Ｋ３０１０ ＳＰＥＣ
１． Ｓｃｏｐｅ：
Ｔｈｅ ＭＯＮＴＥＲＥＹ Ｋｅｙｂｏａｒｄ Ｋ３０１０ ｉｓ １０４／１０５／１０７／１０９ ｋｅｙｓ ｅｎｈａｎｃｅｄ ｌａｙｏｕｔ．
Ｅｓｐｅｃｉａｌｌｙ ｗｉｔｈ ｎｅｗ ｋｅｙ ｓｕｐｐｏｒｔ ｆｏｒ Ｍｉｃｒｏｓｏｆｔ Ｗｉｎｄｏｗｓ ｋｅｙ ．Ｉｔ ｉｓ ａｌｓｏ
ｃｏｍｐａｔｉｂｌｅ Ｗｉｔｈ ＩＢＭ ＰＣ ＡＴ ｏｒ ＰＳ／２ ａｎｄ ｃｏｍｐａｔｉｂｌｅ ｐｅｒｓｏｎａｌ ｃｏｍｐｕｔｅｒ．
２． Ｆｅａｔｕｒｅｓ：
Ｆａｓｈｉｏｎ Ｓｔｙｌｉｎｇ
１０４／１０５／１０７／１０９ ｅｎｈａｎｃｅｄ ｌａｙｏｕｔ
Ｍｉｃｒｏｓｏｆｔ Ｗｉｎｄｏｗｓ ｃｏｍｐａｔｉｂｌｅ
ＩＢＭ ＰＣ／ＡＴ、ＰＳ／２ ｃｏｍｐａｔｉｂｌｅ
Ｌａｓｅｒ ｅｎｇｒａｖｅｄ ｐｒｉｎｔｉｎｇ
Ｃｏｍｐａｃｔ ｌｏｗ ｐｒｏｆｉｌｅ
３． Ｓｐｅｃｉｆｉｃａｔｉｏｎ
３．１ Ｅｌｅｃｔｒｉｃａｌ Ｓｐｅｃｉｆｉｃａｔｉｏｎ
３．１．１．Ｐｏｗｅｒ Ｒｅｑｕｉｒｅｍｅｎｔ
Ｉｎｐｕｔ Ｖｏｌｔａｇｅ： ＤＣ ５Ｖ
Ｉｎｐｕｔ Ｃｕｒｒｅｎｔ： １００ｍＡ Ｍａｘ
３．１．２．Ｃａｂｌｅ Ｃｏｎｎｅｃｔｏｒ
３．１．２．１．Ｍｉｄｉ Ｄｉｎ ６ ｐｉｎ Ｃｏｎｎｅｃｔｏｒ ｐｉｎ ａｓｓｉｇｎｍｅｎｔ．
ＰＩＮ ＳＩＧＨＡＬ
１ Ｄａｔａ
２ Ｒｅｓｅｒｖｅ
３ Ｇｒｏｕｎｄ
４ ＶＣＣ
５ Ｃｌｏｃｋ
６ Ｒｅｓｅｒｖｅ
Ｓｈｉｅｌｄ Ｆｒａｍｅ Ｇｒｏｕｎｄ
3
1 2
4
6 5
３．１．３．Ｃｏｎｔａｃｔ Ｒｅｓｉｓｔａｎｃｅ： ５００Ω Ｍａｘ
３．１．４．Ｉｎｓｕｌａｔｉｏｎ Ｒｅｓｉｓｔａｎｃｅ： １００Ω， ２５０Ｖ ＤＣ
３．１．５．Ｂｏｕｎｃｅ： ≦ １０ Ｍｉｌｌｉｓｅｃｏｎｄ
