Nokia E52 User Guide
9214349
Issue DRAFT 9 Nov
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-481 product is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at www.nokia.com/phones/
declaration_of_conformity/.
© 2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Mail for Exchange, OVI, Eseries, and Nokia E52 are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a
sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is
prohibited. Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described
in this document without prior notice.
This product includes software licensed from Symbian Software Ltd ©1998-2009. Symbian and Symbian OS are trademarks of Symbian Ltd.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
Portions of the Nokia Maps software are ©1996-2009 The FreeType Project. All rights reserved.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has
been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection
with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that
related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF
DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY,
RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
Reverse engineering of software in the device is prohibited to the extent permitted by applicable law. Insofar as this user guide contains any limitations on
Nokia's representations, warranties, damages and liabilities, such limitations shall likewise limit any representations, warranties, damages and liabilities of
Nokia's licensors.
The third-party applications provided with your device may have been created and may be owned by persons or entities not affiliated with or related to Nokia.
Nokia does not own the copyrights or intellectual property rights to the third-party applications. As such, Nokia does not take any responsibility for end-user
support, functionality of the applications, or the information in the applications or these materials. Nokia does not provide any warranty for the third-party
applications. BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED,
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT
THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details and
availability of language options. This device may contain commodities, technology or software subject to export laws and regulations from the US and other
countries. Diversion contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada
can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device
complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved
by Nokia could void the user's authority to operate this equipment.
9214349/Issue DRAFT 9 Nov EN
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
Contents
Safety................................................................7
About your device.................................................................7
Network services...................................................................8
1. Find help.......................................................9
Support..................................................................................9
Keep your device software up to date................................9
In-device help......................................................................10
Extended user guide...........................................................11
2. Get started..................................................12
SIM card, battery, charging, memory card.......................12
Keys and parts.....................................................................14
First start-up........................................................................16
Lock the keys.......................................................................17
Accessories..........................................................................17
Volume control....................................................................18
Home screen........................................................................18
Transfer content from another device.............................18
Set up your e-mail..............................................................19
Antennas..............................................................................19
Nokia PC Suite.....................................................................20
Access codes........................................................................20
Tips for efficient use...........................................................21
Visit Ovi................................................................................21
3. Nokia E52 – The basics ...............................22
Phone setup........................................................................22
Settings wizard...................................................................22
Menu....................................................................................22
Display indicators...............................................................23
Write text.............................................................................24
Search..................................................................................25
Common actions in several applications..........................26
Free memory.......................................................................26
4. Personalisation..........................................28
Profiles ................................................................................28
Select ringing tones............................................................28
Customise profiles..............................................................28
Personalise the home screen............................................29
Change the display theme.................................................29
Change audio themes.........................................................30
5. New from Nokia Eseries.............................31
Key features.........................................................................31
Home screen........................................................................31
One-touch keys...................................................................32
Turn to silence calls or alarms...........................................33
Calendar...............................................................................33
Contacts...............................................................................35
Multitasking.........................................................................37
6. Messaging...................................................38
Nokia Messaging.................................................................38
E-mail...................................................................................38
Write and send messages..................................................41
7. Phone..........................................................43
Voice calls............................................................................43
Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
Voice mail ...........................................................................44
Video calls............................................................................44
Video sharing......................................................................45
Internet calls.......................................................................48
Voice functions....................................................................49
8. Internet......................................................50
Browser................................................................................50
Browse the intranet ..........................................................54
Ovi Store..............................................................................54
Connect your computer to web.........................................54
9. Travelling...................................................56
Positioning (GPS)................................................................56
Maps.....................................................................................58
10. Nokia Office Tools.....................................63
Active notes.........................................................................63
Calculator.............................................................................63
File manager.......................................................................63
Quickoffice...........................................................................64
Converter.............................................................................64
Zip manager........................................................................65
PDF reader...........................................................................65
Printing................................................................................65
Clock.....................................................................................66
Dictionary............................................................................67
11. Media........................................................68
Camera.................................................................................68
Gallery..................................................................................69
Photos..................................................................................70
Share online........................................................................71
Nokia Video Centre.............................................................73
Music player.........................................................................75
Recorder..............................................................................75
Flash player.........................................................................76
FM radio...............................................................................76
12. Connectivity..............................................78
Fast packet data..................................................................78
Data cable............................................................................78
Bluetooth.............................................................................79
Wireless LAN .......................................................................82
Connection manager..........................................................83
13. Security and data management...............85
Lock the device...................................................................85
Memory card security.........................................................85
Encryption...........................................................................86
Certificate manager............................................................86
Application manager..........................................................88
Sync......................................................................................89
Mobile VPN...........................................................................90
14. Settings.....................................................92
General settings..................................................................92
Telephone settings.............................................................95
Connection settings............................................................96
Application settings.........................................................101
15. Green tips...............................................102
Save energy.......................................................................102
Recycle...............................................................................102
Save paper.........................................................................102
Learn more........................................................................102
Accessories...................................................103
Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
Battery..........................................................104
Battery and charger information....................................104
Nokia battery authentication guidelines.......................105
Taking care of your device...........................106
Recycle...............................................................................106
Additional safety information.....................108
Small children...................................................................108
Operating environment...................................................108
Medical devices.................................................................108
Vehicles..............................................................................109
Potentially explosive environments...............................109
Emergency calls................................................................109
Certification information (SAR).......................................110
Index............................................................111
Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel,
chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
About your device
The wireless device described in this guide is approved for
use on the UMTS 850 and 2100 networks, and GSM 850,
900, 1800, and 1900 networks. Contact your service
provider for more information about networks.
Your device supports several connectivity methods and
like computers may be exposed to viruses and other
harmful content. Exercise caution with messages,
connectivity requests, browsing, and downloads. Only
install and use services and software from trustworthy
sources that offer adequate security and protection, such
as applications that are Symbian Signed or have passed
the Java Verified™ testing. Consider installing antivirus
and other security software on your device and any
connected computer.
Your device may have preinstalled bookmarks and links for
third-party internet sites and may allow you to access
third-party sites. These are not affiliated with Nokia, and
Nokia does not endorse or assume liability for them. If you
access such sites, take precautions for security or content.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on. Do 7
Safety
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
not switch the device on when wireless device use may
cause interference or danger.
When using this device, obey all laws and respect local
customs, privacy and legitimate rights of others, including
copyrights. Copyright protection may prevent some
images, music, and other content from being copied,
modified, or transferred.
Make back-up copies or keep a written record of all
important information stored in your device.
When connecting to any other device, read its user guide
for detailed safety instructions. Do not connect
incompatible products.
The images in this guide may differ from your device
display.
Refer to the user guide for other important information
about your device.
Network services
To use the device you must have service from a wireless
service provider. Some features are not available on all
networks; other features may require that you make
specific arrangements with your service provider to use
them. Network services involve transmission of data.
Check with your service provider for details about fees in
your home network and when roaming on other
networks. Your service provider can explain what charges
will apply. Some networks may have limitations that affect
how you can use some features of this device requiring
network support such as support for specific technologies
like WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP
protocols and language-dependent characters.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have customized items such as menu
names, menu order, and icons.
8
Safety
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
1. Find help
Support
When you want to learn more about how to use your
product or you are unsure how your device should
function, see the support pages at www.nokia.com/
support or your local Nokia website, www.nokia.mobi/
support (with a mobile device), the Help application in the
device, or the user guide.
If this does not resolve your issue, do one of the following:
•Restart the device: switch off the device, and remove
the battery. After about a minute, replace the battery,
and switch on the device.
•Restore the original factory settings as explained in the
user guide. Your documents and files will be deleted in
the reset, so back up your data first.
•Update your device software regularly for optimum
performance and possible new features, as explained
in the user guide.
If your issue remains unsolved, contact Nokia for repair
options. See www.nokia.com/repair. Before sending your
device for repair, always back up the data in your device.
Keep your device
software up to date
About software updates
Software updates may include new features and enhanced
functions that were not available at the time of purchase
of your device. Updating the software may also improve
the device performance.
To get a notification when new software is available for
your device, register with My Nokia, and subscribe to
notifications for text or e-mail messages. For more
information, go to www.nokia.com/mynokia.
Warning: If you install a software update, you
cannot use the device, even to make emergency calls, until
the installation is completed and the device is restarted.
Be sure to back up data before accepting installation of an
update.
Downloading software updates may involve the
transmission of large amounts of data (network service).
Make sure that the device battery has enough power, or
connect the charger before starting the update.
After updating your device software or applications, the
instructions related to the updated applications in the user
guide or helps may no longer be up to date. 9
Find help
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
Software updates over the air
Select Menu > Ctrl. panel > Phone > SW update.
With Software update (network service), you can check if
there are updates available for your device software or
applications, and download them to your device.
Downloading software updates may involve the
transmission of large amounts of data (network service).
Make sure that the device battery has enough power, or
connect the charger before starting the update.
Warning: If you install a software update, you
cannot use the device, even to make emergency calls, until
the installation is completed and the device is restarted.
Be sure to back up data before accepting installation of an
update.
After updating your device software or applications using
Software update, the instructions related to the updated
applications in the user guide or the helps may no longer
be up to date.
Select Options and from the following:
•Start update — Download the available updates. To
unmark specific updates that you do not want to
download, select the updates from the list.
•Update via PC — Update your device using a PC. This
option replaces the Start update option when updates
are only available using the Nokia Software Updater PC
application.
•View details — View information on an update.
•View update history — View the status of previous
updates.
•Settings — Change the settings, such as the default
access point used for downloading updates.
•Disclaimer — View the Nokia licence agreement.
Update software using your PC
Nokia Software Updater is a PC application that enables
you to update your device software. To update your device
software, you need a compatible PC, broadband internet
access, and a compatible USB data cable to connect your
device to the PC.
To get more information and to download the Nokia
Software Updater application, go to www.nokia.com/
softwareupdate.
In-device help
Your device contains instructions to help to use the
applications in your device.
To open help texts from the main menu, select Menu >
Help > Help and the application for which you want to
read instructions.
When an application is open, to access the help text for
the current view, select Options > Help.
When you are reading the instructions, to change the size
of the help text, select Options > Decrease font size or
Increase font size.
You may find links to related topics at the end of the help
text. If you select an underlined word, a short explanation
is displayed. Help texts use the following indicators:
10
Find help
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
Link to a related help topic. Link to the application
being discussed.
When you are reading the instructions, to switch between
help texts and the application that is open in the
background, select Options > Show open apps. and the
desired application.
Extended user guide
For more information on applications or functions in your
device, see the extended version of this user guide, which
is available on the product support pages of the Nokia
website.
11
Find help
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
2. Get started
Your Nokia E52 is a business device that adapts to your free
time as well.
Read these first pages to get started, then use the rest of
the guide to explore what new features Nokia E52 brings
to you.
SIM card, battery,
charging, memory card
Put the pieces together, and get started with your Nokia
E52.
Insert the SIM card and battery
1. To open the back cover of the device, with the back
facing you, unlock the back cover release latch, and lift
the back cover.
2. If the battery is inserted, lift the battery in the direction
of the arrow to remove it.
3. Insert the SIM card. Ensure the contact area on the card
is facing the connectors on the device and that the
bevelled corner is facing the bottom of the device.
4. Align the contacts of the battery with the
corresponding connectors on the battery
compartment, and insert the battery in the direction
of the arrow.
12
Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
5. To replace the back cover, direct the top locking
catches toward their slots, and press down until the
cover locks into place.
Charge the battery
Your battery has been partially charged at the factory. If
the device indicates a low charge, do the following:
1. Connect the charger to a wall outlet.
2. Connect the charger plug to the USB port in the device.
3. When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging. If
the battery is completely discharged, it may take several
minutes before the charging indicator appears on the
display or before any calls can be made.
Charging with the USB data cable
Charging with the USB data cable is slower than charging
with the charger. Charging with the USB data cable may
not work if you use a USB hub. USB hubs may be
incompatible for charging a USB device.
Charging with the USB data cable may take a long time if
the battery is completely discharged.
When the USB data cable is connected, you can transfer
data at the same time as charging.
1. Connect a compatible USB device to your device using
a compatible USB data cable.
Depending on the type of the device that is used for
charging, it may take a while for charging to start.
2. If the device is switched on, select from the available
USB modes.
Insert the memory card
Use a memory card to save the memory on your device.
You can also back up information from your device to the
memory card.
Use only compatible microSD and microSDHC cards
approved by Nokia for use with this device. Nokia uses
approved industry standards for memory cards, but some
brands may not be fully compatible with this device.
Incompatible cards may damage the card and the device
and corrupt data stored on the card.
13
Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
Keep all memory cards out of the reach of small
children.
Check the compatibility of a memory card with
its manufacturer or provider.
A compatible memory card may be included in the sales
package. The memory card may be already inserted in the
device. If not, do the following:
1. To prevent the battery from coming loose, place the
device so that the back cover is facing up.
2. Remove the back cover.
3. Insert the memory card in the slot with the contact
area first. Ensure the contact area is facing the
connectors on the device.
4. Push the card in until it locks into place.
5. Replace the back cover.
Remove the memory card
Important: Do not remove the memory card
during an operation when the card is being accessed.
Doing so may damage the memory card and the device,
and corrupt data stored on the card.
1. Press the power key briefly, and select Remove
memory card.
2. To prevent the battery from coming loose, place the
device so that the back cover is facing up.
3. Remove the back cover.
4. Press the end of the memory card to release it from the
memory card slot, and remove the card.
5. Replace the back cover.
Keys and parts
Keys and parts
1 — Power key
2 — Light sensor
3 — Selection key. Press the selection key to perform the
function displayed above it.
4 — Home key
14
Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
5 — Call key
6 — Calendar key
7 — Microphone
8 — E-mail key
9 — End key
10 — Backspace key. Press the key to delete items.
11 — Selection key
12 — Navi™ key; hereafter referred to as scroll key. Press
the scroll key to make a selection, or to scroll left, right,
up, or down on the display. Press and hold the scroll key
to accelerate the scrolling.
13 — Earpiece
14 — Secondary camera
15 — Headset connector
1 — Flash
2 — Main camera
3 — Loudspeaker
Keys and parts (sides)
1 — Micro USB connector
2 — Volume up/Zoom in key
3 — Mute/Push to talk key
4 — Volume down/Zoom out key
5 — Capture key
The surface of this device is nickel-free.
During extended operation such as an active video call and
high speed data connection, the device may feel warm. In
most cases, this condition is normal. If you suspect the
device is not working properly, take it to the nearest
authorised service facility.
Keep your device away from magnets or magnetic fields.
15
Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
One-touch keys
With One-touch keys, you can access applications and
tasks quickly.
To change the assigned application or task, select Menu >
Ctrl. panel > Settings and General >
Personalisation > One-touch keys. Your service
provider may have assigned applications to the keys, in
which case you cannot change them.
1 — Home key
2 — E-mail key
3 — Calendar key
Key Press quickly Press and hold
Home key (1) Access the home
screen
View the list of
active
applications
E-mail key (2) Open your default
mailbox
Create a new e-
mail message
Calendar key (3) Open the
Calendar
application
Create a new
meeting entry
First start-up
1. Press and hold the power key until
you feel the device vibrate.
2. If prompted, enter the PIN code or
lock code, and select OK.
3. When prompted, enter the country in
which you are located and the current
date and time. To find your country,
enter the first letters of the country
name. It is important to select the
correct country, because scheduled
calendar entries may change if you
change the country later and the new
country is located in a different time
zone.
4. The Phone setup application opens. To set up an
application, select Start. To bypass setting up
applications, select Skip repeatedly. To open the
Phone setup application later, select Menu > Help >
Phone setup.
To configure the various settings in your device, use the
wizards available in the home screen and the Settings
wizard application. When you switch the device on, it may
recognise the SIM card provider and configure some
settings automatically. You can also contact your service
provider for the correct settings.
You can switch the device on without inserting a SIM card.
The device starts up in the Offline profile, and you cannot
use the network-dependent phone functions.
To switch the device off, press and hold the power key.
16
Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
Lock the keys
When the device or keypad is locked, calls may be possible
to the official emergency number programmed into your
device.
The keypad of your device locks automatically to prevent
accidental keypresses.
To change the length of time after which the keypad is
locked, select Menu > Ctrl. panel > Settings and
General > Security > Phone and SIM card > Keypad
autolock period.
To lock the keys manually in the
home screen, press the left selection
key and then the right selection key.
To lock the keys manually in the
menu or in an open application,
press the power key briefly, and
select Lock keypad.
To unlock the keys, press the left selection key and then
the right selection key.
Accessories
You can connect your device to a range of compatible
accessories. Check the availability of the approved
accessories with your dealer.
Connect the headset
Warning: When you use the headset, your ability
to hear outside sounds may be affected. Do not use the
headset where it can endanger your safety.
Connect the compatible headset to the headset connector
of your device.
Attach a wrist strap
Thread the wrist strap, and tighten
it.
17
Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
Volume control
To adjust the earpiece volume during a phone call or the
volume of the media applications, use the volume keys.
Home screen
In the home screen, you can quickly access your most
frequently used applications, and view at a glance if you
have missed calls or new messages.
Whenever you see the icon, scroll right to access a list
of available actions. To close the list, scroll left.
The home screen consists of the
following:
1. Application shortcuts. To
access an application, select
the shortcut of the
application.
2. Information area. To check
an item displayed in the
information area, select the
item.
3. Notification area. To view
the notifications, scroll to a
box. A box is only visible if
there are items in it.
You can define two separate home screens for different
purposes, for example, one screen to show your business
e-mail and notifications, and another to show your
personal e-mail. This way, you do not have to see business-
related messages outside office hours.
To switch between the home screens, select .
To define which items and shortcuts you want in the home
screen, and to set the appearance of the home screen,
select Menu > Ctrl. panel and Modes.
Transfer content from
another device
Select Menu > Ctrl. panel > Switch.
With the Switch application, you can transfer content, such
as contacts, between two compatible Nokia devices.
The type of content that can be transferred depends on
the model of the device from which you want to transfer
content. If the other device supports synchronisation, you
can also synchronise data between the other device and
your Nokia E52. Your device notifies you if the other device
is not compatible.
If the other device cannot be switched on without a SIM
card, you can insert your SIM card in it. When the Nokia
E52 is switched on without a SIM card, the Offline profile
is automatically activated.
Transfer content
To retrieve data from your other device for the first time:
1. Select the connection type you want to use to transfer
the data. Both devices must support the selected
connection type.
2. Select the device from which you want to transfer
content. You are asked to enter a code on your Nokia
E52. Enter a code (1-16 digits), and select OK. Enter the
18
Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
same code on the other device, and select OK. The
devices are now paired.
For some device models, the Switch application is sent
to the other device as a message. To install the Switch
application on the other device, open the message, and
follow the instructions on the display.
3. From your Nokia E52, select the content you want to
transfer from the other device.
Content is transferred from the memory of the other
device to the corresponding location in your Nokia E52.
Transfer time depends on the amount of data to be
transferred. You can cancel the transfer and continue later.
The synchronisation is two-way, and the data in both
devices is the same. If an item is deleted from either
device, it is deleted from the other device when
synchronising; you cannot restore deleted items by
synchronising.
To view the log of the last transfer, select a shortcut in the
main view and Options > View log.
Set up your e-mail
Your Nokia Eseries device works the same hours as you,
and at the same speed. Keep your e-mail, contacts, and
calendar synchronised - quickly and conveniently with
high speed connections.
When setting up your e-mail, you may be prompted for the
following information: user name, e-mail type, incoming
mail server, incoming mail server port, outgoing mail
server, outgoing mail server port, password, or access
point.
With the E-mail wizard, you can set up business e-mail
accounts, such as Microsoft Exchange, or internet e-mail
accounts, such as Google's e-mail services. The wizard
supports POP/IMAP, and ActiveSync protocols.
If you are setting up your business e-mail, ask your
company IT department for details. If you are setting up
your internet e-mail, see your e-mail service provider’s
website for details.
To start the E-mail wizard:
1. In the home screen, scroll to the E-mail wizard.
2. Enter your e-mail address and password. If the wizard
is not able to configure your e-mail settings
automatically, select your e-mail account type, and
enter the related settings.
Tip: If you have not configured your mailbox, press
the e-mail key to start the E-mail wizard.
If your device contains additional e-mail clients, those are
offered to you when you start the E-mail wizard.
Antennas
Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while the
antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.
19
Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
Nokia PC Suite
Nokia PC Suite is a set of applications that you can install
to a compatible PC. Nokia PC Suite groups all available
applications in a launcher window from which you can run
the applications. Nokia PC Suite may be included on a
memory card if one is provided with your device.
You can use Nokia PC Suite to synchronise contacts,
calendar, and to-do and other notes between your device
and a compatible PC application, such as Microsoft Outlook
or Lotus Notes. You can also use Nokia PC Suite to transfer
bookmarks between your device and compatible
browsers, and transfer images and video clips between
your device and compatible PCs.
Note: Pay attention to synchronisation settings.
Data deletion as part of normal synchronisation process is
determined by the settings selected.
To use Nokia PC Suite, you need a PC that runs Microsoft
Windows XP (SP2) or Windows Vista, and is compatible
with a USB data cable or with Bluetooth connectivity.
Nokia PC Suite does not work with Macintosh.
For further information on Nokia PC Suite, see its help
function or the Nokia website.
To install Nokia PC Suite:
1. Ensure the memory card is inserted in your Nokia E52.
2. Connect the USB cable. Your PC recognises the new
device and installs the necessary drivers. This can take
several minutes to complete.
3. Select Mass storage as the USB connection mode in
your device. Your device is displayed in Windows file
browser as a Removable Disk.
4. Open the root of the memory card drive with the
Windows file browser, and select the PC Suite
installation.
5. The installation is started. Follow the displayed
instructions.
Tip: To update Nokia PC Suite, or if you have
problems when installing Nokia PC Suite from the
memory card, copy the installation file to your PC,
and start the installation from your PC.
Access codes
If you forget any of the access codes, contact your service
provider.
•Personal identification number (PIN) code — This code
protects your SIM card against unauthorised use. The
PIN code (4 - 8 digits) is usually supplied with the SIM
card. After three consecutive incorrect PIN code entries,
the code is blocked, and you need the PUK code to
unblock it.
20
Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
•UPIN code — This code may be supplied with the USIM
card. The USIM card is an enhanced version of the SIM
card and is supported by 3G mobile phones.
•PIN2 code — This code (4 - 8 digits) is supplied with
some SIM cards, and is required to access some
functions in your device.
•Lock code (also known as security code) — The lock
code helps you to protect your device against
unauthorised use. The preset code is 12345. You can
create and change the code, and set the device to
request the code. Keep the new code secret and in a
safe place separate from your device. If you forget the
code and your device is locked, your device will require
service. Additional charges may apply, and all the
personal data in your device may be deleted. For more
information, contact a Nokia Care point or your device
dealer.
•Personal Unblocking Key (PUK) code and PUK2
code — These codes (8 digits) are required to change a
blocked PIN code or PIN2 code, respectively. If the codes
are not supplied with the SIM card, contact the network
service provider whose SIM card is in your device.
•UPUK code — This code (8 digits) is required to change
a blocked UPIN code. If the code is not supplied with
the USIM card, contact the network service provider
whose USIM card is in your device.
Tips for efficient use
To switch profiles, press the power key briefly.
To switch to the Silent profile, press and hold #.
To search for items in your device or on the internet
(network service), select Menu > Applications >
Search.
When browsing web pages with the Web browser
application or maps in the Maps application, press * to
zoom in and # to zoom out.
Visit Ovi
Ovi contains services provided by Nokia. With Ovi you can,
for example, create an e-mail account, share your images
and video clips with friends and family, plan trips and view
locations on a map, download games, applications, video
clips, and tones to your device, and purchase music. The
available services may vary by region, and not all
languages are supported.
Access the services — Go to www.ovi.com, and register
your own Nokia account.
For more information on how to use the services, see the
support pages of each service.
21
Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:45
3. Nokia E52 – The basics
Phone setup
When you switch on your device for the first time, the
Phone setup application opens.
To access the Phone setup application later, select Menu >
Help > Phone setup.
To set up the device connections, select Sett. wizard.
To transfer data to your device from a compatible Nokia
device, select Switch.
The available options may vary.
Settings wizard
Select Menu > Ctrl. panel > Sett. wizard.
Use Settings wizard to define e-mail and connection
settings. The availability of the items in Settings wizard
depends on the features of the device, SIM card, service
provider, and the data in the Settings wizard database.
To start Settings wizard, select Start.
To get the best results when using the settings wizard,
keep your SIM card inserted in the device. If the SIM card
is not inserted, follow the instructions on the display.
Select from the following:
•Operator — Define the operator-specific settings, such
as MMS, internet, WAP, and streaming settings.
•E-mail setup — Configure a POP, IMAP, or Mail for
Exchange account.
•Push to talk — Configure push to talk settings.
•Video sharing — Configure video sharing settings.
The settings available for editing may vary.
Menu
Select Menu.
The menu is a starting point
from which you can open all
applications in the device or on
a memory card.
The menu contains applications
and folders, which are groups
of similar applications. All
applications you install in the
device yourself are by default
saved in the Applications folder.
To open an application, select
the application, that is, scroll to it, and press the scroll key.
To switch between the open applications, press and hold
the home key, and select an application. Leaving
applications running in the background increases the
demand on battery power and reduces the battery life.
Select Options and from the following:
22
Nokia E52 – The basics
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Change Menu view — View applications in a list or a
grid.
•Memory details — View the memory consumption of
different applications and data stored on the device or
memory card and to check the amount of free memory.
•New folder — Create a new folder.
•Rename — Rename a new folder.
•Move — Rearrange the folder. Scroll to the application
you want to move, and select Move. A check mark is
placed beside the application. Scroll to a new location,
and select OK.
•Move to folder — Move an application to a different
folder. Scroll to the application you want to move, and
select Move to folder, the new folder, and OK.
•Download applications — Download applications
from the web.
Display indicators
The device is being used in a UMTS network
(network service).
The battery charge level. The higher the bar, the
stronger the charge in the battery.
You have one or more unread messages in the
Inbox folder in Messaging.
You have received new e-mail in the remote
mailbox.
There are messages waiting to be sent in the
Outbox folder in Messaging.
You have one or more missed phone calls.
The keys of the device are locked.
An alarm is active.
You have activated the Silent profile, and the
device does not ring for an incoming call or
message.
Bluetooth connectivity is activated.
A Bluetooth connection is established. When the
indicator is blinking, your device is trying to
connect with another device.
A GPRS packet data connection is available
(network service). indicates that the
connection is active. indicates that the
connection is on hold.
An EGPRS packet data connection is available
(network service). indicates that the
connection is active. indicates that the
connection is on hold.
23
Nokia E52 – The basics
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
A UMTS packet data connection is available
(network service). indicates that the
connection is active. indicates that the
connection is on hold.
High-speed packet access (HSPA) is supported and
available (network service). The icon may vary
between regions. indicates that the connection
is active. indicates that the connection is on
hold.
You have set the device to scan for wireless LANs
(WLAN), and a WLAN is available.
A WLAN connection is active in a network that
does not have encryption.
A WLAN connection is active in a network that has
encryption.
Your device is connected to a computer with a USB
data cable.
The second phone line is being used (network
service).
All calls are forwarded to another number. If you
have two phone lines, a number indicates the
active line.
A headset is connected to the device.
A handsfree car kit is connected to the device.
A loopset is connected to the device.
A text phone is connected to the device.
Your device is synchronising.
You have an ongoing push to talk (PTT)
connection.
Your push to talk connection is in do not disturb
mode, because the ringing type of your device is
set to Beep once or Silent, or you have an
incoming or ongoing phone call. In this mode, you
cannot make PTT calls.
Write text
The input methods provided in the device may vary
according to different sales markets.
Traditional text input
indicates traditional text input.
and indicate the uppercase and lowercase.
indicates the sentence case, that is, the first letter
of the sentence is written in uppercase and all the other
24
Nokia E52 – The basics
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
letters are automatically written in lowercase.
indicates number mode.
To write text with the keypad, press a number key, 2-9,
repeatedly until the desired character is displayed. There
are more characters available for a number key than are
printed on the key. If the next letter is located on the same
key as the present one, wait until the cursor is displayed,
and enter the letter.
To insert a number, press and hold the number key.
To switch between the different character cases and
modes, press #.
To erase a character, press the backspace key. Press and
hold the backspace key to erase more than one character.
To enter the most common punctuation marks, press 1
repeatedly until the desired punctuation mark is
displayed.
To add special characters, press and hold *.
To insert a space, press 0. To insert a line break, press 0
three times.
Predictive text input
With predictive input, you can enter any letter with a
single keypress. Predictive text input is based on a built-
in dictionary.
To activate or deactivate predictive text input, select
Options > Input options. The indicator is
displayed. When you start writing a word, your device
suggests possible words. When the correct word is found,
press the space key (0) to confirm it and to add a space.
While writing, you can scroll down to access a list of
suggested words. If the desired word is on the list, select
the word. If the ? character is displayed after the word, the
word you intended to write is not in the dictionary. To add
a word to the dictionary, select Spell, enter the word using
traditional text input, and select OK. When the dictionary
is full, the new word replaces the oldest added word.
To deactivate automatic word completion, select
Options > Input options > Settings.
To change the writing language, select Options > Input
options > Writing language.
Search
About Search
Select Menu > Applications > Search.
Search enables you to use various internet-based search
services to find, for example, websites, and images. The
content and availability of the services may vary.
Start a search
Select Menu > Applications > Search.
To search the contents of your mobile device, enter search
terms in the search field, or browse the content categories.
While you enter the search terms, the results are organised
into categories.
To search for web pages on the internet, select Search the
Internet or a search provider, and enter your search terms 25
Nokia E52 – The basics
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
in the search field. The search provider you selected is set
as your default internet search provider.
To change the default search provider, select Options >
Settings > Search services.
To change the country or region setting to find more
search providers, select Options > Settings > Country
or region.
Common actions in
several applications
You can find the following actions in several applications:
To change the profile, or switch off or lock the device, press
the power key briefly.
If an application consists of
several tabs (see figure), open a
tab by scrolling right or left.
To save the settings that you
have configured in an
application, select Back.
To save a file, select Options > Save. There are different
saving options depending on the application you use.
To send a file, select Options > Send. You can send a file
in an e-mail or multimedia message, or using different
connectivity methods.
To copy, press and hold the shift key, and select the text
with the scroll key. Press and hold the shift key, and select
Copy. To paste, scroll to where you want to paste the text,
press and hold the shift key, and select Paste. This method
may not work in applications that have their own copy and
paste commands.
To select different items, such as messages, files, or
contacts, scroll to the item you want to select. Select
Options > Mark/Unmark > Mark to select one item or
Options > Mark/Unmark > Mark all to select all items.
Tip: To select almost all items, first select Options >
Mark/Unmark > Mark all, then select the items
you do not want, and Options > Mark/Unmark >
Unmark.
To select an object (for example, an attachment in a
document) scroll to the object so that square markers
appear on each side of the object.
Free memory
To view how much memory is available for different data
types, select Menu > Office > File mgr..
Many features of the device use memory to store data. The
device notifies you if available memory is low.
To free memory, transfer data to an alternative memory
(if available) or compatible computer.
To remove data you no longer need, use File manager or
the respective application. You can remove the following:
•Messages in the folders in Messaging and retrieved e-
mail messages from the mailbox
•Saved web pages
•Contact information
•Calendar notes
26
Nokia E52 – The basics
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Applications shown in Application manager that you do
not need
•Installation files (with .sis or .sisx file extensions) of
installed applications. Back up the installation files to a
compatible computer.
•Images and video clips in Photos. Back up the files to a
compatible computer using Nokia PC Suite.
27
Nokia E52 – The basics
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
4. Personalisation
You can personalise your device by, for example, adjusting
the various tones, background images, and screen savers.
Profiles
Select Menu > Ctrl. panel > Profiles.
You can adjust and customise the ringing tones, alert
tones, and other device tones for different events,
environments, or caller groups. The active profile is shown
at the top of the display in the home screen. However, if
the active profile is General, only today's date is shown.
To create a new profile, select Options > Create new,
and define the settings.
To customise a profile, select a profile and Options >
Personalise.
To change a profile, select a profile and Options >
Activate. The Offline profile prevents your device from
accidentally switching on, sending or receiving messages,
or using wireless LAN, Bluetooth connectivity, GPS, or FM
radio; it also closes any internet connection that may be
in operation when the profile is selected. The Offline
profile does not prevent you from establishing a wireless
LAN or Bluetooth connection at a later time, or from
restarting the GPS or FM radio, so comply with any
applicable safety requirements when establishing and
using these features.
To set the profile to be active until a certain time within
the next 24 hours, scroll to the profile, select Options >
Timed, and set the time. When the time expires, the
profile changes back to the previously active non-timed
profile. When the profile is timed, is displayed in the
home screen. The Offline profile cannot be timed.
To delete a profile that you created, select Options >
Delete profile. You cannot delete the predefined profiles.
Select ringing tones
To set a ringing tone for a profile, select Options >
Personalise > Ringing tone. Select a ringing tone from
the list, or select Download sounds to open a bookmark
folder containing a list of bookmarks for downloading
tones using the browser. Any downloaded tones are saved
to Gallery.
To play the ringing tone for a selected contact group only,
select Options > Personalise > Alert for, and select the
desired group. Phone calls coming from outside that
group have a silent alert.
To change the message tone, select Options >
Personalise > Message alert tone.
Customise profiles
Select Menu > Ctrl. panel > Profiles.
28
Personalisation
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Select Options > Personalise and from the following:
•Ringing tone — Select a ringing tone from the list, or
select Download sounds to open a bookmark folder
containing a list of bookmarks for downloading tones
using the browser. If you have two alternate phone
lines in use, you can specify a ringing tone for each line.
•Video call tone — Select a ringing tone for video calls.
•Say caller's name — When you select this option and
someone from your contacts list calls you, the device
sounds a ringing tone that is a combination of the
spoken name of the contact and the selected ringing
tone.
•Ringing type — Select how you want the ringing tone
to alert.
•Ringing volume — Select the volume level of the
ringing tone.
•Message alert tone — Select a tone for received text
messages.
•E-mail alert tone — Select a tone for received e-mail
messages.
•Vibrating alert — Set the device to vibrate when you
receive a call or message.
•Keypad tones — Select the volume level of the keypad
tones.
•Warning tones — Deactivate the warning tones. This
setting also affects the tones of some games and
Java™ applications.
•Alert for — Set the device to ring only upon calls from
phone numbers that belong to a selected contact
group. Phone calls coming from outside that group
have a silent alert.
•PTT call alert tone — Select a ringing tone for PTT calls.
•Push to talk status — Set the PTT status to each
profile.
•Profile name — You can give a name to a new profile
or rename an existing profile. The General and Offline
profiles cannot be renamed.
Personalise the home
screen
Select Menu > Ctrl. panel > Modes.
To change the name of the current home screen, select
Options > Rename mode.
To select which applications and notifications you want to
see in the home screen, select Home screen
applications.
To change the theme of the home screen currently in use,
select General theme.
To change the background image of the home screen
currently in use, select Wallpaper.
To change from one home screen to another, scroll to
Current mode, and select Options > Change.
Change the display
theme
Select Menu > Ctrl. panel > Themes.
To change the theme used in all applications, select
General.29
Personalisation
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
To change the theme used in the main menu, select Menu
view.
To change the theme for a particular application, select
the application-specific folder.
To change the background image of the home screen,
select Wallpaper.
To select an animation for the screen saver, select Power
saver.
To turn theme effects on or off, select General >
Options > Theme effects.
Change audio themes
Select Menu > Ctrl. panel > Themes and Audio
themes.
You can set sounds for various device events. The sounds
can be tones, speech, or a combination of both.
To change the current audio theme, select Active audio
theme.
To set a sound for an event, select an event group, such as
ringing tones, and the desired event.
To use all the preset sounds in an event group, select the
group and Options > Activate sounds.
Select Options and from the following:
•Play voice — Play the sound before activating it.
•Save theme — Create a new audio theme.
•3-D ringing tones — Add 3-D effects to the audio
theme.
•Speech — Select Speech to set speech as the sound
for an event. Enter the desired text to the text field. The
Speech option is not available if you have activated the
Say caller's name option in the current profile.
•Deactivate sounds — Silence all the sounds in an
event group.
30
Personalisation
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
5. New from Nokia Eseries
Your new Nokia Eseries device contains new versions of
the Calendar, Contacts, and E-mail applications, as well as
a new home screen.
Key features
Your new Nokia E52 helps you manage your business and
personal information. Some of the key features are
highlighted here:
Read and reply to your e-mail while on the
move.
Stay up-to-date and plan your meetings with
the Calendar application.
Manage your business partners and free time
friends with the Contacts application.
Connect to a wireless LAN (WLAN) with the
WLAN wizard application.
Work with documents, spreadsheets, and
presentations with the Quickoffice application.
Find points of interest with the Maps
application.
Switch from business to personal mode.
Edit the appearance and setup of your home
screen with the Modes application.
Browse your company intranet with the
Intranet application.
Move your contact and calendar information
from a previous device to your Nokia E52 with
the Switch application.
Check the available updates for applications
and download them to your device with the
Software update application.
Encrypt your device or memory card to prevent
outsiders from accessing your important
information.
Home screen
In the home screen, you can quickly access your most
frequently used features and applications, and view at a
glance if you have missed calls or new messages.
31
New from Nokia Eseries
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Home screen
In the home screen, you can quickly access your most
frequently used applications, and view at a glance if you
have missed calls or new messages.
Whenever you see the icon, scroll right to access a list
of available actions. To close the list, scroll left.
The home screen consists of the
following:
1. Application shortcuts. To
access an application, select
the shortcut of the
application.
2. Information area. To check
an item displayed in the
information area, select the
item.
3. Notification area. To view
the notifications, scroll to a
box. A box is only visible if
there are items in it.
You can define two separate home screens for different
purposes, for example, one screen to show your business
e-mail and notifications, and another to show your
personal e-mail. This way, you do not have to see business-
related messages outside office hours.
To switch between the home screens, select .
To define which items and shortcuts you want in the home
screen, and to set the appearance of the home screen,
select Menu > Ctrl. panel and Modes.
Work on the home screen
To search for contacts in the home screen, start entering
the contact's name. When entering the characters, press
each key once. For example, to enter "Eric", press 3742.
The device suggests matching contacts. To switch
between the alphabetic and number modes, select
Options > Alpha mode or Number mode. Select the
desired contact from the list of proposed matches. This
feature may not be available in all languages.
To call the contact, press the call key.
To disable the contact search, select Options > Contact
search off.
To check your received messages, select the message box
in the notification area. To read a message, select the
message. To access other tasks, scroll right.
To view your missed calls, select the calls box in the
notification area. To return a call, select a call, and press
the call key. To send a text message to a caller, select a call,
scroll right, and select Send message from the list of
available actions.
To listen to your voice mail, select the voice mail box in the
notification area. Select the desired voice mailbox, and
press the call key.
One-touch keys
With the One-touch keys, you can access applications and
tasks quickly. Each key has been assigned an application
or a task. To change these, select Menu > Ctrl. panel >
Settings and General > Personalisation > One-touch
keys. Your service provider may have assigned
32
New from Nokia Eseries
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
applications to the keys, in which case you cannot change
them.
1 — Home key
2 — E-mail key
3 — Calendar key
Home key
To access the home screen, press the home key briefly.
Press the home key briefly again to access the menu.
To view the list of active applications, press the home key
for a few seconds. When the list is open, press the home
key briefly to scroll the list. To open the selected
application, press the home key for a few seconds, or press
the scroll key. To close the selected application, press the
backspace key.
Leaving applications running in the background increases
the demand on battery power and reduces the battery life.
Calendar key
To open the Calendar application, press the calendar key
briefly.
To create a new meeting entry, press the calendar key for
a few seconds.
E-mail key
To open your default mailbox, press the e-mail key briefly.
To create a new e-mail message, press the e-mail key for
a few seconds.
Turn to silence calls or
alarms
When you activate the sensors in your device, you can
control certain functions by turning the device.
Select Menu > Ctrl. panel > Settings and General >
Sensor settings.
Select from the following:
•Sensors — Set the display to rotate automatically
according to the device's orientation.
•Turning control — Set the device to silence incoming
calls or snooze alarms when you turn the device face
down. To enable this option, the Sensors option needs
to be activated.
Calendar
Select Menu > Calendar.
About Calendar
Select Menu > Calendar.33
New from Nokia Eseries
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
With calendar, you can create and view scheduled events
and appointments, and switch between different calendar
views.
In the month view, calendar entries are marked with a
triangle. Anniversary entries are also marked with an
exclamation mark. The entries of the selected day are
displayed as a list.
To open calendar entries, select a calendar view and an
entry.
Whenever you see the icon, scroll right to access a list
of available actions. To close the list, scroll left.
Create calendar entries
Select Menu > Calendar.
You can create the following types of calendar entries:
•Meeting entries remind you of events that have a
specific date and time.
•Meeting requests are invitations that you can send to
the participants. Before you can create meeting
requests you must have a compatible mailbox
configured to your device.
•Memo entries are related to the whole day but not to a
specific time of the day.
•Anniversary entries remind you of birthdays and special
dates. They refer to a certain day but not a specific time
of the day. Anniversary entries are repeated every year.
•To-do entries remind you of a task that has a due date
but not a specific time of the day.
To create a calendar entry, select a date, Options > New
entry, and the entry type.
To set the priority for meeting entries, select Options >
Priority.
To define how the entry is handled during
synchronisation, select Private to hide the entry from
viewers if the calendar is available online, Public to make
the entry visible to viewers, or None to not copy the entry
to your computer.
To send the entry to a compatible device, select Options >
Send.
To make a meeting request of a meeting entry, select
Options > Add participants.
Create meeting requests
Select Menu > Calendar.
Before you can create meeting requests, you must have a
compatible mailbox configured for your device.
To create a meeting entry:
1. To create a meeting entry, select a day and Options >
New entry > Meeting request.
2. Enter the names of the required participants. To add
names from your contacts list, enter the first few
characters, and select from the proposed matches. To
add optional participants, select Options > Add
participants.
3. Enter the subject.
4. Enter the start and end times and dates, or select All-
day event.
5. Enter the location.
6. Set an alarm for the entry, if needed.
34
New from Nokia Eseries
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
7. For a recurring meeting, set the recurrence time, and
enter the end date.
8. Enter a description.
To set the priority for the meeting request, select
Options > Priority.
To send the meeting request, select Options > Send.
Calendar views
Select Menu > Calendar.
You can switch between the following views:
•Month view shows the current month and the calendar
entries of the selected day in a list.
•Week view shows the events for the selected week in
seven day boxes.
•Day view shows the events for the selected day grouped
into time slots according to their starting time.
•To-do view shows all to-do items.
•Agenda view shows the events for the selected day in
a list.
Tip: To switch between views, press *.
To change the view, select Options > Change view and
the desired view.
Tip: To open the week view, select the week
number.
To move to the next or the previous day in month, week,
day, and agenda view, select the desired day.
To change the default view, select Options > Settings >
Default view.
Contacts
About Contacts
Select Menu > Contacts.
With Contacts, you can save and update contact
information, such as phone numbers, home addresses,
and e-mail addresses of your contacts. You can add a
personal ringing tone or a thumbnail image to a contact.
You can also create contact groups, which allow you to
communicate with several contacts at the same time, and
send contact information to compatible devices.
Whenever you see the icon, scroll right to access a list
of available actions. To close the list, scroll left.
Work with contacts
Select Menu > Contacts.
To create a contact, select Options > New contact, and
enter the details of the contact.
To copy contacts from the memory card, if available, select
Options > Create backup > Memory card to phone.
To search for contacts, start entering the contact's name
in the search field.
To switch to predictive search mode, select Options >
Activate predict. search.35
New from Nokia Eseries
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
To search for contacts in predictive search mode, start
entering the contact's name in the search field.
Create contact groups
Select Menu > Contacts.
1. To create a contact group, scroll to each contact you
want to add to the group, and select Options > Mark/
Unmark > Mark.
2. Select Options > Group > Add to group > Create
new group, and enter a name for the group.
If you want to make conference calls to the group using a
conference service, define the following:
•Conf. service number — Enter the conference call
service number.
•Conf. service ID — Enter the conference call ID.
•Conf. service PIN — Enter the conference call PIN code.
To make a conference call to the group using the
conference service, select the group, scroll right, and select
Call conf. service.
Search for contacts in a remote
database
To activate remote contact search, select Options >
Settings > Contacts > Remote search server. You
must define a remote server before you can do remote
contact searches.
To search for contacts in a remote database, select
Contacts > Options > Search from remote. Enter the
name of the contact you want to search for, and select
Search. The device establishes a data connection to the
remote database.
To search for contacts in the home screen, start entering
characters in the home screen, and select the database
from the proposed matches.
To change the remote contacts database, select Options >
Settings > Contacts > Remote search server. This
setting affects the database used in the Contacts and
Calendar applications and the home screen, but not the
database that is used for e-mail.
Add ringing tones for contacts
Select Menu > Contacts.
To add a ringing tone for a contact, select the contact,
Options > Ringing tone, and a ringing tone. The ringing
tone sounds when the contact calls you.
To add a ringing tone for a contact group, select the
contact group, Options > Group > Ringing tone, and a
ringing tone.
To remove the ringing tone, select Default tone from the
list of ringing tones.
Contacts settings
Select Menu > Contacts.
To modify the settings of the Contacts application, select
Options > Settings > Contacts and from the following:
•Contacts to display — Show contacts that are stored
in the device memory, on the SIM card, or both.
36
New from Nokia Eseries
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Default saving memory — Select where to save
contacts.
•Name display — Change the way contacts' names are
displayed.
•Default contact list — Select which contacts list opens
when you open the Contacts application. This setting is
only available when there is more than one contacts
list.
•Remote search server — Change the remote contacts
database. This option is available only if remote
contacts databases are supported by your service
provider.
Multitasking
You can have several applications open at the same time.
To switch between active applications, press and hold the
home key, scroll to an application, and press the scroll key.
To close the selected application, press the backspace key.
Example: When you have an active phone call and
want to check your calendar, press the home key to
access the menu, and open the Calendar
application. The phone call remains active in the
background.
Example: When you are writing a message and
want to check a web site, press the home key to
access the menu, and open the Web application.
Select a bookmark or enter the web address
manually, and select Go to. To return to your
message, press and hold the home key, scroll to the
message and press the scroll key.
37
New from Nokia Eseries
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
6. Messaging
Select Menu > Messaging.
In Messaging (network service), you can send and receive
text messages, multimedia messages, audio messages,
and e-mail messages. You can also receive web service
messages, cell broadcast messages, and special messages
containing data, and send service commands.
Before sending or receiving messages, you may need to
do the following:
•Insert a valid SIM card in the device and be located in
the service area of a cellular network.
•Verify that the network supports the messaging
features you want to use and that they are activated on
your SIM card.
•Define the internet access point settings on the device.
•Define the e-mail account settings on the device.
•Define the text message settings on the device.
•Define the multimedia message settings on the device.
The device may recognise the SIM card provider and
automatically configure some of the message settings. If
not, you may need to define the settings manually; or
contact your service provider to configure the settings.
Nokia Messaging
The Nokia Messaging service automatically pushes e-mail
from your existing e-mail address to your Nokia E52. You
can read, respond to, and organise your e-mails on the go.
The Nokia Messaging service works with a number of
internet e-mail providers that are often used for personal
e-mail, such as Google e-mail services.
The Nokia Messaging service may be chargeable. For
information on possible costs, contact your service
provider or the Nokia Messaging service.
The Nokia Messaging service must be supported by your
network and may not be available in all regions.
Install the Nokia messaging application
1. Select Menu > Email > New.
2. Read the information on the display, and select Start.
3. Select Connect to allow your device to access the
network.
4. Enter your e-mail address and password.
The Nokia Messaging service can run on your device even
if you have installed other e-mail applications, such as Mail
for Exchange.
E-mail
Set up your e-mail
With the E-mail wizard, you can set up your corporate e-
mail account, such as Microsoft Outlook or Mail for
Exchange, and your internet e-mail account.
38
Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
When setting up your corporate e-mail, you may be
prompted for the name of the server associated with your
e-mail address. For details, contact your company IT
department.
1. To open the wizard, in the home screen, select Set up
e-mail.
2. Enter your e-mail address and password. If the wizard
is not able to configure your e-mail settings
automatically, you need to select your e-mail account
type, and enter the related account settings.
If your device contains any additional e-mail clients, those
are offered to you when you open the wizard.
ActiveSync
Use of the Mail for Exchange is limited to over-the-air
synchronisation of PIM information between the Nokia
device and the authorised Microsoft Exchange server.
Send e-mail
Select Menu > Messaging.
1. Select your mailbox and Options > Create email.
2. In the To field, enter the recipient's e-mail address. If
the recipient's e-mail address can be found in Contacts,
start entering the recipient's name, and select the
recipient from the proposed matches. If you add
several recipients, insert ; to separate the e-mail
addresses. Use the Cc field to send a copy to other
recipients, or the Bcc field to send a blind copy to
recipients. If the Bcc field is not visible, select
Options > More > Show Bcc field.
3. In the Subject field, enter the subject of the e-mail.
4. Enter your message in the text area.
5. Select Options and from the following:
•Add attachment — Add an attachment to the
message.
•Priority — Set the priority of the message.
•Flag — Flag the message for follow-up.
•Insert template — Insert text from a template.
•Add recipient — Add recipients to the message
from Contacts.
•Editing options — Cut, copy, or paste the selected
text.
•Input options — Activate or deactivate predictive
text input, or select the writing language.
6. Select Options > Send.
Add attachments
Select Menu > Messaging.
To write an e-mail message, select your mailbox and
Options > Create email.
To add an attachment to the e-mail message, select
Options > Add attachment.
To remove the selected attachment, select Options >
Remove attachment.
Read e-mail
Select Menu > Messaging.
39
Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Important: Exercise caution when opening
messages. Messages may contain malicious software or
otherwise be harmful to your device or PC.
To read a received e-mail message, select the mailbox, and
select the message from the list.
To reply to the message sender, select Options > Reply.
To reply to the sender and all other recipients, select
Options > Reply to all.
To forward the message, select Options > Forward.
Download attachments
Select Menu > Messaging and a mailbox.
To view the attachments in a received e-mail message,
scroll to the attachment field, and select Options >
Actions. If there is one attachment in the message, select
Open to open the attachment. If there are several
attachments, select View list to see a list showing which
attachments have been downloaded or not.
To download the selected attachment or all the
attachments from the list to your device, select Options >
Download or Download all. The attachments are not
saved in your device, and are deleted when you delete the
message.
To save the selected attachment or all the downloaded
attachments in your device, select Options > Save or
Save all.
To open the selected, downloaded attachment, select
Options > Actions > Open.
Reply to a meeting request
Select Menu > Messaging and a mailbox.
Select a received meeting request, Options, and from the
following:
•Accept — Accept the meeting request.
•Decline — Decline the meeting request.
•Forward — Forward the meeting request to another
recipient.
•Remove from calendar — Remove a cancelled
meeting from your calendar.
Search for e-mail messages
Select Menu > Messaging and a mailbox.
To search for items within the recipients, subjects, and
body texts of the e-mail messages in the mailbox, select
Options > Search.
To stop the search, select Options > Stop search.
To start a new search, select Options > New search.
Delete e-mails
Select Menu > Messaging and a mailbox.
To delete an e-mail message, select the message and
Options > Actions > Delete. The message is placed in
the Deleted items folder, if available. If there is no Deleted
items folder available, the message is deleted
permanently.
To empty the Deleted items folder, select the folder and
Options > Empty deleted items.
40
Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Switch between e-mail folders
Select Menu > Messaging and a mailbox.
To open another e-mail folder or mailbox, select Inbox at
the top of the display. Select the e-mail folder or mailbox
from the list.
Disconnect from the mailbox
Select Menu > Messaging and a mailbox.
To cancel the synchronisation between the device and the
e-mail server, and to work with e-mail without a wireless
connection, select Options > Disconnect. If your mailbox
does not have the Disconnect option, select Options >
Exit to disconnect from the mailbox.
To start the synchronisation again, select Options >
Connect.
Set an out-of-office reply
Select Menu > Email.
To set an out-of-office reply, if available, select your
mailbox andOptions > Settings > Mailbox > Out of
office > On or Options > Settings > Mailbox
settings > Out of office > On.
To enter the text for the reply, select Out of office reply.
General e-mail settings
Select Menu > Email and Settings > Global settings.
Select from the following:
•Message list layout — Select whether the e-mail
messages in Inbox display one or two lines of text.
•Body text preview — Preview messages when
scrolling through the list of e-mail messages in Inbox.
•Title dividers — To be able to expand and collapse the
list of e-mail messages, select On.
•Download notifications — Set the device to display
a notification when an e-mail attachment has been
downloaded.
•Warn before delete — Set the device to display a
warning before you delete an e-mail message.
•Home screen — Define how many lines of e-mail are
displayed in the home screen information area.
Write and send
messages
Select Menu > Messaging.
Important: Exercise caution when opening
messages. Messages may contain malicious software or
otherwise be harmful to your device or PC.
Before you can create a multimedia message or write an
e-mail, you must have the correct connection settings in
place.
The wireless network may limit the size of MMS messages.
If the inserted picture exceeds this limit, the device may
make it smaller so that it can be sent by MMS.
Check the size limit of e-mail messages with your service
provider. If you attempt to send an e-mail message that
exceeds the size limit of the e-mail server, the message is 41
Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
left in the Outbox folder, and the device attempts to resend
it periodically. Sending an e-mail requires a data
connection, and continuous attempts to resend the e-mail
may increase your data transfer costs. In the Outbox folder,
you can delete such a message, or move it to the Drafts
folder.
1. Select New message > Message to send a text or
multimedia message (MMS), Audio message to send
a multimedia message that includes one sound clip, or
E-mail to send an e-mail message.
2. In the To field, press the scroll key to select recipients
or groups from the contacts list, or enter the recipient’s
phone number or e-mail address. To add a semicolon
(;) that separates the recipients, press *. You can also
copy and paste the number or address from the
clipboard.
3. In the subject field, enter the subject of the e-mail. To
change the fields that are visible, select Options >
Message header fields.
4. In the message field, write the message. To insert a
template or note, select Options > Insert content >
Insert text > Template or Note.
5. To add a media file to a multimedia message, select
Options > Insert content, the file type or source, and
the desired file. To insert a business card, slide, note,
or some other file to the message, select Options >
Insert content > Insert other.
6. To capture an image or record a video or sound clip for
a multimedia message, select Options > Insert
content > Insert image > New, Insert video
clip > New, or Insert sound clip > New.
7. To add an attachment to an e-mail, select Options and
the attachment type. E-mail attachments are indicated
by .
8. To send the message, select Options > Send, or press
the call key.
Note: The message sent icon or text on your device
screen does not indicate that the message is received at
the intended destination.
Your device supports text messages beyond the limit for a
single message. Longer messages are sent as two or more
messages. Your service provider may charge accordingly.
Characters with accents, other marks, or some language
options take more space, and limit the number of
characters that can be sent in a single message.
You may not be able to send video clips that are saved in
the MP4 file format or that exceed the size limit of the
wireless network in a multimedia message.
42
Messaging
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
7. Phone
To make and receive calls, the device must be switched on,
it must have a valid SIM card installed, and you must be
located in the service area of a cellular network.
To make or receive a net call, your device must be
connected to a net call service. To connect to a net call
service, your device must be in the coverage of a
connection network, such as a wireless LAN (WLAN) access
point.
Voice calls
Note: The actual invoice for calls and services from
your service provider may vary, depending on network
features, rounding off for billing, taxes, and so forth.
Noise cancellation
Noise from the surrounding environment is actively
removed from your speech using dual microphone noise
cancellation technology.
Noise picked up by a secondary microphone is removed
from the signal of the main microphone into which you
speak. This results in a significantly improved
transmission of speech in a noisy environment.
Noise cancellation is not available when using the
loudspeaker or a headset.
For the best results,
hold the device with
the main
microphone
towards your
mouth.
Answer a call
To answer a call, press the call key.
To reject a call, press the end key.
To mute the ringing tone instead of answering a call, select
Silence.
When you have an active call and the call waiting function
(network service) is activated, press the call key to answer
a new incoming call. The first call is put on hold. To end
the active call, press the end key.
Make a call
To make a call, enter the phone number, including the area
code, and press the call key.
Tip: For international calls, add the + character that
replaces the international access code, and enter
the country code, area code (omit the leading 0, if
necessary), and phone number. 43
Phone
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
To end the call or cancel the call attempt, press the end
key.
To make a call using the saved contacts, open the contacts.
Enter the first letters of the name, scroll to the name, and
press the call key.
To make a call using the log, press the call key to view up
to 20 numbers that you last called or attempted to call.
Scroll to the desired number or name, and press the call
key.
To adjust the volume of an active call, use the volume keys.
To switch from a voice call to a video call, select Options >
Switch to video call. The device ends the voice call and
makes a video call to the recipient.
Make a conference call
1. To make a conference call, enter a participant's phone
number, and press the call key.
2. When the participant answers, select Options > New
call.
3. When you have made a phone call to all the
participants, select Options > Conference to merge
the calls into a conference call.
To mute the microphone during the call, press the mute
key.
To drop a participant from the conference call, select
Options > Conference > Drop participant and the
participant.
To discuss privately with a conference call participant,
select Options > Conference > Private and the
participant.
Voice mail
Select Menu > Ctrl. panel > Phone > Call mailbox.
When you open the Voice mail application (network
service) for the first time, you are asked to enter the
number of your voice mailbox.
To call your voice mailbox, scroll to Voice mailbox, and
select Options > Call voice mailbox.
If you have configured net call settings to your device and
have an internet call mailbox, to call the mailbox, scroll to
the mailbox, and select Options > Call internet call
mbx..
To call your mailbox in the home screen, press and hold
1; or press 1 and then the call key. Select the mailbox you
want to call.
To change the mailbox number, select the mailbox and
Options > Change number.
Video calls
About video calls
To be able to make a video call, you need to be in the
coverage of a UMTS network. For availability and
subscription to video call services, contact your service
provider. While talking, you can see a real-time, two-way
video between you and the recipient of the call, if the
recipient has a compatible device. The video image
recorded by the camera in your device is shown to the
video call recipient. A video call can only be made between
two parties.
44
Phone
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Make a video call
To make a video call, enter the phone number or select the
recipient from the contacts list and Options > Call >
Video call. When the video call starts, the camera of the
device is activated. If the camera is already in use, video
sending is disabled. If the recipient of the call does not
want to send video back to you, a still image is shown
instead. To define the still image sent from your device
instead of video, select Menu > Ctrl. panel > Settings
and Phone > Call > Image in video call.
To disable the sending of audio, video, or video and audio,
select Options > Disable > Sending audio, Sending
video, or Sending aud. & video.
To adjust the volume of an active video call, use the volume
keys.
To use the loudspeaker, select Options > Activate
loudspeaker. To mute the loudspeaker and use the
earpiece, select Options > Activate handset.
To swap the places of images, select Options > Swap
images.
To zoom the image on the display, select Options >
Zoom and scroll up or down.
To end the video call and make a new voice call to the same
recipient, select Options > Switch to voice call.
Video sharing
About Video sharing
Use Video sharing (network service) to send live video or
a video clip from your mobile device to another
compatible mobile device during a voice call.
When you activate Video sharing, the loudspeaker is
automatically activated. If you do not want to use the
loudspeaker for the voice call while sharing video, you can
also use a compatible headset.
Warning: Continuous exposure to high volume
may damage your hearing. Listen to music at a moderate
level, and do not hold the device near your ear when the
loudspeaker is in use.
Note: Video sharing involves transmission of data.
Check with your service provider for details about fees in
your home network and when roaming on other
networks. Your service provider can explain what charges
will apply. The availability of video sharing depends on the
offer of your service provider. Check with your service
provider for the availability of video sharing.
Video sharing requirements
Video sharing requires a 3G connection. For more
information on the service, 3G network availability, and
fees associated with using this service, contact your
service provider.
To use video sharing you must do the following: 45
Phone
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Ensure that your device is set up for person-to-person
connections.
•Ensure you have an active 3G connection and are within
3G network coverage. If you move outside the 3G
network during a video sharing session, the sharing
stops while your voice call continues.
•Ensure that both the sender and recipient are
registered to the 3G network. If you invite someone to
a sharing session and the recipient’s device is not
within 3G network coverage, does not have video
sharing installed, or person-to-person connections set
up, the recipient does not receive invitations. You
receive an error message that indicates that the
recipient cannot accept the invitation.
Video sharing settings
To adjust video sharing settings, select Menu > Ctrl.
panel > Settings and Connection > Video sharing.
To set up video sharing, you need person-to-person and
UMTS connection settings.
Person-to-person connection settings
A person-to-person connection is also known as a session
initiation protocol (SIP) connection. The SIP profile
settings must be configured in your device before you can
use video sharing. Contact your service provider for the SIP
profile settings, and save them to your device. Your service
provider may send you the settings or give you a list of the
needed parameters.
To add a SIP address to a contact:
1. Select Menu > Contacts.
2. Select the contact, or create a new contact.
3. Select Options > Edit.
4. Select Options > Add detail > Share video.
5. Enter the SIP address in the format
username@domainname (you can use an IP address
instead of a domain name).
If you do not know the SIP address for the contact, you
can use the phone number of the recipient, including
the country code, to share video (if supported by the
network service provider).
UMTS connection settings
To set up your UMTS connection:
•Contact your service provider to establish an agreement
for you to use the UMTS network.
•Ensure that the UMTS access point connection settings
for your device are configured properly. For more
information about the settings, contact your service
provider.
Share live video or video clips
During an active voice call, select Options > Share
video.
1. To share live video during the call, select Live video.
To share a video clip, select Video clip and the clip you
want to share.
You may need to convert the video clip into a suitable
format to be able to share it. If your device notifies you
that the video clip must be converted, select OK. Your
device must have a video editor for the conversion to
work.
46
Phone
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
2. If the recipient has several SIP addresses or phone
numbers including the country code saved in the
contacts list, select the desired address or number. If
the SIP address or phone number of the recipient is not
available, enter the address or number of the recipient
including the country code, and select OK to send the
invitation. Your device sends the invitation to the SIP
address.
Sharing begins automatically when the recipient
accepts the invitation.
Options during video sharing
Zoom the video (available for sender only).
Adjust the brightness (available for sender only).
or Mute or unmute the microphone.
or Turn the loudspeaker on and off.
or Pause and resume video sharing.
Switch to full screen mode (available for receiver
only).
3. To end the sharing session, select Stop. To end the
voice call, press the end key. When you end the call,
video sharing also ends.
To save the live video you shared, select Yes when
prompted. The device notifies you of the memory location
of the saved video. To define the preferred memory
location, select Menu > Ctrl. panel > Settings and
Connection > Video sharing > Preferred saving
memory.
If you access other applications while you are sharing a
video clip, the sharing is paused. To return to the video
sharing view, and to continue sharing, in the home screen,
select Options > Continue.
Accept an invitation
When someone sends you a video sharing invitation, the
invitation message displays the sender’s name or SIP
address. If your device is not set to silent, it rings when
you receive an invitation.
If someone sends you a share invitation and you are not
within UMTS network coverage, you will not know that you
received an invitation.
When you receive an invitation, select from the following:
•Yes — Accept the invitation, and activate the sharing
session.
•No — Reject the invitation. The sender receives a
message that you rejected the invitation. You can also
press the end key to reject the invitation and end the
voice call.
To mute the video on your device, select Options >
Mute.
To play the video at the original volume, select Options >
Original volume. This does not affect the audio playback
of the other party of the phone call.
To end the sharing session, select Stop. To end the voice
call, press the end key. When you end the call, also video
sharing ends.
47
Phone
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Internet calls
About internet calls
With the internet call service (network service), you can
make and receive calls over the internet. Internet calls can
be established between computers, between mobile
phones, and between a VoIP device and a traditional
telephone.
To be able to use the service, you must subscribe to the
service, and have a user account.
To make or receive an internet call, you must be in the
service area of a wireless LAN, and connected to an
internet call service.
Activate internet calls
Select Menu > Contacts. Scroll left, and select the
internet calls service from the list.
To make or receive internet calls, contact your service
provider to receive the internet call connection settings.
To connect to an internet call service, your device must be
in a network service area.
To activate your internet call service, select Options >
Activate service.
To search for available wireless LAN (WLAN) connections,
select Options > Search for WLAN.
Make internet calls
When you have activated the internet call feature, you can
make an internet call from all applications where you can
make a regular voice call, such as the contacts list or log.
For example, in the contacts list, scroll to the desired
contact, and select Options > Call > Internet call.
To make an internet call in the home screen, enter the
phone number or internet address, and select Net call.
1. To make an internet call to an internet address that
does not start with a digit, press any number key in the
home screen, then press # for a few seconds to clear
the display and to switch from number mode to letter
mode.
2. Enter the internet address, and press the call key.
Internet call settings
Select Menu > Contacts. Scroll left, and select the
internet calls service from the list.
To view or edit internet call settings, select Options >
Settings and from the following:
•Service connectivity — Select the destination settings
for internet call connectivity, and edit destination
details.
To change a destination, scroll to the service, and select
Change.
•Availability requests — Select whether to
automatically accept all incoming presence requests
without a confirmation query.
•Service information — View technical information
about the selected service.
48
Phone
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Voice functions
Voice functions
With the Voice functions application, you can use your
voice to carry out basic tasks. You can call or send audio
messages to contacts, answer calls, and listen to your
messages. You need to record a personal wake-up
command before you can carry out these tasks. When
Voice functions is activated, the device is listening for your
wake-up command. When the wake-up command is given,
the tasks can be carried out.
Activate Voice functions
Select Menu > Applications > Voice funct..
To activate the application, do the following:
1. Select Rec. commands > Start command to record
the wake-up command.
2. In the main view, select Voice functions.
3. Say the wake-up command.
Select from the following:
•Rec. commands — Record commands.
•Settings — Change the settings.
•What is this? — Read information about the
application.
The available options may vary.
49
Phone
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
8. Internet
With your Nokia E52, you can browse the web and
download and install new applications to your device. You
can also use your device as a modem and connect your PC
to the internet.
Browser
About Browser
Select Menu > Internet > Web.
With the Browser application, you can view hypertext
markup language (HTML) web pages on the internet as
originally designed. You can also browse web pages that
are designed specifically for mobile devices, and use
extensible hypertext markup language (XHTML), or the
wireless markup language (WML).
To browse the web, you need to have an internet access
point configured in your device. The browser requires
network service.
Browse the web
Select Menu > Internet > Web.
Shortcut: To start the browser, press and hold 0 in
the home screen.
To browse the web, in the bookmarks view, select a
bookmark, or start to enter a web address (the field
opens automatically), and select Go to.
Some web pages may contain material, such as graphics
and sounds, that requires a large amount of memory to
view. If your device runs out of memory while loading such
a web page, the graphics on the page are not shown.
To browse web pages with graphics disabled, to save
memory and increase the page loading speed, select
Options > Settings > Page > Load content > Text
only.
To enter a web address, select Options > Go to > New
web page.
To refresh the content of the web page, select Options >
Web page options > Reload.
To save the current web page as a bookmark, select
Options > Web page options > Save as bookmark.
To view snapshots of the web pages you have visited
during the current browsing session, select Back
(available if History list is activated in the browser
settings and the current web page is not the first web page
you visit).
To prevent or allow the automatic opening of multiple
windows, select Options > Web page options > Block
pop-ups or Allow pop-ups.
To view the shortcut key map, select Options > Keypad
shortcuts. To edit the shortcut keys, select Edit.
50
Internet
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Tip: To minimise the browser without exiting the
application or connection, press the end key once.
Browser toolbar
The browser toolbar helps you select frequently used
functions of the browser.
To open the toolbar, press and hold the scroll key on a
blank spot on a web page.
To move within the toolbar, scroll left or right.
To select a function, press the scroll key.
To view a description of a toolbar icon's function, scroll to
the toolbar icon.
Navigate pages
Mini Map and Page overview help you navigate web pages
that contain a large amount of information.
To activate Mini Map, select Options > Settings >
General > Mini map > On. When you scroll through a
large web page, Mini Map opens and shows an overview
of the page.
To move in Mini Map, scroll left, right, up, or down. When
you find the desired location, stop scrolling. Mini Map
disappears and leaves you at the selected location.
When you are browsing a web page that contains a large
amount of information, you can also use Page overview to
view what kind of information the web page contains.
To see an overview of the current web page, press 8. To
find the desired spot on the web page, scroll up, down,
left, or right. Press 8 again to zoom in and view the desired
section of the web page.
Web feeds and blogs
Select Menu > Internet > Web.
Web feeds are XML files on web pages that are used to
share, for example, the latest news headlines or blogs. It
is common to find web feeds on web, blog, and wiki pages.
The browser application automatically detects if a web
page contains web feeds.
If web feeds are available, to subscribe to a web feed,
select Options > Subscribe to web feeds.
To update a web feed, in the Web feeds view, select a feed
and Options > Web feed options > Refresh.
To define whether the web feeds are updated
automatically, in the Web feeds view, select Options >
Edit > Edit. This option is not available if one or more
feeds are marked.
Widgets
Your device supports widgets. Widgets are small,
downloadable web applications that deliver multimedia,
news feeds, and other information, such as weather
reports, to your device. Installed widgets appear as
separate applications in the Applications folder.
To find and download widgets, visit the Ovi Store at
store.ovi.com.
You can also install widgets on a compatible memory card
(if available). 51
Internet
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
The default access point for widgets is the same as in the
web browser. When active in the background, some
widgets may update information automatically to your
device.
Using widgets may involve the transmission of large
amounts of data through your service provider's network.
For information about data transmission charges, contact
your service provider.
Content search
Select Menu > Internet > Web.
To search for text, phone numbers, or e-mail addresses
within the current web page, select Options > Find
keyword and the appropriate option.
To go to the next match, scroll down.
To go to the previous match, scroll up.
Tip: To search for text within the current web page,
press 2.
Bookmarks
Select Menu > Internet > Web.
Select Options > Go to > Bookmarks. You can select
web addresses from a list or from a collection of
bookmarks in the Recently visited pages folder.
If you start to enter a web address, the field opens
automatically.
indicates the homepage defined for the default access
point.
To go to a new web page, select Options > Go to > New
web page.
To send and add bookmarks, or to set a bookmark as the
homepage, select Options > Bookmark options.
To edit, move, or delete bookmarks, select Options >
Bookmark manager.
Empty the cache
The information or services you have accessed are stored
in the cache memory of the device.
A cache is a memory location that is used to store data
temporarily. If you have tried to access or have accessed
confidential information requiring passwords, empty the
cache after each use.
To empty the cache, select Options > Clear privacy
data > Cache.
End the connection
To end the connection and close the browser, select
Options > Exit.
To delete the information the network server collects
about your visits to various web pages, select Options >
Clear privacy data > Cookies.
Connection security
If the security indicator ( ) is displayed during a
connection, the data transmission between the device and
the internet gateway or server is encrypted.
52
Internet
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
The security icon does not indicate that the data
transmission between the gateway and the content server
(where the data is stored) is secure. The service provider
secures the data transmission between the gateway and
the content server.
Security certificates may be required for some services,
such as banking services. You are notified if the identity of
the server is not authentic or if you do not have the correct
security certificate in your device. For more information,
contact your service provider.
Important: Even if the use of certificates makes the
risks involved in remote connections and software
installation considerably smaller, they must be used
correctly in order to benefit from increased security. The
existence of a certificate does not offer any protection by
itself; the certificate manager must contain correct,
authentic, or trusted certificates for increased security to
be available. Certificates have a restricted lifetime. If
"Expired certificate" or "Certificate not valid yet" is shown,
even if the certificate should be valid, check that the
current date and time in your device are correct.
Before changing any certificate settings, you must make
sure that you really trust the owner of the certificate and
that the certificate really belongs to the listed owner.
Web settings
Select Menu > Internet > Web and Options >
Settings and from the following:
General settings
•Access point — Change the default access point. Some
or all access points may be preset for your device by
your service provider. You may not be able to change,
create, edit, or remove them.
•Homepage — Define the homepage.
•Mini map — Turn Mini Map on or off. Mini Map helps
with web page navigation.
•History list — If you select On, while browsing, to see
a list of the pages you have visited during the current
session, select Back.
•Security warnings — Hide or show security
notifications.
•Java/ECMA script — Enable or disable the use of
scripts.
•Java/ECMA script errors — Select whether you want
to receive script notifications.
•Open while downloading — Select whether you
want to be able to open a file while it is being
downloaded.
Page settings
•Load content — Select whether you want to load
images and other objects while browsing. If you select
Text only, to load images or objects later during
browsing, select Options > Display options > Load
images.
•Default encoding — If text characters are not shown
correctly, you can select another encoding according to
the language for the current page.
•Block pop-ups — Allow or block automatic opening of
different pop-ups while browsing.
•Automatic reload — Select whether you want the web
pages to be refreshed automatically while browsing.
•Font size — Define the font size that is used for web
pages.
Privacy settings 53
Internet
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Recently visited pages — Enable or di sable automatic
bookmark collecting. If you want to continue saving the
addresses of the visited web pages into the Recently
visited pages folder, but hide the folder from the
bookmarks view, select Hide folder.
•Form data saving — Select whether you want the
password data or data you enter on different forms on
a web page to be saved and used the next time you
open the page.
•Cookies — Enable or disable the receiving and sending
of cookies.
Web feed settings
•Acc. point for auto-update — Select the desired
access point for updating. This option is only available
when Automatic updates is active.
•Update when roaming — Select whether you want
the web feeds to be updated automatically when
roaming.
Browse the intranet
Select Menu > Office > Intranet.
To connect to an intranet, open the Intranet application
and select Options > Connect. If you have several
intranet destinations defined in Connection settings,
select Change destination to select which intranet to
browse.
To define the settings for the intranet connection, select
Options > Settings.
Ovi Store
About Ovi Store
In Ovi Store, you can download mobile games,
applications, videos, images, and ringing tones to your
device. Some of the items are free of charge; others you
need to purchase using your credit card or through your
phone bill. Ovi Store offers you content that is compatible
with your mobile device and relevant to your tastes and
location.
The content in Ovi Store is sorted into the following
categories:
•Recommended
•Games
•Personalisation
•Applications
•Audio & video
Connect your computer
to web
You can use your device to connect your PC to the web.
1. Connect the data cable to the USB connectors of your
device and your PC.
2. Select Connect PC to web. The necessary software is
automatically installed from your device to the PC.
54
Internet
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
3. Accept the installation in your PC. Accept also the
connection, if prompted. When the connection to the
web is established, the web browser of your PC opens.
You must have administrator rights to your PC, and the
autorun option enabled in the PC.
If you use Mac OS, select PC Suite as the connection
method. For more information, see www.nokia.com/
support.
55
Internet
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
9. Travelling
Need directions? Looking for a restaurant? Your device has
the tools to get you where you want to be.
Positioning (GPS)
You can use applications such as GPS data to determine
your location or measure distances. These applications
require a GPS connection.
About GPS
The coordinates in the GPS are expressed using the
international WGS-84 coordinate system. The availability
of the coordinates may vary by region.
The Global Positioning System (GPS) is operated by the
government of the United States, which is solely
responsible for its accuracy and maintenance. The
accuracy of location data can be affected by adjustments
to GPS satellites made by the United States government
and is subject to change with the United States
Department of Defense civil GPS policy and the Federal
Radionavigation Plan. Accuracy can also be affected by
poor satellite geometry. Availability and quality of GPS
signals may be affected by your location, buildings,
natural obstacles, and weather conditions. GPS signals
may not be available inside buildings or underground and
may be impaired by materials such as concrete and metal.
GPS should not be used for precise location measurement,
and you should never rely solely on location data from the
GPS receiver and cellular radio networks for positioning or
navigation.
The trip meter has limited accuracy, and rounding errors
may occur. Accuracy can also be affected by availability
and quality of GPS signals.
Different positioning methods can be enabled or disabled
in positioning settings.
Assisted GPS (A-GPS)
Your device also supports assisted GPS (A-GPS).
A-GPS requires network support.
Assisted GPS (A-GPS) is used to retrieve assistance data
over a packet data connection, which assists in calculating
the coordinates of your current location when your device
is receiving signals from satellites.
When you activate A-GPS, your device receives useful
satellite information from an assistance data server over
the cellular network. With the help of assisted data, your
device can obtain the GPS position faster.
Your device is preconfigured to use the Nokia A-GPS
service, if no service provider-specific A-GPS settings are
available. The assistance data is retrieved from the Nokia
A-GPS service server only when needed.
To disable the A-GPS service, select Menu >
Applications > GPS > GPS data and Options >
Positioning settings > Positioning methods >
Assisted GPS > Disable.
56
Travelling
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
You must have an internet access point defined in the
device to retrieve assistance data from the Nokia A-GPS
service over a packet data connection. The access point for
A-GPS can be defined in positioning settings. A wireless
LAN (WLAN) access point cannot be used for this service.
Only a packet data internet access point can be used. Your
device asks you to select the internet access point when
GPS is used for the first time.
Hold your device correctly
The GPS receiver is located on the back of the device. When
using the receiver, make sure that you do not cover the
antenna with your hand.
Establishing a GPS connection may take from a
couple of seconds to several minutes.
Establishing a GPS connection in a vehicle may
take longer.
The GPS receiver draws its power from the
device battery. Using the GPS receiver may
drain the battery faster.
Tips on creating a GPS
connection
Check satellite signal status
To check how many satellites your device has found, and
whether your device is receiving satellite signals, select
Menu > Applications > GPS and GPS data > Options >
Satellite status.
If your device has found
satellites, a bar for each satellite
is shown in the satellite info
view. The longer the bar, the
stronger the satellite signal.
When your device has received
enough data from the satellite signal to calculate your
location, the bar colour changes.
To view the positions of found satellites, select Chg.
view.
Initially your device must receive signals from at least four
satellites to be able to calculate your location. When the
initial calculation has been made, it may be possible to
continue calculating your location with three satellites.
However, the accuracy is generally better when more
satellites are found.
If no satellite signal can be found, consider the following:
•If you are indoors, go outdoors to receive a better
signal.
•If you are outdoors, move to a more open space.
•Ensure that your hand does not cover the GPS antenna
of your device.
•If the weather conditions are bad, the signal strength
may be affected.
•Some vehicles have tinted (athermic) windows, which
may block the satellite signals.
57
Travelling
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Maps
About Maps
Select Menu > Applications > GPS > Maps.
With Maps, you can see your current location on the
map, browse maps of different cities and countries, search
for places of interest, plan routes from one location to
another, save locations, and send them to compatible
devices. You can also purchase traffic information and
navigation services, if available for your country or region.
When you use Maps for the first time, you may need to
select an internet access point for downloading maps.
When you have an active data connection and browse the
map on the display, a new map is automatically
downloaded, if you browse to an area not covered by the
maps that have already been downloaded. You can also
use the Nokia Map Loader PC software to download maps.
To install Nokia Map Loader to a compatible PC, go to
www.nokia.com/maps.
Tip: To avoid data transfer costs, you can also use
Maps without an internet connection, and browse
the maps that are saved in your device or memory
card, if available in your device.
Note: Downloading content such as maps, satellite
images, voice files, guides or traffic information may
involve transmission of large amounts of data (network
service).
Almost all digital cartography is inaccurate and
incomplete to some extent. Never rely solely on the
cartography that you download for use in this device.
Network positioning
You can use the mobile network to find your current
location. This is faster but less accurate than with GPS, and
you cannot use the location as a starting point for
navigation.
Select Menu > Applications > GPS > Maps.
Use the mobile network for positioning — Select the
network-based positioning method from the device
settings.
When you start the Maps application and your GPS
connection is ready, GPS replaces mobile network as the
positioning method.
Move on a map
Select Menu > Applications > GPS > Maps.
When the GPS connection is active, shows your current
location on the map.
View your current or last known location — Select
Options > My position.
Move on the map — Use the scroll key. By default, the
map is oriented north.
When you have an active data connection and browse the
map on the display, a new map is automatically
downloaded, if you browse to an area not covered by the
maps that have already been downloaded. The maps are
58
Travelling
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
automatically saved in the device memory or on a
compatible memory card, if available in your device.
Zoom in and out on the map — Press * and #.
Change the map type — Select Options > Map mode.
Display indicators
Select Menu > Applications > GPS > Maps.
The GPS indicator shows the availability of
the satellite signals. One bar is one satellite. When the
device tries to find satellite signals, the bar is yellow. When
the device receives enough data from the satellites for GPS
to calculate your location, the bar turns green. The more
green bars, the more reliable the location calculation.
Initially, your device must receive signals from at least four
satellites to calculate your location. After the initial
calculation, signals from three satellites may be enough.
The data transfer indicator shows the
internet connection used, and the amount of data
transferred since the application started.
Find locations
To search for locations, press the scroll key and select
Explore. Start entering the location name in the search
field. The device suggests matching nearby locations.
Select the location from the list, or enter the location name
in the search field, and select Search.
1. To find a specific address, select Options > Address
search.
2. Start entering the required information. The fields
marked with an asterisk (*) are mandatory.
3. Select the address from the list of suggested matches.
4. Select Options > Search.
To find an address saved in the contacts list, select
Options > Address search > Options > Select from
Contacts.
To search for locations by their coordinates, select
Options > Address search > Options > Search by
coordinates. To select the coordinate format, scroll up or
down.
To search for locations in specific categories, such as
restaurants or shopping, press the scroll key, and select
Explore. Select a category, and enter the search terms in
the search field.
Plan routes
You can create routes and view them on the map.
Select Menu > Applications > GPS > Maps.
Create a route
1. Go to your starting point on the map.
2. Press the scroll key, and select Add to route.
3. Select Add new route point, and add the destination
and more locations to the route.
Change the order of the locations in the route
1. Go to a location.
2. Press the scroll key, and select Move.59
Travelling
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
3. Go to the place where you want to move the location,
and select Select.
Edit the route — Press the scroll key, and select Edit
route.
Show the route on the map — Select Show route.
Navigate to the destination — Select Show route >
Options > Start driving or Start walking. To be able to
navigate, you need to purchase a licence.
Save the route — Select Show route > Options > Save
route.
Synchronise your favourite
locations with Ovi Maps
The Ovi website contains the internet services that Nokia
provides. The Ovi Maps section contains services related to
Maps. You can synchronise your saved locations,
collections, and routes with Ovi Maps, if you have a Nokia
account in Ovi. To create the account, visit www.ovi.com.
Select Menu > Applications > GPS > Maps.
Synchronise saved items with Ovi Maps — Select
Options > Favourites > Synchronise with Ovi.
Set the device to synchronise items automatically —
Select Options > Tools > Settings >
Synchronisation > Synchronise with Ovi > At start-
up and shut-d.. The device starts the synchronisation
when you open and close the Maps application.
Synchronising may involve the transmission of large
amounts of data through your service provider’s network.
Contact your service provider for information about data
transmission charges.
Your search history
In the history view, you can quickly return to the locations
you have recently searched for.
Select Menu > Applications > GPS > Maps.
View your search history — Select Options > History.
View the selected location on the map — Press the
scroll key, and select Show on map.
Send the location to a compatible device — Press the
scroll key, and select Send.
Add the location to a route — Press the scroll key, and
select Add to route.
Walk to your destination
When you purchase a licence for pedestrian navigation,
you can create routes that include pedestrian zones and
parks, prioritise walkways and smaller roads, and omit
motorways.
With the licence, you also get the enhanced search service
to your device, if available for your country or region. The
enhanced search service enables you to find local events
and travelling-related information when you perform
searches.
Select Menu > Applications > GPS > Maps.
Purchase a licence for pedestrian navigation — Select
Options > Shop & licences > Options > Shops for
other regions > All regions > City explorer. You can
60
Travelling
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
pay for the licence through a credit card or in your phone
bill, if supported by your service provider.
Start navigating — Go to a location, press the scroll key,
and select Walk to.
The distance between the start and end points of a
walking route is limited to a maximum of 50 kilometres
(31 miles) and the travelling speed to a maximum of 30
kph (18 mph). If the speed limit is exceeded, navigation
stops and is resumed once the speed is back within limits.
If the destination is on off-road terrain, the route is
displayed as a straight line to indicate the walking
direction.
There is no voice guidance available for pedestrian
navigation, but the device guides you with a tone or
vibration approximately 20 metres (22 yards) before you
need to turn or make another manoeuvre. The guiding
method depends on the settings of the profile currently
active in your device.
See an overview of the route — Select Options >
Route overview.
Stop navigating — Select Stop.
Drive to your destination
You can purchase a licence for navigating on foot or by car.
The licence is region-specific and can be used only in the
selected area.
To help navigating and driving, you also have lane
assistance and speed limit warning services in your device,
if available for your country or region.
Select Menu > Applications > GPS > Maps.
Purchase a licence — Select Options > Shop &
licences > Shop, and select the drive navigation option
for your region.
Start navigating by car — Go to a location, press the
scroll key, and select Drive to.
When you use car navigation for the first time, you are
asked to select the language of the voice guidance and
download the related voice guidance files.
Note: Downloading content such as maps, satellite
images, voice files, guides or traffic information may
involve transmission of large amounts of data (network
service).
Switch views during the navigation — Press the scroll
key, and select 2D view, 3D view, Arrow view, or Route
overview.
Find an alternative route — Select Options > Diff.
route.
Repeat the voice guidance — Select Options >
Repeat.
Adjust the volume of the voice guidance — Select
Options > Volume.
View the trip distance and duration — Select
Options > Dashboard.
Stop navigating — Select Stop.
Your first consideration while using Maps should be road
safety. The service should not be used by the driver of a
motor vehicle while driving.
61
Travelling
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Use Maps with the compass
Select Menu > Applications > GPS > Maps.
When the compass in your device is enabled, the circle
around the compass is green, and the map view rotates
automatically according to the direction to which the top
of the device is pointing.
To enable the compass, select Options > Tools > Turn
compass on. When the compass is not in use, the circle
around the compass is white, and the map view does not
rotate automatically.
Calibrate the compass
Your device has an internal compass. When the compass
is calibrated, the circle around the compass is green, and
the map view rotates automatically according to the
direction to which the top of the device is pointing.
The compass has limited accuracy. Electromagnetic fields,
metal objects, or other external circumstances may also
affect the accuracy of the compass. The compass should
always be properly calibrated.
To calibrate the compass, do the following:
1. Select Menu > Applications > GPS > Maps.
2. The compass is active by default. To deactivate the
compass, select Options > Tools > Turn compass
off. When the compass is deactivated, the circle around
the compass is white, and the map view does not
rotate automatically. Deactivating the compass is only
valid for the current session. When you open Maps the
next time, the compass is activated automatically.
3. Rotate
the
device
around
all axes
in a
continuous movement until the calibration indicator
changes its colour to green . If the indicator is
yellow, the accuracy of the compass is low. If the
indicator is red, the compass is not calibrated.
Maps settings
Select Menu > Applications > GPS > Maps.
Select Options > Tools > Settings and from the
following:
•Internet — Define the internet settings.
•Navigation — Define the navigation settings.
•Route — Define the routing settings.
•Map — Define the map settings.
•Synchronisation — Define the settings for
synchronising saved items with the Ovi Maps web
service.
62
Travelling
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
10. Nokia Office Tools
Nokia Office Tools support mobile business and enable
effective communication with work teams.
Active notes
Select Menu > Office > Active notes.
Active notes allows you to create, edit, and view different
kinds of notes, for example, meeting memos, hobby notes,
or shopping lists. You can insert images, videos, and sound
in the notes. You can link notes to other applications, such
as Contacts, and send notes to others.
Calculator
Select Menu > Office > Calculator.
This calculator has limited accuracy and is designed for
simple calculations.
To make a calculation, enter the first number of the
calculation. Select a function such as add or subtract from
the function map. Enter the second number of the
calculation, and select =. The calculator performs
operations in the order they are entered. The result of the
calculation remains in the editor field and can be used as
the first number of a new calculation.
The device saves the result of the last calculation in its
memory. Exiting the Calculator application or switching off
the device does not clear the memory. To recall the last
saved result the next time you open the Calculator
application, select Options > Last result.
To save the numbers or results of a calculation, select
Options > Memory > Save.
To retrieve the results of a calculation from the memory
and use them in a calculation, select Options >
Memory > Recall.
File manager
Select Menu > Office > File mgr..
About File manager
Select Menu > Office > File mgr..
With File manager, you can browse, manage, and open
files.
The available options may vary.
To map or delete drives, or to define settings for a
compatible remote drive connected to your device, select
Options > Remote drives.
Find and organise files
Select Menu > Office > File mgr..63
Nokia Office Tools
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
To find a file, select Options > Find. Enter a search term
that matches the file name.
To move and copy files and folders, or to create new
folders, select Options > Organise.
Shortcut: To apply actions to multiple items at
once, mark the items. To mark or unmark items,
press #.
Manage a memory card
Select Menu > Office > File mgr..
These options are available only if a compatible memory
card is inserted in the device.
Select Options and from the following:
•Memory card options — Rename or format a memory
card.
•Memory card password — Password protect a
memory card.
•Unlock memory card — Unlock a memory card.
Back up files to a memory card
Select Menu > Office > File mgr..
To back up files to a memory card, select the file types you
want to back up, and Options > Back up phone
memory. Ensure that your memory card has enough free
memory for the files that you have chosen to back up.
Quickoffice
About Quickoffice
Select Menu > Office > Quickoffice.
Quickoffice consists of Quickword for viewing Microsoft
Word documents, Quicksheet for viewing Microsoft Excel
worksheets, Quickpoint for Microsoft PowerPoint
presentations, and Quickmanager for purchasing
software. You can view Microsoft Office 2000, XP, 2003,
and 2007 documents (DOC, XLS, and PPT file formats) with
Quickoffice. If you have the editor version of Quickoffice,
you can also edit files.
Not all file formats or features are supported.
Work with files
Select Menu > Office > Quickoffice.
To open a file, select the file from the list.
To sort files according to the type, select Options > Sort
by.
To send files to a compatible device, select Options >
Send and the sending method.
Converter
Select Menu > Office > Converter.
The converter has limited accuracy, and rounding errors
may occur.
64
Nokia Office Tools
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Convert measurements
Select Menu > Office > Converter.
1. Scroll to the type field, and select Options >
Conversion type to open a list of measures. Select the
measurement type to use (other than currency) and
OK.
2. Scroll to the first unit field, and select Options >
Select unit. Select the unit from which to convert and
OK. Scroll to the next unit field, and select the unit to
which to convert.
3. Scroll to the first amount field, and enter the value to
convert. The other amount field changes automatically
to show the converted value.
Set base currency and
exchange rate
Select Menu > Office > Converter.
When you change base currency, you must enter new
exchange rates because all previously set exchange rates
are cleared.
Before you can make currency conversions, you must
choose a base currency and add exchange rates. The rate
of the base currency is always 1. The base currency
determines the conversion rates of the other currencies.
1. To set the exchange rate for the unit of currency, scroll
to the type field, and select Options > Currency
rates.
2. Scroll to the currency type, and enter the exchange rate
you would like to set per single unit of currency.
3. To change the base currency, scroll to the currency, and
select Options > Set as base currency.
4. Select Done > Yes to save the changes.
After you have set all the necessary exchange rates, you
can make currency conversions.
Zip manager
Select Menu > Office > Zip.
With Zip manager, you can create new archive files to store
compressed ZIP formatted files; add single or multiple
compressed files or directories to an archive; set, clear, or
change the archive password for protected archives; and
change settings, such as compression level, and file name
encoding.
You can save the archive files in the device memory or on
a memory card.
PDF reader
Select Menu > Office > Adobe PDF.
With PDF reader, you can read PDF documents on the
display of your device; search for text in the documents;
modify settings, such as zoom level and page views; and
send PDF files using e-mail.
Printing
You can print documents, such as files, notes, or messages,
from the device, or print to a file. You can print directly 65
Nokia Office Tools
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
from applications that allow printing. Select a document
you want to print andOptions > Printing options >
Print.
You can print images directly from Gallery. Select an image
you want to print and Options > To printer or kiosk.
To define printer settings, select Menu > Ctrl. panel >
Printers.
Clock
Select Menu > Applications > Clock.
In the Clock application, you can view your local time and
time zone information, set and edit alarms, or modify date
and time settings.
Alarm clock
Select Menu > Applications > Clock.
To view your active and inactive alarms, open the alarms
tab. To set a new alarm, select Options > New alarm.
Define the repetition, if needed. When an alarm is active,
is displayed.
To turn off the sounding alarm, select Stop. To stop the
alarm for a certain time period, select Snooze. If your
device is switched off when an alarm is due, your device
switches itself on and starts sounding the alarm tone.
Tip: To define the time period after which the alarm
sounds again when you set it to snooze, select
Options > Settings > Alarm snooze time.
To cancel an alarm, select Options > Remove alarm.
To change the time, date, and clock type settings, select
Options > Settings.
To automatically update the time, date, and time zone
information to your device (network service), select
Options > Settings > Automatic time update > On.
World clock
Select Menu > Applications > Clock.
To view the time in different locations, open the world
clock tab. To add locations to the list, select Options >
Add location. You can add a maximum of 15 locations to
the list.
To set your current location, scroll to a location, and select
Options > Set as current location. The location is
displayed in the clock main view, and the time in your
device is changed according to the selected location.
Ensure that the time is correct and matches your time
zone.
Clock settings
Select Options > Settings.
To change the time or date, select Time or Date.
To change the clock shown on the home screen, select
Clock type > Analogue or Digital.
To allow the mobile phone network to update the time,
date, and time zone information to your device (network
service), select Automatic time update > On.
To change the alarm tone, select Clock alarm tone.
66
Nokia Office Tools
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Dictionary
Select Menu > Office > Dictionary.
To translate words from one language to another, enter
text in the search field. As you enter text, suggestions of
words to translate are displayed. To translate a word,
select the word from the list. All languages may not be
supported.
Select Options and from the following:
•Listen — Listen to the selected word.
•History — Find previously translated words from the
current session.
•Languages — Change the source or target language,
download languages from the internet, or remove a
language from the dictionary. You cannot remove the
English language from the dictionary. You can have two
additional languages installed, besides English.
•Speech — Edit the voice feature settings. You can
adjust the speed and volume of the voice.
67
Nokia Office Tools
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
11. Media
Your device contains a variety of media applications for
both business and leisure time use.
Camera
Activate the camera
To activate the camera, select Menu > Media >
Camera.
Tip: You can also activate the camera by pressing
and holding the capture key until the Camera
application opens.
Full focus
Your device camera has a Full focus feature. Full focus
enables you to capture images in which objects in both
the foreground and background are in focus.
Capture an image
Select Menu > Media > Camera, or press the capture
key to activate the camera.
Your device supports an image capture resolution of
2048x1536 pixels. The image resolution in this guide may
appear different.
To capture an image, use the display as a viewfinder, and
press the capture key. The device saves the image in
Gallery.
To zoom in or out before capturing an image, use the zoom
keys.
The toolbar provides you with shortcuts to different items
and settings before and after capturing an image or
recording a video. Select to a toolbar item and press the
scroll key.
Switch to image mode.
Switch to video mode.
Select the scene.
Switch the video light on or off (video mode only)
Select the flash mode (images only).
Activate the self-timer (images only).
Activate sequence mode (images only).
Select a colour tone.
Adjust the white balance.
Adjust the exposure compensation (images only).
The available options vary depending on the capture mode
and view you are in. The settings return to the default
values when you close the camera.
To customise the camera toolbar, switch to image mode,
and select Options > Customise toolbar.
68
Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
To view the toolbar before and after capturing an image
or recording a video, select Options > Show toolbar.
To view the toolbar only when you need it, select
Options > Hide toolbar.
Record videos
Select Menu > Media > Camera.
1. If the camera is in image mode, select video mode from
the toolbar.
2. To start recording, press the capture key.
3. To pause recording, select Pause. Select Continue to
resume recording.
4. To stop recording, select Stop. The video clip is
automatically saved in Gallery. The maximum length of
the video clip depends on the available memory.
Gallery
About Gallery
Select Menu > Media > Gallery.
Gallery is a storage place for your images, video and sound
clips, songs, and streaming links.
Main view
Select Menu > Media > Gallery.
Select from the following:
•Images — View images and video clips in Photos.
•Video clips — View video clips in Video centre.
•Songs — Open Music player.
•Sound clips — Listen to sound clips.
•Streaming links — View and open streaming
links.
•Presentations — View presentations.
You can browse and open folders and copy and move items
to folders. You can also create albums and copy and add
items to albums.
Files stored on your compatible memory card (if inserted)
are indicated with .
To open a file, select the file from the list. Video clips and
streaming links open and play in Video centre, and music
and sound clips in Music player.
To copy or move files to another memory location, select
a file, Options > Move and copy, and the appropriate
option.
Sound clips
Select Menu > Media > Gallery and Sound clips.
This folder contains all the sound clips you have
downloaded from the web. The sound clips created with
the Recorder application with MMS optimised or normal
quality settings are also saved in this folder, but the sound
clips created with high quality settings are stored in the
Music player application.
To listen to a sound file, select the file from the list.
To rewind or fast-forward, scroll left or right.
To download sounds, select Downld. sounds.
69
Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Streaming links
Select Menu > Media > Gallery and Streaming links.
To open a streaming link, select the link from the list.
To add a new streaming link, select Options > New
link.
Presentations
Select Menu > Media > Gallery.
With presentations, you can view scalable vector graphics
(SVG) and flash files (SWF), such as cartoons and maps. SVG
images maintain their appearance when printed or
viewed with different screen sizes and resolutions.
To view files, select Presentations. Go to an image, and
select Options > Play. To pause playing, select Options >
Pause.
To zoom in, press 5. To zoom out, press 0.
To rotate the image 90 degrees clockwise or
anticlockwise, press 1 or 3, respectively. To rotate the
image 45 degrees, press 7 or 9.
To switch between full and normal screen mode, press *.
Photos
About Photos
Select Menu > Media > Gallery > Images and from the
following:
•Captured — View all the images and videos you have
captured.
•Months — View images and videos categorised by the
month they where captured.
•Albums — View the default albums and the ones you
have created.
•Tags — View the tags you have created for each item.
•Downloads — View items and videos downloaded
from the web or received as a multimedia or e-mail
message.
•All — View all items.
•Share online — Post your images or videos to the web.
Files stored on your compatible memory card (if inserted)
are indicated with .
To copy or move files to another memory location, select
a file, Options > Move and copy, and from the available
options.
View images and videos
Select Menu > Media > Gallery > Images and from the
following:
•All — View all images and videos.
•Captured — View images captured and video clips
recorded with the camera of your device.
•Downloads — View downloaded video clips.
70
Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Images and video clips
can also be sent to you
from a compatible
device. To be able to
view a received image
or video clip in Photos,
you must first save it.
The images and video
clip files are in a loop
and ordered by date
and time. The number of files is displayed. To browse the
files one by one, scroll left or right. To browse files in
groups, scroll up or down.
To open a file, select the file. When an image opens, to
zoom in the image, use the zoom keys. The zooming ratio
is not stored permanently.
To edit an image or a video clip, select Options > Edit.
To see where an image marked with was captured,
select Options > Show on map.
To print your images on a compatible printer, select
Options > Print.
To move images to an album for later printing, select
Options > Add to album > Print later.
Active toolbar
The active toolbar is available only when you have selected
an image or a video clip in a view.
In the active toolbar, go to different items, and select the
desired option. The available options vary depending on
the view you are in and whether you have selected an
image or a video clip.
To hide the toolbar, select Options > Hide controls. To
activate the active toolbar when it is hidden, press the
scroll key.
Select an image or a video clip and from the following:
Play the video clip.
Send the image or video clip.
Upload the image or video clip to a compatible online
album (only available if you have set up an account for a
compatible online album).
Add the item to an album.
Manage tags and other properties of the item.
Share online
About Share online
Select Menu > Media > Share online.
With Share online, you can post your images, video clips,
and sound clips from your device to compatible online
sharing services, such as albums and blogs. You can also
view and send comments to the posts in these services,
and download content to your compatible Nokia device.
The supported content types and the availability of the
Share online service may vary.
71
Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Subscribe to services
Select Menu > Media > Share online.
To subscribe to an online sharing service, go to the service
provider's website, and check that your Nokia device is
compatible with the service. Create an account as
instructed on the website. You receive a user name and
password needed to set up your device with the account.
1. To activate a service, open the Share online application
in your device, select a service and Options >
Activate.
2. Allow the device to create a network connection. If you
are prompted for an internet access point, select one
from the list.
3. Sign in to your account as instructed on the service
provider’s website.
Nokia's services in the online sharing service are free of
charge. Any data transferred over the network may incur
charges from your service provider. For the availability and
cost of the third party services and data transfer costs,
contact your service provider or the relevant third party.
Manage your accounts
To view your accounts, select Options > Settings > My
accounts.
To create a new account, select Options > Add new
account.
To change your user name or password for an account,
select the account and Options > Open.
To set the account as the default when sending posts from
your device, select Options > Set as default.
To remove an account, select the account and Options >
Delete.
Create a post
Select Menu > Media > Share online.
To post media files to a service, select a service and
Options > New upload. If the online sharing service
provides channels for posting files, select the desired
channel.
To add an image, video clip, or sound clip to the post, select
Options > Insert.
Enter a title or description for the post, if available.
To add tags to the post, select Tags:.
To enable the posting of location information contained
in the file, select Location:.
To set the level of privacy for a file, select Privacy:. To allow
everyone to view your file, select Public. To restrict others
from seeing your files, select Private. You can define the
Default setting on the service provider's website.
To send the post to the service, select Options >
Upload.
Post files from Photos
You can post your files from Photos to an online sharing
service.
72
Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
1. Select Menu > Media > Gallery > Images and the
files you want to post.
2. Select Options > Send > Upload and the desired
account.
3. Edit your post as required.
4. Select Options > Upload.
One-click upload
One-click upload lets you post images to an online sharing
service immediately after capturing them.
To use one-click upload, capture an image with your
device camera, and select the online sharing icon from the
toolbar.
Nokia Video Centre
With Nokia Video Centre (network service), you can
download and stream video clips over the air from
compatible internet video services using a packet data or
wireless LAN (WLAN) connection. You can also transfer
video clips from a compatible PC to your device and view
them in Video centre.
Using packet data access points to download videos may
involve the transmission of large amounts of data through
your service provider's network. Contact your service
provider for information about data transmission charges.
Your device may have predefined services.
Service providers may provide free content or charge a fee.
Check the pricing in the service or from the service
provider.
View and download video
clips
Connect to video services
1. Select Menu > Media > Video centre.
2. To connect to a service to install video services, select
Add new services and the desired video service from
the service catalogue.
View a video clip
To browse the content of installed video services, select
Video feeds.
The content of some video services is divided into
categories. To browse video clips, select a category.
To search for a video clip in the service, select Video
search. Search may not be available in all services.
Some video clips can be streamed over the air, but others
must be first downloaded to your device. To download a
video clip, select Options > Download. Downloads
continue in the background if you exit the application. The
downloaded video clips are saved in My videos.
To stream a video clip or view a downloaded one, select
Options > Play. When the video clip is playing, use the
selection keys and the scroll key to control the player. To
adjust the volume, use the volume key.
Warning: Continuous exposure to high volume
may damage your hearing. Listen to music at a moderate
level, and do not hold the device near your ear when the
loudspeaker is in use.
Select Options and from the following: 73
Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Resume download — Resume a paused or failed
download.
•Cancel download — Cancel a download.
•Preview — Preview a video clip. This option is
available if supported by the service.
•Feed details — View information about a video clip.
•Refresh list — Refresh the list of video clips.
•Open link in browser — Open a link in the web
browser.
Schedule downloads
Setting the application to download video clips
automatically may involve the transmission of large
amounts of data through your service provider's network.
For information about data transmission charges, contact
your service provider. To schedule an automatic download
for video clips in a service, select Options > Schedule
downloads. Video centre automatically downloads new
video clips daily at the time you define.
To cancel scheduled downloads, select Manual
download as the download method.
My videos
My videos is a storage place for all video clips in the Video
centre application. You can list downloaded video clips
and video clips recorded with the device camera in
separate views.
1. To open a folder and view video clips, use the scroll key.
To control the video player when the video clip is
playing, use the scroll key and the selection keys.
2. To adjust the volume, press the volume key.
Select Options and from the following:
•Resume download — Resume a paused or failed
download.
•Cancel download — Cancel a download.
•Video details — View information about a video clip.
•Find — Find a video clip. Enter a search term that
matches the file name.
•Show via home network — Play a downloaded video
clip in a compatible home network. The home network
must be configured first.
•Memory status — View the amount of free and used
memory.
•Sort by — Sort video clips. Select the desired category.
•Move and copy — Move or copy video clips. Select
Copy or Move and the desired location.
Transfer videos from your PC
Transfer your own video clips to Video centre from
compatible devices using a compatible USB data cable.
Video centre will display only the video clips which are in
a format supported by your device.
1. To view your device on a PC as a mass memory device
where you can transfer any data files, make the
connection with a USB data cable.
2. Select Mass storage as the connection mode. A
compatible memory card needs to be inserted in the
device.
3. Select the video clips you want to copy from your PC.
4. Transfer the video clips to E:\My Videos in the memory
card.
The transferred video clips appear in the My videos
folder in Video centre. Video files in other folders of
your device are not displayed.
74
Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Music player
Select Menu > Media > Music player.
Music player supports files formats such as AAC, AAC+, eAAC
+, MP3, and WMA. Music player does not necessarily
support all features of a file format or all the variations of
file formats.
You can transfer music from other compatible devices to
your device. See "Transfer music from PC", p. 75.
Play a song
To add all available songs to the music library, select
Options > Refresh library.
To play a song, select the desired category, and the song.
To pause playback, press the scroll key; to resume, press
the scroll key again. To stop playback, scroll down.
To fast-forward or rewind, press and hold the scroll key to
the right or left.
To skip to the next item, scroll right. To return to the
beginning of the item, scroll left. To skip to the previous
item, scroll left again within 2 seconds after a song has
started.
To modify the tone of the music playback, select
Options > Equaliser.
To modify the balance and stereo image, or to enhance the
bass, select Options > Settings.
To return to the home screen and leave the player playing
in the background, press the end key.
Nokia Music Store
Select Menu > Media > Ovi Music.
In the Nokia Music Store (network service) you can search,
browse, and purchase music to download to your device.
To purchase music, you first need to register for the
service.
To access the Nokia Music Store, you must have a valid
internet access point defined in the device.
Nokia Music Store is not available for all countries or
regions.
To find more music in the different categories, select
Options > Find in Music store.
To select the access point to use with the Nokia Music
Store, select Default access point.
Transfer music from PC
To transfer music from your PC, connect your device to the
PC using Bluetooth connectivity or a compatible USB data
cable. If you are using the USB cable, select Mass
storage as the connection mode. Make sure that a
compatible memory card is inserted in the device.
If you selectPC Suite as the connection mode, you can use
Nokia Music to synchronise music between your device
and PC.
Recorder
Select Menu > Media > Recorder.75
Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
With the Recorder application, you can record voice
memos and telephone conversations.
The recorder cannot be used when a data call or GPRS
connection is active.
To record a sound clip, select .
To stop recording a sound clip, select .
To listen to the sound clip, select .
To select the recording quality or where you want to save
your sound clips, select Options > Settings.
Recorded sound clips are saved in the Sound clips folder in
Gallery.
To record a telephone conversation, open recorder during
a voice call, and select . Both parties hear a tone at
regular intervals during recording.
Flash player
With Flash player, you can view, play, and interact with
flash files made for mobile devices.
To open Flash player and play a flash file, select the file.
To send a flash file to compatible devices, select Options >
Send. Copyright protection may prevent the sending of
some flash files.
To switch between flash files saved in the device memory
or on the memory card, scroll to the corresponding tabs.
To change the flash file quality, select Options >
Quality when you are playing the flash file. If you select
High, the playback of some flash files may appear uneven
and slow due to their original settings. Change the quality
setting of such files to Normal or Low for improved
playback.
To organise your flash files, select Options > Organise.
FM radio
The FM radio depends on an antenna other than the
wireless device antenna. A compatible headset or
accessory needs to be attached to the device for the FM
radio to function properly.
Select Menu > Media > Radio > FM radio.
The quality of the radio broadcast depends on the
coverage of the radio station in that particular area.
Listen to the radio
Select Menu > Media > Radio > FM radio.
The quality of the radio broadcast depends on the
coverage of the radio station in that particular area.
You can make a call or answer an incoming call while
listening to the radio. The radio is muted when there is an
active call.
To start a station search, select or .
If you have saved radio stations in your device, to go to
the next or previous saved station, select or .
Select Options and from the following:
•Activate loudspeaker — Listen to the radio using the
loudspeaker.
76
Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Manual tuning — Change the frequency manually.
•Station directory — View available stations based on
location (network service).
•Save station — Save the station to which you are
currently tuned to your station list.
•Stations — Open the list of your saved stations.
•Play in background — Return to the home screen
while listening to the FM radio in the background.
Saved stations
Select Menu > Media > Radio > FM radio.
To open the list of your saved stations, select Options >
Stations.
To listen to a saved station, select Options > Station >
Listen.
To change station details, select Options > Station >
Edit.
FM radio settings
Select Menu > Media > Radio > FM radio.
To automatically search for alternative frequencies if the
reception is weak, select Options > Settings >
Alternative frequencies > Auto scan on.
To set the default access point for the radio, select
Options > Settings > Access point.
To select the region where you currently are, select
Options > Settings > Current region. This setting is
displayed only if there is no network coverage when you
start the application. 77
Media
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
12. Connectivity
Your device offers several options to connect to the
internet, a corporate intranet, another mobile device, or a
computer.
Fast packet data
High-speed packet access (HSPA, also called 3.5G, indicated
with ) is a network service in UMTS networks and
provides high-speed data downloads and uploads. When
HSPA support in the device is activated and the device is
connected to a UMTS network that supports HSPA,
downloading and uploading data such as e-mail and
browser pages through the cellular network may be faster.
An active HSPA connection is indicated with . The icon
may vary between regions.
To activate HSPA, select Menu > Ctrl. panel > Settings
and Connection > Packet data > High speed packet
access. Some cellular networks do not allow incoming
voice calls when HSPA is active, in which case you need to
deactivate HSPA to receive calls. For more information,
contact your service provider.
For availability and subscription to data connection
services, contact your service provider.
Data cable
To avoid damaging the data, do not remove the data cable
in the middle of a data transfer.
Transfer data between your device and a PC
1. Insert a memory card to your device, and connect the
device to a compatible PC with the USB data cable.
2. When the device asks which mode is used, select Mass
storage. In this mode, you can see your device as a
removable hard drive in your computer.
3. End the connection from the computer (for example,
from an Unplug or Eject Hardware wizard in Windows)
to avoid damaging the memory card.
To use Nokia PC Suite with your device, install Nokia PC
Suite on your PC, connect the data cable, and select PC
Suite.
To use your device to connect your PC to the web, connect
the data cable, and select Connect PC to web.
To synchronise the music in your device with Nokia Music
Player, install the Nokia Music Player software on your PC,
connect the data cable, and select PC Suite.
To print images on a compatible printer, select Image
transfer.
To change the USB mode you normally use with the data
cable, select Menu > Ctrl. panel > Connectivity >
USB and USB connection mode, and the desired option.
78
Connectivity
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
To set the device to ask for the mode each time you
connect the USB data cable to the device, select Menu >
Ctrl. panel > Connectivity > USB and Ask on
connection > Yes.
Bluetooth
Select Menu > Ctrl. panel > Connectivity >
Bluetooth.
About Bluetooth
Bluetooth technology in your device enables wireless
connections between electronic devices within a range of
10 metres (33 feet). A Bluetooth connection can be used
to send images, videos, text, business cards, calendar
notes, or to connect wirelessly to devices that use
Bluetooth technology.
Since devices using Bluetooth technology communicate
using radio waves, your device and the other devices do
not need to be in direct line-of-sight. The two devices only
need to be within a maximum of 10 metres of each other,
although the connection can be subject to interference
from obstructions such as walls or other electronic
devices.
Several Bluetooth connections can be active at a time. For
example, if your device is connected to a headset, you can
also transfer files to another compatible device at the
same time.
This device is compliant with Bluetooth Specification 2.0
+ EDR supporting the following profiles: Advanced Audio
Distribution, Audio Video Remote Control, Basic Imaging,
Basic Printing, Dial-up Networking, File Transfer, Generic
Access, Hands-free, Headset, Human Interface Device,
Local Positioning, Object Push, Phone Book Access, SIM
Access, Serial Port, Video Distribution. To ensure
interoperability between other devices supporting
Bluetooth technology, use Nokia approved accessories for
this model. Check with the manufacturers of other devices
to determine their compatibility with this device.
Features using Bluetooth technology increase the demand
on battery power and reduce the battery life.
Send and receive data with
Bluetooth
Select Menu > Ctrl. panel > Connectivity >
Bluetooth.
1. When you activate Bluetooth connectivity for the first
time, you are asked to name your device. Give your
device a unique name to make it easy to recognise if
there are several Bluetooth devices nearby.
2. Select Bluetooth > On.
3. Select My phone's visibility > Shown to all or
Define period. If you select Define period, you need
to define the time during which your device is visible
to others. Your device and the name you entered can
now be seen by other users with devices using
Bluetooth technology.
4. Open the application where the item you want to send
is stored.
5. Select the item and Options > Send > Via
Bluetooth. The device searches for other devices using
Bluetooth technology within range and lists them.
79
Connectivity
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Tip: If you have sent data using Bluetooth
connectivity before, a list of the previous search
results is displayed. To search for more
Bluetooth devices, select More devices.
6. Select the device with which you want to connect. If
the other device requires pairing before data can be
transmitted, you are asked to enter a passcode.
When the connection has been established, Sending
data is displayed.
The Sent folder in the Messaging application does not
store messages sent using Bluetooth connectivity.
To receive data using Bluetooth connectivity, select
Bluetooth > On and My phone's visibility > Shown to
all to receive data from a non-paired device or Hidden to
receive data from a paired device only. When you receive
data through Bluetooth connectivity, depending on the
settings of an active profile, a tone sounds, and you are
asked if you want to accept the message in which the data
is included. If you accept, the message is placed in the
Inbox folder in the Messaging application.
Tip: You can access the files in the device or on the
memory card using a compatible accessory that
supports the File Transfer Profile Client service (for
example, a laptop computer).
A Bluetooth connection is disconnected automatically
after sending or receiving data. Only Nokia PC Suite and
some accessories such as headsets may maintain a
connection even if not actively used.
Pair devices
Select Menu > Ctrl. panel > Connectivity >
Bluetooth.
Open the paired devices tab.
Before pairing, decide on your own passcode (1-16 digits),
and agree with the user of the other device to use the same
code. Devices that do not have a user interface have a fixed
passcode. You need the passcode only when you connect
the devices for the first time. After pairing, it is possible to
authorise the connection. Pairing and authorising the
connection makes connecting quicker and easier, as you
do not have to accept the connection between paired
devices every time you establish a connection.
The passcode for remote SIM access must have 16 digits.
In remote SIM mode you can use your device's SIM card
with compatible accessories.
When the wireless device is in the remote SIM mode, you
can only use a compatible connected accessory, such as a
car kit, to make or receive calls.
Your wireless device will not make any calls, except to the
emergency numbers programmed into your device, while
in this mode.
To make calls, you must first leave the remote SIM mode.
If the device has been locked, enter the lock code to unlock
it first.
1. Select Options > New paired device. The device
starts to search for Bluetooth devices within range. If
you have sent data using Bluetooth connectivity
before, a list of the previous search results is displayed.
To search for more Bluetooth devices, select More
devices.
80
Connectivity
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
2. Select the device with which you want to pair, and
enter the passcode. The same passcode must be
entered in the other device as well.
3. To make the connection between your device and the
other device automatic, select Yes. To confirm the
connection manually every time a connection attempt
is made, select No. After pairing, the device is saved to
the paired devices page.
To give a nickname to the paired device, select Options >
Assign short name. The nickname is displayed in your
device.
To delete a pairing, select the device whose pairing you
want to delete and Options > Delete. To delete all
pairings, select Options > Delete all. If you are currently
connected to a device and cancel the pairing with that
device, pairing is removed immediately, and the
connection is ended.
To allow a paired device to connect automatically to your
device, select Set as authorised. Connections between
your device and the other device can be made without
your knowledge. No separate acceptance or authorisation
is needed. Use this status only for your own devices, such
as your compatible headset or computer, or devices that
belong to someone you trust. If you want to accept
connection requests from the other device separately
every time, select Set as unauthorised.
To use a Bluetooth audio accessory, such as a Bluetooth
handsfree or headset, you need to pair your device with
the accessory. For the passcode and further instructions,
see the accessory user guide. To connect to the audio
accessory, switch on the accessory. Some audio
accessories connect automatically to your device.
Otherwise, open the paired devices tab, and select the
accessory and Options > Connect to audio device.
Block devices
Select Menu > Ctrl. panel > Connectivity >
Bluetooth.
1. To block a device from establishing a Bluetooth
connection to your device, open the paired devices tab.
2. Select a device you want to block and Options >
Block.
To allow the pairing of a device again after it was blocked,
delete it from the blocked devices list.
Open the blocked devices tab, and select Options >
Delete.
If you reject a pairing request from another device, you are
asked if you want to block all future connection requests
from this device. If you accept the query, the remote device
is added to the list of blocked devices.
Security tips
Operating the device in hidden mode is a safer way to
avoid malicious software. Do not accept Bluetooth
connectivity from sources you do not trust. Alternatively,
switch off the Bluetooth function. This does not affect
other functions of the device.
Select Menu > Ctrl. panel > Connectivity >
Bluetooth.
When you are not using Bluetooth connectivity, select
Bluetooth > Off or My phone's visibility > Hidden.81
Connectivity
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Do not pair with an unknown device.
Wireless LAN
About WLAN
Your device can detect and connect to WLANs. Using a
WLAN, you can connect your device to the internet and
compatible devices that support WLAN.
To use a WLAN connection, you need the following:
•WLAN must be available in your location.
•Your device must be connected to the WLAN. Some
WLANs are protected, and you need an access key from
the service provider to connect to them.
•An internet access point created for WLAN. Use the
access point for applications that need to connect to the
internet.
A WLAN connection is established when you create a data
connection using a WLAN internet access point. The active
WLAN connection ends when you end the data connection.
You can use WLAN during a voice call or when packet data
is active. You can only be connected to one WLAN access
point device at a time, but several applications can use the
same access point.
There might be some restrictions for WLAN use in some
countries. Check with your local authorities for more
information.
Features that use WLAN, or that are allowed to run in the
background while using other features, increase the
demand on battery power and reduce the battery life.
Your device supports the following WLAN features:
•IEEE 802.11b/g standard
•Operation at 2.4 GHz
•Wired equivalent privacy (WEP), Wi-Fi protected access
(WPA/WPA2), and 802.1x authentication methods.
These functions can be used only if they are supported
by the network.
Important: Always enable one of the available
encryption methods to increase the security of your
wireless LAN connection. Using encryption reduces the risk
of unauthorised access to your data.
When the device is in the offline profile, you can still use
WLAN, if available. Remember to comply with any
applicable safety requirements when establishing and
using a WLAN connection.
Tip: To check the unique media access control (MAC)
address that identifies your device, enter
*#62209526# in the home screen.
See WLAN availability
To set your device to show wireless LAN (WLAN)
availability, select Menu > Ctrl. panel > Settings and
Connection > Wireless LAN > Show WLAN
availability.
If a WLAN is available, is displayed.
WLAN wizard
Select Menu > Ctrl. panel > Connectivity > WLAN
wiz..
82
Connectivity
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
The WLAN wizard helps you find and connect to a wireless
LAN (WLAN). When you open the application, your device
starts to scan for available WLANs and lists them.
Select Options and from the following:
•Refresh — Update the list of available WLANs.
•Filter WLAN networks — Filter out WLANs in the list
of found networks. The selected networks are filtered
out the next time the application searches for WLANs.
•Start web browsing — Start browsing the web using
the access point of the WLAN.
•Cont.web browsing — Continue web browsing using
the currently active WLAN connection.
•Disconnect WLAN — Disconnect the active connection
to the WLAN.
•Details — View the details of the WLAN.
Important: Always enable one of the available
encryption methods to increase the security of your
wireless LAN connection. Using encryption reduces the risk
of unauthorised access to your data.
Use the WLAN wizard in the home screen
In the home screen, the WLAN wizard shows the status of
your WLAN connections and network searches. If the WLAN
wizard is not activated by default in the home screen, you
can activate it in the home screen settings. To view the
available options, select the row showing the status.
Depending on the status, you can start the web browser
using a WLAN connection, connect to your net call service,
disconnect from a WLAN, search for WLANs, or enable or
disable network scanning.
If WLAN scanning is disabled, and you are not connected
to any WLAN, WLAN scanning off is displayed in the home
screen. To enable WLAN scanning, and to search for
available WLANs, select the row showing the status.
To start a search for available WLANs, select the row
showing the status and Search for WLAN.
To disable WLAN scanning, select the row showing the
status and Switch WLAN scan off.
When Start web browsing or Use for is selected, the
WLAN wizard automatically creates an access point for the
selected WLAN. The access point can also be used with
other applications requiring WLAN connection.
If you select a secured WLAN, you are asked to enter the
relevant passcodes. To connect to a hidden network, you
must enter the correct service set identifier (SSID).
To use the found WLAN for a net call connection, select the
row showing the status, Use for, the desired net call
service, and the WLAN to be used.
Connection manager
Select Menu > Ctrl. panel > Connectivity > Conn.
mgr..
View and end active
connections
Select Menu > Ctrl. panel > Connectivity > Conn.
mgr..
To see the open data connections, select Active data
connections.83
Connectivity
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
To view detailed information about network connections,
select a connection from the list and Options > Details.
The type of information shown depends on the connection
type.
To end the selected network connection, select Options >
Disconnect.
To end all active network connections simultaneously,
select Options > Disconnect all.
Search for WLAN
To search for WLANs available within range, select
Available WLAN networks. The available WLANs are
listed with their network mode (infrastructure or ad-hoc),
signal strength, and network encryption indicators, and
whether your device has an active connection with the
network.
To view the details of a network, scroll to it, and press the
scroll key.
To create an internet access point for a network, select
Options > Define access point.
84
Connectivity
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
13. Security and data management
Manage the data and software on your device, and take
care of the security of the device and its contents.
Important: Your device can only support one
antivirus application. Having more than one application
with antivirus functionality could affect performance and
operation or cause the device to stop functioning.
Lock the device
The lock code protects your device against unauthorised
use. The preset code is 12345.
To lock the device, in the home screen, press the power
key, and select Lock phone.
To unlock your device, select Unlock, enter the lock code,
and select OK.
To change the lock code, select Menu > Ctrl. panel >
Settings and General > Security > Phone and SIM
card. Enter the old code and then the new code twice. The
new code can be 4-255 characters long. Both alphabets
and digits can be used, and both uppercase and lowercase
alphabets are possible.
Write down the new code, and keep it secret and in a safe
place separate from your device. If you forget the lock code
and your device is locked, you must take the device to a
Nokia authorised service facility and additional charges
may apply. To unlock the device, the software must be
reloaded, and the data you have saved in the device may
be lost.
You can also lock the device remotely by sending a text
message to the device. To enable remote locking, and to
define the text for the message, select Menu > Ctrl.
panel > Settings and General > Security > Phone
and SIM card > Remote phone locking > Enabled.
Enter the remote lock message, and confirm the message.
The message must be at least 5 characters long. Write
down the text, as you may need it later.
Memory card security
Select Menu > Office > File mgr..
You can protect a memory card with a password to prevent
unauthorised access. To set a password, select Options >
Memory card password > Set. The password can be up
to 8 characters long and is case-sensitive. The password is
stored in your device. You do not need to enter it again
while you use the memory card on the same device. If you
use the memory card on another device, you are asked for
the password. Not all memory cards support password
protection.
To remove the memory card password, select Options >
Memory card password > Remove. When you remove
the password, the data on the memory card is not
protected against unauthorised use. 85
Security and data management
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
To open a locked memory card, select Options > Unlock
memory card. Enter the password.
If you cannot recall the password to unlock a locked
memory card, you may reformat the card, in which case
the card is unlocked and password removed. Formatting
a memory card deletes all data stored on the card.
Encryption
Select Menu > Ctrl. panel > Phone > Encryption.
Encrypt your device or memory card to prevent outsiders
from accessing your important information.
Encrypt device memory or
memory card
To encrypt the device memory, select Phone memory.
To encrypt the memory card, select Memory card and
from the following:
•Encrypt without saving key — Encrypt the memory
card without saving the encryption key. If you select
this option, you cannot use the memory card in other
devices, and if you restore factory settings, you cannot
decrypt the memory card.
•Encrypt and save key — Encrypt the memory card and
save the key manually in the default folder. For security,
store the key to a safe place outside the device. For
example, you can send the key to your computer. Enter
a pass phrase for the key and a name for the key file.
The pass phrase should be long and complex.
•Encrypt with restored key — Encrypt the memory
card with a key you have received. Select the key file,
and enter the pass phrase.
Decrypt device memory or
memory card
Always remember to decrypt the device memory and/or
the memory card before updating the device software.
To decrypt the device memory, select Phone memory.
To decrypt the memory card without destroying the
encryption key, select Memory card > Decrypt.
To decrypt the memory card and destroy the encryption
key, select Memory card > Decrypt and turn off
encryption.
Certificate manager
Select Menu > Ctrl. panel > Settings and General >
Security > Certificate management.
Digital certificates are used to verify the origins of
software but do not guarantee safety. There are four
different types of certificates: authority certificates,
personal certificates, trusted site certificates, and device
certificates. During a secure connection, a server may send
a server certificate to your device. Upon receipt, it is
checked through an authority certificate stored in your
device. You receive notification if the identity of the server
is not authentic or if you do not have the correct certificate
in your device.
86
Security and data management
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
You can download a certificate from a web site, or receive
a certificate as a message. Certificates should be used
when you connect to an online bank or a remote server to
transfer confidential information. They should also be
used if you want to reduce the risk of viruses or other
malicious software, and to check the authenticity of
software when you download and install software to your
device.
Tip: When you add a new certificate, check its
authenticity.
View certificate details
You can only be sure of the correct identity of a server
when the signature and the validity period of a server
certificate have been checked.
To view certificate details, open a certificate folder, and
select a certificate and Options > Certificate details.
One of the following notes may appear:
•Certificate not trusted — You have not set any
application to use the certificate. You may want to
change the trust settings.
•Expired certificate — The period of validity has ended
for the selected certificate.
•Certificate not valid yet — The period of validity has
not yet begun for the selected certificate.
•Certificate corrupted — The certificate cannot be
used. Contact the certificate issuer.
Certificate trust settings
Select Menu > Ctrl. panel > Settings and General >
Security > Certificate management.
Trusting a certificate means that you authorise it to verify
web pages, e-mail servers, software packages, and other
data. Only trusted certificates can be used to verify services
and software.
Important: Even if the use of certificates makes the
risks involved in remote connections and software
installation considerably smaller, they must be used
correctly in order to benefit from increased security. The
existence of a certificate does not offer any protection by
itself; the certificate manager must contain correct,
authentic, or trusted certificates for increased security to
be available. Certificates have a restricted lifetime. If
"Expired certificate" or "Certificate not valid yet" is shown,
even if the certificate should be valid, check that the
current date and time in your device are correct.
Before changing any certificate settings, you must make
sure that you really trust the owner of the certificate and
that the certificate really belongs to the listed owner.
To change the trust settings, select a certificate and
Options > Trust settings. Scroll to an application field,
and press the scroll key to select Yes or No. You cannot
change the trust settings of a personal certificate.
Depending on the certificate, a list of applications that can
use the certificate is displayed:
•Symbian installation — New Symbian operating
system application.
•Internet — E-mail and graphics.
•App. installation — New Java application.
87
Security and data management
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Online certif. check — Online certificate status
protocol.
Application manager
With Application manager, you can see the software
packages installed in your device. You can view details of
installed applications, remove applications, and define
installation settings.
You can install two types of applications and software to
your device:
•JME applications based on Java technology with the .jad
or .jar file extensions
•Other applications and software suitable for the
Symbian operating system with the .sis or .sisx file
extensions
Only install software that is compatible with your device.
Install applications
Select Menu > Ctrl. panel > App. mgr..
You can transfer installation files to your device from a
compatible computer, download them during browsing,
or receive them in a multimedia message, as an e-mail
attachment, or using other connectivity methods, such as
Bluetooth connectivity. You can use Nokia Application
Installer in Nokia PC Suite to install an application to your
device.
Icons in Application manager indicate the following:
SIS or SISX application
Java application
widgets
Important: Only install and use applications and
other software from trusted sources, such as applications
that are Symbian Signed or have passed the Java
Verified™ testing.
Before installation, note the following:
•To view the application type, version number, and the
supplier or manufacturer of the application, select
Options > View details.
To display the security certificate details of the
application, select Details: > Certificates: > View
details.
•If you install a file that contains an update or repair to
an existing application, you can only restore the
original application if you have the original installation
file or a full backup copy of the removed software
package. To restore the original application, remove
the application, and install the application again from
the original installation file or the backup copy.
The JAR file is required for installing Java applications.
If it is missing, the device may ask you to download it.
If there is no access point defined for the application,
you are asked to select one. When you are downloading
the JAR file, you may need to enter a user name and
password to access the server. You obtain these from
the supplier or manufacturer of the application.
To install software or an application, do the following:
88
Security and data management
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
1. To locate an installation file, select Menu > Ctrl.
panel > App. mgr.. Alternatively, search for
installation files using File manager, or select
Messaging > Inbox, and open a message that
contains an installation file.
2. In Application manager, select Options > Install. In
other applications, select the installation file to start
the installation.
During installation, the device shows information
about the progress of the installation. If you install an
application without a digital signature or certification,
the device displays a warning. Continue installation
only if you are sure of the origin and contents of the
application.
To start an installed application, locate the application in
the menu, and select the application.
To see which software packages are installed or removed
and when, select Options > View log.
Important: Your device can only support one
antivirus application. Having more than one application
with antivirus functionality could affect performance and
operation or cause the device to stop functioning.
After you install applications to a compatible memory
card, installation files (.sis, .sisx) remain in the device
memory. The files may use large amounts of memory and
prevent you from storing other files. To maintain sufficient
memory, use Nokia PC Suite to back up installation files to
a compatible PC, then use the file manager to remove the
installation files from the device memory. If the .sis file is
a message attachment, delete the message from the
Messaging inbox.
Remove applications and
software
Select Menu > Ctrl. panel > App. mgr..
Scroll to a software package, and select Options >
Uninstall. Select Yes to confirm.
If you remove software, you can only reinstall it if you have
the original software package or a full backup of the
removed software package. If you remove a software
package, you may no longer be able to open documents
created with that software.
If another software package depends on the software
package that you removed, the other software package
may stop working. For more information, see the
documentation of the installed software package.
Sync
Select Menu > Ctrl. panel > Phone > Sync.
Sync enables you to synchronise your notes, calendar
entries, text and multimedia messages, browser
bookmarks, or contacts with various compatible
applications on a compatible computer or on the internet.
You may receive synchronisation settings in a special
message from your service provider.
A synchronisation profile contains the necessary settings
for synchronisation.
When you open the Sync application, the default or
previously used sync profile is displayed. To modify the
profile, scroll to a sync item, and select Mark to include it
in the profile or Unmark to leave it out.
89
Security and data management
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
To manage sync profiles, select Options and the desired
option.
To synchronise data, select Options > Synchronise. To
cancel synchronisation before it finishes, select Cancel.
Mobile VPN
Select Menu > Ctrl. panel > Settings and Connection >
VPN.
The Nokia mobile virtual private network (VPN) client
creates a secure connection to compatible corporate
intranet and services, such as e-mail. Your device connects
from a mobile network, through the internet, to a
corporate VPN gateway that acts as a front door to the
compatible corporate network. The VPN client uses IP
Security (IPSec) technology. IPSec is a framework of open
standards for supporting the secure exchange of data over
IP networks.
VPN policies define the method used by the VPN client and
a VPN gateway to authenticate each other, and the
encryption algorithms that they use to help protect the
confidentiality of data. For a VPN policy, contact your
company's IT department.
To install and configure the VPN client, certificates, and
policies, contact the IT administrator of your organisation.
Manage VPN
Select from the following:
•VPN policies — Install, view, and update VPN policies.
•VPN policy servers — Edit the connection settings of
VPN policy servers from which you can install and
update VPN policies. A policy server refers to a Nokia
Security Service Manager (NSSM), which is not
necessarily required.
•VPN log — View the log for your VPN policy
installations, updates and synchronisations, and other
VPN connections.
Edit VPN access points
Select Menu > Ctrl. panel > Settings and Connection >
Destinations.
An access point is where your phone connects to the
network. To use e-mail and multimedia services, or to
browse web pages, you must first define internet access
points for these services. Virtual private network (VPN)
access points pair VPN policies with regular internet access
points to create secure connections.
Your service provider may preset some or all access points
for your device, and you may not be able to create, edit,
or remove them.
Select a destination and Options > Edit, and define the
following:
•Connection name — Enter a name for the VPN access
point.
•VPN policy — Select the VPN policy to combine with
the internet access point.
•Internet access point — Select the internet access
point with which to combine the VPN policy to create
secure connections for data transfer.
•Proxy server address — Enter the proxy server
address of the private network.
•Proxy port number — Enter the proxy port number.
90
Security and data management
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Use access point — Select whether connections using
this access point are established automatically.
The settings available for editing may vary.
For the correct settings, contact your company's IT
department.
Use a VPN connection in an
application
You may have to prove your identity when you log on to
the enterprise network. Contact your company's IT
department for the credentials.
To use a VPN connection in an application, the application
must be associated with a VPN access point.
Tip: You can configure the application's connection
setting to Always ask, in which case you select the
VPN access point from a list of connections when a
connection is established.
1. In the application in which you want to create a VPN
connection, select a VPN access point as the access
point.
2. If you are using legacy authentication, enter your VPN
user name and passcode or password. If the SecurID
token has become out of synchronisation with the
clock of the ACE/Server, enter the next passcode. If you
are using certificate-based authentication, you may
have to enter the key store password.
91
Security and data management
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
14. Settings
Select Menu > Ctrl. panel > Settings.
You can define and modify various settings of your device.
Modifying these settings affects the operation of your
device across several applications.
Some settings may be preset for the device or sent to you
in a special message by your service provider. You may not
be able to change such settings.
Select the setting you want to edit to do the following:
•Switch between two values, such as on or off.
•Select a value from a list.
•Open a text editor to enter a value.
•Open a slider, and scroll left or right to adjust a value.
General settings
Select Menu > Ctrl. panel > Settings and General.
Personalisation settings
Select Menu > Ctrl. panel > Settings and General >
Personalisation.
Display settings
To define the level of light that the device needs before
switching on the backlight, select Display > Light
sensor.
To change the text size, select Display > Font size.
To adjust the length of time the display can be left idle
before the screen saver is activated, select Display >
Power saver time-out.
To select a welcome note or logo for the display, select
Display > Welcome note / logo. You can either choose
the default welcome note, enter your own text, or select
an image.
To set how quickly the display dims after the last keypress,
select Display > Light time-out.
Tone settings
Select Menu > Ctrl. panel > Settings.
Select General > Personalisation > Tones and from the
following:.
•Ringing tone — Select a ringing tone from the list, or
select Download sounds to open a bookmark folder
containing a list of bookmarks for downloading tones
using the browser. If you have two alternate phone
lines in use, you can specify a ringing tone for each line.
•Video call tone — Select a ringing tone for video calls.
•Say caller's name — If you select this setting, and
someone from your contacts list calls you, the device
sounds a ringing tone that is a combination of the
spoken name of the contact and the selected ringing
tone.
•Ringing type — Select how you want the ringing tone
to alert you.
92
Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Ringing volume — Set the volume level of the ringing
tone.
•Message alert tone — Select a tone for received text
messages.
•E-mail alert tone — Select a tone for received e-mail
messages.
•Calendar alarm tone — Select a tone for calendar
alerts.
•Clock alarm tone — Select a tone for clock alarms.
•Vibrating alert — Set the device to vibrate when you
receive a call or message.
•Keypad tones — Set the volume level of the keypad
tones.
•Warning tones — Turn the warning tones on or off.
Language settings
Select Menu > Ctrl. panel > Settings and General >
Personalisation > Language.
•Phone language — Set the device language.
•Writing language — Select the language used for
writing notes and messages.
•Predictive text — Activate predictive text input.
•Input options — Define the settings for predictive text
input.
Scroll key lights
Select Menu > Ctrl. panel > Settings and General >
Personalisation > Notification lights.
When you miss a call or receive a message, the scroll key
starts blinking to indicate the event. To select of which
events you want to be notified or to set the blinking time,
select Notification light.
When you do not use the device for a certain period of
time, the scroll key starts blinking slowly as if it was
breathing. To turn the breathing effect on or off, select
Breathing light.
Settings for One-touch keys
Select Menu > Ctrl. panel > Settings and General >
Personalisation > One-touch keys.
To select which application and task is opened when you
press a One-touch key, select the key and Options >
Open.
To restore the preset applications and tasks, select
Restore defaults.
Date and time settings
Select Menu > Ctrl. panel > Settings and General >
Date and time.
Select from the following:
•Date and Time — Set the current date and time.
•Time zone — Define your time zone.
•Date format and Date separator — Define the date
format and separator.
•Time format and Time separator — Select whether
to use the 12-hour or 24-hour clock system and with
which symbol to separate hours and minutes.
•Clock type — Define the clock type.
•Clock alarm tone — Select the tone for the alarm clock.
•Alarm snooze time — Define the snooze time for the
alarm clock.
•Workdays — Define the days of the week that are work
days for you. 93
Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Automatic time update — Update the time, date, and
time zone information automatically (network service).
Common accessory settings
Select Menu > Ctrl. panel > Settings and General >
Enhancement.
With most accessories, you can do the following:
To define which profile is activated when you attach an
accessory to your device, select the accessory and Default
profile.
To set the device to answer phone calls automatically after
5 seconds when an accessory is attached, select
Automatic answer > On. If the ringing type is set to
Beep once or Silent in the selected profile, automatic
answering is disabled.
To illuminate the device while it is attached to an
accessory, select Lights > On.
Turn to silence calls or alarms
When you activate the sensors in your device, you can
control certain functions by turning the device.
Select Menu > Ctrl. panel > Settings and General >
Sensor settings.
Select from the following:
•Sensors — Set the display to rotate automatically
according to the device's orientation.
•Turning control — Set the device to silence incoming
calls or snooze alarms when you turn the device face
down. To enable this option, the Sensors option needs
to be activated.
Security settings
About security settings
Select Menu > Ctrl. panel > Settings and General >
Security.
Avoid using codes that are similar to emergency numbers
to prevent accidental dialling of the emergency number.
Codes are shown as asterisks. When you change a code,
enter the current code, then the new code twice.
Device and SIM card security
To change the PIN code, select Phone and SIM card >
PIN code. The new code must be 4 to 8 digits long. The
PIN code protects your SIM card against unauthorised use
and is provided with the SIM card. After three consecutive
incorrect PIN code entries, the code is blocked, and you
need to use the PUK code to unblock it before you can use
the SIM card again.
To set the keypad to lock automatically after a defined
period, select Phone and SIM card > Keypad autolock
period.
To set a time-out after which the device is automatically
locked and can be used only if the correct lock code is
entered, select Phone and SIM card > Phone autolock
period. Enter a number for the time-out in minutes, or
select None to set off the autolock period. When the device
is locked, you can still answer incoming calls, and calls may
still be possible to the official emergency number
programmed into your device.
94
Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
To set a new lock code, select Phone and SIM card > Lock
code. The preset lock code is 12345. Enter the current code
and then the new code twice. The new code can be 4-255
characters long. Both alphabets and digits can be used,
and both uppercase and lowercase alphabets are possible.
The device notifies you if the lock code is not properly
formatted.
Restore original settings
To restore the original device settings, select Menu > Ctrl.
panel > Settings and General > Factory settings. To
do this, you need your device lock code. After resetting,
the device may take a longer time to switch on.
Documents, contact information, calendar entries, and
files are unaffected.
Positioning settings
Select Menu > Ctrl. panel > Settings and General >
Positioning.
To use a specific positioning method to detect the location
of your device, select Positioning methods.
To select a positioning server, select Positioning server.
To select which measurement system you want to use for
speeds and distances, select Notation preferences >
Measurement system.
To define in which format the coordinate information is
displayed in your device, select Notation preferences >
Coordinate format.
E-mail key settings
Select Menu > Ctrl. panel > Settings and General.
To select which mailbox to open with the e-mail key, select
E-mail key settings > E-mail key, and press the scroll
key.
Telephone settings
Select Menu > Ctrl. panel > Settings and Phone.
Call settings
Select Menu > Ctrl. panel > Settings and Phone >
Call.
Select from the following:
•Send my caller ID — Display your phone number to
the person you are calling.
•Send my internet call ID — Display your internet call
address to the person you are calling using an internet
call.
•Call waiting — Set the device to notify you of incoming
calls while you are in a call (network service).
•Internet call waiting — Set the device to notify you
of new incoming internet calls while you are in a call.
•Internet call alert — To set the device to notify you
of incoming internet calls, select On. If you select Off,
you receive only a notification if you missed a call.
•Reject call with message — Reject a call, and send a
text message to the caller.
•Message text — Write the standard text message that
is sent when you reject a call. 95
Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Own video in recvd. call — Allow or deny video
sending during a video call from your device.
•Image in video call — Display a still image if video is
not sent during a video call.
•Automatic redial — Set your device to make a
maximum of 10 attempts to connect the call after an
unsuccessful call attempt. To stop automatic redialling,
press the end key.
•Show call duration — Display the length of a call
during the call.
•Summary after call — Display the length of a call after
the call.
•Speed dialling — Activate speed dialling.
•Anykey answer — Activate anykey answer.
•Contact search — Activate contact search in the home
screen.
•Line in use — This setting (network service) is
displayed only if the SIM card supports two subscriber
numbers, that is, two phone lines. Select which phone
line you want to use for making calls and sending text
messages. Calls on both lines can be answered
irrespective of the selected line. If you select Line 2 and
have not subscribed to this network service, you are not
able to make calls. When line 2 is selected, is
displayed in the home screen.
•Line change — Prevent line selection (network
service), if supported by your SIM card. To change this
setting, you need the PIN2 code.
Network settings
Select Menu > Ctrl. panel > Settings and Phone >
Network.
To select the network mode, select Network mode and
Dual mode, UMTS, or GSM. In dual mode, the device
switches automatically between networks.
Tip: Selecting UMTS enables faster data transfer,
but may increase the demand on battery power and
reduce the battery life. In regions close to both GSM
and UMTS networks, selecting Dual mode may
cause constant jumping between the two networks,
which also increases the demand on battery power.
To select the operator, select Operator selection and
Manual to select from available networks, or Automatic
to set the device to select the network automatically.
To set the device to indicate when it is used in a
microcellular network (MCN), select Cell info display >
On.
Connection settings
Select Menu > Ctrl. panel > Settings and Connection.
Select from the following:
•Bluetooth — Edit the Bluetooth settings.
•USB — Edit the data cable settings.
•Destinations — Set up new or edit existing access
points. Some or all access points may be preset for your
device by your service provider, and you may not be
able to create, edit, or remove them.
•VPN — Manage the settings for virtual private
networking.
•Packet data — Define when packet data network is
attached, and enter the default packet switched access
point name if you use your device as a modem for a
computer.
96
Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Wireless LAN — Set the device to display an indicator
when a wireless LAN (WLAN) is available, and define
how often the device searches for networks.
•Video sharing — Enable video sharing, select the SIP
profile for video sharing, and define the video saving
settings.
•SIP settings — View or create session initiation
protocol (SIP) profiles.
•XDM profile — Create an XDM profile. The XDM profile
is required for many communications applications, for
example, presence.
•Presence — Edit the settings for presence (network
service). To register for the service, contact your service
provider.
•Remote drives — Connect the device to a remote
drive.
•Configurations — View and delete trusted servers
from which your device may receive configuration
settings.
•APN control — Restrict packet data connections.
Access points
Create a new access point
Select Menu > Ctrl. panel > Settings and Connection >
Destinations.
You may receive access point settings in a message from
a service provider. Some or all access points may be preset
for your device by your service provider, and you may not
be able to change, create, edit, or remove them.
When you select one of the access point groups ( , ,
, , ), you can see the access point types:
indicates a protected access point
indicates a packet data access point
indicates a wireless LAN (WLAN) access point
Tip: You can create internet access points in a WLAN
with the WLAN wizard.
To create a new access point, select Access point. The
device asks to check for available connections. After the
search, connections that are already available are
displayed and can be shared by a new access point. If you
skip this step, you are asked to select a connection method
and to define the settings needed.
To edit the settings of an access point, select one of the
access point groups, scroll to an access point, and select
Edit. Use the instructions provided by your service
provider to edit the following:
•Connection name — Enter a name for the connection.
•Data bearer — Select the data connection type.
Depending on the data connection you select, only certain
setting fields are available. Fill in all fields marked with
Must be defined or with a red *. Other fields can be left
empty, unless your service provider has instructed
otherwise.
To use a data connection, your service provider must
support this feature, and if necessary, activate it for your
SIM card.
Create access point groups
Select Menu > Ctrl. panel > Settings and Connection >
Destinations.
Some applications allow you to use access point groups to
connect to a network.
97
Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
To avoid selecting which access point to use every time
the device attempts to connect to a network, you can
create a group that contains various access points, and
define the order in which the access points are used to
connect to a network.
For example, you can add wireless LAN (WLAN) and packet
data access points to an internet access point group and
use the group for browsing the web. If you give the WLAN
access point the higher priority, the device connects to the
internet through a WLAN if available and through a packet
data connection if not.
To create a new access point group, select Options >
Manage > New destination.
To add access points to an access point group, select the
group and Options > New access point. To copy an
existing access point from another group, select the
group, scroll to an existing access point, and select
Options > Organise > Copy to other dest..
To change the priority order of access points within a
group, scroll to an access point, and select Options >
Organise > Change priority.
Packet data access points
Select Menu > Ctrl. panel > Settings and Connection >
Destinations > Access point, and follow the instructions
on the display. Or, open one of the access point groups,
select an access point marked with , and select Edit.
Use the instructions provided by your service provider to
edit the following:
•Access point name — The access point name is
provided by your service provider.
•User name — The user name may be needed to make
a data connection, and is usually provided by your
service provider.
•Prompt password — If you want to set the device to
ask for a password every time you log in to a server, or
if you do not want to save your password in the device,
select Yes.
•Password — A password may be needed to make a
data connection and is usually provided by your service
provider.
•Authentication — Select Secure to always send your
password encrypted or Normal to send your password
encrypted when possible.
•Homepage — Depending on the access point type you
are setting up, enter the web address or the address of
the multimedia message centre.
•Use access point — Select After confirmation to set
the device to ask for confirmation before the
connection using this access point is created, or
Automatically to set the device to connect to the
destination using this access point automatically.
Select Options > Advanced settings and from the
following:
•Network type — Select the internet protocol type to
transfer data to and from your device. The other
settings depend on the selected network type.
•Phone IP address (for IPv4 only) — Enter the IP address
of your device.
•DNS addresses — Enter the IP addresses of the primary
and secondary DNS servers, if required by your service
provider. To obtain these addresses, contact your
internet service provider.
•Proxy server address — Enter the address of the proxy
server.
98
Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Proxy port number — Enter the port number of the
proxy server.
WLAN internet access points
Select Menu > Ctrl. panel > Settings and Connection >
Destinations > Access point, and follow the instructions
on the display. Or, open one of the access point groups,
select an access point marked with , and select Edit.
Use the instructions provided by your service provider to
edit the following:
•WLAN network name — Select Enter manually or
Search for networks. If you select an existing network,
WLAN network mode and WLAN security mode are
determined by the settings of its access point device.
•Network status — Define whether the network name
is displayed.
•WLAN network mode — Select Ad-hoc to create an
ad hoc network, and to allow devices to send and
receive data directly; a WLAN access point device is not
needed. In an ad hoc network, all devices must use the
same WLAN network name.
•WLAN security mode — Select the encryption used:
WEP, 802.1x, or WPA/WPA2. (802.1x and WPA/WPA2
are not available for ad hoc networks.) If you select
Open network, no encryption is used. The WEP, 802.1x,
and WPA functions can be used only if the network
supports them.
•Use access point — Select After confirmation to set
the device to ask for confirmation before the
connection using this access point is created or
Automatically to set the device to connect to the
destination using this access point automatically.
To enter the settings for the selected security mode, select
WLAN security settings.
Advanced WLAN settings
Select Options > Advanced settings and from the
following:
•IPv4 settings — Enter the IP address of your device,
the subnet IP address, the default gateway, and the IP
addresses of the primary and secondary DNS servers.
Contact your internet service provider for these
addresses.
•IPv6 settings — Define the type of DNS address.
•Ad-hoc channel (only for ad hoc networks) — To enter
a channel number (1-11) manually, select User
defined.
•Proxy server address — Enter the address for the
proxy server.
•Proxy port number — Enter the proxy port number.
Packet data (GPRS) settings
Select Menu > Ctrl. panel > Settings and Connection >
Packet data.
Your device supports packet data connections, such as
GPRS in the GSM network. When you are using your device
in GSM and UMTS networks, it is possible to have multiple
data connections active at the same time; access points
can share a data connection, and data connections remain
active, for example, during voice calls.
To define the packet data settings, select Packet data
connection and When available to register the device to
the packet data network when you switch the device on
in a supported network, or When needed to register the 99
Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
device to a packet data network only when an application
or action attempts to establish a packet data connection.
This setting affects all access points for packet data
connections. To use the device as a packet data modem
for your computer, select Access point, and enter the
access point name provided by your service provider. To
use a high-speed data connection, select High speed
packet access > Enabled.
WLAN settings
SelectMenu > Ctrl. panel > Settings and Connection >
Wireless LAN.
To have an indicator displayed when there is a wireless
LAN (WLAN) available in your current location, select Show
WLAN availability > Yes.
To select the interval for your device to scan for available
WLANs, and to update the indicator, select Scan for
networks. This setting is not available unless you select
Show WLAN availability > Yes.
To set the device to test the internet capability of the
selected WLAN automatically, to ask for permission every
time, or to never perform the connectivity test, select
Internet connectivity test > Run automatically, Ask
every time, or Never run. If you select Run
automatically or allow the test to be performed when the
device asks for it, and the connectivity test is performed
successfully, the access point is saved to internet
destinations.
To check the unique media access control (MAC) address
that identifies your device, enter *#62209526# in the
home screen. The MAC address is displayed.
WLAN security settings
Select Menu > Ctrl. panel > Settings and Connection >
Destinations > Access point, and follow the instructions
on the display.
To edit a wireless LAN (WLAN) access point, open one of
the access point groups, and select an access point marked
with .
To enter the settings for the selected security mode, select
WLAN security settings.
Session initiation protocol
(SIP) settings
Select Menu > Ctrl. panel > Settings and Connection >
SIP settings.
The session initiation protocol (SIP) is used for creating,
modifying, and terminating certain types of
communication sessions with one or more participants
(network service). Typical communication sessions are
video sharing and net calls. SIP profiles include settings for
these sessions. The SIP profile used by default for a
communication session is underlined.
To create a SIP profile, select Options > New SIP
profile > Use default profile or Use existing profile.
To select the SIP profile you want to use by default for
communication sessions, select Options > Default
profile.
100
Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Edit SIP profiles
Select Menu > Ctrl. panel > Settings and Connection >
SIP settings.
Select Options > Edit and from the following:
•Profile name — Enter a name for the SIP profile.
•Service profile — Select IETF or Nokia 3GPP.
•Default destination — Select the destination to use
for the internet connection.
•Default access point — Select the access point to use
for the internet connection.
•Public user name — Enter your user name provided
by your service provider.
•Use compression — Select if compression is used.
•Registration — Select the registration mode.
•Use security — Select if security negotiation is used.
•Proxy server — Enter the proxy server settings for this
SIP profile.
•Registrar server — Enter the registration server
settings for this SIP profile.
Configuration settings
Select Menu > Ctrl. panel > Settings and Connection >
Configurations.
You can receive messages from your service provider or
company information management containing
configuration settings for trusted servers. These settings
are automatically saved in Configurations. You may
receive configuration settings for access points,
multimedia, or e-mail services, and instant messaging (IM)
or synchronisation settings from trusted servers.
To delete configurations for a trusted server, select
Options > Delete. The configuration settings for other
applications provided by this server are also deleted.
Restrict packet data
Select Menu > Ctrl. panel > Settings and Connection >
APN control.
With the access point control service, you can restrict
packet data connections from your device to certain access
points only. Your SIM card may not support the access
point control service. For more information, contact your
service provider.
To restrict packet data connections from your device,
select Options > Activate restrictions. You need your
PIN2 code to activate and deactivate access point control
or to edit the packet data access points on the control list.
To add access points that can be used for packet data
connections to the control list, select Options > Add
name manually. To enable connections to an operator-
provided access point, create an empty access point.
To remove access points from the list, select Options >
Remove.
Application settings
Select Menu > Ctrl. panel > Settings and
Applications.
Select an application from the list to adjust its settings.
101
Settings
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
15. Green tips
Here are tips on how you can contribute to
protecting the environment.
Save energy
When you have fully charged the battery and disconnected
the charger from the device, unplug the charger from the
wall outlet.
You do not need to charge your battery so often if you do
the following:
•Close and disable applications, services, and
connections when not in use.
•Decrease the brightness of the screen.
•Set the device to enter the power saver mode after the
minimum period of inactivity, if available in your
device.
•Disable unnecessary sounds, such as keypad and
ringing tones.
Recycle
Most of the materials in a Nokia phone are recyclable.
Check how to recycle your Nokia products at
www.nokia.com/werecycle, or with a mobile device,
www.nokia.mobi/werecycle.
Recycle packaging and user guides at your local recycling
scheme.
Save paper
This user guide helps you get started with your device. For
more detailed instructions, open the in-device help (in
most applications, select Options > Help). For further
support, see www.nokia.com/support.
Learn more
For more information on the environmental attributes of
your device, see www.nokia.com/ecodeclaration.
102
Green tips
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Accessories
Warning: Use only batteries, chargers, and
accessories approved by Nokia for use with this particular
model. The use of any other types may invalidate any
approval or warranty, and may be dangerous. In
particular, use of unapproved chargers or batteries may
present a risk of fire, explosion, leakage, or other hazard.
For availability of approved accessories, please check with
your dealer. When you disconnect the power cord of any
accessory, grasp and pull the plug, not the cord.
103
Accessories
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Battery
Battery and charger
information
Your device is powered by a rechargeable battery. The
battery intended for use with this device is BP-4L. Nokia
may make additional battery models available for this
device. This device is intended for use when supplied with
power from the following chargers: AC-10. The exact
charger model number may vary depending on the type
of plug. The plug variant is identified by one of the
following: E, EB, X, AR, U, A, C, K, or UB.
The battery can be charged and discharged hundreds of
times, but it will eventually wear out. When the talk and
standby times are noticeably shorter than normal, replace
the battery. Use only Nokia approved batteries, and
recharge your battery only with Nokia approved chargers
designated for this device.
If a battery is being used for the first time or if the battery
has not been used for a prolonged period, it may be
necessary to connect the charger, then disconnect and
reconnect it to begin charging the battery. If the battery
is completely discharged, it may take several minutes
before the charging indicator appears on the display or
before any calls can be made.
Safe removal. Always switch the device off and disconnect
the charger before removing the battery.
Proper charging. Unplug the charger from the electrical
plug and the device when not in use. Do not leave a fully
charged battery connected to a charger, since
overcharging may shorten its lifetime. If left unused, a fully
charged battery will lose its charge over time.
Avoid extreme temperatures. Always try to keep the
battery between 15°C and 25°C (59°F and 77°F). Extreme
temperatures reduce the capacity and lifetime of the
battery. A device with a hot or cold battery may not work
temporarily. Battery performance is particularly limited in
temperatures well below freezing.
Do not short-circuit. Accidental short-circuiting can occur
when a metallic object such as a coin, clip, or pen causes
direct connection of the positive (+) and negative (-)
terminals of the battery. (These look like metal strips on
the battery.) This might happen, for example, when you
carry a spare battery in your pocket or purse. Short-
circuiting the terminals may damage the battery or the
connecting object.
Disposal. Do not dispose of batteries in a fire as they may
explode. Dispose of batteries according to local
regulations. Please recycle when possible. Do not dispose
as household waste.
Leak. Do not dismantle, cut, open, crush, bend, puncture,
or shred cells or batteries. In the event of a battery leak,
prevent battery liquid contact with skin or eyes. If this
happens, flush the affected areas immediately with water,
or seek medical help.
Damage. Do not modify, remanufacture, attempt to insert
foreign objects into the battery, or immerse or expose it
104
Battery
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
to water or other liquids. Batteries may explode if
damaged.
Correct use. Use the battery only for its intended purpose.
Improper battery use may result in a fire, explosion, or
other hazard. If the device or battery is dropped, especially
on a hard surface, and you believe the battery has been
damaged, take it to a service centre for inspection before
continuing to use it. Never use any charger or battery that
is damaged. Keep your battery out of the reach of small
children.
Nokia battery
authentication
guidelines
Always use original Nokia batteries for your safety. To
check that you are getting an original Nokia battery,
purchase it from a Nokia authorised service centre or
dealer, and inspect the hologram label using the following
steps:
Authenticate hologram
1. When you look at the hologram on
the label, you should see the Nokia
connecting hands symbol from
one angle and the Nokia Original
Enhancements logo when looking
from another angle.
2. When you angle the hologram left,
right, down and up, you should see
1, 2, 3 and 4 dots on each side
respectively.
Successful completion of the steps is
not a total assurance of the
authenticity of the battery. If you
cannot confirm authenticity or if you
have any reason to believe that your
Nokia battery with the hologram on
the label is not an authentic Nokia
battery, you should refrain from using it, and take it to the
nearest Nokia authorised service centre or dealer for
assistance.
To find out more about original Nokia batteries, see
www.nokia.com/battery.
105
Battery
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Taking care of your device
Your device is a product of superior design and
craftsmanship and should be treated with care. The
following suggestions will help you protect your warranty
coverage.
•Keep the device dry. Precipitation, humidity, and all
types of liquids or moisture can contain minerals that
will corrode electronic circuits. If your device does get
wet, remove the battery, and allow the device to dry
completely before replacing it.
•Do not use or store the device in dusty, dirty areas. Its
moving parts and electronic components can be
damaged.
•Do not store the device in high or cold temperature.
High temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt certain
plastics. When the device warms to its normal
temperature from a cold temperature, moisture can
form inside the device and damage electronic circuit
boards.
•Do not attempt to open the device other than as
instructed in this guide.
•Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards and fine
mechanics.
•Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the device. Only use a soft, clean,
dry cloth to clean the surface of the device.
•Do not paint the device. Paint can clog the moving parts
and prevent proper operation.
•Use only the supplied or an approved replacement
antenna. Unauthorised antennas, modifications, or
attachments could damage the device and may violate
regulations governing radio devices.
•Use chargers indoors.
•Backup all data you want to keep, such as contacts and
calendar notes.
•To reset the device from time to time for optimum
performance, power off the device and remove the
battery.
These suggestions apply equally to your device, battery,
charger, or any accessory.
Recycle
Always return your used electronic products, batteries,
and packaging materials to dedicated collection points.
This way you help prevent uncontrolled waste disposal
and promote the recycling of materials. Check product
environmental information and how to recycle your Nokia
products at www.nokia.com/werecycle, or nokia.mobi/
werecycle.
The crossed-out wheeled-bin symbol on your
product, battery, literature, or packaging reminds
you that all electrical and electronic products,
batteries, and accumulators must be taken to
106
Taking care of your device
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
separate collection at the end of their working life. This
requirement applies in the European Union. Do not
dispose of these products as unsorted municipal waste.
For more environmental information, see the product Eco-
Declarations at www.nokia.com/environment.
107
Taking care of your device
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Additional safety information
Small children
Your device and its accessories are not toys. They may
contain small parts. Keep them out of the reach of small
children.
Operating environment
This device meets RF exposure guidelines in the normal
use position at the ear or at least 2.2 centimetres (7/8
inch) away from the body. Any carry case, belt clip, or
holder for body-worn operation should not contain metal
and should position the device the above-stated distance
from your body.
To send data files or messages requires a quality
connection to the network. Data files or messages may be
delayed until such a connection is available. Follow the
separation distance instructions until the transmission is
completed.
Parts of the device are magnetic. Metallic materials may
be attracted to the device. Do not place credit cards or
other magnetic storage media near the device, because
information stored on them may be erased.
Medical devices
Operation of radio transmitting equipment, including
wireless phones, may interfere with the function of
inadequately protected medical devices. Consult a
physician or the manufacturer of the medical device to
determine whether they are adequately shielded from
external RF energy. Switch off your device when
regulations posted instruct you to do so. Hospitals or
health care facilities may use equipment sensitive to
external RF energy.
Implanted medical devices
Manufacturers of medical devices recommend a minimum
separation of 15.3 centimetres (6 inches) between a
wireless device and an implanted medical device, such as
a pacemaker or implanted cardioverter defibrillator, to
avoid potential interference with the medical device.
Persons who have such devices should:
•Always keep the wireless device more than 15.3
centimetres (6 inches) from the medical device.
•Not carry the wireless device in a breast pocket.
•Hold the wireless device to the ear opposite the medical
device.
•Turn the wireless device off if there is any reason to
suspect that interference is taking place.
108
Additional safety information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
•Follow the manufacturer directions for the implanted
medical device.
If you have any questions about using your wireless device
with an implanted medical device, consult your health
care provider.
Hearing aids
Some digital wireless devices may interfere with some
hearing aids.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles such as
electronic fuel injection, electronic antilock braking,
electronic speed control, and air bag systems. For more
information, check with the manufacturer of your vehicle
or its equipment.
Only qualified personnel should service the device or
install the device in a vehicle. Faulty installation or service
may be dangerous and may invalidate your warranty.
Check regularly that all wireless device equipment in your
vehicle is mounted and operating properly. Do not store
or carry flammable liquids, gases, or explosive materials
in the same compartment as the device, its parts, or
accessories. Remember that air bags inflate with great
force. Do not place your device or accessories in the air bag
deployment area.
Switch off your device before boarding an aircraft. The use
of wireless teledevices in an aircraft may be dangerous to
the operation of the aircraft and may be illegal.
Potentially explosive
environments
Switch off your device in any area with a potentially
explosive atmosphere. Obey all posted instructions. Sparks
in such areas could cause an explosion or fire resulting in
bodily injury or death. Switch off the device at refuelling
points such as near gas pumps at service stations. Observe
restrictions in fuel depots, storage, and distribution areas;
chemical plants; or where blasting operations are in
progress. Areas with a potentially explosive atmosphere
are often, but not always, clearly marked. They include
areas where you would be advised to turn off your vehicle
engine, below deck on boats, chemical transfer or storage
facilities and where the air contains chemicals or particles
such as grain, dust, or metal powders. You should check
with the manufacturers of vehicles using liquefied
petroleum gas (such as propane or butane) to determine
if this device can be safely used in their vicinity.
Emergency calls
Important: This device operates using radio
signals, wireless networks, landline networks, and user-
programmed functions. If your device supports voice calls
over the internet (internet calls), activate both the internet
calls and the cellular phone. The device may attempt to
make emergency calls over both the cellular networks and
through your internet call provider if both are activated.
Connections in all conditions cannot be guaranteed. You 109
Additional safety information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
should never rely solely on any wireless device for
essential communications like medical emergencies.
To make an emergency call:
1. If the device is not on, switch it on. Check for adequate
signal strength. Depending on your device, you may
also need to complete the following:
•Insert a SIM card if your device uses one.
•Remove certain call restrictions you have activated
in your device.
•Change your profile from Offline or Flight profile to
an active profile.
2. Press the end key as many times as needed to clear the
display and ready the device for calls.
3. Enter the official emergency number for your present
location. Emergency numbers vary by location.
4. Press the call key.
When making an emergency call, give all the necessary
information as accurately as possible. Your wireless device
may be the only means of communication at the scene of
an accident. Do not end the call until given permission to
do so.
Certification
information (SAR)
This mobile device meets guidelines for exposure to
radio waves.
Your mobile device is a radio transmitter and receiver. It
is designed not to exceed the limits for exposure to radio
waves recommended by international guidelines. These
guidelines were developed by the independent scientific
organisation ICNIRP and include safety margins designed
to assure the protection of all persons, regardless of age
and health.
The exposure guidelines for mobile devices employ a unit
of measurement known as the Specific Absorption Rate or
SAR. The SAR limit stated in the ICNIRP guidelines is 2.0
watts/kilogram (W/kg) averaged over 10 grams of tissue.
Tests for SAR are conducted using standard operating
positions with the device transmitting at its highest
certified power level in all tested frequency bands. The
actual SAR level of an operating device can be below the
maximum value because the device is des igned to use only
the power required to reach the network. That amount
changes depending on a number of factors such as how
close you are to a network base station.
The highest SAR value under the ICNIRP guidelines for use
of the device at the ear is 1.20 W/kg.
Use of device accessories may result in different SAR
values. SAR values may vary depending on national
reporting and testing requirements and the network
band. Additional SAR information may be provided under
product information at www.nokia.com.
Your mobile device is also designed to meet the
requirements for exposure to radio waves established by
the Federal Communications Commission (USA) and
Industry Canada. These requirements set a SAR limit of 1.6
W/kg averaged over one gram of tissue. The highest SAR
value reported under this standard during product
certification for use at the ear is 1.04 W/kg and when
properly worn on the body is 0.70 W/kg.
110
Additional safety information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
Index
A
A-GPS (assisted GPS) 56
access codes 20
access points 97
groups 97
VPN 90
accessories
settings 94
active toolbar
in Photos 71
alarm clock 66
alert tones 92
animated screen saver 29
antennas 19
application manager 88
application settings 101
applications 88
common actions 26
assisted GPS (A-GPS) 56
audio messages 41
audio themes 30
auto-update for time/date 66
autolock period 94
B
background image 29
backing up device memory 63
battery
charge level 23
charging 13
inserting 12
blogs 51
Bluetooth 80
receiving data 79
security 81
sending data 79
Bluetooth connectivity
blocking devices 81
bookmarks 52
browser 50
bookmarks 52
browsing pages 50, 51
cache memory 52
searching content 52
security 52
settings 53
toolbar 51
widgets 51
browsing
intranet 54
C
cable 78
cache memory 52
calculator 63
calendar 33
creating entries 34
meeting requests 34
views 35
calendar key 33
caller ID 95
calls
answering 43
conference call 44
internet calls 48
making 43
muting the ringing tone 43
rejecting 43
settings 95
voice mail 44
camera
capturing images 68
full focus 68
toolbar 68
video clips 69
certificates
details 87
settings 87
charger
battery 13
Clock
settings 66
compass 62
conference calls 44
configuration messages 101
connection methods
Bluetooth 79
data cable 78
connections
PC connection 54
connectors 14
111
Index
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
contacts 35
adding ringing tones 36
contact groups 36
searching 36
settings 36
synchronising 89
converting
currencies 65
measurements 65
currency conversions 65
D
data connections 83
synchronisation 89
wireless 82
date
settings 93
date and time 66
decrypting
device memory and memory
card 86
dictionary 67
display
changing the look 29
indicators 23
settings 92
E
e-mail
accounts 41
adding attachments 39
deleting 40
disconnecting 41
downloading attachments 40
folders 41
out-of-office reply 41
reading 39
searching 40
sending 39
settings 41
setup 38
e-mail key 33
e-mail key settings 95
encrypting
device memory and memory
card 86
F
feeds, news 51
file manager 63
files
flash files 76
FM radio 76
G
gallery 69
presentations 70
sound clips 69
streaming links 70
general information 9
GPRS
settings 99
GPS (global positioning
system) 56
H
headset
connecting 17
help application 10
home key 33
home screen 32
settings 29
HSPA
HSDPA, HSUPA 78
I
indicators 23
inserting
battery 12
memory card 13
SIM card 12
installing applications 88
internet calls 48, 95
activating 48
making 48
settings 48
internet connection 50
See also
browser
intranet
browsing 54
J
Java applications 88
JME Java application support 88
K
keyguard 17
keypad
lock settings 94
locking 17
tones 92
keys 14, 15
112
Index
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
L
language
settings 93
location information 56
lock code 20, 85, 94
locking
device 85
device autolock 94
keypad 17, 94
logos
welcome logo 92
M
making a call 43
maps 58
browsing 58
compass 62
driving routes 61
finding locations 59
history 60
indicators 59
network positioning 58
routes 59
settings 62
synchronising 60
walking routes 60
measurements
converting 65
media
radio 76
meeting requests
receiving 40
memory
clearing 26
web cache 52
memory card
inserting 13
locking 85
passwords 85
removing 14
menu 22
messages
configuration messages 101
Mini Map 51
MMS (multimedia message
service) 41
modem 54
multimedia 69
multimedia messages 41
multitasking 37
music player
playing 75
transferring music 75
N
navigation tools 56
network
settings 96
news feeds 51
noise cancellation 43
Nokia support information 9
O
One-touch keys 93
operator
selecting 96
original settings 95
out-of-office reply message 41
Ovi 21
Ovi Maps 60
Ovi Store 54
P
packet data
restricting 101
settings 99
packet data connection
access point settings 98
page overview 51
pairing devices 80
PDF reader 65
personalisation 29
changing language 93
display 92
tones 92
phone setup 22
photos
toolbar 71
viewing 70
PIN code 20
changing 94
PIN2 code 20
positioning
settings 95
positioning information 56
predictive text input 25, 93
presentations 70
printing
printing files 65
printing images 65
profiles
creating 28
customising 28
113
Index
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
personalising 28
selecting ringing tones 28
proxy settings 98
PUK codes 20
Q
Quickoffice 64
R
radio 76
listening 76
settings 77
stations 77
remote database search 36
remote lock 85
restoring original settings 95
ringing tones 92
contacts 36
in profiles 28
vibrating alert 92
S
saving
files 26
settings 26
screen saver 29, 92
scroll key lights 93
searching 25
available WLANs 84
contacts 36
security
Bluetooth 81
device and SIM card 94
memory card 85
web browser 52
security code 20, 85
sending
files 26
using Bluetooth 79
services 21
settings
access points 97
accessories 94
applications 101
browser 53
call 95
certificate 87
clock 66
contacts 36
date 93
display 92
e-mail key 95
FM radio 77
GPRS 99
internet calls 48
keypad lock 94
language 93
network 96
packet data 99
packet data access points 98
positioning 95
restoring 95
scroll key lights 93
SIP 100
time 93
tones 92
video sharing 46
WLAN 99, 100
WLAN internet access points 99
WLAN security 100
settings wizard 22
Share online 71
accounts 72
activating services 72
creating posts 72
one-click upload 73
posting 72
subscribing 72
sharing media files online 71
signal strength 23
SIM card
inserting 12
SIP
creating profiles 100
editing profiles 101
settings 100
SMS (short message service) 41
software
updating 10
software applications 88
software updates 9, 10
sound clips 69
streaming links 70
support resources 9
switching device on and off 16
Symbian applications 88
synchronisation of data 89
T
tabs 26
text
changing size 92
letter mode 24
number mode 24
114
Index
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
predictive input 25
traditional input 24
text messages
sending 41
themes
audio 30
changing 29
time
settings 93
time and date 66
time zone settings 66
tones 92
settings 92
toolbar
camera 68
traditional text input 24
U
updates 10
UPIN code 20
changing 94
uploading media files 71
UPUK code 20
USB data cable 78
useful information 9
V
vibrating alert 92
video
shared 45
video calls
making a call 45
switching to voice call 45
Video Centre 73
video centre
downloading 73
my videos 74
transferring videos 74
viewing 73
video sharing
accepting invitation 47
sharing live video 46
sharing video clips 46
virtual private network
use in applications 91
voice functions 49
activating 49
voice mail
calling 44
changing number 44
volume 18
VPN
access points 90
use in applications 91
W
warning tones 92
web connection 50
web logs 51
welcome note 92
widgets 51
WLAN
access points 82
availability 82
MAC address 100
searching for networks 84
security settings 100
settings 100
WLAN (wireless local area
network) 82
WLAN wizard 82
world clock 66
Z
Zip manager 65
115
Index
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2009-11-09 15:1:46
