Mizco SWISHQ Bluetooth Headphone Adaptor User Manual
Mizco International Inc. Bluetooth Headphone Adaptor
Mizco >
User Manual
For additional languages please
visit our support page at:
www.DigipowerSolutions.com/
support.
Questions? Problems? Picked upthe wrong item?
Before RETURNING to the Store,
please give our customer service team
a chance to help. Call us toll free at: 1.800.838.3200
for a seamless and speedy resolution.
•
¿Preguntas? ¿Problemas?
¿Se compró el producto equivocado?
Antes de REGRESARLO a la tienda, por favor dele una
oportunidada nuestro personal del servicio
al cliente a que le ayuden.
Llámenos gratuitamente al: 1.800.838.3200
para una resolución rápida y sin problemas.
•
Des questions? Des problèmes?
Vous avez ramassé le mauvais article?
Avant de REVENIR au magasin, laissez la chance à
notre
équipe du Service à la clientèle de vous aider.
Appelez-nous sans frais au numéro 1.800.838.3200
pour que nous puissions corriger rapidement la
situation.
Declaration of Conformity with FCC Rules for Electromagnetic
Compatibility
We, Mizco International, Inc., of 80 Essex Ave East, Avenel, NJ 07001,
declare under our sole responsibility that the product JS1-V9H to
which this declaration relates, complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
ICES
This Class B digital apparatus complies with Canadian ICES-003.
Declaración de conformidad con los reglamentos de la FCC
para compatibilidad electromagnética
Nosotros, Mizco International, Inc., de 80 Essex Ave East, Avenel, NJ
07001, declaramos bajo nuestra responsabilidad única que el producto
JS1-V9H relacionado con esta declaración, cumple con la Parte 15
de las reglas de la FCC. Su operación está sujeta a las siguientes dos
condiciones: (1) este dispositivo no puede causar interferencia dañina,
y (2) este dispositivo deberá aceptar cualquier interferencia recibida,
incluyendo interferencia que pudiera causarle una operación no
deseada.
Este equipo ha sido probado y se encontró que cumple con los límites
establecidos para un dispositivo digital Clase B, de conformidad con
la sección 15 de las reglas de la FCC. Estos límites están diseñados
para ofrecer una protección razonable contra interferencia perjudicial
cuando el equipo se opera en una instalación residencial. Este equipo
genera, usa y puede emitir energía de radio frecuencia y si no se instala
y usa de acuerdo con las instrucciones podría provocar interferencia
perjudicial a las comunicaciones de radio. Sin embargo, no hay garantía
de que dicha interferencia no ocurrirá en una instalación en particular.
Si este equipo ocasiona interferencia perjudicial a la recepción de radio
o televisión, lo cual se puede determinar apagando y encendiendo
el equipo, se sugiere que el usuario trate de corregir la interferencia
mediante una de las siguientes medidas:
• Colocar u orientar la antena receptora en otro lado.
• Aumentar la separación entre el equipo y el receptor.
• Conectar el equipo una salida o circuito distinto al que está conectado
el receptor.
• Consultar a su proveedor o un técnico de radio o televisión con
experiencia para que le ayuden.
Mizco International, Inc. no es responsable por cualquier interferencia
causada por modicaciones no autorizadas a este equipo. Dichas
modicaciones podría invalidar la autorización del usuario para operar
este equipo.
ICES
Este aparato digital Clase B cumple con el ICES-003 de Canadá.
Déclaration de conformité à la réglementation FCC en
matière de compatibilité électromagnétique
Nous, Mizco International, Inc., sis au 80 Essex Ave East, Avenel, NJ
07001, déclarons sous notre seule responsabilité que le produit JS1-V9H
auquel se réfère la présente déclaration, est conforme aux normes
énoncées à l’alinéa 15 de la réglementation FCC. Le fonctionnement
est assujetti aux deux conditions suivantes: (1) cet appareil ne peut pas
provoquer d’interférence nuisible, et (2) cet appareil doit accepter toute
interférence reçue, y compris des interférences pouvant entraîner un
fonctionnement non désiré.
Cet appareil a été contrôlé et jugé conforme aux limites imposées
pour les unités numériques de classe B, en vertu de l’alinéa 15 de
la réglementation FCC. Ces limites visent à assurer une protection
raisonnable contre les interférences en milieu résidentiel. Cet appareil
génère, utilise et peut émettre de l’énergie radioélectrique et, s’il n’est
pas installé et utilisé selon les instructions fournies, il peut causer des
interférences dans les communications radio. Néanmoins, aucune
installation n’est par dénition exempte de ce phénomène. Si cet
appareil cause eectivement des interférences nuisibles lors de la
réception d’émissions radio ou télévisées (et il sut, pour s’en rendre
compte, d’allumer et d’éteindre l’appareil), l’utilisateur devra tenter de
corriger ces interférences en prenant l’une des mesures suivantes:
• Réorienter ou changer la position de l’antenne réceptrice.
• Augmenter la distance entre l’équipement et le récepteur.
• Brancher l’équipement sur une prise de courant appartenant à un
circuit diérent de celui sur lequel est branché le récepteur.
• Demander l’assistance du fournisseur ou d’un technicien de télé ou
de radio expérimenté.
Mizco International, Inc., n’est pas responsable des interférences
causées par des modications non autorisées de cet équipement. De
telles modications peuvent rendre nulle l’autorisation accordée aux
utilisateurs de se servir de cet équipement.
ICES
Ce périphérique numérique de classe B est conforme à la norme
canadienne ICES-003.
Item No: SWISHQ
USER GUIDE • GUÍA DEL USUARIO • GUIDE D’UTILISATION
BLUETOOTH HEADPHONE ADAPTER
Package Includes:
1. Swish Bluetooth Adapter
2. 3.5mm audio cables
3. Micro USB charging cable
4. Swish Bluetooth Adapter
mounting plate
5. Armband
6. Headphone band
7. Magnetic mount with
adhesive backing
©2015 Mizco International, Inc.
Avenel, New Jersey
All rights reserved.
Todos los derechos reservados.
Tous droits réservés.
www.digipowersolutions.com
tel: 800•838•3200
email: digipowersolutions@mizco.com
DIGIPOWER is a registered trademark
of Mizco International Inc.
DIGIPOWER es una marca registrada
de Mizco International Inc.
DIGIPOWER est une marque de
commerce enregistrée
de Mizco International, Inc.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
| 1 | 2 | 3 | 4 | 5 | 6 | 7 |
usIng the swIsh wIth the magnetIc mount
• For headphones with a at surface on the outside of the
earpiece measuring 1.5” (38mm) or greater you can use the
magnetic mount to attach the Swish to your headphones
• Peel o the paper backing on the mounting piece and apply to
the backside of the earcup with the 3.5mm jack. The open part
of the ring should be facing downward (6 o’clock position)
• Attach the Swish BT Adaptor to the magnetic plate.
• There are small magnets inside the body of the Swish to hold
it in place and a notch on the back to keep it in the correct
position.
• The power button on the Swish should be facing upward (12
o’clock position)
• Attach the audio cable between the Swish and your
headphones
• See USER INSTRUCTION CHART for operation of the SWISH
Bluetooth adapter
usIng the swIsh wIth the aRmBand and
mountIng Plate
• Insert the Swish onto the mounting plate so a short clockwise
turn aligns the audio jack with the white dot on the side of the
mounting plate
• Feed the buckle through the left or right slot on the mounting
plate. The long Velcro strip needs to be facing outward
• Loop the other end of the strap through the buckle and tighten
• Place on your arm and feed the strap through the opposite slot,
adjust so the strap is comfortable. Press the strap down against
the Velcro pad to hold it in place.
• See USER INSTRUCTION CHART for operation of the SWISH
Bluetooth adapter
usIng the swIsh wIth the headPhone Band and
mountIng Plate
• Insert the Swish onto the mounting plate so a short clockwise
turn aligns the audio jack with the white dot on the side of the
mounting plate.
• Feed the buckle through the left or right slot on the mounting
plate. The long Velcro strip needs to be facing outward.
• Loop the other end of the strap through the buckle and tighten
• Place on the band of your headphones, close to the earpiece
with the audio jack
• Loop the strap through the opposite slot and secure it on the
headband. Press the strap down against the Velcro pad to hold
it in place.
• See USER INSTRUCTION CHART for operation of the SWISH
Bluetooth adapter
PaIRIng and usIng the swIsh Bluetooth adaPteR
• On rst use charge the Swish by connecting the micro USB cable
to a USB power supply or your computer
• The red LED will remain on while the Swish is charging and turn
o when it is fully charged
• Press and hold the power button for 3 seconds to turn on the
device
• Press and hold the center button for 3 seconds to put the Swish
into pairing mode. Make sure your devices’ Bluetooth is turned
on and it is set for discoverable
• “Swish” will show up in the list of devices and should now be
paired
• See USER INSTRUCTION CHART for operation of the SWISH
Bluetooth adapter
useR InstRuctIon chaRt
Power on When the product is o , hold the Power button for 3 seconds. The blue lights
ashes three times and a tone is heard through your headphones/earbuds.
Pair & connect When the receiver is in standby or playing music, press the play button for 3
seconds until the red and blue lights ash alternately. Operate your Bluetooth
Smartphone/Tablet to search for this Bluetooth receiver, there is a tone when
it is connected.
Answer calls After connecting, when an external call comes in , short press the power button
to answer, there is a beep.
Hang up calls During a call, short press the power button to hang up, there is a tone.
Refuse calls When an external call comes in, hold the power button 3 seconds to reject, there
is a beep.
Voice dial Connect a Bluetooth phone and in standby mode, short press the power button to
voice dial (your phone must support this function )
Voice change During a call, hold the power button for 3 seconds, the voice switches to the
phone. Do the same operation, the voice switches to Bluetooth (Note: cannot
shut down during a call )
Redial the last dialed
number Connect a Bluetooth phone in standby mode , double-click the power button ,
there is a beep
Mic mute During a call, hold the volume down button for 3 seconds, the red and blue lights
ash simultaneously twice , there is a tone , the other party cannot hear the
sound. The same operation can resume the microphone sound.
Line out Plug in your headphones or speakers audio cable to play music
Volume adjust Short press volume up button to increase the volume , press the volume down key
to decrease ( beep is heard when sound is at Min or Max )
Play and pause In standby mode , press the play button to play or pause music.
Previous/next When playing music press Previous button to play the last song, short press the
next button to play the next
iPhone battery status Supported
Delete the Pairing
information Hold the power button and volume down button for 7 seconds, the red and blue
lights will ash twice.
Exit the pairing mode
automatically If receiver is in Pairing state but not connected it will automatically exit pairing
mode within 5 minutes.
Auto power-o Receiver will shut down automatically if there is no connection for 10 minutes or
the battery level is very low.
Manual shutdown Power on state , hold the power button for 3 seconds to shut down, the red light
ashes 3 times with a tone
led FunctIon chaRt
Power on Blue light ashes 3 times
Power o Red light ashes 3 times
Standby not connected with mobile phone Blue light ashes once every 5 seconds
standby connected with mobile phone Blue light ashes once every 7 seconds
Calling in Blue light ashes 2 times every 5 seconds
On a call Blue light ashes once every 7 seconds
Mute Red and blue lights ash twice
Charging Red light remains on
Full charge Red light turns o
Low battery level Red Light ashes
PRoduct sPecIFIcatIons
Size: 62.4(L)*49.5(W)*23.8(H)mm
Weight: 18.6g
Button: Power button , multi-function button,
Previous button, Next Button,volume +, volume -
LED light: Red LED*1 Blue LED*1
Microphone: One 4015 Omnidirectional -42±2dB
Battery: Lithium polymer battery422417, 85mAh
Antenna: Built-in Antenna
Charge port: Micro USB
Line Out audio interface: 3.5mm Audio interface
Charge time: 2 hours (approximately)
Bluetooth version: Bluetooth4.0
haRdwaRe sPecIFIcatIons
Bluetooth chip CSR8645
Transmit power: CLASS2 MAX4dbm
Receiver sensitivity: -88dbm
Working frequency(HZ) 2.4GISM band 2.402-2.480GHZ
Modulate way: GFSK, TT/4 DQPSK,8DPSK
Rated power(W) 10mW
Rated operational voltage(V) 3.7V
Rated charging voltage(V) 5V
soFtwaRe sPecIFIcatIons
BT software version: 1.5
BT HF software version: 1.2
Bluetooth stereo Stereo
AVRCP Supported
AAC Supported
APT-X Supported
A2DP Supported
Roduct dIagRam
On/O Light Indicator
Next Track
Call Answer/Pairing
Volume Up
Micro USB
charging port
3.5mm Audio Jack
Volume Down
Previous Track
Microphone
lImIted waRRanty:
Mizco’s responsibility with regard to this limited warranty shall
be limited solely to the repair or replacement at its option, of any
product, which fails during normal consumer use for a period of 2
Years from the date of purchase. This warranty does not extend to
damage or failure, which results from misuse, neglect, accident,
alteration, abuse, improper installation or maintenance. This warranty
does not extend to equipment used with this product. If at any time
during the 2 Year period following the purchase the product fails due
to defects in materials or workmanship, return the defective product
with freight prepaid and proof of purchase. All brands represented
herein are registered trademarks of their respective manufacturers.
Design and specications are subject to change without notice.
waRnIng! ImPoRtant saFety InstRuctIons!
Failure to read and follow these safety instructions could result in re,
explosion, electrical shock or other hazard, causing serious and/or
fatal injury and/or property damage.
1. Do not modify, disassemble, open, drop, crush, puncture or
shred the product
2. Do not expose the product to rain or water
3. Keep the product away from open ame or sunlight to
prevent heat build-up
4. Keep the product away from children. This product is not a toy.
5. Ensure that all persons who use the product read and follow
these warnings and instructions.
ENGLISH
USER GUIDE
