Motorola Mobility P56KB1 Portable Cellular/ PCS CDMA Transceiver with Bluetooth User Manual Exhibit 8 Users Manual
Motorola Mobility LLC Portable Cellular/ PCS CDMA Transceiver with Bluetooth Exhibit 8 Users Manual
Exhibit 8 Users Manual
APPLICANT MOTOROLA INC. FCC ID: IHDP56KB1
INSTRUCTION MANUAL
A representative version of the user's manual follows:
Exhibit 8
motorola CRUSH™
User’s Guide
1
HELLOMOTO
Introducing your new
Motorola
CRUSH™ CDMA wireless phone!
Touch Screen Ease of Use
– Just touch the large, high-resolution display to open all of your phone's features,
including music, pictures, navigation, or incoming messages.
Connect on So Many Levels
– Whether it’s with work or friends, connect in all kinds of ways—voice (page 12),
messaging (page 50), downloads (page 74), or swapping an optional memory card (page 23)—you’ll be on top of all
the latest news and views to share!
Rich Multimedia Experience
– Use the robust music player to listen to your tunes (page 63). Slip a microSD card
into the removable memory slot (page 23) to save many more songs! Your phone’s 2.0 megapixel camera lets you
take great quality pictures you can save or send (page 72). You can even make a mini-movie with your phone’s
camcorder (page 70).
Handsfree Convenience
– Use your phone with Bluetooth® wireless headsets (page 86) to answer and make calls
or listen to music.
2
Here’s a quick anatomy lesson.
Power Key
Turn your phone on & off, end calls.
To u ch Screen
Voice Key
microSD Memory Card Slot
Camera Key
Speaker
(on back)
3.5 mm Headset Jack
Volume Keys
Micro USB Port
Microphone
Lock Key
Lock the touch screen & phone keys.
3
Motorola, Inc.
Consumer Advocacy Office
600 N US Hwy 45
Libertyville, IL 60048
www.hellomoto.com
Note:
Do not ship your phone to the above address. If you need to
return your phone for repairs, replacement, or warranty service, please
contact the Motorola Customer Support Center at:
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain
features may not be activated by your service provider, and/or the
provider’s network settings may limit the feature’s functionality. Always
contact your service provider about feature availability and functionality.
All features, functionality, and other product specifications, as well as
the information contained in this guide, are based upon the latest
available information and believed to be accurate at the time of
printing. Motorola reserves the right to change or modify any
information or specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. All other product or service names are the property of
their respective owners. The Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under license. Microsoft,
Windows, Windows Me, and Windows Vista are registered trademarks
of Microsoft Corporation in the United States and other countries.
© 2009 Motorola, Inc. All rights reserved.
Caution:
Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user’s authority to operate
the equipment.
Software Copyright Notice
The Motorola products described in this manual may include
copyrighted Motorola and third-party software stored in semiconductor
memories or other media. Laws in the United States and other countries
preserve for Motorola and third-party software providers certain
exclusive rights for copyrighted software, such as the exclusive rights to
distribute or reproduce the copyrighted software. Accordingly, any
copyrighted software contained in the Motorola products may not be
modified, reverse-engineered, distributed, or reproduced in any manner
to the extent allowed by law. Furthermore, the purchase of the Motorola
products shall not be deemed to grant either directly or by implication,
estoppel, or otherwise, any license under the copyrights, patents, or
patent applications of Motorola or any third-party software provider,
except for the normal, non-exclusive, royalty-free license to use that
arises by operation of law in the sale of a product.
Manual Number: TBD-A
4
contents
contents
menu map . . . . . . . . . . . . . . . . . 6
Use and Care . . . . . . . . . . . . . . . 7
get started . . . . . . . . . . . . . . . . . 8
about this guide . . . . . . . . . . . 8
battery . . . . . . . . . . . . . . . . . . 8
Battery Use & Safety . . . . . . . . 8
turn it on & off . . . . . . . . . . . 12
make a call . . . . . . . . . . . . . . 12
answer a call. . . . . . . . . . . . . 12
end a call. . . . . . . . . . . . . . . . 13
store a phone number . . . . . 13
call a stored phone number . 14
see your phone number . . . . 14
basics . . . . . . . . . . . . . . . . . . . . 15
main screen . . . . . . . . . . . . . 15
touch cover . . . . . . . . . . . . . . 18
adjust volume . . . . . . . . . . . . 19
handsfree. . . . . . . . . . . . . . . 19
airplane mode . . . . . . . . . . . 20
lock & unlock phone. . . . . . . 21
manage memory . . . . . . . . . 23
TTY operation. . . . . . . . . . . . 25
voice privacy . . . . . . . . . . . . 27
personalize . . . . . . . . . . . . . . . 28
sounds . . . . . . . . . . . . . . . . . 28
talking phone . . . . . . . . . . . . 30
voice recognition . . . . . . . . . 31
answer options . . . . . . . . . . 35
flip open display . . . . . . . . . . 36
wallpaper . . . . . . . . . . . . . . . 36
clock format . . . . . . . . . . . . . 36
banner . . . . . . . . . . . . . . . . . 37
backlight. . . . . . . . . . . . . . . . 37
brightness . . . . . . . . . . . . . . 38
languages . . . . . . . . . . . . . . 38
calls. . . . . . . . . . . . . . . . . . . . . 39
redial a number . . . . . . . . . . 39
automatic redial. . . . . . . . . . 39
Visual Voice Mail . . . . . . . . . 40
recent calls . . . . . . . . . . . . . 40
return missed calls . . . . . . . 41
restrict calls . . . . . . . . . . . . . 41
insert special characters . . . 42
3-way calls. . . . . . . . . . . . . . 42
in-call options . . . . . . . . . . . 42
emergency calls . . . . . . . . . 43
call times & data volumes . . 45
DTMF tones . . . . . . . . . . . . 46
hearing aid. . . . . . . . . . . . . . 47
5
contents
text entry . . . . . . . . . . . . . . . . 48
change your text entry mode 49
ABC mode. . . . . . . . . . . . . . 50
iTAP® mode . . . . . . . . . . . . 50
messages . . . . . . . . . . . . . . . . 51
send a picture, video, or sound
message . . . . . . . . . . . . . . . 51
send a text message. . . . . . 52
receive a message . . . . . . . 52
view sent messages . . . . . . 53
view drafts. . . . . . . . . . . . . . 53
erase messages . . . . . . . . . 53
access your email . . . . . . . . 54
use mobile IM. . . . . . . . . . . 54
chat . . . . . . . . . . . . . . . . . . . 55
entertainment . . . . . . . . . . . . 56
V CAST Mobile TV . . . . . . . . 56
music . . . . . . . . . . . . . . . . . 59
sound clips . . . . . . . . . . . . . 70
video clips . . . . . . . . . . . . . . 71
photos . . . . . . . . . . . . . . . . . 73
fun & games. . . . . . . . . . . . . 75
Web access . . . . . . . . . . . . . 76
tools . . . . . . . . . . . . . . . . . . . . . 78
contacts . . . . . . . . . . . . . . . . 78
calendar . . . . . . . . . . . . . . . . 82
alarm. . . . . . . . . . . . . . . . . . . 83
world clock . . . . . . . . . . . . . . 84
notepad . . . . . . . . . . . . . . . . 84
calculators . . . . . . . . . . . . . . 84
connections. . . . . . . . . . . . . . . 85
Bluetooth® connections. . . . 85
network . . . . . . . . . . . . . . . . 92
service & repairs . . . . . . . . . . . 94
SAR (IEEE) . . . . . . . . . . . . . . . . 95
Safety Information . . . . . . . . . 98
Industry Canada Notice . . . . 101
FCC Notice. . . . . . . . . . . . . . . 101
Warranty . . . . . . . . . . . . . . . . 102
Hearing Aids . . . . . . . . . . . . . 105
WHO Information. . . . . . . . . 106
Registration . . . . . . . . . . . . . 106
Export Law . . . . . . . . . . . . . . 106
Recycling Information . . . . . 107
Perchlorate Label . . . . . . . . . 107
Privacy & Data Security . . . . 108
Driving Safety. . . . . . . . . . . . 108
index . . . . . . . . . . . . . . . . . . . 110
6
menu map
menu map
To open the menu, open your phone and
touch
Menu
at the top of your main screen.
Visual Voice Mail
Bluetooth
Calls
Music
Media Center
Settings
•My Verizon
• Sounds
•Display
• Phone
•Call
• Messaging
• Security
• Memory
To o l s
• Calendar
•Alarm Clock
•Calculator
• Tip Calculator
• Notepad
• Voice Commands
• World Clock
Browser
VCAST TV
VZ Nav
V CAST Videos
Email
To return to the main screen at any point,
press the Home key
B
.
Note:
When you touch icons or menu items,
your touch screen might send out small
vibrations (also called haptics).
Touch screen tips:
Your touch screen goes dark
when your
phone is inactive, to conserve battery life. To
reactivate the screen, press
B
.
To
select
menu items, touch the screen.
To
highlight
an item, like a message in your
inbox, drag across the item from left to right.
To unhighlight, drag right to left.
To
move a long list
, touch the bottom item in
your screen and drag upward, just like pushing
a piece of paper. If you accidentally open an
item rather than moving the menu, go back
and try touching the display in one corner and
sliding to the opposite corner.
For
best results
:
•
Touch the screen with your fingertip,
not your fingernail or other object.
•
Touch the screen lightly.
•
Do not touch the screen with wet or
dirty fingers.
7
Use and Care
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water, rain, extreme
humidity, sweat, or other moisture. If it does get
wet, don’t try to accelerate drying with the use of
an oven or dryer, as this may damage the phone.
Don’t expose your phone to dust, dirt, sand, food,
or other inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below 0°C/32°F or
above 45°C/113°F.
To clean your phone, use only a dry soft cloth.
Don’t use alcohol or other cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a microwave oven. Don’t drop your phone.
8
get started
get started
about this guide
battery
Battery Use & Safety
Battery Use & Safet y
Important: Handle and store batteries properly to
avoid injury or damage.
Most battery issues arise
from improper handling of batteries, and particularly
from the continued use of damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred, or
otherwise attempt to change the form of your
battery.
symbols
This means a feature depends on your
network, SIM card, or subscription, and
may not be available everywhere. Contact
your service provider for more information.
CAUTION: Before using the
phone for the first time, read the
Important Safety and Legal
Information
included in the gray-
edged pages at the back of this
guide.
This means a feature requires an optional
accessory.
symbols
9
get started
• Don’t let the phone or battery come in contact
with water.
Water can get into the phone’s circuits,
leading to corrosion. If the phone and/or battery get
wet, have them checked by your carrier or contact
Motorola, even if they appear to be working
properly.
• Don’t allow the battery to touch metal objects.
If
metal objects, such as jewelry, stay in prolonged
contact with the battery contact points, the battery
could become very hot.
• Don’t place your battery near a heat source.
Excessive heat can damage the phone or the
battery. High temperatures can cause the battery to
swell, leak, or malfunction. Therefore:
•
Do
not
dry a wet or damp battery with an
appliance or heat source, such as a hair dryer or
microwave oven.
•
Avoid leaving your phone in your car in high
temperatures.
DOs
• Do avoid dropping the battery or phone.
Dropping these items, especially on a hard surface,
can potentially cause damage.
• Do contact your service provider or Motorola if
your phone or battery has been damaged from
dropping or high temperatures.
Important: Use Motorola Original products for
quality assurance and safeguards.
To aid consumers
in identifying authentic Motorola batteries from
non-original or counterfeit batteries (that may not have
adequate safety protection), Motorola provides
holograms on its batteries. Consumers should confirm
that any battery they purchase has a
“Motorola Original” hologram.
Motorola recommends you always use
Motorola-branded batteries and chargers.
Motorola
mobile devices are designed to work with Motorola
10
get started
batteries. If you see a message on your display such as
Invalid Battery
or
Unable to Charge
, take the following steps:
•
Remove the battery and inspect it to confirm that it
has a “Motorola Original” hologram;
•
If there is no hologram, the battery is not a Motorola
battery;
•
If there is a hologram, replace the battery and retry
charging it;
•
If the message remains, contact a Motorola
authorized service center.
Important:
Motorola’s warranty does not cover
damage to the phone caused by non-Motorola batteries
and/or chargers.
Warning:
Use of a non-Motorola battery or charger may
present a risk of fire, explosion, leakage, or other
hazard.
Proper and safe battery disposal and recycling:
Proper battery disposal is not only important for safety,
it benefits the environment. Consumers may recycle
their used batteries in many retail or service provider
locations. Additional information on proper disposal and
recycling may be found on the Web:
•
www.motorola.com/recycling
•
www.rbrc.org/call2recycle/
(inEnglishonly)
Disposal:
Promptly dispose of used batteries in
accordance with local regulations. Contact your
local recycling center or national recycling organizations
for more information on how to dispose of batteries.
Warning:
Never dispose of batteries in a fire because
they may explode.
032375o
11
get started
install the battery
1
Remove the battery
door.
2
Insert the battery
by aligning the
metal contacts and
then gently
pressing it into
place.
3
Replace the battery
door.
charge the battery
Notes for charging your phone’s battery:
•
When charging your battery, keep it near room
temperature. Never expose batteries to
temperatures below 0°C (32°F) or above 45°C
(113°F) when charging.
•
New batteries are not fully charged.
•
New batteries or batteries stored for a long time
may take more time to charge.
•
Motorola batteries and charging systems have
circuitry that protects the battery from damage from
overcharging.
Plug the wall charger
into your phone and an
electrical outlet. Your
phone may take several
seconds to start
charging the battery.
When the battery is
fully charged, your phone displays
N
.
12
get started
You can also charge your battery by connecting a cable
from your phone’s micro USB port to a USB port on a
computer. Both your phone and the computer must be
turned on, and your computer must have the correct
software drivers installed.
conserve battery charge
Using certain features can quickly deplete your
battery’s charge.
These features can include
downloading music, using the camera, replaying
video clips, watching streaming video or TV, and
using Bluetooth® wireless connections.
To conserve your battery’s charge:
•
Turn Bluetooth power off when not in use (see
page 85).
•
Set the backlight to a short duration (see page 36).
•
Keep the touch cover lock on when your phone is
not in use (see page 2).
turn it on & off
To turn on your phone
,
press and hold the
Power key
%
until the
display turns on.
The phone will take several
seconds to turn on. If
prompted, enter your
four-digit unlock code to unlock the phone.
To turn off your phone
, press and hold the
Power key
%
.
make a call
1
With the flip open, touch
Dialpad
.
2
Enter a phone number.
3
Touch
Call
.
Messages Dialpad Menu Contacts
13
get started
Tip:
To prevent accidental touches, your touch screen
might
go dark
during a call. To reactivate it, press
B
.
answer a call
When your phone rings and/or vibrates, open the
phone to answer.
If your phone is
closed when you receive a call
,
unlock the Touch Key Lock (see page 18) and
touch
Answer
to answer the call with the handsfree
speaker.
end a call
To hang up, touch
End Call
.
You can also end a call by closing the phone if you are
not connected to a headset or a handsfree car kit and
are not using the speakerphone. Closing the phone
does not end these activities:
•
a data connection using a USB cable to connect the
phone to a computer
•
wallpapers, screen savers, banners, and other
similar applications
•
active BREW® download sessions, such as
downloading music or ringtones
store a phone number
1
With the flip open, from the main screen,
touch
Contacts
.
2
Touch
Add New Contact
to create a new contact, or
touch a contact in your list to add or edit
information.
3
Touch the contact’s details (such as
Name
) to enter
or edit information. To move through the list of
details, touch the bottom of your screen and drag
upward, just like pushing a piece of paper. For help
with entering text, see page 47.
14
get started
call a stored phone
number
1
With the flip open, from the main screen,
touch
Contacts
.
2
Touch the icon next to the name to call the contact.
Note:
If you store more than one phone number
for a contact, you can open the list of numbers by
touching the name. To edit a contact or set its
default phone number, see page 78.
see your phone number
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Settings
.
3
Touch
Phone
. Your phone number is at the top of the
screen.
15
basics
basics
See page 2 for a basic phone diagram.
main screen
The main screen appears when you turn on the phone.
Note:
When the phone is
closed
, the main screen
shows different feature shortcuts. You can unlock them
by sliding down the Touch Key Lock on the right side of
your phone (see page 18).
To dial a number
, touch
Dialpad
. To return to the
main screen at any point, press the Home key
B
.
To open the main menu
, touch
Menu
:
new message new voicemail new missed
call
11 1
Thu, Mar 13 4:27pm
Menu ContactsMessages Dialpad
VCast VideosVZ Nav Email
BrowserTools VCast TV
Media CenterMusic Settings
BluetoothVisual Vmail Calls
Back ContactsMessages Dialpad
To open an
option, touch it.
To close the
menu, touch
Back
16
basics
Note: Your touch screen goes dark
when your phone
is inactive, to conserve battery life. To reactivate the
screen, press
B
.
Your phone shows system status indicators across the
top of the display (to see a glossary of icons,
touch
Menu
, then touch
Settings
, touch
Phone
, and
touch
Icon Glossary
):
alert/indicator
0
Signal Strength
Indicates when the phone is in an EVDO coverage
area (necessary for V CAST services). 1X indicates
when the phone is in a 1x-RTT coverage area. The
number of bars shows the strength of each signal,
from 1 (weak) to 4 (strong).
EV
1X
2
Roaming
Indicates when the phone is roaming off your home
network. If you make a call while roaming, additional
charges may apply.
5
SSL
Indicates that application verification is via SSL
during a download session.
L
Data Call, Tethered, or Embedded
WAP/BREW Application
Shows during data calls, tethered mode, or
WAP/BREW application.
M
Dormant
Indicates that the phone is dormant and the Internet
connection is active.
alert/indicator
17
basics
9
No Service
Indicates that the phone is in area with no service
coverage.
8
TTY
Indicates that the phone is in TTY mode.
t
Voice Call
Shows during an active voice call.
VCAST TV
Shows when V CAST TV is available or not
P
.
To u ch C o v e r L o c k
When your phone is closed, this shows that the main
screen shortcuts are locked. You can unlock them by
sliding down the Touch Key Lock on the right side of
your phone (see page 18).
alert/indicator
P
E911
Indicates that
E911
is
On
.
O
Location On
Indicates that
Location
is set to
On
.
N
Battery Level
Shows battery strength. The more bars, the greater
the charge.
All Sounds Off
Indicates that
Master Volume
is set to
Off
.
Alarm Only
Indicates that
Master Volume
is set to
Alarm Only
.
r
Vibrate On
Indicates that
Master Volume
is set to
Vibrate On
.
alert/indicator
18
basics
adjust volume
To
decrease
your phone’s
main ringer volume, open
your phone and press
down on the Volume keys.
The volume screen
appears, and your phone
switches to
Vibrate Only
, then
Alarm Only
, and, finally,
All Sounds Off
(to quickly switch to
All Sounds Off, hold down on the Volume keys).
To
increase
your phone’s main ringer volume, open
your phone and press up on the Volume keys. The
s
Missed Call
Indicates that a call was missed.
g
Message
Shows when you receive a new message.
x
Calendar Event
Shows that you have calendar appointments.
y
New Voicemail
Shows when a voicemail message is received.
A
Alarm On
Shows when an alarm has been set.
E
Bluetooth Power On
Indicates that Bluetooth® power is on. To conserve
battery charge, turn off Bluetooth power when not in
use (see page 85).
alert/indicator
I
Bluetooth Connection Active
Indicates that your phone is paired with another
Bluetooth device.
alert/indicator
Messages Dialpad Menu Contacts
19
basics
volume screen appears, and the volume setting
increases.
Tip:
When you press the Volume keys and open the
volume screen, you can touch the screen to choose a
volume level.
You can also press the Volume keys to:
•
turn off an incoming call alert with the phone closed.
•
change the earpiece or Bluetooth® device volume
during calls with the phone open.
handsfree
Note:
The use of wireless phones while driving may
cause distraction. Discontinue a call if you can’t
concentrate on driving. Additionally, the use of wireless
devices and their accessories may be prohibited or
restricted in certain areas. Always obey the laws and
regulations on the use of these products.
handsfree speaker
You can use your phone’s handsfree speaker to make
calls without holding the phone to your ear.
Note:
The handsfree speaker won’t work when your
phone is connected to a handsfree car kit or headset.
To turn on the speakerphone
during a call, touch
Speaker
. Your phone plays an audio alert and shows
SPEAKER ON
. When the speakerphone is on, you can close
your phone without ending the call.
To turn off the speakerphone
with your phone open,
touch
Speaker
.
If your phone is
closed when you receive a call
,
unlock the Touch Key Lock (see page 18) and
touch
Answer
to answer the call with the handsfree
speaker.
20
basics
volume settings for car kits or
headsets
To adjust volume of Bluetooth® wireless headsets or
car kit accessories, press up or down on the Volume
keys during an active call.
airplane mode
Note:
Consult airline staff about the use of
Airplane Mode
in flight. Turn off your phone whenever instructed to do
so by airline staff.
Use airplane mode to turn off your phone’s calling
features in locations where wireless phone use is
prohibited.
You cannot make or receive calls or use
Bluetooth® devices in airplane mode
, but you can
use your phone’s other non-calling features.
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Settings
.
3
Touch
Phone
.
4
Drag the button below
Airplane Mode
to the right to
turn it
On
(calling is blocked) or to the left to turn it
Off
(calling is active).
Your phone shows a
9
status icon to indicate that
Airplane Mode
is
On
.
Tip:
When you turn
Airplane Mode
to
Off
so that you can
make calls again, your phone might take a few minutes
to look for a network. To turn off
Airplane Mode
and look for
a network right away, turn your phone off and back on
again.
lock & unlock phone
You can lock your phone to keep others from using it.
To lock or unlock your phone, you need the four-digit
lock code (which is originally set to the last four digits of
your phone number).
21
basics
Note:
You can make emergency calls on a locked
phone (see page 42). A locked phone still rings or
vibrates for incoming calls or messages,
but you need
to unlock it to answer
.
To manually lock your phone:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Security
.
4
Enter your four-digit lock code.
Tip:
This code is originally set to the last four digits
of your phone number.
5
Touch
Done
.
6
Touch
Lock Phone Now
.
7
Touch
Yes
to confirm.
To unlock the phone
, open the phone and touch
Unlock
.
Then, enter your four-digit lock code and touch
Done
.
To automatically lock your phone whenever you
turn it off:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Security
.
4
Enter the four-digit lock code.
Tip:
This code is originally set to the last four digits
of your phone number.
5
Touch
Done
.
6
Drag the button below
Power Up Lock
to the right to
turn it
On
or to the left to turn it
Off
.
22
basics
change lock code
Your phone’s four-digit
lock code
is originally set to the
last four digits of your phone number. To keep your
phone secure, you should change the code.
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Settings
.
3
Touch
Security
.
4
Enter the current four-digit lock code.
5
Touch
Done
.
6
Touch
Change Passcode
.
7
Enter a new four-digit lock code.
8
Touch
Done
.
9
Re-enter the new four-digit lock code.
10
Touch
Done
.
how to use your phone while
you’re on a call with the flip open
During calls, your phone’s
display locks to prevent
accidental touches. Your display
also becomes dim, then dark,
to save power.
• To unlock the display
during a call, drag across the
DRAG TO UNLOCK
message, from left to right.
• To reactivate a dim display
, just touch the screen.
If the display is completely
dark
, press a
side key,
B
,or
%
. Then, to end a call, press
%
.
manage memory
You can store multimedia content, such as songs and
photos, on your phone’s internal memory or on a
removable microSD memory card.
Memory cards are
sold separately.
1-888-390-6456
DRAG TO
UNLOCK
End Call
Switch
BluetoothMute Speaker
23
basics
Note:
If you download a copyrighted file to your phone
and store it on your memory card, you can use the file
only when your memory card is inserted in your phone.
You cannot send, copy, or change copyrighted files.
insert or remove a memory card
1
Open the memory
card slot cover on
the side of your
phone.
2
To
insert
the card:
Slide it in, with the
gold contacts facing down, until you feel it click
into place. Your display should show
MMC Inserted
.
To
remove
the card: Press it in until you feel it
click, then release it. You should be able to drag it
the rest of the way out.
3
Replace the slot cover.
set memory for multimedia content
You can set whether multimedia content that you
download or create with your phone’s camera is stored
in phone memory or on the memory card.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Memory
.
4
Touch
Pictures
,
Videos
, or
Audios
.
5
Touch
Automatic
,
Phone Memory
, or
Card Memory
.
Note:
Automatic
saves files to the memory card
when one is inserted. If a memory card is not
inserted,
Card Memory
is not available.
view memory information
1
With the flip open, touch
Menu
to open the
menu.
24
basics
2
To u ch
Settings
.
3
Touch
Memory
.
4
Touch
Phone Memory
or
Card Memory
.
Note:
If you do not have a memory card in your
phone,
Card Memory
is not available.
5
Under
Phone Memory
or
Card Memory
, touch
My Pictures
,
My Videos
,
My Music
, or
My Sounds
.
Note:
To erase all of the files on your memory card
and reformat it, touch
Format Card
.
move files between phone and
memory card
You can move files (such as pictures, video clips,
sounds, and music files) to your memory card to free
up phone memory.
Caution:
Moving a file to the memory card deletes it
from the phone.
To move photos, videos, or sound clips:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Media Center
.
3
Touch
Tones & Sounds
or
Pictures & Videos
.
4
Touch
My Pictures
,
My Videos
, or
My Sounds
.
Files with a memory card icon are stored on the
memory card. Files without a memory card icon
are stored on the phone. Files with a
0
are
protected, and cannot be moved.
5
Touch the file you want to move.
6
Touch
Send
and then touch
Memory Card
or
Phone Memory
.
7
Touch
Yes
to confirm.
25
basics
TTY operation
You can use an optional teletypewriter (TTY) device
with your phone to send and receive calls. You must
plug the TTY device into the phone’s micro USB port
and set the phone to operate in one of three TTY
modes.
Notes:
•
A TTY is a communication device used by people
who are hard of hearing or have a speech
impairment. TTY does not work from mobile phone
to mobile phone.
•
Use a TSB-121 compliant cable (provided by the TTY
manufacturer) to connect the TTY device to your
phone.
•
Set the phone to Medium volume level for proper
operation. If you experience a high number of
incorrect characters, adjust the volume as needed
to minimize the error rate.
•
For optimal performance, your phone should be at
least 12 inches (30 centimeters) from the TTY
device. Placing the phone too close to the TTY
device may cause high error rates.
set TTY mode
ù
When you set your phone to a TTY mode, it
operates in that mode whenever a TTY device is
connected.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Call
.
4
Touch
TTY Mode
.
TTY Mode
can include these options:
option
TTY Full
Transmit and receive TTY characters.
TTY + Talk
(VCO)
Receive TTY characters but transmit
by speaking into microphone.
26
basics
5
Touch a mode to select it.
In a TTY mode, your phone displays the international
TTY symbol and mode setting during a TTY call.
return to voice mode
To return to standard voice mode, select
TTY Off
from the
TTY Mode
menu.
voice privacy
Encrypt outgoing voice calls and use secure channels
when available:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Call
.
4
Drag the button below
Voice Privacy
to the right to
turn it
On
or to the left to turn it
Off
.
TTY + Hear
(HCO)
Transmit TTY characters but receive
by listening to earpiece.
TTY Off
All TTY modes are turned off.
option
27
personalize
personalize
sounds
To set your phone’s master volume, see page 18.
To set alerts for dropped calls or other network
changes, see page 91.
call, event, & alert sounds
Note:
You will not hear ringtones if the master volume
is set to
Vibrate Only
,
Alarm Only
, or
All Sounds Off
.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Sounds
.
4
Touch
RingTones & Alerts
.
5
Move to and touch the tone you want to change,
such as
Call Alerts
or
TXT Message
.
6
Touch a ringtone sound.
get ringtones
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Sounds
.
4
Touch
RingTones & Alerts
.
5
Move to and touch the tone you want to change,
such as
Call Alerts
or
TXT Message
.
6
Touch
Tone
.
7
Touch
Get New Ringtone
.
28
personalize
Your phone connects to the ringtone collections
site. Follow the prompts on the screen to browse
ringtone lists and to select and download a
ringtone.
Note:
Normal airtime and/or carrier usage charges
may apply.
power on/off sounds
Set whether your phone plays a tone when you turn the
power on or off.
Note:
You will not hear these sounds if the master
volume is set to
Vibrate Only
,
Alarm Only
, or
All Sounds Off
.
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Settings
.
3
Touch
Sounds
.
4
Touch
Power On/Off
.
5
Drag the button below
Power On/Off
to the right to
turn it
On
or to the left to turn it
Off
.
keypad volume
Note:
You will not hear these sounds if the master
volume is set to
Vibrate Only
,
Alarm Only
, or
All Sounds Off
.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Sounds
.
4
Touch
Keypad Volume
.
5
Drag the volume level or touch the volume bar to
select
Off
,
Low
,
Medium Low
,
Medium
,
Medium High
, or
High
.
29
personalize
call drop tone and other service
alerts
Your phone can beep to let you know when network
conditions change.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Sounds
.
4
Touch
Service Alerts
. You can turn on:
•
ERI
to beep if your phone switches to a network
that is not your home network.
•
Minute Beep
to beep every 60 seconds during a
call.
•
Call Connect
to beep when an outgoing call
connects.
•
Network Lost Tone
to beep if your phone loses the
network.
talking phone
You can set your phone to
speak aloud
when you
touch keys, receive a call with caller ID available, or
move through recent calls or contacts:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Sounds
.
4
Touch
Voice Readout
.
5
To change whether your phone speaks
Keypad Digits
,
Contact List Entries
,
Main Menu Entries
,or
Calls List Entries
, drag
the button below each option to the right to turn it
On
or to the left to turn it
Off
.
To change whether your phone speaks a name (for
Contacts
) or phone number when you receive a call,
30
personalize
touch
Caller ID Alert
, and choose
Ring Only
,
Caller ID Then Ring
,
or
Caller ID Repeat
.
Note:
If your phone is set to
Vibrate Only
,
Alarm Only
, or
All Sounds Off
, it does not speak when you receive a
call.
voice recognition
Your phone’s voice recognition feature lets you make
calls and complete other actions by speaking
commands to your phone.
voice recognition tips
•
When speaking the name of a
Contacts
entry, say the
name exactly as it is listed. For example, to call the
mobile number for an entry named Bill Smith, say
“Call Bill Smith mobile.” If you only have one
number for Bill Smith, say “Call Bill Smith.”
•
Speak numbers at a normal speed and volume, and
pronounce each digit distinctly. Avoid pausing
between digits.
•
When you press the Voice key with your phone
open, your phone says voice command prompts
through the speakerphone. To change this, see
page 33.
voice commands
1
With your phone open, press the Voice key on the
right side of the phone (if your phone is
closed
,
hold
the Voice key).
Your phone opens a list of voice commands and
says
Please say a command
.
2
Say a voice command (If your phone is closed and
unlocked, you can only say
Call <Name or #>
or
Play <Playlist>
):
voice commands
Call <Name or #>
For example, say “Call Bill Smith mobile” or
“Call 8475551212.”
31
personalize
Send <MSG Ty p e >
Say “Send text” or “Send picture,” then:
•
the name of a
Contacts
entry
or
•
a phone number
For instructions on sending messages, see
page 50.
Go To <Shortcut>
Open one of the following features by saying it after
“Go To:”
Contacts
,
Recent Calls
,
Messages
,
Media Center
,
Settings
,
Tools
,
Browser
,
V CAST Videos
,
My Music
, or
Redial
.
Note:
If you don’t have any content (music, recent
calls, and so on), the phone returns to the main
screen.
voice commands
Check <Item>
Show phone details by saying them after “Check:”
Status
,
Voicemail
,
Messages
,
Missed Calls
,
Time
,
Signal Strength
,
Battery
, or
Volume
.
Contact <Name>
Look up a
Contacts
entry by saying the contact’s
name.
Play <Playlist>
Say the name of one of your playlists to play it.
Note:
If you don’t have any music, the phone
returns to the main screen.
My Verizon
Launch the
Browser
and open your account options.
voice commands
32
personalize
voice recognition settings
To modify voice recognition settings:
1
With the phone open, press and release the Voice
key on the right side of the phone.
2
To u ch
Settings
.
3
Touch the desired option:
Help
Show help information for the voice recognition
feature.
voice recognition settings
Digit Dial Readout
Set your phone to say numbers aloud as you touch
them on the dialpad.
voice commands
Confirmation
If your phone is not sure that it has correctly
identified a name or number that you speak, it can
display up to three choices and prompt you to
confirm the correct one.
You can control when choice lists appear:
Automatic
—Display a list of choices from multiple
alternatives.
Always Confirm
—Always display a list of choices when
there are multiple alternatives.
Never Confirm
—Never display a choice list. The phone
chooses from the best alternatives.
voice recognition settings
33
personalize
Tip:
To see a brief description of a setting, touch the
setting, then touch
Info
.
Sensitivity
You can fine tune your phone’s ability to recognize
voice commands. Select
Most Sensitive
,
Recommended
, or
Least Sensitive
.
If sensitivity is too strict
, your phone often rejects
voice commands and displays “Please repeat ...” or
“No match found.” Select Most Sensitive.
If sensitivity is too forgiving
, you experience false
activations (indicating that the phone detects a
wrong match). Select
Least Sensitive
.
Adaptation
Follow the prompts on your screen to improve
recognition of spoken words. Adaptation takes
about sixty seconds and requires you to be in a
quiet place (no background noise).
voice recognition settings
Prompts
Mode
—Set whether your phone says
Prompts
,
Readout
(to
read every word on the screen), or
Tones Only
.
Audio Playback
—Set how you want to hear prompts:
Automatic
detection,
Speakerphone
, or through your
Earpiece
.
Call Alert
For an incoming call, set whether you hear a
Ring Only
,
Caller ID + Ring
, or
Name Repeat
(repeat the name until you
answer or the call goes to voicemail).
voice recognition settings
34
personalize
answer options
You can use different ways to answer an incoming call.
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Settings
.
3
Touch
Call
.
4
Touch
Answer Option
.
flip open display
You can choose whether your phone shows the
Main Menu
or
Home Screen
when you open the flip:
1
With the flip open, from the main screen,
touch
Menu
.
2
Touch
Settings
.
3
Touch
Display
.
4
Touch
Screen Upon Flip Open
.
5
Touch
Main Menu
or
Home Screen
.
wallpaper
Set a picture or animation as a wallpaper (background)
image on your main screen
and
your phone’s external
display.
1
With the flip open, touch
Menu
to open the
menu.
options
Flip Open
Answer by opening the phone.
Auto w/
Handsfree
Automatically answer an incoming
call (works with headset,
Bluetooth® connections, and when
the phone is operating in handsfree
mode).
35
personalize
2
Touch
Settings
.
3
Touch
Display
.
4
Touch the button below
Wallpaper
.
5
Touch
Pictures
or
Animations
.
Note:
If your phone does not list any animations,
you can download an animated wallpaper
application as described on page 74.
6
Move to an image and touch it.
7
Touch
Insert
.
clock format
Set how your phone shows the current time on the
main screen (as shown on page 15):
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Display
.
4
Touch
Clock Format
.
5
Select the clock format including whether you
want a 12-hour clock or a 24-hour clock.
banner
Create a heading to display on your phone’s main
screen:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Display
.
4
To enter text you want to show on your main
screen, touch the blank space under
Personal Banner
.
or
36
personalize
To show your service provider’s name on your
main screen, drag the button below
ERI Banner
to the
right to turn it
On
(show) or to the left to turn it
Off
(hide).
backlight
Your phone’s backlight turns on for a new button press,
call, or other event. You can adjust how long the
backlight stays on:
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Settings
.
3
Touch
Display
.
4
Touch
Backlight
.
5
Select how long you want the backlight to stay on.
Tip:
To extend battery life, set the backlight to a
short duration.
brightness
Set the brightness of your phone display:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Display
.
4
Touch
Brightness
.
•
Manual
lets you set your phone’s brightness
using a scroll bar.
•
Auto
tells your phone to adjust automatically
based on the brightness of your environment.
37
personalize
languages
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Phone
.
4
Touch
Phone Settings
.
5
Touch
Language
.
6
Touch
English
or
Español
.
38
calls
calls
To make and answer calls, see page 12.
redial a number
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Calls
.
3
Move to the entry you want to call.
4
Touch the phone icon to the right of the entry.
automatic redial
When you receive a busy signal, your phone displays
Call Failed, Number Busy
. If you turn on
Auto Retry
, your phone
redials the number for four minutes. If the call goes
through, your phone rings or vibrates once, displays
Redial Successful
, and connects the call. To turn on
Auto Retry
:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Call
.
4
Drag the button below
Auto Retry
to the right to turn
it
On
.
When automatic redial is turned off, you can manually
activate it to redial a number. When you hear a fast
busy signal and see
Call Failed
, touch
Retry
to automatically
redial.
39
calls
Visual Voice Mail
Note:
Your service provider may include additional
information about using this feature.
Your network stores the voicemail messages
you receive. When you
receive
a voicemail
message and your phone shows the voicemail
message indicator:
To h e a r
the voicemail message, touch
Call Voicemail
. You
might need to enter your password, originally set to
your 10-digit phone number (including your area code).
To d i s m i s s
the voicemail alert, touch
Dismiss
. To check
voicemail messages later, touch the voicemail message
indicator in your home screen (shown on page 15), then
touch
Call Voicemail
. You might need to enter your
password, originally set to your 10-digit phone number
(including your area code).
To s e e
your voicemail list at any time, you can use
Visual Voice Mail. Just touch
Menu
, then
touch
Visual Voice Mail
to open a list of your voicemail
messages. You can use this list to hear, erase, or
manage your voicemail messages.
recent calls
Your phone keeps a list of the calls you received or
dialed, even if the calls didn’t connect. When your
phone adds a new call to the top of the list, it deletes
an old call from the bottom of the list.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Calls
.
3
Touch the icon to the
left
of an entry to choose
Call
,
Send Message
,
View Contact Details
,
Save to Contacts
,
Lock
, or
Remove
.
Touch the icon to the
right
of an entry to call it.
40
calls
To send or erase multiple contacts,
highlight
them
by sliding across each one, from
left to right
.
Highlighted contacts have a light background on
the left side of the screen. To
unhighlight
a
contact, drag across it from
right to left
. After you
highlight the contacts you want, touch
Options
.
Tip:
Want to clean up? To delete calls, select one
or more by sliding across each one from left to
right, then touch
Remove
.
return missed calls
Your phone keeps a record of your missed calls, and
displays
[Number] Missed Calls
. When you see the missed
call alert:
To r e t u r n
the call, touch
View Now
, then touch the phone
icon next to the call.
To d i s m i s s
the missed call alert, touch
View Later
. If you
want to see the call details later, touch
Menu
,
then
Calls
. Missed calls have a red
x
next to them.
restrict calls
You can tell your phone to allow all calls, no calls, or
only calls from numbers in your
Contacts
.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Security
.
4
Enter your four-digit
lock code
(originally set to the
last four digits of your phone number as described
on page 22).
Tip:
Your call restrictions use a restriction code
that is different from your lock code. To change
your restriction code, touch
Change Code
under
Restrictions
in the
Security
menu. Enter your current
restriction code (originally set to the last four digits
of your phone number), then enter and confirm a
new four-digit code.
41
calls
5
Under
Restrictions
, touch
Update Settings
.
6
Enter the four-digit
restriction code
(originally set
to the last four digits of your phone number).
7
Touch
Done
.
8
Under
Calls
, touch
Incoming Calls
or
Outgoing Calls
.
9
Touch
Allow All
,
Block All
, or
Contacts Only
.
insert special
characters
While entering a number, touch
Options
to select:
Insert Pause
—Tells your phone to pause for two seconds
before it dials the next digit.
Insert Wait
—Tells your phone to prompt you for
confirmation before it dials the next digit.
3-way calls
You can make conference calls.
1
During a call, add another caller by touching
Dialpad
.
2
Dial the second person’s number and touch
Call
.
3
When the second person answers, touch
Switch
to
connect the calls together.
To disconnect the second person, touch
Switch
.
To end both calls at once, touch
End Call
.
in-call options
During a call, you can touch shortcuts to open your
Messages
,
Dialpad
,
Calls
,or
Contacts
. You can also
touch shortcuts to switch the call to
Mute
, the
Speaker
,or
Bluetooth
(Bluetooth device).
42
calls
Note:
When you have a Bluetooth® device connected
during a call, you also see
Audio to Phone
and
Disconnect Bluetooth
options. When you have TTY Mode on,
you also see a
TTY Setup
option.
emergency calls
Your service provider programs emergency phone
numbers, such as 911, that you can call under any
circumstances, even when your phone is locked.
1
With the flip open, touch
Dialpad
.
2
Enter the emergency number.
3
Touch
Call
.
Note:
Emergency numbers vary by country. Your
phone’s preprogrammed emergency number(s) may
not work in all locations, and sometimes an emergency
call cannot be placed due to network, environmental, or
interference issues.
AGPS & emergency calls
When you make an emergency call, your phone
can use Assisted Global Positioning System (AGPS)
satellite signals to tell the emergency response center
your approximate location.
The AGPS feature has limitations, so always tell the
emergency response center your best knowledge of
your location. Remain on the phone for as long as the
emergency response center instructs you.
AGPS
might not work
for emergency calls if your local
emergency response center does not process AGPS
location information. For details, contact your local
authorities.
If your phone cannot find strong AGPS satellite signals,
the location of the nearest cell tower in contact with
your phone is automatically provided to the emergency
response center.
43
calls
AGPS limitations & tips
To improve AGPS accuracy:
•
Go outside and away from underground locations,
covered vehicles, structures with metal or concrete
roofs, tall buildings, and foliage. Indoor performance
might improve if you move closer to a window, but
some window sun-shielding films can block satellite
signals.
•
Move away from radios, entertainment equipment,
and other electronic devices that might interfere
with or block AGPS satellite signals.
AGPS uses satellites controlled by the U.S. government
and is subject to changes implemented in accordance
with the Department of Defense AGPS user policy and
the Federal Radio Navigation Plan. These changes
might affect AGPS performance.
hiding your location
Your phone can use the automatic location
information (ALI) feature, along with Assisted Global
Positioning System (AGPS) satellite signals, to tell the
network where you are physically located.
When ALI is set to
Location On
, your phone displays
O
.
Services may use your known location to provide
useful information (for example, driving directions, or
the location of the nearest bank). Your phone prompts
you when the network or a service asks for your
location. You can refuse at this point.
When ALI is set to
E911 Only
, your phone displays
P
.
The phone does not send location information unless
you call an emergency phone number (such as 911).
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Phone
.
4
Touch
Phone Settings
.
5
Touch
Location
.
44
calls
6
Touch
Location On
or
E911 Only
.
call times & data
volumes
Network connection time
is the elapsed time from
the moment you connect to your service provider's
network to the moment you end the call. This time
includes busy signals and ringing.
The amount of network connection time you track
on your resettable timer may not equal the amount
of time for which you are billed by your service
provider. For billing information, contact your
service provider.
view and reset call timers &
data volumes
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Calls
.
3
Touch the list title,
ALL CALLS
, to open the list of call
options.
4
Touch
CALL TIMERS
or
DATA COUNTER
.
5
Move to a category to view details. To reset a
timer or counter, touch
Reset
.
6
Touch
Yes
to confirm.
ALL CALLS
MISSED CALLS
RECEIVED CALLS
DIALED CALLS
CALL TIMERS
DATA COUNTER
Touch an
option to select
it.
Touch
ALL
CALLS
to open
or close the
options.
45
calls
set an in-call timer alert
You can set your phone to beep every minute
that you are on a call. The person you are talking to
does not hear the minute beep.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Sounds
.
4
Touch
Service Alerts
.
5
Drag the button below
Minute Beep
to the right to turn
it
On
.
DTMF tones
Your phone sends Dual-tone multi-frequency (DTMF)
tones for calling card calls or to navigate automated
systems (such as banking by phone).
If you know you need to change your phone’s DTMF
tones
:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Call
.
4
Touch
DTMF
.
5
Touch
Normal
or
Long
.
46
calls
hearing aid
If you use a hearing aid, set your phone to be
compatible with your hearing aid.
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Settings
.
3
To u ch
Call
.
4
Drag the button below
Hearing Aid
to the to the right
to turn it
On
.
Note:
For more information about hearing aid
compatibility, see “Hearing Aid Compatibility with
Mobile Phones” on page 105.
47
text entry
text entry
Some features let you enter text, like this text message
screen:
Use the keypad that appears on your screen to type.
Tip:
To
move the cursor back
, just touch where you
want the cursor to appear. You can also move the
cursor by using the Volume keys or touching the
on-screen arrows.
If you turn the phone sideways (toward the left) while
you are entering text, your phone shows a text keypad:
Touch the text entry area for on-screen navigation
arrows (
9:
). Resume typing to bring back the
counter and text entry mode indicator.
Text entry tips:
•
Try to touch the screen in only one place at a time.
More than one touch at once may cause your phone
to incorrectly interpret what you want.
•
Make each touch distinct and try not to hover over
the screen. If you are too close to the screen after
21/1000
I am going home soon
Abc def
Abc Done
CLR
.,?
1abc
2def
3
ghi
4jhl
5mno
6
pqrs
7tuv
8wxyz
9
0
Enter up
to 1000
characters.
Enter a space
f
, change
to uppercase
0
, or delete
characters
CLR.
Change your
text entry
mode.
Move the
cursor left or
right.
21/1000
Abc
q
a
w
s
e
d
x
r
f
t
g
y
h
u
j
i
k
o
l
X 123!/ Space Done
p
!?
zcvbnm,.
I am going home soon
CLR
Change to
uppercase.
Start a new
line.
Delete.
Cancel the
message.
48
text entry
touching it, your phone might detect it as more
touches.
change your text entry
mode
Multiple entry modes make it easy for you to enter
names, numbers, and messages. The default mode is
Abc
.
To change the entry mode
when you are entering
text, touch the key in the lower left corner. You can
choose:
To use uppercase letters
when you are entering text in
the
Predictive
or
ABC
modes, touch
0
. A symbol at the
top of your screen indicates whether your phone will
use no uppercase letters (
abc
), one uppercase letter at
the beginning of each sentence (
Abc
), or all uppercase
letters (
ABC
).
entry modes
iTAP
Touch a key once for each letter and let
the phone predict the word you are
entering.
ABC
Touch a key multiple times for each
letter, to cycle through the letters and
the number shown on the key.
123
Touch a number key to enter the
number.
Symbols
Touch a symbol key to enter a symbol.
To show more symbols, touch the
arrows at the bottom of the dialpad.
entry modes
49
text entry
ABC mode
ABC
is the standard text entry mode.
To enter letters
, touch a key once to insert the first
letter on the key, twice for the second letter, and so on.
If you pause briefly, your phone moves on to the next
letter.
To enter a space
, touch
f
.
To enter punctuation
, touch
1
. Touch it multiple
times to cycle through your options.
To d e l e t e
the character to the left of the cursor,
touch
CLR
. To keep deleting, hold
CLR
.
example
To enter “home” you would touch
4
twice (for “h”),
touch
6
three times (for “o”), then pause, touch
6
once (for “m”), and touch
3
twice (for “e”).
Tip:
When you enter three or more letters in a row,
your phone might guess the rest of your word (it shows
red letters after your cursor). To accept the guess,
touch the screen. To enter a space instead, touch
f
.
iTAP® mode
The
iTAP
text entry mode combines your key touches
into common words.
To enter letters
, touch a key once for each letter.
To enter a space
, touch
f
.
To enter punctuation
, touch
1
.
To delete
the character to the left of the cursor,
touch
CLR
. To keep deleting, hold
CLR
.
example
To enter “home” you would touch
4
663
. If
the word in your display is not “home,” touch
More
to
show other word options for that key combination.
Touch the one you want.
Tip:
When you enter three or more letters in a row,
your phone might guess the rest of your word (it shows
red letters after your cursor). To accept the guess,
touch
Complete
. To remove the guess, touch it.
50
messages
messages
send a picture, video,
or sound message
You can insert pictures, videos, sounds, or
Contacts
entries in multimedia messages that you can send to
email addresses or other compatible phones.
1
With the flip open, from the main screen,
touch
Messages
.
2
Touch
New Message
.
3
Touch
Pic-Voice Message
or
Video Message
.
4
To u ch
TO:
to enter recipients.
Touch a
Contacts
entry and then touch
Add Number
, or
touch
Dial Pad
, enter a new phone number, then
touch
Done
.
Note:
You can repeat this step to add up to ten
recipients.
5
Touch
Text
, then enter the message text.
6
Touch
Insert
to add a subject, prewritten text,
picture, video, or other object.
Enter the text you want to insert and touch
Done
, or
touch the item you want to insert and touch
Insert
.
7
Touch
Send
to send the message.
51
messages
send a text message
1
With the flip open, from the main screen,
touch
Messages
.
2
Touch
New Message
.
3
Touch
New TXT Message
.
4
Touch
TO:
to enter recipients.
Touch a
Contacts
entry and then touch
Add Number
, or
touch
Dial Pad
, enter a new phone number, then
touch
Done
.
Note:
You can repeat this step to add up to ten
recipients.
5
Touch
Text
, then enter the message text.
6
Touch
Insert Quick Text
to insert prewritten text.
Touch the text you want to insert.
7
Touch
Send
to send the message.
receive a message
When you receive a message, your phone shows
<
and a
New Message
notification.
To read
the message now, touch
View Now
, then touch
the message.
To d i s mi s s
the new message alert, touch
View Later
. Your
phone stores the message in your inbox and shows
<
with the number of unread messages.
To open your inbox:
1
With the flip open, from the main screen,
touch
Messages
.
2
Touch
Messages
.
3
Touch a message to open it.
When you open a message, your phone shows or
plays any pictures, sounds, or videos inserted in it.
You can use the Volume keys to adjust sound
volume.
52
messages
view sent messages
1
With the flip open, from the main screen,
touch
Messages
.
2
Touch
Messages
to open the
Inbox
.
3
Touch the list title,
INBOX
, to open your folder list.
4
Touch
Sent
.
5
Touch the message you want to view.
view drafts
1
With the flip open, from the main screen,
touch
Messages
.
2
Touch
Messages
to open the
Inbox
.
3
Touch the list title,
INBOX
, to open your folder list.
4
Touch
Drafts
(this option only appears if you have
saved draft messages).
5
Touch the message you want to view.
erase messages
1
With the flip open, from the main screen,
touch
Messages
.
2
Touch
Messages
to open the
Inbox
.
To open your
Sent
or
Drafts
folders, touch the list title,
INBOX
, then touch
Sent
or
Drafts
.
3 Highlight
a message by sliding across it, from
left
to right
. Highlighted messages have a light
background on the left side of the screen. You can
highlight more than one message.
INBOX
SENT
LOCKED
Touch an
option to select
it.
Touch
INBOX
to open or
close the
options.
53
messages
To
unhighlight
a message, drag across it, from
right to left
.
4
Touch
Erase
.
5
Touch
Yes
to confirm your choice.
access your email
You can access your Internet email account to read and
send email from your phone.
1
With the flip open, from the main screen,
touch
Messages
.
2
Touch
Email
.
3
Touch
Mobile Email
or
Mobile Web Email
.
4
Follow the on-screen prompts to log into your
account.
use mobile IM
Access your Internet Instant Messaging account to
exchange messages in real time with family and
friends.
1
With the flip open, from the main screen,
touch
Messages
.
2
Touch
Mobile IM
.
3
Touch the name of your IM community.
4
Follow the on-screen prompts to log into your
account.
Note:
If this procedure does not work for you, you can
use the browser to open the URL (Web address) for
your IM community. With the flip open, from the main
screen, touch
Menu
, then touch
Browser
to open the
browser. Touch
Menu
, then touch
Go to URL
and enter
the URL.
54
messages
chat
Access your Internet chat account to keep in touch with
friends and family in real time.
1
With the flip open, from the main screen,
touch
Messages
.
2
Touch
Chat
.
3
Follow the on-screen prompts to log into your
account.
55
entertainment
entertainment
Have fun with your phone!
V CAST Mobile TV
Your phone can deliver full-length programs from some
of the most popular TV channels. During a program,
you can still take calls and messages—when you hang
up, go right back to enjoying your program. Get
unlimited access to entertainment when you use
V CAST Mobile TV. Visit
www.verizonwireless.com/vcast
for more information. Sign up for V CAST Mobile TV by
calling 1-800-2 JOIN IN, visit a Verizon Wireless
Communications store, or subscribe directly from your
phone.
Note:
V CAST Mobile TV is available only in the V CAST
Mobile TV coverage area. See coverage area maps at
www.verizonwireless.com
. Additional fees may apply.
manage your subscription
1
With the flip open, touch
Menu
to open
the menu.
2
Touch
VCASTTV
.
3
Touch
Options
.
4
Touch
Subscription
.
Note:
Normal airtime and/or carrier usage charges
apply.
watch live TV
Shortcut:
If your phone is closed and unlocked,
just touch
VCASTTV
.
1
With the flip open, touch
Menu
to open the
menu.
56
entertainment
2
To u ch
VCASTTV
. Your phone shows a program
guide like this:
3
Touch a program to play it.
Note:
For TV service, you must be in an EVDO
coverage area and see (not
P
) at the top of the
screen. For best reception, you need three or more
status bars of signal strength.
To adjust the volume
, use the Volume keys on the
side of your phone.
To change the channel
up or down, touch
Â
or
Ã
.
Touch
Options
to select more options:
Note:
Your phone might show
Program Blacked Out
if you
choose a sporting event that did not sell out and is not
being shown on TV.
12:00pm
1 JAN
VOD
CBS
NBC
12:00pm 12:30pm 1:00pm
12:00-1:00pm
VCAST On Demand Video
V CAST Video On Demand
Select this line to choose
V CAST Video On Demand
options
Description
View information about a show
including the TV rating (G, PG-13, R,
NC-17).
Subscription
Select from basic or premium TV
viewing packages. Fees apply.
Upgrade Check
Check for software upgrades.
Parental
Controls
Restrict certain channels from
under-age viewers by setting a
four-digit PIN.
About
View software information.
57
entertainment
restrict channel access
To control access to some channels based on
what they are rated by the MPAA (such as NC-17 or R
ratings), you can specify a PIN:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
VCASTTV
.
3
Touch
Parental Controls
to turn them
On
.
4
When prompted, enter your four-digit PIN.
5
Touch
Parental Control Ratings
.
6
When prompted, enter your PIN to start setting
controls for TV, movies, or audio files.
Note:
If you forget your PIN, contact your service
provider for help.
download V CAST videos
1
With the flip open, touch
Menu
to open
the menu.
2
Touch
VCASTVideos
.
3
Touch a video category.
4
Touch a video program (selection) to watch or
download it.
Note:
Normal airtime and/or carrier usage charges
apply.
Tip:
To get the best reception for
V CAST Videos
, keep your
phone open.
58
entertainment
music
V CAST Music with Rhapsody
V CAST Music with Rhapsody is a digital music service
that lets you listen to millions of songs from thousands
of artists for one low monthly price. Discover new and
old favorites in an extensive music catalog. Download
V CAST Music with Rhapsody software to your
Windows PC to sync tracks, albums, and playlists to
your new compatible phone, while managing your
existing PC music library all in one place.
For more information about this service,
visit
www.verizonwireless.com/music
.
download V CAST music
directly to your phone
Note:
Your phone must be in an EVDO coverage area
to download music. If you are in an EVDO coverage
area, your phone displays the EV symbol ( ) with at
least one signal strength bar in the status area of the
screen (see page 16).
When you purchase music using your V CAST Music
with Rhapsody-capable phone*, you receive a second
copy of the music that you can download to your PC
using V CAST Music with Rhapsody on your PC.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Music
.
3
Touch
VCASTMusic
.
4
Browse or search the catalog to find the songs you
want.
To preview a song, highlight the song and then
touch
Preview
.
5
To buy a song, highlight the song and touch
Buy
.
EV
1X
* Per-song charges apply.
59
entertainment
After you touch
Buy
, your phone shows song details
and price.
6
Touch
Buy
to confirm your selection.
7
When you see a confirmation that your purchase
was successful and your music is available for
download, touch
OK
to continue, or touch
Later
.
8
When prompted to select a storage location, touch
Phone Memory
or
Memory Card
to start downloading.
Your phone displays a status indicator. After
downloading, you must wait for the phone to
acquire the content license.
9
Touch
Play
to play the downloaded song
immediately.
download music to your PC
Note:
V CAST Music Manager works only with
Microsoft® Windows® XP™ and Windows Vista™
with Windows Media Player 10 or later. Mac OS is not
supported.
1
On your PC, open V CAST Music Manager.
Tip:
Don’t have V CAST Music Manager?
Download it for free at
http://www.vzam.net/vcastmusic/
2
Follow the prompts to log in and download the
music your purchased.
sync music between your PC and
phone
You can use V CAST Music with Rhapsody to transfer
songs from a computer to your phone through a USB
cable connection. You can purchase these songs using
V CAST Music with Rhapsody or import them from
your CD collection.
60
entertainment
computer system requirements
To transfer music from a computer to your phone
,
you need the Windows XP® or Windows Vista®
operating system and an active internet connection.
Note:
You need a USB cable for syncing.
Motorola Original USB data cables and
supporting software may be sold
separately. Check your computer or
hand-held device to determine the type of cable you
need.
To download V CAST Music with Rhapsody for free
:
1
From your computer’s web browser, go to
http://www.verizonwireless.com/music
.
2
Follow the on-screen instructions to select,
download, and install V CAST Music with
Rhapsody for your phone.
downloading and purchasing music using
V CAST Music with Rhapsody
To download copies of music purchased using your
phone
:
1
On your computer, launch V CAST Music with
Rhapsody.
2
Click on the “Log In” button, then log in by
entering your mobile phone number and password.
For each V CAST Music with Rhapsody track
you’ve downloaded to your phone, you can
download a copy to your computer at no additional
charge. Song tracks available for free download will
pop up when you complete the login process.
3
Check the boxes beside the songs you wish to
download.
4
Select “Download Tracks.”
Downloading can take several minutes.
61
entertainment
5
When downloading is complete, click on the “My
Library” tab in the V CAST Music with Rhapsody”
window to find and play the song(s) you
downloaded.
To buy music from the V CAST Music Store
:
1
On your computer, launch V CAST Music with
Rhapsody.
2
In the V CAST Music with Rhapsody window, click
on the “BUY MUSIC” tab.
3
Click on the “Log In” button, then log in by
entering your mobile phone number and password.
If you have not registered yet, click on the
“Register” button, then follow the instructions to
register and get your password.
4
Browse or search the store to find the songs you
want.
To preview a song, click on the headset icon next
to the song title.
5
To buy a song, click on the “Purchase” or “Buy”
button next to the song title.
6
Repeat steps 4 and 5 to add more songs to your
shopping cart.
7
When you finish shopping, click on “MY
PURCHASES,” follow the on-screen instructions to
complete your purchase(s) and download the
song(s) you have purchased.
Downloading can take several minutes.
8
When downloading is complete, click on the
“My Library” tab in the V CAST Music with
Rhapsody” window to find and play the song(s)
you downloaded.
To transfer the songs to your phone, see “sync music
from your PC to your V CAST Music with Rhapsody
phone” on page 62.
62
entertainment
import songs from an audio CD
1
On your computer, launch V CAST Music with
Rhapsody.
2
Insert an audio CD into your computer’s CD ROM
drive.
3
If the “Music on My CD” window is not already
open in V CAST Music with Rhapsody, click on the
“MUSIC ON MY CD” tab.
The names of all the tracks on the CD are listed in
the window. (You may need to enter artist name
and other information for the tracks.)
4
Select the tracks you want to import or “Rip” by
clicking the check box next to them.
Select
all
tracks by checking the “Title” check box
at above the list of tracks.
5
Click on the “Rip CD” button.
The songs you selected are imported to the
V CAST Music Manager.
To transfer the songs to your phone, see “sync music
from your PC to your V CAST Music with Rhapsody
phone” on page 62.
sync music from your PC to your
V CAST Music with Rhapsody phone
1 On your computer
, launch V CAST Music with
Rhapsody.
2
Connect the USB
cable (purchased
separately) to your
phone and to an
available USB port
on your computer.
If this is the first
time you have connected the phone to a computer
with a USB cable, additional software drivers may
be installed.
63
entertainment
The
SYNC MUSIC V CAST MOBILE PHONE
screen appears on
your phone. Your phone should display
Connected
.
3 On your computer
, click on the “Sync List”
button to open an empty sync list.
4 On your computer
, drag each song you want to
sync “My Library” and drop it on the Rhapsody
mobile phone, listed under the “Sources” tab.
5 On your computer
, click “Sync now.”
You computer syncs the songs from the sync list
with your phone.
6 On your phone
, when synchronization is
complete, press the Power key
%
.
7
Disconnect the cable from the phone and the
computer.
You can now use your phone’s music player to play the
songs you transferred from your computer.
play music
Shortcut:
If your phone is closed and unlocked, just
touch
Music
.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Music
.
3
Touch
My Music
.
The
Search
,
Shop
, and
Help
options appear on all screens in
the Music Library.
The
Music Library
includes these categories:
option
Genres
Find & play music from a specific genre
(type of music) such as rock, jazz, or
blues.
Artists
Find & play music by a specific artist.
64
entertainment
•
Press the Home key
B
from any Music Library
screen to return to the main screen.
•
On screens that show a list of items (such as album
titles), enter letters in the
Go To
area to jump directly
to items beginning with those letters.
play an album
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Music
.
3
Touch
My Music
.
4
Touch
Genres
,
Artists
, or
Albums
.
From the
GENRES
screen
:
1
Touch the
genre
you want.
2
Touch
artist
you want.
3
Touch
album
you want to play.
4
Touch
Play album
.
From the
ARTISTS
screen
:
1
Touch the
artist
.
Albums
Find & play music from a specific album.
Note:
Even if you have only one song
from an album, you will see a listing for
that album.
Songs
Find & play specific songs.
Playlists
Play songs from personalized playlists
that you create.
Inbox
View alert notifications received when
new music from a selected artist is
available for download.
Play All
Play all songs in the Music Library in list
order.
Shuffle
Play songs in the Music Library in
random order.
option
65
entertainment
2
Touch the
album
you want to play.
3
Touch
Play album
.
From the
ALBUMS
screen
:
1
Touch
Ñ
to the right of an
album
to select from
these options:
2
Touch
Play album
.
play a song
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Music
.
3
Touch
My Music
.
4
Touch
Genres
,
Artists
,
Albums
. or
Songs
.
option
Play album
Play the selected album, beginning
with the first song.
Listeners also
liked
For music that you’ve downloaded,
see music recommendations.
Lock album
Lock album so you do not
accidentally delete it.
Erase album
Remove the selected album from
the Music Library.
Album info
See more info about the album.
Rebuild Library
Database
Under normal conditions, the Music
Library is maintained automatically.
If the library behaves unexpectedly,
use this option to re-initialize it. This
option deletes the existing library
and creates a new one that contains
all currently installed music.
option
66
entertainment
From the
GENRES
screen
:
1
Touch the
genre
you want.
2
Touch
artist
you want.
3
Touch
album
you want to play.
4
Touch
Play album
.
From the
ARTISTS
screen
:
1
Touch the
artist
.
2
Touch the
album
you want to play.
3
Touch
Play album
.
From the
ALBUMS
screen
:
1
Touch the
album
.
2
Touch the song you want to play. The song plays
only once, followed by the next song in the list.
or
To u ch
Ñ
to select other options (see page 67).
From the
SONGS
screen
:
Touch the song you want to play. (The song plays only
once, followed by the next song in the list.)
or
Touch
Ñ
to select other options (see page 67).
play all songs on phone
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Music
.
3
Touch
My Music
.
4
Touch
Play All
.
67
entertainment
music library options menus
When you touch
Ñ
to the right of a
song
, your phone
displays these options:
When you touch
Ñ
while a song is playing
, your
phone displays these options:
Note:
The song is paused when you touch
Ñ
.
option
Add to playlist
Add the selected song to a playlist.
Listeners also
liked
For music that you’ve downloaded,
see music recommendations.
Lock Song
Lock a song so you do not
accidentally delete it.
Erase song
Remove the selected song from the
Music Library.
Erase all songs
Remove the selected songs from the
Music Library.
Song Info
View the following information for
the song: title, artist, album title,
genre, copyright year, duration, and
track number (if available).
Rebuild Music
Database
Under normal conditions, the Music
Library is maintained automatically. If
the library behaves unexpectedly,
use this option to re-initialize it. This
option deletes the existing library and
creates a new one that contains all
currently installed music.
option
Play All
Play all songs in the Music Library in
list order.
Shuffle
Play songs in the Music Library in
random order.
option
68
entertainment
create a playlist
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Music
.
3
Touch
My Music
.
4
Touch
Playlists
.
If playlists already exist, touch
Ñ
to the right of a
playlist, then move down the options to
touch
Create Playlist
.
5
Enter a title for the playlist.
6
Touch the songs you want to add to the playlist.
7
When finished adding songs to the playlist, touch
Done
.
play music from a playlist
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Music
.
3
Touch
My Music
.
4
Touch
Playlists
.
To play an entire playlist
, touch the playlist to start the
first song. The music player plays all songs in that
playlist.
To play a song from a playlist
, touch the playlist, then
move to the song you want and touch
Play
.
My Music
Go back to your Music Library.
Shop
Connect to the V CAST Music catalog
to download more songs.
Listeners also
liked
For music that you’ve downloaded,
see music recommendations.
Help
Get help with your media player.
option
69
entertainment
Note:
The first song in the playlist starts playing while
you move through the playlist to select the song
you want.
edit a playlist
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Music
.
3
Touch
My Music
.
4
Touch
Playlists
.
5
Touch the playlist you want to edit.
6
Touch
Edit
.
7
Edit the playlist as desired.
To change the order of songs in your playlist, drag
the songs into the order you want.
To delete a song, touch the song and then touch
Remove
.
8
Press the Home key
B
to return to the main
screen.
listening tips
When you’re on the go, you can listen to your music
through a wired headset or Bluetooth® stereo
headphones (see page 86).
When you are not using a wired or wireless headset,
music is played through the phone’s speaker.
sound clips
You can create a sound clip that you can play back later.
record a sound clip
Shortcut:
To create a sound clip quickly, flip open the
phone, press and hold the Voice key (on the right side
of the phone), then touch
OK
to start recording. Touch
Stop
to stop recording.
70
entertainment
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Media Center
.
3
Touch
Tones & Sounds
.
4
Touch
My Sounds
.
5
Touch
Record New
.
6
To start recording, touch
OK
.
7
To stop recording, touch
Stop
. The sound clip is
saved in your
My Sounds
list, and is named after the
date and time you recorded it.
8
To record another clip, touch
OK
. To exit, press the
Home key
B
.
play a sound clip
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Media Center
.
3
Touch
Tones & Sounds
.
4
Touch
My Sounds
.
5
Touch the sound clip to play it. Sound clips are
named after the date and time you recorded them.
video clips
You can record a video clip and send it in a multimedia
message.
Your camera lens is on the back of your phone.
To g e t
the clearest video clips, wipe the lens clean with a
soft, dry cloth before you capture a video clip.
record & send a video clip
Shortcut:
To quickly open the video viewfinder, press
and hold the Camera key
e
on the right side of your
phone.
1
With the flip open, touch
Menu
to open the
menu.
71
entertainment
2
Touch
Media Center
.
3
Touch
Pictures & Video
.
4
Touch
Record Video
.
Your phone shows the video viewfinder.
5
Point the camera lens at the subject.
6
To start recording, press the Camera key
e
on
the right side of your phone.
7
To stop recording, press the Camera key
e
again. The video clip is saved in your
My Videos
list,
and is named after the date and time you recorded
it.
Your phone shows two buttons (
Send
and
Erase
) for a
moment, then returns to the video viewfinder. Your
video clip appears in a red box next to the
viewfinder.
8
With your flip open, touch your video clip (in the
red box next to the viewfinder). The video clip
plays, and you can touch it to show these buttons:
•
Send
opens a message with the video clip
inserted.
•
Info
shows details about the video clip file.
•
Erase
deletes the video clip.
Tip:
To return to the viewfinder, touch the red box
next to your video clip. To record a new video clip,
just press the Camera key
e
. Each new video
clip you record appears in a new red box next to
the viewfinder.
play a video clip
To play a video clip stored on your phone:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Media Center
.
72
entertainment
3
Touch
Pictures & Video
.
4
Touch
My Videos
.
5
Touch the clip you want to play. While the clip is
playing, you can touch these options (files with
a
0
are protected, and cannot be sent or erased):
•
Send
opens a message with the video clip
inserted.
•
Mute
silences the video clip sound.
•
Info
shows details about the video clip file.
•
Erase
deletes the video clip.
photos
Your phone has a 2.0 megapixel digital camera that
takes photos at 1280 x 1600 pixels resolution. You can
take a photo and send it in a multimedia message.
Your camera lens is on the back of your phone.
To g e t
the clearest photos, wipe the lens clean with a soft,
dry cloth before you capture a photo.
take & send a photo
Shortcut:
To quickly open the photo viewfinder, press
and release the Camera key
e
on the right side of
your phone.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Media Center
.
3
Touch
Pictures & Video
.
4
Touch
Take Picture
.
Your phone shows the photo viewfinder.
5
Point the camera lens at the subject.
6
To take the photo, press the Camera key
e
on
the right side of your phone. The photo is saved in
your
My Pictures
list, and is named after the date and
time you took it.
Your phone shows two buttons (
Send
and
Erase
) for a
moment, then returns to the photo viewfinder.
73
entertainment
Your photo appears in a red box next to the
viewfinder.
7
With your phone open, touch your photo (in the red
box next to the viewfinder). The photo opens, and
you can touch it to show these buttons:
•
Send
opens a message with the photo inserted.
•
Set As
lets you set the photo as your wallpaper or
as a picture ID for a
Contact
.
•
Info
shows details about the photo file.
•
Erase
deletes the photo.
Tip:
To return to the viewfinder, touch the red box
next to your photo. To take a new photo, just press
the Camera key
e
. Each new photo you take
appears in a new red box next to the viewfinder.
open a photo
Shortcut:
If your phone is closed and unlocked,
just touch
My Pics
.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Media Center
.
3
Touch
Pictures & Video
.
4
Touch
My Pictures
.
5
Touch the picture you want to open. With a photo
open, you can:
•
touch
Á
to play your photos as a slide show.
•
drag right to left to open the next photo.
•
touch
Send
to open a message with the photo
inserted (files with a
0
are protected, and
cannot be sent or erased).
•
touch
Set
to set the photo as your wallpaper or
as a picture ID for a
Contact
.
•
touch
Info
shows details about the photo file.
•
touch
Erase
to delete the photo (files with a
0
are protected, and cannot be sent or erased).
74
entertainment
download a picture
1
With the flip open, touch
Menu
to open
the menu.
2
To u ch
Media Center
.
3
Touch
Pictures & Video
.
4
Touch
Get New Pictures
.
5
Touch
Get New Application
to connect to the picture
catalog.
Note:
Normal airtime and/or carrier usage charges
apply.
Tip:
You can view pictures by sliding across the screen
or by touching
Play
for a slide show.
fun & games
launch a game or application
1
With the flip open, touch
Menu
to open
the menu.
2
Touch
Media Center
.
3
Touch
Games
.
4
Touch the game or application you want to launch
or touch
Get New Application
to connect to the catalog.
download a ringtone, game, or
application
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Media Center
.
3
You can download different types of files:
75
entertainment
•
To download ringtones, touch
Tones & Sounds
, then
touch
Get New Ringtones
.
•
To download games, touch
Games
.
•
To download other applications,
touch
Browse & Download
.
4
Touch
Get New Application
.
5
Select an application and pricing option.
Note:
Normal airtime and/or carrier usage
charges apply.
Web access
Note:
Web access is a subscription service. Contact
your service provider for more information.
To open the Web browser:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Browser
.
Note:
Your browser supports these types of Web
pages: W3C HTML 4.01 Spec, W3C XHTML Basic,
OMA XHTML Mobile Profile 1.2, and WAP 2.0.
To go to a Web site:
In the browser, touch
www
, then enter the site’s URL
address using the text entry screen.
Tip:
How do you move around on a Web page? Some
sites are not made to be viewed on a mobile device and
may be bigger than your screen, so you have to scroll
around on a page. Touch and slide across the screen.
The screen image scrolls in the direction that you slide.
76
entertainment
Here’s how your browser looks when you hold your
phone
upright
:
To see the browser’s landscape view instead, turn your
phone
sideways
.
Menuwww
Headlines
Weather
Sports
National News
To open a link,
slide the
pointer to it,
then touch the
pointer.
Go back one
page.
Go to your
home page.
Enter a Web
page address.
Open your
favorite links
and history.
www Menu
Headlines
Weather
Sports
National News
To open a link, slide the pointer
to it, then touch the pointer.
Go back one
page.
Go to your
home page.
Open your
history.
Refresh the
page.
Open your
favorites.
Enter a Web
page address.
Open the
browser menu.
77
tools
tools
contacts
To store or call a contact, see page 13.
create emergency contacts &
information
If you are injured, emergency workers might check your
phone for emergency contact information. Store the
phone numbers for relatives or friends as emergency
contacts.
Note:
Before you assign emergency contacts, create
standard
Contacts
entries for the emergency contacts.
1
With the flip open, from the main screen,
touch
Contacts
.
2
Touch
In Case of Emergency
.
3
Touch
Assign ICE Contact 1
.
4
Touch a
Contacts
entry to assign it as your primary
contact.
To assign contacts to call if this contact is
unavailable, touch
Assign ICE Contact 2
and
Assign ICE Contact 3
.
To add personal information that may assist
emergency workers, touch
Personal Info 1
,
Personal Info 2
,
or
Personal Info 3
.
add and call favorite contacts
1
With the flip open, from the main screen,
touch
Contacts
.
2
Touch the name of the contact you want.
3
Touch
Set as favorite
.
78
tools
4
Touch
Yes
to confirm.
Tip:
To open your favorite contacts, touch
Contacts
,
then touch the list title,
CONTACT LIST
, and
touch
FAVORITES LIST
. To call a favorite, touch the icon next
to it.
speed dial contacts
To
set
a speed dial number for a contact:
1
With the flip open, from the main screen,
touch
Contacts
.
2
Touch the list title,
CONTACT LIST
, to open options.
3
Touch
SPEED DIAL
to open your speed dial list.
4
Touch the speed dial number you want to set.
5
Touch the contact for the speed dial number.
To
call
a speed dial contact:
1
With the flip open, from the main screen,
touch
Dialpad
.
2
To call speed dial 1-9, touch and hold the number.
To call speed dial 10-99, touch the first number,
then touch and hold the second number.
Tip:
To turn off speed dial, touch
Menu
to open the
menu. Touch
Settings
, then touch
Calls
. Drag the button
below
OneTouchDial
to the left to turn it
Off
.
edit a contact
1
With the flip open, from the main screen,
touch
Contacts
.
2
Touch the entry to open it.
3
Touch
Edit
.
4
Edit the contact information.
CONTACT LIST
FAVORITES LIST
SPEED DIAL
Touch
FAVORITES
LIST
to select
it.
Touch
CONTACT LIST
to open or
close the
options.
79
tools
Tip:
If you store more than one number in a
contact, you can set the
default number
by
touching the circle to the right of a number.
5
Touch
Save
.
send or erase a contact
1
With the flip open, from the main screen,
touch
Contacts
.
2
To send or erase one contact, open it by touching
it.
To send or erase multiple contacts,
highlight
them
by sliding across each one, from
left to right
.
Highlighted contacts have a light background on
the left side of the screen. To
unhighlight
a
contact, drag across it from
right to left
. After you
highlight the contacts you want, touch
Options
.
3
To erase the contacts, touch
Erase
. Then, touch
Yes
to confirm.
To send the contacts, touch
Send vCard
. Then, touch
Send Via Bluetooth
and add or choose a
Bluetooth® device (for more details, see page 84).
set the default number for a
contact
Set the default number for a contact that has more than
one phone number:
1
With the flip open, from the main screen,
touch
Contacts
.
2
Touch the entry to open it.
3
Touch
Edit
.
4
Touch the circle to the right of the default number.
The circle next to the default number is green.
5
Touch
Save
.
80
tools
assign or download a ringtone for
a contact
You can assign a ringtone for your phone to use when
you receive calls from a contact.
1
With the flip open, from the main screen,
touch
Contacts
.
2
Touch the entry to open it.
3
To u ch
Edit
.
4
Touch
Ringtone
.
5
Touch
Add Ringtone
.
6
Touch the ringtone.
To download a new ringtone, touch
Get New Ringtone
,
then touch
Get New App
and follow the prompts.
7
Touch
Save
.
Note:
You will not hear the ringtone if the
Master Volume
is
set to
Vibrate Only
,
Alarm Only
, or
All Sounds Off
.(see page 27).
assign a picture for a contact
You can assign a picture for your phone to show when
you receive calls from a contact.
1
With the flip open, from the main screen,
touch
Contacts
.
2
Touch the entry to open it.
3
Touch
Edit
.
4
Touch the picture area to select a picture.
5
Touch
Add Picture
.
6
Touch a picture.
7
Touch
Insert
.
8
Touch
Save
.
81
tools
calendar
add a calendar appointment
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Tools
.
3
Touch
Calendar
.
4
Touch the date for the appointment.
5
Touch
New Event
.
6
Enter the appointment name and details. To
change the time, recurrence, or alert type, touch
the detail.
7
Touch
Save
.
see calendar appointment
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Tools
.
3
Touch
Calendar
.
Tip:
When a day includes one or more
appointments, it has a red line at the top.
4
Touch the date for the appointment.
5
Drag the calendar up to show the list of
appointments for the selected day. Touch an
appointment in the list to see its details.
82
tools
alarm
set alarm
1
With the flip open, touch
Menu
to open the
menu.
2
To u ch
Tools
.
3
To u ch
Alarm Clock
.
4
Touch
Add Alarm 1
,
Add Alarm 2
, or
Add Alarm 3
.
5
Drag the button below
Set Alarm
to the to the right to
turn it
On
.
6
Set the alarm time, tone, and recurrence by
touching the details.
7
Touch
Done
.
turn off alarm
When an alarm rings, touch
Dismiss
.
To disable an alarm that has not rung yet:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Tools
.
3
Touch
Alarm Clock
.
4
Touch
Add Alarm 1
,
Add Alarm 2
, or
Add Alarm 3
.
5
Touch
Set Alarm
to turn it
Off
.
6
Touch
Save
.
83
tools
world clock
View current time in cities around the world:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Tools
.
3
Touch
World Clock
.
4
Touch
Add Clock
.
5
Touch a global region.
6
Touch the city that matches the time you want.
notepad
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Tools
.
3
Touch
Notepad
.
4
Touch
Add Note
.
5
Enter text and touch
SAVE
.
6
Touch
Done
to confirm.
calculators
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Tools
.
3
Touch
Calculator
for basic math functions, or
Tip Calculator
for figuring gratuities.
Use the keypad to enter numbers and
mathematical functions.
84
connections
connections
Bluetooth® connections
Your phone supports Bluetooth 2.0 wireless
connections. You can connect your phone with a
Bluetooth headset or car kit to make handsfree calls or
to listen to music.
Note:
The use of wireless phones while driving may
cause distraction. Discontinue a call if you can’t
concentrate on driving. Additionally, the use of wireless
devices and their accessories may be prohibited or
restricted in certain areas. Always obey the laws and
regulations on the use of these products.
Your phone currently supports these profiles:
• Headset
(HSP v1.1): Supports use of a compatible
Bluetooth headset for mono voice.
• Handsfree
(HFP v1.5): Supports Bluetooth
headsets, and may also support other installed
compatible Bluetooth devices with speakerphone
capabilities, such as car kits or a conference room
device. For Handsfree Car Kit compatibility, refer to
www.verizonwireless.com/bluetoothchart
on the
Verizon Wireless Website.
• Dial Up Networking
(DUN v1.1): Allows the phone
to be used as a data modem with a compatible
Bluetooth device, such as a laptop or PDA, over the
VZW NationalAccess and/or VZW BroadbandAccess
systems.
• Stereo
(A2DP v1.0 and AVRCP v1.0): Supports
delivery of stereo audio to a compatible Bluetooth
device.
• Phonebook Access
(PBAP v1.0): Allows sharing of
your name card, phonebook entries, and calendar
files with a compatible Bluetooth device.
85
connections
• Basic Printing
(BPP v1.2): Allows printing of JPEG
files to a Bluetooth enabled printer.
• Basic Imaging
(BIP v1.0): Allows sending and
receiving of non-protected images for storing and
printing.
•Object Push
(OPP v1.1): Allows sending and
receiving of contact name cards and other
nonprotected data between devices.
• File Transfer
(FTP v1.1): Allows the capability to
send or receive non-protected data files to a
compatible Bluetooth device.
• Basic Imaging
(BIP v1.0): Allows sending and
receiving of non-protected images for storing and
printing.
To show descriptions of the profiles your phone
supports:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Bluetooth
.
3
Touch
My Supported Profiles
.
For more information about Bluetooth wireless
connections supported by this device, go to FAQ
www.verizonwireless.com/bluetooth
.
For information about vehicle compatibility, go to
www.verizonwireless.com/bluetoothchart
.
Note:
All multimedia (video player, audio player, shutter
tone, V CAST) play from the speakerphone when your
phone is connected to a mono Bluetooth device.
For maximum Bluetooth security
, you should always
connect Bluetooth devices in a safe, private
environment.
turn Bluetooth power on or off
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Bluetooth
.
3
Drag the button next to
Bluetooth Power
to the to the
right to turn it
On
or to the left to turn it
Off
.
86
connections
Note:
To extend battery life, set Bluetooth power to
Off
when not in use. Your phone does not automatically
turn off Bluetooth power when it closes a connection.
connect a new device
Note: If you use your Motorola Bluetooth
headset with both an audio device and your
phone, use your phone’s Bluetooth menus to
connect the phone with the headset.
If you establish
the connection by pressing a button on the headset, or
if you allow the headset to connect automatically by
turning it on, you may experience unexpected results.
Before you try to connect your phone with another
Bluetooth device
, make sure the other device is in
pairing, bonding, or discoverable mode (see the user’s
guide for the device). Your phone can connect with only
one Bluetooth device at a time.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Bluetooth
.
3
Touch
DeviceList/NewDevice
.
4
Touch
Add New
.
Note:
If your Bluetooth power is not turned on,
your phone prompts you to turn it on.
5
Make sure the other device is in discoverable
mode, then touch
OK
on your phone.
Your phone lists the devices it finds within range.
6
Touch
Pair
next to the device you want to connect.
Your phone tries to pair with the device.
If your phone prompts you to
ENTER PASSKEY
, touch
the passkey field to show a dialpad. Enter the
passkey or PIN code for the device (usually set to
87
connections
0000), then touch
Done
and touch
OK
. The other
device might ask you to enter the same passkey.
Note:
See the instructions that came with your
device for the device PIN code and other
information about the device.
7
Touch
Yes
to confirm the connection.
When the connection is made, your phone shows the
the Bluetooth connection active status indicator
I
.
Tip:
When your phone’s Bluetooth power is on, it
shows the Bluetooth power on status indicator
O
and
it can automatically connect to a handsfree device you
have used before. Just turn on the device or move it
near the phone.
reconnect a device
Note:
Make sure the other device has Bluetooth
power on. Your phone can connect with only one
Bluetooth device at a time.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Bluetooth
.
3
Touch
DeviceList/NewDevice
to show the devices your
phone has connected before.
4
Touch
Connect
next to the device name.
Note:
Your phone will prompt you to turn on its
Bluetooth power if it is off.
5
If prompted, enter the passkey (usually set to
0000).
If the connection fails, try using
Add New Device
to find
and add the device as if it is new.
reconnect a handsfree device
during a call
During a call, you can connect a handsfree device if the
device is
on
and your phone has
used it before
.
88
connections
Note:
Your phone can connect with only one Bluetooth
device at a time.
1
During a call, touch
Bluetooth Menu
.
If your phone has only connected one handsfree
device before, and that device is on and nearby,
your phone connects it automatically.
2
If necessary, touch
Add New Device
or select the name
of a handsfree device you have used before.
3
Place the handsfree device in discoverable mode,
then touch
OK
on your phone.
4
When your phone finds the handsfree device,
touch
Pair
next to the device name.
send files to a computer or another
phone
You can use a Bluetooth connection to send a
contact or media file to a computer or another
phone that you have connected before (to connect a
new device
, see page 86).
To send a contact (vCard file)
:
Note:
Not all Bluetooth phones can receive vCards.
Make sure the other phone’s Bluetooth power is
on
and
ready
in discoverable mode (see the user’s guide
for the phone). Also, make sure the phone is not busy
with another similar Bluetooth connection.
1
With the flip open, from the main screen,
touch
Contacts
.
2
To send one contact, open it by touching it.
To send multiple contacts,
highlight
them by
sliding across each one, from
left to right
.
Highlighted contacts have a light background on
the left side of the screen. To
unhighlight
a
contact, drag across it from
right to left
. After you
highlight the contacts you want to send,
touch
Options
.
89
connections
3
Touch
Send Name Card
or
Send vCard
.
4
Touch
Send Via Bluetooth
.
Note:
If your phone does not already have
Bluetooth power turned on, it prompts you to turn
it on.
5
Touch
Send
next to the receiving phone or computer
to send the vCard. If the receiving phone or
computer is not listed, touch
Add New
to find it.
6
If prompted, enter the PIN code (usually set to
0000) or accept the transfer.
To send a media file
:
Note:
Make sure the other phone’s Bluetooth power is
on
and
ready
in discoverable mode (see the user’s
guide for the phone). Also, make sure the phone is not
busy with another similar Bluetooth connection.
1
On your phone, touch the file (such as a picture,
video, or sound) you want to transfer and touch
Send
.
2
Touch
Send
.
3
Touch
Bluetooth
.
Note:
If your phone does not already have
Bluetooth power turned on, it prompts you to turn
it on.
4
Touch
Send
next to the receiving phone or computer
to send the file. If the receiving phone or computer
is not listed, touch
Add New
to find it.
5
If prompted, enter the PIN code (usually set to
0000) or accept the transfer.
receive files from another phone
Note:
Make sure your phone’s Bluetooth power
is
on
and
ready
in discoverable mode
(touch
Menu
, then
Bluetooth
, and confirm that both
Bluetooth Power
and
Discovery Mode
are
On
).
1
Place your phone near the other phone, then send
the file from the other phone.
90
connections
2
Touch
Accept
on your phone to accept the file from
the other device.
Your phone notifies you when file transfer is complete.
If necessary, touch
Save
to save the file.
receive files from a computer
You can use a Bluetooth connection to transfer
some media files between your computer
and phone.
Note:
Your computer’s Bluetooth interface may be
different.
1
Pair your phone and computer (see “connect a
new device” on page 86).
2 On your computer
, right-click the Bluetooth icon
in your System Tray to open the Bluetooth menu.
On Windows® Vista™:
•
Select “Send a File.”
•
Click “Browse” to locate your phone name, and
then click “Next.”
•
Click “Browse” to locate the file you want to
transfer, and then click “Next.”
On Windows® XP™:
•
Select “Wireless File Transfer.”
•
Click the checkmark next to your phone in the
“Transfer-enabled device” list.
•
Click “Add” to locate the file you want to
transfer.
•
Click “Send” to send the file.
3 On your phone
, when prompted, touch
Yes
to
accept the file transfer.
make your phone discoverable
for other Bluetooth devices
Note:
For the best Bluetooth connection, connect with
Bluetooth devices using your phone’s menus rather
than making your device discoverable.
91
connections
To let other Bluetooth devices discover your phone:
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Bluetooth
.
3
Drag the button next to
Discovery Mode
to the to the
right to turn it
On
.
disconnect a device
Shortcut:
Turn off the other device.
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Bluetooth
.
3
Touch
Device List/New Device
.
4
Touch
Disconnect
next to the name of the connected
device.
5
Touch
Yes
to confirm.
network
adjust network settings
1
With the flip open, touch
Menu
to open
the menu.
2
Touch
Settings
.
3
Touch
Phone
.
4
Touch
Phone Settings
.
5
Touch the button below
System Select
to choose
Home Only
or
Automatic
(these options may vary).
set call drop alerts
Set the phone to beep whenever the network
drops a call. (Because digital networks are so quiet, the
call drop alert may be the only sign that a call dropped.)
1
With the flip open, touch
Menu
to open the
menu.
2
Touch
Settings
.
3
Touch
Sounds
.
92
connections
4
Touch
Service Alerts
.
5
Drag the button below
Network Lost Tone
to the right to
turn it
On
.
set call connect alerts
Set the phone to beep when an outgoing call
connects.
1
With the flip open, touch
Menu
to open the menu.
2
To u ch
Settings
.
3
To u ch
Sounds
.
4
Touch
Service Alerts
.
5
Drag the button below
Call Connect
to the to the right
to turn it
On
.
set roaming alerts
1
With the flip open, touch
Menu
to open
the menu.
2
To u ch
Settings
.
3
To u ch
Sounds
.
4
Touch
Service Alerts
.
5
Drag the button below
ERI
to the to the right to turn
it
On
.
93
service & repairs
service & repairs
If you have questions or need assistance, we're here to
help.
Go to
www.motorola.com/support
, where you can select
from a number of customer care options. You can also
contact the Motorola Customer Support Center at
1-800-331-6456 (United States), 1-888-390-6456
(TTY/TDD United States for hearing impaired), or
1-800-461-4575 (Canada).
94
service & repairs
Specific Absorption Rate Data
SAR Data
This model wireless phone meets the
government’s requirements for exposure to radio
waves.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed limits for exposure to
radio frequency (RF) energy set by the Federal Communications
Commission (FCC) of the U.S. Government and by the Canadian
regulatory authorities. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the
general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure
the safety of all persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit
of measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC and by the Canadian regulatory
authorities is 1.6 W/kg.
1
Tests for SAR are conducted using
standard operating positions accepted by the FCC and by Industry
Canada with the phone transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the
maximum value. This is because the phone is designed to operate
at multiple power levels so as to use only the power required to
reach the network. In general, the closer you are to a wireless
base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S.
and Canada, it must be tested and certified to the FCC and Industry
Canada that it does not exceed the limit established by each
government for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body)
reported to the FCC and available for review by Industry Canada.
The highest SAR value for this model phone when tested for use at
the ear is 1.53W/kg, and when worn on the body, as described in
this user guide, is 1.43 W/kg. (Body-worn measurements differ
among phone models, depending upon available accessories and
regulatory requirements).
2
While there may be differences between the SAR levels of various
phones and at various positions, they all meet the governmental
requirements for safe exposure. Please note that improvements to
this product model could cause differences in the SAR value for
later products; in all cases, products are designed to be within the
guidelines.
95
SAR
Additional information on SAR can be found on the Cellular
Telecommunications & Internet Association (CTIA) Web site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA)
Web site:
http://www.cwta.ca
96
SAR
97
Important Safety and
Legal Information
98
Safety Information
Safety & General Information
Safety Information
This section contains important information on the safe and
efficient operation of your mobile device. Read this information
before using your mobile device.
Exposure to Radio Frequency (RF) Energy
Your mobile device contains a transmitter and receiver. When it is ON, it
receives and transmits RF energy. When you communicate with your
mobile device, the system handling your call controls the power level at
which your mobile device transmits.
Your mobile device is designed to comply with local regulatory
requirements in your country concerning exposure of human beings to
RF energy.
Operational Precautions
For optimal mobile device performance, and to be sure that human
exposure to RF energy does not exceed the guidelines set forth in the
relevant standards, always follow these instructions and precautions.
Product Operation
When placing or receiving a phone call, hold your mobile device just like
you would a landline phone.
If you wear the mobile device on your body, always place the mobile
device in a Motorola-supplied or approved clip, holder, holster, case, or
body harness. If you do not use a body-worn accessory supplied or
approved by Motorola, keep the mobile device and its antenna at least
2.5 centimeters (1 inch) from your body when transmitting.
Using accessories not supplied or approved by Motorola may cause your
mobile device to exceed RF energy exposure guidelines. For a list of
Motorola-supplied or approved accessories, visit our Web site at:
www.motorola.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from
external sources if inadequately shielded, designed, or otherwise
configured for RF energy compatibility. In some circumstances, your
mobile device may cause interference with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices
instruct you to do so.
In an aircraft, turn off your mobile device whenever instructed to do so
by airline staff. If your mobile device offers an airplane mode or similar
feature, consult airline staff about using it in flight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or
defibrillator, consult your physician before using this mobile device.
Persons with implantable medical devices should observe the following
precautions:
99
Safety Information
•
ALWAYS keep the mobile device more than 20 centimeters
(8 inches) from the implantable medical device when the
mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the implantable medical device to
minimize the potential for interference.
•
Turn OFF the mobile device immediately if you have any
reason to suspect that interference is taking place.
Read and follow the directions from the manufacturer of your
implantable medical device. If you have any questions about using your
mobile device with your implantable medical device, consult your
healthcare provider.
Driving Precautions
The use of wireless phones while driving may cause distraction.
Discontinue a call if you can’t concentrate on driving.
Additionally, the use of wireless devices and their accessories may be
prohibited or restricted in certain areas. Always obey the laws and
regulations on the use of these products.
For more information, see “Smart Practices While Driving.”
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often, but not always,
posted and can include fueling areas, such as below decks on boats,
fuel or chemical transfer or storage facilities, or areas where the air
contains chemicals or particles, such as grain dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not
remove, install, or charge batteries. In such areas, sparks can occur and
cause an explosion or fire.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as
follows:
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile device in a
fire.
Your battery or mobile device may require recycling in
accordance with local laws. Contact your local
regulatory authorities for more information.
Do not throw your battery or mobile device in the
trash.
032374o
032376o
032375o
100
Safety Information
Batteries & Chargers
Caution:
Improper treatment or use of batteries may present a danger
of fire, explosion, leakage, or other hazard. For more information, see
“Battery Use & Safety.”
Keep Your Mobile Device & Its Accessories
Away From Small Children
These products are not toys and may be hazardous to small children. For
example:
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing
hearing injury.
•
Improperly handled batteries could overheat and cause a burn.
Glass Parts
Some parts of your mobile device may be made of glass. This glass
could break if the product is dropped on a hard surface or receives a
substantial impact. If glass breaks, do not touch or attempt to remove.
Stop using your mobile device until the glass is replaced by a qualified
service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when
exposed to flashing lights, such as when playing video games. These
may occur even if a person has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family
history of such occurrences, please consult with your physician before
playing video games or enabling a flashing-lights feature (if available)
on your mobile device.
Discontinue use and consult a physician if any of the following
symptoms occur: convulsion, eye or muscle twitching, loss of
awareness, involuntary movements, or disorientation. It is always a
good idea to hold the screen away from your eyes, leave the lights on in
the room, take a 15-minute break every hour, and stop use if you are
tired.
Caution About High Volume Usage
Warning:
Exposure to loud noise from any source for
extended periods of time may affect your hearing. The
louder the volume sound level, the less time is required
before your hearing could be affected. To protect your
hearing:
•
Limit the amount of time you use headsets or headphones at
high volume.
•
Avoid turning up the volume to block out noisy surroundings.
Do not let your battery, charger, or mobile device get
wet.
Listening at full volume to music or voice through a
headset may damage your hearing.
Symbol Definition
101
Industry Canada Notice
•
Turn the volume down if you can’t hear people speaking near
you.
If you experience hearing discomfort, including the sensation of
pressure or fullness in your ears, ringing in your ears, or muffled speech,
you should stop listening to the device through your headset or
headphones and have your hearing checked.
For more information about hearing, see our Web site at
direct.motorola.com/hellomoto/nss/AcousticSafety.asp
(in English only).
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering
finger-written characters, you may experience occasional discomfort in
your hands, arms, shoulders, neck, or other parts of your body. If you
continue to have discomfort during or after such use, stop use and see a
physician.
[Apr0109]
Industry Canada Notice to Users
Indust ry Cana da Notice
Operation is subject to the following two conditions: (1) This device may
not cause interference and (2) This device must accept any interference,
including interference that may cause undesired operation of the
device. See RSS-GEN 7.1.5.
FCC Notice to Users
FCC Notice
The following statement applies to all products that have
received FCC approval. Applicable products bear the FCC logo,
and/or an FCC ID in the format FCC-ID:xxxxxx on the product
label.
Motorola has not approved any changes or modifications to this device
by the user. Any changes or modifications could void the user’s authority
to operate the equipment. See 47 CFR Sec. 15.21.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. See 47 CFR
Sec. 15.19(3).
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
102
Warranty
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the
receiver.
•
Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for
help.
Motorola Limited Warranty for the United States and Canada
Wa rr a n t y
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its
telephones, pagers, messaging devices, and consumer and professional
two-way radios (excluding commercial, government or industrial radios)
that operate via Family Radio Service or General Mobile Radio Service,
Motorola-branded or certified accessories sold for use with these
Products (“Accessories”) and Motorola software contained on
CD-ROMs or other tangible media and sold for use with these Products
(“Software”) to be free from defects in materials and workmanship
under normal consumer usage for the period(s) outlined below. This
limited warranty is a consumer's exclusive remedy, and applies as
follows to new Motorola Products, Accessories, and Software
purchased by consumers in the United States or Canada, which are
accompanied by this written warranty:
Products and Accessories
Products Covered Length of Coverage
Products and
Accessories
as defined
above, unless otherwise
provided for below.
One (1) year
from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
Decorative Accessories
and Cases.
Decorative
covers, bezels,
PhoneWrap™ covers and
cases.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the product.
Monaural Headsets.
Ear
buds and boom headsets
that transmit mono sound
through a wired connection.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the product.
103
Warranty
Exclusions (Products and Accessories)
Normal Wear and Tear.
Periodic maintenance, repair and replacement
of parts due to normal wear and tear are excluded from coverage.
Batteries.
Only batteries whose fully charged capacity falls below 80%
of their rated capacity and batteries that leak are covered by this limited
warranty.
Abuse & Misuse.
Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such as
physical damage (cracks, scratches, etc.) to the surface of the product
resulting from misuse; (b) contact with liquid, water, rain, extreme
humidity or heavy perspiration, sand, dirt or the like, extreme heat, or
food; (c) use of the Products or Accessories for commercial purposes or
subjecting the Product or Accessory to abnormal usage or conditions; or
(d) other acts which are not the fault of Motorola, are excluded from
coverage.
Use of Non-Motorola Products and Accessories.
Defects or
damage that result from the use of non-Motorola branded or certified
Products, Accessories, Software or other peripheral equipment are
excluded from coverage.
Unauthorized Service or Modification.
Defects or damages
resulting from service, testing, adjustment, installation, maintenance,
alteration, or modification in any way by someone other than Motorola,
or its authorized service centers, are excluded from coverage.
Altered Products.
Products or Accessories with (a) serial numbers or
date tags that have been removed, altered or obliterated; (b) broken
seals or that show evidence of tampering; (c) mismatched board serial
numbers; or (d) nonconforming or non-Motorola housings, or parts, are
excluded from coverage.
Communication Services.
Defects, damages, or the failure of
Products, Accessories or Software due to any communication service or
signal you may subscribe to or use with the Products Accessories or
Software is excluded from coverage.
Software
Exclusions (Software)
Software Embodied in Physical Media.
No warranty is made that
the software will meet your requirements or will work in combination
Consumer and
Professional Two-Way
Radio Accessories.
Ninety (90) days
from the date of
purchase by the first consumer
purchaser of the product.
Products and
Accessories that are
Repaired or Replaced.
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Products Covered Length of Coverage
Products Covered Length of
Coverage
Software.
Applies only to physical defects
in the media that embodies the copy of the
software (e.g. CD-ROM, or floppy disk).
Ninety (90) days
from the date of
purchase.
104
Warranty
with any hardware or software applications provided by third parties,
that the operation of the software products will be uninterrupted or
error free, or that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media.
Software that is not
embodied in physical media (e.g. software that is downloaded from the
Internet), is provided “as is” and without warranty.
Who is Covered?
This warranty extends only to the first consumer purchaser, and is not
transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the
purchase price of any Products, Accessories or Software that does not
conform to this warranty. We may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products, Accessories or
parts. No data, software or applications added to your Product,
Accessory or Software, including but not limited to personal contacts,
games and ringer tones, will be reinstalled. To avoid losing such data,
software and applications please create a back up prior to requesting
service.
How to Obtain Warranty Service or Other
Information
You will receive instructions on how to ship the Products, Accessories or
Software, at your expense, to a Motorola Authorized Repair Center. To
obtain service, you must include: (a) a copy of your receipt, bill of sale or
other comparable proof of purchase; (b) a written description of the
problem; (c) the name of your service provider, if applicable; (d) the
name and location of the installation facility (if applicable) and, most
importantly; (e) your address and telephone number.
What Other Limitations are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR
USA Phones:
1-800-331-6456
Pagers:
1-800-548-9954
Two-Way Radios and Messaging Devices:
1-800-353-2729
Canada All Products:
1-800-461-4575
TTY
1-888-390-6456
For
Accessories
and
Software
, please call the telephone number
designated above for the product with which they are used.
105
Hearing Aids
REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS
THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT
SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE
PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR
FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF
BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR
APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR INABILITY TO USE THE
PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE
DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation
on the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that
vary from state to state or from one jurisdiction to another.
Hearing Aid Compatibility with Mobile Phones
Heari ng Aids
Some Motorola phones are measured for compatibility with hearing
aids. If the box for your particular model has “Rated for Hearing Aids”
printed on it, the following explanation applies.
When some mobile phones are used near some hearing devices
(hearing aids and cochlear implants), users may detect a buzzing,
humming, or whining noise. Some hearing devices are more immune
than others to this interference noise, and phones also vary in the
amount of interference they generate.
The wireless telephone industry has developed ratings for some of their
mobile phones, to assist hearing device users in finding phones that
may be compatible with their hearing devices. Not all phones have been
rated. Phones that are rated have the rating on their box or a label on
the box. To maintain the published Hearing Aid Compatibility (HAC)
rating for this mobile phone, use only the original equipment battery
model.
The ratings are not guarantees. Results will vary depending on the
user’s hearing device and hearing loss. If your hearing device happens to
be vulnerable to interference, you may not be able to use a rated phone
successfully. Trying out the phone with your hearing device is the best
way to evaluate it for your personal needs.
M-Ratings:
Phones rated M3 or M4 meet FCC requirements and are
likely to generate less interference to hearing devices than phones that
are not labeled. M4 is the better/higher of the two ratings.
T-Ratings:
Phones rated T3 or T4 meet FCC requirements and are likely
to be more usable with a hearing device’s telecoil (“T Switch” or
“Telephone Switch”) than unrated phones. T4 is the better/higher of the
two ratings. (Note that not all hearing devices have telecoils in them.)
106
WHO Information
Hearing devices may also be measured for immunity to this type of
interference. Your hearing device manufacturer or hearing health
professional may help you find results for your hearing device. The more
immune your hearing aid is, the less likely you are to experience
interference noise from mobile phones.
Information from the World Health Organization
WHO Information
Present scientific information does not indicate the need for any special
precautions for the use of mobile phones. If you are concerned, you may
want to limit your own or your children’s RF exposure by limiting the
length of calls or by using handsfree devices to keep mobile phones
away from your head and body.
Source: WHO Fact Sheet 193
Further information:
http://www.who.int/peh-emf
Product Registration
Registration
Online Product Registration:
www.motorola.com/us/productregistration
Product registration is an important step toward enjoying your new
Motorola product. Registering permits us to contact you for product or
software updates and allows you to subscribe to updates on new
products or special promotions. Registration is not required for warranty
coverage.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola Personal Communications Product
you will need to provide a copy of your dated sales receipt to confirm
warranty status.
Thank you for choosing a Motorola product.
Export Law Assurances
Export Law
This product is controlled under the export regulations of the United
States of America and Canada. The Governments of the United States
of America and Canada may restrict the exportation or re-exportation of
this product to certain destinations. For further information contact the
107
Recycling Information
U.S. Department of Commerce or the Canadian Department of Foreign
Affairs and International Trade.
Caring for the Environment by Recycling
Recycli ng Informat ion
This symbol on a Motorola product means the product should
not be disposed of with household waste.
Disposal of your Mobile Device &
Accessories
Please do not dispose of mobile devices or electrical
accessories (such as chargers, headsets, or batteries) with
your household waste. Do not dispose of your battery or
mobile device in a fire. These items should be disposed of in accordance
with the national collection and recycling schemes operated by your
local or regional authority. Alternatively, you may return unwanted
mobile devices and electrical accessories to any Motorola Approved
Service Center in your region. Details of Motorola approved national
recycling schemes, and further information on Motorola recycling
activities can be found at:
www.motorola.com/recycling
Disposal of your Mobile Device Packaging
& Product Guide
Product packaging and product guides should only be disposed of in
accordance with national collection and recycling requirements. Please
contact your regional authorities for more details.
California Perchlorate Label
Perchlorat e Label
Some mobile phones use an internal, permanent backup battery on the
printed circuit board that may contain very small amounts of
perchlorate. In such cases, California law requires the following label:
Perchlorate Material – special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate
There is no special handling required by consumers.
032376o
108
Privacy & Data Security
Privacy & Data Security
Priva cy & Data Secu rity
Motorola understands that privacy and data security are important to
everyone. Because some features of your mobile device may affect your
privacy or data security, please follow these recommendations to
enhance protection of your information:
• Monitor access
—Keep your mobile device with you and do
not leave it where others may have unmonitored access. Lock
your device’s keypad where this feature is available.
• Keep software up to date
—If Motorola or a
software/application vendor releases a patch or software fix
for your mobile device that updates the device’s security,
install it as soon as possible.
• Erase before recycling
—Delete personal information or
data from your mobile device prior to disposing of it or turning
it in for recycling. For instructions on how to delete all
personal information from your device, see your product
guide.
Note:
For information on backing up your mobile device data
before erasing it, go to
www.motorola.com
and navigate to
the “downloads” section of the consumer Web page for
“Motorola Backup” or “Motorola Phone Tools.”
• Understanding AGPS
—To provide location information for
emergency calls, certain Motorola mobile devices incorporate
Assisted Global Positioning System (AGPS) technology. AGPS
technology also can be used in non-emergency applications to
track and monitor a user’s location—for example, to provide
driving directions. Users who prefer not to permit such
tracking and monitoring should avoid using such applications.
If you have further questions regarding how the use of your mobile
device may impact your privacy or data security, please contact
Motorola at
privacy@motorola.com
, or contact your service provider.
Smart Practices While Driving
Drivi ng Safety
Drive Safe, Call Smart
Check the laws and regulations on the use of mobile devices
and their accessories in the areas where you drive. Always obey
them. The use of these devices may be prohibited or restricted in
certain areas—for example, handsfree use only. Go to
www.motorola.com/callsmart
(in English only) for more
information.
Your mobile device lets you communicate by voice and data—almost
anywhere, anytime, wherever wireless service is available and safe
conditions allow. When driving a car, driving is your first responsibility.
109
Driving Safety
If you choose to use your mobile device while driving, remember the
following tips:
• Get to know your Motorola mobile device and its
features such as speed dial and redial.
If available, these
features help you to place your call without taking your
attention off the road.
• When available, use a handsfree device.
If possible, add an additional layer of
convenience to your mobile device with one of
the many Motorola Original handsfree
accessories available today.
• Position your mobile device within easy reach.
Be able
to access your mobile device without removing your eyes from
the road. If you receive an incoming call at an inconvenient
time, if possible, let your voicemail answer it for you.
• Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic
or hazardous weather conditions.
Rain, sleet, snow, ice,
and even heavy traffic can be hazardous.
• Do not take notes or look up phone numbers while
driving.
Jotting down a “to do” list or going through your
address book takes attention away from your primary
responsibility—driving safely.
• Dial sensibly and assess the traffic; if possible, place
calls when your car is not moving or before pulling into
traffic.
If you must make a call while moving, dial only a few
numbers, check the road and your mirrors, then continue.
• Do not engage in stressful or emotional conversations
that may be distracting.
Make people you are talking with
aware you are driving and suspend conversations that can
divert your attention away from the road.
• Use your mobile device to call for help.
Dial 911 or other
local emergency number in the case of fire, traffic accident, or
medical emergencies (wherever wireless phone service is
available).
• Use your mobile device to help others in emergencies.
If you see an auto accident, crime in progress, or other serious
emergency where lives are in danger, call 911 or other local
emergency number (wherever wireless phone service is
available), as you would want others to do for you.
• Call roadside assistance or a special non-emergency
wireless assistance number when necessary.
If you see
a broken-down vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call roadside
assistance or other special non-emergency wireless number
(wherever wireless phone service is available).
110
index
index
A
ABC text entry mode 50
accessories 20
Alarm On indicator 18
Alarm Only indicator 17
alarm, set 83
alert
sounds 28
turn off 19
All Sounds Off indicator 17
answer a call 12
applications, download 75
auto retry 39
B
backlight 37
banner 37
battery 10
charging 11
conserving 11, 87
Battery Level indicator 17
Bluetooth connection 85
Bluetooth Connection Active
indicator 18
Bluetooth Power On indicator 18
brightness 38
browser 76
C
cable 61
calculator 84
calendar 82
call
3-way 42
answer 12
end 13
make 12
missed 41
restrict 41
call connect alert 93
call connect tone 30
call drop alerts 92
call drop tone 30
call sounds 28
call timers 45, 46
camera 73
car kit 20
chat 55
111
index
clock
alarm, set 83
alarm, turn off 83
world 84
codes 21, 22, 41
conference calls 42
conserve battery 11
Contacts
assign picture 81
assign ringtone 81
edit entry 79
emergency 78
erase entry 80
favorite 78
send entry 80
set default number 80
speed dial 79
D
dark touch screen 12, 16
Data Call indicator 16
data volume 45
dial a phone number 12
dialed calls 40
display 15
Dormant indicator 16
download
applications 75
copyrighted files 23
games 75
memory 24
music 59
music to your PC 59, 60
pictures 75
ringtone 81
ringtones 75
videos 58
draft message 53
DTMF tones 46
E
E911 indicator 17
earpiece volume 19
email 54
emergency number 43
end a call 13
erase messages 53
event sounds 28
F
favorite contacts 78
G
games, download 75
glossary of icons 16
112
index
H
handsfree speaker 19, 20
haptics. See touch screen
vibrations.
headset 20
hearing aids 47
I
ICE contact 78
icon glossary 16
in case of emergency 78
Internet browser 76
iTAP text entry mode 50
K
keypad volume 29
L
language 36, 38
lens, cleaning 73
linking. See Bluetooth connection
Location On indicator 17
lock
code 22
phone 21
M
main screen 15
make a call 12
megapixels 73
message 51
chat 55
draft 53
email 54
erase 53
Mobile IM 54
sent 53
Message indicator 18
micro-USB cable 61
minute beep 30
Missed Call indicator 18
missed calls 41
Mobile IM 54
music
download 59, 60
playing 64
N
network lost tone 30
network settings 92
New Voicemail indicator 18
No Service indicator 17
notepad 84
number. See phone number
O
optional accessory 8
P
pairing. See Bluetooth connection
phone number 14
phonebook 78
113
index
photo 74
pictures, download 75
power key 12
Power/End key 13
R
received calls 40
recent calls 40
recording 70
redial 39
redial, automatic 39
reset timer 45
restrict calls 41
restriction code 41
ringtones, download 75, 81
roaming alert 93
Roaming indicator 16
S
sent message 53
service alerts 30
service tones 93
set
call connect alert 93
call drop alert 92
roaming alert 93
set alarm 83
Signal Strength indicator 16
soft keys 15
sound clips 70
sound settings 28
sounds, turn off 29
speak keypad digits 30
speakerphone 20
speed dial 79
SSL indicator 16
standalone mode 20
status icon glossary 16
status indicators 16
store your number 14
T
take notes 84
talking phone 30
telephone number. See phone
number
Tethered indicator 16
text entry 48
text message 51
3-way calls 42
timers 45, 46
touch cover 18
touch screen
reactivating 12, 16
tips 6
vibrations 6
TTY indicator 17
turn off alarm clock 83
114
index
turn off sounds 29
turn phone on/off 12
TV
controls 56
ratings 56
shows, watching 56
U
unanswered calls 41
unlock
code 21
phone 21
USB cable 61
V
V CAST
TV 56
videos 58
Vibrate On indicator 17
videos, download 58
Visual Voice Mail 40
Voice Call indicator 17
voice privacy 27
voice readout 30
voice recognition 31
voicemail 40
voicemail message indicator 40
volume 19, 29
W
wallpaper 36
WAP/BREW Application indicator
16
Web access 76
world clock 84
Y
your phone number 14
U.S. patent Re. 34,976
www.motorola.com
