RouterBOARD Groove 2Hn
Quick Setup Guide and Warranty Information
The RouterBOARD Groove 2Hn comes preinstalled in an outdoor enclosure, with a built-in 2GHz
802.11b/g wireless, an N-Male antenna connector, and one 10/100 Ethernet connector which sup-
ports MDI-X auto detection. The device is packaged with a 24V power adapter, a PoE injector and
two mounting loops. Note: Another model, the Groove A-2Hn is an AP version of this device, and
includes a Level4 RouterOS license for wireless access point mode support.
First use
1. Connect the antenna to the N-Male connector.
2. Twist to open the Groove case, connect an Ethernet cable to the Ethernet port
3. Use the provided rubber insulator to put on the Ethernet cable, and push it into the case
opening, so that the opening is tightly closed
4. The Groove accepts 8-30V Passive PoE from a PoE injector
5. The default IP address from Ether1 is 192.168.88.1 for configuration
Username is admin and there is no password
Powering
The board accepts powering from the Ethernet port (Passive PoE):
Ethernet port accepts passive Power over Ethernet 8-30V DC. Package contains a 24V
adapter and a PoE injector.
Maximum power consumption of the device is 4W.
Booting process
This device doesn't come fitted with a Serial Port connector, so initial connection has to be done via the Ethernet cable, using
the MikroTik Winbox utility. Winbox should be used to connect to the default IP address of 192.168.88.1 with the username
admin and no password.
In case IP connection is not available, Winbox can also be used to connect to the MAC address of the device. More infor-
mation here: http://wiki.mikrotik.com/wiki/First_time_startup
In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the de-
vice when starting it until the LED light turns off, and Groove will start to look for Netinstall servers.
Mounting
If you wish to tighten the Groove to a pole, you can do it with the provided mounting loops. The Groove comes bundled with
two mounting loops - guide the loops around the Groove though the provided edge markings, and around the pole where it
will be mounted. You should avoid connecting a loose Ethernet cable to the Ethernet port, secure the cable to a wall or the
pole, so that the cable weight is not pulling the port. It is recommended to secure the Ethernet cable less than 2m from the
Groove device. This is to ensure that the cable doesn't damage the port by it's weight, or doesn't fall out.
Expansion Slots and Ports
Built in 2GHz 802.11b/g wireless, 1x1 MIMO, station mode
One 10/100 Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X), so you can use either
straight or cross-over cable for connecting to other network devices. The Ethernet port accepts 8-30V DC powering
from a passive PoE injector.
![](/img.php?id=1582188&img=bg2.png)
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 15-Nov-2011
Buttons and Jumpers
RouterOS reset jumper hole (no direct access, board has removed from case) – resets RouterOS software to de-
faults. Must short circuit the metallic sides of the hole (with a screwdriver, for example) and boot the device. Hold
screwdriver in place until RouterOS configuration is cleared.
RouterBOOT reset button (access through the plastic door) has two functions:
o Hold this button during boot time until LED light starts flashing,
release the button to reset RouterOS configuration (same result as with reset hole)
o Hold this button during boot time longer, until LED turns off,
then release it to make the device look for Netinstall servers.
Operating System Support
Currently tested operating system is MikroTik RouterOS (starting from version v5).
Copyright and Trademarks.
Copyright MikroTikls SIA. This manual contains information protected by copyright law. No part of it may be reproduced or
transmitted in any form without prior written permission from the copyright holder. RouterBOARD, RouterOS, RouterBOOT
and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks appearing in this manual are the
property of their respective holders.
Hardware. MikroTik warrants all RouterBOARD series equipment for the term of fifteen (15) months from the shipping date
to be free of defects in materials and workmanship under normal use and service, except in case of damage caused by me-
chanical, electrical or other accidental or intended damages caused by improper use or due to wind, rain, fire or other acts of
nature.
To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization) procedure. Fol-
low the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA process.
1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company regarding all war-
ranty and repair issues, the following instructions apply ONLY if you purchased your equipment directly from
MikroTik in Latvia.
2. We do not offer repairs for products that are not covered by warranty. Exceptions can be made for RB1000, RB1100
and RB1200.
3. Out-of-warranty devices and devices not covered by warranty sent to Mikrotikls will be returned to the sender at
sender's cost.
RMA Instructions are located on our webpage here: http://rma.mikrotik.com
Manual. This manual is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to,
the implied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every effort to en-
sure the accuracy of the contents of this manual, however, it is possible that it may contain technical inaccuracies, typo-
graphical or other errors. No liability is assumed for any inaccuracy found in this publication, nor for direct or indirect, inci-
dental, consequential or other damages that may result from such an inaccuracy, including, but not limited to, loss of data or
profits. Please report any inaccuracies found to support@mikrotik.com
![](/img.php?id=1582188&img=bg3.png)
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 15-Nov-2011
Federal Communication Commission Interference Statement (FCC ID:
TV7GROOVE-2HN)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation. This device and its antenna must not be co-located or op-
eration in conjunction with any other antenna or transmitter.
IMPORTANT: Exposure to Radio Frequency Radiation.
32 cm minimum distance has to be maintained between the antenna and the occupational user and 100 cm to general public.
Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satis-
fied.
MODIFICATIONS
The FCC requires the user to be notified that any changes or modifications to this device that are not expressly approved by the
manufacturer may void the user’s authority to operate the equipment. The correction of interference caused by unauthorized
modification, substitution or attachment will be the responsibility of the user. The manufacturer and its authorized resellers or
distributors are not liable for any damage or violation of government regulations that may arise from failing to comply with
these guidelines.
PROFFESIONAL INSTALLATION ATTESTATION
MIKROTIKLS SIA addresses the following items to ensure that the above referenced equipment is professionally installed:
1. The TV7GROOVE-2HN will only be sold by MIKROTIKLS SIA or one of its authorized dealers. MIKROTIKLS
SIA and its authorized dealers will be under strict marketing control and will only market and sell the TV7GROOVE-
2HN to professionals.
2. Professional installation is required for the TV7GROOVE-2HN and will be performed only by someone knowledgea-
ble of its use. MIKROTIKLS SIA will ensure that the TV7GROOVE-2HN is only marketed and sold to professionals.
3. The TV7GROOVE-2HN is not sold to the general public and is sold only for industrial or commercial use by profes-
sional installers.
LIST OF APPROVED ANTENNAS
o 24 dBi Dish DC 24-HD-PFIP
o 20 dBi Panel WLP-2450-20
o 17 dBi Sector SA 24-90-17-WB
o 15 dBi Omni Directional (pole) WL0-2450-15
o 13 dBi Omni Directional (hor. Polarization) HP, 0DH 24-13
Antennas of same type and lower gain than those listed above may be used in compliance with certification.
