Manual 2
Messaging
71
•Defer retrieval - To let the multimedia messaging centre save the
message to be retrieved later. To retrieve the message, set On
receiving msg. to Retr. immediately.
•Reject message - To reject multimedia messages. The multimedia
message centre deletes the messages.
•Allow anon. messages - Select No to reject messages coming from an
anonymous sender.
•Receive adverts - Define whether you want to allow reception of
multimedia message advertisements or not.
•Reports - Set to Yes, if you want the status of the sent message
(Pending, Failed, Delivered) to be shown in the Reports.
•Deny report sending - Choose Yes, if you do not want your phone to
send delivery reports of received multimedia messages.
•Message validity (network service) - If the recipient of a message
cannot be reached within the validity period, the message is removed
from the multimedia message centre. Maximum time is the
maximum amount of time allowed by the network for which the
message remains valid.
•Image size - Define the size of the image in a multimedia message.
The options are: Small (max. of 160x120 pixels) and Large (max.
640x480 pixels).
•Default speaker - Choose Loudspeaker or Handset, depending on
whether you want the sounds in a multimedia message to be played
through the loudspeaker or the earpiece.
The default setting of the multimedia message service is generally on.
The appearance of a multimedia message may vary depending on the receiving
device.
E-mail messages
Go to E-mail.
Open Mailbox in use to select which mailbox you want to use.
r1024_en.book Page 71 Thursday, July 8, 2004 12:40 PM
Messaging
72
Settings for Mailboxes
Options when editing e-mail settings: Editing options, New
mailbox, Delete, Help, and Exit.
Select Mailboxes to open a list of defined mailboxes. If no mailboxes
have been defined, you are prompted to do so. The following list of
settings is shown (this information is available from your e-mail service
provider):
•Mailbox name - Write a descriptive name for the mailbox.
•Access point in use (Must be defined) - The Internet Access Point
(IAP) used for the mailbox. Choose an IAP from the list. See
“Connection settings” on page 90.
•My e-mail address (Must be defined) - Write the e-mail address
given to you by your service provider. The address must contain the
@ character. Replies to your messages are sent to this address.
•Outgoing mail server: (Must be defined) - Write the IP address or
host name of the computer that sends your e-mail.
•Send message (network service) - Define how e-mail is sent from
your phone. Immediately - The phone tries to connect to the mailbox
immediately after you have selected Send. During next conn. - E-mail
is sent the next time you connect to your remote mailbox.
•Send copy to self - Select Yes to save a copy of the e-mail to your
remote mailbox and to the address defined in My e-mail address.
•Include signature - Select Yes to attach a signature to your e-mail
messages and to start to write or edit a signature text.
•User name: - Write your user name, provided by your service
provider.
•Password: - Write your password. For increasing security, you can
leave this field blank, so that every time you try to connect to your
remote mailbox, you are prompted for the password Otherwise the
password is sent automatically.
•Incoming mail server: (Must be defined) - The IP address or host
name of the computer that receives your e-mail.
•Mailbox type: - Defines the e-mail protocol your remote mailbox
service provider recommends. The options are POP3 and IMAP4.
r1024_en.book Page 72 Thursday, July 8, 2004 12:40 PM
Messaging
73
This setting can be selected only once and cannot be changed if you
have saved or exited from the mailbox settings.
•Security - Used with the POP3, IMAP4, and SMTP protocols to secure
the connection to the remote mailbox.
•APOP secure login - Used with the POP3 protocol to encrypt the
sending of passwords to the remote e-mail server. Not shown if
IMAP4 is selected for Mailbox type:.
•Retrieve attachments (not shown if the e-mail protocol is set to
POP3) - To retrieve e-mail with or without attachments.
•Retrieve headers - To limit the number of e-mail headers you want to
retrieve to your phone. The options are All and User defined. Used
with the IMAP4 protocol only.
Service messages
Go to Service message. The following list of settings opens:
•Service messages - Choose whether or not you want to allow
reception of service messages.
•Authentic. needed - Choose to receive service messages only from
authorised sources.
Cell broadcast
Check with your service provider whether Cell broadcast (network
service) is available and what the available topics and related topic
numbers are.
Go to Cell broadcast to change the settings:
• Reception - On or Off.
•Language - All allows you to receive cell broadcast messages in every
possible language. Selected allows you to choose in which languages
you wish to receive cell broadcast messages. If the language you
prefer could not be found in the list, select Other.
•Topic detection - If you receive a message that does not belong to
any of the existing topics, Topic detection→On allows you to save
the topic number automatically. The topic number is saved to the
r1024_en.book Page 73 Thursday, July 8, 2004 12:40 PM
Messaging
74
topic list and shown without a name. Choose Off if you do not want
to save new topic numbers automatically.
Settings for the Other folder
Go to Other. The following list of settings opens:
•Save sent messages - Choose to save a copy of every text message,
multimedia message, or e-mail that you have sent to the Sent items
folder.
•No. of saved msgs. - Define how many sent messages are saved to the
Sent items folder at a time. The default limit is 20 messages. When
the limit is reached, the oldest message is deleted.
•Memory in use - Define the memory store. The choices are the
phone’s memory or the memory card, if one is used.
■Chat
Go to Menu→Chat.
Options in the Chat main view are: Open, Login, Logout, Settings,
Help, and Exit.
Chat (network service) allows you to converse with other people using
instant messages, and join discussion forums (chat groups) with specific
topics. Once you have registered with a chat service, you can log into
the service provider’s chat server.
Check the availability of chat services, pricing, and tariffs with your
network operator and/or service provider. Service providers also give you
instructions on how to use their services.
To access a chat service you need to save the settings for that service.
You may receive the settings from the network operator or service
provider that offers the service. See “Receiving smart messages” on
page 64. You can also key in the settings manually. See “Chat and
Presence servers” on page 80.
Connecting to a chat server
Go to Menu→Chat.
r1024_en.book Page 74 Thursday, July 8, 2004 12:40 PM
Messaging
75
1. The phone automatically tries to connect to a chat server. You can
change the chat server to connect to. See “Chat and Presence
servers” on page 80.
2. Once the connection has been established, key in your user ID and
password and press , or press Cancel to stay offline. When you
are offline, your phone is not connected to the chat server and you
cannot send or receive messages. To log in later, select
Options→Login.
You obtain the user ID and password from your service provider.
To log out, select Options→Logout.
Modifying your chat settings
Go to Options→Settings→Chat settings.
•Use screen name - Select Yes to key in a nickname (max. 10
characters).
•Chat presence - Prevent others from seeing if you are online, select
Not active.
•Allow messages from - Select All, From chat contacts or None.
•Allow invitations from - Select All, From chat contacts or None.
•Message speed - Select the speed at which new messages are
displayed.
•Availability reloading - Choose how to update information about
whether your chat contacts are online or offline. Select Automatic or
Manual.
•Reload availab. for - Select All contacts or Selected contacts.
Joining and leaving a chat group
Go to Menu→Chat→Chat groups.
A list of chat groups that you have saved or are currently joined to is
shown. The icon next to a group indicates what type it is:
• - A group that you have created and are currently joined to.
• - A group that you have created but are not currently joined to.
• - A group that you have saved and are currently joined to.
r1024_en.book Page 75 Thursday, July 8, 2004 12:40 PM
Messaging
76
• - A group that you have saved but are not currently joined to.
Options in the Chat groups view are: Open, Join group, Create
new group, Leave chat group, Chat group, Search, Settings, Help, and
Exit.
• - A group that you are currently joined to but have not saved.
To join a chat group: Scroll to a group on the list and press . To
join a chat group not on the list but for which you know the group ID,
select Options→Join group. Key in the group ID and press .
You can scroll to a group, press Options→Chat group and then select:
Save group, Delete, View members to see which members are currently
joined to the group, Chat group details to see the group ID, topic,
members, editing rights in the group, and whether sending private
messages is allowed in the group, and Chat group settings to view and
edit the chat group’s settings. See “Editing chat group settings” on
page 79.
To leave the chat group: Select Options→Leave chat group.
Searching for chat groups and users
Go to Chat groups→ Options→Search→Groups or Users.
•You can search for Groups by Group name, Topic, and Members (user
ID). For groups that you have found you can select New search, Join
and Save group.
•You can search for Users by User's name, User ID, Phone number, and
E-mail address. For users that you have found you can select New
search, Open conversation, Add to Chat contact to save the contact,
Send invitation, and Add to blocked list to block (or unblock)
messages from the contact.
When the search result is displayed, you can select Options→New
search, More results from the same search, and Previous results to see
your previous search result.
Chatting in a chat group
Go to Menu→Chat→Chat groups.
r1024_en.book Page 76 Thursday, July 8, 2004 12:40 PM
Messaging
77
Once you have joined a chat group, you can view the messages that are
exchanged in the group, and send your own messages.
Options while chatting: Send, Send private msg., Reply, Send
invitation, Leave chat group, Save group, Record convers./Stop
recording, Help, and Exit.
• To send a message, write the message and press .
• To send a private message to a member (if allowed in the group),
select Options→Send private msg., select the recipient, write the
message, and press .
To reply to a private message sent to you, select Options→Reply.
To invite chat contacts who are online to join the chat group (if allowed
in the group), select Options→Send invitation, select the contacts you
want to invite, write the invitation message, and press Done.
Recording messages
To record the messages that are exchanged in a chat group or during an
individual conversation, select Options→Record convers.. Key in the
name for the message file and press . To stop recording, select
Options→Stop recording.
The recorded message files are saved to Notes. See “Notes” on page 105.
Blocking messages
To prevent receiving messages from certain chat users, select
Options→Blocking options and then select:
•Add to blocked list - To block messages from the currently selected
user.
•Add ID to list manually - Key in the user ID of the user and press .
•View blocked list - To see the users whose messages are blocked.
•Unblock - Select the user that you want to remove from the blocked
list and press .
Starting and viewing individual conversations
Go to Menu→Chat→Conversations.
This shows a list of the chat users with whom you have an ongoing
conversation.
r1024_en.book Page 77 Thursday, July 8, 2004 12:40 PM
Messaging
78
To start a new conversation, select Options→New conversation and
then select:
Options in the Conversations view are: Send, Add to chat contact,
Forward, Record convers./Stop recording, Blocking options, End
conversation, Help, and Exit.
•Select recipient - To see a list of your saved chat contacts that are
currently online. Scroll to the contact and press .
•Enter user ID - Key in the user ID and press . The user ID is
provided by the service provider to those who register to the service.
To view an ongoing conversation, scroll to the user and press . To
continue the conversation, write your message and press . To return
to the conversations list without closing the conversation, press Back.
To close the conversation, select Options→End conversation.
Icon: next to a user indicates that you have received a new message
from that user.
Ongoing conversations are automatically closed when you exit Chat.
To save a user to your chat contacts, scroll to the user and select
Options→Add to Chat contact.
To send automatic replies to incoming messages, select Options→Set
auto reply on. Key in the text and press Done.
Chat contacts
Go to Menu→Chat→Chat contacts.
Options in the Chat contacts view are: Open, Open conversation,
Switch tracking on, Belongs to groups, New Chat contact, Edit, Delete,
Reload user availab., Blocking options, Search, Settings, Help, and Exit.
This shows a list of your saved chat contacts. is shown next to
contacts that are currently online, and indicates contacts that are
offline.
To create a new contact, select Options→New chat contact. Fill in the
Name and User ID fields and press Done.
You can scroll to a contact and press to view contact details. Press
Options and select:
r1024_en.book Page 78 Thursday, July 8, 2004 12:40 PM
Messaging
79
•Edit - Edit the contact’s details.
•Open conversation - Start a new conversation or continue an
ongoing conversation with the contact.
•Switch tracking on - Be notified every time the chat contact goes
online or offline.
•Belongs to groups - See which groups the chat contact has joined.
•Reload user availab. - Update information about whether contacts
are online or offline. This option is not available if you have set the
Availability reloading to Automatic in Chat settings.
Creating a new chat group
Go to Chat groups→Options→Create new group. Key in the
settings for the group:
•Group name, Group topic, and a Welcome note that the participants
see when they join the group.
•Group size - Maximum number of members allowed to join the
group.
•Allow search - Define if others can find the chat group by searching.
•Editing rights - Scroll to the chat group members to whom you want
to give editing rights and permission to invite contacts to join the
group.
•Group members - See “Restricting access to a chat group” on
page 80.
•Banned - Displays a list of banned users.
•Allow private msgs. - Allow or prevent private messaging between
members.
•Group ID - Is created automatically and cannot be changed.
Editing chat group settings
Go to Menu→Chat→Chat groups.
You can edit the settings for a chat group if you have created the group
or if the creator of the group has given you editing rights. In the Chat
groups view, scroll to the desired group and select Options→Chat
r1024_en.book Page 79 Thursday, July 8, 2004 12:40 PM
Messaging
80
group→Chat group settings. See “Creating a new chat group” on
page 79.
Restricting access to a chat group
You can make a chat group closed by creating a Group members list.
Only the users on the list are allowed to join the group. Go to the Chat
groups view, scroll to the group and select Options→Chat group→Chat
group settings→Group members→Selected only.
• To add a user to the list, select Add and Chat contact or Enter user ID.
• To remove a user from the list, scroll to the user and select Remove.
• To clear the list and allow all chat users to join the group again select
Remove all.
Chat and Presence servers
Go to Options→ Settings→Server settings. You may receive the
settings as a smart message from the service provider that offers the
chat service.
• To change the chat or presence server you wish to connect to, select
Default server.
• To change the Presence login type, select Login type and select
Automatic, Aut. in home net., or Manual.
• To change the Chat login type, select Login type and select
Automatic or Manual.
• To add a new server, select Options→New server. Key in or select the
settings: Server name and Access point in use to connect to the
server, Web address of the chat server, your User ID and login
Password. See “Connection settings” on page 90.
You obtain the user ID and password from your service provider
when you register for the service. If you do not know your user ID or
password, contact your service provider.
r1024_en.book Page 80 Thursday, July 8, 2004 12:40 PM
Tools
81
8. Tools
■File manager
Go to Menu→Tools→File manager.
In the File manager, you can browse, open, and manage files and folders
in the phone memory or on the memory card, if you use one.
Options in the File manager main view are: Open, Send, Delete,
Move to folder, Copy to folder, New folder, Mark/Unmark, Rename, Find,
Receive via infrared, View details, Memory details, Help, and Exit.
Open the File manager to see a list of the folders in the phone memory.
Press to see the folders on the memory card, if you use one.
You can browse, open, and create folders, mark, copy and move items to
folders. See “Actions common to all applications” on page 19.
Copyright protections may prevent some images, ringing tones, and other
content from being copied, modified, transferred or forwarded.
Receiving files via Infrared
Go to Options→Receive via infrared.
Files are automatically received into the root level of the folder
structureand can be moved or copied to other folders. See “Infrared
connection” on page 125.
Viewing memory consumption
Go to Options→Memory details.
If you have a memory card installed in your phone, you have a choice of
two memory views, one for the phone memory and one for the memory
card.
Press or to move from one memory tab to another.
To check memory consumption of the current memory select Options→
Memory details.
The phone calculates the approximate amount of free memory for
storing data and installing new applications.
r1024_en.book Page 81 Thursday, July 8, 2004 12:40 PM
Tools
82
In the memory views, you can view the memory consumption of the
different data groups: Calendar, Contacts, Documents, Messages,
Images, Sound files, Video clips, Applications, Mem. in use, and Free
memory.
If the phone memory is getting low, remove some files, or move them to
the memory card. See “Troubleshooting” on page 130.
■Voice commands
Go to Menu→Tools→Voice com..
You can use Voice commands to start applications and
profiles, and to dial numbers from Contacts, without having to look at
your phone’s display. You record a word, or words (voice command) and
then pronounce this voice command to open an application, activate a
profile, or dial a number.
You can have only one voice command per item.
Options in the Voice commands main view are: Add voice
command, Open, New application, Playback, Change, Delete, Delete all,
Help, and Exit.
Any spoken word(s) can be a voice command.
• When recording, hold the phone at a short distance away from your
mouth. After the starting tone, clearly pronounce the word, or words,
you want to record as a voice command.
Before using voice tags, note that:
• Voice tags are not language-dependent. They are dependent on the speaker's
voice.
• You must say the name exactly as you said it when you recorded it.
• Voice tags are sensitive to background noise. Record voice tags and use them
in a quiet environment.
• Very short names are not accepted. Use long names and avoid similar names
for different numbers.
r1024_en.book Page 82 Thursday, July 8, 2004 12:40 PM
Tools
83
Note: Using voice tags may be difficult in a noisy environment or during
an emergency, so you should not rely solely upon voice dialling in all
circumstances.
Adding a voice command to an application
1. In the Voice commands main view, scroll to the application that you
want to add a voice command to, and select Options→Add voice
command.
To add a voice command to a profile, the Profiles folder must be
opened and a specific profile selected.
To add an application to the list of applications in the Voice
commands main view, select Options→New application, scroll to
the application that you want to add and press Select.
2. The text Press 'Start', then speak after tone is displayed.
• Press Start to record a voice command. The phone sounds a
starting tone and the note Speak now is displayed.
3. Pronounce the voice command. The phone stops recording after
approximately 5 seconds.
4. After recording, the phone plays the recorded command and the note
Playing voice command is displayed. If you do not want to save the
recording, press Quit.
5. When the voice command has been successfully saved, the note
Voice command saved is displayed and a beep sounds. A symbol
can be seen next to the application.
Starting an application using a voice command
1. In standby mode, press and hold . A short tone is played and
the note Speak now is displayed.
2. When you are starting an application by saying a voice command,
hold the phone a short distance away from your mouth and
pronounce the voice command clearly.
3. The phone plays the original voice command and starts the
application. If the phone plays an incorrect voice command, press
Retry.
r1024_en.book Page 83 Thursday, July 8, 2004 12:40 PM
Tools
84
Replaying, erasing, or changing a voice command
To replay, erase, or change a voice command, scroll to the item that has
a voice command (indicated by ), select Options, and then either:
•Playback - Listen to the voice command again.
•Delete - Erase the voice command.
•Change - Record a new voice command. Press Start to record.
r1024_en.book Page 84 Thursday, July 8, 2004 12:40 PM
Personalising your phone
85
9. Personalising your phone
■Profiles
Go to Menu→Profiles.
Options in the Profiles main view are: Activate,
Personalise, Create new, Delete profile, Tone downloads, Help, and Exit.
In Profiles, you can adjust and customise the phone tones for different
events, environments, or caller groups. You can see the currently
selected profile at the top of the display in standby mode. If the General
profile is in use, only the current date is shown.
To change the profile, scroll to a profile and select Options→Activate.
To modify a profile, scroll to the profile in the Profiles list and select
Options→Personalise. To create a new profile, select Options→Create
new. A list of profile settings opens. Scroll to the setting you want to
change and press to open the choices:
•Ringing tone - Set the ringing tone for voice calls, choose a ringing
tone from the list. Press any key to stop the sound. If a memory card
is used, tones stored on it have the icon next to the tone name.
Ringing tones use shared memory. See “Shared memory” on page 9.
You can also change ringing tones in Contacts. See “Adding a ringing
tone” on page 38.
•Ringing type - When Ascending is selected, the ringing volume starts
from level one and increases level by level to the set volume level.
•Ringing volume - Set the volume level for the ringing and message
alert tones.
•Message alert tone - Set the tone for messages.
•Chat alert tone - Set the tone for instant messages.
•Vibrating alert - Set the phone to vibrate at incoming voice calls and
messages.
•Keypad tones - Set the volume level for keypad tones.
•Warning tones - The phone sounds a warning tone, for example,
when the battery is running low.
r1024_en.book Page 85 Thursday, July 8, 2004 12:40 PM
Personalising your phone
86
•Alert for - Set the phone to ring only upon calls from phone numbers
that belong to a selected contact group. Phone calls coming from
people outside the selected group have a silent alert. The choices are
All calls or (a list of contact groups, if you have created them).
•Availability - Select Available, Busy, or Not available. See “Presence
settings” on page 43.
•Private message - Key in a message to display your current presence
status. See “Presence settings” on page 43.
■Themes
Go to Menu→Themes.
Options in the Themes main view are: Preview, Apply, Edit, Help,
and Exit.
You can change the look of your phone’s display by activating a theme.
A theme can include the idle screen wallpaper, colour palette, screen
saver, and icons and background image in ’Go to’. Edit a theme for more
detailed personalisation.
When you open Themes you see a list of the available themes. The
currently active theme is indicated by a check mark. Press to see the
themes on the memory card, if you use one.
To preview a theme, scroll to the theme and select Options→Preview to
view the theme. Press to activate the theme. You can activate the
theme without previewing it by selecting Options→Apply from the
main view.
Group together elements from other themes, or images from the Gallery
to personalise themes further.
Editing a theme:
1. Scroll to a theme, select Options→Edit, and select:
•Wallpaper - Select an image from one of the available themes, or
select your own image from the Gallery, to use as a background
image in standby mode.
•Colour palette - Change the colour palette used on the display.
r1024_en.book Page 86 Thursday, July 8, 2004 12:40 PM
Personalising your phone
87
•Screen saver - Select what is shown on the screen saver bar: the
time and date or a text that you have written yourself. The
location and background colour of the screen saver bar changes
in 1-minute intervals. Also, the screen saver changes to indicate
the number of new messages or missed calls. You can set the time
that elapses before the screen saver is activated. See “Phone
settings” on page 88.
•Icons - Select a different icon set from any one of the themes.
All pre-installed themes have the same icon set.
•Image in 'Go to' - Select an image from one of the available
themes, or select your own image from the Gallery, to use as a
background image in Go to.
2. Scroll to the element to be edited and select Options→Change.
3. Select Options→Set to select the current setting. To preview the
selected element, select Options→ Preview. Note that you cannot
preview all elements.
To restore the currently selected theme to its original settings, select
Options→Restore orig. theme when editing a theme.
■Settings
Changing general settings
Go to Menu→Settings
1. Scroll to a setting group and press to open it.
2. Scroll to a setting you want to change and press to:
• switch between options if there are only two (On/Off),
• open a list of options or an editor,
• open a slider view and press or to increase or decrease
the value respectively.
You may be able to receive some settings from your service provider in a
short message. See “Receiving smart messages” on page 64.
r1024_en.book Page 87 Thursday, July 8, 2004 12:40 PM
Personalising your phone
88
Phone settings
Go to Phone settings.
General
•Phone language - Change the language for the display texts in your
phone. This change may also affect the format used for date and
time and the separators used, for example, in calculations. If you
select Automatic, the phone selects the language according to the
information on your SIM card. After you have changed the display
text language, you must restart the phone.
• Changing the settings for Phone language or Writing language
affects every application in your phone and the change remains
effective until you change these settings again.
•Writing language - Change the writing language of your phone.
Changing the language affects:
• the characters available when you press any key -
• the predictive text dictionary used
• the special characters that are available when you press the
and keys.
•Dictionary - Set predictive text input On or Off for all editors in the
phone. Select a language for entering predictive text from the list
available. You can also change this setting when you are in an editor.
Press and select Dictionary→Dictionary on or Off.
•Welcome note or logo - The welcome note or logo is displayed briefly
each time you switch on the phone. Select Default if you want to use
the default image or animation. Select Text to write a welcome note
(max. 50 letters). Select Image to select a photo or picture from the
Gallery.
•Orig. phone settings - Reset some of the settings to their original
values. To do this, you need the lock code. See “Security” on page 94.
After resetting the settings, the phone may take a longer time to
power up. All documents and files that you have created are left as
they are.
r1024_en.book Page 88 Thursday, July 8, 2004 12:40 PM
Personalising your phone
89
Standby mode
•Left selection key and Right selection key - Change the shortcuts that
appear over the left and right selection keys in standby
mode. In addition to the applications, you can have the shortcut
point to a function, for example, New message.
You can only have shortcuts to pre-installed applications and functions.
Display
•Screen saver timeout - The screen saver is activated when the screen
saver time-out period is over. When the screen saver is active, the
display is cleared and you can see the screen saver bar.
• To deactivate the screen saver press any key.
Call settings
Go to Call settings.
Send my caller ID (network service)
• Set your phone number to be displayed (Yes) or hidden (No) from the
person whom you are calling. Or, the value may be set by your
network operator or service provider when you make a subscription.
Call waiting (network service)
• The network notifies you of a new incoming call while you have a call
in progress. Select Activate to request the network to activate call
waiting, Cancel to request the network to deactivate call waiting, or
Check status to check if the function is active or not.
Automatic redial
• When this setting is activated, your phone makes a maximum of ten
attempts to connect the call after an unsuccessful call attempt. Press
to stop automatic redialling.
Summary after call
• Activate this setting if you want the phone to briefly display the
approximate duration of the last call.
r1024_en.book Page 89 Thursday, July 8, 2004 12:40 PM
Personalising your phone
90
Speed dialling
• Select On, and the numbers assigned to the speed-dialling keys (
- ) can be dialled by pressing and holding the key. See
“Assigning speed-dialling keys” on page 39.
Anykey answer
• Select On, and you can answer an incoming call by briefly pressing
any key, except , , and .
Line in use (network service)
• This setting is shown only if the SIM card supports two subscriber
numbers, that is, two phone lines. Select which phone line (Line 1 or
Line 2) you want to use for making calls and sending short messages.
Calls on both lines can be answered irrespective of the selected line.
Note: You cannot make calls if you select Line 2 and have not
subscribed to this network service.
To prevent line selection, select Line change→Disable if supported by
your SIM card. To change this setting, you need the PIN2 code.
Connection settings
Go to Connection settings.
Access points
Here you can see a short explanation for every setting that may be
needed for different data connections and access points. If you have not
yet used your phone to make a WAP connection, you may need to
contact your service provider for assistance with the first-time
connection.
Many service providers require you to use an IAP for your default access
point. Other service providers allow you to use a WAP access point.
Contact your service provider for more information.
Start to fill in the settings from the top since, depending on the data
connection you select (Data bearer), only certain fields are available.
•Connection name - Give a descriptive name for the connection.
•Data bearer - The options are GPRS or Data call. Depending on what
data connection you select, only certain setting fields are available.
r1024_en.book Page 90 Thursday, July 8, 2004 12:40 PM
Personalising your phone
91
Fill in all fields marked with Must be defined, or with an asterisk.
Other fields can be left empty, unless you have been instructed
otherwise by your service provider.
To be able to use a data connection, the network operator or service
provider must support this feature, and if necessary, activate it for your
SIM card
•Access point name (for packet data only) - The access point name is
needed to establish a connection to the GPRS network. You obtain
the access point name from your network operator or service
provider.
•Dial-up number (for data call only) - The modem telephone number
of the access point.
•User name - Write a user name if required by the service provider.
The user name may be needed to make a data connection, and is
usually provided by the service provider. The user name is often case-
sensitive.
•Prompt password - If you must key in a new password every time you
log onto a server, or if you do not want to save your password to the
phone, choose Yes.
•Password - A password may be needed to make a data connection,
and is usually provided by the service provider. The password is often
case-sensitive. When you are writing the password, the characters
you enter are shown briefly and then changed to asterisks (*). The
easiest way to enter numbers is to press and hold the digit you want
to enter, and then continue entering letters.
•Authentication - Normal/Secure.
•Homepage - Depending on what you are setting up, enter either:
• the service address, or
• the address of the multimedia messaging centre.
•Data call type (for data call only) - Analogue, ISDN v.110, or ISDN
v.120 defines whether the phone uses an analogue or digital
connection. This setting depends on both your GSM network
operator and Internet Service Provider (ISP), because some GSM
networks do not support certain types of ISDN connections. For
r1024_en.book Page 91 Thursday, July 8, 2004 12:40 PM
Personalising your phone
92
details, contact your ISP. If ISDN connections are available, they
establish connections more quickly than analogue methods.
•Maximum data speed (for data call only) - The options are
Automatic, 9600, 14400, 19200, 28800, 38400or 43200, depending
on the chosen Data call type. This option allows you to limit the
maximum connection speed when GSM data are used. Higher data
rates may cost more, depending on the service provider.
The speeds above represent the maximum speed at which your
connection operates. During the connection, the operating speed may
be less, depending on network conditions.
Options→ Advanced settings
•Network type – The internet protocol (IP) version of the network.
•Phone IP address - The IP address of your phone.
•Name servers - The IP address of the primary and secondary DNS
servers.
•Proxy serv. address - The IP address of the proxy server.
•Proxy port number - The port number of the proxy server.
To enter these settings, contact your Internet service provider.
The following settings are shown if you have selected data call as the
connection type:
•Use callback - This option allows a server to call you back once you
have made the initial call. Contact your service provider to subscribe
to this service.
The phone expects the callback call to use the same data call settings
that were used in the callback-requesting call. The network must
support that type of call in both directions, to and from the phone.
•Callback type - The options are Use server no./Use other no.. Ask your
service provider for the correct setting to use.
•Callback number - Key in your phone’s data phone number which the
dial-back server uses. Usually, this number is the data-call phone
number of your phone.
•Use PPP compression - When set to Yes, this option speeds up data
transfer, if supported by the remote PPP server. If you have problems
r1024_en.book Page 92 Thursday, July 8, 2004 12:40 PM
Personalising your phone
93
with establishing a connection, try setting this to No. Contact your
service provider for guidance.
•Use login script - The options are Yes/No.
•Login script - Insert the login script.
•Modem initialisation (Modem initialisation string) - Controls your
phone using modem AT commands. If required, enter characters
specified by your service provider or Internet service provider.
GPRS
Go to GPRS.
The GPRS settings affect all access points using a packet data
connection.
GPRS connection - If you select When available and you are in a
network that supports packet data, the phone registers to the GPRS
network and short messages are sent via GPRS. Also, starting an active
packet data connection, for example, to send and receive e-mail, is
quicker. If you select When needed, the phone uses a packet data
connection only if you start an application or action that needs it. The
GPRS connection can be closed when it is not needed by any
application.
If there is no GPRS coverage and you have chosen When available, the
phone periodically tries to establish a packet data connection.
Access point - The access point name is needed when you want to use
your phone as a packet data modem to your computer.
Data call
Go to Data call.
The Data call settings affect all access points that use a GSM data call.
Online time - If there are no actions the data call is dropped
automatically after a time-out period. The options are User defined, in
which case you enter a time, or Unlimited.
Date and time
Go to Date and time.
r1024_en.book Page 93 Thursday, July 8, 2004 12:40 PM
Personalising your phone
94
The Date and time settings allow you to define the date and time used in
your phone, as well as change the date and time format and separators.
•Clock type→Analogue or Digital - To change the clock shown in
standby mode. See “Clock” on page 105.
•Auto time update - To allow the network to update time, date, and
time zone information to your phone (network service). For the Auto
time update setting to take effect, the phone needs to be restarted.
Check any alarms as these may be affected by Auto time update.
•Clock alarm tone - To change the tone played when the clock alarm
time is reached.
•GMT offset - To change the time zone for the clock time.
•Daylight-saving - To turn daylight saving time on or off.
Security
Go to Security.
Phone and SIM
You can change the following codes: lock code, PIN code, and PIN2
code. These codes can only include the numbers from 0 to 9.
Avoid using access codes similar to emergency numbers, such as 112, to
prevent accidental dialling of the emergency number.
PIN code request - When the PIN code request is active, the code is
requested each time the phone is switched on. Note that some SIM
cards may not allow the PIN code request to be deactivated.
PIN code/PIN2 code/Lock code - Open this setting if you want to change
the code.
Autolock period - You can set an autolock period, a time-out after which
the phone is automatically locked and can be used only if the correct
lock code is entered. Key in a number for the time-out in minutes or
select None to turn off the autolock period.
• To unlock the phone, key in the lock code.
Lock if SIM changed - Select Yes if you want the phone to prompt for the
lock code when an unknown, new SIM card is inserted into your phone.
r1024_en.book Page 94 Thursday, July 8, 2004 12:40 PM
Personalising your phone
95
The phone maintains a list of SIM cards that are recognised as the
owner’s cards.
Options in the Fixed dialling view are: Open, Call, Activ. fixed
dialling Deact. fixed dialling, New contact, Edit, Delete, Add to Contacts,
Add from Contacts, Find, Mark/Unmark, Help, and Exit.
Fixed dialling - You can restrict your outgoing calls to selected phone
numbers, if supported by your SIM card. You need the PIN2 code for this
function. When this function is active, you can only call those phone
numbers that are included in the fixed-dialling list or which begin with
the same digit(s) as a phone number on the list.
• Press to set Fixed dialling on.
• To add new numbers to the Fixed dialling list, select Options→New
contact or Add from Contacts.
Closed user group (network service) - You can specify a group of people
whom you can call and who can call you. For more information, contact
your network operator or service provider. Select: Default to activate the
default group agreed on with the network operator, On if you want to
use another group (you need to know the group index number), or Off.
When security features that restrict calls are in use (such as call barring, closed
user group and fixed dialing) calls still may be possible to the official emergency
number programmed into your device.
Confirm SIM services (network service) - To set the phone to display
confirmation messages when you are using a SIM card service.
Certificate management
Options in the certificate management main view are: Certificate
details, Delete, Trust settings, Mark/Unmark, Help, and Exit.
In the certificate management main view, you can see a list of authority
certificates that have been stored in your phone. Press to see a list
of personal certificates, if available.
Authority certificates are used by some browser services, such as
banking services, for checking signatures or server certificates or other
authority certificates.
Server certificates are used to improve security in the connection
between the phone and the gateway. The phone receives the server
r1024_en.book Page 95 Thursday, July 8, 2004 12:40 PM
Personalising your phone
96
certificate from the service provider before the connection is
established and its validity is checked using the authority certificates
saved in the phone. Server certificates are not saved.
Server certificates may be needed when you, for example:
• want to connect to an online bank or another site or remote server
for actions that involve transferring confidential information, or
• want to be sure of the authenticity of software when downloading
and installing software.
Important: Note that even if the use of certificates considerably
reduces the risks involved in remote connections and software
installation, they must be used correctly in order to benefit from
increased security. The existence of a certificate does not offer any
protection by itself; the certificate manager must contain correct,
authentic, or trusted certificates for increased security to be available.
Certificates have a restricted lifetime. If Expired certificate or
Certificate not valid yet is shown even if the certificate should be valid,
check that the current date and time in your device are correct.
Before changing any certificate settings, you must make sure that you
actually trust the owner of the certificate and that the certificate really
belongs to the listed owner.
Changing the trust settings of an authority certificate
• Scroll to an authority certificate and select Options→ Trust settings.
Depending on the certificate, a list of the applications that can use
the selected certificate is shown. For example:
Application manager/Yes - The certificate is able to certify the origin
of new software.
Internet/Yes - The certificate is able to certify e-mail and imaging
servers.
Call barring
Go to Call barring.
Call barring (network service) allows you to restrict the making and
receiving of calls with your phone. For this function, you need the
barring password obtainable from your service provider.
1. Scroll to one of the barring options.
r1024_en.book Page 96 Thursday, July 8, 2004 12:40 PM
Personalising your phone
97
2. Select Options→Activate to request the network to set call
restriction on, Cancel to set the selected call restriction off, or Check
status to check if the calls are barred or not.
• Select Options→Edit barrings passw. to change the barring
password.
• Select Options→Cancel all barrings to cancel all active call barrings.
Call barring and call diverting cannot be active at the same time.
When calls are barred, calls still may be possible to certain official emergency
numbers.
Network
Go to Network.
Operator selection
•Automatic - Set the phone to automatically search for and select
one of the cellular networks available in your area.
•Manual - Select the desired network manually from a list of
networks. If the connection to the manually selected network is lost,
the phone sounds an error tone and asks you to select a network
again. The selected network must have a roaming agreement with
your home network, that is, the operator whose SIM card is in your
phone.
Cell info display
•On - Set the phone to indicate when it is used in a cellular network
based on Micro Cellular Network (MCN) technology and to activate
cell info reception (network service).
Enhancement settings
Go to Enhancement.
Scroll to an enhancement folder and open the settings:
•Default profile - Select the profile you want to activate each time
you connect a certain enhancement to your phone.
•Automatic answer - Set the phone to answer an incoming call
automatically after 5 seconds after you connect this enhancement to
r1024_en.book Page 97 Thursday, July 8, 2004 12:40 PM
Personalising your phone
98
your phone. If the Ringing type is set to Beep once or Silent,
automatic answer cannot be used, and you must answer the phone
manually.
■Go to
Go to Menu→Go to or press Go to in standby mode.
Options in the Go to main view are: Open, Edit shortcut name,
Shortcut icon, Delete shortcut, Move, List view/Grid view, Help, and Exit.
Use Go to for storing shortcuts, links to your favourite photos, video
clips, notes, Recorder sound files, browser bookmarks, and saved
browser pages.
The default shortcuts are: - opens the Notes editor, - opens the
Calendar at the current date, and - opens the Messaging Inbox.
Shortcuts can be added only from pre-installed applications and
functions. Not all applications have this functionality.
Adding and using shortcuts:
1. Open the application and scroll to the item that you want to add as a
shortcut.
2. Select Options→Add to 'Go to' and press OK.
•To open a shortcut, scroll to the icon and press . The file is
opened in the corresponding application.
•To delete a shortcut, scroll to the shortcut that you want to remove
and select Options→Delete shortcut. Removing a shortcut does not
affect the file it is referring to.
•To change the shortcut name, select Options→Edit shortcut name.
Write the new name. This change affects only the shortcut, not the
file or the item that the shortcut refers to.
r1024_en.book Page 98 Thursday, July 8, 2004 12:40 PM
Extras
99
10. Extras
■Wallet
Go to Menu→Extras→Wallet.
Options in the wallet main view are: Open, Settings, Help, and
Exit.
Wallet provides you with a storage area for your personal information,
such as credit and debit card numbers, addresses and other useful data,
for example, user names and passwords.
The information stored in the wallet can be easily retrieved while
browsing to automatically complete online forms on browser pages, for
example, when the service asks for credit card details. Data in the wallet
are encrypted and protected with a wallet code that you define.
You can group wallet data into profiles that can be accessed, for
example, when making purchases online.
Due to the nature of the wallet, it automatically closes after 5 minutes.
Enter the wallet code to regain access to the contents. You can change
this automatic time-out period, if required. See “Wallet settings” on
page 102.
Entering the wallet code
Each time you open the wallet you are prompted for a wallet code.
When you open the wallet for the first time, you must create your own
access code:
1. Enter a code of your choice (4 - 10 alphanumeric characters), and
press OK.
2. You are prompted to verify the code. Enter the same code and press
OK. Do not give your wallet code to anyone else.
3. Enter the code that you have created and press OK.
If you enter the wallet code incorrectly on three consecutive occasions,
the wallet application is blocked for 5 minutes. The block time increases
if further incorrect wallet codes are entered.
r1024_en.book Page 99 Thursday, July 8, 2004 12:40 PM
Extras
100
If you forget your wallet code, you have to reset the code, and you will
lose all information stored in the wallet. See “Resetting the wallet and
wallet code” on page 103.
Storing personal card details
1. Select the Cards category from the main wallet menu and press
.
2. Select a type of card from the list and press .
•Payment cards - Credit and debit cards.
•Loyalty cards - Membership and store cards.
•Online acc. cards - Personal user names and passwords to online
services.
•Address cards - Basic contact details for home/office.
•User info cards - Customised personal preferences for online
services.
3. Select Options→New card. A blank form opens.
4. Fill in the fields and press Done.
You can also receive card information directly to the phone from a card
issuer or service provider (if they offer this service). You are notified
which category the card belongs to. Either save or discard the card. You
can view and rename a saved card, but you cannot edit it.
You can open, edit or delete the fields in the card. Any changes are saved
upon exiting.
Options when viewing or editing card details: Delete, Help, and
Exit.
Creating personal notes
Personal notes are a means of storing sensitive information, for
example, a bank account number. You can access the data in a personal
note from the browser. You can also send a note as a message.
• Select the Personal notes category from the main wallet menu and
press .
• Select Options→New card. A blank note opens.
r1024_en.book Page 100 Thursday, July 8, 2004 12:40 PM
Extras
101
• Press - to start writing. Press to clear
characters. Press Done to save.
Creating a wallet profile
Once you have stored your personal details, you can combine them
together into a wallet profile. Use a wallet profile to retrieve wallet data
from different cards and categories to the browser.
1. Select the Wallet profiles category from the main wallet menu and
press .
2. Select Options→New card. A new wallet profile form opens.
3. Fill in the fields as indicated below and press Done.
Some of the fields must contain data selected from the wallet. Save
the data under the relevant category before creating a wallet profile,
or the profile cannot be created.
•Profile name - Choose and enter a name for the profile.
•Payment card - Select a card from the Payment card category.
•Loyalty card - Select a card from the Loyalty card category.
•Online access card - Select a card from the Online access card
category.
•Shipping address - Select an address from the Address card
category.
•Billing address - By default this is the same as the Shipping
address. If you require a different address, select one from the
Address card category.
•User info card - Select a card from the User info card category.
•Receive e-receipt - Select a destination from the Address card
category.
•Deliver e-receipt - Select To phone, To e-mail, or To pho. & e-mail.
•RFID sending - Set to On or Off. Defines whether or not your
unique phone identification is sent with the wallet profile (for
future development dependent on RFID-based ticketing).
r1024_en.book Page 101 Thursday, July 8, 2004 12:40 PM
Extras
102
Retrieving information from the wallet to your browser
When using online mobile services supporting the wallet functionality,
you can upload the data stored in your wallet to automatically enter
your details into an online form. For example, by uploading your
payment card details you do not need to key in the card number and
expiry date each time you need them (depending on the content being
browsed). Also, you can retrieve your user name and password stored as
an access card when connecting to a mobile service that requires
authentication. See “Purchasing an item” on page 114.
A cache is a memory location that is used to store data temporarily. If you have
tried to access or have accessed confidential information requiring passwords,
empty the cache after each use. The information or services you have accessed is
stored in the cache. To empty the cache, select Menu→Web→Options→
Navigation options→Clear Cache.
Viewing ticket details
Options in the Tickets main view are: View, Delete, Rename,
Mark/Unmark, Help, and Exit.
You can receive notifications of tickets purchased online via the
browser. Received notifications are stored in the wallet. To view the
notifications:
1. Select the Tickets category from the main wallet menu and press
.
2. Select Options→View.
Wallet settings
Select Options→Settings from the main wallet menu:
•Wallet code - Change your wallet code. You are prompted to enter
the current code, create a new code, and verify the new code.
•RFID - Set the phone ID code, type, and sending options (for future
development dependent on RFID-based ticketing).
•Automatic close - Change the automatic time-out period (1 - 60
minutes). After the time-out period has elapsed, the wallet code
must be re-entered to gain access to the contents.
r1024_en.book Page 102 Thursday, July 8, 2004 12:40 PM
Extras
103
Resetting the wallet and wallet code
To reset both the contents of the wallet and the wallet code:
1. Key in *#7370925538# in standby mode.
2. Enter the phone’s lock code, and press OK. See “Security” on page 94.
3. You are asked to confirm the erasing of data. Press OK.
When opening the wallet again, you must enter a new wallet code. See
“Entering the wallet code” on page 99.
■Calculator
Go to Menu→Extras→Calculator.
1. Enter the first number of your calculation. If you make a mistake,
press to erase it.
2. Scroll to an arithmetic function and press to select it.
3. Enter the second number.
4. To execute the calculation, scroll to and press .
Options in Calculator are: Last result, Memory, Clear screen, Help,
and Exit.
Note: This calculator has limited accuracy and is designed for simple
calculations.
• To add a decimal, press .
• Press and hold to clear the result of the previous calculation.
• Use and to view previous calculations and move in the
sheet.
■Converter
Go to Menu→Extras→Converter.
In Converter, you can convert measurement parameters such as Length
from one unit to another, for example, Yards to Metres.
The Converter has limited accuracy and rounding errors may occur.
r1024_en.book Page 103 Thursday, July 8, 2004 12:40 PM
Extras
104
Converting units
Options in Converter: Conversion type, Currency rates (not
applicable to other units), Help, and Exit.
To make currency conversion you must first set the exchange rate. See
“Setting a base currency and exchange rates” on page 104.
1. Scroll to the Type field and press to open a list of measurement
parameters. Scroll to the measurement parameter you want to use
and press OK.
2. Scroll to the first Unit field and press to open a list of available
units. Select the unit from which you want to convert and press OK.
3. Scroll to the next Unit field and select the unit to which you want to
convert.
4. Scroll to the first Amount field and key in the value that you want to
convert. The other Amount field changes automatically to show the
converted value.
Press to add a decimal and press for the +, - (for
temperature), and E (exponent) symbols.
The conversion order changes if you write a value in the second Amount
field. The result is shown in the first Amount field.
Setting a base currency and exchange rates
Before you can carry out currency conversions, you need to choose a
base currency (usually your domestic currency) and add exchange rates.
The rate of the base currency is always 1. The base currency determines
the conversion rates of the other currencies.
1. Select Currency as the measurement parameter type and select
Options→Currency rates. A list of currencies opens and you can see
the current base currency at the top.
2. To change the base currency, scroll to the currency (usually your
domestic currency), and select Options→Set as base curr..
3. Add exchange rates, scroll to the currency, and key in a new rate,
that is, how many units of the currency equal one unit of the base
currency you have selected.
r1024_en.book Page 104 Thursday, July 8, 2004 12:40 PM
Extras
105
4. After you have inserted all the required exchange rates, you can
make currency conversions. See “Converting units” on page 104.
■Notes
Go to Menu→Extras→Notes.
You can link notes to Go to and send them to other devices.
Plain text files (TXT format) you receive can be saved to Notes.
• Press - to start to write. Press to clear letters.
Press Done to save.
■Clock
Go to Menu→Extras→Clock.
Changing clock settings
Options in Clock: Set alarm, Reset alarm, Remove alarm, Settings,
Help, and Exit.
• To change the time or date, select Options→Settings in Clock.
Setting an alarm
1. To set a new alarm, select Options→Set alarm.
2. Enter the alarm time and press OK. When the alarm is active, the
indicator is shown.
• To cancel an alarm, go to Clock and select Options→Remove alarm.
Turning off the alarm
•Press Stop to turn off the alarm.
• Press any key or Snooze to stop the alarm for5 minutes, after which
it resumes. You can do this a maximum of five times.
If the alarm time is reached while the device is switched off, the device switches
itself on and starts sounding the alarm tone. If you press Stop, the device asks
whether you want to activate the device for calls. Press No to switch off the
device or Yes to make and receive calls. Do not press Yes when wireless phone use
may cause interference or danger.
r1024_en.book Page 105 Thursday, July 8, 2004 12:40 PM
Extras
106
Personalising the alarm tone
1. To personalise the alarm tone, select Options→Settings.
2. Scroll to Clock alarm tone and press .
3. When you scroll through the list of tones, you can stop on a tone to
listen to it before you make your selection. Press Select to select the
current tone.
■Recorder
Go to Menu→Extras→Recorder.
The voice recorder allows you to record telephone
conversations and voice memos. If you are recording a telephone
conversation, both parties hear a tone every 5 seconds during recording.
Recorded files are stored in the Gallery. See “Gallery” on page 57.
Options in Recorder are: Record sound clip, Delete, Rename sound
clip, Send, Go to Gallery, Settings, Add to 'Go to', Help, and Exit.
• Select Options→Record sound clip and scroll to a function and press
to select it. Use: - to record, - to pause, - to stop,
- to fast forward, - to rewind, or - to play an opened
sound file.
The recorder cannot be used when a data call or GPRS connection is active.
■Memory card
Go to Menu→Extras→Memory card.
Options in the memory card: Backup phone mem., Restore from
card, Format mem. card, Memory card name, Set password, Change
password, Remove password, Unlock memory card, Memory details,
Help, and Exit.
For details on inserting a memory card into the phone, see the Getting
Started section. You can use it to store your multimedia files such as
video clips and sound files, photos, and messaging data, and to back up
information from your phone’s memory.
Included with your Nokia phone is a Multimedia Memory Card (MMC)
that may contain add-on applications from independent developers.
r1024_en.book Page 106 Thursday, July 8, 2004 12:40 PM
Extras
107
These applications are designed by the developers to be compatible with
your phone.
Use only compatible Multimedia cards (MMC) with this device. The compatible
MMC for your phone is Reduced Size Dual Voltage MultiMediaCard. Other
memory cards, such as Secure Digital (SD) cards, do not fit in the MMC card slot
and are not compatible with this device. Using an incompatible memory card may
damage the memory card as well as the device, and data stored on the
incompatible card may be corrupted.
Details of how you can use the memory card with other features and
applications of your phone are given in the sections describing these
features and applications.
Keep all memory cards out of the reach of small children.
Formatting the memory card
When a memory card is formatted, all data on the card are permanently
lost.
Some memory cards are supplied pre-formatted and others require
formatting. Consult your retailer to find out if you must format the
memory card before you can use it.
• Select Options→ Format mem. card.
Select Yes to confirm. When formatting is complete, key in a name
for the memory card (max. 11 letters or numbers).
Backing up and restoring information
To back up information from your phone’s memory to the memory card,
select Options→ Backup phone mem.
To restore information from the memory card to the phone’s memory,
select Options→ Restore from card.
You can only back up the phone memory and restore it to the same
phone.
Locking the memory card
To set a password to lock your memory card to help prevent
unauthorised use, select Options→ Set password.
r1024_en.book Page 107 Thursday, July 8, 2004 12:40 PM
Extras
108
You are asked to enter and confirm your password. The password can be
up to eight characters long.
The password is stored in your phone and you do not have to enter it
again while you are using the memory card on the same phone. If you
want to use the memory card on another phone, you are asked for the
password.
Unlocking a memory card
If you insert another password-protected memory card into your phone,
you are prompted to enter the password of the card. To unlock the card:
• Select Options→ Unlock memory card.
Once the password is removed, the memory card is unlocked and can be
used on another phone without a password.
Checking memory consumption
You can check the memory consumption of different data groups and
the available memory for installing new applications or software on
your memory card:
• Select Options→Memory details.
■Quickword
Go to Menu→Extras→Quickword.
Quickword allows you to open and view MS Word documents on your
phone.
Note: Quickword is designed to support documents saved in Microsoft
Word 97, 2000, and XP document format (.doc). Note that this
application does not necessarily support all variations or features of the
mentioned file formats.
■Quickpoint
Go to Menu→Extras→Quickpoint.
Quickpoint allows you to:
• view presentations and move between the Outline, Slide, Thumb, and
Notes views,
r1024_en.book Page 108 Thursday, July 8, 2004 12:40 PM
Extras
109
• manage your presentation files: open, browse through the folders on
your phone or memory card, sort files by name, date, size or
extension, view details, delete files, or send files via multimedia, e-
mail, Infrared or Bluetooth connection,
and
• make a presentation via a compatible computer projector.
Note: Quickpoint is designed to support presentations created in
Microsoft Powerpoint 97, 2000, and XP file formats (.ppt). Note that this
application does not necessarily support all variations or features of the
mentioned file formats.
r1024_en.book Page 109 Thursday, July 8, 2004 12:40 PM
Services and Applications
110
11. Services and Applications
■Web (Mobile browser)
Go to Menu→Web or press and hold in standby
mode.
Various service providers maintain pages specifically designed for
mobile phones, offering services that can be, for example, news,
weather reports, banking, travel information, entertainment, and
games. With the mobile browser, you can view these services as WAP
pages written in HTML, WML, and XHTML pages written in XHTML, or a
mixture of WML and XHTML. If you have not yet used your phone to
make a WAP connection, you may need to contact your service provider
for assistance with the first-time connection.
Check the availability of services, pricing, and tariffs with your network
operator and/or service provider. Service providers also give you
instructions on how to use their services.
Basic steps for accessing
• Save the settings that are needed to access the browser service that
you want to use. See “Setting up the phone for the browser service”
on page 110.
• Make a connection to the service. See “Making a connection” on
page 111.
• Start browsing the web pages. See “Browsing” on page 112.
• End the connection to the service. See “Ending a connection” on
page 115.
Setting up the phone for the browser service
Receiving settings in a smart message
You may receive service settings in a special text message, a so-called
smart message, from the network operator or service provider that
offers the service. See “Receiving smart messages” on page 64. For more
information, contact your network operator or service provider.
r1024_en.book Page 110 Thursday, July 8, 2004 12:40 PM
Services and Applications
111
Keying in the settings manually
Follow the instructions given to you by your service provider.
1. Go to Menu→Settings→Connection→Access points and define the
settings for an access point. See “Connection settings” on page 90.
2. Go to Menu→ Web→Options→Bookmark manager→Add
bookmark. Write a name for the bookmark and the address of the
browser page defined for the current access point.
Making a connection
Once you have stored all the required connection settings, you can
access browser pages.
There are three different ways to access browser pages:
• Select the homepage ( ) of your service provider.
• Select a bookmark from the Bookmarks view.
• Press the keys - to start to write the address of a
browser service. The Go to field at the bottom of the display is
immediately activated and you can continue writing the address
there.
After you have selected a page or written the address, press to
start to download the page.
Viewing bookmarks
Your device may have some bookmarks loaded for sites not affiliated with Nokia.
Nokia does not guarantee or endorse these sites. If you choose to access them,
you should take the same precautions, for security or content, as you would with
any Internet site.
Options in the Bookmarks view (when a bookmark or folder is
selected): Open, Download, Back to page, Bookmark manager, Mark/
Unmark, Navigation options, Advanced options, Send, Find bookmark,
Details, Settings, Help, and Exit.
In the Bookmarks view, you can see bookmarks pointing to different
kinds of browser pages. Bookmarks are indicated by the following icons:
r1024_en.book Page 111 Thursday, July 8, 2004 12:40 PM
Services and Applications
112
- The starting page defined for the browser access point. If you use
another browser access point for browsing, the starting page is changed
accordingly.
- The last visited page. When the phone is disconnected from the
service, the address of the last visited page is kept in memory until a
new page is visited during the next connection.
When you scroll through bookmarks, you can see the address of the
highlighted bookmark in the Go to field at the bottom of the display.
- A bookmark showing the title.
Adding bookmarks manually
1. In the Bookmarks view, select Options→Bookmark manager→ Add
bookmark.
2. Start to fill in the fields. Only the address must be defined. The
default access point is assigned to the bookmark if no other one is
selected. Press to enter special characters such as /, ., :, and
@. Press to clear characters.
3. Select Options→Save to save the bookmark.
Browsing
On a browser page, new links appear underlined in blue and previously
visited links in purple. Images that act as links have a blue border around
them.
Options when browsing: Open, Service options, Bookmarks, Save
as bookmark, View image, Navigation options, Advanced options, Send
bookmark, Find, Details, Settings, Help, and Exit.
Keys and commands used in browsing
• To open a link, press .
• To scroll the view, use the scroll key.
• To enter letters and numbers in a field, press the keys - .
Press to enter special characters such as /, ., :, and @. Press
to clear characters.
• To go to the previous page while browsing, press Back. If Back is not
available, select Options→Navigation options→History to view a
r1024_en.book Page 112 Thursday, July 8, 2004 12:40 PM
Services and Applications
113
chronological list of the pages you have visited during a browsing
session. The history list is cleared each time a session is closed.
• To check boxes and make selections, press .
• To retrieve the latest content from the server, select
Options→Navigation options→Reload.
• To open a sub-list of commands or actions for the currently open
browser page, select Options→Service options.
• To disconnect from a browser service and to quit browsing, press and
hold .
Saving bookmarks
• To save a bookmark while browsing, select Options→Save as
bookmark.
• To save a bookmark received in a smart message, open the message
in the Inbox in Messaging and select Options→Save to bookmarks.
See “Receiving smart messages” on page 64.
Viewing saved pages
Options in the Saved pages view are: Open, Back to page, Reload,
Saved pages, Mark/Unmark, Navigation options, Advanced options,
Details, Settings, Help, and Exit.
If you regularly browse pages containing information which doesn’t
change very often, you can save and then browse them when offline.
• To save a page, while browsing select Options→Advanced
options→Save page.
Saved pages are indicated by the following icon:
- The saved browser page.
In the saved pages view you can also create folders to store your
saved browser pages.
Folders are indicated by the following icon:
- Folder containing saved browser pages.
To open the Saved pages view, press in the Bookmarks view. In the
Saved pages view, press to open a saved page.
r1024_en.book Page 113 Thursday, July 8, 2004 12:40 PM
Services and Applications
114
To start a connection to the browser service and to retrieve the page
again, select Options→Navigation options→Reload.
The phone stays online after you reload the page.
A cache is a memory location that is used to store data temporarily. If you have
tried to access or have accessed confidential information requiring passwords,
empty the cache after each use. The information or services you have accessed is
stored in the cache. To empty the cache, select Menu→ Web→Options→
Navigation options→Clear Cache.
Downloading
You can download items such as ringing tones, images, operator logos,
software, and video clips using the mobile browser. These items can be
provided free or you can purchase them.
Once downloaded, items are handled by the respective applications on
your phone, for example, a downloaded photo is saved in the Gallery.
Important: Only install and use applications and other software from
sources that offer adequate security and protection against harmful
software.
Purchasing an item
To download the item:
1. Scroll to the link and select Options→Open.
2. Choose the appropriate option to purchase the item, for example,
Buy.
Carefully read all the information provided.
If the online content is compatible, you can use your wallet information
to make the purchase:
1. Select Open wallet. You are prompted for your wallet code. See
“Entering the wallet code” on page 99.
2. Select the appropriate card category from your wallet.
3. Select Fill in. This uploads the selected wallet information.
If the wallet does not contain all information necessary for the
purchase, you are requested to enter the remaining details manually.
r1024_en.book Page 114 Thursday, July 8, 2004 12:40 PM
Services and Applications
115
Copyright protection may prevent some images, ringing tones, and other content
from being copied, modified, transferred or forwarded.
Checking an item before downloading
You can see details about an item before you download it. Details about
an item may include the price, a brief description and size.
• Scroll to the link and select Options→Open.
Details about the item are displayed on your phone.
• If you want to continue with the downloading, press Accept, or if you
want to cancel the download, press Cancel.
Ending a connection
• Select Options→Advanced options→Disconnect, or
• Press and hold to quit browsing and to return to standby
mode.
Browser settings
Select Options→Settings:
•Default access point - To change the default access point, press
to open a list of available access points. The current default access
point is highlighted. See “Connection settings” on page 90.
•Show images - Choose whether to view pictures when you are
browsing. If you choose No, you can later load images during
browsing by selecting Options→Show images.
•Text wrapping - Choose Off if you do not want the text in a
paragraph to automatically wrap, or On if you do. If text is not
wrapped, the ends of lines may be truncated.
•Font size - You can choose five text sizes in the browser: Smallest,
Small, Normal, Large, and Largest.
•Default encoding - To make sure your browser pages display text
characters correctly, select the appropriate language type.
•Cookies - Allow/Reject. You can enable or disable the receiving and
sending of cookies (a means for content providers to identify users
and their preferences for frequently used content).
r1024_en.book Page 115 Thursday, July 8, 2004 12:40 PM
Services and Applications
116
•Security warnings - Choose to hide or show security notifications.
•Conf. DTMF sending - Always/First time only. Choose whether you
want to confirm before the phone sends DTMF tones during a voice
call. See “Options during a call” on page 24. For example, you can
make a voice call while you are viewing a browser page, send DTMF
tones while a voice call is in progress, and save a name and phone
number from a browser page into Contacts.
•Wallet - Choose On to open the wallet automatically when a
compatible browser page is opened.
■Applications
Go to Menu→Manager.
You can install new compatible Symbian operating system applications
(SIS files) and Java™ applications (Java MIDlets and MIDlet suites) on
your phone. You can also update and uninstall applications from the
phone, and monitor the installation history.
Your phone supports J2ME™Java applications. Do not download
PersonalJava™ applications to your phone as they cannot be installed.
Options in the Application manager main view are: Install, View
details, View certificate, Update, Go to web address, Remove, View log,
Send log, Settings, App. downloads, Help, and Exit.
Applications in the Application manager use shared memory. See
“Shared memory” on page 9.
When you open the Application manager, you can see a list of:
• Applications saved in the Application manager.
• Partially installed applications (indicated by ).
• Fully installed applications that you can remove (indicated by ).
You can only use Symbian operating system applications with a .SIS
extension.
r1024_en.book Page 116 Thursday, July 8, 2004 12:40 PM
Services and Applications
117
Downloading an application
Your phone supports J2METM Java applications. Make sure that the
application is compatible with your phone before downloading it. You
can download new Java applications in different ways:
•Go to Menu→Manager→App. downloads and the list of available
bookmarks is shown.
Select the appropriate bookmark to connect to the desired page. If
the connection fails, you may not be able to access the page from the
service whose connection settings are currently active. In this case,
enter the Web menu and activate another set of service settings. See
“Making a connection” on page 111. Try again to connect to the
page.
For the availability of different services, pricing and tariffs, contact
your network operator and/or the service provider.
•Go to Menu→Web→Download. Select to download an appropriate
application or game.
• Use the Nokia Application installer from PC Suite to download the
applications to your phone.
Important: Only install and use applications and other software from
sources that offer adequate security and protection against harmful
software.
• Note that when downloading an application, it may be saved in the
Games menu instead of the Web menu.
Installing an application
You can install applications that are specifically intended for this phone
and suitable for the Symbian operating system.
If you install an application that is not intended specifically for this
phone, it may function and look different from what was originally
intended.
• Open the Application manager, scroll to the application, and select
Options→Install to start the installation.
• Alternatively, search the phone memory or the memory card, select
the application, and press to start the installation.
r1024_en.book Page 117 Thursday, July 8, 2004 12:40 PM
Services and Applications
118
Applications may be downloaded to your phone during browsing,
received as attachments in multimedia messages or e-mails, or received
via infrared or Bluetooth technology from another device, for example, a
phone or a compatible PC.
Important: Use only services that you trust and that offer adequate
security and protection against harmful software.
To increase protection, the application installation system uses digital
signatures and certificates for applications. Do not install the
application if the Application manager gives a security warning during
installation.
If you install an application that contains an update or repair to an
existing application, you can only restore the original application if you
have the original application or a full backup copy of the removed
application. To restore the original application, first remove the updated
or repaired application and then re-install it from the original
application or the backup copy.
During installation, the phone checks the integrity of the application to
be installed. The phone shows information about the checks being
carried out and you are given options whether to continue or cancel the
installation. Once the phone has checked the integrity of the
application, it is installed on your phone.
Installing a Java™application
The .JAR file is required for installation. If it is missing, the phone may
ask you to download it. If there is no access point defined for the
Application manager, you are asked to select one. When downloading
the .JAR file, you may need to enter a user name and password to access
the server. You obtain these from the supplier or manufacturer of the
application.
• To start a data connection and to view extra information about the
application, scroll to it and select Options→Go to web address.
• To start a data connection and to check if there is an update
available for the application, scroll to it and select Options→Update.
r1024_en.book Page 118 Thursday, July 8, 2004 12:40 PM
Services and Applications
119
Java settings
• To change the default access point that a Java application uses for
downloading extra data, select Options→Settings→Access point.
See “Access points” on page 90.
• To change the security settings that determine the actions that a
Java application is permitted to perform, select Options→Settings.
Not all Java applications permit you to change the security settings.
Launching an application
1. Go to Menu→Web→Applications→Select application:.
2. Scroll to an application or an application set (the name depends on
the application).
3. Press Options and select Open or press . If the selection is a
single application it is launched.
Otherwise, a list of applications in the selected application set is
displayed. To launch a single application, scroll to the desired
application and press Options and select Open, or press .
Note that running some applications may consume the phone’s battery
faster (and you may need to connect the phone to the charger).
Other options available for an application or application set
•Delete - Delete the application or application set from the phone.
•Application access - Restrict the application from accessing the
network. Select Ask first and the phone asks for net access, Always
allowed to allow the net access, or Not allowed not to allow the net
access.
•Update - Check if a new version of the application is available for
download from the services (network service).
•Go to web address - Provide further information or additional data
for the application from an Internet page. This feature needs to be
supported by the network. It is only shown if an Internet address has
been provided with the application.
•Details - Give additional information about the application.
r1024_en.book Page 119 Thursday, July 8, 2004 12:40 PM
Services and Applications
120
Memory status for applications
Go to Menu→Extras→Memory.
This shows the amount of memory available for game and application
installations.
The applications use shared memory. See “Shared memory” on page 9.
Removing an application
1. To remove an application, scroll to it and select Options→Remove.
2. Press Yes to confirm the removal.
If you remove an application, you can only re-install it if you have the
original application or a full backup of the removed application. If you
remove an application, you may no longer be able to open documents
created with that application. If another application depends on the
application that you removed, the other application may stop working.
Refer to the documentation of the installed application for details.
■Games
Go to Menu→Games.
To start a game, scroll to the game icon and press . For instructions
on how to play the game, select Options→Help.
r1024_en.book Page 120 Thursday, July 8, 2004 12:40 PM
Connectivity
121
12. Connectivity
■Bluetooth connection
Go to Menu→Connectivity→Bluetooth.
This device is compliant with Bluetooth wireless
technology Specification 1.1 supporting the fol-
lowing profiles: Hands-free, Object Push Profile,
File Transfer Profile, HID (Human Interface Device)
Profile, Dial Up Networking Profile and Fax Profile.
To ensure interoperability between other devices
supporting Bluetooth wireless technology, use
Nokia approved enhancements for this model.
Check with the manufacturers of other devices to
determine their compatibility with this device.
There may be restrictions on using Bluetooth
technology in some locations. Check with your
local authorities or service provider.
Features using Bluetooth wireless technology, or allowing such features to run in
the background while using other features, increase the demand on battery
power and reduces the battery life.
Bluetooth technology enables wireless connections between electronic
devices within a maximum range of 10 metres. A Bluetooth connection
can be used to send images, videos, texts, business cards, calendar
notes, or to connect wirelessly to compatible devices using Bluetooth
technology, such as computers. Please note that not all computers using
Bluetooth technology are necessarily compatible.
Since devices using Bluetooth technology communicate using radio
waves, your phone and the other devices do not need to be in direct
line-of-sight. The two devices only need to be within a maximum of 10
metres of each other, although the connection can be subject to
interference from obstructions such as walls or from other electronic
devices. Using Bluetooth technology consumes the battery and the
phone's operating time is reduced. Take this into account when
performing other operations with your phone. There may be restrictions
on using devices using Bluetooth technology. Check with your local
authorities.
r1024_en.book Page 121 Thursday, July 8, 2004 12:40 PM
Connectivity
122
When you activate Bluetooth technology for the first time, you are
asked to give a name to your phone.
Bluetooth connection settings
•Bluetooth - On/Off.
•My phone's visibility - Shown to all - Your phone can be found by
other Bluetooth devices or Hidden - Your phone cannot be found by
other devices. For security reasons it is advisable to use the hidden
mode whenever possible.
•My phone's name - Define a name for your phone.
After you have set the Bluetooth connection as active and changed My
phone's visibility to Shown to all, your phone and this name can be seen
by other Bluetooth device users.
Sending data via Bluetooth technology
There can be only one active Bluetooth connection at a time.
1. Open an application where the item you wish to send is stored. For
example, to send a photo to another device, open the Gallery
application.
2. Scroll to the item you want to send and select Options→Send→Via
Bluetooth.
3. The phone starts to search for devices within range. Devices using
Bluetooth technology that are within range start to appear on the
display one by one. You can see a device icon, the device’s name, the
device type, or a short name. Paired devices are shown with . A
paired device is one where a Bluetooth connection already exists
between your phone and the other device.
• To interrupt the search, press Stop. The device list freezes and you
can start to form a connection to one of the devices already
found.
4. When searching for devices, some devices may show only the unique
device addresses. To find out the unique address of your phone, enter
the code *#2820# in standby mode when the Bluetooth connection
is active.
r1024_en.book Page 122 Thursday, July 8, 2004 12:40 PM
Connectivity
123
If you have searched for devices earlier, a list of the devices that were
found previously is shown first. To start a new search, select More
devices. If you switch off the phone, the list of devices is cleared and
the device search needs to be started again before sending data.
5. Scroll to the device you want to connect with and press Select. The
item you are sending is copied to Outbox and the note Connecting is
shown.
6. Pairing (if not required by the other device, go to step 7.)
• If the other device requires pairing before data can be
transmitted, a tone sounds and you are asked to enter a passcode.
• Create your own passcode (1-16 characters long, numeric) and
agree with the owner of the other device to use the same code.
This passcode is used only once and you do not have to memorise
it.
• After pairing, the device is saved to the Paired devices view.
7. When the connection has been successfully established, the note
Sending data is shown.
Data received via Bluetooth connection can be found in the Inbox folder
in Messaging. See "Inbox - receiving messages".
Icons for different devices: - Computer, - Phone, - Audio/
video, and - Bluetooth device.
If sending fails, the message isor data are deleted. The Drafts folder in
Messaging does not store messages sent via Bluetooth connection.
Checking the status of the Bluetooth connection
• When is shown in standby mode, the Bluetooth connection is
active.
• When is blinking, your phone is trying to connect to the other
device.
• When is shown continuously, the Bluetooth connection is active.
r1024_en.book Page 123 Thursday, July 8, 2004 12:40 PM
Connectivity
124
Paired devices view
Paired devices are easier to recognise, they are indicated by in the
search result list. In the Bluetooth main view, press to open a list of
paired devices ( ).
•To pair with a device: Select Options→New paired device. The
phone starts a device search. Scroll to the device you want to pair
with and press Select. Exchange passcodes. The device is added to
the Paired devices list.
•To cancel pairing: Scroll to the device whose pairing you want to
cancel and press or select Options→Delete. If you want to
cancel all pairings, select Options→Delete all.
If you are currently connected to a device, and delete the pairing
with that device, the pairing is removed and the device connection is
terminated, but Bluetooth connection remains active on the
handset.
•To set a device to be authorised or unauthorised: Scroll to the
device and select Options→Set as authorised - Connections
between your phone and this device can be made without your
knowledge. No separate acceptance or authorisation is needed. Use
this status only for your own devices that others do not have access
to, for example your PC, or devices that belong to someone you trust.
The icon is added next to authorised devices in the Paired devices
view. Set as unauthorised - Connection requests from this device
need to be accepted separately every time.
Receiving data via Bluetooth wireless technology
When you receive data via Bluetooth wireless technology, a tone sound
is played and you are asked if you want to accept the message. If you
accept, the item is placed in the Inbox folder in Messaging. Messages
received via Bluetooth technology are indicated by . See “Inbox -
receiving messages” on page 63.
Disconnecting Bluetooth connection
A Bluetooth connection is disconnected automatically after sending or
receiving data.
r1024_en.book Page 124 Thursday, July 8, 2004 12:40 PM
Connectivity
125
■Infrared connection
Go to Menu→Connectivity→Infrared.
Via infrared, you can send or receive data such as business cards and
calendar notes to and from a compatible phone or data device.
Do not point the IR (infrared) beam at anyone's eye or allow it to interfere with
other IR devices. This device is a Class 1 laser product.
Sending and receiving data via infrared
1. Make sure that the infrared ports of the sending and receiving
devices are pointing at each other and that there are no obstructions
between the devices. The preferable distance between the two
devices is 1 metre at most. See “Keys and connectors” on page 16.
2. The user of the receiving device activates the infrared port.
To activate the infrared port of your phone to receive data via
infrared, go to Menu→Connectivity→Infrared.
3. The user of the sending device selects the desired infrared function
to start data transfer.
To send data via infrared, select Options→Send→Via infrared in an
application.
If data transfer is not started within 1 minute after the activation of
the infrared port, the connection is cancelled and must be started
again.
All items that are received via infrared are placed in the Inbox folder in
Messaging. New infrared message are indicated by .
Tip: Microsoft Windows 2000: To be able to use infrared to
transfer files between your phone and a compatible computer,
go to Control Panel and select Wireless Link. In the Wireless Link
File Transfer tab, check the Allow others to send files to your
computer using infrared. After transferring the files, it is
advisable to change back the default settings to prevent
unauthorized file transfer.
Checking the status of the infrared connection
• When blinks, your phone is trying to connect to the other device
or a connection has been lost.
r1024_en.book Page 125 Thursday, July 8, 2004 12:40 PM
Connectivity
126
• When is shown continuously, the infrared connection is active
and your phone is ready to send and receive data via its infrared port.
■VPN
Virtual Private Network (VPN) connections allow you to create
encrypted connections over unsecured networks like the Internet. VPN
connections require VPN policies, which define how network
transactions are protected, and an Internet access point.
A virtual private network connection provides privacy, integrity, and
nonrepudiation of data, as well as authentication and authorisation for
access to networks and network services.
System administrators provide VPN policies.
■Connection manager
Go to Menu→Connectivity→Connection manager.
In the Connection manager, you can identify the status of
multiple data connections, view details on the amount of data sent and
received, and end unused connections.
You can view details of data connections only. Voice calls are not listed.
When you open the Connection manager, you can see a list of:
• Open data connections, - Data call, - GPRS.
• The status of each connection.
• Amount of data uploaded and downloaded for each connection
(GPRS connections only).
• The duration of each connection (Data call connections only).
Note: The actual time invoiced for calls by your service provider may
vary, depending on network features, rounding off for billing, and so
forth.
Options in the Connection manager main view when there are one
or more connections are: Details, Disconnect, Disconnect all, Help and
Exit.
r1024_en.book Page 126 Thursday, July 8, 2004 12:40 PM
Connectivity
127
Viewing connection details
To view the details of a connection, scroll to a connection and select
Options→Details. The following is displayed:
•Name - The name of the Internet Access Point (IAP) in use.
•Bearer - The type of data connection: Data call or GPRS.
•Status - The current status of the connection.
•Received - The amount of data, in bytes, received to the phone.
•Sent - The amount of data, in bytes, sent from the phone.
•Duration - The length of time that the connection has been open.
•Speed - The current speed of both sending and receiving data in kB/s
(kilobytes per second).
•Dial-up (GSM) - The dial-up number used, or Name (GPRS) - access
point name used.
•Shared (not displayed if the connection is not shared) - The number
of applications using the same connection.
Ending connections
• Scroll to a connection and select Options→Disconnect to end that
connection only.
• Select Options→Disconnect all to close all currently open
connections.
■Connecting your phone to a compatible
computer
For further information on how to make a connection to a compatible
computer via USB, infrared or Bluetooth technology, and how to install
Nokia PC Suite 6.1, see the Quick Guide for Nokia PC Suite on the CD-
ROM. For further information on how to use Nokia PC Suite, see the help
function on PC Suite or visit the support pages at www.nokia.com.
■Using your phone as a modem
Go to Menu→Connectivity→Modem.
r1024_en.book Page 127 Thursday, July 8, 2004 12:40 PM
Connectivity
128
Use your phone as a modem to connect to the Internet with a
compatible PC, or to send and receive faxes.
Detailed installation instructions can be found in Quick guide for
Modem Options for Nokia 6260 on the CD-ROM supplied with the
phone.
■Remote synchronisation
Go to Menu→Connectivity→Sync.
The Sync application enables you to synchronise your calendar or
contacts with various calendar and address book applications on a
compatible computer or on the Internet. Synchronisation takes place
over a GSM data call or packet data connection.
The synchronisation application uses SyncML technology for
synchronisation. For information on SyncML compatibility, contact the
supplier of the calendar or address book application you want to
synchronise your phone data with.
Creating a new synchronisation profile
Options in the Remote sync main view are: Synchronise, New
sync profile, Edit sync profile, Delete, View log, Help, and Exit.
1. If no profiles have been defined, the phone asks you if you want to
create a new profile. Select Yes.
To create a new profile in addition to existing ones, select
Options→New sync profile. Choose whether you want to use the
default setting values or copy the values from an existing profile to
be used as the basis for the new profile.
2. Define the following:
Sync profile name - Write a descriptive name for the profile.
Access point - Select an access point you want to use for the data
connection.
Host address - Contact your service provider or system administrator
for the correct values.
Port - Contact your service provider or system administrator for the
correct values.
r1024_en.book Page 128 Thursday, July 8, 2004 12:40 PM
Connectivity
129
User name - Your user ID for the synchronisation server. Contact
your service provider or system administrator for your correct ID.
Password - Write your password. Contact your service provider or
system administrator for the correct value.
Press and select the application that you wish to synchronise.
The available applications that you can synchronise may vary.
Contact your service provider for more information.
3. Press Done to save the settings.
Synchronising data
In the Sync main view, you can see the different profiles, and what kind
of data are synchronised: Calendar, Contacts, or both.
1. In the main view, scroll to a profile and select
Options→Synchronise. The status of the synchronisation is shown at
the bottom of the screen.
To cancel synchronisation before it is finished, press Cancel.
2. You are notified when the synchronisation has been completed.
• After synchronisation is complete, select Options→View log to open
a log file showing the synchronisation status (Complete or
Incomplete) and how many calendar or contact entries have been
added, updated, deleted, or discarded (not synchronised) in the
phone or on the server.
r1024_en.book Page 129 Thursday, July 8, 2004 12:40 PM
Troubleshooting
130
13. Troubleshooting
Memory low
When the following notes are shown, the phone memory is low and you
must start to delete some data: Not enough memory to perform
operation. Delete some data first. or Memory low. Delete some data. To
view what kind of data you have and how much memory the different
data groups consume, go to File manager and select Options→Memory
details.
You may want to delete the following items regularly to avoid
memory getting low:
• Messages from the Inbox, Drafts, and Sent folders in Messaging.
• Retrieved e-mail messages from the phone memory.
• Saved browser pages.
• Images and photos in Images.
To delete contact information, calendar notes, call timers, call cost
timers, game scores, or any other data, go to the respective application
to remove the data.
If you are deleting multiple items and another of the following notes are
shown: Not enough memory to perform operation. Delete some data
first. or Memory low. Delete some data. try deleting items one by one
(starting from the smallest item).
Clearing the calendar memory - To remove more than one event at a
time, go to the Month view and select Options→Delete entry→ and
either:
•Before date - to delete all calendar notes which take place before a
certain date. Enter the date before which all calendar notes are
deleted.
or
•All entries - to delete all calendar notes.
Erasing log information - To erase all the log contents, Recent calls
register, and Messaging delivery reports permanently, go to Logs and
select Options→Clear log or go to Settings→Log duration→No log.
r1024_en.book Page 130 Thursday, July 8, 2004 12:40 PM
Troubleshooting
131
Different ways to store data:
• Use Nokia PC Suite 6.1 to make a backup copy of all data to a
compatible computer.
• Send images to your e-mail address and then save the images to your
computer (network service).
• Send data via infrared or Bluetooth technology to a compatible
device.
• Store data on a compatible memory card.
■Q&A
Phone display
• Q. Why do missing, discoloured or bright dots appear on the screen
every time I turn on my phone?
A. This is a characteristic of this type of display. Some displays may
contain pixels or dots that remain on or off. This is normal, not a
fault.
Camera
• Q: Why do images look smudgy?
A: Check that the camera lens protection window is clean.
Bluetooth
• Q: Why can’t I end a Bluetooth connection?
A: If another device is connected to your phone, you can either end
the connection using the other device or by deactivating Bluetooth.
Go to Bluetooth and select the setting Bluetooth→Off.
• Q: Why can’t I find my friend’s Bluetooth-enabled device.
A: Check that both you and your friend have activated Bluetooth.
Check that the distance between the two devices is not over 10
metres or that there are no walls or other obstructions between the
devices.
Check that the other device is not in ‘Hidden’ mode.
Check that both devices are compatible.
r1024_en.book Page 131 Thursday, July 8, 2004 12:40 PM
Troubleshooting
132
Multimedia messaging
• Q: What should I do when the phone tells me that it cannot receive a
multimedia message because the memory is full?
A: The amount of memory needed is indicated in the error message:
Not enough memory to retrieve message. Delete some data first. To
view what kind of data you have and how much memory the
different data groups consume, go to File manager and select
Options→Memory details.
• Q: How can I end the data connection when the phone starts a data
connection again and again? The brief notes on the display state that
the phone is retrieving or trying to retrieve a message. What is
happening?
A: The phone is trying to retrieve a multimedia message from the
multimedia messaging centre.
Check that the settings for multimedia messaging have been defined
correctly and that there are no mistakes in phone numbers or
addresses. Go to Messaging and select
Options→Settings→Multimedia message.
To stop the phone from making a data connection, you have the
following options. Go to Messaging and select
Options→Settings→Multimedia message, and then:
• Select On receiving msg.→Defer retrieval if you want the
multimedia messaging centre to save the message to be retrieved
later, for example, after you have checked the settings. After this
change, the phone still needs to send information notes to the
network. To retrieve the message later, select Retr. immediately.
• Select On receiving msg.→Reject message - if you want to reject
all incoming multimedia messages. After this change, the phone
needs to send information notes to the network and the
multimedia-messaging centre deletes all multimedia messages
that are waiting to be sent to you.
• Select Multimedia reception→Off - if you want to ignore all
incoming multimedia messages. After this change, the phone will
not make any network connections related to multimedia
messaging.
r1024_en.book Page 132 Thursday, July 8, 2004 12:40 PM
Troubleshooting
133
Messaging
• Q: Why can’t I select a contact?
A: If you cannot select a contact in the Contacts directory, the
contact card does not have a phone number or an e-mail address.
Add the missing information to the contact card in the Contacts
application.
Calendar
• Q: Why are the week numbers missing?
A: If you have changed the Calendar settings so that the week starts
on a day other than Monday, then the week numbers are not shown.
Browser Services
•Q: No valid access point defined. Define one in Web settings.
A: Insert proper browser settings. Contact your service provider for
instructions.
Log
• Q: Why does the log appear to be empty?
A: You may have activated a filter, and no communication events
fitting that filter have been logged. To see all events, select
Options→Filter→All communication.
PC connectivity
• Q: Why do I have problems in connecting the phone to my PC?
A: Make sure that Nokia PC Suite 6.2 is installed and running on your
PC. See the Quick Guide for Nokia PC Suite on the CD-ROM. For
further information on how to use Nokia PC Suite, see the help
function on PC Suite or visit the support pages at www.nokia.com.
Access codes
• Q: What is my password for the lock, PIN, or PUK codes?
A: The default lock code is 12345. If you forget or lose the lock code,
contact your phone dealer.
If you forget or lose a PIN or PUK code, or if you have not received
such a code, contact your network service provider.
r1024_en.book Page 133 Thursday, July 8, 2004 12:40 PM
Troubleshooting
134
For information about passwords, contact your access point provider,
for example, a commercial Internet Service Provider (ISP), service
provider, or network operator.
Application not responding
• Q: How do I close an application that is not responding?
A: Open the application switching window by pressing and holding
. Then scroll to the application, and press to close the
application.
r1024_en.book Page 134 Thursday, July 8, 2004 12:40 PM
Battery information
135
14. Battery information
Your device is powered by a rechargeable battery. The full performance
of a new battery is achieved only after two or three complete charge
and discharge cycles. The battery can be charged and discharged
hundreds of times but it will eventually wear out. When the talk and
standby times are noticeably shorter than normal, buy a new battery.
Use only Nokia-approved batteries, and recharge your battery only with
Nokia-approved chargers designated for this device.
Unplug the charger from the electrical plug and the device when not in
use. Do not leave the battery connected to a charger. Overcharging may
shorten its lifetime. If left unused, a fully charged battery loses its
charge over time. Temperature extremes can affect the ability of your
battery to charge.
Always switch the device off and disconnect the charger before
removing the battery.
Check the model number of any charger before use with this device. This
device is intended for use when supplied with power from AC-1, ACP-7,
ACP-8, ACP-9, ACP-12, LCH-8, LCH-9, or LCH-12 chargers.
To prolong the battery life of NiMh batteries, discharge the battery from
time to time by leaving your device switched on until it turns itself off.
Do not attempt to discharge the battery by any other means.
Use the battery only for its intended purpose. Never use any charger or
battery that is damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur
when a metallic object such as a coin, clip, or pen causes direct
connection of the positive (+) and negative (-) terminals of the battery.
(These look like metal strips on the battery.) This might happen, for
example, when you carry a spare battery in your pocket or purse. Short-
circuiting the terminals may damage the battery or the connecting
object.
Leaving the battery in hot or cold places, such as in a closed car in
summer or winter conditions, reduces the capacity and lifetime of the
battery. Always try to keep the battery between 15°C and 25°C (59°F
r1024_en.book Page 135 Thursday, July 8, 2004 12:40 PM
Battery information
136
and 77°F). A device with a hot or cold battery may not work temporarily,
even when the battery is fully charged. Battery performance is
particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire! Dispose of batteries according to
local regulations. Recycle when possible. Do not dispose as household
waste.
Warning: Use only batteries, chargers, and enhancements
approved by Nokia for use with this particular model. The use of
any other types may invalidate any approval or warranty, and
may be dangerous.
For availability of approved enhancements, check with your dealer.
When you disconnect the power cord of any enhancement, grasp and
pull the plug, not the cord.
Your device and its enhancements may contain small parts. Keep them
out of reach of small children.
A few practical rules about accessories and enhancements.
• Keep all accessories and enhancements out of the reach of small
children.
• When you disconnect the power cord of any accessory or
enhancement, grasp and pull the plug, not the cord.
• Check regularly that enhancements installed in a vehicle are
mounted and are operating properly.
• Installation of any complex car enhancements must be made by
qualified personnel only.
r1024_en.book Page 136 Thursday, July 8, 2004 12:40 PM
Care and Maintenance
137
Care and Maintenance
Your device is a product of superior design and craftsmanship and should be
treated with care. The suggestions below help you protect your warranty
coverage.
• Keep the device dry. Precipitation, humidity and all types of liquids or
moisture can contain minerals that corrode electronic circuits. If your device
does get wet, remove the battery and allow the device to dry completely
before replacing it.
• Do not use or store the device in dusty, dirty areas. Its moving parts and
electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
• Do not store the device in cold areas. When the device returns to its normal
temperature, moisture can form inside the device and damage electronic
circuit boards.
• Do not attempt to open the device other than as instructed in this guide.
• Do not drop, knock, or shake the device. Rough handling can break internal
circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean
the device.
• Do not paint the device. Paint can clog the moving parts and prevent proper
operation.
• Use a soft, clean, dry cloth to clean any lenses (such as camera, proximity
sensor, and light sensor lenses).
• Use only the supplied or an approved replacement antenna. Unauthorised
antennas, modifications, or attachments could damage the device and may
violate regulations governing radio devices.
All of the above suggestions apply equally to your device, battery, charger, or any
enhancement. If any device is not working properly, take it to the nearest
authorized service facility for service.
r1024_en.book Page 137 Thursday, July 8, 2004 12:40 PM
Additional safety information
138
Additional safety information
■Operating environment
Remember to follow any special regulations in force in any area and always
switch off your device when its use is prohibited or when it may cause
interference or danger. Use the device only in its normal operating positions. To
maintain compliance with radio frequency exposure guidelines only use
enhancements approved by Nokia for use with this device. When the device is on
and being worn on the body, always use an approved holder or carrying case.
Parts of the device are magnetic. Metallic materials may be attracted to the
device, and persons with a hearing aid should not hold the device to the ear with
the hearing aid. Always secure the device in its holder, because metallic materials
may be attracted by the earpiece. Do not place credit cards or other magnetic
storage media near the device, because information stored on them may be
erased.
■Medical devices
Operation of any radio transmitting equipment, including wireless phones, may
interfere with the functionality of inadequately protected medical devices.
Consult a physician or the manufacturer of the medical device to determine if
they are adequately shielded from external RF energy or if you have any
questions. Switch off your device in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or health care facilities may
be using equipment that could be sensitive to external RF energy.
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of 6 in. (15.3
cm) be maintained between a wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations are consistent with
the independent research by and recommendations of Wireless Technology
Research. Persons with pacemakers should:
• always keep the device more than 6 in. (15.3 cm) from their pacemaker when
the device is switched on;
• not carry the device in a breast pocket; and
• hold the device to the ear opposite the pacemaker to minimise the potential
for interference.
If you have any reason to suspect that interference is taking place, switch off
your device immediately.
r1024_en.book Page 138 Thursday, July 8, 2004 12:40 PM
Additional safety information
139
Hearing aids
Some digital wireless devices may interfere with some hearing aids. If
interference occurs, consult your service provider.
■Vehicles
RF signals may affect improperly installed or inadequately shielded electronic
systems in motor vehicles such as electronic fuel injection systems, electronic
antiskid (antilock) braking systems, electronic speed control systems, air bag
systems. For more information, check with the manufacturer or its representative
of your vehicle or any equipment that has been added.
Only qualified personnel should service the device, or install the device in a
vehicle. Faulty installation or service may be dangerous and may invalidate any
warranty that may apply to the device. Check regularly that all wireless device
equipment in your vehicle is mounted and operating properly. Do not store or
carry flammable liquids, gases, or explosive materials in the same compartment
as the device, its parts, or enhancements. For vehicles equipped with an air bag,
remember that air bags inflate with great force. Do not place objects, including
installed or portable wireless equipment in the area over the air bag or in the air
bag deployment area. If in-vehicle wireless equipment is improperly installed and
the air bag inflates, serious injury could result.
Using your device while flying in aircraft is prohibited. Switch off your device
before boarding an aircraft. The use of wireless teledevices in an aircraft may be
dangerous to the operation of the aircraft, disrupt the wireless telephone
network, and may be illegal.
■Potentially explosive environments
Switch off your device when in any area with a potentially explosive atmosphere
and obey all signs and instructions. Potentially explosive atmospheres include
areas where you would normally be advised to turn off your vehicle engine.
Sparks in such areas could cause an explosion or fire resulting in bodily injury or
even death. Switch off the device at refuelling points such as near gas pumps at
service stations. Observe restrictions on the use of radio equipment in fuel
depots, storage, and distribution areas, chemical plants or where blasting
operations are in progress. Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include below deck on boats, chemical
transfer or storage facilities, vehicles using liquefied petroleum gas (such as
propane or butane), and areas where the air contains chemicals or particles such
as grain, dust or metal powders.
r1024_en.book Page 139 Thursday, July 8, 2004 12:40 PM
Additional safety information
140
■Safety information about video games
About photosensitive seizures
A very small percentage of people may experience a seizure when exposed to
certain visual images, including flashing lights or patterns that may appear in
video games. Even people who have no history of seizures or epilepsy may have
an undiagnosed condition that can cause photosensitive epileptic seizures while
watching video games. These seizures may have a variety of symptoms, including
lightheadedness, altered vision, eye or face twitching, jerking or shaking of arms
or legs, disorientation, confusion, or momentary loss of awareness. Seizures may
also cause loss of consciousness or convulsions that can lead to injury from
falling down or striking nearby objects.
Immediately stop playing and consult a doctor if you experience any of these
symptoms. Adults who allow teenagers (or children) to play the games should
watch for or ask their children about these symptoms as they are more likely than
adults to experience these seizures. The risk of photosensitive epileptic seizures
may be reduced by playing in a well-lit room and by not playing when you are
drowsy or fatigued. If you or any of your relatives have a history of seizures or
epilepsy, consult a doctor before playing.
Play safely
Take a break from playing games at least every half hour. Stop playing
immediately if you begin to feel tired of if you experience an unpleasant
sensation or pain in your hands and/or arms. If the condition persists, consult a
doctor.
Use of vibration can aggravate injuries. Do not turn vibration on if you have any
ailment in the bones or joints of your fingers, hands, wrists, or arms.
■Emergency calls
Important: Wireless phones, including this device, operate using radio
signals, wireless networks, landline networks, and user-programmed
functions. Because of this, connections in all conditions cannot be
guaranteed. You should never rely solely on any wireless device for
essential communications like medical emergencies.
To make an emergency call:
1. If the device is not on, switch it on. Check for adequate signal strength.
Some networks may require that a valid SIM card is properly inserted in the
device.
r1024_en.book Page 140 Thursday, July 8, 2004 12:40 PM
Additional safety information
141
2. Press as many times as needed to clear the display and ready the
device for calls.
3. Key in the official emergency number for your present location. Emergency
numbers vary by location.
4. Press .
If certain features are in use, you may first need to turn those features off before
you can make an emergency call. If the device is in offline or flight mode you
must change the profile to activate the phone function before you can make an
emergency call. Consult this guide or your service provider for more information.
When making an emergency call, give all the necessary information as accurately
as possible. Your wireless device may be the only means of communication at the
scene of an accident. Do not end the call until given permission to do so.
■Certification information (SAR)
THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO
WAVES
Your mobile device is a radio transmitter and receiver. It is designed and
manufactured not to exceed the limits for exposure to radio frequency (RF)
recommended by international guidelines (ICNIRP). These limits are part of
comprehensive guidelines and establish permitted levels of RF energy for the
general population. The guidelines were developed by independent scientific
organisations through periodic and thorough evaluation of scientific studies. The
guidelines include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for mobile devices employs a unit of measurement known
as the Specific Absorption Rate, or SAR. The SAR limit stated in the international
guidelines is 2.0 W/kg*. Tests for SAR are conducted using standard operating
positions with the device transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is determined at the highest certified
power level, the actual SAR of the device while operating can be well below the
maximum value. This is because the device is designed to operate at multiple
power levels so as to use only the power required to reach the network. In
general, the closer you are to a base station, the lower the power output of the
device.
The highest SAR value for this device when tested for use at the ear is 0.72 W/kg.
This device meets RF exposure guidelines when used either in the normal use
position against the ear or when positioned at least 2,2 cm away from the body.
r1024_en.book Page 141 Thursday, July 8, 2004 12:40 PM
Additional safety information
142
When a carry case, belt clip or holder is used for body-worn operation, it should
not contain metal and should position the product at least 2,2 cm away from
your body.
In order to transmit data files or messages, this device requires a quality
connection to the network. In some cases, transmission of data files or messages
may be delayed until such a connection is available. Ensure the above separation
distance instructions are followed until the transmission is completed.
* The SAR limit for mobile devices used by the public is 2.0 watts/kilogram (W/kg)
averaged over ten grams of body tissue. The guidelines incorporate a substantial
margin of safety to give additional protection for the public and to account for
any variations in measurements. SAR values may vary depending on national
reporting requirements and the network band. For SAR information in other
regions look under product information at www.nokia.com.
r1024_en.book Page 142 Thursday, July 8, 2004 12:40 PM
