Exhibit 8 Users Manual
APPLICANT: MOTOROLA, INC. FCC ID: IHDT56CL1
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:
DIGITAL WIRELESS
TELEPHONE
User's Guide >
1
PRELIMINARY
Welcome
Earpiece
USB Connector
Insert data cable.
Right Soft Key
Perform functions
identified by right
display prompt.
Menu Key
Open a menu
when
G
appears.
Power/End Key
Press & hold to
turn phone on &
off.
Press & release to
end phone calls,
exit menu.
Send/Answer Key
Make and answer
calls; press in idle
to see recent
dialed calls.
Navigation Key
Scroll through lists,
set volume.
Left Soft Key
Perform functions
identified by left
display prompt.
Microphone
Headset ConnectorPower Connector
Insert charger.
You can change your C330 Series phone’s covers and keypads
(see “Changing Your Phone’s Cover” on page 13). Your phone may
not appear exactly as the phone image above.
All key locations, sequences and functions remain the same with
any of the various covers.
2
PRELIMINARY
Personal Communications Sector
600 North U.S. Highway 45
Libertyville, Illinois 60048
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States)
1-800-461-4575 (Canada)
www.motorola.com
(United States)
www.motorola.ca
(Canada)
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. All other product or service names are the property of
their respective owners. TrueSync, Sidekick, Starfish and the Stylized
Starfish Logo are registered trademarks of Starfish Software, Inc., a
wholly owned independent subsidiary of Motorola, Inc.
© Motorola, Inc. 2002.
Software Copyright Notice
The Motorola products described in this manual may include copyrighted
Motorola and third party software stored in semiconductor memories or
other media. Laws in the United States and other countries preserve for
Motorola and third party software providers certain exclusive rights for
copyrighted software, such as the exclusive rights to distribute or
reproduce the copyrighted software. Accordingly, any copyrighted
software contained in the Motorola products may not be modified,
reverse-engineered, distributed, or reproduced in any manner to the
extent allowed by law. Furthermore, the purchase of the Motorola
products shall not be deemed to grant either directly or by implication,
estoppel, or otherwise, any license under the copyrights, patents, or
patent applications of Motorola or any third party software provider,
except for the normal, non-exclusive, royalty-free license to use that
arises by operation of law in the sale of a product.
Manual number: 6809451A61-O
Cover number: 8988485L49-O
3
PRELIMINARY
Contents
Safety and General Information
. . . . . . . . . . . . . . . . . . . . 6
Getting Started
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
What’s in the Box?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Changing Your Phone’s Cover. . . . . . . . . . . . . . . . . . . . 13
Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . . 18
Adjusting the Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . 20
Learning to Use Your Phone
. . . . . . . . . . . . . . . . . . . . . 21
Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Using the 4-Way Navigation Key . . . . . . . . . . . . . . . . . . 23
Using Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Locking and Unlocking Your Phone. . . . . . . . . . . . . . . . 35
Changing a Code or Password . . . . . . . . . . . . . . . . . . . 37
If You Forget a Code or Password. . . . . . . . . . . . . . . . . 37
Locking and Unlocking the Keypad . . . . . . . . . . . . . . . . 38
Setting Up Your Phone
. . . . . . . . . . . . . . . . . . . . . . . . . . 39
Storing Your Name and Phone Number . . . . . . . . . . . . 39
Setting the Time and Date. . . . . . . . . . . . . . . . . . . . . . . 39
Setting a Ring Style. . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Setting Answer Options. . . . . . . . . . . . . . . . . . . . . . . . . 40
Setting a Screen Saver Image . . . . . . . . . . . . . . . . . . . 41
4
PRELIMINARY
Zooming In and Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Setting Display Contrast . . . . . . . . . . . . . . . . . . . . . . . . . 42
Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Calling Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Changing the Active Line . . . . . . . . . . . . . . . . . . . . . . . . 43
Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Using Automatic Redial. . . . . . . . . . . . . . . . . . . . . . . . . . 43
Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . . . . 44
Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Calling an Emergency Number. . . . . . . . . . . . . . . . . . . . 45
Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . . 47
Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Attaching a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Calling With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . 49
Calling With One-Touch Dial . . . . . . . . . . . . . . . . . . . . . . 49
Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Muting the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Using Call Waiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Phone Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Feature Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . 55
Specific Absorption Rate Data
. . . . . . . . . . . . . . . . . . . . 64
Additional Health and Safety Information
. . . . . . . . . . . 66
Warranty
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Product Registration
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Export Law Assurances
. . . . . . . . . . . . . . . . . . . . . . . . . . 79
Index
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Wireless Phone Safety Tips
. . . . . . . . . . . . . . . . . . . . . . . 89
5
PRELIMINARY
6
PRELIMINARY
Safety and General
Information
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION.
READ THIS INFORMATION BEFORE USING YOUR PHONE.
The information provided in this document supersedes the general safety
information contained in user guides published prior to July 2000. For
information regarding radio use in a hazardous atmosphere please refer
to the Factory Mutual (FM) Approval Manual Supplement or Instruction
Card, which is included with radio models that offer this capability.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
RF Operational Characteristics
Your phone contains a transmitter and a receiver. When it is ON, it
receives and transmits radio frequency (RF) energy. The phone operates
in the frequency range of ___ MHz to ___ MHz in digital mode.
When you communicate with your phone, the system handling your call
controls the power levels at which your phone transmits. The output
power level typically may vary over a range from ___ watts to___ watts in
digital mode.
Exposure To Radio Frequency Energy
Your Motorola phone is designed to comply with the following national
and international standards and guidelines regarding exposure of human
beings to radio frequency electromagnetic energy:
•
United States Federal Communications Commission, Code of
Regulations; 47 CFR part 2 sub-part J
7
PRELIMINARY
•
American National Standards Institute (ANSI) / Institute of Electrical
and Electronic Engineers (IEEE) C95. 1-1992
•
Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999
Edition
•
National Council on Radiation Protection and Measurements
(NCRP) of the United States, Report 86, 1986
•
International Commission on Non-Ionizing Radiation Protection
(ICNIRP) 1998
•
Ministry of Health (Canada) Safety Code 6. Limits of Human
Exposure to Radiofrequency Electromagnetic Fields in the
Frequency Range from 3 kHz to 300 GHz, 1999
•
Australian Communications Authority Radiocommunications
(Electromagnetic Radiation-Human Exposure) Standard 1999
To assure optimal phone performance and make sure human exposure to
radio frequency electromagnetic energy is within the guidelines set forth
in the above standards, always adhere to the following procedures:
Portable Phone Operation and EME Exposure
Antenna Care
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage the
phone and may violate FCC regulations.
Do NOT hold the antenna when the phone is in use.
Holding the
antenna affects call quality and may cause the phone to operate at a
higher power level than needed.
Phone Operation
When placing or receiving a phone call, hold your phone as you would a
wireline telephone.
Speak directly into the microphone.
8
PRELIMINARY
Body-Worn Operation
To maintain compliance with FCC/Health Canada RF exposure
guidelines, if you wear a phone on your body when transmitting, always
place the phone in a Motorola-supplied or approved clip, holder, holster,
case, or body harness for this product. Use of non-Motorola-approved
accessories may exceed FCC/Health Canada RF exposure guidelines. If
you do not use one of the Motorola-supplied or approved body-worn
accessories, and are not using the phone held in the normal use position,
ensure the phone and its antenna are at least one inch
(2.5 centimeters) from your body when transmitting.
Data Operation
When using any data feature of the phone, with or without an accessory
cable,
position the phone and its antenna at least one inch
(2.5 centimeters) from your body.
Approved Accessories
For a list of approved Motorola accessories, visit our website at
www.mot.com
.
Electromagnetic Interference/Compatibility
Note:
Nearly every electronic device is susceptible to electromagnetic
interference (EMI) if inadequately shielded, designed, or otherwise
configured for electromagnetic compatibility.
Facilities
To avoid electromagnetic interference and/or compatibility conflicts, turn
off your phone in any facility where posted notices instruct you to do so.
Hospitals or health care facilities may be using equipment that is sensitive
to external RF energy.
Aircraft
When instructed to do so, turn off your phone when on board an aircraft.
Any use of a phone must be in accordance with applicable regulations per
airline crew instructions.
9
PRELIMINARY
Medical Devices
Pacemakers
The Advanced Medical Technology Association recommends that a
minimum separation of 6 inches (15 centimeters) be maintained between
a handheld wireless phone and a pacemaker. These recommendations
are consistent with the independent research by, and recommendations
of, the United States Food and Drug Administration.
Persons with pacemakers should:
•
ALWAYS keep the phone more than six inches (15 centimeters)
from your pacemaker when the phone is turned ON.
•
NOT carry the phone in the breast pocket.
•
use the ear opposite the pacemaker to minimize the potential for
interference.
•
turn OFF the phone immediately if you have any reason to suspect
that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing aid
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of
your device to determine if it is adequately shielded from RF energy. Your
physician may be able to assist you in obtaining this information.
Safety and General Use While Driving
Check the laws and regulations on the use of phones in the area where
you drive. Always obey them.
When using your phone while driving, please:
•
give full attention to driving and to the road.
•
use hands-free operation, if available.
10
PRELIMINARY
•
pull off the road and park before making or answering a call if driving
conditions so require.
Operational Warnings
For Vehicles With an Air Bag
Do not place a portable phone in the area over an air bag or in the air bag
deployment area. Air bags inflate with great force. If a portable phone is
placed in the air bag deployment area and the air bag inflates, the phone
may be propelled with great force and cause serious injury to occupants
of the vehicle.
Potentially Explosive Atmospheres
Turn off your phone prior to entering any area with a potentially explosive
atmosphere, unless the phone is a model specifically identified as being
“Intrinsically Safe.” Do not remove, install, or charge batteries in such
areas. Sparks in a potentially explosive atmosphere can cause an
explosion or fire resulting in bodily injury or even death.
Note:
The areas with potentially explosive atmospheres referred to above
include fueling areas such as below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air contains chemicals or
particles, such as grain, dust, or metal powders, and any other area
where you would normally be advised to turn off your vehicle engine.
Areas with potentially explosive atmospheres are often but not always
posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn OFF your
phone when you are near electrical blasting caps, in a blasting area, or in
areas posted: “Turn off two-way radio.” Obey all signs and instructions.
11
PRELIMINARY
Operational Cautions
Antennas
Do not use any portable phone that has a damaged antenna.
If a
damaged antenna comes into contact with your skin, a minor burn can
result.
Batteries
All batteries can cause property damage and/or bodily injury such as
burns if a conductive material such as jewelry, keys, or beaded chains
touches exposed terminals. The conductive material may complete an
electrical circuit (short circuit) and become quite hot. Exercise care in
handling any charged battery, particularly when placing it inside a pocket,
purse, or other container with metal objects.
12
PRELIMINARY
Getting Started
Getting Started
What’s in the Box?
Your wireless phone typically comes with a battery and
a charger. Optional accessories can customize your phone
for maximum performance and portability.
To purchase Motorola Original™ accessories, call the
Motorola Customer Call Center at 1-800-331-6456 in the
United States or 1-800-461-4575 in Canada.
About this Guide
This user guide introduces you to your Motorola wireless
phone and shows you how use its features.
To obtain another copy of this user guide, see the
Motorola Web site at:
http://motorola.com/consumer/manuals
or contact the Motorola Customer Call Center at
1-800-331-6456 in the United States or 1-800-461-4575 in
Canada.
Optional Features
This label identifies an optional network or
subscription-dependent feature that may not be
offered by all service providers in all
geographical areas. Contact your service
provider for more information.
13
PRELIMINARY
Getting Started
Optional Accessories
This label identifies a feature that requires an
optional Motorola Original™ accessory.
Changing Your Phone’s Cover
Note:
Since you can change your C330 Series phone’s
covers and keypads, it may not appear exactly as the
phone pictured. All key locations, sequences, and
functions remain the same with any of the covers.
To Remove a Cover and Keypad
1
Press down on the
cover release
button at the top of
your phone.
2
Pull the top of the
phone’s back
cover to release it.
Note:
If the cover
has a removable
side band, remove
it at this point.
Release
button
12
Side
band
14
PRELIMINARY
Getting Started
Note:
Always use Motorola Original™ covers. The
phone warranty does not cover damage caused
from using non-Motorola accessories.
Always use the keypad and side band (if applicable) that
matches the new cover.
3
Pull the side tabs
away from the
phone, then
4
Lift up on the
bottom of the
phone to pull it out
of the front cover.
To Install a Cover and Keypad
Note:
If your phone has an end cap, install it before
attaching the front cover.
1
Place the keypad
in the new front
cover and slide the
top of the phone
into the top of the
new front cover.
2
Press the bottom of the phone into the front
cover until the side tabs snap into place.
Note:
If the cover has a removable side band,
attach it at this point.
To Remove a Cover and Keypad
Side tabs
3
4
1
2
15
PRELIMINARY
Getting Started
Installing the Battery
Install and charge the battery before you use your phone.
Your phone is designed to be used only with
Motorola Original batteries and accessories. We
recommend that you store batteries in their
protective cases when not in use.
3
Insert the bottom
of the back cover.
4
Press the top of
the back cover
down until it hooks
over the cover
release button.
To Install the Battery
1
Remove the phone’s back cover as described in
“Changing Your Phone’s Cover” on page 13.
2
Remove the battery from its protective clear
plastic case.
3
Insert the battery,
printed arrow first,
under the tabs
at
the top of the
battery
compartment and
push down.
To Install a Cover and Keypad
3
4
16
PRELIMINARY
Getting Started
Charging the Battery
Before you can use your phone, fully charge the
battery as follows. Some batteries perform best after
several full charge/discharge cycles.
When you charge the battery, the battery level indicator in
the upper right corner of the display shows how much of
the charging process is complete. See “Battery Level
Indicator” on page 21.
Battery Use
Caution:
To prevent injuries or burns, do not allow metal
objects to contact or short-circuit the battery terminals.
4
Replace the phone’s cover.
To Charge the Battery
1
Plug the charger
into the left jack
on the bottom of
your phone.
2
Plug the other end of the charger into the
appropriate electrical outlet.
3
When your phone indicates
Charge Complete
,
remove the charger.
To Install the Battery
17
PRELIMINARY
Getting Started
To maximize battery performance:
•
Always use Motorola Original™ battery chargers. The
phone warranty does not cover damage caused
from using non-Motorola battery chargers.
•
New batteries or batteries that have been stored
for a long time may require a longer initial charge
time.
•
Keep the battery at or near room temperature when
charging.
•
Do not expose batteries to temperatures below -10° C
(14° F) or above 45° C (113° F). Always take your
phone with you when you leave your vehicle.
•
When you do not intend to use a battery for a while,
store it uncharged in a cool, dark, dry place, such as a
refrigerator.
•
Over time, batteries gradually wear down and require
longer charging times. This is normal. If you charge
your battery regularly and notice a decrease in talk
time or an increase in charging time, then it is
probably time to buy a new battery.
The rechargeable batteries that power this
product must be disposed of properly and may
need to be recycled. Refer to your battery’s label
for battery type. Contact your local recycling center for
proper disposal methods. Never dispose of batteries in a
fire because they may explode.
18
PRELIMINARY
Getting Started
Extending Battery Life
• Turn off the screen saver
See page 41.
• Minimize keypad-intense functions
Activities that require intensive keystrokes (such
as playing a game or using messaging) reduce your
phone’s talk and standby time. Lock the keypad when
storing the phone in your purse or pocket to avoid
unnecessary keypad and backlight activations. See
page 38.
• Turn off the display backlight
See page 42.
Turning Your Phone On
To Turn Your Phone On
1
Press and hold
O
(the
End/Power key)
2
If necessary, enter your four-digit unlock code
and press
OK
(
+
) to unlock your phone
Note:
The unlock code is originally set to 1234.
(For more information, see “Locking and
Unlocking Your Phone” on page 35.)
End/
Power Key
19
PRELIMINARY
Getting Started
Adjusting the Volume
Press right and left on the
S
to:
•
increase or decrease earpiece volume during a
call
•
increase or decrease the ringer volume setting
when the idle display is visible
Tip:
At the lowest volume setting, press
S
down to
activate silent alert. Press up to reset ring alert.
•
Turn off an incoming call alert
Making a Call
Do not block the antenna while you are on a call.
Press To
1
keypad keys dial the phone number
Tip:
If you make a mistake,
press
DELETE
(
-
) to delete
the last digit, or press and
hold
DELETE
(
-
) to clear all
digits.
2
N
make the call
3
O
end the call and “hang up” the
phone when you are finished
20
PRELIMINARY
Getting Started
Answering a Call
When you receive a call, your phone rings and/or
vibrates and displays an incoming call message.
Note:
If the phone is locked, unlock it to answer the call.
Viewing Your Phone Number
Press
M#
to view your number from idle. While you are
on a call, press
M
>
My Tel. Numbers
.
Press To
1
N
or
ANSWER
(
+
)
answer the call
2
O
end the call and “hang up” the
phone when you are finished
21
PRELIMINARY
Learning to Use Your Phone
Learning to Use Your
Phone
See page 1 for a basic phone diagram.
Using the Display
The idle display (shown below) is the standard display
when you are not on a call or using the menu.
The
G
(menu) indicator at the bottom center of the display
indicates you can press the menu key (
M
) to go to the
main menu to see more features.
Labels at the bottom corners of the display show the
current soft key functions. Press the left soft key (
-
) or
right soft key (
+
) to perform the function indicated by the
left or right soft key label.
12:00
E
PH.BOOK MESSAGE
U;gf
59ã
YJ
G
Clock
Menu Indicator
Soft Key Labels
22
PRELIMINARY
Learning to Use Your Phone
At the top of the display are a number of status indicators:
➊
Signal Strength Indicator
Vertical bars show the
strength of the network connection. You cannot make or
receive calls when the
0
(no signal) indicator is displayed.
➋
Digital or Analog Signal Indicator
Shows
whether you are receiving a digital or analog
signal.
➌
In Use Indicator
Shows that a call is in progress.
➍
Roam Indicator
Shows that your phone is
seeking or using another network system
outside your home network.
➎
Message Waiting Indicator
Displays when
you receive a text message.
12:00
E
PH.BOOK MESSAGE
U;gf
59ã
YJ
G
➐
Battery
Level
Indicator
➌
In Use
Indicator
➍
Roam
Indicator
➎
Message
Waiting
Indicator
➏
Voice
Message
Waiting
Indicator
➓
Ring Style Indicator
➊
Signal
Strength
Indicator
➋
Digital/
Analog
Signal
Indicator
➑
Active
Line
Indicator
➒
ALI Indicator
23
PRELIMINARY
Learning to Use Your Phone
➏
Voice Message Waiting Indicator
Appears
when you receive a voicemail message.
➒
ALI Indicator
Shows the status of the automatic
location information feature:
➐
Battery Level Indicator
Vertical bars show the
battery charge level. Recharge the battery when you
see
Low Battery
and hear the low battery alert.
➑
Active Line Indicator
Shows the current
active phone line.
➓
Ring Style Indicator
Shows the ring style setting.
Using the 4-Way
Navigation Key
Use the 4-way navigation key
like a joystick to navigate the
menu system, change feature
settings, and play games.
Tip:
Down and up are the primary movements within
menus. Move left and right to change feature settings,
navigate the datebook, and edit text.
ã
=ALI on
ä
=ALI off
Y
=loud
X
=soft
W
=vibrate
Z
= vibrate and ring
a
= silent
4-way
navigation
key
24
PRELIMINARY
Learning to Use Your Phone
Using Menus
From the idle display, press
M
to display the main menu.
Select a Menu Feature
From the idle display, select a menu feature as follows:
This example shows that from the idle display, you must
press
M
, scroll to and select
Messages
from the main
Find the Feature
M
>
Messages
>
Create Message
Right Soft Key
Perform
functions
identified by
right display
prompt.
Menu Key
Power/End Key
Press & hold to
power phone
on & off.
Press &
release to end
phone calls
and exit
menus.
Send/Answer
Key
Make and
answer calls &
view recent
dialed calls.
Navigation Key
Scroll through
menus and
lists, and set
feature values.
Left Soft Key
Perform
functions
identified by
left display
prompt.
25
PRELIMINARY
Learning to Use Your Phone
menu, then scroll to and select
Create Message
. Use
S
to scroll, and the left/right soft keys to select the functions
listed in the bottom left and right corners of the display.
Select a Feature Option
Some features require you to select an item from a list:
•
Press
S
to scroll up or down to highlight an item.
•
In a numbered list, press a number key to highlight the
item.
•
In an alphabetized list, press a key repeatedly to cycle
through the letters on the key and highlight the closest
matching list item.
•
When an item has a list of possible values, press
S
to the left or right to scroll and select a value.
•
When an item has a list of possible numeric values,
press a number key to set the value.
Dialed Calls
10)John Smith
9)Mary Smith
BACK VIEW
59
G
Press
BACK
(
-
)
to display
the previous
screen.
Press
M
to
open the sub-menu.
Highlighted
item
Press
VIEW
(
+
) to display
details for the highlighted item
26
PRELIMINARY
Learning to Use Your Phone
Entering Text
Some features require you to enter information:
The message center lets you compose and send text
messages. A flashing cursor shows where text will appear:
Entry Details
Name:_____________
No.:_______________
CANCEL CHANGE
Press
S
to
scroll down.
Press
CANCEL
(
-
) to exit
without making changes.
DONE
(
-
) displays when
you enter or edit information.
Press
CHANGE
(
+
)
to edit the
information.
Highlighted
item
59
G
Msg:
CANCEL INSERT
Press
INSERT
(
+
)
to view and
insert a
quick note.
Press
CANCEL
(
-
) to exit
without making changes.
Flashing
cursor
Press
M
to open
the sub-menu.
59
G
27
PRELIMINARY
Learning to Use Your Phone
When you enter text using the standard tap method (see
page 28), the flashing cursor changes to a block cursor,
and the soft key functions change:
Choosing a Text Mode
Multiple text entry modes make it easy for you to enter
names, numbers, and messages.
Press
M
from any text entry screen to select a text mode:
iTAP
(
é
)
Let the phone predict each word as you
enter it (see page 30).
Tap Method
(
t
)
Enter letters, numbers, and symbols by
pressing a key one or more times (see
page 28).
Numeric
(
è
)
Enter numbers only.
Symbol
(
ê
)
Enter symbols only (see page 34).
Browse
Browse your phonebook or recent call
lists to select a name or number.
Msg:
T
CANCEL OK
Press
OK
(
+
)
to accept
and store
the text.
Press
DELETE
(
-
)
to clear the last letter.
Block
cursor
indicates
current
highlighted
character.
After 2 seconds, the block
cursor reverts to a flashing
cursor and moves to the
next position.
59
G
28
PRELIMINARY
Learning to Use Your Phone
Note:
The text mode you select remains active until you
select another mode.
Using Tap Method
This is the standard mode for entering text on your phone.
Press
M
from a text entry screen and select
Tap Method
.
Tap Method Text Entry Rules
•
Press a number key repeatedly to cycle through its
characters. See “Character Chart” on page 30.
•
If you do not press a key for 2 seconds, the character
in the block cursor is accepted, and the cursor moves
to the next position.
•
Press
S
left or right to move the flashing cursor to
the left or right in a text message.
•
The first character of every sentence is capitalized.
Press
S
down to force the character to lowercase
while it is highlighted by the block cursor.
Press To
1
A number key 1
or more times
select a letter, number, or
symbol shown in the
“Character Chart” on page 30
2
Number keys enter the remaining
characters
3
OK
(
+
) store the text
29
PRELIMINARY
Learning to Use Your Phone
•
Your phone may support multiple languages. The
current language setting determines whether a new
message begins on the left or right side of the display.
You can switch languages within a message. Press
M
to select the text mode and language you want to
use.
•
If you enter or edit information and do not want to
save your changes, press
O
to exit without
saving.
•
Press and hold a number key to cycle between tap
method and numeric text entry mode.
30
PRELIMINARY
Learning to Use Your Phone
Character Chart
Use this chart as a guide for entering characters with the
tap method.
Note:
This chart may not reflect the exact character set
available on your phone.
Using iTAP™ Software Text Entry Method
iTAP™ software is a predictive text entry method that lets
you enter a word using one keypress per letter.
Press
M
from any text entry screen and select
iTAP
.
Note:
You can switch languages within a message in iTAP
text mode. Press
M
to select the language.
1
space . 1 ? ! , @ _ & ~ : ; " -
( ) ' ¿ ¡ % £ $ ¥
2
a b c 2 ä å á à â ã
α
β
ç
3
d e f 3
δ
ë é è ê
ε
φ
4
g h i 4 ï í î
γ
η
ι
5
j k l 5
κ
λ
6
m n o 6 ñ ö ø ó ò ô õ
µ
υ
ω
7
p q r s 7
π
ß
σ
8
t u v 8
θ
ü ú ù û
τ
9
w x y z 9
ξ ψ
0
+ - 0 x * / \ [ ] = > < # §
31
PRELIMINARY
Learning to Use Your Phone
Entering Words
Do This To
1
Press a number
key one time
enter the first letter of the
word
The letters associated with
the key are shown at the
bottom of the display.
2
Press number
keys (one per
letter)
enter the rest of the word
Alternative words and letter
combinations are shown at
the bottom of the display. The
word choices are updated
with each keypress.
3
Press
S
highlight the word you want
4
Press
SELECT
(
+
)
enter the word at the flashing
cursor
A space is automatically
inserted after the word.
32
PRELIMINARY
Learning to Use Your Phone
For example, to spell the word “act,” press
2
2
8
.
The display shows:
Entering Novel Words
If the word you want is not displayed by the iTAP software:
Do This To
1
Press
DELETE
(
-
)
one or more times
delete letters until you
see a letter combination
that matches the start of
the word
2
Press
S
left or right highlight the letter or
letter combination
3
Press
SELECT
(
+
),
then press
S
to the
left
shift the cursor to the left
and “lock” the selected
word portion
4
Continue to enter
letters and highlight
letter combinations
spell the word
Act
Cat Bat Abu
c
DELETE SELECT
Press
SELECT
(
+
) to
insert the highlighted word.
Press
DELETE
(
-
)
to clear the last letter.
Flashing
cursor
indicates
insertion
point.
Press
S
to
see additional
word choices.
59
G
33
PRELIMINARY
Learning to Use Your Phone
Entering Punctuation
Using Capitalization
The first word of a sentence is automatically
capitalized, with the words that follow in lowercase.
Entering Numbers
Press To
0
or
1
enter punctuation or other
characters (see “Character
Chart” on page 30).
Press To
S
up or down change the words to initial
character capitalized, all
uppercase characters, or all
lowercase characters
Do This To
1
Enter the first
digit and then
highlight it
put the iTAP software in
number entry mode
2
Press number
keys
add digits to the number
3
Press
SELECT
(
+
)
enter the number
34
PRELIMINARY
Learning to Use Your Phone
Deleting Letters and Words
Place the cursor to the right of the text you want to delete,
and then:
Using Symbol Mode
To enter symbol characters in a message, press
M
from any text entry screen and select
Symbol
.
Do This To
Press
DELETE
(
-
) delete one letter at a time
Hold
DELETE
(
-
) delete the entire message
Do This To
1
Press a number
key one time
display its symbol options at
the bottom of the display
See “Symbol Chart” on
page 35.
2
Press
S
or
Press the
number key
repeatedly
highlight the symbol you want
3
Press
SELECT
(
+
)
enter the symbol
35
PRELIMINARY
Learning to Use Your Phone
Symbol Chart
Use this chart as a guide for entering characters in symbol
mode.
Locking and Unlocking Your
Phone
You can lock your phone manually or set the phone to lock
automatically whenever you turn it off.
A locked phone still rings or vibrates for incoming calls or
messages, but you must unlock it to answer. To use a
locked phone, enter the unlock code.
You can make emergency calls on your phone even when
it is locked. For more information, see page 45.
1
space . ? ! , @ _ &
~ : ; " - ( ) ' ¿ ¡ %
£ $ ¥
2
@ _ \
3
/ : ;
4
" & '
5
( ) [ ] { }
6
¿ ¡ ~
7
< > =
8
$ £ ¥
9
# % *
0
+ - x * / = > < # §
36
PRELIMINARY
Learning to Use Your Phone
Lock Your Phone Manually
Unlock Your Phone
Tip:
Your phone’s unlock code is set to 1234 at the
factory. Many service providers reset the unlock code to
the last four digits of your phone number.
At the
Enter Unlock Code
prompt:
Set Your Phone to Lock Automatically
You can set your phone to lock every time you turn it off.
Find the Feature
M
>
Settings
>
Security
>
Phone Lock
>
Lock Now
Press To
1
keypad keys enter your unlock code
2
OK
(
+
) lock the phone
Press To
1
keypad keys enter your unlock code
2
OK
(
+
) unlock your phone
Find the Feature
M
>
Settings
>
Security
>
Phone Lock
>
Automatic Lock
>
On
Press To
1
keypad keys enter your unlock code
2
OK
(
+
) activate automatic lock
37
PRELIMINARY
Learning to Use Your Phone
Changing a Code or Password
Your phone’s four-digit unlock code is set to 1234, and the
six-digit security code is set to 000000 at the factory. Your
service provider may reset these numbers before you
receive your phone.
If your service provider has not reset these numbers, we
recommend that you change them to prevent others from
accessing your personal information. The unlock code
must contain four digits, and the security code must
contain six digits.
To change a code or password:
If You Forget a Code or
Password
If you forget your security code, contact your service
provider.
If you forget your unlock code, try entering 1234 or the last
four digits of your phone number. If that does not work, at
the
Enter Unlock Code
prompt:
Find the Feature
M
>
Settings
>
Security
>
New Passwords
Press To
1
M
display the unlock code
bypass screen
2
keypad keys enter your security code
3
OK
(
+
) submit your security code
38
PRELIMINARY
Learning to Use Your Phone
Locking and Unlocking the
Keypad
You can lock the keypad to prevent accidental keypresses
(for example, when carrying your phone in a purse or
pocket).
Note:
Incoming calls and messages unlock the
keypad.
Press To
M*
lock or unlock your keypad
39
PRELIMINARY
Setting Up Your Phone
Setting Up Your
Phone
Storing Your Name and Phone
Number
To store or edit the name and phone number
information on your phone:
Setting the Time and Date
To use the datebook, you must set the time and date.
Setting a Ring Style
Your phone rings or vibrates to notify you of an incoming
call or other event. This ring or vibration is called an alert.
You can select one of five different ring styles:
Find the Feature
M
>
Settings
>
Phone Status
>
My Tel. Numbers
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Time and Date
Y
= loud
X
=soft
40
PRELIMINARY
Setting Up Your Phone
The ring style indicator in the display shows the current
ring style (see page 22).
To set a ring style:
Each ring style contains settings for specific event
alerts, ringer ID, and ringer and keypad volume.
To change these settings:
Setting Answer Options
You can use different methods to answer an incoming call.
The
Answer Options
menu includes:
W
=vibrate
Z
= vibrate and ring
A
= silent
Find the Feature
M
>
Settings
>
Ring Styles
>
Style
Press To
1
S
scroll to the ring style
2
SELECT
(
+
) select the ring style
Find the Feature
M
>
Settings
>
Ring Styles
>Style
Detail
Find the Feature
M
>
Settings
>
In-Call Setup
>
Answer Options
Multi-Key
answer by pressing any key
41
PRELIMINARY
Setting Up Your Phone
Setting a Screen Saver Image
You can set a picture or an animation as a screen saver
image. The image displays when the phone detects no
activity for a specified time.
The screen saver image is shrunk to fill the display, if
necessary. An animation repeats for one minute, then the
first frame of the animation displays.
Note:
The screen saver displays only when your phone is
open.
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Screen Saver
Press To
1
S
scroll to
2
CHANGE
(
+
) open the picture viewer
3
S
up or down scroll to a picture/animation
Scroll to
(None)
to turn off the
screen saver image.
4
SELECT
(
+
) select the image
5
S
scroll to
Delay
6
CHANGE
(
+
) set the delay interval
7
S
scroll to the inactivity interval
that triggers the screen saver
8
SELECT
(
+
) confirm the delay setting
9
DONE
(
-
) save the screen saver
settings
42
PRELIMINARY
Setting Up Your Phone
Zooming In and Out
Press and release
M
, then press and hold
M
to zoom in
and out on the display. Zoom in to increase text size, zoom
out to display more information.
You can also zoom in and out from the menu:
Setting Display Contrast
Adjusting the Backlight
You can set the amount of time that the display backlight
remains on, or turn off the backlight to conserve battery
power.
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Zoom
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Contrast
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Backlight
43
PRELIMINARY
Calling Features
Calling Features
For basic instructions on how to make and answer calls,
see page 19.
Changing the Active Line
Change the active phone line to make and
receive calls from your other phone number.
The active line indicator in the display shows the current
active phone line (see page 22).
Redialing a Number
If you hear an ordinary busy signal:
Using Automatic Redial
If the network is busy, you hear a fast busy signal, and
your phone displays
Call Failed
.
Find the Feature
M
>
Settings
>
Phone Status
>
Active Line
Press To
1
O
hang up
2
N
redial the busy number
44
PRELIMINARY
Calling Features
With automatic redial, your phone automatically redials the
number for four minutes. When the call goes through, your
phone rings or vibrates one time, displays
Redial Successful
, and then connects the call.
You must turn on automatic redial to use the feature. To
turn automatic redial on or off:
When automatic redial is turned off, you can manually
activate the feature to redial a phone number. When you
hear a fast busy signal and see
Call Failed
:
Using Caller ID
Calling line identification (caller ID) displays
the phone number for incoming calls.
The phone displays the caller’s name when
the name is stored in your phonebook, or
Incoming Call
when caller ID information is not available.
Canceling an Incoming Call
While the phone is ringing or vibrating:
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Auto Redial
Press To
N
or
RETRY
(
+
)activate automatic redial
Press To
O
or
IGNORE
(
-
) cancel the incoming call
45
PRELIMINARY
Calling Features
Depending on your phone settings and/or
service subscription, the call may be forwarded
to another number, or the caller may hear a
busy signal.
Turning Off a Call Alert
You can turn off your phone’s incoming call alert before
answering the call.
Calling an Emergency Number
Your service provider programs one or more emergency
phone numbers, such as 911, that you can call under any
circumstances, even when your phone is locked.
Note:
Emergency numbers vary by country. Your phone’s
preprogrammed emergency number(s) may not work in all
locations, and sometimes an emergency call cannot be
placed due to network, environmental, or interference
issues.
Viewing Recent Calls
Your phone keeps a list of the calls you recently received
and dialed, even if the calls did not connect. The lists are
Press To
S
up or down turn off the alert
Press To
1
keypad keys dial the emergency number
2
N
call the emergency number
46
PRELIMINARY
Calling Features
sorted from newest to oldest, and contain up to 10 entries.
The oldest entries are deleted as new ones are added.
Shortcut:
From the idle display, press
N
to display the
dialed calls list.
Find the Feature
M
>
Recent Calls
Press To
1
S
scroll to
Received Calls
or
Dialed Calls
2
SELECT
(
+
) select the list
3
S
scroll to an entry
Note:
\
means the call
connected.
4
N
or
VIEW
(
+
)
or
M
call the entry’s number
Tip:
Press and hold
N
for
2 seconds to send the
number as DTMF tones
during a call.
view entry details
open the
Last Calls
menu to
display other options as
described in the following list
47
PRELIMINARY
Calling Features
The
Last Calls
menu can include the following options:
Returning an Unanswered
Call
Your phone keeps a record of your unanswered calls,
and displays:
•
the
N
(missed call) indicator
Option Description
Store
Create a phonebook entry with
the number in the
No.
field.
Delete
Delete the entry.
Delete All
Delete all entries in the list.
Send Message
Open a new text message with
the number in the
To
field.
Add Digits
Add digits after the number.
Attach Number
Attach a number from the
phonebook or recent call lists,
after the highlighted number.
Send Tones
Send the number to the network
as DTMF tones.
This option is only available
during a call.
48
PRELIMINARY
Calling Features
•
X Missed Calls
Y Unknown
, where
X
is the total
number of missed calls and
Y
is the number of missed
calls with no caller ID information
Using the Notepad
Your phone stores the most recent number entered on the
keypad in a temporary notepad. This can be a phone
number that you called, or a number that you entered but
did not call. To retrieve the number stored in the notepad:
Press To
1
VIEW
(
+
) see the received calls list
2
S
select a call to return
3
N
make the call
Find the Feature
M
>
Recent Calls
>
Notepad
Press To
N
or
M
or
STORE
(
+
)
call the number
open the
Dialing Menu
to
attach a number or insert a
special character
create a phonebook entry
with the number in the
No.
field
49
PRELIMINARY
Calling Features
Attaching a Number
While dialing (with digits visible in the display):
Calling With Speed Dial
Each entry you store in your phonebook is assigned a
unique speed dial number. To speed dial a phonebook
entry:
Calling With One-Touch Dial
To call phonebook entries 1 through 9, just press and hold
the one-digit speed dial number for 1 second.
We recommend that you reserve phonebook entry 1
(speed dial number 1) for storing and dialing your
Press To
M
>
Attach Number
attach a number from the
phonebook or recent call lists
Press To
1
keypad keys enter the speed dial number
for the entry you want to call
2
#
submit the number
Note:
Some
networks let you
skip this step for
speed dial
numbers 1 through 99.
3
N
call the entry
50
PRELIMINARY
Calling Features
voicemail number. Your service provider may have already
done this for you.
Using Voicemail
You can listen to your voicemail messages by
calling your network voicemail phone number.
Voicemail messages are stored on the
network—not on your phone.
Store Your Voicemail Number
Storing your voicemail number on your phone makes it
easy for you to listen to new voicemail messages. Your
service provider may have already done this for you.
Your service provider may also store your voicemail
number as phonebook entry 1, so you can use
one-touch dial to listen to your voicemail messages. If
necesary, see your reference guide for steps on how to
store your voicemail number as a phonebook entry.
Find the Feature
M
>
Messages
M
>
VoiceMail Setup
Press To
1
keypad keys enter your voicemail number
2
OK
(
+
) store the number
51
PRELIMINARY
Calling Features
Receive a Voicemail Message
When you receive a voicemail message, your phone
displays the
f
(voice message waiting) indicator and a
New VoiceMail
notification.
Listen to a Voicemail Message
The phone calls your voicemail number. If no voicemail
number is stored, your phone prompts you to store one.
Shortcut:
If your voicemail number is also stored as
phonebook entry number 1, you can press and hold
1
to
listen to your voicemail message(s).
Turn Off the Voice Message Waiting
Indicator
To clear the
f
(voice message waiting) indicator:
Muting the Phone
To mute your phone during a call, press
MUTE
(
+
) (if
available) or
M
>
Mute
.
Press To
CALL
(
+
) listen to the message(s)
Find the Feature
M
>
Messages
>
VoiceMail
Find the Feature
M
>
Messages
M
>
Clear Count
52
PRELIMINARY
Calling Features
Using Call Waiting
When you are on a call, an alert tone sounds to
indicate that you have received a second call.
Press To
1
N
answer the new call
2
N
switch back to the first call
53
PRELIMINARY
Phone Features
Phone Features
Main Menu
This is the standard main menu layout.
Menu
organization and feature names may vary on your
phone.
Not all features may be available for all users.
z
Recent Calls
• Received Calls
• Dialed Calls
• Notepad
• Call Times
à
Phonebook
g
Datebook
U
Messages
•Voicemail
• Create Message
•Inbox
• Outbox
• Quick Notes
•Drafts
• Browser Alerts
:
Shortcuts
L
Web Browser
•Home
• Go To URL
•Mark Site
• Reload
• About Openwave
•Advanced
a
Calculator
-
Games
v
Picture Viewer
/
Settings
(see next page)
Shortcuts
Change display zoom:
Press
M
, then
press and hold
M
Change ringer alert:
Press
S
down to
switch to silent alert.
Press up to reset to
ring alert.
Display my phone
number:
Press
M#
Display dialed calls
list:
Press
N
Exit menu system:
Press
O
54
PRELIMINARY
Phone Features
Settings Menu
•Ring Styles
•Style
•Style Detail
• My Tones
• Phone Status
•My Tel. Numbers
• Active Line
• Battery Meter
• Other Information
•Browser Setup
• Connection
• Incoming Call
• In-Call Setup
• In-Call Timer
• Answer Options
• Security
• Phone Lock
• Lock Keypad
• Lock Application
• Restrict Calls
•New Passwords
• Location
• Other Settings
• Personalize
•Main Menu
•Keys
•Greeting
• Screen Saver
• Banner
• Initial Setup
• Time and Date
• Auto PIN Dial
• Auto Redial
• Backlight
•Zoom
• TTY Setup
•Scroll
• Animation
• Language
• Contrast
•DTMF
•Master Reset
• Master Clear
•Network
• Current Network
•Set Mode
•Srvc Status
• Service Tone
• Call Drop Tone
• Car Settings
• Auto Answer
• Auto Handsfree
• Power-Off Delay
•Charger Time
• Headset
55
PRELIMINARY
Phone Features
Feature Quick Reference
You can do more with your phone than make and receive
phone calls! For example, you can:
•
store frequently called numbers in the phonebook for
easy dialing
•
organize your meetings and other events in the
datebook
•
browse the Web
•
download applications
•
send messages, and more.
This section provides information to help you use features
on your phone that are not described in this user guide.
For more detailed information, see the reference guide.
Calling Features
Feature Description
Three-Way
Call
During a call:
Dial third party’s number,
press
N
to call, and then
press
N
again to connect
Restrict
Calls
Restrict outgoing or
incoming calls:
M
>
Settings
>
Security
>
Restrict Calls
56
PRELIMINARY
Phone Features
Message Features
Phonebook Features
TTY Calls
Set up your phone for use
with an optional TTY device:
M
>
Settings
>
Other Settings
>
Initial Setup
>
TTY Setup
Feature Description
Send
Message
Send a text message:
M
>
Messages
>
Create Message
Receive
Message
Read a new text message that you
have received:
Press
READ
(
+
)
Feature Description
Create Entry
Create a new phonebook entry:
M
>
Phonebook
M
>
New
>
Phone Number
or
Email Address
Dial Number
Call a number in the phonebook:
M
>
Phonebook
> entry to call
Voice Dial
Number
Voice dial a number in the
phonebook:
Press and release the voice key, and
say the entry’s name (in 2 seconds)
Feature Description
57
PRELIMINARY
Phone Features
Personalizing Features
Feature Description
Event Alert
Change an event alert:
M
>
Settings
>
Ring Styles
>Style
Detail
> event name
Ring
Volume
Adjust ringer volume:
M
>
Settings
>
Ring Styles
>Style
Detail
>
Ring Volume
Keypad
Volume
Adjust keypad keypress volume:
M
>
Settings
>
Ring Styles
>Style
Detail
>
Key Volume
My Tones
Compose your own ring tones,
manage ring tones that you have
composed or downloaded:
M
>
Settings
>
Ring Styles
>
My Tones
Soft Keys
Change soft key labels in the idle
display:
M
>
Settings
>
Other Settings
>
Personalize
>
Keys
Shortcuts
Create a shortcut to a menu item:
Highlight the menu item, then press
and hold
M
Select a shortcut:
M
>
Shortcuts
> shortcut name
58
PRELIMINARY
Phone Features
Menu Features
Dialing Features
Feature Description
Language
Set menu language:
M
>
Settings
>
Other Settings
>
Initial Setup
>
Language
Master
Reset
Reset all options except unlock code,
security code, lifetime timer:
M
>
Settings
>
Other Settings
>
Initial Setup
>
Master Reset
Master
Clear
Reset all options except unlock code,
security code, lifetime timer, clear all
user settings and entries:
M
>
Settings
>
Other Settings
>
Initial Setup
>
Master Clear
Feature Description
Auto PIN
Dial
Automatically dial an
authenticating PIN code for
outgoing calls:
M
>
Settings
>
Other Settings
>
Initial Setup
>
Auto PIN Dial
59
PRELIMINARY
Phone Features
Call Monitoring Features
DTMF
Tones
Activate DTMF tones:
M
>
Settings
>
Other Settings
>
Initial Setup
>
DTMF
Send DTMF tones during a call:
Press number keys
Send stored numbers as DTMF tones
during a call:
Highlight a number in the phonebook
or recent call lists, then press
M
>
Send Tones
Feature Description
Call Times
View call timers:
M
>
Recent Calls
>
Call Times
In-Call
Timer
Display time or cost
information during a call:
M
>
Settings
>
In-Call Setup
>
In-Call Timer
Feature Description
60
PRELIMINARY
Phone Features
Handsfree Features
Feature Description
Speaker-
phone
Activate a connected external
speakerphone during a call:
Press
SPEAKER
(
+
)
(if available) or
M
>
Spkrphone On
Auto
Answer
(car kit or
headset)
Automatically answer calls
when connected to a car kit or
headset:
M
>
Settings
>
Other Settings
>
Car Settings
or
Headset
>
Auto Answer
Auto
Hands-
Free
(car kit)
Automatically route calls to a
car kit when connected:
M
>
Settings
>
Other Settings
>
Car Settings
>
Auto Handsfree
Power-Off
Delay
(car kit)
Set the phone to stay on for a
period of time after the ignition
is switched off:
M
>
Settings
>
Other Settings
>
Car Settings
>
Power-Off Delay
Charger
Time
(car kit)
Charge the phone for a period
of time after the ignition is
switched off:
M
>
Settings
>
Other Settings
>
Car Settings
>
Charger Time
61
PRELIMINARY
Phone Features
Data and Fax Call Features
Network Features
Personal Organizer Features
Feature Description
Send Data
or Fax
Connect your phone to the
device, then place the call
through the device application
Receive
Data or
Fax
Connect your phone to the
device, then:
M
>
Settings
>
Connection
>
Incoming Call
>
Next Call
>
Data In Only
or
Fax In Only
Reset normal voice operation:
M
>
Settings
>
Connection
>
Incoming Call
>
Next Call
>
Normal
Feature Description
Network
Settings
View network information and
adjust network settings:
M
>
Settings
>
Other Settings
>
Network
Feature Description
Add
Datebook
Event
Add an event to the datebook:
M
>
Datebook
> day
M
>
New
62
PRELIMINARY
Phone Features
Security Features
News and Entertainment Features
View
Datebook
Event
View or edit event details:
M
>
Datebook
> day > event name
Event
Reminder
View event reminder:
VIEW
(
+
)
Dismiss event reminder:
EXIT
(
-
)
Calculator
Calculate numbers:
M
>
Calculator
Currency
Converter
Convert currency:
M
>
Calculator
M
>
Exchange Rate
Enter exchange rate, press
OK
(
+
),
enter amount, select
$
function
Feature Description
Lock
Application
Lock phone applications:
M
>
Settings
>
Security
>
Lock Application
Feature Description
Launch
Micro-
Browser
Start a micro-browser session:
M
>
Web Browser
Feature Description
64
PRELIMINARY
Specific Absorption Rate Data
The Motorola C333 CDMA wireless phone meets the
government’s requirements for exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission (FCC) of the
U.S. Government and by Health Canada for Canada. These limits are
part of comprehensive guidelines and establish permitted levels of RF
energy for the general population. The guidelines are based on standards
that were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC and by Health Canada is 1.6 W/kg.
1
Tests for SAR
are conducted using standard operating positions accepted by the FCC
and by Industry Canada with the phone transmitting at its highest certified
power level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR level of the
phone while operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power levels so as
to use only the power required to reach the network. In general, the closer
you are to a wireless base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S. and
Canada, it must be tested and certified to the FCC and Industry Canada
that it does not exceed the limit established by each government for safe
exposure. The tests are performed in positions and locations (e.g., at the
ear and worn on the body) reported to the FCC and available for review
by Industry Canada. The highest SAR value for this model phone when
tested for use at the ear is ____ W/kg and when worn on the body, as
described in this user guide, is _____ W/kg. (Body-worn measurements
65
PRELIMINARY
differ among phone models, depending upon available accessories and
regulatory requirements).
2
While there may be differences between the SAR levels of various
phones and at various positions, they all meet the governmental
requirements for safe exposure.
Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications & Internet Association (CTIA) Web
site:
http://phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA) Web
site:
http://www.cwta.ca
1. In the United States and Canada, the SAR limit for mobile phones used by
the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The
standard incorporates a substantial margin of safety to give additional
protection for the public and to account for any variations in measurements.
2. The SAR information includes the Motorola testing protocol, assessment
procedure, and measurement uncertainty range for this product.
66
PRELIMINARY
The U.S. Food and Drug
Administration's Center for
Devices and Radiological Health
Consumer Update on Mobile Phones
Additional Health and Safety Information
FDA has been receiving inquiries about the safety of mobile phones,
including cellular phones and PCS phones. The following summarizes
what is known—and what remains unknown—about whether these
products can pose a hazard to health, and what can be done to minimize
any potential risk. This information may be used to respond to questions.
Why the concern?
Mobile phones emit low levels of radio frequency energy (i.e., radio
frequency radiation) in the microwave range while being used. They also
emit very low levels of radio frequency energy (RF), considered non-
significant, when in the stand-by mode. It is well known that high levels of
RF can produce biological damage through heating effects (this is how
your microwave oven is able to cook food). However, it is not known
whether, to what extent, or through what mechanism, lower levels of RF
might cause adverse health effects as well. Although some research has
been done to address these questions, no clear picture of the biological
effects of this type of radiation has emerged to date. Thus, the available
science does not allow us to conclude that mobile phones are absolutely
safe, or that they are unsafe. However, the available scientific evidence
does not demonstrate any adverse health effects associated with the use
of mobile phones.
What kinds of phones are in question?
Questions have been raised about hand-held mobile phones, the kind
that have a built-in antenna that is positioned close to the user's head
during normal telephone conversation. These types of mobile phones are
of concern because of the short distance between the phone's antenna—
67
PRELIMINARY
the primary source of the RF—and the person's head. The exposure to
RF from mobile phones in which the antenna is located at greater
distances from the user (on the outside of a car, for example) is drastically
lower than that from hand-held phones, because a person's RF exposure
decreases rapidly with distance from the source. The safety of so-called
“cordless phones,” which have a base unit connected to the telephone
wiring in a house and which operate at far lower power levels and
frequencies, has not been questioned.
How much evidence is there that hand-held
mobile phones might be harmful?
Briefly, there is not enough evidence to know for sure, either way;
however, research efforts are on-going. The existing scientific evidence is
conflicting and many of the studies that have been done to date have
suffered from flaws in their research methods. Animal experiments
investigating the effects of RF exposures characteristic of mobile phones
have yielded conflicting results. A few animal studies, however, have
suggested that low levels of RF could accelerate the development of
cancer in laboratory animals. In one study, mice genetically altered to be
predisposed to developing one type of cancer developed more than twice
as many such cancers when they were exposed to RF energy compared
to controls. There is much uncertainty among scientists about whether
results obtained from animal studies apply to the use of mobile phones.
First, it is uncertain how to apply the results obtained in rats and mice to
humans. Second, many of the studies that showed increased tumor
development used animals that had already been treated with cancer-
causing chemicals, and other studies exposed the animals to the RF
virtually continuously—up to 22 hours per day.
For the past five years in the United States, the mobile phone industry has
supported research into the safety of mobile phones. This research has
resulted in two findings in particular that merit additional study:
1
In a hospital-based, case-control study, researchers looked for an
association between mobile phone use and either glioma (a type of
brain cancer) or acoustic neuroma (a benign tumor of the nerve
68
PRELIMINARY
sheath). No statistically significant association was found between
mobile phone use and acoustic neuroma. There was also no
association between mobile phone use and gliomas when all types of
types of gliomas were considered together. It should be noted that
the average length of mobile phone exposure in this study was less
than three years.
When 20 types of glioma were considered separately, however, an
association was found between mobile phone use and one rare type
of glioma, neuroepithelliomatous tumors. It is possible with multiple
comparisons of the same sample that this association occurred by
chance. Moreover, the risk did not increase with how often the mobile
phone was used, or the length of the calls. In fact, the risk actually
decreased with cumulative hours of mobile phone use. Most cancer
causing agents increase risk with increased exposure. An ongoing
study of brain cancers by the National Cancer Institute is expected to
bear on the accuracy and repeatability of these results.
1
2
Researchers conducted a large battery of laboratory tests to assess
the effects of exposure to mobile phone RF on genetic material.
These included tests for several kinds of abnormalities, including
mutations, chromosomal aberrations, DNA strand breaks, and
structural changes in the genetic material of blood cells called
lymphocytes. None of the tests showed any effect of the RF except
for the micronucleus assay, which detects structural effects on the
genetic material. The cells in this assay showed changes after
exposure to simulated cell phone radiation, but only after 24 hours of
exposure. It is possible that exposing the test cells to radiation for this
long resulted in heating. Since this assay is known to be sensitive to
heating, heat alone could have caused the abnormalities to occur.
The data already in the literature on the response of the micronucleus
assay to RF are conflicting. Thus, follow-up research is necessary.
2
FDA is currently working with government, industry, and academic groups
to ensure the proper follow-up to these industry-funded research findings.
Collaboration with the Cellular Telecommunications Industry Association
(CTIA) in particular is expected to lead to FDA providing research
69
PRELIMINARY
recommendations and scientific oversight of new CTIA-funded research
based on such recommendations.
Two other studies of interest have been reported recently in the literature:
1
Two groups of 18 people were exposed to simulated mobile phone
signals under laboratory conditions while they performed cognitive
function tests. There were no changes in the subjects' ability to recall
words, numbers, or pictures, or in their spatial memory, but they were
able to make choices more quickly in one visual test when they were
exposed to simulated mobile phone signals. This was the only
change noted among more than 20 variables compared.
3
2
In a study of 209 brain tumor cases and 425 matched controls, there
was no increased risk of brain tumors associated with mobile phone
use. When tumors did exist in certain locations, however, they were
more likely to be on the side of the head where the mobile phone was
used.
Because this occurred in only a small number of cases, the increased
likelihood was too small to be statistically significant.
4
In summary, we do not have enough information at this point to assure
the public that there are, or are not, any low incident health problems
associated with use of mobile phones. FDA continues to work with all
parties, including other federal agencies and industry, to assure that
research is undertaken to provide the necessary answers to the
outstanding questions about the safety of mobile phones.
What is known about cases of human cancer
that have been reported in users of hand-held
mobile phones?
Some people who have used mobile phones have been diagnosed with
brain cancer. But it is important to understand that this type of cancer also
occurs among people who have not used mobile phones. In fact, brain
cancer occurs in the U.S. population at a rate of about 6 new cases per
100,000 people each year. At that rate, assuming 80 million users of
70
PRELIMINARY
mobile phones (a number increasing at a rate of about 1 million per
month), about 4800 cases of brain cancer would be expected each year
among those 80 million people, whether or not they used their phones.
Thus it is not possible to tell whether any individual's cancer arose
because of the phone, or whether it would have happened anyway. A key
question is whether the risk of getting a particular form of cancer is
greater among people who use mobile phones than among the rest of the
population. One way to answer that question is to compare the usage of
mobile phones among people with brain cancer with the use of mobile
phones among appropriately matched people without brain cancer. This
is called a case-control study. The current case-control study of brain
cancers by the National Cancer Institute, as well as the follow-up
research to be sponsored by industry, will begin to generate this type of
information.
What is FDA's role concerning the safety of
mobile phones?
Under the law, FDA does not review the safety of radiation-emitting
consumer products such as mobile phones before marketing, as it does
with new drugs or medical devices. However, the agency has authority to
take action if mobile phones are shown to emit radiation at a level that is
hazardous to the user. In such a case, FDA could require the
manufacturers of mobile phones to notify users of the health hazard and
to repair, replace or recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory actions
at this time, FDA has urged the mobile phone industry to take a number of
steps to assure public safety. The agency has recommended that the
industry:
•
support needed research into possible biological effects of RF of the
type emitted by mobile phones
•
design mobile phones in a way that minimizes any RF exposure to
the user that is not necessary for device function
71
PRELIMINARY
•
cooperate in providing mobile phone users with the best possible
information on what is known about possible effects of mobile phone
use on human health
At the same time, FDA belongs to an interagency working group of the
federal agencies that have responsibility for different aspects of mobile
phone safety to ensure a coordinated effort at the federal level. These
agencies are:
•
National Institute for Occupational Safety and Health
•
Environmental Protection Agency
•
Federal Communications Commission
•
Occupational Health and Safety Administration
•
National Telecommunications and Information Administration
The National Institutes of Health also participates in this group.
In the absence of conclusive information about
any possible risk, what can concerned
individuals do?
If there is a risk from these products—and at this point we do not know
that there is—it is probably very small. But if people are concerned about
avoiding even potential risks, there are simple steps they can take to do
so. For example, time is a key factor in how much exposure a person
receives. Those persons who spend long periods of time on their hand-
held mobile phones could consider holding lengthy conversations on
conventional phones and reserving the hand-held models for shorter
conversations or for situations when other types of phones are not
available.
People who must conduct extended conversations in their cars every day
could switch to a type of mobile phone that places more distance between
their bodies and the source of the RF, since the exposure level drops off
dramatically with distance. For example, they could switch to:
•
a mobile phone in which the antenna is located outside the vehicle
72
PRELIMINARY
•
a hand-held phone with a built-in antenna connected to a different
antenna mounted on the outside of the car or built into a separate
package
•
a headset with a remote antenna to a mobile phone carried at the
waist
Again, the scientific data do not demonstrate that mobile phones are
harmful. But if people are concerned about the radio frequency energy
from these products, taking the simple precautions outlined above can
reduce any possible risk.
Where can I find additional information?
For additional information, see the following Web sites:
Federal Communications Commission
(FCC) RF Safety Program
(select “Information on Human Exposure to RF Fields from Cellular and
PCS Radio Transmitters”):
http://www.fcc.gov/oet/rfsafety
World Health Organization
(WHO) International Commission on
Non-Ionizing Radiation Protection (select Qs & As):
http://
www.who.int/emf
United Kingdom, National Radiological Protection Board
:
http://www.nrpb.org.uk
Cellular Telecommunications Industry Association
(CTIA):
http://www.wow-com.com
U.S. Food and Drug Administration
(FDA) Center for Devices and
Radiological Health:
http://www.fda.gov/cdrh/consumer/
73
PRELIMINARY
1. Muscat et al. Epidemiological Study of Cellular Telephone Use and Malignant
Brain Tumors. In: State of the Science Symposium;1999 June 20; Long
Beach, California.
2. Tice et al. Tests of mobile phone signals for activity in genotoxicity and other
laboratory assays. In: Annual Meeting of the Environmental Mutagen Society;
March 29, 1999, Washington, D.C.; and personal communication,
unpublished results.
3. Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim, E, and Varey,
A. Effect of a 915-MHz simulated mobile phone signal on cognitive function
in man. Int. J. Radiat. Biol., April 8, 1999.
4. Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH. Use of cellular
telephones and the risk for brain tumors: a case-control study. Int. J. Oncol.,
15: 113-116, 1999.
74
PRELIMINARY
Motorola Limited Warranty for
the United States and Canada
Warranty
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its
telephones, pagers, messaging devices, and consumer and professional
two-way radios (excluding commercial, government or industrial radios)
that operate via Family Radio Service or General Mobile Radio Service,
Motorola-branded or certified accessories sold for use with these
Products (“Accessories”) and Motorola software contained on CD-ROMs
or other tangible media and sold for use with these Products (“Software”)
to be free from defects in materials and workmanship under normal
consumer usage for the period(s) outlined below. This limited warranty is
a consumer's exclusive remedy, and applies as follows to new Motorola
Products, Accessories and Software purchased by consumers in the
United States or Canada, which are accompanied by this written
warranty:
Products and Accessories
Products Covered Length of Coverage
Products and Accessories
as
defined above, unless otherwise
provided for below.
One (1) year
from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
Decorative Accessories and
Cases
. Decorative covers,
bezels, PhoneWrap™ covers
and cases.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the
product.
75
PRELIMINARY
Exclusions
Normal Wear and Tear.
Periodic maintenance, repair and replacement
of parts due to normal wear and tear are excluded from coverage.
Batteries.
Only batteries whose fully charged capacity falls below 80% of
their rated capacity and batteries that leak are covered by this limited
warranty.
Abuse & Misuse.
Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such as
physical damage (cracks, scratches, etc.) to the surface of the product
resulting from misuse; (b) contact with liquid, water, rain, extreme
humidity or heavy perspiration, sand, dirt or the like, extreme heat, or
food; (c) use of the Products or Accessories for commercial purposes or
subjecting the Product or Accessory to abnormal usage or conditions; or
(d) other acts which are not the fault of Motorola, are excluded from
coverage.
Use of Non-Motorola Products and Accessories.
Defects or damage
that result from the use of Non-Motorola branded or certified Products,
Accessories, Software or other peripheral equipment are excluded from
coverage.
Monaural Headsets.
Ear buds
and boom headsets that transmit
mono sound through a wired
connection.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the
product.
Consumer and Professional
Two-Way Radio Accessories.
Ninety (90) days
from the date of
purchase by the first consumer
purchaser of the product.
Products and Accessories that
are Repaired or Replaced.
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Products Covered Length of Coverage
76
PRELIMINARY
Unauthorized Service or Modification.
Defects or damages resulting
from service, testing, adjustment, installation, maintenance, alteration, or
modification in any way by someone other than Motorola, or its authorized
service centers, are excluded from coverage.
Altered Products.
Products or Accessories with (a) serial numbers or
date tags that have been removed, altered or obliterated; (b) broken seals
or that show evidence of tampering; (c) mismatched board serial
numbers; or (d) nonconforming or non-Motorola housings, or parts, are
excluded from coverage.
Communication Services.
Defects, damages, or the failure of Products,
Accessories or Software due to any communication service or signal you
may subscribe to or use with the Products Accessories or Software is
excluded from coverage.
Software
Exclusions
Software Embodied in Physical Media.
No warranty is made that the
software will meet your requirements or will work in combination with any
hardware or software applications provided by third parties, that the
operation of the software products will be uninterrupted or error free, or
that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media.
Software that is not
embodied in physical media (e.g. software that is downloaded from the
internet), is provided “as is” and without warranty.
Who is Covered?
This warranty extends only to the first consumer purchaser, and is not
transferable.
Products Covered Length of Coverage
Software.
Applies only to physical defects
in the media that embodies the copy of the
software (e.g. CD-ROM, or floppy disk).
Ninety (90) days
from
the date of purchase.
77
PRELIMINARY
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the
purchase price of any Products, Accessories or Software that does not
conform to this warranty. We may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products, Accessories or
parts. No data, software or applications added to your Product, Accessory
or Software, including but not limited to personal contacts, games and
ringer tones, will be reinstalled. To avoid losing such data, software and
applications please create a back up prior to requesting service.
How to Obtain Warranty Service or Other
Information
You will receive instructions on how to ship the Products, Accessories or
Software, at your expense, to a Motorola Authorized Repair Center. To
obtain service, you must include: (a) a copy of your receipt, bill of sale or
other comparable proof of purchase; (b) a written description of the
problem; (c) the name of your service provider, if applicable; (d) the name
and location of the installation facility (if applicable) and, most importantly;
(e) your address and telephone number.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF
USA
Phones
1-800-331-6456
Pagers
1-800-548-9954
Two-Way Radios
and Messaging Devices
1-800-353-2729
Canada
All Products
1-800-461-4575
TTY
1-888-390-6456
For
Accessories
and
Software
, please call the telephone number
designated above for the product with which they are used.
78
PRELIMINARY
THIS LIMITED WARRANTY, OTHERWISE THE REPAIR,
REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS
LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL
MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE
PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR
SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE
OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR
DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS
ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR
INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE
TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY
LAW.
Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation on
the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights that vary from state
to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for Motorola
certain exclusive rights for copyrighted Motorola software such as the
exclusive rights to reproduce and distribute copies of the Motorola
software. Motorola software may only be copied into, used in, and
redistributed with, the Products associated with such Motorola software.
No other use, including without limitation disassembly of such Motorola
software or exercise of the exclusive rights reserved for Motorola, is
permitted.
79
PRELIMINARY
Product Registration
Online Product Registration:
http://www.motorola.com/warranty
Product registration is an important step toward enjoying your new
Motorola product. Registering helps us facilitate warranty service, and
permits us to contact you should your product require an update or
other service. Registration is for U.S. residents only and is not required
for warranty coverage.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola Personal Communications Product
you will need to provide a copy of your dated sales receipt to confirm
warranty status.
Thank you for choosing a Motorola product.
Export Law Assurances
This product is controlled under the export regulations of the United
States of America and Canada. The Governments of the United States
of America and Canada may restrict the exportation or re-exportation
of this product to certain destinations. For further information contact
the U.S. Department of Commerce or the Canadian Department of
Foreign Affairs and International Trade.
80
PRELIMINARY
Index
A
accessories
connector ports 1
optional 13, 56
standard 12
active line indicator
defined 23
illustration 22
Add Digits
feature 47
alert
creating 57
defined 39
turning off 19, 45
ALI indicator 23
analog signal indicator
defined 22
illustration 22
animation
screen saver 41
answering a call 20
application, locking and
unlocking 62
Attach Number
feature 47
auto PIN dial 58
automatic location
information
indicators 23
automatic redial
using 43
B
battery
car kit charger time 60
charging 16
extending battery life 16
installing 15
level indicator 16, 22, 23
block cursor, defined 27
browse text mode 27
C
calculator 62
call
adding digits after phone
number 47
alert 19
alert, turning off 45
answer options 40
answering 20
call waiting 52
canceling 44
deleting 45
dialed calls list 45
dialing 19
dialing a recent call 45
emergency number 45
81
PRELIMINARY
ending 19, 20
making 19
muting 51
placing
received calls list 45
receiving 20
recent calls 45
restricting 55
speakerphone 60
storing 45
three-way call 55
timers 59
unanswered call 47
Call Failed
message 43
call waiting 52
caller ID 44, 48
calling line identification.
See caller ID
car kit
automatic answer 60
automatic hands-free 60
charger time 60
power-off delay 60
clock
illustration 21
codes
changing 37
default 36, 37
if you forget a
code/password 37
contrast, display 42
cursor 26
D
data call
receive 61
send 61
date, setting 39
datebook 61
deleting a call 45
dialed calls list 45
dialing a number 19
digital signal indicator
defined 22
illustration 22
display
contrast 42
description 21
idle display 21
illustration 21
language 58
zooming in/out 42
DTMF tones 46
activating 59
sending 47, 59
E
earpiece
illustration 1
volume, adjusting 19
emergency number 45
end key
functions 1, 18, 24
ending a call 19, 20
82
PRELIMINARY
Enter Unlock Code
message
36, 37
F
fax call
receive 61
send 61
flashing cursor, defined 26
FM Stereo Radio Headset
63
4-way navigation key 23
H
hands-free use
automatic answer 60
automatic call routing 60
charger time 60
power-off delay 60
speakerphone, activating
60
headset
automatic answer 60
FM Stereo Radio Headset
63
I
idle display, defined 21
in use indicator
defined 22
illustration 22
incoming call
canceling 44
Incoming Call
message 44
indicators
active line 22, 23
ALI 23
battery level 16, 22, 23
digital/analog signal 22
in use 22
loud ring style 23, 39
menu 21
message waiting 22
missed call 47
ring style 22, 23, 40
roam 22
signal strength 22
silent alert 23
silent ring style 23, 40
soft ring style 23, 39
vibrate and ring style 23,
40
vibrate style 23, 40
voice message waiting
22, 23, 51
iTAP software 30
K
key
end 1, 18, 24
4-way navigation 23
left soft key 1, 21, 24, 57
lock 38
menu 1, 24, 25
83
PRELIMINARY
navigation 1
right soft key 1, 21, 24,
57
send 1, 19, 20, 24, 46
volume control 19
keypad
answering calls 40
locking and unlocking 38
volume, adjusting 57
L
language, setting 58
left soft key
functions 1, 21, 24
personalizing 57
lock
application 62
keypad 38
phone 35
loud ring style indicator 23,
39
Low Battery
message 23
M
making a call 19
master clear 58
master reset 58
menu
Dialing Menu
48
entering text 26
language, setting 58
Last Calls Menu
47
lists 25
navigating 24
using features 12, 25
menu indicator 21
menu key 1, 24, 25
message
receiving 56
sending 56
message waiting indicator
defined 22
illustration 22
micro-browser
using 62
microphone 1
missed call indicator 47
Missed Call
message 48
muting a call 51
my telephone number 20,
39, 53
my tones 57
N
navigation key 1
network settings 61
notepad
defined 48
entering digits 48
retrieving digits 48
number
storing your number 39
viewing your number 20,
53
84
PRELIMINARY
numeric text mode 27
O
one-touch dial
defined 49
using 49
voicemail number 49
optional accessory, defined
13
optional feature, defined 12
P
passwords. See codes
phone
active line indicator 23
active phone line,
changing 43
alert, turning off 19, 45
answer options 40
clear stored information
58
codes 37
date, setting 39
keypad, answering calls
40
keypad, locking and
unlocking 38
language, setting 58
locking 35, 36
network settings 61
reset all options 58
security code 37
time, setting 39
turning on/off 18
unlock code 36, 37
unlocking 18, 35, 36
phone number
active line indicator 23
active phone line,
changing 43
adding digits after 47
attaching two numbers
47, 49
redialing 43
storing in phonebook 56
storing your number 39
viewing your number 20,
53
phonebook
attaching two numbers
47, 49
dialing a number 56
one-touch dial 49
speed dial number,
defined 49
speed dial, using 49
storing an entry 56
voice dialing 56
screen saver 41
PIN code
dialing automatically 58
predictive text entry 30
85
PRELIMINARY
R
radio 63
received calls list 45
recent calls 45
redial
automatic redial 43
busy number 43
restricting calls 55
right soft key
functions 1, 21, 24
personalizing 57
ring alert
turning off 19, 45
ring style
defined 40
indicators 23, 39
personalizing 40, 57
setting 39
ring style indicator
defined 23, 40
illustration 22
ring tone, creating 57
ringer
volume, adjusting 19
ringer volume, adjusting 57
roam indicator
defined 22
illustration 22
S
screen saver 41
security code
changing 37
default 37
send key 1, 19, 20, 24, 46
sending a call. See making
a call
shortcuts
creating 57
standard 53
signal strength indicator
defined 22
illustration 22
silent alert indicator 23
silent ring style indicator 23,
40
soft keys
functions 21
illustration 1, 24
labels 21
personalizing 57
soft ring style indicator 23,
39
speakerphone, activating
60
speed dial
number, defined 49
using 49
storing a call 45
symbol text entry 34, 35
86
PRELIMINARY
T
tap method text entry 28,
30
telephone number
storing your number 39
viewing your number 20,
53
text
block cursor 27
browse mode 27
character chart 30
entering from keypad 26
entry mode, changing 27
flashing cursor 26
iTAP software predictive
text entry 30
numeric mode 27
symbol chart 35
symbol mode 34, 35
tap method 28, 30
text mode, changing 27
three-way call 55
time, setting 39
timers 59
travel charger, using 16
TTY device 56
U
unlock
application 62
keypad 38
phone 35
unlock code 37
bypassing 37
changing 37
default 36, 37
entering 36
V
vibrate alert
turning off 19, 45
vibrate and ring style
indicator 23, 40
vibrate ring style
setting 39
vibrate style
indicator 23, 40
voice dial
dialing a number 56
voice key
dialing a number 56
voice message waiting
indicator 22, 23, 51
voicemail
dialing with one-touch dial
49
volume
earpiece 19
keypad 57
ringer 19, 57
W
warranty 74
88
PRELIMINARY
art# 020827-O.eps
✂
PRELIMINARY
89
Wireless Phone Safety
Tips
“Safety is your most important call!”
Your Motorola wireless telephone gives you
the powerful ability to communicate by voice—
almost anywhere, anytime, wherever wireless
phone service is available and safe conditions allow.
But an important responsibility accompanies the
benefits of wireless phones, one that every user
must uphold.
When driving a car, driving is your first
responsibility. If you find it necessary to use your
wireless phone while behind the wheel of a car,
practice good common sense and remember the
following tips:
1 Get to know your Motorola wireless phone and its
features such as speed dial and redial.
If available,
these features help you to place your call without taking
your attention off the road.
2 When available, use a hands-free device.
If possible,
add an additional layer of convenience to your wireless
✂
PRELIMINARY
90
phone with one of the many Motorola Original™ hands-
free accessories available today.
3 Position your wireless phone within easy reach.
Be
able to access your wireless phone without removing
your eyes from the road. If you receive an incoming call
at an inconvenient time, if possible, let your voice mail
answer it for you.
4 Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions.
Rain, sleet,
snow, ice, and even heavy traffic can be hazardous.
5 If you receive an incoming call at an inconvenient
time do not take notes or look up phone numbers
while driving.
Jotting down a “to do” list or going
through your address book takes attention away from
your primary responsibility—driving safely.
6 Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic.
Try to plan calls when your car will
be stationary. If you need to make a call while moving,
dial only a few numbers, check the road and your
mirrors, then continue.
7 Do not engage in stressful or emotional
conversations that may be distracting.
Make people
you are talking with aware you are driving and suspend
conversations which have the potential to divert your
attention away from the road.
8 Use your wireless phone to call for help.
Dial 9-1-1 or
other local emergency number in the case of fire, traffic
accident or medical emergencies.*
✂
PRELIMINARY
91
9 Use your wireless phone to help others in
emergencies.
If you see an auto accident, crime in
progress or other serious emergency where lives are in
danger, call 9-1-1 or other local emergency number, as
you would want others to do for you.*
10 Call roadside assistance or a special
non-emergency wireless assistance number when
necessary.
If you see a broken-down vehicle posing no
serious hazard, a broken traffic signal, a minor traffic
accident where no one appears injured, or a vehicle you
know to be stolen, call roadside assistance or other
special non-emergency wireless number.*
* Wherever wireless phone service is available.
✂
PRELIMINARY
92
Check the laws and regulations on the use of
wireless telephones and their accessories in the
areas where you drive. Always obey them. The
use of these devices may be prohibited or
restricted in certain areas.
For more information,
please call
1-888-901-SAFE
or visit the
CTIA Web site at
www.wow-com.com™
motorola.com
8988485L49-O
