Microsoft RA-6 QUAD BAND GSM/WCDMA CELLULAR PHONE User Manual
Microsoft Mobile Oy QUAD BAND GSM/WCDMA CELLULAR PHONE
Contents
- 1. User manual
- 2. User Guide
- 3. Manual
User manual
Nokia Exx User Guide
9251041
Issue 1
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 1 Jan 8, 2007 1:39:30 PM
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RA-6 product is in compliance with the essential requirements and
other relevant provisions of Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found at
www.nokia.com/phones/declaration_of_conformity/.
© 2007 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nokia Care, Eseries and Exx are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark
of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia
is prohibited.
This product includes software licensed from Symbian Software Ltd © 1998-2006. Symbian and Symbian OS are trademarks of Symbian
Ltd.
US Patent No 5818437 and other pending patents. T9 text input software Copyright © 1997-2006. Tegic Communications, Inc. All rights reserved.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which
has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in
connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information,
including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this
document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS
OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION
TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME
WITHOUT PRIOR NOTICE.
The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for
details, and availability of language options.
Export controls
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 2 Jan 8, 2007 1:39:30 PM
This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary
to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry
Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service
facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or
modifications not expressly approved by Nokia could void the user's authority to operate this equipment.
Model number: Exx-1
9251041/Issue 1
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 3 Jan 8, 2007 1:39:30 PM
Contents
For your safety..............................................................7
About your device....................................................................8
Network services......................................................................8
Enhancements, batteries, and chargers............................9
Basic information about your device..................10
Welcome...................................................................................10
Switch from cover use to communicator.......................10
Menu key, scroll key, and Chr key......................................11
Menu..........................................................................................11
Common actions in several applications........................12
Standby modes.......................................................................12
Write text with the cover keypad.....................................13
Volume control.......................................................................15
Profiles .....................................................................................15
Themes .....................................................................................15
Memory.....................................................................................16
Help and tutorial....................................................................17
Settings wizard ......................................................................18
Nokia PC Suite.........................................................................18
Transfer content between devices ......................19
Telephone....................................................................21
Answer a call...........................................................................21
Make a call................................................................................21
Make a conference call.........................................................22
Video calls................................................................................22
Video sharing..........................................................................23
Net calls ....................................................................................23
1-touch dialing ......................................................................25
Call forward settings.............................................................25
Call restriction.........................................................................26
Send touch tones...................................................................26
Voice mail ................................................................................27
Log .................................................................................28
Monitor all communications..............................................28
Log settings.............................................................................28
Messaging ...................................................................29
Organize messages...............................................................29
Message reader......................................................................30
Text messages........................................................................30
Multimedia messages...........................................................31
E-mail messages.....................................................................32
Special messages...................................................................35
Instant messaging ................................................................36
Service messages...................................................................37
Messaging settings................................................................38
Contacts .......................................................................42
Copy contacts between SIM and device
memory.....................................................................................42
Manage contacts....................................................................42
Manage contact groups.......................................................43
Add ringing tones for contacts..........................................43
Business cards.........................................................................43
Calendar .......................................................................45
Contents
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 4 Jan 8, 2007 1:39:30 PM
Create calendar entries........................................................45
To-do entries...........................................................................45
Calendar views........................................................................46
Clock ..............................................................................47
Alarm clock...............................................................................47
World clock..............................................................................47
Clock settings..........................................................................47
Office applications.....................................................48
File manager ..........................................................................48
Search .......................................................................................48
Calculator .................................................................................49
Nokia Team Suite ..................................................................49
Quickoffice ..............................................................................50
Active notes ............................................................................51
Converter .................................................................................51
PDF reader ...............................................................................52
Zip manager ...........................................................................52
Print ..........................................................................................52
Wireless keyboard ................................................................53
Notes .........................................................................................53
Connectivity.................................................................55
Modem .....................................................................................55
Cable connection ...................................................................55
Connection manager ...........................................................56
Bluetooth .................................................................................56
SIM access profile...................................................................59
Infrared ....................................................................................60
Internet access points..........................................................60
Wireless local area network...................................63
See WLAN availability...........................................................63
WLAN connections.................................................................63
WLAN wizard ..........................................................................64
WLAN access points...............................................................64
Set up an internet access point for WLAN
manually...................................................................................65
WLAN settings.........................................................................65
Web ...............................................................................66
Access points...........................................................................66
Browse the web.....................................................................66
Bookmarks...............................................................................66
End a connection....................................................................67
Clear the cache........................................................................67
Web settings...........................................................................67
Global Positioning System (GPS) ..........................68
Maps ..........................................................................................68
GPS data ...................................................................................70
Landmarks ..............................................................................71
Business voice applications....................................72
Push to talk .............................................................................72
Recorder ..................................................................................73
Voice aid ..................................................................................74
Speech ......................................................................................74
Voice commands ...................................................................75
Media applications....................................................77
RealPlayer ................................................................................77
Music player ............................................................................78
Flash player .............................................................................79
Camera .....................................................................................79
Gallery .......................................................................................81
Radio .........................................................................................82
Contents
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 5 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 5 Jan 8, 2007 1:39:30 PM
Settings ........................................................................83
General settings.....................................................................83
Telephone settings................................................................85
Connection settings..............................................................86
Application settings..............................................................89
Device and data management..............................90
Back up data............................................................................90
Remote configuration .........................................................90
Application manager ...........................................................90
Activation keys ......................................................................91
Data synchronization ..........................................................91
Barcode reader ......................................................................92
Download! ...............................................................................92
Security.........................................................................93
Fixed dialing............................................................................93
Certificate manager...............................................................93
Security modules...................................................................94
Memory card security...........................................................94
Lock the device.......................................................................94
Shortcuts.......................................................................96
Glossary.........................................................................98
Battery information................................................102
Nokia battery authentication guidelines.........103
Authenticate hologram.....................................................103
What if your battery is not authentic?.........................104
Care and maintenance...........................................105
Disposal..................................................................................105
Additional safety information.............................107
Small children.......................................................................107
Operating environment.....................................................107
Medical devices....................................................................107
Vehicles...................................................................................108
Potentially explosive environments..............................108
Emergency calls....................................................................108
CERTIFICATION INFORMATION (SAR)................................109
Index............................................................................111
Contents
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 6 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 6 Jan 8, 2007 1:39:30 PM
For your safety
Read these simple guidelines. Not following them may
be dangerous or illegal. Read the complete user guide
for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands
free to operate the vehicle while driving.
Your first consideration while driving should
be road safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect
performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the device off
near medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can
cause interference in aircraft.
SWITCH OFF WHEN REFUELING
Do not use the device at a refueling point. Do
not use near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the device
where blasting is in progress.
USE SENSIBLY
Use only in the normal position as explained
in the product documentation. Do not touch
the antenna unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and
batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it
dry.
BACK-UP COPIES
Remember to make back-up copies or keep
a written record of all important information
stored in your device.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read
its user guide for detailed safety instructions.
Do not connect incompatible products.
7
For your safety
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 7 Jan 8, 2007 1:39:30 PM
EMERGENCY CALLS
Ensure the phone function of the device is
switched on and in service. Press the end key
as many times as needed to clear the display
and return to the standby mode. Enter the
emergency number, then press the call key.
Give your location. Do not end the call until
given permission to do so.
About your device
The wireless device described in this guide is approved
for use on the GSM 850/900/1800/1900, WCDMA 2100
network. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws
and respect local customs, privacy and legitimate rights
of others, including copyrights.
Copyright protections may prevent some images, music
(including ringing tones), and other content from being
copied, modified, transferred, or forwarded.
Your device supports internet connections and other
methods of connectivity. Like computers, your device
may be exposed to viruses, malicious messages and
applications, and other harmful content. Exercise
caution and open messages, accept connectivity
requests, download content, and accept installations
only from trustworthy sources. To increase the security
of your device, consider installing antivirus software
with a regular update service and using a firewall
application.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on.
Do not switch the device on when wireless device use
may cause interference or danger.
The office applications support common features of
Microsoft Word, PowerPoint, and Excel (Microsoft Office
2000, XP, and 2003). Not all file formats can be viewed
or modified.
Network services
To use the phone you must have service from a wireless
service provider. Many of the features require special
network features. These features are not available on
all networks; other networks may require that you
make specific arrangements with your service provider
before you can use the network services. Your service
provider can give you instructions and explain what
charges will apply. Some networks may have
limitations that affect how you can use network
services. For instance, some networks may not support
all language-dependent characters and services.
Your service provider may have requested that certain
features be disabled or not activated in your device. If
so, these features will not appear on your device menu.
Your device may also have a special configuration such
as changes in menu names, menu order, and icons.
Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL)
that run on TCP/IP protocols. Some features of this
device, such as e-mail, browsing, multimedia messages,
8
For your safety
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 8 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 8 Jan 8, 2007 1:39:30 PM
and content downloading, require network support for
these technologies.
Enhancements, batteries,
and chargers
Always switch the device off and disconnect the charger
before removing the battery.
Check the model number of any charger before use with
this device. This device is intended for use when
supplied with power from the AC-4 and DC-4 chargers.
Warning: Use only batteries, chargers, and
enhancements approved by Nokia for use with this
particular model. The use of any other types may
invalidate any approval or warranty, and may be
dangerous.
For availability of approved enhancements, please
check with your dealer. When you disconnect the power
cord of any enhancement, grasp and pull the plug, not
the cord.
9
For your safety
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 9 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 9 Jan 8, 2007 1:39:30 PM
Basic information about your device
Note: Your service provider may have requested
that certain features be disabled or not activated in
your device. If so, they do not appear on your device
menu. Your device may also have been specially
configured for your network provider. This
configuration may include changes in menu names,
menu order and icons. Contact your service provider for
more information.
Model number: Nokia Exx-1.
Hereinafter referred to as Nokia Exx Communicator.
An extended version of this user guide is available on
the Nokia web site.
Welcome
Select > {No display_text mapping for
'qtn_apps_help_grid.menu_diy', locale='en'} >
Welcome.
When you switch on your device for the first time, the
Welcome application opens. Select from the following:
•Tutorial provides information about your device and
shows you how to use it. See "Tutorial
" on page 18.
•Transfer enables you to transfer content, such as
contacts and calendar entries, from a compatible
Nokia device. See "Transfer content between devices
" on page 19.
•Settings wizard helps you configure various settings.
See "Settings wizard " on page 18.
•Demo contains a link to a presentation of the device
features.
•Operator contains a link to your operator's home
portal.
Switch from cover use to
communicator
The applications and functions on the cover of your
device are the same as on the communicator. If you use
an application on the cover, and then open the
communicator, the application shows on the
communicator display in the same status as it was on
the cover. The cover display switches off. If you switch
back to the cover use, press on the cover for a few
seconds to open a list of active applications. Select the
application you were using. If you want the application
to continue automatically on the cover, select >
Tools > Settings > General > Personalization >
Display > {No display_text mapping for
'qtn_set_display_cover_to_desk.gsdisplplugindelta',
locale='en'} > {No display_text mapping for
'qtn_set_display_desk_off.gsdisplplugindelta',
locale='en'}.
Some applications contain a preview pane when they
are viewed from the communicator display. The
10
Basic information about your device
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 10 Jan 8, 2007 1:39:30 PM
preview pane is for viewing only; you cannot select or
open items from it.
If you have an active phone or net call and switch from
cover use to communicator, the loudspeaker activates
automatically. When you close the communicator, the
loudspeaker is muted and the audio comes through the
earpiece. If you have an active video call and use the
cover phone, the camera on the back of the device is
used. When you open the communicator, the camera
on the communicator is used.
Menu key, scroll key, and
Chr key
To access the applications in your device, press the
menu key . To return to the menu from an
application, leaving the application open in the
background, press . Press and hold to see a list of
applications that are open in the background. Leaving
applications running in the background increases the
demand on battery power and reduces the battery life.
Use the scroll key to move and make selections. With
the scroll key, you can move up, down, left, and right in
the menu or in different applications or lists. Press the
scroll key to open applications, files, or edit settings.
When writing text, press the Chr key to open a list of
special characters. Use the scroll key to move in the list
and select a character.
To add accented characters, press and hold the Chr key
and simultaneously press another key, such as A or E, as
many times as is needed before the character you want
is shown.
Menu
The menu is a starting point from which you can open
all applications in the device or on a memory card. The
menu contains applications and folders, which are
groups of similar applications.
All applications you install in the device yourself are by
default saved in the Installat. folder.
To open an application, scroll to it, and press the scroll
key.
To view the applications in a list, select Options >
Change view > {No display_text mapping for
'qtn_menu_view_list.appshelltheme', locale='en'}. To
return to the grid view, select Options > Change
view > {No display_text mapping for
'qtn_menu_view_grid.appshelltheme', locale='en'}.
To view the memory consumption of different
applications and data stored on the device or memory
card and to check the amount of free memory, select
Options > Memory details.
To create a new folder, select Options > New folder.
You cannot create folders inside folders.
To rename a new folder, select Options > Rename.
To rearrange the folder, scroll to the application you
want to move, and select Options > Move. A check mark
is placed beside the application. Scroll to a new location,
and select OK.
11
Basic information about your device
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 11 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 11 Jan 8, 2007 1:39:30 PM
To move an application to a different folder, scroll to
the application you want to move to another folder, and
select Options > Move to folder, the new folder, and
OK.
To download applications from the web, select
Options > Download applications.
Common actions in several
applications
You can find the following actions in several
applications:
To change the profile, or switch off or lock the device,
press the power key briefly.
If an application consists of several tabs, open a tab by
scrolling right or left.
To save the settings that you have configured in an
application, select Back.
To save a file, select Options > Save. There are different
saving options depending on the application you use.
To send a file, select Options > Send. You can send a
file in an e-mail or multimedia message, or using
Bluetooth connectivity or infrared.
To copy, press and hold the shift key, and select the text
with the scroll key. Press and hold the shift key, and
select Copy. To paste, scroll to where you want to paste
the text, press and hold the shift key, and select Paste.
This method may not work in applications that have
their own copy and paste commands.
To select different items, such as messages, files, or
contacts, scroll to the item you want to select. Select
Options > Mark/Unmark > Mark to select one item or
Options > Mark/Unmark > Mark all to select all items.
To select an object (for example, an attachment in a
document) scroll to the object so that square markers
appear on each side of the object.
Standby modes
Your device has two different standby modes: active
standby mode and standby mode.
Active standby
After you have switched on your device and it is ready
for use, but you have not entered any characters or
made other selections, the device is in the active
standby mode. In the active standby mode, you can
view different indicators such as network operator
indicators or indicators for alarms, and applications you
want to access fast.
To select applications that you want to access from
active standby, select > Tools > Settings >
General > Personalization > Standby mode > Active
standby apps..
To change the functions of the selection keys in active
standby, select > Tools > Settings > General >
Personalization > Standby mode > Shortcuts.
To use the basic standby mode, select > Tools >
Settings > General > Personalization > Standby
mode > Active standby > Off.
12
Basic information about your device
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 12 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 12 Jan 8, 2007 1:39:30 PM
Tip: To see the messages in a messaging folder
such as Inbox or mailbox in the active standby
mode, select > Messaging > Options >
Settings > Other and the folders in {No
display_text mapping for
'qtn_mce_settings_gen_active_idle.mcesetting
s_diy', locale='en'}.
Standby
In the basic standby mode, you can see your service
provider, time, and different indicators, such as
indicators for alarms.
To view the most recently dialed numbers, press the call
key. Scroll to a number or name, and press the call key
again to call the number.
To call your voice mailbox (network service), press and
hold 1.
To view calendar information, scroll right.
To write and send text messages, scroll left.
To change these shortcuts, select > Tools >
Settings > General > Personalization > Standby
mode > Shortcuts.
News ticker
Select > Tools > Settings > General >
Personalization > Standby mode > News ticker. Select
your news service and select On. This setting is only
available if in you have selected Standby mode > Active
standby > On.
The news ticker (network service) displays the news
pushed to your device using cell broadcast. You can
select channels from which the news is displayed. To
view the latest news in a separate Latest news view,
scroll to the area where the news text is scrolling across
the display, and press the scroll key. You can read a
maximum of 10 news clips. If there are 10 news clips
already in the device and a new one arrives, it replaces
the oldest clip.
News channels
To subscribe or unsubscribe to a news channel, open
the Latest news view and select Options > Settings >
Subscribed channels. The web page provided by your
service provider opens.
To view news from specific channels or to change the
news channel, open the Latest news view and select
Options > Channels.
To disable the news ticker, open the Latest news view
and select Options, your service, and Off.
Write text with the cover
keypad
Traditional text input
is shown on the top right of the display when you
are writing text using traditional text input.
and indicate the selected case.
indicates that the first letter of the sentence is written
13
Basic information about your device
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 13 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 13 Jan 8, 2007 1:39:30 PM
in uppercase and all the other letters are automatically
written in lowercase. indicates the number mode.
To write text with the keypad, press a number key 1–
9 repeatedly until the desired character appears. There
are more characters available for a number key than are
printed on the key. If the next letter is located on the
same key as the present one, wait until the cursor
appears, and enter the letter.
To insert a number, press and hold the number key.
To switch between the letter and number mode, press
and hold #.
To erase a character, press the clear key. Press and hold
the clear key to clear more than one character.
To access the most common punctuation marks, press
the 1 key. Press 1 repeatedly to reach the desired
punctuation mark.
To add special characters, press *. Scroll to the desired
character and press the scroll key.
To insert a space, press 0. To move the cursor to the next
line, press 0 three times.
To switch between the different character cases, press
#.
To select text, press and hold # and scroll right or left.
Predictive text input
1. To activate predictive text input, press # twice
quickly. This activates predictive text input for all
editors in the device. The indicator is shown
on the display.
2. To write the desired word, press 2–9. Press each key
only once for one letter.
3. When you have finished writing the word and it is
correct, scroll right to confirm it, or press 0 to add a
space.
If the word is not correct, press * repeatedly to view
the matching words the dictionary has found.
If the ? character is shown after the word, the word
you intended to write is not in the dictionary. To add
a word to the dictionary, select Spell, enter the word
(up to 32 letters) using traditional text input, and
select OK. The word is added to the dictionary. When
the dictionary is full, the new word replaces the
oldest added word.
Write the first half of a compound word; to confirm it,
scroll right. Write the last part of the compound word.
To complete the compound word, press 0 to add a
space.
To switch predictive text input off for all editors in the
device, press # twice quickly.
Change the writing language
When you are writing text, you can change the writing
language. For example, if you press the 6 key repeatedly
to reach a specific character, changing the writing
language gives you access to characters in a different
order.
If you are writing text using a non-Latin alphabet and
want to write Latin characters, for example e-mail or
web addresses, you may need to change the writing
language. To change the writing language, select
14
Basic information about your device
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 14 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 14 Jan 8, 2007 1:39:30 PM
Options > Writing language, and a writing language
that uses Latin characters.
Volume control
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume
may be extremely loud.
To adjust the earpiece volume during a phone call, scroll
left or right.
To adjust the volume when using the loudspeaker,
press Chr + or Chr + on the communicator.
To adjust the volume of Music player or the radio, scroll
left or right.
Profiles
Important: In the offline profile you cannot make
or receive any calls, or use other features that require
cellular network coverage. Calls may still be possible to
the official emergency number programmed into your
device. To make calls, you must first activate the phone
function by changing profiles. If the device has been
locked, enter the lock code.
Select > Tools > Profiles.
You can adjust and customize the ringing tones, alert
tones, and other device tones for different events,
environments, or caller groups. The profile currently in
use is shown at the top of the display in the standby
mode. However, if the active profile is Normal, only
today's date is shown.
The Offline profile prevents your device from
accidentally switching on, sending or receiving
messages, or using wireless LAN, Bluetooth, GPS, or FM
radio; it also closes any internet connection that may
be in operation when the profile is selected. The Offline
profile does not prevent you from establishing a
wireless LAN or Bluetooth connection at a later time, or
from restarting the GPS or FM radio, so comply with any
applicable safety requirements when establishing and
using these features.
Tip: To change the profile in any view, press the
power key briefly. Select the profile you want
to activate.
To create a new profile, select Options > Create new,
and define the settings.
To customize a profile, select a profile and Options >
Customize.
To change a profile, select a profile and Options >
Activate. If you select the Offline profile, you cannot
send or receive messages.
To delete a profile that you created, select Options >
Delete profile. You cannot delete the predefined
profiles.
Themes
Select > Tools > Themes.
With Themes, you can change the look of the display of
your device, such as the background image and colors.
15
Basic information about your device
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 15 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 15 Jan 8, 2007 1:39:30 PM
To change the theme used in all applications, select the
General folder.
To change the theme for a particular application, select
the application-specific folder.
To change the background image for the standby mode,
select the Wallpaper folder.
To select an image or write a text for the screen saver,
select the Power saver folder.
Memory
There are two types of memory into which you can save
data or install applications: device memory and
removable memory.
The device memory is a dynamic memory pool shared
by many applications. The amount of internal memory
available varies but cannot be increased past the
maximum factory setting. Data stored on the device,
such as software applications, images, and music,
consume the device memory.
Removable memory is a data storage that is not built
into your device, such as a SIM card or a memory card.
A SIM card stores information about the network
operator and contacts, for example. A memory card
serves as an external storage for software applications,
images, music, contacts, text, or any other form of
electronic data. High-capacity memory cards are
available.
To see how much memory is currently in use, how much
free memory remains, and how much memory is
consumed by each data type, select > Options >
Memory details > Phone memory or Memory card.
Tip: To ensure that you have adequate
memory, delete or transfer data regularly to a
memory card or computer.
Memory card
Select > Tools > Memory.
Your Nokia device supports the FAT16 and FAT32 file
system for memory cards. If you use a memory card
from another device or if you want to ensure
compatibility of the memory card with your Nokia
device, you may need to format the memory card with
your Nokia device. Formatting a memory card destroys
all data saved on the card.
You can insert and remove a memory card without
removing the battery or powering off the device. Do not
remove the memory card when the card is being
accessed. Removing the card in the middle of an
operation may damage the memory card as well as the
device, and data stored on the card may be corrupted.
If you cannot use a memory card in your device, you
may have the wrong type of memory card, the card may
not be formatted for your device, or the card has a
corrupted file system.
MicroSD
Use only compatible microSD cards approved by Nokia
for use with this device. Nokia uses approved industry
standards for memory cards, but some brands may not
be fully compatible with this device. Incompatible cards
16
Basic information about your device
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 16 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 16 Jan 8, 2007 1:39:30 PM
may damage the card and the device and corrupt data
stored on the card.
This device uses a microSD memory card.
To ensure interoperability, use only
compatible microSD cards with this device.
Check the compatibility of a microSD card with its
manufacturer or provider. Other memory cards than
microSD cards are not compatible with this device.
Using an incompatible memory card may damage the
memory card as well as the device, and data stored on
the incompatible card may be corrupted.
Use a memory card
To eject the memory card safely, select Options >
Remove memory card.
To format a memory card for your device, select
Options > Format memory card. When a memory card
is formatted, all data on the card is lost permanently.
Consult your retailer to find out if you must format the
memory card before you can use it.
To change the name of the memory card, select
Options > Memory card name.
You can protect a memory card with a password to
prevent unauthorized access. To set a password, select
Options > Set password. The password can be up to
eight characters long and is case-sensitive. The
password is stored in your device. You do not need to
enter it again while you use the memory card in the
same device. If you use the memory card in another
device, you are asked for the password. Not all memory
cards support password protection.
To remove the memory card password, select Options >
Remove password. When you remove the password,
the data on the memory card is not protected against
unauthorized use.
To open a locked memory card, select Options > Unlock
memory card. Enter the password.
To check the memory consumption of applications and
data, select Options > Memory details.
Help and tutorial
You can find answers to your questions while using the
device even with no user guide present, because your
device includes both a task-specific help and a tutorial.
Device help
To read instructions for the current view of the open
application, select Options > Help.
To browse the help topics and conduct searches,
select > {No display_text mapping for
'qtn_apps_help_grid.menu_diy', locale='en'} > {No
display_text mapping for
'qtn_apps_help_grid.menu_diy', locale='en'}. You can
select categories for which you want to see instructions.
Select a category, such as Messaging, to see what
instructions (help topics) are available. While you are
reading the topic, scroll left or right to see the other
topics in that category.
To switch between the application and help, press and
hold .
17
Basic information about your device
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 17 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 17 Jan 8, 2007 1:39:30 PM
Tutorial
Select > {No display_text mapping for
'qtn_apps_help_grid.menu_diy', locale='en'} >
Tutorial.
The tutorial provides you information about your
device and shows you how to use it.
Settings wizard
Select > Tools > Sett. wizard.
Settings wizard configures your device for operator
(MMS, GPRS, and internet), e-mail, push-to-talk
(network service), and video sharing (network service)
settings based on your network operator information.
To use these services, you may have to contact your
service provider to activate a data connection or other
services.
If Settings wizard is not available from your wireless
service provider, it may not appear in the menu of your
device. For more information on the availability of
Settings wizard, contact your service provider or dealer.
The availability of the different settings items in
Settings wizard depends on the features of the device,
SIM card, wireless service provider, and the availability
of the data in the Settings wizard database.
To start the wizard, select Start. When you use the
wizard for the first time, you are guided through the
settings configuration. If there is no SIM card inserted,
you need to select the home country of your wireless
service provider, and your service provider. If the
country or service provider suggested by the wizard is
not correct, select the correct one from the list. If the
settings configuration is interrupted, the settings are
not defined. After closing the wizard, you can start to
use the configured applications.
To access the main view of the Settings wizard after the
wizard has finished the settings configuration, select
OK.
If you are not able to use Settings wizard, visit the Nokia
phone settings web site at www.nokia.com.
Nokia PC Suite
You can install Nokia PC Suite from the DVD or from the
web. Nokia PC Suite can be used only with Windows
2000 and Windows XP. With Nokia PC Suite, you can
make backups, synchronize your device with a
compatible computer, move files between your device
and a compatible computer, or use your device as a
modem.
18
Basic information about your device
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 18 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 18 Jan 8, 2007 1:39:30 PM
Transfer content between devices
Select > Tools > Transfer.
You can transfer content, such as contacts, from a
compatible Nokia device to your Nokia Exx
Communicator using Bluetooth connectivity or
infrared. The type of content that can be transferred
depends on the device model. If the other device
supports synchronization, you can also synchronize
data between the other device and your Nokia Exx
Communicator.
If you transfer data from your previous device, the
device may require you to insert the SIM card. Your
Nokia Exx Communicator does not need a SIM card
when transferring data.
Transfer data with Bluetooth
1. In the information view, select Continue.
2. Select Via Bluetooth. Both devices must support the
selected connection type.
3. Activate Bluetooth in your other device, and select
Continue in your Nokia Exx Communicator to start
searching for devices with active Bluetooth
connectivity.
4. Select Stop in your Nokia Exx Communicator after it
has found your other device.
5. Select your other device from the list. You are asked
to enter a passcode (1 to 16 digits) on your Nokia
Exx Communicator. The passcode is used only once
to confirm this connection.
6. Enter the code on your Nokia Exx Communicator,
and select OK. Enter the passcode on your other
device, and select OK. The devices are now paired.
See "Pair devices" on page 58.
For some phone models, the Transfer data
application is sent to your other device as a
message. To install Transfer data on your other
device, open the message, and follow the
instructions on the display.
7. From your Nokia Exx Communicator, select the
content you want to transfer from your other
device.
Transfer data with infrared
1. In the information view, select Continue.
2. Select Via infrared. Both devices must support the
selected connection type.
3. Connect the two devices. See "Infrared
" on page 60.
4. From your Nokia Exx Communicator, select the
content you want to transfer from your other
device, and select OK.
Content is copied from the memory of the other device
to the corresponding location in your device. Copying
time depends on the amount of data to be transferred.
You can also cancel and continue later.
The necessary steps for data transfer may vary
depending on your device, and whether you have
19
Transfer content between devices
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 19 Jan 8, 2007 1:39:30 PM
interrupted data transfer earlier. The items that you can
transfer vary depending on the other device.
20
Transfer content between devices
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 20 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 20 Jan 8, 2007 1:39:30 PM
Telephone
Answer a call
Note: The actual invoice for calls and services
from your service provider may vary, depending on
network features, rounding off for billing, taxes, and so
forth.
To make and receive calls, the device must be switched
on, the device must have a valid SIM card installed, and
you must be located in a service area of the cellular
network.
To answer a call, press the call key.
To decline the call, press the end key.
To mute the ringing tone instead of answering a call,
select Silence.
When you have an active call and the call waiting
function is activated, press the call key to answer a new
incoming call. The first call is put on hold. To end the
active call, press the end key.
Make a call
Important: If the device has been locked, enter
the lock code to activate the phone function. When the
device is locked, calls may be possible to the official
emergency number. Making an emergency call in the
offline profile or when the device is locked requires that
the device recognize the number to be an official
emergency number. It is advisable to change the profile
or unlock the device by entering the lock code before
you make the emergency call.
To make a call, enter the phone number, including the
area code, and press the call key.
Tip: For international calls, add the + character
that replaces the international access code, and
enter the country code, area code (omit the
leading 0, if necessary), and phone number.
To end the call or cancel the call attempt, press the end
key.
To make a call using the saved contacts, select
Contacts in the standby mode. Enter the first letters of
the name, scroll to the name, and press the call key. See
"Contacts " on page 42.
To make a call using the log, press the call key to view
up to 20 numbers that you last called or attempted to
call. Scroll to the desired number or name, and press the
call key. See "Log " on page 28.
To adjust the volume of an active call, scroll right or left.
To switch from a voice call to a video call, select
Options > Switch to video call. The device ends the
voice call and makes a video call to the recipient.
21
Telephone
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 21 Jan 8, 2007 1:39:30 PM
Make a conference call
1. To make a conference call, enter a participant's
phone number, and press the call key.
2. When the participant answers, select Options >
New call.
3. When you have made a phone call to all the
participants, select Options > Conference to merge
the calls into a conference call.
To mute the microphone of your device during the call,
select Options > Mute.
To drop a participant from the conference call, scroll to
the participant, and select Options > Drop
participant.
To discuss privately with a conference call participant,
scroll to the participant, and select Options > Private.
Video calls
To be able to make a video call, you need to be in the
coverage of a UMTS network. For availability of and
subscription to video call services, contact your network
operator or service provider. While talking, you can see
a real-time, two-way video between you and the
recipient of the call, if the recipient has a compatible
mobile phone. The video image captured by the camera
in your device is shown to the video call recipient. A
video call can only be made between two parties.
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume
may be extremely loud.
To make a video call, enter the phone number or select
the recipient of the call from Contacts, and select
Options > Call > Video call. When the video call starts,
the camera on the back of the device is activated, if you
use the cover phone. If the communicator is open, the
camera on the communicator is activated. If the camera
is already in use, video sending is disabled. If the
recipient of the call does not want to send a video back
to you, a still image is shown instead. You can define
the still image in > Tools > Settings > Call >
Image in video call.
To disable the sending of audio, video, or video and
audio, select Options > Disable > Sending audio,
Sending video, or Sending aud. & video.
To use the loudspeaker for receiving audio, select
Options > Activate loudspeaker. To mute the
loudspeaker and use the earpiece, select Options >
Activate handset.
To swap the places of images, select Options > Change
image order.
To zoom the image on the display, select Options >
Zoom in or Zoom out.
To end the video call and make a new voice call to the
same recipient, select Options > Switch to voice call.
22
Telephone
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 22 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 22 Jan 8, 2007 1:39:30 PM
Video sharing
To share videos (network service) during a voice call,
you need to configure the session initiation protocol
settings at > Tools > Settings > Connection > SIP
settings. Contact your service provider for the correct
settings.
You also need to set the network mode to UMTS at >
Tools > Settings > Phone > Network.
Share a video
1. Make a phone call to the selected recipient. The
recipient needs to have a compatible phone. You
can start sharing a video once the phone call is
established and your device has been registered to
the SIP server.
2. To send live video or a video clip from your device,
select Options > Share video > Live video or
Recorded clip. To preview the clip, select Options >
Play.
3. Select the recipient from Contacts, or enter the
recipient's phone number or SIP address manually
to send an invitation to the recipient. Sharing begins
automatically when the recipient accepts the video
sharing.
4. To end sharing the video, select Stop. The voice call
continues normally.
Receive a video sharing invitation
When you receive a video sharing invitation, a message
is displayed showing the caller’s name or SIP address.
To accept the invitation and begin the sharing session,
select Accept.
To reject the invitation, select Reject. The voice call
continues normally.
Net calls
Your device supports voice calls over the internet (net
calls). Your device attempts emergency calls primarily
over cellular networks. If an emergency call using
cellular networks is not successful, your device
attempts an emergency call through your net call
provider. Due to the established nature of cellular
telephony, you should use cellular networks for
emergency calls, if possible. If you have cellular network
coverage available, make sure that your cellular phone
is switched on and ready to make calls before you
attempt an emergency call. The capability for an
emergency call using internet telephony depends on
the availability of a WLAN network and your net call
provider's implementation of emergency call
capabilities. Contact your net call provider to check the
internet telephony emergency call capability.
Select > Connectivity > Internet tel..
With the net call service (network service), you can
make and receive calls over the internet using the VoIP
(voice over internet protocol) technology. Net calls can
be established between computers, between mobile
23
Telephone
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 23 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 23 Jan 8, 2007 1:39:30 PM
phones, and between a VoIP device and a traditional
telephone. To make or receive a net call, your device
must be within WLAN coverage, for example.
The availability of the net call service may vary
according to your country or area.
Create a net call profile
Before you can make net calls, you need to create a net
call profile.
1. Select > Tools > Settings > Connection > SIP
settings > Options > Add new, and enter the
required information. Ensure that Registration is set
to Always on. Contact your net call provider for the
correct settings.
2. Select Proxy server > Transport type > {No
display_text mapping for 'qtn_sip_auto.gs_voip',
locale='en'}.
3. Select Back until you return to the Connection
settings main view.
4. Select Internet tel. > Options > New profile. Enter
a name for the profile, and select the SIP profile you
just created.
To set the created profile to be used when connecting
to the net call service automatically, select >
Connectivity > Internet tel. > Preferred profile.
To login to the net call service manually, select
Registration > When needed, and Transport type >
UDP or TCP in the SIP settings when creating a net call
profile.
Connect to the net call service
To make or receive a net call, your device must be
connected to a net call service. If you have selected
automatic login, your device automatically connects to
the net call service. If you login to the service manually,
choose an available network from the list, and select
Select.
The list of networks is refreshed automatically every 15
seconds. To refresh the list manually, select Options >
Refresh. Use this option, if your WLAN is not shown on
the list.
To select a net call service for outgoing calls if the device
is connected to more than one service, select Options >
Change service.
To configure new services, select Options > Configure
service. This option is shown only if there are services
that have not been configured.
To save the network to which you are currently
connected, select Options > Save network. The saved
networks are marked with a star on the list of networks.
To connect to a net call service using a hidden WLAN.
select Options > Use hidden network.
To end the connection to a net call service, select
Options > Disconnect from serv..
Make net calls
You can make a net call from all applications where you
can make a regular voice call. For example in Contacts,
24
Telephone
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 24 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 24 Jan 8, 2007 1:39:30 PM
scroll to the desired contact, and select Call > Options >
Internet call.
To make a net call in the standby mode, enter the phone
number or internet address, and press the call key.
To make a net call with the cover keypad to an address
that does not start with a digit, press any number key
when the device is in standby mode, then press # for a
few seconds to clear the display and to switch the
device from the number mode to the letter mode. Enter
the address, and press the call key.
To set net call as the preferred call type for outgoing
calls, select > Connectivity > Internet tel. >
Options > Settings > Preferred call type > Internet
call. When your device is connected to a net call service,
all calls are made as net calls.
1-touch dialing
Select > Tools > Settings > Phone > Call > 1-
touch dialing > On.
1-touch dialing allows you to make a call by pressing
and holding a number key in the standby mode.
To assign a number key to a phone number, select >
Tools > 1-touch. Scroll to the number key (2 - 9) on the
display, and select Options > Assign. Select the desired
number from Contacts.
To delete the phone number assigned to a number key,
scroll to the 1-touch dialing key, and select Options >
Remove.
To modify a phone number assigned to a number key,
scroll to the 1-touch dialing key, and select Options >
Change.
Call forward settings
Select > Tools > Settings > Phone > Call
forwarding.
Forward incoming calls to your voice mailbox or to
another phone number. For details, contact your service
provider.
Select to forward voice, data, or fax calls, and select from
the following options:
•All voice calls, All data calls, or All fax calls — Forward
all incoming voice, data, or fax calls.
•If busy — Forward incoming calls when you have an
active call.
•If not answered — Forward incoming calls after your
device rings for a specified period of time. Define the
time you let the device ring before forwarding the
call in the Delay time: field.
•If out of reach — Forward calls when the device is
switched off or out of network coverage.
•If not available — Activate the last three settings at
the same time. This option forwards calls if your
device is busy, not answered, or out of reach.
To check the current forwarding status, scroll to the
forwarding option, and select Options > Check status.
To stop forwarding calls, scroll to the forwarding
option, and select Options > Cancel.
Call restriction and call forwarding cannot be active at
the same time.
25
Telephone
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 25 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 25 Jan 8, 2007 1:39:30 PM
Call restriction
Select > Tools > Settings > Phone > Call
restriction.
You can restrict the calls that can be made or received
with the device (network service). To change the
settings, you need the restriction password from your
service provider. Call restriction affects all calls,
including data calls. Call restriction and call forwarding
cannot be active at the same time.
When calls are restricted, calls may be possible to the
official emergency number programmed into your
device.
To restrict calls, select Voice call restriction, and select
from the following options:
•Outgoing calls — Prevent making voice calls with
your device.
•Incoming calls — Restrict incoming calls.
•International calls — Prevent calling to foreign
countries or regions.
•Incoming calls if roaming — Restrict incoming calls
when outside your home country.
•International calls except to home
country — Prevent calls to foreign countries or
regions, but allow calls to your home country.
To check the status of voice call restriction, select the
restriction option, and select Options > Check status.
To stop all voice call restrictions, select a restriction
option, and select Options > Cancel all restrict..
Net call restriction
To restrict net calls, select > Tools > Settings >
Call restriction > Internet call restriction.
To reject net calls from anonymous callers, select
Anonymous call restriction > On.
Change the restriction password
To change the password used for restricting voice, fax,
and data calls, select > Tools > Settings > Call
restriction > Voice call restriction > Options > Edit
restriction passwd.. Enter the current code, then the
new code twice. The restriction password must be four
digits long. For details, contact your service provider.
Send touch tones
You can send touch tones during an active call to control
your voice mailbox or other automated phone services.
Send a touch tone sequence
1. Make a call, and wait until the other end answers.
2. Select > Options > Send touch tones.
3. Enter the touch tone sequence, or select a
predefined sequence.
Attach a touch tone sequence to a contact card
1. Select > Contacts. Open a contact, and select
Options > Edit > Options > Add detail > Touch
tones.
26
Telephone
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 26 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 26 Jan 8, 2007 1:39:30 PM
2. Enter the tone sequence. To insert a pause of about
2 seconds before or between touch tones, enter p.
To set the device to send the touch tones only after
you select Send touch tones during a call, enter w.
3. Select Done.
Voice mail
Select > Tools > Call mailbox.
When you open the Voice mail application for the first
time, you are asked to enter the number of your voice
mailbox. To change the number, select Options >
Change number.
To call your voice mail, select Options > Call voice
mailbox.
To call your voice mailbox in the standby mode, press
and hold 1; or press 1 and then the call key.
27
Telephone
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 27 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 27 Jan 8, 2007 1:39:30 PM
Log
Select > Log.
Log stores information about the communication
history of the device. The device registers missed and
received calls only if the network supports these
functions, the device is switched on and within the
network service area.
To view recently missed, received, and dialed calls,
select Recent calls.
Tip: To open Dialed numbers in the standby
modes, press the call key.
To view the approximate duration of calls to and from
your device, select Call timers.
To view the amount of data transferred during packet
data connections, select Packet data.
Monitor all
communications
To monitor all voice calls, text messages, or data
connections registered by the device, open the general
log tab.
To view detailed information about a communication
event, scroll to it, and press the scroll key.
Tip: Subevents, such as a text message sent in
more than one part and packet data
connections, are logged as one communication
event. Connections to your mailbox,
multimedia messaging center, or web pages
are shown as packet data connections.
To add the phone number from a communication event
to Contacts, select Options > Save to Contacts, and
select a new or an existing contact.
To copy the number, for example to paste it to a text
message, select Options > Copy number.
To view a single type of communication event or
communication events with one other party, select
Options > Filter, and select the desired filter.
To erase the contents of the log, recent calls register,
and messaging delivery reports permanently, select
Options > Clear log. To erase a single event, select the
event and Options > Delete.
Log settings
Select Options > Settings.
To set the time for keeping all communication events
in the log, select Log duration, and the time. If you select
No log, all log contents are permanently deleted.
To set the device to display the duration of a call during
the call, select Show call duration > Yes.
28
Log
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 28 Jan 8, 2007 1:39:30 PM
Messaging
Select > Messaging.
In Messaging (network service), you can send and
receive text messages, multimedia messages, and e-
mail messages. You can also receive web service
messages, cell broadcast messages, and special
messages containing data, and send service
commands.
Before sending or receiving messages, you may need to
do the following:
•Insert a valid SIM card in the device and be located
in the service area of a cellular network.
•Verify that the network supports the messaging
features you want to use and that they are activated
on your SIM card.
•Define the internet access point (IAP) settings on the
device. See "Access points" on page 87.
•Define the e-mail account settings on the device. See
"E-mail account settings" on page 39.
•Define the text message settings on the device. See
"Text message settings" on page 38.
•Define the multimedia message settings on the
device. See "Multimedia message
settings" on page 38.
The device may recognize the SIM card provider and
automatically configure some of the message settings.
If not, you may need to define the settings manually; or
contact your service provider to configure the settings.
Messages and data received using Bluetooth
connectivity or infrared are stored in the Inbox folder.
E-mail messages are stored in Mailbox. Messages that
you have been writing can be stored in the Drafts folder.
Messages that are waiting to be sent are stored in the
Outbox folder, and messages that have been sent,
excluding Bluetooth and infrared messages, are stored
in the Sent folder.
Tip: Messages are placed in Outbox, for
example, when your device is outside network
coverage. You can also schedule e-mail
messages to be sent the next time you connect
to your remote mailbox.
To request the network to send you a delivery report of
the text messages and multimedia messages you have
sent (network service), select Options > Settings >
Text message or Multimedia message > Receive
report. The reports are saved in the Reports folder.
Organize messages
To create a new folder to organize your messages,
select My folders > Options > New folder.
To rename a folder, select Options > Rename folder.
You can only rename folders that you have created.
To move a message to another folder, select Options >
Move to folder, the folder, and OK.
29
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 29 Jan 8, 2007 1:39:30 PM
To sort messages in a specific order, select Options >
Sort by. You can sort the messages by Date, Sender,
Subject, or Message type.
To view the properties of a message, select the message
and Options > Message details.
Message reader
The message reader reads your received messages
aloud.
To play a message, press and hold the left selection key
when you receive a text message.
To start reading a message in Inbox or mailbox, select
Options > Play.
To start reading the next message in Inbox or mailbox,
scroll down. To start reading the message again, scroll
up. In the beginning of the message, scroll up to hear
the previous message.
To adjust the volume, scroll left or right.
To pause the reading, press the left selection key briefly.
To continue, press the left selection key briefly again.
To end the reading, press the end key.
To set the voice properties, select > Tools >
Speech.
Text messages
Select > Messaging.
Your device supports the sending of text messages
beyond the character limit for a single message. Longer
messages are sent as a series of two or more messages.
Your service provider may charge accordingly.
Characters that use accents or other marks, and
characters from some language options, take up more
space, limiting the number of characters that can be
sent in a single message.
1. To write a text message, select New message >
Text message.
2. In the To field, enter a recipient's number, or press
the scroll key to add a recipient from Contacts. If you
enter more than one number, separate the numbers
with a semicolon.
3. Enter the text of the message. To use a template,
select Options > Insert > Template.
4. Select Options > Send.
Picture messages
Select > Messaging.
Note: The picture message function can be used
only if it is supported by your service provider. Only
compatible devices that offer picture message features
can receive and display picture messages. The
appearance of a message may vary depending on the
receiving device.
To view a picture message, open the message from the
Inbox folder.
30
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 30 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 30 Jan 8, 2007 1:39:30 PM
Forward a picture message
1. To forward the message, select Options >
Forward.
2. In the To field, enter a recipient's number, or press
the scroll key to add a recipient from Contacts. If you
enter more than one number, separate the numbers
with a semicolon.
3. Enter the text of your message. The text can have
120 characters. To use a template, select Options >
Insert > Template.
4. Select Options > Send.
Multimedia messages
Only devices that have compatible features can receive
and display multimedia messages. The appearance of
a message may vary depending on the receiving device.
Select > Messaging.
A multimedia message (MMS) can contain text and
objects such as images, sound clips, or video clips.
Before you can send or receive multimedia messages
on your device, you must define the multimedia
message settings. Your device may have recognized the
SIM card provider and automatically configured the
multimedia message settings. If not, contact your
service provider. See "Multimedia message
settings" on page 38.
Create and send multimedia
messages
1. To create a new message, select New message >
Multimedia message.
2. In the To field, enter a recipient's number or e-mail
address, or press the scroll key to add a recipient
from Contacts. If you enter more than one number
or e-mail address, separate them with a semicolon.
3. In the Subject field, enter a subject for the message.
To change the fields that are visible, select Options >
Address fields.
4. Enter the text of the message, and select Options >
Insert object to add media objects. You can add
objects such as Image, Sound clip, or Video clip.
The wireless network may limit the size of MMS
messages. If the inserted picture exceeds this limit,
the device may make it smaller so that it can be sent
by MMS.
5. Each slide of your message can contain only one
video or sound clip. To add more slides to your
message, select Options > Insert new > Slide. To
change the order of slides in your message, select
Options > Move.
6. To preview a multimedia message before sending
it, select Options > Preview.
7. Select Options > Send.
To delete an object from a multimedia message, select
Options > Remove.
To set the sending options for the current multimedia
message, select Options > Sending options.
31
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 31 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 31 Jan 8, 2007 1:39:30 PM
Create presentations
Creating multimedia presentations is not possible if the
MMS creation mode setting is set to Restricted. To
change the setting, select Messaging > Options >
Settings > Multimedia message > MMS creation
mode > Free.
1. To create a presentation, select New message >
Multimedia message.
2. In the To field, enter a recipient's number or e-mail
address, or press the scroll key to add a recipient
from Contacts. If you enter more than one number
or e-mail address, separate them with a semicolon.
3. Select Options > Create presentation and a
presentation template. A template may define
which media objects you can include in the
presentation, where they appear, and which effects
are displayed between images and slides.
4. Scroll to the text area and enter the text.
5. To insert images, sound, video, or notes in your
presentation, scroll to the corresponding object
area, and select Options > Insert.
6. To add slides, select Insert > New slide.
To preview the presentation, select Options >
Preview. Multimedia presentations may only be viewed
in compatible devices that support presentations. They
may appear different in different devices.
To select the background color for the presentation and
background images for different slides, select
Options > Background settings.
To set effects between images or slides, select
Options > Effect settings.
View presentations
To view a presentation, open the multimedia message
from the Inbox folder. Scroll to the presentation, and
press the scroll key.
To pause the presentation, press either selection key.
To resume playing the presentation, select Options >
Continue.
If the text or images are too large to fit on the display,
select Options > Activate scrolling, and scroll to see the
entire presentation.
To find phone numbers and e-mail or web addresses in
the presentation, select Options > Find. You may use
these numbers and addresses to make calls, send
messages, or create bookmarks, for example.
E-mail messages
To receive and send e-mail, you must have a remote
mailbox service. This service may be offered by an
internet service provider, a network service provider, or
your company. Your device is compliant with internet
standards SMTP, IMAP4 (revision 1), and POP3, and with
different vendor-specific e-mail solutions. Other e-mail
providers may offer services with different settings or
features than those described in this user guide.
Contact your e-mail provider or service provider for
more details.
32
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 32 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 32 Jan 8, 2007 1:39:30 PM
Before you can send, receive, retrieve, reply to, and
forward e-mail on your device, you must also do the
following:
•Configure an internet access point (IAP). See "Access
points" on page 87.
•Set up an e-mail account, and define the e-mail
settings correctly. See "E-mail account
settings" on page 39.
Follow the instructions from your remote mailbox and
internet service providers. Contact your network and
internet service providers or operator for the correct
settings.
Set up your e-mail with the
mailbox guide
If you select > Messaging > Mailbox, and have not
set up your e-mail account, you are prompted to do so.
To start setting up the e-mail account with the mailbox
guide, select Yes.
1. To start entering the e-mail settings, select Start.
2. In Mailbox type, select IMAP4 or POP3, and select
Next.
Tip: POP3 is a version of the post office
protocol that is used to store and retrieve
e-mail or internet mail messages from a
server. IMAP4 is a version of the internet
message access protocol that lets you
access and manage e-mail messages while
the messages are still on the e-mail server.
You can then choose which messages to
download to your device.
3. In My e-mail address, enter your e-mail address.
Select Next.
4. In Incoming mail server, enter the name of the
remote server that receives your e-mail, and select
Next.
5. In Outgoing mail server, enter the name of the
remote server that sends your e-mail, and select
Next. Depending on your mobile operator, you
might have to use your mobile operator's outgoing
mail server instead of your e-mail provider's.
6. In Access point, select the internet access point your
device should use when it retrieves the e-mail. If you
select Always ask, each time the device starts to
retrieve e-mail, it asks which internet access point
it should use. Select Next.
7. Enter a name for your new mailbox, and select
Finish.
When you create a new mailbox, the name you give to
the mailbox replaces Mailbox in the Messaging main
view. You can have up to six mailboxes.
If you have defined several mailboxes, select one of
them as your default mailbox. That mailbox is used
every time you start composing a new e-mail message.
To define the default mailbox, select Options >
Settings > E-mail > {No display_text mapping for
'qtn_mce_settings_mail_default.mcesettings_diy',
locale='en'} and the mailbox.
33
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 33 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 33 Jan 8, 2007 1:39:30 PM
Connect to a remote mailbox
E-mail addressed to you is not automatically received
by your device, but by your remote mailbox. To read
your e-mail, you must first connect to the remote
mailbox; then select the e-mail messages you wish to
retrieve into your device.
1. To retrieve received e-mail messages to your device
and view them, select your mailbox in the
Messaging main view. When the device asks
Connect to mailbox?, select Yes.
2. Select Options > Retrieve e-mail > New to retrieve
new messages that you have neither read nor
retrieved, Selected to retrieve only messages you
select from the remote mailbox, or All to retrieve all
messages not previously retrieved.
3. To manage your e-mail offline to save in connection
costs and work in conditions that do not allow a
data connection, select Options > Disconnect to
disconnect from the remote mailbox. Any changes
you make in the remote mailbox folders while
offline, take effect in your remote mailbox the next
time you go online and synchronize.
Read and reply to e-mail
Important: Exercise caution when opening
messages. E-mail messages may contain malicious
software or otherwise be harmful to your device or PC.
To read a received e-mail, open it from the mailbox.
To open an attachment, select Options >
Attachments. Scroll to the attachment, and press the
scroll key.
To reply only to the sender of an e-mail, select Options >
Reply > To sender.
To reply to all recipients of an e-mail, select Options >
Reply > To all.
To delete an attachment from an e-mail that you are
sending, select the attachment and Options >
Remove.
Tip: If you reply to an e-mail that contains
attached files, the attachments are not
included in the reply. If you forward the
received e-mail, the attachments are included.
To set the message priority, select Options > Sending
options > Priority.
To set the sending time for the e-mail message, select
Options > Sending options > Send message. Select
Immediately, or select When conn. avail. if you are
working offline.
To call the sender of the e-mail message, if the sender
can be found in Contacts, select Options > Call.
To reply to the sender of the e-mail with an audio
message or multimedia message, select Options >
Create message.
To forward an e-mail, select Options > Forward.
34
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 34 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 34 Jan 8, 2007 1:39:30 PM
Delete messages
To free up memory space on your device, regularly
delete messages from the Inbox and Sent folders, and
delete retrieved e-mail messages.
To delete e-mail from the device only, and keep the
original on the server, select Options > Delete > {No
display_text mapping for
'qtn_mce_pop_up_phone_only.imum_diy', locale='en'}.
To delete e-mail both from the device and the remote
server, select Options > Delete > {No display_text
mapping for
'qtn_mce_pop_up_phone_server.imum_diy',
locale='en'}.
To cancel the deleting, select Options > Restore.
Subfolders in your remote e-mail
If you create subfolders in your IMAP4 mailboxes on a
remote server, you can view and manage these folders
with your device when you subscribe to them. You can
only subscribe to folders in your IMAP4 mailboxes.
To view folders in your IMAP4 mailbox, establish a
connection, and select Options > E-mail settings >
Retrieval settings > Folder subscriptions.
To view a remote folder, select a folder and Options >
Subscribe. Every time you go online, the subscribed
folders are updated. This may take some time if the
folders are large.
To update the list of folders, select a folder and
Options > Update folder list.
Special messages
Select > Messaging.
You can receive special messages that contain data,
such as operator logos, ringing tones, bookmarks, or
internet access or e-mail account settings.
To save the contents of these messages, select
Options > Save.
Send service commands
You can send a service request message (also known as
a USSD command) to your service provider and request
activation for certain network services. Contact your
service provider for the service request text.
To send a service request message, select Options >
Service command. Enter the service request text, and
select Options > Send.
Receive cell broadcast messages
To receive messages on various topics, such as weather
or traffic conditions, from your service provider, select
Options > Cell broadcast (network service). For
available topics and relevant topic numbers, contact
your service provider. Cell broadcast messages cannot
be received in UMTS (3G) networks. A packet data
connection may prevent cell broadcast reception.
35
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 35 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 35 Jan 8, 2007 1:39:30 PM
Instant messaging
Select > Connectivity > IM.
Instant messaging (IM) (network service) allows you to
converse with other people using instant messages and
join discussion forums (IM groups) with specific topics.
Various service providers maintain IM servers that you
can log in to after you register to an IM service. Service
providers may differ in their support of features.
If IM is not available from your wireless service provider,
it may not appear in the menu of your device. Contact
your service provider for more information about
signing up for IM services and costs of services. For more
information on IM settings, contact your service
provider.
You may receive the settings in a special text message
from the service provider that offers the IM service. If
not, enter the settings manually.
Define IM settings
To define the IM application settings, select Options >
Settings > IM settings. You can, for example, set your
screen name and IM alert tones.
To converse with an IM user or users, and to view and
edit your IM contacts, you must log into an instant
messaging server. To add an IM server, select Options >
Settings > Server settings > Servers. Ask your service
provider for the correct settings. To set the server as the
one to which your device automatically logs in, select
Options > Settings > Server settings > Default
server.
To define how your device connects to the IM server,
select Options > Settings > Server settings > IM login
type. To establish a connection between your device
and the default server automatically, select Automatic.
To automate the connection only when in your home
network, select Auto in home netw. To connect to the
server when you open the IM application, select On app.
start-up. To connect to the server manually, select
Manual and log into the server in the IM main view by
selecting Options > Log in. Enter your user ID and
password at the prompt. You can obtain the user name,
password, and other settings to log in from your service
provider when you register for the service.
Start a conversation
Open Conversations.
To search for IM users and user IDs, select IM contacts >
Options > New IM contact > Search. You can search by
User's name, User ID, Phone number, and E-mail
address.
To view a conversation, select a participant.
To continue the conversation, enter your message, and
select Options > Send.
To return to the conversations list without closing the
conversation, select Back. To close the conversation,
select Options > End conversation.
To start a new conversation, select Options > New
conversation. You can start a new conversation with a
contact while you are inside an active conversation.
However, you cannot have two active conversations
with the same contact.
36
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 36 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 36 Jan 8, 2007 1:39:30 PM
To insert an image to an instant message, select
Options > Send image, and select the image you want
to send.
To save a conversation participant to your IM contacts,
select Options > Add to IM contacts.
To save a conversation, while in the conversation view,
select Options > Record chat. The conversation is saved
as a text file that can be opened and viewed in the Notes
application.
IM groups
Open IM groups. IM groups is available only if you are
logged into an IM server, and the server supports IM
groups.
To create an IM group, select Options > Create new
group.
To join an IM group or to continue a group conversation,
scroll to the group, and press the scroll key. Enter a
message, and select Options > Send.
To join an IM group that is not on the list, but for which
you know the group ID, select Options > Join new
group.
To leave the IM group, select Options > Leave IM
group.
To search for IM groups and group IDs, select IM
groups > Options > Search. You can search by Group
name, Topic, and Members (user ID).
To add an IM user to the group, select Options > Add
member. Select a user from your IM contacts or enter
the contact ID.
To remove a member from the IM group, select
Options > Remove.
To provide members with editing rights to the group,
select Options > Add editor. Select a user from your IM
contacts or enter the ID of the user. IM users with editing
rights can edit group settings and invite other users to
join the group or ban them from the group.
To remove editing rights from a group member, select
Options > Remove.
To prevent IM users from joining the group, select
Options > Add to banned list. Select a user from your
IM contacts or enter the ID of the user.
To allow a banned user to join the group, select
Options > Remove.
Service messages
Select > Messaging.
Service messages are sent to your device by service
providers. Service messages may contain notifications
such as news headlines, services, or links through which
the message content can be downloaded.
To define the service message settings, select Options >
Settings > Service message.
To download the service or message content, select
Options > Download message.
37
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 37 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 37 Jan 8, 2007 1:39:30 PM
To view information about the sender, web address,
expiration date, and other details of the message
before downloading it, select Options > Message
details.
Messaging settings
Select > Messaging > Options > Settings.
Fill in all fields marked with Must be defined or with a
red asterisk.
Your device may recognize the SIM card provider and
configure the correct text message, multimedia
message, and GPRS settings automatically. If not,
contact your service provider for the correct settings,
order the settings from your service provider in a
configuration message, or use the Settings wizard
application.
Text message settings
Select > Messaging > Options > Settings > Text
message.
Select from the following:
•Message centers — View the available message
centers for your device.
•Message center in use — Select a message center to
send the message.
•Character encoding — Select Reduced support to use
automatic character conversion to another
encoding system when available.
•Receive report — Select Yes if you want the network
to send you delivery reports on your messages
(network service).
•Message validity — Select how long the message
center resends your message if the first attempt fails
(network service). If the recipient cannot be reached
within the validity period, the message is deleted
from the message center.
•Message sent as — Convert the message to another
format, such as Text, Fax, Paging or E-mail. Change
this option only if you are sure that your message
center is able to convert text messages into these
other formats. Contact your network operator.
•Preferred connection — Select the preferred method
of connection when sending text messages from
your device.
•Reply via same center — Select whether you want
the reply message to be sent using the same text
message center number (network service).
Multimedia message settings
Select > Messaging > Options > Settings >
Multimedia message.
Define the following settings:
•Image size — Select Small or Large to scale images
in multimedia messages. Select Original to maintain
the original image size.
•MMS creation mode — Select Restricted to have your
device prevent you from including content in
multimedia messages that may not be supported by
the network or the receiving device. To receive
warnings about including such content, select
38
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 38 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 38 Jan 8, 2007 1:39:30 PM
Guided. To create a multimedia message with no
restrictions on attachment type, select Free. If you
select Restricted, creating multimedia presentations
is not possible.
•Access point in use — Select the default access point
to connect to the multimedia message center. You
may not be able to change the default access point
if it is preset in your device by your service provider.
•Multimedia retrieval — Select Always automatic to
receive multimedia messages always automatically,
Auto in home netw. to receive notification of a new
multimedia message that you can retrieve from the
message center (for example, when you are
traveling abroad and are outside your home
network), Manual to retrieve multimedia messages
from the message center manually, or Off to prevent
receipt of any multimedia messages.
•Allow anon. msgs. — Select whether you want to
receive messages from unknown senders.
•Receive ads — Select whether you want to receive
messages defined as advertisements.
•Receive report — Select Yes to have the status of the
sent message to be shown in the log (network
service). Receiving a delivery report of a multimedia
message that has been sent to an e-mail address
may not be possible.
•Deny report sending — Select Yes to not send
delivery reports from your device for received
multimedia messages.
•Message validity — Select how long the messaging
center tries to send the message (network service).
If the recipient of a message cannot be reached
within the validity period, the message is removed
from the multimedia messaging center. Maximum
time is the maximum amount of time allowed by the
network.
E-mail account settings
Select > Messaging > Options > Settings > E-
mail.
If you try to edit mailbox settings but have not set up
an e-mail account, the mailbox guide opens and helps
you set up your e-mail account.
If you have defined a mailbox, scroll to it, and press the
scroll key to edit the settings.
The settings available for editing may vary. Some
settings may be preset by your service provider.
User settings
Select the e-mail account, and Options > Edit > User
settings, and define the following settings:
•My name — Enter a name to appear before your e-
mail address when you send e-mail.
•{No display_text mapping for
'qtn_mbxs_settings_def_replyto.imum_diy',
locale='en'} — Select whether you want replies to be
redirected to a different address. Select {No
display_text mapping for
'qtn_mbxs_settings_def_replyto_on.imum_diy',
locale='en'}, and enter the e-mail address to which
you want to direct the replies. You can only enter one
address to which replies are directed.
•{No display_text mapping for
'qtn_mbxs_settings_def_delete_messages.imum_diy
', locale='en'} — Select whether you want to delete
39
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 39 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 39 Jan 8, 2007 1:39:30 PM
the e-mail messages only from the device or from
both the device and the server. Select {No
display_text mapping for
'qtn_mbxs_settings_def_allwaysask.imum_diy',
locale='en'} if you want to confirm from where the
e-mail should be deleted every time you delete an e-
mail.
•Send message — Select to send the e-mail
immediately or when a connection is available.
•Send copy to self — Select whether you want to save
a copy of the e-mail to your remote mailbox and to
the address defined in My e-mail address in the
Outgoing e-mail settings.
•Include signature — Select whether you want to
attach a signature to your e-mail messages.
•New e-mail alerts — Select whether you want to be
notified of a new received e-mail message with a
tone and a note.
Retrieval settings
Select the e-mail account, and Options > Edit >
Retrieval settings, and define the following settings:
•E-mail to retrieve (for POP3 mailboxes only) — Select
whether you want to retrieve only the e-mail header
information such as sender, subject and date, e-mail,
or e-mail with attachments.
•Retrieval amount — Select the number of e-mail
messages you want to retrieve from the remote
server to your mailbox.
•IMAP4 folder path (for IMAP4 mailboxes
only) — Define the folder path for folders to be
subscribed.
•Folder subscriptions (for IMAP4 mailboxes
only) — Subscribe to other folders in the remote
mailbox and retrieve content from those folders.
Automatic retrieval settings
Select the e-mail account, select Options > Edit >
Automatic retrieval, and define the following settings:
•E-mail retrieval — Select Enabled to retrieve new e-
mail messages automatically from your remote
mailbox, or Only in home netw. to retrieve new e-
mail messages automatically from your remote
mailbox only when you are in your home network
and not, for example, traveling.
•Retrieval days — Select the days on which e-mail is
retrieved to your device.
•Retrieval hours — Define the hours between which
the e-mail is retrieved.
•Retrieval interval — Select the interval between
retrieving new e-mail messages.
•E-mail notifications — Select whether you want to
receive notifications on received e-mail.
Cell broadcast settings
Select > Messaging > Options > Settings > Cell
broadcast.
Select from the following:
•Reception — Select On to receive cell broadcast
messages.
•Language — Select the languages in which you want
to receive cell broadcast messages.
40
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 40 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 40 Jan 8, 2007 1:39:30 PM
•Topic detection — Select On to display new topics in
the cell broadcast topics list.
Other settings
Select > Messaging > Options > Settings >
Other.
Select from the following:
•Save sent messages — Select whether to store sent
messages in the Sent folder.
•Number of saved msgs. — Enter the number of sent
messages to save. When the limit is reached, the
oldest message is deleted.
•Memory in use — Select where to save your
messages. You can save messages to the memory
card only if a memory card is inserted.
•{No display_text mapping for
'qtn_mce_settings_folder_view.mcesettings_diy',
locale='en'} — Define how you want the messages
in the Inbox to be shown.
41
Messaging
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 41 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 41 Jan 8, 2007 1:39:30 PM
Contacts
Select > Contacts.
You can save and update contact information, such as
phone numbers, home addresses, or e-mail addresses
of your contacts. You can add a personal ringing tone
or a thumbnail image to a contact. You can also create
contact groups, which allow you to send text messages
or e-mail to many recipients at the same time. You can
add received contact information (business cards) to
Contacts. Contact information can only be sent to or
received from compatible devices.
Copy contacts between SIM
and device memory
If you already have contacts saved on your SIM card, you
can copy them to the device memory.
To copy contacts from a SIM card to the device memory,
select Options > SIM contacts > SIM directory. Mark the
contacts to copy, or select Options > Mark/Unmark >
Mark all to copy all contacts. Select Options > Copy to
Contacts.
To copy contacts from the device memory to a SIM card,
select Options > Copy to SIM directory. Mark the
contacts you want to copy, or select Options > Mark/
Unmark > Mark all to copy all contacts. Select Options >
Copy to SIM directory.
Tip: If you have saved contacts on your previous
device, you can use the Transfer application to
copy them. See "Transfer content between
devices " on page 19.
To search for a contact, enter the first letters of the
name to the search field. A list of the contacts starting
with the letters appear on the display.
Manage contacts
To add a contact, select Options > New contact.
To attach a small thumbnail image to a contact, select
Options > Edit > Options > Add thumbnail. The
thumbnail image is shown when the contact calls.
To listen to the voice tag assigned to the contact, select
Options > Play voice tag.
To edit information in a contact, select Options >
Edit.
Tip: You can also use Nokia PC Suite to add and
edit contacts.
To send contact information, select Options > Send.
You can assign a default number or address to a contact
so you can easily call or send a message to the default
number or address, even if several numbers or
addresses are saved to that contact. The default
number is also used in voice dialing.
42
Contacts
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 42 Jan 8, 2007 1:39:30 PM
To change the default information for a contact, open
the contact, and select Options > Defaults. Select the
number or address you want to set as a default. The
default number or address is underlined in the contact.
To add a contact to a group, select Options > Add to
group (shown only if you have created a group).
Tip: To check to which groups a contact
belongs, select Options > Belongs to groups.
To add a 1-touch key to the contact's phone number,
select Options > Assign 1-touch no..
To change the display order of the first and last names
of your contacts, select Options > Settings, and Last
name First name, or First name Last name.
Manage contact groups
You can create a contact group so that you can send text
or e-mail messages to several recipients at the same
time.
1. Open the contact groups tab, and select Options >
New group.
2. Enter a name for the group, and select OK.
3. Open the group, and select Options > Add
members.
4. Scroll to each contact you want to add to the group,
and press the scroll key to mark it.
5. Select OK to add all marked contacts to the group.
To remove a contact from a contact group, scroll to the
contact that you want to remove, and select Options >
Remove from group.
To rename a group, select Options > Rename.
Add ringing tones for
contacts
You can select a ringing tone for a contact or contact
group. If the caller's phone number is sent with the
incoming call and your device recognizes the number,
the ringing tone plays when the contact calls you.
To select a ringing tone for a contact or contact group,
open the contact or contact group, and select Options >
Ringing tone. A list of ringing tones opens. Select the
ringing tone you want to use.
To remove the assigned ringing tone, select Default
tone from the list of ringing tones.
Business cards
You can send, receive, view, and save contacts as
business cards in vCard or Nokia compact business card
format.
To send a business card, select the contact from
Contacts, select Options > Send, and the sending
method. Enter the phone number or address, or add a
recipient from Contacts. Select Options > Send. If you
select text message as the sending method, business
cards are sent without thumbnail images.
To view a received business card, select Open from the
displayed notification, or open the message from the
Inbox folder in the Messaging application.
43
Contacts
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 43 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 43 Jan 8, 2007 1:39:30 PM
To save a received business card, select Options > Save
business card.
44
Contacts
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 44 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 44 Jan 8, 2007 1:39:30 PM
Calendar
Select > Calendar.
You can create and view scheduled events and
appointments. You can also set alarms for calendar
entries.
You can synchronize your calendar data with a
compatible computer using Nokia PC Suite. For
information on synchronization, see the Nokia PC Suite
guide.
Create calendar entries
You can create the following types of calendar entries:
•Meeting entries have a specific date and time.
•Memo entries are related to the whole day but not
to a specific time of the day. Memo entries do not
appear in the week view.
•Anniversary entries remind you of birthdays and
special dates. They refer to a certain day but not a
specific time of the day. Anniversary entries are
repeated every year.
•To-do entries remind you of a task that has a due
date but not a specific time of the day.
To create a calendar entry, scroll to a date, and select
Options > New entry. Select the entry type. The
available settings for meeting, memo, anniversary, and
to-do entries vary.
To delete a calendar entry, select Options > Delete, and
select Before date to delete all entries before the
selected date, or All entries to delete all calendar entries
from the device.
To send a calendar entry to a compatible device, select
Options > Send > Via text message, Via multimedia,
Via e-mail, Via Bluetooth, or Via infrared.
To add a received calendar entry, open the calendar
entry attachment in the message, and select Options >
Save to Calendar.
To respond to a received calendar entry, select Accept,
Tentative, or Decline. If you accept the entry or mark it
as tentative, the entry is added to your calendar. You
can send a response to the sender of the calendar entry
by e-mail. Select Yes, and the message is saved in
Outbox to wait for sending.
To-do entries
You can create and maintain a task or list of tasks that
must be done by a certain day. Each task can be
assigned a due date, and an alarm.
Create a to-do entry
1. Scroll to a date, and select Options > New entry >
To-do.
2. Enter the subject in the Subject field.
3. Enter the due date.
45
Calendar
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 45 Jan 8, 2007 1:39:30 PM
4. To set an alarm for the to-do entry, select Alarm >
On. Enter the alarm time and date.
5. Specify a priority. The priority icons are ( ! ) High and
( - ) Low. There is no icon for Normal.
6. Define how the entry is handled during
synchronization in the Synchronization field. Select
Private to hide the entry from viewers if the
calendar is available online, Public to make the entry
visible to viewers if the calendar is available online,
or None to not copy the entry to your computer
when you synchronize.
To mark a task as completed, select Options > Mark as
done.
To restore a task, select Options > Mark as not done.
Calendar views
To switch between the different calendar views, select
Options in any calendar view. Select the type of view
from the list.
To set the default calendar view, select Options >
Settings > Default view, and the view you want.
To view a specific date, select Options > Go to date, and
enter the date.
46
Calendar
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 46 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 46 Jan 8, 2007 1:39:30 PM
Clock
Select > Clock.
In Clock, you can view your local time and time zone
information, set and edit alarms, or modify date and
time settings.
Alarm clock
Open the alarm clock tab.
To set an alarm, select Options > Set alarm, and enter
the alarm time. When an alarm is active, is
displayed.
To switch off the alarm, select Stop, or to stop the alarm
for 5 minutes, select Snooze. If the alarm time is reached
while the device is switched off, the device switches
itself on and starts sounding the alarm tone. If you
select Stop, the device asks whether you want to
activate the device for calls. Select No to switch off the
device or Yes to make and receive calls. Do not select
Yes when wireless phone use may cause interference
or danger.
To change the alarm time, select Options > Reset
alarm.
To remove the alarm, select Options > Remove alarm.
World clock
Open the world clock tab to check the time in different
cities.
To add a city to the world clock view, select Options >
Add city.
To change the city that determines the time and date
in your device, select Options > Set as current city. The
city is displayed in the Clock main view, and the time in
your device is changed according to the city selected.
Check that the time is correct and matches your time
zone.
To remove a city from the list, select Options >
Remove.
Clock settings
Select Options > Settings.
To change the time or date, select Time or Date.
To change the clock shown in the standby modes, select
Clock type > Analog or Digital.
To allow the mobile phone network to update the time,
date, and time zone information to your device
(network service), select Network operator time >
Auto-update.
To change the alarm tone, select Clock alarm tone.
47
Clock
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 47 Jan 8, 2007 1:39:30 PM
Office applications
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'}.
Some office applications may not be available in all
languages, in which case the application is in English in
your device.
Opening a large file may not be possible or it may take
a while.
File manager
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} > File
mgr..
With File manager, you can manage the contents and
properties of files and folders on your device memory
and memory card. You can open, create, move, copy,
rename, send, and search for files and folders. Copyright
protection may prevent sending some files.
Open the device tab or the memory card tab.
To select multiple files, scroll to each file, and select
Options > Mark/Unmark > Mark.
To send the selected files, select Options > Send.
To move or copy files or folders to another folder, select
Options > Move to folder or Copy to folder. Default
folders such as Sound clips in Gallery cannot be moved.
To search for files, select Options > Find. Enter the
search text, and press the scroll key. The folders and files
whose names contain the search text are displayed.
To view information about the selected file, select
Options > Details. To view additional information
about the file online, select Options > Additional
details.
Search
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} > {No
display_text mapping for
'qtn_title_indevice_search.search', locale='en'}.
With Search, you can search for information in your
contacts, notes, calendar appointments, to-do notes, e-
mail messages, multimedia messages, and text
messages. You can also search for files by the file names
in your device memory and memory card.
1. Select the content types you want to search in. To
remove the selection, select it again. To include all
content types in your search, select {No display_text
mapping for 'qtn_search_types_select_all.search',
locale='en'}. To remove all content types, select {No
display_text mapping for
'qtn_search_types_deselect_all.search', locale='en'}.
2. Enter your search keywords or some part of the
keywords. To include two words in your search,
48
Office applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 48 Jan 8, 2007 1:39:30 PM
separate them with a space. You only find items that
contain both keywords.
3. Select {No display_text mapping for
'qtn_softkey_search.search', locale='en'}.
Tip: Wildcards may help you find items. In your
search keyword, use ? to substitute a single
character, and * to substitute zero or more
characters. If you use the ? or * wildcard, you
must add * to the beginning and end of a
search keyword, for example *s?all* ("shall") or
*dev*ment* ("development").
To view the search results from your previous search,
select Options > {No display_text mapping for
'qtn_options_previous_search.search', locale='en'}.
Calculator
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} >
Calculator.
Note: This calculator has limited accuracy and is
designed for simple calculations.
To make a calculation, enter the first number of the
calculation. Select a function such as add or subtract
from the function map. Enter the second number of the
calculation, and select =.
The calculator performs operations in the order they are
entered. The result of the calculation remains in the
editor field and can be used as the first number of a new
calculation.
To save the results of a calculation, select Options >
Memory > Save. The saved result replaces the
previously stored result in the memory.
To retrieve the results of a calculation from the memory
and use them in a calculation, select Options >
Memory > Recall.
To view the last saved result, select Options > Last
result. Exiting the Calculator application or switching off
the device does not clear the memory. You can recall
the last saved result the next time you open the
Calculator application.
Nokia Team Suite
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} > Team
suite.
With Nokia Team Suite, you can create, edit, and delete
teams, and send messages, view teams' web pages and
communication history, and make phone calls to teams.
To create a new team, select Options > Team >
Create. Give a name for the team and enter the
conference call service information, if needed. Then
select the members for the team.
To select an action, first select the team to which you
want to apply the action, then scroll right to the action
bar, and select the desired action. If you do not want to
apply the action to all team members, open the team,
and select the desired members. Then select the action.
49
Office applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 49 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 49 Jan 8, 2007 1:39:30 PM
To find more actions than are shown on the action bar,
select Options > Actions. The following actions are
available:
•Call — Make a phone call to the team or selected
team members. The team members are called one
by one and put on hold until the calls can be merged
into a conference call (network service). The
maximum number of participants depends on the
network service.
•Create message — Send a text message, a
multimedia message, or an e-mail to the team or
selected team members.
•Call conference service — Start a call to the
conference call service (network service) defined for
the selected team.
•Communication log — View the communication log
for the team or selected team members.
•{No display_text mapping for
'qtn_team_options_sm_ezynotes.teamuiappezynot
esplugin', locale='en'} — Write and read notes
related to the team.
•In-device search — Search for content related to the
team or selected team members.
•Push to talk — Communicate through push to talk
(network service) with the team or selected team
members.
•Team Web pages — Open the bookmark folder that
contains the team web pages.
To select which actions are shown in the action bar and
in which order, select Options > Settings > Action
icons.
Edit teams
To add team members, select Options > Members >
Add.
To remove team members, select Options >
Members > Remove.
To edit the details of a member, select Options >
Members > Edit.
To select whether to see the team members' pictures
on the display, select Options > Settings > View
contact image.
To see to which teams a member belongs, select
Options > Members > Belongs to teams.
Quickoffice
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} >
Quickoffice.
Quickoffice consists of Quickword for Microsoft Word,
Quicksheet for Microsoft Excel, Quickpoint for Microsoft
PowerPoint, and Quickmanager for purchasing
software. You can create, view, and edit Microsoft Office
2000, XP, and 2003 documents (*.doc, *.xls and *.ppt)
and plain text files (*.txt) with Quickoffice. All file
formats or features are not supported. Apple Macintosh
is not supported.
To open a file, press the scroll key. Quickoffice opens the
file in the correct application.
50
Office applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 50 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 50 Jan 8, 2007 1:39:30 PM
Active notes
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} > Active
notes.
Active notes allows you to create, edit, and view
different kinds of notes, for example, meeting memos,
hobby notes, or shopping lists. You can insert images,
videos, and sound in the notes. You can link notes to
other applications, such as Contacts, and send notes to
others.
To create a note, start writing.
To create a folder, select Options > Organize > New
folder.
To sort the notes by date and time, name, or size, select
Options > Organize > Sort by.
To move the notes or folders, select the desired item
and Options > Organize > Move to. Select the folder
to which you want to move the item.
To edit the settings, select Options > Settings.
To send the note using a short message, multimedia
message, e-mail, Bluetooth, or infrared, select
Options > Send.
Create and edit notes
To edit a note, scroll to it, and press the scroll key.
To insert images, sound clips, video, business cards,
web bookmarks, and files, select Options > Insert
object.
To add new items to the note, select Options > Insert
new. You can record sound and video clips, and capture
images.
To add boldface, italics, or underlining to your text or
change the font color, press and hold the shift key and
use the scroll key to select the text. Then select
Options > Text.
To link a note to a contact, select Options > Link note
to call > Add contacts. You can see the note on the
display of your device when making a call to or
receiving a call from the contact.
Converter
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} >
Converter.
The converter has limited accuracy, and rounding errors
may occur.
Convert measurements
1. Scroll to the Type field, and select Options >
Conversion type to open a list of measures. Select
the measure to use, and select OK.
2. Scroll to the first Unit field, and select Options >
Select unit. Select the unit from which to convert,
and select OK. Scroll to the next Unit field, and select
the unit to which to convert.
3. Scroll to the first Amount field, and enter the value
to convert. The other Amount field changes
automatically to show the converted value.
51
Office applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 51 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 51 Jan 8, 2007 1:39:30 PM
Set base currency and exchange
rate
Note: When you change base currency, you must
enter new exchange rates because all previously set
exchange rates are cleared.
Before you can make currency conversions, you must
choose a base currency and add exchange rates. The
rate of the base currency is always 1. The base currency
determines the conversion rates of the other
currencies.
1. To set the rate of exchange for the unit of currency,
scroll to the Type field, and select Options >
Currency rates.
2. Scroll to the currency type and enter the exchange
rate you would like to set per single unit of currency.
3. To change the base currency, scroll to the currency,
and select Options > Set as base currency.
4. Select Done > Yes to save the changes.
After you have inserted all the necessary exchange
rates, you can make currency conversions.
PDF reader
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} > Adobe
Reader.
With PDF reader you can read PDF documents on the
display of your device; search for text in the documents;
modify settings, such as zoom levels and page views;
and send PDF files using e-mail.
Zip manager
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'}.
With Zip manager, you can create new archive files to
store compressed ZIP formatted files; add single or
multiple compressed files or directories to an archive;
set, clear, or change the archive password for protected
archives; and change settings, such as compression
level, and file name encoding.
You can store the archive files on the device memory or
on a memory card.
Print
You can print a message or file from the device, preview
a print job, define page layout options, select a printer,
or print to a file. You may not be able to print all
messages, such as multimedia messages or other
special messages.
To configure a printer for your device, select > {No
display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} >
Printers > Options > Add. To set the printer as the
default printer, select Options > Set as default.
Before you print, make sure your device is properly
connected to the printer.
To print a message or a file, select Options > Print.
52
Office applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 52 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 52 Jan 8, 2007 1:39:30 PM
To print to a file, select Options > Printing options >
Print to file, and determine the location for the file.
To change the printing options, select Options >
Printing options. You can select the printer you want to
use, the number of copies and the range of pages you
want to print.
To change the page layout before printing, select
Options > Printing options > Page setup. You can
change the paper size and orientation, define the
margins, and insert a header or a footer. The maximum
length of the header and footer is 128 characters.
To preview a file or message before you print, select
Options > Printing options > Preview.
Wireless keyboard
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} >
Wireless keybd..
Use the Wireless keyboard application to set up a Nokia
Wireless Keyboard or other compatible wireless
keyboard supporting the Bluetooth Human Interface
Devices (HID) profile for use with your device.
Connect to the keyboard
1. Activate Bluetooth connectivity on your device:
select > Connectivity > Bluetooth >
Bluetooth > On.
2. Switch on the wireless keyboard.
3. Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} >
Wireless keybd. > Options > Find keyboard to start
searching for devices with Bluetooth connectivity.
4. Select the keyboard from the list, and press the scroll
key to start the connection.
5. To pair the keyboard with your device, enter a
passcode of your choice (1-9 digits) on the device
and the same passcode on your keyboard.
6. If you are asked for a keyboard layout, select it from
the list on your device.
When the name of the keyboard appears on the device
display, its status changes to Keyboard connected, and
the green indicator of your keyboard blinks slowly; the
keyboard is ready for use.
Disconnect the keyboard
To close the Bluetooth connection but keep the Wireless
keyboard application running, select Options >
Keyboard disconnected.
To disconnect the keyboard and end the Bluetooth
connection, select > Connectivity > Bluetooth >
Bluetooth > Off.
For details on the operation and maintenance of your
keyboard, see its user guide.
Notes
Select > {No display_text mapping for
'qtn_apps_office_grid.menu_diy', locale='en'} > Notes.
You can create and send notes to other compatible
devices, and save received plain text files (.txt format)
to Notes.
53
Office applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 53 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 53 Jan 8, 2007 1:39:30 PM
To write a new note, select Options > New note.
To send the note to compatible devices, select
Options > Send.
To view notes that are added as descriptions to
calendar entries, open the calendar entry. Select
Description:.
To edit the note, select Options > Edit.
54
Office applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 54 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 54 Jan 8, 2007 1:39:30 PM
Connectivity
Your device offers several options to connect to the
internet, a corporate intranet, or to another device or
computer. Wireless methods include wireless LAN,
Bluetooth, and infrared. Your device supports a wired
solution with a USB (Universal Serial Bus) cable
connection for Nokia PC Suite. Your device also allows
you to communicate using net calls (Voice over IP), push
to talk, instant messaging (chat), and modem-based
connections.
Modem
Select > Connectivity > Modem.
Together with a compatible computer, you can use your
device as a modem to connect to the web.
Before you can use your device as a modem
•You need the appropriate data communications
software on your computer.
•You must subscribe to the appropriate network
services from your service provider or internet
service provider.
•You must have the appropriate drivers installed on
your computer. You must install drivers for the cable
connection, and you may need to install or update
Bluetooth or infrared drivers.
To connect the device to a compatible computer using
infrared, press the scroll key. Make sure the infrared
ports of the device and computer are directly facing
each other with no obstacles between them.
To connect your device to a computer using Bluetooth
wireless technology, initiate the connection from the
computer. To activate Bluetooth in your device, select
> Connectivity > Bluetooth and select Bluetooth >
On.
If you use a cable to connect your device to a computer,
initiate the connection from the computer.
You may not be able to use some of the other
communication features when the device is used as a
modem.
Cable connection
Select > Connectivity > USB.
Using a USB data cable, you can connect your device to
a compatible computer. Connect the USB data cable to
the USB connector of the device. To change the device
type you normally connect to your device with the data
cable, press the scroll key.
Install Nokia PC Suite to your computer before you use
a cable connection, as Nokia PC Suite automatically
installs the USB data cable driver to your computer. You
can use the Data transfer mode without installing the
USB data cable drivers.
55
Connectivity
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 55 Jan 8, 2007 1:39:30 PM
To use your device as a modem, start Nokia PC Suite on
your computer, connect the computer to your device
with the data cable, and select PC Suite.
Transfer data from a computer
1. Make sure that you have selected USB as a
connection type in the Manage connections settings
in Nokia PC Suite.
2. Insert a memory card to your device and connect
the device to a compatible computer with the USB
data cable.
3. When the device asks which mode is used, select
Data transfer. In this mode, you can see your device
as a removable hard drive in your computer.
4. End the connection from the computer (for
example, from an Unplug or Eject Hardware wizard
in Windows) to avoid damaging the memory card.
Connection manager
Select > Connectivity > Conn. mgr..
To see the open data connections, select Active data
connections. You can see the data calls, packet data
connections, and WLAN connections.
To view detailed information about network
connections, select a connection from the list and
Options > Details. The type of information shown
depends on the connection type.
To end the selected network connection, select
Options > Disconnect.
To end all active network connections simultaneously,
select Options > Disconnect all.
Search for WLAN
To search for WLANs available within range, select
Available WLAN networks. The available WLAN view
shows a list of WLANs within range, their network mode
(infrastructure or ad-hoc), signal strength and network
encryption indicators, and if your device has an active
connection with the network.
To view the details of a network, scroll to it, and press
the scroll key.
To create an internet access point for a network, select
Options > Define access point.
Bluetooth
This device is compliant with Bluetooth Specification
2.0 supporting the following profiles: Dial-up
Networking Profile, Object Push Profile, File Transfer
Profile, Handsfree Profile, Headset Profile, Basic
Imaging Profile, SIM Access Profile, Generic Object
Exchange Profile, Generic Access Profile, Generic Audio/
Video Distribution Profile, Advanced Audio Distribution
Profile, and Audio/Video Remote Control Profile. To
ensure interoperability between other devices
supporting Bluetooth technology, use Nokia approved
enhancements for this model. Check with the
manufacturers of other devices to determine their
compatibility with this device.
Select > Connectivity > Bluetooth.
56
Connectivity
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 56 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 56 Jan 8, 2007 1:39:30 PM
Bluetooth technology enables wireless connections
between electronic devices within a range of 10 meters
(33 feet). A Bluetooth connection can be used to send
images, videos, text, business cards, calendar notes, or
to connect wirelessly to devices using Bluetooth
technology, such as computers.
Since devices using Bluetooth technology
communicate using radio waves, your device and the
other devices do not need to be in direct line-of-sight.
The two devices only need to be within a maximum of
10 meters of each other, although the connection can
be subject to interference from obstructions such as
walls or other electronic devices.
Several Bluetooth connections can be active at a time.
For example, if your device is connected to a headset,
you can also transfer files to another compatible device
at the same time.
Send and receive data with
Bluetooth
There may be restrictions on using Bluetooth
technology in some locations. Check with your local
authorities or service provider.
Features using Bluetooth technology, or allowing such
features to run in the background while using other
features, increase the demand on battery power and
reduce the battery life.
1. When you activate Bluetooth for the first time, you
are asked to give a name to your device. Give your
device a unique name to make it easy to recognize
if there are several Bluetooth devices in the vicinity.
2. Select Bluetooth > On.
3. Select My phone's visibility > Shown to all or Define
period. If you select Define period, you need to
define the time during which your device is visible
to others. Your device and the name you entered can
now be seen by other users with devices using
Bluetooth technology.
4. Open the application where the item you want to
send is stored.
5. Select the item, and select Options > Send > Via
Bluetooth. The device searches for other devices
using Bluetooth technology within range and lists
them.
Tip: If you have sent data using Bluetooth
before, a list of the previous search results
is displayed. To search for more Bluetooth
devices, select More devices.
6. Select the device with which you want to connect.
If the other device requires pairing before data can
be transmitted, you are asked to enter a passcode.
When the connection has been established, Sending
data is shown.
The Sent folder in the Messaging application does not
store messages sent using Bluetooth connectivity.
To receive data using Bluetooth, select Bluetooth >
On and My phone's visibility > Shown to all to receive
data from a non-paired device or Hidden to receive data
from a paired device only. When you receive data
through Bluetooth, a tone sounds, and you are asked if
you want to accept the message in which the data is
57
Connectivity
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 57 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 57 Jan 8, 2007 1:39:30 PM
included. If you accept, the message is placed in the
Inbox folder in the Messaging application.
Tip: You can access the files in the device or on
the memory card using a compatible accessory
that supports the File Transfer Profile Client
service (for example, a laptop computer).
A Bluetooth connection is disconnected automatically
after sending or receiving data. Only Nokia PC Suite and
some enhancements such as headsets may maintain a
connection even if not actively used.
Pair devices
Open the paired devices tab.
Before pairing, create your own passcode (1-16 digits),
and agree with the user of the other device to use the
same code. Devices that do not have a user interface
have a fixed passcode. You need the passcode only
when you connect the devices for the first time. After
pairing, it is possible to authorize the connection.
Pairing and authorizing the connection makes
connecting quicker and easier, as you do not have to
accept the connection between paired devices every
time you establish a connection.
The passcode for remote SIM access must have 16 digits.
1. Select Options > New paired device. The device
starts to search for Bluetooth devices within range.
If you have sent data using Bluetooth before, a list
of the previous search results is displayed. To search
for more Bluetooth devices, select More devices.
2. Select the device with which you want to pair, and
enter the passcode. The same passcode must be
entered to the other device as well.
3. Select Yes to make the connection between your
device and the other device automatic, or No to
confirm the connection manually every time a
connection attempt is made. After pairing, the
device is saved to the paired devices page.
To give a nickname to the paired device, select
Options > Assign short name. The nickname is only
displayed in your device.
To delete a pairing, select the device whose pairing you
want to delete and Options > Delete. To delete all
pairings, select Options > Delete all. If you are currently
connected to a device and cancel the pairing with that
device, pairing is removed immediately, and the
connection is ended.
To allow a paired device to connect automatically to
your device, select Set as authorized. Connections
between your device and the other device can be made
without your knowledge. No separate acceptance or
authorization is needed. Use this status for your own
devices, such as your compatible headset or computer,
or devices that belong to someone you trust. If you
want to accept connection requests from the other
device separately every time, select Set as
unauthorized.
To use a Bluetooth audio enhancement such as a
Bluetooth handsfree or headset, you need to pair your
device with the enhancement. See the enhancement
user guide for the passcode and further instructions. To
connect to the audio enhancement, switch on the
58
Connectivity
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 58 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 58 Jan 8, 2007 1:39:30 PM
enhancement. Some audio enhancements connect
automatically to your device. Otherwise open the
paired devices tab, scroll to the enhancement, and
select Options > Connect.
Security tips
When you are not using Bluetooth connectivity, select
Bluetooth > Off or My phone's visibility > Hidden.
Do not pair with an unknown device.
Bluetooth connectivity indicators
Bluetooth is active.
When the icon is blinking, your device is trying to
connect to the other device. When the icon is shown
continuously, the Bluetooth connection is active.
SIM access profile
When the wireless device is in the remote SIM mode,
you can only use a compatible connected enhancement,
such as a car kit, to make or receive calls. Your wireless
device will not make any calls, except to the emergency
numbers programmed into your device, while in this
mode. To make calls from your device, you must first
leave the remote SIM mode. If the device has been
locked, enter the lock code to unlock it first.
With the SIM access profile, you can access the SIM card
of your device from a compatible car kit device. This
way, you do not need a separate SIM card to access SIM
card data and connect to the GSM network.
To use the SIM access profile, you need the following:
•Compatible car kit device that supports Bluetooth
wireless technology
•Valid SIM card in your Nokia Exx Communicator
For more information about car kit devices and
compatibility with your Nokia Exx Communicator, see
www.nokia.com and your car kit user guide.
Use the SIM access profile
1. Select > Connectivity > Bluetooth > Remote
SIM mode > On.
2. Activate Bluetooth in the car kit device.
3. Use your car kit device to start a search for
compatible devices. For instructions, see the user
guide of your car kit device.
4. Select your Nokia Exx Communicator from the list of
compatible devices.
5. To pair the devices, enter the Bluetooth passcode
shown on the display of the car kit device to your
Nokia Exx Communicator.
Tip: If you have already accessed the SIM card
from the car kit with the active user profile, the
car kit searches automatically for a device with
the SIM card. If it finds your Nokia Exx
Communicator, and automatic authorization is
activated, the car kit automatically connects to
the GSM network when you switch on the car
ignition.
59
Connectivity
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 59 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 59 Jan 8, 2007 1:39:30 PM
When you activate the remote SIM access profile, you
can use applications on your device that do not need
network or SIM services.
To make connections between your device and the car
kit device without separate acceptance or
authorization, select > Connectivity > Bluetooth,
and open the paired devices tab. Scroll to the car kit
device, press the scroll key, and enter the Bluetooth
passcode. When the device asks to make the connection
automatic, select Yes. If you select No, connection
requests from this device must be accepted separately
every time.
To end the remote SIM access connection from your
device, select > Connectivity > Bluetooth >
Remote SIM mode > Off.
Infrared
Do not point the infrared (IR) beam at anyone's eye or
allow it to interfere with other IR devices. This device is
a Class 1 laser product.
Use infrared to connect two devices and transfer data
between them. With infrared, you can transfer data
such as business cards, calendar notes, and media files
with a compatible device.
Send and receive data
1. Ensure that the infrared ports of the devices face
each other. The positioning of the devices is more
important than the angle or distance.
2. Select > Connectivity > Infrared to switch on
infrared on your device.
3. Switch on infrared on the other device and wait a
few seconds until the infrared connection is
established.
4. Locate the desired file in an application or File
manager, and select Options > Send > Via
infrared.
If the data transfer is not started within 1 minute after
the activation of the infrared port, the connection is
cancelled and must be started again.
All items received through infrared are placed in the
Inbox folder in Messaging.
Positioning the devices away from each other breaks
the connection, but the infrared light beam remains
active on your device until it deactivates.
Internet access points
An access point is where your device connects to a
network. To use e-mail and multimedia services or to
connect to the internet and browse web pages, you
must first define the internet access point for these
services. You may need to set up several internet access
points, depending on the sites you want to access. For
example, browsing the web may require one access
point, and accessing your company intranet may
require another. To connect to the internet over GPRS,
your device may have predefined, default internet
access point settings.
When you switch on your device for the first time, the
access points may be configured automatically based
on the service provider information in your SIM card.
You can also receive the access point settings in a
60
Connectivity
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 60 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 60 Jan 8, 2007 1:39:30 PM
message from your service provider. This might reduce
the number of settings you need to enter yourself.
The available options may vary. Some or all access
points may be preset for your device by your service
provider. You may not be able to add, edit, or delete
access points. Contact your service provider and e-mail
service provider for more information on access points
and their settings.
Set up an internet access point for
data calls
1. Select > Tools > Settings > Connection >
Access points.
2. Select Options > New access point. To use an
existing access point as a basis for the new one,
select Use existing settings. To start with an empty
access point, select Use default settings.
3. Define the following settings.
•Connection name — Enter a descriptive name for
the connection.
•Data bearer — Select Data call or High speed
(GSM).
•Dial-up number — Enter the modem telephone
number of the access point. Use + before
international numbers.
•User name — Enter your user name if required
by the service provider. User names are often
case-sensitive and provided by your service
provider.
•Prompt password — Select Yes to enter your
password each time you log into a server or No
to save the password in your device memory and
automate the login.
•Password — Enter your password if required by
the service provider. The password is often case-
sensitive and provided by the service provider.
•Authentication — Select Secure to send your
password always encrypted or Normal to send
your password encrypted when possible.
•Homepage — Enter the web address of the page
you want to display as the home page when you
use this access point.
•Data call type — Select Analog, ISDN v.110, or
ISDN v.120.
•Maximum data speed — Select the limit to apply
to the transfer speed. If you select Automatic, the
data transfer rate is determined by the network
and may be affected by network traffic. Some
service providers may charge more for higher
data rates.
4. After defining the basic settings, select Options >
Advanced settings to define the advanced settings
or Back to save the settings and exit.
Set up an internet access point for
packet data (GPRS)
1. Select > Tools > Settings > Connection >
Access points.
2. Select Options > New access point. To use an
existing access point as a basis for the new one,
select Use existing settings. To start with an empty
access point, select Use default settings.
3. Define the following settings.
61
Connectivity
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 61 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 61 Jan 8, 2007 1:39:30 PM
•Connection name — Enter a descriptive name for
the connection.
•Data bearer — Select Packet data.
•Access point name — Enter the name for the
access point. The name is usually provided by
your service provider.
•User name — Enter your user name if required
by the service provider. User names are often
case-sensitive and provided by your service
provider.
•Prompt password — Select Yes to enter your
password each time you log into a server or No
to save the password in your device memory and
automate the login.
•Password — Enter your password if required by
the service provider. The password is often case-
sensitive and provided by the service provider.
•Authentication — Select Secure to send your
password always encrypted, or Normal to send
your password encrypted when possible.
•Homepage — Enter the web address of the page
you want to display as the home page when you
use this access point.
4. After defining the settings, select Options >
Advanced settings to define the advanced settings
or Back to save the settings and exit.
For information on the advanced settings, see the
extended user guide on the web.
62
Connectivity
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 62 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 62 Jan 8, 2007 1:39:30 PM
Wireless local area network
Some places, like France, have restrictions on the use of
wireless LAN. Check with your local authorities for more
information.
Your device can detect and connect to a wireless local
area network (WLAN). To use WLAN, a network must be
available in the location and your device must be
connected to it.
See WLAN availability
To have your device show WLAN availability, select >
Tools > Settings > Connection > Wireless LAN >
Options > Advanced settings > Show WLAN
availability.
If WLAN is available, is shown on the display.
Tip: You can also scan for networks in range.
WLAN connections
Important: Always enable one of the available
encryption methods to increase the security of your
wireless LAN connection. Using encryption reduces the
risk of unauthorized access to your data.
To use WLAN, you must create an internet access point
(IAP) in a WLAN. Use the access point for applications
that need to connect to the internet. A WLAN connection
is established when you create a data connection using
a WLAN internet access point. The active WLAN
connection is ended when you end the data connection.
You can also end the connection manually. See
"Connection manager " on page 56.
You can use WLAN during a voice call or when packet
data is active. You can only be connected to one WLAN
access point device at a time, but several applications
can use the same internet access point.
When the device is in the Offline profile, you can still use
WLAN (if available). Remember to comply with any
applicable safety requirements when establishing and
using a WLAN connection.
If you move the device to another location within the
WLAN and out of range of a WLAN access point, the
roaming functionality can automatically connect your
device to another access point that belongs to the same
network. As long as you remain within range of access
points that belong to the same network, your device
can stay connected to the network.
Tip: To check the unique media access control
(MAC) address that identifies your device, for
example to configure the MAC address of your
device to a WLAN router, enter *#62209526#
on the device keypad. The MAC address is
shown on the device display.
63
Wireless local area network
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 63 Jan 8, 2007 1:39:30 PM
WLAN wizard
Select > Connectivity > WLAN wiz..
The WLAN wizard helps you find and connect to a
wireless LAN. When you open the application, your
device starts to scan for available WLANs and lists them.
To update the list of available WLANs, select Options >
Refresh.
To start or continue browsing the web using the access
point of the WLAN, scroll to the desired network, and
select Options > Start Web browsing or Cont. Web
browsing.
To disconnect the active connection to the WLAN, select
Options > Disconnect WLAN.
To view the details of the WLAN, select Options >
Details.
To define an internet access point for the selected
WLAN, select Options > Define access point.
Always enable one of the available encryption methods
to increase the security of your WLAN connection. Using
encryption reduces the risk of unauthorized access to
your data.
Use the wizard in the active standby mode
In the active standby mode, the WLAN wizard shows the
status of your WLAN connections and network searches.
To view the available options, scroll to the row showing
the status, and press the scroll key. Depending on the
status, you can start the Web browser using a WLAN
connection, disconnect from a WLAN, search for WLANs,
or set the network scanning on or off.
If WLAN scanning is off and you are not connected to
any WLAN, WLAN scanning off is displayed in the active
standby mode. To set scanning on and search for
available WLANs, scroll to the row showing the status,
and press the scroll key.
To start a search for available WLANs, scroll to the row
showing the status, press the scroll key, and select
Search for WLAN. To set WLAN scanning off, scroll to the
row showing the status, press the scroll key, and select
Switch WLAN scan off.
When Start Web browsing is selected, the WLAN wizard
automatically creates an internet access point for the
selected WLAN. The access point can also be used with
other applications requiring WLAN connection.
If you select a secured WLAN, you are asked to enter the
relevant passcodes. To connect to a hidden network,
you must enter the correct hidden service set identifier
(SSID).
WLAN access points
To search for WLANs available within range, select >
Connectivity > WLAN wiz.. To create an internet access
point in a WLAN, select Options > Define access point.
To view the details of a network shown in the list, select
Options > Details.
When an application asks you to select an access point,
select the created access point. You can also create an
internet access point by selecting Search for WLAN, or
use Connection manager to create internet access
points. See "Connection manager " on page 56.
64
Wireless local area network
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 64 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 64 Jan 8, 2007 1:39:30 PM
Set up an internet access
point for WLAN manually
1. Select > Tools > Settings > Connection >
Access points.
2. Select Options > New access point. To use an
existing access point as a basis for the new one,
select Use existing settings. To start with an empty
access point, select Use default settings.
3. Define the following settings.
•Connection name — Enter a descriptive name for
the connection.
•Data bearer — Select Wireless LAN.
•WLAN network name — To enter the service set
identifier (SSID), that is, the name that identifies
the specific WLAN, select Enter manually. To
select the network from the WLANs in range,
select Search for networks.
•Network status — Select Hidden if the network
you are connecting to is hidden or Public if it is
not hidden.
•WLAN network mode — If you select
Infrastructure, devices can communicate with
each other and with wired LAN devices through
a WLAN access point. If you select Ad-hoc, devices
can send and receive data directly with each
other, and no WLAN access point is needed.
•WLAN security mode — You must select the same
security mode that is used in the WLAN access
point. If you select WEP (wired equivalent
privacy), 802.1x, or WPA2 (Wi-Fi protected
access), you must also configure the relevant
additional settings. See the extended user guide
on the web or the device help for more
information.
•WLAN security settings — Edit the security
settings for the selected WLAN security mode.
•Homepage — Enter the web address of the page
you want to display as the home page when you
use this access point.
WLAN settings
See "WLAN settings" on page 87.
65
Wireless local area network
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 65 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 65 Jan 8, 2007 1:39:30 PM
Web
Select > Web.
To browse the web (network service), you need to
configure the internet access point settings. If you are
using a data call or GPRS connection, your wireless
network must support data calls or GPRS, and the data
service must be activated for your SIM card.
Check the availability of services, pricing, and fees with
your service provider. Service providers also give you
instructions on how to use their services.
Access points
Your device might have configured the internet access
point settings automatically based on your SIM card. If
not, contact your service provider for the correct
settings.
Tip: You may receive the internet access point
settings from your service provider as a special
text message or from the web page of the
service provider.
You can also enter the internet access point settings
manually. See "Internet access points" on page 60.
Browse the web
To browse the web, select a bookmark or enter the web
address manually. Use only services that you trust and
that offer adequate security and protection against
harmful software.
Tip: When you start to enter the address, the
addresses of the pages you have previously
visited that match your input are displayed. To
open a page, scroll to its address, and press the
scroll key.
To move on a web page, use the scroll key, which is
shown as a pointer on the page. When you move the
pointer over a link, the pointer changes into a hand.
Press the scroll key to open the link. On a web page, new
links usually appear underlined in blue and previously
visited links in purple. Images that act as links have a
blue border around them.
The addresses of the pages you visit are saved in the
Auto. bookmarks folder.
Bookmarks
Your device may have preinstalled bookmarks and links
for third-party internet sites. You may also access other
third-party sites through your device. Third-party sites
are not affiliated with Nokia, and Nokia does not
endorse or assume liability for them. If you choose to
access such sites, you should take precautions for
security or content.
To view a bookmarked web page, scroll to the
bookmark, and press the scroll key.
66
Web
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 66 Jan 8, 2007 1:39:30 PM
To browse to another web page, select Options >
Navigation options > Go to web address, enter the
page address, and select Go to.
To organize your bookmarks, select Options >
Bookmark manager in the Web main view. You can
move and edit bookmarks, and create new folders.
To add a bookmark, select Options > Bookmark
manager > Add bookmark, and define the following:
•Name — Give a descriptive name for the bookmark.
•Address — Enter the web page address.
•Access point — Define the access point to connect to
the web page.
•User name — Enter your user name, if required by
the service provider.
•Password — Enter your password, if required by the
service provider.
End a connection
To end the connection and view the browser page
offline, select Options > Advanced options >
Disconnect. To end the connection and close the
browser, select Options > Exit.
Clear the cache
A cache is a memory location that is used to store data
temporarily. If you have tried to acce ss or have accesse d
confidential information requiring passwords, empty
the cache after each use. The information or services
you have accessed are stored in the cache.
To empty the cache, select Options > Advanced
options > Clear cache.
Web settings
Select Options > Settings. The Web settings are divided
into four groups:
•General contains access point and home page
related settings.
•Page contains imaging, audio, and pop-up settings.
•Privacy contains settings related your privacy.
•Web feeds contains settings related to web feeds
and blogs.
67
Web
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 67 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 67 Jan 8, 2007 1:39:30 PM
Global Positioning System (GPS)
Select > {No display_text mapping for
'qtn_apps_gpsfolder_grid', locale='en'}.
The Global Positioning System (GPS) is a worldwide
radio navigation system that includes 24 satellites and
their ground stations that monitor the operation of the
satellites.
A GPS terminal, such as the GPS receiver in the Nokia Exx
Communicator, receives low-power radio signals from
the satellites, and measures the travel time of the
signals. From the travel time, the GPS receiver can
calculate its location to the accuracy of meters.
Coordinates are expressed in degrees and decimal
degrees format using the WGS-84 coordinate system.
The Global Positioning System (GPS) is operated by the
government of the United States, which is solely
responsible for its accuracy and maintenance. The
accuracy of location data can be affected by
adjustments to GPS satellites made by the United States
government and is subject to change with the United
States Department of Defense civil GPS policy and the
Federal Radionavigation Plan. Accuracy can also be
affected by poor satellite geometry. Availability and
quality of GPS signals may be affected by your location,
buildings, natural obstacles, and weather conditions.
The GPS receiver should only be used outdoors to allow
reception of GPS signals.
GPS should only be used as a navigation aid. It should
not be used for precise location measurement and you
should never rely solely on location data from the GPS
receiver for positioning or navigation.
The trip meter has limited accuracy, and rounding
errors may occur. Accuracy can also be affected by
availability and quality of GPS signals.
Maps
Select > {No display_text mapping for
'qtn_apps_gpsfolder_grid', locale='en'} > Maps.
With Maps, you can see your current location on the
map, browse maps for different cities and countries,
search for addresses and different points of interest,
and plan routes from one location to another. You can
also purchase extra services, such as city guides and a
navigation service with voice guidance.
Basic world maps are currently available through Maps
and are downloaded to your device when you use the
application. Some maps may be delivered with the
device. The map coverage and availability may vary.
Browse maps
When you open Maps, you see an overview of the globe.
When your device finds the satellite signal, Maps starts
to locate your device, and zooms in to your current
location. At the same time, Maps downloads the map of
your current location. The downloaded maps are
68
Global Positioning System (GPS)
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 68 Jan 8, 2007 1:39:30 PM
automatically saved in the device memory or a memory
card.
When you browse the map on the display, a new map
is downloaded automatically. All the maps downloaded
by Maps are free of charge, but downloading may
involve the transmission of large amounts of data
through your service provider network. For more
information on data transmission charges, contact your
service provider.
Your current location is indicated on the map. The
compass rose shows the orientation of the map, which
is towards north by default.
To move on the map, scroll up, down, left, or right. To
view detailed information of a location on the map,
press the scroll key and select Details. To return to your
current location, select Options > Current location.
To zoom in or out on the map, press * or #.
To switch between the 2-D and 3-D views, press 0.
To define what kind of points of interest are shown on
the map, select Options > View > Categories and the
desired categories.
To view points of interest near your current location,
select Options > Find > Near current location. To find
points of interest near other locations, move on the
map, and select Options > Find > Near focused
location.
Save locations
To take a screenshot of your location, select Save
location > As image. The screenshot is saved in Gallery.
To save a location as a landmark in Favorites, press the
scroll key, and select Save location > As landmark. Enter
a name for the landmark, and select the categories in
which you want to include it.
To view saved landmarks, select Options > Favorites.
To send a landmark to a compatible device, select
Favorites > Options > Landmark location > Send
location. If you send the landmark in a text message,
the information is converted to plain text.
Maps settings
To check whether the maps that are downloaded to
your device have been updated on the map server,
select Options > Settings > Network > Options >
Check for map updates.
To prevent the device from automatically downloading
maps through the internet, for example, when you are
outside your home cellular network, select Options >
Settings > Network > Use network > Off.
To adjust the size of the cache that is used for saving
maps, select Options > Settings > Max memory card
use (%). This option is available only when a memory
card is inserted. When the memory is full, the oldest
map is deleted. The cache cannot be emptied.
To view the number and signal strength of satellites
when you are using Maps, select Options > View >
Satellite info.
69
Global Positioning System (GPS)
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 69 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 69 Jan 8, 2007 1:39:30 PM
Search for locations
To search for a point of interest by name, select
Options > Find > By name, or start entering the first
letters of the name, and select Search.
To search for a location, select Options > Find > By
address. You must enter the city and country. To use an
address you have saved in Contacts, select Options >
Find > By address > Options > Select from contacts.
To view the search result on a map, press the scroll key.
To switch between search results, scroll up or down. To
move on the map, select Options > Full screen, and use
the scroll key.
Plan a route
To plan a route from one location to another, select
Options > Plan route. Select the start and end point for
the route, and select Options > Show route to show
the route on the maps downloaded in your device or
Search route online to use online map data.
Tip: The Search route online option accesses all
available map data on the server and may
provide a more accurate route.
To adjust the routing settings, such as the priority of
the route or the mode of transportation, select
Options > Settings > Routing.
To view the itinerary of the route, select Options >
Route details, and scroll right. To view locations on the
map, select Options > Show on map.
To run a simulation of the created route, select
Options > Start simulation.
To return to the main map view, select Options > Full
screen.
GPS data
This feature is not designed to support positioning
requests for related calls. Contact your service provider
for more information about how your phone complies
with government regulations on location based
emergency calling services.
GPS should only be used as a navigation aid. It should
not be used for precise location measurement and you
should never rely solely on location data from the GPS
receiver for positioning or navigation.
Select > {No display_text mapping for
'qtn_apps_gpsfolder_grid', locale='en'} > GPS data.
With GPS data, you can view your current location, find
your way to a desired location, and track distance.
Select Navigation to view navigating information to
your trip destination, Position to view positioning
information about your current location, or Trip dist. to
view your traveling information such as the distance
and duration you have traveled, and your average and
maximum speeds.
The application must receive positioning information
from at least three satellites to be used as a traveling
aid.
To select a positioning method to detect the location of
your device, select Options > Positioning settings,
70
Global Positioning System (GPS)
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 70 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 70 Jan 8, 2007 1:39:30 PM
scroll to the desired positioning method, and select
Options > Enable.
To check the signal strength of the satellites that
provide the positioning information necessary for
navigation, open any of the three views and select
Options > Satellite status.
To set a landmark or location as the destination of your
trip, select Navigation > Options > Set destination.
You can also enter the destination latitude and
longitude coordinates.
To remove the destination set for your trip, select
Navigation > Options > Stop navigation.
To save your current position as a landmark, select
Navigation or Position, and Options > Save position.
To activate the trip meter, select Trip dist. > Options >
Start. To stop the trip meter, select Options > Stop.
To reset all fields and start calculating the trip again,
select Trip dist. > Options > Restart.
To change the measuring system in use, select
Options > Settings > Measurement system > Metric
or Imperial.
To enter the altitude calibration to correct the altitude
received from the positioning satellites, select
Options > Settings > Altitude calibration.
Landmarks
Select > {No display_text mapping for
'qtn_apps_gpsfolder_grid', locale='en'} > Landmarks.
Landmarks are coordinates to geographic locations
that you can save to your device for later use in different
location-based services. You can create landmarks
using the internal GPS receiver of your device or
network (network service).
To create a landmark, select Options > New
landmark. Select Current position to make a network
request for the latitude and longitude coordinates of
your current location, Use map to select the location
from a map, or Enter manually to fill in necessary
location information such as a name, category, address,
latitude, longitude, and altitude.
To show the landmark on the map, select Options >
Show on map.
71
Global Positioning System (GPS)
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 71 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 71 Jan 8, 2007 1:39:30 PM
Business voice applications
Push to talk
Select > Connectivity > PTT.
Push to talk (PTT) (network service) provides direct
voice communication connected with the push of a key.
With push to talk, you can use your device as you would
use a walkie-talkie.
You can use push to talk to have a conversation with
one person or with a group of people, or to join a
channel. A channel is like a chat room: you can call the
channel to see if anyone is online. The channel call does
not alert the other users; the users just join the channel
and start speaking with each other.
In push-to-talk communication, one person talks while
the other users listen through the built-in loudspeaker.
Users take turns responding to each other. Because only
one user can talk at a time, the maximum duration of
a speech turn is limited. For details of the speech turn
duration for your network, contact your service
provider.
Before you can use push to talk, you must define the
push-to-talk access point and push-to-talk settings. You
may receive the settings in a message from the service
provider that offers the push-to-talk service.
Phone calls always take priority over push to talk.
Push-to-talk settings
Select Options > Settings and select User settings to
define your preferences for push to talk, or Connection
settings to change the connection details. Contact your
service provider for the correct settings.
The settings available for editing may vary.
Log in to push-to-talk service
If you have set Application start-up on in User
settings, push to talk automatically logs in to the service
when started. If not, you must log in manually.
To log in to push-to-talk service manually, select
Options > Log in to PTT.
When the Ringing type setting of your device is set to
Beep once or Silent, or there is an ongoing phone call,
you cannot make or receive push-to-talk calls.
Make a push-to-talk call
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume
may be extremely loud.
To make a push-to-talk call, select Options > Contacts,
select one or several contacts from the list, and press
the voice key. Remember to hold the device in front of
72
Business voice applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 72 Jan 8, 2007 1:39:30 PM
you during a push-to-talk call so you can see the display.
The display informs you when it is your turn to speak.
Speak towards the microphone, and do not cover the
loudspeaker with your hands. Press and hold the voice
key the entire time you are talking. When you have
finished talking, release the key.
To end the push-to-talk call, press the end key.
When you receive a push-to-talk call, press the call key
to answer the call or the end key to dismiss the call.
Manage PTT contacts
To view, add, modify, delete, or call contacts, select
Options > Contacts. A list of names from the Contacts
application is displayed with information about their
login status.
To call a selected contact, select Options > Talk 1 to 1.
To make a group call, select several contacts and
Options > Talk to many.
To send the contact a request to call you, select
Options > Send callback request.
To answer a callback request, select Show to open the
callback request. To make a push-to-talk call to the
sender, press the voice key.
Create a PTT channel
To create a channel, select Options > New channel >
Create new.
To register the channel to the push-to-talk service,
select Options > Register.
To join a channel, select the channel you want to talk
to, and press the voice key.
To invite a user to a channel, select Options > Send
invitation.
To view the currently active users of a channel, select
Options > Active members.
To view more information about a selected user, select
Options > Contact details.
When you log in to push to talk, push to talk
automatically connects to the channels that were active
when the application was last closed.
Exit push to talk
To exit push to talk, select Options > Exit. Select Yes to
log out and close the service. Select No if you want to
keep the application active in the background.
Recorder
Select > Media > Recorder.
With Recorder, you can record up to 60 seconds of a
voice memo, save the voice recording as a sound clip,
and play the sound clip. Recorder supports the AMR file
format.
Press the voice key to activate Recorder. If you have
logged in to push to talk, the voice key works as a push-
to-talk key and does not activate Recorder.
73
Business voice applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 73 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 73 Jan 8, 2007 1:39:30 PM
To record a voice memo, select Options > Record sound
clip. Select Pause to pause the recording, and Record to
resume recording. When you finish recording, select
Stop. The sound clip is automatically saved to the Sound
clips folder in Gallery.
The maximum length of a voice recording is 60 seconds,
but it also depends on the storage space available in
the device memory or on a memory card.
Play a voice recording
To listen to a voice recording that you just recorded,
select Play. The progress bar displays the playing time,
position, and length of the voice recording. Select
Stop to cancel the playback.
To pause the playback of a voice recording, select
Pause. Playback resumes when you select Play.
Voice recorder settings
Voice recordings are automatically saved to the device
memory unless you change the default location. Voice
recordings that you create or receive after you change
the settings are affected.
To change the default location of saved voice
recordings, select Options > Settings > Memory in
use.
To define the recording quality, select Options >
Recording quality.
Tip: Waveform files (.wav) are a more common
audio file format, but adaptive multirate files
(.amr) are smaller for comparable sound
quality.
Voice aid
Select > Tools > Voice aid.
The Voice aid application reads text on the screen,
allowing you to use the basic functions of your device
without looking at the display.
To hear the entries in your contacts list, select
Contacts. Do not use this option if you have more than
500 contacts.
To hear information on your missed and received calls,
dialed numbers, and frequent calls, select Recent calls.
To listen to your voice messages, select Voice mailbox.
To dial a telephone number, select Dialer.
To hear the current time, select Clock > Time. To hear
the current date, select Clock > Date.
To hear more options, select Options.
Speech
Select > Tools > Speech.
With Speech, you can set the language, voice, and voice
properties for the message reader.
To set the language for the message reader, select
Language.
74
Business voice applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 74 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 74 Jan 8, 2007 1:39:30 PM
To set the speaking voice, select Voice. The voice is
language-dependent.
To set the speaking rate, select Voice settings >
Speed.
To set the speaking volume, select Voice settings >
Volume.
To listen to a voice, open the voice tab, select the voice,
and select Play voice.
Voice commands
Select > Tools > Voice comm..
Use voice commands to make phone calls and launch
applications, profiles, or other functions on the device.
The device creates a voice tag for the entries in Contacts
and for the functions designated in the Voice
commands application. When a voice command is
spoken, the device compares the spoken words to the
voice tag in the device. Voice commands are not
dependent on a speaker’s voice; however, the voice
recognition in the device adapts to the main user’s
voice to recognize voice commands better.
Make a call
A voice tag for a contact is the name or nickname that
is saved on the contact in Contacts.
To listen to a voice tag, open a contact, and select
Options > Play voice tag.
1. To make a call using a voice command, press and
hold the voice key.
2. When you hear the tone or see the visual display,
clearly speak the name saved on the contact.
3. The device plays a synthesized voice tag for the
recognized contact in the selected device language,
and displays the name and number. After a timeout
of 1.5 seconds, the device dials the number. If the
recognized contact was not correct, select Next to
view a list of other matches or Quit to cancel dialing.
If several numbers are saved under the contact, the
device selects the default number, if it has been set.
Otherwise, the device selects the first available
number of the following fields: Mobile, Mobile
(home), Mobile (work), Telephone, Tel. (home), and
Tel. (work).
Launch an application
The device creates voice tags for the applications listed
in the Voice commands application.
To launch an application using a voice command, press
and hold the voice key, and clearly speak the name of
the application. If the recognized application was not
correct, select Next to view a list of other matches or
Quit to cancel.
To add more applications to the list, select Options >
New application.
To change the voice command of an application, select
Options > Change command, and enter the new
command.
75
Business voice applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 75 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 75 Jan 8, 2007 1:39:30 PM
Change profiles
The device creates a voice tag for each profile. To set on
a profile using a voice command, press and hold the
voice key, and say the name of the profile.
To change the voice command, select Profiles >
Options > Change command.
Voice command settings
To switch off the synthesizer that plays recognized
voice commands in the selected device language, select
Settings > Synthesizer > Off.
To reset voice recognition learning when the main user
of the device has changed, select Remove voice
adapts..
76
Business voice applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 76 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 76 Jan 8, 2007 1:39:30 PM
Media applications
Select > Media.
Media contains different media applications that allow
you to save and view images, record sounds, and play
sound clips.
RealPlayer
Select > Media > RealPlayer.
RealPlayer plays video clips and audio files that are
stored in the device memory or on a memory card,
transferred to your device from an e-mail message or a
compatible computer, or streamed to your device over
the web. Supported formats include MPEG-4, MP4 (not
streaming), 3GP, RV, RA, AAC, AMR, and Midi. RealPlayer
does not necessarily support all variations of a media
file format.
Play video clips and stream links
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume
may be extremely loud.
To play a video clip or audio file, select Options >
Open > Most recent clips to play one of the six video
clips you most recently played, or Saved clip to play a
video clip, or to open a web link. Select Play.
To play streaming media, select a web link that points
to a media clip, and select Play; or connect to the web,
browse to a video clip or audio file, and select Play.
RealPlayer recognizes two kinds of links: an rtsp:// URL
and an http:// URL that points to a RAM file. Before the
content begins streaming, your device must connect to
a web site and buffer the content. If a network
connection problem causes a playback error, RealPlayer
attempts automatically to reconnect to the internet
access point.
To adjust the volume during playback, scroll right or
left.
To fast-forward during playback, scroll up and hold. To
rewind during play, scroll down and hold.
To stop the playback or streaming, select Stop.
Buffering or connecting to a streaming site stops, the
playback of a clip stops, and the clip rewinds to the
beginning.
To download video clips from the web, select Options >
Download videos.
To view the video clip in full-screen size, select
Options > Play in full screen. Full screen increases the
size of the video to cover the maximum video area
possible while the aspect ratio is maintained.
77
Media applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 77 Jan 8, 2007 1:39:30 PM
RealPlayer settings
You may receive RealPlayer settings in a message from
your service provider.
To define the settings manually, select Options >
Settings > Video or Streaming.
Music player
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume
may be extremely loud.
Select > Media > Music player.
With Music player, you can play music files, and create
and listen to track lists. Music player supports files with
extensions such as MP3 and AAC.
Listen to music
Warning: Listen to music at a moderate level.
Continuous exposure to high volume may damage your
hearing.
To select a music track, select Options > Music library.
All tracks lists all music on your device. To view sorted
songs, select Albums, Artists, Genres, or Composers.
To play the track, select Options > Play. To pause the
playing, scroll to and press the scroll key.
To select the previous or next track, scroll up or down.
To control the music volume, scroll right or left. To mute
the volume, scroll left until the volume is muted.
To stop a track, scroll to and press the scroll key.
To play the music tracks repeatedly, select Options >
Loop. Select All to repeat all the tracks in the current
folder, One to repeat the selected track, or Off to set off
the repeating.
To play music in random order, select a folder and
Options > Random play.
After you have added or removed music files in the
device, update your music library. Select Options >
Update Music library. Music player searches the device
memory for music files and updates them to the music
library.
To view music track information, select Options > View
details.
Track lists
You can create a new track list and add tracks to it, or
edit a saved track list.
To create a new track list, select Options > Music
library > Track lists > Options > New track list.
To add a track to a track list, open the track list, and
select Options > Add tracks.
Equalizer
Select > Media > Music player > Options >
Equalizer.
78
Media applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 78 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 78 Jan 8, 2007 1:39:30 PM
With Equalizer, you can personalize the sound of your
music files. You can use preset frequency settings based
on styles of music. You can also create customized
settings based on your own listening preferences.
You cannot use the other functions of Music player
while Equalizer is open.
To use a preset frequency setting when playing music,
select the frequency setting you want to use, and select
Options > Activate.
To modify the frequency of a preset setting, select
Options > Edit, select a frequency band, and scroll up
or down to increase or decrease its value. You hear your
frequency adjustment immediately in the playback.
To reset the frequency bands to their original values,
select Options > Reset to defaults.
To create your own frequency setting, select Options >
New preset. Enter a name for the frequency setting.
Scroll up or down to move between the frequency
bands and set the frequency on each band.
Flash player
Select > Media > Flash Player.
With Flash player, you can view, play, and interact with
flash files made for mobile devices.
To play a flash file, scroll to it, and press the scroll key.
To send a flash file to compatible devices, select
Options > Send. Copyright protection may prevent the
sending of some flash files.
To switch between flash files saved on your device
memory or memory card, open the corresponding tabs.
To change the flash file quality, select Options >
Quality when you are playing the flash file. If you select
High, the playback of some flash files may appear
uneven and slow due to their original settings. Change
the quality setting of such files to Normal or Low for
improved playback.
Camera
Select > Media > Camera.
You can capture images or record video clips with the
built-in camera. The camera produces images in .jpeg
format and video clips in .mp4 or .3gpp format.
Capture an image
Your device supports an image capture resolution of up
to 2048 x 1536 pixels.
To capture an image, use the display as a viewfinder,
aim at your subject, and press the capture key half way
down. The camera focuses on the subject. Then press
the capture key all the way down. The device saves the
image in Gallery.
Tip: To zoom in or out before capturing an
image, scroll left or right.
79
Media applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 79 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 79 Jan 8, 2007 1:39:30 PM
Camera toolbar
The toolbar provides you with shortcuts to different
actions and settings before and after capturing an
image or recording a video. Scroll to the desired action,
and press the scroll key.
To show the toolbar before and after capturing an
image or recording a video, select Options > Show
icons.
To hide the toolbar, select Options > Hide icons. To
show the toolbar again, press the scroll key.
The available actions are:
Switch between the video and image modes.
Select the scene. A scene helps you to find the right
color and lighting settings for the current environment.
Use the flash (images only).
Activate the self-timer (images only).
Activate the sequence mode (images only).
Select a color effect.
Adjust the white balance.
Adjust the exposure compensation (images only).
Adjust the light sensitivity (images only).
The available options vary depending on the capture
mode and view you are in.
After capturing an image
To delete the captured image, select Delete from the
toolbar. Select Back to return to the viewfinder to
capture another image.
To print the image, select Print from the toolbar.
To set the image as the background image in the active
standby, select Options > Set as wallpaper.
To assign the image for a contact, select Set as contact
call image.
To view and modify images, select > Media >
Gallery > Images.
Record a video clip
Select Video mode from the toolbar. To start recording
a video clip, press the capture key. To pause the
recording, select Pause; to resume the recording, select
Continue. To stop the recording, select Stop. The device
saves the clip in Gallery.
After recording a video clip
To play the video clip you just recorded, select Play from
the toolbar.
To delete the video clip, select Delete from the toolbar.
To record a new video clip, select New video from the
toolbar.
80
Media applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 80 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 80 Jan 8, 2007 1:39:30 PM
Gallery
Select > Media > Gallery.
Use Gallery to access and use different types of media,
including images, videos, music, and sounds. All viewed
images and videos and all received music and sounds
are automatically saved to Gallery. You can browse,
open, and create folders and mark, copy, and move
items to folders. Sound clips are opened in the Music
player, and video clips and streaming links in the
RealPlayer application. Images are opened in the image
viewer.
To open a file or a folder, scroll to it, and press the scroll
key.
To create a new folder, select Options > Organize >
New folder.
To copy or move files, select a file and Options >
Organize > Move to folder, New folder, Move to
memory card, Copy to memory card, Copy to phone
mem., or Move to phone mem..
To download files into Gallery using the browser, select
Downl. graphics, Downld. videos, Downld. tracks, or
Downld. sounds. The browser opens, and you can
choose a bookmark or enter the address for the
download site.
To search for a file, select Options > Find. Write the item
you are searching for. Files that match the search are
shown.
Images
Select > Media > Gallery > Images.
Images consists of two views:
•In the image browser view you can organize, delete,
and rename images stored in your device or mem ory
card. You can also set images as wallpaper for your
display, or add them to contacts.
•In the image viewer, which opens when you select
an image in the image browser view, you can view
and send individual images.
The following file formats are supported: JPEG, BMP,
PNG, and GIF 87a/89a. The device does not necessarily
support all variations of the file formats.
To open an image for viewing, select Options > Open.
To open the next or previous image for viewing, scroll
right or left.
To enlarge the image on the display, select Options >
Zoom in. To reduce the image on the display, select
Zoom out.
To view the image in full screen size, select Options >
Full screen. To return to normal view, select Options >
Normal screen.
To rotate the image, select Options > Rotate. Select
Right to rotate the image clockwise by 90 degrees, or
select Left to rotate the image counterclockwise by 90
degrees.
81
Media applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 81 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 81 Jan 8, 2007 1:39:30 PM
Manage image files
To view detailed information about the image, select
Options > View details.
To send the image, select Options > Send, and the
method for sending.
To rename the image, select Options > Rename.
To set the image as wallpaper, select Options > Use
image as > Set as wallpaper.
To add the image to a contact, select Options > Add to
contact. The Contacts application opens, and you can
select the contact for the image.
Radio
Select > Media > Radio.
With the radio, you can search for radio channels, listen
to them, and save them on your device. You can leave
the radio open in the background while using the
device for other purposes. The wired headset works as
an antenna, so always connect the headset when using
the radio, even if you listen to it through the
loudspeaker. When you make or receive a phone call,
the radio stops playing, and resumes when you end the
call. You cannot listen to the radio when the device is
in the Offline profile.
To tune channels automatically, select the or
button.
To tune channels manually, select Options > Manual
tuning, and enter the frequency.
To save the found channel, select Options > Save
station. Select the position for the channel in the list.
The position corresponds to the number keys on the
keypad. A short press of a number key opens the radio
channel saved in that position. If you have a channel
saved to position 10 or higher, first press 1 and then the
second digit.
To listen to the next available channel, select the
button. To listen to the previous channel, select the
button. You can also go from channel to channel by
pressing the answer button in your headset.
To adjust the volume, scroll left or right.
To switch from headset use to loudspeaker, select
Options > Activate loudspeaker. To switch back to
headset use, select Options > Deactivate loudspeaker.
To set the radio to play in the background while you are
using your device for other purposes, select Options >
Play in background.
To switch the radio off, select Exit.
82
Media applications
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 82 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 82 Jan 8, 2007 1:39:30 PM
Settings
Select > Tools > Settings.
You can define and modify various settings of your
device. Modifying these settings affects the operation
of your device across several applications.
Some settings may be preset for the device or sent to
you in a special message by your service provider. You
may not be able to change such settings.
Select the setting you want to edit to do the following:
•Switch between two values, such as on or off.
•Select a value from a list.
•Open a text editor to enter a value.
•Open a slider to decrease or increase the value by
scrolling left or right.
General settings
Select > Tools > Settings > General.
Select from the following:
•Personalization — Change the display settings and
personalize the device.
•Date and time — Change the date and time.
•Enhancement — Define the settings for your
enhancements.
•Security — Define the security settings.
•Factory settings — Restore the original settings of
the device.
Personalization settings
Select > Tools > Settings > General >
Personalization.
Display settings
To define the level of light that the device needs before
switching on the backlight, select Display > Light
sensor.
To change the text size, select Display > Font size.
To adjust the length of time the display can be left idle
before the screen saver is activated, select Display >
Power saver time-out.
To select a welcome note or logo for the display, select
Display > Welcome note / logo. You can either choose
the default welcome note, enter your own text, or select
an image.
To set how quickly the display dims after the last
keypress, select Display > Light time-out.
To set the active application to continue on the cover
display when you close the communicator, select
Display > {No display_text mapping for
'qtn_set_display_cover_to_desk.gsdisplplugindelta',
locale='en'} > {No display_text mapping for
'qtn_set_display_desk_off.gsdisplplugindelta',
locale='en'}.
83
Settings
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 83 Jan 8, 2007 1:39:30 PM
Standby mode settings
To select whether to use the active standby, select
Standby mode > Active standby.
To assign shortcuts for the scroll key and selection keys,
select Standby mode > Shortcuts. These shortcuts are
not available in the active standby.
To assign shortcuts to applications, select Standby
mode > Standby apps.
To specify the settings for the news ticker, select
Standby mode > News ticker.
To select whether to show or hide the operator logo,
select Operator logo > On or Off.
Tone settings
To select a ringing tone for voice or video calls, select
Tones > Ringing tone or Video call tone.
To set the ringing type, select Tones > Ringing type.
You can also set the device to sound a ringing tone that
is a combination of the spoken name of the caller and
the selected ringing tone, when someone from your
contacts list calls you. Select Tones > Say caller's
name.
To set the volume level of the ringing tone, select
Tones > Ringing volume.
To set the various alert tones, select Tones > Message
alert tone, E-mail alert tone, Calendar alarm tone, or
Clock alarm tone.
To set the device to vibrate when you receive a call,
select Tones > Vibrating alert.
To set the volume level of the device keypad tones,
select Tones > Keypad tones.
To set the warning tones on or off, select Tones >
Warning tones.
Language settings
To set the language used on the device display, select
Language > Phone language.
To select the language in which you write notes and
messages, select Language > Writing language.
To select whether to use the predictive text input, select
Language > Predictive text. To reset the predictive text
dictionary to its original state, select Language > Reset
predictiv. dict..
To set how quickly the cursor moves to the next
character when you write text, select Language >
Keypress time-out. If you select None, you must move
the cursor manually with the scroll key.
Date and time settings
Select > Tools > Settings > General > Date and
time.
Select from the following:
•Time — Enter the time.
•Time zone — Enter the time zone.
•Date — Enter the date.
•Date format — Change how the date is displayed.
•Date separator — Change the symbol that separates
days, months, and years.
84
Settings
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 84 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 84 Jan 8, 2007 1:39:30 PM
•Time format — Select the 12-hour or 24-hour clock
system.
•Time separator — Select the symbol that separates
hours and minutes.
•Clock type — Select Analog or Digital.
•Clock alarm tone — Select the tone that you want to
use for the alarm clock.
•Network operator time — Select Auto-update to
update the time, date, and time zone information
automatically (network service). This service may
not be available in all networks.
Enhancement settings
Select > Tools > Settings > General >
Enhancement.
With most enhancements, you can do the following:
To determine which profile is activated when you
attach an enhancement to your device, select Default
profile.
To let the device answer phone calls automatically after
5 seconds when an enhancement is attached, select
Automatic answer > On. If the ringing type is set to
Beep once or Silent in the selected profile, the
automatic answer is disabled.
To illuminate the device while it is attached to an
enhancement, select Lights > On.
Device security
Select > Tools > Settings > General > Security.
Define the following security settings:
•Phone and SIM card — Adjust the security settings
for your device and SIM card.
•Certificate management — Manage your security
certificates.
•Track protected object — Manage your transaction
security.
•Security module — Manage your security module.
Avoid using codes that are similar to emergency
numbers to prevent accidental dialing of the
emergency number. Codes are shown as asterisks.
When you change a code, enter the current code, then
the new code twice.
Restore original settings
To restore the original device settings, select Factory
settings. To do this, you need your device lock code.
After resetting, the device may take a longer time to
power on. Documents, contact information, calendar
entries, and files are unaffected.
Telephone settings
Select > Tools > Settings > Phone.
Select from the following:
•Call — Define general call settings.
•Call forwarding — Define your call forward settings.
See "Call forward settings" on page 25.
•Call restriction — Define your call restriction settings.
See "Call restriction" on page 26.
•Network — Adjust the network settings.
85
Settings
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 85 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 85 Jan 8, 2007 1:39:30 PM
Call settings
To display your phone number to the person you are
calling, select Call > Send my caller ID > Yes. To let the
network determine whether your caller ID is sent, select
Set by network.
To display your net call address to the person you are
calling using a net call, select Call > Send my internet
call ID > Yes.
To be notified of a new incoming call while you have a
call in progress, select Call > Call waiting > Options >
Activate. To check if the function is active on the
network, select Options > Check status.
To select whether net calls alert or not, select Call >
Internet call alert. You are notified of missed net calls
with a notification.
To set the default call type, select Call > Default call
type and select Voice call if you make a GSM calls, or
Internet call if you make net calls.
To send a text message automatically to the person
who is calling you informing why you cannot answer
the incoming call, select Call > Reject call with SMS >
Yes. To set the text for the message, select Call >
Message text.
Network settings
Select > Tools > Settings > Phone > Network.
To select the network mode, select Network mode and
Dual mode, UMTS, or GSM. In the dual mode, the device
switches automatically between networks.
To select the operator, select Operator selection and
Manual to choose from available networks, or
Automatic to have the device select the network
automatically.
To set the device to indicate when it is used in Micro
Cellular Network (MCN), select Cell info display > On.
Connection settings
Select > Tools > Settings > Connection.
Select from the following:
•Access points — Set up new or edit existing access
points. Some or all access points may be preset for
your device by your service provider, and you may
not be able to create, edit, or remove them.
•Packet data — Determine when packet data
connections are used, and enter the access point if
you use your device as a modem for a computer.
•Wireless LAN — Determine if the device displays an
indicator when a WLAN is available, and how often
the device searches for networks.
•Data call — Set the time-out period after which data
call connections automatically end.
•SIP settings — View or create session initiation
protocol (SIP) profiles.
•Internet tel. — Define settings for net calls.
•VPN — Install and manage VPN policies, manage VPN
policy servers, see the VPN log, and create and
manage VPN access points.
•Configurations — View and delete trusted servers
from which your device may receive configuration
settings.
86
Settings
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 86 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 86 Jan 8, 2007 1:39:30 PM
To obtain information about WLAN or subscribing to a
packet data service and the appropriate connection and
configuration settings, contact your service provider.
The settings available for editing may vary.
Access points
Select > Tools > Settings > Connection > Access
points.
An access point is where your device connects to the
network by way of a data connection. To use e-mail and
multimedia services or to browse web pages, you must
first define access points for these services.
Some or all access points may be preset for your device
by your service provider, and you may not be able to
create, edit, or remove them.
To create a new access point, select Options > New
access point. Select Use default settings to enter the
necessary changes to the default access point settings,
or select Use existing settings to use an existing access
point as the basis for the new access point.
Packet data settings
Select > Tools > Settings > Connection > Packet
data.
Your device supports packet data connections, such as
GPRS in the GSM network. When you are using your
device in GSM and UMTS networks, it is possible to have
multiple data connections active at the same time;
access points can share a data connection, and data
connections remain active, for example, during voice
calls. See "Connection manager " on page 56.
To define the packet data settings, select Packet data
connection and select When available to register the
device to the packet data network when you switch the
device on in a supported network, or When needed to
establish a packet data connection only when an
application or action requires it. Select Access point and
enter the access point name provided by your service
provider to use the device as a packet data modem to
your computer.
These settings affect all access points for packet data
connections.
WLAN settings
Select > Tools > Settings > Connection > Wireless
LAN.
To have an indicator displayed when there is a WLAN
available in your current location, select Show WLAN
availability > Yes.
To select the interval for your device to scan for
available WLANs and update the indicator, select Scan
for networks. This setting is not visible unless you select
Show WLAN availability > Yes.
To check the unique media access control (MAC) address
that identifies your device, enter *#62209526# in the
standby mode. The MAC address is shown on the device
display.
87
Settings
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 87 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 87 Jan 8, 2007 1:39:30 PM
WLAN security settings
Select Access points > Options > New access point, or
select an access point and Options > Edit.
In the access point settings, select WLAN security
mode > WEP.
The wired equivalent privacy (WEP) encryption method
encrypts data before it is transmitted. Access to the
network is denied to users who do not have the
required WEP keys. When the WEP security mode is in
use, and your device receives a data packet not
encrypted with the WEP keys, the data is discarded.
In an Ad-hoc network, all devices must use the same
WEP key.
Select WLAN security settings and from the following:
•WEP key in use — Select the desired WEP key.
•Authentication type — Select Open or Shared.
•WEP key settings — Edit the settings for the WEP key.
EAP
Select > Tools > Settings > Connection > Access
points.
The EAP (extensible authentication protocol) plug-ins
are used in wireless networks to authenticate wireless
devices and authentication servers, and the different
EAP plug-ins make possible the use of various EAP
methods (network service).
You can view the EAP plug-ins currently installed in your
device (network service).
1. To define the EAP plug-in settings, select Options >
New access point and define an access point that
uses WLAN as a data bearer.
2. Select 802.1x or WPA/WPA2 as the security mode.
3. Select WLAN security settings > WPA/WPA2 >
EAP > EAP plug-in settings.
To use an EAP plug-in when you connect to a WLAN
using the access point, select the desired plug-in and
Options > Enable. The EAP plug-ins enabled for use
with this access point have a check mark next to them.
To not use a plug-in, select Options > Disable.
To edit the EAP plug-in settings, select Options > Edit.
To change the priority of the EAP plug-in settings, select
Options > Raise priority to attempt to use the plug-in
before other plug-ins when connecting to the network
with the access point, or Options > Lower priority to
use this plug-in for network authentication after
attempting to use other plug-ins.
See the device help for more information on EAP
plugins.
Data call settings
Select > Tools > Settings > Connection > Data
call.
To set the time-out period after which data calls
automatically end if no data has been transferred,
select Online time. Select User defined to enter the time
yourself or Unlimited to keep the connection active
until you select Options > Disconnect.
88
Settings
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 88 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 88 Jan 8, 2007 1:39:30 PM
Session initiation protocol (SIP)
settings
Select > Tools > Settings > Connection > SIP
settings.
Session initiation protocols (SIP) are used for creating,
modifying, and terminating certain types of
communication sessions with one or more participants
(network service). SIP profiles include settings for these
sessions. The SIP profile used by default for a
communication session is underlined.
To create a SIP profile, select Options > Add new >
Use default profile or Use existing profile.
To select the SIP profile you want to use by default for
communication sessions, select Options > Default
profile.
Net call settings
Select > Tools > Settings > Connection > Internet
tel..
To create a new net call profile, select Options > New
profile.
To edit an existing profile, select Options > Edit.
VPN access points
Select > Tools > Settings > Connection > VPN >
VPN access points.
To create a new VPN access point, select Options > New
access point.
To edit a VPN access point, select Options > Edit.
Configurations
Select > Tools > Settings > Connection >
Configurations.
You can receive messages from your service provider or
company information management containing
configuration settings for trusted servers. These
settings are automatically saved in Configurations. You
may receive configuration settings for access points,
multimedia, or e-mail services, and IM or
synchronization settings from trusted servers.
To delete configurations for a trusted server, select
Options > Delete. The configuration settings for other
applications provided by this server are also deleted.
Application settings
Select > Tools > Settings > Applications.
Select an application from the list.
89
Settings
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 89 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 89 Jan 8, 2007 1:39:30 PM
Device and data management
Back up data
It is recommended to back up device memory regularly
to the memory card or a compatible computer.
To back up information from the device memory to a
memory card, select > Tools > Memory >
Options > Back up phone memory.
To restore information from the memory card to the
device memory, select > Tools > Memory >
Options > Restore from card.
You can also connect your device to a compatible
computer and use Nokia PC Suite to back up data.
Remote configuration
Select > Tools > Device mgr..
With Device manager, you can manage data and
software on your device.
You can connect to a server, and receive configuration
settings for your device. You may receive server profiles
and different configuration settings from your service
providers or company information management
department. Configuration settings may include
connection and other settings used by different
applications in your device. Available options may vary.
The remote configuration connection is usually started
by the server when the device settings need to be
updated.
To create a new server profile, select Options > New
server profile.
To connect to the server and receive configuration
settings for your device, select Options > Start
configuration.
To view the configuration log of the selected profile,
select Options > View log.
Application manager
Select > Installat. > App. mgr..
With Application manager, you can see the software
packages that have been installed, with their name,
version number, type, and size. You can view the details
of installed applications, remove them from your
device, and specify installation settings.
Important: Only install and use applications and
other software from trusted sources, such as
applications that are Symbian Signed or have passed
the Java Verified™ testing.
90
Device and data management
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 90 Jan 8, 2007 1:39:30 PM
Activation keys
Select > Tools > Actv. keys.
Some media files, such as images, music, or video clips,
are protected by digital usage rights. The activation
keys for such files may allow or restrict their usage. For
example, with some activation keys you may listen to
a music track only a limited number of times. During
one playback session you may rewind, fast-forward, or
pause the track, but once you stop it, you have used one
of the instances allowed.
To view your activation keys by type, select Valid keys,
Invalid keys, or Not in use.
To view the key details, select Options > Key details.
To activate a key, go to the main view of the activation
keys, and select Invalid keys > Options > Get
activation key. Establish a network connection at the
prompt, and you are directed to a web site where you
can purchase rights to the media.
To remove file rights, open the valid keys tab or the keys
not in use tab, scroll to the desired file, and select
Options > Delete. If there are several rights related to
the same media file, all the rights are deleted.
The group key view displays all of the files related to a
group right. If you have downloaded multiple media
files with the same rights, they are all displayed in this
view. You can open the group view from either the valid
keys or invalid keys tabs. To access these files, open the
group rights folder.
To rename a group, select Options > Rename. Enter the
new name to change the name of the group rights.
Data synchronization
Select > Tools > Sync.
With Sync, you can synchronize your contacts, calendar
entries, notes, or mailboxes with corresponding
applications on a compatible computer or remote
internet server. Your synchronization settings are saved
in a synchronization profile. The Sync application uses
SyncML technology for remote synchronization. For
information on SyncML compatibility, contact the
supplier of the applications with which you want to
synchronize your device.
You may receive the synchronization settings as a
message from your service provider. The available
applications you can synchronize may vary. Contact
your service provider for more information.
Create a synchronization profile
To create a profile, select Options > New sync profile
and assign a name for the profile, select the
applications to synchronize with the profile, and specify
the needed connection settings. Contact your service
provider for details.
Select applications to synchronize
1. To select the applications to synchronize with a
synchronization profile, select Options > Edit sync
profile > Applications.
2. Select the desired application, and select Include in
sync > Yes.
91
Device and data management
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 91 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 91 Jan 8, 2007 1:39:30 PM
3. Specify the Remote database and Synchronization
type settings.
Barcode reader
Select > Tools > Barcode.
Use the Barcode application to decode different types
of codes, such as barcodes and codes in magazines. The
codes may contain information such as web addresses,
e-mail addresses, and phone numbers. These are
indicated by icons on the top of the display in the
direction they appear in the decoded information.
The Barcode application uses the camera in your device
to scan codes.
To scan the code with the camera, select Scan code. Set
the code between the red lines on the display. The
decoded information appears on the display.
To save the scanned data, select Options > Save. The
data is saved in .bcr format.
To view previously saved, decoded information, select
Saved data. To open a code, press the scroll key.
The device reverts to the standby mode to save battery
power if no keys are pressed for 1 minute. To continue
scanning or viewing saved information, press the scroll
key.
Download!
Select > #Download!.
With Download! (network service), you can browse,
download, and install items, such as latest applications
and related documents, to your device from the web.
The items are categorized under catalogs and folders
provided by Nokia or independent service providers.
Some items may be chargeable, but you can usually
preview them free of charge.
Only install and use applications and other software
from sources that offer adequate security and
protection against harmful software.
92
Device and data management
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 92 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 92 Jan 8, 2007 1:39:30 PM
Security
Fixed dialing
Select > Contacts > Options > SIM contacts >
Fixed dial contacts.
With the fixed dialing service, you can restrict calls from
your device to certain phone numbers. Not all SIM cards
support the fixed dialing service. Contact your service
provider for more information.
When fixed dialing is activated, calls may be possible to
the official emergency number programmed into your
device.
1. To restrict calls from your device, select Options >
New SIM contact and enter the contact name and
phone number to the list of numbers to which calls
are allowed, or select Add from Contacts to copy the
contact from Contacts. To restrict calls by a country
prefix, enter the country prefix in the list of
numbers. All phone numbers to which calls are
allowed must start with this country prefix.
2. Select Options > Activate fixed dialing. You need
your PIN2 code to activate and deactivate fixed
dialing or edit your fixed dialing contacts. Contact
your service provider if you do not have the code.
To cancel the service, select Options > Deactivate
fixed dialing.
Tip: To send text messages to the SIM contacts
while the fixed dialing service is active, you
need to add the text message center number
to the fixed dialing list.
Certificate manager
Important: Even if the use of certificates makes
the risks involved in remote connections and software
installation considerably smaller, they must be used
correctly in order to benefit from increased security. The
existence of a certificate does not offer any protection
by itself; the certificate manager must contain correct,
authentic, or trusted certificates for increased security
to be available. Certificates have a restricted lifetime. If
"Expired certificate" or "Certificate not valid yet" is
shown even if the certificate should be valid, check that
the current date and time in your device are correct.
Before changing any certificate settings, you must
make sure that you really trust the owner of the
certificate and that the certificate really belongs to the
listed owner.
Select > Tools > Settings > General > Security >
Certificate management.
Digital certificates are used to verify the origins of
software but do not guarantee safety. There are three
different types of certificates: authority certificates,
personal certificates, and server certificates. During a
secure connection, a server may send a server
93
Security
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 93 Jan 8, 2007 1:39:30 PM
certificate to your device. Upon receipt, it is checked
through an authority certificate stored on your device.
You receive notification if the identity of the server is
not authentic or if you do not have the correct
certificate in your device.
Download a certificate from a web site, or receive a
certificate as an e-mail attachment, or as a message
sent through a Bluetooth or infrared connection.
Certificates should be used when you connect to an
online bank or a remote server to transfer confidential
information. They should also be used if you want to
reduce the risk of viruses or other malicious software,
and to check the authenticity of software when you
download and install software to your device.
Tip: When you add a new certificate, check its
authenticity.
Security modules
Select > Tools > Settings > General > Security >
Security module.
To view or edit a security module, scroll to it, and press
the scroll key.
To view detailed information about a security module,
select Options > Security details.
The key store contains the contents of the security
module. To delete the key store, select Key store, select
the desired key store, and Options > Delete. You may
not be able to delete the key store of all security
modules.
Memory card security
Select > Tools > Memory.
You can protect a memory card with a password to
prevent unauthorized access. To set a password, select
Options > Set password. The password can be up to
eight characters long and is case-sensitive. The
password is stored in your device. You do not need to
enter it again while you use the memory card on the
same device. If you use the memory card on another
device, you are asked for the password. Not all memory
cards support password protection.
To remove the memory card password, select Options >
Remove password. When you remove the password,
the data on the memory card is not protected against
unauthorized use.
To open a locked memory card, select Options > Unlock
memory card. Enter the password.
If you cannot recall the password to unlock a locked
memory card, you may reformat the card, in which case
the card is unlocked and password removed.
Formatting a memory card destroys all data stored on
the card.
Lock the device
When the device is locked, calls may be possible to the
official emergency number programmed into your
device.
To prevent access to the contents of your device, lock
the device in the standby mode. Press the power key,
94
Security
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 94 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 94 Jan 8, 2007 1:39:30 PM
select Lock phone, and enter your lock code. The default
lock code is 12345. To unlock, press the left selection
key, enter your lock code, and press the scroll key.
You can also lock the device remotely by sending a text
message to the device. To enable remote locking and
to define the text for the message, select > Tools >
Settings > General > Security > Phone and SIM
card > {No display_text mapping for
'qtn_set_remotelock_status.remotelockui',
locale='en'} > {No display_text mapping for
'qtn_set_remotelock_on.remotelockui', locale='en'}.
Enter the remote lock message and confirm the
message. The message must be at least 5 characters
long.
To change the lock code, select > Tools >
Settings > General > Security > Phone and SIM
card > Lock code. Enter the old code and then the new
code twice. The new code can be 4-255 characters long.
Both alphabets and digits can be used, and both
uppercase and lowercase alphabets are possible.
95
Security
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 95 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 95 Jan 8, 2007 1:39:30 PM
Shortcuts
Here are some of the available keyboard shortcuts in
your device. Shortcuts can make the use of the
applications more efficient.
General shortcuts
Power key Press and hold to switch your device
on and off.
Press once to switch between
profiles.
Menu key Press once to open the main menu
for access to all applications.
Press and hold to bring up a list of
open applications. To navigate
between the open applications,
select an application. To close open
applications, select an application,
and press the backspace key .
Active standby mode
Left selection
key + *
Lock and unlock the keypad.
Call key Open the call log.
0Press and hold to open your home
page in the Web browser.
#Press and hold to switch between
the Silent and Normal profiles.
1Press and hold to call your voice
mailbox.
Number key (2–
9)
Call a phone number using speed
dialing. You must first activate
speed dialing at > Tools >
Settings > Phone > Call > 1-touch
dialing > On.
Web
*Zoom in the page.
#Zoom out the page.
2Open the search dialog.
5View the active pages.
8View the page overview.
9Open the dialog for entering a new
web address.
0Open the Bookmarks folder.
Image viewer
Call key Send the image.
0Zoom out.
5Zoom in.
96
Shortcuts
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 96 Jan 8, 2007 1:39:30 PM
7Zoom in. Press twice for the full
screen size.
4Scroll left in the zoomed image.
6Scroll right in the zoomed image.
2Scroll up in the zoomed image.
8Scroll down in the zoomed image.
3Rotate clockwise.
1Rotate counterclockwise.
*Switch between the full screen size
and normal view.
Editing shortcuts
Chr key Press once to view a table of special
characters not found on the keypad.
Chr + tab Switch between open applications.
Ctrl+A Select all.
Ctrl+C Copy.
Ctrl+V Paste.
Ctrl+X Cut.
Ctrl+Z Undo.
Ctrl + scroll right Move the focus one word forward.
Ctrl + scroll left Move the focus one word backward.
Chr + scroll right Move to the end of the line.
Chr + scroll left Move to the start of the line.
Chr + scroll up Page up.
Chr + scroll
down
Page down.
Ctrl + chr + scroll
up
Move to the start of the document.
Ctrl + chr + scroll
down
Move to the end of the document.
Shift + scroll
right
Select the next character on the
right.
Shift + scroll left Select the next character on the left.
Ctrl + shift +
scroll right
Select the next word on the right.
Ctrl + shift +
scroll left
Select the next word on the left.
Shift +
backspace
Delete text from the right.
Chr + alphabet Insert an accented character.
Ctrl + chr Change the writing language.
Shift + scroll up Select all the text on top and/or left
side of the cursor.
Shift + scroll
down
Select all the text below and/or right
side of the cursor.
97
Shortcuts
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 97 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 97 Jan 8, 2007 1:39:30 PM
Glossary
3G 3rd generation mobile
communications. A digital system for
mobile communications which aims at
global use and provides increased
bandwidth. 3G lets a mobile device user
access a wide variety of services, such as
multimedia.
Ad-hoc
operating
mode
In a wireless LAN, the ad hoc operating
mode allows you to send and receive
data from other devices with
compatible wireless LAN support. These
functions may require an additional
third party application to work. No
wireless LAN access point is required.
Simply make the necessary
configurations and start
communicating. Ad hoc networking is
easy to set up, but communication is
limited to devices that are within range
and support compatible wireless LAN
technology.
Cookies Cookies are little pieces of information,
given by the server to you, to store
information about your visits to a web
site. When you accept cookies, the
server is able to evaluate your use of the
web site, what you are interested in,
what you want to read, and so on.
DNS Domain name service. An internet
service that translates domain names
such as www.nokia.com into IP
addresses such as 192.100.124.195.
Domain names are easier to remember
but this translation is needed because
the internet is based on IP addresses.
DTMF tones Dual Tone Multi-Frequency tones. The
DTMF system is used by touch-tone
telephones. DTMF assigns a specific
frequency, or tone, to each key so that it
can easily be identified by a
microprocessor. DTMF tones allow you
to communicate with voice mailboxes,
computerized telephony systems, and
so on.
EAP Extensible authentication protocol. EAP
plug-ins are used in wireless networks
to authenticate wireless devices and
authentication servers.
EGPRS Enhanced GPRS. EGPRS is similar to GPRS,
but it enables faster connection. For
more information on the availability of
EGPRS and data transfer speed, contact
your service provider.
98
Glossary
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 98 Jan 8, 2007 1:39:30 PM
GPRS General packet radio service. GPRS
enables wireless access for mobile
phones to data networks (network
service). GPRS uses packet data
technology where information is sent in
short bursts of data over the mobile
network. The benefit of sending data in
packets is that the network is occupied
only when sending or receiving data. As
GPRS uses the network efficiently, it
allows for quick data connection setup
and fast data transmission speeds.
You must subscribe to the GPRS service.
For availability and subscription to
GPRS, contact your service provider.
During a voice call, you cannot establish
a GPRS connection, and any existing
GPRS connection is put on hold unless
the network supports dual transfer
mode.
GPS Global positioning system. GPS is a
worldwide radio navigation system.
HSDPA High-speed downlink packet access.
HSDPA brings high-speed data delivery
to 3G terminals, ensuring that users
requiring effective multimedia
capabilities benefit from data rates
previously unavailable because of
limitations in the radio access network.
HTTP Hypertext transfer protocol. A document
transfer protocol used in the web.
HTTPS HTTP over a secure connection.
IMAP4 Internet mail access protocol, version 4.
A protocol used for accessing your
remote mailbox.
Internet
access point
An access point is where your device
connects to a network. To use e-mail
and multimedia services or to connect
to the internet and browse web pages,
you must first define internet access
points for these services.
Infrastructur
e operating
mode
The infrastructure operating mode
allows two kinds of communication:
wireless devices communicate with
each other through a wireless LAN
access point or wireless devices
communicate with a wired LAN device
through a wireless LAN access point. The
advantage of the infrastructure
operating mode is that you can have
more control over network connections
because they pass through an access
point. A wireless device can access the
services that are available in a regular
wired LAN: company database, e-mail,
the Internet, and other network
resources, for example.
99
Glossary
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 99 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 99 Jan 8, 2007 1:39:30 PM
PIN Personal identity number. The PIN code
protects your device from unauthorized
use. The PIN code is supplied with the
SIM card. If the PIN code request is
selected, the code is required each time
the device is switched on. The PIN code
must be 4 to 8 digits long.
PIN2 The PIN2 code is supplied with some SIM
cards. The PIN2 code is required to
access certain functions supported by
the SIM card. The length of the PIN2 code
is 4 to 8 digits.
POP3 Post office protocol, version 3. A
common mail protocol that can be used
for accessing your remote mailbox.
SIP Session initiation protocol. SIP is used
for creating, modifying, and
terminating certain types of
communication sessions with one or
more participants.
SSID Service set identifier. SSID is the name
that identifies the specific wireless LAN.
Streaming Streaming audio and video files means
playing them directly from the web
without downloading them first to your
device.
UMTS Universal mobile telecommunications
system. UMTS is a 3G mobile
communication system. Besides voice
and data, UMTS enables audio and video
delivery to wireless devices.
When you use your device in GSM and
UMTS networks, multiple data
connections can be active at the same
time, and access points can share a data
connection. In the UMTS network, data
connections remain active during voice
calls. You can, for example, browse the
web faster than previously possible
while simultaneously speaking on the
phone.
UPIN PIN code used in UMTS network.
USIM SIM card used in UMTS network.
USSD
command
A service request, such as request to
activate an application or configure
various settings remotely, that you can
send to your operator or service
provider with your device.
VoIP Voice over internet protocol technology.
VoIP is a set of protocols that facilitate
phone calls over an IP network, such as
the internet.
VPN Virtual private network. VPN creates a
secure connection to compatible
corporate intranet and services, such as
e-mail.
WAP Wireless application protocol. WAP is an
international standard for wireless
communication.
100
Glossary
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 100 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 100 Jan 8, 2007 1:39:30 PM
WEP Wired equivalent privacy. WEP is an
encryption method that encrypts data
before it is transmitted.
WLAN Wireless local area network. A wireless
LAN connection is established when you
create a data connection using a
wireless LAN internet access point. The
active wireless LAN connection is ended
when you end the data connection.
If you move the device to another
location within the wireless LAN and out
of range of a wireless LAN access point,
the roaming functionality can
automatically connect your device to
another access point that belongs to the
same network. As long as you remain
within range of access points that
belong to the same network, your
device can stay connected to the
network.
WPA2 Security method for WLAN.
101
Glossary
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 101 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 101 Jan 8, 2007 1:39:30 PM
Battery information
Your device is powered by a rechargeable battery. The
battery can be charged and discharged hundreds of
times, but it will eventually wear out. When the talk and
standby times are noticeably shorter than normal,
replace the battery. Use only Nokia approved batteries,
and recharge your battery only with Nokia approved
chargers designated for this device.
If a replacement battery is being used for the first time
or if the battery has not been used for a prolonged
period, it may be necessary to connect the charger, then
disconnect and reconnect it to begin charging the
battery.
Unplug the charger from the electrical plug and the
device when not in use. Do not leave a fully charged
battery connected to a charger, since overcharging may
shorten its lifetime. If left unused, a fully charged
battery will lose its charge over time.
If the battery is completely discharged, it may take
several minutes before the charging indicator appears
on the display or before any calls can be made.
Use the battery only for its intended purpose. Never use
any charger or battery that is damaged.
Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object such as a
coin, clip, or pen causes direct connection of the positive
(+) and negative (-) terminals of the battery. (These look
like metal strips on the battery.) This might happen, for
example, when you carry a spare battery in your pocket
or purse. Short-circuiting the terminals may damage
the battery or the connecting object.
Leaving the battery in hot or cold places, such as in a
closed car in summer or winter conditions, will reduce
the capacity and lifetime of the battery. Always try to
keep the battery between 15°C and 25°C (59°F and 77°
F). A device with a hot or cold battery may not work
temporarily, even when the battery is fully charged.
Battery performance is particularly limited in
temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode.
Batteries may also explode if damaged. Dispose of
batteries according to local regulations. Please recycle
when possible. Do not dispose as household waste.
Do not dismantle or shred cells or batteries. In the event
of a battery leak, do not allow the liquid to come in
contact with the skin or eyes. In the event of such a leak,
flush your skin or eyes immediately with water, or seek
medical help.
102
Battery information
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 102 Jan 8, 2007 1:39:30 PM
Nokia battery authentication guidelines
Always use original Nokia batteries for your safety. To
check that you are getting an original Nokia battery,
purchase it from an authorized Nokia dealer, look for
the Nokia Original Enhancements logo on the
packaging, and inspect the hologram label using the
following steps:
Successful completion of the four steps is not a total
assurance of the authenticity of the battery. If you have
any reason to believe that your battery is not an
authentic, original Nokia battery, you should refrain
from using it, and take it to the nearest authorized
Nokia service point or dealer for assistance. Your
authorized Nokia service point or dealer will inspect the
battery for authenticity. If authenticity cannot be
verified, return the battery to the place of purchase.
Authenticate hologram
1. When looking at the hologram
on the label, you should see the
Nokia connecting hands
symbol from one angle and the
Nokia Original Enhancements
logo when looking from
another angle.
2. When you angle the hologram
left, right, down, and up, you
should see 1, 2, 3, and 4 dots
on each side respectively.
3. Scratch the side of the label to
reveal a 20-digit code, for
example,
12345678919876543210.
Turn the battery so that the
numbers are facing upwards.
The 20-digit code reads
starting from the number at
the top row followed by the
bottom row.
4. Confirm that the 20-digit code
is valid by following the
instructions at
www.nokia.com/
batterycheck.
103
Nokia battery authentication guidelines
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 103 Jan 8, 2007 1:39:30 PM
What if your battery is not
authentic?
If you cannot confirm that your Nokia battery with the
hologram on the label is an authentic Nokia battery,
please do not use the battery. Take it to the nearest
authorized Nokia service point or dealer for assistance.
The use of a battery that is not approved by the
manufacturer may be dangerous and may result in poor
performance and damage to your device and its
enhancements. It may also invalidate any approval or
warranty applying to the device.
To find out more about original Nokia batteries, visit
www.nokia.com/battery.
104
Nokia battery authentication guidelines
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 104 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 104 Jan 8, 2007 1:39:30 PM
Care and maintenance
Your device is a product of superior design and
craftsmanship and should be treated with care. The
following suggestions will help you protect your
warranty coverage.
•Keep the device dry. Precipitation, humidity, and all
types of liquids or moisture can contain minerals
that will corrode electronic circuits. If your device
does get wet, remove the battery, and allow the
device to dry completely before replacing it.
•Do not use or store the device in dusty, dirty areas.
Its moving parts and electronic components can be
damaged.
•Do not store the device in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt certain
plastics.
•Do not store the device in cold areas. When the
device returns to its normal temperature, moisture
can form inside the device and damage electronic
circuit boards.
•Do not attempt to open the device other than as
instructed in this guide.
•Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards and fine
mechanics.
•Do not use harsh chemicals, cleaning solvents, or
strong detergents to clean the device.
•Do not paint the device. Paint can clog the moving
parts and prevent proper operation.
•Use a soft, clean, dry cloth to clean any lenses, such
as camera, proximity sensor, and light sensor lenses.
•Use only the supplied or an approved replacement
antenna. Unauthorized antennas, modifications, or
attachments could damage the device and may
violate regulations governing radio devices.
•Use chargers indoors.
•Always create a backup of data you want to keep,
such as contacts and calendar notes.
•To reset the device from time to time for optimum
performance, power off the device and remove the
battery.
These suggestions apply equally to your device, battery,
charger, or any enhancement. If any device is not
working properly, take it to the nearest authorized
service facility for service.
Disposal
The crossed-out wheeled-bin symbol on your
product, literature, or packaging reminds you that
in the European Union all electrical and electronic
products, batteries, and accumulators must be
taken to separate collection at the end of their working
life. Do not dispose of these products as unsorted
municipal waste.
105
Care and maintenance
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 105 Jan 8, 2007 1:39:30 PM
Return the products to collection to prevent possible
harm to the environment or human health from
uncontrolled waste disposal and to promote the
sustainable reuse of material resources. Collection
information is available from the product retailer, local
waste authorities, national producer responsibility
organizations, or your local Nokia representative. For
more information, see product Eco-Declaration or
country-specific information at /www.nokia.com.
106
Care and maintenance
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 106 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 106 Jan 8, 2007 1:39:30 PM
Additional safety information
Small children
Your device and its enhancements may contain small
parts. Keep them out of the reach of small children.
Operating environment
This device meets RF exposure guidelines when used
either in the normal use position against the ear or
when positioned at least 1,5 centimeters (5/8 inches)
away from the body. When a carry case, belt clip, or
holder is used for body-worn operation, it should not
contain metal and should position the device the
above-stated distance from your body.
To transmit data files or messages, this device requires
a quality connection to the network. In some cases,
transmission of data files or messages may be delayed
until such a connection is available. Ensure the above
separation distance instructions are followed until the
transmission is completed.
Parts of the device are magnetic. Metallic materials may
be attracted to the device. Do not place credit cards or
other magnetic storage media near the device, because
information stored on them may be erased.
Medical devices
Operation of any radio transmitting equipment,
including wireless phones, may interfere with the
functionality of inadequately protected medical
devices. Consult a physician or the manufacturer of the
medical device to determine if they are adequately
shielded from external RF energy or if you have any
questions. Switch off your device in health care facilities
when any regulations posted in these areas instruct you
to do so. Hospitals or health care facilities may be using
equipment that could be sensitive to external RF
energy.
Implanted medical devices
Manufacturers of medical devices recommend that a
minimum separation of 15.3 centimeters (6 inches)
should be maintained between a wireless device and
an implanted medical device, such as a pacemaker or
implanted cardioverter defibrillator, to avoid potential
interference with the medical device. Persons who have
such devices should:
•Always keep the wireless device more than 15.3
centimeters (6 inches) from the medical device when
the wireless device is turned on.
•Not carry the wireless device in a breast pocket.
•Hold the wireless device to the ear opposite the
medical device to minimize the potential for
interference.
•Turn the wireless device off immediately if there is
any reason to suspect that interference is taking
place.
107
Additional safety information
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 107 Jan 8, 2007 1:39:30 PM
•Read and follow the directions from the
manufacturer of their implanted medical device.
If you have any questions about using your wireless
device with an implanted medical device, consult your
health care provider.
Hearing aids
Some digital wireless devices may interfere with some
hearing aids. If interference occurs, consult your service
provider.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles such as electronic fuel injection systems,
electronic antiskid (antilock) braking systems,
electronic speed control systems, and air bag systems.
For more information, check with the manufacturer, or
its representative, of your vehicle or any equipment
that has been added.
Only qualified personnel should service the device or
install the device in a vehicle. Faulty installation or
service may be dangerous and may invalidate any
warranty that may apply to the device. Check regularly
that all wireless device equipment in your vehicle is
mounted and operating properly. Do not store or carry
flammable liquids, gases, or explosive materials in the
same compartment as the device, its parts, or
enhancements. For vehicles equipped with an air bag,
remember that air bags inflate with great force. Do not
place objects, including installed or portable wireless
equipment in the area over the air bag or in the air bag
deployment area. If in-vehicle wireless equipment is
improperly installed and the air bag inflates, serious
injury could result.
Potentially explosive
environments
Switch off your device when in any area with a
potentially explosive atmosphere, and obey all signs
and instructions. Potentially explosive atmospheres
include areas where you would normally be advised to
turn off your vehicle engine. Sparks in such areas could
cause an explosion or fire resulting in bodily injury or
even death. Switch off the device at refueling points
such as near gas pumps at service stations. Observe
restrictions on the use of radio equipment in fuel
depots, storage, and distribution areas; chemical
plants; or where blasting operations are in progress.
Areas with a potentially explosive atmosphere are
often, but not always, clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), and areas where the air contains
chemicals or particles such as grain, dust, or metal
powders.
Emergency calls
Important: Wireless phones, including this
device, operate using radio signals, wireless networks,
landline networks, and user-programmed functions.
108
Additional safety information
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 108 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 108 Jan 8, 2007 1:39:30 PM
Because of this, connections in all conditions cannot be
guaranteed. You should never rely solely on any
wireless device for essential communications like
medical emergencies.
To make an emergency call:
1. If the device is not on, switch it on. Check for
adequate signal strength.
Some networks may require that a valid SIM card is
properly inserted in the device.
2. Press the end key as many times as needed to clear
the display and ready the device for calls.
3. Enter the official emergency number for your
present location. Emergency numbers vary by
location.
4. Press the call key.
If certain features are in use, you may first need to turn
those features off before you can make an emergency
call. If the device is in the offline or flight profile mode,
you may need to change the profile to activate the
phone function before you can make an emergency call.
Consult this guide or your service provider for more
information.
When making an emergency call, give all the necessary
information as accurately as possible. Your wireless
device may be the only means of communication at the
scene of an accident. Do not end the call until given
permission to do so.
CERTIFICATION
INFORMATION (SAR)
THIS MOBILE DEVICE MEETS GUIDELINES FOR EXPOSURE TO
RADIO WAVES.
Your mobile device is a radio transmitter and receiver.
It is designed not to exceed the limits for exposure to
radio waves recommended by international guidelines.
These guidelines were developed by the independent
scientific organization ICNIRP and include safety
margins designed to assure the protection of all
persons, regardless of age and health.
The exposure guidelines for mobile devices employ a
unit of measurement known as the Specific Absorption
Rate or SAR. The SAR limit stated in the ICNIRP
guidelines is 2.0 watts/kilogram (W/kg) averaged over
10 grams of tissue. Tests for SAR are conducted using
standard operating positions with the device
transmitting at its highest certified power level in all
tested frequency bands. The actual SAR level of an
operating device can be below the maximum value
because the device is designed to use only the power
required to reach the network. That amount changes
depending on a number of factors such as how close
you are to a network base station. The highest SAR value
under the ICNIRP guidelines for use of the device at the
ear is 0.65 W/kg.
Use of device accessories and enhancements may result
in different SAR values. SAR values may vary depending
on national reporting and testing requirements and the
network band. Additional SAR information may be
provided under product information at
www.nokia.com.
109
Additional safety information
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 109 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 109 Jan 8, 2007 1:39:30 PM
Your mobile device is also designed to meet the
requirements for exposure to radio waves established
by the Federal Communications Commission (USA) and
Industry Canada. These requirements set a SAR limit of
1.6 W/kg averaged over one gram of tissue. The highest
SAR value reported under this standard during product
certification for use at the ear is 0.59 W/kg and when
properly worn on the body is 0.72 W/kg. Information
about this device model can be found at www.fcc.gov/
oet/fccid by searching the equipment authorization
system using FCC ID: PYARA-6.
110
Additional safety information
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 110 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 110 Jan 8, 2007 1:39:30 PM
Index
Symbols/Numerics
1-touch dialing 25
A
access points 60
creating 86, 87
setting up 61
VPN 89
activation keys 91
Active notes 51
active standby 12
active standby mode
WLAN wizard 64
alarm clock 47
alert tones 84
altitude calibration 71
application manager 90
application settings 89
applications
common actions 12
shortcuts 84
attachments
e-mail 34
audio files 77
authority certificates 93
automatic answer 85
B
backing up data 90
Barcode reader 92
Bluetooth
authorizing devices 58
connections 56
display indicators 59
pairing 58
passcode 58
receiving data 57
security 59
sending data 57
bookmarks
adding 67
browsing 66
deleting 66
browsing
maps 68
offline 67
web 66
business cards 43
deleting 43
saving 43
sending 43
C
cable 55
cache
emptying 67
Calculator 49
Calendar 45
adding received entries 45
changing the view 46
creating entries 45
deleting entries 45
sending entries 45
call forward settings 25
caller ID 86
calls
1-touch dialing 25
answering 21
automatic answer 85
call waiting 86
caller ID 86
conference call 22
data call settings 61, 88
declining 21
fixed dialing 93
forwarding 25
making 21
making a net call 24
muting the ringing tone 21
net call alert 86
net calls 23
push to talk 72
rejecting 21
rejecting calls with text
message 86
restricting 26
restricting net calls 26
restricting outgoing calls 93
selecting call type 86
settings 85, 86
111
Index
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 111 Jan 8, 2007 1:39:30 PM
video calls 22
voice commands 75
voice dialing 75
voice mail 27
camera 79
capturing an image 79
light sensitivity 80
recording a video clip 80
self-timer 80
sequence mode 80
using the toolbar 80
capture key 79
car kit
remote SIM access 59
cell broadcast 29
settings 40
cell broadcast messages 35
Certificate manager 93
certificates 93
changing the lock code 94
channels
news ticker 13
push to talk 73
radio 82
chat
See
IM
Chr key 11
Clock 47
alarms 47
settings 47
world clock 47
conference calls 22
configuration messages 89
Connection manager 56
connection methods
Bluetooth 56
cable 55
infrared 60
modem 55
connection settings 86
connections
data call 61
ending 56
GPRS settings 61
internet 60
WLAN settings 65
contact groups 43
contacts
adding thumbnails 42
changing name order 43
copying information 42
creating 42
default information 42
editing 42
groups 43
ringing tones 43
searching 42
sending 42
SIM card contacts 42
voice tags 42
converting
currencies 52
measurements 51
currency conversions 52
D
data and software
management 90
data back-ups 90
data call settings 88
data synchronization 91
date
changing 84
settings 84
deleting
pairing 58
destination
removing 71
setting 71
device management 90
Device manager 90
digital certificates 93
display
brightness 83
contrast 83
language 84
light time-out 83
screen saver 83
settings 83
welcome note 83
E
e-mail
accounts 39
automatic retrieval
settings 40
connecting to mailbox 34
creating folders 35
deleting 35
messages 32
replying 34
retrieval settings 40
112
Index
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 112 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 112 Jan 8, 2007 1:39:30 PM
setting up 33
user settings 39
EAP
plug-in settings 88
using an EAP plug-in 88
ending
internet connections 67
network connections 56
enhancements
remote SIM access 59
settings 85
equalizer 78
frequency settings 79
F
File manager 48
managing files 48
files
audio files 77
downloading 81
file rights 91
flash files 79
image files 81
sending 48
video files 77
find 48
fixed dialing 93
Flash player 79
forwarding calls 25
frequency settings 79
G
Gallery 81
general settings 83
Global positioning system
See
GPS
GPRS
access point settings 61
settings 87
GPS 68
GPS data 70
H
hearing
call information 74
contacts 74
current time 74
help 17
I
IM 36
groups 37
settings 36
starting a conversation 36
images 81
adding to contacts 80, 82
adjusting 80
background images 80
capturing 79
color effect 80
printing 80
renaming 82
rotating 81
sending 82
timing 80
wallpaper 82
white balance 80
zooming 81
infrared 60
instant messaging
See
IM
internet 66
access points 60
browsing 66
ending connections 67
settings 60
internet telephony
See
net calls
K
key store 94
keypad tones 84
keypress time-out 84
keys
shortcuts 84
L
landmarks 71
creating 71
language
changing 14
display language 84
settings 84
writing language 84
lights 85
listening to music 78
lock code
changing 94
locking the device 94
Log 28
adding numbers to
Contacts 28
113
Index
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 113 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 113 Jan 8, 2007 1:39:30 PM
deleting 28
settings 28
logos
operator logo 84
welcome logo 83
M
MAC address 87
mail
See
e-mail
mailboxes
connecting 34
creating 33
making a call 21
Maps 68
browsing 68
planning routes 70
saving locations 69
searching 70
settings 69
measurements
converting 51
measuring system
changing 71
media applications 77
memory
details 16
memory card 16
backing up data 90
formatting 17
locking 94
microSD 16
passwords 94
setting a password 17
setting password 48
unlocking 17
menu 11
menu key 11
message reader 30, 74
messages 29
call rejection messages 86
cell broadcast messages 35
cell broadcast settings 40
configuration messages 89
e-mail 32
folders 29
multimedia messages 31
other settings 41
picture messages 30
service messages 37
special messages 35
text message settings 38
text messages 30
writing 13
Messaging 29
Drafts folder 29
folders 29
Outbox folder 29
Sent folder 29
microSD 16
MMS
See
multimedia messages
modem 55
multimedia messages 31
creating 31
creating presentations 32
sending 31
settings 38
Music player 78
track lists 78
N
navigation 70
net calls 23
alert settings 86
connecting 24
making a call 24
profiles 24, 89
restricting 26
settings 86, 89
network
selecting mode 86
settings 86
news channels 13
news ticker 13
subscribing to channels 13
Nokia PC Suite 18
Nokia Team Suite 49
editing teams 50
notes
editing 54
writing 53
O
operator
logo 84
selecting 86
original settings 85
P
packet data
access point settings 61
114
Index
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 114 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 114 Jan 8, 2007 1:39:30 PM
settings 87
pairing
devices 58
passcode 58
passcode 58
passwords
memory card password 17,
48
restriction password 26
PC Suite 18
PDF reader 52
personal certificates 93
personalization 15
changing language 84
display 83
settings 83
standby modes 84
tones 84
phone
See
calls
picture messages 30
viewing 30
planning routes 70
playing
messages 30
music 78
video and audio 77
video clips 80
voice recordings 74
predictive text input 14, 84
presentations
creating 32
viewing 32
printing 52
profiles 15
creating 15
customizing 15
net call profile 24, 89
PTT
See
push to talk
push messages 37
push to talk 72
contacts 73
creating a channel 73
exiting 73
logging in 72
making a call 72
settings 72
Q
Quickoffice 50
R
radio 82
adjusting volume 82
saving channels 82
tuning channels 82
RealPlayer 77
playing media clips 77
settings 78
recorder 73
playing voice memos 74
recording a memo 74
recording
calls 74
video clips 80
voice 73
remote configuration 90
remote lock 94
remote synchronization 91
restoring original settings 85
restricting
calls 26
net calls 26
restriction
password 26
rights 91
ringing tones 43
ringing type 84
selecting 84
vibrating alert 84
volume 84
routes
planning 70
S
satellite signal strength 71
saving
current position 71
files 12
settings 12
screen saver 83
scroll key 11
Search 48
searching
available WLANs 56
contacts 42
locations 70
security
Bluetooth 59
memory card 94
settings 85
115
Index
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 115 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 115 Jan 8, 2007 1:39:30 PM
security module 94
sending
contacts 42
files 12, 48
images 82
using Bluetooth 57
videos 23
service commands 35
service messages 37
session initiation protocol
See
SIP
settings 83
applications 89
call forward 25
calls 85, 86
cell broadcast 40
clock 47
connection 86
data call 88
date 84
device security 85
display 83
e-mail retrieval 40
e-mail user 39
EAP plug-ins 88
enhancements 85
frequency 79
general 83
GPRS 61, 87
IM 36
internet 60
language 84
Log 28
Maps 69
multimedia messages 38
net call 89
network 86
packet data 87
personalization 83
profiles 15
push to talk 72
RealPlayer 78
restoring 85
SIP 89
standby mode 84
telephone 85
text messages 38
time 84
tones 84
voice commands 76
voice recorder 74
Web 67
WLAN 87
WLAN access point 65
WLAN security 88
Settings wizard 18
sharing videos 23
shortcuts 96
applications 84
keys 84
SIM access profile 59
SIP
creating profiles 86, 89
settings 89
SMS
See
text messages
software packages
removing 90
special messages 35
Speech 74
standby modes 12
active standby 12
basic standby mode 13
settings 84
Sync 91
synchronization 91
synchronization profiles 91
T
tabs 12
taking a picture 79
telephone
See
calls
telephone settings 85
text
letter mode 13
number mode 13
predictive input 14
traditional input 13
writing 13
text messages
sending 30
settings 38
writing 30
text size
changing 83
themes 15
time
changing 84
settings 84
to-do entries 45
tones
alert tones 84
keypad tones 84
116
Index
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 116 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 116 Jan 8, 2007 1:39:30 PM
settings 84
warning tones 84
touch tones 26
track lists 78
traditional text input 13
Transfer 19
transferring data
between devices 19
using Bluetooth 19
using infrared 19
trip destination 71
trip meter 71
tutorial 17
U
USB data cable 55
V
vibrating alert 84
video calls 22
making a call 22
switching to voice call 22
video clips 77, 80
playing 77, 80
video sharing 23
receiving invitations 23
Voice aid 74
voice commands 75
launching an application 75
setting on a profile 76
settings 76
voice dialing 75
voice mail 27
calling 27
changing number 27
voice memos 74
voice over IP
See
net calls
voice recorder
settings 74
volume 15
radio 82
VPN
access points 89
W
wallpaper 82
WAP
push messages 37
warning tones 84
Web 66
settings 67
Welcome 10
welcome note 83
Wi-Fi
See
WLAN
Wireless keyboard
connecting 53
disconnecting 53
wireless LAN
See
WLAN
WLAN 63
access point settings 65
access points 64
availability 63
EAP 88
MAC address 87
searching for networks 56
security settings 88
settings 87
WLAN wizard 64
world clock 47
writing language 14
Z
Zip manager 52
117
Index
file:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 117 Jan 8, 2007 1:39:30 PMfile:///C:/USERS/MODEServer/lkatajis/11051417/ra-6_maxi/en/issue_1/ra-6_maxi_en_1.xml Page 117 Jan 8, 2007 1:39:30 PM
