Congratulaons on the purchase of the Mobi® Pure Sounds™ Audio Monitor-
ing System, which brings you the latest in wireless technology. We recommend
that you read the instrucons carefully before use.
The Mobi® Pure Sounds™ enables you to transmit audio wirelessly, which is
ideal for monitoring a babies, young children, pets, or the elderly.
Your Mobi® Pure Sounds™ uses a digital transmission to ensure clear and con-
sistent audio transmission. The signal also passes easily through interior walls.
However, buildings with metal frames or placing the transmier near large
metal objects may cause signal degradaon. If recepon is poor, moving the
transmier or receiver may x this problem.
1
PACKAGE CONTENTS FEATURES
• Trasmission Range up to 600Ft
• 2.4 GHz Private Digital Transmission
• No installaon needed—ready to use
• Compact design for easy portability
• Auto Mute with Voice Acvaon
• Low Baert and Out of Range Indicators
• Rechargeable Baeries Included for Receiver
• AC Adaptors included for Receiver and Transmior
1 x Receiver Unit (#70294R)
1 x Transmier Unit (#70294T)
1 X Receiver Power Cord
1 X Transmier Power Cord
1 x Rechargeable Baery Pack
NOTE: If you nd any of the contents are missing or should you need to order replace-
ment parts, please contact the manufacturer or visit www.getmobi.com.
2 3
• Always use transmier and receiver where there is adequate
venlaon. To prevent overheang, keep away from heat sources
such as radiators, heat registers, stoves, or other appliances that
produce heat.
• Use only a dry coon cloth to keep the Camera and Monitor units
free of dust. Do no use a dampened cloth, water, or liquid cleaner
of any kind.
• Remove the baery from the Monitor during long periods of non-
use as alkaline baeries can leak.
• Unplug the AC adaptors from the Monitor and Camera during peri
ods of non-use. To disconnect from the power supply, grip the
transformer and pull from the power socket. Never pull by the
cord.
• Replace baery with the same equivalent type. Please dispose of
old, defecve baeries in an environmentally friendly manner in
accordance with the relevant legislaon.
• Only use the Monitoring System with the supplied power adaptors.
CONSUMER GUIDE TO PRODUCT SAFETY
Please read this instrucon manual before using your Mobi® Pure Sounds™ sys-
tem. When using electrical appliances, basic safety precauons should always
be followed.
Please keep safe for future reference.
• This product is not intended to be used as a medical monitor and its
use should not replace adult supervision.
• Periodically examine this product for damage to the cord, housing or
other parts that may result in the risk of re, electric shock or injury.
Do not operate any product with a damaged cord or plug. If the Color
Wireless Monitor malfuncons or is damaged in any manner please
contact the manufacturer for examinaon and repair to avoid a hazard.
• Never use transmier and receiver near water (i.e. bathtub, sink, etc.).
• The AC adaptors are not Toys.
4 5
KNOWING YOUR RECEIVER KNOWING YOUR TRANSMITTER
11. Power On Indicator
12. DC Jack (5V/600mA)
Buon & LED Funcons
1. Power On/O Buon
2. Volume Up ( + )
3. Volume Down ( - )
4. Sound Level Indicator (LED will ash indicang noise level increase)
5. Power On Indicator (baery charge indicator)
6. Link Indicator LED (LED will blink if connecon is poor/lost)
7. Speaker
8. DC Jack (5V/600mA)
9. Belt Clip
10. Baery Compartment
6 7
1
2
3
4
5
6
7
89
10
11
12
INSTALLATION & SETUP RECEIVER/TRANSMITTER OPERATION
The Mobi® Pure Sounds™ transmier is designed to be powered by either
rechargeable baeries (provided) or the AC/DC adaptors.
Using AC/DC adaptor:
• Plug the connector of the AC adaptor into the DC Jack on the unit (g.
7 pg. 6, g. 12 pg. 7).
• Plug the power cord into an outlet.
• Press the Power On/O Buon (g. 1 pg. 7) to turn ON your receiver.
• The power indicator lights will illuminate indicang units are ON
(g. 5 pg. 6, g. 11 pg. 7)
Using Baeries:
• Remove the belt clip (g.8 pg. 6) by sliding the clip downwards
• Remove the baery door on your receiver (g. 9 pg. 6)
• Plug in the supplied baery pack into your baery compartment
• Return baery cover and belt clip to their original posion
Note: Baery life is between 3-4 hours. When monitoring over long periods
and, in parcular, overnight, it is recommended to use AC adaptors for the
receiver.
Warning:
1. Use on the supplied baery pack with your receiver.
2. Do not mix old and new baeries.
3. Do not mix alkaline, standard or rechargeable baeries
4. Remove the baeries during long periods of non-use.
5. Use only the AC adaptors supplied with the package.
Note: Transmier only funcons with AC Adaptor.
Receiver Power ON/OFF
Press the Power On/O Buon (g. 1 pg. 7) to turn on your receiver. The power
indicator light (g. 5 pg. 6) will turn red indicang receiver is ON.
Volume Adjustment
Press the volume up (g. 2 pg. 6) or volume down (g. 3 pg. 6) to adjust the
volume to the desired level.
LED Indicator Lights
The Link Indicator Light (g. 6 pg 6)
will blink connuously if your
connecon to the receiver is poor or lost.
The Sound Indicator Light (g. 4 pg 6) will blink when sound levels increase
Auto Mute/VOX Acvaon Seng
Your receiver is equiped with automaca mute seng. When sound levels
reach a preset level the mute opon will engage to conserve baery power,
once the transmier picks up noise the receiver will automacally begin trans-
ming.
Note: If link is lost between transmier and receiver you must place both units near each
other, turn them o then on and link will resume.
Transmier Power ON/OFF
Your trasmier will automacally turn ON once you plug in the AC/DC adaptor
(g. 12 pg. 7)
8 9
RADIO INTERFERENCE ADVICETROUBLESHOOTING
10 11
Problem Soluon
Transmier will not
turn on
• Check AC/DC Connecon.
• Conrm power outlet is working properly.
• Charge Baery Pack
Receiver will not turn
on
• Check AC/DC Connecon.
• Conrm power outlet is working properly.
Baery does not
recharge
• AC/DC adaptor has not been connected.
• Check baery pack connecon to receiver.
Connecon is lost • Conrm receiver and transmier are ON.
• Conrm AC/DC adaptor is connected properly.
• Place transmier and receiver near each other,
• turn o both units and turn the back on to
• resume link
FCC Statement
15.19:
This device complies with part 15 of the FCC Rules.
Operaon is subject to the following two condions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received,
including interference that may cause undesired operaon.
15.21:
Changes or modicaons not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC Radiaon Exposure Statement:
-
-
IC STATEMENT:
Operaon of this device is subject to the following two condions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that
may cause undesired operaon of the device.
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment .For baby unit it should
be installed and operated with minimum distance 20cm between the
radiator& your body.
This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
WARRANTY
12
Mobi Technologies, Inc. warrants this product to be free from defects in
material and workmanship for a period of ninety (90) days from the date of
purchase. Should this product prove to be defecve at any me during the
warranty period, Mobi Technologies, Inc. will, at its opon, either replace
or repair it without charge. Aer the warranty period, a service charge will
be applied for replacement of parts or labor for repair. To obtain warranty
service, please return the product to Mobi along with a dated sales re-
ceipt from the place of purchase. Purchaser is responsible for shipping the
product to Mobi Technologies, Inc. at the address indicated below and for all
associated freight and insurance costs. This warranty does not cover damage
caused by accident, misuse, abuse, improper maintenance, unauthorized
modicaon, or connecon to an improper power supply. A charge will be
made for repair of such damage. This warranty excludes all incidental or
consequenal damages and any liability other than what is stated above. ©
2011 Mobi Technologies, Inc. All Rights Reserved.
Mobi Technologies, Inc.
5913 Blackwelder St
Culver City CA 90232
Toll Free Number (877) 662-4462
www.getmobi.com
Please register your product at: www.getmobi.com/registerproduct.php
