User Manual
Long press to disconnect the
current Bluetooth connection and search
for a new device
ITEMS INCLUDED:
1. TT-SP45 Speaker
2. USB Charging Cable
3. 3.5mm Audio Cable
CONNECTING TO A DEVICE:
1. Activate your phone’s Bluetooth setting.
2.Long press to power on the speaker.
3. Go to your phone’s Bluetooth settings, scan for new
Bluetooth devices.
4. Once the speaker is discovered, click on “TT-SP45”
to pair with it.
5. If your phone asks for a pairing code, please enter
‘0000’ and conrm it.
6. The speaker will beep to indicate it is now paired
and the LED light will stay lit.
HANDS FREE FUNCTION:
The speaker will emit a ringtone for an incoming call.
Short press to answer the call and talk to the
speaker directly. Short press to end the call and go
back to play status. Long press to reject the
incoming call.
AUX AUDIO-IN CONNECTOR
The speaker is equipped with an aux-in port for a wired
connection. Plug in any device with a 3.5mm jack and
once the green indicator light turns on, you are capable
of playing your music through a wired connection.
LOW POWER INDICATION
See how much battery power the Rugged Speaker has
left, with four LED lights. If all 4 LEDs illuminate, the
device is fully charged. If only 3 illuminate the device is
75% charged, 2 means only 50% charged, and 1 means
25% or less. When the speaker reaches 10% battery life,
a voice prompt will inform you that it is time to charge
the speaker.
CHARGING THE SPEAKER:
1. Connect the included USB cable to your computer or
USB power adapter.
2. 4 red LEDs illuminate. 1 light indicates 25% battery
life. 2 lights indicate 50% battery life, 3 lights 75%
battery life, 4 lights indicate 100% battery life.
3. A blinking white light indicates the battery is
charging.
4. illuminated white lights indicate that charging in
complete.
Function Operation
Answering calls When receiving an incoming call, short
press to answer the call and short
press again to end the call.
End or reject a call Short press key to end the
call or long press to reject
the call
Power ON/OFF Long press to ON/OFF
Play/Pause Short press control music playback
Volume – or + Short press +/- to raise/lower volume
Next/previous Long press + to skip to the next track. Long
press - to skip to the previous track
Un-pairing the
Bluetooth
connection
Flashlight Short press to change 4 modes of the
ashlight (normal mode, quick ash mode,
SOS slow ash mode, ashlight OFF)
Note:
1. If the device is in Bluetooth mode and a wire is
inserted into the 3.5mm audio jack, the speaker will
automatically switch to AUX mode.
2. Turn o the speaker when it is not in use to
conserve power.
2. AUX mode: Green light stays lit
3. Charging Status: 4 red LEDs illuminate. 1 light
indicates 25% battery life. 2 lights indicate 50%
battery life, 3 lights 75% battery life, 4 lights indicate
100% battery life. A blinking white light indicates the
battery is charging. 4 illuminated white lights indicate
charging is complete.
LED Status:
1. Bluetooth Mode: Blue light ashes when ready to
pair. Blue light stays lit once connected.
WORKING TEMPERATURE STORAGE CONDITION
Temperature:
0°C~40°C
Humidity: 0% ~85% RH
Temperature:
-30°C~60°C
Humidity: 0% ~90% RH
12
345
SPECIFICATIONS:
3.5mm Audio Jack AUX-in Port
Micro USB Charge Port
Bluetooth Version: 4.1
Power Bank Output : 5V – 1A
Driver Unit: Diameter 53mm, 5W*2=10W
Battery: 4400mAh
Play Time: 15 hours
Charge Time: 7 hours
Flashlight Lumen: 100 LM
Length: 258mm / 10.16 in
Width: 85mm / 3.35 in
Height: 118mm / 4.65 in
Material: ABS + Silicone + Aluminum
Weight: TBA once tooling nished
Waterproof Level: IP67
Transmission Distance: 10m / 33 feet
Signal to Noise Ratio: ≥75dB
Frequency Range: 180Hz-18KHz
THD: ≤1%
Front
Top
Bottom
Back
Left
Right
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
