To aid in reporting this microwave oven in case of loss or theft, please record below the model number and serial
number located on the unit. We also suggest you record all the information listed and retain for future reference.
MODEL NUMBER _______________________ SERIAL NUMBER _____________
DATE OF PURCHASE ______________________
DEALER ___________________________ TELEPHONE ________________
SERvICER ___________________________ TELEPHONE ________________
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can result
in harmful exposure to microwave energy. It is important not to defeat or tamper with the
safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door
close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches
(broken or loosened), (3) door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualied service
personnel.
TO PHONE:
SERVICE (for your nearest Sharp Authorized Servicer)
PARTS (for your authorized parts distributor)
ADDITIONAL CUSTOMER INFORMATION
ACCESSORIES and COOKBOOK
TO WRITE:
Sharp Electronics Corporation
Attn: Customer Assistance Center
Sharp Plaza Blvd
Memphis, Tennessee 38193
TO ACCESS INTERNET:
www.sharpusa.com
Please provide the following information when you write or call: model number, serial number, date of purchase,
your complete mailing address (including zip code), your daytime telephone number (including area code) and
description of the problem.
FOR CUSTOMER ASSISTANCE
2
SHARP ELECTRONICS CORPORATION warrants to the rst consumer purchaser that this Sharp brand
product (the “Product”), when shipped in its original container, will be free from defective workmanship and
materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or
part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the
period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s)
set forth below nor to any Product the exterior of which has been damaged or defaced, which has been
subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or
modied in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below
and provide proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted to pur-
chasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET
FORTH BELOW. Some states do not allow limitations on how long an implied warranty lasts, so the above
limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other
than those described herein, or to extend the duration of any warranties beyond the time period described
herein on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be
the sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for the
period of time described herein, shall constitute complete fulllment of all liabilities and responsibilities of
Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether
based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way
responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs
performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible
for any incidental or consequential economic or property damage. Some states do not allow the exclusion
of incidental or consequential damages, so the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH
VARY FROM STATE TO STATE.
R-248BS Home Use Carousel Microwave Oven. (Be sure to have this
information available when you need service for your Product.)
One (1) year parts and labor. The warranty period continues for an
additional four (4) years, for a total of ve (5) years, with respect to the
magnetron tube in the Product for parts only; labor and service are not
provided free of charge for this additional period.
Non-functional accessories, turntable and light bulb.
From a Sharp Authorized Servicer located in the United States.
To nd the location of the nearest Sharp Authorized Servicer, call Sharp
toll free at 1-800-BE-SHARP (1-800-237-4277).
Ship prepaid or carry in your Product to a Sharp Authorized Servicer.
Be sure to have Proof of Purchase available. If you ship the Product,
be sure it is insured and packaged securely.
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP OR VISIT www.sharpusa.com.
SAVE THE PROOF OF PURCHASE AS IT IS NEEDED SHOULD YOUR OVEN EVER REQUIRE WARRANTY SERVICE.
CONSUMER LIMITED WARRANTY
3
11. Read all instructions before using the appliance.
12. Read and follow the specific “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” found on page 2.
13. This appliance must be grounded. Connect only to
properly grounded outlet. See “GROUNDING
INSTRUCTIONS” found on page 5.
14. Install or locate this appliance only in accordance with
the provided installation instructions.
15. Some products such as whole eggs and sealed
containers - for example, closed glass jars are able to
explode and should not be heated in this oven.
16. Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type of
oven is specically designed to heat, cook, or dry food.
It is not designed for industrial or laboratory use.
17. As with any appliance, close supervision is necessary
when used by children.
18. Do not operate this appliance if it has a damaged
cord or plug, if it is not working properly, or if it has
been damaged or dropped.
19. This appliance should be serviced only by qualified
service personnel.
Contact nearest authorized service facility for
examination, repair or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this
product near water — for example, near a kitchen
sink, in a wet basement, near a swimming pool, or
similar locations.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cord hang over edge of table or counter.
15. Either.
a) When cleaning surfaces of door and oven that
comes together on closing the door, use only mild,
non-abrasive soaps or detergents applied with a
sponge or soft cloth., or
b) See door surface cleaning instructions on page 16.
16. To reduce the risk of re in the oven cavity:
a) Do not overcook food. Carefully attend appliance
when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from paper or plastic bags
before placing bag in oven.
c) If materials inside the oven ignite, keep oven door
closed, turn oven off, and disconnect the power
cord, or shut off power at the fuse or circuit breaker
panel.
d) Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in
the cavity when not in use.
17. Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing
to be boiling due to surface tension of the liquid. Visible
bubbling or boiling when the container is removed
from the microwave oven is not always present. THIS
COULD RESULT IN VERY HOT LIQUIDS
SUDDENLY BOILING OVER WHEN A SPOON OR
OTHER UTENSIL IS INSERTED INTO THE LIQUID.
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through
heating it.
c) Do not use straight-sided containers with narrow
necks.
d) After heating, allow the container to stand in the
microwave oven for a short time before removing
the container.
e) Use extreme care when inserting a spoon or other
utensil into the container.
18. Do not use this microwave oven to heat corrosive
chemicals (for example, sulfides and chlorides).
Vapors from such corrosive chemicals may interact
with the contact and springs of the safety interlock
switches thereby rendering them inoperable.
19. Keep the waveguide cover clean at all times.
Wipe the oven interior with a soft damp cloth after
each use. If you leave grease or fat anywhere in the
cavity it may overheat, smoke or even catch re when
next using the oven.
20. Never heat oil or fat for deep frying as you cannot
control the temperature and doing so may lead to
overheating and re.
21. Do not operate the oven without the glass tray in
place. Be sure it is properly sitting on the rotating base.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
4
This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in
strict accordance with the manufacturer's instructions, may cause interference to radio and television
reception.
It has been type-tested and found to comply with limits for an ISM Equipment pursuant to part 18 of FCC
Rules, which are designed to provide reasonable protection against such interference in a residential
installation.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the followings.
• Reorient the receiving antenna of radio or television.
• Relocate the Microwave oven with respect to the receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so that microwave oven and receiver are on different
branch circuits.
THE MANUFACTURER is not responsible for any radio or TV interference caused by
UNAUTHORIZED MODIFICATION to this microwave oven. It is the responsibility of the user to correct
such interference.
This appliance must be grounded. In the event of an electrical short circuit, the grounding plug reduces the risk of
electric shock by providing an escape wire for electric current. This appliance is equipped with a cord having a
grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and
grounded.
Improper use of the grounding can result in a risk of electric shock.
Consult a qualied electrician or serviceman if the grounding instructions are not completely understood, or if
doubt exists as to whether the appliance is properly grounded, and either :
(1) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding
plug, and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension
cord shall be equal to or greater than the electrical rating of the appliance.
or
(2) Do not use an extension cord, if the power supply cord is too short, have a qualified electrician or
serviceman install an outlet near the appliance.
Do not cut or remove the third (ground) prong from the power cord under any circumstances.
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
GROUNDING INSTRUCTIONS
5
1.
Check for damage such as a misaligned door, broken door or dent in the cavity.
If any damage is visible, DO NOT INSTALL, and notify your dealer immediately.
2.
Install the microwave oven on a level, at surface.
3.
Do not block air vents. If they are blocked during operation, the oven may overheat and eventually cause a
failure.
For proper ventilation, allow 4 inches of space between oven top, sides, rear and adjacent surfaces.
4.
Poor television reception and radio interference may result if the oven is located close to a TV, radio, antenna,
feeder, etc.
Place the oven as far from them as possible.
5.
Keep the oven away from heat, steam or splashing liquids. These things can adversely affect oven wiring and
contacts.
6.
• Check your local power source.
This microwave oven requires a current of approximately 14 amperes, 120Volts, 60Hz and a grounded outlet.
1. A short power-supply cord is provided to reduce the risks of the user becoming entangled in or tripping over
a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised in their use.
3. If a long cord or extension cord is used:
• The marked electrical rating of the cord set or extension cord should be at least as great as the electrical
rating of the oven.
• The extension cord must be a grounding type 3-wire cord.
• The longer cord should be arranged so that it will not drape the table top or counter where it can be pulled
on by children or tripped over unintentionally.
7.
3-prong Receptacle
Receptacle
Box cover
3-prong plug
Receptacle Box Cover
Receptacle
Grounding
Lead
Grounding
Adaptor
“THE CANADIAN ELECTRICAL CODE DOES NOT ALLOW THE USE OF THE GROUNDING ADAPTOR”
INSTALLATION GUIDE
6
19.1 11.5
SPECIFICATIONS
POWER SUPPLY 120V AC, 60Hz SINGLE PHASE WITH
GROUNDING
MICROWAVE
INPUT POWER 1 50 W
ENERGY OUTPUT
FREQUENCY 2,450MHz
OUTSIDE DIMENSIONS (W x H x D)
CAVITY DIMENSIONS (W x H x D)
CAVITY VOLUME
NET WEIGHT APPROX. 28.0 lbs.
TIMER
POWER SELECTIONS 11 Levels
* Specifications are subject to change without notice.
95 min. 00 sec.
7
900 W
0.9 cu.ft
12.4 x 13.7 x 8.7 in.
19.1 x 16.1 x 11.5 in.
16.1
3
FEATURES DIAGRAM
OVEN
1. Door handle
2. Oven lamp
3. Door hinges
4. Door safety latches
5. Door
6. Door seals and sealing surfaces
7. Turntable motor shaft
8. Oven cavity
9. Control panel
10. Waveguide cover (DO NOT REMOVE)
11. Power supply cord
12. Ventilation openings
13. Outer cabinet
ACCESSORIES:
Check to make sure the following accessories are
provided:
(14) Turntable (15) Turntable support (16) Coupling
Place the coupling into the turntable motor shaft and then place
the turntable support in the centre of the oven floor so that it can
freely rotate around the coupling. Place the turntable onto the
turntable support so that it locates firmly into the coupling. To
avoid turntable damage, ensure dishes and containers are lifted
clear of the turntable rim when removing them from the oven.
NOTE: When you order accessories, please mention two items: part
name and model name to your dealer or SHARP authorised service
agent.
Hub (inside)
14. Turntable
(glass)
16. Coupling 15. Turntable
support
8
12
11
13
48735
9
62
10
1
4
FEATURES DIAGRAM
1. DIGITAL DISPLAY
2. AUTO MENU options
button
button
ENTRY
Rotate to enter the cooking time, time, power level, weight and select auto
menu
6. POWER LEVEL
button
Popcorn , Potato , Pizza , Frozen Vegetable , Beverage , Reheat , Pasta , Fresh Vegetable
dial
button
button
9
AUTO
MENUS
TIME/
WEIGHT
POWER
LEVEL
AUTO
MENU
TIME
DEFROST
AUTO
DEFROST
STOP/
CLEAR
TIMER/
CLOCK
START/+30sec.
POPCORN
POTATO
PIZZA
FROZEN VEG.
BEVERAGE
REHEAT
PASTA
FRESH VEG.
A-1
A-2
A-3
A-4
A-5
A-6
A-7
A-8
7
6
8
2
1
3
4
5
9
10
10.
8. TIMER/CLOCK
5. STOP/CLEAR
7. AUTO DEFROST
button
AUTO MENU3.
9. START/ +30sec.
button
TIME DEFROST4.
Plug power supply cord into a standard 3-pronged
14 Amp, 120V AC 60Hz power outlet.
After placing the food in a suitable container, open
the oven door and put it on the glass tray.
The glass tray and roller guide must always be in
place during cooking.
Close the door. Make sure that it is rmly closed.
The oven light is on when the microwave oven is
operating.
Each time a key is touched, a BEEP will sound to
acknowledge the touch.
The oven automatically cooks on full power
unless set to a lower power level.
The display will show “ 0:00” when the oven
Time clock returns to the present time when the
cooking time ends.
When the STOP/CLEAR key is touched during the
oven operation, the oven stops cooking and all
information retained. To erase all information(except
the present time), touch the STOP/CLEAR key once
more. If the oven door is opened during the oven
operation, all information is retained.
If the START key is touched and the oven does not
operate, check the area between the door and door
seal for obstructions and make sure the door is
closed securely. The oven will not start cooking until
the door is completely closed or the program has
been reset.
Make sure the oven is properly installed and
plugged into the electrical outlet.
WATTAgE OUTPUT CHART
• The power-level is set by touching the Power Level key. The chart shows the display, the power level
and the percentage of power.
OPERATION PROCEDURE
This section includes useful information about oven operation.
TOUCH THE POWER KEY POWER LEvEL (DISPLAY)
A P P R O x I M A T E P E R C E N T A G E O F P O W E R
once P100 100%
twice P90 90%
3 times P80 80%
4 times P70 70%
5 times P60 60%
6 times P50 50%
7 times P40 40%
8 times P30 30%
9 times P20 20%
10 times P10 10%
11 times P 0 0%
10
is plugged in.
The oven door can be opened at any time during
operation by pull the door handle. The oven
will automatically shut off.
SETTINg THE CLOCK
CONTROLS
KITCHEN TIMER MODE
Your oven has a 12 hour clock feature.
1. Press the button twice. The hour gure will ash and the clock indicator will illuminate.
2. Rotate the ENTRY dial until the correct hour is displayed, the input time should be within 2.
3. Press the button, the minute gure will ash.
4. Set the minutes. Rotate the ENTRY dial until the correct minutes are displayed, the input time should be within 0-59.
5. Press the button to start the clock. The icon “:” of the digital time will be ashing on the display and
the clock indicator will disappear.
NOTES:
• If the clock is set, when cooking is complete, the display will show the correct time of day. If the clock has not been set,
the display will show "0:00".
• To check the time of day during a cooking process, press button and the LED will display the time of day
for 2-3 seconds. This does not a ect the cooking process.
• If in the process of setting the clock, the STOP/CLEAR button is pressed, the oven will revert back to the former setting.
•
If the electrical power supply to your microwave oven is interrupted, the display will intermittently show "0:00" after the power
is reinstated. If this occurs during cooking, the programme will be erased. As will the time of day.
You can use the kitchen timer, in instances where microwave cooking is not involved for example to time boiled eggs
cooked on conventional cooktop or to monitor the standing time for cooked/defrosted food.
Example:
To set the timer for 5 minutes.
1. Press
once.
2. Rotate ENTRY dial to select
time .
3. Press the START/+30sec
key to start the timer.
4. Check the display.
(The display will count down
through the programmed
time.)
When the timer arrives at 0:00, an audible signal will sound 5 times and the LED will then display the time of day.
You can enter any time up to 95 minutes. To cancel the KITCHEN TIMER while counting down, simply press the STOP/CLEAR
button.
NOTE: The KITCHEN TIMER function cannot be used whilst cooking.
11
1
TIMER/CLOCK
TIMER/CLOCK
TIMER/CLOCK
TIMER/CLOCK
TIMER/CLOCK
CONTROLS
• If “P0” is selected, the oven will work with the
fan but no power. You can use this level to
remove the odor.
Generally the following recommendations apply:
- (HIGH) used for fast cooking or reheating
e.g. for casseroles, hot beverages, vegetables etc.
- (MEDIUM HIGH) used for longer cooking of
dense foods such as roasts, meat loaf and plated meals,
also for sensitive dishes such as sponge cakes.
At this reduced setting, the food will cook evenly
without over cooking at the sides.
- (MEDIUM) for dense foods which require a
long cooking time when cooked conventionally, e.g.
beef casserole, it is advisable to use this power setting
to ensure the meat will be tender.
- (MEDIUM LOW) to defrost, select this
power setting, to ensure that the dish defrosts evenly.
This setting is also ideal for simmering rice, pasta,
dumplings and cooking egg custard.
- (LOW) For gentle defrosting, e.g. cream
gateaux or pastry.
P100/ P90
P60/ P50
P80/ P70
P40/ P30
P20/ P10
• Press the POWER LEVEL button once, P100
will be displayed and at the same time the
microwave indicator and power level indicator
will illuminate on the display.
• Press POWER LEVEL or rotate the ENTRY
dial to change the power level until the display
indicates the desired level.
• Press the START/+30sec. button to
confirm the setting, enter the cooking time
and then press the START/ +30sec.
button again to start the oven.
• To check the power level during cooking, press
the POWER LEVEL button, the current power
level will be displayed for 3 seconds. The oven
will continue to count down although the
display will show
the power level.
MICROWAVE FUNCTION
Power Level Press the POWER LEVEL
key
Display
(Percentage)
HIGH x1 P100
x2 P90
MEDIUM HIGH x3 P80
x4 P70
MEDIUM x5 P60
x6 P50
MEDIUM LOW
(DEFROST)
x7 P40
x8 P30
LOW x9 P20
x10 P10
x11 P0
Your oven can be programmed for up to 95 minutes (95:00).
The input unit of cooking /defrosting time varies from 5
seconds to 95 minutes. It depends on the total length of
Cooking Time
0-1 minute
1-5 minutes
5-10 minutes
10-30 minutes
30-95 minutes
Increasing Unit
5 seconds
10 seconds
30 seconds
1 minute
5 minutes
MANUAL COOKING/MANUAL DEFROSTING
• Enter the cooking time and use the microwave power levels P100 to P10 to cook or defrost .
• Stir or turn the food, where possible, 2 - 3 times during cooking.
• After cooking, cover the food and leave to stand, where recommended.
• After defrosting, cover the food in foil and leave to stand until thoroughly defrosted.
the cooking/defrosting time as shown on the table.
12
CONTROLS
OTHER CONVENIENT FUNCTION
1. MULTI-STAGE COOKING
This function allows you to cook using up to 2 di erent stages which can include manual cooking times or time
defrost as well as a auto defrost function. Once programmed there is no need to interfere with the cooking
operation as the oven will automatically move onto the next stage. An audible signal will sound once after the
rst stage. If the defrost function is needed within sequence cooking, please note that this should always be
the rst stage of sequence cooking.
NOTE: AUTO MENU cannot be set as one of the multi-stage sequences.
Example: If you want to cook food for 20 minutes on 100% microwave power and then for 5 minutes with
80% microwave power. The
steps are as follows:
1. Press the POWER LEVEL button, P100 will appear in the LED display.
2. Press the START/+30sec button once to con rm the setting.
3. Enter the cooking time by rotating the ENTRY dial until the display shows “20:00” minutes.
4. Press the POWER LEVEL button, P100 will appear in the LED display.
5. Press the POWER LEVEL button twice or rotate the ENTRY dial to select the microwave power to P80.
6. Press the START/+30sec. button once more to con rm the setting.
7. Enter the cooking time by rotating the ENTRY dial until the display shows “5:00” minutes.
8. Press the START/ +30sec. button to start cooking.
2. +30sec FUNCTION / Direct tart
Direct start
You can directly start cooking on P100 microwave power level for 30 seconds by pressing the START/ +30sec.
button. The cooking process will start immediately and each time the button is pressed this will increase the
cooking time by 30 sec.
NOTE: The cooking time may be extended to a maximum of 95 minutes.
S
3. CHILD LOCK:
Use to prevent unsupervised operation of the oven by children.
a. To set the CHILD LOCK:
Press and hold the STOP/CLEAR button for 3 seconds until the display shows:
b. To cancel the CHILD LOCK:
Press and hold the STOP/CLEAR button for 3 seconds until a long beep sounds.
Example:
To cook for 2 minutes and 30 seconds on P80 (80%) microwave power.
1. Press the
POWER LEVEL
button. P100 will be
displayed.
2. Rotate the ENTRY dial
to select the power
level for P80.
3. Press the START/
+30sec. button
to con rm the setting.
4. Enter the cooking time
by rotating the ENTRY
dial.
5. Press the START/
+30sec. button to
start cooking. (The
display will count
down through the
programmed cooking
time.)
NOTE:
• When the oven starts, the oven lamp will illuminate and the turntable will rotate clockwise or counterclockwise.
• If the door is opened during cooking/defrosting to stir or turn over food, the cooking time on the display will stop automatically. The
cooking/defrosting time starts to count down again when the door is closed and the START/ +30sec. button is pressed.
• When cooking/defrosting is complete, the time of day will reappear on the display, if the clock has been set.
• If you wish to know the power level during cooking, press the POWER LEVEL button. The current power level will displayed for 3 seconds.
13
CONTROLS
The microwave oven is pre-programmed with a timer and power levels so that foods such as pork, beef and chicken can be easily defrosted.
The weight range for this is from 1 – 100 ounces.
Follow the example below for details on how to operate this function.
Example: To defrost meat weighing 12 oz using .
1. Press the button. 2. Enter the desired weight by rotating the
ENTRY dial until the display shows:
3. Press the START/+30sec. button to
start defrosting.
(The display will count down through
defrosting time)
NOTE:
• Frozen foods are defrosted from 0°F.
• Before freezing foods, ensure food is fresh and of good quality.
• If necessary, shield small areas of meat or poultry with at pieces of aluminium foil. This will prevent the areas from becoming warm
during defrosting. Ensure the foil does not touch the oven walls.
• Food weight should be rounded up to the nearest 1 Oz , for example, 6.5 Oz to 7 Oz .
• After defrosting an audible signal will sound ve times and the LED will then display time of day, if the clock has been set. If the clock has
not been set, the display will only show "0:00" when defrosting is complete.
DEFROST FUNCTION
TIME DEFROST
This function quickly defrosts food while enabling you to choose a suitable defrost period, depending on the food type. Follow the example
below for details on how to operate this function. The time range is 0:05 – 95:00.
Example: To defrost food for 10 minutes.
1. Press the
button. 2. Enter the cooking time by rotating the
ENTRY dial until the display shows: 10:00
3. Press the START/ +30sec. button
to start defrosting.
(The display will count down through
defrosting time)
Notes for Time Defrost:
• The preset microwave power level can not be changed.
• Before freezing foods, ensure food is fresh and of good quality.
• If necessary, shield small areas of meat or poultry with at pieces of aluminium foil. This will prevent the areas from becoming warm
during defrosting. Ensure the foil does not touch the oven walls.
• After defrosting an audible signal will sound ve times and the LED will then display the time of day, if the clock has been set. If the clock
has not been set, the display will only show "0:00" when defrosting is complete.
TIME DEFROST FUNCTION
14
Use only containers that are microwave-safe .
AUTO DEFROST
TIME DEFROST
AUTO DEFROST
AUTO DEFROST
AUTO
CONTROLS
AUTO MENU FUNCTION
The AUTO MENU automatically calculates the correct cooking mode and cooking time of foods . Follow the example below
for details on how to operate this function.
Example: To cook pizza with a weight of 8 Oz by using the AUTO MENU function.
1. Press the button 2. Press the START/ +30sec.
button to con rm the
setting.
3. Enter the desired weight by
rotating the ENTRY dial.
4. Press the START/ +30sec./
button to start cooking.
(The display will count down
through the programmed
cooking time.)
NOTES:
• The weight or quantity of the food can be input by rotating the ENTRY dial until the desired weight/quantity illuminates on the
display. Enter the weight of the food only. Do not include the weight of the container.
• For food weighing more or less than the weights/quantities given in the AUTO MENU chart cook by manual operation.
Menu Weight Display
A-2
A-3
A-5
A-4
A-6
A-8
A-1
A-7
1.75 Oz
3.0 Oz
3.5 Oz
1.75
3.0
3.5
Potato
Pizza
Popcorn
4 Oz
8 Oz
14 Oz
Frozen Vegetable
Beverage
Pasta
Fresh Vegetable
1 cup(120 ml)
2 cups(240 ml)
3 cups(360ml)
1
2
3
4.0
8.0
14.0
2
3
2
3
11
4 Oz
8 Oz
16 Oz
4.0
8.0
16.0
18 Oz 18.0
9 Oz
12 Oz
9.0
12.0
1.75 Oz
3.5 Oz
1.75
3.5
4 Oz
8 Oz
16 Oz
4.0
8.0
16.0
15
ENTRY dial
to
select the desired auto menu.
AUTO M ENU
auto menu.
OR
Press the buttonAUTO M ENU
once, then rotate the
3 times to select the desired
Reheat
Turn the oven off before cleaning.
Keep the inside of the oven clean. When food
spatters or spilled liquids adhere to oven walls, wipe
with a damp cloth. Mild detergent may be used if the
oven gets very dirty.
The use of harsh detergent or abrasives is not
recommended.
The outside oven surface should be cleaned with
soap and water, rinsed and dried with a soft cloth. To
prevent damage to the operating parts inside the
oven, water should not be allowed to seep into the
ventilation openings.
If the Control Panel becomes wet, clean with a soft,
dry cloth. Do not use harsh detergents or abrasives
on Control Panel.
If steam accumulates inside or around the outside of
the oven door, wipe with a soft cloth. This may occur
when the microwave oven is operated under high
humidity conditions and in no way indicates
malfunction of the unit.
It is occasionally necessary to remove the glass tray
for cleaning. Wash the tray in warm sudsy water or in
a dishwasher.
The roller guide and oven cavity floor should be
cleaned regularly to avoid excessive noise.
Simply wipe the bottom surface of the oven with mild
detergent water or window cleaner and dry. The roller
guide may be washed in mild sudsy water.
1
2
3
4
5
6
7
ROLLER GUIDE
Glass Tray Roller Guide
The ROLLER GUIDE and oven floor should be
cleaned frequently to prevent excessive noise.
The ROLLER GUIDE MUST ALWAYS be used for
cooking together with the Glass Tray.
1
2
GLASS TRAY
DO NOT operate the oven without the Glass Tray
in place.
DO NOT use any other Glass Tray with this oven.
If Glass Tray is hot, ALLOW TO COOL before
cleaning or placing it in water.
DO NOT cook directly on the Glass Tray.
(Except for popcorn)
1
2
3
4
CARE OF YOUR MICROWAvE OvEN
16
CARE AND CLEANINg
Although your oven is provided with safety features, it is important to observe the following:
1. It is important not to defeat or tamper with safety
interlocks.
2. Do not place any object between the oven front face
and the door or allow residue to accumulate on
sealing surfaces. Wipe the sealing area frequently
with a mild detergent, rinse and dry. Never use
abrasive powders or keys.
3. When opened, the door must not be subjected to
strain, for example, a child hanging on an opened
door or any load could cause the oven to fall forward
to cause injury and also damage to the door. Do not
operate the oven if it is damaged, until it has been
repaired by a competent service technician. It is
particularly important that the oven closes properly
and that there is no damage to the:
i) Door(bent)
ii) Hinges and Hookes(broken or loosened)
iii) Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by
anyone except a properly competent service
technician.
5. The oven should be cleaned regularly and any food
deposits removed;
6. Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly
result in a hazardous situation.
BEFORE YOU CALL FOR SERVICE
Refer to following checklist, you may prevent an unnecessary service call.
* The oven doesn’t work :
1. Check that the power cord is securely plugged in.
2. Check that the door is rmly closed.
3. Check that the cooking time is set.
4. Check for a blown circuit fuse or tripped main circuit
breaker in your house.
* Sparking in the cavity;
1. Check utensils. Metal containers or dishes with metal
trim should not be used.
2. Check that metal skewers or foil does not touch the
interior walls.
CARE OF YOUR MICROWAvE OvEN
17
paiticles/splatter or grease.
3. Ensure the microwave is clean and free of all food
* A : Running the oven empty for a short time will not
d a m a g e t h e o v e n . H o w e v e r, i t i s n o t
recommended.
* A : No. Both the glass tray and roller guide must
always be used in the oven before cooking.
* A : The door can be opened anytime during the
cooking operation. Then microwave energy will be
instantly switched off and the time setting will
maintain until the door is closed.
* A : The moisture on the side of your microwave oven
is normal. It is caused by steam from cooking food
hitting the cool oven surface.
* A : No. The metal screen bounces back the energy to
the oven cavity. The holes are made to allow light
to pass through. They do not let microwave
energy pass through.
* A : When baking or poaching eggs, the yolk may pop
due to steam build-up inside the yolk membrane.
To prevent this, simply pierce the yolk with a
toothpick before cooking. Never cook eggs without
piercing their shells.
* A : Standing time is very important.
With microwave cooking, the heat is in the food,
not in the oven. Many foods build up enough
internal heat to allow the cooking process to
continue, even after the food is removed from the
oven. Standing time for joints of meat, large
vegetables and cakes is to allow the inside to
cook completely, without overcooking the outside.
* A : “Standing time” means that food should be
removed from the oven and covered for additional
time to allow it to finish cooking. This frees the
oven for other cooking.
* A : Check your cooking guide again, to make sure
you’ve followed directions exactly ; and to see
what might cause variations in cooking time.
Cooking guide times and heat settings are
suggestions, to help prevent over-cooking... the
most common problem in getting used to a
microwave oven.
Variations in the size, shape and weights and
dimensions could require longer cooking time.
Use your own judgement along with the cooking
guide suggestions to check whether the food has
been properly cooked just as you would do with a
conventional cooker.
* A : Yes. Never run it empty.
* A : No. If you remove or turn over the turntable, you
will get poor cooking results. Dishes used in your
oven must t on the turntable.
* A : Yes. Th e tur nta ble rotate s c lock wis e o r
counterclockwise, depending on the rotation of
the motor when the cooking cycle begins.
* A : Yes. Pop packaged microwave popcorn following
manufacture’s guidelines. Do not use regular
paper bags. Use the “listening test” by stopping
the oven as soon as the popping slows to a “pop”
every 1 or 2 seconds. Do not repop unpopped
kernels. Do not pop popcorn in glass cookware.
QUESTIONS AND ANSWERS
18
UTENSIL gUIDE
Only use utensils that are suitable for use in microwave ovens.
To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reected
or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the utensil is marked
microwave-safe, you do not need to worry. The following table lists various utensil and indicates whether and
how they should be used in a microwave oven.
: Recommended use
: Limited Use
: Not Recommended
COOKING INSTRUCTIONS
UTENSIL SAFE COMMENTS
Can be used in small quantities to protect areas against
overcooking. Arcing can occur if the foil is too close to
the oven wall or if too much foil is used.
Do not preheat for more than 8minutes.
Porcelain, pottery, glazed earthenware and bone china
are usually suitable, unless deco-rated with a metal trim.
Some frozen foods are packaged in these dishes.
• Polystyrene cups containers
• Paper bags or newspaper
• Recycled paper or metal trims
Can be used to warm food. Overheating may cause
the polystyrene to melt.
May catch re.
May cause arcing.
• Oven-to-table ware
• Fine glassware
• Glass jars
Can be used, unless decorated with a metal trim.
Can be used to warm foods or liquids.
Delicate glass may break or crack if heated suddenly.
Must remove the lid. Suitable for warming only.
• Dishes
• Freezer bag twist ties
May cause arcing or re.
• Plates, cups, napkins and Kitch-
en paper
• Recycled paper
For short cooking times and warming. Also to absorb
excess moisture.
May cause arcing.
• Containers
• Cling lm
• Freezer bags
Particularly if heat-resistant thermoplastic. Some other
plastics may warp or discolour at high temperatures.
Do not use Melamine plastic.
Can be used to retain moisture. Should not touch the
food.
Take care when removing the lm as hot steam will
escape.
Only if boilable or oven-proof. Should not be airtight.
Prick with a fork, if necessary.
Can be used to retain moisture and prevent spattering.
19
ARCINg
If you see arcing, open the door and correct the problem.
Arcing is the microwave term for sparks in the oven.
Arcing is caused by:
• Metal or foil touching the side of the oven.
• Foil not molded to food (upturned edges act like
antennas).
• Metal, such as twist-ties, poultry pins, or gold rimmed
dishes, in the microwave.
• Recycled paper towels containing small metal pieces
being used in the microwave.
USE YOUR MICROWAVE OVEN SAFELY
General Use
Food
COOKING INSTRUCTIONS
Do not attempt to defeat or tamper with safety
interlocks.
Do not place any object between the oven front frame
and the door or allow residue to build up on sealing
surfaces. Wipe with a mild detergent, rinse and dry.
Never use abrasive powders or s.
Do not subject the oven door to strain or weight such
as a child hanging on an open door.
This could cause the oven to fall forward resulting in
injury to you and damage to the oven.
Do not operate the oven if door seals or sealing
surfaces are damaged; or if door is bent; or if hinges
are loose or broken.
Do not operate the oven empty. This will damage the
oven.
Do not attempt to dry clothes, newspapers or other
materials in the oven. They may catch on re.
Do not use recycled paper products as they may
contain impurities which may cause sparks or res.
Do not hit or strike the control panel with hard objects.
This can damage the oven.
Never use your microwave oven for home canning. The
oven is not designed for proper home canning.
Improperly canned food may spoil and be dangerous to
consume.
Always use the minimum recipe cooking time. It is
better to undercook rather than overcook foods.
Undercooked foods can be returned to the oven for
more cooking. If food is overcooked, nothing can be
done.
Heat small quantities of food or foods with low moisture
carefully. These can quickly dry out, burn or catch on
re.
Do not heat eggs in the shell. Pressure may build up
and eggs can explode.
Potatoes, apples, egg yolks and sausages are
examples of food with non-porous skins.
These must be pierced before cooking to prevent
bursting.
Do not attempt to deep fat fry in your microwave oven.
Always allow a standing time of at least 20 seconds
after the oven has been switched off to allow the
temperature to even out, stir during heating, if
necessary, and ALWAYS stir after heating. To prevent
eruptive boiling and possible scalding, you should put a
spoon or glass stick into the beverages and stir before,
during and after heating.
Do not leave the oven unattended while popping corn.
Do not pop corn in a paper bag unless it is the
commercially prepared Microwave Popcorn product.
The kernels can overheat and ignite a brown paper
bag.
Do not put packaged Microwave Popcorn bags directly
on the oven tray. Place the package on a microwave
safe glass or ceramic plate to avoid overheating and
cracking the oven tray.
Do not exceed the Microwave Popcorn manufacturers
suggested popping time.
Longer popping does not yield more popcorn but it can
result in scorch, burn of re. Remember, the Popcorn
bag and tray can be too hot to handle. Remove with
caution and use pot holders.
20
key
Then they pass through the
cooking containers to be
a b s o r b e d b y t h e w a te r
molecules in the food, all
foods contain water to a more
or lesser extent.
The microwaves cause the water molecules to vibrate
which causes FRICTION, i.e. HEAT. This heat then cooks
the food. Microwaves are also attracted to fat and sugar
particles, and foods high in these will cook more quickly.
Microwaves can only penetrate to a depth of 1½ - 2
inches(4-5cm) and as heat spreads through the food by
conduction, just as in a traditional oven, the food cooks
from the outside inwards.
MICROWAVINg PRINCIPLES
Microwave energy has been used in this country to cook and reheat food since early experiments with RADAR in
World War ll. Microwaves are present in the atmosphere all the time, both naturally and manmade sources.
Manmade sources include radar, radio, television, telecommunication links and car phones.
CONVERSION CHARTS
HOW MICROWAVES COOK FOOD
In a microwave oven,
electricity is converted
into microwave by the
MAGNETRON.
The microwaves bounce
off the metal walls and
the metal door screen.
Oven Cavity Magnetron
Waveguide
Turntable
Microwave Water Molecule Absorption Vibration
COOKING INSTRUCTIONS
15 g 1/2 oz.
25 g 1 oz.
50 g 2 oz.
100 g 4 oz.
175 g 6 oz.
225 g 8 oz.
450 g 1 lb.
30 ml 1 .oz.
100 ml 3 .oz.
150 ml 5 .oz. (1/4 pt)
300 ml 10 .oz. (1/2 pt)
600 ml 20 .oz. (1pt)
1.25 ml 1/4 tsp
2.5 ml 1/2 tsp
5 ml 1 tsp
15 ml 1 tbsp
1 Cup = 8 .oz = 240 ml
1 Pint = 16 .oz. (UK 20 .oz.) = 480 ml (UK 560 ml)
1 Quart = 32 .oz. (UK 40 .oz.) = 960 ml (UK 1120 ml)
1 Gallon = 128 .oz. (UK 160 .oz.) = 3840 ml (UK 4500 ml)
21
STANDING TIME
Dense foods e.g. meat, baked potatoes and cakes,
require standing time(inside or outside of the oven) after
cooking, to allow heat to finish conducting to cook the
center completely. Wrap roasts and baked potatoes
in aluminium foil while standing. Roasts need approx.
10-15 minutes, baked potatoes 5 minutes. Other foods
such as plated meal, vegetables, fish etc require 2-5
minutes standing. After defrosting food, standing time
should also be allowed. If food is not cooked after
standing time, return to the oven and cook for additional
time.
MOISTURE CONTENT
Many fresh foods e.g. vegetables and fruit, vary in their
moisture content throughout the season, particularly
to be adjusted. Dry ingredients e.g. rice, pasta, can dry
out during storage so cooking times may differ.
DENSITY
Porous airy foods heat more quickly than dense heavy
foods.
CLING FILM
Cling film helps keep the food moist and the trapped
steam assists in speeding up cooking times. Pierce
before cooking to allow excess steam to escape. Always
take care when removing cling film from a dish as the
build-up of steam will be very hot.
SHAPE
Even shapes cook evenly. Food cooks better by
microwave when in a round container rather than square.
SPACING
Foods cook more quickly and evenly if spaced apart.
NEVER pile foods on top of each other.
STARTING TEMPERATURE
The colder the food, the longer it takes to heat up. Food
from a fridge takes longer to reheat than food at room
temperature.
LIQUIDS
All liquids must be stirred before and during heating.
Water especially must be stirred before and during
heating, to avoid eruption. Do not heat liquids that have
previously been boiled. DO NOT OVERHEAT.
TURNING & STIRRING
Some foods require stirring during cooking. Meat and
poultry should be turned after half the cooking time.
ARRANGING
Individual foods e.g. chicken portions or chops, should be
placed on a dish so that the thicker parts are towards the
outside.
QUANTITY
Small quantities cook faster than large quantities, also
small meals will reheat more quickly than large portions.
PIERCING
The skin or membrane on some foods will cause steam
to build up during cooking. These foods must be pierced
or a strip of skin should be peeled off before cooking to
allow the steam to escape. Eggs, potatoes, apples,
sausages etc, will all need to be pierced before cooking.
DO NOT ATTEMPT TO BOIL EGGS IN THEIR SHELLS.
COVERING
Cover foods with microwave cling lm or a lid. Cover sh,
vegetables, casseroles, soups. Do not cover cakes,
sauces,baked potatoes or pastry items.
COOKINg TECHNIQUES
COOKING INSTRUCTIONS
22
baked potatoes. For this reason cooking times may have
DEFROSTINg gUIDE
▶ Do not defrost covered meat. Covering might allow
cooking to take place. Always remove outer wrap and
tray. Use only containers that are microwave-safe.
▶ Begin defrosting whole poultry breast-side-down.
Begin defrosting roasts fat-side-down.
▶ The shape of the package alters the defrosting time.
Shallow rectangular shapes defrost more quickly
than a deep block.
▶ After 1/3 of the defrost time has elapsed, check the
food. Toy may wish to turn over, break apart,
rearrange or remove thawed portions of the food.
▶ During defrost, the oven will prompt you to turn the
over. At this point, open oven door and check the
food. Follow the techniques listed below for optimum
defrost results.
Then, close oven door, touch the START key to
complete defrosting.
▶ When defrosted, food should be cool, but softened in
all areas. If still slightly icy, return to microwave oven
ver y briefly, or let stand a few minutes. After
defrosting, allow food to stand 5-60 minutes if there
are any icy areas.
Poultry and sh may be placed under running cool
water until defrosted
Turn over : Roast, ribs, whole poultry, turkey
breasts, hot dogs, sausages, steaks, or chops.
Rearrange : Break apart or separate steaks, chops,
hamburger patties, ground meat, chicken or seafood
pieces, chunks of meat such as stew beef.
Shield : Use small strips of aluminum foil to protect
thin areas or edges of unevenly shaped foods such
as chicken wings. To prevent arcing, do not allow foil
to come within 1-inch of oven walls or door.
Remove : To prevent cooking, thawed portions
should be removed from the oven at this point. This
may shorten defrost time for food weighing less than
3 lbs.(1350g).
Cooking chart
COOKING INSTRUCTIONS
ITEM POWER LEvEL COOKING TIME
PER LB./450G SPECIAL INSTRUCTION
Beef roast - Rare
- Medium
- well done
Pork roast
Bacon roast
P-80
P-80
P-80
P-HI
P-HI
6-8 min.
7-9 min.
9-11 min.
10-13 min.
8-10 min.
- Chilled meat and poultry should be
removed from the refrigerator at least
30 minutes before cooking.
- Always let the meat and poultry stand,
covered after cooking.
Whole chicken
Portions chicken
Breast (boned)
P-HI
P-80
P-80
4-9 min.
5-7 min.
6-8 min.
Fish Fillets
Whole Mackerel, Cleaned
and prepared
Whole Trout, Cleaned
& Prepared
Salmon steaks
P-HI
P-HI
P-HI
P-HI
3-5 min.
3-5 min.
4-6 min.
4-6 min.
- Brush a little oil or melted butter over the
sh, or add 15~30ml(1-2 tbsp) lemon
juice, wine, stock, milk or water.
- Always let the sh stand, covered, after
cooking
: The above times should be regarded only as a guide. Allow for difference in individual tastes and preferences.
The times may vary due to the shape, cut, and composition of the food. Frozen meat, poultry and sh
must be thoroughly thawed before cooking.
23
Reheating chart
• Baby food particularly needs to be checked carefully before serving to prevent burns.
• When heating pre-packaged ready-cooked foods, always follow the pack instructions carefully.
• If you freeze foods which were bought from the fresh or chilled counters, remember that they should be thoroughly
thawed before following the heating instructions on the packed. It’s worth putting a note on them so that other
members of the household will remember too.
• Remember metal ties and transfer food from foil containers before reheating.
• Chilled(refrigerated) food takes longer to reheat than food at room temperature (such as just-cooled food or food
from the store cupboard).
• All foods should be reheated using full microwave power.
COOKINg & REHEATINg CHART
COOKING INSTRUCTIONS
ITEM COOKING TIME SPECIAL INSTRUCTIONS
Baby food
128g jar
20 sec. Empty into a small serving bowl.
Stir well once or twice during heating.
Before serving, check the temperature carefully.
Baby milk
100ml / 4.oz.
225ml / 8.oz.
20-30 sec.
40-50 sec.
Stir or shake well and pour into a sterilized bottle.
Before serving, shake well and check the temperature carefully.
Sandwich roll or bun
1 roll 20-30 sec. Wrap in paper towel and place on glass microwaveable rack.
Lasagna
1 serving
(10 ½ oz./300g)
4-6 min. Place lasagna on microwaveable plate.
Cover with plastic wrap and vent.
Casserole
1 cup
4 cups
1 ½-3 min.
5-7 min.
Cook covered, in microwaveable casserole.
Stir once halfway through cooking.
Mashed potatoes
1 cup
4 cups
2-3 min.
6-8 min.
Cook covered, in microwaveable casserole.
Stir once halfway through cooking.
Baked beans
1 cup 2-3 min. Cook covered, in microwaveable casserole.
Stir once halfway through cooking.
Ravioli or pasta in sauce
1 cup
4 cups
2-3 min.
6-9 min.
Cook covered, in microwaveable casserole.
Stir once halfway through cooking.
24
Cooking Guide for fresh vegetables
Cooking Guide for frozen vegetables
Use a suitable glass bowl with lid. Add 30-45ml cold water(2-3 tbsp.) for every half pound unless another water
quantity is recommended - see table. Cook covered for the minimum time - see table.
Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs or butter
after cooking. Cover during a standing time of 3 minutes.
Hint : cut the fresh vegetables into even sized pieces. The smaller they are cut, the quicker they will cook.
All vegetables should be cooked using full microwave power.
VEgETABLE CHART
COOKING INSTRUCTIONS
vEGETABLES WEIGHT TIME COMMENTS
Broccoli ½ lb./250g
1 lb./500g
2-3 min
4-6 min
Prepare even sized orets.
Arrange the stems to the centre.
Brussels sprouts ½ lb./250g 3-4 min Add 60-75ml(4-5 tbsp.) water.
Carrots ½ lb./250g 2-3 min Cut carrots into even sized slices.
Cauliower ½ lb./250g
1 lb./500g
2-3 min
4-6 min
Prepare even sized orets. Cut big orets into halves.
Arrange stems to the centre.
½ lb./250g 2-3 min Cut zucchini into slices. Add 30ml(2tbsp.) water or a
knob of butter. Cook until just tender.
Aubergine
(eggplant)
½ lb./250g 2-3 min Cut eggplant into small slices and sprinkle with 1 table-
spoon lemon juice.
Leeks ½ lb./250g 2-3 min Cut leeks into thick slices.
Mushrooms 0.3 lb./125g
½ lb./250g
1-2 min
2-4 min
Prepare small whole or sliced mushrooms. Do not add
any water. Sprinkle with lemon juice. Spice with salt and
pepper. Drain before serving.
Onions ½ lb./250g 2-3 min Cut onions into slices or halves. Add only 15ml(1tbsp.)
water.
Pepper ½ lb./250g 2-4 min Cut pepper into small slices.
Potatoes ½ lb./250g
1 lb./500g
3-5 min
5-7 min
Weigh the peeled potatoes and cut them into similar sized
halves or quarters.
vEGETABLES WEIGHT TIME INSTRUCTIONS
spinach 0.3 lb./125g 1-2 min Add 15ml(1tbsp.) cold water.
broccoli ½ lb./250g 2½-4 min Add 30ml(2 tbsp.) cold water.
Peas ½ lb./250g 2½-4 min Add 15ml(1 tbsp.) cold water.
Green beans ½ lb./250g 3-5 min Add 30ml(2 tbsp.) cold water.
Mixed vegetables
(carrots/peas/corn)
½ lb./250g 2½-4 min Add 15ml(1 tbsp.) cold water.
Mixed vegetables
(Chinese style)
½ lb./250g 3-5 min Add 15ml(1 tbsp.) cold water.
25
Zucchini
TOMATO & ORANGE SOUP
1 oz.(25g) butter
1 medium onion, chopped
1 large carrot & 1 large potato, chopped
13/4lb(800g) canned, chopped tomatoes
juice and grated rind of 1 small orange
11/2pints(900ml) hot vegetable stock
salt and pepper to taste
1. Melt the in a large bowl on P-HI for 1 minute.
2. Add the onion, carrot and potato and cook on P-HI
for 4 minutes. stir halfway through cooking.
3. Add the tomatoes, orange juice, orange rind and
stock. Mix thoroughly. Season with salt and pepper to
taste. Cover the bowl and cook on P-HI for 15
minutes. stir 2-3 times during cooking, until the
vegetables are tender.
4. Blend and serve immediately.
FRENCH ONION SOUP
1 large onions, sliced
1 tbsp (15ml) corn oil
2 oz.(50g) plain our
2 pints(1.2 liters) hot meat
or vegetable stock
salt and pepper to taste
2 tbsp (30ml) parsley, chopped
4 thick slices French bread
2 oz.(50g) cheese, grated
1. Place the onion and oil a bowl, mix well and cook on
P-HI for 1 minutes.
2. Stir in the our to make a paste and gradually add
stock. Season and add the parsley.
3. Cover the bowl and cook on P-70 for 16 minutes.
4. Pour the soup into serving bowls, submerge bread
and sprinkle generously with cheese.
5. Cook on P-70 for 2 minutes, until the cheese has
melted.
STIR FRIED VEGETABLES
1 tbsp(15ml) sunower oil
2 tbsp (30ml) soy sauce
1 tbsp (15ml) sherry
1"(2.5cm) root ginger,
peeled and nely grated
2 medium carrots, cut into ne strips
4 oz.(100g) button mushrooms,
chopped
2 oz.(50g) beansprouts
4 oz.(100g) snow peas
1 red pepper, seeded and thinly sliced
4 spring onions, chopped
4 oz.(100g) canned water chestnuts,
sliced
1/4 head of chinese cabbage, thinly sliced
1. Place the oil, soy sauce, sherry, ginger, garlic and
carrots in a large bowl, mix thoroughly
2. Cover and cook on P-HI for 3-5 minutes, stirring
once.
3. Add the button mushrooms, beansprouts, mange-
tout, red pepper, spring onions, water chestnuts and
chinese leaves. Mix thoroughly.
4. Cook on P-HI for 5-6 minutes, until the vegetables
are tender. Stir 2-3 times during cooking.
Stir fried vegetables are ideally served with meat or
fish.
HONEYED CHICKEN
4 boneless chicken breasts
2 tbsp(30ml) clear honey
1 tbsp(15ml) whole grain mustard
1/2 tsp(2.5ml) dried tarragon
1 tbsp(15ml) tomato puree
1/4 pint(150ml) chicken stock
1. Place the chicken breasts in a casserole dish.
2. Mix all remaining ingredients together and pour over
the chicken. Salt and pepper to taste.
3. Cook on P-HI for 13-14 minutes. Rearrange and coat
the chicken with the sauce twice during cooking.
RECIPES
COOKING INSTRUCTIONS
26
BLUE CHEESE & CHIVE JACKETS
2 baking potatoes,
(approx.9 oz.(250g) each)
2 oz.(50g) butter
4 oz.(100g) blue cheese, chopped
1 tbsp(15ml) fresh chives, chopped
2 oz.(50g) mushrooms, sliced
salt and pepper to taste
1. Prick each potato in several places. Cook on P-HI for
7-9 minutes. Halve and scoop the esh into a bowl,
add the butter, cheese, chives, mushrooms, salt and
pepper, mix thoroughly.
2. Pile mixture into the potato skins and place in a an
dish.
3. Cook on P-50 for 10 minutes.
WHITE SAUCE
1 oz.(25g) butter
1 oz.(25g) plain our
1/2 pint(300ml) milk
salt and pepper to taste
1. Place the butter in a bowl and cook on P-HI for 1
minute, until melted.
2. Stir in the our and whisk in the milk. Cook on P-HI
for 3-4 minutes, stirring every 2 minutes until thick
and smooth. Season with salt and pepper to taste.
STRAWBERRY JAM
11/2 lb.(675g) strawberries, hulled
3 tbsp(45ml) lemon juice
1 /
12 lb.(675g) confectioners sugar
1. Place strawberries and lemon juice in a very large
bowl, heat on P-HI for 4 minutes, or until the fruit has
softened. Add sugar, mix well.
2. Cook on P-70 for 20-25 minutes, until setting point*is
reached, stir every 4-5 minutes.
3. Pour into hot, clean jars. Cover, seal and label.
* setting point : To determine setting point, place 1
tsp(5ml)jam onto chilled saucer. Allow to stand for 1
minute. Move surface of jam gently with your finger, if
the surface wrinkles setting point has been reached.
PLAIN MICROWAVE CAKE
4 oz.(100g) margarine
4 oz.(100g) sugar
1 eggs
4 oz.(100g) self raising our, sifted
2-3 tbsp(30-45ml) milk
1. line the base of 8" (20.4cm) cake dish with grease-
proof paper.
2. Cream the margarine and sugar together until light
and uffy. Beat in the eggs and fold in the sifted our
alternately with the milk.
3. Pour into prepared container. Cook on P-HI for 4-5
minutes, until a skewer comes out cleanly.
4. Leave the cake to stand for 5 minutes before turning
out.
OMELETTS
1/2 oz.(15g) butter
4 eggs
6 tbsp(90ml) milk
salt & pepper
1. Whisk together eggs and milk.
2. Place butter in 10"(26cm) an dish. Cook on P-HI for
1 minute, until melted. Coat the dish with the melted
butter.
3. Pour omelette mixture into an dish. Cook on P-HI for
2 minutes. whisk mixture and cook again on P-HI for
1 minutes.
COOKING INSTRUCTIONS
27
SCRAMBLED EGG
1/2 oz.(15g) butter
2 eggs
2 tbsp(30ml) milk
salt & pepper
1. Melt the butter in a bowl on P-HI for 1 minute.
2. Add the eggs, milk and seasoning and mix well.
3. Cook on P-HI for 3 minutes, stirring every 30
seconds.
SAVORY MINCE
1 small onion, diced
1 clove garlic, crushed
1 tsp(5ml) oil
7 oz.(200g) can chopped tomatoes
1 tbsp(15ml) tomato puree
1 tsp(5ml) mixed herbs
8 oz.(225g) ground beef
salt and pepper
1. Place onion, garlic and oil in casserole, and cook on
P-HI for 2 minutes or until soft.
2. Place all other ingredients in casserole. Stir well.
3. Cover and cook on P-HI for 5 minutes then P-50 for
8-13 minutes or until the meat is cooked.
COOKING INSTRUCTIONS
28
