulations from the US and other
countries. Diversion contrary to law is
prohibited.
Introduction
Congratulations on your purchase.
With Nokia Bluetooth Speakers
MD-5W you can listen to music from
your compatible phone or music
device and enjoy the high-quality
audio. You can also use the speakers
as a speakerphone thanks to the
integrated microphone.
You can connect the speakers to a
compatible device using Bluetooth
wireless technology or the supplied
cable.
Read this user guide carefully before
using the speakers. Also read the user
guide for your phone, which provides
important safety and maintenance
information, or the user guide for the
compatible music device. Keep all
accessories and enhancements out of
the reach of small children.
Bluetooth wireless technology
Bluetooth wireless technology allows
you to connect compatible devices
without cables. A Bluetooth
connection does not require that the
speakers and the other device be in
line of sight, but both devices should
be within 10 meters (30 feet) of each
other. Connections may be subject to
MD-5W_en1_DRAFT_8_WITH_FFC&IC_notice.fm Page 3 Thursday, December 14, 2006 7:10 PM
ENGLISH
interference from obstructions, such
as walls, or other electronic devices.
The speakers comply with the
Bluetooth Specification 1.2 that
supports Advanced Audio Distribution
Profile (A2DP) 1.0, Headset Profile 1.1,
Hands-Free Profile 1.0, and Audio/
Video Remote Control Profile (AVRCP)
1.0. Check with the manufacturers of
other devices to determine their
compatibility with this device.
There may be restrictions on using
Bluetooth technology in some
locations. Check with your local
authorities or service provider.
Getting started
Parts
The speakers contain the parts shown
on the title page: indicator light (1),
rewind key (2), multifunction key (3),
play/pause key (4), answer/end key (5),
fast forward key (6), microphone (7),
speakers (8), volume down key (9),
stereo widening key (10), volume up
key (11), power connector (12), battery
compartment (13), and audio input
(14).
Parts of the speakers are magnetic.
Metallic materials may be attracted to
the speakers. Do not place credit cards or
other magnetic storage media near the
speakers, because information stored on
them may be erased.
Chargers
Check the model number of any charger
before use with this device. The speakers
are intended for use with the supplied
AC-4 charger.
MD-5W_en1_DRAFT_8_WITH_FFC&IC_notice.fm Page 4 Thursday, December 14, 2006 7:10 PM
ENGLISH
Warning: Use only chargers
approved by Nokia for use
with this particular device.
The use of any other types may invalidate
any approval or warranty and may be
dangerous.
When you disconnect the power cord of
any enhancement, grasp and pull the
plug, not the cord.
Connect to power
The speakers can be powered by four
AA batteries or the supplied charger.
Install AA batteries
When you use batteries, alkaline
batteries are recommended. To install
the batteries, ensure that the speakers
are off, and open the cover of the
battery compartment by pushing the
lower part of the cover and pulling the
cover up.
Place the batteries as indicated in the
compartment, and push the cover
until it snaps into place.
During long periods where the
speakers are not used, remove the
batteries to prevent damage from
battery leakage.
When battery power falls low, the red
indicator light starts to flash and the
speakers beep once a minute.
Connect to wall outlet
To use the speakers with the charger,
connect the charger to a wall outlet,
and plug the charger cable to the
power connector.
If rechargeable batteries are placed in
the battery compartment, they are not
charged by the charger.
MD-5W_en1_DRAFT_8_WITH_FFC&IC_notice.fm Page 5 Thursday, December 14, 2006 7:10 PM
ENGLISH
Switch the speakers on or off
To switch on, press and hold the
multifunction key until the blue
indicator light is displayed.
To switch off, press and hold the
multifunction key until the red
indicator light is displayed.
Connect the speakers
You can connect the speakers to a
compatible device (such as a mobile
phone or music player) using
Bluetooth wireless technology or the
supplied cable.
Pair and connect using Bluetooth
wireless technology
The following instructions apply for a
mobile phone but the procedure is the
same for a music player, except that
you may not need to give the
Bluetooth passcode.
1. Ensure that the speakers are off
and that the phone is on.
2. Press and hold the multifunction
key until the blue and red indicator
lights start to alternate.
3. Activate the Bluetooth feature on
the phone, and set it to search for
Bluetooth devices.
4. Select the speakers from the list of
found devices.
5. Enter the Bluetooth passcode
0000 to pair and connect the
speakers to the phone. In some
phones you may need to make the
connection separately after
pairing.
If the pairing is successful, the blue
indicator light flashes five times, and
the speakers appear in the phone
menu where you can view the paired
Bluetooth devices.
MD-5W_en1_DRAFT_8_WITH_FFC&IC_notice.fm Page 6 Thursday, December 14, 2006 7:10 PM
ENGLISH
Connect using a cable
You can connect the speakers to a
compatible device with the supplied
CA-63U cable.
To connect the speakers to a device
that has a 3.5-mm audio connector,
plug the cable into the audio input on
the speakers and the audio connector
on the device.
Basic use
Adjust the volume
To set the volume of the speakers,
press either volume key. If the sound
level of the speakers becomes too low
when using battery power, change the
batteries.
Listen to music
To listen to music, connect the
speakers to a compatible music player
such as a mobile phone with a music
player feature or other music player
device.
To use the music functions, connect
the compatible device to the speakers
using Bluetooth wireless technology.
The compatible music player should
support the A2DP Bluetooth profile. If
you use a cable connection, you can
only adjust the volume of the
speakers; to control music, use the
keys on your music player.
If you answer or make a call while
listening to music, playing is paused
until the call ends.
Warning: Listen to music at a
moderate level. Continuous
exposure to high volume may
damage your hearing.
MD-5W_en1_DRAFT_8_WITH_FFC&IC_notice.fm Page 7 Thursday, December 14, 2006 7:10 PM
ENGLISH
To play music, select a track on your
music player, and press the play/pause
key.
To select the next track, press the fast
forward key. To select the previous
track, press the rewind key.
To pause or resume playing, press the
play/pause key. To stop playing, press
and hold the play/pause key.
To widen the stereo image of the
sound, check that this feature is off in
your music player, and press the stereo
widening key.
Call handling
The speakers can be used for call
handling if connected to a compatible
phone using Bluetooth wireless
technology.
To make a call, use your phone in the
normal way when the speakers are
connected to your phone. Speak
toward the microphone on the
speakers.
If your phone supports last number
redialing with the speakers, press the
answer/end key twice when no call is
in progress.
If your phone supports voice dialing
with the speakers, press the answer/
end key when no call in progress, and
proceed as described in the user guide
of your phone.
To answer or end a call, press the
answer/end key. If you do not want to
answer the call, press and hold either
volume key.
To switch an ongoing call from the
speakers to a compatible phone, press
and hold either volume key. To switch
the call back to the speakers, press the
multifunction key.
MD-5W_en1_DRAFT_8_WITH_FFC&IC_notice.fm Page 8 Thursday, December 14, 2006 7:10 PM
ENGLISH
Clear settings or reset
To clear the settings, switch off the
speakers. Press and hold the volume
down and multifunction keys until the
purple indicator light is displayed.
Press and hold the volume down key
until the blue indicator light is
displayed.
To reset the speakers if they do not
work, remove the batteries and unplug
the speakers from the charger.
Care and maintenance
Your device is a product of superior
design and craftsmanship and should be
treated with care. The following
suggestions will help you protect your
warranty coverage.
• Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits. If your
device does get wet, allow it to dry
completely.
• Do not use or store the device in
dusty, dirty areas. Its moving parts
and electronic components can be
damaged.
• Do not store the device in hot areas.
High temperatures can shorten the
life of electronic devices, damage
batteries, and warp or melt certain
plastics.
• Do not store the device in cold areas.
When the device returns to its normal
temperature, moisture can form
inside the device and damage
electronic circuit boards.
• Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and fine
mechanics.
MD-5W_en1_DRAFT_8_WITH_FFC&IC_notice.fm Page 9 Thursday, December 14, 2006 7:10 PM
ENGLISH
• Do not use harsh chemicals, cleaning
solvents, or strong detergents to
clean the device.
• Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
If the product is not working properly,
take it to the nearest authorized service
facility for service.
FCC/Industry
Canada notice
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: 1. This device may not cause
harmful interference; and 2. This device
must accept any interference received,
including interference that may cause
undesired operation. This equipment has
been tested and found to comply with the
limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and,
if not installed and used in accordance with
the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver. Connect the
equipment into an outlet on a circuit
different from that to which the receiver is
connected. Consult the dealer or an
experienced radio/TV technician for help.
NOTE: FCC Radiation Exposure Statement:
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be
co-located or operating in conjunction with
any other antenna or transmitter. NOTE:
Changes or modifications not expressly
MD-5W_en1_DRAFT_8_WITH_FFC&IC_notice.fm Page 10 Thursday, December 14, 2006 7:10 PM
ENGLISH
approved by Nokia could void the user's
authority to operate the equipment.
MD-5W_en1_DRAFT_8_WITH_FFC&IC_notice.fm Page 11 Thursday, December 14, 2006 7:10 PM
