Motion Access MATRIX Door Radio Control User Manual
Motion Access LLC Door Radio Control Users Manual
Users Manual
MATRiX
Transmitter / Receiver
MOTION
ACCESS
,
LLC
automatic entrance solutions
For technical assistance call 866-357-8832MAXTRiX_MNL_revB
Transmitter: MAX-TX Transmitter: MAX-TX
Receiver: MAX-RX
Frequency Code
Signal
Output
Sequence
Delay
2
ON
Set Signal
Output dip
switch #2 to
ON (up).
Switch #1 is
not used.
Set the 12 Frequency Code switches to the desired
positions. This code must match the Receiver
Frequency Code. Note: Dip switch "UP" is "ON".
121
Receiver: MAX-RX
Frequency Code
Signal
Output
Sequence
Delay
2
ON
Set Signal
Output dip
switch #2 to
OFF (down).
Switch #1 is
not used.
Set the 12 Frequency Code switches to the desired
positions. This code must match the Receiver "A"
Frequency Code. Note: Dip switch "UP" is "ON". The
Receiver "B" Frequency Code is the same as "A"
except with switch #2* in the opposite position.
121
Set the Sequence Delay to the desired time between
door "A" & "B" activations. The range of this
potentiometer is 1-20 seconds.
2
*
common
10-36
Vac
/8-25
Vdc
10-36
Vac
/8-25
Vdc
Normally Closed
Normally Open
Hold ON
Time
Frequency Code
ON
121
Match the 12 Frequency Code switches to the
Transmitter Frequency Code. Note: Dip switch
"DOWN" is "ON".
Set the Hold ON Time to the
desired duration of the activation
signal. The range of this
potentiometer is 1-20 seconds.
Notes: The receiver antenna must protrude through the
operator housing. The maximum relay capacity is 1A @
120Vac / 30Vdc.
Frequency Code
ON
121
common
10-36
Vac
/8-25
Vdc
10-36
Vac
/8-25
Vdc
Normally Closed
Normally Open
Hold ON
Time
Set the Hold ON Time to the
desired duration of the activation
signal. The range of this
potentiometer is 1-20 seconds.
*
For Receiver "A", match the 12 Frequency Code
switches to the Transmitter Frequency Code. Note:
Dip switch "DOWN" is "ON". The Receiver "B"
Frequency Code will be the same as "A" except
with switch #2* in the opposite position.
2
The Sequence Delay is not used for single doors. It is
only used for sequenced doors.
11
1 1
2 2
3 3
44
5 5
Changes or modifications not expressly approved by MotionAccess could void the user's authority to operate the equipment. This device
complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Notes: The receiver antenna must protrude through the
operator housing. The maximum relay capacity is 1A @
120Vac / 30Vdc.
2) Sequenced Doors Setup1) Single Door Setup
