User Manual Safety Regulatory and Legal
1
Safety, Regulatory, & Legal
Where is my legal, safety and regulatory information?.In order to
provide you with better access to this important information, we’ve
made the materials accessible from the phone’s settings menu and on
the web. Please review these materials prior to using your device. To
access the materials from a connected phone, go to Settings > Legal
information, and select a topic. To access the materials on the web,
visit www.motorola.com/device-legal.
Specific Absorption Rate (FCC/IEEE and ICNIRP).
YOUR MOBILE DEVICE MEETS INTERNATIONAL GUIDELINES FOR
EXPOSURE TO RADIO WAVES. The highest SAR values under the
ICNIRP guidelines for your device model are listed below:
Model XT1789-01
Head SAR GSM, CDMA, WCDMA, LTE,
Wi-Fi, Bluetooth 0.87 W/kg
Body-worn SAR LTE Band 2, Wi-Fi, Bluetooth 1.10 W/kg
Model XT1789-02
Head SAR GSM, CDMA, WCDMA, LTE,
Wi-Fi, Bluetooth 0.87 W/kg
Body-worn SAR LTE Band 2, Wi-Fi, Bluetooth 1.10 W/kg
Model XT1789-03
Head SAR GSM, CDMA, WCDMA, LTE,
Wi-Fi, Bluetooth 0.87 W/kg
Body-worn SAR LTE Band 41, Wi-Fi, Bluetooth 1.13 W/kg
Model XT1789-04
Head SAR GSM, CDMA, WCDMA, LTE,
Wi-Fi, Bluetooth 0.87 W/kg
Body-worn SAR LTE Band 2, Wi-Fi, Bluetooth 1.10 W/kg
FCC/CE
06Jun2017
2
Model XT1789-05 and XT1789-06
Head SAR GSM, CDMA, WCDMA, LTE,
Wi-Fi, Bluetooth 0.87 W/kg
Body-worn SAR LTE Band 7, Wi-Fi, Bluetooth 1.18 W/kg
To view additional SAR information on your phone, go to Settings >
Legal information > RF information. To view the information on the
web, visit www.motorola.com/rfhealth.
Electronic Label. Your mobile device may use an electronic label
that provides some regulatory information about the device. To see
the electronic label, go to Settings > About phone > Regulatory
information.
Battery charging. Charge your mobile device using a compatible
Motorola charger, another brand class 2 Limited Power Source USB
charger that complies with USB 1.1, 2.0, 3.0, or greater, and complies
with EN301489-34, EN60950-1 or equivalent, or a high-power USB
port on a PC. Chargers that do not comply with these standards may
be unsafe and may cause slow charging, product damage, or reduced
device performance.
• Your mobile device will not charge if the temperature is too high
or low.
• Only use Motorola-approved batteries, which contain safety
circuitry and are designed to give the best performance in your
mobile device.
• Don’t use a damaged charger or charger cable to charge your
device.
• Don’t use tools, sharp objects, or excessive force to clean the USB
port, as this may damage your mobile device.
Distractions. Using your mobile device in some circumstances could
distract you and may cause a dangerous situation. Be aware of your
surroundings and environmental hazards when using your mobile
device.
Driving Precautions. Responsible and safe driving is your primary
responsibility when driving a vehicle. Always obey local laws and
regulations.
Seizures, blackouts, eyestrain & discomfort. Prolonged use of any
device may cause discomfort in hands, fingers, arms, neck, and other
parts of your body, and may cause eyestrain and headaches. It is good
practice to use your device in a safe area with comfortable ambient
lighting, and take frequent breaks if you feel discomfort. Seek medical
advice if symptoms persist.
In rare cases, flashing patterns or lights, for example in video games
or movies, may cause seizures or blackouts. If you suer any seizures
FCC/CE
06Jun2017
3
or blackouts, or have a history of seizures, stop using your device and
seek medical advice.
Medical devices. If you use an implantable pacemaker or defibrillator,
or other medical device, consult your healthcare provider and the
device manufacturer’s directions before using this mobile device.
If you use a pacemaker or defibrillator, the FCC recommends that you
observe the following precautions:
• ALWAYS keep the mobile device more than 20 centimeters (8
inches) from the pacemaker or defibrillator.
• Use the ear opposite the pacemaker or defibrillator to minimize
the potential for interference.
• Turn OFF the mobile device immediately if you have any reason to
suspect that interference is taking place.
Important: Some products contain magnets. Always keep products
with magnets more than 20 cm. (8 in.) from medical devices, such as
pacemakers, internal cardio defibrillators or other devices that can
be aected by a magnetic field. Also, keep away from credit cards, ID
cards and other media that use magnetically encoded information.
Children and animals. Keep your mobile device and its accessories
away from small children and animals. These products are not toys
and maybe hazardous to small children and animals. For example, a
choking hazard may exist for small, detachable parts. Keep plastic
bags away from babies and children to avoid danger of suocation
and choking. Supervise access. If children use your mobile device and
accessories, monitor their access for their safety, and to help prevent
loss of data or unexpected charges for data or app purchases.
Glass parts. Some parts of your mobile device, like your screen, could
be made of glass. If the glass breaks, chips, or cracks, do not touch
or attempt to remove it. Stop using your mobile device until it can be
repaired by a qualified service center.
Use & care. To care for your Motorola mobile device, please observe
the following:
• Liquids. Don’t expose your mobile device to water, rain, extreme
humidity, sweat, or other liquids.
• Drying. Don’t try to dry your mobile device using a microwave
oven, conventional oven, or dryer.
• Extreme heat or cold. Don’t store, charge, or use your mobile
device in extreme heat or cold.
• Dust and dirt. Don’t expose your mobile device to dust, dirt, sand,
food, or similar materials.
• Cleaning. To clean your mobile device, use only a dry soft cloth.
Don’t use chemicals or compressed air.
• Shock and vibration. Don’t drop your mobile device or expose it
FCC/CE
06Jun2017
4
to strong vibration.
• Protection. To help protect your mobile device, always make sure
that any available connectors, compartments and removable
covers are closed and secure, and avoid carrying it with hard
objects such as keys or coins.
Supported Frequencies and Power. This device is capable of
operation on the following frequencies, subject to location and
network availability.
Model XT1789-01 and XT1789-02
Operating Mode Frequency Range
MHz / Band Maximum Nominal
Transmit Power
(conducted) dBm
Bluetooth 2400 – 2483.5 20
WLAN 2400 – 2483.5 20
WLAN 5150 - 5850 23
NFC 13.56 60dBuA/m @10m
GPS 1575.42 N /A
GSM 2/3/5/8 33
UMTS 1/2/4/5/8 24
LTE 1/2/4/5/7/8/12/13
/17/20/25/26/28
/46/66
23
Model XT1789-03
Operating Mode Frequency Range
MHz / Band Maximum Nominal
Transmit Power
(conducted) dBm
Bluetooth 2400 – 2483.5 20
WLAN 2400 – 2483.5 20
WLAN 5150 - 5850 23
NFC 13.56 60dBuA/m @10m
FCC/CE
06Jun2017
5
CDMA BC0/BC1/BC10
GPS 1575.42 N /A
GSM 2/3/5/8 33
UMTS 1/2/4/5/8 24
LTE 1/2/3/4/5/8/12/13/1
7/20/25/26/41 23
Model XT1789-04
Operating Mode Frequency Range
MHz / Band Maximum Nominal
Transmit Power
(conducted) dBm
Bluetooth 2400 – 2483.5 20
WLAN 2400 – 2483.5 20
WLAN 5150 - 5850 23
NFC 13.56 60dBuA/m @10m
GPS 1575.42 N /A
GSM 2/3/5/8 33
UMTS 1/2/4/5/8 24
LTE 1/2/3/4/5/7/8/12/13
/17/18/20/25/26/28
/46/66/252/255
23
Model XT1789-05
Operating Mode Frequency Range
MHz / Band Maximum Nominal
Transmit Power
(conducted) dBm
Bluetooth 2400 – 2483.5 20
WLAN 2400 – 2483.5 20
WLAN 5150 - 5850 23
FCC/CE
06Jun2017
6
NFC 13.56 60dBuA/m @10m
GPS 1575.42 N /A
GSM 2/3/5/8 33
UMTS 1/2/4/5/8 24
LTE 1/2/3/4/5/7/8/12/17
/20/25/26/28/34/3
9/40/41/46/255
23
Model XT1789-06
Operating Mode Frequency Range
MHz / Band Maximum Nominal
Transmit Power
(conducted) dBm
Bluetooth 2400 – 2483.5 20
WLAN 2400 – 2483.5 20
WLAN 5150 - 5850 23
NFC 13.56 60dBuA/m @10m
GPS 1575.42 N /A
GSM 2/3/5/8 33
UMTS 1/2/4/5/8/19 24
LTE 1/2/3/4/5/7/8/12/17
/18/19/20/26/34/3
8/39/40/41/46
23
European Conformance (CE). Contact point: Regulatory Compliance,
Motorola Mobility UK Ltd., Redwood, Crockford Lane, Chineham
Business Park, Basingstoke, RG24 8WQ, UK.
Hereby, Motorola Mobility LLC declares that the radio
equipment with this declaration and bearing the CE mark is
in compliance with Directive 2014/53/EU.
The full DoC can be found at www.motorola.com/red. Use the search
feature to find your device’s model or type. Your device’s model
and type may be under the battery, under the rear cover, or on the
exterior of the device.
Restrictions of Use. This product may be used in the
FCC/CE
06Jun2017
7
following member states subject to the following
restrictions. For products that support Wi-Fi 802.11a/ac
(as defined in your product information): Outside the
United States, this device is restricted to indoor use when
operating in the 5.15 to 5.25 GHz (802.11a) Wi-Fi frequency
band.
AT BE BG CH CY CZ DE DK EE EL ES
FI FR HR HU IE IS IT LI LT LU LV
MT NL NO PL PT RO SE SI SK TR UK
FCC and IC Compliance. [en-US, fr-CA] This device complies with
part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that might cause undesired operation. This device
complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference received, including interference that might cause
undesired operation.
Hearing Aid Compatibility. [en-US] In the US, specific hearing aid
compatibility (HAC) performance ratings can help clarify how certain
wireless phones and hearing aids perform together. HAC compliant
wireless phones are capable of working with hearing aids that have a
minimal immunity rating of at least 2. The immunity rating indicates
how susceptible a hearing aid is to picking up interference from a
digital wireless phone. It can rate the performance of the hearing
aid for either microphone and/or telecoil coupling. Some hearing
aids are more immune than others to this interference noise, and
phones also vary in the amount of interference they generate. The
US performance rating system for HAC compliant wireless phones
is as follows:
The “M” (microphone) indicates that the product has been tested
and rated for acoustic coupling. The “T” (telecoil) represents that
the product has been tested and rated for inductive coupling. The
higher the “M” or “T” rating, the less likely the hearing aid user will
experience interference when the hearing aid is set to the respective
microphone or telecoil mode. The highest values to date are 3 and 4
(e.g., “M4” or “M3/T3”).
To determine if a product is rated for HAC, please look for the HAC
rating or logo on the phone’s packaging. For a list of current HAC
models, visit www.motorola.com/hacphones.
Results will vary depending on the user’s hearing aid and hearing
loss. If your hearing aid happens to be vulnerable to interference,
you may not be able to use a rated phone successfully. Trying out
FCC/CE
06Jun2017
8
the phone with your hearing device is the best way to evaluate it for
your personal needs. To couple the device to your telecoil equipped
hearing aid, switch your hearing aid to the “T” or telecoil setting.
Then, enable the ‘Hearing Aid’ mode feature on your phone with the
following sequence: Phone > Menu > Settings > Calls > Hearing aids.
Hearing aid compatible phones have been tested and rated for use
with hearing aids for some of the wireless technologies that it uses.
However, there may be newer wireless technologies used in this phone
that have not been tested yet for use with hearing aids. It is important
to try the dierent features of this phone thoroughly and in dierent
locations, using your hearing aid or cochlear implant, to determine if
you hear any interfering noise.
Contact your service provider or Motorola for information on hearing
aid compatibility. If you have questions about return or exchange
policies, contact your service provider or phone retailer.
Service & Repairs. If you have questions or need assistance, we’re
here to help. Go to www.motorola.com/support, where you can select
from a number of customer care options.
Copyright & Trademarks. MOTOROLA, the stylized M logo, MOTO,
and the MOTO family of marks are trademarks or registered
trademarks of Motorola Trademark Holdings, LLC. LENOVO is a
trademark of Lenovo. All other product or service names are the
property of their respective owners.
© 2017 Motorola Mobility LLC. All rights reserved.
Manual Number: TBD-A
Motorola Mobility LLC
222 W. Merchandise Mart Plaza
Chicago, IL 60654
www.motorola.com
FCC/CE
06Jun2017
User Manual Safety, Regulatory, and Legal
1
Safety, Regulatory, & Legal
Where is my legal, safety and regulatory information?.In order to
provide you with better access to this important information, we’ve
made the materials accessible from the phone’s settings menu and on
the web. Please review these materials prior to using your device. To
access the materials from a connected phone, go to Settings > Legal
information, and select a topic. To access the materials on the web,
visit www.motorola.com/device-legal.
Specific Absorption Rate (FCC/IEEE and ICNIRP).
YOUR MOBILE DEVICE MEETS INTERNATIONAL GUIDELINES FOR
EXPOSURE TO RADIO WAVES. The highest SAR values under the
ICNIRP guidelines for your device model are listed below:
Model XT1789-01
Head SAR GSM, CDMA, WCDMA, LTE,
Wi-Fi, Bluetooth 0.87 W/kg
Body-worn SAR LTE Band 2, Wi-Fi, Bluetooth 1.10 W/kg
Model XT1789-02
Head SAR GSM, CDMA, WCDMA, LTE,
Wi-Fi, Bluetooth 0.87 W/kg
Body-worn SAR LTE Band 2, Wi-Fi, Bluetooth 1.10 W/kg
Model XT1789-03
Head SAR GSM, CDMA, WCDMA, LTE,
Wi-Fi, Bluetooth 0.87 W/kg
Body-worn SAR LTE Band 41, Wi-Fi, Bluetooth 1.13 W/kg
Model XT1789-04
Head SAR GSM, CDMA, WCDMA, LTE,
Wi-Fi, Bluetooth 0.87 W/kg
Body-worn SAR LTE Band 2, Wi-Fi, Bluetooth 1.10 W/kg
FCC/CE
06Jun2017
2
Model XT1789-05 and XT1789-06
Head SAR GSM, CDMA, WCDMA, LTE,
Wi-Fi, Bluetooth 0.87 W/kg
Body-worn SAR LTE Band 7, Wi-Fi, Bluetooth 1.18 W/kg
To view additional SAR information on your phone, go to Settings >
Legal information > RF information. To view the information on the
web, visit www.motorola.com/rfhealth.
Electronic Label. Your mobile device may use an electronic label
that provides some regulatory information about the device. To see
the electronic label, go to Settings > About phone > Regulatory
information.
Battery charging. Charge your mobile device using a compatible
Motorola charger, another brand class 2 Limited Power Source USB
charger that complies with USB 1.1, 2.0, 3.0, or greater, and complies
with EN301489-34, EN60950-1 or equivalent, or a high-power USB
port on a PC. Chargers that do not comply with these standards may
be unsafe and may cause slow charging, product damage, or reduced
device performance.
• Your mobile device will not charge if the temperature is too high
or low.
• Only use Motorola-approved batteries, which contain safety
circuitry and are designed to give the best performance in your
mobile device.
• Don’t use a damaged charger or charger cable to charge your
device.
• Don’t use tools, sharp objects, or excessive force to clean the USB
port, as this may damage your mobile device.
Distractions. Using your mobile device in some circumstances could
distract you and may cause a dangerous situation. Be aware of your
surroundings and environmental hazards when using your mobile
device.
Driving Precautions. Responsible and safe driving is your primary
responsibility when driving a vehicle. Always obey local laws and
regulations.
Seizures, blackouts, eyestrain & discomfort. Prolonged use of any
device may cause discomfort in hands, fingers, arms, neck, and other
parts of your body, and may cause eyestrain and headaches. It is good
practice to use your device in a safe area with comfortable ambient
lighting, and take frequent breaks if you feel discomfort. Seek medical
advice if symptoms persist.
In rare cases, flashing patterns or lights, for example in video games
or movies, may cause seizures or blackouts. If you suer any seizures
FCC/CE
06Jun2017
3
or blackouts, or have a history of seizures, stop using your device and
seek medical advice.
Medical devices. If you use an implantable pacemaker or defibrillator,
or other medical device, consult your healthcare provider and the
device manufacturer’s directions before using this mobile device.
If you use a pacemaker or defibrillator, the FCC recommends that you
observe the following precautions:
• ALWAYS keep the mobile device more than 20 centimeters (8
inches) from the pacemaker or defibrillator.
• Use the ear opposite the pacemaker or defibrillator to minimize
the potential for interference.
• Turn OFF the mobile device immediately if you have any reason to
suspect that interference is taking place.
Important: Some products contain magnets. Always keep products
with magnets more than 20 cm. (8 in.) from medical devices, such as
pacemakers, internal cardio defibrillators or other devices that can
be aected by a magnetic field. Also, keep away from credit cards, ID
cards and other media that use magnetically encoded information.
Children and animals. Keep your mobile device and its accessories
away from small children and animals. These products are not toys
and maybe hazardous to small children and animals. For example, a
choking hazard may exist for small, detachable parts. Keep plastic
bags away from babies and children to avoid danger of suocation
and choking. Supervise access. If children use your mobile device and
accessories, monitor their access for their safety, and to help prevent
loss of data or unexpected charges for data or app purchases.
Glass parts. Some parts of your mobile device, like your screen, could
be made of glass. If the glass breaks, chips, or cracks, do not touch
or attempt to remove it. Stop using your mobile device until it can be
repaired by a qualified service center.
Use & care. To care for your Motorola mobile device, please observe
the following:
• Liquids. Don’t expose your mobile device to water, rain, extreme
humidity, sweat, or other liquids.
• Drying. Don’t try to dry your mobile device using a microwave
oven, conventional oven, or dryer.
• Extreme heat or cold. Don’t store, charge, or use your mobile
device in extreme heat or cold.
• Dust and dirt. Don’t expose your mobile device to dust, dirt, sand,
food, or similar materials.
• Cleaning. To clean your mobile device, use only a dry soft cloth.
Don’t use chemicals or compressed air.
• Shock and vibration. Don’t drop your mobile device or expose it
FCC/CE
06Jun2017
4
to strong vibration.
• Protection. To help protect your mobile device, always make sure
that any available connectors, compartments and removable
covers are closed and secure, and avoid carrying it with hard
objects such as keys or coins.
Supported Frequencies and Power. This device is capable of
operation on the following frequencies, subject to location and
network availability.
Model XT1789-01 and XT1789-02
Operating Mode Frequency Range
MHz / Band Maximum Nominal
Transmit Power
(conducted) dBm
Bluetooth 2400 – 2483.5 20
WLAN 2400 – 2483.5 20
WLAN 5150 - 5850 23
NFC 13.56 60dBuA/m @10m
GPS 1575.42 N /A
GSM 2/3/5/8 33
UMTS 1/2/4/5/8 24
LTE 1/2/4/5/7/8/12/13
/17/20/25/26/28
/46/66
23
Model XT1789-03
Operating Mode Frequency Range
MHz / Band Maximum Nominal
Transmit Power
(conducted) dBm
Bluetooth 2400 – 2483.5 20
WLAN 2400 – 2483.5 20
WLAN 5150 - 5850 23
NFC 13.56 60dBuA/m @10m
FCC/CE
06Jun2017
5
CDMA BC0/BC1/BC10
GPS 1575.42 N /A
GSM 2/3/5/8 33
UMTS 1/2/4/5/8 24
LTE 1/2/3/4/5/8/12/13/1
7/20/25/26/41 23
Model XT1789-04
Operating Mode Frequency Range
MHz / Band Maximum Nominal
Transmit Power
(conducted) dBm
Bluetooth 2400 – 2483.5 20
WLAN 2400 – 2483.5 20
WLAN 5150 - 5850 23
NFC 13.56 60dBuA/m @10m
GPS 1575.42 N /A
GSM 2/3/5/8 33
UMTS 1/2/4/5/8 24
LTE 1/2/3/4/5/7/8/12/13
/17/18/20/25/26/28
/46/66/252/255
23
Model XT1789-05
Operating Mode Frequency Range
MHz / Band Maximum Nominal
Transmit Power
(conducted) dBm
Bluetooth 2400 – 2483.5 20
WLAN 2400 – 2483.5 20
WLAN 5150 - 5850 23
FCC/CE
06Jun2017
6
NFC 13.56 60dBuA/m @10m
GPS 1575.42 N /A
GSM 2/3/5/8 33
UMTS 1/2/4/5/8 24
LTE 1/2/3/4/5/7/8/12/17
/20/25/26/28/34/3
9/40/41/46/255
23
Model XT1789-06
Operating Mode Frequency Range
MHz / Band Maximum Nominal
Transmit Power
(conducted) dBm
Bluetooth 2400 – 2483.5 20
WLAN 2400 – 2483.5 20
WLAN 5150 - 5850 23
NFC 13.56 60dBuA/m @10m
GPS 1575.42 N /A
GSM 2/3/5/8 33
UMTS 1/2/4/5/8/19 24
LTE 1/2/3/4/5/7/8/12/17
/18/19/20/26/34/3
8/39/40/41/46
23
European Conformance (CE). Contact point: Regulatory Compliance,
Motorola Mobility UK Ltd., Redwood, Crockford Lane, Chineham
Business Park, Basingstoke, RG24 8WQ, UK.
Hereby, Motorola Mobility LLC declares that the radio
equipment with this declaration and bearing the CE mark is
in compliance with Directive 2014/53/EU.
The full DoC can be found at www.motorola.com/red. Use the search
feature to find your device’s model or type. Your device’s model
and type may be under the battery, under the rear cover, or on the
exterior of the device.
Restrictions of Use. This product may be used in the
FCC/CE
06Jun2017
7
following member states subject to the following
restrictions. For products that support Wi-Fi 802.11a/ac
(as defined in your product information): Outside the
United States, this device is restricted to indoor use when
operating in the 5.15 to 5.25 GHz (802.11a) Wi-Fi frequency
band.
AT BE BG CH CY CZ DE DK EE EL ES
FI FR HR HU IE IS IT LI LT LU LV
MT NL NO PL PT RO SE SI SK TR UK
FCC and IC Compliance. [en-US, fr-CA] This device complies with
part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that might cause undesired operation. This device
complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference received, including interference that might cause
undesired operation.
Hearing Aid Compatibility. [en-US] In the US, specific hearing aid
compatibility (HAC) performance ratings can help clarify how certain
wireless phones and hearing aids perform together. HAC compliant
wireless phones are capable of working with hearing aids that have a
minimal immunity rating of at least 2. The immunity rating indicates
how susceptible a hearing aid is to picking up interference from a
digital wireless phone. It can rate the performance of the hearing
aid for either microphone and/or telecoil coupling. Some hearing
aids are more immune than others to this interference noise, and
phones also vary in the amount of interference they generate. The
US performance rating system for HAC compliant wireless phones
is as follows:
The “M” (microphone) indicates that the product has been tested
and rated for acoustic coupling. The “T” (telecoil) represents that
the product has been tested and rated for inductive coupling. The
higher the “M” or “T” rating, the less likely the hearing aid user will
experience interference when the hearing aid is set to the respective
microphone or telecoil mode. The highest values to date are 3 and 4
(e.g., “M4” or “M3/T3”).
To determine if a product is rated for HAC, please look for the HAC
rating or logo on the phone’s packaging. For a list of current HAC
models, visit www.motorola.com/hacphones.
Results will vary depending on the user’s hearing aid and hearing
loss. If your hearing aid happens to be vulnerable to interference,
you may not be able to use a rated phone successfully. Trying out
FCC/CE
06Jun2017
8
the phone with your hearing device is the best way to evaluate it for
your personal needs. To couple the device to your telecoil equipped
hearing aid, switch your hearing aid to the “T” or telecoil setting.
Then, enable the ‘Hearing Aid’ mode feature on your phone with the
following sequence: Phone > Menu > Settings > Calls > Hearing aids.
Hearing aid compatible phones have been tested and rated for use
with hearing aids for some of the wireless technologies that it uses.
However, there may be newer wireless technologies used in this phone
that have not been tested yet for use with hearing aids. It is important
to try the dierent features of this phone thoroughly and in dierent
locations, using your hearing aid or cochlear implant, to determine if
you hear any interfering noise.
Contact your service provider or Motorola for information on hearing
aid compatibility. If you have questions about return or exchange
policies, contact your service provider or phone retailer.
Service & Repairs. If you have questions or need assistance, we’re
here to help. Go to www.motorola.com/support, where you can select
from a number of customer care options.
Copyright & Trademarks. MOTOROLA, the stylized M logo, MOTO,
and the MOTO family of marks are trademarks or registered
trademarks of Motorola Trademark Holdings, LLC. LENOVO is a
trademark of Lenovo. All other product or service names are the
property of their respective owners.
© 2017 Motorola Mobility LLC. All rights reserved.
Manual Number: TBD-A
Motorola Mobility LLC
222 W. Merchandise Mart Plaza
Chicago, IL 60654
www.motorola.com
FCC/CE
06Jun2017
