USERS MANUAL
Ｋ３７６ ＳＰＥＣ
１． Ｓｃｏｐｅ：
Ｔｈｅ ＭＯＮＴＥＲＥＹ Ｋｅｙｂｏａｒｄ Ｋ３７６ ｉｓ １０１／１０２／１０３／１０４ ｋｅｙｓ ｅｎｈａｎｃｅｄ ｌａｙｏｕｔ．
Ｅｓｐｅｃｉａｌｌｙ ｗｉｔｈ ｎｅｗ ｋｅｙ ｓｕｐｐｏｒｔ ｆｏｒ Ｍｉｃｒｏｓｏｆｔ Ｗｉｎｄｏｗｓ ｋｅｙ ．Ｉｔ ｉｓ ａｌｓｏ
ｃｏｍｐａｔｉｂｌｅ Ｗｉｔｈ ＩＢＭ ＰＣ ＡＴ ｏｒ ＰＳ／２ ａｎｄ ｃｏｍｐａｔｉｂｌｅ ｐｅｒｓｏｎａｌ ｃｏｍｐｕｔｅｒ．
２． Ｆｅａｔｕｒｅｓ：
Ｆａｓｈｉｏｎ Ｓｔｙｌｉｎｇ
１０１／１０２／１０３／１０４ ｅｎｈａｎｃｅｄ ｌａｙｏｕｔ
Ｍｅｄｉａ ｆｕｎｃｔｉｏｎ ｋｅｙｓ
Ｍｉｃｒｏｓｏｆｔ Ｗｉｎｄｏｗｓ ｃｏｍｐａｔｉｂｌｅ
ＩＢＭ ＰＣ／ＡＴ、ＰＳ／２ ｃｏｍｐａｔｉｂｌｅ
Ｌａｓｅｒ ｅｎｇｒａｖｅｄ ｐｒｉｎｔｉｎｇ
Ｃｏｍｐａｃｔ ｌｏｗ ｐｒｏｆｉｌｅ
３． Ｓｐｅｃｉｆｉｃａｔｉｏｎ
３．１ Ｅｌｅｃｔｒｉｃａｌ Ｓｐｅｃｉｆｉｃａｔｉｏｎ
３．１．１．Ｐｏｗｅｒ Ｒｅｑｕｉｒｅｍｅｎｔ
Ｉｎｐｕｔ Ｖｏｌｔａｇｅ： ＤＣ ５Ｖ
Ｉｎｐｕｔ Ｃｕｒｒｅｎｔ： １００ｍＡ Ｍａｘ
３．１．２．Ｃａｂｌｅ Ｃｏｎｎｅｃｔｏｒ
３．１．２．１．Ｍｉｄｉ Ｄｉｎ ６ ｐｉｎ Ｃｏｎｎｅｃｔｏｒ ｐｉｎ ａｓｓｉｇｎｍｅｎｔ．
ＰＩＮ ＳＩＧＨＡＬ
１ Ｄａｔａ
２ Ｒｅｓｅｒｖｅ
３ Ｇｒｏｕｎｄ
４ ＶＣＣ
５ Ｃｌｏｃｋ
６ Ｒｅｓｅｒｖｅ
Ｓｈｉｅｌｄ Ｆｒａｍｅ Ｇｒｏｕｎｄ
3
1 2
4
6 5
３．１．３．Ｃｏｎｔａｃｔ Ｒｅｓｉｓｔａｎｃｅ： ５００Ω Ｍａｘ
３．１．４．Ｉｎｓｕｌａｔｉｏｎ Ｒｅｓｉｓｔａｎｃｅ： １００Ω， ２５０Ｖ ＤＣ
３．１．５．Ｂｏｕｎｃｅ： ≦ １０ Ｍｉｌｌｉｓｅｃｏｎｄ
Federal Communication Commission Interference Statement
The equipment has been tested and found to comply with the limits for Class B
Digital Device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction, may
cause harmful interference to radio communication. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
l Reorient of relocate the receiving antenna.
l Increase the separation between the equipment and receiver.
l Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
l Consult the dealer or an experienced radio/TV technician for help.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1)
THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2)
THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.
