Exhibit 8 Users Manual
APPLICANT: MOTOROLA, INC. FCC ID: IHDT56KV2
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:
FOCUS ON
WHAT MATTERS.
MOTOROL A DEXT™ with MOTOBLUR™
1Congratulations
Congratulations
MOTOROLA DEXT with MOTOBLUR
MOTOROLA DEXT with MOTOBLUR brings your
conversations, friends, and favorite stuff front and
center, so you spend less time managing your life and
more time living it.
•Only MOTOBLUR syncs your favorite social
networking sites – all your contacts, all your
messages, all the latest updates – straight to your
MOTOROLA DEXT.
•Download thousands of cool apps from Android
Market™ and the Motorola app store, to play and
surf to your heart’s content.
•Backs it all up too. So relax, already.
Caution: Before assembling, charging or using your
phone for the first time, please read the important
legal and safety information packaged with your
phone. Once your phone is up and running, press
Menu >
Settings
>
About phone
>
Safety &
Regulatory
to read the full information.
More information
On your phone—Press Home >
Help Center
.
On your computer—Go to www.motorola.com/
mydext.
After you create a MOTOBLUR account, you can also
go to www.motorola.com/mymotoblur, log in, and
select “Help Center.”
So, whether you want to read, watch, or play, we can
help.
2Your phone
Your phone
Tip: To change the Notification LED, press Menu
>
Settings
>
Display & security
>
Notification LED
.
Trevor Gilley
Black turtleneck
and a beret, and
he thought I was
serious?
5 min ago
298 minutes away from cake.
15 min ago
Browser
Vanessa Eskridge
Ultra secret
double-agent
party agenda
London
Partly Sunny
20˚
11:35
3G
Market
B
M
a
rk
et
˚
Power Key
Press to put the
display to sleep,
or hold to turn
off.
3.5mm Headset Jack
Home Key
Back Key
Microphone
Menu Key
Micro USB
Connector
Charge or
connect to PC.
Notification
LED
On=Charged.
Flashing=New
notification.
Volume Keys
Ringer Off
Switch
To u chscreen
Camera
Key
Note: Your phone might look a little different.
Trevor Gilley
Black turtleneck and a
5 min ago
298 minutes away from cake.
15 min ago
Browser
Vanessa Eskridge
Ultra secret double-agent
London
Partly Sunny
20˚
11:35
3G
Market
M
a
r
ket
Delete
Return
Space
Alternate
Symbols
Back
Shift
When you turn your phone, the home
screen adjusts for you.
Search
Press for text
search, or hold
for voice search.
Scroll
Select
3Let’s go
Contents
Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 5
Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
YouTube™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Google Maps™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Latitude. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . 40
Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
USB & memory card. . . . . . . . . . . . . . . . . . . . . . . . 43
Synchronize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 52
Let’s go
let’s get you up and running
Assemble & charge
Caution: Please read the battery use and safety text at
the back of your Getting Started Guide.
1cover off 2SIM in
3battery in 4microSD in
(already done)
5cover on 6charge up
3H
4Let’s go
Set up & go
Create or log into a MOTOBLUR account to get your
contacts, email, messages, and status information, for
all your accounts, all in one place, all the time. There’s
more in “Your MOTOBLUR account” on page 10.
Registration is secure, and should only take a few
minutes:
1Turn on. 2Select a language.
3Register or log in.
Tip: Open your phone
to type.
If you have not created
a MOTOBLUR
account, you’ll need to
register: Enter your
name, your current
email address (where
MOTOBLUR can send
account information),
and a new
MOTOBLUR account
password.
Please choose a language
English
NextEmergency Call
To make an emergency call during
setup, press the “Menu” key.
MOTOBLUR ID:
Enter email address
Your name:
e.g. John Smith
Password:
Password
NextBack
Creating your
MOTOBLUR account...
Tu rn i t o n & off
To turn on your phone,
press Power (on the right side).
To turn off your phone, press and
hold Power , then tap
Power off
in the menu that opens.
4Add your accounts. To add an account, tap
it. Then, enter the user
name or email and
password that you set
up on that account.
Tip: For more, or to
add accounts anytime,
go to “Add accounts”
on page 10.
5Import your SIM
contacts.
After you sign in, your
phone shows your
home screen. Tap
Contacts
, then
press Menu
>
Settings
>
Import
from SIM card
. Tap
OK
to confirm.
Facebook MyspaceGMail Twitter
Last FM
PicasaPhotobucket
5Touchscreen & keys
Wi-Fi connect
If you want to use a Wi-Fi network for even faster
Internet access, press Menu >
Settings
>
Wireless controls
>
Wi-Fi settings
. Tap
Wi-Fi
to
search for and connect to wireless networks. There’s
more in “Wi-Fi” on page 42.
Cool content & more
Browse and download thousands of the coolest apps
on the planet from Android. On top of that, you get a
full HTML browser, so you can surf in style.
Download new apps with “Android Market™” on
page 40. Your phone comes with a microSD memory
card installed—you can load it up with photos, videos,
and music from your computer using “USB drag &
drop” on page 43.
Security
Your contacts are backed-up on MOTOBLUR, so don’t
worry. Even if you lose your phone, MOTOBLUR can
help you find it or wipe it. And when you get your next
MOTOBLUR product, your stored info makes it a snap
to set up with just a username and password.
Of course it doesn't stop there. There are plenty of
ways to protect your phone and your information,
in “Security” on page 47.
Touchscreen & keys
a few essentials
Touch tips
Here are some tips on how to navigate around your
phone.
Tap
To choose an icon or
option, Tap it. Try it: In the
home screen, tap
Contacts
.
Tap & hold
To open special options,
tap and hold an icon or
other item. Try it: In the
home screen, tap
Contacts
, then tap
and hold a contact to open
options.
Contacts
Alex Pico
Delete contact
Alex Pico
View contact
Call
Send Text Message
6Touchscreen & keys
Drag
To scroll through a list or
move slowly, drag across
the touchscreen. Try it: In
the home screen, tap
Contacts
, then drag
your
Contacts
list up or
down.
Tip: When you drag or flick
a list, a scroll bar appears
on the right. Drag the scroll
bar to move the list to a
letter A - Z.
Flick
To scroll through a list or move quickly, flick across the
touchscreen (drag quickly and release).
Tip: When you flick a long list, tap the screen to stop it
from scrolling.
B
Contacts
StatusHistory A-Z
Alex Pico
Mariana Bukvic
Luke Carmody
Dan Smith
Keith Zang
Kate Shunney
Key tips
Menu, home, & back
Press Home to
close any menu or app
and return to the home
screen. Press and hold
Home to show the
last few apps you used,
then tap an app to open
it. In the home screen, press Home to open or
close the main menu.
Press Menu to open menu options, or Back to
go back.
Sleep & wake up
To save your battery, prevent
accidental taps, or when you want
to wipe smudges off your
touchscreen, put the touchscreen to
sleep by pressing Power . To
wake up the touchscreen, just
press Power , Menu , Home , or Back ,
or open the phone.
To change how long your phone waits before the
screen goes to sleep automatically, press Menu
>
Settings
>
Display & security
>
Screen timeout
.
Home
Key
Back
Key
Menu
Key
7Home screen
Tip: To make the screen lock when it goes to sleep,
use “Screen lock” on page 48.
Power key menu
Press and hold Power to open the power key
menu, where you can turn off the phone (
Power off
),
or turn off features (
Airplane mode
,
Bluetooth
,
Wi-Fi
,
or
GPS
).
Adjust volume
Press the volume keys to
change the ring volume (in
the home screen), or the
earpiece volume (during a
call).
Ringer off switch
To switch off your ring sound, slide down the
Ringer off switch.
Spin the screen
The touchscreen can spin to stay right-side up when
you rotate your phone:
Find it: Menu >
Settings
>
Display & security
>
Orientation
Ringer Off
Switch
Volume Keys
Home screen
quick access to the things you need most
Quick start: Home screen
The home screen gives you all your latest information
in one place. It’s what you see when you turn on the
phone or press Home from a menu. It’s basically
like this:
Trevor Gilley
Black turtleneck
and a beret, and
he thought I was
serious?
5 min ago
298 minutes away from cake.
15 min ago
Browser
Vanessa Eskridge
Ultra secret
double-agent
party agenda
London
Partly Sunny
20˚
11:35
3G
Market
B
M
ar
k
e
t
Status Indicators
Your Online Status
Tap to change your status.
Widgets
Tap to open, or tap & hold to
move or delete.
Flick left or right to open
more panels of widgets.
Shortcuts
Tap to open.
Open the main menu.
Notifications
Flick this bar down to see
details.
8Home screen
Use & change your home screen
On your home screen, shortcuts are icons that you
open your favorite apps, Web bookmarks, contacts,
mail labels, or music playlists. Widgets show you
news, weather, messages, and other updates.
Flick the home screen left or right to open other panels
of shortcuts and widgets.
•To open something, tap it. Press Home to
return to the home screen.
To change a widget’s settings, open it and then
press Menu >
Settings
.
You can find details about the settings for
Happenings
(“Add accounts” on page 10),
Messages
(“Set up messaging” on page 19),
Music
(“Music”
on page 30),
Social Status
(“Update your status” on
page 10), or
News
or
Weather
(“Set up widgets” on
page 24).
•To add something or change your wallpaper, tap
and hold an empty spot until you see the
Add to
Home screen
menu.
You can add a folder to organize your shortcuts.
•To move or delete something, tap and hold it until
you feel a vibration, then drag it to another spot,
another panel, or the trash at the bottom of the
screen.
Search
To search, use a Search widget (if you have one on
your home screen), or open your phone and press
Search .
Tip: In your main menu or
Contacts
, you can open your
phone (or press and hold Menu to open a display
keypad), then type an entry name to find it.
Phone status & notifications
At the top of the screen, icons
on the left notify you about new
messages or events (flick the bar
down for details). Icons on the
right tell you about phone status:
Bluetooth™ active network (full signal)
GPS active network (roaming)
Wi-Fi active GPRS (fast data)
downloading EDGE (faster data)
vibrate 3G (fastest data)
silent flight mode
Google Search
Tap the icon, then speak for
a voice search.
Type, then tap the icon for a
text search.
11:35
3G
9Main menu
Tip: To see today’s date, tap and hold the status
indicators.
mute call battery (charging)
speakerphone active battery (full charge)
Google™ sync
active
alarm set
Main menu
Quick start: Main menu
The main menu shows you all of
your applications. To open it from
the home screen,
press Home . To close it,
press Home again.
Note: Your main menu will vary.
Tip: To find an app in the main menu, open your
phone (or press and hold Menu to open a display
keypad), then type the app name.
Switching apps
Press and hold Home to see the last few apps you
used, then tap the app you want. Press Home to
close an app and return to the home screen.
10 Social networking
Social networking
my life, your life
Your MOTOBLUR account
The first time you turned on your phone, you
registered for a MOTOBLUR account that manages
your messages, contacts, and more (“Set up & go” on
page 4). You can log into this account from a computer
to upload contacts, manage the account, get help, or
even locate your phone: www.motorola.com/
mymotoblur
What is MOTOBLUR?
MOTOROLA DEXT with MOTOBLUR is the first phone
with social skills.
Only MOTOBLUR synchs contacts, posts, feeds,
messages, e-mails, photos and much more—from
sources like Facebook, Twitter, MySpace, your work
e-mail, Picasa, Photobucket—and automatically serves
it up just the way you want it. No opening and closing
apps and menus, it’s all front and center on your home
screen and integrated throughout the entire phone so
you can communicate anyway you like.
Update your status
After you add a social networking account, you can
update and see your current status in a
Social Status
widget on your home screen.
To update your status, just tap your
Social Status
widget and enter text. If you have more than one
account, you can use the pull-down menu to limit
which accounts are updated. If you don’t see a
Social
Status
widget, flick your home screen left or right to
check all panels.
To add a
Social Status
widget:
1Tap and hold an empty spot on your home screen to
open the
Choose widget
menu.
2Tap
Social Status
. The widget appears in the empty
spot, and will show your status the next time your
phone updates from the network.
Add accounts
Note: You can add your
Facebook
,
MySpace
,
Twitter
,
or other accounts to your phone. If you don’t have
accounts, you can visit their Web sites to set them up.
Find it: Menu >
Settings
>
Accounts
> Menu
>
New account
To sign into your account, use the user name or email
and password that you set up on that account (the
same as on your computer).
11Social networking
When you sign into social networking accounts, you’ll
see your friends and contacts in your
Contacts
list, and
your status and updates can appear in
Social Status
and
Happenings
widgets.
Twitter and MySpace messages will always appear
as “read” on your phone, but your phone notifies you
when you receive a new message. MySpace marks
your messages as “read” online.
For email accounts, see “Set up messaging” on
page 19.
Tip: To download updates faster, use “Wi-Fi” on
page 42.
View account updates & features
After you add a social networking account, you can see
and respond to friends’ updates with the
Happenings
widget on your home screen. If you don’t see one, set
one up in “Widgets” on page 24.
When you tap the
Happenings
widget to open an
update, you can tap on the social network’s icon to
open its Web site.
Note: Your network or other factors might affect the
speed of widget updates.
Edit & delete accounts
Find it: Menu >
Settings
>
Accounts
Tap and hold an account, then tap
Open account
to
edit it, or tap
Delete account
to remove it (along with
its contacts and messages).
12 Calls
Calls
it’s good to talk
Quick start: Calls
Dialing options
Find it:
Dialer
Recent Frequent
Dialer
Speed Dial
GHI
ABC DEF
MNO
TUVPQRS WXY
*+#
4
123
6
8
79
0
5
JKL
Call
Speed Dial List
Tap to open, then press
to add or edit.
Frequent Call List
Tap to open, then tap an
entry to call.
Delete
Tap to delete a digit you
entered.
Recent Calls
Tap to open, then tap an
entry to call.
Voice Dial
Open Your Contacts
Call
Enter a phone number and
tap here to call it.
In-call options
During a call, press Menu to choose
Hold
,
New
call
, or
Use Bluetooth
, or to wake up the touchscreen
if it’s dark.
Tip: You can press Home or Back to hide the
active call display. To reopen it, tap
Dialer
.
Make & answer calls
To make a call, tap
Dialer
, enter a number, then
tap
Call
.
Alex Pico
Mobile (555) 555-2505
Just found $100 on the street! Drinks on
me tonight!
End call
SpeakerMute
Active Call ( 00:12 )
Call Timer
Mute
Tap to mute or unmute the
call.
End Call
Tap to hang up.
Speakerphone
Tap to turn the speakerphone
on or off.
Dial Pad
Tap to open a dial pad, to
enter numbers during a call.
13Calls
Tip: To enter the international dialing code, tap and
hold .
To answer a call, drag
Answer
to
the right (when your phone is
unlocked,
Answer
is just a tap
button).
End calls
Tap
End call
.
Note: When you hold your phone
to your ear, the display goes dark
to avoid accidental taps. When
you move your phone away from your ear, the display
lights up again.
Tip: You can press Home or Back to hide the
active call display. To reopen it, tap
Dialer
.
Speed dial
Find it:
Dialer
>
Spd Dial
•To call a number, tap it.
•To add, edit, or clear entries, press Menu .
Voice dial
Find it:
Dialer
>
Say a number, or a name from
your
Contacts
.
Slide to Answer
Press Power/Lock button to ignore
End call
SpeakerMute
Call
Handsfree
Note: Using a mobile device or accessory while
driving may cause distraction and may be illegal.
Always obey the laws and drive safely.
During a call:
•To use the speakerphone, tap
Speaker
.
•To use a Bluetooth™ device, press Menu >
Use
Bluetooth
.
Mute & hold
During a call:
•To mute the current call, tap
Mute
.
•To put a call on hold, press Menu >
Hold
.
Enter numbers during a call
To enter numbers during a call,
tap and then tap the dial pad.
Recent calls
Find it:
Dialer
>
Recent
•To call a number, tap it.
•To send a text message, create a contact, view a
contact, add the call to speed dial, or other options,
tap and hold an entry.
End call
SpeakerMute
14 Calls
•To filter the list, tap the view name (like
All calls
) at
the top.
•To clear the list, press Menu .
Frequent calls
Find it:
Dialer
>
Frequent
•To call a number, tap it.
•To send a text message, view a contact, add the call
to speed dial, or other options, tap and hold an
entry.
Conference calls
To start a conference call, call the first number. After
they answer, press Menu >
New call
and call the
next number. When the next number answers,
press Menu >
Join
.
Your phone number
Find it: Menu >
Settings
>
About phone
>
Status
>
Phone number
Your caller ID
To hide your number from the people you call,
press Menu >
Settings
>
Call settings
>
Additional call settings
>
Caller ID
.
Emergency calls
Note: Your service provider programs one or more
emergency phone numbers (such as 911 or 112) that
you can call under any circumstances, even when your
phone is locked. Emergency numbers vary by country.
Your pre-programmed emergency number(s) may not
work in all locations, and sometimes an emergency
call cannot be placed due to network, environmental,
or interference issues.
1Tap
Dialer
(if your phone is locked,
tap
Emergency Call
).
2Enter the emergency number.
3Tap
Call
to call the emergency number.
Note: Your mobile device can use AGPS satellite
signals to help emergency services find you.
Call forwarding & waiting
You can forward calls all the time, or only when your
phone is busy, unanswered, or unreachable (not on the
network):
Find it: Menu >
Settings
>
Call settings
>
Call
forwarding
When you’re on a call and a second call comes in,
Call
waiting
lets you answer it by tapping
Answer
. You can
turn off
Call waiting
, to send second calls straight to
your voicemail:
15Contacts
Find it: Menu >
Settings
>
Call settings
>
Additional call settings
>
Call waiting
Restrict outgoing calls
To restrict your phone so that it can only dial a few
numbers:
Find it: Menu >
Settings
>
Call settings
>
Fixed
dialing number
•To turn fixed dialing on, tap
FDN disabled
.
•To add or delete the allowed numbers, tap
Manage
FDN list
.
Contacts
contacts like you’ve never had before
Quick start: Contacts
Find it:
Contacts
Tip: To search the list, open your phone (or press and
hold Menu to open a display keypad), then type a
name. When you flick or drag this list, a scroll bar
appears on the right. Drag the scroll bar to move the
list faster.
Contacts
StatusHistory A-Z
Alex Pico
Mariana Bukvic
Luke Carmody
Dan Smith
Keith Zang
Kate Shunney
Group
Press Menu to choose
which group to show (like
All, Favorites, or Facebook).
Create Contacts
Views
Tap a list view, or flick the
display right or left to
show:
History - recently used
A-Z - list without status
Status - list with status
Contacts List
Tap to view contact
information. Tap & hold to
edit, delete, and more.
16 Contacts
Import contacts from your SIM
Note: You might have already done this during “Set up
& go” on page 4.
If you need to import the
contacts from your SIM card,
tap
Contacts
, then
press Menu >
Settings
>
Import from SIM card
.
Call, text, or email contacts
Find it:
Contacts
For
Call
,
Send Text Message
,
Email
,
View contact
, or
other options, tap and hold the contact.
View & use contacts
With a MOTOROLA DEXT with MOTOBLUR, you’ll
know what everybody’s up to and when. Every time
you pick up a call, check a message, or look up a
friend’s contact info, sure, you’ll see their name and
number, but you’ll see their social network status and
smiling face, too.
Find it:
Contacts
•To filter the contacts by group (
All
,
Facebook
, and so
on) tap the filter name at the top.
Tip: To change which account provides the pictures
for your
Contacts
, from the home screen
press Menu >
Settings
>
Accounts
>Menu
>
Picture Source
.
•To change the list view, tap
History
(recently used),
A-Z
(list without status), or
Status
(list with status) at
the bottom.
•To find a contact, just type the name.
Tap a contact to open their details. To start a call or
message, just tap their phone number or other info.
Yo u c a n t a p
History
,
Info
, or
Happenings
at the
bottom of the screen to see more.
Edit or delete contacts
Find it:
Contacts
Tap the contact, then press Menu >
Edit
or
Delete
. You can set a ringer, address, and other details
that will be saved on your phone and your MOTOBLUR
account.
Where are contacts edited or deleted? Your phone
edits the contacts in its memory, and also updates
your MOTOBLUR account. Your changes won’t affect
your SIM card.
Link contacts
You might have two
Contacts
for the same person,
maybe a Facebook friend who is also stored on your
17Contacts
SIM card, or one friend with two email addresses. To
combine these two contacts:
Find it:
Contacts
Tap a contact to open it, then press Menu >
Link
contact
and tap the second entry. Your MOTOBLUR
account remembers this connection.
Create contacts
Find it:
Contacts
>Menu >
Add contact
Open your phone to type the name and details.
Exchange
Adam Aaronson
Phone number
Phone
First Last
Phone
Edit Contact
Exchange, Gmail
Home
Mobile
Tap Mobile to choose a
different type for this
entry.
Tap + to add another
entry.
Tap - to remove this
entry.
To see more details, flick up.
When you’re finished, press Menu >
Save
.
Where are contacts saved? Your phone saves new
contacts in its memory, and also updates your
MOTOBLUR account. So, if you get another
MOTOBLUR phone, you can just log into MOTOBLUR
to download your contacts. You can’t save new
contacts on your SIM card, but you can update your
accounts: In
Contacts
, press Menu >
Settings
to
choose which accounts are updated with new
contacts.
Synchronize contacts
When you change one of your
Contacts
, your phone
automatically updates your MOTOBLUR account
online. Also, your phone updates your
Contacts
and
MOTOBLUR account whenever you change a friend in
your social networking accounts.
So, you don’t have to do anything to synchronize your
Contacts
with your other accounts! MOTOBLUR takes
care of it for you.
My details
Find it:
Contacts
>Menu >
View my
details
To edit details, tap them.
18 Messaging
Groups
You can put your
Contacts
into groups that you create
(like “friends,” “family,” or “work”). Then, you can find
contacts faster by showing one group at a time.
To create a group in your
Contacts
, press Menu
>
Add group
. Enter a group name, then tap
Add
member
to add members.
To show only one group in your
Contacts
, tap
Contacts
at the top of your screen and choose the group name.
Messaging
sometimes it’s best 2 text, or IM, or email . . .
Quick start: Messaging
Find it:
Messaging
>
Universal Inbox
Tip: To see more messages, flick or drag up.
Read & reply to messages
Every text, email, friend-feed, wall post, and bulletin is
automatically delivered to you, ready for your
immediate reply with the slide-out keypad. The best
part is you don’t have to dig through any apps, screens
8:34 PM
Alex Pico
Some guys have all the luck - me...
Right now, you’re busy flexing...
Sep 25
Keith Zang
Job
It’s only a freelance gig, but it pays...
Sep 25
Kate Shunney
I have so much energy today, I have
no IDEA why.
Universal Inbox (4)
Sep 25
Seth Rementer
The cinnamon bun place is right
next to the store. It’s like 8 hours...
Create Message
Tap to create a new
message, and see a list of
your drafts (indicated by the
number).
Message List
Tap to open a message. Tap
& hold to move, delete, and
more.
Check for Messages Now
Message Type
Message Status
Icons indicate a message:
unread
urgent
has attachments
19Messaging
or menus—every message streams right to the phone,
viewable exactly the way you want.
Find it:
Messaging
>
Universal Inbox
Note:
Universal Inbox
shows all of your messages
together—text, email, and social networking
messages. To show only one type of message, tap a
message account type instead of
Universal Inbox
.
•To open a message and all of its replies, tap it.
•To respond to a message, just open it and enter
your response in the text box at the bottom.
For email, tap to show the
text box.
•To open options, tap and hold
a message.
Tip: Try the
Messages
widget in “Widgets” on
page 24.
Create messages
Find it:
Messaging
>
Choose a message type. Then,
enter the recipient and message.
In text messages and emails, press Menu for
options like
Insert...
or
Attach Files
.
Messaging
Send & receive attachments
To send a file in a message, open a new message and
press Menu >
Insert...
or
Attach Files
.
When you receive a message with an attachment,
open the message and tap the file name to download
it. Then, tap the name again to open it. Some file
formats can be converted to HTML for faster viewing,
and your phone will show a button that says
Get HTML
version
.
Tip: To send and receive large attachments faster, use
a Wi-Fi connection, in “Wi-Fi” on page 42.
Set up messaging
To add email accounts, press Menu >
Settings
>
Accounts
> Menu >
New account
.
•
Corporate Sync
is for Exchange server work email
accounts. Enter details from your IT administrator.
Tip: You might need to enter your domain name
with your user name (like domain/username)
Note: Some work accounts might require you to
add a password lock to your phone, for security. To
stop an account from showing the contacts you
create on your phone, tap
Contacts
,
press Menu >
Settings
, then uncheck the
account under
New contacts
.
20 Messaging
•
Email
is for most personal email accounts. For
account details, contact the account provider.
Note: While you are using a Wi-Fi network, you
cannot access
Yahoo Mail
accounts. You can still
use your browser to see these accounts at
mail.yahoo.com.
To change your settings, press Home
>
Messaging
> Menu , then tap:
•
Manage accounts
to change your user name or
password (or server settings, for email).
•
Edit Universal Inbox
to choose which accounts
show messages in the
Universal Inbox
.
•
Messaging Settings
to set the notification for each
account type (along with other preferences, for
email).
To g e t Gmail™ in your Messages widget and
Universal Inbox
, you’ll need to add it as an
Email
account: Tap
Messaging Settings
>
Add account
>
Email
and enter your Gmail™ details. If you added
your
Google
account too, turn off its email sync to
avoid duplicate email notices: Press Home
>
Accounts
, tap your Google™ account, and tap the
checkmark to turn off
Gmail
.
Tip: For social network accounts, see “Add accounts”
on page 10.
Instant messages
To send and receive instant messages, you can use an
instant messaging app or your browser.
•To download and use an instant messaging app,
press Home >
Market
>
Applications
>
Communication
, then choose an app for your
provider. Once you download the app, you’ll see it in
“Main menu” on page 9.
•If you don’t see an app for your IM provider, you can
use your Web browser. Press Home
>
Browser
>Menu >
Settings
, then enter
your provider’s Web site and tap
Go
. Once you’re
there, follow the link to sign in.
Note: Your IM options will depend on your IM provider.
To browse instant messaging apps from your
computer, go to www.android.com/market.
Voicemail
When you have a new voicemail, shows at the top
of your screen. To hear the voicemail,
tap
Dialer
, then tap and hold .
If you need to change your voicemail number, in the
home screen press Menu >
Settings
>
Call
settings
>
Voicemail
.
21Text entry
Text entry
think keyboard, now think smaller
Typing tips
To use the full keypad, slide open your phone (there’s a
keypad diagram within “Your phone”):
To . ..
Enter symbols chosen from
a list
Press Symbols
Enter alternate characters
in the corners of keys
Press Alternate
Enter several alternate
characters, until you press
Alternate again
Press Alternate
twice
Enter one capital letter Press Shift
Enter only capital letters,
until you press Shift
again
Press Shift twice
Select text (Scroll left/
right), or skip pages
(Scroll up/down)
Press Shift +
Scroll
Cut selected text Press Menu > X
Copy selected text Press Menu > C
To change your text entry settings and see the
dictionary of terms you’ve used, from the home
screen, press Menu >
Settings
>
Locale & text
.
Touchscreen keypad
When your phone is closed, you can open a display
keypad by tapping a text field, or pressing and
Paste cut or copied text Press Menu > V
Delete a character (hold to
delete more)
Press Delete
Delete the current line Press Alternate +
Delete
Jump to the beginning/end
of a line
Press Alternate +
Scroll
Start a new line (email or
social networking) or send
the message (text
messages)
Press Return
To...
22 Text entry
holding Menu . To close the keypad, press
Back .
To change your settings for this keypad, from the home
screen, press Menu >
Settings
>
Locale & text
>
Android keyboard
.
Delete
Return
Space
Symbols/Numbers
Tap to open a keypad for symbols and numbers.
Shift
Text Entry
Tap to open the
touchscreen keypad.
Format text in emails
When you create an email, you can format your
message. To select text for formatting, press and
hold Shift , then press Scroll left or right.
Text entry settings
When you use the touchscreen keypad, your phone
suggests words from your dictionary and chosen
language. Your phone also automatically enters
apostrophes in some words, like “dont.”
Find it: Menu >
Settings
>
Locale & text
•To edit your dictionary, tap
User dictionary
.
New gmail message
To:
Subject:
Send Discard
Font
Bold, Italic,
or Underline
Bullet FontSmiley
23Tips & tricks
•To change the language and the style for your
touchscreen keypad, tap
Select locale
.
•To change the sounds, corrections, and other
settings for your touchscreen keypad, tap
Android
keyboard
.
•To change the automatic correction settings for your
full keypad, tap
Device keyboard
.
Tips & tricks
a few handy hints
To...
Return to the home
screen
Press Home .
See recently dialed
numbers
Tap
Dialer
>
Recent
.
Sleep/wake your
phone
To sleep, press Power . To
wake, press Menu .
Set lock screen Press Menu >
Settings
>
Display & security
>
Screen lock
.
Turn ringer on/off Slide ringer switch up (ringer
on) or down (ringer off).
Google™ search Press Search .
Google™ search by
voice
Press and hold Search .
Show last few apps
used
Press and hold Home .
Turn airplane mode
on/off
Press and hold Power
>
Airplane mode
.
Turn Bluetooth™
on/off
Press and hold Power
>
Bluetooth
.
24 Personalize
Tur n Wi-Fi on/off Press and hold Power
>
Wi-Fi
.
Tur n GPS on/off Press and hold Power
>
GPS
.
Zoom in to select a
link on a web page
Press > link.
Go to the top of a
list
Press Alternate >
Scroll up.
Go to the bottom of
a list
Press Alternate >
Scroll down.
Scroll list up one
screen
Press Shift > Scroll
up.
Scroll list down
one screen
Press Shift > Scroll
down.
To . ..
Personalize
add your personal touch
Widgets
Create widgets
1Find an empty spot on your home screen where you
want to add a widget. You can flick left or right to
open other panels on your home screen.
2Tap and hold the empty spot until you see the
Add
to Home screen
menu.
3Tap
Widgets
.
4Tap the type of widget. If necessary, enter the
widget settings.
Set up widgets
You can customize some widgets. Tap a widget to
open it, then press Menu :
•
Happenings
: Update your status, choose which
accounts appear in this widget, or manage your
accounts (the same as “Add accounts” on page 10).
•
Messages
: Change the widget name or choose how
long it shows new messages. To add email
accounts, “Set up messaging” on page 19.
25Personalize
•
Music
: Set this widget to an artist, album, song,
playlist, or just press Menu >
Party shuffle
.
There’s more about “Music” on page 30.
•
News
: Change the widget name, choose how long it
shows new stories, or choose a news source. To
choose a source, tap , then choose preset
Bundles
or
Channels
, or choose
Custom
to enter a
URL for a
Webpage
or an
RSS feed
.
•
Weather
: Change temperature units or add
locations. To add locations, tap , enter a city, and
tap
Search
. When you open the weather widget,
flick left to see other locations you added.
Ringtones
To personalize your ringtones:
Find it: Menu >
Settings
>
Sound & ringtones
>
Phone ringtone
or
Notification ringtone
To set your ringer and vibrate options:
Find it: Menu >
Settings
>
Sound & ringtones
>
Ringer & Vibrate Modes
Tip: To switch off your ring sound, slide down the
Ringer off switch.
Sounds
Display settings
features
set volume for media and videos
Menu >
Settings
>
Sound & ringtones
>
Media
volume
play tones when using dial pad
Menu >
Settings
>
Sound & ringtones
>
Audible
touch tones
play sound on screen selection
Menu >
Settings
>
Sound & ringtones
>
Audible
selection
features
notification LED
Blinks to tell you that a notification has been
received. Menu >
Settings
>
Display & security
>
Notification LED
set display brightness
Menu >
Settings
>
Display & security
>
Brightness
26 Photos & videos
Quick launch shortcuts
To use a quick launch shortcut, press Search and
the assigned key, like Search and B to launch the
browser.
Date & time
Set date, time, time zone, and formats:
Find it: Menu >
Settings
>
Date & time
Language & region
Set your menu language and region:
Find it: Menu >
Settings
>
Locale & text
>
Select
locale
set orientation
Menu >
Settings
>
Display & security
>
Orientation
set animation
Menu >
Settings
>
Display & security
>
Animation
features
Photos & videos
see it, capture it, share it!
Photos
Take & share photos
Take that family photo, and post it online for everyone
to see.
Find it: Press Camera
Note: Photos are stored on your microSD memory
card.
Picture Resolution
is 3MP, unless you change it.
245
5MP
New York, New York 10006
United States
Autofocus Box Tap the screen to show a
thumbnail of your last photo.
27Photos & videos
To take the photo, lightly press Camera halfway
until the autofocus box turns green, then press all the
way to take the photo.
Tap the viewfinder to see a thumbnail of the photo
you’ve just taken (on the right). Tap the thumbnail,
then:
•To see all your photos, tap
Gallery
.
•To set the photo as a wallpaper, contact photo, or
social network profile photo, tap
Set as
.
•To send the photo in a message or post it online,
tap
Share
. For more info on sharing your photos,
see “Share your photo gallery” on page 28.
•To delete the photo and return to the viewfinder, tap
Delete
.
Photo options
In the viewfinder, press Menu >
Settings
to open
the camera menu:
options
Store
location in
pictures
Save the details of where the photo
was taken.
Resolution
Set the resolution of your photo.
View your photos
Find it: Home >
Picture Gallery
Play a slideshow
Press Home >
Picture Gallery
, tap a picture,
then tap to start a slideshow. To stop the
Color Effects
Choose your color settings, like
None
,
Negative
, or
B/W
.
Advanced
settings
Set the
Picture Quality
of your
photo, or choose your
White
Balance
light settings, like
Auto
,
Daylight
, or
Cloudy
..
options
All Pictures (10/43) 2010-07-12 12.00.00
2
2
0
0
1
1
0
0
0
0
0
2
2
2
2
0
0
0
0
0
0
0
0
9
9
7
7
6
5
4
3
2
1
1
1
1
1
1
1
1
2
2
2
ctures
(
10/43
)
20
1
0
-
0
7-12 12.
00
.
00
A
ll P
i
i
My Pictures AllPictures
Picture Dates
Tap on the left to open the
date list, then drag the dates
to find pictures.
Categories
Tap at the top to open, then
tap a category.
28 Photos & videos
slideshow, tap the display. To return to the gallery,
press Back .
Share your photo gallery
Find it: Home >
Picture Gallery
To send your photo in a message or post it online:
1Tap and hold a photo, then tap
Share
.
2Choose how you want to share—like
Email
,
MySpace
,
Social sharing
or
Text Messaging
.
Tip: With
Social sharing
, you can post a photo to more
than one social network at the same time.
Manage your photos
Find it: Home >
Picture Gallery
Tap and hold a photo, then:
•To delete the photo, press Menu >
Delete
.
•To set the photo as a contact picture, social network
profile picture, or wallpaper, press Menu >
Set
as
.
•To open file details, press Menu >
More
>
Picture Info
.
•To set your photo order list, press Menu
>
Settings
>
Picture Sort
.
Tip: To copy photos to/from a computer, go to “USB
drag & drop” on page 43.
Edit your photos
Find it: Home >
Picture Gallery
> picture
>Menu >
Edit
To crop a photo, tap the crop tool, stretch and drag the
crop square to the image you want, then tap the crop
save icon.
Videos
Record & share videos
Find it: Home >
Camcorder
Tip: To send your video in a message, set the video
quality to
Low (for MMS messages)
: Press
Menu >
Settings
>
Select Video Quality
.
0:00
Tap the screen to show a thumbnail of your last
recording.
29Photos & videos
To record the video, press Camera . To stop the
video recording, press Camera again. Tap the
viewfinder to see a thumbnail of the video you’ve just
taken. Tap the thumbnail, then:
•To see all your videos, tap
Gallery
.
•To play the video, tap
Play
.
•To send the video in a message or post it online, tap
Share
. For more info on sharing your photos, see
“Share your video gallery” on page 29.
•To delete the video, tap
Delete
.
Play your videos
Find it: Home >
Video Gallery
> video
1:14 3:45
Video ControlsProgress Bar
Share your video gallery
Find it: Home >
Video Gallery
To send your video in a message or post online:
1Tap & hold a video, then tap
Share
.
2Choose how you want to share—like
MMS
,
Facebook
, or
MySpace
.
Manage your videos
Find it: Home >
Video Gallery
To delete a video, tap and hold a video, then tap
Delete
.
30 Music
Music
when music is what you need...
Quick start: Music
Tap, tap, play—instant music. Just open your music
library, then select what you want to play.
Find it: Home >
Music
Tip: When a song is playing, you can add it to a playlist
by pressing Menu >
Add to playlist
.
Music Artist
Album Title
Song Title
1:14 3:45
Artists Albums
Songs Playlists
Music
Music ControlsCategories
Tap a category, then
tap a song or playlist.
Set up music
What music transfer tools do I need?
To put music on your computer and then load it on
your phone, you need:
•A Microsoft™ Windows™ PC or
Apple™Macintosh™
•A USB data cable.
You need a memory card
Your music is stored on your memory card. Your phone
supports removable microSD memory cards up to
32 GB capacity. To make sure your memory card is
installed, go to “Assemble & charge” on page 3.
Tip: To see the available memory on your memory
card, press Menu >
Settings
>
SD card & phone
storage
.
What music file formats can I play?
Your phone can play many types of files: MP3, M4A,
AAC, ACC+, MIDI, WAV, and OGG Vorbis.
Note: Your phone does not support any DRM
protected files.
What headphones can I use?
Your phone has a 3.5mm headset jack for wired stereo
listening. You can go wireless with Bluetooth™ stereo
31Music
headphones or speakers (see “Bluetooth™ wireless”
on page 40).
Get music
Rip a CD
Not literally. If you’re new to digital music transfer, this
means transferring music from a music CD to your
computer.
To rip a music CD on your computer, you can use
Microsoft™ Windows™ Media Player. You can
download Windows Media Player from
www.microsoft.com.
1On your computer, open Windows Media Player.
2Insert a music CD into the computer’s CD
ROM drive.
Note: Make sure you change the format to MP3 in
“Rip > Format > Rip Settings”.
3In the Windows Media Player window, click on the
“Rip” tab.
4Highlight the songs you want to import, and click
“Start Rip“.
The songs are imported to the Windows Media Player
Library.
Transfer using Windows Media Player
Transfer music files from a computer to your memory
card.
Note: Copyright—do you have the right? Always follow
the rules.
1With a memory card inserted, and your phone
showing the home screen, connect a Motorola
micro USB data cable from your phone’s micro USB
port to a USB port on your computer. Your phone
should show in the status bar.
Note: Your phone supports Microsoft™ Windows™
XP, Windows Vista™, and Apple™Macintosh™.
Other operating systems may not be compatible.
2Your phone shows a USB connection dialog. Tap
USB drive
. You can’t use the files on your memory
card while it is connected.
3On your computer, open Windows Media Player.
4On the “Sync” tab, select “More Options”. Under
“Device”, select your phone.
5Select “Properties”, check the “Create folder
hierarchy on device” box, and click “OK”.
6Drag your music files over to the “Sync List” and
press “Start Sync”.
32 Music
Transfer using USB
Transfer music files from a computer to your memory
card.
1With a memory card inserted, and your phone
showing the home screen, connect a Motorola
micro USB data cable from your phone’s micro USB
port to a USB port on your computer. Your phone
should show in the status bar.
Note: Your phone supports Microsoft™ Windows™
XP, Windows Vista™, and Apple™Macintosh™.
Other operating systems may not be compatible.
2Your phone shows a USB connection dialog. Tap
USB drive
. You can’t use the files on your memory
card while it is connected.
3Find “Removable Device” (your memory card) in the
“My Computer” window.
4Drag and drop your music to a folder on your
memory card.
Tip: To help manage your music, create a “Music”
folder on your memory card.
5When you’re done, use the “Safely Remove
Hardware” feature to finish.
Play music
Music library
Open your music library, then select what you want to
play.
Find it: Home >
Music
Your music is stored by artists, albums, songs, and
playlists. Tap a category, then tap the song or playlist
you want to play. Press Menu >
Party shuffle
to
randomly play all your songs, or tap
Search
to look for a
song.
Artists Albums
Songs Playlists
Music
Music Artist
Song Title
Categories
Tap to list songs or
playlists.
Last Played
Tap to play again.
33Music
Music player
Just tap a song or playlist to get going.
Music player controls
controls
play/pause Tap / .
previous/next Tap / .
fast forward/rewind Tap & hold / .
Music Artist
Album Title
Song Title
1:14 3:45
Open Playlist
Shuffle On/Off
Repeat Off/All
/Current
Artist
Album
Song T itle
Music Controls
To t al Song T ime
Progress Bar
Hide, wake, turn off
Press Home to use another app. Your music
continues to play.
When you see in the status bar a song is playing,
flick down to see details. Tap the song to return to the
music controls.
To turn off your music tap .
view playlist Tap .
shuffle Tap .
repeat Tap .
volume Press the side volume keys.
view library Press Menu >
Library
.
turn shuffle on/off Press Menu >
Party
shuffle
.
add to playlist Press Menu >
Add to
playlist
.
use as ringtone Press Menu >
Use as
ringtone
.
delete Press Menu >
Delete
.
controls
34 Web
Playlists
To add a song from the music library to a playlist, tap
and hold the song then tap
Add to playlist
. Choose an
existing playlist, or tap
New
to create a new playlist.
To add a song to the playlist you're playing, press
Menu >
Add to playlist
in the music player.
To edit, delete and rename playlists, tap and hold the
playlist, in the music library.
Web
you don’t need a computer, surf the web with your
phone
Quick start: Browser
Find it: Home >
Browser
Note: If you can’t connect, contact your service
provider.
www.google.com: Google
Web
Google Search
My Location: Off - Turn On
Images
12:00 PM
3G
Local
View Google in: Mobile
©2009 Google
Classic
Sign in --Preferences Help
News more
Go Bookmarks New window
Refresh Forward More
Connection
Over the air:
Mobile Network: , ,
Wi-Fi:
Links
Tap to open.
The page is loading.
Web Address
To go to a URL, press
> Go.
Press to open a menu
where you can open a Web
page, your bookmarks, a
new window, and more.
Drag or flick to scroll.
35Web
Connect
Your phone uses the mobile phone network (over the
air) to automatically connect to the Web.
Note: Your service provider may charge to surf the
Web or download data.
To use a wireless network, press Menu >
Settings
>
Wireless controls
. Tap
Wi-Fi
to turn it on, then tap
Wi-Fi settings
to search for nearby wireless networks.
Tap a network to connect. There’s more in “Wi-Fi” on
page 42.
Web touch tips
Zoom & magnify
In Web pages, when you scroll (drag or flick), zoom
icons appear at the bottom of your screen.
www.google.com: Google
Android | Official Website
Official site for the development of the open source project. Provides a directory
of applications and links to download the source of the project.
Market - Official Website - Android application developer site
www.android.com/ - Cached - Similar
Android (operating system) - Wikipedia, the free encyclopedia
Android is a software platform for mobile devices, running on the Linux operating
system. It was initially developed by Google and later the Open Handset ...
en.wikipedia.org/wiki/Android_(mobile_phone_platform) - Cached - Similar
What is Android? | Android Developers
Android is a software stack for mobile devices that includes an operating system,
middleware and key applications. The Android SDK provides the tools and ...
developer.android.com/guide/basics/what-is-android.html - Cached - Similar
Android Developers
The Android SDK has the tools, sample code, and docs you need to create ...
AndroidOpen Source Project gives you access to the entire platform source. ...
developer.android.com/ - Cached - Similar
More results from developer.android.com »
Open Handset Alliance
Android™ delivers a complete set of software for mobile devices: an ... Android is
built on the open Linux Kernel. Furthermore, it utilizes a custom virtual ...
www.openhandsetalliance.com/android_overview.html - Cached - Similar
Android Community - Tracking the Android Platform
myTouch 3G Android phone is getting its day in the sun on July 8 when T-Mobile
introduce it to the world – in NYC. We'll be there to bring you live coverage ...
androidcommunity.com/ - Similar
Welcome (Android Open Source Project)
Oct 21, 2008 ... Android is the first free, open source, and fully customizable
mobile platform. Android offers a full stack: an operating system, ...
source.android.com/ - Cached - Similar
Blog posts about android
SciPhone Dream G2 Android charger is best ever - Engadget - 14 hours ago
Google Android Mobile Phones are now in India - HTC Magic from Airtel - Digital
Inspiration - Technology Blog - 6 days ago
T-Mobile Will Drop Its Second Android Phone, The myTouch 3G, This ... -
TechCrunch - Jun 21, 2009
source/android.com/ - Options
Android Community - Tracking the Android
Platform
Apr 26, 2009 .. HTC and Google have released
Android 1.5 Cupcake for owners of the Android
Dev Phone, available as a free ..
androidcommunity.com/ - Options
application
developer
sreern
Magnify
Tap to open a magnifying
window that you can drag.
Zoom In/Out
Select links
When you tap a link, your
phone outlines it. If you tap
and hold the link, your
phone shows options, like
Open in new window
or
Bookmark link
.
Browser options
Press Menu to see browser options:
options
Go
Enter the Web address (URL) you
want.
Tip: Some sites are optimized for
mobile phones, and they use an
“m” in the URL instead of
“www” (like m.youtube.com).
Search
Enter text to find.
Bookmarks
Shows a list of your bookmarks.
Tap
Add bookmark...
to add the
current page to your list.
New window
Opens a new window.
Refresh
Reloads the current page.
source/android.com/ - Options
Android Community - Tracking the Android
Platform
application
developer
sreern
36 Web
Download apps
Warning: Apps downloaded from the Web can be
from unknown sources. To protect your phone and
personal data, only download apps from sources you
trust, like “Android Market™” on page 40.
Note: All apps downloaded are stored in your phone
memory.
To download apps:
1If you want to download apps from any Web page,
press Menu >
Settings
>
Applications
>
Unknown sources
.
2To launch the browser, press
Home >
Browser
.
3Find the app you want to download and tap the
download link.
More
Shows browser options, like
Find
on page
,
Select text
,
Page info
,
Share page
,
Downloads
, and
Settings
.
options Manage your downloads
To view files or applications you have downloaded,
press Home >
Browser
> >
More
>
Downloads
.
To clear your download history, tap
Clear list
. To
cancel, tap
Cancel all downloads
.
37YouTube™
Yo u Tu b e ™
go and create your own classic
Quick start: YouTube
Find it: Home >
YouTube
The YouTube user-generated content Web site lets you
share videos with YouTube users everywhere. You
don’t need a YouTube account to browse and view
videos.
Loading
Featured
Latest video:
Most popular
Search Favorites Categories
My account Upload Settings
Categories
Tap a video to play.
Press to open a menu
where you can open a Web
page, your bookmarks, a
new window, and more.
Note: If you don’t have a YouTube account, visit
www.youtube.com to find out more. To create an
account or sign in, go to “Your account” on page 38.
Watch YouTube videos
See popular video categories, like Featured, Most
viewed, and Top rated. Tap a category, then tap the
video to start playing it. To see more video categories,
press Menu >
Categories
.
Search for YouTube videos
Find it: Menu >
Search
Enter text, then tap
Search
.To clear your search
history, press Menu >
Settings
>
Clear search
history
.
Share videos
Send someone a link to a video that you are watching.
1Press Menu >
Share
.
Tip: Just tap and hold a video to open the
Share
menu.
2Address and complete your email, then tap
Send
.
38 Google Maps™
Your account
Log in or create account
Find it: Menu >
My account
1To create your YouTube account, tap the “Don’t have
a YouTube account? Click here to create one” link.
If you already have a YouTube account, enter your
username, password and tap
Sign in
.
2For a new account, enter a username, and complete
the fields, then tap
I accept
.
Upload videos
Find it: Menu >
Upload
1Tap the video you want to upload. You can change
the video title, description, set the access, and add
tags.
2Tap
Upload
.
Google Maps™
where you are, where you’re going
Quick start: Google Maps
Where am I? What's around here? Don't worry—let
Google Maps help you explore your surroundings and
find what you're looking for.
Find it: Home >
Google Maps
Google Maps opens by default in “Map mode.”
44 West Street
A
E Ontario St
E
O
n
ta
Ontario St
E Ohio St
N Rush St
N Park St
N New St
N Wabash Ave
N Dearborn St
N Clark St
h
io St
E Grand Ave
nd Ave
n
ois St
ubbard St
Wacker Dr
R
andolph St
E Randolph St
N Micigan Ave
N Micigan Ave
rD submuloC N
W Lake St W Lake St
E Wacker Pl
State/Lake
Grand Red
Lake
Randolph
St Metra
Randolph/
Wabash
Washington-Blue
a
rk/Lake
ubway
E S WaterSt
Water St
M
MM
M
M
E S W
a
Search Directions Map mode
My Location Clear map More
Map View
Drag or flick to scroll.
Tap to show zoom.
Press to open a menu
where you can open a Web
page, your bookmarks, a
new window, and more.
39Latitude
Latitude
where are your friends & family?
Join Latitude
See where your friends and family are on Google
Maps™. Plan to meet up, check that your parents got
home safely, or just stay in touch.
Don’t worry, your location is not shared unless you
agree to it. You need to join Latitude, and then invite
your friends to view your location or accept their
invitations. When using Google Maps (in any mode
except in Street View), press Menu >
Latitude
.
Read the privacy policy and if you agree with it, tap
Agree & share
.
Add & remove friends
Find it: Home >
Google Maps
Menu
>
Latitude
To add friends:
1Press Menu >
Add friends
.
2Tap
Select from Contacts
or
Add via email address
,
then tap a contact and
Add friends
>
OK
.
If your friends already use Latitude, they’ll receive an
email request and a notification. If they have not yet
joined Latitude, they’ll receive an email request that
invites them to sign in to Latitude with their Google
account.
To remove friends:
1Press Menu >
Latitude
to show your friend’s
list, then tap a friend in your list.
2Tap
Remove
.
Share location
When you receive a request to share location details
you can choose to:
•
Accept and share back
—see your friend’s location,
and your friend can see yours.
•
Accept, but hide my location
—see your friend's
location, but they can't see yours.
•
Don't accept
—location information is not shared
between you and your friend.
Hide your location
To hide your location from a friend, press Menu
>
Latitude
to show your friend’s list. Tap your contact
name, then press Menu >
Privacy
>
Hide your
location
.
Turn off Latitude
Press Menu >
Latitude
to show your friend’s list.
Tap Me nu >
Privacy
>
Turn off Latitude
.
40 Apps for all
Apps for all
get the app you want
Android Market™
get the app you want
About Android Market™
Find it: Home >
Market
Get all the fun games and cool apps you want! Android
Market provides access to applications developed by
developers worldwide, so you can find the app you
want. If you need help or have questions about
Android Market, press Menu >
Help
.
Browse & install apps
Scroll to and tap the app you want to install. Then, tap
Install
(if app is free) or
Buy
.
Manage & restore apps
Find it: Menu >
Settings
>
Applications
>
Manage applications
Tap an app in the list, then tap
Uninstall
(for apps you
downloaded),
Clear cache
, or other options.
To reinstall any downloaded items, press Home
>
Market
>
My downloads
. All previously installed
apps are listed and available for download.
Bluetooth™ wireless
lose the wires and go wireless
Quick start: Bluetooth wireless
Find it: Menu >
Settings
>
Wireless
controls
>
Bluetooth settings
Turn Bluetooth power on or off
Find it: Press and hold Power >
Bluetooth
Note: To extend battery life, turn Bluetooth power
off when not in use.
Bluetooth devices
Bluetooth settings
(#########) 38.4 MHz Class 1.5
Device name
Pair with this device
(found device name)
Make device discoverable
Discoverable
Scan for devices
Bluetooth Tap to turn on & scan.
Tap to re-scan.
Tap to connect.
41Bluetooth™ wireless
Connect new devices
Note: This feature requires an optional accessory.
To connect with a new device, you need to pair with it.
You only need to do this once for each device—to
connect again, see “Reconnect devices” on page 41.
1Make sure the device you are pairing with is in
discoverable mode.
Note: Refer to the guide that came with the device
for details.
2Press Menu >
Settings
>
Wireless controls
>
Bluetooth settings
.
3Tap
Bluetooth
to turn on and scan. If Bluetooth is
already on, tap
Scan for devices
.
4Tap a device to connect.
5If necessary, tap
OK
, or enter the device passkey
(like
0000
) to connect to the device. When the
device is connected, the Bluetooth indicator
appears in the status bar.
Note: Using a mobile device or accessory while
driving may cause distraction and may be illegal.
Always obey the laws and drive safely.
Reconnect devices
To automatically reconnect your phone with a paired
device, simply turn on the device.
To manually reconnect your phone with a paired
device, tap the device name in the
Bluetooth devices
list.
Disconnect devices
To automatically disconnect your phone from a paired
device, simply turn off the device.
To manually disconnect your phone from a paired
device, tap the device name in the devices list, then
press Menu >
Disconnect
.
Edit properties
Press Menu >
Settings
>
Wireless controls
>
Bluetooth settings
>
Device name
. Enter a name
and tap
OK
.
42 Wi-Fi
Wi-Fi
home, office, or hotspot
Quick start: Wi-Fi
Find it: Menu >
Settings
>
Wireless
controls
>
Wi-Fi settings
Note: Your phone's Wi-Fi features and power levels
are not allowed for outdoor operation in France. To
avoid unlawful interference with radio signals, do not
use the Wi-Fi features in France unless you are
indoors.
Use a wireless network for fast Internet access and to
download data.
Wi-Fi networks
Wi-Fi settings
Notify me when an open network is
available
Network notification
Your network
Add Wi-Fi network
Wi-Fi Tap to turn on & scan.
Tap to connect.
Tu rn Wi-Fi on or off
Find it: Press and hold Power >
Wi-Fi
Note: To extend battery life, turn off Wi-Fi power when
not in use.
Wi-Fi search & connect
To find networks in your range:
1Press Menu >
Settings
>
Wireless controls
>
Wi-Fi settings
.
2Tap
Wi-Fi
to turn on and scan. If Wi-Fi is already on,
press Menu >
Scan
. Your phone lists the
networks it finds within range.
Tip: To see your phone’s MAC address or other
Wi-Fi details, press Menu >
Advanced
.
3Tap a network to connect.
4If necessary, enter
Network SSID
,
Security
, and
Wireless password
, and tap
Connect
. When your
phone is connected to the network, the wireless
indicator appears in the status bar.
Tip: When you are in range and Wi-Fi is on, you will
automatically reconnect to available networks you’ve
connected to before.
43USB & memory card
USB & memory card
connect your phone and computer, then drag & drop
USB drag & drop
Note: This feature requires an optional accessory.
You can transfer your pictures, videos, music,
ringtones, and more, from your computer to your
phone’s memory card.
1With a memory card inserted, and
your phone showing the home
screen, connect a Motorola micro
USB data cable from your phone’s
micro USB port to a USB port on
your computer. Your phone should
show in the status bar.
Note: Make sure to connect the phone to a high
power USB port. Typically, these are located directly
on your computer.
2Your phone shows a USB connection dialog. Tap
USB drive
. You can’t use the files on your memory
card while it is connected.
3On your computer, use the “My Computer”
window to find “Removable Disk”.
4Click on the “Removable Disk” icon to access the
memory card.
5Drag and drop your pictures, videos, music,
ringtones, and more, to your phone folder. To help
manage your files, you can create more folders in
your phone folder.
6When you’re done, use the “Safely Remove
Hardware” feature to finish.
Memory card
Note: You need the memory card installed for some
features on your phone, like
Camera
.
Manage files
Find it: Home >
Quickoffice
>
Memory card
Tap a file or folder to open, tap and hold a file to
Delete
or
Share
.
To manage your folders and move stuff around use
your USB connection, see “USB & memory card” on
page 43.
Remove or format your memory card
Before you remove or format your memory card you
need to unmount it. Press Menu >
Settings
>
SD
card & phone storage
>
Unmount SD card
.
To format your memory card, tap
Format SD card
.
Warning: All data on your memory card will be
deleted.
44 Synchronize
Synchronize
keep up-to-date
Google™ data synchronization
Find it: Menu >
Settings
>
Google
synchronization
The Google apps on your phone give you access to the
same personal information (emails, events, and
contacts) that you have on a computer using Gmail™,
Google Calendar™, and Contacts. It’s easy to
synchronize the Google apps information you want to
keep up-to-date.
Select apps to synchronize
1Tap
Background data
and
Auto-sync
.
Tip: To save battery power do not tap
Background
data
.
2Tap the apps you want to synchronize, like
Gmail
,
Calendar
, or
Contacts
.
Synchronize with Microsoft™ Office
Outlook
If you use Microsoft Office Outlook on your work
computer, your phone can synchronize emails, events,
and contacts with your Microsoft Exchange server.
Find it: Menu >
Settings
>
Accounts
> Menu
>
New account
>
Corporate Sync
1Enter your username (username@company.com),
password, email address, and server details (server
address is the same URL you use to access your
company’s email using the Web on your computer).
Note: Contact your business IT department for
server details.
2Tap
Next
.
45Tools
To o l s
stay on top of things
Alarm clock
Find it: Home >
Alarm Clock
To turn on an alarm, tap the check
box.
When an alarm sounds, tap
Dismiss
to turn it off or
Snooze
to
delay.
To add an alarm, press Menu
>
Add alarm
, then enter alarm
details.
To set a snooze period, tap the
alarm, then press Menu
>
Snooze time
.
Calendar
Find it: Home >
Calendar
Alarm
7:00am
Wake Up
8:30am Tuesday
9:00am Tue, Fri
Alarm Clock
Your calendar events can be
viewed in different ways:
Press Menu >
Month
,
Agenda
,
Week
, or
Day
. When you
highlight an event in the day and
week views, more details appear.
The calendar on your phone can
be synchronized with your Google
Calendar™. Press Home
>
CalendarSync
to manually
sync your calendar.
Add calendar events
From any calendar view, press Menu >
New event
.
Enter event details and tap
Save
.
Manage calendar events
To edit an event, press Menu >
Edit event
. Edit
event details, then when you’re done, tap
Save
.
To delete an event, press Menu >
Delete event
.
To go to today, press Menu >
Today
.
Calculator
Find it: Home >
Calculator
Your calculator has two views: basic and advanced. To
change your views, press Menu >
Advanced panel
January 2009
Sun Mon Tue Wed Thu Sat
28 29 30 31 123
456 8910
11 12 13 15 16 17
18 19 20 22 23 24
25 26 27 29 30 31
123 567
7
14
21
28
4
Fri
46 Management
or
Basic panel
. To clear history, press Menu
>
Clear history
.
Quickoffice
Use Quickoffice to view recent documents and files on
your memory card.
Find it: Home >
Quickoffice
Management
stay in control
Wireless manager
Find it: Menu >
Settings
>
Wireless controls
Manage all your wireless connections: Wi-Fi,
Bluetooth™, airplane mode, & mobile networks
(“Network” on page 46).
Shortcut: Press and hold Power to display the
power menu—from here you can control Bluetooth,
Wi-Fi and GPS as well as turn the phone off and set
airplane mode.
Airplane mode
Use airplane mode to turn all your wireless
connections off—useful when flying. Press Power
>
Airplane mode
.
Update my phone
To keep your phone current, software updates may be
available. Press Menu >
Settings
>
About phone
>
System updates
to see if your phone is up to date. If
it isn’t, tap
Update
.
Network
You should not need to change any network settings.
Contact your service provider for help.
47Security
Press Menu >
Settings
>
Wireless controls
>
Mobile networks
to show options for roaming
networks, network selection, operator selection, and
access point names.
Security
help keep your phone safe
Quick start: Security
Find it: Menu >
Settings
>
Security & location
You have lots of ways to keep your phone safe.
If you lose your phone, you can access your
MOTOBLUR account www.motorola.com/mymotoblur
(and remotely locate your phone, clear the data on
your phone, and more).
Security
Display a screen preventing
accidental touches
Set the phone’s background wallpaper
Wallpaper settings
Adjust the brightness of the screen
Brightness
Set up SIM card lock
Screen lock
Display & security
Passwords
SIM card lock
Security lock
Tap to set SIM card lock and
change SIM PIN.
Tap to set lock type, code,
and timer.
Tap to turn on.
48 Security
Screen lock
Set your phone to display a lock screen, and prevent
accidental key presses, press Menu >
Settings
>
Security & location
>
Screen lock
. You can also set a
security lock to prevent others from using your phone.
To set your security level, press Menu >
Settings
>
Security & location
>
Security lock
>
Security lock
type
:
•
None
- press Menu , then Menu again to
unlock.
•
Pattern lock
- press Menu , then draw a pattern
to unlock.
•
Passcode lock
- press Menu , then enter a code
to unlock.
Note: You can make emergency calls on a locked
phone (“Emergency calls” on page 14). A locked
phone still rings, but you need to unlock it to
answer.
Lock pattern
To set the lock pattern, press
Menu >
Settings
>
Security
& location
>
Security lock
>
Security lock type
>
Pattern
lock
.
Follow the instructions to draw
your lock pattern.
When prompted, draw the
pattern to unlock the phone.
Passcode lock
To set the passcode, press Menu >
Settings
>
Security & location
>
Security lock
>
Security lock
type
>
Passcode lock
.
Enter a passcode, then tap
OK
. Enter the passcode
again to confirm it, and tap
OK
.
When prompted, enter the passcode to unlock the
phone.
Personalize your lock screen
To change your timeout, press Menu >
Settings
>
Security & location
>
Screen timeout
. If you don't
tap the screen or press any keys for this amount of
time, the screen locks automatically. To unlock, see
“Lock & unlock” on page 49.
Draw Pattern to unlock
E
mergency Call
49Security
To change your lock screen picture, press Menu
>
Settings
>
Display & security
>
Wallpaper settings
.
Lock & unlock
To lock the screen/phone:
•Press Power .
•Let the screen time out (don’t press anything).
•Switch the power off.
To unlock the screen/phone:
•Press Menu or switch the phone on to display
the lock screen.
•Press Menu to unlock—if you've set a lock
pattern or passcode, you'll be asked to enter it.
Forgot your pattern or passcode?
If you forget your pattern or passcode you will need to
reset your phone to its initial factory settings, see
“Reset” on page 49.
Lock your SIM
Enable SIM PIN
To lock your SIM (the next time you power up the
phone you will need to enter your SIM PIN), press
Menu >
Settings
>
Security & location
>
Set up
SIM card lock
>
Lock SIM card
. Enter your SIM PIN
code.
Caution: If you enter an incorrect PIN code three
times, your phone locks your SIM card and asks for
your PIN unlock code, see “PUK code” on page 49.
Change SIM PIN
To change your SIM PIN, press Menu >
Settings
>
Security & location
>
Set up SIM card lock
>
Change
SIM PIN
.
PUK code
To unlock your SIM PIN, you need to enter your PIN
unlock code (PUK code) when prompted.
Note: Your PUK code is provided by your service
provider.
Reset
To reset your phone to factory settings and erase all
the data on your phone, press Menu >
Settings
>
SD card & phone storage
>
Factory data reset
>
Reset phone
.
Warning: All data on your phone will be deleted.
Lost, stolen, broken, cleared
Don't you just hate it when your life is on your phone
and it all goes wrong. Lose it, break it, reset it, or even
50 Security
worse - stolen! Relax, MOTOBLUR can help find your
phone, clear it (if you need to) and best of all, restore
all your stuff.
Track your phone
Access your MOTOBLUR account and remotely locate
your phone.
1Log into your MOTOBLUR account at:
www.motorola.com/mymotoblur.
2In the MOTOBLUR window, click on “Locate
Device”. Your phone’s location is shown on a map.
Remote clear
Access your MOTOBLUR account and remotely clear
the data on your phone.
1Log into your MOTOBLUR account at:
www.motorola.com/mymotoblur.
2In the MOTOBLUR window, click “Wipe Device”.
3A warning notification is displayed, enter your
MOTOBLUR password again.
Warning: All downloaded apps and user data will be
deleted.
Restore your phone
If you lose your phone don’t worry, your contacts are
backed-up on MOTOBLUR.
When you get your next MOTOBLUR product, just log
into your existing MOTOBLUR account on your phone
to recover all your stuff automatically.
To recover your Android Market apps, see “Manage &
restore apps” on page 40.
51Troubleshooting
Troubleshooting
we’re here to help
Crash recovery
In the unlikely event that your phone stops responding
to taps and key presses, try a quick reset. Remove the
back cover and battery (“Assemble & charge” on
page 3), then replace and turn on your phone as usual.
Service & repairs
If you have questions or need assistance, go to
www.motorola.com/support, where you can select
from a number of customer care options. You can also
contact the Motorola Customer Support Center at
1-800-331-6456 (United States), 1-888-390-6456 (TTY/
TDD United States for hearing impaired), or
1-800-461-4575 (Canada).
52
Legal & Safety
Battery Use & Safety
Important: Handle and store batteries properly to avoid injury or damage.
Most battery issues arise from improper handling of batteries, and particularly from
the continued use of damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred, or otherwise attempt to
change the form of your battery.
• Don’t let the phone or battery come in contact with water.
Water can get
into the phone’s circuits, leading to corrosion. If the phone and/or battery get
wet, have them checked by your carrier or contact Motorola, even if they appear
to be working properly.
• Don’t allow the battery to touch metal objects.
If metal objects, such as
jewelry, stay in prolonged contact with the battery contact points, the battery
could become very hot.
• Don’t place your battery near a heat source.
Excessive heat can damage the
phone or the battery. High temperatures can cause the battery to swell, leak, or
malfunction. Therefore:
•
Do
not
dry a wet or damp battery with an appliance or heat source, such as a
hair dryer or microwave oven.
•
Avoid leaving your phone in your car in high temperatures.
DOs
• Do avoid dropping the battery or phone.
Dropping these items, especially on
a hard surface, can potentially cause damage.
• Do contact your service provider or Motorola if your phone or battery
has been damaged from dropping or high temperatures.
Important: Use Motorola Original products for quality assurance and
safeguards.
To aid consumers in identifying authentic Motorola batteries from
non-original or counterfeit batteries (that may not have adequate safety protection),
Motorola provides holograms on its batteries. Consumers should confirm that any
battery they purchase has a “Motorola Original” hologram.
53
Motorola recommends you always use Motorola-branded batteries and
chargers.
Motorola mobile devices are designed to work with Motorola batteries.
If you see a message on your display such as
Invalid Battery
or
Unable to Charge
, take
the following steps:
•
Remove the battery and inspect it to confirm that it has a “Motorola Original”
hologram;
•
If there is no hologram, the battery is not a Motorola battery;
•
If there is a hologram, replace the battery and retry charging it;
•
If the message remains, contact a Motorola authorized service center.
Important:
Motorola’s warranty does not cover damage to the phone caused by
non-Motorola batteries and/or chargers.
Warning:
Use of a non-Motorola battery or charger may present a risk of fire,
explosion, leakage, or other hazard.
Proper and safe battery disposal and recycling:
Proper battery disposal is not
only important for safety, it benefits the environment. Consumers may recycle their
used batteries in many retail or service provider locations. Additional information on
proper disposal and recycling may be found on the Web:
•
www.motorola.com/recycling
•
www.rbrc.org/call2recycle/
(in English only)
Disposal:
Promptly dispose of used batteries in accordance with local
regulations. Contact your local recycling center or national recycling
organizations for more information on how to dispose of batteries.
Warning:
Never dispose of batteries in a fire because they may explode.
Battery Charging
Notes for charging your phone’s battery:
•
When charging your battery, keep it near room temperature. Never expose
batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when
charging.
•
New batteries are not fully charged.
•
New batteries or batteries stored for a long time may take more time to charge.
•
Motorola batteries and charging systems have circuitry that protects the battery
from damage from overcharging.
032375o
54
Specific Absorption Rate
SAR
Your model wireless phone meets the governmental
requirements for exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured to not exceed limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the U.S. Government and by the
Canadian regulatory authorities. These limits are part of comprehensive guidelines
and establish permitted levels of RF energy for the general population. The
guidelines are based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed for the safety of all persons,
regardless of age or health, and to account for any variations in measurements.
The exposure standard for wireless mobile phones employs a unit of measurement
known as the Specific Absorption Rate (SAR). The SAR limit set by the FCC and by
the Canadian regulatory authorities is 1.6 watts per kilogram (W/kg), averaged over
one gram of tissue. Tests for SAR are conducted using procedures accepted by the
FCC and by Industry Canada with the phone transmitting at its highest certified
power level in all tested frequencies. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone while operating can be
below the maximum value. This is because the phone is designed to operate at
multiple power levels so as to use only the power required to reach the network. In
general, the closer you are to a wireless base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S. and Canada, it
must be tested and certified to the FCC and Industry Canada that it does not exceed
the limit established by each government for safe exposure. The tests are performed
in positions and locations (e.g., at the ear and worn on the body) submitted to the
FCC and available for review by Industry Canada. The highest SAR value for this
model phone when tested for use at the ear is 1.22 W/kg, and when worn on the
body, as described in this guide, is 0.32 W/kg. The SAR value for this product in its
data transmission mode (body-worn use) is 0.38 W/kg. Body-worn measurements
can differ, depending upon available accessories and regulatory requirements. The
SAR information includes the Motorola testing protocol, assessment procedure, and
measurement uncertainty range for this product.
55
While there may be differences between the SAR levels of various phones and at
various positions, they meet the governmental requirements for safe exposure.
Please note that improvements to this product model could cause differences in the
SAR value for later products; in all cases, products are designed to be within the
guidelines.
Additional information on SAR can be found on the Cellular Telecommunications &
Internet Association (CTIA) Web site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA) Web site:
http://www.cwta.ca
Software Copyright Notice
Soft ware Copyright Notice
Motorola products may include copyrighted Motorola and third-party software
stored in semiconductor memories or other media. Laws in the United States and
other countries preserve for Motorola and third-party software providers certain
exclusive rights for copyrighted software, such as the exclusive rights to distribute
or reproduce the copyrighted software. Accordingly, any copyrighted software
contained in Motorola products may not be modified, reverse-engineered,
distributed, or reproduced in any manner to the extent allowed by law. Furthermore,
the purchase of Motorola products shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any license under the copyrights, patents, or
patent applications of Motorola or any third-party software provider, except for the
normal, non-exclusive, royalty-free license to use that arises by operation of law in
the sale of a product.
Content Copyright
Content Copyright
The unauthorized copying of copyrighted materials is contrary to the provisions of
the Copyright Laws of the United States and other countries. This device is intended
solely for copying non-copyrighted materials, materials in which you own the
copyright, or materials which you are authorized or legally permitted to copy. If you
are uncertain about your right to copy any material, please contact your legal
advisor.
AGPS & Emergency Calls
AGPS & Emergency Cal ls
56
When you make an emergency call, your mobile device can use Assisted Global
Positioning System (AGPS) satellite signals to tell the emergency response center
your approximate location.
The AGPS feature has limitations, so always tell the emergency response center
your best knowledge of your location. Remain on the phone for as long as the
emergency response center instructs you.
AGPS
might not work
for emergency calls, if your local emergency response center
does not process AGPS location information. For details, contact your local
authorities.
If your mobile device cannot find strong AGPS satellite signals, the location of the
nearest cell tower in contact with your mobile device is automatically provided to
the emergency response center.
AGPS Performance Tips
•
Go outside and away from underground locations, covered vehicles, structures
with metal or concrete roofs, tall buildings, and foliage. Indoor performance
might improve if you move closer to windows, but some window sun shielding
films can block satellite signals.
•
Move away from radios, entertainment equipment, and other electronic devices
that might interfere with or block AGPS satellite signals.
AGPS uses satellites controlled by the U.S. government and subject to changes
implemented in accordance with the Department of Defense AGPS user policy and
the Federal Radio Navigation Plan. These changes might affect AGPS performance.
Safety & General Information
Safety Information
This section contains important information on the safe and efficient
operation of your mobile device. Read this information before using your
mobile device.
Exposure to Radio Frequency (RF) Energy
Your mobile device contains a transmitter and receiver. When it is ON, it receives
and transmits RF energy. When you communicate with your mobile device, the
system handling your call controls the power level at which your mobile device
transmits.
57
Your mobile device is designed to comply with local regulatory requirements in your
country concerning exposure of human beings to RF energy.
Operational Precautions
For optimal mobile device performance, and to be sure that human exposure to RF
energy does not exceed the guidelines set forth in the relevant standards, always
follow these instructions and precautions.
Product Operation
When placing or receiving a phone call, hold your mobile device just like you would
a landline phone.
If you wear the mobile device on your body, always place the mobile device in a
Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do
not use a body-worn accessory supplied or approved by Motorola, keep the mobile
device and its antenna at least 2.5 centimeters (1 inch) from your body when
transmitting.
Using accessories not supplied or approved by Motorola may cause your mobile
device to exceed RF energy exposure guidelines. For a list of Motorola-supplied or
approved accessories, visit our Web site at:
www.motorola.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from external
sources if inadequately shielded, designed, or otherwise configured for RF energy
compatibility. In some circumstances, your mobile device may cause interference
with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct you to do
so.
In an aircraft, turn off your mobile device whenever instructed to do so by airline
staff. If your mobile device offers an airplane mode or similar feature, consult airline
staff about using it in flight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or defibrillator,
consult your physician before using this mobile device.
Persons with implantable medical devices should observe the following precautions:
58
•
ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the
implantable medical device when the mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the implantable medical device to minimize the potential
for interference.
•
Turn OFF the mobile device immediately if you have any reason to suspect that
interference is taking place.
Read and follow the directions from the manufacturer of your implantable medical
device. If you have any questions about using your mobile device with your
implantable medical device, consult your healthcare provider.
Driving Precautions
The use of wireless phones while driving may cause distraction. Discontinue a call if
you can’t concentrate on driving.
Additionally, the use of wireless devices and their accessories may be prohibited or
restricted in certain areas. Always obey the laws and regulations on the use of
these products.
Responsible driving practices can be found in “Smart Practices While Driving.”
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often, but not always, posted and
can include fueling areas, such as below decks on boats, fuel or chemical transfer or
storage facilities, or areas where the air contains chemicals or particles, such as
grain dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not remove,
install, or charge batteries. In such areas, sparks can occur and cause an explosion
or fire.
59
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as follows:
Batteries & Chargers
Caution:
Improper treatment or use of batteries may present a danger of fire,
explosion, leakage, or other hazard. For more information, see “Battery Use &
Safety.”
Keep Your Mobile Device and Its Accessories
Away From Small Children
These products are not toys and may be hazardous to small children. For example:
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile device in a fire.
Your battery or mobile device may require recycling in
accordance with local laws. Contact your local regulatory
authorities for more information.
Do not throw your battery or mobile device in the trash.
Do not let your battery, charger, or mobile device get wet.
Listening at full volume to music or voice through a headset may
damage your hearing.
032374o
032376o
032375o
60
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing hearing injury.
•
Improperly handled batteries could overheat and cause a burn.
Glass Parts
Some parts of your mobile device may be made of glass. This glass could break if
the product is dropped on a hard surface or receives a substantial impact. If glass
breaks, do not touch or attempt to remove. Stop using your mobile device until the
glass is replaced by a qualified service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when exposed to
flashing lights, such as when playing video games. These may occur even if a person
has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family history of such
occurrences, please consult with your physician before playing video games or
enabling a flashing-lights feature (if available) on your mobile device.
Discontinue use and consult a physician if any of the following symptoms occur:
convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or
disorientation. It is always a good idea to hold the screen away from your eyes,
leave the lights on in the room, take a 15-minute break every hour, and stop use if
you are tired.
Caution About High Volume Usage
Warning:
Exposure to loud noise from any source for extended
periods of time may affect your hearing. The louder the volume sound
level, the less time is required before your hearing could be affected.
To protect your hearing:
•
Limit the amount of time you use headsets or headphones at high volume.
•
Avoid turning up the volume to block out noisy surroundings.
•
Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness
in your ears, ringing in your ears, or muffled speech, you should stop listening to the
device through your headset or headphones and have your hearing checked.
61
For more information about hearing, see our Web site at
www.motorola.com/
hearingsafety
(in English only).
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering
finger-written characters, you may experience occasional discomfort in your hands,
arms, shoulders, neck, or other parts of your body. If you continue to have discomfort
during or after such use, stop use and see a physician.
[Jan0109]
FCC Notice to Users
FCC Notice
The following statement applies to all products that have received FCC
approval. Applicable products bear the FCC logo, and/or an FCC ID in the
format FCC-ID:xxxxxx on the product label.
Motorola has not approved any changes or modifications to this device by the user.
Any changes or modifications could void the user’s authority to operate the
equipment. See 47 CFR Sec. 15.21.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation. See 47 CFR Sec. 15.19(3).
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the receiver.
62
•
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Use & Care
Use & Care
To care for your Motorola phone, please keep it away from:
liquids of any kind
Don’t expose your phone to water, rain, extreme humidity, sweat, or
other moisture. If it does get wet, don’t try to accelerate drying with the
use of an oven or dryer, as this may damage the phone.
extreme heat or cold
Avoid temperatures below 0°C/32°F or above 45°C/113°F.
microwaves
Don’t try to dry your phone in a microwave oven.
dust and dirt
Don’t expose your phone to dust, dirt, sand, food, or other inappropriate
materials.
cleaning solutions
To clean your phone, use only a dry soft cloth. Don’t use alcohol or other
cleaning solutions.
the ground
Don’t drop your phone.
Smart Practices While Driving
Drivi ng Safety
Drive Safe, Call Smart
63
Check the laws and regulations on the use of mobile devices and their
accessories in the areas where you drive. Always obey them. The use of
these devices may be prohibited or restricted in certain areas—for
example, handsfree use only. Go to
www.motorola.com/callsmart
(in English only) for more information.
Your mobile device lets you communicate by voice and data—almost anywhere,
anytime, wherever wireless service is available and safe conditions allow. When
driving a car, driving is your first responsibility. If you choose to use your mobile
device while driving, remember the following tips:
• Get to know your Motorola mobile device and its features such as speed
dial and redial.
If available, these features help you to place your call without
taking your attention off the road.
• When available, use a handsfree device.
If possible, add
an additional layer of convenience to your mobile device with
one of the many Motorola Original handsfree accessories
available today.
• Position your mobile device within easy reach.
Be able to
access your mobile device without removing your eyes from the road. If you
receive an incoming call at an inconvenient time, if possible, let your voicemail
answer it for you.
• Let the person you are speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous weather conditions.
Rain,
sleet, snow, ice, and even heavy traffic can be hazardous.
• Do not take notes or look up phone numbers while driving.
Jotting down a
“to do” list or going through your address book takes attention away from your
primary responsibility—driving safely.
• Dial sensibly and assess the traffic; if possible, place calls when your
car is not moving or before pulling into traffic.
If you must make a call while
moving, dial only a few numbers, check the road and your mirrors, then continue.
• Do not engage in stressful or emotional conversations that may be
distracting.
Make people you are talking with aware you are driving and
suspend conversations that can divert your attention away from the road.
64
•Use your mobile device to call for help.
Dial 911 or other local emergency
number in the case of fire, traffic accident, or medical emergencies (wherever
wireless phone service is available).
•Use your mobile device to help others in emergencies.
If you see an auto
accident, crime in progress, or other serious emergency where lives are in
danger, call 911 or other local emergency number (wherever wireless phone
service is available), as you would want others to do for you.
•Call roadside assistance or a special non-emergency wireless
assistance number when necessary.
If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a minor traffic accident where
no one appears injured, or a vehicle you know to be stolen, call roadside
assistance or other special non-emergency wireless number (wherever wireless
phone service is available).
65
Motorola, Inc.
Consumer Advocacy Office
600 N US Hwy 45
Libertyville, IL 60048
www.hellomoto.com
Certain mobile phone features are dependent on the capabilities and settings of
your service provider’s network. Additionally, certain features may not be activated
by your service provider, and/or the provider’s network settings may limit the
feature’s functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other product
specifications, as well as the information contained in this guide, are based upon
the latest available information and believed to be accurate at the time of printing.
Motorola reserves the right to change or modify any information or specifications
without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark
Office. The Bluetooth trademarks are owned by their proprietor and used by
Motorola, Inc. under license. Microsoft, Windows, Windows Me, and Windows
Vista are registered trademarks of Microsoft Corporation in the United States and
other countries. Macintosh is a registered trademark of Apple Computer, Inc.
Google, YouTube, Picasa, Gmail, and the Google logo are trademarks of Google, Inc.
is a Certification Mark of the Wireless Fidelity Alliance, Inc. All other product
or service names are the property of their respective owners.
© 2009 Motorola, Inc. All rights reserved.
Caution:
Changes or modifications made in the radio phone, not expressly approved
by Motorola, will void the user’s authority to operate the equipment.
Bluetooth ID: B015537
MOTOROLA
DEXT
with MOTOBLUR (MB200)
Manual Number: 68XXXXX367-A
U.S. patent Re. 34,976
