Microsoft RM-774 GSM/WCDMA cellular telephone phone with BT, WLAN, FM Tx and NFC User Manual Manual 2

Microsoft Mobile Oy GSM/WCDMA cellular telephone phone with BT, WLAN, FM Tx and NFC Manual 2

Contents

Manual 2

Get to know your Nokia 701
1111111 Issue 1 EN
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Keys and parts
1 End key
2 Menu key
3 Call key
4 Microphone
5 Volume up/Zoom in key
6 Voice recorder key
7 Volume down/Zoom out key
8 Key lock switch
9 Camera key
10 Micro-USB connector
11 Nokia AV connector (3.5 mm)
12 Power key
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Insert the SIM card and
battery
1. Unlock the back cover release latch, and lift the
back cover. If the battery is inserted, remove it.
2. Insert the SIM card into the SIM card slot. Push
the card in, until it locks into place.
3. To remove the SIM card, push the card in, until
it is released.
4. Insert the battery.
5. To replace the back cover, direct the top locking
catches toward their slots, and press down until
the cover locks into place.
Insert the memory card
1. Remove the back cover and battery.
2. Insert the memory card into the memory card
slot. Push the card in, until it locks into place.
3. To remove the memory card, push the card in,
until it is released.
4. Replace the battery and back cover.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Using the touch screen
Access the options menu
Tap the icon.
Go back to the previous screen
Tap the icon.
Access functions quickly
Tap and hold the item. A pop-up menu with
available options opens. If you tap and hold the
home screen, editing mode is activated.
Swipe
Place a finger on the screen, and slide your finger
in the desired direction.
Zoom in or out
Place two fingers on an item, such as a map,
picture, or web page, and slide your fingers apart
or together.
Use shortcuts
You don't have to navigate long paths to, for
example, open or close an internet connection, or
to silence your phone. You can access these
settings directly in the status menu, no matter
what application or view you are in.
Swipe down from the notification area.
In the status menu, you can do the following:
• View notifications of missed calls or unread
messages
•Silence your phone
• Modify the connectivity settings
• View available WLAN connections, and connect
to a WLAN
•Manage Bluetooth connections
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Make a call
1. On the home screen, select , and enter the
phone number.
To delete a number, select .
To enter the + character, used for international
calls, select * twice.
2. To make the call, press the call key.
3. To end the call, press the end key.
Tip: On the home screen, select , and start
entering the contact's first or second name. You
can also search by company name.
Copy from old phone
To copy contacts, pictures, and other content
from your previous Nokia phone, select >
Settings > Connectivity > Data transfer > Phone
switch.
To copy contacts from other phones, use Nokia Ovi
Suite. To learn more, go to www.ovi.com/
suite.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Touch to pair and share
NFC is a wireless technology that makes
connecting with other phones and devices and
sharing your own content, such as your pictures,
videos, and contacts, easy and fun.
To activate NFC, select > Settings and
Connectivity > NFC > NFC > On.
To connect to a compatible Bluetooth accessory,
touch the NFC area of the accessory with the NFC
area of your phone.
Share a picture with a friend
1. Select a picture in Gallery.
2. Touch the NFC area of your friend's phone with
the NFC area of your phone.
You can also touch NFC tags to, for example,
access online services.
Play a game with a friend
using NFC
Want to have fun playing games with a friend? If
you and a friend both have a Nokia phone that
supports NFC, you can play games together.
1. Open a game that supports NFC.
2. Follow the in-game instructions.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Make home screens live
Add static or changing content using mini-apps
(widgets), and you'll see your most relevant
information at a glance.
For example, dedicate one home screen for music
and feeds from web TV channels. Modify another
to see your latest mail, favourite contacts, and
status updates.
To switch pages, swipe left or right.
indicates the current home screen.
Add a home screen
Select > New Home screen.
You can also change the wallpaper, and drag and
drop items between home screens, to personalise
them to your liking.
Make it yours
Personalise all your home screens individually
with widgets, shortcuts, and wallpapers. Tap and
hold an empty area on the home screen, and from
the pop-up menu, select the desired option.
Tip: It's also possible to add shortcuts to apps
from the main menu. Select and hold an app, and
from the pop-up menu, select Add shortcut.
You can drag and drop widgets and shortcuts,
even between different home screens.
Tip: You can also use the options menu. For
example, to add a home screen, select > New
Home screen.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Download apps, games,
and more
Select > Store.
Access Nokia’s Ovi Store, and fill your phone with
new content. Browse or search for apps, games,
audio and video, or content to personalise your
phone.
For featured apps, such as Travel, Go Green, or
Web TV, see the Collections section. You can
continue to browse while downloading. Once
you’re finished, you can open apps and games
directly from Ovi Store.
Browse the web
Who needs a computer, when you can use your
phone browser to catch up on the news and visit
your favourite websites?
Select > Web.
Enter a web address in the address bar at the top,
and select .
You can easily access your favourite websites
using bookmarks or shortcuts that you have
added to the main menu. While browsing, tap and
hold the web page, and from the pop-up menu,
select Add bookmark or Add as an application.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Write text
Select a text input field, and write the text using
the virtual keyboard. When you are finished,
select in the virtual keyboard.
To change the writing language, select >
Writing language or > Input options >
Writing language.
Active noise cancellation
If you are calling from a noisy environment, your
phone filters out background noise to make your
voice sound clearer to the person at the other end
of the line.
Noise cancellation is not available when using the
loudspeaker or a headset. For the best noise
cancellation, hold the phone with the earpiece to
your ear and the main microphone towards your
mouth. Do not cover the secondary microphone
on the back of the phone.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Find your way for free
With Ovi by Nokia, navigation is free. To see where
you are, and to find places around you with
detailed information on where to eat, drink, shop,
and more, select > Maps.
For voice-guided turn-by-turn directions, lane
assistance, and traffic updates, select Drive.
To get directions for the shortest route to your
destination via dedicated pedestrian shortcuts,
over squares, through parks, and even in
shopping centres, select Walk.
Update street maps
The free voice-guided navigation is available in
over 80 countries, even without a network
connection.
Save new street maps to your phone before a
journey, so you can browse the maps without an
internet connection when travelling.
Download maps
1. Select > Maps and Update > Add new
maps.
2. Select a continent and a country, and select
Download.
Update maps
Select Update > Check for updates.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Take pictures and share
Take pictures with the camera on your phone, and
share them with your family and friends.
To open the camera, press and hold the camera
key.
To zoom in or out, use the volume keys.
To take a picture, press the camera key.
You can share your pictures directly from the
camera or Gallery to multiple social networking
services. After taking a picture with the camera,
or opening a picture in Gallery, select and a
service.
See your friends’ status
updates
You can see your friends’ status updates, from
multiple social networking services, in a single
view.
1. Select > Social.
2. Sign in to the services you use.
3. In the Social application main view, select All
Activity.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Back up and update
With the Nokia Ovi Suite PC app, you can back up
the contents of your phone, copy your music,
pictures, and other files, as well as keep your
phone software and apps up to date.
To install Nokia Ovi Suite on your compatible PC,
use a compatible USB cable to connect your phone
to your computer, and follow the displayed
instructions. If the installation doesn’t start
automatically, use your computer’s file browser
to locate and select the
Install_Nokia_Ovi_Suite.exe file on your phone.
If you are using a Mac, download Nokia Ovi Suite
from www.ovi.com/suite.
Find help and support
Your phone has a complete user guide. It's always
with you, available when needed. Select > User
guide.
If your phone stops responding, switch your
phone off, and remove the battery for a few
seconds. Insert the battery, and switch your
phone on again. No content, such as contacts or
messages, is deleted.
For more information, go to www.nokia.com/
support.
© 2011 Nokia. All rights reserved.
