Manual 1
Product and safety information
5555555
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. For further information, read the
complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when
mobile phone use is not
allowed or when it may cause
interference or danger, for
example, in aircraft, in
hospitals or near medical
equipment, fuel, chemicals, or
blasting areas. Obey all
instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep
your hands free to operate the
vehicle while driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
BATTERIES, CHARGERS, AND OTHER
ACCESSORIES
Use only batteries, chargers,
and other accessories approved
by Nokia for use with this
device. Do not connect
incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-
resistant. Keep it dry.
GLASS PARTS
The front cover of the device is
made of glass. This glass can
break if the device is dropped
on a hard surface or receives a
substantial impact. If the glass
breaks, do not touch the glass
parts of the device or attempt
to remove the broken glass
from the device. Stop using the
device until the glass is
replaced by qualified service
personnel.
PROTECT YOUR HEARING
Listen to a headset at a
moderate level, and do not hold
the device near your ear when
the loudspeaker is in use.
2Safety
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Charge the battery
Your battery has been partially charged at
the factory, but you may need to recharge
it before you can switch on your phone for
the first time.
If the phone indicates a low charge, do the
following:
1
2
You do not need to charge the battery for
a specific length of time, and you can use
the phone while it is charging.
If the battery is completely discharged, it
may take several minutes before the
charging indicator is displayed or before
any calls can be made.
Tip: You can also use a compatible USB
charger to charge your battery.
Product and safety information
Feature specific instructions
Your device contains an in-device user guide, which you can
refer to for additional information about your device. To read
the user guide, select > User guide.
For additional product support information, see the warranty
and reference leaflet included with your Nokia device.
Some home screen widgets may connect to the internet
automatically. To prevent this, select > Widgets to
offline mode.
The social networking services are third-party services and
not provided by Nokia. Check the privacy settings of the social
networking service you are using as you may share
information with a large group of people. The terms of use
of the social networking service apply to sharing information
on that service. Familiarise yourself with the terms of use and
the privacy practices of that service.
This device is able to communicate with Microsoft Exchange
ActiveSync enabled servers. The provision of this device to
you does not grant you, and you do not receive, any rights
under any Microsoft intellectual property with respect to any
server software, or server device, that is accessed using this
device or with respect to use of Microsoft Exchange ActiveSync
apart from this device.
Important: To prevent damage to the SIM card,
always remove the battery before you insert or remove the
card.
Charge the battery 3
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Important: Do not use a mini-UICC SIM card, also
known as a micro-SIM card, a micro-SIM card with an adapter,
or a SIM card that has a mini-UICC cutout (see figure) in this
device. A micro SIM card is smaller than the standard SIM card.
This device does not support the use of micro-SIM cards and
use of incompatible SIM cards may damage the card or the
device, and may corrupt data stored on the card.
Note: Using FM transmitter may be restricted in
some countries. For more information, contact your local
authorities and go to www.nokia.com/fmtransmitter
Important: Before sharing your location, always
consider carefully with whom you are sharing. Check the
privacy settings of the social networking service you are
using, as you might share your location with a large group of
people.
Do not connect products that create an output signal, as this
may damage the device. Do not connect any voltage source
to the Nokia AV connector. If you connect an external device
or headset, other than those approved by Nokia for use with
this device, to the Nokia AV connector, pay special attention
to volume levels.
The personal unblocking key (PUK) code and the universal
personal unblocking key (UPUK) code (8 digits) are required
to change a blocked PIN code and UPIN code, respectively. The
PUK2 code (8 digits) is required to change a blocked PIN2
code. These codes are not supplied with the SIM card. Contact
your local service provider for the codes.
The availability and quality of GPS signals may be affected by
your location, satellite positions, buildings, natural obstacles,
weather conditions, and adjustments to GPS satellites made
by the United States government. GPS signals may not be
available inside buildings or underground.
Do not use GPS for precise location measurement, and never
rely solely on the location information provided by GPS and
cellular networks.
You can send text messages that are longer than the character
limit for a single message. Longer messages are sent as two
or more messages. Your service provider may charge
accordingly.
Characters with accents, other marks, or some language
options, take more space, limiting the number of characters
that can be sent in a single message.
Network services and costs
Your device is approved for use on the GSM 850, 900, 1800,
1900 MHz networks, and WCDMA 850, 900, 1700, 1900, 2100
MHz networks.
To use the device, you need a subscription with a service
provider.
Using network services and downloading content to your
device requires a network connection and may result in data
traffic costs. Some product features require support from the
network, and you may need to subscribe to them.
Take care of your device
Handle your device, battery, charger and accessories with
care. The following suggestions help you protect your
warranty coverage.
•Keep the device dry. Precipitation, humidity, and all
types of liquids or moisture can contain minerals that
corrode electronic circuits. If your device gets wet,
remove the battery, and allow the device to dry.
•Do not store the device in cold temperatures.
•Do not attempt to open the device other than as
instructed in the user guide.
•Unauthorised modifications may damage the device
and violate regulations governing radio devices.
•Do not drop, knock, or shake the device.
•Only use a soft, clean, dry cloth to clean the surface of
the device.
•Switch off the device and remove the battery from time
to time for optimum performance.
•Keep your device away from magnets or magnetic
fields.
•To keep your important data safe, store it in at least
two separate places, such as your device, memory card,
or computer, or write down important information.
During extended operation, the device may feel warm. In
most cases, this is normal. If you suspect the device is not
working properly, take it to the nearest authorised service
facility.
4 Product and safety information
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Recycle
Always return your used electronic products, batteries, and
packaging materials to dedicated collection points. This way
you help prevent uncontrolled waste disposal and promote
the recycling of materials. Check how to recycle your Nokia
products at www.nokia.com/werecycle, or with a mobile
device, http://nokia.mobi/werecycle.
About Digital Rights Management
When using this device, obey all laws and respect local
customs, privacy and legitimate rights of others, including
copyrights. Copyright protection may prevent you from
copying, modifying, or transferring images, music, and other
content.
Content owners may use different types of digital rights
management (DRM) technologies to protect their intellectual
property, including copyrights. This device uses various types
of DRM software to access DRM-protected content. With this
device you can access content protected with WM DRM 10 and
OMA DRM 2.0. If certain DRM software fails to protect the
content, content owners may ask that such DRM software's
ability to access new DRM-protected content be revoked.
Revocation may also prevent renewal of such DRM-protected
content already in your device. Revocation of such DRM
software does not affect the use of content protected with
other types of DRM or the use of non-DRM-protected content.
Digital rights management (DRM) protected content comes
with an associated licence that defines your rights to use the
content.
If your device has OMA DRM-protected content, to back up
both the licences and the content, use the backup feature of
Nokia Ovi Suite.
Other transfer methods may not transfer the licences which
need to be restored with the content for you to be able to
continue the use of OMA DRM-protected content after the
device memory is formatted. You may also need to restore
the licences in case the files on your device get corrupted.
If your device has WMDRM-protected content, both the
licences and the content will be lost if the device memory is
formatted. You may also lose the licences and the content if
the files on your device get corrupted. Losing the licences or
the content may limit your ability to use the same content on
your device again. For more information, contact your service
provider.
Some licences may be connected to a specific SIM card, and
the protected content can be accessed only if the SIM card is
inserted in the device.
Batteries and chargers
Battery and charger information
Your device is intended for use with a BL-5Krechargeable
battery. Nokia may make additional battery models available
for this device. Always use original Nokia batteries.
This device is intended for use when supplied with power
from the following chargers: AC-15. The exact Nokia charger
model number may vary depending on the plug type,
identified by E, X, AR, U, A, C, K, or B.
The battery can be charged and discharged hundreds of
times, but it will eventually wear out. When the talk and
standby times are noticeably shorter than normal, replace the
battery.
Battery safety
Always switch the device off and disconnect the charger
before removing the battery. When you unplug a charger or
an accessory, hold and pull the plug, not the cord.
When your charger is not in use, unplug it from the electrical
plug and the device. Do not leave a fully charged battery
connected to a charger, as overcharging may shorten the
battery’s lifetime. If left unused, a fully charged battery will
lose its charge over time.
Always keep the battery between 15°C and 25°C (59°F and
77°F). Extreme temperatures reduce the capacity and lifetime
of the battery. A device with a hot or cold battery may not
work temporarily.
Accidental short-circuiting can happen when a metallic object
touches the metal strips on the battery, for example, if you
carry a spare battery in your pocket. Short-circuiting may
damage the battery or the connecting object.
Do not dispose of batteries in a fire as they may explode.
Dispose of batteries according to local regulations. Recycle
when possible. Do not dispose as household waste.
Do not dismantle, cut, open, crush, bend, puncture, or shred
cells or batteries. If a battery leaks, do not let battery liquid
touch skin or eyes. If this happens, immediately flush the
affected areas with water, or seek medical help.
Do not modify, remanufacture, attempt to insert foreign
objects into the battery, or immerse or expose it to water or
other liquids. Batteries may explode if damaged.
Use the battery and charger for their intended purposes only.
Improper use, or use of unapproved batteries or incompatible
chargers may present a risk of fire, explosion, or other hazard,
Product and safety information 5
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
and may invalidate any approval or warranty. If you believe
the battery or charger is damaged, take it to a service centre
for inspection before continuing to use it. Never use a
damaged battery or charger. Only use the charger indoors.
Additional safety information
Make an emergency call
1 Make sure the device is switched on.
2 Check for adequate signal strength. You may also need
to do the following:
•Insert a SIM card.
•Deactivate call restrictions you have activated for
your device, such as call barring, fixed dialling, or
closed user group.
•Make sure the offline or flight profile is not
activated.
•If the device screen and keys are locked, unlock
them.
3 Press the end key repeatedly, until the home screen is
displayed.
4 To open the dialler, select .
5 Enter the official emergency number for your present
location. Emergency call numbers vary by location.
6 Press the call key.
7 Give the necessary information as accurately as
possible. Do not end the call until given permission to
do so.
Important: Activate both cellular and internet
calls, if your device supports internet calls. The device may
attempt to make emergency calls both through cellular
networks and through your internet call service provider.
Connections in all conditions cannot be guaranteed. Never
rely solely on any wireless device for essential
communications like medical emergencies.
Small children
Your device and its accessories are not toys. They may contain
small parts. Keep them out of the reach of small children.
Medical devices
Operation of radio transmitting equipment, including
wireless phones, may interfere with the function of
inadequately protected medical devices. Consult a physician
or the manufacturer of the medical device to determine
whether they are adequately shielded from external radio
frequency energy.
Implanted medical devices
Manufacturers of medical devices recommend a minimum
separation of 15.3 centimetres (6 inches) between a wireless
device and an implanted medical device, such as a pacemaker
or implanted cardioverter defibrillator, to avoid potential
interference with the medical device. Persons who have such
devices should:
•Always keep the wireless device more than 15.3
centimetres (6 inches) from the medical device.
•Not carry the wireless device in a breast pocket.
•Hold the wireless device to the ear opposite the medical
device.
•Turn the wireless device off if there is any reason to
suspect that interference is taking place.
•Follow the manufacturer directions for the implanted
medical device.
If you have any questions about using your wireless device
with an implanted medical device, consult your health care
provider.
Accessibility solutions
Nokia is committed to making mobile phones easy to use for
all individuals, including those with disabilities. For more
information, visit the Nokia website at
www.nokiaaccessibility.com.
Hearing
Warning:
When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it can
endanger your safety.
Some wireless devices may interfere with some hearing aids.
Your mobile device complies with FCC rules governing hearing
aid compatibility. These rules require an M3 microphone or
higher. The M value of your device microphone is marked on
the device sales package. To determine the M-rating of your
hearing aid and compatibility with this device, consult your
hearing health professional. For more information about
accessibility, see www.nokiaaccessibility.com.
Protect your device from harmful content
Your device may be exposed to viruses and other harmful
content. Take the following precautions:
6 Product and safety information
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
•Be cautious when opening messages. They may contain
malicious software or otherwise be harmful to your
device or computer.
•Be cautious when accepting connectivity requests,
browsing the internet, or downloading content. Do not
accept Bluetooth connections from sources you do not
trust.
•Only install and use services and software from sources
that you trust and that offer adequate security and
protection.
•Install antivirus and other security software on your
device and any connected computer. Only use one
antivirus application at a time. Using more may affect
performance and operation of the device and/or
computer.
•If you access preinstalled bookmarks and links to third
party internet sites, take the appropriate precautions.
Nokia does not endorse or assume liability for such
sites.
Operating environment
This device meets radio frequency exposure guidelines in the
normal use position at the ear or at least 1.5 centimetres (5/8
inch) away from the body. Any carry case, belt clip, or holder
for body-worn operation should not contain metal and
should position the device the above-stated distance from
your body.
To send data files or messages requires a quality connection
to the network. Data files or messages may be delayed until
such a connection is available. Follow the separation distance
instructions until the transmission is completed.
Parts of the device are magnetic. Metallic materials may be
attracted to the device. Do not place credit cards or other
magnetic storage media near the device, because
information stored on them may be erased.
Vehicles
Radio signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles such as
electronic fuel injection, electronic antilock braking,
electronic speed control, and air bag systems. For more
information, check with the manufacturer of your vehicle or
its equipment.
Only qualified personnel should install the device in a vehicle.
Faulty installation or service may be dangerous and may
invalidate your warranty. Check regularly that all wireless
device equipment in your vehicle is mounted and operating
properly. Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the device,
its parts, or accessories. Remember that air bags inflate with
great force. Do not place your device or accessories in the air
bag deployment area.
Potentially explosive environments
Switch off your device in any area with a potentially explosive
atmosphere, for example near gas pumps at service stations.
Sparks in such areas could cause an explosion or fire resulting
in bodily injury or death. Observe restrictions in fuel service
stations, storage, and distribution areas; chemical plants; or
where blasting operations are in progress. Areas with a
potentially explosive atmosphere are often, but not always,
clearly marked. They include areas where you would be
advised to turn off your vehicle engine, below deck on boats,
chemical transfer or storage facilities and where the air
contains chemicals or particles such as grain, dust, or metal
powders. You should check with the manufacturers of
vehicles using liquefied petroleum gas (such as propane or
butane) to determine if this device can be safely used in their
vicinity.
Certification information (SAR)
This mobile device meets guidelines for exposure to
radio waves.
Your mobile device is a radio transmitter and receiver. It is
designed not to exceed the limits for exposure to radio waves
recommended by international guidelines. These guidelines
were developed by the independent scientific organisation
ICNIRP and include safety margins designed to assure the
protection of all persons, regardless of age and health.
The exposure guidelines for mobile devices employ a unit of
measurement known as the Specific Absorption Rate or SAR.
The SAR limit stated in the ICNIRP guidelines is 2.0 watts/
kilogram (W/kg) averaged over 10 grams of tissue. Tests for
SAR are conducted using standard operating positions with
the device transmitting at its highest certified power level in
all tested frequency bands. The actual SAR level of an
operating device can be below the maximum value because
the device is designed to use only the power required to reach
the network. That amount changes depending on a number
of factors such as how close you are to a network base station.
The highest SAR value under the ICNIRP guidelines for use of
the device at the ear is 0.69 W/kg.
Use of device accessories may result in different SAR values.
SAR values may vary depending on national reporting and
testing requirements and the network band. Additional SAR
information may be provided under product information at
www.nokia.com.
Product and safety information 7
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Your mobile device is also designed to meet the requirements
for exposure to radio waves established by the Federal
Communications Commission (USA) and Industry Canada.
These requirements set a SAR limit of 1.6 W/kg averaged over
one gram of tissue. The highest SAR value reported under this
standard during product certification for use at the ear is 1.14
W/kg and when properly worn on the body is 0.87 W/kg.
Copyright and other notices
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-774
product is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC. A copy of the
Declaration of Conformity can be found at www.nokia.com/
phones/declaration_of_conformity/.
© 2011 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nokia Original Accessories
logo, and Ovi by Nokia are trademarks or registered
trademarks of Nokia Corporation. Nokia tune is a sound mark
of Nokia Corporation. Other product and company names
mentioned herein may be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or storage of part or all
of the contents in this document in any form without the prior
written permission of Nokia is prohibited. Nokia operates a
policy of continuous development. Nokia reserves the right
to make changes and improvements to any of the products
described in this document without prior notice.
Oracle and Java are registered trademarks of Oracle and/or
its affiliates.
Portions of the Nokia Maps software are ©1996-2011 The
FreeType Project. All rights reserved.
The Bluetooth word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Nokia is
under license.
This product is licensed under the MPEG-4 Visual Patent
Portfolio License (i) for personal and noncommercial use in
connection with information which has been encoded in
compliance with the MPEG-4 Visual Standard by a consumer
engaged in a personal and noncommercial activity and (ii) for
use in connection with MPEG-4 video provided by a licensed
video provider. No license is granted or shall be implied for
any other use. Additional information, including that related
to promotional, internal, and commercial uses, may be
obtained from MPEG LA, LLC. See http://www.mpegla.com.
To the maximum extent permitted by applicable law, under
no circumstances shall Nokia or any of its licensors be
responsible for any loss of data or income or any special,
incidental, consequential or indirect damages howsoever
caused.
The contents of this document are provided "as is". Except as
required by applicable law, no warranties of any kind, either
express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular
purpose, are made in relation to the accuracy, reliability or
contents of this document. Nokia reserves the right to revise
this document or withdraw it at any time without prior
notice.
Reverse engineering of software in the device is prohibited
to the extent permitted by applicable law. Insofar as this user
guide contains any limitations on Nokia's representations,
warranties, damages and liabilities, such limitations shall
likewise limit any representations, warranties, damages and
liabilities of Nokia's licensors.
The availability of products, features, applications and
services may vary by region. For more information, contact
your Nokia dealer or your service provider. This device may
contain commodities, technology or software subject to
export laws and regulations from the US and other countries.
Diversion contrary to law is prohibited.
Nokia does not provide a warranty for or take any
responsibility for the functionality, content, or end-user
support of third-party applications provided with your
device. By using an application, you acknowledge that the
application is provided as is. Nokia does not make any
representations, provide a warranty, or take any
responsibility for the functionality, content, or end-user
8 Copyright and other notices
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
support of third-party applications provided with your
device.
The availability of Ovi services may vary by region.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example,
when using a telephone in close proximity to receiving
equipment). The FCC or Industry Canada can require you to
stop using your telephone if such interference cannot be
eliminated. If you require assistance, contact your local
service facility. This device complies with part 15 of the FCC
rules and Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation. Any changes or
modifications not expressly approved by Nokia could void the
user's authority to operate this equipment.
Th is product i s h omolo ga te d by Anatel in accordance wit h the
procedures set forth by Resolution No. 242/2000 and meets
the applied technical guidelines, including the Specific
Absorption Rate limits for exposure to electrical, magnetic
and electromagnetic radio frequency fields, according to
Resolutions No. 303/2002 and No. 533/2009.
5555555/Issue 1 EN
Copyright and other notices 9
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
