Microsoft NPL-3 GSM/EGPRS Cellular Phone User Manual 6200 1 9356027
Microsoft Mobile Oy GSM/EGPRS Cellular Phone 6200 1 9356027
Manual
DRAFT
Nokia 6200 User Guide
DRAFT
Phone notes
My Nokia information Notes Information source
My number Wireless service provider
Voice mail number Wireless service provider
Provider’s customer care Wireless service provider
Message center number Wireless service provider
Default recipient
number (e-mail gateway
number)
Wireless service provider
International Mobile
Equipment Identifier
(IMEI)
Type label. Located on the
back of your phone,
beneath the battery.
Model number 6200
Phone type NPL-3
DRAFT
The wireless phone described in this guide is approved for use in GSM 850,
1800, and 1900 networks.
LEGAL INFORMATION
Part No. 9356027, Issue No. 1
Copyright ©2003 Nokia. All rights reserved.
Nokia, Nokia 6200, Pop-Port, Nokia Connecting People, and the Nokia
Original Accessories logos are trademarks or registered trademarks of
Nokia Corporation. All other product and company names mentioned
herein may be trademarks or tradenames of their respective owners.
Printed in Canada 02/2003
US Patent No 5818437 and other pending patents.T9 text input software
Copyright «1999-2003. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software
from RSA Security.
Java is a trademark of Sun Microsystems, Inc.
The information contained in this user guide was written for the Nokia
6200 phone. Nokia operates a policy of on-going development. Nokia
reserves the right to make changes and improvements to any of the
products described in this document without prior notice.
UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY
LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND
CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS
REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY
OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO
REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR
NOTICE.
EXPORT CONTROLS
This product contains commodities, technology or software exported from
the United States in accordance with the Export Administration
regulations. Diversion contrary to U.S. law is prohibited.
DRAFT
FCC/INDUSTRY CANADA NOTICE
Your phone may cause TV or radio interference (for example, when using
a telephone in close proximity to receiving equipment). The FCC or
Industry Canada can require you to stop using your telephone if such
interference cannot be eliminated. If you require assistance, contact your
local service facility. This device complies with part 15 of the FCC rules.
Operation is subject to the condition that this device does not cause
harmful interference.
The term “IC:” before the certification/registration number only signifies
that Industry Canada technical specifications were met.
DRAFT
Manufactured or sold under one or more following US Patents:
4868846 5519885 5827082 5966378 6112099 6266330
4969192 5526366 5835889 5970059 6115617 6282436
5001372 5553125 5839101 5987137 6118775 6285888
5045973 5557639 584884 5991716 6121846 6292668
5101175 5565821 5845219 5991857 6122498 6295286
5212834 5570369 5857151 5999523 6128322 6308084
5230091 5581244 5862178 6005857 6128509 6310609
5233634 5597102 5870683 6011853 6138091 6311054
5241284 5625274 5887266 6014573 6140966 6314166
5241583 5640395 5889770 6018277 6144243 6324412
5266782 5664004 5892475 6026161 6144676 6347218
5311151 5664053 5898925 6028567 6148209 6356759
5 3111 7 9 5669069 5907823 6029128 6151485 6359904
5317283 5677620 5914690 6038238 6151507 6363259
5331638 5678224 5914796 6043760 6163609 6370362
5335362 5692032 5915440 6047196 6164547 6370390
5353328 5699406 5917868 6049796 6167248 6377803
5378935 5699482 5920826 6050415 6170073 6393121
5384782 5701392 5926138 6055439 6178535 6430721
5390223 5729534 5926769 6060193 6185295 6434133
5396657 5729541 5930233 6069923 6188909
5400949 5734683 5946651 6072787 6195338
5416435 5754976 5956332 6081534 6199035
5442521 5760568 5956625 6084962 6201876
5444816 5782646 5956633 6088746 6219560
5446364 5794142 5960354 6094587 6240076
5479476 5802465 5960389 6097964 6240079
5487084 5805084 5963901 6105784 6249584
5493255 5805301 5966374 6108553 6259312
DRAFT
DRAFT
[ i ]
Contents
1 For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
2 Overview of functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Multimedia messaging service (MMS). . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Polyphonic sound (MIDI). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
(E)GPRS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Speakerphone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
JavaTM applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
FM stereo radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Welcome and quick guide . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Get the most out of this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Understand wireless network services . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Register your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Learn about accessibility solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Understand your phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Get started with the Quick Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Menu shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Get help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
4 Basic operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Switch your phone on or off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Make and answer calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Options during a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Check the start screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Browse phone menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Set up your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
5 Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Standard mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Predictive text input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
6 Manage phone security . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Security levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Fixed dialing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
DRAFT
[ ii ]
Access codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
View the contacts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Save contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Copy contact list entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
1-touch dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Voice dialing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
View Info, Service, and Own numbers . . . . . . . . . . . . . . . . . . . . . . . . . . 53
8 Menu functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Messages (Menu 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Tips for composing a message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Picture messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
E-mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Multimedia messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Voice messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Message options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Organize messages with folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Delete messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Change text, e-mail, and picture message settings . . . . . . . . . . . . . . . 76
Change multimedia message settings . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Call log (Menu 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Call log options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
View missed calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
View received calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
View dialed numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Delete call lists. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
View call duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Profiles (Menu 3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Select a profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Customize a profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Set a timed profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
DRAFT
[ iii ]
Settings (Menu 4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Right selection key settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Time and date settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Call settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Phone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Display settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Tone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Enhancement settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Security settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Restore factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Alarm clock (Menu 5) . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Set an alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Turn off an alarm that has been set. . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Radio (Menu 6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Turn the radio on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Use the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Save a radio channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Gallery (Menu 7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Open the gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
View folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
Organizer (Menu 8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Send and receive calendar notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Make a to-do list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Games (Menu 9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Launch a game. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Applications (Menu 10) . . . . . . . . . . . . . . . . . . . . . . . . . .118
Launch an application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Download applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
View application memory status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
DRAFT
[ iv ]
Extras (Menu 11) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Use the calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Use the currency converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Voice recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Voice commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Audible alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Connectivity (Menu 12) . . . . . . . . . . . . . . . . . . . . . . . . . 127
Infrared . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
(E)GPRS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Synchronize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Nokia PC Suite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Services (Menu 13) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Notes on wireless Internet access . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Sign on to the wireless Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Use browser options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Navigate the wireless Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Use bookmarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Security issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
9 Reference information. . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Battery statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Use proper care and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Understand important safety information. . . . . . . . . . . . . . . . . . . . . . 144
Emergency calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Certification information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Battery information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Enhancements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Frequently asked questions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Technical information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Appendix A (Message from the CTIA) . . . . . . . . . . . . . . . 167
Appendix B (Message from the FDA) . . . . . . . . . . . . . . . . 171
DRAFT
[ 1 ]
1 For your safety
Read these simple guidelines. Breaking the rules may be dangerous or
illegal. Further detailed information is given in this manual.
Do not switch on the phone when wireless phone use is
prohibited or when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Don't use a handheld phone while driving.
INTERFERENCE
All wireless phones may get interference, which could affect
performance.
SWITCH OFF IN HOSPITALS
Follow any regulations or rules. Switch the phone off near
medical equipment.
SWITCH OFF IN AIRCRAFT
Wireless devices can cause interference in aircraft.
SWITCH OFF WHEN REFUELING
Don't use the phone at a refueling point. Don't use near fuel or
chemicals.
SWITCH OFF NEAR BLASTING
Don't use the phone where blasting is in progress. Observe
restrictions, and follow any regulations or rules.
USE SENSIBLY
Use only in the normal position. Don't touch the antenna
unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair phone
equipment.
DRAFT
[ 2 ]
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not
connect incompatible products.
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
BACKUP COPIES
Remember to make backup copies of all important data.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for
detailed safety instructions. Do not connect incompatible
products.
CALLING
Ensure the phone is switched on and in service. Enter the phone
number, including the area code, then press h. To end a call,
press
i. To answer a call, press h.
EMERGENCY CALLS
Ensure the phone is switched on and in service. Press i as
many times as needed (for example, to exit a call, to exit a
menu) to clear the display. Enter the emergency number, then
press h. Give your location. Do not end the call until told to
do so.
DRAFT
[ 3 ]
Overview of functions
2 Overview of functions
• MULTIMEDIA MESSAGING SERVICE (MMS)
Your phone is able to send and receive multimedia messages made up of
text and pictures. You may also be able to receive polyphonic ringing
tones. You can also save pictures and ringing tones to personalize your
phone. See “Multimedia messages” on page 63 for more information.
Important: This feature uses shared memory. Please see “Shared
memory” on page 13 for more information.
• POLYPHONIC SOUND (MIDI)
Polyphonic sounds are used in ringing tones and message alert tones. They
consist of several sound components played at the same time, like an
actual melody through a speaker. Your phone has sound components from
over 40 instruments that can be used for polyphonic sounds and the
phone can play up to eight instruments simultaneously. The phone
supports Scalable Polyphonic MIDI (SP-MIDI) format.
You can receive polyphonic ringing tones via multimedia service (see
“Read and reply to a multimedia message” on page 68), or download them
via the gallery menu, see “Gallery (Menu 7)” on page 107 for more
information.
•(E)GPRS
Enhanced General Packet Radio Service or (E)GPRS technology allows
mobile phones to send and receive data over a mobile network.
Applications such as xHTML, MMS, text messaging, and JavaTM use
(E)GPRS. Your phone supports up to three simultaneous (E)GPRS
connections. For more information, see “(E)GPRS” on page 129.
Before using (E)GPRS technology:
• Contact your network operator or service provider for availability and
subscription to the (E)GPRS service.
DRAFT
[ 4 ]
• Save the (E)GPRS settings for each of the applications used over
(E)GPRS.
PRICING FOR (E)GPRS AND APPLICATIONS
Your wireless provider may charge for (E)GPRS services. For more
information on pricing, contact your wireless provider.
•SPEAKERPHONE
You can use your phone as a speakerphone during a call. Do not hold the
phone to your ear during speakerphone operation.
• To activate the speakerphone, press Loudsp.
• To deactivate the speakerphone during a call, press Handset.
The speakerphone deactivates automatically when you end the call,
attempt to make a new call, or when you connect a headset.
•JAVA
TM
APPLICATIONS
Your phone supports JavaTM and includes some Java applications and
games that have been specially designed for mobile phones. You may be
able to download new applications and games to your phone from a PC
with Java installer software or from some Mobile Internet services. See
“Applications (Menu 10)” on page 118 for more information.
Important: This feature uses shared memory. Please see “Shared
memory” on page 13 for more information.
• FM STEREO RADIO
Your phone has an integrated FM stereo radio. You can listen to the radio
through a headset or the handsfree speaker (with the headset attached).
See “Radio (Menu 6)” on page 105 for more information.
DRAFT
[ 5 ]
Welcome and quick guide
3 Welcome and quick guide
Congratulations on your purchase of the Nokia 6200 mobile phone.
Your phone provides many functions which are practical for daily use,
such as a calendar, radio, alarm clock, calculator, voice recorder, and
more. Your phone can also connect to a PC, laptop, or other device using
the data cable or built-in IR port.
• GET THE MOST OUT OF THIS GUIDE
The following tips can help you get the most from this guide as you learn
to use your phone.
Learn text conventions
This user guide provides text clues to help make instructions clear and
easy to follow. These clues are called conventions.
Follow graphic clues
This guide uses certain icons to alert you to important information.
Tip: Indicates a shortcut or alternate method of doing something.
Note: Explains a feature or points out an important concept.
Important: Indicates critical information on using a feature.
Caution: Warns when you may lose information.
Convention What it means
bold The word or phrase appears on the phone display.
bold and blue The text refers to an address on the world wide web.
italics Indicates emphasis. Pay close attention to any
information in italics.
DRAFT
[ 6 ]
Warning: Helps you avoid personal injury, damage to the phone,
or property damage.
Look for updates
From time to time, Nokia updates this guide to reflect changes. The latest
version may be available at www.nokia.com/us. Also, an interactive
tutorial may be available at www.nokiahowto.com.
• UNDERSTAND WIRELESS NETWORK SERVICES
A number of features in this guide are called network services. These are
special services that you arrange through your wireless service provider.
Before you can take advantage of any of these network services, you must
subscribe to them through your wireless provider and obtain instructions
for their use from your service provider.
•REGISTER YOUR PHONE
Make sure to register your phone at www.warranty.nokiausa.com or
1-888-NOKIA-2U (1-888-665-4228) so that we can serve your needs
better if you should need to call the center or have your phone repaired.
E-Newsletters
When you register your phone, you can sign up for Nokia's e-newsletter,
Nokia Connections, if you would like. You will receive tips and tricks on
using your phone, enhancement information, and special offers.
• LEARN ABOUT ACCESSIBILITY SOLUTIONS
Nokia is committed to making mobile phones easy to use for all
individuals, including those with disabilities. Nokia maintains an internet
site that is dedicated to accessibility solutions. For more information
about phone features, enhancements, alternate format user guides, and
other Nokia products designed with your needs in mind, visit the website
at www.nokiaaccessibility.com or call 1-888-665-4228 for more
information.
DRAFT
[ 7 ]
Welcome and quick guide
• UNDERSTAND YOUR PHONE
Power key
Volume keys
Left select key Right select key
End key
Talk key
Display screen
Earpiece
Number keys
IR Port
Microphone
Pop-PortTM connector
Charger jack
4-way scroll keys
+
-
Handsfree
speaker
DRAFT
[ 8 ]
Use the antenna
Your phone has a built-in antenna. As with any
other radio transmitting device, avoid touching
the antenna unnecessarily when the phone is
switched on. Contact with the antenna affects
call quality and may cause the phone to operate
at a higher power level than otherwise needed.
Not touching the antenna area during a phone
call optimizes the antenna performance and the
talk time of your phone.
Use the battery
CHARGE THE BATTERY
1Plug the charger transformer in to a standard ac outlet.
2Insert the charger output jack into
the round connector at the bottom
end of the phone.
After a few seconds, the battery
indicator in the display starts to
scroll from bottom to top. If the
battery is completely flat, it may take a few minutes before the
charging indicator appears on the display or any calls can be made.
Tip: You can use the phone while the charger is connected.
IMPORTANT BATTERY INFORMATION
Important: Your phone is powered by a rechargeable battery.
Use only batteries approved by Nokia and recharge your battery
only with the chargers approved by Nokia. Never use any charger or
battery which is damaged.
The battery can be charged and discharged hundreds of times but it will
eventually wear out. When the operating time (talk-time and standby
time) is noticeably shorter than normal, it is time to buy a new battery.
DRAFT
[ 9 ]
Welcome and quick guide
PROLONG THE BATTERY
Use the following guidelines to obtain the best performance from
your battery:
• With your phone turned off, charge your new battery for three hours
before its first use. Use the battery until it is fully discharged. Repeat
this procedure twice for a total of three charging cycles.
• Note that the full performance of a new battery is achieved only after
two or three complete charge and discharge cycles. Battery operation
time may be less than the estimated times during the first charges.
This condition is normal.
• You can use your phone while the battery is charging. However, if the
battery is completely empty, it may need to recharge a few minutes
before you can make or receive calls or the battery indicator appears.
• After the first charge, you can make and receive calls during the
charging cycle, but the calls interrupt the charge. When the phone
call ends, the charge will resume.
• The bars on the screen stop scrolling and remain constant when the
phone is fully charged. If you leave the phone connected to the
charger, the battery receives an additional charge. If you switch the
phone on when charging is complete, the message Battery full
momentarily appears in the display.
Note: The battery will accept a “trickle charge" for an additional
two hours.
DRAFT
[ 10 ]
REPLACE THE BATTERY
You will need to remove the existing battery if you want to replace the
battery or insert the SIM card. Make sure the phone has been turned off
for 10 seconds before removing the battery.
REMOVE THE BACK COVER
1With the back of the phone facing you,
push down on the back cover release
button.
2Slide the back cover toward the
bottom of the phone and remove.
REMOVE THE BATTERY
3After you have removed the back
cover, insert your finger into the
finger grip and lift the battery from its
compartment.
Install the SIM card
The SIM card and its contacts can easily be damaged by scratches or
bending, so be careful when handling, inserting, or removing the card.
Before installing the SIM card, always make sure that the phone is
switched off and that you have removed the cover and battery.
Warning: Keep all SIM cards out of reach of small children.
1Slide the SIM card holder toward the
bottom end of the phone until it
unlocks.
1
2
3
1
DRAFT
[ 11 ]
Welcome and quick guide
2Swing the SIM card holder open.
3Insert the SIM card into the holder
(beveled corner last) with the gold
contacts facing toward the top end
of the phone.
4Close the SIM card holder.
5Slide the SIM card holder toward
the top end of the phone until it
locks into place.
INSTALL THE BATTERY
The SIM card must be installed before
installing the battery.
1Position the battery so the gold
contacts match up with those on the
phone. The battery label should be
facing away from the phone.
2Insert the battery, contact end first
into the battery slot.
2
3
4
5
DRAFT
[ 12 ]
3Snap the other end of the battery into place.
REPLACE THE BACK COVER
4Slide the back cover toward the top
of the phone until you hear a click
and see the back cover release
button.
Use the selection and scroll
keys
Below each corner of the display
are the selection keys. Press b
when Menu appears above it to
show the first of numerous menus.
Page through the rest of the
menus using the up and down
scroll keys (d or g). Press c
when Contacts appears above it to enter the contacts list.
Tip: Press an up or down scroll key (d or g) from the Start
screen to view any entries in your contacts list.
Use four-way scrolling
In features, such as the calendar monthly view, text
messages, and special characters, you can move the
cursor up and down as well as left and right. To move the
cursor:
Left, press f Up, press d
Down, press g
Right, press e
Right
select
Left
select
DRAFT
[ 13 ]
Welcome and quick guide
Shared memory
The following features in this phone may share memory: contacts, text
and multimedia messages, images and ringing tones in gallery, calendar
and to-do notes, Java games and applications, and voice recorder and
commands. Using any such features may reduce the memory available for
any features sharing memory. This is especially true with heavy use of any
of the features (although some of these features may have a certain
amount of memory specially allotted to them in addition to the amount
of memory shared with other features). For example, saving many images,
bookmarks, Java applications, or other features sharing memory may take
all of the shared memory and your phone may display a message that the
memory is full. In this case, delete some of the information or entries
stored in the shared memory features before continuing.
The following functions use shared memory that is dependent on the data
quantity per item and shared memory available at a time in the Nokia
6200:
• Contacts (up to 500 entries)
• SMS messages (up to 150 text messages or 50 picture/concatenated
messages)
• Calendar notes (up to 250 entries)
• To-do list (up to 30 entries)
• Voice tags for commands (up to 5)
• Voice tags for contacts (up to 10)
The following features share a memory pool of 500 kB:
• MMS (up to 5 max size 45 kB MMS messages)
• MIDI ringing tones (31 preset, 20 removable, up to 50 average size 5
kB ringing tones)
• Images (10 preset, up to 6 max size 45 kB images)
• Java applications (3 preset, up to 4 max size 64 kB applications)
DRAFT
[ 14 ]
• GET STARTED WITH THE QUICK GUIDE
Make a call Enter a phone number and press
h
.
Answer a call Press
h
or press Options and select Answer call.
Answer a call with a call
waiting Press
Answer
or
h
.
End a call Press
i
.
Ignore a call Press
Silence
or
i
when your phone rings.
Redial last number Press
h
twice.
Adjust call volume Press up or down on the side volume key.
Use the in-call menu While in a call, press
Options
.
Use 1-touch dialing (if
activated) Press and hold any key 2 through 9.
Save a contact Enter a number, press Options
,
and select Save. Enter a
name and press OK.
Recall a contact Press Contacts
and select Find or press
g
and select
the name.
Check voice mail Press and hold
1
or dial your voice mailbox number.
Write and send a text
message Press Menu 01-1-1. After a pause, write the message.
Press Options, scroll to Send, press Select, enter the
recipient’s number, press OK.
Write and send an e-mail
message Press Menu 01-1-2. After a pause, enter the recipient’s
e-mail address. Press
OK
, enter a subject, and press
OK
.
Write your e-mail message, press Options, scroll to Send
e-mail, and press Select. Enter the e-mail server
number if necessary, and press
OK
. The e-mail
message is sent.
Read a new message Press Show and, if necessary, press Select.
Reply to a message Press Options, select Reply, write the reply, press
Options, select Send, and press OK.
Reply to an e-mail
message Press Options, scroll to Reply, and press Select. Compose
your message and press Options. Scroll to Sending
options and press Select. Scroll to Sending profile and
press Select. Highlight your e-mail profile and press Select.
Press Options, Accept, enter the e-mail address, and
press OK.
Send a business card Recall a contact from the contacts list. Press Details,
press Options, scroll to Send bus. card, scroll to Via text
message, and press
Select
. Enter the recipient’s number
or press Find to retrieve a number from the contacts list.
Press OK. The business card is sent.
DRAFT
[ 15 ]
Welcome and quick guide
• MENU SHORTCUTS
To access a menu or item, press Menu, then enter the numbers associated
with the desired menu or item. For example, press Menu 2-1 (Call log >
Missed calls) to view any missed calls.
1 MESSAGES
Text messages. . . . . . . . . . . . 01-1
Multimedia msgs . . . . . . . . . 01-2
Voice messages. . . . . . . . . . . 01-3
Info messages . . . . . . . . . . . . 01-4
Message settings . . . . . . . . . 01-5
Service commands . . . . . . . . 01-6
2 CALL LOG
Missed calls. . . . . . . . . . . . . . . 2-1
Received calls . . . . . . . . . . . . . 2-2
Dialed numbers. . . . . . . . . . . . 2-3
Delete recent call lists . . . . . . 2-4
Call timers. . . . . . . . . . . . . . . . 2-5
GPRS data counter . . . . . . . . . 2-6
GPRS connection timer . . . . . 2-7
3PROFILES
Normal . . . . . . . . . . . . . . . . . . 3-1
Silent . . . . . . . . . . . . . . . . . . . . 3-2
Meeting. . . . . . . . . . . . . . . . . . 3-3
Outdoor . . . . . . . . . . . . . . . . . . 3-4
Pager . . . . . . . . . . . . . . . . . . . . 3-5
4 SETTINGS
Right selection key settings. . 4-1
Time and date settings. . . . . . 4-2
Call settings . . . . . . . . . . . . . . 4-3
Phone settings . . . . . . . . . . . . 4-4
Display settings . . . . . . . . . . . 4-5
Tone settings. . . . . . . . . . . . . . 4-6
Enhancement settings . . . . . . 4-7
Security settings. . . . . . . . . . . 4-8
Restore factory settings. . . . . 4-9
5ALARM CLOCK
6RADIO
7 GALLERY
8ORGANIZER
Calendar. . . . . . . . . . . . . . . . . . 8-1
To-do list . . . . . . . . . . . . . . . . . 8-2
9GAMES
10 APPLICATIONS
Select application . . . . . . . . . 10-1
App. downloads. . . . . . . . . . . 10-2
Memory . . . . . . . . . . . . . . . . . 10-3
11 EXTRAS
Calculator . . . . . . . . . . . . . . . 11-1
Voice recorder . . . . . . . . . . . . 11-2
Voice commands . . . . . . . . . . 11-3
12 CONNECTIVITY
Infrared . . . . . . . . . . . . . . . . . 12-1
(E)GPRS . . . . . . . . . . . . . . . . . 12-2
Synchronize . . . . . . . . . . . . . . 12-3
13 SERVICES
Home . . . . . . . . . . . . . . . . . . . 13-1
Bookmarks . . . . . . . . . . . . . . . 13-2
Download links . . . . . . . . . . . 13-3
Service inbox . . . . . . . . . . . . . 13-4
Settings . . . . . . . . . . . . . . . . . 13-5
Go to address. . . . . . . . . . . . . 13-6
Clear the cache . . . . . . . . . . . 13-7
DRAFT
[ 16 ]
•GET HELP
Find your phone label
If you need help, Nokia Customer Care is
available for assistance. Before calling,
however, please read “Frequently asked
questions” on page 155.
We also recommend that you write down
the following information and have it
available if you call. The information can
be found on the type label, which is
located on the back of the phone, beneath the battery.
• The International Mobile Equipment Identifier (IMEI)
• We also ask that you write down your zip code.
Contact Nokia
Please have your phone or enhancement with you when contacting any
of the numbers below.
Nokia Customer Care Center, USA Customer Interaction
Center, Canada
Nokia Mobile Phones
7725 Woodland Center Boulevard
Suite #150
Tampa, Florida 33614
Tel: 1-888-NOKIA-2U
(1-888-665-4228)
Fax: 1-813-249-9619
For TTY users: 1-800-24-NOKIA
(1-800-246-6542)
Nokia Products Ltd.
601 Westney Road South
Ajax, Ontario L1S 4N7
Tel: 1-888-22-NOKIA
(1-888-226-6542)
Fax: 1-905-427-1070
Web site: www.nokia.ca
Type label
DRAFT
[ 17 ]
Welcome and quick guide
Contact your service provider
To use the network services available in your phone, you will need to sign
up with a wireless provider. In many cases, the wireless provider will
make available descriptions of their services and instructions for using
features such as:
• Voice mail and voice privacy
• Call waiting, call forwarding, and caller ID
•Messaging
• News and information services
• Selected Internet services
Wireless providers may differ in their support of features. Before you sign
up, make sure a wireless provider supports the features that you need.
DRAFT
[ 18 ]
4 Basic operations
• SWITCH YOUR PHONE ON OR OFF
Warning: Do not switch the phone on when wireless phone use is
prohibited or when it may cause interference or danger.
1To turn your phone on or off, press and hold the
power key (
a
) on top of the phone for at least
4 seconds until the display light comes on.
If the phone displays Insert SIM card even though
the SIM card is properly inserted, or SIM card not
supported, contact your wireless provider.
2Enter the PIN code if necessary and press OK.
3Enter the security code if necessary and press OK.
Note: If the language that appears in your display is not correct,
see “Set the display language” on page 93 for information on
changing your phone’s display language.
• MAKE AND ANSWER CALLS
Note: Your phone must be switched on to use this function. Do
not switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
Use the keypad
1Enter the phone number (including the area code) and press h.
• To delete a character to the left of the cursor, press Clear.
2Press i to end the call or to cancel the call attempt.
Use the contacts list
1At the Start screen, press d or g and scroll to the entry you wish
to view.
DRAFT
[ 19 ]
Basic operations
2Press h to make the call or press Details to view details of the entry.
Tip: To quickly search the list of entries in your contacts list, press
any key in which the letters match the first letter of the name for
which you are searching.
Answer or reject an incoming call
•Press
h to answer the call.
•Press
i to reject the call; the call is diverted to your voice mail if you
have activated call forwarding to your voice mailbox number (see
“Call forwarding” on page 89 for details).
If you press c to Silence the call, only the ringing tone is muted.
You can then either answer or reject the incoming call.
Tip: If the HDB-4 or HDS-3 headset is connected, you can answer
or end a call by pressing the key on the headset.
Answer a call with the keypad locked
To answer a call with Keyguard on, simply press h. During the call, all
features function as normal. When you end or reject the call, the keypad
automatically relocks. For more information on Keyguard, see “Lock the
keypad (Keyguard)” on page 35.
Note: When the phone is locked, calls may be possible to the
emergency number programmed into your phone (for example,
911 or other official emergency number). Key in the emergency
number and press h. The number is displayed only after you have
keyed in its last digit.
Redial the last number
1At the Start screen, press h to display the last 20 numbers dialed.
2Press h to redial the last number, or scroll to the number (or name)
you wish to redial and press h.
DRAFT
[ 20 ]
Adjust the earpiece volume
• To increase the volume of a call, press the
volume up key on the left side of the phone.
• To decrease the volume of a call, press
the volume down key on the left side of
the phone.
When adjusting the volume, a bar chart appears
in the display indicating the volume level.
Make a conference call
Conference calling is a network service that allows up to six persons to
take part in a conference call.
1Make a call to the first participant.
2To call a new participant, press Options, scroll to New call, and
press Select.
3Enter the phone number of the new participant (or press Find to
retrieve a number from your contacts list) and press Call. The first call
is put on hold.
4When the new call picks up, press Options, scroll to Conference, and
press Select to connect the calls.
5To add a new participant to the call, repeat steps 2 through 4.
HAVE A PRIVATE CONVERSATION WITH ONE OF THE PARTICIPANTS:
6Press Options, select Private, and select the desired participant.
Rejoin the conference call as described in step 4.
7To end the conference call, press i.
• OPTIONS DURING A CALL
Many of the options that you can use during a call are network services.
1Press Options during a call to display those in the following table:
V o l u m e
key
DRAFT
[ 21 ]
Basic operations
Option Function
Mute Mute your voice; you can hear the other party but
they can not hear you.
Unmute Return to normal from mute status.
End call End the call.
End all calls End all calls within a conference call.
Phone book Open the phone book menu.
Menu Display the main menus.
Hold Place the current call on hold.
Unhold Remove the current call from hold status.
New call Place a new call; the first call is put on hold.
Conference Call another party and invite them into the call.
Private Have a private conversation with one participant in a
conference call.
Answer Answer another incoming call.
Reject Reject a call; the calling party receives a busy signal.
Loudspeaker Enable the handsfree feature in your phone.
Handset Disable handsfree and return to normal use (earpiece).
Touch tones Send touch tones generated by your phone keypad.
Swap Switch between the active call and the call on hold.
Lock keypad Lock the keypad to prevent accidental key-presses.
Record Voice recorder records an active phone conversation.
DRAFT
[ 22 ]
2Scroll to an option and press Select to activate the option or enter its
submenu.
3Press Swap to switch between the active call and the call on hold,
press Transfer to connect a call on hold, and press i to disconnect
yourself from all calls.
• CHECK THE START SCREEN
The Start screen is “home base” and indicates your phone is in idle mode.
What’s on the Start screen
HOME Your wireless provider’s name may appear here
Signal strength A higher bar indicates a stronger network signal.
Battery level A higher bar indicates more power in the battery.
b Left selection key; press this key when Menu is on the
Start screen to enter the menu list.
c Right selection key; press this key when Contacts is on
the Start screen to enter the contacts list. If you have
modified the right selection key settings in your phone,
Go to appears in the display.
d or g Scroll keys; press either of these keys at the Start
screen to display any entries in your contacts list.
Battery level
Contacts
Signal strength
Menu
DRAFT
[ 23 ]
Basic operations
Understand indicators and icons
Icon Indicates...
You have one or more text or picture messages. See
“Reply to a message or e-mail” on page 63.
You have one or more multimedia messages. See “Read
and reply to a multimedia message” on page 68.
You have one or more voice messages. See “Voice
messages” on page 69.
Your phone’s keypad is locked. See “Lock the keypad
(Keyguard)” on page 35.
Your phone is set to the Silent profile. See “Profiles
(Menu 3)” on page 84.
The alarm clock is set to On. See “Alarm clock (Menu 5)”
on page 103.
An (E)GPRS dial-up connection is established. See
“(E)GPRS dial-up connections” on page 129.
The (E)GPRS connection is not currently active. See
“(E)GPRS dial-up connections” on page 129.
You have an incoming or outgoing call during a (E)GPRS
dial-up connection. (E)GPRS is suspended.
IR connection indicator. See “Infrared” on page 127
Forward all voice calls. All calls are forwarded to
another number. If you have two phone lines, the
indicator for line 1 is and for line 2 .
If you have two phone lines, indicates that you are on
the 2nd phone line. See “Phone settings” on page 93.
DRAFT
[ 24 ]
• BROWSE PHONE MENUS
Your phone features are grouped according to function and are accessed
through the main menus. Each main menu contains submenus and lists
from which you can select or view items and customize phone features.
You can access these menus and submenus by using the scroll method or
by using a shortcut.
Note: Some features may not be available, depending on your
network. For more information, contact your wireless provider.
Use the scroll method
1At the Start screen, press Menu, then use the up and down scroll keys
(d or g) to scroll through the main menus.
As you scroll through the menus, the menu
number appears in the upper right corner of the
display. Below the menu number is a scroll bar
with a tab. The tab moves up or down as you
scroll through the menus, providing a visual
representation of your current position in the
menu structure.
Integrated handsfree is active. See “Speakerphone” on
page 4.
Calls are limited to a closed user group. See “Closed user
groups” on page 38.
The timed profile is selected. See “Profiles (Menu 3)” on
page 84.
or A headset or loopset is connected to the phone.
The phone is connected to a carkit.
Icon Indicates...
Menu
number
Scroll ba
r
with tab
DRAFT
[ 25 ]
Basic operations
When you arrive at a menu:
•Press Select (b) to access submenus.
•Press Back (c) to return to the previous menu.
•Press
i to return to the Start screen from any menu or submenu.
Use a shortcut
You can go directly to almost any menu or submenu, as well as activate
most features by using a shortcut.
•Press Menu, then within 3 seconds, press the key or keys associated
with the menu function you want to view or activate.
For example, to select the Meeting profile, press Menu 3-3-1 from
the Start screen (Menu > 3Profiles > 3Meeting > 1Select). After a
brief pause, the Meeting profile is activated.
A complete list of shortcuts begins on the following page.
Check in-phone help
Many features have brief descriptions (help text) which can be viewed on
the display. To view these descriptions, scroll to a feature and wait for
about 15 seconds. Press More to view all of the description (if necessary),
or press Back to exit.
ACTIVATE OR DEACTIVATE HELP TEXT
1At the Start screen, press Menu 4-4-7 (Settings > Phone settings >
Help text activation).
2After a brief pause, On and Off appear in the display.
3Scroll to On or Off and press Select. A confirmation message appears
in the display indicating your selection.
DRAFT
[ 26 ]
Menu shortcuts
To access a menu or item, press Menu, then enter the numbers associated
with the desired menu or item. For example, press Menu 2-1 (Call log >
Missed calls) to view any missed calls.
1 MESSAGES
TEXT MESSAGES
. . . . . . . . 01-1
Create message. . . . . . . 01-1-1
Inbox . . . . . . . . . . . . . . . 01-1-2
Create e-mail . . . . . . . . 01-1-3
Sent items . . . . . . . . . . . 01-1-4
Archive. . . . . . . . . . . . . . 01-1-5
Templates . . . . . . . . . . . 01-1-6
My folders . . . . . . . . . . . 01-1-7
Distribution lists . . . . . . 01-1-8
Delete messages . . . . . . 01-1-9
MULTIMEDIA MSGS . . . . . . 01-2
Create message. . . . . . . 01-2-1
Inbox . . . . . . . . . . . . . . . 01-2-2
Outbox. . . . . . . . . . . . . . 01-2-3
Sent items . . . . . . . . . . . 01-2-4
Saved items. . . . . . . . . . 01-2-5
Delete messages . . . . . . 01-2-6
VOICE MESSAGES . . . . . . . . 01-3
Listen to voice
messages . . . . . . . . . . . . 01-3-1
Voice mailbox number . 01-3-2
INFO MESSAGES. . . . . . . . . 01-4
Info service . . . . . . . . . . 01-4-1
Topics. . . . . . . . . . . . . . . 01-4-2
Language. . . . . . . . . . . . 01-4-3
Info topics saved on
SIM card . . . . . . . . . . . . 01-4-4
Read (if received only) . 01-4-5
MESSAGE SETTINGS . . . . . . 01-5
Text messages . . . . . . . . 01-5-1
Multimedia msgs. . . . . . 01-5-2
Other settings . . . . . . . . 01-5-3
SERVICE COMMANDS . . . . 01-6
2CALL LOG
MISSED CALLS . . . . . . . . . . . 2-1
RECEIVED CALLS . . . . . . . . . 2-2
DIALED NUMBERS . . . . . . . . 2-3
DELETE RECENT CALL LISTS. 2-4
All . . . . . . . . . . . . . . . . . . . 2-4-1
Missed . . . . . . . . . . . . . . .2-4-2
Received. . . . . . . . . . . . . . 2-4-3
Dialed . . . . . . . . . . . . . . . . 2-4-4
CALL TIMERS . . . . . . . . . . . . 2-5
Duration of last call. . . . . 2-5-1
Duration of received
calls. . . . . . . . . . . . . . . . . . 2-5-2
Duration of dialed
calls. . . . . . . . . . . . . . . . . . 2-5-3
Duration of all calls. . . . . 2-5-4
Clear timers . . . . . . . . . . . 2-5-5
GPRS DATA COUNTER . . . . . 2-6
Data sent in last
session . . . . . . . . . . . . . . . 2-6-1
Data received
in last session. . . . . . . . . . 2-6-2
All sent data. . . . . . . . . . . 2-6-3
All received data . . . . . . .2-6-4
Clear counters . . . . . . . . . 2-6-5
GPRS CONNECTION TIMER. . 2-7
Duration of last session . 2-7-1
Duration of all sessions. .2-7-2
Clear timers . . . . . . . . . . . 2-7-3
DRAFT
[ 27 ]
Basic operations
3PROFILES
NORMAL. . . . . . . . . . . . . . . . 3-1
Select . . . . . . . . . . . . . . . .3-1-1
Customize. . . . . . . . . . . . .3-1-2
Ringing options. . . . .3-1-2-1
Ringing tone . . . . . . .3-1-2-2
Ringing volume. . . . .3-1-2-3
Vibrating alert. . . . . .3-1-2-4
Message alert tone. .3-1-2-5
Keypad tones. . . . . . .3-1-2-6
Warning tones . . . . .3-1-2-7
Alert for. . . . . . . . . . .3-1-2-8
Timed. . . . . . . . . . . . . . . . .3-1-3
SILENT . . . . . . . . . . . . . . . . . 3-2
Select . . . . . . . . . . . . . . . .3-2-1
Customize. . . . . . . . . . . . .3-2-2
Ringing options. . . . .3-2-2-1
Ringing tone . . . . . . .3-2-2-2
Ringing volume. . . . .3-2-2-3
Vibrating alert. . . . . .3-2-2-4
Message alert tone. .3-2-2-5
Keypad tones. . . . . . .3-2-2-6
Warning tones . . . . .3-2-2-7
Alert for. . . . . . . . . . .3-2-2-8
Profile name . . . . . . .3-2-2-9
Timed. . . . . . . . . . . . . . . . .3-2-3
MEETING . . . . . . . . . . . . . . . 3-3
OUTDOOR . . . . . . . . . . . . . . 3-4
PAGER. . . . . . . . . . . . . . . . . . 3-5
Submenus for Meeting, Outdoor,
and Pager are the same as Silent.
4 SETTINGS
RIGHT SELECTION KEY
SETTINGS . . . . . . . . . . . . . . . 4-1
Select options. . . . . . . . . .4-1-1
Organize. . . . . . . . . . . . . . 4-1-2
TIME AND DATE SETTINGS. . 4-2
Clock . . . . . . . . . . . . . . . . 4-2-1
Date . . . . . . . . . . . . . . . . . 4-2-2
Auto-update of
date &
time. . . . . . . . . . . 4-2-3
CALL SETTINGS . . . . . . . . . . 4-3
Call forwarding . . . . . . . . 4-3-1
Anykey answer . . . . . . . . 4-3-2
Automatic redial . . . . . . . 4-3-3
1-touch dialing . . . . . . . . 4-3-4
Call waiting . . . . . . . . . . . 4-3-5
Summary after call . . . . . 4-3-6
Send my caller identity. . 4-3-7
Line for outgoing calls
1
. 4-3-8
PHONE SETTINGS. . . . . . . . . 4-4
Language . . . . . . . . . . . . . 4-4-1
Automatic Keyguard . . . . 4-4-2
Cell info display. . . . . . . . 4-4-3
Welcome note . . . . . . . . . 4-4-4
System selection. . . . . . . 4-4-5
Confirm SIM service
actions . . . . . . . . . . . . . . . 4-4-6
Help text activation . . . . 4-4-7
Start-up tone . . . . . . . . . 4-4-8
Memory status . . . . . . . . 4-4-9
DISPLAY SETTINGS. . . . . . . . 4-5
Wallpaper . . . . . . . . . . . . 4-5-1
Color schemes . . . . . . . . . 4-5-2
Operator logo . . . . . . . . . 4-5-3
Screen saver timeout . . . 4-5-4
Display brightness. . . . . . 4-5-5
TONE SETTINGS . . . . . . . . . . 4-6
Ringing options. . . . . . . . 4-6-1
Ringing tone . . . . . . . . . . 4-6-2
Ringing volume . . . . . . . . 4-6-3
Vibrating alert. . . . . . . . . 4-6-4
Message alert tone . . . . . 4-6-5
Keypad tones. . . . . . . . . . 4-6-6
1 For availability, contact your wireless provider.
DRAFT
[ 28 ]
Warning tones. . . . . . . . . 4-6-7
Alert for . . . . . . . . . . . . . . 4-6-8
ENHANCEMENT SETTINGS . . 4-7
Headset . . . . . . . . . . . . . . 4-7-1
Default profile. . . . . 4-7-1-1
Automatic answer. . 4-7-1-2
Handsfree . . . . . . . . . . . . 4-7-2
Default profile. . . . . 4-7-2-1
Automatic answer. . 4-7-2-2
Lights . . . . . . . . . . . . 4-7-2-3
Loopset . . . . . . . . . . . . . . 4-7-3
Default profile. . . . . 4-7-3-1
Automatic answer. . 4-7-3-2
TTY/TDD . . . . . . . . . . . . . . 4-7-4
Use TTY. . . . . . . . . . . 4-7-4-1
Music stand. . . . . . . . . . . 4-7-5
SECURITY SETTINGS . . . . . . . 4-8
PIN code request. . . . . . . 4-8-1
Call restrictions. . . . . . . . 4-8-2
Fixed dialing . . . . . . . . . . 4-8-3
Closed user group . . . . . . 4-8-4
Security level. . . . . . . . . . 4-8-5
Access codes . . . . . . . . . . 4-8-6
RESTORE FACTORY
SETTINGS . . . . . . . . . . . . . . . 4-9
5ALARM CLOCK
6RADIO
7 GALLERY
8ORGANIZER
CALENDAR . . . . . . . . . . . . . . 8-1
TO-DO LIST . . . . . . . . . . . . . . 8-2
9GAMES
SELECT GAME. . . . . . . . . . . . 9-1
GAME DOWNLOADS . . . . . . . 9-2
MEMORY . . . . . . . . . . . . . . . 9-3
SETTINGS . . . . . . . . . . . . . . . 9-4
10 APPLICATIONS
SELECT
APPLICATION . . . . . . . . . . . 10-1
APP. DOWNLOADS. . . . . . . 10-2
MEMORY . . . . . . . . . . . . . . 10-3
11 EXTRAS
CALCULATOR . . . . . . . . . . . .11-1
VOICE RECORDER. . . . . . . . .11-2
VOICE COMMANDS . . . . . . .11-3
12 CONNECTIVITY
INFRARED . . . . . . . . . . . . . 12-1
GPRS . . . . . . . . . . . . . . . . . 12-2
GPRS connection. . . . . . 12-2-1
GPRS modem settings . . 12-2-2
SYNCHRONIZE . . . . . . . . . . 12-3
13 SERVICES
HOME . . . . . . . . . . . . . . . . 13-1
BOOKMARKS . . . . . . . . . . . 13-2
DOWNLOAD LINKS . . . . . . 13-3
SERVICE INBOX . . . . . . . . . 13-4
SETTINGS . . . . . . . . . . . . . . 13-5
Active service settings. . 13-5-1
Edit active service
settings. . . . . . . . . . . . . . 13-5-2
Appearance settings . . .13-5-3
Cookie settings . . . . . . . 13-5-4
Certificates. . . . . . . . . . .13-5-5
Security module
settings. . . . . . . . . . . . . . 13-5-6
Service inbox settings . . 13-5-7
GO TO ADDRESS . . . . . . . . 13-6
CLEAR THE CACHE . . . . . . . 13-7
DRAFT
[ 29 ]
Basic operations
• SET UP YOUR PHONE
Adjust display brightness
1Press Menu 4-5-5 (Settings > Display settings > Display
brightness).
After a brief pause, a bar chart appears in the display indicating the
current brightness level.
2Press
f
or
e to adjust the brightness to your preference.
Set the clock
Before many functions such as call timers and other features will operate
properly, you need to set the clock.
1At the Start screen, press Menu 4-2-1 (Settings > Time and date
settings > Clock).
After a brief pause, Show clock (or Hide clock), Set the time,
and Time format appear in the display with Show clock (or Hide
clock) highlighted.
2Scroll to Set the time and press Select.
3Enter the time (in hh:mm format) and press OK.
4Scroll to am or pm and press Select. The time is set.
Call and setup your voice mail
See “Voice messages” on page 69 for complete instructions and
information on setting up your voice mail.
1Once you have saved the voice mailbox number, press and hold
1
.
2When you connect and the prerecorded greeting begins, follow the
automated instructions to setup your voice mail.
Listen to your voice messages
Once you have setup voice mail, you can dial the number one of three
ways:
DRAFT
[ 30 ]
• Dial the number using the keypad.
• Press and hold
1
.
•Press Listen if there is a notification message in the display.
When you connect and the prerecorded greeting begins, follow the
automated instructions to listen to your voice messages.
Use the optional headset
The HDB-4 headset kit may be purchased with your phone or separately
as an enhancement.
CONNECT THE HEADSET
1Plug the headset jack into the Pop-
PortTM connector at the bottom end of
your phone.
2Position the headset on your ear as it
appears in the illustration to the right.
With the headset connected, you can
make, answer, and end calls as usual:
• Use the keypad to enter numbers.
•Press
h to place a call.
•Press
i to end a call.
DRAFT
[ 31 ]
Text entry
5 Text entry
You can use two methods for entering text and numbers.
• The standard mode is the only way to enter names into the contacts
list or rename caller groups.
•Predictive text input is a quick and easy method for writing messages
or making calendar notes.
• STANDARD MODE
Enter text (Abc)
• Press a key once to insert the first letter on the key, twice for the
second letter, and so on. If you pause briefly, the last letter in the
display is accepted and your phone awaits the next entry.
•Press
0
to enter a space, thereby accepting a completed word.
•Press
1
to enter a period (.).
•Press
s
to display special characters. See more about special
characters on the following pages.
Enter numbers (123)
To switch to 123 mode from Abc mode, press and hold
p
at any message
entry screen until the icon in the upper left corner of the display switches
from Abc to 123 (or vice versa).
CLEAR THE SCREEN
•Press Clear to backspace the cursor and delete a character.
• Press and hold Clear to backspace continuously and delete multiple
characters.
DRAFT
[ 32 ]
Enter punctuation and special characters
While at any text entry screen, press
s
to display special characters. Press
and hold
s
if predictive text is on. The following characters are available:
Use four-way scrolling
Navigate special characters using the scroll
keys much as you would a joystick. Once a
character is highlighted, press Insert to
insert the character into your message.
• PREDICTIVE TEXT INPUT
Predictive text input allows you to quickly write messages using your
keypad and the built-in dictionary. You can use predictive text to write
messages, create calendar notes, make to-do lists, and more.
Activate/deactivate predictive text
• At a text entry screen, press and hold Options. T9 prediction off or
T9 prediction on appears (depending on the prior mode).
OR
1If predictive text is off, press Options, scroll to Predictive text, and
press Select.
2Scroll to the language of your choice and press Select.
Predictive text is turned on. The predictive text icon ( ) appears in
the upper left corner of the display.
.,‘?!“-()@/
:_ ; + & %*=<>£
$¥¤[ ] {}\ ~^
¡¿ § # l
Up
Down
Left Right
DRAFT
[ 33 ]
Text entry
Note: The Language setting in predictive text affects the time and
date formats of the clock, alarm clock, and calendar.
Write with predictive text
For example, to write Nokia with the English dictionary selected, press
each of the following keys only once: (with predictive text on). The
illustration below simulates your display each time a key is pressed.
6
6
5
4
2
PREDICTIVE TEXT TIPS
•Press
0
to enter a space and begin writing the next word.
• If a displayed word is not correct, press
s
to see other matches.
•If ? appears after a word, press Spell to add the word to the dictionary.
•Press
1
to insert a period into your message.
• Press and hold Options to turn predictive text on and off.
• Press and hold
s
to display special characters. See “Enter
punctuation and special characters” and “Use four-way scrolling” on
the previous page for the easiest way to enter special characters.
Note: Press
p
to switch predictive text on and off or to cycle
through the available modes. As you press
p
, the following icons
(not descriptions) appear in the display:
Uppercase text
Predictive text is Off
Sentence case text
Predictive text is On
Lowercase text
Predictive text is Off
Lowercase text
Predictive text is On
DRAFT
[ 34 ]
Add new words to the dictionary
If you encounter a word that predictive text does not recognize, a
question mark (?) follows the word and Spell appears in the lower left of
the display.
•Press Spell, enter your new word using the keypad, and press Save.
The word is added to the dictionary as well as to the message you are
writing.
NOTES ABOUT ADDING WORDS
• New words that you accept by pressing Select,
0
, or deleting the
space between two words are saved to the dictionary.
• Depending on the language and the length of the words, you may be
able to add hundreds of words to the dictionary.
• When the dictionary is full, the most recent addition replaces the first.
DRAFT
[ 35 ]
Manage phone security
6 Manage phone security
Lock the keypad (Keyguard)
Remember to lock your phone keypad to prevent accidental calls. If the
keypad is locked, it unlocks when you receive a call. After the call, the lock
automatically reactivates.
Important: When the phone is locked, calls may be possible to
emergency numbers (for example, 911 or other official emergency
number). Key in the emergency number and press h. The number
appears in the display after you have keyed in the last digit.
• To lock the keypad, press Menu
s
.
Unlock the keypad
• At the Start screen, press Unlock
s
.
• SECURITY LEVELS
The security level determines your access to features when a “non-owner”
SIM card is used. A “non-owner” SIM card is one (other than the original)
that is inserted after you power off the phone. There are three security
levels:
Off Owner and non-owner cards are treated the same.
Memory Non-owner cards can access SIM memory. Any changes to
the memory setting requires the security code.
The owner card has access to all features, but the security
code is required to change a memory setting.
Phone The security code is required upon power-up.
DRAFT
[ 36 ]
Set your security level
1At the Start screen, press Menu 4-8-5 (Settings > Security settings
> Security level).
2After a brief pause, you are prompted to enter the security code.
The default code is 12345. Enter the security code and press OK.
3Scroll to Off, Memory, or Phone and press Select. A message appears
in the display confirming your selection
• FIXED DIALING
Once you setup and activate a fixed dialing list, your phone can make
calls only to those numbers that you have defined in the fixed dialing list.
Fixed dialing is a network feature and must be supported by your wireless
provider.
Note: When fixed dialing is set on, calls may be possible to certain
emergency numbers in some networks (for example, 911 or other
official emergency number).
Set up and activate a fixed dialing list
1At the Start screen, press Menu 4-8-3 (Settings > Security Settings
> Fixed dialing). After a brief pause, the options in the following
table appear in the display.
Note: If you activate fixed dialing and the number list is empty, a
“Call not allowed” message is displayed if you attempt outgoing
calls, except for emergency numbers such as 911.
On Activate fixed dialing (see note above).
Off Deactivate fixed dialing.
Number list View the numbers in your fixed dialing list.
DRAFT
[ 37 ]
Manage phone security
2Scroll to Number list and press Select. Fixed dialing not active and
then Fixed dialing list empty appear in the display.
3You are prompted to enter the PIN2 code. Enter the PIN2 code and
press OK.
4Enter the fixed dialing number, or press Find to retrieve a number
from your contacts list, and press OK.
5Enter a name for the number and press OK.
A confirmation note appears in the display and you are returned to
the fixed dialing number list.
6Press Back, scroll to On, and press Select to activate fixed dialing.
View or edit the fixed dialing list
1At the Start screen, press Menu 4-8-3 (Settings > Security Settings
> Fixed dialing).
2Scroll to Number list and press Select.
3You are prompted to enter the PIN2 code. Enter the PIN2 code and
press OK.
4Any numbers which you have assigned to fixed dialing appear in
the display.
5Scroll to a number and press Options.
6The options in the following table appear in the display.
View number View the number for an entry
Add Add a number to your fixed dialing list
Edit Edit the highlighted entry
Delete Delete the highlighted entry
Delete all Delete all entries in your fixed dialing list
DRAFT
[ 38 ]
• Use the scroll keys to highlight an option.
•Press Select to activate or enter the submenu of an option.
Notes about fixed dialing
• If a SIM card with fixed dialing that is activated is inserted into a
phone that does not support fixed dialing, the SIM card is rejected.
• If you try to add a name (without a number) to the fixed dialing list,
you will receive an error message.
• If you try to browse the fixed dialing list, but have not stored any
numbers, Fixed dialing list empty appears in the display.
• You cannot access SIM memory manually (view or copy numbers on
the SIM card) while fixed dialing is active.
Closed user groups
A closed user group is a network service that specifies the group of people
whom you can call and who can call you. For more information contact
your network operator or service provider.
Note: When calls are limited to closed user groups, calls may be
possible to certain emergency numbers in some networks (for
example, 911 or other official emergency number).
• ACCESS CODES
Use access codes to change your security code, PIN code, and PIN2 code.
Note: Avoid using codes similar to emergency numbers such as
911 to prevent accidental dialing of the emergency number.
Security code
The security code controls access to features such as the security level and
is supplied with the phone. The preset code is 12345.
Note: If you enter the wrong security code five times in
succession, you will not be able to enter a code for five minutes,
even if you power off the phone between incorrect entries.
DRAFT
[ 39 ]
Manage phone security
CHANGE YOUR SECURITY CODE
Once you change the security code from its preset of 12345, keep the new
code secret, and in a safe place separate from your phone.
1Press Menu 4-7-6-1 (Settings > Security settings > Access codes
> Change security code).
After a brief pause, you are prompted to enter the current security
code (default is 12345).
2Enter the current security code and press OK. You are prompted to
enter the new security code.
Enter the new security code (up to 10 characters) and press OK.
You are asked to re-enter the new security code for verification.
3Enter the new security code again and press OK.
A message appears in the display confirming your security code has
been changed.
PIN code
The PIN code protects the SIM card from unauthorized access. The PIN code
can be 4- 8 digits in length. After three successive incorrect entries the
PIN code is blocked and you will be asked to enter the personal unblocking
key (PUK) code.
Note: The PIN code must be obtained from your wireless provider.
The PIN code is typically provided with your SIM card.
PIN CODE REQUEST
Enable your phone to request the PIN code upon power-up. This provides
extra security in case your phone is lost or stolen.
1Press Menu 4-8-1 (Settings > Security settings > PIN code
request).
2After a brief pause, you are prompted to enter the current PIN code.
Enter the PIN code and press OK.
3Scroll to On and press OK. A message appears in the display
confirming your selection.
DRAFT
[ 40 ]
CHANGE YOUR PIN CODE
Before you can change your PIN code, you will need to enable PIN code
request. See “PIN code request” immediately preceding this section.
1Press Menu 4-7-6-2 (Settings > Security settings > Access codes
> Change PIN code).
2After a brief pause, you are prompted to enter the current PIN code.
Enter the PIN code and press OK.
3You are prompted to enter the new PIN code. Enter the new PIN code
and press OK.
4You are prompted to re-enter the new PIN code for verification.
Enter the new PIN code again and press OK.
A message appears in the display confirming your PIN code has
been changed.
PIN2 Code
The PIN2 code is required for features such as Fixed dialing. If you enter
an incorrect PIN2 code three times in succession, the PIN2 code is blocked
and you will have to enter the PUK2 code.
Note: The original PIN2 code must be obtained from your
wireless provider.
CHANGE YOUR PIN2 CODE
1Press Menu 4-7-6-3 (Settings > Security settings > Access codes
> Change PIN2 code). You are prompted to enter the current PIN2
code.
2Enter the current PIN2 code and press OK. You are prompted to enter
the new PIN2 code.
3Enter the new PIN2 code and press OK. You are asked to verify the
new PIN2 code by entering it again.
4Enter the new PIN2 code again and press OK. A message appears in
the display confirming you have changed the PIN2 code.
DRAFT
[ 41 ]
Manage phone security
Personal unblocking key (PUK) codes
PUK and PUK2 codes are used to restore blocked PIN and PIN2 codes.
Both PUK and PUK2 codes are eight characters in length and cannot
be changed. PUK and PUK2 codes must be obtained from your
wireless provider.
Important: If you enter an incorrect PUK or PUK2 code 10 times
in succession, the message SIM rejected appears in the display and
the SIM card can no longer be used. You must contact your wireless
provider for a new SIM card.
DRAFT
[ 42 ]
7Contacts
Your contacts list can save up to 500 names, with multiple numbers and
text notes for each name. The amount of numbers and text entries that
you can save may vary, depending on their length and the total number
of entries in the contacts list.
Note: This feature uses shared memory. Please see “Shared
memory” on page 13 for more information.
• VIEW THE CONTACTS LIST
1At the Start screen, press the right selection key (c) under
Contacts. The menu items in the left column of the following table
appear in the display
Note: If you have changed the function of the right selection key
on your phone, Go to appears in the Start screen. See “Right
selection key settings” on page 87 for details.
Menu item Function
Find Find a name or select from a list.
Add contact Add an entry to your contacts list.
Edit name Edit an existing contact.
Delete Delete a contact and its associated numbers.
Copy Copy entries from phone memory to SIM and vice versa.
Add number Add a number to an existing contact.
Settings Set memory in use (phone or SIM), change your
contacts list view, and check the memory status of your
phone and SIM card.
DRAFT
[ 43 ]
Contacts
2Scroll to an item. Press Select to activate the feature or enter
its submenu.
• SAVE CONTACTS
You can save contacts to phone memory or to SIM memory.
Quickly save a contact (name and number)
1At the Start screen, enter the phone number you wish to save.
2Press Options, ensure Save is highlighted, and press Select.
3Enter a name for the number and press OK. A confirmation message
appears in the display indicating your entry has been saved.
Quickly save a number only
You can save a phone number as a stand-alone entry in your contacts list.
1At the Start screen, enter the number you wish to save.
2Press and hold Options. A save confirmation is displayed.
1-touch
dialing
Displays the list of 1-touch dialing numbers saved
to memory.
Voice tags “Tag” is a contacts listing with a voice signal so you can
call by speaking the signal into your phone.
Info numbers Contact your wireless provider to obtain information.
Service
numbers
Contact your wireless provider to obtain service.
Own numbers Displays the numbers (line 1, line 2, data) in use by your
SIM card.
Caller groups View and edit the properties (such as the ring tone) for
any of the caller groups.
Menu item Function
DRAFT
[ 44 ]
Save an entry using the contacts list
1At the Start screen, press Contacts, scroll to Add contact, and press
Select.
2Enter a name using the keypad and press OK.
3Enter a number and press OK.
4Press Done to return to the Start screen.
Save addresses and notes
To save an e-mail address, you will need to add it to an existing contact.
1Find the contact (name) in your contacts list to which you would like
to add an address or note.
2With the entry highlighted, press Details.
3Press Options, scroll to Add detail, and press Select.
4Scroll to the address or note of your choice and press Select.
5Enter the text for the note or address and press OK.
Select your contacts view and memory
1Press Contacts, scroll to Settings, and press Select.
2Scroll to any of the options in the following table. Press Select to
enter the submenu.
Option Function
Memory
in use
Select the memory you wish to use. Options are Phone, SIM
card, or Phone and SIM combined. With Phone and SIM
selected, names and numbers are saved to phone memory
but entries saved to both memories appear in the display.
Contacts
view
Select the Name list, Name and number, or Name only view
DRAFT
[ 45 ]
Contacts
Note: Address and notes information cannot be saved into the SIM
card memory.
Save multiple numbers and text items per contact
You can save different types of phone numbers and short text items per
contact to the contacts list. The first number you save for any entry is
automatically set as the default, or primary number.
1At the Start screen, press d or g and scroll to the entry to which
you wish to add a number or text item.
2Press Details, then press Options.
3Scroll to Add number or Add detail and press Select.
4Scroll to one of the following types and press Select:
5Enter the number or text for the type you have selected and press OK.
• To change the type, select Change type in the options list.
CHANGE THE DEFAULT (PRIMARY) NUMBER
1At the Start screen, press d or g, scroll to the entry you wish to
change, and press Details.
2Scroll to the number you wish to set as default and press Options.
3Scroll to As primary number and press Select.
Memory
status
View the amount of phone or SIM memory used as well as
the amount of phone or SIM memory available
General Mobile Home
Work
Fax
E-mail
address
Web
address
Street
address
Note
Option Function
DRAFT
[ 46 ]
Search for a name in the contacts list
1At the Start screen, press d or g to display the contents of your
contacts list.
2Press the key which corresponds to the first letter of the name for
which you are performing a search.
3Press d or g to scroll up and down through contacts in the list.
Press f or e to move the cursor left or right in the search window at
the bottom of the display, if necessary.
4Press Details to view the details of the selected contact.
Edit a name, number, or text item
1Search for the entry as described in the previous section and
press Details.
2Scroll to the name, number, or text item you wish to edit and
press Options.
3Scroll to Edit name, Edit number, or Edit detail and press Select.
4Edit the name, number, or detail to your preference and press OK.
Delete contacts
1At the Start screen, press Contacts, scroll to Delete, and press Select.
2To delete individual names and numbers, scroll to One by one and
press Select.
3Scroll to the entry you wish to delete, press Delete, and press OK to
confirm the deletion.
4To delete the entire contents of your contacts list, scroll to Delete all,
then scroll to the contacts list you wish to delete (Phone or SIM card).
5Press Delete, then press OK to confirm. You are asked to enter the
security code.
6Enter the security code and press OK.
DRAFT
[ 47 ]
Contacts
• COPY CONTACT LIST ENTRIES
1At the Start screen, press Contacts, scroll to Copy, and press Select.
2Scroll to From phone to SIM card or From SIM card to phone and
press Select.
The following options appear in the display:
3Scroll to the copy method of your choice and press Select.
a) If you selected One by one, go to step 4.
b) If you selected All or Primary numbers., go to step 6.
4Scroll to the entry you wish to copy and press Copy.
5Scroll to Keep original or Move original and press Select. The entry
is copied and you are returned to the list of contact list entries.
6If you selected All or Primary numbers in step 3, scroll to Keep
original or Move original and press Select.
7Press OK to confirm your choice. All entries are copied to the selected
destination. Press Back to return to the list of contact list entries, or
press i to exit and return to the Start screen.
Caution: Select Keep original if you are unsure of which copy
method to use. This ensures original entries are merely copied to
the new location. Move original deletes files after copying.
Send and receive business cards
You can send and receive an entry in your contacts list via IR or text
message, if supported by your wireless provider.
One by one Select and copy entries one by one.
All Copies all entries from the SIM card or phone.
*Primary numbers Copies only primary numbers. This appears only if
you select From phone to SIM.
DRAFT
[ 48 ]
RECEIVE A BUSINESS CARD USING IR
1Press Menu 12-1 (Connectivity > Infrared) to ensure IR is activated.
When you receive the business card, your phone beeps and a message
appears in the display.
2Select Save to save the business card in the phone memory, or press
Exit (or OK) to discard the business card.
SEND A BUSINESS CARD
You can send a business card through IR or as an text message to a
compatible phone or other handheld device.
1Highlight an entry from the contacts list that you wish to send and
press Details.
2Press Options, scroll to Send bus. card, and press Select.
• To send the business card through IR, make sure the receiving
device is set up to receive data through its IR port and select Via
infrared.
• To send the business card as a message, select Via text message.
3If you selected Via infrared (and the entry has multiple subentries),
scroll to Primary number or All details and press Select. Your
business card is sent.
4If you selected Via text message (and the entry has multiple sub-
entries), scroll to Primary number or All details and press Select.
5Enter the number for your recipient or press Find to retrieve a number
from your contacts list.
6Press OK and the business card is sent.
•1-TOUCH DIALING
You can assign any entry in your contacts list with keys
2
through
9
,
and then dial those entries by pressing and holding the assigned key.
DRAFT
[ 49 ]
Contacts
Assign a key to 1-touch dialing
1At the Start screen, press Contacts, scroll to 1-touch dialing, and
press Select.
2Scroll to any empty slot and press Assign.
3Enter the number (including the area code) and press OK, or press
Find to retrieve a number from your contacts list.
4Enter a name for the number and press OK.
If 1-touch dialing is off, the phone displays a prompt asking if you
would like to turn 1-touch dialing on. Press Yes to activate 1-touch
dialing.
The entry appears in the slot you have assigned.
Make a call with 1-touch dialing
• Press and hold the key to which an entry has been assigned. Your
phone dials the entry assigned to the key.
OR
• Press the key to which an entry has been assigned and then press h.
Your phone dials the entry assigned to the key.
CHANGE 1-TOUCH DIALING NUMBERS
1At the Start screen, press Contacts, scroll to 1-touch dialing, and
press Select.
2Scroll to the 1-touch dialing entry you wish to change and
press Options.
3Scroll to Change and press Select.
4Enter the new number, or press Find to retrieve a number from your
contacts list, and press OK.
5Enter a name for the entry and press OK.
DRAFT
[ 50 ]
DELETE 1-TOUCH DIALING NUMBERS
1At the Start screen, press Contacts, scroll to 1-touch dialing, and
press Select.
2Scroll to the 1-touch dialing location you wish to delete and
press Options.
3Scroll to Delete and press Select. You are asked to confirm the
deletion.
4Press OK to delete the key assignment.
• VOICE DIALING
You can dial up to 10 stored numbers in your contacts list using the voice
dialing feature. Before you can place a call using voice dialing, you must
first assign a voice ‘tag’ to the number.
Note: Your phone must be on to use this function. Do not switch
on the phone when wireless phone use is prohibited or when it
may cause interference or danger.
Assigning a voice tag to a phone number
You can create a voice tag (such as a person’s name) for up to 10 contact
list entries, then dial the number using the voice dialing feature. See “Dial
a number using voice dialing” on page 51 for more information. It is easier
for the phone to differentiate between long, unique voice tags. For
example, you might want to record a person’s first and last names rather
than only the first name.
ASSIGNING A VOICE TAG TO AN ENTRY
1At the Start screen, scroll to the name you want to give a voice tag.
2Press Details, then Options, and scroll to Add voice tag.
3Press Select. The phone displays Press Start, then speak after tone.
4Press Start.
You hear several beeps, and Please speak now appears.
5Speak clearly into the microphone.
DRAFT
[ 51 ]
Contacts
Note: Do not press Quit unless you want to cancel the recording.
The phone automatically stops recording and then saves and replays the
voice tag. If recording is not successful, your phone displays Voice system
error. Press Options, scroll to Add voice tag, and repeat Steps 3-5.
DIAL A NUMBER USING VOICE DIALING
Before using voice dialing, note that:
• Voice tags are not language dependent. They are dependent on the
speaker’s voice.
• Voice tags are sensitive to background noise. For best results, record
them and make calls in a quiet environment.
• When recording a voice tag or making a call by saying a voice tag,
hold the phone in the normal position near to your ear.
• Very short names are not accepted. Use long names and avoid similar
names for different numbers.
• Voice tags must be shorter than 2 seconds. Record them and make
calls in a quiet environment.
Note: You must say the name exactly as you said it when you
recorded it. This may be difficult in, for example a noisy
environment or during an emergency, so you should not rely solely
upon voice dialing in all circumstances.
1Press and hold the Contacts selection key.
When you hear several beeps and Please speak now appears, release
the button.
Note: If you have the optional headset attached, press and hold
the headset button. When the phone beeps and Please speak now
appears, release the button.
2Pronounce the voice tag clearly into the microphone. When the phone
finds the voice tag, Found appears, and the phone automatically dials
the number.
If the phone does not locate a number, No match found appears.
DRAFT
[ 52 ]
If you are using the headset and the phone does not locate the number,
you will hear an error tone and No match found appears. To start voice
dialing again, press and hold the headset button immediately after
the error tone.
WORK WITH AN EXISTING VOICE TAG
After you have associated a voice tag to a command, you can choose one
of the following options:
Play back a voice tag
1Press Contacts and scroll to Voice tags.
2Press Select, then scroll to the name with the voice tag you want
to hear.
3Press Options, scroll to Playback, and press Select.
Change a voice tag
1Press Contacts and scroll to Voice tags.
2Press Select, then scroll to the name with the voice tag you want
to change.
3Press Options, scroll to Change, and press Select.
4The phone displays Press Start, then speak after tone.
5Press Start.
6The phone repeats your voice tag, and Voice tag saved appears.
Delete a voice tag
1Press Contacts and scroll to Voice tags.
2Press Select, then scroll to the name with the voice tag you want
to erase.
3Press Options, scroll to Delete, and press Select. Delete voice tag?
appears.
4Press OK to erase the voice tag.
DRAFT
[ 53 ]
Contacts
• VIEW INFO, SERVICE, AND OWN NUMBERS
Your wireless provider may save the operating number of your phone, as
well as various information and service numbers, to your SIM card.
Note: This feature may not be supported by your SIM card. If so,
contact your wireless provider for more information.
1Press Contacts at the Start screen, scroll to one of the number types
in the following table, and press Select.
2To view details of any of the number types in the previous table, press
Details when the number type appears in the display.
Caller groups
You can add contact list entries to any of five caller groups, then assign a
unique ringing tone or graphic to that group. This enables you to identify
callers from the group by their unique ringing tone or graphic. A caller
group can be as small as one person or as large as your entire contacts
list. Caller groups can be renamed to suit your preference.
CALLER GROUP OPTIONS
1At the Start screen, press Contacts, scroll to Caller groups, and press
Select. The following caller groups are available.:
2Use the scroll keys (d or g) to highlight a group. Press Select to
display the following caller group options:
Number type Used this number to...
Info numbers Contact your wireless provider to obtain information
Service numbers Contact your wireless provider to obtain service
Own numbers Display the operating number, or numbers which
have been assigned to your phone by your wireless
provider
Family VIP Friends Business Other
DRAFT
[ 54 ]
Set up a caller group
1At the Start screen, press d or g to display a list of entries in your
contacts list.
Tip: Perform a “quick find” when contact list entries are displayed
by entering the first letter of a name. appears at the bottom
of the display to indicate that you are performing a search.
2Scroll to a contact you would like to add to a caller group and press
Details.
3Press Options, scroll to Caller groups, and press Select.
4Scroll to the caller group to which you would like to add the contact
and press Select. A confirmation message appears in the display.
Rename group Rename the group to your preference.
Group ringing tone Set the ringing tone for the group.
Group logo Turn the graphic for the caller group on or off.
Group members Add or remove members from the caller group.
DRAFT
[ 55 ]
Menu functions
8 Menu functions
Messages (Menu 1)
If you have subscribed to a message service, you can
send and receive messages to compatible phones
that are also subscribed to a message service.
You can also send and receive picture messages,
multimedia messages, and e-mail if supported by
your network. Composed messages can be up to 600 characters in length,
and multimedia messages can be up to 1000 characters in length.
Before you can send and receive messages
You will need the following to send and receive messages:
• A messaging service through your wireless provider
• A message center number, which must be saved to your phone (if your
wireless provider has not done so already)
Message icons
Icons that precede the title of a message indicate the following:
The message has not been read.
The message has been read.
A message (which you have composed) has not been sent.
iThe message is a delivery report.
The message is a MMS (multimedia message).
DRAFT
[ 56 ]
Choose your message type
You can choose the type of message sent by your phone. Types include
text, fax, e-mail, and page.
Note: The default message type is Text.
Note: This function can be used only if it is supported by your
wireless provider.
1At the Start screen, press Menu 01-5 (Messages > Message
settings).
2After a brief pause, Text messages appears highlighted. Press Select.
3Sending profile is highlighted. Press Select.
4Default profile is highlighted. Press Select.
5Scroll to Messages sent as and press Select.
6Scroll to the message type of your choice and press Select. A message
appears in the display confirming your selection.
Save your message center number
Messages sent by your phone are routed through your wireless provider’s
message center. Normally, this number is saved to your phone by your
wireless provider. To save the number manually, do the following:
1At the Start screen, press Menu 01-5 (Messages > Message
settings).
2Text messages is highlighted. Press Select.
3Sending profile is highlighted. Press Select.
4Default profile is highlighted. Press Select.
5Scroll to Message center number and press Select.
6If the box in the display is empty, enter the number given by your
wireless provider and press OK.
OR
DRAFT
[ 57 ]
Menu functions
If the box is in the display is full, edit the number only if you are
sure the number is incorrect and you would like to change the
number, and press OK.
A message appears in the display that confirms your number is saved.
• TIPS FOR COMPOSING A MESSAGE
Predictive text input
Predictive text allows you to write messages using a built-in dictionary. It
is much faster than using the traditional “multi-tap” method. For each
letter of the word that you are spelling, you only need to press the
corresponding key on your keypad once. You can use predictive text to
write a message, create a calendar note, make a to-do list, and more. See
“Text entry” on page 31 for more information on writing with predictive
text and special characters.
• TEXT MESSAGES
Important:When sending SMS messages, your phone may display
the words Message sent. This is an indication that the message
has been sent to the SMS network and is not an indication that the
message has been received at the intended destination. For more
details about SMS services, check with your service provider.
Write and send a text message
Note: This feature uses shared memory. Please see “Shared
memory” on page 13 for more information.
1At the Start screen, press Menu 01-1-1 (Messages > Text messages
> Create message).
After a brief pause, the message entry screen appears in the display.
2Compose a message using the keypad and press Options.
3Send is highlighted. Press Select.
4Enter the recipient’s phone number, or press Find to retrieve a number
from your contacts list, and press OK. Your message is sent.
DRAFT
[ 58 ]
Read a message
When you receive a message, your phone beeps and 1 message received
appears in the display as well as the unopened letter icon ( ).
1Press Show to read the message, or Exit to move it to your inbox.
Note: When you have unopened messages in your inbox, is
shown in the upper left corner of the Start screen as a reminder.
2Use the scroll keys (d or g) to view the whole message if
necessary.
Tip: Keep scrolling to view other information, such as the sender
number and time the message was sent.
3Press Exit to return to the Start screen, or press Options for other
choices, such as Reply or Forward.
READ A LINKED MESSAGE
Your phone can receive one long message (up to 600 characters) in
sequences. You can start reading the first part before the phone has
received the entire message.
While viewing the message, you may see Some text missing on the
display. This is normal, and the message content will be updated as soon
as the missing sequence arrives.
If the memory is full, you may have to delete a message from your inbox
or outbox before your phone can update the missing text.
Reply to a message
1While viewing a message, press Options, scroll to Reply, and
press Select.
2Scroll to a format on the Start reply with menu and press Select.
3Compose your reply using the keypad, then press Options, scroll to
Send, and press Select.
4The number of the original sender appears in the display. Press OK and
your reply is sent.
DRAFT
[ 59 ]
Menu functions
Forward a message
1While viewing a message, press Options.
2Scroll to Forward and press Select.
3Choose to forward As text message or As e-mail and press Select.
If you chose to forward As text message, Send is highlighted. Press
Options and select Send. The text message is forwarded.
If you chose to forward As e-mail, enter the recipient’s phone number
or e-mail address, or press Find to retrieve the data from your
contacts list then press OK. The e-mail is forwarded.
• PICTURE MESSAGES
Note: This feature uses shared memory. Please see “Shared
memory” on page 13 for more information.
Note: This function can be used only if it is supported by your
network operator or service provider. Only phones that offer
picture message features can receive and display picture
messages.
Your phone comes with 10 preloaded pictures. You can, however,
overwrite any of the 10 pictures that come with your phone. Pictures can
be attached to a message and sent by way of text message to compatible
phones. Picture messages behave the same as text messages, but pictures
take up more space than text. Pictures are stored in the “Templates” folder
under Messages > Text messages > Templates.
Note: You cannot send a picture message through e-mail.
Download pictures
Your phone can download pictures or receive them from compatible
phones to use in messages. You can also create pictures and send them to
your phone or other compatible phones using Nokia PC Suite.
DRAFT
[ 60 ]
Note: This function can be used only if it is supported by your
wireless provider. Only phones that offer picture message features
can receive and display picture messages.
Receive a picture message
When you receive a picture message, your phone beeps and Message
received appears in the display as well the message icon ( ).
1Press Show to view the picture message, or press Exit to move it to
your inbox.
2If you have more than one picture message, scroll to the message of
your choice and press Select to view the message.
Note: When you have unopened picture messages in your
inbox, is shown in the upper left corner of the Start screen
as a reminder.
3Use the scroll keys to view the whole picture if necessary.
Tip: Keep scrolling to view other information, such as the sender
number and time the message was sent.
4Once you are finished, press Back to move the picture message to the
Inbox, or press Options for other choices, such as Reply or Forward.
TO SAVE THE PICTURE
If you want to save the picture to your Templates folder for later use:
1Press Options, scroll to Save picture, and press Select. You can then
enter a title for the picture and press OK.
Note: If your templates folder is full of pictures, scroll to the
picture you want to replace and press Select.
Compose and send a picture message
One picture message is equivalent in size to at least three text messages.
When you insert a picture into a message, you will have enough remaining
space for about 121 characters in the message. If you try to insert a
picture into a message that is almost full of text, a beep sounds and you
are prompted to delete some text before proceeding.
DRAFT
[ 61 ]
Menu functions
1At the Start screen, press Menu 01-1-1 (Messages > Text messages
> Create message).
After a brief pause, the message edit screen appears in the display.
2Write a message using the keypad (or enter nothing if you choose to
just send a picture), and press Options.
Tip: Insert pictures before adding text. You can then check
remaining space for text in the upper right corner of the display.
3Scroll to Insert picture and press Select. A list of pictures appears in
the display.
4Scroll to a picture and press View.
5Press Insert to insert the picture into your message.
OR
Press Back, scroll to another picture, and press View again.
6To send the picture message, press Options, scroll to Send, and
press Select.
7Enter the phone number for your recipient or press Find to retrieve a
number from your contacts list and press OK. The message is sent.
PREVIEW, CHANGE, OR DELETE A PICTURE MESSAGE
1After a picture has been inserted into your message, press Options at
the message edit screen.
2Scroll to one of the following options and press Select.
a) Preview—Previews the inserted message before sending.
Press Back to return to the list of options.
b) Change picture—Takes you back to the picture list.
Scroll to highlight a new picture, press View, then press Insert to
replace the previous picture in your message.
c) Delete picture—Press OK to delete the picture from your
message, or press Back to return to the list of options.
DRAFT
[ 62 ]
•E-MAIL
You can send e-mail up to 160 characters in length to anyone with an
e-mail address.
Important: The e-mail address is included in the total character
count for an e-mail message, which is 160 characters.
Note: You cannot insert pictures into e-mail.
Note: Wireless providers may customize the text message settings
interface. For more details about text message services, please
contact your wireless provider.
Write and send an e-mail message
Note: See “Tips for composing a message” on page 57 for ways to
write messages faster.
1At the Start screen, press Menu 01-1-3 (Messages > Text messages
> Create e-mail).
After a brief pause, you are prompted to enter the e-mail address.
2Enter the e-mail address or press Find to retrieve an e-mail address
from your contacts list, and press OK.
3Enter a subject for the e-mail and press OK.
4Compose your e-mail using the keypad and press Options.
Tip: Be sure and leave enough space in the total character count
(160) for the e-mail address.
5Scroll to Send e-mail, if necessary, and press Select. An E-mail server
number box appears in the display.
6If the box in the display is empty, enter the e-mail server number and
press OK.
OR
DRAFT
[ 63 ]
Menu functions
If the box is in the display is full, edit the number only if you are
sure the number is incorrect and you would like to change the
number, then press OK.
A message appears in the display confirming your e-mail is sent.
Reply to a message or e-mail
When you have received a text message or e-mail, , the number of
new messages and ___ Message(s) received appears in the display.
Note: The blinking indicates that the message memory is
full. Before you can receive new messages, delete some of your old
messages. See “Delete messages” on page 75 for more
information.
•Press Show to view the message now or Exit to view it later.
READING THE MESSAGE LATER:
1Press Menu, and select Messages, Text messages, and Inbox.
2If more than one message is received, select the message you want to
read and press Select.
An unread text message is indicated by in front of the message,
and an unviewed picture message by .
• MULTIMEDIA MESSAGES
Note: This feature uses shared memory. Please see “Shared
memory” on page 13 for more information.
A multimedia message (MMS) can contain text, images, and MIDI tones.
Your phone has a multimedia message viewer for playing messages and a
multimedia inbox for storing saved messages. Once you save the
multimedia message, the image can be used as a screen saver or the
sound as a ringing tone.
DRAFT
[ 64 ]
Your phone supports multimedia messages of up to 45 kB. If the
maximum size is exceeded, the phone may not be able to receive the
message. Depending upon your network, you may receive a message that
includes an Internet address where you can go to view the multimedia
message.
Note: This function can be used only if it is supported by
your wireless provider. Only compatible devices can receive and
display multimedia messages.
Pictures included in multimedia messages are scaled down to fit the size
of your display.
Note: The default setting of the multimedia message service is on,
and your wireless provider may charge for messages received.
Multimedia messaging supports the following formats:
• Picture: JPEG, GIF, PNG, OTA-BMP and WBMP.
• Sound: MIDI
Note: If a received message contains unsupported elements, they
may be replaced with the text Object format not supported.
Define MMS settings
Before you can use the multimedia message feature, you need to first
define the way you want to receive the messages.
ALLOW MULTIMEDIA RECEPTION
You can choose to receive all messages or to receive messages only when
you are in the service provider’s home network.
1At the Start screen, press Menu 01-6-2-2 (Messages > Message
settings > Multimedia msgs. > Allow multimedia reception). After
a brief pause, a list of options appears in the display.
•Yes to allow all incoming messages
•In home system to allow incoming messages only if you are in the
service provider’s home system
DRAFT
[ 65 ]
Menu functions
2After selecting one of the reception options, scroll to Incoming
multimedia messages, then press Select.
3Scroll to Retrieve, then press Select.
BLOCK MULTIMEDIA RECEPTION
1At the Start screen, press Menu 01-6-2-2 (Messages > Message
settings > Multimedia msgs. > Allow multimedia reception). After
a brief pause, a list of options appears in the display.
2Scroll to No and press Select.
ALLOW OR NOT ALLOW ADVERTISEMENTS
1At the Start screen, press Menu 01-6-2-5 (Messages > Message
settings > Multimedia msgs. > Allow advertisements). After a brief
pause, Yes and No appear in the display.
2Scroll to the setting of your choice and press Select.
Other MMS settings
Other multimedia settings include saving your messages to the Sent
items folder and editing your connection settings.
1At the Start screen, press Menu 01-5-2 (Messages > Message
settings > Multimedia msgs.). After a brief pause, a list of options
appears in the display.
2Scroll to an option. Press Select to activate the option or to enter
its submenu.
Message
Setting Function
Save sent
messages
Saves sent multimedia messages to the Sent
items folder.
Allow
multimedia
reception
Chooses Yes, No, or In home network for your
multimedia service. In home network cannot receive
multimedia messages outside the home network.
DRAFT
[ 66 ]
Edit multimedia connection settings
1At the Start screen, press Menu 01-6-2-4 (Messages > Message
settings > Multimedia msgs. > Connection settings).
2Scroll to Edit active multimedia settings and press Select.
3The connection settings in the following table appear in the display.
Scroll to a setting. Press Select to enter the setting submenu.
Incoming
multimedia
messages
Select Retrieve to receive multimedia messages, or
Reject if you do not wish to receive multimedia
messages.
Connection
settings
Define connection settings for retrieving multimedia
messages. Activate the set where you want to save
the connection settings and then edit the settings.
Allow
advertisements
Allows you to enable or disable reception of
automatic multimedia advertisements.
Connection
setting Function
Settings’ name Rename the setting to your preference.
Homepage Enter the internet address where your browser
retrieves multimedia messages.
Session mode Select session modes Temporary or Permanent.
Data bearer Select the data bearer.
GPRS access
point
Define the access point.
Message
Setting Function
DRAFT
[ 67 ]
Menu functions
ABOUT CONNECTION SETTINGS
You may be able to receive multimedia connection settings as a text
message from your wireless provider or they may already be programmed
into your phone. For more information, contact your wireless provider.
SELECT A FONT SIZE FOR YOUR MESSAGES
1Press Menu 01-6-3-1 (Messages > Message settings > Other
settings > Font size). After a brief pause a list of choices appear in
the display.
2Scroll to Small font or Large font and press Select. A message
appears in the display confirming your selection.
Write and send a multimedia message
For availability and subscription to the multimedia messaging service,
contact your wireless provider.
1At the Start screen, press Menu 01-2-1 (Messages > Multimedia
msgs. > Create message) and press Select.
2Enter the text of your message and press Options.
3Scroll to Insert image or Insert sound clip and press Select.
4From the Gallery menu, select Graphics or Tones and press Open.
5Choose an image or sound clip from the list and press Options.
6Scroll to Insert and press Select.
IP address Enter or change the IP address.
Authentication
type
Select from Normal or Secure.
User name Edit or enter your user name.
Password Edit or enter a password.
Connection
setting Function
DRAFT
[ 68 ]
A confirmation message appears when the object is added and
appears at the top of the display screen to indicate that a multimedia
message has been created.
7Press Options, scroll to Send to number or Send to e-mail, and press
Select.
8Enter the number of the recipient or the e-mail address and press OK.
The message is sent.
Read and reply to a multimedia message
When a multimedia message is being received, appears (blinking) in
the display. Once the message has been fully downloaded, and
Multimedia message received appears in the display.
1To view the message, press Show. To view the message later, press
Exit (and then No when asked to discard).
2While viewing the message, press Options. Some or all of the
following options may appear in the display. Scroll to an option and
press Select to activate the option or enter its submenu.
Option Function
Delete
message
Delete a saved message.
Reply Reply to the message. Press Options and then Send. The
sender’s phone number or e-mail is used as the default.
Forward to no. Forward the message to another number.
Forward to
e-mail
Forward the message to an e-mail address.
Edit Edit the message. You can only edit messages that you
have written.
Details View the message subject, size, and class.
DRAFT
[ 69 ]
Menu functions
Note: If blinks and Multimedia memory full, view waiting
msg. appears in the display, memory for multimedia messages is
full. You need to delete some of your old messages. See “Delete
messages” on page 75 for more information.
• VOICE MESSAGES
If you subscribe to voice mail, your wireless provider will furnish you with
a voice mailbox number. You need to save this number to your phone to
use voice mail. When you receive a voice message, your phone lets you
know by beeping, displaying a message, or both. If you receive more than
one message, your phone shows the number of messages received.
Save your voice mailbox number
Your wireless provider may have already saved your voice mailbox number
to your phone. If so, the number will appear in the display in Step 2. Press
OK to leave the number unchanged.
1At the Start screen, press Menu 01-3-2 (Messages > Voice messages
> Voice mailbox number).
2After a brief pause, the Voice mailbox number screen appears in
the display.
3If the box is empty, enter the voice mailbox area code and number.
4Press OK. Your phone confirms the number has been saved.
Play Listen to a sound clip in the message, if one is included.
Save tone Save a ringing tone, if included, to the gallery.
Save image Save any picture that is attached to your picture
gallery.
Option Function
DRAFT
[ 70 ]
Tip: Save yourself the trouble of entering the mailbox codes each
time you dial voice mail. See “Automate voice mail” later in this
section for more information.
Call and setup your voice mail
1Once you have saved the voice mailbox number, press and hold
1
.
2When you connect to voice mail and the prerecorded greeting begins,
follow the service’s automated instructions to setup your voice mail.
Listen to your voice messages
Once you have setup voice mail, you can dial the number in one of four
ways:
• Dial the number using the keypad.
• Press and hold
1
.
•Press Listen if there’s a notification message in the display.
•Press Menu 01-3-1 (Messages > Voice messages > Listen to
voice messages). After a brief pause, your phone dials the voice
mail number.
Once you connect and the prerecorded greeting begins, follow the
automated instructions to listen to your voice messages.
Automate voice mail
You can insert special characters called “dialing codes” into phone numbers
such as voice mail and then save the number to a 1-touch dialing
location. Dialing codes instruct the receiving system to pause, wait,
bypass, or accept the numbers that follow them in the dialing string.
Note: Each voice mail service can vary. The examples and steps
that follow are for clarification. Check with your wireless provider
if you have specific questions about your voice mail service.
DRAFT
[ 71 ]
Menu functions
Write down some information
1Write down your voice mailbox number.
2Call and check your voice mail as you normally would.
3Write down your step-by-step interaction with the recorded prompts.
Keep in mind that each voice mail service may vary. However, it
should look something like this:
Dial 2145551212, pause 5 seconds, press 1, pause 2 seconds, press
1234, press pound key.
Important: Be precise. You will need this information in “Setup
voice mail with dialing codes” later in this section.
LEARN HOW TO INSERT DIALING CODES
Press
s
repeatedly to cycle through dialing codes. Once the desired code
appears in the display, pause briefly and the code is inserted into the
dialing string.
For example, press
s
four times to display the “w” (wait character). Pause
briefly and the wait character is inserted into the dialing string. Available
dialing codes are as follows:
*Bypasses a set of instructions
+Precedes an international telephone number
pPauses for 2.5 seconds before sending any numbers that follow
wWait. Your phone waits for you to press h before it sends any
numbers or codes that follow.
DRAFT
[ 72 ]
Setup voice mail with dialing codes
1At the Start screen, press Contacts, scroll to 1-touch dialing, and
press Select.
2Scroll to an empty 1-touch dialing slot and press Assign.
3Enter your voice mailbox number, including the area code.
4Refer to the table entitled “dialing codes,” and enter any codes as
necessary using the information that you wrote down earlier.
For example, if you pause for 5 seconds after connecting to voice
mail, enter p twice after the voice mailbox number, such as
2145551212pp.
5Enter any remaining pauses, PIN codes, and other information that
allows you to listen to your messages, then press OK.
6Enter a name (such as Voice mail) and press OK. A message appears
in the display confirming your 1-touch dialing location has been
saved.
Now, to dial and listen to your voice mail, just press and hold the
assigned 1-touch dialing key at the Start screen. No other keypresses
should be necessary to connect and listen to your messages.
• MESSAGE OPTIONS
Some or all of the options in the following table are available for text
messages, picture messages, multimedia messages, and e-mail.
1While viewing a text, picture, multimedia message, or e-mail
press Options.
2Scroll to highlight an option. Press Select to activate the option or
enter its submenu:
Option Function
Delete Delete the message you are viewing.
DRAFT
[ 73 ]
Menu functions
• ORGANIZE MESSAGES WITH FOLDERS
Save messages to folders
You can save messages to an existing folder or to a folder that you have
created.
1Press Menu 01-1-1 (Messages > Text messages > Create message).
After a brief pause, the message entry screen appears in the display.
2Write your message and press Options.
3Scroll to Save message and press Select.
4Scroll to the Archive, Templates, or My folders (if you have created a
folder of your own) and press Select. The message is saved.
Reply Reply to the message; you have the option to include
the original text in the reply, a template, or empty
screen.
Use detail Extract numbers, e-mail addresses and website
addresses from the current message.
Forward Forward the message to another recipient.
Edit Edit the message.
Move Move the message to a folder you specify.
Rename Rename the message before it is saved to a folder.
Copy to
calendar
Copy text from the beginning of the message to your
phone calendar as a reminder note for the current day.
Message
details
View the sender’s name and phone number, the
message center used, reception date and time.
Option Function
DRAFT
[ 74 ]
See “My folders” on page 74 for more information on creating your
own folders.
View saved messages
1At the Start screen, press Menu 01-1 (Messages > Text messages).
2After a brief pause, scroll to the folder containing the message you
wish to view and press Select.
3Once the folder opens, scroll to the message you wish to view and
press Select.
Inbox folder
Messages are automatically stored in the inbox after they have been read
or if you press Back when Message received appears on the Start screen.
Archive folder
Store messages that have been read in the Archive folder.
Templates folder
Pictures and prewritten templates are stored in the Templates folder.
Preloaded templates can be edited/customized.
USE TEMPLATES
1At the Start screen, press Menu 01-1-6 (Messages > Text messages
> Templates). After a brief pause, the folder opens.
2Scroll to a template and press Select.
My folders
Keep your messages organized by creating custom folders and saving
some of your messages there.
ADD A FOLDER OF YOUR OWN
1At the Start screen, press Menu 01-1-7 (Messages > Text messages
> My folders). After a brief pause, the folder opens.
2Press Options. Scroll to Add folder and press Select.
3Enter a name for the new folder and press OK. The folder is added.
DRAFT
[ 75 ]
Menu functions
REMOVE A FOLDER
Only folders created in My folders can be deleted. The Inbox, Outbox,
Archive, and Template folders are protected. When you delete a folder, all
messages in the folder are also deleted.
1At the Start screen, press Menu 01-1-7 (Messages > Text messages
> My folders). After a brief pause, the folder opens.
2Any folders that you have created appear in the display. Scroll to the
folder you wish to remove and press Options.
3Scroll to Delete folder and press Select. You are asked to confirm the
deletion.
4Press OK to delete or Back to exit.
Move a message to a folder
1While viewing the message, press Options.
2Scroll to Move and press Select.
3Scroll to the destination folder and press Select.
• DELETE MESSAGES
If your message memory is full and you have more messages waiting at
the network, blinks in on Start screen. You can do the following to
create more space:
• Read some of the unread messages and then delete them.
• Delete messages from some of your folders.
Delete a single message
To delete a single message, you need to open it first.
1Press Menu 01-1 (Messages > Text messages). After a brief pause, a
list of options appears in the display.
2Scroll to the folder containing the message you wish to delete and
press Select. A list of messages, if you have any, appears in the
display.
DRAFT
[ 76 ]
3Scroll to the message you wish to delete and press Select. The
message opens.
4Press Options, scroll to Delete, and press Select.
5You are asked to confirm the erasure. Press OK to delete the message
or Back to exit.
Delete all messages in a folder
1At the Start screen, press Menu 01-1-9 (Messages > Text messages
> Delete messages). After a brief pause, a list of your folders appears
in the display.
2Scroll to the folder containing the messages you wish to delete and
press Select. You are asked to confirm your request.
Important: If you select All messages, it deletes all messages in
all of the folders.
3Press OK to empty the folder.
• CHANGE TEXT, E-MAIL, AND PICTURE MESSAGE
SETTINGS
1At the Start screen, press Menu 01-6-1-1 (Messages > Message
settings > Text messages > Sending profile).
2If more than one message profile set is supported by your SIM card,
scroll to the set you wish to change and press Select.
Message Setting Function
Message center
number
Save the phone number of the message center,
which is necessary for sending text messages;
obtain this number is from your wireless provider.
Default recipient
number
For text messages, the default number used to
send messages.
DRAFT
[ 77 ]
Menu functions
OVERWRITE SETTINGS FOR TEXT, E-MAIL, AND PICTURE MESSAGES
When the message memory is full, your phone cannot send or receive any
new messages. However, you can set your phone to automatically replace
old messages in the Inbox and Outbox folders when new ones arrive.
1Press Menu 01-5-1 (Messages > Message settings > Text
messages). After a brief pause, a list of options appear in the display.
2Scroll to Overwriting in sent items or Overwriting in inbox and
press Select.
3Scroll to Allowed and press Select to replace the old messages with
new ones in the Sent items or Inbox folder, respectively.
Use GPRS Set GPRS as the preferred method of sending
text messages.
Reply via same
center
Allow the recipient of your message to send you a
reply message by way of your message center
(network service).
Messages
sent as
Select the message type: Text, E-mail, Page, or
Fax.
Message validity Define how long the network attempts to send your
messages before it gives up.
E-mail server
number
The default number used to send e-mail.
Delivery reports Request the network to send delivery reports on
your messages.
Rename sending
profile
Change the name of the selected sending profile;
the sending profile sets display only if your SIM
card supports more than one set.
Message Setting Function
DRAFT
[ 78 ]
• CHANGE MULTIMEDIA MESSAGE SETTINGS
1At the Start screen, press Menu 01-5-2 (Messages > Message
settings > Multimedia msgs.). After a brief pause, a list of options
appears in the display.
2Scroll to an option. Press Select to activate the option or to enter its
submenu.
Receive multimedia connection settings as a
text message
You may be able to receive multimedia connection settings as a text
message from your wireless provider. For more information, contact your
wireless provider.
Message Setting Function
Save sent messages Saves sent multimedia messages to the Sent
items folder.
Allow multimedia
reception
Choose Yes, No, or In home network for your
multimedia service. In home network cannot
receive multimedia messages outside the
home network.
Incoming multimedia
messages
Select Retrieve to receive multimedia
messages, or Reject if you do not wish to
receive multimedia messages.
Connection settings Allows you to view or edit active multimedia
message settings
Allow advertisements Allows you to enable or disable reception of
automatic multimedia advertisements.
DRAFT
[ 79 ]
Menu functions
Use the info message service
With the info message network service, you can receive short text
messages on various topics, such as weather and traffic conditions, from
your wireless provider.
1At the Start screen, press Menu 01-4 (Messages > Info messages).
After a brief pause, the list of options in the following table appears
in the display.
2Scroll to an option. Press Select to activate the option or to enter its
submenu.
Note: For more information on topics, contact your wireless
provider.
Message setting Function
Info service Select On, Off, or Topic index to activate or
deactivate the service.
Topics Displays options for selecting, adding, editing, and
deleting info topics.
Language Select the language in which info messages
are received. The language you select does not
affect the language you select under the phone
settings menu.
Info topics saved
on SIM card
Select one or more info topics to save to your SIM
card.
DRAFT
[ 80 ]
Call log (Menu 2)
Call log stores information about the last 20
missed, 20 received, or 20 dialed calls. It also adds
the total duration of all calls. When the number of
calls exceed the maximum, the most recent call
replaces the oldest. For Call log to work properly:
• Your wireless provider must support caller ID, and it must be enabled.
• Your calls cannot be blocked.
• Your phone must be on and within the service area.
• CALL LOG OPTIONS
Whether you are viewing missed, received, or dialed calls, each of the
menu options will be the same. Please refer to the following table
regarding menu options for these features.
Call time Display the date and time of the call.
Send message Send a message to the number.
View number Display the number.
Edit number Edit the number and associate a name with the number.
Save Enter a name for the number and save it to your
contacts list.
Add to
contacts
Add the number to an existing entry in your contacts
list, if the number is not associated with a name.
Delete Clear the number from memory.
Call Call the number.
DRAFT
[ 81 ]
Menu functions
• VIEW MISSED CALLS
Missed calls are calls that were never answered. You can check for missed
calls in two ways:
Note: The missed calls feature does not function while your phone
is off or outside of the service area.
1If # missed call appears in the display, press List. The phone number
appears in the display.
2Press Options to display the options listed in the table on page 80.
3Scroll to an option, press Select to activate the option or to enter
its submenu.
OR
1At the Start screen, press Menu 2-1 (Call log > Missed calls).
After a brief pause, a list of missed calls appears in the display
(if any exist).
2Scroll to a name or number and press Options to display the options
listed under “Call log options” on page 80.
3Scroll to an option, press Select to activate the option or to enter
its submenu.
• VIEW RECEIVED CALLS
Received calls are calls that have been answered.
1At the Start screen, press Menu 2-2 (Call log > Received calls).
After a brief pause, a list of received calls appears in the display
(if any exist).
2Scroll to a name or number and press Options to display the options
listed under “Call log options” on page 80.
3Scroll to an option, press Select to activate the option or enter
its submenu.
DRAFT
[ 82 ]
• VIEW DIALED NUMBERS
You can view dialed numbers in one of two ways:
1At the Start screen, press h. Your most recently dialed numbers
appear in the display.
OR
2At the Start screen, press Menu 2-3 (Call log > Dialed numbers).
After a brief pause, your most recently dialed numbers appear in
the display.
3Scroll to a name or number and press Options to display the options
listed under “Call log options” on page 80.
4Scroll to an option, press Select to activate the option or enter
its submenu.
Call times
You can receive up to five calls from the same number and view the time
each call occurred. Your clock must be set for this feature to work accurately.
See “Set the clock” on page 88 for instructions on setting your clock.
1While viewing a missed or received call, press Options, scroll to Call
time, and press Select.
2The time that the last call occurred appears in the display.
3Press g to view other call times from this number. Press Back to
return to the options list.
• DELETE CALL LISTS
To clear any missed, dialed, or received calls from your phone memory:
1At the Start screen, press Menu 2-4 (Call log > Delete recent
call lists).
After a brief pause, All, Missed, Received and Dialed appear in
the display.
2Scroll to the call type you want to clear and press Select.
DRAFT
[ 83 ]
Menu functions
• VIEW CALL DURATION
1Duration of last call. At the Start screen, press Menu 2-5-1
(Call log > Call timers > Duration of last call). The duration of
your last call appears in the display.
2Duration of received calls. At the Start screen, press Menu 2-5-2
(Call log > Call timers > Duration of received calls). The duration of
all received calls appears in the display.
3Duration of dialed calls. At the Start screen, press Menu 2-5-3
(Call log > Call timers > Duration of dialed calls). The duration of
all dialed calls appears in the display.
4Duration of all calls. At the Start screen, press Menu 2-5-4
(Call log > Call timers > Duration of all calls). The duration of all
calls (missed, dialed, and received) appears in the display.
Note: The actual time invoiced for calls by your service provider
may vary, depending upon network features, rounding-off for
billing, and so forth.
DRAFT
[ 84 ]
Profiles (Menu 3)
Profiles define how your phone reacts when you
receive a call or a message, how your keypad sounds
when you press a key, and more. Ringing options,
keypad tones, and other settings for each of the five
available profiles can be left at their default setting, or customized to suit
your needs. Select and customize the most suitable profile for your
situation, such as when you are in a meeting or outdoors. The following
profiles are available:
Note: Profiles are also available for enhancements such as a
headset and car kit. See “Enhancement settings” on page 99 for
more information about enhancement profiles.
• SELECT A PROFILE
1At the Start screen, press Menu 3 (Profiles) or quickly press the
power key.
After a brief pause, the list of profiles appears in the display.
2Scroll through the available profiles and press Select once the profile
of your choice is highlighted.
3Scroll to Select and press Select.
• CUSTOMIZE A PROFILE
You can customize any of the profiles in a variety of ways.
1At the Start screen, press Menu 3 (Profiles).
After a brief pause, the list of profiles appears in the display.
2Scroll to the profile you wish to customize and press Select.
• Normal • Silent • Meeting • Outdoor • Pager
DRAFT
[ 85 ]
Menu functions
3Scroll to Customize and press Select.
4Use the scroll keys to display each of the options in the following
table. Once you arrive at the option you want to customize, press
Select.
Note: You cannot rename the Normal profile.
• SET A TIMED PROFILE
Timed profiles can be used to prevent missed calls. For example, suppose
you attend an event that requires your phone be set to Silent before the
event starts, but you forget to return it to Normal until long after the
event. During this time, you have missed several calls because the ringing
tone was silent. A timed profile can prevent this by automatically
returning your phone to the default profile at a time you specify.
Ringing options Select the ringing tone style
Ringing tone Select the ringing tone for incoming calls
Ringing volume Set the volume of your ringing tone
Vibrating alert Turn the vibrating alert on or off
Message alert tone Select the tone for received messages
Keypad tones Set the volume of your keypad tones (or turn
them off)
Warning tones Turn warning and confirmation tones on or off
Alert for Define which caller groups the selected profile
will accept or decline. See “Caller groups” on
page 53 for more information.
Profile name Rename the profile (up to 16 characters)
DRAFT
[ 86 ]
Note: Timed profiles can be set up to 24 hours in advance.
1At the Start screen, press Menu 3 (Profiles).
After a brief pause, the list of profiles appears in the display.
2Scroll to the profile you wish to activate and set for timed expiration,
then press Select.
3Scroll to Timed and press Select.
4Enter the time (in hh:mm format) and press OK.
5Scroll to am or pm and press Select.
The profile you have set for expiration is now active and appears in
the Start screen along with the icon.
DRAFT
[ 87 ]
Menu functions
Settings (Menu 4)
• RIGHT SELECTION KEY SETTINGS
You can change the function of the right selection
key (c) on your phone so that your most
frequently used functions can be quickly accessed
from the Start screen.
Choose functions
1At the Start screen, press Menu 4-1 (Settings > Right selection key
settings).
2After a brief pause, Options is highlighted in the display. Press Select.
3Use the scroll keys (d or g) to highlight the desired function from
the list of available functions.
4Press Mark. A mark appears in the box next to the selected function
indicating that you have selected the function. Use Unmark to
remove a function from the list.
Note: The Contacts function cannot be Unmarked from the list.
5Repeat steps 3 and 4 to select as many functions as you wish.
6Press Done when you have added all desired functions.
7Save changes? appears in the display. Select Yes.
At the Start screen, Go to is now the right selection key (c) option
on your phone. Selecting Go to displays a list of the functions you
selected in steps 4 and 5.
Organize functions
1At the Start screen, press Menu 4-1 (Settings > Right selection key
settings).
2Scroll to Organize and press OK. The list of functions is displayed.
DRAFT
[ 88 ]
3Use the scroll keys (d or g) to highlight the function you wish to
rearrange and select Move.
4Highlight Move up, Move down, Move to top, or Move to bottom
from the list of choices and press Select.
The list of right selection key functions is displayed in the new order.
• TIME AND DATE SETTINGS
Set the clock
1At the Start screen, press Menu 4-2-1 (Settings > Time and date
settings > Clock).
After a brief pause, Show clock (or Hide clock) Set the time, and Time
format appear in the display with Show clock (or Hide clock)
highlighted.
2Scroll to Set the time and press Select.
3Enter the time (in hh:mm format) and press OK.
4Scroll to am or pm and press Select. The time is set.
Show/hide the clock
You have the option of displaying (or not displaying) the clock on the
Start screen.
1At the Start screen, press Menu 4-2-1 (Settings > Time and date
settings > Clock).
After a brief pause, Show clock (or Hide clock) Set the time,
and Time format appear in the display with Show clock (or Hide
clock) highlighted.
2Press Select.
• If your clock was previously “hidden,” (not shown on the display), it
will now appear in the upper right corner of the Start screen.
• If your clock was previously shown in the display, it will now be
hidden from view.
DRAFT
[ 89 ]
Menu functions
Change the time format
You can set the time format for am/pm or 24-hour format (military time).
1At the Start screen, press Menu 4-2-1 (Settings > Time and date
settings > Clock).
After a brief pause, Show clock (or Hide clock) Set the time,
and Time format appear in the display with Show clock (or Hide
clock) highlighted.
2Scroll to Time format and press Select.
3Scroll to 24-hour or am/pm and press Select. A message appears in
the display confirming your selection.
Set the date
1At the Start screen, press Menu 4-2-2 (Settings > Time and
date settings > Date). After a brief pause, a list of options appears in
the display.
2Scroll to Set the date and press Select.
3Enter the date and press OK. The date is set.
Set or change the date format
1At the Start screen, press Menu 4-2-2 (Settings > Time and date
settings > Date).
2Scroll to Date format or Date separator and press Select.
3Scroll to the format of your choice and press Select. A message
appears in the display confirming your selection.
• CALL SETTINGS
Call forwarding
Call forwarding tells your network to redirect incoming calls to
another number.
DRAFT
[ 90 ]
Note: Call forwarding is network-dependent and may not work
the same in all networks. Contact your wireless provider
for availability.
ACTIVATE CALL FORWARDING
Note: This is a network dependent feature. All options listed in the
following table may not appear in the display. Contact your
wireless provider for more information.
1At the Start screen, press Menu 4-3-1 (Settings > Call settings >
Call forwarding).
2After a brief pause, the forwarding options listed in the following
table appear in the display.
3Scroll to the option of your choice and press Select.
Forward all
voice calls
Forward all calls to the number you specify.
Forward if busy Forward incoming calls when you are in a call.
Forward if
not answered
Forward incoming calls to another number if
you are unable to answer. You can also set a
delay before forwarding takes place.
Forward if out of
reach
Forward incoming calls when your phone is off.
Forward when not
able to take calls
Forward calls that aren’t picked up. You can
also set a delay before forwarding takes place.
Forward all fax calls Forward all fax calls to a fax mailbox.
Forward all data calls Forward all data calls to a data mailbox.
Cancel all
call forwarding
Cancel any call forwarding options you may
have set.
DRAFT
[ 91 ]
Menu functions
4Scroll to Activate and press Select.
5Scroll to the destination to which your calls will be forwarded
(such as To other no.) and press Select.
6Enter the number to which your calls, data, or other information will
be forwarded and press OK.
Your phone calls the network to activate the feature you have requested.
The network sends a confirmation note when the feature has been
activated successfully.
CANCEL CALL FORWARDING
• At the Start screen, press Menu 4-3-1-8 (Settings > Call settings >
Call forwarding > Cancel all call forwarding).
Note: Cancel all call forwarding may affect your ability to receive
voice mail messages. Contact your wireless provider for specific details.
Anykey answer
Anykey answer allows you to answer an incoming call by briefly pressing
any key except a, b, c, and i.
1At the Start screen, press Menu 4-3-2 (Settings > Call settings >
Anykey answer). After a brief pause, On and Off appear in the display.
2Scroll to your choice and press Select.
Automatic redial
Occasionally, your network may experience heavy traffic, resulting in a
“fast” busy signal when you dial. With automatic redial activated, your
phone redials the number up to 10 times, and notifies you once the
network becomes available.
ACTIVATE OR DEACTIVATE AUTOMATIC REDIAL
1At the Start screen, press Menu 4-3-3 (Settings > Call settings >
Automatic redial). After a brief pause, On and Off appear in the
display.
2Scroll to your choice and press Select.
DRAFT
[ 92 ]
Call waiting
If supported by your wireless provider, call waiting notifies you of an
incoming call even while you are in a call. You can then accept, reject, or
ignore the incoming call.
ACTIVATE CALL WAITING
1Press Menu, scroll to Settings, and press Select.
2Scroll to Call settings and press Select.
3Scroll to Call waiting and press Select.
4Scroll to Activate and press Select.
USE CALL WAITING
• During a call, press h to answer the waiting call. The first call is put
on hold.
•Press
i to end the active call.
Activate/deactivate summary after call
Your phone can display the time spent on a call when you hang up.
TURN ON SUMMARY AFTER CALL
1At the Start screen, press Menu 4-3-6 (Settings > Call settings >
Summary after call).
After a brief pause, On and Off appear in the display.
2Scroll to On and press Select.
TURN OFF SUMMARY AFTER CALL
1At the Start screen, press Menu 4-3-6 (Settings > Call settings >
Summary after call).
After a brief pause, On and Off appear in the display.
2Scroll to Off and press Select.
DRAFT
[ 93 ]
Menu functions
Send my caller identity with next call
You can prevent your number from being displayed on the receiving
party’s caller ID. This feature is network dependent and works on a
call-by-call basis. Contact your wireless provider for more information.
1At the Start screen, press Menu 4-3-7 (Settings > Call settings >
Send my caller identity). After a brief pause, Default, Yes, and No
appear in the display.
2Scroll to the selection of your choice and press Select. A message
appears in the display confirming your selection.
Select a line for outgoing calls
Note: This is a network dependent feature. Check with your
wireless provider for availability and a description of the feature.
1At the Start screen, press Menu 4-3-8 (Settings > Call settings >
Line for outgoing calls). After a brief pause, Line 1 and Line 2 appear
in the display.
Important: If you select Line 2 and have not subscribed to this
network service, you will not be able to place calls. However, calls
on both lines can be answered regardless of the selected line.
2Scroll to Line 1 or Line 2 and press Select. A message appears in the
display confirming your selection.
Tip: If supported by your SIM card, you can prevent the line
selection by using the Lock option.
• PHONE SETTINGS
Set the display language
1At the Start screen, press Menu 4-4-1 (Settings > Phone
settings > Language).
After a brief pause, Automatic, English, Português, Español, and
Français appear in the display.
DRAFT
[ 94 ]
2Scroll to the language of your choice and press Select.
Note: The language setting affects the time and date formats of
the clock, alarm clock, and calendar.
Activate or deactivate automatic Keyguard
Important: When Keyguard is on, it may be possible to dial
emergency numbers (for example, 911 or other official emergency
numbers). Key in the emergency number and press h. The number
is displayed only after you have keyed in its last digit.
You can set the keypad of your phone to lock automatically after a preset
time delay (from 10 seconds to 60 minutes). When the preset delay
expires, the keypad locks automatically.
1At the Start screen, press Menu 4-4-2 (Settings > Phone settings >
Automatic keyguard). After a brief pause, On and Off appear in
the display.
2Scroll to On (or Off to deactivate) and press Select.
3If you selected On, Set delay appears in the display.
4Enter the delay (in minutes and seconds) and press OK.
Cell info display
Note: Cell info display is network-dependent and may not work
the same in all networks. Contact your wireless provider
for availability.
When this function is selected, your phone will indicate when it is used in
a system cell based on micro-cellular network technology. MCN
technology increases the capacity of wireless networks in urban areas. The
setting will remain in effect even if the SIM card is changed or the phone
is switched off.
1Press Menu 4-4-3 (Settings > Phone settings > Cell info display).
After a brief pause, On and Off appear in the display.
2Scroll to On (or Off) and press Select. A message appears in the
display confirming your selection.
DRAFT
[ 95 ]
Menu functions
Note: If the GPRS connection is set to Always online, info
messages may not be received. In that case, set the GPRS
connection to When needed. See “(E)GPRS” on page 129 for more
information.
Welcome note
You can write a welcome note which shows up briefly on your display
whenever you power up your phone.
Note: Predictive text input is unavailable for entering welcome
note text.
1At the Start screen, press Menu 4-4-4 (Settings > Phone settings >
Welcome note).
After a brief pause, the message edit screen appears in the display
awaiting text input.
2Enter a note (up to 44 characters).
•Press
s
to display and select from available special characters. For
more information on special characters, “Enter punctuation and
special characters” on page 32.
3When you are finished, press Options, scroll to Save, and press Select.
Scroll to Delete and press Select if you want to delete the previous
text and begin writing another note.
System selection
You may be able to manually search for another network which has a
roaming agreement with your home wireless provider.
1At the Start screen, press Menu 4-4-5 (Settings > Phone settings >
System selection). After a brief pause, Automatic and Manual appear
in the display.
DRAFT
[ 96 ]
2Scroll to Automatic or Manual and press Select.
Note: If No system access appears in the display, you will need
to switch to Automatic mode, or insert another SIM card into
the phone.
Confirm SIM service actions
This option allows you to request notification when your service provider
makes changes to SIM-related services (such as activating (E)GPRS
service).
1Press Menu 4-4-6 (Settings > Phone settings > Confirm SIM
service actions). After a brief pause, Yes and No appear in the display.
2Scroll to the selection of your choice and press Select. A message
appears in the display confirming your selection.
Note: For availability, rates and information on using SIM services,
contact your SIM card vendor, for example, network operator,
service provider, or other vendor.
Help text
Your phone displays brief descriptions for most menu items. When you
arrive at a feature or menu, pause for about 10 seconds. Use the scroll
keys to page through the full help text, if necessary.
ACTIVATE/DEACTIVATE HELP TEXT
The default setting for Help text is On. However, you can turn help text
on or off by doing the following from the Start screen.
Option Function
Automatic Your phone defaults to those settings which have been
preset by your wireless provider.
Manual Your phone searches for a network which has a
roaming agreement with your wireless provider.
DRAFT
[ 97 ]
Menu functions
1Press Menu 4-4-7 (Settings > Phone settings > Help text
activation). After a brief pause, On and Off appear in the display.
2Scroll to your choice and press Select. A message appears in the
display confirming your selection.
Start-up tone
Note: This feature is network dependent and may not be
supported by your wireless provider. Contact your wireless
provider for more information.
You can set your phone to play (or not to play) a start-up tone when the
phone is switched on.
1At the Start screen, press Menu 4-4-8 (Settings > Phone settings >
Start-up tone). After a brief pause, On and Off appear in the display.
2Scroll to your choice and press Select. A message appears in the
display confirming your selection.
• DISPLAY SETTINGS
Wallpaper
You can set your phone to display a background picture (wallpaper) on
the Start screen. Some preselected pictures are saved in the Gallery menu.
You can also receive pictures via multimedia message, download them
from xHTML pages, or transfer them with PC Suite from your PC, then save
them in the Gallery. Your phone supports JPEG, GIF, BMP, PNG, and
WBMP formats.
SELECT WALLPAPER
1Press Menu 4-5-1 (Settings > Display settings > Wallpaper). After
a brief pause, On, Off, and Change image appear in the display.
2Scroll to Change image and press Select to browse the gallery for
another image.
DRAFT
[ 98 ]
3Use the scroll keys (d or g) to browse the image gallery. When you
arrive at the image of your choice, press Options, scroll to Set as
wallpaper, and press Select.
4If Replace current wallpaper? appears in the display, press OK. A
message appears in the display confirming your selection.
ACTIVATE/DEACTIVATE WALLPAPER
1Press Menu 4-5-1 (Settings > Display settings > Wallpaper). After
a brief pause, On, Off, and Change image appear in the display.
2Scroll to On or Off and press Select.
Color schemes
You can change the color of some display components in your phone, such
as indicators and signal bars.
1At the Start screen, press Menu 4-5-2 (Settings > Display settings
> Color Schemes). After a brief pause, a list of color schemes appear
in the display.
2Scroll to the color scheme of your choice and press Select. A message
appears in the display confirming your selection.
Screen saver
The screen saver is activated when no function of the phone is used after
a preset period of time. Press any key to deactivate the screen saver. The
screen saver is also deactivated when the phone is out of the network
coverage area.
You can set your phone to display a screen saver after a preset time or
after a custom time (up to 60 minutes) of your choosing.
1At the Start screen, press Menu 4-5-4 (Settings > Display settings
> Screen saver timeout). After a brief pause, 2 minutes, 5 minutes,
and Other appear in the display.
2Scroll to 2 minutes or 5 minutes and press Select.
3If you want to set a custom time (up to 60 minutes), scroll to Other
and press Select. Enter the custom time and press OK.
DRAFT
[ 99 ]
Menu functions
A message appears in the display confirming your selection.
Display brightness
You can change the brightness of your phone display. See “Adjust display
brightness” on page 29 for more information.
• TONE SETTINGS
You can adjust the ringing volume, keypad tones, and more for the
currently active profile. The same options are described in detail under
“Customize a profile” on page 84.
• ENHANCEMENT SETTINGS
The Enhancement settings menu and submenus are shown only if the
phone is or has been connected to one of the compatible enhancements
such as the headset, car kit, mobile inductive loopset, TTY/TDD device, or
music stand.
1At the Start screen, press Menu 4-7 (Settings > Enhancement
settings).
2Scroll to Headset, Handsfree, Loopset, TTY, or Music stand and press
Select.
Headset
Scroll to the option of your choice and press Select to enter the option
submenu and modify its settings. The following options are available:
•Default profile—Choose the profile you wish to be automatically
activated when a headset is connected.
•Automatic answer—Calls are answered automatically after 1 ring
when a headset is connected. Scroll to On or Off and press Select.
Handsfree
Scroll to the option of your choice and press Select to enter the option
submenu and modify its settings. The following options are available:
DRAFT
[ 100 ]
•Default profile—Choose the profile you wish to be automatically
activated when your phone is connected to a car kit.
•Automatic answer—Calls are answered automatically after one ring
when a car kit is connected. Scroll to On or Off and press Select.
•Lights—Choose to keep the phone lights always on, or to shut off
automatically after several seconds. Scroll to On or Automatic and
press Select.
Loopset
Scroll to the option of your choice and press Select to enter the option
submenu and modify its settings. The following options are available:
•Default profile—Choose the profile you wish to be automatically
activated when a loopset is connected.
•Automatic answer—Calls are answered automatically after one ring
when a loopset is connected. Scroll to On or Off and press Select.
TTY
WHAT YOU WILL NEED
In addition to the Nokia phone, you will need the following for TTY/TDD
communication.
• A TTY/TDD device that is “cellular ready” or “cellular compatible.”
• A cable for connecting the TTY/TDD to your phone, usually supplied by
the manufacturer of the TTY/TDD device.
• The TTY/TDD Adapter (HDA-10), which can be purchased as an
enhancement at www.nokia.com/us. See “Enhancements” on
page 151.
SET UP THE TTY/TDD PROFILE
You can connect your phone to a TTY/TDD using the Nokia TTY/TDD
Adapter (HDA-10). In order for your phone to recognize the TTY/TDD, you
will need to set up the TTY/TDD profile.
DRAFT
[ 101 ]
Menu functions
Important: Some manufacturers of TTY/TDD devices suggest that
the phone be least 18 inches from the TTY/TDD device. When
connecting to any other device, read its user guide or contact its
manufacturer for detailed instructions and safety information.
1Plug the HDA-10 adapter into the connector on the bottom of your
phone, as shown in the illustration.
2Press Menu 4-7-4-1 (Settings > Accessory settings > TTY/TDD >
Use TTY).
3Scroll to Yes, then press Select.
4Connect the TTY/TDD by a cable to the HDA-10 adapter.
NOTES ABOUT TTY/TDD CALLS
• The Nokia TTY/TDD Adapter (HDA-10) is for use with compatible
TTY/TDD devices only. Check with the manufacturer of the TTY/TDD
device to ensure that the connection is compatible.
• Check with the manufacturer of the TTY/TDD device for a connecting
cable that is compatible with the Nokia TTY/TDD Adapter (HDA-10).
• TTY/TDD communications depend on network availability. Check with
your service provider for availability and description of services.
MAKE A TTY/TDD CALL
1From the Start screen, enter the number and press h.
2When the receiving party answers, begin typing your conversation on
the TTY/TDD. Press i
to end the call.
18”
DRAFT
[ 102 ]
RECEIVE A TTY/TDD CALL
1Make sure the TTY/TDD device is connected to your phone.
2Press h to answer the call, then type your responses on the
TTY/TDD. Press i
to end the call.
Music Stand
Scroll to the option of your choice and press Select to enter the option
submenu and modify its settings. The following options are available:
•Default profile—Choose the profile you wish to be automatically
activated when your phone is connected to a music stand.
•Automatic answer—Calls are answered automatically after one ring
when a music stand is connected. Scroll to On or Off and press Select.
•Lights—Choose to keep the phone lights always on, or to shut off
automatically after several seconds. Scroll to On or Automatic and
press Select.
• SECURITY SETTINGS
For information on PIN code request, call restrictions, fixed dialing, and
other security features, see “Manage phone security” on page 35.
• RESTORE FACTORY SETTINGS
You can reset some of the menu settings to their original values.
1At the Start screen, press Menu 4-9 (Settings > Restore
factory settings). After a brief pause, you are prompted to enter the
security code.
2Enter the security code (the default is 12345) and press OK. A
message appears in the display confirming your original settings have
been restored.
Note: Any data that you have entered, such as names and numbers
in your contact list will not be deleted.
DRAFT
[ 103 ]
Menu functions
Alarm clock (Menu 5)
The alarm clock is based on the internal clock of
your phone. It sounds an alert any time you specify
and even works if the phone is off.
• SET AN ALARM
IF AN ALARM HAS NOT BEEN SET
1At the Start screen, press Menu 5 (Alarm clock). After a brief pause,
you are prompted to enter a time for the alarm.
2Enter the time for the alarm in hh:mm format and press OK.
3Scroll to am or pm and press Select. Alarm on appears briefly in the
display and appears on the Start screen.
IF AN ALARM HAS PREVIOUSLY BEEN SET
1At the Start screen, press Menu 5 (Alarm clock). After a brief pause,
On and Off appear in the display.
2Scroll to On and press Select. You are prompted to set the alarm time.
3Enter the time for the alarm (in hh:mm format) and press OK.
4Scroll to am or pm and press Select. Alarm on appears briefly in the
display and appears on the Start screen.
When the alarm sounds
Your phone beeps, vibrates, and the display lights up. Stop and Snooze
appear in the bottom of the display.
WITH THE PHONE ON
Press Stop to shut the alarm off.
OR
Press Snooze. The alarm stops for 10 minutes and Snoozing appears in the
display.
DRAFT
[ 104 ]
Note: If you do not press a key, the alarms stops (snoozes) for
10 minutes, and then sounds again.
WITH THE PHONE OFF
1The alarm sounds. If you press Stop the following appears in
the display:
Switch the phone on?
Note: The phone will only power up if you select Yes when Switch
the phone on? appears in the display.
2Press Yes to power up the phone. Press No to keep it switched off.
Warning: Do not press Yes when wireless phone use is prohibited
or when it may cause interference or danger.
• TURN OFF AN ALARM THAT HAS BEEN SET
1At the Start screen, press Menu 5 (Alarm clock). After a brief pause,
On and Off appear in the display.
2Scroll to Off and press Select. Alarm off appears briefly in the display.
DRAFT
[ 105 ]
Menu functions
Radio (Menu 6)
To listen to the FM radio on your phone, connect
the Stereo Headset (HDS-3) or Headset Kit (HDB-
4) to the connector on the bottom of the phone.
The leads of the headset function as the antenna,
so let it hang freely.
Note: Your phone must be switched on to use this function. Do
not switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
Note: The quality of the radio broadcast depends on the coverage
of the radio station in that particular area.
• TURN THE RADIO ON AND OFF
• At the Start screen, press Menu 6 (Radio).
• To quickly turn off the radio, press and hold i.
• USE THE RADIO
Note: When you place or receive a call, the radio automatically
mutes. Once the call is ended, the radio automatically switches
back on.
• With the radio on, press Options to choose from the options listed in
the following table. Press d or g to scroll to an option. Press Select
to activate the option or enter its submenu.
Option Function
Turn off Turn off the radio.
Save channel Save the current station to one of 20 locations.
Automatic
tuning
Briefly press either scroll key to start the channel
search up or down. Press OK when a channel is found.
DRAFT
[ 106 ]
Tip: To quickly set the radio frequency, press
s
with the radio on.
Tip: To manually tune the radio, press
p
with the radio on.
Note: When an application using a (E)GPRS connection is sending
or receiving data, it may interfere with the radio.
• SAVE A RADIO CHANNEL
You can save a preset station to any one of 20 locations in memory, and
then tune to that station by simply pressing d or g with the radio on.
1With the radio on, press and hold d or g to start the
channel search. Searching stops when a channel is found.
2To save the channel, press Options, scroll to Save channel, and press
Select.
3Enter a name for the channel and press OK.
4Next, scroll to an (empty) location to save the channel and
press Select.
Tip: To quickly save an FM station to a memory location from 1 to
9, press and hold the corresponding number key while the radio is
playing. Then, enter the name of the channel and press OK.
Manual tuning Press d or g to search in increments of 0.1 MHz.
Set frequency Manually enter the frequency of a known radio station.
Delete
channel
Delete a saved channel.
Loudspeaker Listen to the radio through the speakerphone.(The
headset must be connected.)
Mono output/
Stereo output
Listen to the radio in monaural mode. If already in
manual mode, Stereo output appears in the display.
Option Function
DRAFT
[ 107 ]
Menu functions
Gallery (Menu 7)
You can save pictures and ringing tones to folders
in the gallery, or create folders of your own and
save them there. You can download images and
tones using MMS, xHTML, or Nokia PC Suite.
Note: This feature uses shared memory. Please see “Shared
memory” on page 13 for more information.
Note: Your phone must be switched on to use this function. Do not
switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
• OPEN THE GALLERY
At the Start screen, press Menu 7 (Gallery). After a brief pause, the
submenus in the following table appear in the display.
Option Function
View folders Explore the folders in the gallery menu. See “View
folders” in the following section for more info.
Add folder Add a folder of your own.
Delete folder Delete a folder you have created.
Rename folder Rename a folder you have created.
a
Gallery
downloads
a. The phone tries to connect to the Internet using your
xHTML browser and the currently active set of gallery
downloads. If the connection fails, you may need to acti-
vate another set or change the current settings. See “Set
up for browsing” on page 137 for more information.
Use the image and tone downloads in your phone;
see the following for more information.
DRAFT
[ 108 ]
•VIEW FOLDERS
1At the Start screen, press Menu 7 (Gallery), and then press Select.
2Scroll to View Folders and press Select.
A list of folders appear in the display.
3Scroll to a folder, such as Graphics or Tones and press Open.
4Scroll through the list of graphics or tones, and press Options. Press
Select to activate the option or to enter its submenu.
Option Function
Open Open the selected file.
Delete Delete the selected file.
Move Move the file to another folder.
Rename Rename the selected file.
Set as
wallpaper/Set
as ring tone
Set the graphic as wallpaper. In the Tones folder, this
option is Set as ringing tone; the tone is applied to
profile in use.
Details View details of the file, such as the name, time and date
the file was created.
Sort Sort the files according to date, type, name, or size.
DRAFT
[ 109 ]
Menu functions
Organizer (Menu 8)
Your phone has many useful features for
organizing your everyday life, including a calendar
and a to-do list.
Note: Your phone must be switched on to use this function. Do
not switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
•CALENDAR
The calendar keeps track of reminders, calls you need to make, meetings,
and birthdays. It can even sound an alarm for any of these events.
Note: This feature uses shared memory. Please see “Shared
memory” on page 13 for more information.
Open the calendar
• At the Start screen, press Menu 8-1 (Organizer
> Calendar).
After a brief pause, the Monthly view appears
in the display with the current date highlighted
by a black box.
Tip: To quickly open the calendar, press e
at the Start screen.
MONTHLY VIEW
Monthly view provides an overview of the selected month and weeks. It
also allows you to jump to a specific date. Any days or dates that appear
in bold font contain calendar notes such as a meeting or reminder.
DRAFT
[ 110 ]
USE FOUR-WAY SCROLLING
You can move the cursor in some calendar views using the
four-way scroll keys. To move the cursor:
Go to a date
1Press Menu 8-1 (Organizer > Calendar). After a brief pause, the
monthly view appears in the display.
2Press Options, scroll to Go to date, and press Select.
3Enter the date (for example 03/21/2003) and press OK. The monthly
view appears in the display with the “jump date” highlighted.
MAKE A NOTE FOR A SPECIFIC DATE
You can choose from five types of notes; Meeting, Call, Birthday, Memo,
and Reminder. Your phone asks for further information depending on
which note you choose. You also have the option to set an alarm for any
note that you select.
Note: This feature uses shared memory. Please see “Shared
memory” on page 13 for more information.
1Go to the date for which you want to set a reminder. See “Go to a
date” in the previous section if you need more information.
2From the monthly view (with the go to date highlighted),
press Options.
3Scroll to Make a note, and press Select.
4Scroll to one of the following note types and press Select
Left, press f Up, press d
Down, press g
Right, press e
Meeting
Call Birthday
Memo
Reminder
DRAFT
[ 111 ]
Menu functions
5Enter your note, press Options, scroll to Save, then press Select.
•For a Meeting note, you are prompted to enter a subject, location,
and then a start/end time (hh:mm). You are then given the option to
set an alarm.
•For a Call note, you are prompted to enter a phone number, a name,
and the time (hh:mm). You are then given the option to set an alarm.
•For a Birthday note, you are prompted to enter the person’s name and
year of birth. You are then given the option to set an alarm.
•For a Memo note, you are prompted to enter a subject and then an
end date. You are then given the option to set an alarm.
•For a Reminder note, you are prompted to enter the subject you wish
to be reminded about. You are then given the option to set an alarm.
View calendar notes - the Day view
After you have created some calendar notes, you can view them as
follows:
1At the Start screen, press Menu 8-1 (Organizer > Calendar).
After a brief pause, the monthly view appears in the display with the
current date highlighted. Any dates that contain calendar notes will
be in bold font.
2Use four-way scrolling to go to the date containing the note.
3Press Options, scroll to View day, and press Select. Any notes you
have for the day will appear in a list format.
4To view the body of a highlighted note, press Options, scroll to View
and press Select.
Options while viewing a list of notes
1Press Options while viewing the notes of a day to display those
options listed in the following table.
2Scroll to an option. Press Select to activate the option or to enter
its submenu.
DRAFT
[ 112 ]
*Indicates an option that is available only while viewing the body of
a note (not the header).
• SEND AND RECEIVE CALENDAR NOTES
Send a note via Infrared or text message
Note: If sending via IR (infrared), ensure the other device is set to
receive data via IR. For more information on enabling the receiving
device’s IR, refer to the user guide for the receiving device.
View View the full note.
Make a note Make another note for the selected date.
*Delete Delete the note.
*Edit Edit the note.
*Move Move the note to another date on your calendar.
*Repeat Enable the note to recur on a regular basis (daily,
weekly, bi-weekly, monthly, and yearly)
Go to date Jump to another date on your calendar
*Send note Send the note to another device via Infrared or as a text
message or in vCal format.
*Copy Copy the note. You can then paste the note to
another date.
*Settings
Set the date and time, date and time format, the day
each week starts, and whether you want your notes to
auto-delete after a specified time.
Go to
to-do list
Takes you to the to-do list for today’s date.
DRAFT
[ 113 ]
Menu functions
1At the Start screen, press Menu 8-1 (Organizer > Calendar). After a
brief pause, the monthly view appears in the display.
2Jump, or scroll to the date containing the note you wish to send.
Tip: Any days containing notes will be in bold font.
3Press Options, scroll to View day, and press Select.
4Scroll to the note you wish to send and press Options.
5Scroll to Send note and press Select.
6Scroll to Via Infrared, As note, or As text message, and press Select.
7If you selected Via Infrared, align the infrared ports of both devices
and press Select. The note is sent.
• If you selected As note, enter the number for the recipient
(or press Find to retrieve a number from your contacts list), and
press OK. The note is sent.
• If you selected As text message, the note appears in the display.
•Press Options, scroll to Send, and press Select.
• Enter the number for the recipient (or press Find to retrieve a
number from your contacts list), and press OK. The note is sent.
Receive calendar notes from another device
When you receive a calendar note, your phone displays Calendar note
received. You can then save the note in your calendar and set an alarm
for any date and time.
VIEW RECEIVED CALENDAR NOTES
1When your phone displays Calendar note received, press Show.
2The text of your note appears in the display. Use the scroll keys
to view the entire message, if necessary.
SAVE RECEIVED CALENDAR NOTES
1After viewing the Calendar note, press Options.
2Scroll to Save and press Select.
DRAFT
[ 114 ]
DISCARD VIEWED CALENDAR NOTES
1After viewing the calendar note, press Options.
2Scroll to Discard and press Select.
• MAKE A TO-DO LIST
Note: This feature uses shared memory. Please see “Shared
memory” on page 13 for more information.
You can keep track of your tasks with the to-do list feature. You may be
able to save up to 30 notes, depending on their length.
Note: To-do notes are not related to specific dates.
Add a to-do note
1At the Start screen, press Menu 8-2 (Organizer > To-do list).
2After a brief pause, press Options. If this is your first time to use the
to-do list, Add is highlighted. You can also go to the calendar.
3Press Select, enter your to-do note and press Options.
4Scroll to Save and press Select.
5Scroll to High, Medium, or Low priority and press Select. The to-do
note is saved.
Options while viewing notes
Press Options while viewing the header or body of a particular note and
the following options appear in the display:
DRAFT
[ 115 ]
Menu functions
Header view
options
Function Body view
options
Function
View View the body of a
note.
Edit Edit the content of a
note.
Add Add another note. Deadline Set a deadline for
the note.
Delete Delete the note. Mark note
as done
Mark a note or task
as complete; no
more reminders will
follow.
Sort by
deadline
Sort the notes
according to their
deadline.
Delete Delete the note.
Send Send the note as a
text message.
Edit priority Change the priority
to high, medium, or
low.
Go to
calendar
Leave the to-do list
and go to the
calendar.
Send Send the note as a
text message.
Save to
calendar
Save the to-do note
to a date on your
calendar.
Go to
calendar
Leave the to-do list
and go to the
calendar.
NA NA Save to
calendar
Save the to-do note
to a date on your
calendar.
DRAFT
[ 116 ]
Games (Menu 9)
Not only can you use your phone for
communication, but also for some serious fun. Your
phone offers multiple games from which to choose.
Note: Your phone must be switched on to
use this function. Do not switch the phone on when wireless
phone use is prohibited or when it may cause interference or
danger.
• LAUNCH A GAME
1At the Start screen, press Menu 9 (Games). After a brief pause, the
following list of game submenus appear in the display:
Note: Some menus listed in the following table are network
dependent. Contact your wireless provider for more information.
2Scroll to a submenu. Press Select to enter the submenu and choose
other settings.
Submenu Function
Select game Select a game or enter a game option list. See “Game
options” on page 117 for more info on game options.
Game
downloads
Connect to game downloads on the Internet using your
xHTML browser.
Memory Check the available memory for games and game
related applications.
Settings Turn game sounds, lights, and shakes on or off.
DRAFT
[ 117 ]
Menu functions
Play a game
1Press Menu 9-1 (Games > Select game). After a brief pause, a list of
games appears in the display.
2Scroll to a game and press h.
If the selection is a single game it will launch. Otherwise, a list of
games within the selected game set appears in the display. To launch
a single game, scroll to the desired game and press h.
3Choose one of the following options on the game submenu and press
Select:
• Choose New game to begin playing a new game.
• Choose High score to view previous high scores.
• Choose Instructions to get instructions for playing the game.
Tip: If a game uses the whole display area, selection keys such as
Options or Back will not appear in the display. Press e to show the
options keys Select or Back (returns to the game).
Game options
• While viewing the games list, press Options to display those listed in
the following table. Scroll to an option and press Select to activate
the option or enter its submenu.
Option Function
Open Play the game.
Delete Delete the game.
Web access Options for restricting network access.
Check version Display the version of the highlighted game.
Details Display details of the game.
DRAFT
[ 118 ]
Applications (Menu 10)
With the applications menu you can manage the
Java applications installed on your phone, or those
that may be offered by your wireless provider.
Note: The phone must be switched on to use
this function. Do not switch on the phone when the use of a
wireless phone is prohibited or when it may cause interference or
danger.
Note: This feature uses shared memory. Please see “Shared
memory” on page 13 for more information.
• LAUNCH AN APPLICATION
1At the Start screen, press Menu 10-1 (Applications > Select
application). After a brief pause, one or more applications appear in
the display.
2Scroll to an application or an application set and press Options, or
press h.
3If the selection is a single application it will be launched. Otherwise,
a list of applications in the selected application set is displayed.
• To launch a single application within the set, scroll to the desired
application and press Options, then press Select or h.
Application options
While viewing the applications list, press Options to display those listed
in the following table. Scroll to an option and press Select to activate the
option or enter its submenu.
DRAFT
[ 119 ]
Menu functions
• DOWNLOAD APPLICATIONS
You can download new Java applications in different ways.
Use application downloads
1At the Start screen, press Menu 10-2 (Applications > App.
downloads). After a brief pause, the list of available xHTML
bookmarks appears in the display.
Note: This feature is network dependent. Contact your wireless
provider for more information.
2Scroll to More bookmarks (if necessary) and press Select to access
the list of xHTML bookmarks in your Services menu.
3Scroll to the appropriate bookmark that contains the application you
wish to download, and press Select to connect to the xHTML page.
Option Function
Open Opens the selected application or application set.
Delete Delete the application or application set from
your phone.
Web access Provides options for restricting network access:
Ask first (ask for network access)
Allowed (allow network access)
Not allowed (to not allow network access)
Check version Check if a new version of the application is available
for download.
Web page Provides further information or data for the
application from an Internet page; This feature is
network dependent, and only appears if an Internet
address has been provided with the application.
Details Shows additional information about the application.
DRAFT
[ 120 ]
See “Navigate the wireless Internet” on page 138 for information on
browsing xHTML pages.
Use game downloads
• At the Start screen, press Menu 9-2 (Games > Game services). After
a brief pause, your phone connects to the xHTML pages using the
currently active set of xHTML settings.
Note: If the connection fails, you may enter the Services menu and
activate another set of service settings. See “Use browser options”
on page 137 for more info on browser settings.
Use PC Suite
Use the Nokia Application Installer from PC Suite to install Java
applications from the PC to the phone. For more information on PC Suite,
see “Nokia PC Suite” on page 135.
Note: Nokia does not warrant for applications from non-Nokia
sites. If you choose to download Java applications from non-Nokia
sites, take precautions for security or content.
Note: When you download a game or an application, it may be
saved in the Games menu instead of the Applications menu.
• VIEW APPLICATION MEMORY STATUS
You can view the size of memory available for game and application
installations.
• At the Start screen, press Menu 10-3 (Applications > Memory). After
a brief pause, the amount of free memory appears in the display.
DRAFT
[ 121 ]
Menu functions
Extras (Menu 11)
With the Extras menu you can manage the
calculator, voice recorder, voice commands, and
synchronization features installed on your phone,
or those that may be offered by your wireless
provider.
• USE THE CALCULATOR
The calculator in your phone adds, subtracts, multiplies, divides, counts
the square and the square root, and converts currency values.
Note: Your phone must be switched on to use this function. Do not
switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
Note: Calculator has a limited accuracy and rounding errors may
occur, especially in long division.
1Press Menu 11-1 (Extras > Calculator). After a brief pause, the
calculator screen appears in the display.
2Enter the first number in the calculation. Press
p
for a decimal point
if necessary.
3Press
s
repeatedly to cycle through the add (+), subtract (-), multiply
(*), and divide (/) characters. Pause briefly to select the currently
displayed character.
Note: To perform a square or square root calculation, press
Options, scroll to Square or Square root and press Select.
4Enter the second number in your calculation.
5Press Options. The equal sign is highlighted. Press Select. The result
of your calculation appears in the display.
DRAFT
[ 122 ]
• USE THE CURRENCY CONVERTER
You can convert foreign currency to domestic, or vice versa directly from
the Start screen.
1At the Start screen, enter a currency amount to convert.
2Press Options, scroll to one of the following and press Select:
If you have not done so already, you are prompted to enter the
exchange rate.
3Enter the exchange rate and press OK. Press
p
to insert a decimal.
The converted amount appears in the display.
EDIT THE EXCHANGE RATE
1At the Start screen, press Menu 11-1 (Extras > Calculator). After a
brief pause, the calculator screen appears in the display.
2Press Options (Exchange rate is highlighted), then press Select and
scroll to one of the following options:
3Press Select to edit your choice.
4Enter the exchange rate and press OK. The exchange rate is saved.
To home Converts foreign currency to domestic currency
To foreign Converts domestic currency to foreign currency
Foreign units in home
units
Enter the number of home units it takes to
make one unit of foreign currency
Home units in foreign
units
Enter the number of foreign units it takes
to make one unit of your home currency
DRAFT
[ 123 ]
Menu functions
• VOICE RECORDER
This feature allows you to record pieces of speech or sound with your
phone and listen to them later. You can record information such as phone
numbers and personal memos, but the voice recorder can also record an
active phone conversation. The total available time is 90 seconds if no
memos have been stored. The maximum length of a recording depends on
how much memory remains available. The length of time remaining for a
current recording will be displayed on your phone screen.
Note: Obey all applicable laws governing recording of calls. Do not
use this feature illegally.
Record speech or sound
1Press Menu 11-2 (Extras > Voice recorder)
2After the recorder start tone is heard, begin recording speech or
sound.
3When you finish recording, select the Stop option.
4Enter the title you wish to assign to the recording.
Record while in a call
1While in a call, press Options, then select Record.
2After the recorder start tone is heard, the recorder begins recording
the phone conversation. Also, the recorder recording tone will play
every 5 seconds to remind the other person on the call that the
conversation is being recorded.
3When recording is done, select the Stop option.
View recording list and play recordings
1You can view saved recordings by selecting the Recording list option.
Press Menu 11-2-2 (Extras > Voice recorder > Recordings list).
2Once you are in the Recordings list, select the recording you would
like to play, press Options, then select Playback. You can end the
playback by selecting Stop.
DRAFT
[ 124 ]
Delete a recording
From the Recording list menu, select the recording you want to erase,
press Options then select Delete.
Edit a recording title
To change the title of a recording, go to the Recording list option, select
a recording, then select Options and choose Edit title.
Setting the voice memo alarm
You can attach an alarm to a recording by going to the Recording list
option, selecting a recording, and selecting Add alarm.
• VOICE COMMANDS
The voice command feature allows handsfree operation of certain phone
features. Voice commands work similar to voice dialing. Before using voice
commands, you must first associate a “voice tag” to the phone function.
You can set as many as 5 voice commands.
View available functions
Press Menu 11-3 (Extras > Voice commands) and scroll through the list
of functions.
Phone feature Feature options
Profiles Normal, Silent, Meeting, Outdoor, and Pager
Voice mailbox Check your voice messages.
Radio Radio on, Radio off, Next channel, and Previous channel
Infrared Activate infrared.
Recorder Record speech or sound.
Audible alerts Audible battery bar and Audible signal bar
DRAFT
[ 125 ]
Menu functions
Add a voice tag for the command
1Press Menu 11- 3 (Extras > Voice commands)
2Scroll to the phone function you wish to tag, then press Select.
3Press Options, then select Add command.
4Press Start, then speak the voice tag clearly into the microphone.
Note: Do NOT press Quit unless you want to cancel the recording.
The phone replays and then saves the recorded tag. The icon appears
next to commands which have voice tags assigned.
Activate a voice command
After you have associated a voice tag with a phone function, you can issue
a command by speaking the voice tag. There are three ways to activate a
voice command:
1If you have the optional headset attached, press and hold the headset
button.
OR
• Press and hold Contacts.
OR
• Press and hold the volume down key.
2When Please speak now appears, pronounce the voice tag clearly into
the microphone. When the phone finds the tag, Found appears, and
the phone plays the recognized voice tag from the phone memory
through the earpiece.
Work with an existing voice command
After you have associated a voice tag to a command, you can choose one
of the following options:
• Select Playback to listen to the voice command tag.
• Select Change to change the voice command.
• Select Delete to erase the voice command tag.
DRAFT
[ 126 ]
• AUDIBLE ALERTS
Audible alerts provide you with the current signal bar or battery bar
strength of your phone.
Note: In order to obtain audible alerts, the alerts must first be set
up as voice commands. To set up voice commands, see “View
available functions” on page 124 and “Add a voice tag for the
command” on page 125.
Set up audible alerts
1If you have the optional headset attached, press and hold the headset
button.
OR
• Press and hold Contacts.
OR
• Press and hold the volume down key.
2When Please speak now appears, pronounce the voice tag clearly into
the microphone. When the phone finds the tag, Found appears, and
the phone plays the recognized voice tag from the phone memory
through the earpiece.
The phone then beeps, according to the strengths indicated in the
following table (and according to which voice command has been
activated):
Audible Alert One Beep Two Beeps Three beeps Four Beeps
Battery Bar
Strength
Low Half-full Almost full Full
Signal Bar
Strength
Weak Somewhat
strong
Almost
strong
Strong
DRAFT
[ 127 ]
Menu functions
Connectivity (Menu 12)
You can make a serial connection between your
phone and a PC using the DKU-5 data cable, which
is available for purchase as an enhancement. Once
you establish this connection, you can access phone
information from your PC, or use your phone as a
wireless modem. It may also be possible to make this same serial
connection between your phone and an Infrared-equipped laptop or IR-
equipped desktop PC using the infrared port of your phone.
Note: Your phone must be switched on to use this function. Do
not switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
•INFRARED
You can set up the phone to receive data through its infrared (IR) port. To
use an IR connection, transmission and reception must be to or from an
infrared compatible phone or device. You can send or receive data such as
business cards and calendar notes to or from a compatible phone or data
device (such as a computer) through the IR port of your phone.
Important: Do not point the IR (infrared) beam at anyone's eye or
allow it to interfere with other IR devices.
SEND AND RECEIVE DATA USING IR
• Ensure that the IR ports of the
sending and receiving devices are
pointing at each other and that there
are no obstructions between the
devices. The preferable distance
between the two devices in an
infrared connection is from 3 inches
to 3 feet.
3 ft. maximum
distance
DRAFT
[ 128 ]
• Activate IR in your phone by pressing Menu 12-1 (Connectivity >
Infrared) at the Start screen.
• The user of the other device should activate IR as well.
If data transfer is not started within two minutes after the activation of
the IR port, the connection is cancelled and has to be started again.
IR CONNECTION INDICATOR
• When is shown continuously, the IR connection is activated and
your phone is ready to send or receive data through its IR port.
• When blinks, your phone is trying to connect to the other device
or a connection has been lost.
Using data communication applications
For information on using a data communication application, refer to the
documentation provided with the application.
If you use an IR connection:
• Activate the IR connection in your phone by pressing Menu 12-1
(Connectivity > Infrared). Also, make sure that the connection is
active in your PC.
If you use the DKU-5 data cable:
1Connect the cable to the USB port on the back of your computer and
to the connector on your phone.
2Start using the data communications application on the computer.
Note: Making or answering phone calls during a computer
connection is not recommended as it might disrupt the operation.
• For better performance during data calls, place the phone on a
stationary surface with the keypad facing downward. Do not move
the phone by holding it in your hand during a data call.
DRAFT
[ 129 ]
Menu functions
•(E)GPRS
Enhanced General Packet Radio Service or (E)GPRS is a technology used
to send and receive data in short bursts or packets over the wireless
network. With (E)GPRS, you can stay connected to the Internet and allow
faster downloads without completing a dial-up connection. Applications
using (E)GPRS include the xHTML browser, text messaging, and dial-up
connections for making digital data calls.
Enhanced General Packet Radio Service or (E)GPRS may also be available.
(E)GPRS works just like GPRS, but the connection is roughly 2-3 times
faster.
Note: In order to use (E)GPRS for dial-up connections, you must
first subscribe to the (E)GPRS network service. Contact your
service provider for details on pricing and availability.
Some service providers may have already set up information for
your (E)GPRS dial-up connection.
(E)GPRS dial-up connections
When you use your Nokia phone as a wireless modem, you have the option
of enabling (E)GPRS connectivity from your PC or laptop computer.
For more information, see the Nokia PC Suite and PC/PDA Connectivity
Guide. This document can be downloaded from the Nokia website at
http://www.nokia.com/us.
(E)GPRS icons
The following icons appear on the screen to show you the status of your
(E)GPRS connection.
Appears in the upper left corner of the screen. Indicates an
active (E)GPRS connection, for example, when you are using
the xHTML browser.
DRAFT
[ 130 ]
Set up an automatic connection
Some service providers may have customized the options on the Services
menu. Contact your service provider for more information if the options
shown here are not available.
Important: (E)GPRS may not be available in all wireless networks.
The establishment and continuation of a (E)GPRS and Internet
connection depends on network availability, service provider
support, and signal strength.
You can choose one of the following options for your (E)GPRS connection.
1At the Start screen, press Menu 12-2-1 (Connectivity > GPRS >
GPRS connection). After a brief pause, the following options appear
in the display.
2Scroll to an option and press Select to activate the option.
•When needed—the (E)GPRS connection is established when you use
the xHTML browser and is closed when you exit the xHTML browser.
•Always online—the phone is automatically registered to a (E)GPRS
network when you turn your phone on. When you use the xHTML
browser, the connection between your phone and the network is
created and data transfer is possible. When you exit the xHTML
browser, the (E)GPRS connection ends but the registration to the
(E)GPRS network remains.
Appears in the upper left corner of the screen. Indicates you
are registered to a (E)GPRS network but the (E)GPRS
connection is not currently active.
Indicates that circuit switched (CS) or voice calls are not
possible when using (E)GPRS.
Indicates that the (E)GPRS connection has been interrupted
by a voice call.
DRAFT
[ 131 ]
Menu functions
Receive a call while online
If you are using the xHTML browser over (E)GPRS, you can still receive a
voice call. Your data call is put on hold and you can choose to answer the
call.
• To answer the incoming call, press h.
• To reject the incoming call, press i.
Note: After you end your voice call, the (E)GPRS connection
automatically resumes.
Make a call while online
When you are browsing an xHTML page and want to make a call, you can
select Use number. Your phone searches the information on the xHTML
page for a string of numbers. You then choose from the number or
numbers displayed to place the call.
An alternate way is to press i to disconnect from the Internet, then
place your call by searching the contacts list for a name and number or
by keying in the phone number.
Make an emergency call while online
If you are using (E)GPRS to connect to the Internet, you can end your data
connection and then make an emergency call.
1To close your Internet connection, simply press i.
2Enter the emergency number for your present location (for example,
911 or any other official emergency number—emergency numbers
vary by location).
3Press h.
• SYNCHRONIZE
You can synchronize the calendar and contacts list data in your phone
with a remote Internet server or a compatible PC.
Note: The contacts list in your SIM card will not be synchronized.
DRAFT
[ 132 ]
Note: This feature must be supported by your wireless service
provider. For more information on availability and synchronization
service settings, contact your service provider.
Save synchronization settings
You may receive the synchronization settings as a text message or may
need to enter the synchronization settings manually. If you do not receive
the synchronization setting as a text message, see “Save settings
manually” below for more information.
SAVE SETTINGS WHEN RECEIVED AS A TEXT MESSAGE
When you receive the synchronization settings as a text message,
Synchronization settings received is displayed.
•Press Options and select:
•Details to view the received settings first.
•Save to save the synchronization settings.
•Discard to discard the synchronization settings.
SAVE SETTINGS MANUALLY
You need to activate the set where you want to save the synchronization
settings. A set is a collection of settings required to make a connection to
a service.
1At the Start screen, press Menu 12-3-2-1 (Connectivity >
Synchronize > Settings > Active synch. settings).
2Scroll to the set you wish to activate and press Activate.
Select Custom. active Internet sync. settings. Select each setting
from the following table and key in the required settings.
Settings name Rename the synchronization setting and press OK.
Data to be
synchronized
Select All (phone book and calendar), Phone book,
or Calendar and press Done.
DRAFT
[ 133 ]
Menu functions
Synchronize from your phone
If you have saved data in the remote Internet server, you can synchronize
your phone by starting the synchronization from your phone. Once you
have customized and selected the appropriate synchronization settings,
you are ready to synchronize data. (See “Save synchronization settings”
on page 132 or “Save settings manually” on page 132 for more
information.)
1At the Start screen, press Menu 13-5-1 (Services > Settings >
Active service settings). Select the connection settings you need for
synchronization.
Note: The synchronization settings may differ from the service
settings required for xHTML browsing. After synchronizing, change
your Active service settings back to the previous ones if you want
to use other xHTML services later.
2Mark the data to be synchronized. (See “Save settings manually” on
page 132 for more information.)
3At the Start screen, press Menu 12-3-1 (Connectivity > Synchronize
> Synchronize). Synchronization begins.
Database addresses Select Phone book database and/or Calendar
database, key in the name of the database, and
press OK.
User name Key in the user name and press OK. (Contact your
service provider, if necessary, for this
information.)
Password Key in the password and press OK. (Contact your
service provider, if necessary, for this
information.)
Synchronization
server
Key in the name of the server and press OK.
DRAFT
[ 134 ]
Depending on the type of connection you are using to synchronize
data, connecting or initializing messages may appear.
Note: Synchronizing for the first time or after an interrupted
synchronization may take time up to 30 minutes, if the contacts
list or calendar are full.
STOP SYNCHRONIZATION
1To stop synchronization press Quit or i. The Quit synchronization?
message appears.
2Press OK.
HANDLING CALLS DURING SYNCHRONIZATION
During synchronization, outgoing calls are not possible. Incoming calls
can still be received, and can be handled in one of the following ways:
• To reject the incoming call, press i (synchronization continues)
• To answer the incoming call, press h (synchronization is
interrupted and a Synchronization suspended message appears)
Note: Once the incoming call is ended, a Start synchronization
again? message appears. Selecting Yes starts synchronization over
again, from the beginning.
Synchronize from your PC
You can synchronize the data in your phone’s contact list and calendar to
correspond with the data of your PC by starting the synchronization from
your PC.
To synchronize the contact list and calendar from your PC, use either an
IR connection or a data cable. You also need the PC Suite software of your
(See “Nokia PC Suite” in the next section for details.)
Start the synchronization from your PC using PC suite. After
synchronizing, the data in the phone and in the PC are the same.
DRAFT
[ 135 ]
Menu functions
• NOKIA PC SUITE
Once your phone is connected to your PC, you can use the following
features of Nokia PC Suite:
•Nokia Application Installer allows you to install Java applications
from your PC to your phone.
•Nokia Image Converter allows you to convert and optimize graphics
for use in MMS messages or for creating desktop wallpaper for your
phone.
•Nokia Sound Converter allows you to convert General MIDI files for
use with MMS messages and as ringing tones for your phone.
•Nokia Content Copier allows you to copy data between two Nokia
phones, backup your phone’s data to your PC (then restore the data
back to your phone), and erase data from your phone.
•Nokia Connection Manager allows you to monitor the serial
connection between your phone and PC and switch to a different type
of connection (cable, IR, Bluetooth) when copying data from one
phone to another.
•Nokia Phone Editor allows you to edit your phone book and settings
from your PC.
•Nokia PC Sync allows you to synchronize contacts, calendar, and to-
do list items between your phone and PIM applications such as
Microsoft Outlook and Lotus Organizer.
•Nokia Phone Browser allows you to browse the contents of your
phone using Windows Explorer or My Computer.
•Nokia WAP Manager allows you to manage WAP bookmarks and
settings.
For more information, refer to the Nokia PC Suite and PC/PDA Connectivity
Guide for installation and setup instructions.
Note: The Nokia PC Suite and PC/PDA Connectivity Guide, Nokia PC
Suite, and all related software can be downloaded from the U.S.
Mobile Phone products section of www.nokia.com/us.
DRAFT
[ 136 ]
Services (Menu 13)
Your phone has a built-in browser you can use to
connect to selected services on the Internet. You
can view weather reports, check news or flight
times, view financial information, and much more.
Note: This feature is network dependent.
Contact your wireless provider for more information.
Note: Your phone must be switched on to use this function. Do not
switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
• NOTES ON WIRELESS INTERNET ACCESS
This section gives a brief overview of wireless Internet technology.
Technology background
XHTML
A technology called HyperText Markup Language (xHTML) is to mobile
devices what the World Wide Web (WWW) is to personal computers.
xHTML is a relatively new development that provides access to the
Internet for mobile users.
Today, most xHTML sites are made up of text and hyperlinks. Some pages
even contain low-resolution graphics, or require data input. Your service
provider and others are free to design xHTML sites as they choose, so the
sites are as variable as Web pages on the Internet.
Internet content on your personal computer is called a “web page.”
Internet content on your mobile phone is called a “page,” or “xHTML card.”
The wireless provider’s role
Because wireless Internet content is designed to be viewed from your
phone, your wireless provider now becomes your “wireless Internet service
provider” as well.
DRAFT
[ 137 ]
Menu functions
Your wireless provider has probably created a home page and set up your
browser to go to this page when you log on to the Internet. Once at your
service provider’s home page, you may find links to a number of
other sites.
Set up for browsing
It should not be necessary to manually configure the browser on your
phone. Normally this is done by your wireless provider once you have
subscribed to the feature. Contact your wireless provider if you have
problems using the browser.
• SIGN ON TO THE WIRELESS INTERNET
Note: Your phone must be switched on to use this function. Do not
switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
•Press Menu 13-1 (Services > Home). After a brief pause, your phone
attempts to connect to your wireless provider’s home page.
OR
• At the Start screen, press and hold
0
.
Your phone connects to the Internet and to your service provider’s
home page.
If you see the Check service settings message, the phone may not be set
up for browsing. Contact your wireless provider to make sure that your
phone is configured properly.
• USE BROWSER OPTIONS
The Services menu gives you the options shown in the following table.
Some wireless providers may have customized the options on the Services
menu. Contact your wireless provider for more information if any of the
options shown in the following table are not available.
DRAFT
[ 138 ]
• NAVIGATE THE WIRELESS INTERNET
Since your phone screen is much smaller than a computer screen,
Internet content is displayed differently than you may be accustomed to
seeing. This section contains guidelines for using phone keys to navigate a
xHTML site and examples of how to read an xHTML site.
General guidelines for using the phone keys
• Use the four-way scroll keys to browse the xHTML site.
• To select a highlighted item, press h.
• To enter letters and numbers, press the keys
0
through 9.
• To enter special characters, press the
s
key.
Choice What it does
Home Starts the browser and takes you to your service
provider’s home page.
Bookmarks Shows a list of all saved bookmarks. Bookmarks help you
find an xHTML site quickly.
Download
links
Allows you to download content from pre-programmed
xHTML sites.
Service
inbox
Allows you to receive notifications from your service
provider about new e-mail messages, changes in stock
prices, and so on.
Settings Provides options for changing connection settings,
appearance settings, cookie settings, and certificates.
Go to
address
Accepts an address you enter.
Clear the
cache
Empties the browser’s temporary memory. It is advisable
to empty the cache at the end of each session.
DRAFT
[ 139 ]
Menu functions
Examples of wireless Internet sites
The following illustrations show most of the elements you may find on a
wireless Internet site. These are examples only.
1) Header line: shows the
current Internet site.
2) Active link: appears as a
highlighted word.
3) Inactive link: appears as an
underlined word.
Scroll through the list of links
using d or g.
4) Selection list: Brackets [ ]
appear when you have the
option to enter information.
5) Options: Press Options to
go to the site menu and/or
browser page.
6) Back: Press Back to return
to the previous page.
7) Data entry field: Brackets
[ ] that enclose dots indicate
when you need to enter
information. In this example,
you can enter your zip
code to receive the local
weather forecast.
1)
2)
3)
5) 6)
4)
7)
DRAFT
[ 140 ]
• USE BOOKMARKS
You can save addresses for your favorite sites as bookmarks. A bookmark
helps you find a site again, just as a slip of paper helps you find a page in
a book. You can add up to 30 bookmarks to your browser.
Set a bookmark while browsing
1Press Menu 13-2 (Services > Bookmarks). After a brief pause, a list
of bookmarks (if any) appear in the display.
2Press Options, scroll to New bookmark (if necessary), and
press Select.
3Enter an address for the bookmark and press OK.
4Enter a title for the bookmark and press OK. A message appears in the
display confirming your bookmark is saved.
Disconnect from the Internet
• To quit browsing and end the connection, press Options and select
Quit. When the Quit browsing? message appears, press Yes.
OR
•Press
i. If GSM data is the selected data bearer, then press i twice.
• SECURITY ISSUES
Note: The information or services you have accessed are stored in
the cache of your phone. A cache is a buffer memory, which is used
to store data temporarily. If you tried to access or have accessed
confidential information requiring passwords (for example, your
bank account), empty the cache of your phone after each use.
CLEAR THE CACHE
1Press Menu 13 (Services). After a brief pause, a list of options appear
in the display.
OR
If browsing, press Options.
DRAFT
[ 141 ]
Menu functions
2Scroll to Clear the cache and press Select.
About authority certificates
To use some xHTML services, such as banking services, you need an
authority certificate. Using the certificate can help you to improve the
security of connections between your phone and an xHTML server.
You can download the certificate from an xHTML page if the xHTML
service supports the use of authority certificates. After the download, you
can view the certificate, then save or delete it. If you save the certificate,
it is added to the list of certificates in the phone.
Your phone alerts you if the identity of the xHTML server or xHTML
gateway cannot be verified or is not authentic.
VIEW THE LIST OF AUTHORITY CERTIFICATES
1Press Menu 13-5-5-2 (Services > Settings > Certificates >
Authority Certificates). After a brief pause, a list of settings appears
in the display.
2Scroll to Certificate list and press Select. The list of authority
certificates is displayed.
DRAFT
[ 142 ]
9 Reference information
This section provides information about your phone’s batteries,
enhancements, chargers, safety guidelines, and technical information. Be
aware that the information in this section is subject to change as
batteries, chargers, and enhancements change.
Check the model number of any charger before use with this device. This
device is intended for use when supplied with power from ACP-12 and
LCH-9.
Warning: Use only batteries, charters, and enhancements that
have been approved by the phone manufacturer. The use of any
other types could invalidate any approval or warranty applying to
the phone and could be dangerous.
For availability of approved enhancements, please check with your
dealer.
• BATTERY STATEMENTS
Charging and Discharging
Your phone is powered by a rechargeable battery.
Note that a new battery's full performance may be achieved only after
two or three complete charge and discharge cycles!
The battery can be charged and discharged hundreds of times but it will
eventually wear out. When the operating time (talk time and standby
time) is noticeably shorter than normal, it is time to buy a new battery.
Use only batteries approved by the phone manufacturer and recharge
your battery only with the chargers approved by the manufacturer.
Unplug the charger when not in use. Do not leave the battery connected
to a charger for longer than a week, since overcharging may shorten its
lifetime. If left unused, a fully charged battery will discharge itself over
time.
DRAFT
[ 143 ]
Reference information
Temperature extremes can affect the ability of your battery to charge;
allow it to cool down or warm up first.
Use the battery only for its intended purpose.
Never use any charger or battery which is damaged or worn out.
Do not short-circuit the battery. Accidental short-circuiting can occur
when a metallic object (coin, clip, or pen) causes direct connection of the
+ and - terminals of the battery (metal strips on the battery), for example,
when you carry a spare battery in your pocket or purse. Short-circuiting
the terminals may damage the battery or the connecting object.
Leaving the battery in hot or cold places, such as in a closed car in summer
or winter conditions, will reduce the capacity and lifetime of the battery.
Always try to keep the battery between 59°F and 77°F (15°C and 25°C). A
phone with a hot or cold battery may temporarily not work, even when
the battery is fully charged. Batteries' performance is particularly limited
in temperatures well below freezing.
Do not dispose of batteries in a fire!
Dispose of batteries according to applicable local regulations (for
example, recycling). Do not dispose of as household waste.
• USE PROPER CARE AND MAINTENANCE
Your phone is a product of superior design and craftsmanship and should
be treated with care. The suggestions below will help you to fulfill any
warranty obligations and to enjoy this product for many years:
• Keep the phone and all its parts and enhancements out of the reach
of small children.
• Keep the phone dry. Precipitation, humidity and all types of liquids or
moisture can contain minerals that will corrode electronic circuits.
• Do not use or store the phone in dusty, dirty areas. Its moving parts
can be damaged.
• Do not store the phone in hot areas. High temperatures can shorten
the life of electronic devices, damage batteries, and warp or melt
certain plastics.
DRAFT
[ 144 ]
• Do not store the phone in cold areas. When it warms up (to its normal
temperature), moisture can form inside which may damage electronic
circuit boards.
• Do not attempt to open the phone. Nonexpert handling may damage
it.
• Do not drop, knock, or shake the phone. Rough handling can break
internal circuit boards.
• Do not use harsh chemicals, cleaning solvents, or strong detergents
to clean the phone.
• Do not paint the phone. Paint can clog the moving parts and prevent
proper operation.
• Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage
the phone and may violate regulations governing radio devices.
All of the above suggestions apply equally to your phone, battery, charger
or any enhancement. If any of them are not working properly, take them
to your nearest qualified service facility. The personnel there will assist
you, and if necessary, arrange for service.
• UNDERSTAND IMPORTANT SAFETY INFORMATION
Traffic Safety
Do not use a handheld telephone while driving a vehicle. Always secure
the phone in its holder; do not place the phone on the passenger seat or
where it can break loose in a collision or sudden stop.
Remember road safety always comes first!
Operating environment
Remember to follow any special regulations in force in any area and
always switch off your phone whenever it is forbidden to use it, or when
it may cause interference or danger.
Use the phone only in its normal operating positions.
DRAFT
[ 145 ]
Reference information
Electronic devices
Most modern electronic equipment is shielded from radio frequency (RF)
signals. However, certain electronic equipment may not be shielded
against the RF signals from your wireless phone.
PACEMAKERS
Pacemaker manufacturers recommend that a minimum separation of 6
inches (20 cm) be maintained between a handheld wireless phone and a
pacemaker to avoid potential interference with the pacemaker. These
recommendations are consistent with the independent research by and
recommendations of Wireless Technology Research. Persons with
pacemakers:
• Should always keep the phone more than 6 inches (20 cm) from their
pacemaker when the phone is switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to minimize the potential
for interference.
• If you have any reason to suspect that interference is taking place,
switch off your phone immediately.
HEARING AIDS
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your service provider.
Other medical devices
Operation of any radio transmitting equipment, including cellular phones,
may interfere with the functionality of inadequately protected medical
devices. Consult a physician or the manufacturer of the medical device to
determine if they are adequately shielded from external RF energy or if
you have any questions. Switch off your phone in health care facilities
when any regulations posted in these areas instruct you to do so.
Hospitals or health care facilities may be using equipment that could be
sensitive to external RF energy.
DRAFT
[ 146 ]
Vehicles
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles (for example, electronic fuel
injection systems, electronic antiskid/antilock braking systems, electronic
speed control systems, air bag systems). Check with the manufacturer or
its representative regarding your vehicle. You should also consult the
manufacturer of any equipment that has been added to your vehicle.
Posted facilities
Switch your phone off in any facility where posted notices so require.
Potentially explosive atmospheres
Switch off your phone when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas could
cause an explosion or fire resulting in bodily injury or even death.
Users are advised to switch off the phone when at a refueling point
(service station). Users are reminded of the need to observe restrictions on
the use of radio equipment in fuel depots (fuel storage and distribution
areas), chemical plants, or where blasting operations are in progress.
Areas with a potentially explosive atmosphere are often but not always
clearly marked. They include below deck on boats; chemical transfer or
storage facilities; vehicles using liquefied petroleum gas (such as propane
or butane); areas where the air contains chemicals or particles, such as
grain, dust, or metal powders; and any other area where you would
normally be advised to turn off your vehicle engine.
Vehicles
Only qualified personnel should service the phone or install the phone in
a vehicle. Faulty installation or service may be dangerous and may
invalidate any warranty which may apply to the unit.
Check regularly that all wireless phone equipment in your vehicle is
mounted and operating properly.
Do not store or carry flammable liquids, gases, or explosive materials in
the same compartment as the phone, its parts, or enhancements.
DRAFT
[ 147 ]
Reference information
For vehicles equipped with an air bag, remember that an air bag inflates
with great force. Do not place objects, including both installed or portable
wireless equipment in the area over the air bag or in the air bag
deployment area. If in-vehicle wireless equipment is improperly installed
and the air bag inflates, serious injury could result.
FCC regulations prohibit using your phone while in the air. Switch off your
phone before boarding an aircraft. The use of wireless telephones in an
aircraft may be dangerous to the operation of the aircraft, disrupt the
wireless telephone network, and may be illegal.
Failure to observe these instructions may lead to suspension or denial of
telephone services to the offender, legal action, or both.
• EMERGENCY CALLS
Important: This phone, like any wireless phone, operates using
radio signals, wireless, and landline networks as well as user-
programmed functions. Because of this, connections in all
conditions cannot be guaranteed. Therefore you should never rely
solely upon any wireless phone for essential communications (for
example, medical emergencies).
Emergency calls may not be possible on all wireless phone networks or
when certain network services and/or phone features are in use. Check
with local service providers.
To make an emergency call:
1If the phone is not on, switch it on. Check for adequate signal
strength.
Note: Some networks may require that a valid SIM card is properly
inserted in the phone.
2Press i as many times as needed (for example, to exit a call, to exit
a menu, etc.) to clear the display and ready the phone for calls.
3Key in the emergency number for your present location (for example,
911 or other official emergency number). Emergency numbers vary by
location.
DRAFT
[ 148 ]
4Press the h key.
If certain features are in use, you may first need to turn those features off
before you can make an emergency call. Consult this user guide and your
local cellular service provider.
When making an emergency call, remember to give all the necessary
information as accurately as possible. Remember that your wireless phone
may be the only means of communication at the scene of an accident -
do not end the call until given permission to do so.
• CERTIFICATION INFORMATION
THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of
the U.S. Government. These limits are part of comprehensive guidelines
and establish permitted levels of RF energy for the general population. The
guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of
scientific studies. The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6W/kg.* Tests for SAR are conducted using
standard operating positions accepted by the FCC with the phone
transmitting at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest certified power
level, the actual SAR level of the phone while operating can be well below
the maximum value. This is because the phone is designed to operate at
multiple power levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base station antenna,
the lower the power output.
DRAFT
[ 149 ]
Reference information
Before a phone model is available for sale to the public, it must be tested
and certified to the FCC that it does not exceed the limit established by
the government-adopted requirement for safe exposure. The tests are
performed in positions and locations (for example, at the ear and worn on
the body) as required by the FCC for each model. The highest SAR value
for this model phone as reported to the FCC when tested for use at the
ear is 0.91 W/kg, and when worn on the body, as described in this user
guide, is 0.77 W/kg. (Body-worn measurements differ among phone
models, depending upon available enhancements and FCC requirements).
While there may be differences between the SAR levels of various phones
and at various positions, they all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this model phone is on file
with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID LJP NPL-3.
For body worn operation, this phone has been tested and meets the FCC
RF exposure guidelines for use with an enhancement that contains no
metal and that positions the handset a minimum of 7/8 inch (2.2 cm) from
the body. Use of other enhancements may not ensure compliance with
FCC RF exposure guidelines. If you do not use a body-worn enhancement
and are not holding the phone at the ear, position the handset a minimum
of 7/8 inch (2.2 cm) from your body when the phone is switched on.
*In the United States and Canada, the SAR limit for mobile phones used
by the public is 1.6 watts/kilogram (W/kg) averaged over one gram of
tissue. The standard incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in
measurements. SAR values may vary depending on national reporting
requirements and the network band. For SAR information in other regions
please look under product information at http://www.nokia.com/us.
DRAFT
[ 150 ]
• BATTERY INFORMATION
This section provides information about the phone’s battery. Be aware
that the information in this section is subject to change.
Note: Dispose of used batteries in accordance with any local
regulations.
The tables shown in this section provide information about battery options
that are available for your phone, charging times with the Travel Charger
(ACP-12), the Rapid Travel Charger (ACP-8), the Standard Travel Charger
(ACP-7), talk times, and standby times. Consult your service provider for
more information.
Charging times
The following charging times are approximate:
Talk and standby times
Operation times are estimates only and depend on signal strength, phone
use, network conditions, features used, battery age and condition
(including the effect of charging habits), temperatures to which the
battery is exposed, and many other factors. The amount of time a phone
is used for calls will affect its standby time. Likewise, the amount of time
that the phone is turned on and in standby mode will affect its talk time.
Charger Options ACP-12 ACP-8 ACP-7
BLD-3 780 mAh Li-Ion battery Up to 1.5 h Up to 2 h Up to 3 h
Talk/Standby Time 850 1800 1900
Talk time 2.5 h 4 h 3.5 h
Talk time with Speakerphone 2 h 2.5 h 3 h
Radio and Headset standby time 28.5 h
Radio and Speakerphone standby time 6.4 h
Standby time 18 d
DRAFT
[ 151 ]
Reference information
• ENHANCEMENTS
If you want to enhance your phone’s functionality, a
range of enhancements is available for you. You can
select any of these items to help accommodate your
specific communication needs.
Use enhancements safely
A few practical rules for enhancement operation:
• Keep all enhancements out of the reach of small children.
• When you disconnect the power cord of any enhancement, grasp and
pull the plug, not the cord.
• Check regularly that any vehicle-installed enhancements are
mounted and are operating properly.
• Installation of any complex car enhancements must be made by
qualified personnel only.
• Use only batteries, charters, and enhancements that have been
approved by the phone manufacturer. The use of any other types
could invalidate any approval or warranty applying to the phone and
could be dangerous.
780 mAh Li-Ion Battery (BLD-3)
Provides up to 4 hours of talk time and up to 3 hours of
talk time with the speakerphone.
For information on the phone’s battery (including talk,
standby, and charging times), see “Battery information”
on page 150.
DRAFT
[ 152 ]
Mobile Charger (LCH-12)
The mobile charger quickly charges the phone
battery from your vehicle.
Also available:
Rapid Cigarette Lighter Charger (LCH-9)
Travel Charger (ACP-12)
This lightweight ac charger can be used with all battery
options. To use the charger, plug it into a standard 120V ac
wall outlet, and connect the lead from the charger to the
base of your phone. Calls can be made during charging, even
with a fully discharged battery.
Also available:
Standard Travel Charger (ACP-7)
Rapid Travel Charger (ACP-8)
Headset Kit (HDB-4)
New over-the-ear design concept boom headset is small,
lightweight, and provides excellent audio quality.
Also available:
Stereo Headset (HDS-3)
Headset (HS-5)
DRAFT
[ 153 ]
Reference information
Camera Headset
(HS-1C)
The camera headset
allows you to take
single-shot pictures
from a small camera
which is mounted on the headset. The camera is powered by the Pop-
port
TM
connector on the bottom of your phone, and you use the functions
in your phone to store, send, or delete pictures. The microphone on the
camera and the answer/end button on the headset allow you to
conveniently use your phone while snapping pictures.
Loopset (LPS-4)
With the Nokia Loopset, people who use a -Toil equipped
hearing aid have the freedom to talk on a digital mobile
phone. The loopset goes around your neck—so it can be worn
comfortably and discreetly.
Data Cable (DKU-5)
For e-mail, faxes, Internet and data
transmissions. Easy and convenient
connection with no modem or PC
card needed.
TTY/TDD Adapter (HDA-10)
The TTY/TDD adapter is a Nokia enhancement
that allows you to connect your mobile
phone to a Telecommunications Device for
the Deaf (TTY/TDD) to make a call in digital
mode.
DRAFT
[ 154 ]
Complete Car Kit (CARK-143)
The Complete Car Kit is a complete hands-
free solution for your vehicle.
Also available:
Handsfree Headrest (BHF-1)
Mobile Holder (MBC-15S)
RF-Coupler (AXF-15S)
Connectivity Desk Stand
(DCV-14)
The desktop charging stand is an economical
choice when you need your phone close at
hand, always ready for calls.
Also available:
Battery Charging Stand (DDC-1)
Music Stand (DT-1)
The music stand is a
convenient way to listen to the
radio or speaker in your phone.
The music stand has two, full-
range speakers and a built-in
stereo amplifier. The
microphone, answer/end
button, and volume control key
all enhance the convenience
and handsfree method of using
your Nokia phone. The music
stand also has a built-in charger.
DRAFT
[ 155 ]
Reference information
• FREQUENTLY ASKED QUESTIONS
This section lists answers to the most frequently asked questions. Some of
the answers contain menu shortcuts. For a list of shortcuts, see “Menu
shortcuts” on page 15.
Q. What is my security code?
A. The default security code is 12345. However, Nokia recommends that
you change this code immediately. Certain features can be used only
after the correct security code has been successfully entered.
Q. How do I lock and unlock the keypad?
A. Lock the keypad by pressing Menu
s
. To unlock the keypad, press
Unlock
s
.
Q. How do I make the phone ring louder?
A. Press Menu 3 (Profiles), and scroll through the list of profiles until
you find the one for which you want to set the ringing volume. Then
press Select.
• Scroll to Customize and press Select.
• Scroll to Ringing volume and press Select.
• Scroll to the volume level of your preference and press Select.
Q. How do I change the ringing tone?
A. Press Menu 3 (Profiles) and scroll through the list of profiles until
you find the one for which you want to set the ringing tone. Then
press Select.
• Scroll to Customize and press Select.
• Scroll to Ringing tone, and then press Select.
• Scroll through the options. After you hear the tone you want to
use, press Select.
DRAFT
[ 156 ]
Q. How do I store my voice mailbox number?
A. Press Menu 01-3-2 (Messages > Voice messages > Voice mailbox
number). Enter your voice mailbox phone number, and press OK.
Q. How do I call my voice mailbox number (retrieve voice messages)?
A. When your phone alerts you to new voice messages, press Listen and
follow the instructions on the phone. If you would rather listen to
your messages later, press Exit.
To listen to your voice messages at a later time, perform one of the
following actions:
• Press and hold
1
.
•Press Menu 01-3-1 (Messages > Voice messages > Listen to
voice messages). Follow the recorded voice prompts to listen to
your messages.
Q. How do I redial the last-dialed number?
A. Press h twice.
Q. How do I assign a key to 1-touch dialing?
A. First, you must verify that 1-touch dialing is activated:
•Press Menu 4-3-4 (Settings > Call settings > 1-touch dialing).
• After a brief pause, On and Off appear in the display.
• Scroll to On and press Select.
Then you can assign a key to 1-touch dialing:
•Press Contacts and scroll to 1-touch dialing.
•Press Select.
• Scroll to the first (empty) slot and press Assign.
• Enter or retrieve the name/number you want to assign to the key and
press OK.
Repeat these steps as many times as necessary.
DRAFT
[ 157 ]
Reference information
Q. How do I check the contacts list memory status?
A. Press Contacts, scroll to Settings, and press Select. Scroll to Memory
status and press Select. Scroll to Phone or SIM card and press Select.
The memory status for your selection appears in the display.
Q. How do I find my phone’s Model number and IMEI number?
A. The model number and IMEI numbers are located on a label under the
phone battery. Turn your phone off, remove the back cover and then
remove the battery from the phone.
Q. How do I clear my call timers?
Important: Clearing call timers cannot be undone.
A. Press Menu 2-5-5 (Call log > Call timers > Clear timers).
When the security code prompt appears, enter your security code
and press OK.
DRAFT
[ 158 ]
• GLOSSARY
Business card A business card is the same as an entry in the
contacts list. It may contain a name, phone number,
and text entry. It can also be sent to other devices.
Call forwarding A network services feature you use to forward
incoming calls to another number.
Call lists A list used to track numbers for incoming, outgoing,
or missed calls.
Call log A log that registers information about calls you make
and receive.
Call timers Timers used to track the amount of time you spend
on calls.
Call waiting A network services feature that enables your phone
to beep while you are in the middle of a call. The beep
lets you know that someone else is calling you.
Gallery A menu within your phone that stores downloaded
images and tones.
International
Mobile
Equipment
Identifier (IMEI)
The identification number that is assigned to the
phone. This number is located on the type label,
located underneath the battery.
In-call options Features available for use while you are in a call.
Keyguard Locks the keypad to prevent accidental key presses.
Keypad tones The tone you hear when you press a key.
Menu A list of choices you can make to change settings on
your phone or use various phone features.
DRAFT
[ 159 ]
Reference information
Multimedia
messages
A message that contains a combination of text,
images, or MIDI tones
Predictive text A method of entering information in your phone
that uses a dictionary to predict, or guess, what you
are writing.
Profile A group of settings you can use to customize the way
your phone works.
Quick save A fast method for saving a number.
Ringing tone The sound your phone makes when you receive a call.
Ringing tones can be ringing sounds or short tunes.
Scroll bar A bar that appears on the right side of the screen
when you scroll through the main menus.
Start screen Your phone’s idle screen.
Voice mail A network services feature that enables people who
call and miss you to leave a voice message on your
phone.
Warning tones Sounds your phone makes during error conditions,
during confirmations, when the battery is low, and
when you need to recharge the battery.
DRAFT
[ 160 ]
• TECHNICAL INFORMATION
Feature Specification
Weight 3.2 oz. (92 grams) with BLD-3 780 mAh
Li-Ion battery
Wireless networks GSM 850, 1800, and 1900 networks
Size (volume) 4.6 cubic inches (75 cubic centimeters)
Frequency range (Tx) GSM 850: 824-849 MHz
GSM 1800: 1710-1785 MHz
GSM 1900: 1850-1910 MHz
Frequency range (Rx)
GSM 850: 869-894 MHz
GSM 1800: 1805-1880 MHz
GSM 1900: 1930-1990 MHz
Tx output power 2 W (GSM 850 max)
1 W (GSM 1800/GSM 1900 max)
Battery voltage 3.7 Vdc
Operating temperature +14°F to +131°F (-10°C to +55°C)
Number of channels GSM 850: 124
GSM 1800: 374
GSM 1900: 299
Memory locations Up to 500 in phone memory
DRAFT
[ 161 ]
Reference information
• TROUBLESHOOTING
Problem Possible cause Possible solution
My phone is not
charging
The charger and phone are
not properly connected.
Securely connect the
charger to the phone.
The charger is not properly
plugged into the wall.
Ensure the charger is
plugged in correctly.
My phone is not
making/
receiving calls
The battery is not charged. Charge the battery.
The signal strength is poor. If you are indoors, move
toward a window.
I cannot listen to
my voice
messages
You do not have voice mail
service.
Call your wireless
provider.
You have not setup your
voice mail service with your
wireless provider.
Call your wireless
provider.
You have not saved your
voice mail number to your
phone.
See “Save your voice
mailbox number” on
page 69.
You have forgotten your
password or are entering it
incorrectly.
Call your wireless
provider.
The voice mail number you
have saved to your phone is
incorrect.
Call your wireless
provider.
When I insert my
SIM card into
another phone,
it is rejected
Fixed dialing is activated on
your SIM card and the
receiving phone does not
support fixed dialing.
Deactivate fixed dialing
on the SIM.
DRAFT
[ 162 ]
• Nokia ONE-YEAR LIMITED WARRANTY
Nokia Inc. (“Nokia”) warrants that this cellular phone (“Product”) is free
from defects in material and workmanship that result in Product failure
during normal usage, according to the following terms and conditions:
1The limited warranty for the Product extends for ONE (1) year beginning
on the date of the purchase of the Product. This one year period is
extended by each whole day that the Product is out of your possession
for repair under this warranty.
2The limited warranty extends only to the original purchaser (“Consumer”)
of the Product and is not assignable or transferable to any subsequent
purchaser/end-user.
3The limited warranty extends only to Consumers who purchase the
Product in the United States of America.
4During the limited warranty period, Nokia will repair, or replace, at
Nokia’s sole option, any defective parts, or any parts that will not
properly operate for their intended use with new or refurbished
replacement items if such repair or replacement is needed because
of product malfunction or failure during normal usage. No charge
will be made to the Consumer for any such parts. Nokia will also
pay for the labor charges incurred by Nokia in repairing or replacing
the defective parts. The limited warranty does not cover defects in
appearance, cosmetic, decorative or structural items, including
framing, and any non-operative parts. Nokia’s limit of liability under
the limited warranty shall be the actual cash value of the Product at
the time the Consumer returns the Product for repair, determined by
the price paid by the Consumer for the Product less a reasonable
amount for usage. Nokia shall not be liable for any other losses or
damages. These remedies are the Consumer’s exclusive remedies for
breach of warranty.
5Upon request from Nokia, the Consumer must prove the date of the
original purchase of the Product by a dated bill of sale or dated
itemized receipt.
DRAFT
[ 163 ]
Reference information
6The Consumer shall bear the cost of shipping the Product to Nokia in
Melbourne, Florida. Nokia shall bear the cost of shipping the Product
back to the Consumer after the completion of service under this
limited warranty.
7The Consumer shall have no coverage or benefits under this limited
warranty if any of the following conditions are applicable:
a) The Product has been subjected to abnormal use, abnormal
conditions, improper storage, exposure to moisture or dampness,
unauthorized modifications, unauthorized connections,
unauthorized repair, misuse, neglect, abuse, accident, alteration,
improper installation, or other acts which are not the fault of
Nokia, including damage caused by shipping.
b) The Product has been damaged from external causes such as
collision with an object, or from fire, flooding, sand, dirt,
windstorm, lightning, earthquake or damage from exposure to
weather conditions, an Act of God, or battery leakage, theft,
blown fuse, or improper use of any electrical source, damage
caused by computer or internet viruses, bugs, worms, Trojan
Horses, cancelbots or damage caused by the connection to other
products not recommended for interconnection by Nokia.
c) Nokia was not advised in writing by the Consumer of the alleged
defect or malfunction of the Product within fourteen (14) days
after the expiration of the applicable limited warranty period.
d) The Product serial number plate or the enhancement data code
has been removed, defaced or altered.
e) The defect or damage was caused by the defective function of the
cellular system or by inadequate signal reception by the external
antenna, or viruses or other software problems introduced into
the Product.
8Nokia does not warrant uninterrupted or error-free operation of the
Product. If a problem develops during the limited warranty period, the
Consumer shall take the following step-by-step procedure:
DRAFT
[ 164 ]
a) The Consumer shall return the Product to the place of purchase
for repair or replacement processing.
b) If “a” is not convenient because of distance (more than 50 miles)
or for other good cause, the Consumer shall ship the Product
prepaid and insured to:
Nokia Inc., Attn: Repair Department
795 West Nasa Blvd.
Melbourne, FL 32901
c) The Consumer shall include a return address, daytime phone
number and/or fax number, complete description of the problem,
proof of purchase and service agreement (if applicable). Expenses
related to removing the Product from an installation are not
covered under this limited warranty.
d) The Consumer will be billed for any parts or labor charges not
covered by this limited warranty. The Consumer will be
responsible for any expenses related to reinstallation of the
Product.
e) Nokia will repair the Product under the limited warranty within
30 days after receipt of the Product. If Nokia cannot perform
repairs covered under this limited warranty within 30 days, or
after a reasonable number of attempts to repair the same defect,
Nokia at its option, will provide a replacement Product or refund
the purchase price of the Product less a reasonable amount for
usage. In some states the Consumer may have the right to a
loaner if the repair of the Product takes more than ten (10) days.
Please contact the Customer Service Center at Nokia at the
telephone number listed at the end of this warranty if you need
a loaner and the repair of the Product has taken or is estimated
to take more than ten (10) days.
f) If the Product is returned during the limited warranty period, but
the problem with the Product is not covered under the terms and
conditions of this limited warranty, the Consumer will be notified
and given an estimate of the charges the Consumer must pay to
DRAFT
[ 165 ]
Reference information
have the Product repaired, with all shipping charges billed to the
Consumer. If the estimate is refused, the Product will be returned
freight collect. If the Product is returned after the expiration of
the limited warranty period, Nokia’s normal service policies shall
apply and the Consumer will be responsible for all shipping charges.
9You (the Consumer) understand that the product may consist of
refurbished equipment that contains used components, some of
which have been reprocessed. The used components comply with
Product performance and reliability specifications.
10 ANY IMPLIED WARRANTY OF MERCHANTABILITY, OR FITNESS FOR A
PARTICULAR PURPOSE OR USE, SHALL BE LIMITED TO THE DURATION
OF THE FOREGOING LIMITED WRITTEN WARRANTY. OTHERWISE, THE
FOREGOING LIMITED WARRANTY IS THE CONSUMER’S SOLE AND
EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED. NOKIA SHALL NOT BE LIABLE FOR SPECIAL,
INCIDENTAL, PUNITIVE OR CONSEQUENTIAL DAMAGES, INCLUDING
BUT NOT LIMITED TO LOSS OF ANTICIPATED BENEFITS OR PROFITS,
LOSS OF SAVINGS OR REVENUE, LOSS OF DATA, PUNITIVE DAMAGES,
LOSS OF USE OF THE PRODUCT OR ANY ASSOCIATED EQUIPMENT,
COST OF CAPITAL, COST OF ANY SUBSTITUTE EQUIPMENT OR
FACILITIES, DOWNTIME, THE CLAIMS OF ANY THIRD PARTIES,
INCLUDING CUSTOMERS, AND INJURY TO PROPERTY, RESULTING
FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM
BREACH OF THE WARRANTY, BREACH OF CONTRACT, NEGLIGENCE,
STRICT TORT, OR ANY OTHER LEGAL OR EQUITABLE THEORY, EVEN IF
NOKIA KNEW OF THE LIKELIHOOD OF SUCH DAMAGES. NOKIA SHALL
NOT BE LIABLE FOR DELAY IN RENDERING SERVICE UNDER THE
LIMITED WARRANTY, OR LOSS OF USE DURING THE PERIOD THAT THE
PRODUCT IS BEING REPAIRED.
11 Some states do not allow limitation of how long an implied warranty
lasts, so the one year warranty limitation may not apply to you (the
Consumer). Some states do not allow the exclusion or limitation of
incidental and consequential damages, so certain of the above
limitations or exclusions may not apply to you (the Consumer). This
DRAFT
[ 166 ]
limited warranty gives the Consumer specific legal rights and the
Consumer may also have other rights which vary from state to state.
12 Nokia neither assumes nor authorizes any authorized service center
or any other person or entity to assume for it any other obligation or
liability beyond that which is expressly provided for in this limited
warranty including the provider or seller of any extended warranty or
service agreement.
13 This is the entire warranty between Nokia and the Consumer, and
supersedes all prior and contemporaneous agreements or understandings,
oral or written, relating to the Product, and no representation,
promise or condition not contained herein shall modify these terms.
14 This limited warranty allocates the risk of failure of the Product
between the Consumer and Nokia. The allocation is recognized by
the Consumer and is reflected in the purchase price.
15 Any action or lawsuit for breach of warranty must be commenced
within eighteen (18) months following purchase of the Product.
16 Questions concerning this limited warranty may be directed to:
Nokia Inc.
Attn: Customer Service
7725 Woodland Center Blvd., Ste. 150
Tampa, FL 33614
Telephone: 1-888-NOKIA-2U (1-888-665-4228)
Facsimile: (813) 287-6612
TTY/TDD Users Only: 1-800-24-NOKIA (1-800-246-6542)
17 The limited warranty period for Nokia supplied attachments and
enhancements is specifically defined within their own warranty cards
and packaging.
DRAFT
[ 167 ]
Appendix A
Appendix A
Message from the CTIA (Cellular
Telecommunications & Internet
Association) to all users of mobile
phones.
© 2001 Cellular Telecommunications & Internet Association. All Rights
Reserved.1250 Connecticut Avenue, NW Suite 800, Washington, DC 20036.
Phone: (202) 785-0081
DRAFT
[ 168 ]
Safety is the most important call you will ever make.
A Guide to Safe an d R esp on sible Wire less Phone Use
Tens of millions of people in the U.S. today take advantage of the unique
combination of convenience, safety and value delivered by the wireless telephone.
Quite simply, the wireless phone gives people the powerful ability to communicate
by voice--almost anywhere, anytime--with the boss, with a client, with the kids,
with emergency personnel or even with the police. Each year, Americans make
billions of calls from their wireless phones, and the numbers are rapidly growing.
But an important responsibility accompanies those benefits, one that every wireless
phone user must uphold. When driving a car, driving is your first responsibility. A
wireless phone can be an invaluable tool, but good judgment must be exercised at
all times while driving a motor vehicle--whether on the phone or not.
The basic lessons are ones we all learned as teenagers. Driving requires alertness,
caution and courtesy. It requires a heavy dose of basic common sense---keep your
head up, keep your eyes on the road, check your mirrors frequently and watch out
for other drivers. It requires obeying all traffic signs and signals and staying within
the speed limit. It means using seatbelts and requiring other passengers to do the
same.
But with wireless phone use, driving safely means a little more. This brochure is a
call to wireless phone users everywhere to make safety their first priority when
behind the wheel of a car. Wireless telecommunications is keeping us in touch,
simplifying our lives, protecting us in emergencies and providing opportunities to
help others in need.
When it comes to the use of wireless phones, safety is your most important call.
Wire less Phone "S afety Tips"
Below are safety tips to follow while driving and using a wireless phone which
should be easy to remember.
1 Get to know your wireless phone and its features such as speed dial and redial.
Carefully read your instruction manual and learn to take advantage of valuable
features most phones offer, including automatic redial and memory. Also, work
to memorize the phone keypad so you can use the speed dial function without
taking your attention off the road.
2 When available, use a hands free device. A number of hands free wireless phone
accessories are readily available today. Whether you choose an installed mounted
device for your wireless phone or a speaker phone accessory, take advantage of
these devices if available to you.
3 Position your wireless phone within easy reach. Make sure you place your
wireless phone within easy reach and where you can grab it without removing
your eyes from the road. If you get an incoming call at an inconvenient time, if
possible, let your voice mail answer it for you.
4 Suspend conversations during hazardous driving conditions or situations. Let
the person you are speaking with know you are driving; if necessary, suspend the
DRAFT
[ 169 ]
Appendix A
call in heavy traffic or hazardous weather conditions. Rain, sleet, snow and ice
can be hazardous, but so is heavy traffic. As a driver, your first responsibility is
to pay attention to the road.
5 Do not take notes or look up phone numbers while driving. If you are reading an
address book or business card, or writing a "to do" list while driving a car, you
are not watching where you are going. It’s common sense. Don’t get caught in a
dangerous situation because you are reading or writing and not paying attention
to the road or nearby vehicles.
6 Dial sensibly and assess the traffic; if possible, place calls when you are not
moving or before pulling into traffic. Try to plan your calls before you begin your
trip or attempt to coincide your calls with times you may be stopped at a stop
sign, red light or otherwise stationary. But if you need to dial while driving,
follow this simple tip--dial only a few numbers, check the road and your mirrors,
then continue.
7 Do not engage in stressful or emotional conversations that may be distracting.
Stressful or emotional conversations and driving do not mix--they are
distracting and even dangerous when you are behind the wheel of a car. Make
people you are talking with aware you are driving and if necessary, suspend
conversations which have the potential to divert your attention from the road.
8 Use your wireless phone to call for help. Your wireless phone is one of the
greatest tools you can own to protect yourself and your family in dangerous
situations--with your phone at your side, help is only three numbers away. Dial
9-1-1 or other local emergency number in the case of fire, traffic accident, road
hazard or medical emergency. Remember, it is a free call on your wireless phone!
9 Use your wireless phone to help others in emergencies. Your wireless phone
provides you a perfect opportunity to be a "Good Samaritan" in your
community. If you see an auto accident, crime in progress or other serious
emergency where lives are in danger, call 9-1-1 or other local emergency number,
as you would want others to do for you.
10 Call roadside assistance or a special wireless non-emergency assistance number
when necessary. Certain situations you encounter while driving may require
attention, but are not urgent enough to merit a call for emergency services. But
you still can use your wireless phone to lend a hand. If you see a broken-down
vehicle posing no serious hazard, a broken traffic signal, a minor traffic accident
where no one appears injured or a vehicle you know to be stolen, call roadside
assistance or other special non-emergency wireless number.
Careless, distracted individuals and people driving irresponsibly represent a hazard
to everyone on the road. Since 1984, the Cellular Telecommunications Industry
Association and the wireless industry have conducted educational outreach to
inform wireless phone users of their responsibilities as safe drivers and good
citizens. As we approach a new century, more and more of us will take advantage of
the benefits of wireless telephones. And, as we take to the roads, we all have a
responsibility to drive safely.
The wireless industry reminds you to use your phone safely when driving.
DRAFT
[ 170 ]
For more information, please call 1-888-901-SAFE.
For updates: http://www.wow-com.com/consumer/issues/driving/
articles.cfm?ID=85
© 2001 Cellular Telecommunications & Internet Association. All Rights
Reserved.1250 Connecticut Avenue, NW Suite 800, Washington, DC 20036. Phone:
(202) 785-0081
DRAFT
[ 171 ]
Appendix B
Appendix B
Message from the FDA (U.S. Food
and Drug Administration) to all users
of mobile phones.
July 18, 2001...... For updates: http://www.fda.gov/cdrh/phones
DRAFT
[ 172 ]
Consum er Update on Wire less Phones
U.S. Food and Drug Adm inistra tion
1. Do wire less phones pose a health hazard?
The available scientific evidence does not show that any health problems are
associated with using wireless phones. There is no proof, however, that wireless
phones are absolutely safe. Wireless phones emit low levels of radiofrequency energy
(RF) in the microwave range while being used. They also emit very low levels of RF
when in the stand-by mode. Whereas high levels of RF can produce health effects (by
heating tissue), exposure to low level RF that does not produce heating effects causes
no known adverse health effects. Many studies of low level RF exposures have not
found any biological effects. Some studies have suggested that some biological effects
may occur, but such findings have not been confirmed by additional research. In
some cases, other researchers have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
2. What is FD A 's ro le concerning the safety of wire less phones?
Under the law, FDA does not review the safety of radiation-emitting consumer
products such as wireless phones before they can be sold, as it does with new drugs
or medical devices. However, the agency has authority to take action if wireless
phones are shown to emit radiofrequency energy (RF) at a level that is hazardous to
the user. In such a case, FDA could require the manufacturers of wireless phones to
notify users of the health hazard and to repair, replace or recall the phones so that
the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory actions, FDA has
urged the wireless phone industry to take a number of steps, including the following:
• Support needed research into possible biological effects of RF of the type emitted
by wireless phones;
• Design wireless phones in a way that minimizes any RF exposure to the user
that is not necessary for device function; and
• Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human health.
FDA belongs to an interagency working group of the federal agencies that have
responsibility for different aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency working group
activities, as well.
FDA shares regulatory responsibilities for wireless phones with the Federal
Communications Commission (FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF exposure. FCC relies on FDA
and other health agencies for safety questions about wireless phones. FCC also
regulates the base stations that the wireless phone networks rely upon. While these
base stations operate at higher power than do the wireless phones themselves, the
DRAFT
[ 173 ]
Appendix B
RF exposures that people get from these base stations are typically thousands of
times lower than those they can get from wireless phones. Base stations are thus not
the subject of the safety questions discussed in this document.
3. What kinds of phones are th e subject of this update?
The term wireless phone refers here to hand-held wireless phones with built-in
antennas, often called cell mobile or PCS phones. These types of wireless phones can
expose the user to measurable radiofrequency energy (RF) because of the short
distance between the phone and the user’s head. These RF exposures are limited by
Federal Communications Commission safety guidelines that were developed with
the advice of FDA and other federal health and safety agencies. When the phone is
located at greater distances from the user, the exposure to RF is drastically lower
because a person's RF exposure decreases rapidly with increasing distance from the
source. The so-called cordless phones; which have a base unit connected to the
telephone wiring in a house, typically operate at far lower power levels, and thus
produce RF exposures far below the FCC safety limits.
4. What are the re s u lts of the research done alre a d y ?
The research done thus far has produced conflicting results, and many studies have
suffered from flaws in their research methods. Animal experiments investigating the
effects of radiofrequency energy (RF) exposures characteristic of wireless phones
have yielded conflicting results that often cannot be repeated in other laboratories.
A few animal studies, however, have suggested that low levels of RF could accelerate
the development of cancer in laboratory animals. However, many of the studies that
showed increased tumor development used animals that had been genetically
engineered or treated with cancer-causing chemicals so as to be pre-disposed to
develop cancer in the absence of RF exposure. Other studies exposed the animals to
RF for up to 22 hours per day. These conditions are not similar to the conditions
under which people use wireless phones, so we don’t know with certainty what the
results of such studies mean for human health.
Three large epidemiology studies have been published since December 2000.
Between them, the studies investigated any possible association between the use of
wireless phones and primary brain cancer, glioma, meningioma, or acoustic
neuroma, tumors of the brain or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful health effects from wireless
phone RF exposures. However, none of the studies can answer questions about long-
term exposures, since the average period of phone use in these studies was around
three years.
5.What research is needed to decide whether RF exposure fro m wire less
phones poses a health risk?
A combination of laboratory studies and epidemiological studies of people actually
using wireless phones would provide some of the data that are needed. Lifetime
animal exposure studies could be completed in a few years. However, very large
numbers of animals would be needed to provide reliable proof of a cancer promoting
effect if one exists. Epidemiological studies can provide data that is directly
applicable to human populations, but 10 or more years follow-up may be needed to
provide answers about some health effects, such as cancer. This is because the
interval between the time of exposure to a cancer-causing agent and the time tumors
develop - if they do - may be many, many years. The interpretation of epidemiological
studies is hampered by difficulties in measuring actual RF exposure during day-to-
day use of wireless phones. Many factors affect this measurement, such as the angle
at which the phone is held, or which model of phone is used.
DRAFT
[ 174 ]
6.W hat is FDA doing to find out more about the possible health effects
of wire less phone RF?
FDA is working with the U.S. National Toxicology Program and with groups of
investigators around the world to ensure that high priority animal studies are
conducted to address important questions about the effects of exposure to
radiofrequency energy (RF).
FDA has been a leading participant in the World Health Organization International
Electromagnetic Fields (EMF) Project since its inception in 1996. An influential
result of this work has been the development of a detailed agenda of research needs
that has driven the establishment of new research programs around the world. The
Project has also helped develop a series of public information documents on EMF
issues.
FDA and the Cellular Telecommunications
C
Internet Association (CTIA) have a
formal Cooperative Research and Development Agreement (CRADA) to do research
on wireless phone safety. FDA provides the scientific oversight, obtaining input from
experts in government, industry, and academic organizations. CTIA-funded research
is conducted through contracts to independent investigators. The initial research
will include both laboratory studies and studies of wireless phone users. The CRADA
will also include a broad assessment of additional research needs in the context of
the latest research developments around the world.
7. How can I find out how much ra d iofrequency energy exposure I can
get by using my wire less phone?
All phones sold in the United States must comply with Federal Communications
Commission (FCC) guidelines that limit radiofrequency energy (RF) exposures. FCC
established these guidelines in consultation with FDA and the other federal health
and safety agencies. The FCC limit for RF exposure from wireless telephones is set
at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC
limit is consistent with the safety standards developed by the Institute of Electrical
and Electronic Engineering (IEEE) and the National Council on Radiation
Protection and Measurement. The exposure limit takes into consideration the body’s
ability to remove heat from the tissues that absorb energy from the wireless phone
and is set well below levels known to have effects.
Manufacturers of wireless phones must report the RF exposure level for each model
of phone to the FCC. The FCC website (http://www.fcc.gov/oet/rfsafety) gives
directions for locating the FCC identification number on your phone so you can find
your phone’s RF exposure level in the online listing.
8. What has FDA done to measure the ra d iofre q u e n c y energy com ing
fro m wire less phones?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical
standard for measuring the radiofrequency energy (RF) exposure from wireless
phones and other wireless handsets with the participation and leadership of FDA
scientists and engineers. The standard, Recommended Practice for Determining the
Spatial-Peak Specific Absorption Rate (SAR) in the Human Body Due to Wireless
Communications Devices: Experimental Techniques, sets forth the first consistent
test methodology for measuring the rate at which RF is deposited in the heads of
wireless phone users. The test method uses a tissue-simulating model of the human
head. Standardized SAR test methodology is expected to greatly improve the
consistency of measurements made at different laboratories on the same phone. SAR
is the measurement of the amount of energy absorbed in tissue, either by the whole
DRAFT
[ 175 ]
Appendix B
body or a small part of the body. It is measured in watts/kg (or milliwatts/g) of
matter. This measurement is used to determine whether a wireless phone complies
with safety guidelines.
9. What steps can I take to re d u c e my exposure to ra d iofrequency
energy fro m my wire less phone?
If there is a risk from these products--and at this point we do not know that there is-
-it is probably very small. But if you are concerned about avoiding even potential
risks, you can take a few simple steps to minimize your exposure to radiofrequency
energy (RF). Since time is a key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless phone will reduce RF exposure.
If you must conduct extended conversations by wireless phone every day, you could
place more distance between your body and the source of the RF, since the exposure
level drops off dramatically with distance. For example, you could use a headset and
carry the wireless phone away from your body or use a wireless phone connected to
a remote antenna.
Again, the scientific data do not demonstrate that wireless phones are harmful. But
if you are concerned about the RF exposure from these products, you can use
measures like those described above to reduce your RF exposure from wireless phone
use.
10. What about children using wire less phones?
The scientific evidence does not show a danger to users of wireless phones, including
children and teenagers. If you want to take steps to lower exposure to radiofrequency
energy (RF), the measures described above would apply to children and teenagers
using wireless phones. Reducing the time of wireless phone use and increasing the
distance between the user and the RF source will reduce RF exposure.Some groups
sponsored by other national governments have advised that children be discouraged
from using wireless phones at all. For example, the government in the United
Kingdom distributed leaflets containing such a recommendation in December 2000.
They noted that no evidence exists that using a wireless phone causes brain tumors
or other ill effects. Their recommendation to limit wireless phone use by children was
strictly precautionary; it was not based on scientific evidence that any health hazard
exists.
11. What about wire less phone interference with medical equipm ent?
Radiofrequency energy (RF) from wireless phones can interact with some electronic
devices. For this reason, FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This standard will allow
manufacturers to ensure that cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested hearing aids for interference from handheld
wireless phones and helped develop a voluntary standard sponsored by the Institute
of Electrical and Electronic Engineers (IEEE). This standard specifies test methods
and performance requirements for hearing aids and wireless phones so that no
interference occurs when a person uses a compatible phone and a accompanied
hearing aid at the same time. This standard was approved by the IEEE in 2000.
DRAFT
[ 176 ]
FDA continues to monitor the use of wireless phones for possible interactions with
other medical devices. Should harmful interference be found to occur, FDA will
conduct testing to assess the interference and work to resolve the problem.
12. W here can I find additional inform ation?
For additional information, please refer to the following resources:
• FDA web page on wireless phones
http://www.fda.gov/cdrh/phones/index.html
• Federal Communications Commission (FCC) RF Safety Program
http://www.fcc.gov/oet/rfsafety
• International Commission on Non-Ionizing Radiation Protection
http://www.icnirp.de
• World Health Organization (WHO) International EMF Project
http://www.who.int/emf
• National Radiological Protection Board (UK)
http://www.nrpb.org.uk/
July 18, 2001For updates: http://www.fda.gov/cdrh/phones
DRAFT
[ 177 ]
1-touch dialing 48
assign a key 49
change numbers 49
delete numbers 50
make a call 49
A
activate
automatic redial 91
call forwarding 90
adding folders 74
alarm
setting 103
snooze 103
turning off 104
with phone off 104
with phone on 103
alarm clock 103
antenna
use the antenna 8
applications 118
downloading 119
launching 118
options 118
view memory status 120
audible alerts 126
setting up 126
sounds 126
authority certificates 141
about 141
viewing 141
automatic Keygaurd
deactivate 94
automatic Keyguard 94
activate 94
automatic redial 91
B
battery
prolonging battery life 9
use the battery 8
battery (BLD-3) 151
battery info
charging times 150
talk and standby times 150
battery operation times 150
birthday note 110
bookmark
set while browsing 140
bookmarks 140
browser
use bookmarks 140
browser options 137
Business cards
receive 47
send 47
C
calculator 121
calendar
4-way scrolling 110
birthday note 110
call note 110
date notes 110
discard viewed notes 114
go to date 110
meeting note 110
memo note 110
monthly view 110
note options 111
note types 110
opening 109
reminder 110
DRAFT
[ 178 ]
save received notes 113
saving notes 110
uses 109
view notes 111
view received notes 113
calendar notes
sending and receiving 112
call duration 83
viewing 83
call forwarding
activate 90
cancelling 91
definition 89
call log
about 80
call duration 92
delete call lists 82
options 80
view call duration 83
view dialed numbers 82
view missed calls 81
view received calls 81
call note 110
call waiting 92
activate 92
caller groups 53
options 53
setup 54
calls
forwarding 90
ignoring 14
redial last 14
camera headset (HS-1C) 153
cancel call forwarding 91
cell info display 94
certification information 148
change
1-touch dialing numbers 49
keypad tones 85
message alert tone 85
PIN2 code 40
profile names 85
ringing options 85
ringing tone 85
ringing volume 85
security codes 39
security levels 36
time format 89
charger
connecting 8
charging times 150
ACP-12 150
ACP-7 150
ACP-8 150
clock
alarm 103
set 88
set the date 89
show/hide 88
time format 89
closed user groups 38
codes
access 38
dialing 71
PIN2 40
PUK 41
complete car kit (CARK-143) 154
connect to other devices 127
connectivity 127
IR 127
connectivity desk stand (DCV-14)
154
Contacts 42
copy 47
DRAFT
[ 179 ]
delete 46
edit 46
save 43
search 46
view 42
currency
converting 122
exchange rate 122
to foreign 122
to home 122
currency conversion 122
customer care
Canada 16
USA 16
customize
display language 93
D
data cable (DKU-5) 153
deactivate automatic redial 91
definition of terms 158
delete
1-touch dialing numbers 50
messages 75
delete call lists 82
dialed calls, viewing 82
dialing codes
how to use 71
setup voicemail with 72
dictionary
add new words 34
in predictive text 34
disconnect from wireless Internet
140
display brightness
screen brightness 99
display language 93
display settings 97
color schemes 98
screen brightness 29
screen saver 98
wallpaper 97
download
pictures 59
E
(E)GPRS 129
dial-up connections 129
make a call while online 131
make an emergency call 131
phone symbols 129
receive a call while online 131
set up 130
e-mail
replying 63
writing and sending 62
emergency call
make while using (E)GPRS 131
emergency calls 147
with keypad locked 35, 94
enhancement settings 99
handsfree 99
headset 99
loopset 100
music stand 102
TTY 100
enhancements 151
battery (BLD-3) 151
camera headset (HS-1C) 153
complete car kit (CARK-143) 154
connectivity stand (DCV-14) 154
data cable (DKU-5) 153
headset kit (HDB-4) 152
loopset (LPS-4) 153
DRAFT
[ 180 ]
mobile charger (LCH-12) 152
music stand (DT-1) 154
safety 151
travel charger (ACP-12) 152
TTY/TDD adapter (HDA-10) 153
extras 121
F
FAQs 155
FCC information 148
fixed dialing
edit number list 37
emergency numbers 36
notes about 38
setup and activate 36
folders
adding 74
list of 74
organize messages with 73
removing 75
four-way scrolling
in calendar 110
G
games 116
launching 116
options 117
playing 117
glossary 158
H
handsfree 99
headset 99
headset kit (HDB-4) 152
help text 96
I
IMEI
location on the phone 16, 158
Infrared connections 127
sending and receiving data 127
Internet
connect with your phone 137
L
languages
available 93
setting 93
loopset 100
description 153
loopset (LPS-4) 153
M
meeting note 110
memo note 110
menu functions 55
messages 55
messages
change message settings 76
change MMS settings 78
deleting 75
e-mail 62
message center number 56
message icons 55
moving 75
picture messages 59
save to folders 73
text messages 57
view saved 74
voice messages 69
missed calls 81
MMS
DRAFT
[ 181 ]
defining 64
editing 66
reading and replying 68
writing and sending 67
mobile charger (LCH-12) 152
moving messages 75
multimedia messages 63
music stand 102
music stand (DT-1) 154
N
Nokia one-year limited warranty
162
Nokia PC Suite
features 135
Nokia PC Suite 129, 135
O
Organizer 109
P
phone security
security code 38
security levels 35
picture messages
composing and sending 60
downloading pictures for 59
modifying 61
receiving 60
sending 59
PIN 2 code 40
PIN code
changing 40
PIN code request 39
predictive text
about 57
activate and deactivate 32
add new words 34
primary number
copying 47
profiles 84
customizing 84
list of 84
selecting 84
timed 85
PUK codes 41
R
received calls 81
receiving
calendar notes 112
reference information 142
battery statements 142
emergency calls 147
safety information 144
care and maintenance 143
reminder note 110
removing folders 75
restore factory settings 102
right selection key settings 87
S
SAR
definition 148
limits 149
save
calendar notes 110
received calendar notes 113
screen saver 98
security
security code 38
security levels 35
security settings 102
sending
DRAFT
[ 182 ]
calendar notes 112
services 136
set clock 88
set the display language 93
settings 87
right selection key settings 87
time and date settings 88
tone settings 99
setup
voicemail 70
show/hide clock 88
SIM
SIIM-related services 96
SIM card
if rejected 41
info numbers 53
non-owner 35
own numbers 53
PIN code 39
security levels 35
service numbers 53
start-up tone 97
synchronize
from your PC 134
from your phone 133
saving settings 132
synchronize data 131
system selection 95
T
talk and standby times 150
technical information 160
text messages
forwarding 59
reading 58
replying to 58
send calendar notes as 115
writing and sending 57
time and date settings 88
time format 89
timed profiles 85
to-do list 114
adding to a note 114
making 114
options 114
travel charger (ACP-12) 152
troubleshooting 161
TTY/TDD 100
make a call 101
receive a call 102
set up profile 100
TTY/TDD adapter (HDA-10) 153
V
vibrating alert
turn on or off 85
view
calendar notes 111
call duration 83
clock on the start screen 88
dialed numbers 82
fixed dialing numbers 37
missed calls 81
monthly view, calendar 110
picture messages 60
received calendar notes 113
received calls 81
received messages 58
saved messages 74
voice commands
activating 125
adding 125
functions 124
working with 125
DRAFT
[ 183 ]
Voice dialing 50
assigning a voice tag 50
dialing a number 51
voice dialing
change a voice tag 52
delete a voice tag 52
play back a voice tag 52
voice messages 29
voice recorder 123
deleting a recording 124
editing a recording 124
recording speech or sound 123
recording while in a call 123
setting voice memo alarm 124
view and play recordings 123
voicemail
automate 70
call and setup 29, 70
listen to voice messages 29, 70
save voice mailbox number 69
using dialing codes 72
W
wallpaper 97
warning tones
turn on or off 85
warranty information 162
welcome note 95
wireless Internet
browsing 137
navigating 138
security issues 140
signing off 140
signing on 137
wireless internet access
notes 136
wireless Internet site
examples 139
how to read 139
X
xHTML 136
xHTML broswer 137
use phone keys 138
xHTML page
active link 139
enter information 139
examples 139
using bookmarks 140
