Nokia C3 User Guide

5555555

Issue 1

Cyan

Magenta

Yellow

Black

Contents

Safety 4

Support 5

Nokia C3 in brief 5

Key features 5

Keys and parts 5

Get started 6

Insert SIM card and battery 6

Switch on or off 7

Antennas 7

Charge the battery 7

Headset 7

Insert a microSD card 8

Remove the microSD card 8

Connect a USB data cable 8

Attach the wrist strap 9

Magnets and magnetic fields 9

Access codes 9

Home screen 9

Keypad lock 11

Use your device without a SIM card 11

Applications running in background 11

Calls 11

Make and answer a call 11

Loudspeaker 11

Dialling shortcuts 11

Write text 12

Write text using the keyboard 12

Predictive text input 12

Navigate the menus 13

Messaging 13

Text and multimedia messages 13

Flash messages 14

Nokia Xpress audio messages 14

Nokia Messaging Service 14

Voice messages 15

Message settings 15

Contacts 15

Music 16

Media player 16

FM radio 16

Photos 16

Capture images and record video

clips 16

View your images and video clips 17

Applications 17

Alarm clock 17

Gallery 17

Extras 17

Voice recorder 18

Calendar 18

Settings 18

Profiles 18

Tones 18

Display 19

Date and time 19

Shortcuts 19

Synchronisation and backup 19

Connectivity 19

Call and phone 22

Accessories 22

Configuration 22

Restore factory settings 23

Web or Internet 23

Connect to a web service 23

Operator menu 23

2Contents

Cyan

Magenta

Yellow

Black

SIM services 23

Green tips 23

Save energy 23

Recycle 24

Product and safety information 24

Index 30

Contents 3

Cyan

Magenta

Yellow

Black

Safety

Read these simple guidelines. Not

following them may be dangerous or

illegal. Read the complete user guide for

further information.

SWITCH ON SAFELY

Do not switch the device on

when wireless phone use is

prohibited or when it may

cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep

your hands free to operate the

vehicle while driving. Your first

consideration while driving

should be road safety.

INTERFERENCE

All wireless devices may be

susceptible to interference,

which could affect

performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch

the device off in aircraft, near

medical equipment, fuel,

chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may

install or repair this product.

ACCESSORIES AND BATTERIES

Use only approved accessories

and batteries. Do not connect

incompatible products.

WATER-RESISTANCE

Your device is not water-

resistant. Keep it dry.

4Safety

Cyan

Magenta

Yellow

Black

Support

When you want to learn more about how

to use your product or you are unsure how

your device should function, go to

www.nokia.com/support, or using a

mobile device, nokia.mobi/support.

If this does not resolve your issue, do one

of the following:

•Restore the original factory settings.

•Update your device software.

If your issue remains unsolved, contact

Nokia for repair options. Go to

www.nokia.com/repair, or in Latin

America, www.nokia-latinoamerica.com/

centrosdeservicio. Before sending your

device for repair, always back up the data

in your device.

Nokia C3 in brief

Model number: Nokia C3-00.1

Key features

Some of the key features are highlighted

here:

•Enjoy quick messaging experience

with the Full QWERTY keyboard.

•Gain handy internet access with a

wireless LAN (WLAN).

•Read and reply to your mail while on

the move.

•Manage your social network with the

dedicated keys.

•Enjoy quick and easy communication

with your favourite contacts.

•View a tracked correspondence with

conversational messaging view.

•Move your contacts, messages, and

calendar information from your

previous device to your Nokia C3 using

the Phone switch application.

Keys and parts

1Earpiece

2Selection keys

3Call key

4Navi™ key (scroll key)

5End/Power key

6Backspace key

7Enter key

8Microphone

9Space key

Support 5

Cyan

Magenta

Yellow

Black

10 Contacts key

11 Messaging key

12 Function key

13 Shift key

14 Symbol key

15 Ctrl key

16 Charger connector

17 Headset connector/Nokia AV

connector (3.5 mm)

18 Micro USB connector

19 Memory card slot

20 Release button

21 Loudspeaker

22 Camera lens

23 Wrist strap eyelet

Special key functions

•Contacts key and messaging key. To

access some messaging or contacts

features, press the contacts or

messaging key. You can assign

different functions to the keys.

•Function key. To change the writing

language, press the function key, then

the ctrl key.

•Shift key. To switch between the

character cases, press the shift key. To

copy or cut text, press and hold the

shift key, and scroll to highlight the

word, phrase, or line of text you want

to copy or cut. Press and hold the ctrl

key, and then press C (copy) or X (cut).

•Symbol key. To insert a special

symbol, press the symbol key, and

select the desired symbol.

•Ctrl key. To switch between Latin and

other text input methods, press the

ctrl key repeatedly.

Get started

Insert SIM card and battery

Safe removal. Always switch the device off

and disconnect the charger before

removing the battery.

The SIM card and its contacts can be easily

damaged by scratches or bending, so be

careful when handling, inserting, or

removing the card.

6Get started

Cyan

Magenta

Yellow

Black

1 Press the release buttons, and remove

the back cover (1, 2).

2 Remove the battery (3).

3 Insert the SIM card. Ensure the contact

surface area is facing down and the

bevelled corner of the SIM card is

facing the bottom of the device (4, 5,

6).

4 Replace the battery and the back

cover (7, 8, 9).

Switch on or off

Press and hold the power key.

Antennas

Your device may have internal and

external antennas. Avoid touching the

antenna area unnecessarily while the

antenna is transmitting or receiving.

Contact with antennas affects the

communication quality and may cause a

higher power level during operation and

may reduce the battery life.

Charge the battery

Your battery has been partially charged at

the factory. If the device indicates a low

charge, do the following:

1 Connect the charger to a wall outlet.

2 Connect the charger to the device.

3 When the device indicates a full

charge, disconnect the charger from

the device, then from the wall outlet.

You do not need to charge the battery for

a specific length of time, and you can use

the device while it is charging. If the

battery is completely discharged, it may

take several minutes before the charging

indicator appears on the display or before

any calls can be made.

Headset

Warning:

When you use the headset, your ability to

hear outside sounds may be affected. Do

not use the headset where it can

endanger your safety.

When connecting any external device or

any headset, other than those approved

by Nokia for use with this device, to the

Nokia AV Connector, pay special attention

to volume levels.

Get started 7

Cyan

Magenta

Yellow

Black

Do not connect products that create an

output signal as this may cause damage

to the device. Do not connect any voltage

source to the Nokia AV Connector.

Insert a microSD card

Use only compatible microSD cards

approved by Nokia for use with this

device. Nokia uses approved industry

standards for memory cards, but some

brands may not be fully compatible with

this device. Incompatible cards may

damage the card and the device and

corrupt data stored on the card.

Your phone supports microSD cards with

a capacity of up to 8 GB.

A compatible memory card may be

supplied with the device, and may already

be inserted in the device. If not, do the

following:

1 Open the cover of the memory card

slot.

2 Insert the card into the memory card

slot with the contact surface facing

up, and press until it locks into place.

3 Close the cover of the memory card

slot.

Remove the microSD card

Important: Do not remove the memory

card during an operation when the card is

being accessed. Doing so may damage the

memory card and the device, and corrupt

data stored on the card.

You can remove or replace the memory

card during phone operation without

switching the device off, but you need to

ensure that no application is currently

accessing the memory card.

Connect a USB data cable

Connect a compatible USB data cable to

the USB connector. You may need to

purchase a USB data cable separately.

8Get started

Cyan

Magenta

Yellow

Black

To modify the USB settings, select

Menu > Settings > Connectivity > USB

data cable and the desired mode.

Attach the wrist strap

Thread the wrist strap as shown, and

tighten it.

Magnets and magnetic fields

Keep your device away from magnets or

magnetic fields.

Access codes

The security code helps to protect your

device against unauthorised use. You can

create and change the code, and set the

device to request the code. Keep the code

secret and in a safe place separate from

your device. If you forget the code and

your device is locked, your device will

require service. Additional charges may

apply, and all the personal data in your

device may be deleted. For more

information, contact a Nokia Care point or

your device dealer.

The PIN code supplied with the SIM card

protects the card against unauthorised

use. The PIN2 code supplied with some

SIM cards is required to access certain

services. If you enter the PIN or PIN2 code

incorrectly three times in succession, you

are asked for the PUK or PUK2 code. If you

do not have them, contact your service

provider.

The module PIN is required to access the

information in the security module of your

SIM card. The signing PIN may be required

for the digital signature. The barring

password is required when using the call

barring service.

To set how your device uses the access

codes and security settings, select

Menu > Settings > Security.

Home screen

When the device is ready for use, and you

have not entered any characters, the

device is in the home screen.

Display

1Network signal strength

Get started 9

Cyan

Magenta

Yellow

Black

2Battery charge status

3Indicators

4Network name or the operator logo

5Profile

6Clock

7Date (if the enhanced home screen is

deactivated)

8Widget

9Display

10 Function of the selection key

Enhanced home screen

With the enhanced home screen, you can

display a list of selected information and

features that you can directly access.

Select Menu > Settings and Display >

Home screen.

Activate the enhanced home screen

Select Home screen mode > On.

Organise and personalise the

enhanced home screen

Select Personalise view.

Select the key used to activate the

enhanced home screen

Select Home screen key.

Navigate in the home screen

Scroll up or down to navigate the list, and

select Select, View, or Edit. The arrows

indicate that further information is

available.

Stop navigating

Select Exit.

Favourite contacts

Favourite contacts enables ease of

communication with your family and

friends.

Add the Favourite contacts widget to

the home screen

1 To activate the enhanced home

screen, select Menu > Settings and

Display > Home screen > Home

screen mode > On.

2 Select Personalise view. This step is

not needed if there are currently no

widgets added to the home screen.

3 Scroll to the desired content zone, and

select Change or Assign.

4 Select Favourite contacts from the

list.

In the home screen, scroll to the Favourite

contacts widget, and select the

appropriate option.

Add a favourite contact

Select Options > Add new favourite.

Call or send a text message to a

favourite contact

Scroll to the contact, and select

Options > Call or Send message.

Change the image for a favourite

contact

Scroll to the contact, and select

Options > Change image.

Organise your favourite contacts

Scroll to the contact, and select

Options > Organise favourites >

Move. Scroll to where you want to move

the contact, and select OK.

10 Get started

Cyan

Magenta

Yellow

Black

Remove a favourite contact

Scroll to the contact, and select

Options > Remove from favourites.

Removing a favourite contact does not

delete the contact from your contacts list.

Keypad lock

Lock the keypad

Select Menu, and press the function key

within 3.5 seconds.

Unlock the keypad

Select Unlock, and press the function key

within 3 seconds. If requested, enter the

lock code.

Answer a call when the keypad is

locked

Press the call key. When you end or reject

a call, the keypad locks automatically.

Set automatic keypad lock

Select Menu > Settings > Phone >

Automatic keyguard > On, and set the

length of time, after which the keypad

locks.

When the device or keypad is locked, calls

may be possible to the official emergency

number programmed into your device.

Use your device without a SIM card

Some features of your device may be used

without inserting a SIM card, such as

games. Features that are unavailable in

the offline profile cannot be selected in

menus.

Applications running in background

Leaving applications running in the

background increases the demand on

battery power and reduces the battery

life.

Calls

Make and answer a call

Make a call

Enter the phone number, including the

country and area code if necessary, and

press the call key.

Answer an incoming call

Press the call key.

Reject a call

Press the end key.

Adjust the volume

During a phone call, scroll up or down.

Loudspeaker

If available, you may select Loudspeak. or

Handset to use the loudspeaker or the

earpiece of the phone during a call.

Warning:

Continuous exposure to high volume may

damage your hearing. Listen to music at a

moderate level, and do not hold the device

near your ear when the loudspeaker is in

use.

Dialling shortcuts

Assign a phone number to a number

key

Select Menu > Contacts > More >

Speed dials, scroll to a desired number

(2-9), and select Assign. Enter the desired

phone number, or select Search and a

saved contact.

Calls 11

Cyan

Magenta

Yellow

Black

Activate speed dialling

Select Menu > Settings > Call > Speed

dialling > On.

Make a call using speed dialling

In the home screen, press and hold the

desired number key.

Write text

The input methods provided in the device

may vary according to different sales

markets.

Write text using the keyboard

Your device has a full keyboard.

Set the writing language

Select Options > Writing language and

the desired language. To change the

writing language, you can also press the

function key, then the ctrl key.

Switch between number and letter

mode

Press the function key repeatedly, until

the symbol for the desired input method

is displayed.

Lock number mode

Press the function key twice.

Unlock number mode

Press the function key.

Switch between the character cases

Press the shift key.

Insert numbers or characters printed

at the upper right corner of keys

Press and hold the corresponding key.

Delete a character

Select Clear. You can also press the

backspace key.

Insert special symbols

Press the symbol key, and select the

desired symbol. To view more symbols,

press the symbol key again.

Insert a new line

Press the enter key.

Insert a space

Press the space key.

Copy or cut text

Press and hold the shift key, and scroll to

highlight the word, phrase, or line of text

you want to copy or cut. Press and hold the

ctrl key, and then press C (copy) or X (cut).

Paste text

Go to the desired location, press and hold

the ctrl key, and then press V.

Predictive text input

Predictive text input is based on a built-in

dictionary. Not all languages are

supported.

Activate or deactivate predictive text

input

Select Options > More > Prediction

settings > Prediction > On or Off.

Switch between predictive and

traditional text input

Press and hold Options.

12 Write text

Cyan

Magenta

Yellow

Black

Write text with predictive text input

1 Start writing a word, using the

character keys. Your device suggests

possible words.

2 To confirm a word, scroll right or press

the space key.

If the word is not correct, scroll down

to access a list of suggested words,

and select the desired word.

3 Start writing the next word.

Navigate the menus

The device functions are grouped into

menus. Not all menu functions or option

items are described here.

In the home screen, select Menu and the

desired menu and submenu.

Exit the current menu level

Select Exit or Back.

Return to the home screen

Press the end key.

Change the menu view

Select Menu > Options > Main menu

view.

Messaging

Create and receive messages, such as text

and multimedia, with your device. The

messaging services can only be used if

your network or service provider supports

them.

Text and multimedia messages

You can create a message and optionally

attach, for example, a picture. Your phone

automatically changes a text message to

a multimedia message when a file is

attached.

Text messages

Your device supports text messages

beyond the limit for a single message.

Longer messages are sent as two or more

messages. Your service provider may

charge accordingly. Characters with

accents, other marks, or some language

options take more space, and limit the

number of characters that can be sent in

a single message.

The total number of characters left and

the number of messages needed for

sending are displayed.

To send messages, the correct message

centre number must be stored in your

device. Normally, this number is set by

default through your SIM card.

To set the number manually, do the

following:

1 Select Menu > Messaging > More >

Message settings > Text

messages > Message centre.

2 Enter the name and number supplied

by your service provider.

Multimedia messages

A multimedia message can contain text,

pictures, and sound or video clips.

Only devices that have compatible

features can receive and display

multimedia messages. The appearance of

a message may vary depending on the

receiving device.

The wireless network may limit the size of

MMS messages. If the inserted picture

Navigate the menus 13

Cyan

Magenta

Yellow

Black

exceeds this limit, the device may make it

smaller so that it can be sent by MMS.

Important: Exercise caution when

opening messages. Messages may contain

malicious software or otherwise be

harmful to your device or PC.

For availability and subscription to the

multimedia messaging service (MMS),

contact your service provider.

Create a message

1 Select Menu > Messaging > Create

message.

2 Write your message.

To insert a special character or a

smiley, select Options > Insert

symbol.

To attach an object to the message,

select Options > Insert object. The

message type changes automatically

to multimedia message.

3 To add recipients, select Send to and

a recipient.

To enter a phone number or mail

address manually, select Number or

mail. Enter a phone number, or select

E-mail, and enter a mail address.

4 Select Send.

Multimedia messages are indicated with

an icon at the top of the display.

Service providers may charge differently

depending on the message type. For

details, contact your service provider.

Conversation view

Your device supports conversational

messaging view. This feature displays text

and multimedia messages received from

and sent to a contact as a conversation.

This allows you to view your

correspondence with a contact, without

opening different folders.

View a tracked conversation with a

contact

Select Menu > Messaging >

Conversations and the desired

conversation.

Flash messages

Flash messages are text messages that are

instantly displayed upon reception.

Select Menu > Messaging.

1 Select More > Other messages >

Flash message.

2 Write your message.

3 Select Send to and a contact.

Nokia Xpress audio messages

Create and send audio messages using

MMS in a convenient way.

Select Menu > Messaging.

1 Select More > Other messages >

Audio message. The voice recorder

opens.

2 To record your message, select .

3 To stop recording, select .

4 Select Send to and a contact.

Nokia Messaging Service

Your device may support the Nokia

Messaging Service, which includes Mail,

Chat, and Communities for social

networking.

To check if this messaging system is

available, select Menu > Mail. If

14 Messaging

Cyan

Magenta

Yellow

Black

is displayed at the top of

the main view, the Nokia Messaging

Service is in use.

This feature is not available in all

countries. For details, contact your service

provider.

Voice messages

The voice mailbox is a network service to

which you may need to subscribe. For

more information, contact your service

provider.

Call your voice mailbox

Press and hold 1.

Edit your voice mailbox number

Select Menu > Messaging > More >

Voice messages and Voice mailbox

no..

Message settings

Select Menu > Messaging and More >

Message settings.

Select from the following:

General settings — Save copies of sent

messages in your device, overwrite old

messages if the message memory

becomes full, and set up other preferences

related to messages.

Text messages — Allow delivery reports,

set up message centres for SMS and SMS

mail, select the type of character support,

and set up other preferences related to

text messages.

Multimedia messages — Allow delivery

reports, set up the appearance of

multimedia messages, allow the

reception of multimedia messages and

advertisements, and set up other

preferences related to multimedia

messages.

Service messages — Activate service

messages, and set up preferences related

to service messages.

Contacts

You can save names and phone numbers

in the device memory and on the SIM card.

In the device memory, you can save

contacts with numbers and text items.

Names and numbers saved on the SIM card

are indicated with .

Select Menu > Contacts > Names.

Add a contact

Select Options > Add new contact.

Add details to a contact

Ensure that the memory in use is either

Phone or Phone and SIM. Scroll to a

contact, and select Details > Options >

Add detail.

Search for a contact

Select Names. Scroll through the list of

contacts, or enter the first characters of

the contact's name.

Copy a contact between the device

memory and SIM card

Select Names, scroll to the contact, and

select Options > More > Copy contact.

On the SIM card, you can save only one

phone number for each name.

To select the SIM card or device memory

for your contacts, to select how the names

and numbers in the contacts list are

displayed, and to view the memory

capacity for contacts, select Settings and

the appropriate option.

Contacts 15

Cyan

Magenta

Yellow

Black

You can send and receive a person's

contact information as a business card

from a compatible device that supports

the vCard standard.

Send a business card

Select a contact, Options > More > Send

business card, and the sending type.

Music

Media player

Your device includes a media player for

listening to songs or other MP3 or AAC

sound files.

Warning:

Continuous exposure to high volume may

damage your hearing. Listen to music at a

moderate level, and do not hold the device

near your ear when the loudspeaker is in

use.

Select Menu > Music > My music.

FM radio

The FM radio depends on an antenna other

than the wireless device antenna. A

compatible headset or accessory needs to

be attached to the device for the FM radio

to function properly.

Warning:

Continuous exposure to high volume may

damage your hearing. Listen to music at a

moderate level, and do not hold the device

near your ear when the loudspeaker is in

use.

Select Menu > Music > Radio.

Search for a neighbouring station

Press and hold the scroll key to the left or

right.

Save a station

Tune to the desired station, and select

Options > Save station.

Switch between saved stations

Scroll left or right to switch between

stations, or press the corresponding

number key of the memory location of a

desired station.

Adjust the volume

Scroll up or down.

Leave the radio playing in the

background

Press the end key.

Close the radio

Press and hold the end key.

Photos

Capture images and record video clips

Your device supports an image capture

resolution of 1600x1200 pixels.

Camera mode

Use the still image function

Select Menu > Photos > Camera.

Zoom in or out

Scroll up or down.

Capture an image

Select Capture.

16 Music

Cyan

Magenta

Yellow

Black

Set the preview mode and time

Select Options > Settings > Photo

preview time.

Activate the self-timer

Select Options and the desired option.

Video mode

Use the video function

Select Menu > Photos > Video camera.

Start recording a video clip

Select Record.

Switch between camera and video

mode

In camera or video mode, scroll left or

right.

View your images and video clips

View your images

Select Menu > Photos > My photos.

Watch your video clips

Select Menu > Photos > My videos.

Applications

Alarm clock

You can set an alarm to sound at a desired

time.

Set the alarm

1 Select Menu > Applications >

Alarm clock.

2 Set the alarm, and enter the alarm

time.

3 To issue an alarm on selected days of

the week, select Repeat: > On and

the days.

4 Select the alarm tone. If you select the

radio as the alarm tone, connect the

headset to the device.

5 Set the length of the snooze time-out

period, and select Save.

Stop the alarm

Select Stop. If you let the alarm sound for

a minute or select Snooze, the alarm

stops for the length of the snooze time-

out period, then resumes.

Gallery

In Gallery, you can manage images, video

clips, and music files.

View the Gallery contents

Select Menu > Applications > Gallery.

Extras

Your device may include some games and

Java™ applications specially designed for

your device.

Select Menu > Applications > Extras.

Open a game or application

Select Games, Collection, or Memory

card, and a game or an application.

View the amount of memory available

for game and application installations

Select Options > Memory status.

Download a game or application

Select Options > Downloads > Game

downloads or Application downloads.

Applications 17

Cyan

Magenta

Yellow

Black

Your device supports J2ME™ Java

applications. Make sure an application is

compatible with your device before

downloading it.

Important: Only install and use

applications and other software from

sources that you trust. Applications from

untrusted sources may include malicious

software that can access data stored in

your device, cause financial harm, or

damage your device.

The downloaded applications may be

saved in Gallery instead of Applications.

Voice recorder

Select Menu > Applications > Voice

recorder.

Start recording

Select the record icon.

Start recording during a call

Select Options > Record. When

recording a call, hold the phone in the

normal position near to your ear. The

recording is saved in the Recordings folder

in Gallery.

Listen to the latest recording

Select Options > Play last recorded.

Send the last recording in a

multimedia message

Select Options > Send last recorded.

Calendar

Select Menu > Calendar.

The current day is framed. If there are any

notes set for the day, the day is in bold.

Add a calendar note

Go to a date, and select Options > Make

a note.

View the details of a note

Go to the note, and select View.

Delete all notes from the calendar

Select Options > Delete notes > All

notes.

Settings

Profiles

Waiting for a call, but can’t let your device

ring? There are various settings groups

called profiles, which you can customise

with ringing tones for different events

and environments.

Select Menu > Settings > Profiles.

Select the desired profile and from the

following:

Activate — Activate the profile.

Personalise — Modify the profile

settings.

Timed — Set the profile to be active until

a certain time. When the time set for the

profile expires, the previous profile that

was not timed becomes active.

Tones

You can modify the tone settings of the

selected active profile.

Select Menu > Settings > Tones. You can

find the same settings in the Profiles

menu.

18 Calendar

Cyan

Magenta

Yellow

Black

Display

To view or adjust the wallpaper, font size,

or other features related to the device

display, select Menu > Settings >

Display.

Date and time

Select Menu > Settings > Date and

time.

Set the date and time

Select Date & time settings.

Set the date and time format

Select Date & time format.

Update the time automatically

according to the current time zone

Select Auto-update of time (network

service).

Shortcuts

With personal shortcuts, you can get quick

access to frequently used functions.

Select Menu > Settings > My shortcuts.

Assign functions to the selection keys

Select Right selection key or Left

selection key and a function from the list.

Assign shortcut functions to the

contacts or messaging key

Select Contacts key or Messaging key

and a function from the list.

Assign shortcut functions to the scroll

key

Select Navigation key. Scroll to the

desired direction, and select Change or

Assign and a function from the list.

Synchronisation and backup

Select Menu > Settings > Sync and

backup.

Select from the following:

Phone switch — Synchronise or copy

selected data, such as your contacts,

calendar entries, notes, or messages,

between your device and another device.

Create backup — Back up selected data.

Restore backup — Restore data from a

backup. To view the details of a backup

file, select Options > Details.

Data transfer — Synchronise or copy

selected data between your device and a

network server (network service).

Connectivity

Your phone has several features that allow

you to connect to other devices to

transmit and receive data.You can also

connect the phone to a wireless LAN to

access the internet.

WLAN connectivity

WLAN (wireless local area network) uses

wireless connections as transmission

path. You can search and connect to

available networks, save and manage

preferred networks, and change

connectivity settings.

Your device supports automatic WLAN

authentication. This facilitates your

internet access in some public places

requiring WLAN authentication.

To save energy, close your WLAN

connection when not in use.

Features using wireless LAN increase the

demand on battery power and reduce the

battery life.

Settings 19

Cyan

Magenta

Yellow

Black

Note: In France, you are only allowed to

use WLAN indoors.

Connect to a WLAN

Select Menu > Settings >

Connectivity > WLAN.

Search for available wireless local area

networks (WLAN)

Select Available WLANs and the desired

WLAN.

Update the WLAN list

Select Options > Refresh list.

Connect to a WLAN

Scroll to the WLAN, and select Connect.

Save a connected WLAN

Scroll to the WLAN, and select Options >

Save.

Disconnect from a WLAN

Scroll to the WLAN, and select Disconn..

View saved WLANs

Select Saved WLANs.

Modify internet connection settings

Select Internet connection > Ask first or

Do not ask. If you select Ask first, you will

be asked for the connection method every

time you open an application that

requires an internet connection, such as

Browser and Mail.

Modify automatic WLAN search

settings

Select WLAN search > On or Off.

When automatic WLAN search is

activated, the device will periodically

search for available saved WLANs and

open an internet connection, if needed by

an application. To save the battery,

deactivate the automatic search when not

needed.

Hidden WLANs do not broadcast their

service set identifier (SSID). They are

marked as (Hidden network) in the list

of available WLANs. You can only connect

to a hidden network if you know its SSID.

Connect to a hidden network

1 Select (Hidden network).

2 Enter the SSID of the network, and

select OK.

When you save the hidden network, it is

displayed in the list of available WLANs.

Important: Always enable one of the

available encryption methods to increase

the security of your wireless LAN

connection. Using encryption reduces the

risk of unauthorised access to your data.

Saved WLANs

Display, manage, connect to, and

prioritise your saved wireless LANs

(WLAN).

Select Menu > Settings >

Connectivity > WLAN and Saved

WLANs.

The WLAN with the highest priority is

listed first.

Manage your WLANs

Select Options and from the following:

Connect — Connect to the WLAN

manually.

Remove from list — Remove the WLAN.

Organise priority — Change the

priorities of saved WLANs.

20 Settings

Cyan

Magenta

Yellow

Black

Forward settings — Forward the

settings of a saved WLAN. Enter the

security code and phone number, and

select Send.

Add new network — Add a new WLAN,

and define the settings.

Edit WLAN parameters

Scroll to a WLAN, and select Edit and from

the following:

Connection method — Connect to an

available WLAN automatically.

Network name — Enter a name for the

WLAN.

Network settings — Define the WLAN

settings.

Bluetooth wireless technology

Bluetooth technology allows you to

connect your device, using radio waves, to

a compatible Bluetooth device or

accessory that is within 10 metres (32

feet).

Select Menu > Settings >

Connectivity > Bluetooth.

Set up a Bluetooth connection

1 Select My phone's name, and enter a

name for your device.

2 Select Bluetooth > On. indicates

that Bluetooth connectivity is active.

3 To connect your device to an audio

accessory, select Conn. to audio

access. and the device that you want

to connect to.

4 To pair your device with any

Bluetooth device in range, select

Paired devices > Add new device.

Scroll to a found device, and select

Add.

Enter a passcode (up to 16 characters)

on your device, and allow the

connection on the other Bluetooth

device.

If you are concerned about security,

deactivate the Bluetooth function, or set

Phone visibility to Hidden. Accept

Bluetooth communication only from

those you trust.

Connect your PC to the internet

You can use Bluetooth technology to

connect your compatible PC to the

internet without the PC Suite software.

Your device must be able to connect to the

internet (network service), and your PC

must support Bluetooth technology. After

connecting to the network access point

(NAP) service of the device, and pairing

with your PC, your device automatically

opens a packet data connection to the

internet.

This device is compliant with Bluetooth

Specification 2.1 + EDR supporting the

following profiles: generic access, hands-

free, headset, object push, file transfer,

dial-up networking, serial port, SIM

access, and generic object exchange. To

ensure interoperability between other

devices supporting Bluetooth technology,

use Nokia approved accessories for this

model. Check with the manufacturers of

other devices to determine their

compatibility with this device.

Features using Bluetooth technology

increase the demand on battery power

and reduce the battery life.

Packet data

General packet radio service (GPRS) is a

network service that allows mobile

Settings 21

Cyan

Magenta

Yellow

Black

phones to send and receive data over an

internet protocol (IP) based network.

To define how to use the service, select

Menu > Settings > Connectivity >

Packet data > Packet data conn. and

from the following:

When needed — Establish a packet data

connection when needed by an

application. The connection is closed

when the application is closed.

Always online — Automatically connect

to a packet data network when you switch

the device on.

You can use your device as a modem by

connecting it to a compatible PC using

Bluetooth technology. For details, see the

Nokia PC Suite documentation.

Call and phone

Select Menu > Settings > Call.

Divert incoming calls

Select Call divert (network service). For

details, contact your service provider.

Automatically redial ten times after an

unsuccessful attempt

Select Automatic redial > On.

Get a notification of incoming calls

while you are in a call

Select Call waiting > Activate (network

service).

Display or hide your number to the

person you are calling

Select Send my caller ID (network

service).

Select Menu > Settings > Phone.

Set the display language

Select Language settings > Phone

language.

Accessories

This menu is only available if the device is

or has been connected to a compatible

accessory.

Select Menu > Settings > Accessories.

Select an accessory and an option,

depending on the accessory.

Configuration

You can configure your device with

settings that are required for certain

services. Your service provider may also

send you these settings.

Select Menu > Settings and

Configuration.

Select from the following:

Default config. sett. — View the service

providers saved in the device, and set a

default service provider.

Act. def. in all apps. — Activate the

default configuration settings for

supported applications.

Preferred access pt. — View the saved

access points.

Personal settings — Add new personal

accounts for various services, and activate

or delete them. To add a new personal

account, select Add or Options > Add

new. Select the service type, and enter the

required information. To activate a

personal account, scroll to the account,

and select Options > Activate.

22 Settings

Cyan

Magenta

Yellow

Black

Restore factory settings

To restore the device back to the default

settings, select Menu > Settings >

Restore factory sett..

To reset all preference settings without

deleting any personal data, select

Settings only.

To reset all preference settings and delete

all personal data, such as contacts,

messages, media files, and activation

keys, select All.

Web or Internet

You can access various internet services

with your phone browser. The appearance

of the web pages may vary due to screen

size. You may not be able to see all the

details on the web pages.

Depending on your phone, the web

browsing function may be displayed as

Web or Internet in the menu, hereafter

referred to as Web.

Important: Use only services that you

trust and that offer adequate security and

protection against harmful software.

For the availability of these services,

pricing, and instructions, contact your

service provider.

You may receive the configuration

settings required for browsing as a

configuration message from your service

provider.

Connect to a web service

Select Menu > Internet > Home. Or, in

the home screen, press and hold 0.

After you make a connection to the

service, you can start browsing its pages.

The function of the device keys may vary

in different services. Follow the

instructions on the display. For more

information, contact your service

provider.

Operator menu

Access a portal to services provided by

your network operator. For more

information, contact your network

operator. The operator can update this

menu with a service message.

SIM services

Your SIM card may provide additional

services. You can access this menu only if

it is supported by your SIM card. The name

and contents of the menu depend on the

available services.

Green tips

Save energy

You do not need to charge your battery so

often if you do the following (if available

for your device):

•Close applications and data

connections, for example, your

Bluetooth connection, when not in

use.

•Decrease the brightness of the screen.

Web or Internet 23

Cyan

Magenta

Yellow

Black

•Set your device to enter power saver

mode after the minimum period of

inactivity, if available in your device.

•Deactivate unnecessary sounds, such

as key tones.

Recycle

All materials of this device can be

recovered as materials and energy. For

information on how to recycle your old

Nokia products, go to www.nokia.com/

werecycle, or using a mobile device,

www.nokia.mobi/werecycle.

Recycle packaging and user guides at your

local recycling scheme.

For more information on the

environmental attributes of your device,

go to www.nokia.com/ecodeclaration.

Product and safety information

General information

About your device

The wireless device described in this guide is approved for

use on the (E)GSM 850, 900, 1800, and 1900 MHz networks.

Contact your service provider for more information about

networks.

Your device may have preinstalled bookmarks and links for

third-party internet sites and may allow you to access third-

party sites. These are not affiliated with Nokia, and Nokia

does not endorse or assume liability for them. If you access

such sites, take precautions for security or content.

Warning:

To use any features in this device, other than the alarm clock,

the device must be switched on. Do not switch the device on

when wireless device use may cause interference or danger.

When using this device, obey all laws and respect local

customs, privacy and legitimate rights of others, including

copyrights. Copyright protection may prevent some images,

music, and other content from being copied, modified, or

transferred.

Make back-up copies or keep a written record of all important

information stored in your device.

When connecting to any other device, read its user guide for

detailed safety instructions. Do not connect incompatible

products.

The images in this guide may differ from your device display.

Refer to the user guide for other important information about

your device.

Network services

To use the device you must have service from a wireless

service provider. Some features are not available on all

networks; other features may require that you make specific

arrangements with your service provider to use them.

Network services involve transmission of data. Check with

your service provider for details about fees in your home

network and when roaming on other networks. Your service

provider can explain what charges will apply. Some networks

may have limitations that affect how you can use some

features of this device requiring network support such as

support for specific technologies like WAP 2.0 protocols (HTTP

and SSL) that run on TCP/IP protocols and language-

dependent characters.

Your service provider may have requested that certain

features be disabled or not activated in your device. If so,

these features will not appear on your device menu. Your

device may also have customized items such as menu names,

menu order, and icons.

Shared memory

The following features in this device may share memory:

multimedia messaging (MMS). Use of one or more of these

features may reduce the memory available for the remaining

features. If your device displays a message that the memory

is full, delete some of the information stored in the shared

memory.

Digital rights management

Content owners may use different types of digital rights

management (DRM) technologies to protect their intellectual

property, including copyrights. This device uses various types

of DRM software to access DRM-protected content. With this

device you can access content protected with WMDRM 10,

OMA DRM 1.0, OMA DRM 1.0 forward lock, and OMA DRM 2.0. If

certain DRM software fails to protect the content, content

owners may ask that such DRM software's ability to access

new DRM-protected content be revoked. Revocation may also

prevent renewal of such DRM-protected content already in

your device. Revocation of such DRM software does not affect

the use of content protected with other types of DRM or the

use of non-DRM-protected content.

24 Product and safety information

Cyan

Magenta

Yellow

Black

Accessories

Warning:

Use only batteries, chargers, and accessories approved by

Nokia for use with this particular model. The use of any other

types may invalidate any approval or warranty, and may be

dangerous. In particular, use of unapproved chargers or

batteries may present a risk of fire, explosion, leakage, or

other hazard.

For availability of approved accessories, please check with

your dealer. When you disconnect the power cord of any

accessory, grasp and pull the plug, not the cord.

Battery

Battery and charger information

Your device is powered by a rechargeable battery. The battery

intended for use with this device is BL-5J. Nokia may make

additional battery models available for this device. This

device is intended for use when supplied with power from

the following chargers: AC-3. The exact charger model

number may vary depending on the type of plug. The plug

variant is identified by one of the following: E, EB, X, AR, U, A,

C, K, or UB.

The battery can be charged and discharged hundreds of

times, but it will eventually wear out. When the talk and

standby times are noticeably shorter than normal, replace the

battery. Use only Nokia approved batteries, and recharge

your battery only with Nokia approved chargers designated

for this device.

If a battery is being used for the first time or if the battery has

not been used for a prolonged period, it may be necessary to

connect the charger, then disconnect and reconnect it to

begin charging the battery. If the battery is completely

discharged, it may take several minutes before the charging

indicator appears on the display or before any calls can be

made.

Safe removal. Always switch the device off and disconnect the

charger before removing the battery.

Proper charging. Unplug the charger from the electrical plug

and the device when not in use. Do not leave a fully charged

battery connected to a charger, since overcharging may

shorten its lifetime. If left unused, a fully charged battery will

lose its charge over time.

Avoid extreme temperatures. Always try to keep the battery

between 15°C and 25°C (59°F and 77°F). Extreme

temperatures reduce the capacity and lifetime of the battery.

A device with a hot or cold battery may not work temporarily.

Battery performance is particularly limited in temperatures

well below freezing.

Do not short-circuit. Accidental short-circuiting can occur

when a metallic object such as a coin, clip, or pen causes direct

connection of the positive (+) and negative (-) terminals of

the battery. (These look like metal strips on the battery.) This

might happen, for example, when you carry a spare battery

in your pocket or purse. Short-circuiting the terminals may

damage the battery or the connecting object.

Disposal. Do not dispose of batteries in a fire as they may

explode. Dispose of batteries according to local regulations.

Please recycle when possible. Do not dispose as household

waste.

Leak. Do not dismantle, cut, open, crush, bend, puncture, or

shred cells or batteries. In the event of a battery leak, prevent

battery liquid contact with skin or eyes. If this happens, flush

the affected areas immediately with water, or seek medical

help.

Damage. Do not modify, remanufacture, attempt to insert

foreign objects into the battery, or immerse or expose it to

water or other liquids. Batteries may explode if damaged.

Correct use. Use the battery only for its intended purpose.

Improper battery use may result in a fire, explosion, or other

hazard. If the device or battery is dropped, especially on a

hard surface, and you believe the battery has been damaged,

take it to a service centre for inspection before continuing to

use it. Never use any charger or battery that is damaged. Keep

your battery out of the reach of small children.

Nokia battery authentication guidelines

Always use original Nokia batteries for your safety. To check

that you are getting an original Nokia battery, purchase it

from a Nokia authorised service centre or dealer, and inspect

the hologram label using the following steps:

Authenticate hologram

1 When you look at the hologram on the label, you should

see the Nokia connecting hands symbol from one angle

and the Nokia Original Enhancements logo when

looking from another angle.

Product and safety information 25

Cyan

Magenta

Yellow

Black

2 When you angle the hologram left, right, down and up,

you should see 1, 2, 3 and 4 dots on each side

respectively.

Successful completion of the steps is not a total assurance of

the authenticity of the battery. If you cannot confirm

authenticity or if you have any reason to believe that your

Nokia battery with the hologram on the label is not an

authentic Nokia battery, you should refrain from using it, and

take it to the nearest Nokia authorised service centre or

dealer for assistance.

For additional information, refer to the warranty and

reference leaflet included with your Nokia device.

Taking care of your device

Your device is a product of superior design and craftsmanship

and should be treated with care. The following suggestions

will help you protect your warranty coverage.

•Keep the device dry. Precipitation, humidity, and all

types of liquids or moisture can contain minerals that

will corrode electronic circuits. If your device does get

wet, remove the battery, and allow the device to dry

completely before replacing it.

•Do not use or store the device in dusty, dirty areas. Its

moving parts and electronic components can be

damaged.

•Do not store the device in high or cold temperature.

High temperatures can shorten the life of electronic

devices, damage batteries, and warp or melt certain

plastics. When the device warms to its normal

temperature from a cold temperature, moisture can

form inside the device and damage electronic circuit

boards.

•Do not attempt to open the device other than as

instructed in this guide.

•Do not drop, knock, or shake the device. Rough

handling can break internal circuit boards and fine

mechanics.

•Do not use harsh chemicals, cleaning solvents, or strong

detergents to clean the device. Only use a soft, clean,

dry cloth to clean the surface of the device.

•Do not paint the device. Paint can clog the moving parts

and prevent proper operation.

•Use only the supplied or an approved replacement

antenna. Unauthorised antennas, modifications, or

attachments could damage the device and may violate

regulations governing radio devices.

•Use chargers indoors.

•Backup all data you want to keep, such as contacts and

calendar notes.

•To reset the device from time to time for optimum

performance, power off the device and remove the

battery.

These suggestions apply equally to your device, battery,

charger, or any accessory.

Recycle

Always return your used electronic products, batteries, and

packaging materials to dedicated collection points. This way

you help prevent uncontrolled waste disposal and promote

the recycling of materials. Check product environmental

information and how to recycle your Nokia products at

www.nokia.com/werecycle, or nokia.mobi/werecycle.

Additional safety information

The surface of this device is nickel-free.

Small children

Your device and its accessories are not toys. They may contain

small parts. Keep them out of the reach of small children.

Operating environment

This device meets RF exposure guidelines in the normal use

position at the ear or at least 1.5 centimetres (5/8 inch) away

from the body. Any carry case, belt clip, or holder for body-

worn operation should not contain metal and should position

the device the above-stated distance from your body.

To send data files or messages requires a quality connection

to the network. Data files or messages may be delayed until

such a connection is available. Follow the separation distance

instructions until the transmission is completed.

Parts of the device are magnetic. Metallic materials may be

attracted to the device. Do not place credit cards or other

magnetic storage media near the device, because

information stored on them may be erased.

Medical devices

Operation of radio transmitting equipment, including

wireless phones, may interfere with the function of

inadequately protected medical devices. Consult a physician

or the manufacturer of the medical device to determine

whether they are adequately shielded from external RF

26 Product and safety information

Cyan

Magenta

Yellow

Black

energy. Switch off your device when regulations posted

instruct you to do so. Hospitals or health care facilities may

use equipment sensitive to external RF energy.

Implanted medical devices

Manufacturers of medical devices recommend a minimum

separation of 15.3 centimetres (6 inches) between a wireless

device and an implanted medical device, such as a pacemaker

or implanted cardioverter defibrillator, to avoid potential

interference with the medical device. Persons who have such

devices should:

•Always keep the wireless device more than 15.3

centimetres (6 inches) from the medical device.

•Not carry the wireless device in a breast pocket.

•Hold the wireless device to the ear opposite the medical

device.

•Turn the wireless device off if there is any reason to

suspect that interference is taking place.

•Follow the manufacturer directions for the implanted

medical device.

If you have any questions about using your wireless device

with an implanted medical device, consult your health care

provider.

Hearing aids

Some digital wireless devices may interfere with some

hearing aids.

Vehicles

RF signals may affect improperly installed or inadequately

shielded electronic systems in motor vehicles such as

electronic fuel injection, electronic antilock braking,

electronic speed control, and air bag systems. For more

information, check with the manufacturer of your vehicle or

its equipment.

Only qualified personnel should service the device or install

the device in a vehicle. Faulty installation or service may be

dangerous and may invalidate your warranty. Check regularly

that all wireless device equipment in your vehicle is mounted

and operating properly. Do not store or carry flammable

liquids, gases, or explosive materials in the same

compartment as the device, its parts, or accessories.

Remember that air bags inflate with great force. Do not place

your device or accessories in the air bag deployment area.

Switch off your device before boarding an aircraft. The use of

wireless teledevices in an aircraft may be dangerous to the

operation of the aircraft and may be illegal.

Potentially explosive environments

Switch off your device in any area with a potentially explosive

atmosphere. Obey all posted instructions. Sparks in such

areas could cause an explosion or fire resulting in bodily

injury or death. Switch off the device at refuelling points such

as near gas pumps at service stations. Observe restrictions in

fuel depots, storage, and distribution areas; chemical plants;

or where blasting operations are in progress. Areas with a

potentially explosive atmosphere are often, but not always,

clearly marked. They include areas where you would be

advised to turn off your vehicle engine, below deck on boats,

chemical transfer or storage facilities and where the air

contains chemicals or particles such as grain, dust, or metal

powders. You should check with the manufacturers of

vehicles using liquefied petroleum gas (such as propane or

butane) to determine if this device can be safely used in their

vicinity.

Emergency calls

Important: This device operates using radio signals,

wireless networks, landline networks, and user-programmed

functions. If your device supports voice calls over the internet

(internet calls), activate both the internet calls and the

cellular phone. The device may attempt to make emergency

calls over both the cellular networks and through your

internet call provider if both are activated. Connections in all

conditions cannot be guaranteed. You should never rely

solely on any wireless device for essential communications

like medical emergencies.

To make an emergency call:

1 If the device is not on, switch it on. Check for adequate

signal strength. Depending on your device, you may

also need to complete the following:

•Insert a SIM card if your device uses one.

•Remove certain call restrictions you have

activated in your device.

•Change your profile from Offline or Flight profile

to an active profile.

2 Press the end key as many times as needed to clear the

display and ready the device for calls.

3 Enter the official emergency number for your present

location. Emergency numbers vary by location.

4Press the call key.

When making an emergency call, give all the necessary

information as accurately as possible. Your wireless device

may be the only means of communication at the scene of an

accident. Do not end the call until given permission to do so.

Product and safety information 27

Cyan

Magenta

Yellow

Black

Certification information (SAR)

This mobile device meets guidelines for exposure to

radio waves.

Your mobile device is a radio transmitter and receiver. It is

designed not to exceed the limits for exposure to radio waves

recommended by international guidelines. These guidelines

were developed by the independent scientific organisation

ICNIRP and include safety margins designed to assure the

protection of all persons, regardless of age and health.

The exposure guidelines for mobile devices employ a unit of

measurement known as the Specific Absorption Rate or SAR.

The SAR limit stated in the ICNIRP guidelines is 2.0 watts/

kilogram (W/kg) averaged over 10 grams of tissue. Tests for

SAR are conducted using standard operating positions with

the device transmitting at its highest certified power level in

all tested frequency bands. The actual SAR level of an

operating device can be below the maximum value because

the device is designed to use only the power required to reach

the network. That amount changes depending on a number

of factors such as how close you are to a network base station.

The highest SAR value under the ICNIRP guidelines for use of

the device at the ear is 0.99 W/kg.

Use of device accessories may result in different SAR values.

SAR values may vary depending on national reporting and

testing requirements and the network band. Additional SAR

information may be provided under product information at

www.nokia.com.

Your mobile device is also designed to meet the requirements

for exposure to radio waves established by the Federal

Communications Commission (USA) and Industry Canada.

These requirements set a SAR limit of 1.6 W/kg averaged over

one gram of tissue. The highest SAR value reported under this

standard during product certification for use at the ear is 1.06

W/kg and when properly worn on the body is 0.87 W/kg.

DECLARATION OF CONFORMITY

Hereby, NOKIA CORPORATION declares that this RM-614

product is in compliance with the essential requirements and

other relevant provisions of Directive 1999/5/EC. A copy of the

Declaration of Conformity can be found at www.nokia.com/

phones/declaration_of_conformity/.

Nokia, Nokia Connecting People, and Navi are trademarks or

registered trademarks of Nokia Corporation. Nokia tune is a

sound mark of Nokia Corporation. Other product and

company names mentioned herein may be trademarks or

tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all

of the contents in this document in any form without the prior

written permission of Nokia is prohibited. Nokia operates a

policy of continuous development. Nokia reserves the right

to make changes and improvements to any of the products

described in this document without prior notice.

Includes RSA BSAFE cryptographic or security protocol

software from RSA Security.

Java and all Java-based marks are trademarks or registered

trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent

Portfolio License (i) for personal and noncommercial use in

connection with information which has been encoded in

compliance with the MPEG-4 Visual Standard by a consumer

engaged in a personal and noncommercial activity and (ii) for

use in connection with MPEG-4 video provided by a licensed

video provider. No license is granted or shall be implied for

any other use. Additional information, including that related

to promotional, internal, and commercial uses, may be

obtained from MPEG LA, LLC. See http://www.mpegla.com.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,

UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS

LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME

OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT

DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS".

EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF

ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT

LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN

RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS

DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS

DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR

NOTICE.

The availability of particular products and applications and

services for these products may vary by region. Please check

28 Copyright and other notices

Cyan

Magenta

Yellow

Black

with your Nokia dealer for details and availability of language

options. This device may contain commodities, technology or

software subject to export laws and regulations from the US

and other countries. Diversion contrary to law is prohibited.

The third-party applications provided with your device may

have been created and may be owned by persons or entities

not affiliated with or related to Nokia. Nokia does not own

the copyrights or intellectual property rights to the third-

party applications. As such, Nokia does not take any

responsibility for end-user support, functionality of the

applications, or the information in the applications or these

materials. Nokia does not provide any warranty for the third-

party applications.

BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE

APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF

ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT

PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE

THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY

REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED,

INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE,

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR

THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY

PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example,

when using a telephone in close proximity to receiving

equipment). The FCC or Industry Canada can require you to

stop using your telephone if such interference cannot be

eliminated. If you require assistance, contact your local

service facility. This device complies with part 15 of the FCC

rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including

interference that may cause undesired operation. Any

changes or modifications not expressly approved by Nokia

could void the user's authority to operate this equipment.

5555555/Issue 1 EN

Cyan

Magenta

Yellow

Black

Index

access codes 9

accessories 22

alarm clock 17

antennas 7

audio messages 14

backing up data 19

battery 6

— charging 7

battery charge level 9

Bluetooth 21

browser 23

business cards 15

cable connection 8

calendar 18

calls 11

camera 16

configuration 22

contacts 10, 15

conversation view 14

date and time 19

display settings 19

extras 17

factory settings, restoring 23

flash messages 14

Gallery 17

games 17

headset 7

home screen 10

image mode 16

images 17

indicators 9

internet 23

keyboard 12

keyguard 11

keypad lock 11

keys and parts 5

media player 16

memory card 8

menus 13

message centre number 13

message settings 15

messages 14

microSD card 8

Nokia Messaging Service 14

Nokia support information 5

offline profile 11

operator menu 23

passwords 9

PIN code 9

powering device on/off 7

profiles 18

30 Index

Cyan

Magenta

Yellow

Black

restoring settings 23

security code 9

settings 18

— phone 22

settings, display 19

shortcuts 19

signal strength 9

SIM card 6, 11

speed dialling 11

support 5

switching device on/off 7

synchronisation 19

text input 12

text messages 13

tones 18

turning device on/off 7

USB connection 8

video clips 17

video mode 16

voice messages 15

voice recorder 18

web 23

WLAN (wireless local area network) 20

write text 12

Index 31

Cyan

Magenta

Yellow

Black

Microsoft RM-614 GSM 850/900/1800/1900 Cellular Telephone with BT/WLAN User Manual Manual

Microsoft Mobile Oy GSM 850/900/1800/1900 Cellular Telephone with BT/WLAN Manual

Manual

Navigation menu

Namespaces

Views

Navigation
