APPLICANT: MOTOROLA, INC. FCC ID: IHDT56CL1
INSTRUCTION MANUAL
The Users Manual follows:
EXHIBIT 8A
START HERE >
1
Welcome
Earpiece
USB Connector
Insert data cable.
Right Soft Key
Perform functions
identified by right
display prompt.
Menu Key
Open a menu
when
G
appears.
Power/End Key
Press & hold to
turn phone on &
off.
Press & release
to end phone
calls, exit menu.
Send/Answer Key
Make and answer
calls; press in idle
to see recent
dialed calls.
Navigation Key
Scroll through lists,
set volume.
Left Soft Key
Perform functions
identified by left
display prompt.
Microphone
Headset ConnectorPower Connector
Insert charger.
You can change your C330 Series phone’s covers and keypads
(see “Changing Your Phone’s Cover” on page 18). Your phone may
not appear exactly as the phone image above.
All key locations, sequences and functions remain the same with
any of the various covers.
2
Motorola, Inc., Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States)
1-800-461-4575 (Canada)
www.motorola.com
(United States)
www.motorola.ca
(Canada)
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. All other product or service names are the property of
their respective owners. TrueSync, Starfish, and the Stylized Starfish
Logo are registered trademarks of Starfish Software, Inc., a wholly owned
subsidiary of Pumatech, Inc.
© Motorola, Inc. 2002.
Software Copyright Notice
The Motorola products described in this manual may include copyrighted
Motorola and third party software stored in semiconductor memories or
other media. Laws in the United States and other countries preserve for
Motorola and third party software providers certain exclusive rights for
copyrighted software, such as the exclusive rights to distribute or
reproduce the copyrighted software. Accordingly, any copyrighted
software contained in the Motorola products may not be modified,
reverse-engineered, distributed, or reproduced in any manner to the
extent allowed by law. Furthermore, the purchase of the Motorola
products shall not be deemed to grant either directly or by implication,
estoppel, or otherwise, any license under the copyrights, patents, or
patent applications of Motorola or any third party software provider,
except for the normal, non-exclusive, royalty-free license to use that
arises by operation of law in the sale of a product.
Manual number: 6809451A61-C
Cover number: 8988485L61-O
3
Menu Map
Main Menu
This is the standard main menu layout.
Menu organization
and feature names may vary on your phone.
Not all
features may be available for all users.
z
Recent Calls
• Received Calls
• Dialed Calls
• Notepad
• Call Times
à
Phonebook
g
Datebook
U
Messages
•Voicemail
• Create Message
•Inbox
• Outbox
• Quick Notes
•Drafts
• Browser Alerts
s
Ring Styles
:
Shortcuts
L
Web Browser
•Home
• Go To URL
•Mark Site
• Reload
• About Openwave
•Advanced
a
Calculator
-
Games
v
Picture Viewer
/
Settings
(see next page)
Shortcuts
Change display zoom:
Press
M
, then
press and hold
M
Change ringer alert:
Press
S
down to
switch to silent alert.
Press up to reset to
ring alert.
Display my phone
number:
Press
M#
Display dialed calls
list:
Press
N
Exit menu system:
Press
O
4
Settings Menu
•Ring Styles
•Style
•Style Detail
• My Tones
• Phone Status
•My Tel. Numbers
• Active Line
• Battery Meter
• Other Information
•Browser Setup
• Connection
• Incoming Call
• In-Call Setup
• In-Call Timer
• Answer Options
• Security
• Phone Lock
• Lock Keypad
• Lock Application
• Talk Secure
• Restrict Calls
•New Passwords
• Location
• Other Settings
• Personalize
•Main Menu
•Keys
•Greeting
• Wallpaper
• Screen Saver
• Banner
• Initial Setup
• Time and Date
• Auto PIN Dial
• Auto Redial
• Backlight
•Zoom
• TTY Setup
•Scroll
• Animation
• Language
• Contrast
•DTMF
•Master Reset
• Master Clear
•Network
• Current Network
•Set Mode
•Srvc Status
• Service Tone
• Call Drop Tone
• Car Settings
• Auto Answer
• Auto Handsfree
• Power-Off Delay
•Charger Time
• Headset
5
Contents
Menu Map
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Getting Started
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
What’s in the Box?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Changing Your Phone’s Cover. . . . . . . . . . . . . . . . . . . . 18
Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . . 21
Adjusting the Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . 22
Learning to Use Your Phone
. . . . . . . . . . . . . . . . . . . . . 23
Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Using the 4-Way Navigation Key . . . . . . . . . . . . . . . . . . 25
Using Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Locking and Unlocking Your Phone. . . . . . . . . . . . . . . . 36
Changing a Code or Password . . . . . . . . . . . . . . . . . . . 38
If You Forget a Code or Password. . . . . . . . . . . . . . . . . 38
Locking and Unlocking the Keypad . . . . . . . . . . . . . . . . 39
Setting Up Your Phone
. . . . . . . . . . . . . . . . . . . . . . . . . . 40
Storing Your Name and Phone Number . . . . . . . . . . . . 40
Setting the Time and Date. . . . . . . . . . . . . . . . . . . . . . . 40
Setting a Ring Style. . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Setting Answer Options. . . . . . . . . . . . . . . . . . . . . . . . . 41
Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . . 41
6
Setting a Screen Saver Image . . . . . . . . . . . . . . . . . . . . 42
Zooming In and Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Setting Display Contrast . . . . . . . . . . . . . . . . . . . . . . . . . 43
Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Calling Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Changing the Active Line . . . . . . . . . . . . . . . . . . . . . . . . 44
Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Using Automatic Redial. . . . . . . . . . . . . . . . . . . . . . . . . . 44
Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . . . . 45
Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Calling an Emergency Number. . . . . . . . . . . . . . . . . . . . 46
Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . . 48
Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Attaching a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Calling With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . 50
Calling With One-Touch Dial . . . . . . . . . . . . . . . . . . . . . . 50
Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Muting the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Using Call Waiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Messages
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Setting Up the Text Message Inbox . . . . . . . . . . . . . . . . 54
Sending Messages, Pictures, and Sounds . . . . . . . . . . . 54
Sending a Quick Note Text Message . . . . . . . . . . . . . . . 58
Viewing the Status of Sent Text Messages. . . . . . . . . . . 59
Receiving Messages, Pictures, and Sounds. . . . . . . . . . 59
Reading, Locking, or Deleting a Text Message. . . . . . . . 61
Reading Browser Alerts . . . . . . . . . . . . . . . . . . . . . . . . . 64
Reading Information Service Messages . . . . . . . . . . . . . 64
Setting Up Your Phonebook
. . . . . . . . . . . . . . . . . . . . . . 68
Viewing Entry Details . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7
Creating a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . 69
Storing a PIN Code With a Phone Number. . . . . . . . . . 70
Dialing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . 72
Editing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . 72
Deleting a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . 73
Sorting Phonebook Entries . . . . . . . . . . . . . . . . . . . . . . 73
Personalizing Your Phone
. . . . . . . . . . . . . . . . . . . . . . . 74
Personalizing a Ring Style. . . . . . . . . . . . . . . . . . . . . . . 74
Activating Ringer IDs. . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Setting Ringer or Keypad Volume . . . . . . . . . . . . . . . . . 75
Setting Reminders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Creating Alert Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Personalizing Display Text. . . . . . . . . . . . . . . . . . . . . . . 77
Personalizing the Menu. . . . . . . . . . . . . . . . . . . . . . . . . 77
Personalizing Soft Keys. . . . . . . . . . . . . . . . . . . . . . . . . 78
Setting the Menu Language . . . . . . . . . . . . . . . . . . . . . 79
Setting Menu Scroll Behavior . . . . . . . . . . . . . . . . . . . . 79
Setting Menu Animation . . . . . . . . . . . . . . . . . . . . . . . . 79
Resetting All Options. . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Clearing All Information. . . . . . . . . . . . . . . . . . . . . . . . . 80
Using MyMenu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Getting More Out of Your Phone
. . . . . . . . . . . . . . . . . . 84
Making a Three-Way Call . . . . . . . . . . . . . . . . . . . . . . . 84
Restricting Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Using TTY Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Setting Auto PIN Dial. . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Using DTMF Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Monitoring Phone Use. . . . . . . . . . . . . . . . . . . . . . . . . . 89
Using Hands-Free Features . . . . . . . . . . . . . . . . . . . . . 92
Making Data and Fax Calls . . . . . . . . . . . . . . . . . . . . . . 94
Adjusting Network Settings . . . . . . . . . . . . . . . . . . . . . . 97
Monitoring Battery Charge . . . . . . . . . . . . . . . . . . . . . 100
8
Viewing Phone Specifications. . . . . . . . . . . . . . . . . . . . 100
Personal Organizer Features
. . . . . . . . . . . . . . . . . . . . . 101
Using the Datebook . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Calculating Numbers and Currency . . . . . . . . . . . . . . . 106
Security
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Locking and Unlocking Applications . . . . . . . . . . . . . . . 108
News and Entertainment
. . . . . . . . . . . . . . . . . . . . . . . . 109
Using the Micro-Browser. . . . . . . . . . . . . . . . . . . . . . . . 109
Playing Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Picture Viewer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Creating Alert Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Specific Absorption Rate Data
. . . . . . . . . . . . . . . . . . . 131
Additional Health and Safety Information
. . . . . . . . . . 133
Warranty
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Product Registration
. . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Export Law Assurances
. . . . . . . . . . . . . . . . . . . . . . . . . 143
RF Energy Interference
. . . . . . . . . . . . . . . . . . . . . . . . . 143
Index
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Wireless Phone Safety Tips
. . . . . . . . . . . . . . . . . . . . . . 155
9
Safety and General Information
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION.
READ THIS INFORMATION BEFORE USING YOUR PHONE.
The information provided in this document supersedes the general safety
information in user guides published prior to December 1, 2002.
Exposure To Radio Frequency (RF) Energy
Your phone contains a transmitter and a receiver. When it is ON, it
receives and transmits RF energy. When you communicate with your
phone, the system handling your call controls the power level at which
your phone transmits.
Your Motorola phone is designed to comply with local regulatory
requirements in your country concerning exposure of human beings to RF
energy.
Operational Precautions
To assure optimal phone performance and make sure human exposure to
RF energy is within the guidelines set forth in the relevant standards,
always adhere to the following procedures.
External Antenna Care
Use only the supplied or Motorola-approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage the
phone.
Do NOT hold the external antenna when the phone is IN USE. Holding
the external antenna affects call quality and may cause the phone to
operate at a higher power level than needed. In addition, use of
unauthorized antennas may result in non-compliance with the local
regulatory requirements in your country.
10
Phone Operation
When placing or receiving a phone call, hold your phone as you would a
wireline telephone.
Body-Worn Operation
To maintain compliance with RF energy exposure guidelines, if you wear a
phone on your body when transmitting, always place the phone in a
Motorola-supplied or approved clip, holder, holster, case, or body harness
for this phone, where available. Use of accessories not approved by
Motorola may exceed RF energy exposure guidelines. If you do not use
one of the body-worn accessories approved or supplied by Motorola, and
are not using the phone held in the normal use position, ensure the phone
and its antenna are at least 1 inch (2.5 centimeters) from your body when
transmitting.
Data Operation
When using any data feature of the phone, with or without an accessory
cable, position the phone and its antenna at least 1 inch (2.5 centimeters)
from your body.
Approved Accessories
Use of accessories not approved by Motorola, including but not limited to
batteries and antenna, may cause your phone to exceed RF energy
exposure guidelines. For a list of approved Motorola accessories, visit our
website at
www.Motorola.com
.
RF Energy Interference/Compatibility
Note:
Nearly every electronic device is susceptible to RF energy
interference from external sources if inadequately shielded, designed, or
otherwise configured for RF energy compatibility. In some circumstances
your phone may cause interference.
Facilities
Turn off your phone in any facility where posted notices instruct you to do
so. These facilities may include hospitals or health care facilities that may
be using equipment that is sensitive to external RF energy.
11
Aircraft
When instructed to do so, turn off your phone when on board an aircraft.
Any use of a phone must be in accordance with applicable regulations per
airline crew instructions.
Medical Devices
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of
6 inches (15 centimeters) be maintained between a handheld wireless
phone and a pacemaker.
Persons with pacemakers should:
•
ALWAYS keep the phone more than 6 inches (15 centimeters) from
your pacemaker when the phone is turned ON.
•
NOT carry the phone in the breast pocket.
•
Use the ear opposite the pacemaker to minimize the potential for
interference.
•
Turn OFF the phone immediately if you have any reason to suspect
that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing aid
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of
your device to determine if it is adequately shielded from RF energy. Your
physician may be able to assist you in obtaining this information.
Use While Driving
Check the laws and regulations on the use of phones in the area where
you drive. Always obey them.
12
When using your phone while driving, please:
•
Give full attention to driving and to the road.
•
Use hands-free operation, if available.
•
Pull off the road and park before making or answering a call if driving
conditions so require.
Responsible driving best practices may be found in the “Wireless Phone
Safety Tips” at the end of this manual and at the Motorola website:
www.Motorola.com/callsmart
.
Operational Warnings
For Vehicles With an Air Bag
Do not place a phone in the area over an air bag or in the air bag
deployment area. Air bags inflate with great force. If a phone is placed in
the air bag deployment area and the air bag inflates, the phone may be
propelled with great force and cause serious injury to occupants of the
vehicle.
Potentially Explosive Atmospheres
Turn off your phone prior to entering any area with a potentially explosive
atmosphere, unless it is a phone type especially qualified for use in such
areas and certified as “Intrinsically Safe.” Do not remove, install, or charge
batteries in such areas. Sparks in a potentially explosive atmosphere can
cause an explosion or fire resulting in bodily injury or even death.
Note:
The areas with potentially explosive atmospheres referred to above
include fueling areas such as below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air contains chemicals or
particles, such as grain, dust, or metal powders. Areas with potentially
explosive atmospheres are often but not always posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn OFF your
phone when you are near electrical blasting caps, in a blasting area, or in
areas posted “Turn off electronic devices.” Obey all signs and instructions.
13
Batteries
Batteries can cause property damage and/or bodily injury such as burns if
a conductive material such as jewelry, keys, or beaded chains touch
exposed terminals. The conductive material may complete an electrical
circuit (short circuit) and become quite hot. Exercise care in handling any
charged battery, particularly when placing it inside a pocket, purse, or
other container with metal objects.
Use only Motorola original batteries
and chargers.
Your battery or phone may contain symbols, defined as follows:
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when
exposed to blinking lights, such as when watching television or playing
video games. These seizures or blackouts may occur even if a person
never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family
history of such occurrences, please consult with your doctor before
playing video games on your phone or enabling a blinking-lights feature
on your phone. (The blinking-light feature is not available on all products.)
Symbol Definition
Important safety information will follow.
Your battery or phone should not be disposed of in a
fire.
Your battery or phone may require recycling in
accordance with local laws. Contact your local
regulatory authorities for more information.
Your battery or phone should not be thrown in the
trash.
Your phone contains an internal lithium ion battery.
LiIon BATT
14
Parents should monitor their children's use of video game or other
features that incorporate blinking lights on the phones. All persons should
discontinue use and consult a doctor if any of the following symptoms
occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation.
To limit the likelihood of such symptoms, please take the following safety
precautions:
•
Do not play or use a blinking-lights feature if you are tired or need
sleep.
•
Take a minimum of a 15-minute break hourly.
•
Play in a room in which all lights are on.
•
Play at the farthest distance possible from the screen.
Repetitive Motion Injuries
When you play games on your phone, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of your
body. Follow these instructions to avoid problems such as tendonitis,
carpal tunnel syndrome, or other musculoskeletal disorders:
•
Take a minimum 15-minute break every hour of game playing.
•
If your hands, wrists, or arms become tired or sore while playing,
stop and rest for several hours before playing again.
•
If you continue to have sore hands, wrists, or arms during or after
play, stop playing and see a doctor.
15
Getting Started
Getting Started
What’s in the Box?
Your wireless phone typically comes with a battery and
a charger. Optional accessories can customize your phone
for maximum performance and portability.
To purchase Motorola Original™ accessories, call the
Motorola Customer Call Center at 1-800-331-6456 in the
United States or 1-800-461-4575 in Canada.
About this Guide
Optional Features
This label identifies an optional network or
subscription-dependent feature that may not be
offered by all service providers in all
geographical areas. Contact your service
provider for more information.
Optional Accessories
This label identifies a feature that requires an
optional Motorola Original™ accessory.
Installing the Battery
Install and charge the battery before you use your phone.
16
Getting Started
CAUTION:
This phone comes with a 750 mAh (milliamp
hours) battery and should be used only with Motorola
Original batteries rated at 750 mAh or 1100 mAh. Use
of any other battery could affect the performance of the
phone and could also cause the phone to become
noncompliant with the Specific Absorption Rate levels
established by the FCC's Radiofrequency Exposure
Guidelines.
Your phone is designed to be used only with
Motorola Original batteries and accessories. We
recommend that you store batteries in their
protective cases when not in use.
To Install the Battery
1
Remove the phone’s back cover as described in
“Changing Your Phone’s Cover” on page 18.
2
Remove the battery from its protective clear
plastic case.
3
Insert the battery,
printed arrow first,
under the tabs
at
the bottom of the
battery
compartment and
push down.
4
Replace the phone’s cover.
17
Getting Started
Charging the Battery
Before you can use your phone, fully charge the battery
as follows. Some batteries perform best after several
full charge/discharge cycles.
When you charge the battery, the battery level indicator in
the upper right corner of the display shows how much of
the charging process is complete. See “Battery Level
Indicator” on page 23.
Battery Use
Caution:
To prevent injuries or burns, do not allow metal
objects to contact or short-circuit the battery terminals.
To maximize battery performance:
•
Always use Motorola Original™ battery chargers. The
phone warranty does not cover damage caused from
using non-Motorola battery chargers.
To Charge the Battery
1
Plug the charger
into the left jack
on the bottom of
your phone.
2
Plug the other end of the charger into the
appropriate electrical outlet.
3
When your phone indicates
Charge Complete
,
remove the charger.
18
Getting Started
•
New batteries or batteries that have been stored for a
long time may require a longer initial charge time.
•
Keep the battery at or near room temperature
when charging.
•
Do not expose batteries to temperatures below -
10° C (14° F) or above 45° C (113° F). Always take
your phone with you when you leave your vehicle.
•
When you do not intend to use a battery for a while,
store it uncharged in a cool, dark, dry place, such as a
refrigerator.
•
Over time, batteries gradually wear down and require
longer charging times. This is normal. If you charge
your battery regularly and notice a decrease in talk
time or an increase in charging time, then it is
probably time to buy a new battery.
The rechargeable batteries that power this
product must be disposed of properly and may
need to be recycled. Refer to your battery’s label
for battery type. Contact your local recycling center for
proper disposal methods. Never dispose of batteries in a
fire because they may explode.
Changing Your Phone’s Cover
Since you can change your C330 Series phone’s covers
and keypads, it may not appear exactly as the phone
pictured. All key locations, sequences, and functions
remain the same with any of the covers.
Important:
To maintain compliance with FCC RF
exposure guidelines, use only the housings supplied by
19
Getting Started
Motorola with your C330 series CDMA phone, or a
housing approved by Motorola for use with your CDMA
phone. Use of housings not supplied by Motorola, or
not approved by Motorola for use with your C330
series CDMA phone, may cause the phone-housing
combination to exceed FCC RF exposure guidelines.
Removing a Cover and Keypad
Do This
1
Press down on the
cover release
button at the top of
your phone.
2
Pull the top of the
phone’s back
cover to release it.
Note:
If the cover has a removable side band,
remove it at this point.
3
Pull the side tabs
away from the
phone, then
4
Lift up on the
bottom of the
phone to pull it out
of the front cover.
Release
button
Side
band
Side tabs
20
Getting Started
Note:
Always use Motorola Original™ covers. The
phone warranty does not cover damage caused
from using non-Motorola accessories.
Installing a Cover and Keypad
Always use the keypad and side band (if applicable)
that matches the new cover.
Do This
Note:
If your phone has an end cap, install it before
attaching the front cover.
1
Place the keypad
in the new front
cover and slide the
top of the phone
into the top of the
new front cover.
2
Press the bottom of the phone into the front
cover until the side tabs snap into place.
Note:
If the cover has a removable side band,
attach it at this point.
3
Insert the bottom
of the back cover.
4
Press the top of
the back cover
down until it hooks
over the cover
release button.
1
2
3
4
21
Getting Started
Turning Your Phone On
Adjusting the Volume
Press right and left on the
S
to:
•
increase or decrease earpiece volume during a call
•
increase or decrease the ringer volume setting when
the idle display is visible
Tip:
At the lowest volume setting, press
S
down to
activate silent alert. Press up to reset ring alert.
•
Turn off an incoming call alert
To Turn Your Phone On
1
Press and hold
O
(the
End/Power key)
2
If necessary, enter your four-digit unlock code
and press
OK
(
+
) to unlock your phone
Note:
The unlock code is originally set to 1234.
(For more information, see “Locking and
Unlocking Your Phone” on page 36.)
End/
Power Key
22
Getting Started
Making a Call
Do not block the antenna while you are on a call.
Answering a Call
When you receive a call, your phone rings and/or vibrates
and displays an incoming call message.
Note:
If the phone is locked, unlock it to answer the call.
Viewing Your Phone Number
Press
M#
to view your number from idle. While you are
on a call, press
M
>
My Tel. Numbers
.
Press To
1
keypad keys dial the phone number
Tip:
If you make a mistake,
press
DELETE
(
-
) to delete
the last digit. Holding
DELETE
(
-
) clears all digits.
2
N
make the call
3
O
end the call and “hang up” the
phone when you are finished
Press To
1
N
or
ANSWER
(
+
)
answer the call
2
O
end the call and “hang up” the
phone when you are finished
23
Learning to Use Your Phone
Learning to Use Your
Phone
See page 1 for a basic phone diagram.
Using the Display
The idle display (shown below) is the standard display
when you are not on a call or using the menu.
The
G
(menu) indicator at the bottom center of the display
indicates you can press the menu key (
M
) to go to the
main menu to see more features.
Labels at the bottom corners of the display show the
current soft key functions. Press the left soft key (
-
) or
right soft key (
+
) to perform the function indicated by the
left or right soft key label.
12:00pm
E
1/1/04
PH.BOOK MESSAGE
59ã
Y
G
Clock
Menu Indicator
Soft Key Labels
24
Learning to Use Your Phone
At the top of the display are a number of status indicators:
➊
Signal Strength Indicator
Vertical bars show the
strength of the network connection. You cannot make or
receive calls when the
0
(no signal) indicator is displayed.
➋
Digital Signal Indicator
Shows when you
are receiving a digital signal.
➌
In Use Indicator
Shows that a call is in progress.
➍
Roam Indicator
Shows that your phone is
seeking or using another network system
outside your home network.
➎
Message Waiting Indicator
Displays when
you receive a text message.
12:00pm
E
PH.BOOK MESSAGE
U;gf
59ã
YJ
G
➐
Battery
Level
Indicator
➌
In Use
Indicator
➍
Roam
Indicator
➎
Message
Waiting
Indicator
➏
Voice
Message
Waiting
Indicator
➓
Ring Style Indicator
➊
Signal
Strength
Indicator
➋
Digital
Signal
Indicator
➑
Active
Line
Indicator
➒
ALI Indicator
25
Learning to Use Your Phone
➏
Voice Message Waiting Indicator
Appears
when you receive a voicemail message.
➒
ALI Indicator
Shows the status of the automatic
location information feature:
➐
Battery Level Indicator
Vertical bars show the
battery charge level. Recharge the battery when you
see
Low Battery
and hear the low battery alert.
➑
Active Line Indicator
Shows the current
active phone line.
➓
Ring Style Indicator
Shows the ring style setting.
Using the 4-Way
Navigation Key
Use the 4-way navigation key
like a joystick to navigate the
menu system, change feature
settings, and play games.
Tip:
Down and up are the primary movements within
menus. Move left and right to change feature settings,
navigate the datebook, and edit text.
ä
=ALI on
ã
=ALI off
Y
=loud
X
=soft
W
=vibrate
Z
= vibrate and ring
a
= silent
4-way
navigation
key
26
Learning to Use Your Phone
Using Menus
From the idle display, press
M
to display the main menu.
Select a Menu Feature
From the idle display, select a menu feature as follows:
This example shows that from the idle display, you must
press
M
, scroll to and select
Messages
from the main
menu, then scroll to and select
Create Message
. Use
S
to
Find the Feature
M
>
Messages
>
Create Message
Right Soft Key
Perform
functions
identified by
right display
prompt.
Menu Key
Power/End Key
Press & hold to
power phone
on & off.
Press &
release to end
phone calls
and exit
menus.
Send/Answer
Key
Make and
answer calls &
view recent
dialed calls.
Navigation Key
Scroll through
menus and
lists, and set
feature values.
Left Soft Key
Perform
functions
identified by
left display
prompt.
27
Learning to Use Your Phone
scroll, and use the left/right soft keys to select the functions
listed in the bottom left and right corners of the display.
Select a Feature Option
Some features require you to select an item from a list:
•
Press
S
to scroll up or down to highlight an item.
•
In a numbered list, press a number key to highlight the
item.
•
In an alphabetized list, press a key repeatedly to cycle
through the letters on the key and highlight the closest
matching list item.
•
When an item has a list of possible values, press
S
to the left or right to scroll and select a value.
•
When an item has a list of possible numeric values,
press a number key to set the value.
Dialed Calls
10)John Smith
9)Mary Smith
BACK VIEW
59
G
Press
BACK
(
-
)
to display
the previous
screen.
Press
M
to open
the sub-menu.
Highlighted
item
Press
VIEW
(
+
) to display
details for the highlighted item
28
Learning to Use Your Phone
Entering Text
Some features require you to enter information:
The message center lets you compose and send text
messages. A flashing cursor shows where text will appear:
Entry Details
Name:_____________
No.:_______________
CANCEL CHANGE
Press
S
to
scroll down.
Press
CANCEL
(
-
) to exit
without making changes.
DONE
(
-
) displays when
you enter or edit information.
Press
CHANGE
(
+
)
to edit the
information.
Highlighted
item
59
G
Entry Details
Name:_____________
No.:_______________
CANCEL CHANGE
59
G
Msg:
CANCEL INSERT
Press
INSERT
(
+
)
to view and
insert a
quick note.
Press
CANCEL
(
-
) to exit
without making changes.
Flashing
cursor
Press
M
to open
the sub-menu.
59
G
29
Learning to Use Your Phone
When you enter text using the standard tap method (see
page 30), the flashing cursor changes to a block cursor,
and the soft key functions change:
Choosing a Text Mode
Multiple text entry modes make it easy for you to enter
names, numbers, and messages.
Press
M
from any text entry screen to select a text mode:
Note:
The text mode you select remains active until you
select another mode.
iTAP
(
é
)
Let the phone predict each word as you
enter it (see page 31).
Tap Method
(
t
)
Enter letters, numbers, and symbols by
pressing a key one or more times (see
page 30).
Numeric
(
è
)
Enter numbers only.
Symbol
(
ê
)
Enter symbols only (see page 35).
Msg:
T
DELETE OK
Press
OK
(
+
)
to accept
and store
the text.
Press
DELETE
(
-
)
to clear the last letter.
Block cursor
indicates
current
highlighted
character.
After 2 seconds, the block
cursor reverts to a flashing
cursor and moves to the
next position.
59
G
30
Learning to Use Your Phone
Using Tap Method
This is the standard mode for entering text on your phone.
Press
M
from a text entry screen and select
Tap Method
.
Tap Method Text Entry Rules
•
Press a number key repeatedly to cycle through its
characters. See “Character Chart” on page 31.
•
If you do not press a key for 2 seconds, the character
in the block cursor is accepted, and the cursor moves
to the next position.
•
Press
S
left or right to move the flashing cursor to
the left or right in a text message.
•
The first character of every sentence is capitalized.
Press
S
down to force the character to lowercase
while it is highlighted by the block cursor.
•
Your phone may support multiple languages. The
current language setting determines whether a new
message begins on the left or right side of the display.
You can switch languages within a message. Press
M
to select the text mode and language you want to use.
Press To
1
A number key 1
or more times
select a letter, number, or
symbol shown in the
“Character Chart” on page 31
2
Number keys enter the remaining
characters
3
OK
(
+
) store the text
31
Learning to Use Your Phone
•
If you enter or edit information and do not want to save
your changes, press
O
to exit without saving.
•
Press and hold a number key to cycle between tap
method and numeric text entry mode.
Character Chart
Use this chart as a guide for entering characters with the
tap method.
Note:
This chart may not reflect the exact character set
available on your phone.
Using iTAP™ Software Text Entry Method
iTAP™ software is a predictive text entry method that lets
you enter a word using one keypress per letter.
Press
M
from any text entry screen and select
iTAP
.
1
space . 1 ? ! , @ _ & ~ : ; " -
( ) ' ¿ ¡ % £ $ ¥
2
a b c 2 ä å á à â ã
α
β
ç
3
d e f 3
δ
ë é è ê
ε
φ
4
g h i 4 ï í î
γ
η
ι
5
j k l 5
κ
λ
6
m n o 6 ñ ö ø ó ò ô õ
µ
υ
ω
7
p q r s 7
π
ß
σ
8
t u v 8
θ
ü ú ù û
τ
9
w x y z 9
ξ ψ
0
+ - 0 x * / \ [ ] = > < # §
32
Learning to Use Your Phone
Note:
You can switch languages within a message in iTAP
text mode. Press
M
to select the language.
Entering Words
Do This To
1
Press a number
key one time
enter the first letter of the
word
The letters associated with
the key are shown at the
bottom of the display.
2
Press number
keys (one per
letter)
enter the rest of the word
Alternative words and letter
combinations are shown at
the bottom of the display. The
word choices are updated
with each keypress.
3
Press
S
highlight the word you want
4
Press
SELECT
(
+
)
enter the word at the flashing
cursor
A space is automatically
inserted after the word.
33
Learning to Use Your Phone
For example, to spell the word “art,” press
2
7
8
.
The display shows:
Entering Novel Words
If the word you want is not displayed by the iTAP software:
Do This To
1
Press
DELETE
(
-
)
one or more times
delete letters until you
see a letter combination
that matches the start of
the word
2
Press
S
left or right highlight the letter or
letter combination
3
Press
SELECT
(
+
),
then press
S
to the
left
shift the cursor to the left
and “lock” the selected
word portion
4
Continue to enter
letters and highlight
letter combinations
spell the word
Art Apt Cpu Cst Cru
c
DELETE SELECT
Press
SELECT
(
+
) to
insert the highlighted word.
Press
DELETE
(
-
)
to clear the last letter.
Flashing
cursor
indicates
insertion
point.
Press
S
to
see additional
word choices.
59
G
34
Learning to Use Your Phone
Entering Punctuation
Using Capitalization
The first word of a sentence is automatically
capitalized, with the words that follow in lowercase.
Entering Numbers
Press To
0
or
1
enter punctuation or other
characters (see “Character
Chart” on page 31).
Press To
S
up or down change the words to initial
character capitalized, all
uppercase characters, or all
lowercase characters
Do This To
1
Enter the first
digit and then
highlight it
put the iTAP software in
number entry mode
2
Press number
keys
add digits to the number
3
Press
SELECT
(
+
)
enter the number
35
Learning to Use Your Phone
Deleting Letters and Words
Place the cursor to the right of the text you want to delete,
and then:
Using Symbol Mode
To enter symbol characters in a message, press
M
from any text entry screen and select
Symbol
.
Do This To
Press
DELETE
(
-
) delete one letter at a time
Hold
DELETE
(
-
) delete the entire message
Do This To
1
Press a number
key one time
display its symbol options at
the bottom of the display
See “Symbol Chart” on
page 36.
2
Press
S
or
Press the
number key
repeatedly
highlight the symbol you want
3
Press
SELECT
(
+
)
enter the symbol
36
Learning to Use Your Phone
Symbol Chart
Use this chart as a guide for entering characters in symbol
mode.
Locking and Unlocking Your
Phone
You can lock your phone manually or set the phone to lock
automatically whenever you turn it off.
A locked phone still rings or vibrates for incoming calls or
messages, but you must unlock it to answer. To use a
locked phone, enter the unlock code.
You can make emergency calls on your phone even when
it is locked. For more information, see page 46.
1
space . ? ! , @ _ & ~ : ; " - ( ) ' ¿ ¡ % £ $ ¥
2
@ _ \
3
/ : ;
4
" & '
5
( ) [ ] { }
6
¿ ¡ ~
7
< > =
8
$ £ ¥
9
# % *
0
+ - x * / = > < # §
37
Learning to Use Your Phone
Lock Your Phone Manually
Unlock Your Phone
Tip:
Your phone’s unlock code is set to 1234 at the
factory. Many service providers reset the unlock code to
the last four digits of your phone number.
At the
Enter Unlock Code
prompt:
Set Your Phone to Lock Automatically
You can set your phone to lock every time you turn it off.
Find the Feature
M
>
Settings
>
Security
>
Phone Lock
>
Lock Now
Press To
1
keypad keys enter your unlock code
2
OK
(
+
) lock the phone
Press To
1
keypad keys enter your unlock code
2
OK
(
+
) unlock your phone
Find the Feature
M
>
Settings
>
Security
>
Phone Lock
>
Automatic Lock
>
On
Press To
1
keypad keys enter your unlock code
2
OK
(
+
) activate automatic lock
38
Learning to Use Your Phone
Changing a Code or Password
Your phone’s four-digit unlock code is set to 1234, and the
six-digit security code is set to 000000 at the factory. Your
service provider may reset these numbers before you
receive your phone.
If your service provider has not reset these numbers, we
recommend that you change them to prevent others from
accessing your personal information. The unlock code
must contain four digits, and the security code must
contain six digits.
To change a code or password:
If You Forget a Code or
Password
If you forget your security code, contact your service
provider.
If you forget your unlock code, try entering 1234 or the last
four digits of your phone number. If that does not work, at
the
Enter Unlock Code
prompt:
Find the Feature
M
>
Settings
>
Security
>
New Passwords
Press To
1
M
display the unlock code
bypass screen
2
keypad keys enter your security code
3
OK
(
+
) submit your security code
39
Learning to Use Your Phone
Locking and Unlocking the
Keypad
You can lock the keypad to prevent accidental keypresses
(for example, when carrying your phone in a purse or
pocket).
Note:
Incoming calls and messages unlock the keypad.
Press To
M*
lock or unlock your keypad
40
Setting Up Your Phone
Setting Up Your Phone
Storing Your Name and Phone
Number
To store or edit the name and phone number
information on your phone:
Setting the Time and Date
To use the datebook, you must set the time and date.
Setting a Ring Style
Your phone rings or vibrates to notify you of an incoming
call or other event. This ring or vibration is called an alert.
You can select one of five different ring styles:
Find the Feature
M
>
Settings
>
Phone Status
>
My Tel. Numbers
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Time and Date
Y
= loud
X
=soft
W
=vibrate
Z
=vibrate and ring
aA
=silent
41
Setting Up Your Phone
The ring style indicator in the display shows the current
ring style (see page 24).
To set a ring style:
Each ring style contains settings for specific event alerts,
ringer ID, and ringer and keypad volume.
To change these settings:
Setting Answer Options
You can use different methods to answer an incoming call.
The
Answer Options
menu includes:
Setting a Wallpaper Image
You can set a picture or an animation as a wallpaper
(background) image in your phone’s idle display.
Find the Feature
M
>
Ring Styles
>
Style
Press To
1
S
scroll to the ring style
2
SELECT
(
+
) select the ring style
Find the Feature
M
>
Ring Styles
>Style
Detail
Find the Feature
M
>
Settings
>
In-Call Setup
>
Answer Options
Multi-Key
answer by pressing any key
42
Setting Up Your Phone
Note:
When you set an animation as a wallpaper image,
only the first frame of the animation is displayed.
Setting a Screen Saver Image
You can set a picture or an animation as a screen saver
image. The image displays when the phone detects no
activity for a specified time.
The screen saver image fills the display. An animation
repeats for one minute, then the first frame of the
animation displays.
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Wallpaper
Setting Description
select the picture or animation for the
background image in your idle display
Layout
select
Center
or
Tile
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Screen Saver
Setting Description
select the picture that appears when
your phone is idle
Delay
select how long your phone must be
idle before the screen saver picture
appears
43
Setting Up Your Phone
Zooming In and Out
Press and release
M
, then press and hold
M
to zoom in
and out on the display. Zoom in to increase text size, zoom
out to display more information.
You can also zoom in and out from the menu:
Setting Display Contrast
Adjusting the Backlight
You can set the amount of time that the display backlight
remains on, or turn off the backlight to conserve battery
power.
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Zoom
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Contrast
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Backlight
44
Calling Features
Calling Features
For basic instructions on how to make and answer calls,
see page 22.
Changing the Active Line
Change the active phone line to make and
receive calls from your other phone number.
The active line indicator in the display shows the current
active phone line (see page 24).
Redialing a Number
If you hear an ordinary busy signal:
Using Automatic Redial
If the network is busy, you hear a fast busy signal, and your
phone displays
Call Failed
.
Find the Feature
M
>
Settings
>
Phone Status
>
Active Line
Press To
1
O
hang up
2
N
redial the busy number
45
Calling Features
With automatic redial, your phone automatically redials the
number for four minutes. When the call goes through, your
phone rings or vibrates one time, displays
Redial Successful
, and then connects the call.
You must turn on automatic redial to use the feature. To
turn automatic redial on or off:
When automatic redial is turned off, you can manually
activate the feature to redial a phone number. When you
hear a fast busy signal and see
Call Failed
:
Using Caller ID
Calling line identification (caller ID) displays
the phone number for incoming calls.
The phone displays the caller’s name when
the name is stored in your phonebook, or
Incoming Call
when caller ID information is not available.
Canceling an Incoming Call
While the phone is ringing or vibrating:
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Auto Redial
Press To
N
or
RETRY
(
+
) activate automatic redial
Press To
O
or
IGNORE
(
-
) cancel the incoming call
46
Calling Features
Depending on your phone settings and/or
service subscription, the call may be forwarded
to another number, or the caller may hear a busy
signal.
Turning Off a Call Alert
You can turn off your phone’s incoming call alert before
answering the call.
Calling an Emergency Number
Your service provider programs one or more emergency
phone numbers, such as 911, that you can call under any
circumstances, even when your phone is locked.
Note:
Emergency numbers vary by country. Your phone’s
preprogrammed emergency number(s) may not work in all
locations, and sometimes an emergency call cannot be
placed due to network, environmental, or interference
issues.
Viewing Recent Calls
Your phone keeps a list of the calls you recently received
and dialed, even if the calls did not connect. The lists are
Press To
S
up or down turn off the alert
Press To
1
keypad keys dial the emergency number
2
N
call the emergency number
47
Calling Features
sorted from newest to oldest, and contain up to 10 entries.
The oldest entries are deleted as new ones are added.
Shortcut:
From the idle display, press
N
to display the
dialed calls list.
Find the Feature
M
>
Recent Calls
Press To
1
S
scroll to
Received Calls
or
Dialed Calls
2
SELECT
(
+
) select the list
3
S
scroll to an entry
Note:
\
means the call
connected.
4
N
or
VIEW
(
+
)
or
M
call the entry’s number
Tip:
Press and hold
N
for
2 seconds to send the
number as DTMF tones
during a call.
view entry details
open the
Last Calls
menu to
display other options as
described in the following list
48
Calling Features
The
Last Calls
menu can include the following options:
Returning an Unanswered
Call
Your phone keeps a record of your unanswered calls,
and displays:
•
the
N
(missed call) indicator
Option Description
Store
Create a phonebook entry with
the number in the
No.
field.
Delete
Delete the entry.
Delete All
Delete all entries in the list.
Send Message
Open a new text message with
the number in the
To
field.
Add Digits
Add digits after the number.
Attach Number
Attach a number from the
phonebook or recent call lists,
after the highlighted number.
Send Tones
Send the number to the network
as DTMF tones.
This option is only available
during a call.
49
Calling Features
•
X Missed Calls
Y Unknown
, where
X
is the total
number of missed calls and
Y
is the number of missed
calls with no caller ID information
Using the Notepad
Your phone stores the most recent number entered on the
keypad in a temporary notepad. This can be a phone
number that you called, or a number that you entered but
did not call. To retrieve the number stored in the notepad:
Press To
1
VIEW
(
+
) see the received calls list
2
S
select a call to return
3
N
make the call
Find the Feature
M
>
Recent Calls
>
Notepad
Press To
N
or
M
or
STORE
(
+
)
call the number
open the
Dialing Menu
to
attach a number or insert a
special character
create a phonebook entry
with the number in the
No.
field
50
Calling Features
Attaching a Number
While dialing (with digits visible in the display):
Calling With Speed Dial
Each entry you store in your phonebook is assigned a
unique speed dial number. To speed dial a phonebook
entry:
Calling With One-Touch Dial
To call phonebook entries 1 through 9, just press and hold
the one-digit speed dial number for 1 second.
We recommend that you reserve phonebook entry 1
(speed dial number 1) for storing and dialing your
Press To
M
>
Attach Number
attach a number from the
phonebook or recent call lists
Press To
1
keypad keys enter the speed dial number
for the entry you want to call
2
#
submit the number
Note:
Some
networks let you
skip this step for
speed dial
numbers 1 through 99.
3
N
call the entry
51
Calling Features
voicemail number. Your service provider may have already
done this for you.
Using Voicemail
You can listen to your voicemail messages by
calling your network voicemail phone number.
Voicemail messages are stored on the
network—not on your phone.
Storing Your Voicemail Number
Storing your voicemail number on your phone makes it
easy for you to listen to new voicemail messages. Usually,
your service provider has already done this for you.
Note:
You cannot store
Pause
,
Wait
, or
n
characters in
this number. If you want to store your voicemail number
with these characters, create a phonebook entry for it.
Then, you can use the entry to call your voicemail. For
more about these characters, see page 70.
Find the Feature
M
>
Messages
M
>
VoiceMail Setup
Press To
1
keypad keys enter your voicemail number
2
OK
(
+
) store the number
52
Calling Features
Receiving a Voicemail Message
When you receive a voicemail message, your phone
displays the
f
(voice message waiting) indicator and a
New VoiceMail
notification.
Listening to a Voicemail Message
The phone calls your voicemail number. If no voicemail
number is stored, your phone prompts you to store one.
Shortcut:
If your voicemail number is also stored as
phonebook entry number 1, you can press and hold
1
to
listen to your voicemail message(s).
Turning Off the Voice Message Waiting
Indicator
To clear the
f
(voice message waiting) indicator:
Muting the Phone
To mute your phone during a call, press
MUTE
(
+
) (if
available) or
M
>
Mute
.
Press To
CALL
(
+
) listen to the message(s)
Find the Feature
M
>
Messages
>
VoiceMail
Find the Feature
M
>
Messages
M
>
Clear Count
53
Calling Features
Using Call Waiting
When you are on a call, an alert tone sounds to
indicate that you have received a second call.
Press To
1
N
answer the new call
2
N
switch back to the first call
54
Messages
Messages
You can send and receive text messages,
pictures, and ring tones with your wireless
phone. Text messages that you receive can
contain ring tones that you can store on your
phone.
Setting Up the Text Message
Inbox
Your message inbox must be set up before you can send
and receive messages.
Note:
Your service provider may have already set up the
message inbox for you.
Sending Messages, Pictures,
and Sounds
Note:
Your message inbox must be set up before you can
send and receive messages (see page 54).
Find the Feature
M
>
Messages
M
>
Inbox Setup
Setting Description
Cleanup
number of days you want to
keep messages in the
inbox, or number of
messages you want to keep
55
Messages
You can send text messages and pictures or sounds to
one or more recipients. You can manually enter each
recipient’s phone number or email address, or select
numbers/addresses from the phonebook or recent calls
lists.
When you manually enter multiple numbers/addresses,
you must insert a space between each entry. Press
S
to
the right to insert a space.
Shortcut:
Enter a phone number in the idle display, then
press
M
>
Send Message
to create a text message
addressed to the number entered.
Find the Feature
M
>
Messages
M
>
Create Message
Press To
1
keypad keys enter the text message (see
page 28)
To insert a picture, animation,
or sound file in the message,
press:
M
>
Insert
> object type
>object
(see page 56)
2
OK
(
+
) store the message contents
and open the address editor
56
Messages
Inserting Picture or Sound Files
Notes:
•
The recipient’s phone may be unable to display the
pictures or play the sounds in your message.
•
You cannot send pictures or sounds to an email
address.
3
keypad keys enter one or more phone
numbers or email addresses
where you want to send the
message
Tip:
Press
S
to the right to
add a space between each
number/address that you
enter manually.
or
BROWSE
(
+
) select numbers/addresses
from the phonebook or recent
calls lists
4
OK
(
+
) store the numbers/addresses
5
DONE
(
-
) finish the message
6
SELECT
(
+
) select
Send Message
Note:
You can scroll down to
select
Save to Drafts
Press To
57
Messages
Enter your message as usual. When you want to insert a
picture or sound:
Inserted pictures and animations appear in the message,
while ring tones are represented by a
p
(sound file)
indicator.
Note:
You cannot send or forward some downloaded
objects (such as those you pay for). These objects do not
appear in the selection lists for attachments.
Viewing or Deleting an Inserted File
To view or delete an image or sound file in a message you
are typing:
Press To
1
M
open the
Message Menu
2
S
scroll to
Insert
3
SELECT
(
+
) display a list of items you can
insert
4
S
scroll to
,
Animation
, or
Sound
5
SELECT
(
+
) select the file type
6
S
highlight the file you want
7
VIEW
(
+
) or
PLAY
(
+
)
preview the file
8
INSERT
(
+
) insert the file
Press To
1
S
place the cursor to the right of
the file type indicator
58
Messages
Sending a Quick Note Text
Message
Quick notes are pre-written text messages that you can
insert into a message and send quickly (for example,
Call me at ...
). You can also create new quick notes.
The
Quick Note Menu
can include the following options:
2
S
to the left highlight the file type indicator
3
SELECT
(
+
)
oror
DELETE
(
-
)
view or play the inserted file
delete the inserted file
Find the Feature
M
>
Messages
>
Quick Notes
Press To
1
S
scroll to the quick note
2
READ
(
+
) read the quick note
or
M
open the
Quick Note Menu
to
perform other procedures as
described in the following list
Option Description
New
Create a new quick note.
Edit
Edit the quick note.
Press To
59
Messages
Viewing the Status of Sent
Text Messages
Text messages that you send are stored in the outbox.
Messages in the outbox are sorted from newest to oldest.
The following indicators show message status:
Receiving Messages, Pictures,
and Sounds
Note:
Your message inbox must be set up before you can
send and receive messages. See page 54.
When you receive a new message, your phone displays
the
g
(message waiting) indicator and
New Message,
and
gives an alert.
Delete
Delete the quick note.
Send
Open a new message with the quick note
in the Msg field.
Find the Feature
M
>
Messages
>
Outbox
<
= sending in progress
h
= delivered
>
= sending failed
Press To
1
READ
(
+
) open the message (or your
text message inbox if there
are multiple messages)
Option Description
60
Messages
If reminders are turned on, your phone sends a reminder
at regular intervals until you close the new message
notification, read the message, or turn off your phone.
When your phone displays
Memory is Full!
, you must
delete some existing messages from your inbox,
outbox, or drafts folder to receive new messages.
Storing Picture or Sound Files
Text messages that you receive can contain pictures,
animations, and ring tones. Pictures and animations are
displayed as you read the message. A ring tone begins
playing when you scroll to or select the
p
(sound file)
indicator.
You can store these embedded object files on your phone,
and use them as screen saver images, wallpaper images,
and event alerts. While reading the message:
Press To
1
S
up or down highlight the file in the
message
2
M
open the
Text Msg Menu
3
S
scroll to
Store
4
SELECT
(
+
) display a list of items you can
store
5
S
scroll to
File Attachment
6
SELECT
(
+
) display the file name
7
STORE
(
+
) view storage options
61
Messages
Note:
When you set an animation as a wallpaper image,
only the first frame of the animation displays.
For more information about using pictures and animations,
see page 117. For more information about using ring
tones, see page 74.
Reading, Locking, or Deleting a
Text Message
Messages in the text message inbox are sorted from
newest to oldest.
8
S
scroll to
Store Only
,
Set as Screen Saver
,
Set as Wallpaper
, or
Set as Ring Tone
9
SELECT
(
+
) store the file and, optionally,
set it as your screen saver,
wallpaper image, or ring tone
If you select
Set As Ring
Tone
, your phone displays
Set As Which?
Select the event for the ring
tone, and enter a name for
the tone.
Find the Feature
M
>
Messages
>
Inbox
Press To
62
Messages
Press To
1
S
scroll to the message
(
i
= unread,
j
= read,
{
= read and
locked)
The following indicators show
message status:
i
unread
n
unread (with
attachment)
j
read
l
read (with attachment)
{
read and locked
o
read and locked (with
attachment)
2
READ
(
+
) open the message
3
BACK
(
-
) close the message
or
REPLY
(
+
) open a new message, with
the sender’s
Reply To
number or email address in
the
To
field.
or
M
open the Inbox Menu to
perform other procedures as
described in the following list
63
Messages
The
Inbox Menu
can include the following options:
Option Description
Delete
Delete the message.
Call Back
Call the number in the message
header or embedded in the
message.
Reply
Open a new text message, with
the sender’s
Reply To
number or
email address in the
To
field.
Forward
Open a copy of the text
message, with an empty
To
field.
Chat
Open a chat session with the
message sender
Lock
Lock the message so that
cleanup does not delete it.
Store
Display a list of items that can
be stored, including the sender’s
number or email address, and a
selected image or sound file.
See page 60.
Delete All
Delete all inbox messages.
Cleanup
Delete all unlocked messages,
or all unlocked and read
messages.
New Message
Open a new text message.
Setup
Open the text message inbox
setup menu.
64
Messages
Reading Browser Alerts
Your network’s Web server can send you browser
alerts that you can read in your micro-browser.
When you receive a browser alert message, your
phone displays the
g
(message waiting) indicator and
a
New Browser Message
notification, and sounds an alert.
To view your browser alert messages at any time:
Reading Information Service
Messages
Information service messages are broadcast
messages that you can receive, such as stock
updates or news headlines.
Press To
GO TO
(
+
)
or
EXIT
(
-
)
launch the micro-browser and
view the message
close the new message
notification
Find the Feature
M
>
Messages
>
Browser Alerts
Press To
1
S
scroll to a message
2
SELECT
(
+
) open the message
65
Messages
Your information services message inbox must be set up
before you can receive information services messages.
The number of messages the inbox can hold depends
on the length of the messages, and the number of
other messages and drafts stored on your phone.
Setting Up the Information Services
Message Inbox
You must set up your information services message inbox
before you can receive information services messages.
Note:
Your service provider may have already set up the
information services inbox for you.
To set up the information services inbox, you must
configure the following settings. Contact your service
provider to obtain the following information, if necessary.
Actual field names and values may vary depending on the
technologies available to your service provider. Some
settings may not be available for all phone models.
Find the Feature
M
>
Messages
M
>
Info Srvc Setup
Setting Description
Service
select
Yes
or
No
to turn
broadcasts on or off
Active Channels
set the subscription
channels
Quick View
enter or edit the quick view
channel number
66
Messages
Receiving an Information Services
Message
Note:
Your information services message inbox must be
set up before you can receive information services
messages. See page 65.
Receiving Long Messages
If the new message is a
long information services
message
, your phone displays the
g
(message waiting
indicator) and
New Message,
and gives an alert. To view
the new message, see page 59. To read, lock, or delete an
existing message, see page 61.
Save Q. View
select whether to save
single-line quick view
messages in the inbox
Language
select the language(s) in
which you want to accept
broadcasts
Cleanup
select the number of days
to keep messages in the
inbox, or the number of
messages to keep
Setting Description
67
Messages
Receiving Quick View Messages
If the new message is a short quick view message, it
appears directly in your display.
If the message is more than two lines, you can press
SAVE
(
-
) to save it in your information services inbox. To
automatically save quick view messages, or change the
channels that send messages, change your information
services setup on page 65.
Do This To
Read the message
and press
O
read and delete the quick
view message
68
Setting Up Your Phonebook
Setting Up Your
Phonebook
You can store a list of names and phone numbers or email
addresses in your phone’s electronic phonebook.
To see the names in your phonebook, press
M
>
Phonebook
from the idle display. Scroll to a name
and press
VIEW
(
+
) to view details of the phonebook
entry as shown in the following display.
Shortcut:
In idle, press
S
up or down to open the
Phonebook.
Viewing Entry Details
Note:
Email Address
entries do not have
Type
, or
Ringer ID
information.
T
Carlo
Emrys
5551212
Speed No.15#(P)
G
59
Entry’s
phone
number
or
email
address
.
Type
indicator
identifies
number
type:
T
Work
P
Home
O
Main
Q
Mobile
S
Fax
R
Pager
h
Email
Entry’s
Name
Edit entry
Press
M
to open the
Phonebook Menu
Return
to list
69
Setting Up Your Phonebook
Creating a Phonebook Entry
Entering Information
To create or edit a phonebook entry:
Shortcut:
Enter a phone number in the idle display,
then press
STORE
(
+
) to create a phonebook entry
with the number in the
No.
field.
A phone number or email address is required for a
phonebook entry. All other information is optional. You can
enter the following information for a phonebook entry
Find the Feature
M
>
Phonebook
M
>
New
>
Phone Number
or
Email Address
Phonebook item Description
Name
entry name
Tip:
Press
M
to select a text
entry mode. See page 28.
No.
or
Email
entry’s phone number or
email address (maximum 32
characters)
Type
entry type
Note:
This option is not
available for email entries.
Speed No.
entry’s default speed dial
number (select to change)
70
Setting Up Your Phonebook
Completing a Phonebook Entry
When you are finished entering information for a
phonebook entry:
Storing a PIN Code With a
Phone Number
You can store a PIN code with the phone number for calls
that require additional digits (for example, to make a
calling card call, or to retrieve voicemail or answering
machine messages). Insert one or more of the following
Ringer ID
the alert your phone should
use when you receive calls or
messages from this entry
More
create another entry with the
same
Name
You must use a different
Type
identifier for each number.
Press To
DONE
(
-
) store the entry
Phonebook item Description
71
Setting Up Your Phonebook
characters in the dialing sequence to ensure that the
number dials and connects properly:
Note:
You can store a maximum of 32 digits per number
for a phonebook entry stored on the phone. Each
character counts as one digit.
Press To
M
>
Insert Pause
inserts a
p
(pause) character
Your phone dials the
preceding digits, waits for the
call to connect, then sends
the remaining digit(s).
Note:
If your network does
not recognize the first pause
character, try two (
pp
).
M
>
Insert Wait
inserts a
w
(wait) character
Your phone dials the
preceding digits, waits for the
call to connect, then prompts
you for confirmation before it
sends the remaining digit(s).
M
>
Insert 'n'
inserts an
n
(number)
character
Your phone prompts you for a
number before dialing the
call. The number you enter is
inserted into the dialing
sequence in place of the
n
character
72
Setting Up Your Phonebook
Dialing a Phonebook Entry
Use the following procedure to call a number (or send a
text message to an email address) stored in your
phonebook.
Note:
You can also use speed dial or 1-touch dial. See
page 50.
Editing a Phonebook Entry
Edit the entry as described on page 69.
Tip:
Press
M
to open the Phonebook Menu to perform
various operations on the selected entry.
Find the Feature
M
>
Phonebook
Press To
1
keypad key
letters
jump to entries that begin
with that letter (optional)
2
S
scroll to the entry you want
3
N
call the entry
Find the Feature
M
>
Phonebook
Press To
1
S
scroll to the entry
2
VIEW
(
+
) view entry details
3
EDIT
(
+
) edit the entry
73
Setting Up Your Phonebook
Deleting a Phonebook Entry
Sorting Phonebook Entries
You can sort your phonebook list by speed dial number
(the standard), name, or email address.
Find the Feature
M
>
Phonebook
Press To
1
S
scroll to the entry
2
M
open the
Phonebook Menu
3
S
scroll to
Delete
4
SELECT
(
+
) delete the entry
Find the Feature
M
>
Phonebook
Press To
1
M
open the
Phonebook Menu
2
S
scroll to
Setup
3
SELECT
(
+
)select
Setup
4
S
scroll to
Sort by
5
CHANGE
(
+
)select
Sort by
6
S
scroll to the sort order
7
SELECT
(
+
) select the sort order
74
Personalizing Your Phone
Personalizing Your
Phone
Personalizing a Ring Style
You can change the alerts that notify you of events such as
incoming calls, text messages, etc. Any changes you make
are saved to the current ring style.
Note:
Alert represents the current alert style.
To create new alert tones, see page 75.
Activating Ringer IDs
When ringer IDs are turned on, your phone uses distinctive
ringer alerts to notify you of incoming calls or messages
from specific entries stored in your phonebook.
Find the Feature
M
>
Ring Styles
>Alert
Detail
Press To
1
S
scroll to the event
2
CHANGE
(
+
) select the event
3
S
scroll to the alert you want
4
SELECT
(
+
) select the alert
Find the Feature
M
>
Ring Styles
>Alert
Detail
>
Ringer IDs
>
On
or
Off
75
Personalizing Your Phone
Note:
Alert represents the current ring style.
To assign a ringer ID to a new or existing phonebook entry,
see page 69.
Setting Ringer or Keypad
Volume
Note:
Alert represents the current ring style.
Setting Reminders
A reminder is an alert that rings or vibrates at regular
intervals to notify you about a voicemail, text, email, or
chat message that you have received.
Note:
Alert represents the current ring style.
Creating Alert Tones
You can create and store custom alert tones on your
phone. The tones appear in the list of available alerts.
Find the Feature
M
>
Ring Styles
>Alert
Detail
>
Ring Volume
or
Key Volume
Find the Feature
M
>
Ring Styles
>Alert
Detail
>
Reminders
>
Beep
,
Vibrate
, or
Off
76
Personalizing Your Phone
Creating a Tone
Editing a Tone
You cannot edit the standard alert tones included with your
phone. To edit a custom tone that you created:
Find the Feature
M
>
Ring Styles
>
My Tones
>
[New Tone]
Press To
1
CHANGE
(
+
) select
Notes
2
S
enter notes for the tone
3
OK
(
+
) store the notes
4
CHANGE
(
+
) select
Name
5
keypad keys enter the name for the tone
6
OK
(
+
) store the name
7
DONE
(
-
) store the tone
Find the Feature
M
>
Ring Styles
>
My Tones
Press To
1
S
scroll to the tone
2
EDIT
(
+
) open the tone details
3
S
scroll to
Name
or
Notes
4
CHANGE
(
+
) select the details
5
keypad keys enter new text or notes
77
Personalizing Your Phone
Deleting a Tone
You cannot delete the standard alert tones included with
your phone. To delete a custom tone that you created:
Personalizing Display Text
To change the text displayed when you turn on
your phone:
Personalizing the Menu
You can reorder the items in your phone’s main menu.
6
OK
(
+
) store the details
Find the Feature
M
>
Ring Styles
>
My Tones
Press To
1
S
scroll to the tone
2
M
open the
My Tones Menu
3
S
scroll to
Delete
4
SELECT
(
+
) delete the tone
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Greeting
Press To
78
Personalizing Your Phone
Note:
You cannot alter the location of the
More
(
>
)
graphic icon. This icon remains in the introductory menu
display to provide access to additional menu features.
Personalizing Soft Keys
You can relabel the soft keys (left
-
and right
+
) to
access different main menu items from the idle display.
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Main Menu
Press To
1
S
scroll to a menu item
2
GRAB
(
-
) grab the menu item
3
S
move the item to a new
location in the menu
4
INSERT
(
-
) insert the menu item
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Keys
Press To
1
S
scroll to
Left
or
Right
2
CHANGE
(
-
) select the key
3
S
scroll to a menu feature
4
SELECT
(
-
) confirm the menu feature
79
Personalizing Your Phone
Setting the Menu Language
Set the language in which menu features and options are
displayed.
Setting Menu Scroll Behavior
Set the highlight bar to stop or wrap around when you
reach the top or bottom of a menu list.
Setting Menu Animation
Menu animation provides smooth scrolling of the highlight
bar and menu items as you scroll through a menu list. Turn
off menu animation to extend battery life.
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Language
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Scroll
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Animation
80
Personalizing Your Phone
Resetting All Options
You can reset all options back to their factory settings
except for the unlock code, security code, and lifetime
timer.
Clearing All Information
You can reset all options back to their factory settings
except for the unlock code, security code, and lifetime
timer and clear all user entries (such as Phonebook
entries and downloaded wallpapers, screen savers,
and sounds).
Caution:
Master clear erases all user-downloaded
content and user-entered information stored in your
phone’s memory, including phonebook and datebook
entries. Once you erase the information, it cannot be
recovered. Master clear does not delete any information
stored on the SIM card.
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Master Reset
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Master Clear
81
Personalizing Your Phone
Using MyMenu
Your phone includes several standard shortcuts. You can
create additional custom shortcuts to frequently used
menu items.
Standard Shortcuts
The following shortcuts are pre-programmed in your
phone. You cannot edit or delete these shortcuts.
Do This To
Press
M
, then press
and hold
M
(within
two seconds)
zoom in/out on your phone
display
Press
M
*
in idle lock/unlock your keypad
Press
S
down when
your phone is ringing
switch to vibrate alert, then
silent alert
Press
S
up to cycle back
to vibrate alert, then ring
alert.
Press
M
#
in idle see your phone number
Press
N
in idle go to the dialed calls list
Press
O
exit the menu system and
return to the idle display
Press
S
up or down open the phonebook
82
Personalizing Your Phone
Creating a MyMenu Shortcut
To add a menu item to the MyMenu list, just select the
menu item and hold
M
until the phone asks you for a
confirmation.
Using a MyMenu Shortcut
You can use MyMenu from the idle display, while on a call,
or while scrolling through a menu. Just press
M
and then
the MyMenu key number (
1
through
99
).
To select a feature from the MyMenu list:
Note:
To edit or delete a MyMenu feature, highlight it in the
list and press
M
to open a menu of options for the
feature.
Editing or Deleting a Shortcut
The shortcut list is sorted by key. If you change a shortcut’s
key, you change its place in the list.
Find the Feature
M
>
MyMenu
> the feature
Find the Feature
M
>
Shortcuts
Press To
1
S
scroll to the shortcut
2
M
open the
Shortcut Menu
to
perform procedures as
described in the following list
83
Personalizing Your Phone
The
Shortcut Menu
can include the following options:
Option Description
Edit
Edit the shortcut.
Reorder List
Change the shortcut list order.
Delete
Delete the shortcut.
Delete All
Delete all shortcuts.
84
Getting More Out of Your Phone
Getting More Out of
Your Phone
Making a Three-Way Call
During a call, you can call and connect a third
party for a three-way call. You cannot do this if
you already have a call on hold.
Restricting Calls
You can stop all incoming and/or outgoing calls, or you
can restrict outgoing calls to the numbers stored in your
phonebook.
Notes:
•
You can make emergency calls when outgoing calls
are restricted.
Press To
1
keypad keys dial the third party’s number
Note:
Some networks might
require you to press
N
first.
2
N
call the number
3
N
connect the two calls
4
O
end the entire call
85
Getting More Out of Your Phone
•
Your phone still receives incoming text messages
when incoming calls are restricted.
Tip:
The phonebook is not locked when you restrict
outgoing calls to numbers stored in the phonebook. To
prevent a user from adding (and then calling) a new
phonebook entry, you may want to lock the phonebook.
See page 108.
Using TTY Mode
You can use an optional TTY device with your
phone to send and receive calls. You must plug the
TTY device into the phone’s headset jack and set
the phone to operate in one of three TTY modes.
Find the Feature
M
>
Settings
>
Security
>
Restrict Calls
Press To
1
keypad keys enter your unlock code
2
OK
(
+
)open the restrict calls menu
3
S
scroll to
Outgoing Calls
or
Incoming Calls
4
CHANGE
(
+
)select the option
5
CHANGE
(
+
)change the
Allow
setting
6
S
scroll to
All
,
None
, or
Phonebook
7
SELECT
(
+
)select the allowed calls
86
Getting More Out of Your Phone
Notes:
•
Use a TSB-121 compliant cable (provided by the TTY
manufacturer) to connect the TTY device to your
phone.
•
Set the phone volume to level 4 (middle setting) for
proper operation. If you experience a high number of
incorrect characters, adjust the volume as necessary
to minimize the error rate.
•
For optimal performance, your phone should be at
least 12 inches (30 centimeters) away from the TTY
device. Placing the phone too close to the TTY device
may cause high error rates.
Setting TTY Mode
When you set your phone to a TTY mode, it operates in
that mode whenever the TTY device is connected.
The
TTY Setup
menu includes the following options:
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
TTY Setup
Press To
1
S
scroll to
TTY Setup
2
CHANGE
(
+
) change the TTY mode
3
S
scroll to the TTY mode
4
SELECT
(
+
) select the TTY mode
TTY
Transmit and receive TTY characters
87
Getting More Out of Your Phone
When your phone is in a TTY mode, the international
TTY symbol and the mode setting are shown in the
display during an active digital TTY call. You can press
TTYMODE
(
-
) to change the mode setting.
Switching to TTY Mode During a Voice Call
Returning to Voice Mode
To return to normal voice mode, select
Voice
from the
TTY Setup
menu.
VCO
Receive TTY characters but transmit
by speaking into the microphone
HCO
Transmit TTY characters but receive
by listening to the earpiece
Voice
Return to normal voice mode
Press To
1
M
open the
Call
menu
2
S
scroll to
TTY Setup
3
SELECT
(
+
) display the
TTY Setup
menu
4
S
scroll to the TTY mode
5
SELECT
(
+
) select the TTY mode
v
88
Getting More Out of Your Phone
Setting Auto PIN Dial
Some networks require an authenticating PIN code to
allow outgoing calls. Use this feature to automatically dial
your PIN.
Using DTMF Tones
You can send numbers to the network as dual tone
multi-frequency (DTMF) tones during a call. Use DTMF
tones to communicate with automated systems that
require you to submit a PIN code or credit card number.
To set DTMF tones to be long, short, or off:
Short
sends a short fixed-duration tone for each keypress.
Long
sends each tone for as long as you depress the key.
Short DTMF tones work with most automated systems.
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Auto PIN Dial
Press To
M
>
Send Tones
send a number to the
network as DTMF tones, for
credit card calling or
password entry
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
DTMF
89
Getting More Out of Your Phone
Some systems (such as home answering machines) may
require long tones for proper activation.
Sending DTMF Tones
Using the Keypad
Press the number keys to send the numbers as DTMF
tones during a call.
To send numbers as long tones, make sure that DTMF is
set to
Long
. During a call, enter any single short keypress
to put the phone in DTMF mode, then send the required
numbers by pressing and holding each key in turn.
Sending Stored Numbers
During a call, highlight a number in the phonebook or
recent call lists, then:
Monitoring Phone Use
Viewing and Resetting Call Timers
Network connection time is the elapsed time
from the moment you connect to your service
provider’s network to the moment you end the
call by pressing
O
. This time includes busy
signals and ringing.
Press To
1
M
open the sub-menu
2
S
scroll to
Send Tones
3
SELECT
(
+
) send number as DTMF tones
90
Getting More Out of Your Phone
The amount of network connection time you track on
your resettable timer may not equal the amount of time
for which you are billed by your service provider. For
billing information, please contact your service
provider directly.
To view a call timer:
Select one of the following options:
Find the Feature
M
>
Recent Calls
>
Call Times
Timer Description
Last Call
Approximate spent on the last call
dialed or received. You cannot
reset this timer.
Dialed Calls
Approximate time spent on dialed
calls since the last time you reset
this timer.
Received Calls
Approximate time spent on calls
received since the last time you
reset this timer.
All Calls
Approximate time spent on dialed
and received calls since the last
time you reset this timer.
Lifetime
Approximate time spent on all
calls on this phone. You cannot
reset this timer.
91
Getting More Out of Your Phone
To reset the call timer:
Using Timers During a Call
You can set a timer to beep at selected intervals during a
call, and display elapsed time during a call.
Select one of the following
Beep
options:
Select one of the following
Display
options:
Press To
1
RESET
(
+
) reset the time (if available)
2
YES
(
-
) confirm the reset
Find the Feature
M
>
Settings
>
In-Call Setup
>
In-Call Timer
Option Description
60 Seconds
Beep at one-minute intervals
during a call.
Off
No in-call beep.
Option Description
Time
Display the approximate elapsed
time for the current call.
Off
No in-call timer display.
92
Getting More Out of Your Phone
Using Hands-Free Features
You can purchase an optional Motorola Original™
Easy-Install Hands-Free Kit for your car. This
accessory provides an alternative way for you to
use your phone without using your handset.
Note:
The use of wireless devices and their accessories
may be prohibited or restricted in certain areas. Always
obey the laws and regulations on the use of these
products.
Activating a Connected Speakerphone
To use an external speakerphone with your phone,
connect the speakerphone and, during an active call:
Setting Automatic Answer
You can set your phone to automatically answer calls
after 2 rings (4 seconds) when connected to the
Easy-Install Hands-Free Kit or a phone headset.
Press To
SPEAKER
(
+
) (if
available) or
M
>
Spkrphone On
activate the connected
speakerphone
Find the Feature
M
>
Settings
>
Other Settings
>
Car Settings
or
Headset
>
Auto Answer
93
Getting More Out of Your Phone
Setting Automatic Hands-Free
You can set up your phone to automatically route calls to
the Easy-Install Hands-Free Kit when it detects a
connection.
Setting Power-Off Delay
When your phone is connected to a car kit, you can set it to
stay on for a period of time after you switch off the ignition.
This prevents the phone from draining your vehicle battery,
but leaves the phone on long enough that you do not have
to re-enter your unlock code when making short stops.
Note:
This feature may not work with all car ignition
switches.
Caution:
If you select
Continuous
, the phone does not
power off when you turn off the ignition. Be careful not
to drain your vehicle battery if you select this option.
Setting Charger Time
When your phone is connected to a car kit, you can set it to
charge itself for a specified time period after you switch off
Find the Feature
M
>
Settings
>
Other Settings
>
Car Settings
>
Auto Handsfree
>
On
or
Off
Find the Feature
M
>
Settings
>
Other Settings
>
Car Settings
>
Power-Off Delay
>time delay
94
Getting More Out of Your Phone
the ignition. This helps ensure that the phone battery gets
fully charged while the vehicle is parked.
Note:
This feature may not work with all car ignition
switches.
Making Data and Fax Calls
An optional Motorola Original™ data kit lets you
transfer data between your phone and a computer
or other external device. You can:
•
Synchronize phonebook and datebook information
between your phone and a computer or PDA.
•
Use your phone as a modem to connect to the
Internet
•
Use your phone to make and answer data and fax
calls on your computer or hand-held device.
Making a Cable Connection
Installing the Software
To transfer data between your phone and computer, you
must install the software included with the Motorola
Original data kit. See the data kit’s user guide for more
information.
Find the Feature
M
>
Settings
>
Other Settings
>
Car Settings
>
Charger Time
>charge time
95
Getting More Out of Your Phone
Attaching the Cable
Use a Motorola Original USB cable to connect your phone
to the external device.
Note:
Your phone requires a mini-USB connector. Check
your computer or hand-held device to determine the type
of cable you need.
Synchronizing Data
You can synchronize phonebook and datebook information
between your phone, computer, and PDA with Starfish
TrueSync
®
software, a Motorola accessory product. See
the TrueSync user guide for more information.
Note:
TrueSync software is designed to synchronize with
basic features of many popular Personal Information
Management (PIM) software and hardware products.
Making a Data or Fax Call
Use this procedure to transfer data or a fax from a
connected device.
Connect your phone to the device and do the following:
Do This To
1
Check the phone make sure that the phone is
connected and powered on
96
Getting More Out of Your Phone
Receiving a Data or Fax Call
Use this procedure to transfer data or a fax to a connected
computer or hand-held device.
Setting Up Your Phone
Connect your phone to the device as described on
page 94.
Note:
You cannot answer incoming voice calls when your
phone is in data or fax mode. Any voice calls you receive
are treated as unanswered calls. To return a voice call,
2
Open the
application on
your computer
place the call through the
application (such as
dial-up-networking or fax)
Note:
You cannot dial data or
fax numbers through your
phone’s keypad. You must
dial them through your
computer.
3
End the call from
the connected
device
close the call and connection
when the transfer is complete
Find the Feature
M
>
Settings
>
Connection
>
Incoming Call
>
Next Call
>
Data In Only
or
Fax In Only
Do This To
97
Getting More Out of Your Phone
reset your phone to normal voice operation as described
below.
Transferring the Data or Fax
Your phone notifies you when the call arrives, and transfers
the call to the connected device. Use the application
running on the device to answer the call.
Ending the Data/Fax Connection
When the data or fax transfer is complete, end the call
from the connected device to close the connection.
Resetting Normal Voice Operation
After making a data or fax call, you must reset your phone
to resume normal voice operation.
Your phone also reverts to normal voice operation when
you turn it off and then turn it back on.
Adjusting Network Settings
Your service provider registers your phone to a
network. In some situations, such as using the
phone as a modem or connecting it to a TTY
device, you may need to change the network
registration.
Note:
Some settings and/or options described in this
section may not be available for all phone models.
Find the Feature
M
>
Settings
>
Connection
>
Incoming Call
>
Next Call
>
Normal
98
Getting More Out of Your Phone
Viewing Current Registered Network
Your phone displays the network ID.
Setting Network Search Mode
Set how your phone searches for a network connection.
Network search mode options:
Setting Service Status
When this feature is set to automatic, the network
automatically transmits service updates to your phone.
Find the Feature
M
>
Settings
>
Other Settings
>
Network
>
Current Network
Find the Feature
M
>
Settings
>
Other Settings
>
Network
>
Set Mode
>search mode
Setting Description
Home Only
match the Home SID
Standard
search automatically based
on priority
99
Getting More Out of Your Phone
When set to manual, you must select the
Update Service
feature to initiate a service update (if available).
Setting Service Tones
You can set your phone to beep each time the network
registration status changes.
Setting Call Drop Alert
You can set your phone to emit an alert tone whenever the
network drops a call. Because digital networks are so
quiet, the call drop alert may be your only indication
that a call has been dropped.
Find the Feature
M
>
Settings
>
Other Settings
>
Network
>
Srvc Status
>
Automatic
or
Manual
Find the Feature
M
>
Settings
>
Other Settings
>
Network
>
Service Tone
>
On
or
Off
Find the Feature
M
>
Settings
>
Other Settings
>
Network
>
Call Drop Tone
>
On
or
Off
100
Getting More Out of Your Phone
Monitoring Battery Charge
To view a detailed battery charge meter:
Viewing Phone Specifications
To view your phone’s feature specifications:
Find the Feature
M
>
Settings
>
Phone Status
>
Battery Meter
Find the Feature
M
>
Settings
>
Phone Status
>
Other Information
101
Personal Organizer Features
Personal Organizer
Features
Using the Datebook
The datebook is a calendar that lets you schedule and
organize events such as appointments and meetings. You
can set the datebook to send a reminder alarm for specific
events.
Note:
You must set the correct time and date on your
phone to use the datebook (see page 40).
To schedule or review events in the datebook:
Week View
The datebook initially displays a calendar for the week.
Find the Feature
M
>
Datebook
b
9 JAN-15 JAN
c
EXIT VIEW
S
MTWTFS
G
59
Go to selected
day
Exit the
datebook
Untimed
event
12 hour
window One-hour event
Days of week
(press
S
to
select)
Full day (12-hour)
event scheduled Press
M
to open the
Datebook Menu
102
Personal Organizer Features
Day View
Select a day and press
VIEW
(
+
) to see the day’s events.
Event View
Select an event and press
VIEW
(
+
) to see event details.
Adding a Datebook Event
A title is required for a datebook event. All other
information is optional.
Notes:
•
You must create an event to use the reminder
alarm.
b
THU 13-JAN
c
yJoes B-day
9:00
x
Marie,...
BACK VIEW
G
59
Day of week
Show event
details
Return to
previous
screen
Untimed
event
Event
Alarm
Down
scroll
Press
M
to open
the
Datebook Menu
x
THU 9:00am
Marie, meeting about
new product
BACK EDIT
G
59
Day and time
Edit event
Return to
previous
screen
Event details
Alarm
Down
scroll
Press
M
to open
the
Datebook Menu
103
Personal Organizer Features
•
Your phone must be turned on for the reminder alarm
to sound.
Changing Event Information
Find the Feature
M
>
Datebook
> day
M
>
New
Press To
1
CHANGE
(
+
)select
Title
2
keypad keys enter a title for the event
3
OK
(
+
) store the event title
4
S
scroll to other fields and enter
information as necessary
You can enter start time,
duration, date, repeating
events, and reminder alarm.
5
DONE
(
-
) store the event
Find the Feature
M
>
Datebook
Press To
1
S
left or right scroll to the day
2
VIEW
(
+
) display the day view
3
S
scroll to the event
4
VIEW
(
+
) display the event view
5
EDIT
(
+
) edit the event
6
S
scroll to the information you
want to change
104
Personal Organizer Features
Copying an Event
7
CHANGE
(
+
) edit the information
8
keypad keys enter the new information
9
DONE
(
-
) store the information
Find the Feature
M
>
Datebook
Press To
1
S
scroll to the day
2
VIEW
(
+
) display the day view
3
S
scroll to the event to copy
4
M
open the
Datebook Menu
5
S
scroll to
Copy
6
SELECT
(
+
) copy the event
7
YES
(
+
) confirm the copy
Your phone assumes that
you want to change the date,
and displays the
Date
field.
8
keypad keys enter the date information
9
}
(
+
) move to day, month, and year
10
DONE
(
-
) save the copy of the event
11
S
scroll to and edit event
information, if necessary
12
DONE
(
-
) store the information
Press To
105
Personal Organizer Features
Deleting an Event
Viewing and Dismissing an Event Reminder
When you set a reminder alarm for an event, the phone
displays an event reminder and sounds a reminder alarm.
To view or dismiss an event reminder:
If you have more than one event set up for the same
time, the phone displays each event in sequence. As
you view and dismiss each event reminder, the next one is
displayed.
Find the Feature
M
>
Datebook
Press To
1
S
scroll to the day
2
VIEW
(
+
) display the day view
3
S
scroll to the event to delete
4
M
open the
Datebook Menu
5
S
scroll to
Delete
6
SELECT
(
+
)select
Delete
Press To
VIEW
(
+
)
or
EXIT
(
-
)
view the event
Press
S
to scroll through
the event details.
dismiss the reminder
106
Personal Organizer Features
Changing the Datebook Setup
You can change the datebook’s daily start time, and set the
length of time that events are stored
Calculating Numbers and
Currency
You can use your phone as a calculator and currency
converter.
Calculating Numbers
The calculator can perform the following functions:
Find the Feature
M
>
Datebook
M
>
Setup
Find the Feature
M
>
Calculator
Press To
1
number keys enter a number
2
S
left or right highlight a calculator function
3
SELECT
(
+
) perform the function
Function Description
.
Insert a decimal point
C
Clear the calculation
CE
Clear entry (replaces the
C
function
when you enter more values in a
calculation)
+
Add
107
Personal Organizer Features
Converting Currency
The currency converter works just like the calculator, but
uses the
$
(currency) function:
-
Subtract
x
Multiply
÷
Divide
%
Divide the displayed value by 100
$
Calculate the exchange rate
±
Change the entry’s sign (positive/
negative)
MR
Recall the value stored in memory
MS
Store the displayed number in memory
MC
Clear memory
Find the Feature
M
>
Calculator
M
>
Exchange Rate
Press To
1
number keys enter the exchange rate
2
OK
(
+
) store the exchange rate
3
number keys enter the amount to convert
(amount to multiply by the
exchange rate)
4
S
(left or right) highlight the
$
function
5
SELECT
(
+
) perform the conversion
Function Description
108
Security
Security
Locking and Unlocking
Applications
You can lock specific phone applications (such as the
phonebook) so that users must enter the unlock code to
use them.
Find the Feature
M
>
Settings
>
Security
>
Lock Application
Press To
1
keypad keys enter your unlock code
2
OK
(
+
) open the lock application
menu
3
S
scroll to the application
4
CHANGE
(
+
) select the application
5
S
scroll to
Locked
or
Unlocked
6
SELECT
(
+
) select
Locked
or
Unlocked
109
News and Entertainment
News and
Entertainment
Using the Micro-Browser
The micro-browser lets you access Web pages
and Web-based applications on your phone.
Contact your service provider to set up
access, if necessary.
Starting a Micro-Browser Session
Shortcut:
If you open a text message with a Web address
(URL) in it, you can press
M
>
Go To
to launch the micro-
browser and go directly to the URL.
If you are unable to establish a network connection with
the micro-browser, contact your service provider.
Find the Feature
M
>
Browser
Press To
1
S
scroll to a bookmark or
service, or application
2
SELECT
(
+
) select the item
110
News and Entertainment
Interacting With Web Pages
Downloading Pictures, Games, and
Sounds
You can download a picture, animation, sound, or
game upgrade from a Web page by selecting its link. A
picture or animation is displayed when downloading is
complete. A sound begins to play when downloading is
complete.
You can store these object files on your phone, and use
them as screen saver images, wallpaper images, and ring
tones.
To download files with the browser on a desktop computer
or your phone:
Press To
S
up or down scroll through text, or
highlight a selectable item
M
open the
Browser Menu
Downloading a File Using a Web Browser
1
In the browser, go to the Web site and find the
file you want.
2
Follow the directions on the site to purchase the
file (payment details vary). The site sends a text
message to your phone, containing the attached
file or a URL link to the file.
3
Open the message and store the file (see
page 59).
111
News and Entertainment
Notes:
•
Call charges apply during download sessions.
•
When your phone runs out of memory for downloaded
files, new files overwrite the old ones. Downloaded
files share your phone’s memory, so you can make
room for a picture, for example, by deleting ring tones.
Selecting or Creating a Web Session
Use this feature to select or create a Web session, or
network connection profile. You can use different Web
sessions to connect to the Internet in different ways.
To create a Web session, you must configure the following
settings. Contact your service provider to obtain the
following information, if necessary. Actual field names and
values may vary depending on the technologies available
to your service provider. Some settings may not be
available for all phone models.
Find the Feature
M
>
Web Sessions
>
[New Entry]
Setting Description
Name
Web session name
Homepage
default home page
WAPIP1
primary WAP gateway IP address
WAP Port 1
primary WAP port number
WAPIP2
secondary WAP gateway IP
address
WAP Port 2
secondary WAP port number
112
News and Entertainment
Playing Games
You can play games on your phone between phone calls.
An incoming call, message, alarm, or alert automatically
ends the game.
Timeout
time at which the phone exits the
micro-browser application when
no keypress activity is detected
CSD No. 1
primary phone number to use to
set up a CSD connection
User Name 1
user name for primary CSD
number
Password 1
password for primary CSD
number
Speed (Bps) 1
connection speed for primary
CSD number
Line Type 1
line type (modem or ISDN) for
primary CSD number
CSD No. 2
secondary CSD dial-up phone
number
User Name 2
user name for secondary CSD
number
Password 2
password for secondary CSD
number
Speed (Bps) 2
connection speed for secondary
CSD number
Line Type 2
line type (modem or ISDN) for
secondary CSD number
Setting Description
113
News and Entertainment
Playing a Game
When the game is over:
Astrosmash
In Astrosmash, your job as Commander is to repel an
attack of meteors and spinning bombs. You try to shoot as
many meteors, bombs, missiles, and flying saucers as
possible without getting hit.
Level One: 1500 point limit
Game upgrades remove point limits and add UFOs (100
points) and Hyperspace.
Find the Feature
M
>
Games
Press To
1
S
scroll to a game
2
SELECT
(
+
)start the game
Press To
NEW
(
+
) or
YES
(
+
)
start another session of the
same game
BACK
(
-
) or
NO
(
-
)
end the game session
Item Points Item Points
Big Rock 10 Guided Missile 50
Small Rock 20 Small Spinner 80
Big Spinner 40
114
News and Entertainment
Rules of the game
•
Guided Missiles move toward the Laser Gun.
•
UFOs appear when the score is greater than or equal
to 5,000. UFOs sweep across the screen and release
bombs at the Laser Gun. The bombs cannot be
destroyed
•
When you shoot a Big Rock, it breaks into 2 Small
Rocks.
•
When you are out of Laser Guns, the game is over.
You lose a Laser Gun if a spinner (both big and
small) hits the ground, or if a rock, rock pieces, or a
guided missile collides with a Laser Gun.
•
Every time the peak score goes up by another 1,000
points, you get another Laser Gun.
How to Play
MotoGP
In this game, you are a MotoGP motorcycle racer.
Level One: “Quick Race”, with one lap and one racer
Press To
S
move the Laser Gun
8
move the Laser Gun to a random
position
2
toggle control for firing between you
and the phone (Auto-Fire)
5
fire the Laser Gun, if Auto-Fire is off
115
News and Entertainment
Game upgrades include other racers and tracks, with
“Time Attack” (a time trial with yourself only), and “Grand
Prix” (a series of 3 races with other competitors). You can
choose a team and a track.
How to Play
Snood 21
In this solitaire game, you try to use all the cards in a deck
by making combinations of 21 on any of four columns.
When a combination of 21 is created, the cards are
discarded, letting you start another combination of 21.
Level One: 32 cards, with a one-minute time limit
If you finish the first level in one minute, you can move on
to the next one. Game upgrades allow more time.
Rules of the game
•
Aces are worth either 1 or 11, Jacks, Queens, and
Kings are worth 10, and all other cards are worth the
amount written on their faces.
•
You can place a wild card in any non-frozen column
for an automatic 21.
•
When the countdown timer reaches 20 seconds, the
word
HURRY
blinks twice in place of the cards left field.
If the timer reaches zero and there is a card still on the
deck,
OUT OF TIME
appears in place of the cards left
field for 2 seconds and the game is over.
Press To
S
accelerate, brake, and turn your
motorcycle
116
News and Entertainment
•
The number of cards in a deck depends on the current
level: the first level contains 32 cards (two complete
suits plus six wild cards), the second level contains 45
cards (three complete suits plus six wild cards), the
third and fourth levels contain 58 cards (all four
complete suits plus six wild cards)
•
When there are no more cards in the deck, you score
200 times the number of cards left in all the columns.
•
Every time you place a card, you score 50 points.
•
Whenever the total of all the cards placed on a
column is equal to 21, you score 100 times the
column’s position (21 on the first column scores 100
points, while 21 on the third column scores 300). 5
cards totalling less than 21 in a column is treated as
21.
•
If the value of the cards in a column is greater than 21,
the column is frozen and marked with an
X
(the
column’s total displays
BUST
).
•
If all the columns become frozen,
NO MORE MOVES
appears in place of the cards left field for 2 seconds,
and the game is over.
How to Play
Press To
1
place a card on the first column
2
place a card on the second column
3
place a card on the third column
4
place a card on the fourth column
117
News and Entertainment
Picture Viewer
Your phone contains pictures and animations
that you can insert into text messages, and use
as wallpaper and screen saver images.
Note:
Your phone may include predefined images. These
images are identified by a
ë
(predefined object) indicator.
You cannot rename, delete, or view details about
predefined images.
The
Picture Viewer
menu can include the following
options:
Find the Feature
M
>
Media Center
>
Picture Viewer
Press To
1
S
scroll to the picture
2
SELECT
(
+
) view the picture
3
S
up or down
or
DETAILS
(
+
)
or
M
view the previous/next picture
view picture information
open the
Picture Viewer
menu to perform other
procedures
Option Description
Details
View picture information.
118
News and Entertainment
Creating Alert Tones
You can create and store custom alert tones on your
phone. The tones appear in the list of available alerts.
Creating a Tone
Set as Wallpaper
Set the picture as your
phone’s wallpaper image.
Set as Screen Saver
Set the picture as your
phone’s screen saver
image.
Rename
Rename the picture.
Delete
Delete the picture.
Find the Feature
M
>
Ring Styles
>
My Tones
>
[New Tone]
Press To
1
CHANGE
(
+
) select
Notes
2
S
enter notes for the tone
3
OK
(
+
) store the notes
4
CHANGE
(
+
) select
Name
5
keypad keys enter the name for the tone
6
OK
(
+
) store the name
7
DONE
(
-
) store the tone
Option Description
119
News and Entertainment
Editing a Tone
You cannot edit the standard alert tones included with your
phone. To edit a custom tone that you created:
Deleting a Tone
You cannot delete the standard alert tones included with
your phone. To delete a custom tone that you created:
Find the Feature
M
>
Ring Styles
>
My Tones
Press To
1
S
scroll to the tone
2
EDIT
(
+
) open the tone details
3
S
scroll to
Name
or
Notes
4
CHANGE
(
+
) select the details
5
keypad keys enter new text or notes
6
OK
(
+
) store the details
Find the Feature
M
>
Ring Styles
>
My Tones
Press To
1
S
scroll to the tone
2
M
open the
My Tones Menu
3
S
scroll to
Delete
4
SELECT
(
+
) delete the tone
120
News and Entertainment
Downloading a Ring Tone
You can download custom ring tones from the
micro-browser application, or from a text
message. To download tones from the
micro-browser, see page 110. To download ring
tones from a text message, see page 60.
Sending Ring Tones
You can send ring tones to other wireless
phone users. To insert a ring tone in a text
message, see page 56.
Radio
You can use your phone to listen to FM radio
stations when the optional Motorola Original™ FM
Stereo Radio Headset accessory is plugged into
the phone’s accessory connector port.
Turning the Radio On and Off
Alternatively, you can use the following procedure:
Press To
Radio
(
+
) turn the radio on and off
Find the Feature
M
>
Radio
Press To
On
(
+
) or
Off
(
+
) turn the radio on or off
121
News and Entertainment
Note:
The
Radio
menu feature and soft key options appear
only when the FM Stereo Radio Headset is plugged into
the accessory connector port.
Tuning a Station
Storing a Preset
Selecting a Preset
Action
Press
S
to scroll to the next frequency
or
Press and hold
S
to scroll to the next available
stereo station
Action
Press and hold a number key (
1
to
9
) to assign
its preset number to the tuned station
Press To
a number key
(
1
to
9
)
tune the station stored at the
preset location
122
News and Entertainment
Sending and Receiving Calls With the
Radio On
Your phone rings or vibrates as usual to notify you of an
incoming call, message, or other event.
To end the call and resume the FM broadcast:
Turn the radio off before dialing outgoing calls from the
phone keypad. You do not have to turn off the radio to dial
emergency numbers, or numbers selected from your
phonebook or recent call lists.
To dial a recently called number, press
N
or the button on
the FM Stereo Radio Headset microphone to go to the
dialed calls list. For information on how to use the dialed
calls list, see page 46.
Action
Press
IGNORE
(
-
) to ignore the call
Press
ANSWER
(
+
), or press the button on the FM
Stereo Radio Headset microphone, to answer the
call
Note:
You can use the FM Stereo Radio Headset
microphone to converse with the other party during a
call
Action
Press
O
, or press and hold the button on the FM
Stereo Radio Headset microphone, to end the call
123
Troubleshooting
Troubleshooting
Check these questions first if you have problems with your
phone. If you need additional help, contact the Motorola
Customer Call Center at 1-800-331-6456 (United States)
or 1-800-461-4575 (Canada).
Question Answer
Is your phone
set up
correctly?
Press
M
#
. If you do not see
your phone number, contact your
service provider.
Is your battery
charged? Do
you see
6
in
the display?
The battery level indicator should
have at least one segment
showing (
7
). If it does not,
recharge your battery. See
page 17.
Does the
handset have
a signal? Do
you see
0
in
the display?
The signal strength indicator
should have at least one segment
showing (
1
). If it does not, move
to an area with a stronger signal
to use your phone.
Is the earpiece
volume too
low?
While on a call, press right on the
S
key.
124
Troubleshooting
The following refer to specific problems:
Is the other
party unable to
hear you?
Your phone may be muted. Press
UNMUTE
(
+
) if necessary to
unmute the phone.
Also, make sure that your phone’s
microphone is not blocked by its
carrying case or a sticker.
Has the phone
been
damaged,
dropped, or
gotten wet?
Dropping your phone, getting it
wet, or using a non-Motorola
battery charger can damage the
phone. The phone’s limited
warranty does not cover liquid
damage or damage caused from
using non-Motorola accessories.
Was a
non-Motorola
battery
charger used?
Problem Solution
My phone was
stolen. To
whom should I
report this?
Report a stolen phone to the
police and to your service provider
(the company that sends you your
monthly wireless service bill).
I forgot my
password.
See page 38.
Question Answer
125
Troubleshooting
I pressed the
End/Power
key, but
nothing
happened.
Be sure to press and hold
O
(the
End/Power key) until the display
appears and you hear an audible
alert (this could take a couple of
seconds). If nothing happens,
check that the battery is charged.
See page 17.
The display
says:
Enter
Unlock Code
.
How do I
unlock my
phone?
Enter the factory-preset unlock
code (1234), or the last four digits
of your phone number. See
page 36. If this fails, call your
service provider (the company
that sends you your monthly
wireless service bill).
My phone asks
for an unlock
code when I
try to open a
feature.
The application you want is
locked. If you own the phone but
do not know the unlock code, see
page 38.
My phone
does not ring.
If you see
W
or
a
in the display,
then the ring tone is turned off. To
turn a ring tone on, see page 40.
Also, the ring tone may be set to
Silent
even though your phone is
set to a ring alert profile. Be sure
to listen to your ring tone before
setting it to make sure it is
effective in the environment where
you use your phone.
Problem Solution
126
Troubleshooting
I tried to place
a call and
heard an
alternating
high/low tone.
Your call did not reach the
wireless system. You may have
dialed the number too soon after
turning the phone on. Wait until
the display shows the name of
your service provider before
making a call.
I cannot make/
answer calls.
Make sure that you have a phone
signal (see the “Signal Strength
Indicator” item on page 24). Avoid
electrical or radio interference,
and obstructions such as bridges,
parking garages, or tall buildings.
Your phone also may have the
Call Barring
feature turned on. If
you know the unlock code, you
can change this setting in the
security menu
(
M
>
Settings
>
Security
). Also,
check to be sure your SIM card is
installed and working.
My phone has
poor reception
and drops
calls.
Make sure that your antenna is
not bent or damaged.
Also, make sure you have a
phone signal (see the “Signal
Strength Indicator” item on
page 24). Stay clear of any
obstructions such as bridges,
parking garages, or tall buildings.
Problem Solution
127
Troubleshooting
I cannot hear
others on my
phone.
While on a call, press the volume
key on the left side of your phone.
Your phone display should show
the volume increasing.
Also, make sure that your phone’s
earpiece is not blocked by its
carrying case.
I cannot open
my inbox.
Before you can use text or
information services messages,
you must set up the appropriate
inbox. See page 54.
How do I see
the calls I sent
or received?
To see the most recent calls you
dialed or received, open the
“Recent Calls” lists:
M
>
Recent Calls
>
Received Calls
or
Dialed Calls
Problem Solution
128
Troubleshooting
My phone will
not dial
voicemail
commands,
passwords, or
other codes.
Your phone sends commands and
passwords as DTMF tones. You
can set your phone’s DTMF tones
to be
Long
,
Short
, or
Off
. If you
have trouble sending numbers,
check your DTMF setting.
From the idle display, press:
M
>
Settings
>
Other Settings
>
Initial Setup
>
DTMF
>
Long
or
Short
Note:
Some analog networks may
not recognize short tones.
My phone’s
display is too
dark.
Use the
Contrast
feature to
change the level of contrast in
your display. See page 43.
You can also use the
Backlight
feature to change the length of
time that the display backlight
stays on. See page 43.
What can I do
to extend
battery life?
Your battery’s performance is
affected by charge time, feature
use, temperature changes, and
other factors. For tips on
extending your battery life, see
page 17.
I can’t find a
file I
downloaded.
When your phone memory is full,
it writes new downloaded files
over the old ones.
Problem Solution
129
Troubleshooting
I plugged the
data cable into
my phone but
my phone did
not beep. How
do I know if
the data cable
is ready to go?
The beep indicates that you are
set up correctly. If you did not
hear a beep, make sure that both
ends of the data cable are
connected—the smaller end to
your phone and the larger end to
your computer.
Finally, your computer may have
deactivated the port to save
power. Try opening an application
that uses the port, like a fax or
dial-up application, and your
computer will automatically
activate the port.
My phone
beeped when I
attached the
data cable, but
my fax and
data
applications
don’t work.
Some wireless networks may not
support data or fax transmission.
If you are roaming on an
unfamiliar network, this may be
the case.
Also, remember that data and fax
transmission usually requires a
subscription. Call your service
provider for more information.
Problem Solution
130
Troubleshooting
When sending
data with the
data cable,
why does the
computer
show a
connection
rate of 19200
Kbps?
19200 Kbps is the data transfer
rate of the connection between
your computer and the phone in a
standard CSD (Circuit Switch
Data) connection. The rate of the
connection between your phone
and the network is displayed on
your phone, and will be either
14400 or 9600 Kbps.
I can’t end my
data call by
closing the
application on
my computer.
What can I do?
Try pressing
O
on your phone.
Also try disconnecting the cable or
turning off the phone. If possible,
always close the connection
through your computer. These
alternative methods may disrupt
the application on your computer.
I launched the
micro-browser
but the display
says:
Service Not
Available
.
You may be in an area without
service, or you may be connected
to a network that does not support
Internet access.
I launched the
micro-browser
but the display
says:
Data Server
Unavailable
.
Try again in a few minutes. The
servers may be temporarily busy.
Problem Solution
131
Specific Absorption Rate Data
Specific Absorption Rate Data
This model wireless phone meets the government’s requirements
for exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission (FCC) of the U.S.
Government and by the Canadian regulatory authorities. These limits are
part of comprehensive guidelines and establish permitted levels of RF
energy for the general population. The guidelines are based on standards
that were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC and by the Canadian regulatory authorities is 1.6 W/
kg.
1
Tests for SAR are conducted using standard operating positions
accepted by the FCC and by Industry Canada with the phone transmitting
at its highest certified power level in all tested frequency bands. Although
the SAR is determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the maximum value.
This is because the phone is designed to operate at multiple power levels
so as to use only the power required to reach the network. In general, the
closer you are to a wireless base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S. and
Canada, it must be tested and certified to the FCC and Industry Canada
that it does not exceed the limit established by each government for safe
exposure. The tests are performed in positions and locations (e.g., at the
ear and worn on the body) reported to the FCC and available for review by
Industry Canada. The highest SAR value for this model phone when
tested for use at the ear is 1.58W/kg, and when worn on the body, as
described in this user guide, is 0.60 W/kg (Body-worn measurements
132
differ among phone models, depending upon available accessories and
regulatory requirements).
2
While there may be differences between the SAR levels of various phones
and at various positions, they all meet the governmental requirements for
safe exposure. Please note that improvements to this product model
could cause differences in the SAR value for later products; in all cases,
products are designed to be within the guidelines.
Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications & Internet Association (CTIA) Web
site:
http://phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA) Web
site:
http://www.cwta.ca
1. In the United States and Canada, the SAR limit for mobile phones used by
the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The
standard incorporates a substantial margin of safety to give additional
protection for the public and to account for any variations in measurements.
2. The SAR information includes the Motorola testing protocol, assessment
procedure, and measurement uncertainty range for this product.
133
Additional Health and Safety Information
Consumer Information on
Wireless Phones from
the FDA
The U.S. Food and Drug Administration (FDA) provides consumer
information on wireless phones at:
http://www.fda.gov/cellphones/qa.html
Following are safety-related questions and answers discussed at this web
site.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems
are associated with using wireless phones. There is no proof, however,
that wireless phones are absolutely safe. Wireless phones emit low levels
of radio frequency energy (RF) in the microwave range while being used.
They also emit very low levels of RF when in the stand-by mode. Whereas
high levels of RF can produce health effects (by heating tissue), exposure
to low level RF that does not produce heating effects causes no known
adverse health effects. Many studies of low level RF exposures have not
found any biological effects. Some studies have suggested that some
biological effects may occur, but such findings have not been confirmed
by additional research. In some cases, other researchers have had
difficulty in reproducing those studies, or in determining the reasons for
inconsistent results.
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of radiation-emitting
consumer products such as wireless phones before they can be sold, as it
does with new drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown to emit radio
frequency energy (RF) at a level that is hazardous to the user. In such a
134
case, FDA could require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or recall the phones so
that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory actions,
FDA has urged the wireless phone industry to take a number of steps,
including the following:
•
Support needed research into possible biological effects of RF of the
type emitted by wireless phones;
•
Design wireless phones in a way that minimizes any RF exposure to
the user that is not necessary for device function; and
•
Cooperate in providing users of wireless phones with the best
possible information on possible effects of wireless phone use on
human health.
FDA belongs to an interagency working group of the federal agencies that
have responsibility for different aspects of RF safety to ensure
coordinated efforts at the federal level. The following agencies belong to
this working group:
•
National Institute for Occupational Safety and Health
•
Environmental Protection Agency
•
Federal Communications Commission
•
Occupational Safety and Health Administration
•
National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency working
group activities, as well.
FDA shares regulatory responsibilities for wireless phones with the
Federal Communications Commission (FCC). All phones that are sold in
the United States must comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies for safety
questions about wireless phones.
135
FCC also regulates the base stations that the wireless phone networks
rely upon. While these base stations operate at higher power than do the
wireless phones themselves, the RF exposures that people get from
these base stations are typically thousands of times lower than those they
can get from wireless phones. Base stations are thus not the primary
subject of the safety questions discussed in this document.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with
groups of investigators around the world to ensure that high priority
animal studies are conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health Organization
International Electromagnetic Fields (EMF) Project since its inception in
1996. An influential result of this work has been the development of a
detailed agenda of research needs that has driven the establishment of
new research programs around the world. The Project has also helped
develop a series of public information documents on EMF issues.
FDA and the Cellular Telecommunications & Internet Association (CTIA)
have a formal Cooperative Research and Development Agreement
(CRADA) to do research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in government, industry,
and academic organizations. CTIA-funded research is conducted through
contracts to independent investigators. The initial research will include
both laboratory studies and studies of wireless phone users. The CRADA
will also include a broad assessment of additional research needs in the
context of the latest research developments around the world.
136
What steps can I take to reduce my exposure to
radio frequency energy from my wireless
phone?
If there is a risk from these products--and at this point we do not know that
there is--it is probably very small. But if you are concerned about avoiding
even potential risks, you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is a key factor in how
much exposure a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
If you must conduct extended conversations by wireless phone every day,
you could place more distance between your body and the source of the
RF, since the exposure level drops off dramatically with distance. For
example, you could use a headset and carry the wireless phone away
from your body or use a wireless phone connected to a remote antenna
Again, the scientific data do not demonstrate that wireless phones are
harmful. But if you are concerned about the RF exposure from these
products, you can use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless
phones, including children and teenagers. If you want to take steps to
lower exposure to radio frequency energy (RF), the measures described
above would apply to children and teenagers using wireless phones.
Reducing the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF exposure.
Some groups sponsored by other national governments have advised that
children be discouraged from using wireless phones at all. For example,
the government in the United Kingdom distributed leaflets containing such
a recommendation in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by children was strictly
137
precautionary; it was not based on scientific evidence that any health
hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF emissions from
wireless phones, there is no reason to believe that hands-free kits reduce
risks. Hands-free kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of RF energy in the
head because the phone, which is the source of the RF emissions, will not
be placed against the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use, then that part of the
body will absorb more RF energy. Wireless phones marketed in the U.S.
are required to meet safety requirements regardless of whether they are
used against the head or against the body. Either configuration should
result in compliance with the safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF emissions from
wireless phones, there is no reason to believe that accessories that claim
to shield the head from those emissions reduce risks. Some products that
claim to shield the user from RF absorption use special phone cases,
while others involve nothing more than a metallic accessory attached to
the phone. Studies have shown that these products generally do not work
as advertised. Unlike “hand-free” kits, these so-called “shields” may
interfere with proper operation of the phone. The phone may be forced to
boost its power to compensate, leading to an increase in RF absorption.
In February 2002, the Federal Trade Commission (FTC) charged two
companies that sold devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated claims. According to
FTC, these defendants lacked a reasonable basis to substantiate their
claim.
138
Warranty
Motorola Limited Warranty for
the United States and Canada
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its
telephones, pagers, messaging devices, and consumer and professional
two-way radios (excluding commercial, government or industrial radios)
that operate via Family Radio Service or General Mobile Radio Service,
Motorola-branded or certified accessories sold for use with these
Products (“Accessories”) and Motorola software contained on CD-ROMs
or other tangible media and sold for use with these Products (“Software”)
to be free from defects in materials and workmanship under normal
consumer usage for the period(s) outlined below. This limited warranty is
a consumer's exclusive remedy, and applies as follows to new Motorola
Products, Accessories and Software purchased by consumers in the
United States or Canada, which are accompanied by this written
warranty:
Products and Accessories
Products Covered Length of Coverage
Products and Accessories
as
defined above, unless otherwise
provided for below.
One (1) year
from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
Decorative Accessories and
Cases
. Decorative covers,
bezels, PhoneWrap™ covers
and cases.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the
product.
Monaural Headsets.
Ear buds
and boom headsets that transmit
mono sound through a wired
connection.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the
product.
139
Exclusions
Normal Wear and Tear.
Periodic maintenance, repair and replacement of
parts due to normal wear and tear are excluded from coverage.
Batteries.
Only batteries whose fully charged capacity falls below 80% of
their rated capacity and batteries that leak are covered by this limited
warranty.
Abuse & Misuse.
Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such as physical
damage (cracks, scratches, etc.) to the surface of the product resulting
from misuse; (b) contact with liquid, water, rain, extreme humidity or
heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of
the Products or Accessories for commercial purposes or subjecting the
Product or Accessory to abnormal usage or conditions; or (d) other acts
which are not the fault of Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories.
Defects or damage
that result from the use of Non-Motorola branded or certified Products,
Accessories, Software or other peripheral equipment are excluded from
coverage.
Unauthorized Service or Modification.
Defects or damages resulting
from service, testing, adjustment, installation, maintenance, alteration, or
modification in any way by someone other than Motorola, or its authorized
service centers, are excluded from coverage.
Consumer and Professional
Two-Way Radio Accessories.
Ninety (90) days
from the date of
purchase by the first consumer
purchaser of the product.
Products and Accessories that
are Repaired or Replaced.
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Products Covered Length of Coverage
140
Altered Products.
Products or Accessories with (a) serial numbers or
date tags that have been removed, altered or obliterated; (b) broken seals
or that show evidence of tampering; (c) mismatched board serial
numbers; or (d) nonconforming or non-Motorola housings, or parts, are
excluded from coverage.
Communication Services.
Defects, damages, or the failure of Products,
Accessories or Software due to any communication service or signal you
may subscribe to or use with the Products Accessories or Software is
excluded from coverage.
Software
Exclusions
Software Embodied in Physical Media.
No warranty is made that the
software will meet your requirements or will work in combination with any
hardware or software applications provided by third parties, that the
operation of the software products will be uninterrupted or error free, or
that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media.
Software that is not
embodied in physical media (e.g. software that is downloaded from the
internet), is provided “as is” and without warranty.
Who is Covered?
This warranty extends only to the first consumer purchaser, and is not
transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the
purchase price of any Products, Accessories or Software that does not
conform to this warranty. We may use functionally equivalent
Products Covered Length of Coverage
Software.
Applies only to physical defects
in the media that embodies the copy of the
software (e.g. CD-ROM, or floppy disk).
Ninety (90) days
from
the date of purchase.
141
reconditioned/refurbished/pre-owned or new Products, Accessories or
parts. No data, software or applications added to your Product, Accessory
or Software, including but not limited to personal contacts, games and
ringer tones, will be reinstalled. To avoid losing such data, software and
applications please create a back up prior to requesting service.
How to Obtain Warranty Service or Other
Information
You will receive instructions on how to ship the Products, Accessories or
Software, at your expense, to a Motorola Authorized Repair Center. To
obtain service, you must include: (a) a copy of your receipt, bill of sale or
other comparable proof of purchase; (b) a written description of the
problem; (c) the name of your service provider, if applicable; (d) the name
and location of the installation facility (if applicable) and, most importantly;
(e) your address and telephone number.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF
THIS LIMITED WARRANTY, OTHERWISE THE REPAIR,
REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS
LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER
USA
Phones
1-800-331-6456
Pagers
1-800-548-9954
Two-Way Radios
and Messaging Devices
1-800-353-2729
Canada
All Products
1-800-461-4575
TTY
1-888-390-6456
For
Accessories
and
Software
, please call the telephone number
designated above for the product with which they are used.
142
WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL
MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE
PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE,
OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE
OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR
DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS
ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR
INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE
TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY
LAW.
Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation on
the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights that vary from state
to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for Motorola
certain exclusive rights for copyrighted Motorola software such as the
exclusive rights to reproduce and distribute copies of the Motorola
software. Motorola software may only be copied into, used in, and
redistributed with, the Products associated with such Motorola software.
No other use, including without limitation disassembly of such Motorola
software or exercise of the exclusive rights reserved for Motorola, is
permitted.
143
Product Registration
Product Registration
Online Product Registration:
http://www.motorola.com/warranty
Product registration is an important step toward enjoying your new
Motorola product. Registering helps us facilitate warranty service, and
permits us to contact you should your product require an update or
other service. Registration is for U.S. residents only and is not required
for warranty coverage.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola Personal Communications Product
you will need to provide a copy of your dated sales receipt to confirm
warranty status.
Thank you for choosing a Motorola product.
Export Law Assurances
Export Law Assurances
This product is controlled under the export regulations of the United
States of America and Canada. The Governments of the United States
of America and Canada may restrict the exportation or re-exportation
of this product to certain destinations. For further information contact
the U.S. Department of Commerce or the Canadian Department of
Foreign Affairs and International Trade.
RF Energy Interference
RF Energy Interference
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
144
Index
A
accessories 120
connector ports 1
optional 15, 85, 92, 94
standard 15
active line indicator
defined 25
illustration 24
Add Digits
feature 48
alert
creating 75, 118
defined 40
downloading 60
reminders 75
setting 60
turning off 21, 46
type, selecting 74
alert profile 74
ALI indicator 25
animation 79, 110
downloading 60
inserting in message 56
managing 117
screen saver 42, 118
wallpaper 41, 42, 60, 118
answering a call 22
application, locking and
unlocking 108
appointments. See
datebook
Astrosmash 113
Attach Number
feature 48
auto PIN dial 88
automatic location
information
indicators 25
automatic redial 44
B
battery
car kit charger time 93
charging 17
extending battery life 17,
79, 128
installing 15
level indicator 17, 24, 25
block cursor, defined 29
browser alerts 64
browser. See micro-browser
C
calculator 106
calendar. See datebook
call
adding digits after phone
number 48
145
alert 21
alert type, selecting 74
alert, creating 75, 118
alert, turning off 46
answer options 41
answering 22
call waiting 53
calling card 70
canceling 45
costs 91
deleting 46
dialed calls list 46
dialing 22
dialing a recent call 46
emergency number 46
ending 22
making 22
muting 52
placing
received calls list 46
receiving 22
recent calls 46
restricting 84
speakerphone 92
storing 46
timing 89
unanswered call 48
call cost information 91
Call Failed
message 44
call timers 89
call waiting 53
caller ID 45, 49
calling card call 70
calling line identification.
See caller ID
car kit
automatic answer 92
automatic hands-free 93
charger time 93
power-off delay 93
clock
illustration 23
codes
changing 38
default 37, 38
if you forget a
code/password 38
computer
connecting to phone 94
synchronizing data 95
conference call 84
contrast, display 43
currency converter 107
cursor 28
customizing the menu 77
D
data call
connecting to external
device 94
receiving 96
sending 95
date, setting 40
datebook
146
adding an event 102
alarm 103
calendar 101
changing event
information 103
copying an event 104
day view 102
deleting an event 105
event view 102
reminders 75, 102, 103,
105
synchronizing 95
week view 101
Datebook Menu
101, 102
deleting a call 46
dialed calls list 46
dialing a number 22
digital signal indicator
defined 24
illustration 24
display
animation 79
contrast 43
description 23
greeting 77
idle display 23
illustration 23
language 79
zooming in/out 43
DTMF tones 47, 88, 128
defined 88
sending 48, 89
E
earpiece
illustration 1
volume, adjusting 21
email
reminders, turning on/off
75
email address, storing in
phonebook 69
emergency number 46
end key
functions 1, 21, 26
ending a call 22
Enter Unlock Code
message
37, 38
event alert 74
exchange rate, calculating
107
external device
connecting to phone 94
synchronizing data 95
F
factory settings, resetting
80
fax call
connecting to external
device 94
receiving 96
sending 95
fixed dial
147
editing an entry 72
storing an entry 69, 70
flashing cursor, defined 28
FM Stereo Radio Headset
120
4-way navigation key 25
frequency, changing 97
G
games 112
greeting, display 77
H
hands-free mode
automatic answer 92
automatic call routing 93
charger time 93
defined 92
power-off delay 93
headset
automatic answer 92
FM Stereo Radio Headset
120
I
idle display, defined 23
in use indicator
defined 24
illustration 24
inbox, text message 54
incoming call
canceling 45
Incoming Call
message 45
indicators
active line 24, 25
ALI 25
battery level 17, 24, 25
digital signal 24
in use 24
loud ring style 25, 40
menu 23
message waiting 24, 64
missed call 48
ring style 24, 25, 41
roam 24
signal strength 24
silent ring style 25, 40
soft ring style 25, 40
vibrate and ring style 25,
40
vibrate style 25, 40
voice message waiting
24, 25, 52
information services 64
iTAP software 31
K
key
end 1, 21, 26
4-way navigation 25
left soft key 1, 23, 26, 78
lock 39
menu 1, 26
148
navigation 1
right soft key 1, 23, 26,
78
send 1, 22, 26, 47
volume control 21
keypad
answering calls 41
locking and unlocking 39
L
language, setting 79
left soft key
customizing 78
functions 1, 23, 26
lock
application 108
keypad 39
phone 36
loud ring style indicator 25,
40
Low Battery
message 25
M
making a call 22
master clear 80
master reset 80
menu
Browser Menu
110
customizing 77
Datebook Menu
101, 102
Dialing Menu
49
entering text 28
features 84
language, setting 79
Last Calls Menu
48
lists 27
My Tones Menu
77, 119
MyMenu 81
navigating 26
Phonebook Menu
68
rearranging features 77
scroll feature 79
using features 27
menu indicator 23
menu key 1, 26
message
animation 56, 60
browser alerts 64
deleting 61
inbox setup 54
information services 64
locking 61
outbox 59
picture 56, 60
quick note 58
quick view 67
reading 61
receiving 59
reminders, text message
60, 75
reminders, turning on/off
75
reminders, voicemail 75
ring tone 56, 60
149
sending 54, 55
status 59
message waiting indicator
64
defined 24
illustration 24
micro-browser
animation 110
browser alerts 64
Browser Menu
110
defined 109
functions 110
picture 110
sound 110
starting 109
microphone 1
missed call indicator 48
Missed Call
message 49
Moto GP 114
muting a call 52
My Menu
creating 82
using 82
my telephone number 3,
22, 40
my tones 75, 118
My Tones Menu
77, 119
N
navigation key 1
network settings 97
notepad
defined 49
entering digits 49
retrieving digits 49
number
storing your number 40
viewing your number 3,
22
numeric text mode 29
O
one-touch dial
defined 50
using 50
voicemail number 50
optional accessory, defined
15
optional feature, defined 15
outbox 59
P
passwords. See codes
phone
active line indicator 25
active phone line,
changing 44
alert, turning off 21, 46
answer options 41
codes 38
connecting to external
device 94
date, setting 40
150
erase user-entered
information 80
frequency, changing 97
keypad, answering calls
41
keypad, locking and
unlocking 39
language, setting 79
locking 36, 37
network settings 97
reset all options 80
security code 38
startup greeting 77
time, setting 40
turning on/off 21
unlock code 37, 38
unlocking 21, 36, 37
phone number
active line indicator 25
active phone line,
changing 44
adding digits after 48
attaching two numbers
48, 50
redialing 44
sending text message to
55
storing in phonebook 69,
70
storing your number 40
viewing your number 3,
22
phonebook
attaching two numbers
48, 50
deleting an entry 73
dialing a number 72
editing an entry 72
email address 68
entry name 68
fields 68
number type indicator 68
one-touch dial 50
phone number 68
sorting entries 73
speed dial number 69
speed dial number,
defined 50
speed dial, using 50
storing an entry 69, 70
synchronizing 95
Phonebook Menu
68
downloading 60
inserting in message 56
managing 117
screen saver 42, 118
storing 110
wallpaper 41, 42, 60, 118
PIN code
dialing automatically 88
predictive text entry 31
profile
customizing 74
151
Q
quick note 58
quick view message 67
R
radio 120
received calls list 46
recent calls 46
redial
automatic redial 44
busy number 44
reminders
datebook 102, 103, 105
setting 75
text message 60, 75
turning on/off 75
voicemail message 75
restricting calls 84
right soft key
customizing 78
functions 1, 23, 26
ring alert
creating 75, 118
setting 60
turning off 21, 46
type, selecting 74
ring style
defined 41
indicators 25, 40
personalizing 41
setting 40
ring style indicator
defined 25, 41
illustration 24
ring tone
downloading 60
inserting in message 56
setting as event alert 60
ringer
volume, adjusting 21
roam indicator
defined 24
illustration 24
S
screen saver 42, 118
scroll feature 79
security code
changing 38
default 38
send key 1, 22, 26, 47
sending a call. See making
a call
short message service. See
text message
shortcuts
standard 3
signal strength indicator
defined 24
illustration 24
silent ring style indicator 25,
40
SMS. See text message
152
Snood 21 115
soft keys
customizing 78
functions 23
illustration 1, 26
labels 23
soft ring style indicator 25,
40
sound
downloading 60
inserting in message 56
storing 110
speakerphone 92
speed dial
changing number 69
number, defined 50
sorting phonebook entries
by 73
using 50
storing a call 46
symbol text entry 35, 36
synchronizing data 95
T
tap method text entry 30,
31
telephone number
storing your number 40
viewing your number 3,
22
text
block cursor 29
character chart 31
entering from keypad 28
entry mode, changing 29
flashing cursor 28
iTAP software predictive
text entry 31
numeric mode 29
symbol chart 36
symbol mode 35, 36
tap method 30, 31
text message
deleting 61
inbox setup 54
locking 61
reading 61
receiving 59
reminders 60, 75
sending 54, 55
status 59
text mode, changing 29
Text Msg Menu
63
time, setting 40
timers 89
travel charger, using 17
TrueSync 95
TTY device 85, 87
U
unlock
application 108
keypad 39
phone 36
153
unlock code
bypassing 38
changing 38
default 37, 38
entering 37
V
vibrate alert
indicator 25, 40
setting 40
turning off 21, 46
type, selecting 74
voice message waiting
indicator 24, 25, 52
voicemail
checking 52
dialing with one-touch dial
50
setup 51
volume
earpiece 21
ringer 21
W
wallpaper 41, 42, 60, 118
warranty 138
Web pages 109, 110
Z
zooming in/out 43
U.S. patent Re. 34,976
154
art# 020827-O.eps
✂
155
Wireless Phone Safety
Tips
“Safety is your most important call!”
Your Motorola wireless telephone gives you
the powerful ability to communicate by voice—
almost anywhere, anytime, wherever wireless
phone service is available and safe conditions allow.
But an important responsibility accompanies the
benefits of wireless phones, one that every user
must uphold.
When driving a car, driving is your first
responsibility. If you find it necessary to use your
wireless phone while behind the wheel of a car,
practice good common sense and remember the
following tips:
1 Get to know your Motorola wireless phone and its
features such as speed dial and redial.
If available,
these features help you to place your call without taking
your attention off the road.
2 When available, use a hands-free device.
If possible,
add an additional layer of convenience to your wireless
✂
156
phone with one of the many Motorola Original™ hands-
free accessories available today.
3 Position your wireless phone within easy reach.
Be
able to access your wireless phone without removing
your eyes from the road. If you receive an incoming call
at an inconvenient time, if possible, let your voice mail
answer it for you.
4 Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions.
Rain, sleet,
snow, ice, and even heavy traffic can be hazardous.
5 If you receive an incoming call at an inconvenient
time do not take notes or look up phone numbers
while driving.
Jotting down a “to do” list or going
through your address book takes attention away from
your primary responsibility—driving safely.
6 Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic.
Try to plan calls when your car will
be stationary. If you need to make a call while moving,
dial only a few numbers, check the road and your
mirrors, then continue.
7 Do not engage in stressful or emotional
conversations that may be distracting.
Make people
you are talking with aware you are driving and suspend
conversations which have the potential to divert your
attention away from the road.
8 Use your wireless phone to call for help.
Dial 9-1-1 or
other local emergency number in the case of fire, traffic
accident or medical emergencies.*
✂
157
9 Use your wireless phone to help others in
emergencies.
If you see an auto accident, crime in
progress or other serious emergency where lives are in
danger, call 9-1-1 or other local emergency number, as
you would want others to do for you.*
10 Call roadside assistance or a special
non-emergency wireless assistance number when
necessary.
If you see a broken-down vehicle posing no
serious hazard, a broken traffic signal, a minor traffic
accident where no one appears injured, or a vehicle you
know to be stolen, call roadside assistance or other
special non-emergency wireless number.*
* Wherever wireless phone service is available.
✂
158
Check the laws and regulations on the use of
wireless telephones and their accessories in the
areas where you drive. Always obey them. The
use of these devices may be prohibited or
restricted in certain areas.
For more information,
please call
1-888-901-SAFE
or visit the
CTIA Web site at
www.wow-com.com™
8988485L61-0
motorola.com
