Users Manual Revised

User Guide for

Nokia 2220/2260 Phone

What information is

needed? Numbers Where is the number?

My number Wireless service provider

Voice mail number Wireless service provider

Wireless provider’s number Wireless service provider

Provider’s customer care Wireless service provider

Model number 2220

2260

Label on back of phone

(under battery).

Phone type RH-40 (for 2220)

RH-39 (for 2260)

Back of title page.

Electronic serial number

(ESN)

Label on back of phone

(under battery). See “Find

your phone’s label” on

page 14.

2220_2260.ENv1_9356390_.book Page i Wednesday, May 28, 2003 4:10 PM

The wireless phone described in this guide is approved for use in the TDMA and AMPS networks.

LEGAL INFORMATION

Part No. 9356390, Issue No. 1a

Nokia, Nokia Connecting People, the Nokia Original Accessories logos, Nokia 2220, Nokia 2260,

Xpress-on, Pairs II, Space Impact and Snake II are trademarks or registered trademarks of Nokia.

All other product and company names mentioned herein may be trademarks or tradenames of

their respective owners

Printed in Canada 05/2003, electronic file created 05/28/2003

US Patent No 5818437 and other pending patents.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

The information contained in this user guide was written for the Nokia RH-39 phone and the

Nokia RH-40 phone. Nokia operates a policy of continuous development. Nokia reserves the

right to make changes and improvements to any of the products described in this document

without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR

INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES

HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY

APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,

BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR

CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR

WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

EXPORT CONTROLS

This product contains commodities, technology or software exported from the United States in

accordance with the Export Administration regulations. Diversion contrary to U.S. or Canadian

law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your phone may cause TV or radio interference (for example, when using a telephone in close

proximity to receiving equipment). The FCC or Industry Canada can require you to stop using

your telephone if such interference cannot be eliminated. If you require assistance, contact

your local service facility. This device complies with part 15 of the FCC rules. Operation is

subject to the condition that this device does not cause harmful interference.

2220_2260.ENv1_9356390_.book Page ii Wednesday, May 28, 2003 4:10 PM

Contents

1 For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2 Welcome and quick guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Get the most out of this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Get started with the quick guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Understand wireless network services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Register your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

E-newsletters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

The antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

The battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Set up your headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Get help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3 Basic operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Switch your phone on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Make and answer calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Check the start screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Check in-phone help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Browse phone menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Contact list menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4 Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Standard text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Spaces, punctuation, and special characters entry . . . . . . . . . . . . . . . . . . . . . . . . 27

Predictive text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

5 Contact list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Use contact list menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Save names, numbers, and e-mail addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Recall names and numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Edit a name or number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Delete names and numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

2220_2260.ENv1_9356390_.book Page iii Wednesday, May 28, 2003 4:10 PM

Customize your contacts view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Check memory status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

6 Call log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Call log options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Check missed calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Check received calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Check dialed calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Use call timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

7 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Voice mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Text, e-mail, and picture messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Picture messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

E-mail messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

8 Personalization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

9 Advanced calling features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Understand active-call options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Use voice privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

Use call forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Use call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Use send own caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

Select a phone number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

Use automatic redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

Use 1-touch dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

Set touch tone strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

Link contact list entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

Select a system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

10 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Use Keyguard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

2220_2260.ENv1_9356390_.book Page iv Wednesday, May 28, 2003 4:10 PM

Understand the security code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Restrict calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

11 Special features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Use the alarm clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Use the calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Business cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Download a ringing tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

12 Prepaid services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Manage prepaid service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Check your prepaid balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Add money to your account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Call customer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Save your access numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Expiration date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

13 Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Start a new game . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Snake II . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Space impact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Pairs II . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

14 Minute Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Check your call information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Check your account information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Customer care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

15 Reference information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Battery statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Proper care and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Important safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Make emergency calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Accessory safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

2220_2260.ENv1_9356390_.book Page v Wednesday, May 28, 2003 4:10 PM

Technical information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

Nokia One-Year Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Appendix A

Message from the CTIA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Appendix B

Message from the FDA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

2220_2260.ENv1_9356390_.book Page vi Wednesday, May 28, 2003 4:10 PM

1For your safety

Read these simple guidelines. Breaking the rules may be dangerous or illegal.

Further detailed information is given in this manual..

Do not switch on the phone when wireless phone use is prohibited or

when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Don’t use a hand-held phone while driving.

INTERFERENCE

All wireless phones may get interference, which could affect

performance.

SWITCH OFF IN HOSPITALS

Follow any regulations or rules. Switch the phone off near medical

equipment.

SWITCH OFF IN AIRCRAFT

Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Don’t use the phone at a refueling point. Don’t use near fuel or

chemicals.

SWITCH OFF NEAR BLASTING

Don’t use the phone where blasting is in progress. Observe restrictions,

and follow any regulations or rules.

USE SENSIBLY

Use only in the normal position. Don’t touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair phone equipment.

2220_2260.ENv1_9356390_.book Page 1 Wednesday, May 28, 2003 4:10 PM

For your safety

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect

incompatible products.

WATER-RESISTANCE

Your wireless phone is not water-resistant. Keep it dry.

CALLING

Ensure the phone is switched on and in service. Enter the phone number,

including the area code, then press the Talk key. To end a call, press the

End key. To answer a call, press the Talk key.

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press the End key as

many times as needed (for example, to exit a call, to exit a menu) to

clear the display. Enter the emergency number, then press the Talk key.

Give your location. Do not end the call until told to do so.

2220_2260.ENv1_9356390_.book Page 2 Wednesday, May 28, 2003 4:10 PM

NOTES

2220_2260.ENv1_9356390_.book Page 3 Wednesday, May 28, 2003 4:10 PM

For your safety

Nokia 2220/2260 phone at a glance

Talk key

Display screen

Scroll up key

Left

selection key

Star key

End key

Microphone

Earpiece

Right

selection key

Power key

Connection port

Pound key

Number keys

Scroll down

key

2220_2260.ENv1_9356390_.book Page 4 Wednesday, May 28, 2003 4:10 PM

2 Welcome and quick guide

Congratulations on your purchase of a Nokia mobile phone, a new tool for the

mobile information society.

• GET THE MOST OUT OF THIS GUIDE

The diagram to the left illustrates the various components of your phone.

Familiarize yourself with the diagram to help you better understand the

instructions that follow.

Understand the terms

This guide uses certain terms for the steps that you are asked to perform.

•Press means to briefly press, then release a key. For example, press 7 means

press the key on the keypad that is labeled with the number 7 and the letters,

“p,q,r,s.”

•Press and hold means to press and hold a key for two to three seconds

(depending on the feature being used), then release the key.

• Highlighted options on the

screen are enclosed within a

dark bar. The selection keys are

used to act on the highlighted

option.

•Selection keys are used to

select a menu option, press the

selection key below the menu

item on the phone’s screen. In

the example to the right, to

select Menu, you would press

the left selection key. To access

the contact list, press Contacts

(the right selection key).

•Scroll keys are used to move up

and down in the menus. For

example, if instructed to scroll to another contact list entry, this means to

press Scroll up or Scroll down key.

•The Talk key is used to place a call or to answer an incoming call.

•The End key is used to end a call or press and hold to return to the idle screen.

Left

Selection

Right

Selection

Scroll down

End

Talk

Scroll up

2220_2260.ENv1_9356390_.book Page 5 Wednesday, May 28, 2003 4:10 PM

Welcome and quick guide

Notice text clues

This user guide provides text clues to make instructions clear and easy to follow.

Follow graphic clues

This guide uses icons (graphic clues) to alert you to important information.

Tip: Information about a shortcut or an alternate method of doing

something.

Note: Explanation about a feature or an important concept.

Important: Critical information about a feature.

Caution: Help to avoid information loss.

Warning: Help to avoid personal injury, damage to the phone, or property

damage.

Look for updates

From time to time, Nokia updates this user guide to reflect changes or corrections.

The latest version may be available at www.nokia.com/us.

Also, an interactive tutorial may be available at www.nokiahowto.com.

Clue What it means

bold

Indicates one of the following items:

• The word or phrase appears on the phone’s screen.

• Special text, such as Notes and Warnings.

• The name of one of the phone keys.

bold and blue Indicates the text is an address on the World Wide Web.

italic Italics indicate emphasis. Pay close attention to any information

in italics.

2220_2260.ENv1_9356390_.book Page 6 Wednesday, May 28, 2003 4:10 PM

• GET STARTED WITH THE QUICK GUIDE

Make a call Enter phone number, press the Talk key.

Answer a call Press the Talk key or Answer.

Answer with call waiting Press the Talk key.

End a call Press the End key.

Silence a call Press the End key.

Redial Press the Talk key twice.

Adjust call volume During a call, press the Scroll up key to increase the

volume or the Scroll down key to decrease the volume.

Use the in-call menu In a call, press Options.

Use 1-touch dialing Press and hold one of keys 2-9.

Save a name and number Enter a number, press Save, enter a name, and press OK.

Retrieve a name/number Press Contacts, select Find.

Retrieve a name/number

during a call

Press Options, scroll New call, press Select, press Find,

enter first letter of the name.

Check voice mail Press and hold 1 or call your voice mailbox number.

Send a text message Press Menu 1-1. Write the message. Press Options (Send

will be the first option), press Select, enter the recipient’s

number, then press Send.

Send a business card Retrieve a name from the contact list, press Options,

select Send bus. card, enter the recipient’s number, then

press Send.

2220_2260.ENv1_9356390_.book Page 7 Wednesday, May 28, 2003 4:10 PM

Welcome and quick guide

Send an e-mail message Press Menu 1-2. Enter the recipient’s address, press OK,

enter the subject, press OK, write the message, press

Options, scroll to Send, then press Select. (You may need

to enter the gateway number your service provider gave

you.)

Read new message Press Read. If you have more than one message, scroll to

the one you want, then press Read again.

Reply to a message Press Options, scroll to Reply, then press Select.

Reply to an E-mail

message

When reading the message, press Options, scroll to Reply,

then press Select.

2220_2260.ENv1_9356390_.book Page 8 Wednesday, May 28, 2003 4:10 PM

• UNDERSTAND WIRELESS NETWORK SERVICES

The wireless phone described in this guide is approved for use on the TDMA and

AMPS networks. A number of features included in this guide are called Network

Services. These are special services you arrange through your wireless service

provider. Before you can take advantage of any of these Network Services, you

must subscribe to them through your service provider and obtain instructions for

their use from your service provider.

Note: Some networks may not support all language-dependent characters

and/or services.

Network services for your Nokia phone include:

• Voice mail and voice privacy

• Call waiting, call forwarding, and caller ID

• Text, e-mail, and picture messages

• Ability to send your own number

Before you can use any network services, you must sign up with a wireless service

provider. Your service provider will supply descriptions of special features and

instructions for using their services.

• REGISTER YOUR PHONE

Make sure to register your phone at www.warranty.nokiausa.com or 1-888-NOKIA-2U

(1-888-665-4228) so that we can better serve you, if you should need to call the

center or have your phone repaired.

• E-NEWSLETTERS

When you register your phone, you can sign up for Nokia's e-newsletter Nokia

Connections if you would like. You will receive tips and tricks on using your phone,

accessory information, and special offers.

2220_2260.ENv1_9356390_.book Page 9 Wednesday, May 28, 2003 4:10 PM

Welcome and quick guide

• THE ANTENNA

Tip: Your phone has a built-in antenna. As with

any other radio transmitting device, do not

touch the antenna unnecessarily when the

phone is switched on.

Contact with the antenna affects call quality and may

cause the phone to operate at a higher power level than

otherwise needed.

Not touching the antenna area during a phone call optimizes

the antenna performance and the talk-time of your phone.

Normal position: Hold the phone as you would any other

telephone with the antenna pointed up and over your shoulder.

• THE BATTERY

This section tells you how to install and remove the battery. You will need to remove

the battery when replacing it, or to view the phone’s label (located under the

battery). For important safety information on using batteries and chargers, see

“Accessory safety” on page 88.

Install the battery

1Place the battery in the

compartment with the label side

facing up and the golden

contact area of the battery

aligned with the contact prongs

inside the phone.

2Press down on the battery until

it snaps into place.

2220_2260.ENv1_9356390_.book Page 10 Wednesday, May 28, 2003 4:10 PM

3Align the cover over the back of

the phone, placing the end of the

cover approximately 1/4 inch past

the end of the phone. Lower the

back cover onto the phone.

4Press down slightly and slide the

cover until it locks into place.

Remove the battery

If you purchase a new battery or need to access information on the phone’s label,

you may need to remove the battery. Make sure the phone has been turned off for

at least 10 seconds.

Important: Dispose of batteries according to applicable local regulations

(for example, recycling). Do not dispose as household waste.

1Hold the phone with the back

facing you. At the bottom

corners of the phone, press the

battery cover with your thumb

and forefinger.

2Place the thumb of your other

hand in the groove, approximately

1 inch from the top of the phone.

Apply pressure with the thumb,

slide the back cover toward you

to release it, then remove it.

1/4 inch

2220_2260.ENv1_9356390_.book Page 11 Wednesday, May 28, 2003 4:10 PM

Welcome and quick guide

3Look for the battery latch

that runs along the end

of the battery nearest

the top of the phone.

4Place your thumbs on

the corners of the latch

and press away from

the battery.

5Once the battery is

released from the latch,

it will lift slightly so that it can be removed from the phone.

Warning: Use only your hands to remove the battery. Do not use any

objects that may damage the phone or the battery.

Charge the battery

Before you begin using your phone, you need to

prepare your phone by charging the battery.

1Plug the charger into a standard wall

outlet, then connect the lead from the

charger to the bottom of the phone.

2The battery power indicator (or battery

bar) appears on the screen and starts

scrolling. Charging appears if the phone is on.

3When the battery bar stops scrolling, the battery charge is complete.

Battery full appears if the phone is on.

4Disconnect the charger from the phone.

IMPORTANT BATTERY INFORMATION

Use the following guidelines to obtain the best performance from your battery:

• With your phone turned off, charge your new battery for three hours before

its first use. Use the battery until it is fully discharged. Repeat this procedure

twice for a total of three charging cycles.

• Battery operation time may be less than the estimated times during the first

charges. This condition is normal.

• If the battery is fully discharged, the scrolling bars may not appear

immediately when charging.

• After the first charge, you can make and receive calls during the charging

cycle, but the calls interrupt the charge. When the phone call ends, the charge

will resume.

2220_2260.ENv1_9356390_.book Page 12 Wednesday, May 28, 2003 4:10 PM

• The bars on the screen stop scrolling and remain constant when the phone is

charged. If you leave the phone connected to the charger, the battery receives

an additional charge.

Note: The battery will accept a “trickle charge” for an additional two hours.

See “Reference information” on page 81 for more information on batteries.

• Charging time depends on the charger and battery used. See “Batteries” on

page 89 for charging, talk, and standby times.

PROLONG BATTERY LIFE

For good operation times with NiMH batteries, discharge the battery from time

to time by leaving your phone switched on until it turns itself off. Ignore any

messages to recharge your battery and let the battery completely discharge.

Important: Do not attempt to discharge the battery by any other means.

• SET UP YOUR HEADSET

Your phone is compatible with the HDC-5, HDC-10, HDE-2, and

HDB-5 headsets. The headset provides convenient, hands-free use

of the phone.

Connect the headset

1Plug the headset plug into the bottom of your phone.

2Put the round ear plug into one ear.

Use the headset

With the headset connected, you can make

and answer calls as usual.

The microphone for the headset hangs at the

side of your head. Although the microphone

may seem far from your mouth, you can speak

at a normal volume.

Note: You can set your phone to answer automatically when the headset

is connected. See “Automatic answer” on page 51 for more information.

2220_2260.ENv1_9356390_.book Page 13 Wednesday, May 28, 2003 4:10 PM

Welcome and quick guide

•GET HELP

Find your phone’s label

When you call the Nokia Customer Care Center or your service provider, you will

need to provide specific information about your phone. This information is recorded

on the phone’s type label. The type label is located under the battery inside the

phone’s back cover. It contains the model and serial numbers as well as other

important information about your phone. Please do not remove or deface the label.

Contact Nokia

If you have a question and have already checked the Troubleshooting section

(see page 99), we recommend that you have the following information available

before contacting the Nokia Customer Care Center or your service provider:

• Your phone’s model number

• Nokia 2220 phone (single band)

• Nokia 2260 phone (dual band)

•ESN (Electronic serial number – located on the label under the battery)

• Your billing address ZIP code

• The phone or accessory in question

Contact your service provider

You may want to save your service provider’s customer support telephone number

into your phone. This will let you easily contact your provider if you have questions

or issues with your phone service.

Nokia Customer Care Center, USA Customer Care Centre, Canada

Nokia Mobile Phones

7725 Woodland Center Blvd. Suite #150

Tampa, Florida 33614

Tel: 1-888-NOKIA-2U

(1-888-665-4228)

Fax: 1-813-249-9619

For TTY/TDD users: 1-800-24-NOKIA

(1-800-246-6542)

Nokia Products Ltd.

601 Westney Road South

Ajax, Ontario L1S 4N7

Tel: 1-888-22-NOKIA

(1-888-226-6542)

Fax: 1-905-427-1070

Web site: www.nokia.ca

2220_2260.ENv1_9356390_.book Page 14 Wednesday, May 28, 2003 4:10 PM

Receive accessibility information

Nokia is committed to making mobile phones easy to use for all individuals, including

those with disabilities. Nokia maintains an internet site that is dedicated to

accessibility solutions. For more information about phone features, accessories and

other Nokia products designed with your needs in mind, visit the web site at:

www.nokiaaccessibility.com

LPS-3 MOBILE INDUCTIVE LOOPSET

The LPS-3 Loopset is a Nokia accessory designed to make the phone more accessible

to hearing-aid users. The loopset gives hearing-aid users clear access to digital

telephony for the first time. It allows people with T-coil equipped hearing aids to

make and receive calls without noise interference.

To activate the Loopset, see “Accessory settings” on page 50.

Note: The loopset is sold separately as an accessory to the phone.

HOW THE LOOPSET WORKS

The LPS-3 Loopset uses inductive technology

to transmit sound to a hearing aid equipped

with a T-coil. The sound from the phone is

amplified more efficiently and background

noise is eliminated.

The loopset is easy to use. Wear the loopset

around your neck, connect it to your phone,

and speak directly toward the microphone.

For detailed instructions on using the loopset,

refer to the booklet that comes with the LPS-3.

Set up the TTY/TDD profile

You can connect your phone to a TTY/TDD using the

Nokia TTY/TDD Adapter (HDA-9). In order for your

phone to recognize the TTY/TDD, you will need to

connect the adapter to your phone.

Important: Some manufacturers of TTY/TDD devices suggest that the phone

be least 18 inches from the TTY/TDD device. When connecting to any other

device, read its user guide or contact its manufacturer for detailed

instructions and safety information.

1Connect the TTY/TDD with a cable to the HDA-9 adapter.

2220_2260.ENv1_9356390_.book Page 15 Wednesday, May 28, 2003 4:10 PM

Welcome and quick guide

2Plug the HDA-9 adapter into the connector on the bottom of your phone, as

shown in the illustration.

3Press Menu 4-4-4-1 (Settings > Accessory settings > TTY/TDD > Use TTY).

4Scroll to Yes, then press Select.

NOTES ABOUT TTY/TDD CALLS

• The Nokia TTY/TDD Adapter (HDA-9) is for use with compatible TTY/TDD

devices only. Check with the manufacturer of the TTY/TDD device to ensure

that the connection is compatible.

• Check with the manufacturer of the TTY/TDD device for the appropriate

connecting cable.

• TTY/TDD communications depend on network availability. Check with your

service provider for availability and description of services.

MAKE A TTY/TDD CALL

Tip: Before making a TTY/TDD call with your phone, check the signal

strength. See “Understand indicators and icons” on page 19 for details.

1From the start screen, enter the number, and press the Talk key.

2When the receiving party answers, begin typing your conversation on

the TTY/TDD.

RECEIVE A TTY/TDD CALL

1Make sure the TTY/TDD device is connected to your phone.

2Press the Talk key to answer the call, then type your responses on the TTY\TDD.

END A TTY/TDD CALL

Press the End key.

18”

2220_2260.ENv1_9356390_.book Page 16 Wednesday, May 28, 2003 4:10 PM

3 Basic operations

This section gives a brief introduction to the phone and shows quick steps for:

• Making and answering calls

• Adjusting the earpiece volume

• Navigating through menus

• Using menu shortcuts

You will also find information about the phone’s icons and how to use in-phone

help. The rest of this guide provides complete details on phone use.

• SWITCH YOUR PHONE ON OR OFF

Warning: Do not switch on the phone when

wireless phone use is prohibited or when it may

cause interference or danger.

To switch on your phone, press and hold the power key

for 2 seconds.

To switch off your phone.

• Press and hold the power key.

• Press the power key quickly. When Switch off! is

highlighted on the screen, press Select.

• MAKE AND ANSWER CALLS

There are several ways to make and answer calls on

your phone. Once learning about the basic methods,

you will discover other tips throughout this guide when

reading about the phone’s features.

Use the keypad

1Enter the phone number, including the area code

if needed.

2Press the Talk key.

Important: Do not touch the antenna when

the phone is switched on. Contact with the

antenna affects call quality and may cause the phone to operate at a

higher power level than otherwise needed.

Power

key

2220_2260.ENv1_9356390_.book Page 17 Wednesday, May 28, 2003 4:10 PM

Basic operations

Use the contact list

1From the start screen, press the Scroll up or Scroll down key and scroll to the

number you want.

2Press the Talk key to make the call.

Tip: To skip ahead quickly in the list, press the number key that has the first

letter of the name. You may have to press the key more than once to get

to the correct letter.

Make a 1-touch dial call

Press and hold the key assigned to the number you wish to call.

To learn how to store a number for use with 1-touch dialing see “Assign a key to

1-touch dialing” on page 61.

End a call

Press the End key to end the call or to cancel the call attempt.

Answer a call

When your phone rings, press the Talk key. You can press any key to answer a call

except the power key, end key, or the scroll keys.

Note: If Keyguard is active, the keypad will unlock when you have an

incoming call.

Silence an incoming call

Press the End key or Silent to mute the ringing of an incoming call.

Redial the last-dialed number

Press the Talk key twice.

Adjust the earpiece volume

Adjust the earpiece volume during a call by pressing

the scroll keys located just below the screen.

• Press the Scroll up key to increase the volume.

• Press the Scroll down key to decrease the

volume.

2220_2260.ENv1_9356390_.book Page 18 Wednesday, May 28, 2003 4:10 PM

• CHECK THE START SCREEN

When you switch on your phone, a welcome

appears, then you see the start screen.

The start screen appears when the phone is

idling or standing by.

Understand the Scroll Bar

When you press Menu, a vertical scroll

bar appears on the right side of the screen.

This scroll bar has a tab which moves up or

down to indicate your location in the

menu.

Understand indicators and icons

You have two types of identifiers on your phone:

Indicators show the status of something. The phone uses three types of indicators:

signal strength, battery power and handset volume.

Icons are graphical representations of a specific item or situation. For example, an

icon appears when you have a voice message in your mailbox.

Indicators

• Signal strength – shows the signal strength of the wireless network at your

current location. The higher the bar, the stronger the signal.

• Battery power – shows the battery charge level. The higher the bar, the more

power in the battery.

Start screen

Scroll

bar

Signal

strength

indicator

Battery

power

indicator

2220_2260.ENv1_9356390_.book Page 19 Wednesday, May 28, 2003 4:10 PM

Basic operations

Icons

• CHECK IN-PHONE HELP

Many menu items have brief help text. To view the help text, scroll to the

menu item and wait for about 15 seconds. Press More or the Scroll down

key to continue reading the text. Press Back to exit or wait a few seconds to

return to the current menu.

Screen

Icon What it means

Active call in progress.

Silent has been selected as the current profile.

The phone’s keypad is locked to prevent any accidental key presses.

One (or more) new voice messages waiting.

One or more new text messages waiting. (If blinking, the text

message memory is full.)

Digital service is available.

Standard text input mode for entering alpha characters. Press to

switch between uppercase and lowercase input.

Predictive text mode for quickly entering text messages. Press # to

switch between uppercase and lowercase input.

123 mode. This icon appears when you press and hold # while

entering text. You can now enter only numbers (not alpha

characters). Press and hold # again to return to text entry mode.

Special character mode. This appears when you press * while

entering text. Once the characters appear, you can select a special

character by selecting Insert.

Alarm clock is set.

2220_2260.ENv1_9356390_.book Page 20 Wednesday, May 28, 2003 4:10 PM

• BROWSE PHONE MENUS

A menu is a list of choices you can make to change settings on your phone or use

various phone features. Each menu can contain several levels of submenus. You can

use menus and submenus two ways: by scrolling or by using a shortcut. This guide

uses the shortcut method when describing how to use the phone’s features.

Scroll through menus

1At the start screen, press Menu, then scroll through the menus using the

Scroll up and Scroll down keys.

2Use the scroll and selection keys to navigate the submenus; press the End key

to return to the start screen.

For example, when you see (Profiles > Silent) the scrolling method is: press

Menu, scroll to Profiles and press Select, scroll to Silent and press Options.

Return to the previous menu level

You can return to the previous menu level by pressing the selection key labeled Exit

or Back. Return to the start screen from any menu level by pressing the End key.

Use shortcuts

Menus and options are numbered so that you can quickly find your way to an option.

The numbers appear in the top right corner of the screen and show your location in

the menu.

1Press Menu.

2Within 3 seconds, enter the first number of the menu function you want

to access.

3Repeat until you have entered all the numbers.

For example, to select the Silent profile, press Menu 3-2-1.

MENU TIPS

• You can scroll upward to quickly access the last option in a menu list.

• You can return to the previous menu level by pressing Back.

• To exit a menu and return to the start screen, press the End key. If you

leave a menu by pressing the End key, you cancel any changes you made.

• Some menus may not appear. Ask your service provider for details.

2220_2260.ENv1_9356390_.book Page 21 Wednesday, May 28, 2003 4:10 PM

Basic operations

Menu shortcuts

1 MESSAGES

1 Write message . . . . . . . . . . . .1-1

2 Write e-mail . . . . . . . . . . . . . 1-2

3 Inbox . . . . . . . . . . . . . . . . . . . .1-3

4 Outbox . . . . . . . . . . . . . . . . . . 1-4

5 Archive . . . . . . . . . . . . . . . . . .1-5

6 Delete all. . . . . . . . . . . . . . . . .1-6

7 Picture messages . . . . . . . . . .1-7

8 Voice messages. . . . . . . . . . . .1-8

1 Listen to voice

messages . . . . . . . . . . . .1-8-1

2 Voice mailbox number . .1-8-2

2 CALL LOG

1 Missed calls . . . . . . . . . . . . . .2-1

2 Received calls . . . . . . . . . . . . .2-2

3 Dialed calls . . . . . . . . . . . . . . .2-3

4 Clear call lists . . . . . . . . . . . . . 2-4

1 All . . . . . . . . . . . . . . . . . . 2-4-1

2 Missed. . . . . . . . . . . . . . . 2-4-2

3 Received . . . . . . . . . . . . . 2-4-3

4 Dialed . . . . . . . . . . . . . . . 2-4-4

5 Call timers. . . . . . . . . . . . . . . .2-5

1 Duration of last call. . . . 2-5-1

2 Duration of all calls . . . . 2-5-2

3 Clear timers . . . . . . . . . . 2-5-3

3PROFILES

1 Normal. . . . . . . . . . . . . . . . . . .3-1

1 Select . . . . . . . . . . . . . . .3-1-1

2 Customize . . . . . . . . . . . .3-1-2

1 Ringing options . . .3-1-2-1

2 Ringing tone. . . . . .3-1-2-2

3 Ringing volume . . .3-1-2-3

4 Vibrating alert . . . .3-1-2-4

5 Message alert

tone. . . . . . . . . . . . .3-1-2-5

6 Keypad tones . . . . .3-1-2-6

7 Warning tones . . . .3-1-2-7

8 Profile name1

2 Silent . . . . . . . . . . . . . . . . . . . .3-2

1 Select . . . . . . . . . . . . . . .3-2-1

2 Customize . . . . . . . . . . . .3-2-2

3 Meeting . . . . . . . . . . . . . . . . . .3-3

1 Select . . . . . . . . . . . . . . .3-3-1

2 Customize . . . . . . . . . . . .3-3-2

4 Outdoor . . . . . . . . . . . . . . . . . .3-4

1 Select . . . . . . . . . . . . . . .3-4-1

2 Customize . . . . . . . . . . . .3-4-2

5 Pager . . . . . . . . . . . . . . . . . . . .3-5

1 Select . . . . . . . . . . . . . . .3-5-1

2 Customize . . . . . . . . . . . .3-5-2

1 The Profile name option is available

for Silent, Meeting, Outdoor and

Pager. The Normal profile cannot

be renamed.

2220_2260.ENv1_9356390_.book Page 22 Wednesday, May 28, 2003 4:10 PM

4 SETTINGS

1 Time settings . . . . . . . . . . . . . 4-1

1 Alarm clock . . . . . . . . . . 4-1-1

1 On . . . . . . . . . . . . . 4-1-1-1

2 Off . . . . . . . . . . . . . 4-1-1-2

2 Clock . . . . . . . . . . . . . . . 4-1-2

1 Show/Hide clock. . 4-1-2-1

2 Set the time . . . . . 4-1-2-2

3 Time format . . . . . 4-1-2-3

3 Auto-update of time. . . 4-1-3

2 Call settings . . . . . . . . . . . . . . 4-2

1 Automatic redial . . . . . . 4-2-1

2 Current call timer . . . . . 4-2-2

3 Phone settings . . . . . . . . . . . . 4-3

1 Language . . . . . . . . . . . . 4-3-1

2 Touch tones . . . . . . . . . . 4-3-2

1 Manual touch

tones . . . . . . . . . . . 4-3-2-1

2 Touch tone length 4-3-2-2

3 Welcome note . . . . . . . . 4-3-3

4 Restore factory

settings . . . . . . . . . . . . . 4-3-4

4Accessory settings

1. . . . . . . . 4-4

1 Headset . . . . . . . . . . . . . 4-4-1

2 Handsfree . . . . . . . . . . . 4-4-2

3 Loopset . . . . . . . . . . . . . 4-4-3

4 TTY/TDD . . . . . . . . . . . . . 4-4-4

5 Security settings . . . . . . . . . . 4-5

1 Call restrictions. . . . . . . 4-5-1

2 Change security code . . 4-5-2

1 The Accessory settings menu will not

appear until after an accessory has been

connected to the phone.

6 Network services . . . . . . . . . . 4-6

1 Voice privacy . . . . . . . . . 4-6-1

2 Call forwarding 2 . . . . . 4-6-2

3 Call waiting 2 . . . . . . . . 4-6-3

4 Send own caller ID 2. . . 4-6-4

5 Network feature

setting . . . . . . . . . . . . . . 4-6-5

6 Own number selection 4-6-6

2 Call forwarding, call waiting and send

own caller ID are network-dependent

features. In some networks, the codes

for these features must be activated

and these sub menus will not appear

until they are activated.

5SYSTEM

1 Automatic . . . . . . . . . . . . . . . 5-1

2 Manual . . . . . . . . . . . . . . . . . . 5-2

3 New search . . . . . . . . . . . . . . 5-3

6GAMES

1 Snake II. . . . . . . . . . . . . . . . . . 6-1

2 Space Impact . . . . . . . . . . . . . 6-2

3 Pairs II. . . . . . . . . . . . . . . . . . . 6-3

4 Settings . . . . . . . . . . . . . . . . . 6-4

7 CALCULATOR

2220_2260.ENv1_9356390_.book Page 23 Wednesday, May 28, 2003 4:10 PM

Basic operations

8 PREPAID 1

1 Check account balance . . . . . 8-1

2 Add money to account. . . . . .8-2

3 Call customer service. . . . . . . 8-3

4 Save access phone

numbers . . . . . . . . . . . . . . . . .8-4

1 Balance phone

number . . . . . . . . . . . . . . 8-4-1

2 Replenish phone

number . . . . . . . . . . . . . . 8-4-2

3 Customer service

phone number . . . . . . . .8-4-3

5 Expiration date . . . . . . . . . . . .8-5

1 The Prepaid menu is visible only when

prepaid service is available in your

network and/or activated on your

account. Please contact your service

provider for more information on

Prepaid services.

9 MINUTE MGR. 2

1 My calls. . . . . . . . . . . . . . . . . .9-1

2 My account . . . . . . . . . . . . . . .9-2

3 Customer care. . . . . . . . . . . . .9-3

2 The Minute Manager menu is visible

only when Minute Manager service is

activated on your account. Please

contact your service provider for more

information.

2220_2260.ENv1_9356390_.book Page 24 Wednesday, May 28, 2003 4:10 PM

• CONTACT LIST MENU

For access to the contact list and its menus:

1Switch back to the start screen.

2Press Contacts.

These options are available:

1Find

2Add new

3 Delete all

4Options

1 Contacts view

2Memory status

5 1-touch dialing

2220_2260.ENv1_9356390_.book Page 25 Wednesday, May 28, 2003 4:10 PM

Text entry

4Text entry

There are two ways to enter letters and

numbers into your phone:

• Standard text input - for making

entries in the contact list.

• Predictive text input - for writing

text messages, picture messages, and

e-mails. For more detail, see

“Predictive text” on page 29.

• STANDARD TEXT ENTRY

Standard text input is used when entering text into information prompts. You can

use this method for all text entry, but predictive text input is the faster method for

writing messages.

Enter letters (ABC mode)

When you add new names to the contact list, your

phone automatically switches to the ABC mode and

displays the icon.

1Find the key that has the letter you want

to enter.

2Press the key as many times as needed for the

letter to appear on the screen.

Enter numbers (123 mode)

To enter numbers:

1Press and hold # to switch to 123 mode. Press the appropriate number key to

enter a number.

While in ABC mode, press and hold the corresponding number key until the

number appears. If you make a mistake, press Clear to delete that character.

2To return to the ABC mode, press and hold # again for two seconds.

DELETE MISTAKES

If you make a mistake, press Clear as needed to delete one or more characters.

Press and hold Clear to delete the entire field of characters.

Current

entry

method

2220_2260.ENv1_9356390_.book Page 26 Wednesday, May 28, 2003 4:10 PM

CHANGE FROM CAPITAL (UPPERCASE) LETTERS

To switch between capital (uppercase) and lowercase letters, press #.

The icon in the upper left corner of the screen switches to ,

indicating that you can now enter lowercase letters. To switch back to uppercase

letters again, press #.

• SPACES, PUNCTUATION, AND SPECIAL

CHARACTERS ENTRY

Depending on the selected display language, the following characters may be

available when entering characters from the keypad:

Note: Some networks may not support all language-dependent characters

and/or services.

• To enter a space, press 0 once.

• To enter punctuation, press 1 repeatedly until the character you want appears.

Key Characters Key Characters

1. , ’ ? ! @ ~ / “ - 18T U V 8

2A B C 2 9W X Y Z 9

3D E F 3 0Enters an empty space or 0.

4G H I 4 *Special characters

5J K L 5 #Changes letter case; long press

toggles between text input mode

and number input mode.

6M N O 6 Scroll up

key

Moves cursor to the left of

character.

7P Q R S 7 Scroll down

key

Moves cursor to the right of

character.

2220_2260.ENv1_9356390_.book Page 27 Wednesday, May 28, 2003 4:10 PM

Text entry

Use special characters

While entering text, press * (or press and hold *, if

predictive text is on) to display special characters.

Press * again to cycle through all characters:

Use scroll keys to select the character you want, then press Insert.

Note: The order and availability of special characters may vary depending

on your service provider.

Use four-way scrolling

Navigate special characters,

using the 2, 4, 6, and 8 keys

much as you would a joystick.

Once a character is highlighted

press 5 to insert the character

into your message.

Use symbols in names and numbers

• To enter a symbol while adding a name to the contact list, press *.

• To add a special character for creating a number string in the number box,

press *. See “Set touch tone strings” on page 61.

.?!@

‘-_()

,:;&/~\%*

#+<=> “ £$ ¥

¤¡¿

Scroll up

Scroll rightScroll left

Scroll down

Insert

character

2220_2260.ENv1_9356390_.book Page 28 Wednesday, May 28, 2003 4:10 PM

• PREDICTIVE TEXT

Predictive text input allows you to write messages much faster than the standard

text method. With predictive text input, you only need to press each number key

once for each letter. Your phone uses a built-in dictionary to predict or guess what

you are writing. You can also add new words to the dictionary.

Turn on predictive text

1Press Menu, then press Select.

2Scroll to Write message, then press Select.

3Press Options, scroll to Predictive text, then press Select.

4Scroll to the language you want, then press Select.

T9 prediction on appears.

Enter predictive text

To write “Steve” with the English dictionary selected, press:

7 (for S) 8 (for t) 3 (for e) 8 (for v) 3 (for e)

Since the displayed word changes after each key stroke, disregard the word until you

have keyed in all the characters. If the finished word is not the one you wanted,

press * until your word appears. If it does not appear you will have an option to spell

your word using standard text input.

Note: Predictive text input may not be available for all languages.

Turn off predictive text

1While writing a text message, press Options.

2Scroll to Predictive text, then press Select.

3Scroll to Prediction off, then press Select.

T9 prediction off appears.

Save a word in the dictionary

If the word Options changes to Spell, the word you intended to write is not in the

dictionary. You can add the word to predictive text.

Press Spell, enter the word using standard text entry and press OK to save the

word. See “Standard text entry” on page 26 for more information.

The display shows the above words for each key pressed.

2220_2260.ENv1_9356390_.book Page 29 Wednesday, May 28, 2003 4:10 PM

Text entry

Enter numbers

1To add a number to the message, press and hold # until appears on

the screen.

2Enter the numbers you want, then press and hold # to return to the ABC mode.

Note: You can also enter numbers from the Options menu (Insert number),

or by a long press of the number key.

Enter punctuation and special characters

There are two ways to enter punctuation when using predictive text.

Press and hold * to access the special characters list. See “Use special characters”

on page 28 for more information.

You can also enter symbols from the Options menu:

1From the Messages screen, press Options.

2Scroll to Insert symbol and press Select.

3Scroll to the symbol you want and press Insert.

Change the case

Predictive text uses sentence case, but you can manually change between upper

and lower case by pressing #.

Tip: You can switch between uppercase and lowercase standard text input

and uppercase and lowercase predictive text input by repeatedly pressing #.

Write compound words

1Write the first part of the word and press the

Scroll down key to accept it.

2Write the last part of the compound word and

press 0 to enter the word and a space.

Clear the screen

To clear the text screen, press and hold Clear. You can also use the Options menu

by selecting the Clear text option.

Delete information

To delete information when using predictive text, press Clear. Press and hold the

clear key to delete text more quickly.

2220_2260.ENv1_9356390_.book Page 30 Wednesday, May 28, 2003 4:10 PM

5 Contact list

Your phone includes a contact list that can store

up to 200 entries (names and associated phone

numbers). In addition, the contact list can store

an e-mail address for a name.

• An entry in the contact list can consist of

a number only or a name and a number.

• You cannot enter the same name twice. If

you try to save a name that is already in

the contact list, the phone asks if you

want to replace the existing name.

• USE CONTACT LIST MENUS

The contact list has several menus from which you can choose. These menus appear

when you press Contacts. Use the scroll keys to move to the menu you want to use.

• SAVE NAMES, NUMBERS, AND E-MAIL ADDRESSES

For information on entering text, see “Standard text entry” on page 26.

Quickly save a name and number

This method is called quick save.

1Enter the phone number using the keypad, then press Save.

2Enter a name and press OK.

Menu Function

Find Allows you to search for a specific entry.

Add new Allows you to add a new contact to your contact list.

Delete all Allows you to delete names and numbers one by one or all

at once.

Options Takes you to a new menu list which includes the contact

list’s memory status and scrolling view.

1-touch dialing Allows you to assign up to eight keys for speed dialing.

Contact list

2220_2260.ENv1_9356390_.book Page 31 Wednesday, May 28, 2003 4:10 PM

Contact list

Save an entry using the contact list menu

1Press Contacts to enter the contact list.

2Scroll to Add new, then press Select.

3Enter a name, then press OK.

4Enter a number, then press OK.

Save an e-mail address

Once you have added a contact to your contact list, you can add an e-mail address

to that contact.

Note: E-mail addresses can only be added to existing contacts. For example,

you cannot enter an e-mail address until you have selected a name or number.

1Find the name to which you want to add an e-mail address.

2Press Details, then press Options.

3Scroll to E-mail address, then press Select.

4Enter the e-mail address, and press OK.

Important: If you have selected the Name+number contacts view, you will

not need to press Details.

• RECALL NAMES AND NUMBERS

1At the start screen, press Contacts.

2Select Find, then enter one or two letters of the name you want to recall.

3Press Find, then press the Talk key to dial the number.

You may have to scroll to the appropriate entry in a list if you have stored

names that are similar to each other.

Recall information with shortcuts

You may want to use some of these shortcuts or alternate methods for recalling

a number.

• Press Contacts, enter the first letter of the name, scroll to the name, and press

the Talk key to dial the number.

• At the start screen, press the scroll keys to enter your list of names, scroll to

the name you want to dial, and press the Talk key.

• Press the Talk key to access a list of your last ten dialed calls, scroll to the one

you want to dial, then press the Talk key again.

2220_2260.ENv1_9356390_.book Page 32 Wednesday, May 28, 2003 4:10 PM

• EDIT A NAME OR NUMBER

You can edit a name, a number, or both.

1Recall the name or number you want to edit.

2Press Details, then press Options.

3 Edit appears, then press Select.

4Edit the name or number and press OK.

Important: If you have selected the Name+number contacts view, you do

not need to press Details.

• DELETE NAMES AND NUMBERS

Erasing stored names and numbers removes them from your phone. Once you

delete an item, you can restore it only by re-entering it.

Individual entries

1Recall the contact list entry you want to delete.

2Press Details, then press Options.

3Scroll to Delete, and press Select.

The message Delete? appears.

4Press OK.

Important: If you have selected the Name+number contacts view, you do

not need to press Details.

Entire contents

1Press Names, scroll to Delete all, and press Select.

2Scroll to Delete all and press Select.

3When you see the message Are you sure?, press OK.

4Enter your security code and press OK.

Note: For information on your security code, see “Understand the security

code” on page 67.

2220_2260.ENv1_9356390_.book Page 33 Wednesday, May 28, 2003 4:10 PM

Contact list

• CUSTOMIZE YOUR CONTACTS VIEW

You can change how the information in your contact list looks on your screen.

There are three different ways to view your contact list. In all views, you can use

the scroll keys to move up and down through the list of names.

Select your scrolling view

To change the way you view names and numbers in your contact list.

1Press Contacts, scroll to Options, and press Select.

2At Contacts view, press Select.

3Scroll to the view you want and press Select.

Important: If you have selected the Name+number contacts view, you will

not need to press Details when working with contact list options.

• CHECK MEMORY STATUS

You can check how much contact list memory is free and how much has been used.

1Press Contacts and scroll to Options.

2Press Select, scroll to Memory status, and press Select.

Choice What it does

Name list Displays three names on the screen at a time.

Name+number Only one name and its corresponding number appears on the

screen at a time.

Name only Displays individual names only. You can view the corresponding

phone number by pressing Details and then scrolling up or down.

2220_2260.ENv1_9356390_.book Page 34 Wednesday, May 28, 2003 4:10 PM

6 Call log

Your phone provides a call log that registers

information about calls you make and receive.

The call log keeps track of the following:

• Missed calls

• Received calls

• Dialed calls

Note: This function only works in digital networks and only when caller ID

is enabled.

• CALL LOG OPTIONS

When you view the missed calls, received calls, or dialed calls list, and press

Options, the following choices may appear.

Note: Not all options will appear each time. Also, the order of options

may vary.

Choice What it does

Call time Shows the time when the call was connected. (You must first

set the phone’s clock)

Send message Allows you to write a short text message to the person who

called you or to whom you called.

Edit number Allows you to edit the displayed number and save it with a

name to your contact list.

Save Allows you to enter a name for the number and save both to

your contact list.

Delete Allows you to delete the number from the call list.

View number

Allows you to view the caller’s phone number. In order to see

this option, the caller’s name and number must be stored in

the contact list.

Call Dials the number from the call log.

2220_2260.ENv1_9356390_.book Page 35 Wednesday, May 28, 2003 4:10 PM

Call log

• CHECK MISSED CALLS

If you do not answer a call, the message Missed calls appears on your phone’s

screen, along with the number of calls missed. Your phone stores the last ten

numbers associated with calls you have missed.

Check missed calls

1Press Menu 2-1 (Call log > Missed calls).

The phone displays a list of the numbers of the calls you missed.

2Press the Scroll up or Scroll down key to scroll through the list.

3Press the Talk key if you want to dial the number.

• CHECK RECEIVED CALLS

Your phone stores the last ten numbers associated with calls that you have

answered. To check this list of numbers:

1Press Menu 2-2 (Call log > Received calls).

2Scroll through the list of received numbers and highlight your selection.

3Press the Talk key if you want to dial the number.

• CHECK DIALED CALLS

Your phone stores the last ten numbers associated with calls that you have dialed.

To check this list of numbers:

1Press Menu 2-3 (Call log > Dialed calls).

2Scroll through the list of dialed numbers and highlight your selection.

3Press the Talk key if you want to dial the number.

Clear call lists

Your phone uses call lists to track numbers for incoming, outgoing, and missed

calls. You can delete some or all of the numbers that appear in the call log.

Caution: You cannot undo this operation.

1Press Menu 2-4 (Call log > Clear call lists).

2Use the Scroll up or Scroll down key to scroll through the options list.

The list includes All, Missed, Received, and Dialed.

3Stop at the appropriate option and press Select.

The All option clears every number in every list, whereas the other options clear

only the numbers associated with that option. For example, the Dialed option

clears only the numbers associated with calls you previously dialed.

2220_2260.ENv1_9356390_.book Page 36 Wednesday, May 28, 2003 4:10 PM

• USE CALL TIMERS

Your phone tracks the amount of time you spend on each call. To obtain

information about time spent on phone calls:

1Press Menu 2-5 (Call log > Call timers).

2Scroll through the following options:

Note: The actual time invoiced for calls by your service provider may vary,

depending upon network features, rounding-off for billing, and so forth.

Caution: If you select the Clear timers option, the action cannot be

undone. If you use the call timers to log the amount of time spent on calls,

you may want to record the call timer information before you clear it.

Clear call timers

1Press Menu 2-5-3 (Call log > Call timers > Clear timers).

2Enter your security code and press OK.

Note: For information on your security code, see “Understand the security

code” on page 67.

Turn on a current call timer

You can set your phone to show the running elapsed time while a call is active.

1Press Menu 4-2-2 (Settings > Call settings > Current call timer).

2Scroll to On and press Select.

From this point on, the timer is active during each call you make or receive.

The time appears on the phone’s screen.

3After a call has ended, press any key on the phone’s keypad to clear the current

call time from the screen.

Option What it does

Duration of last call Shows the call duration of the last call.

Duration of all calls Shows the call duration of all calls that have been

made and received since you reset the timers.

Clear timers

Clears all call timers for the currently selected phone

number. Your phone includes separate timers for each

number used.

2220_2260.ENv1_9356390_.book Page 37 Wednesday, May 28, 2003 4:10 PM

Messages

7 Messages

Use mobile messages to keep in touch with friends,

family and business associates. Your phone allows

you to do the following:

• Voice mail

• Send and receive text messages

• Send and receive picture messages

• Communicate with e-mail

Not all messaging features are available in all wireless networks. Contact your

service provider for availability and subscription information.

• VOICE MAIL

Voice mail provides a way for callers who miss you to leave a message that you can

retrieve later.

Check for messages

Your phone beeps when you receive a voice message. Also, the message New voice

message appears on your phone’s screen, along with the icon.

If you receive more than one voice mail message, your phone may show the number

of messages that you have received. The wireless network provider determines the

type of indication you will receive.

Note: To use voice mail, you need to learn the voice mail system’s

various greetings, passwords, and prompts. Your service provider can

provide instructions.

Save the voice mailbox number

As part of your network’s voice mail feature, your service provider gives you a voice

mailbox phone number.

1Press Menu 1-8-2 (Messages > Voice messages > Voice mailbox number).

2Enter your voice mailbox phone number, then press OK.

Your voice mailbox number can be up to 32 digits long and is used until you change

it. Therefore, if your phone number changes, the voice mail number will probably

change also. For further information, contact your service provider.

2220_2260.ENv1_9356390_.book Page 38 Wednesday, May 28, 2003 4:10 PM

Listen to your voice messages

The way you listen to your voice messages depends on your service provider. Call your

service provider if you have any questions.

1When your phone alerts you to new voice messages, press Listen and follow

the instructions given on the phone.

2If you want to listen to your messages later, press Exit.

3To listen to your voice messages:

Press and hold 1.

Press Menu 1-8-1 (Messages > Voice messages > Listen to voice messages).

Follow the prompts to review your messages.

• TEXT, E-MAIL, AND PICTURE MESSAGES

Your phone is capable of a variety of messaging services including text messages

(SMS or Short Message Service), picture messages, and e-mail messages. Messaging

services are Network Services. Consult your service provider for information on

availability, subscribing to and using messaging services.

Understand messaging

Message recipients: The phone to which you send a message must support messages.

The recipient may not receive the SMS message you send if the recipient’s account

is with a different service provider or uses a different protocol.

Message length: The maximum length of a sent or received message is 160 characters.

Your phone has space for several messages, depending on the length of each message.

The maximum length of a message also may depend on the capabilities of the network

from which the message originated.

Options when working with messages

There are several options available when working with text, picture, and e-mail

messages. The order and availability of options may vary depending on the

messaging function and your service provider.

2220_2260.ENv1_9356390_.book Page 39 Wednesday, May 28, 2003 4:10 PM

Messages

Tip: When writing messages, you can switch between uppercase and

lowercase standard text input and uppercase and lowercase predictive

text input by repeatedly pressing #.

Option Description

Send Attempts to send the text message to the recipient.

Settings Allows you to set Urgent, Read receipt, Reply req., and

Callback no. options for the message.

Save Saves the message in the archive folder.

Clear text Clears the text in the message editor.

Exit editor Takes you back to the Write message menu.

Predictive text Allows you to turn predictive text on and off.

Insert word If predictive text (T9) is activated, you can manually spell

a word and insert it into your message.

Insert number Allows you to insert numbers into the message.

Insert symbol Allows you to access the list of special characters.

Save picture Allows you to save a picture to the template folder.

Matches Lists alternative word choices while using predictive text.

Details Available when viewing a picture message. This option

allows you to view the name and number of the sender.

Preview Previews your picture message before sending.

Edit text Allows you to add text to a picture message.

Delete Allows you to delete a message.

Forward Allows you to forward a message.

Use number Allows you to use the number associated with a message.

Replay Allows you to replay messages you receive.

Edit recipient Allows you to edit the e-mail address.

Edit subject Allows you to edit the subject of an e-mail message.

2220_2260.ENv1_9356390_.book Page 40 Wednesday, May 28, 2003 4:10 PM

Organize messages using folders

Your phone has folders for managing text messages. Text message folders are

located under the Messages menu.

THE INBOX FOLDER

The inbox stores messages you receive. Messages remain in the inbox until you

delete them or save them in the archive folder. You can forward or reply to

messages in your inbox.

THE OUTBOX FOLDER

The outbox stores messages you have written, sent, edited, and forwarded. Messages

in the outbox are not saved messages. As you send new messages, old messages will

automatically be removed from the outbox. When message memory is full, one or

more messages of the lowest priority are automatically deleted from the outbox. If

you want to save a message you have sent, read the message while it is in the outbox

and use the options menu to save it to the archive folder.

THE ARCHIVE FOLDER

The archive folder stores messages you have saved. You can save messages to the

archive folder from the inbox and the outbox. You can reply to or forward saved

messages.

DELETE MESSAGES FROM FOLDERS

You can delete all messages located within a specific folder.

1Press Menu 1-6 (Messages > Delete all).

2Scroll to one of the following options, then press Select.

All read

Inbox

Archive

Outbox

3Enter your security code, then press OK.

Note: For information on your security code, see “Understand the security

code” on page 67.

2220_2260.ENv1_9356390_.book Page 41 Wednesday, May 28, 2003 4:10 PM

Messages

• TEXT MESSAGES

Use your phone to send and receive short text messages.

Write and send a text message

When writing text messages, use the predictive text method for faster text entry.

For details, see “Predictive text” on page 29.

1Press Menu, select Messages, then select Write message.

The message screen appears.

2Enter a message of up to 160 characters.

A counter in the upper right corner of the screen shows the number of

characters remaining.

3When you have finished writing the message, press Options, scroll to Send,

then press Select.

4Enter or recall the recipient’s phone number, then press Send.

Sending message appears.

Note: When sending messages via the SMS network service, your phone may

display the words, Message Sent. This is an indication that the message has

been sent by your phone to the message center number programmed into

your phone. This is not an indication that the message has been received

at the intended destination. For more details about SMS services, check

with your service provider.

Read a text message

When you receive a text message, the phone beeps and displays Message received

and the indicator in the upper left corner of the screen.

1Press Read to view the message.

2Use the scroll keys to view the whole message, if necessary.

3Once you’ve finished, press the End key to return to the start screen, or press

Options for other choices, such as Reply or Forward.

When the phone displays Message received, pressing Exit moves the new message

to the inbox and returns you to the start screen. To read the message later, press

Menu 1-3 (Messages > Inbox). If you have more than one new message, scroll to

the message you want to view. Messages in the inbox are listed in the order they

are received, with the most recent message listed first. Unread messages are

indicated by .

2220_2260.ENv1_9356390_.book Page 42 Wednesday, May 28, 2003 4:10 PM

Respond to a text message

There are many options available for working with text messages. For a list of

options and their descriptions, see “Options when working with messages” on

page 39.

REPLY TO THE MESSAGE

1When reading the message, press Options.

2Scroll to Reply, then press Select.

3Choose to reply As message or As e-mail, then press Select.

When replying as e-mail, see “Send an e-mail message” on page 45. When

replying as message, see “Write and send a text message” on page 42.

FORWARD THE MESSAGE

1When reading the message, press Options.

2Scroll to Forward, then press Select.

3Choose to forward As message or As e-mail, then press Select.

When forwarding as e-mail, see “Send an e-mail message” on page 45. When

forwarding as message, see “Write and send a text message” on page 42.

SAVE A MESSAGE

1When reading the message, press Options.

2Scroll to Save, then press Select.

The message will be moved to the archive folder.

DELETE A MESSAGE

1When reading the message, press Options.

2Scroll to Delete, then press Select.

Delete message? appears.

3Press OK.

WHEN MEMORY IS FULL

When message memory is full, one or more messages of the lowest priority are

automatically deleted. When you receive an emergency message, messages may be

deleted from any of your message folders.

If you have more messages waiting at the network, blinks on the start screen.

You can delete old messages to create space for new messages.

2220_2260.ENv1_9356390_.book Page 43 Wednesday, May 28, 2003 4:10 PM

Messages

• PICTURE MESSAGES

Your phone offers five picture messages that you can use to send pictures and text

to your friends and family. You can also save a new picture by replacing an existing

picture. For possible message options, see “Options when working with messages”

on page 39.

Each picture message is made up of several text messages. Therefore, sending one

picture message may cost more than sending one text message. Contact your

service provider for pricing information.

Note: This function can be used only if it is supported by your network

operator or service provider. Only phones that offer picture message

features can receive and display picture messages.

Send a picture message

1Press Menu 1-7 (Messages > Picture Messages).

2Scroll to the picture you want to send, then press Show.

The picture appears. To choose a different picture, press Back and scroll to

another picture.

3Press Options.

Edit text appears.

4Press Select, then add a text message to send with the picture.

After you enter the text, you have several options. To view a list of possible

options, see “Options when working with messages” on page 39.

5To send the picture and message, press Options.

6Scroll to Send, then press Select.

7Enter or recall the recipient’s phone number, then press Send.

Sending message appears.

PREVIEW A PICTURE MESSAGE BEFORE SENDING

After writing text for your picture message, you can preview the message before

sending it.

1Press Options.

2Scroll to Preview, then press Select.

3After viewing the message, press Back.

2220_2260.ENv1_9356390_.book Page 44 Wednesday, May 28, 2003 4:10 PM

Receive a picture message

1When your phone displays Picture message received, press Show and the

message appears.

2If the picture has a text message with it, scroll up or down to see the

entire message.

Save a picture message

1Press Show to view the message, then press Save.

You have the option to replace a current message.

2Scroll to the picture you want to delete, then press Replace.

• E-MAIL MESSAGES

You can send e-mail up to 160 characters in length to anyone with an e-mail

address. This is a Network Service.

• Messages sent to you by e-mail arrive as regular text messages. You can use

all the options described earlier to save, reply to, or forward a message.

• Contact your service provider to get the e-mail address and gateway number

for your phone, and for more information on using e-mail.

Send an e-mail message

1Press Menu 1-2 (Messages > Write e-mail).

Note: If you get a prompt asking you to enter your e-mail gateway

number, you must obtain this number from your service provider.

2At the prompt, enter your recipient’s e-mail address or press Find to look

through and select a saved e-mail address from your phone list.

3Press OK.

4At the prompt, enter a subject for your e-mail message. (You are not required

to enter a subject.)

5Press OK when you are finished.

Note: Predictive text is not available when entering an e-mail address or

a subject line for your e-mail.

A screen will appear allowing you to enter the text of your message. Your total

message, including the address and subject line, can be up to 160 characters.

There is a running total of remaining characters in the top right corner of

the screen.

6After you finish entering the text of your e-mail, press Options, scroll to Send,

then press Select.

2220_2260.ENv1_9356390_.book Page 45 Wednesday, May 28, 2003 4:10 PM

Messages

Receive an e-mail message

When you receive an e-mail message, the phone makes a sound and displays

Message received and the indicator in the upper left corner of the screen.

To read the message, press Read.

When reading a received e-mail message, you can choose other options, such as

Reply and Forward. See “Options when working with messages” on page 39.

Edit an existing e-mail message

Edit an e-mail message by replying to the message or forwarding it. You can edit

messages from any folder.

Reply to an e-mail message

1When reading the message, press Options.

2Scroll to Reply, then press Select.

3Choose to reply As message or As e-mail, then press Select.

When replying as e-mail, see “Send an e-mail message” on page 45. When

replying as message, see “Write and send a text message” on page 42.

Forward an e-mail message

1When reading the message, press Options.

2Scroll to Forward, then press Select.

3Choose to forward As message or As e-mail, then press Select.

When forwarding as e-mail, see “Send an e-mail message” on page 45. When

forwarding as a message, see “Write and send a text message” on page 42.

2220_2260.ENv1_9356390_.book Page 46 Wednesday, May 28, 2003 4:10 PM

8 Personalization

The Nokia 2200 series can be easily customized to fit your lifestyle. The display

language, ringing tones, audio, and accessory settings (among others) can all be

modified to suit your needs.

Your phone has various profiles which allow you to customize ringing and alert

tones for different environments. Once you modify the profiles, you can activate the

profile that is appropriate for your surroundings. For example, you can select the

Silent profile while at the movies or the Outdoor profile when at a sporting event.

• PROFILES

Profiles let you set sound settings to match your

environment, whether it is a meeting or a soccer

game. Just pick the profile that suits your current

environment: Normal, Silent, Meeting, Outdoor

or Pager.

You can customize any of the profiles and set your

own preferences for the following settings:

• Ringing options

• Ringing tone

• Ringing volume

• Message alert tone

• Vibrating alert

• Keypad tones

• Warning tones

• Profile name (except for the Normal profile)

Important: You can select a default profile for each of these accessories:

Headset, Handsfree, and Loopset. To learn more about accessories, see

“Accessory settings” on page 50.

Select a profile

1Quickly press and release the Power key.

2Use the Scroll up or Scroll down key to move to the profile you want to use.

Profile names are highlighted as you scroll through them.

3Press Select to activate a profile.

2220_2260.ENv1_9356390_.book Page 47 Wednesday, May 28, 2003 4:10 PM

Personalization

Customize a profile

1Press Menu 3 (Profiles).

2Scroll to the profile you want to customize, then press Options.

3Scroll to Customize, then press Select.

4Use the scroll keys to display each of the profile options. Once you find the

option you’d like to customize, press Select.

SET THE RINGING OPTIONS

You can choose the type of ring your phone uses to notify you of an incoming call.

This setting does not affect any incoming text message alert tones.

1Press Menu 3 (Profiles).

Your phone lists each profile.

2Scroll to the desired profile in the list for which you want to set the ringing

options, and press Options.

3Scroll to Customize, then press Select.

4Scroll to Ringing options and press Select.

5Scroll to one of the ringing options, as described below, and press Select.

Ring: The phone rings normally.

Ascending: Ringing volume increases (gets louder) if the phone is not answered.

Ring once: The phone rings once to indicate an incoming call.

Beep once: The phone beeps once to indicate an incoming call.

Silent: The phone makes no sound.

SET THE RINGING TONE

The ringing tone is the sound your phone makes when you receive a call. Your phone

contains preprogrammed ringing tones. You can set the ringing tone to a specific

sound or tune to personalize how the phone rings. You can also add custom ringing

tones to your phone. See “Download a ringing tone” on page 72 for more information.

1Press Menu 3 (Profiles).

Your phone lists each profile.

2Scroll to the profile for which you want to set the ringing tone, then

press Options.

3Scroll to Customize, then press Select.

4Scroll to Ringing tone and press Select.

2220_2260.ENv1_9356390_.book Page 48 Wednesday, May 28, 2003 4:10 PM

5Scroll through the options when you hear the tone you want, press Select.

Note: If you have already chosen a ringing option of either Silent or Beep

once, the ringing tones are already turned off. See “Set the ringing options” on

page 48 for details. As you scroll through the ringing tones, you can listen to

a sample of each if your current ringing option is not set to Silent.

SET THE RINGING VOLUME

Set the default ringing volume for incoming voice calls and message alert tones.

1Press Menu 3 (Profiles).

2Scroll to the profile you will set and press Options.

3Scroll to Customize, then press Select.

4Scroll to Ringing volume and press Select.

5Scroll through the options. When you hear the right volume level, press Select.

SET THE MESSAGE ALERT TONE

Set your phone to use a certain tone to indicate an incoming text message.

1Press Menu 3 (Profiles).

2Scroll to the profile for which you want to set the message alert tone and

press Options.

3Scroll to Customize, then press Select.

4Scroll to Message alert tone, then press Select.

5Scroll through the tone selections.

The phone plays samples of each selection as you scroll to it.

6When you find the tone you want, press Select.

SET A VIBRATING ALERT

Set your phone to vibrate to indicate an incoming call.

1Press Menu 3 (Profiles).

2Scroll to the profile for which you want to set the vibrating alert and

press Options.

3Scroll to Customize, then press Select.

4Scroll to Vibrating alert and press Select.

5Scroll to On and press OK.

The phone does not vibrate when it is connected to or placed in any

charging device.

2220_2260.ENv1_9356390_.book Page 49 Wednesday, May 28, 2003 4:10 PM

Personalization

SET KEYPAD TONES

Keypad tones set the volume of the tone you hear when you press phone keys.

1Press Menu 3 (Profiles).

2Scroll to the profile for which you want to set the keypad tones and press Options.

3Scroll to Customize, then press Select.

4Scroll to Keypad tones and press Select.

5Scroll to one of the levels and press Select.

• If you choose Off, no keypad tones are heard.

• If you chose the Silent profile in step 2, the keypad tones are turned off.

SET THE WARNING TONES

Warning tones include the sounds your phone makes during error conditions, during

confirmations, when the battery is low, and when you need to recharge the battery.

1Press Menu 3 (Profiles).

2Scroll to the profile for which you want to set the warning tones, then

press Options.

3Scroll to Customize, then press Select.

4Scroll to Warning tones, then press Select.

5Scroll to On or Off and press Select.

Rename a profile

1Press Menu 3 (Profiles).

2Scroll to the desired profile, then press Options.

3Scroll to Customize, then press Select.

4Scroll to Profile name, then press Select.

5Enter the new name and press OK.

Note: You cannot rename the Normal profile.

Accessory settings

Use your phone with these Nokia accessories:

• Headset (HDC-5, HDE-2, HDB-5, and HDC-10)

• Handsfree Car Kit (CARK-125, CARK-134 and PPH-1)

• Loopset (LPS-3)

• TTY/TDD Adapter (HDA-9)

2220_2260.ENv1_9356390_.book Page 50 Wednesday, May 28, 2003 4:10 PM

Note: You can select a default profile that will be associated with each

accessory, such as Normal. However, the Accessory settings menu will

not appear until after an accessory has been connected to the phone at

least once.

SET UP THE LOOPSET

When you want to use the loopset, you will have to activate the accessory setting.

1Attach the loopset to the phone.

2Press Menu 4-4-3 (Settings > Accessory settings > Loopset).

3Scroll to Use loopset, then press Select.

4Scroll to Yes, then press Select.

AUTOMATIC ANSWER

This feature lets your phone answer incoming calls after just one ring when an

accessory is connected to the phone.

1Press Menu 4-4 (Settings > Accessory settings).

2Scroll to Headset, Handsfree, or Loopset, then press Select.

3Scroll to Automatic answer, then press Select.

4Scroll to On and press Select.

SET THE LIGHTS (CAR KIT ONLY)

When your phone is connected to a car kit, you have a choice of having the phone

lights on (a) continuously or (b) only when you use it.

1Press Menu 4-4-2-3 (Settings > Accessory settings > Handsfree > Lights).

2Choose one of the following options, then press OK:

On: The lights will remain on while the phone is connected to the car kit.

Automatic: The lights will be turned on only when the phone is being used.

SET THE DEFAULT PROFILE

When you use the headset, car kit or loopset, you have the option of selecting a

default profile. You can use the currently selected profile (for example, Normal) or

you can choose from the list.

1Press Menu 4-4 (Settings > Accessory settings).

2Scroll to Headset, Handsfree or Loopset, then press Select.

3Scroll to Default profile, then press Select.

4Scroll to the profile you want, then press Select.

Note: The Active profile uses the current profile setting you have selected

for your phone.

2220_2260.ENv1_9356390_.book Page 51 Wednesday, May 28, 2003 4:10 PM

Personalization

Set the display language

You can choose your phone’s display language.

1Press Menu 4-3-1 (Settings > Phone settings > Language).

2Scroll to the language you want, then press Select.

Set the clock

Your phone contains a real-time clock that can be set two different ways: the clock

can use the time information provided by the wireless system or it can be set

manually. Once the time is set, you can display the clock on the start screen.

For added convenience, the clock is connected to an alarm clock. See “Use the

alarm clock” on page 69 for additional information.

SELECT THE TIME FORMAT

You can choose whether your clock shows time in an am/pm format or a

24-hour format.

1Press Menu 4-1-2-3 (Settings > Time settings > Clock > Time format).

2Scroll to 24-hour or am/pm and press Select.

SET THE CLOCK USING AM/PM FORMAT

1Press Menu 4-1-2-2 (Settings > Time settings > Clock > Set the time).

2Enter the time using an hh:mm format and press OK.

For example, to set your clock to 8:40, enter 08:40.

3Scroll to am or pm and press Select.

Note: Even if you have selected the am/pm format, you can still set the

clock in the 24-hour format.

SET THE CLOCK USING 24-HOUR FORMAT

1Press Menu 4-1-2-2 (Settings > TIme settings > Clock > Set the time).

2Enter the time using an hh:mm format and press OK.

For example, to set your clock to 8:40, enter 08:40 (for am) or 20:40 (for pm).

3Press OK.

Automatic update of time

Set your phone to update the time from the network when you turn the phone on.

If the clock in your phone is 30 seconds or more off the network time, the phone

will automatically update to reflect the network time.

Note: Auto update time is a network dependent feature. Contact your

service provider for details and availability.

2220_2260.ENv1_9356390_.book Page 52 Wednesday, May 28, 2003 4:10 PM

1Press Menu 4-1-3 (Settings > Time settings > Auto update of time).

2Scroll to one of the following options, then press Select.

On: Updates the time automatically.

Confirm first: Requires you to confirm that you want the update. You can

accept or decline the update.

Off: Prevents the time from being automatically updated.

Display the clock

1Press Menu 4-1-2 (Settings > Time settings > Clock).

2Scroll to Hide clock or Show clock (only one choice appears, depending on

the current setting).

3Press Select.

Add a welcome note

You can add a welcome note that your phone displays briefly each time you turn it on.

1Press Menu 4-3-3 (Settings > Phone settings > Welcome note).

2Enter a note, then press Options.

3Scroll to Save, then press Select.

To delete the welcome note, follow steps 1-2, scroll to Delete, then press Select.

Restore factory settings

If you have made changes to your phone’s profiles (settings), you can restore them

to their original or factory settings. The memory, timers, language selection, and

security code are not reset. However, profile and accessory settings are reset.

1Press Menu 4-3-4 (Settings > Phone settings > Restore factory settings).

2At the prompt, enter your five-digit security code and press OK.

See “Understand the security code” on page 67. for more information.

2220_2260.ENv1_9356390_.book Page 53 Wednesday, May 28, 2003 4:10 PM

Advanced calling features

9 Advanced calling features

This chapter covers advanced calling features, including:

• Options available while in a call

• Managing two calls at the same time

• Network services, such as call forwarding

Not all features that are described are available in all wireless networks. Contact

your service provider for availability of network services.

• UNDERSTAND ACTIVE-CALL OPTIONS

Your phone allows you to use a number of features during a call; however, you may

not be able to use all options at all times. Also, the order of in-call options may vary.

Note: Many in-call options are network dependent features. To use these

options, you may need to contact your service provider.

During a call, press Options to see the in-call menu choices:

Access menus

You can access your phone’s menus while in a call.

1Press Options.

2Scroll to Menu, then press Select. To exit the menus, press Exit.

Note: Do not press the End key to exit the menus or you will end your call.

Menu Options What it does

Lock keys Allows you to lock the phone’s keypad during a call.

Mute Mutes the phone’s microphone. This option can affect the

microphones of accessories connected to the phone.

End all calls Ends all active calls.

Touch tones Sends touch tones.

New call Allows you to make a call while you have a call in progress.

Menu Allows you to access the menus.

Contacts Allows you to access the contact list.

2220_2260.ENv1_9356390_.book Page 54 Wednesday, May 28, 2003 4:10 PM

Make a new call

To make a new call while already in a call, dial the number, then press the Talk key.

End all calls

Press the End key.

Access the contact list

You can access information in the contact list during a call.

1Press Options.

2Scroll to Contacts, then press Select.

Save a name and/or number

You can save a name and number during a call.

1Enter the number you want to save.

2Press Options, scroll to Contacts, then press Select.

3Scroll to Add new, then press Select.

Add the name and number as you normally would.

Mute the phone’s microphone

While in a call, you can mute the phone’s microphone.

Press Options, scroll to Mute, press Select.

Use conference call

While in a call, you can call another number to add a third party to the call.

Note: Conference calling is a provider dependent feature. Contact your

service provider for availability and details.

CONFERENCE A CALL

1While in a call, you can either dial the number you want to add and press the

Talk key.

Press Options, scroll to New call, press Select, enter the phone number, and

press OK.

2When the third party answers, press the Talk key to connect all three parties.

2220_2260.ENv1_9356390_.book Page 55 Wednesday, May 28, 2003 4:10 PM

Advanced calling features

DISCONNECT THIRD PARTY

While all three parties are connected, pressing the Talk key disconnects the third

caller, keeping the second party’s call active.

DISCONNECT SECOND PARTY

If you wish to disconnect with the second party and remain connected to the third

party, have the second party terminate the call on his/her end.

RECALL A NUMBER FROM THE CONTACT LIST DURING A CALL

If you don’t remember the number of the second party you want to include in the

conference and the number is in your contact list, you can recall the number.

1To access the contact list, press Options, scroll to Contacts, and press Select.

2Follow the prompts to find the number as you normally would.

3Locate the number in your contact list, then press Select.

The number appears in the number prompt.

4Press OK to call the number.

END A CONFERENCE CALL

To end all calls, press the End key.

• USE VOICE PRIVACY

The voice privacy feature encrypts the voice channel so that people cannot eavesdrop

on your phone conversations.

Note: Voice privacy is a network dependent feature. Contact your service

provider for more information on this feature.

TURN VOICE PRIVACY ON/OFF

1Press Menu 4-6-1 (Settings > Network services > Voice privacy).

2Scroll to On or Off and press Select.

During a call, voice privacy becomes active and notifies you with a beep. A

notification message also appears on the screen.

If you turn this feature on and voice privacy becomes inactive, your phone beeps

and displays Voice privacy not active.

Note: Use caution when sending confidential information, if voice privacy

is not active.

2220_2260.ENv1_9356390_.book Page 56 Wednesday, May 28, 2003 4:10 PM

• USE CALL FORWARDING

With call forwarding, you can forward incoming calls to another phone number.

Before you can use call forwarding, you must first store the feature codes. Once

call forwarding has been activated, Call forwarding appears as a menu option.

Note: Call forwarding is a network-dependent feature. Some networks

require that call forwarding be activated manually. Contact your service

provider for availability and full details.

Learn about call forwarding feature codes

Your network requires separate codes for activating and cancelling the various

types of call forwarding. Your carrier can provide you with the necessary feature

codes for these network services.

Once you store these feature codes in your phone, they are sent automatically to the

network when you select one of the call forwarding options from your phone’s

menu. Your phone can store the following types of feature codes:

Store the call forwarding feature code

Before you can activate call forwarding, you must contact your service provider to

obtain the feature codes.

1Press Menu 4-6-5 (Settings > Network services).

2Enter the feature code your service provider gave you, then press OK.

3Scroll to Call forwarding and press Select.

Option What it does

Forward all calls Forwards incoming calls to the number you specify.

Forward if busy Forwards incoming calls when you are in a call.

Forward if not

answered

Forwards incoming calls to another number when you are

unable to answer.

Forward if out of

reach

Forwards incoming calls to another number when the

phone is out of the network or switched off.

Cancel all call

forwarding

Cancels all active call forwarding options.

2220_2260.ENv1_9356390_.book Page 57 Wednesday, May 28, 2003 4:10 PM

Advanced calling features

4Scroll to the call forwarding option you want and press Select.

5Scroll to Activate and press Select.

Activate/cancel call forwarding

After you store the correct feature codes, you can activate (or cancel) call

forwarding as follows:

1Press Menu 4-6-2 (Settings > Network services > Call forwarding).

2Scroll to the desired call forwarding option, then press Select.

3Highlight Activate and press Select.

4Enter the number to which you want your calls forwarded or press Find to

recall a number from the contact list.

5Press OK.

Note: When canceling call forwarding, follow steps 1 and 2.

• USE CALL WAITING

During a call, call waiting beeps to let you know that someone else is calling you.

Depending on your caller ID setup, the phone might also display the number of the

incoming call. Once call waiting has been activated, Call waiting appears as a

menu option.

Note: Call waiting is a network-dependent feature. In some networks the call

waiting code must be activated manually. Contact your service provider for

availability and full details.

Store the call waiting feature code

1Press Menu 4-6-5 (Settings > Network services > Network feature setting).

The Feature code prompt appears.

2Enter the feature code issued by your service provider and press OK.

3Scroll to Call waiting and press Select.

4Scroll to Activate and press Select.

Activate call waiting

1Press Menu 4-6-3 (Settings > Network services > Call waiting).

2Scroll to Activate and press Select.

2220_2260.ENv1_9356390_.book Page 58 Wednesday, May 28, 2003 4:10 PM

Manage calls

Call waiting works with both local and long distance calls.

• To answer an incoming call, press the Talk key.

• To switch from one call to another, press the Talk key.

• To end both calls, press the End key.

• USE SEND OWN CALLER ID

This feature allows you to block caller ID when you call someone (your number will

not be displayed on their caller ID). This feature is only effective when calling a

number equipped with caller ID.

Note: This feature is available only when supported by the wireless

network and may not function if you are roaming.

Important: This feature works on a call-by-call basis. You must enable this

feature each time you want to block the sending of your own number to

the recipient’s caller ID.

STORE THE FEATURE CODE

Before you can use the Send own caller ID call feature, you must store the feature

codes for activating this feature. Once the code is stored in your phone, it is sent

automatically to the network when you select this option from your phone’s menu.

1Press Menu 4-6-5 (Settings > Network services > Network feature setting).

The Feature code prompt appears.

2Enter the feature code issued by your service provider and press OK.

3Scroll to Send own caller ID, press Select, then select Yes.

PLACE A CALL WITHOUT SENDING YOUR NUMBER

1Press Menu 4-6-4 (Settings > Network services > Send own caller ID).

2Scroll to No, then press Select.

3Enter the desired phone number, then press OK or press Find to recall a phone

number from the contact list.

The phone automatically inserts the feature code into the dialing string and

dials the phone number. The phone you are calling will not display your phone

number through caller ID.

2220_2260.ENv1_9356390_.book Page 59 Wednesday, May 28, 2003 4:10 PM

Advanced calling features

• SELECT A PHONE NUMBER

Your service provider programs your phone number and system information into your

phone’s memory when your phone is first activated. Your phone can hold up to

three numbers. This means that your phone can be activated in three different service

areas. For example, your phone could be activated in Dallas, Chicago, and New York.

Each service area would assign a different phone number or account to your phone.

You must select a phone number for your home system. Only one phone number

can be active at a time. If you travel outside your home system, you can choose

another number. One phone number is usually enough if your service provider has

service or roaming agreements for each area in which you wish to use your phone.

Contact your service provider for details.

Note: Phone number selection is a network dependent feature. Some

networks may not support more than one number. Contact your service

provider for availability and full details.

Select the phone number

1Press Menu 4-6-6 (Settings > Network services > Own number selection).

2Scroll to the phone number you want and press Select.

Note: The first phone number on this list is selected. You need at least one

active number to make calls. You cannot change from one phone number

to another during a call.

• USE AUTOMATIC REDIAL

There are times when you may not be able to place a call (for example, due to the

high volume of traffic on the wireless network). When the wireless network is busy

or unavailable, Automatic redial instructs your phone to retry the call.

ACTIVATE AUTOMATIC REDIAL

1Press Menu 4-2-1 (Settings > Call settings > Automatic redial).

2Scroll to On and press Select.

If the system is busy, your phone makes three additional call attempts. If you want to

stop the automatic redial process before the last attempt, press the End key or Quit.

Important: This feature does not automatically retry a number when the

number you are calling is busy.

2220_2260.ENv1_9356390_.book Page 60 Wednesday, May 28, 2003 4:10 PM

• USE 1-TOUCH DIALING

You can assign a name from your contact list to a 1-touch dial location, using your

phone’s keys 2-9. (The 1 key is used exclusively to dial your voice mailbox.) Once

assigned, the phone number you associate with that key is dialed automatically

when you press and hold the key.

Assign a key to 1-touch dialing

1Press Contacts, scroll to 1-touch dialing and press Select.

2Scroll to a number that has the message (empty) and press Assign.

3Scroll to the name and number to which you want to assign this key and

press Select.

Repeat steps 1-3 times as many times as necessary.

4To call a number using 1-touch dialing, press and hold the appropriate key for

a few seconds.

Change 1-touch dialing numbers

You can change the 1-touch dialing key assignments at any time.

1Press Contacts, scroll to 1-touch dialing, and press Select.

2Scroll to the key you want to change and press Options.

3Scroll to Change and press Select.

4Scroll through the contact list until you reach the new number you want to

select and press Select.

Delete 1-touch dialing numbers

You can delete 1-touch dialing key assignments at any time.

1Press Contacts, scroll to 1-touch dialing and press Select.

2Scroll to the key you want to delete and press Options.

3Scroll to Delete, press Select, then press OK.

• SET TOUCH TONE STRINGS

Your phone allows you to create special sets of numbers known as touch tone

strings which will dial a series of digits after a “wait” or a “pause.” For example,

you can program your phone to send your account number while you are banking

by phone.

2220_2260.ENv1_9356390_.book Page 61 Wednesday, May 28, 2003 4:10 PM

Advanced calling features

You must be in the mode to enter these characters. Enter the numbers

as usual. When you want to insert the special characters, press * repeatedly to

switch among *, +, p, w characters.

Note: Use caution when sending confidential information, if voice privacy

is not active.

Set manual touch tones

1Press Menu 4-3-2-1 (Settings > Phone settings > Touch tones > Manual

touch tones).

2Select one of the following options, then press Select:

Continuous: Sounds tone for as long as you press and hold a key.

Fixed: Sets the tone length to 0.1 second, regardless of how long you press a key.

Off: Turns off the tones. No tones are sent.

Set touch tone length

You can also set the length of each touch tone.

1Press Menu 4-3-2-2 (Settings > Phone settings > Touch tones > Touch

tone length).

2Use the Scroll up or Scroll down key to scroll to Short or Long.

Short sets the tone length to 0.1 second. Long sets the tone length to 0.5 second.

3Press Select.

Character Action

Creates a pause when a number is dialed. The numbers you

enter after this special character are automatically sent as

touch tones after a 2.5-second pause.

Creates a wait when a number is dialed. This means that

your phone waits for you to press the left selection key

before it sends the number as touch tones.

* Sends command strings to the network. Contact your

service provider for details.

+Use this character to link a 1-touch dialing number to a

number in the contact list.

2220_2260.ENv1_9356390_.book Page 62 Wednesday, May 28, 2003 4:10 PM

Store touch tone strings

You can store touch tone strings the same way that you store names and numbers

in your contact list. You can store an entire sequence of digits and send it as touch

tones for frequently used strings of numbers.

STORE TOUCH TONE STRINGS WITH PHONE NUMBERS

1Enter the phone number that you want associated with a touch tone.

2Enter the touch tone character where needed (p, w, or *).

3Enter the touch tone string.

4Store the number as you normally would.

SEND A TOUCH TONE STRING

1Press Menu 4-3-2-1 (Settings > Phone settings > Touch tones > Manual

touch tones).

2Make sure that the setting is not set to Off.

If not set to Off., scroll to one of the other options and press Select.

3During your call, press Options, scroll to Touch tones, and press Select.

4Enter the touch tone string or recall the string from the contact list, then

press OK.

If you send touch tones while in the analog mode, be careful not to send

confidential information.

• LINK CONTACT LIST ENTRIES

This feature allows you to store a phone number in one contact list location and link

it to another contact list entry.

For example, linking the phone number of an automated service (for example,

automated banking service) with a touch tone string entry in your contact list

(example: account and PIN numbers) automatically recalls and sends the touch

tone string when you call the service.

USE LINKING OPTIONS

1Store the touch tone string into your contact list.

2Assign the contact list entry with the touch tones to a one-touch dialing location

(example: location 3).

For more information on 1-touch dialing, see “Use 1-touch dialing” on page 61.

3Edit the automated service’s phone number by adding +n to the end of the

phone number (where n is the 1-touch dialing location).

Example: 214-555-1234+3

2220_2260.ENv1_9356390_.book Page 63 Wednesday, May 28, 2003 4:10 PM

Advanced calling features

4Press OK to save your changes.

5Dial the automated service number from your contact list.

Your phone automatically sends the touch tones when the call connects.

Note: You may need to enter a pause (p) or a wait (w) before the + in order

to account for delays in the automated system answering your call (for

example, 214-555-1234p+3).

• SELECT A SYSTEM

Your phone can operate in residential, private, and public systems (such as your home

system). You can choose how your phone selects a network to use. Your phone may

not show the options described here. For information, contact your service provider.

Search for a network

Press Menu 5 (System).

You have the following three options:

•Automatic: Your phone automatically searches for available networks and

chooses the appropriate one. Every time you turn on your phone, it resets

to Automatic.

•Manual: The phone searches for networks and then shows a list of the ones that

are available. If an available network is found, Available: appears on the screen,

followed by the name of the network. To choose the network listed, press OK.

•New search: Your phone begins a new search for both private and residential

systems. When it finds the best system available, the phone shows the system

name. If the phone doesn’t find another system, the question Perform an

extended search? will appear. Press OK if you wish to continue searching.

Select a public system

When you take your phone outside its home system, the phone is said to be roaming.

The phone can search for home-type systems (that is, systems of the same type as

your home system). Or, the phone can search for non-home-type systems.

Your service provider programs a list of preferred systems into your phone. These

are systems with which your service provider has roaming agreements. Your phone

looks for these systems when you’re roaming.

Note: The options described here may not be available for your phone.

Contact your service provider for information.

1Press Menu 4-6-7 (Settings > Network services > Public system selection)

to tell your phone how to choose a public system (network).

Your selection remains active until you change it.

2220_2260.ENv1_9356390_.book Page 64 Wednesday, May 28, 2003 4:10 PM

2Scroll to one of the following options, then press Select.

Any system: When service is not available in your home system, the phone

searches for a preferred system of either type and then searches for a home-

type system. Then it searches for a nonhome-type system. The search

continues until your phone finds a system that can be used.

Home type: When service is not available in your home system, the phone

searches for a home-type system first. However, if a nonhome-type system is

found, your phone will use that system.

Nonhome type: The phone searches for a nonhome-type system only.

The home-type system is not used.

Home only: The phone uses only its home system. It will not roam.

Select digital or analog

Your phone can work in both digital and analog modes. The default mode is both

digital and analog, which appears on your phone as Digital & analog when you press

Menu 4-6-8 (Settings > Network services > Digital/analog selection).

The menu options for choosing the mode you prefer are:

•Digit. & analog

•Analog

•Digital

Your phone uses both digital and analog voice channels. The phone always tries to

find a digital voice channel first, but if a digital voice channel is not available, the

phone looks for an analog voice channel.

Note: This feature is available only for certain phones. Contact your service

provider for more information.

2220_2260.ENv1_9356390_.book Page 65 Wednesday, May 28, 2003 4:10 PM

Security

10 Security

Your phone is equipped with different security features that allow you to do

the following:

• Avoid making accidental calls

• Prevent unauthorized users from changing certain feature settings on your phone

• Restrict outgoing or incoming calls

• USE KEYGUARD

Keyguard disables your keypad to prevent accidental

key presses.

LOCK THE KEYPAD

To lock the keys, press Menu then *.

UNLOCK THE KEYPAD

To unlock the keys, press Unlock then *.

Note: When Keyguard is on, calls may be possible to emergency numbers

(for example, 911 or other official emergency number). Key in the emergency

number and press the Talk key. The number is displayed only after you have

keyed in its last digit.

Answer a call while Keyguard is active

You can answer calls when Keyguard is activated by pressing Answer or the Talk

key. If you are connected to a headset or loopset, press and hold the End key to end

the call.

NOTES ABOUT KEYGUARD

• After you end the call, Keyguard automatically becomes active again.

• If you need the phone’s lights while Keyguard is on, press the Power key to

quickly switch the lights on for 15 seconds.

• Connecting your phone to a car kit automatically disables Keyguard.

2220_2260.ENv1_9356390_.book Page 66 Wednesday, May 28, 2003 4:10 PM

• UNDERSTAND THE SECURITY CODE

The Security code prevents unauthorized users from changing certain important

feature settings on your phone. When the phone requires this code, it displays a

prompt asking you to enter a Security code. The five-digit default Security code

that comes with your phone is 12345. Nokia recommends that you change the

default code immediately.

Note: If you enter an incorrect security code five times in a row, the phone

will not accept the correct code for 5 minutes.

Change your security code

1Press Menu 4-5-2 (Settings > Security settings > Change security code).

2At the Security code prompt, enter your five-digit default security code

(12345) or your current security code and press OK.

3At the Enter new security code prompt, enter your new five-digit security

code and press OK.

4At the Verify new security code prompt, enter your new security code again

and press OK.

The confirmation Security code changed appears.

Keep your security code secret and stored in a safe place away from your phone. If

you have changed your security code and don’t remember the new code, contact

your service provider.

• RESTRICT CALLS

You can create your own list of restrictions to restrict incoming and outgoing calls.

To restrict the calls, you apply the appropriate restriction as desired. The maximum

number of call restrictions you can define is ten.

Before you define restrictions for outgoing calls, Add restriction is the only

available option. After you use the Add restriction option to add at least one

restriction, the following options become available:

•Select: Allows you to select call restrictions from the outgoing calls list.

•Add restriction: Allows you to add a new restriction.

•Edit: Allows you to edit an existing call restriction.

•Delete: Allows you to delete an existing call restriction.

Note: When calls are restricted, calls may be possible to the emergency

number programmed into your phone (for example, 911 or other official

emergency number). For example, you could dial 911 and press the Talk key.

2220_2260.ENv1_9356390_.book Page 67 Wednesday, May 28, 2003 4:10 PM

Security

Add a number to the call restriction list

1Press Menu 4-5-1-1 (Settings > Security settings > Call restrictions >

Restrict outgoing calls).

2Enter your security code, then press OK.

3Scroll to Restrict outgoing calls, then press Select.

4Scroll to Add restriction and press Select.

5At the number prompt, enter the number you want to restrict, and press OK.

For example, if you want to restrict all long distance calls that begin with 1,

enter 1. If you want to restrict all calls that begin with 972, enter 972.

6Enter a name for the restriction, then press OK.

If you press OK without entering a name, the number will be used.

Restrict outgoing calls

1Press Menu 4-5-1-1 (Settings > Security settings > Call restrictions >

Restrict outgoing calls).

2Enter your security code, then press OK.

3Scroll to Restrict outgoing calls, then press Select.

4Scroll to Select to choose from your list of call restrictions.

To deactivate a call restriction, highlight the restriction and press Unmark.

5Scroll to the restriction you want to activate and press Mark.

6Press Back.

7At Save changes?, press Yes.

To return to the start screen, press the End key.

Restrict all incoming calls

1Press Menu 4-5-1-2 (Settings > Security settings > Call restrictions >

Restrict incoming calls).

2Enter your security code, then press OK.

3Scroll to Restrict incoming calls, then press Select.

4Press Mark to restrict all incoming calls.

2220_2260.ENv1_9356390_.book Page 68 Wednesday, May 28, 2003 4:10 PM

11 Special features

This section describes several special features, including transmission of business

cards, downloading ringing tones, using the calculator and setting the alarm clock.

• USE THE ALARM CLOCK

The alarm clock feature is based on your phone’s internal clock and sounds an alert

at a time you specify. The alarm clock works even if you turn your phone off.

Set the alarm clock

1Press Menu 4-1-1 (Settings > Time settings > Alarm clock).

2Enter the alarm time in hh:mm format, then press OK.

Step 3 is necessary only if you have selected am/pm format.

3Select either am or pm, then press Select.

Respond to the alarm

At the time of the alarm, the phone sounds an alert tone. Pressing Stop or the End

key stops the alarm from sounding, and returns you to the start screen.

SNOOZING

There are several ways you can enable the Snooze feature:

1Press the Snooze selection key.

2Press any key except the End key.

3Allow the alarm to sound for one minute.

Once snooze is enabled, the alarm will sound again in ten minutes. If you press

Stop or the End key while snoozing, the alarm will be turned off.

Alarm when phone power is off

If the alarm time is reached while the phone is off, the phone switches itself on and

starts sounding the alarm tone. If you press Stop, the phone asks whether you want

to activate the phone for calls. Press No to switch off the phone or Yes to make

and receive calls.

Note: Do not press Yes when wireless phone use is prohibited or when it

may cause interference or danger.

Turn off the alarm clock

1Press Menu 4-1-1 (Settings > Time settings > Alarm clock).

2Scroll to Off and press Select.

2220_2260.ENv1_9356390_.book Page 69 Wednesday, May 28, 2003 4:10 PM

Special features

• USE THE CALCULATOR

The calculator adds, subtracts, multiplies, divides and converts currencies.

1Press Menu 7 (Calculator)

2Enter the first number in the calculation. To enter a decimal point, press #.

Press Clear to delete any mistakes.

3Press Options and scroll to Add, Subtract, Multiply, or Divide. Press OK.

Based upon the type of calculation, you also can use the following shortcut keys:

4Enter the second number in the calculation and press Options.

Equals appears.

5Press OK.

6Repeat steps 2-6 as many times as necessary.

Your phone must be switched on to use this function. Do not switch the phone on

when wireless phone use is prohibited or when it may cause interference or danger.

Note: This calculator has a limited accuracy and rounding errors may

occur, especially in long divisions.

Convert currency

You can use the calculator function to set an exchange rate and then calculate

prices based on that exchange rate.

SET THE EXCHANGE RATE

1Press Menu 7 (Calculator), then press Options.

2Scroll to Exchange rate, press OK and select one of the following options:

•Foreign units converted to home units – allows you to enter the number

of foreign units to a domestic unit.

•Home units converted to foreign units – allows you to enter the number

of domestic units to a foreign unit.

If you want to... Press...

add ∗ (for + symbol)

subtract ∗∗ twice (for - symbol)

multiply ∗∗∗ (for * symbol)

divide ∗∗∗∗ (for / symbol)

2220_2260.ENv1_9356390_.book Page 70 Wednesday, May 28, 2003 4:10 PM

3Press OK, enter the appropriate exchange rate (press # to enter a decimal

point) and press OK.

The initial default of 1 is overwritten by any number you enter and the Rate

saved confirmation appears.

CONVERT A CURRENCY AMOUNT

1Press Menu 7 (Calculator).

2Enter the amount which you wish to convert.

3Press Options and scroll to one of the following options:

•To home – converts visited units of currency to home units using the

exchange rate.

•To foreign – converts home units of currency to visited units using the

exchange rate.

4Press OK.

• BUSINESS CARDS

Your phone can send or receive electronic business cards consisting of a name,

phone number and e-mail. You can save received business cards in your contact

list. This is a network dependent feature.

Send a business card

1Find the name in your contact list.

2Press Options and scroll to Send bus. card.

3Press Select.

4Enter or recall the phone number to which you want to send the business card

and press Send.

View a received business card

When you receive a business card, the phone displays Business card received.

1When your phone displays Business card received, press Options.

2Show is selected. Press Select.

3Scroll through the available information.

Save a viewed business card

1After viewing the business card, press Back, scroll to Save and press Select.

2At the Name: prompt, edit the name if desired, then press OK.

2220_2260.ENv1_9356390_.book Page 71 Wednesday, May 28, 2003 4:10 PM

Special features

3At the Number: prompt, edit the number if desired, then press OK.

4At the E-mail address prompt, edit the e-mail address if desired, then press OK.

Delete a viewed business card

After viewing the business card:

1Press Back.

2Scroll to Discard, then press Select.

3Discard business card? appears, press OK.

• DOWNLOAD A RINGING TONE

You can download up to ten ringing tones to replace the personal entries in your

list of ringing tones. Since this is a network dependent feature, methods for

downloading ringing tones vary. Some wireless providers allow you to send ringing

tones to your phone via the Internet, but may charge for this service. Please contact

your wireless service provider for details.

Notification of a received ringing tone

If you have this service and your phone receives a downloaded ringing tone, your

phone displays Ringing tone received.

Listen to received ringing tones

1When your phone shows Ringing tone received, press Options.

2Playback is selected. Press OK.

The phone plays the ringing tone.

3To stop playing the ringing tone, press Quit.

Note: An incoming call or pressing any key stops the ringing tone

from playing.

Save a received ringing tone

1After listening to the ringing tone, press Quit.

2Scroll to Save tone. Press OK.

3Choose which ringing tone you want to replace – either an empty Personal

location, if any are remaining, or a previously downloaded tone.

Discard a received ringing tone

1After listening to the ringing tone, press Quit.

2Scroll to Discard tone, then press OK.

2220_2260.ENv1_9356390_.book Page 72 Wednesday, May 28, 2003 4:10 PM

12 Prepaid services

With prepaid service, you buy wireless network

services in advance. Your phone works the same

way it did before, with some additional features.

Since prepaid service may not be available from your

wireless service provider, the Prepaid screen may not

appear. Contact your service provider for details.

• MANAGE PREPAID SERVICE

After you sign up with your service provider for prepaid service, you can activate

the Prepaid menu in your phone. This menu appears on your screen only if you’ve

activated the service.

ACTIVATE PREPAID

To activate prepaid services, enter the following sequence: *#7766#

DEACTIVATE PREPAID

To deactivate prepaid services, enter the following sequence:*#77633#

USE THE MENU

• To use the prepaid menu, press Menu and then press the Scroll up key to go

immediately to Prepaid.

• Once you select the prepaid menu, press the Scroll up or Scroll down key to

scroll through prepaid options.

• CHECK YOUR PREPAID BALANCE

You can check the balance remaining in your prepaid account. Contact your service

provider for the access number used to check the balance.

Note: When no more charging units or currency units are left, calls may

only be possible to the emergency number programmed into your phone

(for example, 911 or other official emergency number).

1Press Menu 8-1 (Prepaid > Check account balance).

2At Balance number, enter the balance number and press OK.

If you have already saved the balance number under Save access phone

numbers, the phone will initiate a call to the saved number.

3Follow the operator prompts.

2220_2260.ENv1_9356390_.book Page 73 Wednesday, May 28, 2003 4:10 PM

Prepaid services

• ADD MONEY TO YOUR ACCOUNT

Call the access number your service provider gave you to add money to your

account. For convenience, see “Save your access numbers” on page 74.

1Press Menu 8-2 (Prepaid > Add money to account).

2At Replenish no., enter the replenish number and press OK.

If you have already saved the replenish number under Save access phone

numbers, the phone will initiate a call to the saved number.

3Follow the operator prompts.

• CALL CUSTOMER SERVICE

You can call the customer service number for your prepaid account. Contact your

service provider for the access numbers.

1Press Menu 8-3 (Prepaid > Call customer service).

2Enter the customer service number your service provider gave you, then press OK.

If you have already saved the customer service number under Save access phone

numbers, the phone will initiate a call to the saved number.

3Follow the operator prompts.

• SAVE YOUR ACCESS NUMBERS

You can check your prepaid balance, add money to your account, and call customer

service. To do that, you first need to save the correct access numbers in your phone.

Contact your service provider for the access numbers.

1Press Menu 8-4 (Prepaid > Save access phone numbers).

2At Save access phone numbers, press Select.

3Scroll to Replenish phone number, press Select, enter the replenish number

from your service provider, then press OK.

4Scroll to Balance phone number, press Select.

5Enter the balance number from your service provider, then press OK.

6Scroll to Customer service phone number, then press Select.

7Enter the customer service number from your service provider, then press OK.

2220_2260.ENv1_9356390_.book Page 74 Wednesday, May 28, 2003 4:10 PM

• EXPIRATION DATE

You can store and edit the expiration date of your prepaid credit each time you add

money to your account. Enter and change this date manually.

1Press Menu 8 (Prepaid).

2Scroll to Expiration date, then press Select.

3Enter the expiration date, then press OK.

To simply view the current expiration date that you have entered, press

Menu 8-5 (Prepaid > Expiration date).

2220_2260.ENv1_9356390_.book Page 75 Wednesday, May 28, 2003 4:10 PM

Games

13 Games

You can use your phone for communication and some

serious fun. Your phone offers three games:

• Snake II

•Space impact

•Pairs II

Note: Your phone must be switched on to use this function. Do not switch

on the phone when wireless phone use is prohibited or when it may cause

interference or danger.

• START A NEW GAME

1Press Menu 6 (Games)

2Scroll to the desired game and press Select.

3Select New game, then press Select.

Additional options under each game include:

Option What it does

Continue Continue a game that was stopped.

New Game Start a new game.

Level

(Snake II and Pairs II only)

Choose the game’s difficulty level.

Mazes

(Snake II only)

Choose among different maze designs.

Top score Display the top score.

Instructions Learn how to play the game.

Time trial (Pairs II only) To advance to the next level, you must pair up

all tiles before the dynamite fuse runs out.

Puzzle (Pairs II only) Reveal pictures to find pairs with as few tries

as possible.

2220_2260.ENv1_9356390_.book Page 76 Wednesday, May 28, 2003 4:10 PM

Please visit Nokia games services on the Internet for more hints and tips at:

www.nokia.com/us.

GAME SETTINGS

Game sounds and lights can be turned on or off. To access the Settings menu, press

Menu 6-4 (Games > Settings).

•SNAKE II

Feed the snake with as many goodies as possible and watch it grow. Press Menu 6-1.

To turn the snake toward the food, press 2, 4, 6, and 8. The longer the snake’s tail

grows, the higher your score. You can choose to have a clear field, or select from

five different mazes. If the snake runs into its own tail or the surrounding wall,

found in one of the maze levels, the game is over.

• SPACE IMPACT

Use your weapons to survive alien attacks. When you defeat all the enemies, you

progress to the next level. Press Menu 6-2.

• To move up and down, press 8 and 0.

• To move to the left and right, press * and #.

• To fire the main weapons, press 1 or 3.

• To fire the bonus weapons, press 4 or 6.

• PAIRS II

The object of the game is to uncover the pictures to find pairs in as few tries as

possible. Press Menu 6-3 and choose between Time Trial and Puzzle.

Move the cursor with keys 2, 4, 5, and 8.

To reveal the pictures, press 5.

When playing in Time trial mode, you must match all the pairs before the dynamite

fuse runs out in order to advance to the next level.

2220_2260.ENv1_9356390_.book Page 77 Wednesday, May 28, 2003 4:10 PM

Minute Manager

14 Minute Manager

With Minute Manager service, you cap monthly

spending of cellular service. This section describes how

you can use your Minute Manager menu to manage

your cellular account. Since this service may not be

available from your wireless service provider, the

Minute Mgr. screen may not appear. Contact your

service provider for details.

Note: The actual invoice for calls and services from your service provider

may vary, depending upon network features, rounding-off for billing, taxes,

and so forth.

• CHECK YOUR CALL INFORMATION

You can check information on charges, minutes and messages. To access this

information press Menu 9-1 (Minute Mgr. > My calls).

My charges

My charges allows you to view your current call charges. You can view the current

charges for all calls made this billing cycle, or you can view the charge for the last

call you made. My charges information is approximate. The actual charges and

minutes will be listed on your monthly bill. To view your charges:

1Press Menu 9-1-1 (Minute Mgr. > My calls > My charges).

2Scroll to Current or My last call.

3Press Select to view the charges. Press Back to return to the previous screen.

Note: If you exceed your Minute Manager limit, calls may only be possible

to the emergency number programmed into your phone (for example, 911

or other official emergency number).

You can also call 611 and the customer service number for your Minute

Manager account.

My minutes

You can check the minutes you’ve used in the current billing cycle, as well as the

number of anytime minutes remaining in your plan’s package. This information is

for regular plan minutes. It does not include information on long distance calls or

SMS messages. To view your minutes:

1Press Menu 9-1-2 (Minute Mgr. > My calls > My minutes).

2220_2260.ENv1_9356390_.book Page 78 Wednesday, May 28, 2003 4:10 PM

2Scroll to Minutes used or Package mins.

3Press Select to view the number of minutes.

My data

You can check the total number of SMS messages you have sent and received.

This number includes any free messages provided by your plan.

1Press Menu 9-1-3 (Minute Mgr. > My calls > My data).

2Scroll to Messages sent or Msgs received.

3Press Select to view the number of messages.

• CHECK YOUR ACCOUNT INFORMATION

You can check information on your current bill, limit and rate plan.

To access this information press Menu 9-2 (Minute Mgr. > My account).

My bill

Bill information is updated by your service provider and reflects the current

amount owed.

To view your current bill, press Menu 9-2-1 (Minute Mgr. > My account >

My bill).

My bill date

The bill date is the date when the next bill cycle starts.

To view your bill date, press Menu 9-2-2 (Minute Mgr. > My account >

My bill date).

My limit

You can view the spending limit of your account. This amount is set by your service

provider during account activation and is independent of any balance information.

Contact your service provider for more information.

To view your limit, press Menu 9-2-3 (Minute Mgr. > My account > My limit).

My rate plan

This menu provides information about your current rate plan.

Press Menu 9-2-4 (Minute Mgr. > My account > My rate plan).

2220_2260.ENv1_9356390_.book Page 79 Wednesday, May 28, 2003 4:10 PM

Minute Manager

My number

To view your mobile number, press Menu 9-2-5 (Minute Mgr. > My account >

My number).

• CUSTOMER CARE

You can call the customer care number for your Minute Manager account. This is the

same number you will call to make a payment. The customer care number may be

pre-programmed in your phone. If not, contact your service provider for the number.

Make a payment

You can follow these steps to contact customer service and to make a payment.

1Press Menu 9-3 (Minute Mgr. > Customer care).

2When Make payment is highlighted, press Select. The customer care number

will appear on the screen.

3Press Call to dial the number.

2220_2260.ENv1_9356390_.book Page 80 Wednesday, May 28, 2003 4:10 PM

15 Reference information

This section provides information about your phone’s batteries, accessories, chargers,

safety guidelines and technical information. Be aware that the information in this

section is subject to change as batteries, chargers, and accessories change.

• BATTERY STATEMENTS

Charging and discharging

Your phone is powered by a rechargeable battery.

Note that a new battery's full performance may be achieved only after two or three

complete charge and discharge cycles!

The battery can be charged and discharged hundreds of times but it will eventually

wear out. When the operating time (talk time and standby time) is noticeably shorter

than normal, it is time to buy a new battery.

Use only batteries approved by the phone manufacturer and recharge your battery

only with the chargers approved by the manufacturer. Unplug the charger when

not in use. Do not leave the battery connected to a charger for longer than a week,

since overcharging may shorten its lifetime. If left unused, a fully charged battery

will discharge itself over time.

Temperature extremes can affect the ability of your battery to charge; allow it to cool

down or warm up first.

For good operation times with NiMH batteries, discharge the battery from time to

time by leaving your phone switched on until it turns itself off (or by using the

battery discharge facility of any approved accessory available for your phone).

Do not attempt to discharge the battery by any other means.

Use the battery only for its intended purpose.

Never use any charger or battery which is damaged or worn out.

Do not short-circuit the battery. Accidental short-circuiting can occur when a

metallic object (coin, clip, or pen) causes direct connection of the + and - terminals

of the battery (metal strips on the battery), for example, when you carry a spare

battery in your pocket or purse. Short-circuiting the terminals may damage the

battery or the connecting object.

Leaving the battery in hot or cold places, such as in a closed car in summer or

winter conditions, will reduce the capacity and lifetime of the battery. Always try

to keep the battery between 59°F and 77°F (15°C and 25°C). A phone with a hot or

cold battery may temporarily not work, even when the battery is fully charged.

Batteries' performance is particularly limited in temperatures well below freezing.

2220_2260.ENv1_9356390_.book Page 81 Wednesday, May 28, 2003 4:10 PM

Reference information

Do not dispose of batteries in a fire!

Dispose of batteries according to applicable local regulations (for example, recycling).

Do not dispose of as household waste.

Note: For information on how to charge and recharge your battery, refer to

“Important battery information” on page 12.

• PROPER CARE AND MAINTENANCE

Your phone is a product of superior design and craftsmanship and should be treated

with care. The suggestions below will help you to fulfill any warranty obligations

and to enjoy this product for many years:

• Keep the phone and all its parts and accessories out of the reach of small

children.

• Keep the phone dry. Precipitation, humidity and all types of liquids or moisture

can contain minerals that will corrode electronic circuits.

• Do not use or store the phone in dusty, dirty areas. Its moving parts can

be damaged.

• Do not store the phone in hot areas. High temperatures can shorten the life of

electronic devices, damage batteries, and warp or melt certain plastics.

• Do not store the phone in cold areas. When it warms up (to its normal

temperature), moisture can form inside and may damage electronic

circuit boards.

• Do not attempt to open the phone. Nonexpert handling may damage it.

• Do not drop, knock, or shake the phone. Rough handling can break internal

circuit boards.

• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean

the phone.

• Do not paint the phone. Paint can clog the moving parts and prevent

proper operation.

• Use only the supplied or an approved replacement antenna. Unauthorized

antennas, modifications, or attachments could damage the phone and may

violate regulations governing radio devices.

All of the above suggestions apply equally to your phone, battery, charger or any

accessory. If any of them are not working properly, take them to your nearest

qualified service facility. The personnel there will assist you, and if necessary,

arrange for service.

2220_2260.ENv1_9356390_.book Page 82 Wednesday, May 28, 2003 4:10 PM

• IMPORTANT SAFETY INFORMATION

This section provides additional safety information. A brief overview of safety can

be found in “For your safety” on page 1.

Traffic safety

Do not use a hand-held telephone while driving a vehicle. Always secure the phone

in its holder; do not place the phone on the passenger seat or where it can break

loose in a collision or sudden stop.

Remember road safety always comes first!

Operating environment

Remember to follow any special regulations in force in any area and always switch

off your phone whenever it is forbidden to use it, or when it may cause interference

or danger.

Use the phone only in its normal operating positions.

Parts of the phone are magnetic. Metallic materials may be attracted to the phone,

and persons with a hearing aid should not hold the phone to the ear with the

hearing aid. Always secure the phone in its holder, because metallic materials may

be attracted by the earpiece. Do not place credit cards or other magnetic storage

media near the phone, because information stored on them may be erased.

Electronic devices

Most modern electronic equipment is shielded from radio frequency (RF) signals.

However, certain electronic equipment may not be shielded against the RF signals

from your wireless phone.

PACEMAKERS

Pacemaker manufacturers recommend that a minimum separation of 6-8 inches

(20 cm) be maintained between a hand-held wireless phone and a pacemaker to

avoid potential interference with the pacemaker. These recommendations are

consistent with the independent research by and recommendations of Wireless

Technology Research. Persons with pacemakers:

• Should always keep the phone more than 6 inches (20 cm) from their

pacemaker when the phone is switched on

• Should not carry the phone in a breast pocket

• Should use the ear opposite the pacemaker to minimize the potential for

interference.

• If you have any reason to suspect that interference is taking place, switch off

your phone immediately.

2220_2260.ENv1_9356390_.book Page 83 Wednesday, May 28, 2003 4:10 PM

Reference information

HEARING AIDS

Some digital wireless phones may interfere with some hearing aids. In the event of

such interference, you may want to consult your service provider.

Other medical devices

Operation of any radio transmitting equipment, including cellular phones, may

interfere with the functionality of inadequately protected medical devices. Consult

a physician or the manufacturer of the medical device to determine if they are

adequately shielded from external RF energy or if you have any questions. Switch off

your phone in health care facilities when any regulations posted in these areas

instruct you to do so. Hospitals or health care facilities may be using equipment that

could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems

in motor vehicles (for example, electronic fuel injection systems, electronic antiskid/

antilock braking systems, electronic speed control systems, air bag systems). Check with

the manufacturer or its representative regarding your vehicle. You should also consult

the manufacturer of any equipment that has been added to your vehicle.

POSTED FACILITIES

Switch your phone off in any facility where posted notices so require.

Potentially explosive atmospheres

Switch off your phone when in any area with a potentially explosive atmosphere

and obey all signs and instructions. Sparks in such areas could cause an explosion

or fire resulting in bodily injury or even death.

Users are advised to switch off the phone when at a refuelling point (service

station). Users are reminded of the need to observe restrictions on the use of radio

equipment in fuel depots (fuel storage and distribution areas), chemical plants, or

where blasting operations are in progress.

Areas with a potentially explosive atmosphere are often but not always clearly

marked. They include below deck on boats; chemical transfer or storage facilities;

vehicles using liquefied petroleum gas (such as propane or butane); areas where

the air contains chemicals or particles, such as grain, dust, or metal powders; and

any other area where you would normally be advised to turn off your vehicle engine.

Vehicles

Only qualified personnel should service the phone or install the phone in a vehicle.

Faulty installation or service may be dangerous and may invalidate any warranty

which may apply to the unit.

Check regularly that all wireless phone equipment in your vehicle is mounted and

operating properly.

2220_2260.ENv1_9356390_.book Page 84 Wednesday, May 28, 2003 4:10 PM

Do not store or carry flammable liquids, gases or explosive materials in the same

compartment as the phone, its parts or accessories.

For vehicles equipped with an air bag, remember that an air bag inflates with great

force. Do not place objects, including both installed or portable wireless equipment

in the area over the air bag or in the air bag deployment area. If in-vehicle wireless

equipment is improperly installed and the air bag inflates, serious injury could result.

FCC regulations prohibit using your phone while in the air. Switch off your phone

before boarding an aircraft. The use of wireless telephones in an aircraft may be

dangerous to the operation of the aircraft, disrupt the wireless telephone network,

and may be illegal.

Failure to observe these instructions may lead to suspension or denial of telephone

services to the offender, legal action or both.

• MAKE EMERGENCY CALLS

Important: This phone, like any wireless phone, operates using radio signals,

wireless, and landline networks as well as user-programmed functions.

Because of this, connections in all conditions cannot be guaranteed.

Therefore you should never rely solely upon any wireless phone for

essential communications (for example, medical emergencies).

Emergency calls may not be possible on all wireless phone networks or when

certain network services and/or phone features are in use. Check with local service

providers.

To make an emergency call

1If the phone is not on, switch it on, then check for adequate signal strength.

2Press the End key as many times as needed (for example, to exit a call, to exit

a menu, etc.) to clear the display and ready the phone for calls.

3Key in the emergency number for your present location (for example, 911 or

other official emergency number). Emergency numbers vary by location.

4Press the Talk key.

If certain features are in use, (keyguard, etc.) you may first need to turn those

features off before you can make an emergency call. Consult this user guide and

your local wireless service provider.

When making an emergency call, remember to give all the necessary information

as accurately as possible. Remember that your wireless phone may be the only

means of communication at the scene of an accident - do not end the call until

given permission to do so.

2220_2260.ENv1_9356390_.book Page 85 Wednesday, May 28, 2003 4:10 PM

Reference information

Certification Information (SAR)

THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE

TO RADIO WAVES.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured

not to exceed the emission limits for exposure to radio frequency (RF) energy set

by the Federal Communications Commission of the U.S. Government. These limits

are part of comprehensive guidelines and establish permitted levels of RF energy

for the general population. The guidelines are based on standards that were

developed by independent scientific organizations through periodic and thorough

evaluation of scientific studies. The standards include a substantial safety margin

designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless mobile phones employs a unit of measurement

known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is

1.6W/kg.* Tests for SAR are conducted using standard operating positions accepted

by the FCC with the phone transmitting at its highest certified power level in all

tested frequency bands. Although the SAR is determined at the highest certified

power level, the actual SAR level of the phone while operating can be well below

the maximum value. This is because the phone is designed to operate at multiple

power levels so as to use only the power required to reach the network. In general,

the closer you are to a wireless base station antenna, the lower the power output.

Before a phone model is available for sale to the public, it must be tested and

certified to the FCC that it does not exceed the limit established by the government-

adopted requirement for safe exposure. The tests are performed in positions and

locations (for example, at the ear and worn on the body) as required by the FCC for

each model. The highest SAR value for this model phone as reported to the FCC:

When tested for use at the ear -

FCCID # GMLRH-40 is 1.23 W/kg

FCCID # GMLRH-39 is 1.08 W/kg

When worn on the body, as described in this user guide:

FCCID # GMLRH-40 is 1.18W/kg

FCCID # GMLRH-39 is 0.96 W/kg

(Body-worn measurements differ among phone models, depending upon available

accessories and FCC requirements).

While there may be differences between the SAR levels of various phones and at

various positions, they all meet the government requirement.

2220_2260.ENv1_9356390_.book Page 86 Wednesday, May 28, 2003 4:10 PM

The FCC has granted an Equipment Authorization for this model phone with all

reported SAR levels evaluated as in compliance with the FCC RF exposure

guidelines. SAR information on this model phone is on file with the FCC and can

be found under the Display Grant section of http://www.fcc.gov/oet/fccid after

searching on FCC ID GMLRH-40 and GMLRH-39.

For body worn operation, this phone has been tested and meets the FCC RF

exposure guidelines for use with an accessory that contains no metal and that

positions the handset a minimum of 5/8 inch (1.5 cm) from the body. Use of other

accessories may not ensure compliance with FCC RF exposure guidelines. If you do

not use a body-worn accessory and are not holding the phone at the ear, position

the handset a minimum of 5/8 inch (1.5 cm) from your body when the phone is

switched on.

*In the United States and Canada, the SAR limit for mobile phones used by the

public is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard

incorporates a substantial margin of safety to give additional protection for the

public and to account for any variations in measurements. SAR values may vary

depending on national reporting requirements and the network band. For SAR

information in other regions please look under product information at

www.nokia.com/us.

2220_2260.ENv1_9356390_.book Page 87 Wednesday, May 28, 2003 4:10 PM

Reference information

• ACCESSORY SAFETY

This section provides information about the phone’s batteries, chargers, and

accessories. Be aware that the information in this section is subject to change

as the batteries, chargers, and accessories change.

Check the model number of any charger before use with this phone. This device is

intended for use when supplied with power from an ACP-7, ACP-8, ACP-12 or

LCH-9 charger.

Warning: Use only Nokia original accessories or batteries, chargers, and

accessories approved by Nokia, for use with this Nokia phone model. The

use of any other types may invalidate any approval or warranty applying

to the phone, and may be dangerous.

For availability of approved accessories, please check with your dealer.

When you disconnect the power cord of any accessory, grasp and pull the plug, not

the cord.

When you are not using a charger, disconnect it from the power source.

When the battery is running out of power and your phone only has a few minutes

of talk time remaining, a warning tone sounds and the Battery low message appears

briefly. When no more talk time is left, a warning tone is sounded and the phone

switches itself off.

Practical rules for accessory operation

• Keep all accessories out of reach of small children.

• When you disconnect the power cord of any accessory, grasp and pull the plug,

not the cord.

• Check regularly that any vehicle-installed accessories are mounted and are

operating properly.

• Installation of any complex car accessories must be made by qualified

personnel only.

• Use only batteries, chargers, and accessories that have been approved by the

phone manufacturer. The use of any other types could invalidate any approval or

warranty applying to the phone and could be dangerous. Refer to “Accessory

safety” on page 88 for important battery usage information.

2220_2260.ENv1_9356390_.book Page 88 Wednesday, May 28, 2003 4:10 PM

Batteries

This section provides information about the phone’s battery. Be aware that the

information in this section is subject to change.

Note: Dispose of used batteries in accordance with any local regulations.

The tables shown in this section provide information about the batteries that are

available for your phone, charging times with the Rapid Travel Charger (ACP-8 and

ACP-12), the Standard Travel Charger (ACP-7), talk times, and standby times.

Consult your service provider for more information.

Charging times

The charging times listed below are approximate.

Standby and talk times

Battery talk and standby times are estimates only and depend on signal strength,

network conditions, features used, battery age and condition (including the effect

of charging habits), temperatures to which the battery is exposed, use in digital

mode, and many other factors. Please note that the amount of time a phone is used

for calls will affect its standby time. Likewise, the amount of time that the phone

is turned on and in standby mode will affect its talk time.

Battery option ACP-7

Charger

ACP-8

Charger

ACP-12

Charger

BMC-3 NiMH Battery 900 mAh up to 4 hours up to 2 hours up to 1 hour,

40 minutes

Battery

option Talk time Standby Time

Digital Analog Digital Analog

BMC-3 NiMH

Battery 900 mAh

up to 5 hours up to 2 hours up to 15 days up to

2 days

BLC-2 Li-Ion

Battery 950 mAh

up to 5 hours up to 2 hours up to 16 days up to

2 days

2220_2260.ENv1_9356390_.book Page 89 Wednesday, May 28, 2003 4:10 PM

Reference information

• ACCESSORIES

If you want to enhance the functionality of your phone, a

range of accessories is available for you. You can select

any of these items to help accommodate your specific

communication needs. For availability of these and other

accessories, contact your service provider.

Warning: Use only Nokia original accessories, or batteries, chargers and

accessories approved by Nokia, for use with this Nokia phone model. The

use of any other types may invalidate any approval or warranty applying

to the phone, and may be dangerous.

900 mAh NiMH Battery (BMC-3)

Provides up to 5 hours of digital talk time and up to 15 days

of digital standby time. Provides up to 2 hours of analog talk

time and up to 2 days of analog standby time.

Note: Operation times are estimates and may vary

depending on network conditions, charging and

phone use.

950 mAh Li-Ion Battery (BLC-2))

Provides up to 5 hours of digital talk time and up

to 16 days of digital standby time. Provides up to

2 hours of analog talk time and up to 2 days of

analog standby time.

Note: Operation times are estimates and may vary

depending on network conditions, charging and

phone use.

2220_2260.ENv1_9356390_.book Page 90 Wednesday, May 28, 2003 4:10 PM

Standard Travel Charger (ACP-7)

The Standard Travel Charger is a lightweight (187 g)

and durable AC charger.

To use the Standard Travel Charger, plug it into a

standard 120 V AC wall outlet and connect the

lead from the charger to the base of your phone.

Note: If the battery is completely empty,

you cannot use the phone until it has

enough charge to operate.

Rapid Travel Charger (ACP-8)

The Rapid Travel Charger is a lightweight (100 g) and

durable AC charger. Calls can be made during charging,

even with a fully discharged battery.

To use the Rapid Travel Charger (ACP-8), plug it into a

standard 120- or 220-Vac wall outlet, and connect the

lead from the charger to the base of your phone.

Approximate charging times for discharged batteries are

shown in “Charging times” on page 89.

Rapid Travel Charger (ACP-12)

The Rapid Travel Charger is a lightweight and

durable AC charger. Calls can be made during

charging, even with a fully discharged battery.

To use the Rapid Travel Charger (ACP-12), plug

it into a standard 120- or 220-Vac wall outlet,

and connect the lead from the charger to the

base of your phone.

2220_2260.ENv1_9356390_.book Page 91 Wednesday, May 28, 2003 4:10 PM

Reference information

Rapid Cigarette Lighter Charger (LCH-9)

You can charge your phone’s battery from your

vehicle battery by using the Rapid Cigarette

Lighter Charger (LCH-9).

Calls are possible during charging. A green light

indicates that the charger is ready for charging.

The battery charging times are the same as those

for the Rapid Travel Charger (ACP-8).

The input voltage range is from 11-24 Vdc, negative grounding. Avoid prolonged

charging with the Rapid Cigarette Lighter Charger (LCH-9) when the car engine is

not running; this could cause your car battery to drain. Note also, that in some cars,

the cigarette lighter plug is not provided with electricity if the ignition is not

switched on.

Spare Battery Charger (DDC-1)

Lightweight and stylish, this charger provides a

convenient way to charge your spare battery.

This charger is compatible with the Standard

Travel Charger (ACP-7) and the Rapid Travel

Charger (ACP-8).

Headset (HDC-5)

Small and lightweight, the headset allows easy and convenient

hands-free operation. The headset has a foam earpiece cover for

a comfortable fit and has a clip to hold it firmly in place. This

headset’s 4-wire 2.5 mm plug fits directly into the bottom of the

phone. A remote control button located in the microphone

makes the headset convenient to use while answering or

receiving calls.

2220_2260.ENv1_9356390_.book Page 92 Wednesday, May 28, 2003 4:10 PM

Headset (HDE-2)

Small and lightweight, the headset allows easy and convenient

hands-free operation. This headset comes with a clip for a

comfortable fit. This headset’s 4-wire 2.5 mm plug fits directly

into the bottom of your phone.

Boom Headset (HDB-5)

Compact and functional, the Boom Headset provides you with

convenient, portable hands-free facility. A new and modern

“over the ear” concept with a stylish design and basic hands-free

functionality, including the answer/end button.

This headset’s 4-wire 2.5 mm plug fits directly into the bottom

of your phone.

Retractable Headset Kit

(HDC-10)

Compact and functional, this headset provides

you with convenient, portable, hands-free

operation. The retractable mechanism and

remote control provide easy operation.

2220_2260.ENv1_9356390_.book Page 93 Wednesday, May 28, 2003 4:10 PM

Reference information

Loopset (LPS-3)

With the Nokia Loopset, people who use a T-coil

equipped hearing aid have the freedom to talk on a

digital mobile phone. The loopset goes around your

neck - so it can be worn comfortably and discreetly.

TTY/TDD Adapter (HDA-9)

The TTY/TDD Adapter is a Nokia accessory that

allows you to connect your mobile phone to

a Telecommunications Device for the Deaf

(TTY/TDD) to make a call in digital mode.

WHAT YOU’LL NEED

Here is what you’ll need for TTY/TDD

communication.

• A TTY/TDD device that is “cellular ready”

or “cellular compatible”

• A cable for connecting the TTY/TDD to

your phone, usually supplied by the

manufacturer of the TTY/TDD device.

• The TTY/TDD Adapter (HDA-9), which can be purchased separately as an

accessory at www.nokia.com/us.

Mobile Holder (MBC-6)

Small and easy to use, the Mobile Holder provides an

ideal place to hold the phone in a vehicle. The Mobile

Holder is easy to attach to the dashboard via a mounting

plate or swivel. The Mobile Holder is compatible with the

Rapid Cigarette Lighter Charger (LCH-9) and the Express

Car Kit (PPH-1).

TTY/TDD

Adapter

2220_2260.ENv1_9356390_.book Page 94 Wednesday, May 28, 2003 4:10 PM

Express Car Kit

(CARK-125)

This car kit provides charging and hands-

free functionality. With excellent audio

quality, the car kit is easy to use and is

compatible with 12 V systems.

The Express Car Kit includes a holder and

plug-in, hands-free, external microphone.

Express Car Kit (PPH-1)

The Express Car Kit provides charging and hands-free

functionality. Compatible with 12 V systems, the

Express Car Kit plugs into the cigarette lighter socket

for charging. A green light indicates readiness for

charging. The Express Car Kit has a built in speaker

and uses the phone’s microphone. The Express Car Kit

also has a connector for an optional external

microphone (HFM-8). The microphone should be

installed 20 inches apart from the external speaker.

The Express Car Kit requires no screws for installation

and thus can be moved easily from car to car.

2220_2260.ENv1_9356390_.book Page 95 Wednesday, May 28, 2003 4:10 PM

Reference information

Full Car Kit

(CARK-134)

The Full Car Kit (CARK-134) offers

a convenient hands-free option,

automatic charging facility,

transmission capacity with external

antenna connection and car radio

mute.

The Full Car Kit contains the

following:

• HHS-9 Swivel Mount

• HFU-5 Junction Box

• MKU-1 Mounting Plate

• HFM-8 Handsfree Microphone

• HFS-12 External Handsfree Speaker

•PCH-4J Power Cable

Nokia Xpress-on™ color covers

The Xpress-on™ cover is available in several fashion colors. Extra covers may be

purchased from your authorized Nokia dealer.

Note: Before changing the cover, always switch off the power and disconnect

the phone from the charger or any other device. Always store the phone

with covers attached.

REMOVE THE BACK COVER

1Switch off the power and disconnect the phone from the charger or any

other device.

2Push in the release button on the back of the phone, slide the cover toward

the top of the phone, and remove it.

REMOVE THE FRONT COVER

1Use the finger rests on each side of the phone and hold the phone face down.

2While holding the phone, place your finger on the grove between the phone

and the cover.

3Gently pry the front cover away from the phone and lift the phone out of

2220_2260.ENv1_9356390_.book Page 96 Wednesday, May 28, 2003 4:10 PM

the cover.

REMOVE THE KEYPAD

1Lift the keypad from the inside of the front cover.

2Place the keypad into the new front cover.

REPLACE THE FRONT COVER

1Slide the top of the phone into the top of the front cover.

Be careful to align the power key/IR port with its place in the top of the

front cover.

2Gently push the bottom of the phone into the bottom of the front cover until

it snaps into place.

REPLACE THE BACK COVER

1Insert the two catches of the back cover in the corresponding slots in the phone.

2Slide the cover towards the bottom of the phone until it locks into place.

• TECHNICAL INFORMATION

Feature Specification

Weight 4.23 oz with BLC-2 battery

5.17 oz with BMC-3 battery

Volume 108 cc

Frequency Range

Lowband

824.04 - 848.97 MHz (TX)

869.04 - 893.97 MHz (RX)

Highband

1850.04 - 1909.92 MHz (TX)

1930.08 - 1989.96 MHz (RX)

Transmitter Output Power Up to 600 mW

Battery Voltage 3.6 V nominal

Operating Temperature -4°F to + 104°F

(-20°C to + 40°C)

2220_2260.ENv1_9356390_.book Page 97 Wednesday, May 28, 2003 4:10 PM

Reference information

Number of Channels 832 lowband

1997 highband

Phone Numbers Up to 3

Contact List Locations Up to 200

Feature Specification

2220_2260.ENv1_9356390_.book Page 98 Wednesday, May 28, 2003 4:10 PM

• TROUBLESHOOTING

This section lists some of the most commonly encountered problems and provides

possible solutions.

Problem Possible cause Possible solution

My phone is not

charging.

The charger and the phone are not

properly connected.

Securely connect the

charger to the phone.

The charger is not properly

plugged in.

Ensure that the charger

is plugged in correctly.

My phone is not

making or

answering calls.

The battery is not charged. Charge the battery.

The signal strength is too low. If you are indoors, move

toward a window.

I cannot listen to

my voice

messages.

You do not have voice mail service. This is a service provider

dependent feature.

Please call your wireless

service provider.

The voice mail number you have

saved is incorrect.

You have forgotten your password

or are entering in incorrectly.

Your voice mail number is not

saved in the phone.

Refer to “Save the voice

mailbox number” on

page 38.

2220_2260.ENv1_9356390_.book Page 99 Wednesday, May 28, 2003 4:10 PM

Reference information

Nokia One-Year Limited Warranty

Nokia Inc. (“Nokia”) warrants that this cellular phone (“Product”) is free from

defects in material and workmanship that result in Product failure during normal

usage, according to the following terms and conditions:

1The limited warranty for the Product extends for ONE (1) year beginning on the

date of the purchase of the Product. This one year period is extended by each

whole day that the Product is out of your possession for repair under this

warranty.

2The limited warranty extends only to the original purchaser (“Consumer”) of the

Product and is not assignable or transferable to any subsequent purchaser/

end-user.

3The limited warranty extends only to Consumers who purchase the Product in

the United States of America.

4During the limited warranty period, Nokia will repair, or replace, at Nokia’s sole

option, any defective parts, or any parts that will not properly operate for their

intended use with new or refurbished replacement items if such repair or

replacement is needed because of product malfunction or failure during

normal usage. No charge will be made to the Consumer for any such parts.

Nokia will also pay for the labor charges incurred by Nokia in repairing or

replacing the defective parts. The limited warranty does not cover defects in

appearance, cosmetic, decorative or structural items, including framing, and

any non-operative parts. Nokia’s limit of liability under the limited warranty

shall be the actual cash value of the Product at the time the Consumer returns

the Product for repair, determined by the price paid by the Consumer for the

Product less a reasonable amount for usage. Nokia shall not be liable for any

other losses or damages. These remedies are the Consumer’s exclusive

remedies for breach of warranty.

5Upon request from Nokia, the Consumer must prove the date of the original

purchase of the Product by a dated bill of sale or dated itemized receipt.

6The Consumer shall bear the cost of shipping the Product to Nokia in

Melbourne, Florida. Nokia shall bear the cost of shipping the Product back to

the Consumer after the completion of service under this limited warranty.

7The Consumer shall have no coverage or benefits under this limited warranty

if any of the following conditions are applicable:

a) The Product has been subjected to abnormal use, abnormal conditions,

improper storage, exposure to moisture or dampness, unauthorized

modifications, unauthorized connections, unauthorized repair, misuse,

neglect, abuse, accident, alteration, improper installation, or other acts

which are not the fault of Nokia, including damage caused by shipping.

2220_2260.ENv1_9356390_.book Page 100 Wednesday, May 28, 2003 4:10 PM

b) The Product has been damaged from external causes such as collision

with an object, or from fire, flooding, sand, dirt, windstorm, lightning,

earthquake or damage from exposure to weather conditions, an Act of

God, or battery leakage, theft, blown fuse, or improper use of any

electrical source, damage caused by computer or internet viruses, bugs,

worms, Trojan Horses, cancelbots or damage caused by the connection to

other products not recommended for interconnection by Nokia.

c) Nokia was not advised in writing by the Consumer of the alleged defect

or malfunction of the Product within fourteen (14) days after the

expiration of the applicable limited warranty period.

d) The Product serial number plate or the accessory data code has been

removed, defaced or altered.

e) The defect or damage was caused by the defective function of the cellular

system or by inadequate signal reception by the external antenna, or

viruses or other software problems introduced into the Product.

8Nokia does not warrant uninterrupted or error-free operation of the Product.

If a problem develops during the limited warranty period, the Consumer shall

take the following step-by-step procedure:

a) The Consumer shall return the Product to the place of purchase for repair

or replacement processing.

b) If “a” is not convenient because of distance (more than 50 miles) or for

other good cause, the Consumer shall ship the Product prepaid and

insured to:

Nokia Inc., Attn: Repair Department

795 West Nasa Blvd.

Melbourne, FL 32901

c) The Consumer shall include a return address, daytime phone number and/

or fax number, complete description of the problem, proof of purchase

and service agreement (if applicable). Expenses related to removing the

Product from an installation are not covered under this limited warranty.

d) The Consumer will be billed for any parts or labor charges not covered by

this limited warranty. The Consumer will be responsible for any expenses

related to reinstallation of the Product.

e) Nokia will repair the Product under the limited warranty within 30 days

after receipt of the Product. If Nokia cannot perform repairs covered under

this limited warranty within 30 days, or after a reasonable number of

attempts to repair the same defect, Nokia at its option, will provide a

replacement Product or refund the purchase price of the Product less a

reasonable amount for usage. In some states the Consumer may have the

right to a loaner if the repair of the Product takes more than ten (10) days.

2220_2260.ENv1_9356390_.book Page 101 Wednesday, May 28, 2003 4:10 PM

Reference information

Please contact the Customer Service Center at Nokia at the telephone

number listed at the end of this warranty if you need a loaner and the

repair of the Product has taken or is estimated to take more than ten

(10) days.

f) If the Product is returned during the limited warranty period, but the

problem with the Product is not covered under the terms and conditions

of this limited warranty, the Consumer will be notified and given an

estimate of the charges the Consumer must pay to have the Product

repaired, with all shipping charges billed to the Consumer. If the estimate

is refused, the Product will be returned freight collect. If the Product is

returned after the expiration of the limited warranty period, Nokia’s

normal service policies shall apply and the Consumer will be responsible for

all shipping charges.

9You (the Consumer) understand that the product may consist of refurbished

equipment that contains used components, some of which have been

reprocessed. The used components comply with Product performance and

reliability specifications.

10 ANY IMPLIED WARRANTY OF MERCHANTABILITY, OR FITNESS FOR A PARTICULAR

PURPOSE OR USE, SHALL BE LIMITED TO THE DURATION OF THE FOREGOING

LIMITED WRITTEN WARRANTY. OTHERWISE, THE FOREGOING LIMITED

WARRANTY IS THE CONSUMER’S SOLE AND EXCLUSIVE REMEDY AND IS IN

LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. NOKIA SHALL NOT BE

LIABLE FOR SPECIAL, INCIDENTAL, PUNITIVE OR CONSEQUENTIAL DAMAGES,

INCLUDING BUT NOT LIMITED TO LOSS OF ANTICIPATED BENEFITS OR PROFITS,

LOSS OF SAVINGS OR REVENUE, LOSS OF DATA, PUNITIVE DAMAGES, LOSS OF

USE OF THE PRODUCT OR ANY ASSOCIATED EQUIPMENT, COST OF CAPITAL,

COST OF ANY SUBSTITUTE EQUIPMENT OR FACILITIES, DOWNTIME, THE

CLAIMS OF ANY THIRD PARTIES, INCLUDING CUSTOMERS, AND INJURY TO

PROPERTY, RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR

ARISING FROM BREACH OF THE WARRANTY, BREACH OF CONTRACT,

NEGLIGENCE, STRICT TORT, OR ANY OTHER LEGAL OR EQUITABLE THEORY,

EVEN IF NOKIA KNEW OF THE LIKELIHOOD OF SUCH DAMAGES. NOKIA SHALL

NOT BE LIABLE FOR DELAY IN RENDERING SERVICE UNDER THE LIMITED

WARRANTY, OR LOSS OF USE DURING THE PERIOD THAT THE PRODUCT IS

BEING REPAIRED.

11 Some states do not allow limitation of how long an implied warranty lasts, so

the one year warranty limitation may not apply to you (the Consumer). Some

states do not allow the exclusion or limitation of incidental and consequential

damages, so certain of the above limitations or exclusions may not apply to you

(the Consumer). This limited warranty gives the Consumer specific legal rights

and the Consumer may also have other rights which vary from state to state.

2220_2260.ENv1_9356390_.book Page 102 Wednesday, May 28, 2003 4:10 PM

12 Nokia neither assumes nor authorizes any authorized service center or any

other person or entity to assume for it any other obligation or liability beyond

that which is expressly provided for in this limited warranty including the

provider or seller of any extended warranty or service agreement.

13 This is the entire warranty between the Nokia and the Consumer, and

supersedes all prior and contemporaneous agreements or understandings, oral or

written, relating to the Product, and no representation, promise or condition

not contained herein shall modify these terms.

14 This limited warranty allocates the risk of failure of the Product between the

Consumer and Nokia. The allocation is recognized by the Consumer and is

reflected in the purchase price.

15 Any action or lawsuit for breach of warranty must be commenced within

eighteen (18) months following purchase of the Product.

16 Questions concerning this limited warranty may be directed to:

Nokia Inc.

Attn: Customer Service

7725 Woodland Center Blvd., Ste. 150

Tampa, FL 33614

Telephone: 1-888-NOKIA-2U (1-888-665-4228)

Facsimile: (813) 287-6612

TTY/TDD Users Only: 1-800-24-NOKIA (1-800-246-6542)

17 The limited warranty period for Nokia supplied attachments and accessories is

specifically defined within their own warranty cards and packaging.

Manufactured or sold under one or more of the following US patents:

5001372 5371481 5553125 5805084 5893060 6006114 6119002 6229996

5045973 5390223 5594797 5819165 5903839 6026161 6119003 6269331

5101175 5400949 5604921 5822366 5907823 6035194 6128509 6282373

5124672 5416435 5606548 5835858 5914796 6043760 6144243 6285888

5212834 5430740 5613235 5839101 5920826 6049796 6151485 6286122

5230091 5442521 5625274 5842141 5924026 6055439 6151507 6292668

5233634 5446364 5677620 5844884 5924038 6060193 6154457 6308084

5241284 5471655 5692032 5845219 5953665 6084962 6163609 6310609

5241583 5479476 5697074 5857151 5956625 6094587 6164547 6311054

5266782 5487084 5734683 5870683 5987406 6097961 6185295 6314166

5317283 5493255 5760568 5887262 5987639 6097964 6188909 6324412

5335362 5551067 5794142 5892475 5999523 6115617 6219560

Pending: 29158527 29158526 29158528 29158485 29158529 29158524

2220_2260.ENv1_9356390_.book Page 103 Wednesday, May 28, 2003 4:10 PM

Reference information

NOTES

2220_2260.ENv1_9356390_.book Page 104 Wednesday, May 28, 2003 4:10 PM

Appendix A

Message from the CTIA

(Cellular Telecommunications

& Internet Association)

to all users of mobile phones.

2220_2260.ENv1_9356390_.book Page 105 Wednesday, May 28, 2003 4:10 PM

A Guide to Safe and Responsible Wireless Phone Use

Wireless Phone "Safety Tips"

2220_2260.ENv1_9356390_.book Page 106 Wednesday, May 28, 2003 4:10 PM

2220_2260.ENv1_9356390_.book Page 107 Wednesday, May 28, 2003 4:10 PM

2220_2260.ENv1_9356390_.book Page 108 Wednesday, May 28, 2003 4:10 PM

Appendix B

Message from the FDA

(U.S. Food and Drug

Administration)

to all users of mobile phones.

2220_2260.ENv1_9356390_.book Page 109 Wednesday, May 28, 2003 4:10 PM

Consumer Update on Wireless Phones

U.S. Food and Drug Administration

1. Do wireless phones pose a health hazard?

2. What is FDA’s role concerning the safety of wireless phones?

2220_2260.ENv1_9356390_.book Page 110 Wednesday, May 28, 2003 4:10 PM

3. What kinds of phones are the subject of this update?

4. What are the results of the research done already?

2220_2260.ENv1_9356390_.book Page 111 Wednesday, May 28, 2003 4:10 PM

5. What research is needed to decide whether RF exposure from

wireless phones poses a health risk?

6. What is FDA doing to find out more about the possible health effects

of wireless phone RF?

7. How can I find out how much radiofrequency energy exposure I can

get by using my wireless phone?

2220_2260.ENv1_9356390_.book Page 112 Wednesday, May 28, 2003 4:10 PM

8. What has FDA done to measure the radiofrequency energy coming

from wireless phones?

9. What steps can I take to reduce my exposure to radiofrequency

energy from my wireless phone?

10. What about children using wireless phones?

2220_2260.ENv1_9356390_.book Page 113 Wednesday, May 28, 2003 4:10 PM

11. What about wireless phone interference with medical equipment?

12. Where can I find additional information?

2220_2260.ENv1_9356390_.book Page 114 Wednesday, May 28, 2003 4:10 PM

Index

accessibility

loopset 15

web site 15

accessories

boom headset (HDB-5) 93

car kit (PPH-1) 95

charger (ACP-12) 91

charger (ACP-7) 91

charger (ACP-8) 91

charger (LCH-9) 92

headset (HDC-5) 92

headset (HDE-2) 93

mobile holder (MBC-6) 94

reference information 90

safety information 88

settings 50

spare battery charger (DDC-1) 92

accessory

TTY adapter 94

active call options 54

alarm clock 69

phone off 69

set 69

snooze 69

turn off 69

analog selection 65

antenna

contact 10

location 10

performance 10

proper position 10

automatic redial 60

back cover

attaching 11

removing 11

battery

charging 12

charging time 89

important information 12

initial charging 12

install 10

prolong life 13

reference information 88

remove 11

standby time 89

talk time 89

business cards 71

delete 72

receive 71

save 71

send 71

calculator 70

call duration

viewing 37

call forwarding 57

activate 58

feature codes 57

call log

about 35

clear lists 36

dialed calls 36

missed calls 36

options 35

2220_2260.ENv1_9356390_.book Page 115 Wednesday, May 28, 2003 4:10 PM

received calls 36

call timers 37

clear timers 37

current call timer 37

call waiting 58

activate 58

answer 59

feature code 58

manage calls 59

storing the feature code 58

calls

answer 18

automatic redial 60

conference 55

duration of 37

end 18

forward 57

make 17

redial last 18

silence 18

speed dialing 61

touch tones 61

car charger 92

car kit 95

automatic answer 51

default profile 51

set the lights 51

change

1-touch dialing numbers 61

contact list view 34

earpiece volume 18

letter case 27

message alert tone 49

profile name 50

ringing tone 48

ringing volume 49

security code 67

time format 52

charge the battery 12

charger

ACP-12 91

ACP-7 91

ACP-8 91

connecting 12

information 88

clear call lists 36

clock 52

alarm 69

automatic update 52

set the time 52

show/hide 53

time format 52

color covers 96

conference calls 55

contact list

delete entries 33

enter e-mail addresses 32

memory status 34

menu 25

menu options 25

new entry 32

quick access 18

scrolling view 34

contact Nokia 14

cover

attaching 11

removing 11

currency conversion 70

customer care 14

delete

call lists 36

contact list entries 33

2220_2260.ENv1_9356390_.book Page 116 Wednesday, May 28, 2003 4:10 PM

messages from folders 41

text messages 43

dialed calls

deleting 36

viewing 36

digital selection 65

display language 52

download

ringing tones 72

e-mail messages 45

emergency calls

making 85

things to remember 85

with keypad locked 66

entering

e-mail addresses 32

names and numbers 31

text 26

folders

about 41

archive 41

delete messages from 41

inbox 41

outbox 41

four-way scrolling 28

games 76

Pairs II 77

Snake II 77

Space Impact 77

headset

connect 13

HDB-5 93

HDC-5 92

HDE-2 93

make and answer calls 13

hearing impaired solutions 15

help text 20

icons 20

illustrated view

antenna 10

battery install 10

battery removal 11

connect the charger 12

headset connection 13

phone 10

power key 17

in-call options 54

in-phone help 20

Keyguard 66

keypad

illustrated view 10

label 14

language setting 52

letters

uppercase and lowercase 27

lithium ion battery 90

lock/unlock the keypad 66

loopset 15

how it works 15

set for use 51

2220_2260.ENv1_9356390_.book Page 117 Wednesday, May 28, 2003 4:10 PM

memory

contact list 34

text message 43

menu shortcuts

about 21

list of 22

menu tips 21

menus 21

messages

alert tone 49

check voice mail 38

e-mail 45

picture 44

text 42

text entry 26

write and send 42

Minute Manager 78

missed calls

deleting 36

viewing 36

mobile holder 94

network search 64

network services 9

Nokia

accessories 90

customer care center 14

warranty 100

one-touch dialing 61

personalization 47

phone

illustrated 4

menus 21

switch on/off 17

warranty 100

picture messages 44

power 17

predictive text 29

turn off 29

turn on 29

prepaid 73

add money to account 74

check balance 73

saving access numbers 74

profiles

accessory settings 50

customize 48

selecting 47

punctuation 28

received calls

deleting 36

viewing 36

reference information 81

ringing

options 48

tone 48

volume 49

ringing tones

change 48

download 72

receiving 72

save 72

2220_2260.ENv1_9356390_.book Page 118 Wednesday, May 28, 2003 4:10 PM

save

e-mail addresses 32

names and numbers 31

ringing tones 72

text messages 41

voice mailbox number 38

search for network 64

security code 67

service provider

signing up 9

special characters

available 28

four-way scrolling 28

standby time 89

start screen 19

strings, touch tone 63

symbols 28

talk time 89

text clues 6

text messages 42

length 39

recipients 39

time 52

automatic update 52

select the format 52

set the clock 52

timers

check 37

clear 37

current call 37

touch tones

length 62

manual 62

sending 63

setting 61

storing 63

storing with numbers 63

troubleshooting 99

TTY 15

TTY adapter 94

TTY communication 94

turn the phone on/off 17

unlock the keypad 66

user guide

updates 6

user guide conventions 6

vibrating alert 49

view

call duration 37

clock on start screen 53

dialed calls 36

missed calls 36

picture messages 45

received calls 36

received messages 42

special characters 28

voice mail 38

listen to messages 39

messages 38

save number 38

volume

earpiece 18

keypad tones 50

ringing 49

warning tones 50

2220_2260.ENv1_9356390_.book Page 119 Wednesday, May 28, 2003 4:10 PM

warranty 100

web sites

accessibility information 15

write and send a message 42

Xpress-on color covers 96

NOTES

2220_2260.ENv1_9356390_.book Page 120 Wednesday, May 28, 2003 4:10 PM

NOTES

2220_2260.ENv1_9356390_.book Page 121 Wednesday, May 28, 2003 4:10 PM

NOTES

Para obtener un manual del usuario en español favor de

llamar o enviar un fax al teléfono 1-888-NOKIA-2U,

fax 813-249-9619.

2220_2260.ENv1_9356390_.book Page 122 Wednesday, May 28, 2003 4:10 PM

Microsoft RH-40 Single Band, Dual Mode Cellular Phone User Manual Revised

Microsoft Mobile Oy Single Band, Dual Mode Cellular Phone Users Manual Revised

Users Manual Revised

Navigation menu

Namespaces

Views

Navigation
