Nokia E70 User Guide
9242084
Issue 1
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 1 Dec 22, 2005 4:45:59 AM
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product RM-24 is in conformity with the provisions
of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found from www.nokia.com/
phones/declaration_of_conformity/.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada
can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device
complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference. Any changes or modifications
not expressly approved by Nokia could void the user's authority to operate this equipment.
Copyright © 2005 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is
prohibited.
Nokia, Nokia Connecting People, Xpress-on and Pop-Port are trademarks or registered trademarks of Nokia Corporation. Other product and company names
mentioned herein may be trademarks or tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
This product includes software licensed from Symbian Software Ltd (c) 1998-2004. Symbian and Symbian OS are trademarks of Symbian Ltd.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C) 1997-2004. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has
been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection
with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that
related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this
document without prior notice.
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 2 Dec 22, 2005 4:45:59 AM
Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever
caused.
The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either express or implied, including, but
not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of
this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice
The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.
EXPORT CONTROLS
This device may contain commodities, technology, or software subject to export laws and regulations from the US and other countries. Diversion contrary to
law is prohibited.
9242084/Issue 1
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 3 Dec 22, 2005 4:45:59 AM
Contents
For your safety..................................................................7
About your device........................................................................8
NETWORK SERVICES.......................................................................8
Enhancements, batteries, and chargers................................8
Get started..........................................................................9
Charge the battery.......................................................................9
Enter basic settings......................................................................9
CD-ROM.............................................................................................9
Get started (part 2).......................................................10
Insert the SIM card and battery.............................................10
Insert a memory card...............................................................11
Switch on your device..............................................................12
Your device......................................................................13
Settings.........................................................................................13
Menu..............................................................................................13
Help and tutorial........................................................................13
Scroll and make selections......................................................14
Common actions in several applications............................14
Write text.....................................................................................15
Your device (part 2)......................................................17
Keys and parts.............................................................................17
Keypad lock (Keyguard)...........................................................19
Volume control...........................................................................19
Connectors...................................................................................20
Type label.....................................................................................20
Antennas.......................................................................................20
About the display.......................................................................21
Standby modes...........................................................................21
Display regions...........................................................................22
Display indicators.......................................................................23
Memory.........................................................................................24
Transfer content between devices.......................................25
Make calls.........................................................................27
Speed dial.....................................................................................27
Answer a call...............................................................................28
Forward calls...............................................................................28
Call restriction.............................................................................28
Log..................................................................................................29
Push to talk..................................................................................29
Voice over IP................................................................................33
Phone security ...........................................................................33
Contacts............................................................................36
Manage contact groups...........................................................36
Manage default information..................................................36
Copy contacts between SIM and device memory............37
Select ringing tones for contacts..........................................37
Business cards.............................................................................37
Messages..........................................................................39
Messaging folders......................................................................39
Messaging settings....................................................................40
Text messages............................................................................40
Multimedia messages...............................................................42
E-mail messages.........................................................................45
Contents
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 4 Dec 22, 2005 4:45:59 AM
Instant messaging.....................................................................50
Special messages.......................................................................53
Sync e-mail...................................................................................53
Camera..............................................................................54
Take a picture.............................................................................54
Record a video clip....................................................................54
Camera settings..........................................................................54
Connectivity.....................................................................56
Cable connection........................................................................56
Wireless local area network (WLAN)....................................56
Mobile VPN ..................................................................................57
Bluetooth......................................................................................57
SIM access profile.......................................................................60
Infrared.........................................................................................61
Modem..........................................................................................61
Data connections.......................................................................62
Connection manager................................................................62
Web....................................................................................64
Set preferences for browsing.................................................64
Bookmarks...................................................................................65
News feeds and blogs..............................................................66
Web in applications..................................................................66
Services.............................................................................67
Internet access points..............................................................67
Media applications........................................................69
Gallery............................................................................................69
RealPlayer ....................................................................................70
Music player.................................................................................72
Voice recorder.............................................................................73
Flash player..................................................................................73
Office applications.........................................................77
File manager................................................................................77
Documents...................................................................................77
Sheet..............................................................................................79
Presentation................................................................................80
Screen export..............................................................................82
Zip Manager.................................................................................83
Print................................................................................................83
Settings.............................................................................84
Phone settings............................................................................84
Call settings..................................................................................85
Connection settings..................................................................86
Date and time settings.............................................................91
Security settings.........................................................................91
Enhancement settings..............................................................91
Organiser..........................................................................92
Calendar........................................................................................92
Notes..............................................................................................93
Calculator......................................................................................93
Converter......................................................................................94
Clock...............................................................................................94
Tools..................................................................................96
Positioning...................................................................................96
Navigator......................................................................................96
Landmarks....................................................................................96
Voice commands........................................................................97
Activation Keys...........................................................................98
Application manager................................................................98
Contents
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 5 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 5 Dec 22, 2005 4:45:59 AM
Device manager...........................................................100
Remote configuration network service...........................100
Data synchronization.............................................................100
Personalization............................................................101
Profiles........................................................................................101
Themes.......................................................................................102
Nokia original enhancements.................................103
Enhancements..........................................................................103
Battery information...................................................104
1150 mAh Li-Ion battery (BL-6C) information................104
Nokia battery authentication guidelines.........................104
Care and maintenance..............................................106
Additional safety information................................107
Operating environment.........................................................107
Medical devices........................................................................107
Vehicles.......................................................................................108
Potentially explosive environments..................................108
Emergency calls........................................................................108
CERTIFICATION INFORMATION(SAR).....................................109
Technical information...............................................110
Nokia One-Year Limited Warranty.........................111
Appendices ...................................................................115
Appendix A Message from the CTIA ..................................115
Appendix B Message from the FDA....................................116
Index...............................................................................121
Contents
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 6 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 6 Dec 22, 2005 4:45:59 AM
For your safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands
free to operate the vehicle while driving. Your
first consideration while driving should be
road safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the device off
near medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can
cause interference in aircraft.
SWITCH OFF WHEN REFUELLING
Do not use the device at a refueling point. Do
not use near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the device
where blasting is in progress.
USE SENSIBLY
Use only in the normal position as explained in
the product documentation. Do not touch the
antennas unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and
batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up copies or keep a
written record of all important information.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its
user guide for detailed safety instructions. Do
not connect incompatible products.
7
For your safety
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 7 Dec 22, 2005 4:45:59 AM
EMERGENCY CALLS
Ensure the phone function of the device is
switched on and in service. Press the end key
as many times as needed to clear the display
and return to the standby mode. Enter the
emergency number, then press the call key.
Give your location. Do not end the call until
given permission to do so.
About your device
The wireless device described in this guide is approved
for use on the EGSM850/1800/1900 networks. Contact
your service provider for more information about
networks.
When using the features in this device, obey all laws, and
respect privacy and legitimate rights of others.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on. Do
not switch the device on when wireless device use may
cause interference or danger.
NETWORK SERVICES
To use the phone you must have service from a wireless
service provider. Many of the features in this device
depend on features in the wireless network to function.
These network services may not be available on all
networks or you may have to make specific arrangements
with your service provider before you can utilize network
services. Your service provider may need to give you
additional instructions for their use and explain what
charges will apply. Some networks may have limitations
that affect how you can use network services. For
instance, some networks may not support all language-
dependent characters and services.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
they will not appear on your device menu. Your device
may also have been specially configured. This
configuration may include changes in menu names, menu
order and icons. Contact your service provider for more
information.
Enhancements, batteries,
and chargers
Check the model number of any charger before use with
this device. This device is intended for use when supplied
with power from the LCH-12, ACP-12, and AC-1 chargers.
Warning: Use only batteries, chargers, and
enhancements approved by Nokia for use with this
particular model. The use of any other types may
invalidate any approval or warranty, and may be
dangerous.
For availability of approved enhancements, please check
with your dealer. When you disconnect the power cord of
any enhancement, grasp and pull the plug, not the cord.
Your device and its enhancements may contain small
parts. Keep them out of reach of small children.
8
For your safety
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 8 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 8 Dec 22, 2005 4:45:59 AM
Get started
Note: Your service provider may have requested
that certain features be disabled or not activated in your
device. If so, they do not appear on your device menu.
Your device may also have been specially configured for
your network provider. This configuration may include
changes in menu names, menu order and icons. Contact
your service provider for more information.
Charge the battery
1. Connect the charger to an AC wall outlet.
2. Connect the power cord to the bottom of the device.
The battery indicator bar starts scrolling on the
display. If the battery is completely discharged, it may
take a few minutes before the charging indicator is
shown. The device can be used while charging.
3. When the battery is fully charged, the bar stops
scrolling. Disconnect the charger from the device, then
from the AC outlet.
When the battery charge level is too low for operation,
the device switches itself off.
Enter basic settings
When you power on the device for the first time, and
when you power on the device after battery installation,
your device asks for home city, time, and date. You can
change the settings later.
1. Select your home city from the list and OK. To browse
for a city, start to type the name of the city, or scroll
to a city. It is important to select the correct city,
because scheduled calendar entries that you create
can change when the home city is changed.
2. Set the time, and select OK.
3. Set the date, and select OK.
CD-ROM
The sales package CD-ROM is compatible with Windows
98SE, Windows ME, Windows 2000, and Windows XP.
You can install Nokia PC Suite and read the user
documentation from the CD-ROM. Nokia PC Suite can be
used only with Windows 2000 and Windows XP.
9
Get started
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 9 Dec 22, 2005 4:45:59 AM
Get started (part 2)
Insert the SIM card and
battery
1. Always switch the device off, and disconnect the
charger before removing the battery.
With the back of the device facing you, press the cover
release button (1), and slide the back cover in the
direction of the arrow (2).
2. If the battery is installed, lift the battery from the
battery compartment in the direction of the arrow to
remove it .
3. To release the SIM card holder, slide it in the direction
of the arrow (1), and lift it (2). Insert the SIM card into
the SIM card slot (3).
Ensure that the beveled corner of the SIM card is
pointing up and the contact area on the card is facing
the device. Lower the SIM card holder (4), and slide it
until it locks into place (5).
10
Get started (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 10 Dec 22, 2005 4:45:59 AM
4. To insert the battery, align the contacts of the battery
with the corresponding connectors on the battery
compartment, insert in the direction of the arrow, and
gently click the battery into place.
5. Insert the locking catches of the back cover into the
corresponding slots (1), and slide the cover in the
direction of the arrow (2).
Insert a memory card
See "Memory," p. 24.
1. If necessary, remove the battery cover.
2. Slide the memory card into the memory card slot.
Ensure that the beveled corner of the memory card is
pointing towards the device and the contact area is
facing up.
11
Get started (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 11 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 11 Dec 22, 2005 4:45:59 AM
3. Replace the battery cover.
Important: Do not remove the MMC card in the
middle of an operation when the card is being
accessed. Removing the card in the middle of an
operation may damage the memory card as well as
the device, and data stored on the card may be
corrupted.
Switch on your device
1. To switch the device on, press the power key.
2. If the device asks for a PIN code, lock code or security
code, enter the code, and select OK.
3. To switch the device off, press the power key.
Tip: When you switch the device on, it may
recognize the SIM card provider and configure
the correct text message, multimedia message,
and GPRS settings automatically. If not, contact
your service provider for the correct settings.
The device can be used without the phone functions when
a SIM card is not inserted or when the Offline profile is
selected.
The picture shows the location of the power key.
12
Get started (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 12 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 12 Dec 22, 2005 4:45:59 AM
Your device
Settings
When you switch the device on, it may recognize the SIM
card provider and configure the correct text message,
multimedia message, and GPRS settings automatically.
You may also receive the settings as a special text
message from your service provider.
Menu
Menu is a starting point from which you can open all
applications in the device or on a memory card. The
Menu contains applications and folders, which are groups
of similar applications. Use the joystick to move up and
down on the screen.
Applications that you install are saved in the Installat.
folder by default.
To open an application, scroll to it, and press the joystick.
To view the applications in a list, select Options > Change
view > List. To return back to the grid view, select
Options > Change view > Grid.
To view the memory consumption of different
applications and data stored on the phone or memory
card and to check the amount of free memory, select
Options > Memory details, and select the memory.
To rearrange the folder, scroll to the application you want
to move, and select Options > Move. A check mark is
placed beside the application. Scroll to a new location,
and select OK.
To move an application to a different folder, scroll to the
application you want to move to another folder, and
select Options > Move to folder. Select the new folder,
and OK.
To download applications from the Web, select
Options > App. downloads.
To create a new folder, select Options > New folder. You
cannot create folders inside folders.
To rename a new folder, select Options > Rename.
Tip: To switch between several open
applications, press and hold the Menu key. The
application-switching window opens and
displays the open applications. Scroll to an
application, and press the joystick to switch to it.
When you switch off the device, all applications are closed
and unsaved data is saved automatically.
Help and tutorial
Need help? Search for keywords or get a list of help topics.
Also, your device has a tutorial and application help
preinstalled.
13
Your device
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 13 Dec 22, 2005 4:45:59 AM
Help topics
To open help from the main menu, select Menu > Help >
Help.
To search for help topics using keywords, select
Options > Search by keyword.
To display a list of help topics, select from the application
drop-down list. As you read a help topic, scroll left or right
to view related topics.
Application help
To get help inside an application, select Options > Help.
As you read the instructions, press and hold the Menu key
to switch between Help and an application open in the
background.
Tutorial
To learn about key features, select Menu > Help >
Tutorial.
Scroll and make selections
Use the joystick to move and make selections. With the
joystick, you can move up, down, left and right in the
Menu or in different applications or lists. You can also
press the joystick to open applications or files or edit
settings.
To select text, press and hold the edit key, and scroll left
or right until you have selected the text.
To select different items, such as messages, files, or
contacts, scroll up, down, left or right to highlight to the
item you want to select. Select Options > Mark/
Unmark > Mark to select one item, or Options > Mark/
Unmark > Mark all to select all items.
To select an object, for example an attachment in a
document, scroll onto the object so that square markers
appear on each side of the object.
Common actions in several
applications
You can find the following actions in several applications:
To switch between open applications, press and hold
Menu to see a list of open applications. Scroll to the
application, and select Select.
To change the profile or switch off or lock the device, press
the power key briefly.
To save a file, select Options > Save. There are different
save options depending on the application you use.
To send a file, select Options > Send. For example, you
can send a file in an e-mail or multimedia message; or
send them using infrared or Bluetooth.
To print to a compatible printer, select Options > Print.
You can preview items that you want to print, or edit the
way printed pages look. Before you can print, you must
define a compatible printer to your device. See
"Print," p. 83.
To copy, press the edit key and select the text with the
joystick. Press and hold the edit key and select Copy. To
14
Your device
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 14 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 14 Dec 22, 2005 4:45:59 AM
paste, scroll to where you want to paste the text, press
and hold the edit key and select Paste. This method may
not work in applications such as Documents that have
their own copy and paste commands.
To delete a file, press the clear key, or select Options >
Delete.
To insert characters such as question marks or
parenthesis to text, press *.
Write text
Traditional text input
The indicator is shown on the top right of the display
when you are writing text using traditional text input.
and indicate the selected case. indicates
that the first letter of the word is written in uppercase and
all the other letters will automatically be written in
lowercase. indicates number mode.
•Press a number key 1-9 repeatedly until the desired
character appears. There are more characters available
for a number key than are printed on the key.
•To insert a number, press and hold the number key.
•To switch between letter and number mode, press and
hold #.
•If the next letter is located on the same key as the
present one, wait until the cursor appears, and enter
the letter.
•To erase a character, press the clear key. Press and hold
the clear key to clear more than one character.
•The most common punctuation marks are available
under the 1 key. Press 1 repeatedly to reach the desired
punctuation mark. Press * to open a list of special
characters. Use the joystick to move through the list,
and select a character.
•To insert a space, press 0. To move the cursor to the
next line, press 0 three times.
•To switch between the different character cases, press
#.
Predictive text input
1. To activate predictive text input, press the edit key,
and select Predictive text on. This activates predictive
text input for all editors in the device. The indicator
is shown on the top right of the display when
you are writing text using predictive text input.
2. To write the desired word, press 2-9. Press each key
only once for one letter.
3. When you have finished writing the word and it is
correct, to confirm it, press the joystick, or press 0 to
add a space.
If the word is not correct, press * repeatedly to view
the matching words the dictionary has found one by
one.
If the ? character is shown after the word, the word
you intended to write is not in the dictionary. To add
a word to the dictionary, select Spell, enter the word
(up to 32 letters) using traditional text input, and
select OK. The word is added to the dictionary. When
15
Your device
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 15 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 15 Dec 22, 2005 4:45:59 AM
the dictionary is full, a new word replaces the oldest
added word.
4. Start writing the next word.
Tip: To set predictive text input on or off, press
# twice quickly.
Write the first half of a compound word; to confirm it,
press the joystick. Write the last part of the compound
word. To complete the compound word, press 0 to add a
space.
To turn predictive text input off for all editors in the
device, press the edit key, and select Predictive text > Off.
Copy text to the clipboard
1. To select letters and words, press and hold the edit
key. At the same time, scroll in the direction necessary
to highlight the word, phrase, or line of text you want
to copy. As the selection moves, the text is highlighted.
2. To copy the text to the clipboard, while still holding
the edit key, select Copy. To insert the text into a
document, press and hold the edit key, and select
Paste.
16
Your device
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 16 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 16 Dec 22, 2005 4:45:59 AM
Your device (part 2)
You can use your device with the cover keypad closed or
open.
1. To open the cover, lift the keypad into the direction of
the arrow (1). When you open the front cover, you can
use the full-size QWERTY keyboard (2).
2. The device changes the orientation of the display to
portrait or landscape, depending on whether you use
the device with front cover open or closed.
Keys and parts
Full keyboard open
1 — Keypad light key. Press the key to illuminate your
keypad for a period of time.
2 — Power key
3 — Selection keys
4 — Sync key
5 — Clear (backspace) key
6 — Chr key. Press the Chr key to open a character table
where you can select special characters.
17
Your device (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 17 Dec 22, 2005 4:45:59 AM
7 — Menu key. Press the Menu key to access the
applications installed in your device. With a long keypress,
you can see a list of the active applications and switch
between them. In this User Guide, "select Menu" refers to
pressing this key.
8 — Shift key. Press Shift+character key to produce
uppercase letters.
9 — Space bar
10 — Call key
11 — Light sensor and earpiece
12 — Joystick. Press the joystick to enter a selection. Use
the joystick to scroll left, right, up, down, or to move
around on the screen.
13 — End key
Press the end key to reject a call, end active calls and held
calls, close applications, and with a long keypress, end
data connections (GPRS, data call).
14 — Space bar
15 — Shift key. Press shift and character key to produce
uppercase letters.
16 — Ctrl key
17 — Enter key
The display changes from portrait to landscape when you
open the cover. The application that was active the last
time the device was used is shown on the display. When
you close the cover, the display changes from landscape
to portrait.
Full keyboard closed
1 — Power key
2 — Loudspeaker
3 — Infrared port
4 — Left selection key, joystick, and right selection key.
Press either selection key to perform the function shown
above it on the display. Press the joystick to enter a
selection or access most commonly used functions in
different applications. Use the joystick to scroll left, right,
up, down, or to move around on the screen. During a call,
scroll left or right with the joystick to change volume.
5 — End key
18
Your device (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 18 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 18 Dec 22, 2005 4:45:59 AM
6 — Clear key
7 — Menu key. Press the Menu key to access the menu. In
this User Guide, "select Menu" refers to pressing this key.
8 — Sync key
9 — Microphone. Do not cover the microphone with your
hand during phone calls.
10 — PopPort™ connector for the USB data cable,
headset, and loopset
11 — Charger connector
12 — Edit key
13 — Call key
14 — Voice key/push to talk (PTT) key.
15 — Display
16 — Earpiece
17 — Light sensor
Keypad lock (Keyguard)
When the keypad lock is on, calls may be possible to the
official emergency number programmed into your device.
Use the keypad lock (keyguard) to prevent the keys on the
phone from being accidentally pressed.
To lock the keypad in the standby
mode, press the left selection key
and *. To unlock, press the left
selection key and * again.
Tip: To lock the keypad in
the Menu or in an open
application, press the
power key briefly, and
select Lock keypad. To
unlock, press the left
selection key and *.
To lock the device in the standby
mode, press the left selection key
and #, and enter your lock code. To
unlock, press the left selection key
and *. Enter your lock code, and press the joystick.
Volume control
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume may
be extremely loud.
To adjust the volume during a call, scroll left or right, or
press the voice keys.
To adjust the volume when using the loudspeaker, scroll
left or right, or press the voice keys.
19
Your device (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 19 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 19 Dec 22, 2005 4:45:59 AM
Connectors
Warning: When you use the headset, your ability
to hear outside sounds may be affected. Do not use the
headset where it can endanger your safety.
Battery charger connector
Connector for headset and
other enhancements
Type label
The diagram shows the location of the type label.
Antennas
Your device has two internal antennas.
Note: As with any other radio transmitting device,
do not touch either of the antennas unnecessarily when
the device is switched on. Contact with the antenna
affects call quality and may cause the device to operate
at a higher power level than otherwise needed. Not
touching the antenna area during a phone call optimises
the antenna performance and the talktime of your device.
The picture shows the normal use
of the device at the ear for voice
20
Your device (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 20 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 20 Dec 22, 2005 4:45:59 AM
calls. See "Operating environment," p. 107.
About the display
A small number of missing, discolored, or bright dots may
appear on the screen. This is a characteristic of this type
of display. Some displays may contain pixels or dots that
remain on or off. This is normal, not a fault.
Standby modes
Standby mode
After you have switched on your device and it is ready for
use, but you have not entered any characters or made
other selections, the phone is in the standby mode. In the
standby mode, you can see different information, such as
your service provider, time, and different indicators, such
as indicators for alarms.
Your device has two different standby modes: standby
mode, and active standby mode.
1 — Battery indicator
2 — Message display
3 — Right selection text
4 — Left selection text
5 — Active standby applications
6 — Signal indicator
7 — Time and date
Shortcuts in standby mode
In the standby mode, you can use the following shortcuts.
These shortcuts are usually not available in the active
standby mode.
21
Your device (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 21 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 21 Dec 22, 2005 4:45:59 AM
To view the most recently dialed numbers, press the call
key. Scroll to a number or name, and press the call key
again to call the number.
To call your voice mailbox (network service), press and
hold 1.
To view calendar information, scroll right.
To write and send text messages, scroll left.
To open the contacts list, scroll up or down.
To change the profile, press the power key briefly, scroll
to the profile you want, and press the joystick to activate
the profile.
To switch between two phone lines (network service),
press and hold #.
To change these shortcuts, select Menu > Settings >
Phone sett. > Standby mode.
Active standby mode
In the active standby mode, you can view similar
information as in the standby mode, but you can also
define up to five applications you want to access fast.
To activate active standby, select Menu > Tools >
Settings > Phone sett. > Standby mode > Active
standby > On.
To select applications that you want to access from active
standby, scroll to the different shortcut settings and press
the joystick. Scroll to the desired application and press the
joystick.
Display regions
The figures show regions of the display in the Applications
and Settings screens, as these regions are referred to in
this guide.
Applications screen
1 — Menu title
2 — Scroll bar
3 — Folder
4 — Application
22
Your device (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 22 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 22 Dec 22, 2005 4:45:59 AM
Settings screen
1 — Scroll to more pages (tabs)
2 — Active page (tab)
3 — Inactive page (tab)
4 — Setting option
5 — Current setting option
Display indicators
The signal strength of the cellular network at your
current location. The higher the bar, the stronger the
signal.
The battery charge level. The higher the bar, the
stronger the charge in the battery.
The application is open. This icon is shown in the
Menu.
You have received a message.
You have locked the cover phone keypad.
You have locked the device.
You have selected the silent profile, and the device
does not ring for an incoming call or message.
Bluetooth is activated.
Wireless LAN is available.
Wireless LAN is active.
An infrared connection is active. If the indicator
blinks, your device is trying to connect to the other device,
or the connection has been lost.
Your device is connected to a PC with a USB data
cable.
All calls are forwarded to another number.
and Indicate the phone line that you have selected,
if you have subscribed to two phone lines (network
service).
You have missed a phone call.
An alarm is active.
, , A headset, music stand, hands-free car kit,
or loopset is connected.
23
Your device (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 23 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 23 Dec 22, 2005 4:45:59 AM
A GPRS connection is active.
A data call is active.
IP passthrough is active.
Your device is synchronizing.
You have an ongoing push to talk connection.
Memory
There are two types of memory into which you can save
data or install applications: device memory and
removable memory.
Select Menu > Tools > Options > Memory details.
You can see how much memory is currently in use, how
much free memory remains, and how much memory is
consumed by each data type. For example, you can see
how much memory your e-mail messages, text
documents, or calendar appointments consume.
Tip: To ensure that you have adequate memory,
you should regularly delete or transfer data to a
memory card or PC.
Memory card
Use only compatible miniSD MultiMediaCards (MMC) with
this device. Other memory cards, such as Reduced Size
MultiMediaCards, do not fit in the MMC card slot and are
not compatible with this device. Using an incompatible
memory card may damage the memory card as well as
the device, and data stored on the incompatible card may
be corrupted.
Your Nokia device only supports the FAT16 file system for
memory cards. If you use a memory card from another
device or if you want to ensure compatibility of the
memory card with your Nokia device, you may need to
format the memory card with your Nokia device.
However, all data in the memory card is permanently
deleted if you format the memory card.
It is recommended to back up device memory regularly
to the memory card. The information can be restored to
your device later. To back up information from phone
memory to a memory card, select Menu > Tools >
Memory card > Options > Backup phone mem. To
restore information from the memory card to the phone
memory, select Menu > Tools > Memory card >
Options > Restore from card.
Do not remove a memory card when the card is being
accessed. Removing the card in the middle of an
operation may damage the memory card as well as the
device, and data stored on the card may be corrupted.
If you cannot use a memory card in your device, you may
have the wrong type of memory card, the card may not
be formatted for your device, or the card has a corrupted
file system.
Mini SD
This device uses a mini Secure Digital (SD) card.
To ensure interoperability, use only the correct voltage
mini SD. Check the compatibility of a mini SD with its
manufacturer or provider. Use only compatible mini SD
cards with this device. Other memory cards, such as
24
Your device (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 24 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 24 Dec 22, 2005 4:45:59 AM
MultiMediaCards (MMC) or full-size SD cards, do not fit in
the mini SD card slot and are not compatible with this
device. Using an incompatible memory card may damage
the memory card as well as the device, and data stored
on the incompatible card may be corrupted. Keep all
memory cards out of the reach of small children.
Transfer content between
devices
Transfer data from another device
You can transfer content, such as contacts, from a
compatible Nokia device to your Nokia 6830 using
Bluetooth connectivity or infrared. The type of content
that can be transferred depends on the phone model. If
the other device supports synchronization, you can also
synchronize data between the other device and your
Nokia 6830.
1. To start transferring data from a compatible device,
select MenuTools > Switch > Transfer.
2. In the information view, select Continue.
3. Select whether you want to use Bluetooth
connectivity or infrared to transfer the data. Both
devices must support the selected connection type.
4. If you select Via Bluetooth:
Activate Bluetooth in your other device and select
Continue in your Nokia 6830 to start searching for
devices with active Bluetooth connectivity. Select
Stop when your Nokia 6830 has found your other
device. Select your other device from the list. You are
asked to enter a passcode (1-16 digits) on your Nokia
6830. The passcode will be used only once to confirm
this connection. Enter the code on your Nokia 6830,
and select OK. Enter the passcode on your other device,
and select OK. The devices are now paired. See "Pair
devices," p. 59.
For some phone models, the Transfer application is
sent to your other device as a message. To install
Transfer on your other device, open the message, and
follow the instructions on the display.
If you select Via infrared:
Connect the two devices. See "Infrared," p. 61.
5. From your Nokia 6830, select the content you want to
transfer from your other device, and OK.
Content is copied from the memory of the other device to
the corresponding location in your device. Copying time
depends on the amount of data to be transferred. You can
also cancel and continue later.
The necessary steps for data transfer may vary depending
on your device, and whether you have interrupted data
transfer earlier. The items that you can transfer vary
depending on the other device.
Synchronize data with another
device
If you have previously transferred data to your Nokia
6830, and your other device supports synchronization,
you can use Switch to keep the data of the two devices
up to date.
1. Select Menu > Tools > Switch.
25
Your device (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 25 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 25 Dec 22, 2005 4:45:59 AM
2. Select Device, and press the joystick.
3. Scroll to the device from which you transferred data,
and press the joystick.
4. Select Sync and press the joystick. The devices start
synchronizing using the same connection type that
you selected when you originally transferred data and
synchronize only the data that you originally selected
for data transfer.
To modify the data transfer and synchronization settings,
select Sync, scroll to a device, press the joystick, and select
Edit.
26
Your device (part 2)
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 26 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 26 Dec 22, 2005 4:45:59 AM
Make calls
When the device is locked, calls still may be possible to
the official emergency number programmed into your
device.
In the offline profile, you may need to enter the lock code
and change the device to a calling profile before making
any call, including a call to an emergency number.
To make and receive calls, the phone must be switched
on, the device must have a valid SIM card installed, and
you must be located in a service area of the cellular
network. The GPRS connection is put on hold during voice
calls unless the network supports dual transfer mode.
Enter the phone number, including the area code, and
press the call key. If you enter an incorrect character, press
the clear key.
Tip: For international calls, press the * key twice
to add the + character that replaces the
international access code, and enter the country
code, area code (omit the leading 0, if necessary),
and phone number.
To end the call or cancel the call attempt, press the end
key.
To make a call using the saved contacts, press Contacts in
standby mode. Enter the first letters of the name, scroll to
the name, and press the call key. See "Contacts," p. 36.
Press the call key to view up to 20 numbers that you last
called or attempted to call. Scroll to the desired number
or name, and press the call key to dial the number.See
"Log," p. 29.
To adjust the volume of an active call, scroll left or right
with the joystick.
To call your voice mailbox (network service) in standby
mode, press and hold the 1 key, or press the 1 key then
the call key.
Speed dial
1-touch dialing allows you to make a call by pressing and
holding a number key.
Before using 1-touch dialing, select Menu > Tools >
Settings > Call settings > Speed dialling, and ensure that
Speed dialling is set to On.
To assign a number key to a phone number, select
Menu > Tools > Speed dial. Scroll to the number key (2
- 9) on the screen, and select Options > Assign. Select the
desired number from the Contacts directory.
To delete the phone number assigned to a number key,
scroll to the speed dialing key, and select Options > Undo.
To modify a phone number assigned to a number key,
scroll to the 1-touch dialing key, and select Options >
Change.
27
Make calls
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 27 Dec 22, 2005 4:45:59 AM
Answer a call
Note: The actual invoice for calls and services from
your service provider may vary, depending on network
features, rounding off for billing, taxes, and so forth.
To answer a call, press the call key.
To decline the call, press the end key.
To mute a ringing tone instead of answering a call, select
Silence.
To answer a new call during a call when the Call waiting
function is activated, press the call key. The first call is put
on hold. To end the active call, press the end key.
Forward calls
Select Menu > Tools > Settings > Call divert.
Forward incoming calls to your voice mailbox or to
another phone number. For details, contact your service
provider.
1. Select a call type from the following:
•Voice calls — Incoming phone calls
•Data and video calls — Incoming data and video
calls
•Fax calls — Incoming fax calls
2. Select one of the following call forwarding options:
•All voice calls, All data and vid. calls, or All fax
calls. — Forward all incoming voice, data and
video, or fax calls.
•If busy — Forward incoming calls when you have
an active call.
•If not answered — Forward incoming calls after
your device rings for a specified period of time.
Define the time you let the phone ring before
forwarding the call in the Delay time: field.
•If out of reach — Forward calls when the phone is
switched off or out of network coverage.
•If not available — Activate the last three settings
at the same time. This option forwards calls if your
device is busy, not answered, or out of reach.
3. Select Activate.
To check the current forwarding status, scroll to the
forwarding option, and select Options > Check status.
To stop forwarding voice calls, scroll to the forwarding
option, and select Options > Cancel.
Call restriction and call forwarding cannot be active at the
same time.
Call restriction
When calls are restricted, calls still may be possible to the
official emergency number programmed into your device.
Select Menu > Tools > Settings > Call barring.
You can restrict the calls that c an be ma de or re cei ve d w it h
the device (network service). To change the settings, you
need the restriction password from your service provider.
Call restriction affects all calls, including data calls. Call
restriction and call forwarding cannot be active at the
same time.
28
Make calls
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 28 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 28 Dec 22, 2005 4:45:59 AM
To restrict calls, select Cellular call barring, and select from
the following options:
•Outgoing calls — Prevent making voice calls with your
device.
•Incoming calls — Restrict incoming calls.
•International calls — Prevent calling to foreign
countries or regions.
•Incoming if abroad — Restrict incoming calls when
outside your home country.
•Intern. except home — Prevent calls to foreign
countries or regions, but to allow calls to your home
country.
To check the status of voice call restriction, scroll to the
restriction option, and select Options > Check status.
To stop all voice call restrictions, scroll to a restriction
option, and select Options > Cancel all barrings.
Internet call restriction
To restrict Internet calls, select Menu > Tools >
Settings > Call barring > Internet call barring.
To reject Internet calls from anonymous callers, select
Anon. call barring > On.
Log
Select Menu > Log.
In the Log, you can view information about the
communication history of the device.
To view the logs for recent voice calls, their approximate
duration, and packed data connections, select Recent
calls, Call duration, or Packet data and press the joystick.
To sort the events by type or direction, scroll right to open
the general log, and select Options > Filter. Scroll to a
filter type and press the joystick, then select the type or
direction, and press the joystick.
To set the time how long all communication events are
held in the log, select Options > Settings > Log
duration. Select an option and OK.
To clear missed calls, received calls and dialed numbers,
select Recent calls > Options > Clear recent calls.
Push to talk
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume may
be extremely loud.
Select Menu > Connect. > PTT.
Push to talk (PTT) (network service) is a real-time voice
over IP service implemented over a GSM/GPRS network.
Push to talk provides direct voice communication
connected with the push of a key. With push to talk, you
can use your device as you would use a walkie-talkie.
You can use push to talk to have a conversation with one
person or with a group of people, or join a channel. A
channel is like a chat room: you can call the channel to see
if anyone is online. The channel call does not alert the
other participants; the participants just join the channel
and start speaking with each other.
In push to talk communication, one person talks while the
others listen through the built-in loudspeaker. Speakers
take turns responding to each other. Because only one
speaker can talk at a time, the maximum duration of a
29
Make calls
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 29 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 29 Dec 22, 2005 4:45:59 AM
speech turn is limited. For details of the speech turn
duration for your network, contact your network operator
or service provider.
Remember to hold the device in front of you during a push
to talk call so you can see the display. Speak towards the
microphone, and do not cover the loudspeaker with your
hands.
Phone calls always take priority over push to talk.
Before you can use push to talk, you must define the push
to talk access point and push to talk settings. You may
receive the settings in a special text message from the
service provider that offers the push to talk service.
User settings
Select Options > Settings > User settings.
Define the following:
•Incoming PTT calls — Select Notify if you want to see
a notification of incoming calls. Select Auto-accept if
you want push to talk calls to be answered
automatically. Select Not allowed if you want push to
talk calls to be rejected automatically.
•PTT call alert tone — Select Set by profile if you want
the incoming call alert setting for push to talk to follow
your profile settings. If your profile is silent, you are
not available to others using push to talk, except for
callback requests.
•Callback req. tone — Define the ringing tone for
callback requests.
•Application start-up — Select if you want to log in to
the push to talk service when you switch on your
device.
•Default nickname — Enter your default nickname (20
characters maximum) that is displayed to other users.
•Show my PTT address — Define if you want callers to
see your push to talk address. You can let all callers see
the address, show the address only to one-to-one
callers or channel participants, or hide the address
from all callers.
•Show my login status — Define if your login to the
push to talk server is shown or hidden from other
users.
Connection settings
Select Options > Settings > Connection settings.
Define the following:
•Domain — Enter the domain name obtained from
your service provider.
•Access point name — Enter the push to talk access
point name.
•Server address — Enter the IP address or domain
name of the push to talk server obtained from your
service provider.
•User name — Enter your user name obtained from
your service provider.
•PTT password — Enter a password, if required, to
make a data connection. The password is usually
provided by the service provider.
Log in to push to talk service
If you have set Application start-up on in User settings,
push to talk automatically logs in to the service when
started. If not, you must log in manually.
1. To log in to a push to talk service, select Options >
Switch PTT on.
30
Make calls
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 30 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 30 Dec 22, 2005 4:45:59 AM
2. Enter your User name, PTT password, Domain, Server
address, and Access point name, and select OK.
When the Ringing type setting of your device is set to
Beep once or Silent, or there is an ongoing phone call, you
cannot make or receive push to talk calls.
Make a push to talk call
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume may
be extremely loud.
Select Options > PTT contacts.
Select one or several contacts from the list, and press the
push to talk key. Remember to hold the device in front of
you during a push to talk call so you can see the display.
The display informs you when it is your turn to speak.
Speak towards the microphone, and do not cover the
loudspeaker with your hands.
Press and hold the push to talk key the entire time you
are talking. When you have finished talking, release the
key.
To end the call, press the end key.
Answer or reject a call
When you receive a push to talk call, select Accept to start
a call or Reject to dismiss the call.
Callback requests
To send a callback request, select Options > PTT
contacts and the desired contact, and select Options >
Send callback req..
To answer a callback request, press Show to open Callback
inbox. Select a contact and select Options > Talk 1 to 1 to
start a call.
Contacts view
To view, add, modify, delete, or call contacts, select
Options > PTT contacts. A list of names from your device
Contacts application is displayed.
Select Options and:
•Talk 1 to 1 — Make a push to talk call to the selected
contact.
•Make PTT group call — Make a push to talk call to all
contacts that you selected.
•Send callback req. — Send a request to a contact to call
you.
•Show login status — Order the push to talk login
status information of the contact from the push to talk
server.
•Hide login status — Do not order the push to talk login
status information of the contact from the push to talk
server.
•Add to Contacts — Create a contact.
•Edit — Edit the contact.
•Delete — Delete the contact.
•Default PTT address — Set the default push to talk
address for a contact.
•Mark/Unmark — Select one or more contacts.
Create a channel
A channel is like a chat room: you can call the channel to
see if anyone is online. The channel call does not alert the
31
Make calls
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 31 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 31 Dec 22, 2005 4:45:59 AM
other participants; the participants just join the channel
and start speaking with each other.
To create a channel, select Options > New channel >
Create new.
Select Options and:
•Channel name — Write the channel name.
•Channel privacy — Select Private or Public.
•Nickname in channel — Enter your nickname (20
characters maximum) that is displayed to other users.
•Channel thumbnail — Insert a picture that describes
the channel.
To delete a channel, press the clear key.
When you log in to push to talk, push to talk automatically
connects to the channels that were active when the
application was last closed.
Register PTT channels
If a push to talk channel could not be created on the
server, the text (not registered) is shown below the
channel name.
To try to register the channel again, select Options >
Register.
To edit the channel details, select Options > Edit.
Participant details
To view the currently active participants of a channel,
select Options > Active members.
To view more information about a selected participant,
select Options > Contact details.
Select Options and:
•Talk 1 to 1 — Start a one-to-one call.
•Send callback req. — Send a callback request to the
selected contact.
•Add to Contacts — Add the contact to Contacts.
Join a channel
To join a channel, select Options > PTT channels. Select
the channel you want to talk to, and press the push to talk
key. Remember to hold the device in front of you during
a push to talk call so you can see the display. The display
informs you when it is your turn to speak. Speak towards
the microphone, and do not cover the loudspeaker with
your hands. Press and hold the push to talk key the entire
time you are talking. When you have finished talking,
release the key.
To switch between channels during multiple calls,
select Swap. The active channel is highlighted, and the
other channels are passive.
To end the call, press the end key.
Select Options and:
•Active members — View the currently active
participants in the channel.
•Send invitation — Invite another participant to the
channel.
•Deactivate loudsp. or Activate loudsp. — Switch the
loudspeaker off or on.
•PTT contacts — View your push to talk contacts.
•PTT channels — View push to talk channels.
•Callback inbox — View received callback requests.
•PTT log — View the push to talk log.
•Settings — Manage your push to talk settings.
32
Make calls
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 32 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 32 Dec 22, 2005 4:45:59 AM
Push to talk log
To open the push to talk log, select Options > PTT log.
The log shows the date, time, duration, and other details
of Missed PTT calls, Received PTT calls, and Created PTT
calls.
Exit push to talk
Select Options > Exit. Select Yes to log out and close the
service. Press No if you want to keep the application active
on the background.
Voice over IP
Your device supports voice calls over the Internet
(Internet calls). Your device attempts emergency calls
primarily over cellular networks. If an emergency call
using cellular networks is not successful, then your device
attempts an emergency call through your Internet call
provider. Due to the established nature of cellular
telephony, you should use cellular networks for
emergency calls, if possible. If you have cellular network
coverage available, please make sure that your cellular
phone is switched on and ready to make calls before you
attempt an emergency call. The capability for an
emergency call using Internet telephony depends on the
availability of a WLAN network and your Internet call
provider's implementation of emergency call capabilities.
Contact your Internet call provider to check the Internet
telephony emergency call capability
Select Menu > Connect. > Inter. tel..
VoIP (Voice over Internet Protocol) technology is a set of
protocols that facilitate phone calls over an IP network,
such as the Internet. VoIP phone calls can be established
between computers, between mobile phones, and
between a VoIP device and a traditional telephone. To
make or receive a VoIP call, your device must be within
WLAN coverage.
You can make an Internet call from all applications where
you can create a regular voice call.
VoIP settings can be found in Menu > Tools >
Settings > Call and Connection.
Preferred profile
To select the profile that is used by default when you
make Internet calls, select Preferred profile and press the
joystick. Scroll to the desired profile and press the joystick.
Registering profiles
To change the registration of your Internet telephone
profiles, scroll to the profile that you want to register or
unregister and press the joystick. Press the joystick again
to select Registered or Not registered.
To save your setting, press Back.
Phone security
Select Menu > Tools > Settings > Security settings >
Phone and SIM.
33
Make calls
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 33 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 33 Dec 22, 2005 4:45:59 AM
You can modify the security settings for the PIN code,
automatic lock, and SIM card change, and change codes
and passwords.
Avoid using codes that are similar to emergency numbers
to prevent accidental dialing of the emergency number.
Codes are shown as asterisks. When you change a code,
enter the current code, then the new code twice.
Define security settings
To define device and SIM card settings, select a setting and
Options > Change.
When calls are limited to closed user groups, calls may be
possible to the official emergency number programmed
into your device.
Define the following:
•PIN code request — Select On to request that the PIN
code is entered each time the device is switched on.
This setting cannot be changed if the phone is
switched off. Some SIM cards do not allow turning off
the PIN code request.
•PIN code — Change the PIN code. The PIN code must
be 4 to 8 numbers long. The PIN code protects your SIM
card against unauthorized use and is provided with
the SIM card. After three consecutive incorrect PIN code
entries, the PIN code is blocked, and you need to use
the PUK code to unblock it before you can use the SIM
card again.
•PIN2 code — Change the PIN2 code. The PIN2 code
must be 4 to 8 numbers long. The PIN2 code is required
to access some functions of the device and is provided
with the SIM card. After three consecutive incorrect
PIN2 code entries, the PIN2 code is blocked, and you
need to use the PUK2 code to unblock it before you can
use the SIM card again.
•Autolock period — Set a time-out after which the
device is automatically locked and can be used only if
the correct lock code is entered. Enter a number for the
time-out in minutes, or select None to turn off the
autolock period. When the device is locked, you can
still answer incoming calls and calls may still be
possible to the official emergency number
programmed into your device.
•Lock code — Change the lock code. The new code must
be 5 to 10 digits long. The preset code is 12345. To
avoid unauthorized use of your device, change the lock
code. Keep the new code secret and in a safe place
separate from your device.
•Lock if SIM changed — Set the device to ask for the lock
code when an unknown, new SIM card is inserted into
your device. The device maintains a list of SIM cards
that are recognized as the owner’s cards.
•Closed user group (network service) — Specify a group
of people to whom you can call and who can call you.
•Confirm SIM services (network service) — Set the
device to display confirmation messages when you are
using a SIM card service.
Change the restriction password
To change the password used for restricting voice, fax,
and data calls, select Menu > Tools > Settings > Call
barring > Cellular call barring. Select Options > Edit
barrings passw.. Enter the current code, and then the new
code twice. The restriction password must be four digits
long. For details, contact your service provider.
34
Make calls
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 34 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 34 Dec 22, 2005 4:45:59 AM
Fixed dialing
When fixed dialing is activated, calls may be possible to
the official emergency number programmed into your
device.
Select Menu > Contacts > Options > SIM contacts >
Fixed dialling contacts.
With the fixed dialing service, you can restrict calls from
your device to only certain phone numbers. Not all SIM
cards support the fixed dialing service. Contact your
service provider for more information.
Select Options, and select from the following:
•Activ. fixed dialling — Restrict calls from your phone.
To cancel the service, select Deact. fixed dialling. You
need your PIN2 code to activate and deactivate fixed
dialing or edit your fixed dialing contacts. Contact your
service provider if you do not have the code.
•New SIM contact — Add a phone number to the list of
numbers to which calls are allowed. Enter the contact
name and phone number. To restrict calls by a country
prefix, enter the country prefix in New SIM contact. This
way, all phone numbers to which calls are allowed
must start with this country prefix.
•Copy to Contacts — Copy the fixed dialing contact to
Contacts.
•Add from Contacts — Copy a contact from Contacts to
your fixed dialing list.
Tip: To send text messages to the SIM contacts
while the fixed dialing service is activated, you
need to add the text message centre number to
the fixed dialling list.
To view or edit a phone number to which calls from your
device are allowed, select Options > SIM contacts >
Fixed dialling contacts.
To call the contact, press the call key.
To edit the phone number, select Options > Edit. You may
need your PIN2 code to edit your fixed dialling numbers.
To delete the contact, press the clear key.
35
Make calls
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 35 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 35 Dec 22, 2005 4:45:59 AM
Contacts
Select Menu > Contacts.
Manage all of your contact information, such as phone
numbers and addresses. Add a personal ringing tone,
voice tag, or a thumbnail image to a contact. Send contact
information to compatible devices or receive contact
information as business cards from compatible devices
and add them to your own list of contacts.
To add a contact, select Options > New contact. Enter the
contact information, and select Done.
To edit information in a contact card, scroll to the contact
and select Options > Edit. Select from the following
options:
•Add thumbnail — Add a thumbnail image that will
display when a contact calls you. The image must be
previously saved to your phone or memory card.
•Remove thumbnail — Remove the image from the
contact card.
•Add detail — Add fields of information to a contact
card, such as Job title.
•Delete detail — Delete any details that you added to a
contact card.
•Edit label — Edit the field names of the contact card.
Manage contact groups
Create a contact group so that you can send text or e-mail
messages to several recipients at the same time.
1. Scroll to the right, and select Options > New group.
2. Enter a name for the group or use the default name,
and select OK.
3. Open the group, and select Options > Add members.
4. Scroll to each contact you want to add to the group,
and press the joystick to mark it.
5. Select OK to add all marked contacts to the group.
The following options are available when you select
Options in the contact groups view:
•Open — Open the contact group and view the
group members.
•New group — Create a new contact group.
•Delete — Delete a contact group.
•Rename — Rename the contact group.
•Ringing tone — Assign a ringing tone to a contact
group.
•Contacts info — View the information for a contact
group.
•Settings — Set the name display settings for
contact group members.
Manage default information
Assign a default number or address to a contact so you
can easily call or send a message to the default number
or address, even if several numbers or addresses are
saved to that contact.
36
Contacts
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 36 Dec 22, 2005 4:45:59 AM
To change default information for a contact, open the
contact, and select Options > Defaults. Select the number
or address you want to set as a default, and select OK.
The default number or address is underlined in the
contact.
Copy contacts between SIM
and device memory
For availability and information on using SIM card
services, contact your SIM card vendor. This may be the
service provider, network operator, or other vendor.
To copy contacts from a SIM card to device memory, select
Options > SIM contacts > SIM directory to open the SIM
directory. Mark the contacts you want to copy, or select
Mark all to copy all contacts. Select Options > Copy to
Contacts.
To copy contacts from the device memory to a SIM card,
select Options > Copy to SIM direct.. Mark the contacts
you want to copy, or select Mark all to copy all contacts.
Select Options > Copy to SIM direct..
Select Options > SIM contacts > SIM directory to see the
names and numbers stored on the SIM card. In SIM
directory you can add, edit, or copy numbers to Contacts,
and you can make calls.
Select ringing tones for
contacts
Select a ringing tone for a contact or contact group. If the
caller's phone number is sent with the call, and your
device recognizes the number, the ringing tone plays
when the contact calls you.
To select a ring tone for a contact or contacts group, open
the contact or contact group, and select Options >
Ringing tone. A list of ring tones opens. Select the ring
tone you want to use, and select OK.
To remove the ringing tone, select Default tone from the
list of ringing tones.
Business cards
Select Menu > Contacts.
You can send, receive, view, and save contact cards as
business cards in vCard or Nokia Compact Business Card
format.
You can send business cards to compatible devices using
SMS, MMS, or e-mail, or an infrared or Bluetooth
connection.
To send a business card, select the contact card from the
contacts list, and select Options > Send. Select Via text
message, Via multimedia, Via e-mail, Via Bluetooth, or Via
infrared. Enter the phone number or address, or add a
recipient from the contacts list. Select Options > Send
business card. If you select SMS as the sending method,
contact cards are sent without images.
To view a received business card, select Open from the
displayed notification, or open the message from the
inbox folder in Messag..
37
Contacts
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 37 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 37 Dec 22, 2005 4:45:59 AM
To save a business card, select Options > Save business
card when the incoming message appears on the device.
To save a received business card, select Options > Save
business card.
To delete a received business card, select Options >
Delete.
38
Contacts
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 38 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 38 Dec 22, 2005 4:45:59 AM
Messages
Select Menu > Messag..
Before sending or receiving messages, you may need to
do the following:
•Insert a valid SIM card in the device, and be located in
a service area of the cellular network.
•Verify that the network supports the messaging
features you want to use and that they are activated
on your SIM card.
•Define Internet access point (IAP) settings on the
device. See "Access points," p. 86.
•Define e-mail account settings on the device. See "E-
mail account settings," p. 48.
•Define SMS settings on the device. See "Text message
settings," p. 41.
•Define MMS settings on the device. See "Multimedia
message settings," p. 44.
The device may recognize the SIM card provider and
automatically configure some of the message settings. If
not, you may need to define the settings manually, or
contact your service provider, network operator, or
Internet service provider to configure the settings.
The Messag. application displays each type of messaging
folder in a list format, with the newest message displayed
first in each folder. Any remote mailboxes that you define
are displayed last in the list of folders.
Select one of the following:
•New message — Create and send a new text,
multimedia, or e-mail message.
•Inbox — View received messages, except e-mails and
cell broadcast messages.
•My folders — Create your own folders to store
messages and templates.
•Mailbox — View and reply to received e-mail.
•Drafts — Store messages that have not been sent.
•Sent — Store messages that have been sent.
•Outbox — View messages waiting to be sent.
•Reports — View information about the delivery of sent
messages.
Messaging folders
To create a new folder to organize your messages, select
My folders > Options > New folder. Enter the folder
name, and select OK.
To rename a folder, select the folder, and Options >
Rename folder. Enter the new folder name, and select
OK. You can only rename folders that you have created.
To move a message to another folder, open the message,
and select Options > Move to folder. Select the folder and
OK.
To sort messages in a specific order, select Options > Sort
by. You can sort the messages by Date, Sender, Subject, or
Message type.
39
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 39 Dec 22, 2005 4:45:59 AM
Messaging settings
Select Options > Settings.
To define or edit settings for different message types,
select Text msg., Multim. msg., E-mail, Service message,
Cell broadcast, or Other.
Text messages
Your device supports the sending of text messages
beyond the normal 160-character limit. If your message
exceeds 160 characters, it will be sent as a series of two
or more messages.
In the navigation bar, you can see the message length
indicator counting backwards from 160. For example, 10
(2) means that you can still add 10 characters for the text
to be sent as two messages.
Note that using special (Unicode) characters such as ë, â,
á, ì take up more space.
Write and send text messages
Select Menu > Messag. > New message > Text
message.
1. In the To field, press the joystick to select recipients
from Contacts, or enter the recipients' mobile phone
numbers manually. If you enter more than one
number, separate the numbers with a semicolon. To
insert a semicolon, press *.
2. Enter the text of the message. To use a template, select
Options > Insert > Template.
3. Select Options > Send to send the message.
Note: When sending messages, your device
may display Message Sent. This is an indication that
the message has been sent by your device to the
message center number programmed into your
device. This is not an indication that the message has
been received at the intended destination. For more
details about messaging services, check with your
service provider.
Reply to received text messages
To reply to a text message, open the message from the
Inbox. Select Options > Reply. Enter the text of the
message, and select Options > Send.
To call the sender of a text message, open the message
from the Inbox and select Options > Call.
Text messages on the SIM card
Text messages may be stored on your SIM card. Before you
can view SIM messages, you must copy the messages to
a folder in the device. After copying the messages to a
folder, you can view them in the folder or delete them
from the SIM card.
Select Options > SIM messages.
1. Select Options > Mark/Unmark > Mark or Mark all to
mark every message.
2. Select Options > Copy.
3. Select a folder and OK to begin copying.
40
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 40 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 40 Dec 22, 2005 4:45:59 AM
To view SIM card messages, open the folder where you
copied the messages, and open a message.
To delete a text message from the SIM card, select the
message and press the clear key.
Text message settings
Select Options > Settings > Text msg..
Define the following:
•Message centres — View the available message
centers for your device.
•Msg. centre in use — Select a message center to send
the message.
•Character encoding — Select Reduced support to use
automatic character conversion to another encoding
system when available.
•Receive report — Select Yes if you want that the
network sends you delivery reports on your messages
(network service).
•Message validity — Select how long the message
center resends your message if the first attempt fails
(network service). If the recipient cannot be reached
within the validity period, the message is deleted from
the message center.
•Message sent as — Convert the message to another
format, such as Text, Fax, Paging or E-mail. Change this
option only if you are sure that your message center is
able to convert text messages into these other formats.
Contact your network operator.
•Preferred conn. — Select the preferred method of
connection when sending text messages from your
device.
•Reply via same ctr. — Select whether you want the
reply message to be sent using the same text message
center number (network service).
Picture messages
Note: Picture message function can be used only if
it is supported by your network operator or service
provider. Only devices that offer picture message features
can receive and display picture messages.
Select Menu > Messag..
To view a picture message, open the message from the
Inbox folder.
Forward picture messages
1. In the Inbox, open a picture message.
2. In the To field, enter a recipient's number, or press the
joystick to add a recipient from Contacts. If you enter
more than one number, separate the numbers with a
semicolon. To insert a semicolon, press *.
3. Enter the text of your message. The text can have 120
characters. To use a template, select Options >
Insert > Template.
4. To send the message, press the call key.
Tip: To remove the picture from the message,
select Options > Remove picture.
41
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 41 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 41 Dec 22, 2005 4:45:59 AM
Multimedia messages
A multimedia message (MMS) can contain text and objects
such as images, sound clips, or video clips.
Note: Only devices that have compatible features
can receive and display multimedia messages. The
appearance of a message may vary depending on the
receiving device.
Before you can send or receive multimedia messages on
your device, you must define the multimedia message
settings. Your device may have recognized the SIM card
provider and automatically configured the multimedia
message settings. If not, contact your service provider.
See "Multimedia message settings," p. 44.
Create and send multimedia
messages
The default setting of the multimedia message service is
generally on.
Select New message > Multimedia message.
Copyright protections may prevent some images, ringing
tones, and other content from being copied, modified,
transferred or forwarded.
1. In the To field, press the joystick to select recipients
from Contacts, or enter the recipients' mobile phone
numbers or e-mail addresses manually.
2. In the Subject field, enter a subject for the message.
To change the fields that are visible, select Options >
Address fields.
3. Enter the text of the message, and select Options >
Insert object to add media objects. You can add
objects such as Image, Sound clip, or Video clip.
Tip: To take a new picture or record audio or
video for the message, select Options >
Insert new and the type of media object you
want to add.
The wireless network may limit the size of MMS
messages. If the inserted picture exceeds this limit,
the device may make it smaller so that it can be sent
by MMS.
4. Each slide of your message can contain only one video
or audio clip. To add more slides to your message,
select Options > Insert new > Slide. To change the
order of slides in your message, select Options >
Move.
5. To preview a multimedia message before sending it,
select Options > Preview.
6. Press the joystick to send the multimedia message.
Create presentations
Select New message > Multimedia message.
1. In the To field, press the joystick to select recipients
from Contacts, or enter the recipients' mobile phone
numbers or e-mail addresses manually.
2. Select Options > Create presentation, and a
presentation template.
Tip: A template may define which media
objects you can include in the presentation,
42
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 42 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 42 Dec 22, 2005 4:45:59 AM
where they appear, and effects displayed
between images and slides.
3. Scroll to a text area and enter the text.
4. To insert images, sound, video, or notes in your
presentation, scroll to the corresponding object area,
and select Options > Insert.
Tip: To move between object areas, scroll up
and down.
5. To add slides, select Insert > New slide.
6. Select Options and select from the following:
•Preview — See what your multimedia presentation
looks like when it is opened. Multimedia presentations
may only be viewed in compatible devices that support
presentations. They may appear different in different
devices.
•Backgrnd. settings — Select the background color for
the presentation and background images for different
slides.
•Effect settings — Select effects between images or
slides.
Creating multimedia presentations is not possible if MMS
creation mode is Restricted. To change MMS creation
mode, select Messag. > Options > Settings >
Multimedia message.
The available options may vary.
To send your multimedia presentation, press the call key.
Tip: To save the message in Drafts without
sending it, select Done.
Receive and reply to multimedia
messages
Important: Multimedia message objects may
contain viruses or otherwise be harmful to your device or
PC. Do not open any attachment if you are not sure of the
trustworthiness of the sender.
Before you can send or receive multimedia messages on
your device, you must define the multimedia message
settings. Your device may have recognized the SIM card
provider and automatically configured the multimedia
message settings. If not, contact your service provider.
See "Multimedia message settings," p. 44.
If you receive multimedia messages containing objects
unsupported by your device, you cannot open them.
1. To reply to a multimedia message, open the message
from the Inbox, and select Options > Reply.
2. Select Options > To sender to reply to the sender with
a multimedia message or Options > Via text
message to reply to the sender with a text message.
3. Enter the text of the message, and press the joystick
to send it.
View presentations
Open the Inbox, scroll to a multimedia message that
contains a presentation and press the joystick. Scroll to
the presentation and press the joystick.
Tip: To increase or decrease the sound volume,
scroll left or right.
43
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 43 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 43 Dec 22, 2005 4:45:59 AM
To pause the presentation, press either selection key
below the display.
After you pause the presentation or playing finishes,
select Options and select from the following:
•Open link — Open a Web link and browse the Web
page.
•Activate scrolling — Scroll text or images too large to
fit on the display.
•Continue — Resume playing the presentation.
•Play — Replay the presentation from the start.
•Find — Find phone numbers and e-mail or Web
addresses the presentation may contain. You may use
these numbers and addresses to make calls, send
messages, or create bookmarks, for example.
The available options may vary.
View media objects
Open the Inbox, scroll to a received multimedia message
and press the joystick. Press Options > Objects.
To view or play a media object, scroll to it and press the
joystick.
Media objects and message attachments may contain
viruses or other harmful software. Do not open any
objects or attachments unless you are sure of the
trustworthiness of the sender.
To save a media object in its corresponding application,
scroll to the object, select Options > Save.
To send a media object to compatible devices, scroll to it,
and select Options > Send.
Tip: If you receive multimedia messages that
contain media objects your phone cannot open,
you may be able to send these objects to another
device such as a computer.
Multimedia message settings
Select Options > Settings > Multimedia message.
Define the following settings:
•Image size — Select Small or Large to scale images in
multimedia messages. Select Original to maintain the
original image size of multimedia messages.
•MMS creation mode — Select Restricted to have your
device prevent you from including content in
multimedia messages that may not be supported by
the network or the receiving device. To receive
warnings about including such content, select
Guided, or Free to create a multimedia message with
no restrictions on attachment type. If you select
Restricted, creating multimedia presentations is not
possible.
•Access point in use — Select the default access point
to connect to the multimedia message center. You may
not be able to change the default access point if it is
preset in your device by your service provider.
•Multimedia retrieval — Select Always automatic to
always receive multimedia messages automatically,
Aut. in home network to receive notification of a new
multimedia message that you can retrieve from the
message center (for example, when you are traveling
abroad and are outside your home network), Manual
to retrieve multimedia messages from the message
44
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 44 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 44 Dec 22, 2005 4:45:59 AM
center manually , or Off to prevent receipt of any
multimedia messages.
•Allow anon. msgs. — Select whether you want to
receive messages from unknown senders.
•Receive adverts — Select whether you want to receive
messages defined as advertisements.
•Receive report — Select Yes to have the status of the
sent message to be shown in the log (network service).
Receiving a delivery report of a multimedia message
that has been sent to an e-mail address may not be
possible.
•Deny report sending — Select Yes to not send delivery
reports from your device for received multimedia
messages.
•Message validity — Select how long the messaging
center tries to send the message (network service). If
the recipient of a message cannot be reached within
the validity period, the message is removed from the
multimedia messaging center. Maximum time is the
maximum amount of time allowed by the network.
E-mail messages
To receive and send mail, you must have a remote
mailbox service. This service may be offered by an
Internet service provider, a network service provider, or
your company. Your device is compliant with Internet
standards SMTP, IMAP4 (rev 1), and POP3.
Before you can send, receive, retrieve, reply to, and
forward mail on your device, you must also do the
following:
•Configure an Internet access point (IAP). See "Access
points," p. 86.
•Set up an e-mail account, and define the e-mail
settings correctly. See "E-mail account
settings," p. 48.
Follow the instructions from your remote mailbox and
Internet service providers. Contact your network and
Internet service providers or operator for the correct
settings.
Set up your e-mail with the mailbox
guide
If you select Mailbox and have not set up your e-mail
account, you are prompted to do so. To start setting up
the e-mail account with the mailbox guide, select Yes.
1. To start entering the e-mail settings, select Start.
2. In Mailbox type, select IMAP4 or POP3, and select Next.
Tip: POP3 is a version of the post office
protocol that is used to store and retrieve e-
mail or Internet mail messages. IMAP4 is a
version of the Internet message access
protocol that lets you access and manage e-
mail messages while the messages are still on
the e-mail server. You can then choose which
messages to download to your device.
3. In My e-mail address, enter your e-mail address. To
insert the@ sign or other special characters, press *.
To insert a full stop, press 1. Select Next.
4. In Incoming mail serv., enter the name of the remote
server that receives your e-mail, and select Next.
5. In Outgoing mail serv., enter the name of the remote
server that sends your e-mail, and select Next.
45
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 45 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 45 Dec 22, 2005 4:45:59 AM
6. In Access point, select the Internet access point your
device should use when it retrieves the e-mails. If you
select Always ask, each time the device starts to
retrieve e-mail, it asks which Internet access point it
should use, but if you select an access point, the device
makes the connection automatically. Select Next.
7. Enter a name for your new mailbox, and select Finish.
When you create a new mailbox, the name you give to the
mailbox replaces Mailbox in the Messag. main view. You
can have up to six mailboxes.
Connect to mailbox
E-mail addressed to you is not automatically received by
your device, but by your remote mailbox. To read your e-
mail, you must first connect to the remote mailbox; then
select the e-mails you wish to retrieve into your device.
To receive and send e-mail, you need to register for an e-
mail service. To set up a mailbox in your device, select
Messag. > Options > Settings > E-mail > Mailboxes >
Options > New mailbox. Contact your service provider for
the correct settings.
To retrieve received e-mail messages to your device and
view them online, select your mailbox in the Messag. main
view. When the device asks Connect to mailbox? select
Yes.
To view e-mail messages in a folder, scroll to the folder,
and press the joystick. Scroll to a message, and press the
joystick.
To retrieve e-mail messages to your device, select
Options > Retrieve e-mail > New to retrieve new
messages that you have neither read or retrieved,
Selected to retrieve only messages you have select from
the remote mailbox, or All to retrieve all messages not
previously retrieved.
To connect to a remote mailbox, select Options >
Disconnect.
View e-mail offline
Working offline means that your device is not connected
to a remote mailbox. Managing your e-mail offline
enables you to save in connection costs and work in
conditions that do not allow a data connection. Any
changes you make in the remote mailbox folders while
offline take effect in your remote mailbox the next time
you go online and synchronize. For example, if you delete
an e-mail from your device when offline, the e-mail will
be deleted from the remote mailbox the next time you
connect to the mailbox.
To view e-mail offline, select your mailbox. When the
device asks Connect to mailbox? select Yes.
To view new e-mail messages offline, you need to retrieve
them first from your remote mailbox. To retrieve e-mail
messages to your device, select Options > Retrieve e-
mail > New to retrieve new messages that you have
neither read or retrieved, Selected to retrieve only
messages you have select from the remote mailbox, or
All to retrieve all messages not previously retrieved.
To return to the offline mode, select Options >
Disconnect.
To view an e-mail message, scroll to it, and press the
joystick.
46
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 46 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 46 Dec 22, 2005 4:45:59 AM
Some options require you to connect to your remote
mailbox.
Tip: To subscribe to other folders in your remote
mailbox, select E-mail settings > Retrieval
settings > Subscribed folders. E-mail in all
subscribed folders is updated when you retrieve
e-mail from your remote mailbox.
Read and reply to e-mail
Important: E-mail messages may contain viruses
or otherwise be harmful to your device or PC. Do not open
any attachment if you are not sure of the trustworthiness
of the sender.
To read a received e-mail, scroll to the e-mail and press
the joystick.
To open an attachment, select Options > Attachments.
Scroll to the attachment, and press the joystick.
To reply only to the sender of an e-mail, open the e-mail,
and select Options > Reply > To sender.
To reply to all recipients of an e-mail, open the e-mail, and
select Options > Reply > To all.
To delete an attachment from an e-mail that you are
sending, select the attachment and Options >
Attachments > Remove.
Tip: If you reply to an e-mail that contains
attached files, the attachments are not included
in the reply. If you forward the received e-mail,
attachments are included.
To forward an e-mail, open the e-mail, and select
Options > Forward.
Delete messages
To free up memory space on your device, regularly delete
messages from the Inbox and Sent folders, and delete
retrieved e-mail messages.
To delete a message, scroll it, and press the clear key.
You can select to delete local e-mail messages on the
device and keep the original on the server, or you can
delete both the local e-mail messages on the device and
the original messages on the server.
To delete e-mails from the device only, select Options >
Delete > Phone only.
To delete e-mail both from the device and from the
remote server, open an e-mail, and select Options >
Delete > Phone and server.
E-mail folders
If you create subfolders in your IMAP4 mailboxes on a
remote server, you can view and manage these folders
with your device. You can only subscribe to folders in your
IMAP4 mailboxes. Subscribing to folders in a remote
mailbox allows you to view those folders on your device.
To view folders in your IMAP4 mailbox, establish a
connection, and select Options > E-mail sett. > Retrieval
settings > Subscribed folders.
To view a remote folder, select a folder and Options >
Subscribe. Every time you go online, the subscribed
47
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 47 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 47 Dec 22, 2005 4:45:59 AM
folders are updated. This may take some time if the
folders are large.
To update the list of folders, select a folder and Options >
Update folder list.
Write and send e-mail
To write an e-mail, select Options > Add recipient to
select the recipients' e-mail addresses from the contacts
list, or enter the e-mail addresses in the To field. Use a
semicolon to separate entries. Scroll down, and use the
Cc field to copy other recipients, or the Bcc field to blind
copy recipients. In the Subject field, enter the subject of
the e-mail. Enter your e-mail message in the text area, and
select Options > Send.
To attach a file to an e-mail, select Options > Insert. Select
Image, Sound clip, Video clip, Note, or Template.
To set the sending time for an e-mail message, select
Options > Sending options > Send message, and
select Immediately or During next conn. if you are
working offline.
E-mail messages are stored in the Outbox before sending.
Unless the e-mail is sent immediately, you can open the
Outbox and suspend and resume sending or view the e-
mail.
E-mail account settings
Select Menu > Messag. > Mailbox.
The settings available for editing may vary. Some settings
may be preset by your service provider.
If you try to edit mailbox settings but have not set up an
e-mail account, the mailbox guide opens and helps you
set up your e-mail account.
Settings for the e-mail that you receive
Select Incoming e-mail, and define the following:
•User name — Enter the user name for the e-mail
service.
•Password — Enter the password for the e-mail service.
•Incoming mail serv. — Enter the IP address or host
name of the server that receives your e-mail.
•Access point in use — Select the Internet access point
that the device uses for retrieving the e-mail messages
that you receive.
•Mailbox name — Enter a name for the mailbox.
•Mailbox type — Select the mailbox protocol that your
remote mailbox service provider recommends. The
options are POP3 and IMAP4. This setting can be
selected only once and cannot be changed if you have
saved or exited from the mailbox settings. If you use
the POP3 protocol, e-mail messages are not updated
automatically when you are online. To see the latest e-
mail messages, you must disconnect and make a new
connection to your mailbox.
•Security (ports) — Select the security option used to
secure the connection to the remote mailbox.
•Port — Define a port for connection.
•APOP secure login (for POP3 only) — Use with the POP3
protocol to encrypt the sending of passwords to the
remote e-mail server while connecting to the mailbox.
Settings for the e-mail that you send
Select Outgoing e-mail, and define the following:
48
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 48 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 48 Dec 22, 2005 4:45:59 AM
•My e-mail address — Enter the e-mail address given to
you by your service provider. Replies to your messages
are sent to this address.
•User name — Enter the user name for the e-mail
service.
•Password — Enter the password for the e-mail service.
•Outgoing mail serv. — Enter the IP address or host
name of the mail server that sends your e-mail. You
may only be able to use the outgoing server of your
network operator. Contact your service provider for
more information.
•Access point in use — Select the Internet access point
that the device uses for sending the e-mail messages
that you send.
•Security (ports) — Select the security option used to
secure the connection to the remote mailbox.
•Port — Define a port for connection.
User settings
Select User settings, and define the following:
•My name — Enter a name to appear before your e-mail
address when you send e-mail.
•Send message — Select to send the e-mail as soon as
possible, to send it the next time you retrieve e-mail,
or to store the e-mail in the Outbox, from where you
can send it later.
•IMAP4 folder path — Enter the path to the IMAP4 inbox
location in case the server cannot open it
automatically. Normally you do not need to define the
path. This settings is only visible if you are editing an
IMAP4 mailbox.
•Folder subscriptions — Select folders that are
retrieved when connected to a mailbox.
•Send copy to self — Select whether you want to save
a copy of the e-mail to your remote mailbox and to the
address defined in My e-mail address in the settings
for Outgoing e-mail.
•Include signature — Select whether you want to
attach a signature to your e-mail messages.
•New e-mail alerts — Select whether you want to
receive the new e-mail indications, a tone and a note,
when new mail is received to the mailbox.
•Default encoding — Select another encoding
according to language.
Retrieval settings
Select Retrieval settings, and define the following:
•E-mail to retrieve — Select whether you want to
retrieve only the e-mail header information such as
sender, subject and date, e-mail, or e-mail with
attachments.
•Retrieval amount — Select the number of e-mails you
want to retrieve from the remote server to your
mailbox.
•IMAP4 folder path (for IMAP4 mailboxes
only) — Define the folder path for folders to be
subscribed.
•Folder subscriptions (for IMAP4 mailboxes
only) — Subscribe to other folders in the remote
mailbox and retrieve content from those folders.
Automatic retrieval settings
Select Automatic retrieval, and define the following:
•E-mail notifications — Select whether you want to
receive notifications when new e-mail is received in
your remote mailbox. Select Always on to always
49
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 49 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 49 Dec 22, 2005 4:45:59 AM
automatically retrieve new e-mail messages from your
remote mailbox, or Only in home net. to automatically
retrieve new e-mail messages from your remote
mailbox only when you are in your home network and
not, for example, traveling.
•Retrieval days — Select the days on which e-mails are
retrieved to your device.
•Retrieval hours — Define the hours between which
the e-mails are retrieved.
•Retrieval interval — Select the time interval between
retrieving new e-mails.
Instant messaging
Select Menu > Connect. > IM.
Instant messaging (IM, network service) allows you to
converse with other people using instant messages and
join discussion forums (IM groups) with specific topics.
Various service providers maintain IM servers that you can
log in to after you register to an IM service. Service
providers may differ in their support of features.
If IM is not available from your wireless service provider,
it may not appear in the menu of your device. Contact your
service provider for more information about signing up
for IM services and costs for services. For more
information on the availability of IM settings, contact your
network operator, service provider, or dealer.
You may receive the settings in a special text message
from the network operator or service provider that offers
the IM service. You must save the settings to access the
service that you want to use. You can also enter the
settings manually.
Connect to an IM server
To converse with an IM user or users, and to view and edit
your IM contacts, you must log into the instant messaging
server. Open IM, and select Options > Login. Enter your
user ID and password, and press the joystick to log in. You
can obtain the user name, password, and other settings
to log in from your service provider when you register for
the service.
Search IM users or IM groups
To search for IM users and user IDs, select IM contacts >
Options > New IM contact > Search. You can search by
User's name, User ID, Phone number, and E-mail address.
To search for IM groups and group IDs, select IM
groups > Options > Search. You can search by Group
name, Topic, and Members (user ID).
Conversations with a single IM user
The Conversations view shows a list of the individual
conversation participants that you have an ongoing
conversation with. Ongoing conversations are
automatically closed when you exit IM.
To view a conversation, scroll to a participant, and press
the joystick.
To continue the conversation, enter your message, and
press the joystick.
To return to the conversations list without closing the
conversation, select Back. To close the conversation,
select Options > End conversation.
50
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 50 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 50 Dec 22, 2005 4:45:59 AM
To start a new conversation, select Options > New
conversation. You can start a new conversation with a
different contact while you are inside another active
conversation. However, you cannot have two active
conversations with the same contact.
To save a conversation participant to your IM contacts,
select Options > Add to IM contacts.
To save a conversation, while in the conversation view,
select Options > Record chat. The conversation is saved
as a text file that can be opened and viewed in the
Notes application.
To send automatic replies to incoming messages, select
Options > Set auto reply on. You can still receive
messages.
IM groups
The IM groups view shows a list of the IM groups that you
have saved or are currently joined to.
IM groups is available only if you logged into an IM server
when you opened the IM application, and the server
supports IM groups.
To create an IM group, select Options > Create new group.
To join an IM group or to continue a group conversation,
scroll to the group, and press the joystick. Enter a
message, and press the call key to send it.
To join an IM group that is not on the list, but for which
you know the group ID, select Options > Join new group.
To leave the IM group, select Options > Leave IM group.
To remove an IM group, press the clear key.
Ban from groups
Scroll to the IM group, and select Options > Group >
Settings > Banned list.
To prevent IM users from joining the group, select
Options > Add to banned list and select from the
following:
•IM contact — Ban one or several of your IM contacts.
•Enter user ID — Enter the ID of the IM user.
To allow a banned user to join the group, select
Options > Remove.
IM contacts
When login to an IM service is complete, your contact list
for the service provider is retrieved automatically. If your
contact list is not available, wait a few minutes and try to
retrieve your contacts list manually.
Tip: The online status of your IM contacts is
shown by an indicator next to the contact name.
To create an IM contact card, select Options > New IM
contact. Enter the user ID and a nickname, and select
Done. The user ID can be up to 50 characters, and the IM
service provider may require the user ID to be in the
username@domain.com format. The nickname is
optional.
To view a different list of your IM contacts, select
Options > Change contact list.
Scroll to an IM contact, select Options and select from the
following:
51
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 51 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 51 Dec 22, 2005 4:45:59 AM
•Open conversation — Start or continue instant
messaging with the contact.
•Contact details — View the contact card.
•Editing options — Edit or delete the contact card,
move it to another contact list, or receive a note when
the contact's online status changes.
•Belongs to groups — See the IM groups the contact has
joined.
•New contact list — Create a contact list for a specific
group of IM contacts.
•Reload users avail. — Update the online status of your
IM contacts.
•Blocking options — Prevent or allow the reception of
messages from the contact.
•Login — Connect to an instant messaging server if you
did not log in when you opened the application.
•Logout — Disconnect from the IM server.
•Settings — Edit instant messaging application or
server settings.
The available options may vary.
To delete an IM contact, press the clear key.
Blocked contacts
Select IM contacts > Options > Blocking options > View
blocked list.
To find a blocked IM user, enter the first letters of the
user's name. Matching names appear in a list.
To allow receiving messages from a blocked IM user,
select Options > Unblock.
To prevent receiving messages from other IM users, select
Options > Block new contacts. Select the IM user from
your IM contacts, or enter the user ID.
Settings
Select Options > Settings > IM settings.
Define the following:
•Use screen name — To change the name that
identifies you in IM groups, select Yes.
•Allow msgs. from — Select to receive instant messages
from all other IM users, your IM contacts only, or not to
receive messages at all.
•Allow invitats. from — Select to receive invitations to
IM groups from all IM users, your IM contacts only, or
not to receive invitations at all.
•Msg. scrolling speed — To decrease or increase the
speed at which new messages are displayed, scroll left
or right.
•Sort IM contacts — Select to list your IM contacts
alphabetically or by their online status.
•Availabil. reloading — To update the online status of
your IM contacts automatically, select Automatic.
•Offline contacts — Select if IM contacts with an offline
status are shown in the IM contacts list.
The settings available for editing may vary. Contact your
service provider for more information.
IM server settings
Select Options > Settings > Server settings.
Scroll to the following options and press the joystick to
configure your IM server:
•Servers — Add new, edit, or delete servers.
•Default server — Change the server to which your
device automatically logs into, scroll to the desired
server and press the joystick.
52
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 52 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 52 Dec 22, 2005 4:45:59 AM
•IM login type — To establish a connection between
your device and the default server automatically, select
Automatic. Select Aut. in home net. to automate the
connection when in your home network. Select On app.
start-up to connect to the server when you open the
messaging application. Select Manual to connect to the
server manually at any time.
Special messages
Your device can receive many kinds of messages that
contain data:
•Operator logo — To save the logo, select Options >
Save.
•Ringing tone — To save a ring tone, select Options >
Save.
•Configuration message — You may receive settings
from your network operator, service provider, or
company information management department in a
configuration message. To accept the settings, open
the message, and select Options > Save all.
•E-mail notification — The note tells you how many
new e-mails you have in your remote mailbox. An
extended notification may list more detailed
information.
Send service commands
Send a service request message to your service provider
and request activation for certain network services.
To send a service request to your service provider,
select Options > Service command. Enter the service
request as a text message, and select Options > Send.
Sync e-mail
Sync e-mail settings
With Sync e-mail you can synchronize your e-mail
between the device and server.
Select Menu > Messag. > Options > Settings > Sync e-
mail.
To define a new sync mailbox, select Options > New
mailbox. Enter a name for the mailbox and your e-mail
address.
To define the default sync mailbox, scroll to Mailbox in
use and select Options > Change.
Sync mailbox
Select Menu > Messag. > Sync mailbox. The mailbox is
available only if you have defined it in the settings.
The sync mailbox contains four folders: Inbox, Drafts,
Sent, and Outbox. When you synchronize the sync
mailbox, all these folders are synchronized.
To synchronize your mailbox, select Options >
Synchronisation. If you have not synchronized your device
before, select Settings and define the needed settings.
Otherwise, select Start to start the synchronization.
53
Messages
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 53 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 53 Dec 22, 2005 4:45:59 AM
Camera
You can take photos or record video clips with the built-
in camera. The camera lens is on the back of the device,
and the display works as a viewfinder. The camera
produces pictures in .jpeg format and video clips in .3gpp
format.
Take a picture
1. Select Menu > Media > Camera.
The Nokia 6830 device supports an image capture
resolution of 325 x 416 pixels. The image resolution
in these materials may appear different.
2. Use the display as a viewfinder, aim at your subject,
and press the joystick. The device saves the photo in
the default folder, or in the folder you have defined.
Tip: To zoom in or out before taking a picture,
scroll up or down.
3. If you do not want to keep the saved photo, select
Options > Delete. Select Back to return to the
viewfinder to take another picture. Select Options >
Go to Gallery to view the photo in Gallery.
If the light is dim, select Options > Night mode after you
have opened Camera but before taking a picture.
To adjust the image quality, select Options > Adjust >
Brightness, Contrast, White balance, or Colour tone.
To take pictures in a sequence, select Options > Sequence
mode. The camera takes six pictures in a row.
To take timed pictures, select Options > Self-timer, select
the desired timeout, and press Activate. The camera takes
a picture after the timeout has passed.
Tip: You can view and modify photos in Menu >
Media > Gallery > Images.
Record a video clip
1. Select Camera, and scroll right to activate the video
recorder.
2. To start recording a video clip, press the joystick.
3. The remaining recording time is shown on the top of
the display. To pause the recording, select Pause; to
resume the recording, select Continue.
4. To stop the recording, select Stop. The device saves
the clip in the default folder, or in the folder you have
defined.
5. If you do not want to keep the saved video clip, select
Options > Delete. Select Back to return to the
viewfinder to record another video clip. Select
Options > Play to view the video clip in the
RealPlayer application.
Camera settings
To edit the image settings, select Options > Settings >
Image, and define the following:
54
Camera
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 54 Dec 22, 2005 4:45:59 AM
•Image quality — Define how much the picture is
compressed when being saved. High provides the best
image quality, but takes more memory. Normal is the
default quality setting. Basic takes the least amount of
memory.
•Show captured img. — Select whether you want the
captured image to be displayed after the capture.
•Image resolution — Select the resolution of the
images you capture. The default setting for the
resolution is always the lowest setting.
•Default image name — Select Date or Text for the
default title assigned to a picture. Date assigns the date
of the capture as the title. Text assigns the term you
define and a number to the picture.
•Memory in use — Select the memory to use for storing
images: Phone memory or Memory card.
To edit the video settings, select Options > Settings >
Video, and define the following:
•Length — Select the length of the video clips that you
record. The maximum length of a video clip depends
on the available memory. The camera records video
clips up to 100 KB, which is about 10 seconds long. Only
video clips that are of default length or shorter can be
sent in a multimedia message.
•Video resolution — Select the resolution to use during
video recording. The default setting for the resolution
is always the lowest setting.
•Default video name — Select Date or Text for the
default title assigned to a recorded video. Date assigns
the date of the recording as the title. Text assigns the
term you define and a number to the recorded video.
•Memory in use — Select the memory to use for storing
recorded videos: Phone memory or Memory card.
55
Camera
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 55 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 55 Dec 22, 2005 4:45:59 AM
Connectivity
Copyright protections may prevent some images, music
(including ringing tones), and other content from being
copied, modified, transferred or forwarded.
Your device offers several options to connect to the
Internet, a corporate intranet, or to another device or PC.
Wireless methods include wireless LAN, Bluetooth, and
infrared. Your device supports a wired solution with a USB
(Universal Serial Bus) cable connection for Nokia PC Suite
or IP passthrough. Your device also allows you to
communicate using Voice over IP, push to talk, chat, and
fax/modem-based connections.
Cable connection
Install the USB data cable driver to your PC before you use
a cable connection.
Select Menu > Connect. > Data cbl..
Using a USB data cable, you can connect your device to a
compatible PC . Connect the USB data cable to the bottom
of the device or to the desk stand of the device.
To change the device type you normally connect to your
phone with the data cable, press the joystick.
Select from the following:
•Ask on connection — to be asked for the device type
every time you connect the data cable to your phone.
•PC Suite — to connect the PC Suite to your device with
the data cable, or to use your device as a modem.
•Data transfer — to access and transfer data such as
music or image files from your computer to your phone
memory card using the data cable connection. The
device will switch into the Offline mode if this is
selected. End the connection from the PC to avoid
damaging the memory card.
•IP passthrough — to select an access point through
which to transfer data using the Internet protocol.
To save your selection, select Back.
Wireless local area network
(WLAN)
There may be restrictions on using wireless LAN in some
locations. Check with your local authorities or service
provider.
Features using wireless LAN, or allowing such features to
run in the background while using other features,
increase the demand on battery power and reduce the
battery life.
This device can detect and connect to a wireless local area
network.
If you move the device to another location within the
wireless LAN and out of range of a wireless LAN access
point, the roaming functionality can automatically
connect your device to another access point that belongs
to the same network. As long as you remain within range
56
Connectivity
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 56 Dec 22, 2005 4:45:59 AM
of access points that belong to the same network, your
device can stay connected to the network.
Tip: A wireless LAN connection is established
when you create a data connection using a
wireless LAN Internet access point. The active
wireless LAN connection is ended when you end
the data connection.
Your device enables different types of communication in
a wireless LAN. The two operating modes are
infrastructure and ad hoc.
•The infrastructure operating mode allows two kinds of
communication: wireless devices communicate with
each other through a wireless LAN access point or
wireless devices communicate with a wired LAN device
through a wireless LAN access point.
The advantage of the infrastructure operating mode is
that you can have more control over network
connections because they pass through an access
point. A wireless device can access the services that are
available in a regular wired LAN: company database,
e-mail, the Internet, and other network resources, for
example.
•With third party applications, you can send and receive
data directly with each other in the ad hoc operating
mode, for example, to print. No wireless LAN access
point is required. Simply make the necessary
configurations and start communicating. Ad hoc
networking is easy to set up, but communication is
limited to devices that are within range.
Mobile VPN
A mobile virtual private network (VPN) allows you to
access a corporate intranet and e-mail securely. Your
device connects from a mobile network, through the
Internet, to a corporate VPN gateway that acts as a front
door to the corporate network. IPSec is used to create a
secure tunnel to a dedicated VPN access point over
unsecured IP networks. A VPN access point is made up of
an internet access point and a VPN policy.
If VPN software is not integrated into production
software, it may be delivered as a Symbian software
installation system file (.sis). After VPN software is
installed, your device must be restarted to incorporate the
IPSec protocol. VPN policies and policy server definitions
may be delivered as a .sis file. Installation is automatic;
however, a certificate policy contains encrypted private
keys that require a password.
Define a VPN connection through ADSL, GRPS, WLAN, or
dial-up. To use mVPN with an application, the application
must be associated with a VPN access point. To connect
to a VPN gateway, define and select a VPN connection
type, connect to the internet or to a corporate intranet,
and start the mVPN application on your device.
Bluetooth
There may be restrictions on using Bluetooth technology
in some locations. Check with your local authorities or
service provider.
Features using Bluetooth technology, or allowing such
features to run in the background while using other
57
Connectivity
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 57 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 57 Dec 22, 2005 4:45:59 AM
features, increase the demand on battery power and
reduces the battery life.
This device is compliant with Bluetooth Specification 1.2
supporting the following profiles: Generic Access Profile,
Serial Port Profile, Dial-up Networking Profile, Headset
Profile, Handsfree Profile, Generic Object Exchange Profile,
Object Push Profile, File Transfer Profile, SIM Access Profile,
and Basic Imaging Profile. To ensure interoperability
between other devices supporting Bluetooth technology,
use Nokia approved enhancements for this model. Check
with the manufacturers of other devices to determine
their compatibility with this device.
Bluetooth technology enables wireless connections
between electronic devices within a range of 10 meters
(33 feet). A Bluetooth connection can be used to send
images, videos, texts, business cards, calendar notes, or
to connect wirelessly to devices using Bluetooth
technology, such as computers.
Since devices using Bluetooth technology communicate
using radio waves, your device and the other devices do
not need to be in direct line-of-sight. The two devices only
need to be within a maximum of 10 meters of each other,
although the connection can be subject to interference
from obstructions such as walls or from other electronic
devices.
Start using Bluetooth
Select Menu > Connect. > Bluetooth.
1. When you activate Bluetooth for the first time, you are
asked to give a name to your device. Give your device
a unique name to make it easy to recognize if there
are several Bluetooth devices in the vicinity.
2. Select Bluetooth > On.
3. Select My phone's visibility > Shown to all.
Your device and the name you entered can now be seen
by other users with devices using Bluetooth technology.
Bluetooth settings
Define the following:
•Bluetooth — Select On to be abl e to con nec t t o an other
compatible device using Bluetooth connectivity.
•My phone's visibility — Select Shown to all to allow
other devices using Bluetooth technology to find your
device when you have set Bluetooth > On. To prevent
other devices from finding your device, select Hidden.
Even if you select Hidden, paired devices can still detect
your device.
•My phone's name — Enter a name for your device. The
name is visible to other devices that search for devices
using Bluetooth technology. The maximum length of
the name is 30 characters.
•Remote SIM mode — Select On to enable another
device, such as a compatible car kit enhancement, to
use the SIM card in your device to connect to the
network. See "SIM access profile," p. 60.
If Bluetooth was turned off as a result of entering
Offline profile, you must re-enable Bluetooth manually.
Security tips
When you are not using Bluetooth connectivity, select
Bluetooth > Off or My phone's visibility > Hidden.
Do not pair with an unknown device.
58
Connectivity
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 58 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 58 Dec 22, 2005 4:45:59 AM
Send data with Bluetooth
Several Bluetooth connections can be active at a time. For
example, if you are connected to a headset, you can also
transfer files to another compatible device at the same
time.
1. Open the application where the item you want to send
is stored.
2. Select the item, and select Options > Send > Via
Bluetooth. The device searches for other devices using
Bluetooth technology within range and lists them.
Tip: If you have sent data using Bluetooth
before, a list of the previous search results is
displayed. To search for more Bluetooth
devices, select More devices.
3. Select the device with which you want to connect, and
press the joystick to set up the connection. If the other
device requires pairing before data can be
transmitted, you are asked to enter a passcode.
4. When the connection has been established, Sending
data is shown.
The Sent folder in Messag. does not store messages sent
using Bluetooth connectivity.
Bluetooth connectivity indicators
Bluetooth is active.
When the icon is blinking, your device is trying to
connect to the other device. When the icon is shown
continuously, the Bluetooth connection is active.
Pair devices
Select Menu > Connect. > Bluetooth, and scroll right to
open the Paired devic. page.
Pairing means authentication. Pairing with a compatible
device makes connecting to a device quicker and easier,
as you do not have to accept a device manually every time
you connect to it. Before pairing, create your own
passcode (1-16 digits) and agree with the user of the
other device to use the same code. Devices that do not
have a user interface have a preset passcode. The
passcode is used only once.
1. Select Options > New paired device. The phone starts
to search for Bluetooth devices within range.
Tip: If you have sent data using Bluetooth
before, a list of the previous search results is
displayed. To search for more Bluetooth
devices, select More devices.
2. Select the device with which you want to pair, and
enter the passcode. The same passcode must be
entered to the other device as well.
3. Select Yes to make the connection between your
device and the other device automatic, or No to
confirm the connection manually every time a
connection attempt is made. After pairing, the device
is saved to the paired devices page.
To give a nickname to a paired device that is only
displayed in your phone, scroll to the device, and select
Options > Assign short name.
59
Connectivity
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 59 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 59 Dec 22, 2005 4:45:59 AM
To cancel a pairing, select the device whose pairing you
want to cancel, and Options > Delete. To cancel all
pairings, select Options > Delete all.
Tip: If you are currently connected to a device and
cancel the pairing with that device, pairing is
removed immediately, and the connection is
switched off.
Authorize a device
If you trust a paired device, you can allow it to connect
automatically to your device. You can select from the
following options:
•Set as authorised — Connections between your device
and the other device can be made without your
knowledge. No separate acceptance or authorization
is needed. Use this status for your own devices, such
as your compatible headset or PC, or devices that
belong to someone you trust.
•Set as unauthorised — Connection requests from the
other device must be accepted separately every time.
Receive data with Bluetooth
If you want to receive data using Bluetooth, select
Bluetooth > On and My phone's visibility > Shown to
all. When you receive data through Bluetooth
connectivity, a tone sounds, and you are asked if you want
to accept the message. If you accept, the message is
placed in the Inbox folder in Messag.
SIM access profile
With the SIM access profile, you can access the SIM card of
your device from a compatible car kit device. This way,
you do not need a separate SIM card to access SIM card
data and connect to the GSM network.
To use the SIM access profile, you need the following:
•Compatible car kit device that supports Bluetooth
wireless technology
•Valid SIM card in your device
For more information about car kit devices and
compatibility with your device, see www.nokia.com and
your car kit user guide.
Manage the SIM access profile
1. Activate Bluetooth technology in your device. Select
Menu > Connect. > Bluetooth .
2. Scroll to Remote SIM mode, and press the joystick to
enable remote sim access.
3. Activate Bluetooth in the car kit device.
4. Use your car kit device to start a search for compatible
devices. For instructions, see the user guide of your car
kit device.
5. Select your device from the list of compatible devices.
6. To pair the devices, enter the Bluetooth passcode
shown on the display of the car kit device to your
device.
7. Authorize the car kit device. Select Menu >
Connect. > Bluetooth, and scroll to the Paired devic.
page. Scroll to the car kit device, and enter the
Bluetooth passcode. When the device asks to make
60
Connectivity
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 60 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 60 Dec 22, 2005 4:45:59 AM
the connection automatic, select Yes. Connections
between your device and the car kit device can be
made without separate acceptance or authorization.
If you selectNo, connection requests from this device
must be accepted separately every time.
Tip: If you have already accessed the SIM card
from the car kit with the active user profile, the
car kit searches automatically for a device with
the SIM card. If it finds your device, and automatic
authorization is activated, the car device
automatically connects to the GSM network when
you switch on the car ignition.
When you have activated the remote SIM access profile,
you can use applications on your device that do not need
network or SIM services.
To end the remote SIM access connection from your
device, select Menu > Connect. > Bluetooth > Remote
SIM mode > Off.
Infrared
Do not point the IR (infrared) beam at anyone's eye or
allow it to interfere with other IR devices. This device is a
Class 1 laser product.
Use infrared to connect two devices and transfer data
between them. With infrared, you can transfer data such
as business cards, calendar notes, and media files with a
compatible device.
Send and receive data with infrared
1. Ensure that the infrared ports of the devices face each
other. The positioning of the devices is more
important than angle or distance.
2. Select Menu > Connect. > Infrared and press the
joystick to turn on infrared on your device. Turn on
infrared on the other device.
3. Wait a few seconds until an infrared connection is
established.
4. To send, locate the desired file in an application or the
file manager, and select Options > Send > Via
infrared. To receive, the user of the sending device
selects the desired infrared function to start the data
transfer.
If data transfer is not started within 1 minute after the
activation of the infrared port, the connection is cancelled
and must be started again.
All items received through infrared are placed in the Inbox
folder in Messag..
Positioning devices away from each other breaks a
connection, but the infrared light beam remains active on
your device until it is deactivated.
Modem
Select Menu > Connect. > Modem.
Together with a compatible computer, you can use your
device as a modem to connect to the Web and send or
receive faxes.
Before you can use your device as a modem
61
Connectivity
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 61 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 61 Dec 22, 2005 4:45:59 AM
•You need the appropriate data communications
software on your computer.
•You must subscribe to the appropriate network
services from your service provider or Internet service
provider.
•You must have the appropriate drivers installed on
your computer. You must install drivers for your cable
connection, and you may need to install or update
Bluetooth or infrared drivers.
•It is recommended that you have Nokia Modem
Options installed on your computer.
To connect the device to a compatible computer using
infrared, press the joystick. Make sure the infrared ports
of the device and computer are directly facing each other
with no obstacles between them.
To connect your device to a computer using Bluetooth,
initiate the connection from the computer. To activate
Bluetooth in your phone, select Menu > Connect. >
Bluetooth and select Bluetooth > On.
If you use a cable to connect your phone to a computer,
initiate the connection from the computer.
Note that you may not be able to use some of the other
communication features when the device is used as a
modem.
Data connections
This device supports packet data (GPRS), high-speed data
calls (HSCSD), GSM data calls, and wireless LAN.
For more information, see the complete user guide.
Packet data
GPRS (general packet radio service) enables wireless
access for mobile phones to data networks (network
service). GPRS uses packet data technology where
information is sent in short bursts of data over the mobile
network. The benefit of sending data in packets is that
the network is occupied only when sending or receiving
data. As GPRS uses the network efficiently, it allows for
quick data connection set-up and fast data transmission
speeds.
You must subscribe to the GPRS service. For availability
and subscription to GPRS, contact your network operator
or service provider.
Enhanced GPRS (EGPRS) is similar to GPRS, but it enables
faster connection. For more information on the
availability of EGPRS and data transfer speed, contact your
network operator or service provider. Note that when you
have selected GPRS as a data bearer, the device uses EGPRS
instead of GPRS if this is available in the network.
During a voice call, you cannot establish a GPRS
connection, and any existing GPRS connection is put on
hold unless the network supports dual transfer mode.
Connection manager
Select Menu > Connect. > Conn mgr.
To view the status of data connections or end
connections, select Act. data conn..
To search for wireless LANs available within range, select
Availab. WLAN.
62
Connectivity
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 62 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 62 Dec 22, 2005 4:45:59 AM
View and end active connections
Note: The actual time invoiced for calls by your
service provider may vary, depending on network
features, rounding off for billing, and so forth.
In the active connections view, you can see the open data
connections: data calls, packet data connections, and
wireless LAN connections.
To view detailed information about network connections,
select the connection from the list and Options >
Details. The type of information shown depends on the
connection type.
To end a network connection, select the connection from
the list and Options > Disconnect.
To end all active network connections simultaneously,
select Options > Disconnect all.
To view the details of a network, press the joystick.
Wireless LAN
To search for wireless LANs available within range, select
Menu > Connect. > Conn mgr > Availab. WLAN. A list of
found networks is displayed.
The available wireless LAN view shows a list of wireless
LANs within range, their network mode (Infrastructure or
Ad-hoc), signal strength indicator and network
encryption indicators, and if your device has an active
connection with the network.
To view the details of a network, press the joystick.
To create an Internet access point in a network, select
Options > Define access point.
63
Connectivity
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 63 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 63 Dec 22, 2005 4:45:59 AM
Web
Select Menu > Web. Enter the address of a Web page and
select Go to.
When you start to enter the address, addresses of pages
you have previously visited that match your writing
appear. To open a page, scroll up to select to the address
and select Go to.
To zoom the page in or out, press * or #.
To open a Web link, scroll to it and press the joystick.
Keyboard shortcuts:
•Press 1 to open your Bookmarks.
•Press 3 to return to the previous page.
•Press 6 to switch between your open browser
windows.
•Press 9 to go to a different Web page.
The available options may vary.
Set preferences for browsing
Select Menu > Web > Options > Settings.
Scroll to the following settings and press the joystick to
edit:
•Access point — Scroll to the access point to connect to
Web pages and press the joystick.
•Show images and objects — To load pages faster
when browsing by not loading the images on them,
select No. You can still choose to load images when
browsing individual pages. Select Options > Show
images.
•Font size — Select the font size that you want to use
when viewing the Web pages.
•Default encoding — Select the correct character
encoding for your language.
•Auto. bookmarks — To save Web page addresses that
you visit automatically in the Auto. bookmarks folder,
select On. To hide the folder, select Hide folder and
press OK.
•Screen size — To use the whole display area for
viewing Web pages, select Full screen. You can press
the left selection key to open Options and use the
available options while browsing in full screen mode.
•Homepage — To select the page that you want to
appear as your homepage, scroll to Default to use the
access point homepage, User defined to enter the
homepage address, or Use current page to use the
currently open Web page.
•[Page overview] — Select whether you want to see an
overview of the page as a miniature on top of the page
you are viewing.
•[Back list] — Select whether you want to see
miniatures of the pages you have visited when you
want to go back in your browsing history.
•Volume — Scroll to the volume level for music or other
sound in Web pages and select OK.
•Cookies — Select to allow or reject the sending and
receiving of cookies. Cookies are info the network
server collects about your visits to various Web pages.
They are necessary if you shop on the Web to retain
64
Web
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 64 Dec 22, 2005 4:45:59 AM
the items you buy until you reach the cashier page, for
example. However, the info may be misused, and you
may receive unwanted advertisements in your device,
for example.
•Java/ECMA script — Some Web pages may include
program commands that affect the appearance of the
page or interaction between the page and its
browsers. To deny the use of such scripts, if you have
trouble downloading, for example, select Disabled.
•Security warnings — Select Show or Hide to see or hide
the security warnings you may receive during
browsing.
•Block pop-ups — Select whether you want to allow
pop-ups. Some pop-ups may be necessary, for example
smaller windows where you write an e-mail, but they
may also contain unwanted advertising.
•Automatic reload — Select whether you want the
page content be updated automatically.
The settings available for editing may vary.
To save the settings, press Back.
Bookmarks
Select Menu > Web. To view a bookmarked Web page,
scroll to the bookmark and press the joystick.
Addresses of the pages you visit are saved in the Auto.
bookmarks folder.
To browse another Web pages, select Options >
Navigation options > Go to web address, enter the page
address and select Go to.
Scroll to a bookmark, select Options and:
•Back to page — to return to the page you visited
before opening Bookmarks.
•Bookmark manager — Select Move to rearrange your
bookmarks, New folder folder to create a folder to
organise your bookmarks, Move to folder to save the
bookmark in another folder, or Edit to change the title,
URL address, access point, user name, or password of
the bookmark
•Navigation options — Select Go to web address to
open another Web page, Homepage to open your
homepage, or Open search page to search for a specific
Web page.
•Tools — Select Downloads to view files you are
currently downloading from the Web, View images to
open a list of images on the page
•Advanced options — Select Disconnect to end the
connection to the Web, Set as homepage to set the
page as your homepage in the Web, Clear cache to
empty the temporary memory that stores info about
your visits to different Web sites, or Delete cookies to
erase the info the Web sites you visit save to your
device.
•Send — to send the bookmark to compatible devices.
•Details — Select Security to see detailed info about
connection security.
•Settings — to edit the settings necessary to connect to
the Web.
The available options may vary.
To delete a bookmark, scroll to it and press the clear key.
To add a bookmark, select Menu > Web > Options >
Bookmark manager > Add bookmark. Scroll to Name to
enter a descriptive name for the bookmark, Address to
enter the Web page address, Access point to change the
65
Web
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 65 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 65 Dec 22, 2005 4:45:59 AM
access point to connect to the Web page, and User
name or Password to enter your user name and pass
word, if required by the service provider. To save the
bookmark, press Back.
Tip: You can also add bookmarks while browsing.
Select Options > Save to bookmarks.
News feeds and blogs
Select Menu > Web > Web feeds.
Feeds are xml files in various Web pages that usually
contain a headlines and articles often about recent news
or other topics. You can subscribe to interesting feeds on
Web pages. Select Options > Subscribe.
Blog is a shortening of Weblog, which is a continuously
updated Web diary . Often the author's personality is an
important factor in the blog.
To download a feed or blog, scroll to it and press the
joystick.
To add a feed or blog, select Options > Manage feed >
New feed, and enter the information.
To edit a feed or blog, scroll to a feed and select Options >
Manage feed > Edit, and modify the information
The available options may vary.
Web in applications
To open Services from another application, select
Options and the relevant option, or scroll to a Web link, if
available, and press the joystick.
66
Web
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 66 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 66 Dec 22, 2005 4:45:59 AM
Services
Your device has an HTML/XHTML browser that allows you
to connect to the Internet using GPRS or EDGE. The
browser supports compatible plug-ins.
To connect to the World Wide Web:
You must configure the Internet access point and Internet
connection settings. If you are using a data call or a GPRS
connection, your wireless network must support data
calls or GPRS, and the data service must be activated for
your SIM card. Contact your service provider for the correct
settings.
Internet access points
An access point is where your device connects to a
network. To use e-mail and multimedia services or to
connect to the Internet and browse web pages, you must
first define Internet access points for these services. You
may need to set up several Internet access points,
depending on the sites you want to access. For example,
browsing the Web may require one access point, and
accessing your company intranet may require another. To
connect to the Internet over GPRS, your device may have
predefined, default Internet access point settings.
When you switch on your device for the first time, the
access points may be configured automatically based on
the service provider information in your SIM card. You can
also receive the access points settings in a message from
your service provider. This might reduce the number of
settings you need to enter yourself.
The available options may vary. Some or all access points
may be preset for your phone by your service provider.
You may not be able to add, edit, or delete access points.
Contact your service provider and e-mail service provider
for more information on access points and their settings.
See "Connection settings," p. 86.
Set up an Internet access point
1. Select Menu > Tools > Settings > Connection >
Access points.
2. Select Options > New access point. To use an existing
access point as a basis for the new one, select Use
existing settings. To start with an empty access point,
select Use default settings.
3. Define the settings.
•Connection name — Enter a descriptive name for
the connection.
•Data bearer — Select Packet data, Data call, High
speed data (GSM only) or IP passthrough. Packet
data is usually the default.
•Access point name — Enter the name for the access
point. The name is usually provided by your service
provider or network operator.
67
Services
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 67 Dec 22, 2005 4:45:59 AM
•Dial-up number (for data calls only) — Enter the
modem telephone number of the access point. Use
+ before international numbers.
•User name — Enter your user name if required by
the service provider. User names are often case-
sensitive and provided by your service provider.
•Prompt password — Select Yes to enter your
password each time you log into a server, or No to
save the password in your device memory and
automate the login.
•Password — Enter your password if required by
the service provider. The password is often case-
sensitive provided by the service provider.
•Authentication — Select Secure to always send
your password encrypted, or Normal to send your
password encrypted when possible.
•Homepage — Enter the Web address of the page
you want to display as a home page when you use
this access point.
•Data call type (for data calls only) — Select
Analogue or ISDN.
•Max. data speed (for data calls only) — Select the
limit to apply to the transfer speed. If you select
Automatic, the data transfer rate is determined by
the network and may be affected by network
traffic. Some service providers may charge more for
higher data rates.
4. After defining the settings, select Options > Advanced
settings to define the advanced settings, or Back to
save the settings and exit.
68
Services
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 68 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 68 Dec 22, 2005 4:45:59 AM
Media applications
Copyright protections may prevent some images, music
(including ringing tones), and other content from being
copied, modified, transferred or forwarded.
Select Menu > Media.
Media contains different media applications that allow
you to save and view images, record sounds, and play
sound clips.
Gallery
Select Menu > Media > Gallery.
Use Gallery to access and use different types of media,
including images, videos, music, and sounds. All viewed
images and videos and all received music and sounds are
automatically saved to Gallery. You can browse, open, and
create folders; and mark, copy and move items to folders.
Sound clips, video clips, .ram files, and streaming links are
opened in the RealPlayer application.
To open a file or a folder, press the joystick. Images are
opened in the image viewer.
To create a new folder, select Options > Organise > New
folder.
To copy or move files, select a file and Options >
Organise > Move to folder, New folder, Move to memory
card, Copy to memory card, Copy to phone mem., or Move
to phone mem..
To download files into the Gallery in one of the main
folders using the browser, select Graphic downl., Video
downl., Track downl., or Sound downl.. The browser
opens, and you can choose a bookmark or enter the
address for the site to download from.
To search for a file, select Options > Find. Start to enter a
search string (for example, the name or date of the file
you are searching for). Files that match the search are
shown.
Images
Select Menu > Media > Gallery > Images.
Images consists of two views:
•In the image browser view you can send, organize,
delete, and rename images stored in your device or
memory card. You can set images as wallpaper for your
display.
•In the image viewer, which opens when you select an
image in the image browser view, you can view, edit,
and send individual images. TIFF and animated GIF files
cannot be edited.
The following file formats are supported: JPEG, BMP, PNG,
GIF 87a/89a, and TIFF/F (monochrome). The device does
not necessarily support all variations of the file formats.
To open an image for viewing, select an image in the
image browser view, and select Options > Open. The
image opens in the image viewer.
69
Media applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 69 Dec 22, 2005 4:45:59 AM
To open the next or previous image for viewing, scroll
right or left in the image viewer.
To enlarge the viewed image on the display, select
Options > Zoom in, or press 5 or 7. To reduce the viewed
image on the display, select Zoom out or press 0.
To view the image in full screen size, select Options > Full
screen or press 7 twice. To return to normal view, select
Options > Normal screen.
To rotate an image, select an image, and Options >
Rotate. Select Right to rotate the image clockwise by 90
degrees, or select Left to rotate the image
counterclockwise by 90 degrees.
Manage image files
Copyright protections may prevent some images, ringing
tones, and other content from being copied, modified,
transferred or forwarded.
To view detailed information about an image, select an
image and Options > View details. Size, and format of the
file; the time and date the file was last modified; and the
resolution of the image in pixels are displayed.
To send an image, select the image, Options > Send, and
select the method for sending.
To rename an image, select an image, and Options >
Rename. Enter a new name, and select OK.
To set an image as wallpaper, select the image, and
Options > Set as wallpaper.
To add an image to a contact card, select an image, and
Options > Assign to contact. The contacts view opens,
and you can select the contact for the image.
RealPlayer
Copyright protections may prevent some images, ringing
tones, and other content from being copied, modified,
transferred or forwarded.
Select Menu > Media > RealPlayer.
RealPlayer can play video clips and audio files that are
stored in the device memory or on a memory card,
transferred to your device from e-mail or compatible PC,
or streamed to your device over the Web.
Formats supported by RealPlayer include MPEG-4, MP4
(not streaming), 3GP, SDP, RV, RA, RAM, and RM.
RealPlayer does not necessarily support all variations of
a media file format.
Tip: Streaming audio and video files means
playing them directly from the Web, without
downloading them first to your device.
Play video clips and stream links
To select audio and video files to play with RealPlayer,
select Options > Open, and scroll to a media clip in your
device or on a memory card.
To play streaming media, select a Web link that points to
a media clip, and select Play; or connect to the Web,
browse to a video clip or audio file, and select Play.
RealPlayer recognizes two kinds of links: an rtsp:// URL
and an http:// URL that points to a RAM file. Before the
content begins streaming, your device must connect to a
Web site and buffer the content. If a network connection
70
Media applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 70 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 70 Dec 22, 2005 4:45:59 AM
problem causes a playback error, RealPlayer attempts
automatically to reconnect to the Internet access point.
To save a media clip, select Options > Save, scroll to a
folder in device memory or on a memory card, and select
Save. To save a link to a media file on the Web, select Save
link.
To fast-forward or rewind the clip during playback, scroll
up or down.
To increase or decrease the volume during playback, scroll
right or left.
Settings
Select Menu > Media > RealPlayer > Options >
Settings.
Video settings
Select Video, scroll to the following settings and press the
joystick to edit:
•Contrast — Make the image lighter or darker, press the
joystick left or right.
•Loop — Replay video clips automatically after they
finish playing, select On.
Connection settings
Select Connection, scroll to the following settings and
press the joystick to edit:
•Proxy — Select whether to use a proxy server and to
key in the proxy server's IP address and port number.
•Network — Change the access point to connect to the
Internet and to set the port range used when
connecting.
Proxy settings
Proxy servers are intermediate servers between media
servers and their users. Some service providers use them
for additional security or to speed up access to Web pages
that contain media files.
Contact your service provider for the correct settings.
Select Connection > Proxy, scroll to the following settings
and press the joystick to edit:
•Use proxy — Select Enable to use a proxy server.
•Proxy serv. address — Enter the IP address of the proxy
server. This setting is only available if you select to use
a proxy server.
•Proxy port number — Enter the port number of the
proxy server. This setting is only available if you select
to use a proxy server.
Network settings
Contact your service provider for the correct settings.
Select Connection > Network, scroll to the following
settings and press the joystick to edit:
•Default access point — Scroll to the access point to
connect to the Internet, and press the scroll key.
•Online time — Set the time when RealPlayer
disconnects from the network when you pause a
media clip that plays using a network link. Select User
defined, and press the joystick. Enter the time, and
select OK.
•Lowest UDP port — Enter the lowest port number of
the server port range. The minimum value is 1024.
•Highest UDP port — Enter the highest port number of
the server port range. The maximum value is 65535.
71
Media applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 71 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 71 Dec 22, 2005 4:45:59 AM
Music player
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume may
be extremely loud.
Select Menu > Media > Mus. plyr..
With the music player, you can play music files and create
and listen to playlists. The music player supports the
following sound formats: MP3, WAV, MIDI, AMR, and AAC.
Listen to music
Warning: Listen to music at a moderate level.
Continuous exposure to high volume may damage your
hearing.
To select a music track, select Options > Music library. All
tracks lists all music on your device. To view sorted songs,
select Albums, Artists, Genres, or Composers. To play a
track, scroll to the track and select Options > Play. When
a track is playing, to change between play and pause,
press and . To stop a track, press .
After you add or remove music files in the device, update
your Music library. Select Options > Update Music
library. The player searches the device memory for music
files and updates them to the Music library.
To select the previous or next track, scroll the joystick up
or down.
To play the music tracks repeatedly, select Options >
Loop. Select All to repeat all the tracks in the current
folder, One to repeat the selected track, or Off to set off
the repeating.
To play music in random order, select a folder and
Options > Random play.
To view music track information, scroll to the desired
track and select Options > Track details.
Adjust music volume
To control the music volume, scroll left or right. To mute
the volume, scroll left until the volume is muted.
Playlists
You can create a new playlist and add tracks to it, or select
a saved playlist.
To create a new playlist, select Options > Music library >
Track lists > Options > New track list. Write the name of
the new playlist and press OK.
To add a track to a playlist, open the playlist and select
Options > Add tracks.
Equalizer
Select Menu > Media > Mus. plyr. > Options >
Equaliser.
You can personalize the sound of your music files with
Equaliser. You can use preset frequency settings based on
styles of music, like classical or rock. You can also create
customized settings based on your own listening
preferences.
72
Media applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 72 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 72 Dec 22, 2005 4:45:59 AM
You cannot use other functions of Mus. plyr. while
Equaliser is open.
With Equaliser, you can enhance or diminish frequencies
during music playback and modify how your music
sounds. There are preset frequency settings in your
device, for example Classical and Rock.
To use a preset frequency setting when playing music,
scroll to the frequency setting you want to use, and select
Options > Activate.
Create your own frequency setting
1. To create your own frequency setting, select
Options > New preset.
2. Enter a name for the preset frequency setting, and
select OK.
3. Scroll up or down to move between the frequency
bands and set the frequency on each band. To move
between bands, scroll left or right.
4. Select Back to save the new frequency setting, or
select Options > Reset to defaults to set the bands at
a neutral frequency and start over.
Voice recorder
The recorder cannot be used when a data call or GPRS
connection is active.
Select Menu > Media > Recorder.
With Recorder, you can record up to 60 seconds of a voice
memo, save the voice recording as a sound clip, and play
the sound clip. Recorder supports the following formats:
WAV, AMR, AU, and compressed GSM.
To record a voice memo, select Options > Record sound
clip. Select Pause to pause the recording and Record to
resume recording . When you finish recording, select
Stop. The sound clip is automatically saved.
The maximum length of a voice recording is 60 seconds,
but it also depends on the storage space available in
device memory or on a memory card.
Play a voice recording
To listen to a voice recording that you just recorder, select
the play icon. The play icon looks like . Select Stop to
cancel playback. The progress bar displays the playing
time, position, and length of a voice recording.
To pause playback of a voice recording, select Pause.
Playback resumes when you select Play.
Voice recordings that you receive or record are temporary
files. You must save the files that you want to keep.
Flash player
Manage Flash files
Select Menu > Media > Flash plyr.
With Flash plyr, you can view, play, and interact with Flash
files made for mobile devices.
To open a folder or play a Flash file, scroll to the folder or
file and press the joystick.
73
Media applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 73 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 73 Dec 22, 2005 4:45:59 AM
To send a Flash file to compatible devices, scroll to it and
press the Call key.
Copyright protection may prevent the sending of some
Flash files.
Scroll to a Flash file, press Options, and select:
•Organise — Select Copy to folder to save a copy of the
file in another folder, Move to folder to move the file
to a different folder, or New folder to create a folder to
organize your Flash files.
The available options may vary.
To delete a Flash file, scroll to it and press the clear key.
To switch between Flash files saved on your phone
memory or memory card, press the left or right arrow on
the joystick.
Flash files on memory card
Select Menu > Media > Flash plyr. Press the right arrow
on the joystick.
To open a folder or play a Flash file, scroll to the folder or
file and press the joystick.
To send a Flash file to compatible devices, scroll to it and
press the Call key.
Copyright protection may prevent the sending of some
Flash files.
Scroll to a Flash file, press Options, and select:
•Organise — Select Copy to folder to save a copy of the
file in another folder, Move to folder to move the file
to a different folder, or New folder to create a folder to
organize your Flash files.
The available options may vary.
To delete a Flash file, scroll to it and press the clear key.
Flash Player folders
Select Menu > Media > Flash plyr. Scroll to a folder and
press the joystick.
To play a Flash file, scroll to it and press the joystick.
To send a Flash file to compatible devices, scroll to it and
press the call key.
Copyright protection may prevent the sending of some
Flash files.
Scroll to a Flash file, press Options, and select:
•Organise — Copy to folder to save a copy of the file in
another folder, Move to folder to move the file to a
different folder, New folder to create a folder to
organise your Flash files.
The available options may vary.
To delete a Flash file, scroll to it and press the clear key.
To view the contents of other folders, press the left or
right arrow on the joystick.
Play Flash files
Select Menu > Media > Flash plyr. Scroll to a Flash file and
press the joystick.
Options may not be available for all Flash files.
Press Options and select:
•Pause — to pause the playback.
•Stop — to stop the playback.
74
Media applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 74 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 74 Dec 22, 2005 4:45:59 AM
•Save — to save the Flash file on your phone or memory
card.
•Volume — to adjust the playback volume . To increase
or decrease the volume, press the left or right arrow
on the joystick. Press OK.
•Quality — to select the playback quality of the file.
The playback of some Flash files may appear uneven
and slow in High quality due to their original settings.
You may want to change the Quality setting of such
files to Medium or Low for improved playback.
•Full screen — to play the file using the entire display.
To return to normal screen, select Normal screen.
Even though the key functions are not visible in full
screen, they may still be available when you press
either key right below the display.
•Fit to screen — to play the file at its original size after
zooming it.
•Pan mode on — to be able to move around the display
with the joystick when zooming the Flash file.
The available options may vary.
Pause Flash playback
Select Menu > Media > Flash plyr. Scroll to a Flash file and
press the joystick. Press OptionsPause.
Select Options and select:
•Resume — to resume playing the file from where you
paused it.
•Stop — to stop the playback.
•Volume — to adjust the playback volume . To increase
or decrease the volume, press the left or right arrow
on the joystick. Press OK.
•Save — to save the Flash file on your phone or memory
card.
•Quality — to select the playback quality of the file. The
playback of some Flash files may appear uneven and
slow in High quality due to their original settings. You
may want to change the Quality setting of such files to
Medium or Low for improved playback.
•Full screen — to play the file using the entire display.
To return to normal screen, select Normal screen.
Even though the key functions are not visible in full
screen, they may still be available when you press
either key right below the display.
The available options may vary.
Stop Flash playback
Select Menu > Media > Flash plyr. Scroll to a Flash file and
press the joystick. Select OptionsStop.
To send the Flash file to compatible devices, press the call
key.
Select Options and:
•Play — to play the Flash file again.
•Save — to save the Flash file on your phone or memory
card.
•Volume — to adjust the playback volume . To increase
or decrease the volume, press the left or right arrow
on the joystick. Press OK.
•Quality — to select the playback quality of the file. The
playback of some Flash files may appear uneven and
slow in High quality due to their original settings. You
may want to change the Quality setting of such files to
Medium or Low for improved playback
75
Media applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 75 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 75 Dec 22, 2005 4:45:59 AM
•Full screen — to play the file using the entire display.
To return to normal screen, select Normal screen. Even
though the key functions are not visible in full screen,
they may still be available when you press either key
right below the display.
The available options may vary.
76
Media applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 76 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 76 Dec 22, 2005 4:45:59 AM
Office applications
Select Menu > Office.
Some office applications are not available in all
languages.
File manager
With File mgr., you can manage the contents and
properties of files and folders. You can open, create, move,
copy, rename, and search for files and folders. Copyright
protection may prevent sending some files.
Documents
You can open, edit, and save documents created with
Microsoft Word for Windows versions 97 or later. Note
that not all features and formatting of the original files
are supported.
Select Menu > Office > Docum..
To open an existing document, browse for the folder and
document, and press the joystick. To read the document,
select the middle view.
Tip: To open a recently used document, select
Options > Most recent files, select the document,
and press the joystick.
To create a new document, select Options > New file.
Select Blank to create a new document without using a
template, or Use template to create a document based on
an existing template.
To read a document, select the middle view and
Options. You can browse for different types of objects in
the document, zoom in or out, switch between full and
normal screen views, or view objects, such as images. You
can also search for text and edit application settings such
as zooming, scrolling and handling of invisible characters.
Tip: To switch between full and normal screen
views in an open document, press *. To zoom in,
press 5, and to zoom out, press 0.
View objects in a document
To view all objects, such as tables, comments, workbooks,
and video clips in their place in the document, select the
middle view and Options > Browse > Pages and objects.
To open a table, comment, document, workbook, or a
presentation, or to play a sound or a video clip, scroll to
the object or its icon, and press the joystick twice.
To open an image or go to a hyperlink or reference, scroll
to the object, and press the joystick three times.
Edit documents
To be able to edit a document, you must activate the edit
mode: select the middle view and Options > Edit
77
Office applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 77 Dec 22, 2005 4:45:59 AM
document. Select Options > Format, and the appropriate
formatting option. For example, you can add bold, italic,
and underline formatting, change the font size and color,
and add bullets. You can also modify the paragraph
settings such as text alignment and line spacing.
Tip: To cancel an action in the editing mode,
select Options > Undo.
To insert a new object to the document, select Options >
Insert object. Scroll to the desired object type, and
select Options > Insert. If you want to insert a new
document, workbook, or presentation, select Insert new.
To insert an existing document, workbook, presentation,
select Insert existing.
To format the style settings of a paragraph, select
Options > Format > Style. Select the style you want to
format and Options > Edit. Select New style to add a new
style. In the style editing view, select Options > Format,
and the style you want. You can modify the font,
formatting, paragraph, bullet, and border styles.
View document structure
To view the document outline, select the left view. Select
Options > Display headings or Display objects to switch
between chapter heading and object list views. Select
Options > Expand or Collapse to show only main chapters
or all subchapters.
Tip: To open a selected chapter in the normal
view, scroll to the chapter, and press the joystick.
Preview the page layout
To preview the page layout, select the view on the right
and Options.
Define the following options:
•Normal view — Show the current open page in normal
view.
•Pan and zoom — Zoom the page layout view.
•View — Select Full screen or Normal screen to switch
between full screen and normal views.
To zoom the page layout, select the view on the right,
scroll to the desired page, and select Options > Pan and
zoom. A black selection frame appears above the page
layout, showing the area to zoom. Select the area and
Options > Zoom.
Select from the following options:
•In or Out — Select In to zoom in one step in the
selected area, or Out to zoom out one step in the
selected area.
•Fit to screen — Adjust the zoom level to fit the page to
the screen width.
•Ratio — Edit the zoom level, enter the zoom ratio
between 10 and 999, and select OK.
Find text
To find a piece of text from the document, select
Options > Find, enter the text in the Find: field, and press
the joystick.
To change search options such as case sensitivity and
search direction, select Options > Search options.
78
Office applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 78 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 78 Dec 22, 2005 4:45:59 AM
Table editor
You can view tables created in applications, like
documents and MS Word.
To view a table in a file, scroll to the file so that a dotted
line appears around it, and press the joystick.
To change the selected cell, scroll up, down, left or right.
If the selected cell does not fit into visible area, pressing
the joystick pans the whole content first before the cell
changes.
To edit the text in a cell, select the cell, and press the
joystick. To end editing, press the joystick again.
Select Options and:
•Zoom — Zoom the table view in, out and to edit a
zoom ratio.
•Format — You can modify the font style and
formatting, paragraphs, bullets, and borders.
•Cell size — You can change the size of the cells, rows
and columns.
•Cells — Select option to insert, delete, merge or
separate cells.
•Copy table — Copy the text of the whole table to the
clipboard.
Sheet
Select Menu > Office > Sheet.
To open an existing workbook, browse for the folder
where the file is saved, and press the joystick.
To create a new workbook, select Options > New file.
Select Blank to create a new file without using any
template, or Use template to create a file based on an
existing template. Select the worksheet in the outline
view, and press the joystick to open the file.
Work with worksheets
To insert data into cells, open the worksheet view. Use the
joystick to move to the cell, and select Options > Show
cell field > Edit cell field. An upper part editing field
opens. Enter the data, and select Done to finish editing.
To select a range of cells, press and hold the edit key while
you scroll right.
To modify the worksheet view, select Options > View.
Select from the following options:
•Pan worksheet — Define the size of the visible area of
the whole worksheet.
•Full screen — Switch to the full screen view.
•Hide headers — Hide header field and release more
space for the worksheet grid.
•Hide gridlines — Hide gridlines.
To change the font and number formatting, borders, and
alignments, select Options > Format and the appropriate
option.
Work with cells
To insert cells, select the area where you want to insert
new cells and Options > Cells > Insert. You can insert
cells above (Shift cells down) or to the left (Shift cells
right) of the selected range. If you select only one cell, only
one new cell is inserted. If you select a range of cells, a
79
Office applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 79 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 79 Dec 22, 2005 4:45:59 AM
corresponding range of blank cells is inserted. You can
also insert a new row or column.
To delete cells, rows, or columns, select the items you
want to delete and Options > Cells > Delete. You can
delete an entire row or column. If you select Shift cells
left, the selected cells are deleted, and the cells right of
the selected cells are shifted left. If you select Shift cells
up, the cells below the deleted cells are shifted up.
To insert a function into a cell, select a cell. Select
Options > Insert > Function and a function from the list.
For example, MIN finds the lowest value in the numeric
contents of a selected range of cells, AVERAGE calculates
the average of the values, and SUM adds the values
together. Once you have selected a function, press the
joystick. The function is inserted into the selected cell. On
the worksheet, enter the cells you want to include in the
function inside the brackets, and press the joystick.
Tip: Before inserting a function, verify that
Options > Show cell field > Edit grid is active
and that the selected cell is empty or starts with =.
Create and modify charts
When you change the information on a worksheet, the
chart is updated simultaneously.
To open a chart, open the outline view, select the
worksheet and chart, and press the joystick. If charts are
not visible, select Options > Expand.
To create a new chart, select the worksheet cells that
contain the information you want to include in the chart
and Options > Insert > Chart. To change the general
appearance of an existing chart, open a chart view. Select
Options > View > Chart. You can change the name of the
chart and define the cell area. You can change the type of
the chart (line, column, or pie chart). You can make the
chart two or three-dimensional or change the color of the
background and axis. Scroll right to add a title to the chart
and axis.
To format a chart in more detail, open a chart view. Select
Options > View and the object you want to edit. You can
change the series, X-axis, and Y-axis settings (such as the
tick marks of either axis), and data labels.
Presentation
You can open, view, edit, and save presentations created
with Microsoft PowerPoint 97 or later. You can also create
new presentations. Note that not all features and
formatting of the original files are supported.
Select Menu > Office > Presentat..
To open an existing presentation, browse for the folder
and file, and press the joystick.
To create a new presentation, select Options > New file.
Select Blank to create a new presentation without using
a template, or Use template to create a presentation
based on an existing template.
View slide shows
To start a slide show, select Options > Presentation.
Select from the following options:
•Manual — Move from one slide to another manually.
80
Office applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 80 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 80 Dec 22, 2005 4:45:59 AM
•Slide show — Move from one slide to another
manually, or use the automatic slide switching. You
must specify the duration for a slide.
•Manual looped — The slide show continues from the
beginning when the last slide of a presentation has
been shown.
•Looped slide show — The slide show continues
automatically from the beginning when the last slide
of a presentation has been shown.
To move between slides in a slide show, scroll up to
display a previous slide, and scroll down to display the
next slide.
To end the slide show, press the right selection key.
Work with different views
The presentation application consists of different views
that help you when reading and creating presentations.
To switch between the different views, scroll right and left
with the joystick.
Layout view
To open the layout view, select the view in the middle. To
enable or disable the visibility of charts, comments,
tables, images, and shapes, select Options > Settings,
scroll to the settings item, and press the joystick.
Outline view
The outline view is used to navigate through long
presentation documents. The view enables fast vertical
scrolling, rearranging of slides, and editing of objects.
To open the outline view, scroll to the view on the left. In
the outline view, each slide has its own main level entry.
Under the main level there is a sublevel for each text field
and object.
To view the slide content, select Options > Expand. To
hide the content, select Options > Collapse. To collapse
or expand all entries, select Options > View > Collapse
all or Expand all.
To change the order of slides, scroll to the slide you want
to move, and select Options > Slide > Move. Scroll up and
down to select a new location, and select OK.
Notes view
In the notes view, you can read notes that are attached
to slides in the presentation. You can also add your own
notes.
To open the notes view, scroll to the view on the right.
Each slide has its own main level entry. Under the main
level there is a sub level for notes. If notes are not visible,
select Options > View > Expand all. To edit a note, scroll
to the note, and press the joystick.
Edit presentations
To edit a presentation, open the layout view, and select
Options > Edit slide. Scroll right or down with the joystick
to move forward, and scroll left or up to move backward.
Select Options.
Define the following options:
81
Office applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 81 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 81 Dec 22, 2005 4:45:59 AM
•Add title, Add subtitle, Add text, Insert table, Insert
image — Add a new text or object inside the selected
area.
•Edit text, Edit table, Edit document, Edit
workbook — Edit the selected object.
•Edit object — Select Move to move the object, scroll to
the item and press the joystick. Select Resize to change
the size of the object. Scroll right and left to change the
horizontal size of the object, and scroll up and down
to change the vertical size. To accept the changes,
press the joystick. Select Rotate to rotate the object.
Scroll right to rotate the object clockwise, and left to
rotate counterclockwise. To accept the changes, press
the joystick. Select Properties to edit text, line, border,
or background properties of the object.
•Object — Delete, copy, paste, or add a link to the
selected object.
•Object position — Change the layered position of the
selected object in the presentation: up, down, front, or
back.
•Insert — Add a new text box, image, shape, table,
comment, or object to the presentation.
•Undo, Redo — Withdraw the latest modifications.
Find text in a presentation
To find a piece of text from in the presentation, select any
of the views. Select Options > Find, enter the text in
the Find: field, and press the joystick.
To change the search option for case and whole words,
select Options > Search options.
Screen export
You can show the screen of the device to an audience with
a compatible data projector, or other compatible
projection system. The screen content is transferred to
the data projector using, for example, a Bluetooth
connection.
Select Menu > Office > Screen export.
To be able to show screen content with a compatible data
projector, you need to install the drivers of the data
projector. For more information, check with the data
projector manufacturer or its representative.
Not all applications support this feature. You can start the
external viewer in two ways: from the Office folder, or
inside an application that supports it.
Show screen content
To show screen content with a data projector, open the
screen export application, and select Options > Select
device. In the list of available devices, scroll to the device
you want to use, and select OK. Select Options > Enable
to show screen content.
To hide the screen content you are showing, select
Options > Hide. The screen exporter application is moved
to the background.
To stop showing screen content, select Options > Disable.
82
Office applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 82 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 82 Dec 22, 2005 4:45:59 AM
Zip Manager
You can compress files on your device to e-mail or archive
using Zip Manager.
You can perform the following tasks with Zip Manager:
•Create new archive — Create a new archive file to store
compressed ZIP formatted files.
•Update an archive — Add single or multiple
compressed files or directories to an existing archive.
•Delete files — Delete files or directories from an
existing archive.
•Archive password — Set, clear, or change the archive
password for protected archives.
•Zip manager settings — Change Zip manager settings,
such as: compression level, temporary file drive, file
name encoding, default drive, auto-naming, and
default startup view.
You can store archive files on the device or on the memory
card. Zip Manager also has a wizard view that you can use
to perform basic file compression tasks, such as:
extracting, adding, archiving, and listing files.
Print
Print a message or file from the device. Preview a print
job, define page layout options, select a printer, or print
to a file.
Before you print, make sure that your device is properly
connected to the printer.
To print a message or file, open the message or file, and
select Options > Print.
Define the following options:
•Printer — Select an available printer from the list.
•Print — Select All pages, Even pages, or Odd pages as
the print range.
•Print range — Select All pages in range, Current page,
or Defined pages as the page range.
•Number of copies — Select the number of copies to
print.
•Print to file — Select to print to a file and determine
the location for the file.
You may not be able to print all messages, such as
multimedia messages or other special message types.
To preview a file or message before you print, select
Options > Print > Preview.
To change the page layout before printing, select
Options > Print > Page setup and select from the
following tabs:
•Paper size — Change the paper size or orientation and
customize the height and width.
•Margins — Change the size of the left, right, top, or
bottom margins.
•Header — The maximum length of the header is 128
characters. You can set the distance from the header
to the text and choose to include the header on the
first page of the document.
•Footer — The maximum length of the footer is 128
characters. You can set the distance from the footer to
the text.
To add or delete a printer, select Menu > Office >
Printers > Options > Add or Delete.
83
Office applications
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 83 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 83 Dec 22, 2005 4:45:59 AM
Settings
Select Menu > Tools > Settings.
You can define and modify various settings of your device.
Modifying these settings affects the operation of your
device across several applications.
Phone settings
Select Phone sett. to change the language settings,
standby mode settings, and display settings of your
device.
General settings
Select General, and define the following:
•Phone language — Select a language from the list, and
OK. Changing the device language affects every
application in your phone, and remains in effect until
you change the device language again.
•Writing language — Select a language from the list,
and OK. Changing the writing language also affects the
characters that are available when writing text and the
predictive text dictionary that is used. This change
remains in effect until you change the device language
again.
•Predictive text — Select On to use predictive text input.
The predictive text dictionary is not available for all
languages.
•Welcome note / logo — Select Default to use the
default image, Text to enter a welcome note of your
own, or Image to select an image from the Gallery. The
welcome note or image is displayed briefly each time
you switch on the device.
•Orig. phone settings — Restore the original device
settings. To do this, you need your device lock code.
Enter the device lock code, and select OK. After
resetting, the device may take a longer time to power
on. Documents, contact information, calendar entries,
and files are unaffected.
Standby mode settings
Select Standby mode, and define the following:
•Active standby — Select On to have shortcuts to
different applications available in the active standby
mode.
•Left selection key, Right selection key — Change the
shortcuts that open from the left and right selection
keys in the standby screen. Press joystick, select a
function from the list, and OK.
•Navigation key right, Navigation key left, Navigat. key
down, Navigation key up, Selection key — Change the
shortcuts that open when you scroll to different
directions. Press the joystick, select a function from the
list, and OK. These settings are not available if you
select Active standby > On.
84
Settings
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 84 Dec 22, 2005 4:45:59 AM
Display settings
Select Display, and define the following:
•Light sensor — Adjust the amount of light required to
illuminate the device display. Press joystick, scroll right
or left, and select OK.
•Power saver time-out — Select the amount of time
before the screen saver is activated. Press the joystick,
scroll right or left, and select OK.
•Light time-out — Set how quickly after last keypress
the display dims. Press the joystick, scroll right or left,
and select OK.
Call settings
Select Call settings, and define the following:
•Send my caller ID — Select Yes to display your phone
number to the person you are calling or Set by
network to let the network to determine whether your
caller ID is sent.
•Send my Int. call ID — Set this feature on if you want
to display your Internet caller ID to the person you are
calling.
•Call waiting — Select Activate to be notified of a new
incoming call while you have a call in progress, or
Check status to check if the function is active on the
network.
•Internet call waiting — Activate this feature to be
notified of a new incoming call while you have an
internet call in progress.
•Default call type — Select Cellular to make normal calls
to the phone number or Internet to use VoIP to call the
number or address.
•Reject call with SMS — Select Yes to send a text
message automatically to the person who is calling
you informing why you cannot answer their incoming
call.
•Message text — Enter the text that is sent when you
cannot answer an incoming call and want to
automatically send a text message as a reply.
•Image in video call — Select Use selected to select a
still image to be displayed instead of a video during a
video call or None to not send any image during a video
call.
•Automatic redial — Select On to redial a number if it
was busy at the first call attempt. Your device makes a
maximum of 10 attempts to connect the call.
•Summary after call — Select On to briefly display the
approximate duration of the last call.
•Speed dialling — Select On to activate speed dialing on
your device. Dial a phone number assigned to the
speed dialling keys (2 -9) by pressing and holding the
key.
See "Speed dial," p. 27.
•Anykey answer — Select On to answer an incoming
call by briefly pressing any key, except the end key.
•Line in use — Select Line 1 or Line 2 to change the
phone line for outgoing calls and text messages
(network service). This setting is displayed only if the
SIM card supports the alternate line service and a
subscription to two phone lines.
•Line change — Select Disable to prevent line selection
(network service). To change this setting, you need the
PIN2 code.
•Internet call alert — Select Off to notify incoming
Internet calls that your device is busy or On to accept
incoming Internet calls.
85
Settings
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 85 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 85 Dec 22, 2005 4:45:59 AM
Connection settings
Select Menu > Tools > Settings > Connection, and from
the following:
•Access points — Set up new or edit existing access
points. Some or all access points may be preset for your
device by your service provider, and you may not be
able to create, edit, or remove them.
•Packet data — Determine when packet data
connections are used, and enter the access point if you
use your device as a modem for a computer.
•Internet tel. settings — Define settings for Internet
calls.
•SIP settings — View or create session initiation
protocol (SIP) profiles.
•Data call — Set the time-out period after which data
call connections automatically end.
•VPN — Install and manage VPN policies, manage VPN
policy servers, see the VPN log, and create and manage
VPN access points.
•Wireless LAN — Determine if the device displays an
indicator when a wireless LAN is available, and how
often the device searches for networks.
•Configs. — View and delete trusted servers from which
your device may receive configuration settings.
To obtain information about wireless LAN or subscribing
to a packet data service and the appropriate connection
and configuration settings, contact your network
operator or service provider.
The settings available for editing may vary.
Access points
Select Menu > Tools > Settings > Connection > Access
points.
An access point is where your device connects to the
network by way of a data connection. To use e-mail and
multimedia services or to browse web pages, you must
first define access points for these services.
Some or all access points may be preset for your device
by your service provider, and you may not be able to
create, edit, or remove them.
See "Internet access points," p. 67.
Packet data
Select Menu > Tools > Settings > Connection > Packet
data.
Your device supports packet data connections, such as
GPRS in the GSM network. When you are using your phone
in GSM and UMTS networks, it is possible to have multiple
data connections active at the same time; access points
can share a data connection, and data connections
remain active (for example, during voice calls). See
"Connection manager," p. 62.
Packet data settings
The packet data settings affect all access points using a
packet data connection.
Define the following settings:
•Packet data conn. — Select When available to register
the device to the packet data network when you
switch the device on in a supported network. Select
86
Settings
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 86 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 86 Dec 22, 2005 4:45:59 AM
When needed to establish a packet data connection
only when an application or action requires it.
•Access point — Enter the access point name provided
by your service provider to use the device as a packet
data modem to your computer.
These settings affect all access points for packet data
connections.
If you want to use the device as a modem to enable packet
data connectivity from a compatible PC, select Access
point, and enter the access point name. You obtain the
name from your network operator or service provider.
Internet call settings
Edit Internet call profiles
Select Menu > Tools > Settings > Connection >
Internet tel. settings. Select Options > New profile or
Options > Edit.
Scroll to Name, press the joystick, enter a name for the
profile, and select OK.
Scroll to SIP profiles, press the joystick, scroll to a profile,
press the joystick to select it and select OK. SIP protocols
are used for creating, modifying, and terminating
communications sessions such as Internet calls with one
or more participants. SIP profiles include settings for
these sessions.
To save your settings, press Back.
Data calls
VPN
Access points
Select VPN access points.
Some or all access points may be preset for your phone
by your service provider, and you may not be able to
create, edit, or remove them.
To create a VPN access point, select Options > New access
point.
To view and edit a VPN access point, scroll to it, and press
the joystick.
To delete a VPN access point, scroll to it, and press <C>.
Editing access points
Contact your service provider for the correct access point
settings. Define the following settings:
•Connection name — enter a name for the VPN access
point.
•VPN policy — select the VPN policy to pair with the
Internet access point. VPN policies define the method
that your mobile phone and a VPN gateway use to
authenticate each other and the encryption
algorithms used to protect data transfer.
•Internet access pt. — select the Internet access point
to pair the VPN policy with and to be used to create
secure connections for data transfer.
•Proxy serv. address — enter the proxy server address
of the private network.
•Proxy port number — enter the proxy port number.
87
Settings
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 87 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 87 Dec 22, 2005 4:45:59 AM
Wireless LAN
Select Menu > Tools > Settings > Connection >
Wireless LAN.
To have an indicator displayed when there is a wireless
LAN available in your current location, select Show
availability > Yes.
To select the time interval for your device to scan for
available wireless LANs and update the indicator, select
Scan for networks. This setting is not visible unless you
have set Show availability > Yes.
Advanced WLAN settings
Select Menu > Tools > Settings > Connection >
Wireless LAN > Options > Advanced settings. The
wireless LAN advanced settings are normally defined
automatically, and changing them is not recommended.
To edit the settings manually, select Automatic config. >
Disabled, and define the following:
•Long retry limit — Enter the maximum number of
transmission attempts if the device does not receive a
receiving acknowledgement signal from the network.
•Short retry limit — Enter the maximum number of
transmission attempts if the device does not receive a
clear-to-send signal from the network.
•RTS threshold — Select the data packet size at which
the wireless LAN access point device issues a request
to send before sending the packet.
•TX power level — Select the power level of your device
when sending data.
•Radio measurem. — Enable or disable the radio
measurements.
To restore all settings to their original values, select
Options > Restore defaults.
Security settings for wireless LAN access
points
WEP security settings
Select Menu > Tools > Settings > Connection > Access
points. Select Options > New access point, or select an
access point and Options > Edit.
In the access point settings, select WLAN security mode >
WEP.
Wired equivalent privacy (WEP) encryption method
encrypts data before it is transmitted. Access to the
network is denied to users who do not have the required
WEP keys. When WEP security mode is in use, if your device
receives a data packet not encrypted with the WEP keys,
the data is discarded.
In an Ad-hoc network, all devices must use the same WEP
key.
Define the following:
•WEP key in use — Select the desired WEP key.
•Authentication type — Select Open or Shared.
•WEP key settings — Edit the settings for the WEP key.
WEP key settings
Select Menu > Tools > Settings > Connection > Access
points. Select Options > New access point, or select an
access point and Options > Edit.
In the access point settings, select WLAN security mode >
WEP.
In an Ad-hoc network, all devices must use the same WEP
key.
88
Settings
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 88 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 88 Dec 22, 2005 4:45:59 AM
Select WLAN security sett. > WEP key settings and define
the following:
•WEP encryption — Select the desired WEP encryption
key length.
•WEP key format — Select whether you want to enter
the WEP key data in ASCII or Hexadecimal format.
•WEP key — Enter the WEP key data.
802.1x security settings
Select Menu > Tools > Settings > Connection > Access
points. Select Options > New access point, or select an
access point and Options > Edit.
In the access point settings, select WLAN security mode >
802.1x.
802.1x authenticates and authorizes devices to access a
wireless network, and prevents access if the
authorization process fails.
Select WLAN security sett.. and from the following:
•WPA mode — Select EAP (Extensible Authentication
Protocol) or Pre-shared key (a secret key used for
device identification).
•EAP plug-in settings — If you selected WPA mode >
EAP, select which EAP plug-ins defined in your device
to use with the access point.
•Pre-shared key — If you selected WPA mode > Pre-
shared key, enter the shared private key that identifies
your device to the wireless LAN to which you connect.
•TKIP encryption — To enable TKIP encryption, based
on transient keys changed often enough to prevent
misuse, select Allowed.
All devices in the wireless LAN must either allow or
prevent the use of TKIP encryption.
The settings available for editing may vary.
WPA security settings
Select Menu > Tools > Settings > Connection > Access
points. Select Options > New access point, or select an
access point and Options > Edit.
In the access point settings, select WLAN security mode >
WPA/WPA2.
Select WLAN security sett.. and from the following:
•WPA mode — Select EAP (Extensible Authentication
Protocol) or Pre-shared key (a secret key used for
device identification).
•EAP plug-in settings — If you selected WPA mode >
EAP, select which EAP plug-ins defined in your device
to use with the access point.
•Pre-shared key — If you selected WPA mode > Pre-
shared key, enter the shared private key that identifies
your device to the wireless LAN to which you connect.
•TKIP encryption — To enable TKIP encryption, based
on transient keys changed often enough to prevent
misuse, select Allowed.
All devices in the wireless LAN must either allow or
prevent the use of TKIP encryption.
The settings available for editing may vary.
EAP
EAP plug-ins
To view the EAP (extensible authentication protocol)
plug-ins currently installed in your device (network
service), select Menu > Tools > Settings > Security >
EAP plug-ins. Some Internet access points that use
wireless LAN as a data bearer and 802.1x or WPA/WPA2
security mode use the plug-ins for authentication.
89
Settings
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 89 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 89 Dec 22, 2005 4:45:59 AM
EAP settings
Select Menu > Tools > Settings > Connection > Access
points. Select Options > New access point, or select an
access point and Options > Edit.
In the access point settings, select WLAN security mode >
802.1x or WLAN security mode > WPA/WPA2.
Select WLAN security sett. > WPA mode > EAP.
Select EAP plug-in settings and the EAP plug-ins to use
with a wireless LAN access point.
You can also select Options and view the plug-in settings
or change the priority of the plug-in.
Define the following settings:
•User certificate — enter a user certificate.
•CA certificate — enter a CA certificate.
•User name in use — select From certificate or User-
configured.
•User name — enter a user name to be used for
authentication.
•Realm in use — select From certificate or User-
configured.
•Realm — enter a realm name.
Enable or disable a CA certificate, To enable a CA
certificate, select Options > Enable. To disable a CA
certificate, select Options > Disable.
To view details about an EAP type, select View details.
Advanced settings for wireless LAN access
points
Select Menu > Tools > Settings > Connection > Access
points.
Scroll to a packet data access point, and select Options >
Advanced settings and from the following:
•IPv4 settings — Enter the device IP and name server
addresses for the IPv4 Internet protocol.
•IPv6 settings — Select or enter the name server
addresses for the IPv6 Internet protocol.
•Ad-hoc channel — If the selected network mode is ad-
hoc, select User defined to manually enter a channel
number (1-11).
•Proxy serv. address — Enter the proxy server address.
•Proxy port number — Enter the proxy server port
number.
Proxy servers are intermediate servers between a
browsing service and its users, which are used by some
service providers. These servers may provide additional
security and speed up access to the service.
The settings available for editing may vary. Contact your
service provider for more information.
IPv4 settings
In IPv6 settings, define the following:
•Phone IP address — Enter your device IP address.
•Subnet mask — Enter the IP address common to all
devices in the subnet.
•Default gateway — Enter the address of the router
that transmits data from your device to a destination
outside the subnet.
•DNS address — Enter the IP addresses of the Primary
DNS address and Secondary DNS addr., if required by
your service provider. Otherwise, the name server
addresses are provided automatically. Domain name
servers translate domain names (www.nokia.com)
into IP addresses (192.100.124.195).
90
Settings
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 90 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 90 Dec 22, 2005 4:45:59 AM
IPv6 settings
In IPv4 settings > DNS address, select:
•User defined — to enter the IP addresses of the servers
•Automatic — to retrieve the IP addresses
automatically from the network
•Well-known — to use standard name server addresses
Configurations
To view and delete configurations for trusted servers,
select Menu > Tools > Settings > Connection >
Configs..
You can receive messages from your network operator,
service provider, or company information management
that contain configuration settings for trusted servers.
These settings are automatically saved in Configs.. You
may receive configuration settings for access points,
multimedia or e-mail services, and IM or synchronization
settings from trusted servers.
To delete configurations for a trusted server, scroll to the
server, and press the clear key. The configuration settings
for other applications provided by this server are also
deleted.
Date and time settings
See "Clock settings," p. 95.
Security settings
See "Define security settings," p. 34.
Enhancement settings
Select Menu > Tools > Settings > Enhanc. sett..
Warning: When you use the headset, your ability
to hear outside sounds may be affected. Do not use the
headset where it can endanger your safety.
With most enhancements, you can define the following
settings:
•Default profile — Select the profile that is activated
when you attach an enhancement to your device.
•Automatic answer — Let the device answer phone
calls automatically when an enhancement is attached.
Select On to have the device answer an incoming call
automatically after 5 seconds. If the ringing type is set
to Beep once or Silent in the Profiles menu, automatic
answer is disabled.
•Lights — Select On to illuminate the device while it is
attached to an enhancement.
91
Settings
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 91 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 91 Dec 22, 2005 4:45:59 AM
Organiser
Select Menu > Organiser.
Organiser includes tools that help you organize and
manage the details of different events in your personal
and business life.
Calendar
Select Menu > Organiser > Calendar.
In Calendar, you can create and view scheduled events
and appointments. You can also set alarms for calendar
entries.
You can synchronize your calendar data with a
compatible computer using Nokia PC Suite. For
information on synchronization, see the PC Suite guide.
Create calendar entries
You can create four types of calendar entries:
•Meeting entries have a specific date and time.
•Memo entries are related to the whole day but not to
a specific time of the day. Memo entries do not appear
in the weekly time schedule view.
•Anniversary entries remind you of birthdays and
special dates. They refer to a certain day but not a
specific time of the day. Anniversary entries are
repeated every year.
•To-do note entries remind you of a task that has a due
date but not a specific time of the day.
To create a calendar entry, scroll to a date, and select
Options > New entry. Select an entry type. Available
settings for meeting, memo, anniversary, and to-do
entries vary.
To open and edit an existing entry, scroll to the entry, and
select Options > Open. Edit the details in the various
fields.
Tip: When you edit or delete a repeated entry,
choose how you want the change to take effect.
If you select All calendar entries deleted, all
repeated entries are deleted. If you select Delete
entry only the current entry is deleted.
To-do
You can create and maintain a task or list of tasks that
must be done by a certain day. Each task can be assigned
a due date, but not a specific time of the day.
To open the list of to-do notes, select Options > To-do list.
To add a to-do note, select Options > New entry > To-
do. Start to write the task in the Subject field. You can set
a due date for the task, and specify a priority. The priority
icons are ( ! ) High and ( - ) Low. There is no icon for Normal.
To mark a task as completed, scroll to the task in the to-
do list, and select Options > Mark as done.
92
Organiser
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 92 Dec 22, 2005 4:45:59 AM
To restore a task, scroll to it in the todo list, and select
Options > Mark as not done.
Calendar views
To switch between the different calendar views, select
Options in any calendar view. Select a type of view from
the list.
To set the default calendar view, select Options >
Settings > Default view > Month view , Week view, Day
view, or To-do view
To view a specific date in the calendar view, select
Options > Go to date. Enter the date, and select OK.
Add a received calendar entry to
your calendar
You can receive a calendar entry as an attachment to a
multimedia or e-mail message.
To add a received calendar entry to your calendar, open
the calendar entry attachment in the message, and select
Options > Save to Calendar. The entry is added to your
default calendar.
To respond to a received calendar entry, open the
calendar entry attachment, and select Accept, Tentative,
or Decline. If you accept the entry or mark it as tentative,
the entry is added to your default calendar. You can send
a response message to the sender of the calendar entry
by e-mail. Select Yes, and the message is saved in
Outbox to wait for sending.
Notes
Select Menu > Organiser > Notes.
You can create and send notes to other compatible
devices, and save plain text files (.txt format) that you
receive to Notes.
To write a new note, select Options > New note, write
the text and press Done.
Calculator
Note: This calculator has limited accuracy and is
designed for simple calculations.
Select Menu > Organiser > Calculator.
To make a calculation, enter the first number of the
calculation. Scroll to and select a function such as add or
subtract from the function map. Enter the second number
of the calculation and select =. To add a decimal point,
press #.
The calculator performs operations in the order they are
entered. The result of the calculation remains in the editor
field and can be used as the first number of a new
calculation.
To save the results of a calculation, select Options >
Memory > Save. The saved result replaces the previously
stored number in memory.
To retrieve the results of a calculation from memory and
use them in a calculation, select Options > Memory >
Recall.
93
Organiser
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 93 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 93 Dec 22, 2005 4:45:59 AM
To view the last saved result, select Options > Last result.
Exiting the calculator application or turning off the phone
does not clear the memory. You can recall the last saved
result the next time you open the calculator application.
Converter
Select Menu > Organiser > Converter.
The converter has limited accuracy, and rounding errors
may occur.
Convert measurements
1. Scroll to the Type field, and select Options >
Conversion type to open a list of measures. Scroll to
the measure you want to use, and select OK.
2. Scroll to the first Unit field, and select Options > Select
unit. Select the unit from which you want to convert,
and select OK. Scroll to the next Unit field, and select
the unit to which you want to convert.
3. Scroll to the first Amount field, and enter the value you
want to convert. The other Amount field changes
automatically to show the converted value.
Press # to add a decimal and * for + and - (for
temperature), and E (exponent) symbols.
Set base currency and exchange
rate
Note: When you change base currency, you must
key in the new rates because all previously set exchange
rates are set to zero.
Before you can make currency conversions, you must
choose a base currency and add exchange rates. The rate
of the base currency is always 1. The base currency
determines the conversion rates of the other currencies.
1. To set the rate of exchange for the unit of currency,
scroll to the Type field, and select Options > Currency
rates.
2. A list of currencies opens, and you can see the current
base currency at the top. Scroll to the currency type
and enter the exchange rate you would like to set per
single unit of currency.
3. To change the base currency, scroll to the currency,
and select Options > Set as base curr..
4. Select Done > Yes to save the changes.
After you have inserted all the necessary exchange rates,
you can make currency conversions.
Clock
Select Menu > Clock.
94
Organiser
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 94 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 94 Dec 22, 2005 4:45:59 AM
Clock settings
If the alarm time is reached while the device is switched
off, the device switches itself on and starts sounding the
alarm tone. If you select Stop, the device asks whether you
want to activate the device for calls. Select No to switch
off the device or Yes to make and receive calls. Do not
select Yes when wireless phone use may cause
interference or danger.
To change the clock type, select Options > Settings >
Clock type > Analogue or Digital.
To set an alarm, select Options > Set alarm. Enter the
alarm time, and select OK.
To view and change alarms, select Reset alarm.
To remove an alarm, select Remove alarm.
Date and time settings
To change the date and time, their display formats, alarm
tone, and to define whether you want to use automatic
time update and daylight savings time, select Options >
Settings and select from the following:
•Time — Enter the time, and select OK.
•Time zone — Enter the time zone, and select OK.
•Date — Enter the date, and select OK.
•Date format — To change how the date is displayed,
scroll to the desired format, and select OK.
•Date separator — To change the symbol that
separates days, months, and years, scroll to the symbol
you want, and select OK.
•Time format — Select 24-hour or 12-hour.
•Time separator — Select the symbol that separates
hours and minutes.
•Clock type — Select Analogue or Digital.
•Clock alarm tone — Select the tone that you want to
use for the alarm clock.
•Auto time update — Update time, date, and time zone
information automatically (network service). Select
On to activate. This service may not be available in all
networks.
•Daylight-saving — To set the clock to automatically
adjust for daylight savings time, select On. This setting
is only available if Auto time update is set to Off.
Add and delete cities
To add a city, scroll right, and select Options > Add city.
Scroll to a city, and select Options > Select.
To delete a city, scroll right, scroll to the city, and select
Options > Remove.
Changing the home city may change the general system
time of your device.
95
Organiser
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 95 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 95 Dec 22, 2005 4:45:59 AM
Tools
Select Menu > Tools.
The Tools folder contains applications used to configure
your device and to configure other applications.
Memory—See "Memory," p. 24.
Switch (data transfer)—See "Transfer content between
devices," p. 25.
Profiles—See "Profiles," p. 101.
Settings—{unresolved reference to ID
'GUIDB752033CA27811D8A467000BDB6BA40A'}
Positioning
With the positioning service you can receive information
from service providers about local issues such as weather
or traffic conditions, based on the location of your phone
(network service).
Select Menu > Tools > Positioning.
To select a positioning method, scroll to the positioning
method, and select Options > Enable. To stop using it,
select Options > Disable. The Bluetooth positioning
method enables you to use Bluetooth GPS enhancements
for positioning. The Network based positioning method
is provided by your network operator or service provider.
Both positioning methods can be used simultaneously.
Navigator
Select Menu > Tools > Navigator.
Navigator is used to view your current location, find your
way to a desired location, and track distance.
The application must receive positioning info from at
least three satellites to use it as a traveling aid. Changes
to this application may affect your privacy, so you must
control how it is used.
Select the from the following:
•Navigator — View navigating information to your trip
destination.
•Position — View positioning information about your
current location.
•Trip dist. — View your traveling information such as
the distance and duration you have traveled and your
average and maximum speeds.
Landmarks
Select Menu > Tools > Landmarks.
Landmarks are coordinates to geographic locations that
you can save to your device for later use in different
location-based services. You can create landmarks using
a Bluetooth GPS enhancement or network (network
service). See "Navigator," p. 96.
96
Tools
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 96 Dec 22, 2005 4:45:59 AM
To create a landmark, select Options > New landmark.
Select Current position to make a network request for the
latitude and longitude coordinates of your current
location, or Enter manually to fill in the necessary location
information such as a name, category, address, latitude,
longitude and altitude.
To delete a landmark, scroll to it and press the clear key.
For more information, see the extended User's Guide on
the Web.
Voice commands
Select Menu > Tools > Voice commands.
Use voice commands to make phone calls and to launch
applications, profiles, or other functions on the device.
The device creates a voice tag for the entries in the
contacts list and for the functions designated in the Voice
commands application. When a voice command is
spoken, the device compares the spoken words to the
voice tag in the device.
Use a voice command to make a call
The voice tag for a contact is the name or nickname that
is saved on the contact card in Contacts. To listen to the
voice tag, open a contact card, and select Options >
Playback.
1. To make a call using a voice command, press and hold
the call key.
2. When you hear the tone or see the visual display,
clearly speak the name saved on the contact card.
3. The device plays a synthesized voice tag for the
recognized contact in the selected device language,
and displays the name and number. After a timeout
of 1.5 seconds, the device dials the number. If the
recognized contact was not correct, select Next to
view a list of other matches, or Quit to cancel dialing.
Use a voice command to launch an
application
The device creates voice tags for the applications listed in
the Voice commands application.
To launch an application using a voice command, press
and hold the call key, and clearly speak the voice
command. If the recognized application was not correct,
select Next to view a list of other matches, or Quit to
cancel.
To add more applications to the list, select Options > New
application.
To change the voice command of an application, scroll to
the application, and select Options > Change command.
Type the new voice command, and select OK.
Use voice commands for profiles
The device creates a voice tag for each profile. To set on
a profile using a voice command, press and hold the call
key and say the name of the profile.
To change the voice command, scroll to the desired
profile, and select Profiles > Options > Change
command.
97
Tools
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 97 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 97 Dec 22, 2005 4:45:59 AM
Voice command settings
To switch off the synthesizer that plays recognized voice
commands in the selected phone language, select
Settings > Synthesiser > Off.
To reset voice recognition learning when the main user
of the phone has changed, select Reset voice adapts..
Activation Keys
Select Menu > Tools > Actv. keys.
You can view and manage permission rights on your
protected media files using alphanumerical keys. These
keys specify rights that determine when you can play,
display, execute, or print media files. Rights for media files
can also restrict the number of times the media can be
rendered (played, displayed, executed, or printed) or the
period of time you are allowed to render the object before
your rights to the media expire.
Select either Valid keys, Invalid keys, or Not in use. Scroll
to the desired file and select Options > Key details.
The following details are displayed for each media file:
•Status — The status is either Activation key is valid,
Activation key expired, or Activation key not yet valid.
•Content sending — Allowed means that you can send
the file to another device. Not allowed means that you
cannot send the file to another device.
•Content in phone — Yes (%U[14]) means that the file
is in the device and the path of the file is displayed.
No means that the related file is not currently in the
device.
Activate content
From the main view of the Activation Keys, select Invalid
keys > Options > Activate content. Establish a network
connection at the prompt, and you are directed to a Web
site where you can purchase rights to the media.
Delete file rights
In the Valid keys or Not in use tabs, scroll to the desired
file and select Options > Delete. If there are several rights
related to the same media file, all the rights are deleted.
Work with groups
The group key view displays all of the files related to a
group right. If you have downloaded multiple media files
with the same rights, they are all displayed in this view.
You can open the group view from either the Valid keys
or Invalid keys tabs. To access these files, open the group
rights folder.
To rename a group, select Options > Rename. Enter the
new name to change the name of the group rights.
Application manager
Select Menu > Tools > App. manager.
When you open the application manager, you see all the
software packages that have been installed, with their
name, version number, type, and size. View the details of
installed applications, remove them from your device,
and specify installation settings.
98
Tools
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 98 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 98 Dec 22, 2005 4:45:59 AM
Certificate manager
Important: Note that even if the use of certificates
makes the risks involved in remote connections and
software installation considerably smaller, they must be
used correctly in order to benefit from increased security.
The existence of a certificate does not offer any protection
by itself; the certificate manager must contain correct,
authentic, or trusted certificates for increased security to
be available. Certificates have a restricted lifetime. If
Expired certificate or Certificate not valid yet is shown
even if the certificate should be valid, check that the
current date and time in your device are correct.
Before changing any certificate settings, you must make
sure that you really trust the owner of the certificate and
that the certificate really belongs to the listed owner.
Digital certificates are used to verify the origins of
software but do not guarantee safety. There are three
different types of certificates: authority certificates,
personal certificates, and server certificates. During a
secure connection, a server may send a server certificate
to your device. Upon receipt, it is checked through an
authority certificate stored on your device. You receive
notification if the identity of the server is not authentic or
if you do not have the correct certificate in your device.
Download a certificate from a web site, or receive a
certificate as an e-mail attachment, or as a message sent
through a Bluetooth or infrared connection. Certificates
should be used when you connect to an online bank or a
remote server to transfer confidential information. They
should also be used if you want to reduce the risk of
viruses or other malicious software, and to check the
authenticity of software when you download and install
software to your device.
Tip: When you add a new certificate, check its
authenticity.
99
Tools
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 99 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 99 Dec 22, 2005 4:45:59 AM
Device manager
Select Menu > Connectivity > Dev. mgr..
Manage data and software on your device.
Remote configuration
network service
Select Menu > Connectivity > Device mgr..
Configure connection settings for e-mail, multimedia
messaging, Internet settings, and other applications.
The remote configuration connection is usually started by
the server when device settings need to be updated.
To start a configuration session, select a profile from the
list, and select Connect. If no remote configuration
profiles are defined, you must first create a new profile.
To disable a configuration, select a profile, Select Menu >
Connectivity > Device mgr.. Select the profile and select
Disable config.. You cannot receive configuration settings
from any of the configuration servers for which you have
a profile.
When the configuration session has ended, you can view
status information.
To open the configuration log, select a profile, and press
Log. The log file shows the latest configuration status of
the selected profile.
Data synchronization
Menu > Sync
Use Data Synchronization to synchronize your calendar or
contacts with various calendar and address book
applications on a compatible computer or remote
Internet server. Synchronization settings, such as the data
synchronized and the connection method used, are saved
in a synchronization profile.
The available applications you can synchronize may vary.
Contact your service provider for more information.
Tip: You may receive the synchronization settings
as a message from your service provider.
The application uses SyncML technology for remote
synchronization. For information on SyncML
compatibility, contact the supplier of the applications
with which you want to synchronize your device.
100
Device manager
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 100 Dec 22, 2005 4:45:59 AM
Personalization
Profiles
Warning: In the offline profile you cannot make or
receive any calls, including emergency calls, or use other
features that require network coverage. To make calls,
you must first activate the phone function by changing
profiles. If the device has been locked, enter the lock code.
Select Menu > Tools > Profiles.
You can adjust and customize the ringing tones, alert
tones, and other device tones for different events,
environments, or caller groups.
To customize a profile, scroll to the desired profile in the
list, and select Options > Personalise.
Define the following settings:
•Ringing tone — Select a ringing tone from the list, or
select Tone downloads to open a bookmark folder
containing a list of bookmarks for downloading tones
using the browser.
To listen to the selected tone, select Play.
If you have two alternate phone lines in use, you can
specify a ringing tone for each line.
•Video call tone — Select a ringing tone for video calls.
•Say caller's name — Activate the text-to-tone speech
feature. When someone from your contacts list calls
you, the phone sounds a ringing tone that is a
combination of the spoken name of the contact and
the selected ringing tone.
•Ringing type — Select how you want the ringing tone
to alert.
•Ringing volume — Select the volume level of the
ringing tone.
•Message alert tone — Select a tone for received text
messages.
•E-mail alert tone — Select a tone for received e-mail
messages.
•Instant message alert tone — Select a tone for
received instant messages.
•Vibrating alert — Select whether you want the phone
to vibrate when you receive a call.
•Keypad tones — Set the volume level of the device
keypad tones.
•Warning tones — Set the warning tones on or off.
•Alert for — You can set the phone to ring only upon
calls from phone numbers that belong to a selected
contact group. Phone calls coming from outside that
group have a silent alert.
•Profile name — You can give a name to a new profile
or rename an existing profile. The General and Offline
profiles cannot be renamed.
The Offline profile prevents your device from
accidentally switching on, sending or receiving
messages, or using Bluetooth; it also closes any
Internet connection that may be in operation when
the profile is selected.
The Offline profile does not prevent you from
establishing new wireless LAN or Bluetooth
connections at a later time, so comply with any
101
Personalization
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 101 Dec 22, 2005 4:45:59 AM
applicable safety requirements when establishing and
using wireless LAN or Bluetooth connections.
To change a profile, scroll to the desired profile in the list,
and select Options > Activate.
To create a new profile, select Options > Create new, and
define the settings.
Themes
Select Menu > Tools > Themes.
You can change the look of your device's display.
To change the look of the display, highlight the theme you
want to use, and select Options > Apply.
To edit a theme, highlight the theme you want to edit,
and select Options > Edit.
To download themes, you need to establish a network
connection that allows you to download themes from
Internet sources that are compatible with your device.
To download a theme, select Theme downloads. Enter the
link from which you want to download your theme. Once
the theme is downloaded you can preview, activate, or
edit it.
To preview a theme, highlight the theme you want to
preview, and select Options > Preview. Select Apply to
keep the new theme.
102
Personalization
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 102 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 102 Dec 22, 2005 4:45:59 AM
Nokia original enhancements
An extensive range of enhancements is available for your
device. Select the enhancements that accommodate your
specific communication needs. For availability of the
enhancements, check with your local dealer.
Compatible power enhancements:
•1150 mAh Li-Po battery (BL-6C)
•Charger (ACP-12)
•Retractable charger (AC-1)
•Mobile charger (LCH-12)
Compatible audio enhancements:
•Headset (HS-5)
•Boom headset (HDB-4)
•Wireless boom headset (HS-4W)
•Wireless headset (HS-11W)
•Loopset (LPS-4)
•TTY adapter (HDA-10)
Compatible messaging and data enhancements:
•Wireless keyboard (SU-8W)
•Connectivity cable (CA-53)
•Mini SD (64 MB - 1 GB)
•Wireless GPS module (LD-1W)
Compatible imaging enhancements:
•Remote camera (PT-6)
•Image album (PD-1)
•Photo flash (PD-2)
Compatible car enhancements:
•Mobile holder (MBC-13L)
•Hands-free headrest (BHF-3)
•Hands-free car plug-in (HF-3)
•Wireless hands-free car plug-in (HF-6W)
•Basic car kit (CK-10)
•Advanced car kit (CK-7W)
•Car kit phone (N616)
Enhancements
A few practical rules about accessories and
enhancements.
•Keep all accessories and enhancements out of the
reach of small children.
•When you disconnect the power cord of any accessory
or enhancement, grasp and pull the plug, not the cord.
•Check regularly that enhancements installed in a
vehicle are mounted and are operating properly.
•Installation of any complex car enhancements must be
made by qualified personnel only.
103
Nokia original enhancements
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 103 Dec 22, 2005 4:45:59 AM
Battery information
Your device is powered by a rechargeable battery. The full
performance of a new battery is achieved only after two
or three complete charge and discharge cycles. The
battery can be charged and discharged hundreds of times,
but it will eventually wear out. When the talk and standby
times are noticeably shorter than normal, buy a new
battery. Use only Nokia approved batteries, and recharge
your battery only with Nokia approved chargers
designated for this device.
Unplug the charger from the electrical plug and the device
when not in use. Do not leave fully charged battery
connected to a charger, since overcharging may shorten
its lifetime. If left unused, a fully charged battery will lose
its charge over time.
If the battery is completely discharged, it may take a few
minutes before the charging indicator appears on the
display or before any calls can be made.
Use the battery only for its intended purpose. Never use
any charger or battery that is damaged.
Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object such as a coin,
clip, or pen causes direct connection of the positive (+)
and negative (-) terminals of the battery. (These look like
metal strips on the battery.) This might happen, for
example, when you carry a spare battery in your pocket
or purse. Short-circuiting the terminals may damage the
battery or the connecting object.
Leaving the battery in hot or cold places, such as in a
closed car in summer or winter conditions, will reduce the
capacity and lifetime of the battery. Always try to keep
the battery between 15°C and 25°C (59°F and 77°F). A
device with a hot or cold battery may not work
temporarily, even when the battery is fully charged.
Battery performance is particularly limited in
temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode.
Batteries may also explode if damaged. Dispose of
batteries according to local regulations. Please recycle
when possible. Do not dispose as household waste.
1150 mAh Li-Ion battery
(BL-6C) information
Variation in talk time and standby time may occur,
depending on the SIM card, network and usage settings,
and the style and environment of use.
•GSM talk time: up to 6 hours
•WCDMA talk time: up to 6 hours
•GSM standby time: up to 7.6 days
•WCDMA standby time: up to 8.7 days
Nokia battery
authentication guidelines
Always use original Nokia batteries for your safety. To
check that you are getting an original Nokia battery,
104
Battery information
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 104 Dec 22, 2005 4:45:59 AM
purchase it from an authorized Nokia dealer, look for the
Nokia Original Enhancements logo on the packaging, and
inspect the hologram label using the following steps:
Successful completion of the four steps is not a total
assurance of the authenticity of the battery. If you have
any reason to believe that your battery is not an authentic
original Nokia battery, you should refrain from using it,
and take it to the nearest authorized Nokia service point
or dealer for assistance. Your authorized Nokia service
point or dealer will inspect the battery for authenticity. If
authenticity cannot be verified, return the battery to the
place of purchase.
Authenticate hologram
1. When looking at the hologram
on the label, you should see the
Nokia connecting hands symbol
from one angle and the Nokia
Original Enhancements logo
when looking from another
angle.
2. When you angle the hologram
left, right, down, and up, you
should see 1, 2, 3, and 4 dots on
each side respectively.
3. Scratch the side of the label to
reveal a 20-digit code, for
example,
12345678919876543210. Turn
the battery so that the numbers
are facing upwards. The 20-digit
code reads starting from the
number at the top row followed
by the bottom row.
4.
You should receive a message indicating whether the
code can be authenticated.
What if your battery is not
authentic?
If you cannot confirm that your Nokia battery with the
hologram on the label is an authentic Nokia battery,
please do not use the battery. Take it to the nearest
authorized Nokia service point or dealer for assistance.
The use of a battery that is not approved by the
manufacturer may be dangerous and may result in poor
performance and damage to your device and its
enhancements. It may also invalidate any approval or
warranty applying to the device.
To find out more about original Nokia batteries, visit
www.nokia.com/battery.
105
Battery information
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 105 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 105 Dec 22, 2005 4:45:59 AM
Care and maintenance
Your device is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you protect your warranty
coverage.
•Keep the device dry. Precipitation, humidity, and all
types of liquids or moisture can contain minerals that
will corrode electronic circuits. If your device does get
wet, remove the battery, and allow the device to dry
completely before replacing it.
•Do not use or store the device in dusty, dirty areas. Its
moving parts and electronic components can be
damaged.
•Do not store the device in hot areas. High temperatures
can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
•Do not store the device in cold areas. When the device
returns to its normal temperature, moisture can form
inside the device and damage electronic circuit boards.
•Do not attempt to open the device other than as
instructed in this guide.
•Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards and fine
mechanics.
•Do not use harsh chemicals, cleaning solvents, or
strong detergents to clean the device.
•Do not paint the device. Paint can clog the moving
parts and prevent proper operation.
•Use a soft, clean, dry cloth to clean any lenses, such as
camera, proximity sensor, and light sensor lenses.
•Use only the supplied or an approved replacement
antenna. Unauthorized antennas, modifications, or
attachments could damage the device and may violate
regulations governing radio devices.
•Use chargers indoors.
•Always create a backup of data you want to keep, such
as contacts and calendar notes, before sending your
device to a service facility.
All of the above suggestions apply equally to your device,
battery, charger, or any enhancement. If any device is not
working properly, take it to the nearest authorized service
facility for service.
106
Care and maintenance
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 106 Dec 22, 2005 4:45:59 AM
Additional safety information
Operating environment
Remember to follow any special regulations in force in
any area, and always switch off your device when its use
is prohibited or when it may cause interference or danger.
Use the device only in its normal operating positions. This
device meets RF exposure guidelines when used either in
the normal use position against the ear or when
positioned at least 1.5 centimeters (5/8 inches) away
from the body. When a carry case, belt clip or holder is
used for body-worn operation, it should not contain
metal and should position the device the above-stated
distance from your body.
To transmit data files or messages, this device requires a
quality connection to the network. In some cases,
transmission of data files or messages may be delayed
until such a connection is available. Ensure that the above
separation distance instructions are followed until the
transmission is completed.
Parts of the device are magnetic. Metallic materials may
be attracted to the device. Do not place credit cards or
other magnetic storage media near the device, because
information stored on them may be erased.
Medical devices
Operation of any radio transmitting equipment, including
wireless phones, may interfere with the functionality of
inadequately protected medical devices. Consult a
physician or the manufacturer of the medical device to
determine if they are adequately shielded from external
RF energy or if you have any questions. Switch off your
device in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that could
be sensitive to external RF energy.
Pacemakers
Pacemaker manufacturers recommend that a minimum
separation of 15.3 centimeters (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker. These
recommendations are consistent with the independent
research by and recommendations of Wireless
Technology Research. Persons with pacemakers should
do the following:
•Always keep the device more than 15.3 centimeters (6
inches) from the pacemaker
•Not carry the device in a breast pocket
•Hold the device to the ear opposite the pacemaker to
minimize the potential for interference.
•If you suspect interference, switch off your device, and
move the device away.
107
Additional safety information
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 107 Dec 22, 2005 4:45:59 AM
Hearing aids
Some digital wireless devices may interfere with some
hearing aids. If interference occurs, consult your service
provider.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles such as
electronic fuel injection systems, electronic antiskid
(antilock) braking systems, electronic speed control
systems, and air bag systems. For more information,
check with the manufacturer, or its representative, of
your vehicle or any equipment that has been added.
Only qualified personnel should service the device, or
install the device in a vehicle. Faulty installation or service
may be dangerous and may invalidate any warranty that
may apply to the device. Check regularly that all wireless
device equipment in your vehicle is mounted and
operating properly. Do not store or carry flammable
liquids, gases, or explosive materials in the same
compartment as the device, its parts, or enhancements.
For vehicles equipped with an air bag, remember that air
bags inflate with great force. Do not place objects,
including installed or portable wireless equipment in the
area over the air bag or in the air bag deployment area.
If in-vehicle wireless equipment is improperly installed,
and the air bag inflates, serious injury could result.
Potentially explosive
environments
Switch off your device when in any area with a potentially
explosive atmosphere, and obey all signs and
instructions. Potentially explosive atmospheres include
areas where you would normally be advised to turn off
your vehicle engine. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even death.
Switch off the device at refueling points such as near gas
pumps at service stations. Observe restrictions on the use
of radio equipment in fuel depots, storage, and
distribution areas; chemical plants; or where blasting
operations are in progress. Areas with a potentially
explosive atmosphere are often, but not always, clearly
marked. They include below deck on boats, chemical
transfer or storage facilities, vehicles using liquefied
petroleum gas (such as propane or butane), and areas
where the air contains chemicals or particles such as
grain, dust, or metal powders.
Emergency calls
Important: Wireless phones, including this device,
operate using radio signals, wireless networks, landline
networks, and user-programmed functions. Because of
this, connections in all conditions cannot be guaranteed.
You should never rely solely on any wireless device for
essential communications like medical emergencies.
To make an emergency call:
1. If the device is not on, switch it on. Check for adequate
signal strength.
108
Additional safety information
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 108 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 108 Dec 22, 2005 4:45:59 AM
Some networks may require that a valid SIM card is
properly inserted in the device.
2. Press the end key as many times as needed to clear
the display and ready the device for calls.
3. Enter the official emergency number for your present
location. Emergency numbers vary by location.
4. Press the call key.
If certain features are in use, you may first need to turn
those features off before you can make an emergency call.
Consult this guide or your service provider for more
information.
When making an emergency call, give all the necessary
information as accurately as possible. Your wireless
device may be the only means of communication at the
scene of an accident. Do not end the call until given
permission to do so.
CERTIFICATION
INFORMATION(SAR)
THIS MOBILE DEVICE MEETS
GUIDELINES FOR EXPOSURE TO
RADIO WAVES.
Your mobile device is a radio transmitter and receiver. It
is designed not to exceed the limits for exposure to radio
waves recommended by international guidelines. These
guidelines were developed by the independent scientific
organization ICNIRP and include safety margins designed
to assure the protection of all persons, regardless of age
and health.
The exposure guidelines for mobile devices employ a unit
of measurement known as the Specific Absorption Rate
or SAR. The SAR limit stated in the ICNIRP guidelines is 2.0
watts/kilogram (W/kg) averaged over 10 grams of tissue.
Tests for SAR are conducted using standard operating
positions with the device transmitting at its highest
certified power level in all tested frequency bands. The
actual SAR level of an operating device can be below the
maximum value because the device is designed to use
only the power required to reach the network. That
amount changes depending on a number of factors such
as how close you are to a network base station. The
highest SAR value under the ICNIRP guidelines for use of
the device at the ear is 0.90 W/kg.
Use of device accessories and enhancements may result
in different SAR values. SAR values may vary depending
on national reporting and testing requirements and the
network band. Additional SAR information may be
provided under product information at www.nokia.com.
Your mobile device is also designed to meet the
requirements for exposure to radio waves established by
the Federal Communications Commission (USA) and
Industry Canada. These requirements set a SAR limit of 1.6
W/kg averaged over 1 gram of tissue. The highest SAR
value reported under this standard during product
certification for use at the ear is 1.46 W/kg and when
properly worn on the body is 0.81 W/kg. Information
about this device model can be found at /www.fcc.gov/
oet/fccidby searching the equipment authorization
system using FCC ID: PYARM-24.
109
Additional safety information
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 109 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 109 Dec 22, 2005 4:45:59 AM
Technical information
Characteristic Value
Weight 127 g with battery
Size Length: 117 mm (closed)
Width: 53 mm
Thickness: 22 mm
Volume 102 cc (closed)
Frequency RM-24 EGSM 850/1800/1900
Memory User: 90 MB total in device
Memory card: miniSD (hot swap,
storage amount varies)
Display Active matrix color
Colors: 262K
Resolution: 352 x 416 pixels
OS Symbian 9.1a, S60 Averell release 3.0
Connectivity Integrated WLAN (IEEE 802.11g)
USB (USB 2.0)
Bluetooth version 1.2
Headset connector
Pop-Port™ connector
Infrared
110
Technical information
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 110 Dec 22, 2005 4:45:59 AM
Nokia One-Year Limited Warranty
Nokia Inc. (“Nokia”) warrants that this cellular phone
(“Product”) is free from defects in material and
workmanship that result in Product failure during normal
usage, according to the following terms and conditions:
1. The limited warranty for the Product extends for ONE
(1) year beginning on the date of the purchase of the
Product. This one year period is extended by each
whole day that the Product is out of your possession
for repair under this warranty.
2. The limited warranty extends only to the original
purchaser (“Consumer”) of the Product and is not
assignable or transferable to any subsequent
purchaser/end-user.
3. The limited warranty extends only to Consumers who
purchase the Product in the United States of America.
4. During the limited warranty period, Nokia will repair,
or replace, at Nokia’s sole option, any defective parts,
or any parts that will not properly operate for their
intended use with new or refurbished replacement
items if such repair or replacement is needed because
of product malfunction or failure during normal
usage. No charge will be made to the Consumer for
any such parts. Nokia will also pay for the labor
charges incurred by Nokia in repairing or replacing
the defective parts. The limited warranty does not
cover defects in appearance, cosmetic, decorative or
structural items, including framing, and any non-
operative parts. Nokia’s limit of liability under the
limited warranty shall be the actual cash value of the
Product at the time the Consumer returns the Product
for repair, determined by the price paid by the
Consumer for the Product less a reasonable amount
for usage. Nokia shall not be liable for any other losses
or damages. These remedies are the Consumer’s
exclusive remedies for breach of warranty.
5. Upon request from Nokia, the Consumer must prove
the date of the original purchase of the Product by a
dated bill of sale or dated itemized receipt.
6. The Consumer shall bear the cost of shipping the
Product to Nokia in Melbourne, Florida. Nokia shall
bear the cost of shipping the Product back to the
Consumer after the completion of service under this
limited warranty.
7. The Consumer shall have no coverage or benefits
under this limited warranty if any of the following
conditions are applicable:
a) The Product has been subjected to abnormal use,
abnormal conditions, improper storage,
exposure to moisture or dampness,
unauthorized modifications, unauthorized
connections, unauthorized repair, misuse,
neglect, abuse, accident, alteration, improper
installation, or other acts which are not the fault
of Nokia, including damage caused by shipping.
b) The Product has been damaged from external
causes such as collision with an object, or from
fire, flooding, sand, dirt, windstorm, lightning,
earthquake or damage from exposure to
111
Nokia One-Year Limited Warranty
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 111 Dec 22, 2005 4:45:59 AM
weather conditions, an Act of God, or battery
leakage, theft, blown fuse, or improper use of any
electrical source, damage caused by computer or
internet viruses, bugs, worms, Trojan Horses,
cancelbots or damage caused by the connection
to other products not recommended for
interconnection by Nokia.
c) Nokia was not advised in writing by the
Consumer of the alleged defect or malfunction of
the Product within fourteen (14) days after the
expiration of the applicable limited warranty
period.
d) The Product serial number plate or the
enhancement data code has been removed,
defaced or altered.
e) The defect or damage was caused by the
defective function of the cellular system or by
inadequate signal reception by the external
antenna, or viruses or other software problems
introduced into the Product.
8. Nokia does not warrant uninterrupted or error-free
operation of the Product. If a problem develops
during the limited warranty period, the Consumer
shall take the following step-by-step procedure:
a) The Consumer shall return the Product to the
place of purchase for repair or replacement
processing.
b) If “a” is not convenient because of distance (more
than 50 miles) or for other good cause, the
Consumer shall ship the Product prepaid and
insured to:
Nokia Inc., Attn: Repair Department
795 West Nasa Blvd.
Melbourne, FL 32901
c) The Consumer shall include a return address,
daytime phone number and/or fax number,
complete description of the problem, proof of
purchase and service agreement (if applicable).
Expenses related to removing the Product from
an installation are not covered under this limited
warranty.The Consumer shall include a return
address, daytime phone number and/or fax
number, complete description of the problem,
proof of purchase and service agreement (if
applicable). Expenses related to removing the
Product from an installation are not covered
under this limited warranty.
d) The Consumer will be billed for any parts or labor
charges not covered by this limited warranty. The
Consumer will be responsible for any expenses
related to reinstallation of the Product.
e) Nokia will repair the Product under the limited
warranty within 30 days after receipt of the
Product. If Nokia cannot perform repairs covered
under this limited warranty within 30 days, or
after a reasonable number of attempts to repair
the same defect, Nokia at its option, will provide
a replacement Product or refund the purchase
price of the Product less a reasonable amount for
usage. In some states the Consumer may have the
right to a loaner if the repair of the Product takes
more than ten (10) days. Please contact the
Customer Service Center at Nokia at the
telephone number listed at the end of this
warranty if you need a loaner and the repair of
112
Nokia One-Year Limited Warranty
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 112 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 112 Dec 22, 2005 4:45:59 AM
the Product has taken or is estimated to take
more than ten (10) days.
f) If the Product is returned during the limited
warranty period, but the problem with the
Product is not covered under the terms and
conditions of this limited warranty, the
Consumer will be notified and given an estimate
of the charges the Consumer must pay to have
the Product repaired, with all shipping charges
billed to the Consumer. If the estimate is refused,
the Product will be returned freight collect. If the
Product is returned after the expiration of the
limited warranty period, Nokia’s normal service
policies shall apply and the Consumer will be
responsible for all shipping charges.
9. You (the Consumer) understand that the product may
consist of refurbished equipment that contains used
components, some of which have been reprocessed.
The used components comply with Product
performance and reliability specifications.
10. ANY IMPLIED WARRANTY OF MERCHANTABILITY, OR
FITNESS FOR A PARTICULAR PURPOSE OR USE, SHALL BE
LIMITED TO THE DURATION OF THE FOREGOING LIMITED
WRITTEN WARRANTY. OTHERWISE, THE FOREGOING
LIMITED WARRANTY IS THE CONSUMER’S SOLE AND
EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. NOKIA SHALL NOT
BE LIABLE FOR SPECIAL, INCIDENTAL, PUNITIVE OR
CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT
LIMITED TO LOSS OF ANTICIPATED BENEFITS OR
PROFITS, LOSS OF SAVINGS OR REVENUE, LOSS OF DATA,
PUNITIVE DAMAGES, LOSS OF USE OF THE PRODUCT OR
ANY ASSOCIATED EQUIPMENT, COST OF CAPITAL, COST
OF ANY SUBSTITUTE EQUIPMENT OR FACILITIES,
DOWNTIME, THE CLAIMS OF ANY THIRD PARTIES,
INCLUDING CUSTOMERS, AND INJURY TO PROPERTY,
RESULTING FROM THE PURCHASE OR USE OF THE
PRODUCT OR ARISING FROM BREACH OF THE WARRANTY,
BREACH OF CONTRACT, NEGLIGENCE, STRICT TORT, OR
ANY OTHER LEGAL OR EQUITABLE THEORY, EVEN IF
NOKIA KNEW OF THE LIKELIHOOD OF SUCH DAMAGES.
NOKIA SHALL NOT BE LIABLE FOR DELAY IN RENDERING
SERVICE UNDER THE LIMITED WARRANTY, OR LOSS OF
USE DURING THE PERIOD THAT THE PRODUCT IS BEING
REPAIRED.
11. Some states do not allow limitation of how long an
implied warranty lasts, so the one year warranty
limitation may not apply to you (the Consumer). Some
states do not allow the exclusion or limitation of
incidental and consequential damages, so certain of
the above limitations or exclusions may not apply to
you (the Consumer). This limited warranty gives the
Consumer specific legal rights and the Consumer may
also have other rights which vary from state to state.
12. Nokia neither assumes nor authorizes any authorized
service center or any other person or entity to assume
for it any other obligation or liability beyond that
which is expressly provided for in this limited
warranty including the provider or seller of any
extended warranty or service agreement.
13. This is the entire warranty between Nokia and the
Consumer, and supersedes all prior and
contemporaneous agreements or understandings,
oral or written, relating to the Product, and no
representation, promise or condition not contained
herein shall modify these terms.
113
Nokia One-Year Limited Warranty
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 113 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 113 Dec 22, 2005 4:45:59 AM
14. This limited warranty allocates the risk of failure of
the Product between the Consumer and Nokia. The
allocation is recognized by the Consumer and is
reflected in the purchase price.
15. Any action or lawsuit for breach of warranty must be
commenced within eighteen (18) months following
purchase of the Product.
16. Questions concerning this limited warranty may be
directed to: Nokia Inc. Attn: Customer Service 7725
Woodland Center Blvd., Ste. 150 Tampa, FL 33614
Telephone: 1-888-NOKIA-2U (1-888-665-4228)
Facsimile: (813) 287-6612 TTY/TDD Users Only:
1-800-24-NOKIA (1-800-246-6542)
17. The limited warranty period for Nokia supplied
attachments and accessories is specifically defined
within their own warranty cards and packaging.
114
Nokia One-Year Limited Warranty
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 114 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 114 Dec 22, 2005 4:45:59 AM
Appendices
Appendix A Message from
the CTIA
(Cellular Telecommunications &
Internet Association) to all users of
mobile phones
A Guide to Safe and Responsible Wireless
Phone Use
1
Safety is the most important call you will ever make.
Tens of millions of people in the U.S. today take advantage of the
unique combination of convenience, safety and value delivered by the
wireless telephone. Quite simply, the wireless phone gives people the
powerful ability to communicate by voice--almost anywhere,
anytime--with the boss, with a client, with the kids, with emergency
personnel or even with the police. Each year, Americans make billions
of calls from their wireless phones, and the numbers are rapidly
growing.
But an important responsibility accompanies those benefits, one that
every wireless phone user must uphold. When driving a car, driving
is your first responsibility. A wireless phone can be an invaluable tool,
but good judgment must be exercised at all times while driving a motor
vehicle--whether on the phone or not.
The basic lessons are ones we all learned as teenagers. Driving requires
alertness, caution and courtesy. It requires a heavy dose of basic
common sense--keep your head up, keep your eyes on the road, check
your mirrors frequently and watch out for other drivers. It requires
obeying all traffic signs and signals and staying within the speed limit.
It means using seatbelts and requiring other passengers to do the same.
But with wireless phone use, driving safely means a little more. This
brochure is a call to wireless phone users everywhere to make safety
their first priority when behind the wheel of a car. Wireless
telecommunications is keeping us in touch, simplifying our lives,
protecting us in emergencies and providing opportunities to help
others in need.
When it comes to the use of wireless phones, safety is your most
important call .
Wireless Phone "Safety Tips"
Below are safety tips to follow while driving and using a wireless
phone which should be easy to remember.
•Get to know your wireless phone and its features such as speed
dial and redial. Carefully read your instruction manual and learn
to take advantage of valuable features most phones offer, including
automatic redial and memory. Also, work to memorize the phone
keypad so you can use the speed dial function without taking your
attention off the road.
•When available, use a hands free device. A number of hands free
wireless phone accessories are readily available today. Whether
you choose an installed mounted device for your wireless phone
or a speaker phone accessory, take advantage of these devices if
available to you.
•Position your wireless phone within easy reach. Make sure you
place your wireless phone within easy reach and where you can
grab it without removing your eyes from the road. If you get an
1 © 2001 Cellular Telecommunications & Internet Association. All Rights Reserved. 1250 Connecticut Avenue, NW Suite 800,
Washington, DC 20036. Phone: (202) 785-0081
115
Appendices
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 115 Dec 22, 2005 4:45:59 AM
incoming call at an inconvenient time, if possible, let your voice
mail answer it for you.
•Suspend conversations during hazardous driving conditions or
situations. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic or hazardous
weather conditions. Rain, sleet, snow and ice can be hazardous,
but so is heavy traffic. As a driver, your first responsibility is to
pay attention to the road.
•Do not take notes or look up phone numbers while driving. If you
are reading an address book or business card, or writing a "to do"
list while driving a car, you are not watching where you are going.
It’s common sense. Don’t get caught in a dangerous situation
because you are reading or writing and not paying attention to the
road or nearby vehicles.
•Dial sensibly and assess the traffic; if possible, place calls when
you are not moving or before pulling into traffic. Try to plan your
calls before you begin your trip or attempt to coincide your calls
with times you may be stopped at a stop sign, red light or otherwise
stationary. But if you need to dial while driving, follow this simple
tip--dial only a few numbers, check the road and your mirrors, then
continue.
•Do not engage in stressful or emotional conversations that may be
distracting. Stressful or emotional conversations and driving do
not mix--they are distracting and even dangerous when you are
behind the wheel of a car. Make people you are talking with aware
you are driving and if necessary, suspend conversations which
have the potential to divert your attention from the road.
•Use your wireless phone to call for help. Your wireless phone is
one of the greatest tools you can own to protect yourself and your
family in dangerous situations--with your phone at your side, help
is only three numbers away. Dial 9-1-1 or other local emergency
number in the case of fire, traffic accident, road hazard or medical
emergency. Remember, it is a free call on your wireless phone!
•Use your wireless phone to help others in emergencies. Your
wireless phone provides you a perfect opportunity to be a "Good
Samaritan" in your community. If you see an auto accident, crime
in progress or other serious emergency where lives are in danger,
call 9-1-1 or other local emergency number, as you would want
others to do for you.
•Call roadside assistance or a special wireless non-emergency
assistance number when necessary. Certain situations you
encounter while driving may require attention, but are not urgent
enough to merit a call for emergency services. But you still can
use your wireless phone to lend a hand. If you see a broken-down
vehicle posing no serious hazard, a broken traffic signal, a minor
traffic accident where no one appears injured or a vehicle you
know to be stolen, call roadside assistance or other special non-
emergency wireless number.
Careless, distracted individuals and people driving irresponsibly
represent a hazard to everyone on the road. Since 1984, the Cellular
Telecommunications Industry Association and the wireless industry
have conducted educational outreach to inform wireless phone users
of their responsibilities as safe drivers and good citizens. As we
approach a new century, more and more of us will take advantage of
the benefits of wireless telephones. And, as we take to the roads, we
all have a responsibility to drive safely. The wireless industry reminds
you to use your phone safely when driving.
For more information, please call 1-888-901-SAFE. For updates:
www.wow-com.com/consumer/issues/driving/articles.cfm?ID=85
Appendix B Message from
the FDA
Message from the FDA
©July 18, 2001 For updates: www.fda.gov/cdrh/phones
•Do wireless phones pose a health hazard? The available scientific
evidence does not show that any health problems are associated
with using wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones emit low
levels of radio frequency energy (RF) in the microwave range
while being used. They also emit very low levels of RF when in
116
Appendices
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 116 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 116 Dec 22, 2005 4:45:59 AM
the standby mode. Whereas high levels of RF can produce health
effects (by heating tissue), exposure to low level RF that does not
produce heating effects causes no known adverse health effects.
Many studies of low level RF exposures have not found any
biological effects. Some studies have suggested that some
biological effects may occur, but such findings have not been
confirmed by additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in determining
the reasons for inconsistent results.
•What is FDA's role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-
emitting consumer products such as wireless phones before they
can be sold, as it does with new drugs or medical devices.
However, the agency has authority to take action if wireless phones
are shown to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could require the
manufacturers of wireless phones to notify users of the health
hazard and to repair, replace or recall the phones so that the hazard
no longer exists. Although the existing scientific data do not justify
FDA regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the following:
Support needed research into possible biological effects of RF of
the type emitted by wireless phones; Design wireless phones in a
way that minimizes any RF exposure to the user that is not
necessary for device function; and Cooperate in providing users
of wireless phones with the best possible information on possible
effects of wireless phone use on human health. FDA belongs to an
interagency working group of the federal agencies that have
responsibility for different aspects of RF safety to ensure
coordinated efforts at the federal level. The following agencies
belong to this working group: National Institute for Occupational
Safety and Health Environmental Protection Agency Federal
Communications Commission Occupational Safety and Health
Administration National Telecommunications and Information
Administration The National Institutes of Health participates in
some interagency working group activities, as well. FDA shares
regulatory responsibilities for wireless phones with the Federal
Communications Commission (FCC). All phones that are sold in
the United States must comply with FCC safety guidelines that
limit RF exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones. FCC also regulates the
base stations that the wireless phone networks rely upon. While
these base stations operate at higher power than do the wireless
phones themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than those they
can get from wireless phones. Base stations are thus not the subject
of the safety questions discussed in this document.
•What kinds of phones are the subject of this update? The term
wireless phone refers here to hand-held wireless phones with built-
in antennas, often called cell mobile or PCS phones. These types
of wireless phones can expose the user to measurable
radiofrequency energy (RF) because of the short distance between
the phone and the user’s head. These RF exposures are limited by
Federal Communications Commission safety guidelines that were
developed with the advice of FDA and other federal health and
safety agencies. When the phone is located at greater distances
from the user, the exposure to RF is drastically lower because a
person's RF exposure decreases rapidly with increasing distance
from the source. The so-called cordless phones; which have a base
unit connected to the telephone wiring in a house, typically operate
at far lower power levels, and thus produce RF exposures far below
the FCC safety limits.
•What are the results of the research done already? The research
done thus far has produced conflicting results, and many studies
have suffered from flaws in their research methods. Animal
experiments investigating the effects of radiofrequency energy
(RF) exposures characteristic of wireless phones have yielded
conflicting results that often cannot be repeated in other
laboratories. A few animal studies, however, have suggested that
low levels of RF could accelerate the development of cancer in
laboratory animals. However, many of the studies that showed
increased tumor development used animals that had been
genetically engineered or treated with cancer-causing chemicals
so as to be pre-disposed to develop cancer in the absence of RF
exposure. Other studies exposed the animals to RF for up to 22
hours per day. These conditions are not similar to the conditions
under which people use wireless phones, so we don’t know with
certainty what the results of such studies mean for human health.
117
Appendices
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 117 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 117 Dec 22, 2005 4:45:59 AM
Three large epidemiology studies have been published since
December 2000. Between them, the studies investigated any
possible association between the use of wireless phones and
primary brain cancer, glioma, meningioma, or acoustic neuroma,
tumors of the brain or salivary gland, leukemia, or other cancers.
None of the studies demonstrated the existence of any harmful
health effects from wireless phone RF exposures. However, none
of the studies can answer questions about long-term exposures,
since the average period of phone use in these studies was around
three years.
•What research is needed to decide whether RF exposure from
wireless phones poses a health risk? A combination of laboratory
studies and epidemiological studies of people actually using
wireless phones would provide some of the data that are needed.
Lifetime animal exposure studies could be completed in a few
years. However, very large numbers of animals would be needed
to provide reliable proof of a cancer promoting effect if one exists.
Epidemiological studies can provide data that is directly applicable
to human populations, but 10 or more years follow-up may be
needed to provide answers about some health effects, such as
cancer. This is because the interval between the time of exposure
to a cancer-causing agent and the time tumors develop - if they do
- may be many, many years. The interpretation of epidemiological
studies is hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones. Many factors
affect this measurement, such as the angle at which the phone is
held, or which model of phone is used.
•What is FDA doing to find out more about the possible health
effects of wireless phone RF? FDA is working with the U.S.
National Toxicology Program and with groups of investigators
around the world to ensure that high priority animal studies are
conducted to address important questions about the effects of
exposure to radiofrequency energy (RF). FDA has been a leading
participant in the World Health Organization International
Electromagnetic Fields (EMF) Project since its inception in 1996.
An influential result of this work has been the development of a
detailed agenda of research needs that has driven the establishment
of new research programs around the world. The Project has also
helped develop a series of public information documents on EMF
issues. FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research and
Development Agreement (CRADA) to do research on wireless
phone safety. FDA provides the scientific oversight, obtaining
input from experts in government, industry, and academic
organizations. CTIA-funded research is conducted through
contracts to independent investigators. The initial research will
include both laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of additional
research needs in the context of the latest research developments
around the world.
•How can I find out how much radiofrequency energy exposure I
can get by using my wireless phone? All phones sold in the United
States must comply with Federal Communications Commission
(FCC) guidelines that limit radiofrequency energy (RF) exposures.
FCC established these guidelines in consultation with FDA and
the other federal health and safety agencies. The FCC limit for RF
exposure from wireless telephones is set at a Specific Absorption
Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC limit
is consistent with the safety standards developed by the Institute
of Electrical and Electronic Engineering (IEEE) and the National
Council on Radiation Protection and Measurement. The exposure
limit takes into consideration the body’s ability to remove heat
from the tissues that absorb energy from the wireless phone and is
set well below levels known to have effects. Manufacturers of
wireless phones must report the RF exposure level for each model
of phone to the FCC. The FCC website (http://www.fcc.gov/oet/
rfsafety) gives directions for locating the FCC identification
number on your phone so you can find your phone’s RF exposure
level in the online listing.
•What has FDA done to measure the radiofrequency energy coming
from wireless phones? The Institute of Electrical and Electronic
Engineers (IEEE) is developing a technical standard for measuring
the radiofrequency energy (RF) exposure from wireless phones
and other wireless handsets with the participation and leadership
of FDA scientists and engineers. The standard, Recommended
Practice for Determining the Spatial-Peak Specific Absorption
Rate (SAR) in the Human Body Due to Wireless Communications
Devices: Experimental Techniques, sets forth the first consistent
118
Appendices
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 118 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 118 Dec 22, 2005 4:45:59 AM
test methodology for measuring the rate at which RF is deposited
in the heads of wireless phone users. The test method uses a tissue-
simulating model of the human head. Standardized SAR test
methodology is expected to greatly improve the consistency of
measurements made at different laboratories on the same phone.
SAR is the measurement of the amount of energy absorbed in
tissue, either by the whole body or a small part of the body. It is
measured in watts/kg (or milliwatts/g) of matter. This
measurement is used to determine whether a wireless phone
complies with safety guidelines.
•What steps can I take to reduce my exposure to radiofrequency
energy from my wireless phone? If there is a risk from these
products--and at this point we do not know that there is--it is
probably very small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to minimize your
exposure to radiofrequency energy (RF). Since time is a key factor
in how much exposure a person receives, reducing the amount of
time spent using a wireless phone will reduce RF exposure. If you
must conduct extended conversations by wireless phone every day,
you could place more distance between your body and the source
of the RF, since the exposure level drops off dramatically with
distance. For example, you could use a headset and carry the
wireless phone away from your body or use a wireless phone
connected to a remote antenna. Again, the scientific data do not
demonstrate that wireless phones are harmful. But if you are
concerned about the RF exposure from these products, you can use
measures like those described above to reduce your RF exposure
from wireless phone use.
•What about children using wireless phones? The scientific
evidence does not show a danger to users of wireless phones,
including children and teenagers. If you want to take steps to lower
exposure to radiofrequency energy (RF), the measures described
above would apply to children and teenagers using wireless
phones. Reducing the time of wireless phone use and increasing
the distance between the user and the RF source will reduce RF
exposure.Some groups sponsored by other national governments
have advised that children be discouraged from using wireless
phones at all. For example, the government in the United Kingdom
distributed leaflets containing such a recommendation in
December 2000. They noted that no evidence exists that using a
wireless phone causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by children was
strictly precautionary; it was not based on scientific evidence that
any health hazard exists.
•What about wireless phone interference with medical equipment?
Radio frequency energy (RF) from wireless phones can interact
with some electronic devices. For this reason, FDA helped develop
a detailed test method to measure electromagnetic interference
(EMI) of implanted cardiac pacemakers and defibrillators from
wireless telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by FDA,
medical device manufacturers, and many other groups, was
completed in late 2000. This standard will allow manufacturers to
ensure that cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested hearing aids for interference
from handheld wireless phones and helped develop a voluntary
standard sponsored by the Institute of Electrical and Electronic
Engineers (IEEE). This standard specifies test methods and
performance requirements for hearing aids and wireless phones so
that no interference occurs when a person uses a compatible phone
and a accompanied hearing aid at the same time. This standard was
approved by the IEEE in 2000. FDA continues to monitor the use
of wireless phones for possible interactions with other medical
devices. Should harmful interference be found to occur, FDA will
conduct testing to assess the interference and work to resolve the
problem.
•Where can I find additional information? For additional
information, please refer to the following resources:
FDA web page on wireless phoneshttp://www.fda.gov/cdrh/
phones/index.html http://www.fda.gov/cdrh/phones/index.html
Federal Communications Commission (FCC) RF Safety Program
http://www.fda.gov/cdrh/phones/index.html
International Commission on Non-Ionizing Radiation
Protectionhttp://www.icnirp.del World Health Organization
(WHO) International EMF Project http://www.who.int/emf
119
Appendices
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 119 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 119 Dec 22, 2005 4:45:59 AM
National Radiological Protection Board (UK) http://
www.nrpb.org.uk/
2004 For updates:http://www.fda.gov/cdrh/phones
120
Appendices
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 120 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 120 Dec 22, 2005 4:45:59 AM
Index
Symbols/Numerics
1-touch dialing 27
A
access points 67, 86
answering calls 28
application manager 98
applications
common actions 14
audio files 70
authority certificates 99
automatic answer 91
B
battery
charge level 23
charging 9
installing 10
blogs 66
Bluetooth 57
pairing 59
settings 58
bookmarks 65
browsing Web pages 64, 67
business cards 37
C
cable 56
calculator 93
calendar 92
calling 27
calls
forwarding 28
restricting 28
settings 85
Camera 54
camera
editing the settings 54
recording a video clip 54
taking a picture 54
CD-ROM 9
cells 79
certificates 99
charging the battery 9
chart sheets 80
chat 50
clock 94
connecting to the Internet 67
connection manager 62
connection methods 56
Bluetooth 57
cable 56
infrared 61
modem 61
WLAN 56
connections
WLAN settings 88
contact groups 36
contact information 37
contacts
adding 36
copying information 37
default information 36
groups 36
ringing tones 37
copying text 16
D
data
connections 62
declining calls 28
display
indicators 23
settings 85
documents 77
E
e-mail
accounts 48
messages 45
replying 47
writing 48
ending network connections 63
enhancement settings 91
enhancements 103
equalizer 72
F
feeds 66
flash player 73
forwarding calls 28
121
Index
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 121 Dec 22, 2005 4:45:59 AM
front cover
open and close 17
G
gallery 69
general packet radio service
See
GPRS
GPRS 62
H
help 13
I
IM 50
images
add to Contacts 70
renaming 70
rotating 69
sending 70
set as wallpaper 70
zooming in or out 69
indicators 23
infrared 61
infrared port 20
installing
battery 10
SIM card 10
instant messaging 50
Internet 64, 67
access points 67
call settings 86
settings 67
J
joystick 18
joystick settings 84
K
keyboard 17
keyguard 19
keypad lock 19
L
landmarks 96
language 84
listening to music 72
locking
device 19
keypad 19
log
information 29
logs 29
remote configuration 100
M
mail
See
e-mail
Media applications 69
memory 24
memory card 24
menu 13
messages 39
deleting 47
e-mail 45
folders 39
multimedia messages 42
picture messages 41
special messages 53
text messages 40
modem 61
multimedia messages 42
creating 42
receiving 43
replying to 43
sending 42
settings 44
Music player
adjusting music volume 72
playlists 72
music player 72
mVPN
See
VPN
N
navigation 96
navigator 96
notes 93
O
outline view 78
P
packet data 62
settings 86
pairing 59
personal certificates 99
personalization 101, 102
phone 27
calls 27
language 84
settings 84
122
Index
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 122 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 122 Dec 22, 2005 4:45:59 AM
photos 54
picture messages 41
forwarding 41
viewing 41
playing
music 72
video and audio 70
voice recordings 73
PopPort connector 20
predictive text 84
predictive text input 15
presentations 80
printing 83
profiles 101
R
RealPlayer 70
playing media clips 70
recording
calls 73
voice 73
rejecting calls 28
remote configuration 100
remote synchronization 100
restricting
calls 28
restriction password 34
ringing tones 37
S
screen export 82
SD, mini 24
security 33
selecting items 14
selecting objects 14
selecting text 14
selection key settings 84
sending business cards 37
service commands 53
settings 84
Bluetooth 58
calendar 93
calls 85
camera 54
connection 86
display 85
general 84
Internet 67
message centers 40
multimedia messages 44
profiles 101
remote configuration 100
security 34
standby 84
text messages 41
WLAN 88
shortcuts 21
signal strength 23
SIM access profile 60
SIM card
installing 10
text messages 40
slide shows 80
SMS messages 40
special messages 53
standby
mode 21
settings 84
storage 24
switching device on and off 12
T
text
copying 16
predictive input 15
selecting 14
traditional input 15
writing 15
text messages 40
editing message centers 40
managing messages in the
SIM card 40
replying 40
sending 40
writing 40
themes 102
to-do list 92
tools folder 96
traditional text input 15
tutorial 13
U
USB data cable 56
V
video clips 54, 70
virtual private network 57
voice commands 97
voice dialing 97
voice mailbox 27
voice memos 73
voice over IP 33
voice recorder 73
playing a voice recording 73
volume 19
123
Index
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 123 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 123 Dec 22, 2005 4:45:59 AM
VPN 57
W
Web 64, 67
welcome note 84
WLAN 56
access point settings 90
security settings 88, 89
settings 88
worksheets 79
writing language 84
Z
zip manager 83
124
Index
file:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 124 Dec 22, 2005 4:45:59 AMfile:///C:/USERS/MODEServer/miedward/25323280/rm-24_zeus/en/issue_1/rm-24_zeus_en_1.xml Page 124 Dec 22, 2005 4:45:59 AM
