Motorola Mobility T6AW1 PCS portable transceiver User Manual AW EX08
Motorola Mobility LLC PCS portable transceiver AW EX08
Exhibit 8 Users manual
APPLICANT: MOTOROLA, INC. FCC ID: IHDT6AW1
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:
PRELIMINARY
Options Menu
Quick Reference
Restrict My Phone Number
Nav Disc
(A5) Book_8J51.book Page 1 Thursday, May 4, 2000 3:32 PM
PRELIMINARY
Special Keys
Press to turn phone on and off.
Press to accept call, setting, option,...
Press to reject call, setting, option,...
Press to enter the Quick Access features.
Press to access the menu options and navigate menus.
(NavDisc)
Press to select entries and Menu options.
Press to call Voicemail.
Press to read message.
Press to write message.
Press for ALT keys and keypad.
Press for symbols and additional characters.
Making a Call
Enter .
Receiving a Call
Press .
Ending a Call
Press , .
Making an Emergency Call
Enter . The call will be
directed to a central emergency operator.
Quick Access Features
Press followed by the appropriate
key, or press , scroll to the feature and
press to select.
Adjust Ringer Volume
Press followed by the volume button
to either increase or decrease the ringer
volume.
Recording a VoiceNote™
Press the Start/Stop Record button ( ) on
the keyboard. Press the button again to
stop recording.
Playing a VoiceNote
Select Messages, VoiceNote, Play
VoiceNotes, or use the Quick Access item.
Redialing the Last Number
Called
1Press to display the last number
dialed (Made Calls).
2Press to call the number.
3Select ‘Call Number’ and press .
One-Touch Dialling
Press and hold the appropriate digit key
to .
Recalling a Number from the
Phone Book
Press the Smart button ( ) then use the
volume button to scroll to the stored
number, or press the appropriate digit key
to skip to a particular letter. To make the
call, either hold down for 1.5 seconds or
press .
Dialing Phone Book Numbers
Enter
Stopping a Call Alert
Press the volume button when the phone is
ringing or vibrating. This will stop the alert
but not answer the call.
Voice Dialing
Press the Smart button ( ). If there is a
Phone Book entry with a Voice Tag the
prompt Say Name After Tone
appears. Wait for the tone to finish and
then say the name associated with the
number you want to call.
Quick Reference
(A5) Book_8J51.book Page 2 Thursday, May 4, 2000 3:32 PM
PRELIMINARY
Quick Reference
Customizing the Quick Access Menu
You can change the features in the Quick Access
menu to suit your personal preferences.
To customize the menu, you can use either the
Quick Access Setup menu or do the following:
1Press to scroll to the menu item you
wish to change.
2Press and hold to access the list of
features available. The currently selected
feature display.
3Scroll through the list until you find the
feature you wish to store in the Quick Access
menu; press .
4Completed will be displayed to confirm
that the feature has been stored.
The following items are in the Quick Access list:
• Find by Name
• Find by Location
• Add Entry to Phone
• Add Entry to SIM
• Call Voicemail
• Battery Meter
• Phone Lock Now
• Phone Mute On or Off
• Ring Volume
• VibraCall On or Off
• Switch Memory
• Read Messages
• Outgoing Messages
• Message Editor
• Last Calls Missed
Standard setting for
Quick Access‡
Update TBD
• Last Call Charge
• Last Call Timer
• Show Time and Date
• Credit Remaining
• Restrict My ID
• Find New Network
• Switch Line 1/2*
• Change Band
• Play VoiceNotes
• Divert Voice Call
• Adjust Contrast
•Access Internet
• Set Alarm
•Edit Music
* Availability depends on the type and settings of the SIM card, and/or your
subscription of this feature.
(A5) Book_8J51.book Page 5 Thursday, May 4, 2000 3:32 PM
PRELIMINARY
Quick Reference
VoiceNotes Recording
Button Located on top of
the phone, next to the
antenna. Press it to start
recording a VoiceNote Press
the button to stop recording.
Quick Access Key
A dedicated key for short
cuts to 9 of your most
frequently used functions.
Charger / Accessory Port
Expand the use of your
phone through the
accessories offered...
chargers, cigarette lighter
adaptor and data
accessories.
Volume Keys
Upper and lower buttons
adjust keypad, earpiece and
ringer volume.
Smart Button
Smart button gives one touch
access to the phone book and
can place, answer, or end calls
when headset is attached.
Headset Port
For connection to portable,
handsfree headset.
Write Message
Quickly compose a SMS
message.
Read Message
Read incoming SMS
messages.
QWERTY Keyboard
Easily enter the letters per
messages.
Keypad
Dial the phone number.
Access the menu with all
your phone’s features.
Replace with
Layout
Camelot
(A5) Book_8J51.book Page 6 Thursday, May 4, 2000 3:32 PM
Introduction 1
PRELIMINARY
Introduction
Welcome
Congratulations on your purchase of a Personal Interactive Communicator (P.I.C.) phone
from Motorola, the world leader in cellular technology. The phones are packed with
features that put you in control and give you unrivalled power, while remaining
discrete.
Control
• Customizable Quick Access Menu
- Place nine of your most frequently
used features in your own personal menu
so they can be accessed with just two key
presses. Icons make each feature easy to
identify.
• VoiceNotes™ feature - Allows you
to record a number of personal voice
messages or to record part of a phone call
- useful when you haven’t got pen and
paper available for taking directions or
messages.
•Voice Control - Use voice commands to
call Phone Book entries and select Quick
Access options.
Power
• Superb battery performance -
Each phone is capable of several hours
conversation or several days standby, and
still be small and light.
• Dual Band - versions of the phone
include the powerful Dual Band feature
meaning they can use both 900 and
1800MHz bands for greater call success
and allow wider roaming opportunities.
Before you use your phone, please
see Your Battery on page 17, for
important information on charging
a new battery.
Discretion
• VibraCall™ - In locations where you
don’t want your phone to ring, or are too
noisy to hear your phone ring, your
phone can vibrate to alert you of a call.
• Wearable Holster - Wear your phone in
a stylish holster on your belt. It is small
enough and light enough to keep with
you almost anywhere.
• Stop Call Alert - Press the volume button
when the phone is ringing or vibrating.
This will stop the alert but not answer the
call.
Personality™
This cellular telephone incorporates
Personality. Unique to Motorola,
Personality removes the complexity of
cellular communications by guiding you
through the features and presenting you
with simple choices every step of the way.
Personality also allows you to personalize
the way you use your phone - for example,
different ringer tones, a phone book, and
network selection preferences - all presented
with clarity and simplicity. In this manual,
each of the Personality features is identified
with an symbol to indicate that it is
customizable to meet your requirements.
(A5) Book_8J51.book Page 1 Thursday, May 4, 2000 3:32 PM
Introduction
2
PRELIMINARY
Understanding this Manual
Many of your phone options are accessed by a simple menu system. A full description of the
menus and how to move around them is covered in the next section Menu Navigation. When
the manual describes the use of each menu item, it will be assumed that you are familiar with the
menu system.
Key Presses
Key presses are represented in this manual using symbols so you may locate and use the required
sequence quickly. A sequence of key presses may be shown as follows:
This means that you should press the key followed by the key and then the key,
in sequence, not simultaneously.
Entering Information
When you are requested to enter information, such as the number of the phone you wish to call,
this is represented in bold type. For example:
- enter the required telephone number.
- enter your Personal Identification Number.
- enter your unlock code.
- enter the Phone Book location number.
Prompts and Messages
Your phone responds to key presses by displaying either easy to understand prompts that guide
you to the next action, or simple messages confirming that your action is complete. Prompts and
messages are represented in this manual in LCD style, for example:
Enter PIN or Completed.
Other Symbols
You will find the following symbols used throughout this manual:
A Note contains additional information which is relevant to the feature/item.
A Caution contains important additional information which is relevant to the
efficient and/or safe usage of your phone.
This symbol indicates that the feature is a Personality™ feature that can be customised
to meet your requirements.
This symbol indicates a short key sequence for the feature.
(A5) Book_8J51.book Page 2 Thursday, May 4, 2000 3:32 PM
Introduction 3
PRELIMINARY
Menu Navigation
A large number of your phone's options are accessed by using menus which use a common
approach for selection, change and cancellation.
Please read this section carefully before attempting to access a menu option. When you
understand the common approach to menu navigation and how the menus are shown on the
page, you will be able to access and change options with ease.
Entering the Menus
Two different keys are used to access the menus:
enters the Options menu whilst in standby mode; enters the In-call menu
during a call.
enters the Quick Access menu.
Once entered, the menus use the (NavDisc), , and keys in a common manner to
access, select and change individual options.
Leaving the Menus
To leave any of the menus, you can either press and hold the key or repeatedly press the
key. Both of these actions will return your phone to the standby mode.
Alternatively, a quicker way to leave the menus is to press .
Menus and Sub-menus
A menu is a simple list of options. Some of these options provide access to a further list of
options called a sub-menu. When navigating through the menus you may find it is helpful to
think in terms of menu levels - the ‘parent’ menu being on one level and its sub-menus being on
a lower level.
Moving To and Selecting a Menu Option
To move from one option to another on the same level, use the NavDisc™ to move forward and
backward. When you find the option you want, press the key to select it.
Depending on the option you select, one of three things will happen:
• a brief message will be displayed confirming an action, for example Completed.
• a prompt will be displayed requesting you to enter information, for example
Enter PIN or Enter Name or,
• the first option of a sub-menu will be displayed. You can select this option using
the key or browse through the other options using the scroll keys.
To leave an option or sub-menu, press the key. This will take you back to the parent menu
item.
Menu Options with Security Codes
Some options are protected from misuse by requiring you to enter one of the security codes. To
use these options, you must enter the requested code before proceeding.
(A5) Book_8J51.book Page 3 Thursday, May 4, 2000 3:32 PM
Introduction
4
PRELIMINARY
Menu Navigation - A Working Example
The following steps will take you through how to switch the ‘Extended Menus’ option ON:
(The illustration represents the sequence of screens you see on display of your phone).
1When the phone is in the standby mode, press the
key. This will access the Options menu and
Access Internet will be displayed.#
2Press the (NavDisc) key repeatedly until the Phone
Setup sub-menu item is shown in the display.
3Press the key to select the sub-menu.
4Press the (NavDisc) key repeatedly until the
Extended Menus sub-menu item is shown in the
display.
5Press the key to select this item. You can now
select between On or Off, the current setting will be
shown with a character. If the character is next
to Off, press (NavDisc) and then to switch on
the Extended Menus. If the character is next to On,
press to leave the setting as it is.
The arrow(s) on the line at left indicates there are more
options in that direction.
Line below an option indicates it is the last option in the
list. Pressing has no effect.
Short, Extended and Personalized
Menus
With Personality you can personalize the menus by
choosing which features you want readily available. The
features that are less frequently used can be stored out of
sight.
The menu diagrams in this manual show the condition of the
menu settings when you first receive your phone. Some
features are in the Short Menu and are shown in bold type.
Other features are in the Extended Menu and appear in
italics.
You can change which features appear in the Short and Extended Menus, and therefore
personalize the menus, to suit your requirements.
If you want to move a feature from the Short Menu to the Extended Menu (or from the Extended
Menu to the Short Menu), go to the feature and then hold down the key until a prompt
appears offering the following choices:
• Add the current feature to the Short Menu/Extended Menu.
• Leave the current feature in the Short/Extended Menu.
Select the option you want by pressing the key.
# If your service provider has added their own menu, Access Internet will not be the first
item in the Options menu.
† Availability depends on the type and settings of the SIM card and/or your subscription
to these services where available.
(A5) Book_8J51.book Page 4 Thursday, May 4, 2000 3:32 PM
Introduction 5
PRELIMINARY
Total Customer Satisfaction
At Motorola, Total Customer Satisfaction is a top priority. If you have a question, a suggestion or
a concern about your Motorola Cellular Phone, Motorola wants to hear from you.
Please contact the Motorola Cellular Response Centre by fax on: +44 (0) 131 458 6732, or use
one of the local phone numbers in the following countries:
• Australia 1800-667788
• Austria 0660 7246
• Belgium 0800 72 370
• Canada 1 800 461 4575
• Czech Republic
00420 2 21 85 21 01
• Denmark 4348 8005
• Egypt 02 3411800
• Eire 01 402 6887
• Finland 0800 117 036
• France 0 803 303 302
• Germany 0180 35050
• Greece 00800 441 28150
• Hong Kong 852 25063888
• Italy 02 696 333 16
• Jordan 06 863750
• Kuwait 484 2000 Ext 1177
• Lebanon 01 744156
• Luxembourg 0800 21 99
• Netherlands 0800 022 27 43
• Norway 22 55 10 04
• Oman 790925
• People’s Republic of China86 10 68466060
• Portugal 01 318 0051
• Qatar 418999
• Saudi Arabia 01 2303294
• Singapore 65 4855 333
• South Africa 0800 11 48 49
• Spain 902 100 077
• Sweden 08 445 1210
• Switzerland 0800 553 109
• Taiwan 886 2 87731746
• Turkey 0212 425 9090
• UK 0500 55 55 55
• United Arab Emirates 04 32 11 66
• United States of America 1 800 331 6456
• For e-mail queries contact: service1@mot.com
• For Internet queries contact: http://www.mot.com
(A5) Book_8J51.book Page 5 Thursday, May 4, 2000 3:32 PM
Introduction
6
PRELIMINARY
Motorola’s Warranty
Your Cellular Phone is warranted by Motorola to be of satisfactory quality, fit for its purpose and
comply with applicable Motorola specifications for a period of twelve (12) months from the date
you bought it (verified by reference to your proof of purchase).
This warranty does not apply if the phone has:
1been mishandled, misused, wilfully damaged, neglected, improperly tested, repaired,
altered or defaced in any way.
2a defect arising as a result of any failure to follow instructions either in the manual or
product specification.
3a defect which has arisen from the use of non-Motorola approved accessories or
ancillary items attached to or in connection with the telephone.
This warranty does not affect your statutory rights as a consumer.
Warranty conditions may vary depending on the country in which you bought the phone.
(A5) Book_8J51.book Page 6 Thursday, May 4, 2000 3:32 PM
Contents 7
PRELIMINARY
Contents
Safety
Important information for the efficient and safe operation of your phone ....9
About Your Phone, Battery and SIM Card
Introduces your phone, explains how to charge and maintain batteries,
explains about your SIM Card ............................................................................13
Sending and Receiving SMS Messages
Explians how to send and receive SMS Messages............................................21
Making and Receiving Phone Calls
Explains how to make single or conference calls, how to redial, how to
transfer a call, and how to end a call.................................................................24
Using Voice Features
Explains how to use the VoiceNotes™ and Voice Control features
on your phone .....................................................................................................34
Using The Options Menu
Provides an explanation of the Options Menu and how to use it ..................40
Using the Quick Access Menu
Provides an explanation of the Quick Access Menu and how to use it ..........81
Accessories
Details the accessories available for use with your phone ..............................85
What To Do If...
Helps you to solve any problems that may occur.............................................86
The Manufacturer reserves the right to make changes in technical and product specifications
without prior notice.
Add
Icon
(A5) Book_8J51.book Page 7 Thursday, May 4, 2000 3:32 PM
Contents
8
PRELIMINARY
Index
A comprehensive Index.......................................................................................88
(A5) Book_8J51.book Page 8 Thursday, May 4, 2000 3:32 PM
Safety 9
PRELIMINARY
Safety
IMPORTANT
For the efficient and safe operation of your wireless
handheld portable telephone, observe these guidelines.
Exposure To Radio Frequency Signals
Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it
is ON, it receives and also sends out radio frequency (RF) signals.
European and International agencies have set standards and recommendations for the protection
of public exposure to RF electromagnetic energy.
• International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996
• Verband Deutscher Elektringenieure (VDE) DIN-0848
• Directives of the European Community, Directorate General V in Matters of Radio
Frequency Electromagnetic Energy
• National Radiological Protection Board of the United Kingdom, GS 11, 1988
• American National Standards Institute (ANSI) IEEE.C95.1-1992
• National Council on Radiation Protection and Measurements (NCRP). Report 86
• Department of Health and Welfare Canada. Safety Code 6
These standards are based on extensive scientific review. For example, over 120 scientists,
engineers and physicians from universities, government health agencies and industry reviewed
the available body of research to develop the updated ANSI Standard.
The design of your phone complies with these standards when used normally.
Antenna Care
Use only the supplied or approved replacement antenna. Unauthorized antennas, modifications
or attachments could damage the phone and may violate FCC regulations.
Phone Operation
Normal Position: Plug the earpiece into the phone. Hold the phone in your hand or on the
holster of your belt to operate.
Tips on Efficient Operation: For your phone to operate most efficiently:
• Extend your antenna fully (if applicable).
• Do not touch the antenna unnecessarily when the phone is in use. Contact with the
antenna affects call quality and may cause the phone to operate at a higher power level
than otherwise needed.
Batteries
!All batteries can cause property damage, injury or burns if a conductive
material such as jewelry, keys or beaded chains touches exposed terminals.
The material may complete an electrical circuit and become quite hot. To
protect against such unwanted current drain, exercise care in handling any
charged battery, particularly when placing it inside your pocket, purse or
other container with metal objects. When the battery is detached from the
phone, your batteries are packed with a protective battery cover; please
use this cover for storing your batteries when not in use.
(A5) Book_8J51.book Page 9 Thursday, May 4, 2000 3:32 PM
Safety
10
PRELIMINARY
Driving
Check the laws and regulations on the use of wireless telephones in the areas where you drive.
Always obey them. Also, if using your phone while driving, please:
• give full attention to driving - driving safely is your first responsibility
• use hands-free operation, if available
• pull off the road and park before making or answering a call if driving conditions so
require.
Electronic Devices
Most modern electronic equipment is shielded from RF signals. However, certain electronic
equipment may not be shielded against the RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a minimum separation of six
(6”) inches be maintained between a handheld wireless phone and a pacemaker to avoid
potential interference with the pacemaker. These recommendations are consistent with the
independent research by and recommendations of Wireless Technology Research.
Persons with pacemakers:
• Should ALWAYS keep the phone more than six inches from their pacemaker when the
phone is turned on.
• Should not carry the phone in a breast pocket.
• Should use the ear opposite the pacemaker to minimise the potential for interference.
If you have any reason to suspect that interference is taking place, turn your phone OFF
immediately.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the event of such
interference you may want to consult your hearing aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of your device to
determine if they are adequately shielded from external RF energy. Your physician may be able to
assist you in obtaining this information.
Turn your phone OFF in health care facilities when any regulations posted in these areas instruct
you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its representative regarding your vehicle. You should
also consult the manufacturer of any equipment that has been added to your vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notices so require.
Aircraft
FCC regulations prohibit using your phone while in the air. Switch OFF your phone before
boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or
in areas posted: “turn off two-way radio”. Obey all signs and instructions.
(A5) Book_8J51.book Page 10 Thursday, May 4, 2000 3:32 PM
Safety 11
PRELIMINARY
Potentially Explosive Atmospheres
Turn your phone OFF and do not remove the battery when in any area with a potentially
explosive atmosphere and obey all signs and instructions. Sparks, from your battery, in such areas
could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always clearly marked. They
include fueling areas such as gasoline stations; below deck on boats; fuel or chemical transfer or
storage facilities; areas where fuel odors are present, i.e. if a gas/propane leak occurs in a car or
home; areas where the air contains chemicals or particles, such as grain, dust, or metal powders;
and any other area where you would normally be advised to turn off your vehicle engine.
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects, including both installed or portable
wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle
wireless equipment is improperly installed and the air bag inflates, serious injury could result.
(A5) Book_8J51.book Page 11 Thursday, May 4, 2000 3:32 PM
Safety
12
PRELIMINARY
European Union Directives Conformance
Statement
This product is in conformance with the requirements of the applicable EU
Council Directives.
Declarations of Conformance with the requirements are located at:
Motorola Ltd.
European Cellular Subscriber Division
Midpoint, Alençon Link
Basingstoke, Hampshire RG21 7PL
United Kingdom
APPROVED for connection to
telecommunications systems specified
in the instructions for use subject to
the conditions set out in them.
S/1357/4/V/
(A5) Book_8J51.book Page 12 Thursday, May 4, 2000 3:32 PM
About Your Phone, Battery and SIM Card 13
PRELIMINARY
About Your Phone, Battery and
SIM Card
Special Keys
Turns the phone on and off.
Accept call, setting, option.
Reject call, setting, option.
Enter the Quick Access menu.
Press to access the Menu options and navigate menus.
(Read) Press to read message.
(Write) Press to write message.
(ALT) ( 0-9 Press for ALT and associated 0-9 for keypad
(ALT)(SPACE) Press for symbols and additional characters.
(NavDisc) Press to scroll through menus and text.
The shape of the keys that appear in the manual may vary slightly from those on the phone.
The Smart Button
The Smart button ( ) is on the front side of your phone, to the left of the OK
button. Press it to quickly access all your Phone Book entries, and then either
scroll through the entries using the volume buttons or press one of the
alphanumeric keys to search for a specific name - for example, press to
search for the name Pam, or press four times to search for the name
Sam.
If a Phone Book entry does not have a name, it will not be displayed.
You can also use the Smart button to make, answer and end calls as follows:
• To answer a call, press for 1.5 seconds.
• To end a call, press for 1.5 seconds and then quickly press again.
• To make a call, enter or recall a number and then press and hold for
1.5 seconds.
• To voice dial a Phone Book entry, press . The prompt Say Name
After Tone... appears. Wait for the tone to finish and then say the name
associated with the number you want to call.
Front of
Camelot
(A5) Book_8J51.book Page 13 Thursday, May 4, 2000 3:32 PM
About Your Phone, Battery and SIM Card
14
PRELIMINARY
Volume Buttons
The left and right arrows on the NavDisc are your volume control. These buttons are
used for adjusting the keypad, earpiece and ringer volume.
A volume meter will display the current volume setting. The meter will disappear after
a short time, or if you press or .
• To adjust the keypad and earpiece volume, press the buttons with no other features
selected.
• To adjust the ringer volume, first select the ‘Adjust Ring Volume’ option in the Phone
Setup Menu and then use the button to set the required volume.
The volume buttons can also be used to scroll though the Phone Book entries after pressing the
Smart button.
If you receive a call and you do not want to answer it immediately, you can press the volume
button to stop the phone from ringing or vibrating. This will not answer the call.
Automatic Volume Control
If you have set the earpiece volume to maximum and the phone detects a high level of
background noise, the earpiece volume automatically increases by an additional two steps.
When the level of background noise returns to normal, the earpiece volume automatically
returns to the normal maximum.
The Start/Stop Record Button
The Start/Stop Record button ( ) is on the front of your phone.
Press it to start and stop recording VoiceNotes™.
While recording don’t keep mouth piece very close to your mouth.
See Using VoiceNotes on page 34, for more information.
The Display
The display on your phone can show alphanumeric characters as well as useful information
symbols.The various elements of the display are as follows:
ABC123 Characters are used to display messages and telephone numbers.
Signal Strength. The more segments displayed in the bar graph, the better
the signal strength.
In Use. Displayed when a call is in progress.
Roam. Displayed when you are registered on a system other than your home
system.
Home Zone. Availability depends on your service provider.
Short Message Service. Displayed when the phone has received a
message. The symbol will flash when your message storage area is full.
Nav
Disc
Front of Camelot
Camelot Display
(A5) Book_8J51.book Page 14 Thursday, May 4, 2000 3:32 PM
About Your Phone, Battery and SIM Card 15
PRELIMINARY
In addition, when you are expected to press the key, a prompt will appear in the display, for
example Completed.
Low Temperature Use
The liquid crystal display used in your phone will behave differently at extremely low
temperatures. You may notice that the display responds slowly to key presses; this is to be
expected and does not affect the phone operation in any way.
Animated Icons
A set of animated icons is provided in your phone. These icons represent current activity on your
phone.
Voicemail Waiting Indicator. Displayed when you have a voice message
waiting. The availability of this feature depends on your service provider.
Ringer On. Displayed when the call ringer is selected. If you select the No
Ring or Vibrate or the Vibrate Only options this symbol will not be displayed.
Battery Charge Indicator. The more segments displayed, the greater the
battery charge.
... Icons are displayed when you are in the Quick Access menu.
Indicates that a menu item is currently selected.
12:00 Real Time Clock. In the idle display, the real time clock can display the time
in either a 12-hour or 24-hour format.
Shift
ALT
SYM
Locked
Animated Icon Description
Calling a number
Ringing
Ending the call
SMS Message sent
Will Be 2 more symbols
(A5) Book_8J51.book Page 15 Thursday, May 4, 2000 3:32 PM
About Your Phone, Battery and SIM Card
16
PRELIMINARY
Earpiece Connector
The earpiece connector is on the side of your phone, opposite the antenna. Use this connector
for the headset included with the phone.
Looking After Your Phone
• Never leave your phone or battery in extreme temperatures (over 60°C), for example
behind glass in very hot, direct sunlight.
• To clean your phone, use a moistened or antistatic cloth. Do not use a dry or
electrostatically charged cloth.
View that shows all
“????” (See markup)
(A5) Book_8J51.book Page 16 Thursday, May 4, 2000 3:32 PM
About Your Phone, Battery and SIM Card 17
PRELIMINARY
Your Battery
Charging a New Battery
New batteries are supplied in a totally uncharged state.
To ensure maximum battery performance, a new battery (or battery that has not been used for
several months) should be charged for at least 14 hours before use.
A new battery will require several full charge/discharge cycles in order to achieve its optimum
performance.
A new battery, or a battery that has not been used for several months, may cause a
premature fully charged indication. Ignore this indication and let the battery charge for several
more hours, remove and re-insert the battery into the charger, and charge for an additional 14
hours.
Important Battery Information
Always treat your batteries with care. See ‘Batteries’, at the beginning of this
manual.
Never leave your battery in extremely high temperatures (over 60°C), for
example behind glass in very hot, direct sunlight.
Only Motorola Original Accessory batteries can be charged in the phone or the
optional desktop charger. This is to protect you and your phone from the risks
of incorrect charging.
Do not use lithium ion batteries at extremely low temperatures as the maximum standby/talk
time will not be available when cold.
To ensure that you enjoy maximum battery life and use your battery to its fullest capacity:
• The battery should be at or near room temperature when charging.
Battery Performance and Maintenance
• Best battery performance will be achieved when you regularly charge and discharge
batteries as instructed in this manual.
• Battery performance is greatly affected by network coverage.
•Set Battery Saving Mode to On (see Phone Setup Menu on page 64) and/or
Frequency of Search to Slow or Medium (see Network Selection Menu on
page 72).
• If left unused, a fully charged battery will discharge itself in approximately one month.
• When not in use, store your battery uncharged in a cool, dark and dry place.
Low Battery Warning
When the battery level is low and only a few minutes of talk time remain, a warning signal (two
double beeps) will sound, the border of the battery symbol will begin to flash, and Low
Battery will be displayed.
When the battery is completely discharged, your phone will turn off.
(A5) Book_8J51.book Page 17 Thursday, May 4, 2000 3:32 PM
About Your Phone, Battery and SIM Card
18
PRELIMINARY
Removing Your Battery
Switch off your phone before removing the battery. Failure to do so may
damage your phone memory.
1Press the release catch on the battery compartment and lift off the cover.
2Push the battery towards the top of the
phone and lift the battery out from the
bottom end.
Fitting Your Battery
1Remove the battery compartment cover.
2Align the connections on the battery with
the connections on the phone.
3Press the battery towards the connections
and push it downwards until it clicks into
place. Replace the cover.
Charging Your Battery Using
the Travel Charger
The travel charger can power the phone and
charge a fitted battery.
Ensure that the local mains voltage at
your location matches that of your
travel charger.
Fit a battery onto your phone.
To charge your battery:
1Attach the correct adapter plug to the
travel charger.
2Connect the travel charger to the phone.
The connector is keyed and can only be
inserted one way.
3Insert the travel charger plug into a suitable
mains power socket.
A beep-tone is heard and the battery icon flashes
when charging begins.
Your phone can be either on or off during
charging.
The state of charging is monitored and displayed
by your phone. See Battery Meter Indicators
on page 19, in this section for details.
Charge times will increase if you make or receive phone calls while charging.
Battery Indicators
Your Motorola cellular phone includes the Motorola Expert Performance ( ) charging system.
This enables the charging circuits in both the phone and the optional ( ) desktop charger to
communicate directly with the battery. Based on this communication, the charger can implement
the optimum charging cycle for best performance and determine the level of charge.
Your phone monitors and displays information about your battery. The following message will
Camelot Drawings
Camelot Drawings
(A5) Book_8J51.book Page 18 Thursday, May 4, 2000 3:32 PM
About Your Phone, Battery and SIM Card 19
PRELIMINARY
appear on the display, as the condition occurs:
Battery Meter Indicators
The battery meter displays different messages depending on the batteries attached, and whether
or not there is an external power source. The battery meter is found in the Call Related Features
part of the Options Menu.When the battery is completely discharged, you must charge the
When the battery is completely discharged, you must charge the battery for one minute
before you can make or accept a phone call.
Low Battery The battery charge is low. The battery should be recharged.
Insert Battery No battery fitted; external power connected
Invalid Battery This message is accompanied by a single beep. Your phone is
alerting you that you do not have charging capabilities with this
battery even though the battery may be able to power the
phone.
The most likely reason why your charging system does not
recognise the battery is that the battery you have purchased is
not a Motorola original battery and therefore does not have the
communications technology built into it. All Motorola original
batteries include this communications technology.
It is recommended that you use only Motorola original batteries,
chargers and other accessories.
Charging Battery The battery is being charged.
Charging Complete Charging is complete.
Invalid Battery Battery may be defective, or may not be a Motorola original
battery.
(A5) Book_8J51.book Page 19 Thursday, May 4, 2000 3:32 PM
About Your Phone, Battery and SIM Card
20
PRELIMINARY
Your SIM Card
Your SIM (Subscriber Identity Module) card was supplied by your Cellular Service Provider when
you bought your phone. You will not be able to make or receive calls if you do not have a SIM
card inserted in your phone.
Some networks allow you to make emergency calls without a SIM card inserted.
The SIM card is a ‘Smart Card’ that contains your phone number, service details and memory for
storing Phone Book numbers and messages. You can therefore use your SIM card in someone
else’s GSM phone and you will be charged for the call.
Like a bank or credit card, you should keep your SIM card secure. Do not bend or scratch your
card and avoid exposure to static electricity or water.
Switch off your phone before inserting or removing the SIM card. Failure to do
so may damage the memory on your SIM card.
SIM Card Insertion/Removal
1Switch off your phone by pressing and holding the
key, remove the battery cover and the battery.
2Slide the SIM cover towards the right and lift up the
left side of the cover.
3If necessary, remove the SIM card from the recess in
the base of the phone.
4Place the SIM card into the recess in the base of the
phone so that the notch is in the bottom right-hand
corner.
5Replace the SIM cover, then press and slide it to the
left to lock it into place.
6Replace the battery and battery cover.
If the SIM card is inserted the wrong way round, or
damaged, the Check Card message may be displayed.
Remove the SIM card, check that it is the right way round
and then re-insert it into the phone.
If either of the Bad Card See Supplier or Blocked
See Supplier messages are displayed, then you will
need to contact your Cellular Service Provider.
Camelot Drawings
Camelot Drawings
(A5) Book_8J51.book Page 20 Thursday, May 4, 2000 3:32 PM
Sending and Receiving SMS Messages 21
PRELIMINARY
Sending and Receiving SMS
Messages
Switching the Phone On and Off
To switch the phone on or off, press and hold the key. If VibraCall™ is selected, the phone
will vibrate when it is switched on.
If you switch the phone on and there is no SIM card inserted, you will be asked to insert one.
Once inserted, the phone will check that the SIM card is valid.
A number of messages will then be displayed:
•Enter PIN - a request to enter the SIM card PIN code (if required).
•Enter Phone Unlock Code - a request to enter the phone unlock code (if
required).
•Searching... followed by a network name - as the phone searches and then finds a
suitable network to connect to.
Entering Your SIM Card PIN Code
To enter the PIN code, enter .
As you type in each digit of the PIN code a * character will be displayed.
If you make a mistake, press and release the key to remove the last digit. Holding the
key down will remove the entire entry.
When the PIN code is complete press the key.
If the PIN code entered is incorrect, the warning message Wrong PIN will be displayed,
followed by Enter PIN.
If the PIN number is entered incorrectly three times in a row, your phone
will automatically lock-up and the Blocked message will be displayed. See
Unblocking Your Phone on page 69, for details on unblocking your phone.
The PIN code can be changed, see Change SIM PIN Code on page 68, in the Phone Setup
Menu section for more details.
Entering Your Unlock Code
If your phone displays the message Enter Phone Unlock Code you must enter your
unlocking code by entering .
The unlock code is a four digit number which is set at manufacture to 1234. The code can be
changed, see Change Unlock Code on page 68, in the Phone Setup Menu section for
more details.
If you forget your unlock code, press the key. This will display the ‘Change Unlock Code’
option. Enter , enter a new unlock code, and press .
Sending a SMS Message
To send an SMS message, your phone must be switched on and unlocked.
It will not be possible to make a phone call unless you are in an area where there is a GSM900 or
1800 service. When a service has been found, a series of rising bars, , will show the
signal strength.
(A5) Book_8J51.book Page 21 Thursday, May 4, 2000 3:32 PM
Sending and Receiving SMS Messages
22
PRELIMINARY
To send a message, press (msg editor hot key) to enter the messaging editor. Key in the message
on the QWERTY keyboard. Press (OK) when complete. Select whether to sendor store the
message. Select the method to enter the phown number. Press (OK) to send the message.
Storing a SMS Message
You can store a message if you intend to send it several times. After you send a message for the
first time, press (Write Key), to return to the message editor, press (OK) and select Store
Message. When you want to send a stored message, go to the outging messages folder to
retrieve the message, then send it.
Entering a Text Message
To enter text into the phone, press the appropriate key. To access the characters located under
the keys, press (ALT) then the appropriate key. To enter capital letters press (SHIFT) then the press
(SHIFT) followed by the appropriate key. To enter a series of capital letters, press (SHIFT) (SHIFT).
An icon will display to show that this is locked. To unlock capitalization, press (SHIFT) (SHIFT).
Entering Numbers
To enter numbers in a message, press (ALT) followed by the appropriate key. To enter a series of
numbers press (ALT) (ALT) to lock the keypad. An icon will display to show that it is locked. To
unlock the keypad press (ALT) (ALT).
Reading a SMS Message
To read an SMS message, press (READ MESSAGE HOT KEY) to enter the incomeing message to
the message folder. Scroll to the appropriate message and press (OK) to read.
Replying to a Message
Open the message, then select (OK) to view the options. Scroll to select (Reply to Message), then
press (OK). Type in the message, then pres (OK) to send reply.
(A5) Book_8J51.book Page 22 Thursday, May 4, 2000 3:32 PM
Sending and Receiving SMS Messages 23
PRELIMINARY
Reading an Incoming Message
When a message appears, press (OK) to read now. Press (OK) to view options on what to do with
the message.
Sending an Email Message
Your operator must support this feature and provide the number for the email server. To send
the message "Hello" to the internet email address "abc123@isp.com", you would type the
following text message in the phone, "abc123:isp.com#Hello. The : and # are delimiters that
must be in the message to permit correct interpretation of the message. You would then send
this message to the email server number provided by your operator.
Entering Non-Roman Characters
In order to access non-Roman, press (ALT) (SPACE) and the appropriate letter from the following
table. Multiple presses of the character key may be required to access these characters.
Keyboard
Character Alt Space
Press key Alt Space
Press key
2times
Alt Space
Press key
3times
Alt Space
Press key
4times
Alt Space
Press key
5times
Alt Space
Press key
6times
Alt Space
Press key
7times
EéèÉ
R¡
T
Y¥
UüûÜ
Iì
Oöøò ÖØ
P
AäåàæÄÅÆ
S§
D
F
G
L
Z
CÇ
V
Bß
NñÑ
?/ ¿
(A5) Book_8J51.book Page 23 Thursday, May 4, 2000 3:32 PM
Making and Receiving Phone Calls 24
PRELIMINARY
Making and Receiving Phone
Calls
Switching the Phone On and Off
To switch the phone on or off, press and hold the key. If VibraCall™ is selected, the phone
will vibrate when it is switched on.
If you switch the phone on and there is no SIM card inserted, you will be asked to insert one.
Once inserted, the phone will check that the SIM card is valid.
A number of messages will then be displayed:
•Enter PIN - a request to enter the SIM card PIN code (if required).
•Enter Phone Unlock Code - a request to enter the phone unlock code (if
required).
•Searching... followed by a network name - as the phone searches and then finds a
suitable network to connect to.
Entering Your SIM Card PIN Code
To enter the PIN code, enter .
As you type in each digit of the PIN code a * character will be displayed.
If you make a mistake, press and release the key to remove the last digit. Holding the
key down will remove the entire entry.
When the PIN code is complete press the key.
If the PIN code entered is incorrect, the warning message Wrong PIN will be displayed,
followed by Enter PIN.
If the PIN number is entered incorrectly three times in a row, your phone
will automatically lock-up and the Blocked message will be displayed. See
Unblocking Your Phone on page 69, for details on unblocking your phone.
The PIN code can be changed, see Change SIM PIN Code on page 68, in the Phone Setup
Menu section for more details.
Entering Your Unlock Code
If your phone displays the message Enter Phone Unlock Code you must enter your
unlocking code by entering .
The unlock code is a four digit number which is set at manufacture to 1234. The code can be
changed, see Change Unlock Code on page 68, in the Phone Setup Menu section for
more details.
If you forget your unlock code, press the key. This will display the ‘Change Unlock Code’
option. Enter , enter a new unlock code, and press .
(A5) Book_8J51.book Page 24 Thursday, May 4, 2000 3:32 PM
Making and Receiving Phone Calls
25
PRELIMINARY
Making a Phone Call
To make a phone call, your phone must be switched on and unlocked.
It will not be possible to make a phone call unless you are in an area where there is a GSM900 or
1800 service. When a service has been found, a series of rising bars, , will show the
signal strength.
There are a number of different ways to make a phone call:
• Using the digit keys.
• Using automatic redial.
• Redialling the last number called.
• One-touch dialling a Phone Book entry*.
• Dialling a Phone Book entry*.
• Calling an embedded number in a message.
• Using the Smart button ( ) and Voice Dialling.
*Your phone contains a 'phone book' that can be used to store names and telephone
numbers. See ‘What is the Phone Book?’ for further details.
The simplest method of making a phone call is to enter the number using the digit keys then
press .
If you make a mistake, press and release the key to remove the last digit. Holding the
key down will remove the entire number.
To indicate that you are making a phone call, your phone displays the outgoing call animation
and the word Calling. If the call is not answered and you want to end the call, press , or
close the flip (models with flip only).
When the phone call is answered, the display will change to End Call?.
To end your call press , or close the phone.
Automatic Redial
If your call attempt does not succeed, the message Redial? will be displayed for five seconds.
Pressing at this point will automatically redial the phone number.
When the call is answered, you will hear a short ring tone.
The maximum number of redial attempts is set by your Cellular Service Provider. If the phone call
cannot be connected within this maximum, the message Redial Failed will be shown.
Redialling the Last Number Called
When in standby mode, press .
Alternatively, you can retrieve the last number dialled using the ‘Last Ten Calls’ feature in the
Phone Book menu.
One-Touch Dialling Phone Book Numbers
To quickly retrieve and dial a number stored in the first nine locations of your Phone Book#, press
and hold the appropriate digit key. For example, pressing and holding will dial the phone
number stored in location 2 of your Phone Book.
#The Phone Book entries that you are able to access will depend on the One-Touch Dial
Setting option in the Phone Book menu.
Insert graphic of keyboard layout and hilight numeric keypad.
(A5) Book_8J51.book Page 25 Thursday, May 4, 2000 3:32 PM
Making and Receiving Phone Calls 26
PRELIMINARY
You do not need to press to call the number.
Dialling Phone Book Numbers
Alternatively, enter the phone book number followed by .
Dialling Phone Book Numbers with Smart Button
The following Smart button ( ) options are available:
•Press and say the Voice Tag name after the tone. See Using Voice Activation with
Phone Book Entries on page 37, for more information.
•Press and use the volume button to scroll to the stored number, or press the
appropriate digit key to skip to a particular letter. To make the call, either hold down
for 1.5 seconds or press .
Calling an Embedded Number in a Message
Details on how to call a number embedded in a message are given in the Messages Menu
section.
International Phone Calls
To make an international phone call press and hold the key. After a couple of seconds the
international dialling prefix + will appear in the display, this allows you to call from any country
without knowing the local international access code.
Now enter the country code, followed by the phone number. The country code follows the
conventional format, 49 for Germany, 44 for the UK, 46 for Sweden, etc.
Just like a conventional international call, remove the leading '0' of the area code when you dial.
Inserting Pauses Into Phone Numbers
To obtain a three second 'pause' character in a phone number, press and hold the (*) key for a
couple of seconds, the pause symbol Ü will appear.
The pause character produces a three second delay whenever it is used. However, the first pause
character in a phone number is a special case, it will not begin its delay until the call is answered.
Pause - A Working Example.
If, for example, you have a tone-based voicemail system on 555-6911, with a mailbox number
1066 and password 2001. Then you may dial the following number:
5556911Ü1066Ü2001 .
The first part of the number would be used to call the voicemail system.
When the call is answered the first pause will produce a delay of three seconds before the tones
for 1066 are sent to select the mailbox.
There will be a second pause of three seconds before the tones for 2001 are sent as the
password.
GSM Emergency Calls
The world-wide GSM standard provides a single, uniform number, 112, to dial in cases of
emergency.
Provided that your phone has found a network, you will be able to make an emergency call. The
call can be made regardless of any security codes and, depending on the network, with or
without a SIM card inserted.
The emergency call will be directed to a central emergency operator.
To dial the GSM emergency number, press .
While the emergency call is being made and connected, the display will show Emergency
Calling.
AEmergency calls can be made without a battery fitted if the phone is powered by the
travel charger.
(A5) Book_8J51.book Page 26 Thursday, May 4, 2000 3:32 PM
Making and Receiving Phone Calls
27
PRELIMINARY
Receiving a Phone Call
To receive a phone call:
• Your phone must be switched on and unlocked.
• You must be in an area where there is GSM900 or 1800 service.
• Your Call Diversion and Call Barring settings should not be set to divert or bar incoming
calls.
When your phone receives a call, it will ring or vibrate and your phone displays the incoming call
animation and the word Answer?. If you have Caller Line Identification, the caller’s number or
name also appears.
To answer the call, press on the front or keyboard.
When the identification is displayed, you can decide whether or not to answer the call by
pressing , a numeric key ( to ), (NavDisc). If you do not wish to answer a call
you can either:
Press and release the key. If you have enabled the 'Detailed Diverting - If Busy' or
‘Divert when unavailable’ options in the Options Menu, the caller will be diverted to the
forwarding number, otherwise the caller will hear the busy tone.
or
Press and hold the key. This will reject the incoming call. No call divert option will
be offered.
If your phone rings and you do not answer it, the message Unanswered Call will be
displayed to show you that a call attempt was received.
Ending a Phone Call
To end a phone call, press or . Your phone displays the ending call animation.
Insert graphic showing placement of both “OK and “C”
buttons
(A5) Book_8J51.book Page 27 Thursday, May 4, 2000 3:32 PM
Making and Receiving Phone Calls 28
PRELIMINARY
In-Call Menu
The “In-Call” menu provides access to additional
functionality during a call.
Entering the In-Call Menu
The “In-Call” menu is accessed by pressing the
key during a call.
Leaving the In-Call Menu
To leave the “In-Call” menu press the key.
In-Call Menu Options
The options listed in the “In-Call” menu will
dynamically change depending on the current
call state. The following list contains all of the
possible options in the “In-Call” menu.
Only some of the options will appear at any
given time. The order of the options may vary.
Hold Call
This option will put the active call on hold.
Make a New Call
This option allows you to make another call.
Restrict My Number
This option allows you to make a call without
the remote user getting advanced warning of
the number.
End Active Call
This option terminates the active call, and makes the call that was previously on hold, the active
call.
End Held Call
This option will terminate a held call.
End Current And Held Call
This option will terminate all connected calls.
Switch Calls
This option allows you to switch between the active call and the call that is on hold.
Conference Call
This option connects you with up to five other telephones on one call (see Making a
Conference Call on page 32.)
Transfer Call
This option transfers a call to another telephone (see Transfer Call on page 33.)
Split Call
This option allows you to separate an individual from the main Conference Call.
Reject Waiting Call
This option will reject a waiting call.
NavDisc
(A5) Book_8J51.book Page 28 Thursday, May 4, 2000 3:32 PM
Making and Receiving Phone Calls
29
PRELIMINARY
Reconnect
This option will make the call on hold the active call.
Reconnect Held Call
This option is similar to Reconnect but will appear if you have a call on hold, and a call
waiting. Reconnect Held Call will make the call on hold the active call.
Turn Mute On or Off
Temporarily turns the microphone off during a phone call. Reselect this option to resume your
conversation.
(A5) Book_8J51.book Page 29 Thursday, May 4, 2000 3:32 PM
Making and Receiving Phone Calls 30
PRELIMINARY
Call Holding and Call Waiting
Your phone supports the GSM options of Call Holding and Call Waiting. Using these options you
can place a current phone call on hold and accept an incoming call or start a second call (See
‘Call Waiting’ in the ‘Call Related Features’ menu for details of how to control this
feature).
Call Holding and Call Waiting Scenarios
The display will automatically change according to the status of your current call (or calls) and will
propose the option that you are most likely to want. Press to accept this option or press
and then (Nav Disc) to scroll through the “In-Call” menu for the alternative options. By
following this procedure you will find that even the triple combination of an active call, a held
call, and a call waiting is easy to manage.
The following points summarise the more common situations:
• To put an active call on hold, press , the display will show Hold Call Select?
- press to put the call on hold. To reconnect the call, press .
• To put an active call on hold and make another call, first put the active call on hold, then
press and select the Make New Call option#.
• To switch between an active call and a held call press at the Two Calls
Switch? prompt.
• To accept a waiting call during an active call, press at the Call Waiting
Answer? prompt. The active call will be placed on hold. If you prefer to end the active
call before accepting the waiting call, press and select the End Active Call
option.
• To reject a waiting call, press and select the Reject Call Waiting option (or
simply press the key).
If you have an active call, a call on hold and a call waiting, you cannot accept the waiting call
until you end either the active call or the held call, or join the active and held calls.
Call Holding and Call Waiting Messages
During Call Holding and/or Call Waiting operations, your phone may display one or more of the
following messages:
Trying
A request to hold the active call, swap the active with a held call, or add a member to a
Conference Call, has been made.
or
A request to reconnect the held call has been made.
Hold Failed
The request to hold a call has been unsuccessful.
Cannot Hold Second Call
A call is already on hold, you cannot place two calls on hold at the same time.
Connection Failed
The held call could not be made active again.
Busy Try Later
#A quicker method of making another call is to enter the number to be called directly
and press . Your phone will place the current call on hold and attempt to call the
number entered.
(A5) Book_8J51.book Page 30 Thursday, May 4, 2000 3:32 PM
Making and Receiving Phone Calls
31
PRELIMINARY
Your phone is still working on a previous command. Wait a short time before repeating
the command.
Anonymous
The person who is calling you has blocked their number from appearing on your phone.
Unavailable
The network is unable to provide the caller’s number.
Conference Unsuccessful
The request for Conference Call has been unsuccessful.
Transferring Call
A request to transfer a call has been made.
Transfer Unsuccessful
The request to transfer a call has been unsuccessful.
(A5) Book_8J51.book Page 31 Thursday, May 4, 2000 3:32 PM
Making and Receiving Phone Calls 32
PRELIMINARY
Making a Conference Call
This option joins the active call with a held call. With Conference Call, you can have a conference
with up to five other telephones. At any time during your call, you can add, disconnect or
separate individuals from the Conference Call using other “In-Call” menu options.
You must subscribe to both Conference Call and Call Waiting Supplementary Services to be
able to use this feature.
Initiating a Conference Call
To initiate a Conference Call, place the active call on hold, and dial another phone number. You
will then have one active call and one call on hold.
Press the key to enter the “In-Call” menu and select Conference Call. The currently
active call and the call on hold will then join into one Conference Call.
Managing a Conference Call
While in a Conference Call, you will have the option to add new calls to the Conference Call or
separate one of the members from the Conference Call.
Adding a New Call
There are a number of different ways to add new calls to the Conference Call:
• Using the digit keys.
•Using the Make New Call option from the “In-Call” menu.
• Recalling a Phone Book Entry using Quick Access.
• Answer Call Waiting.
No matter which method is chosen to add a new call, the original Conference Call will be first
placed on hold while the new call is being connected. You must then enter the “In-Call” menu
and select Conference Call to join the New Call with the original Conference Call in
progress.
Separate One of the Members in the Conference
During a Conference Call, you will also have the option to separate a selected member from the
main Conference Call.
In order to separate a member from the main Conference Call, there must not be any calls on
hold.
Press during a Conference Call and select Split Call. You will then be presented with
the phone number or name of all members of the Conference Call. Use the scroll keys to find the
selected member of the Conference Call. Once the desired member is selected, press the
key and select Split Call.
At this point, the selected call will be separated from the main Conference Call and private
conversation between you and the selected member is possible.
To re-join all the parties again, select Conference Call from the “In-Call” menu.
(A5) Book_8J51.book Page 32 Thursday, May 4, 2000 3:32 PM
Making and Receiving Phone Calls
33
PRELIMINARY
Transfer Call
Transfer Call transfers a call to another telephone. There are two ways to transfer a call; before or
after the third party is connected.
You must subscribe to both Conference Call and Call Waiting Supplementary Services to be
able to use this feature.
Initiating Transfer Call Before the Third Party is Connected
To transfer a call to another telephone, press the key and select Transfer Call from
the “In-Call” menu. Enter the number where the call will be transferred and press .
Your phone will then attempt to transfer the call. The display will show Transferring Call
followed by Call Transferred. When the call has been successfully transferred, you will
be disconnected automatically.
Initiating Transfer Call After the Third Party is Connected
If you already have an active call and a call on hold, press the key and select Transfer
Call from the “In-Call” menu. Your phone will then attempt to transfer the active call to the
call on hold. The display will show Transferring Call followed by Call
Transferred. Once the call has been successfully transferred, you will be disconnected
automatically.
(A5) Book_8J51.book Page 33 Thursday, May 4, 2000 3:32 PM
Using Voice Features 34
PRELIMINARY
Using Voice Features
Using VoiceNotes
The VoiceNotesTM feature allows you to record up to three minutes of personal voice messages
or to record part of a phone call. This is useful when you don't have a pen and paper handy for
taking directions or a message. Recording is available during the following call scenarios:
• Phone idle (no calls).
• Single active call (includes conference calls).
• Active call plus waiting call.
Recording a VoiceNote
To record a VoiceNote, press the Start/Stop Record button ( ). You will hear a short tone to
indicate that recording has started and the display will show the message Recording and the
remaining recording time available.
If you are recording during a call, the person you are speaking to will hear a tone every 10
seconds to warn them that you are recording the call.
During the recording of an active call, both parties can be recorded at the same time.
To stop recording a call, press the Start/Stop Record button ( ) or ; on models with a flip
you can also close the flip, although this will end the call. The display shows the message
VoiceNote XX Stored where XX is the number of the storage location. VoiceNotes are
stored in sequential locations.
Recording stops immediately with no further notification if:
• you choose to accept an incoming call while you are recording (the Call Waiting alert is
played)
• you choose to initiate a call during recording a VoiceNote.
VoiceNote Storage Capacity
The Show Time Available option in the Messages, VoiceNotes menu displays the amount
of recording time available, see Messages Menu on page 58.
During recording, ten seconds before the recording capacity is reached you will hear a warning
tone. If you do not stop recording within the time limit, recording will automatically stop and a
single, one second tone will be heard, accompanied by the Storage Full message.
Playing VoiceNotes
To play your VoiceNotes, select the Play VoiceNotes option in the Messages, VoiceNotes
menu or the Quick Access menu item (}).
The first VoiceNote will begin to play after two seconds. The display will show Voicenotes,
Playing xxx...
To move to the next VoiceNote, press (up arrow on NavDisc) once (twice if the current note is still
playing). Similarly, to move to the previous VoiceNote, press (down arrow on NavDisc) once
(twice if the current note is still playing). Press to stop playing of the current VoiceNote.
If you selected Play VoiceNotes from the Quick Access Menu, the phone will simply
return to its idle state.
Press (up arrow on NavDisc) twice rapidly to skip back to the previous message.
(A5) Book_8J51.book Page 34 Thursday, May 4, 2000 3:32 PM
Using Voice Features
35
PRELIMINARY
Press (down arrow on NavDisc) to play the next VoiceNote.
To play a VoiceNote stored at a specific location, press the appropriate digit key 1 to 9.
It is not possible to playback VoiceNotes during a call.
Erase VoiceNote
This option allows you to delete your VoiceNotes one by one.
Erase all VoiceNotes
To erase your VoiceNotes, select the Erase All VoiceNotes option in the Messages,
VoiceNotes menu. You will be requested to confirm the deletion with the message Erase All
VoiceNotes - Select?. Press to confirm the deletion.
The confirmation message VoiceNotes Erased is displayed.
Set Alarm (Alarmed VoiceNotes)
This option allows you to attach an alarm to a maximum of 5 recorded VoiceNotes. You can set
the frequency of the alarm and the time at which it will expire. The alarmed VoiceNotes can be
set to expire on a specific day and time (One-Time), daily, weekly, every Monday to Friday or
every Monday to Saturday.
If an alarm has been set to expire at the same time as an alarmed VoiceNote, the alarmed
VoiceNote will be adjusted to expire one minute later than the set time.
(A5) Book_8J51.book Page 35 Thursday, May 4, 2000 3:32 PM
Using Voice Features 36
PRELIMINARY
Using Voice Activation
With Voice Activation, you can call up a phone number or activate a Quick Access feature with a
single spoken command.
The single spoken command is called a Voice Tag.
You can assign Voice Tags to call any of the Phone Book numbers in your phone memory, and
you can also assign Voice Tags to activate any of the Quick Access features.
You cannot assign Voice Tags to call any of the numbers in your SIM card memory.
When you are recording a Voice Tag, you cannot make or receive any calls.
For best results, when you record a Voice Tag, make sure there is no wind or background noise
and speak in a clear, natural voice. Your phone allows you about two seconds for each Voice Tag.
Voice Activation for Phone Book Entries
You can add a new Voice Tag when you set up a new Phone Book entry or when you amend an
existing Phone Book entry. Alternatively, you can overwrite an existing Voice Tag or delete it
completely.
You cannot record a Voice Tag if you have set Prevent Access To Phone Memory.
Add Voice Tag
This option is available from the Phone Book menu and allows you to add a Voice Tag to a new
Phone Book entry.
When you select Add To Phone Memory, your phone prompts you to enter a number, name
and location and then stores the entry. For more details, see The Phone Book Menu on page
45.
After the prompt Stored XXX, your phone then prompts you for a Voice Tag as follows:
1Add Voice Tag?
Press to continue.
If there are already 25 Phone Book Voice Tags in your phone, Voice Tag Storage
Full appears and your phone returns you to the Add To Phone Memory menu
option. You must delete a Voice Tag before you can add another.
If there are Voice Tags available, your phone prompts you to:
2Press OK When Ready
Press to continue.
3Say Name After Tone...
Wait for the tone to finish and then say the name. For best results, use in an area with
(A5) Book_8J51.book Page 36 Thursday, May 4, 2000 3:32 PM
Using Voice Features
37
PRELIMINARY
minimal wind or background noise.
4Press OK When Ready
Press to continue.
5Say Name After Tone...
Wait for the tone to finish and then say the name as you did in step three above. For
best results, use in an area with minimal wind or background noise.
6If the recording is successful, Please Wait appears after two seconds followed by
Voice Tag Stored.
When a Voice Tag recording is successful, your phone returns you to the Add To Phone
Memory menu option.
If the recording is not successful, for example, the name you used is too similar to another Voice
Tag name, the phone displays the reason for not accepting the name and returns you to the
Press OK When Ready prompt.
Add or Edit Voice Tag and Delete Voice Tag
These options are available from the Phone Book menu or the Quick Access menu. First, select
either Find Entry by Name or Find Entry by Location.
After you enter the name or location details, you can select the appropriate Voice Tag menu
option.
Add or Edit Voice Tag
This option does not appear if the phone number is not in phone memory.
Select this option to add a Voice Tag to the Phone Book entry or to overwrite an existing Voice
Tag. If an entry already has a Voice Tag, the symbol )) appears after the location number.
When you select this option, the phone prompts you with Press OK When Ready.
To complete the Voice Tag recording, follow the same process as for ‘Add Voice Tag’.
Delete Voice Tag
This option does not appear if the phone number is not in phone memory or if there is no
Voice Tag to delete.
Select this option to delete the Voice Tag from the Phone Book entry.
When you press , the phone deletes the Voice Tag and returns the prompt Voice Tag
Deleted.
Using Voice Activation with Phone Book Entries
You can use either the Smart button ( ) or you can use the Phone Book menu followed by .
Voice Activation using the Smart button ( )
Press .
If there is a Phone Book entry with a Voice Tag, the following prompt appears:
1Say Name After Tone...
Wait for the tone to finish and then say the name. For best results, use in an area with
minimal wind or background noise.
If you press a key, you return to the Phone Book.
:
(A5) Book_8J51.book Page 37 Thursday, May 4, 2000 3:32 PM
Using Voice Features 38
PRELIMINARY
If the phone does not find a matching Voice Tag, No Match Found appears and you
return to the Phone Book.
2If the name you say matches a Voice Tag, the phone repeats the name and displays the
Phone Book entry.
3Do one of the following:
• Wait for two seconds and the phone makes the call.
•Press to make the call or to cancel the call.
•Press to display the next entry in the Phone Book.
When you scroll to a Phone Book entry that has a Voice Tag, your phone replays the Voice Tag
through the speaker.
Voice Activation using the Phone Book Menu
Select Voice Dialling from the Phone Book menu.
When you press , the phone displays the message Press Smart Button When
Ready.
To complete the voice activation, follow the same process as for ‘Voice Activation using the Smart
button ( )’.
Voice Activation for Quick Access Features
You can use Voice Tags to activate any of the Quick Access features on your phone. You are not
restricted to the nine Quick Access keys.
Quick Access Setup
This option is available from the Phone Setup menu and allows you to do the following:
• Customise your Quick Access menu.
• Set up and change the Voice Tag allocation for the Quick Access features.
When you select Quick Access Setup, your phone displays a list of the Quick Access features. If a
feature already has a Voice Tag, the symbol )) appears with the feature name.
Use (NavDisc) to highlight the feature you require and then press . You can then assign a
key or change the Voice Tag setup.
Assign Key to Feature
Select this option to assign a key to the Quick Access feature. Your phone displays the prompt
Enter 1-9:.
Press to to assign a key and then press .
If you assign a valid key, your phone displays Completed and then returns you to the Quick
Access feature list.
As an alternative, you can also assign a key using the Quick Access key ( ). See Using the
Quick Access Menu on page 81. .
Add or Edit Voice Tag
Select this option to add a Voice Tag to the Quick Access feature or to overwrite an existing Voice
Ta g.
If you attempt to add another Voice Tag when there are already 9 Quick Access Voice Tags in your
phone, Voice Tag Storage Full appears and your phone returns you to the Quick
Access feature list. You must delete a Voice Tag before you can add another.
(A5) Book_8J51.book Page 38 Thursday, May 4, 2000 3:32 PM
Using Voice Features
39
PRELIMINARY
If there are Voice Tags available, your phone prompts you to:
1Press OK When Ready
Press to continue.
2Say Name After Tone...
Wait for the tone to finish and then say the name. For best results, use in an area with
minimal wind or background noise.
3Press OK When Ready
Press to continue.
4Say Name After Tone...
Wait for the tone to finish and then say the name as you did in step 2 above. For best
results, use in an area with minimal wind or background noise.
5If the recording is successful, Please Wait appears after two seconds followed by
Voice Tag Stored.
When a Voice Tag recording is successful, your phone returns you to the Quick Access feature list.
If the recording is not successful, for example, the name you used is similar to another Voice Tag
name, the phone displays the reason for not accepting the name and returns you to the
Press OK When Ready prompt.
Delete Voice Tag
AThis option does not appear if there is no Voice Tag to delete.
Select this option to delete the Voice Tag from the Quick Access feature.
When you press , the phone deletes the Voice Tag and returns the prompt Voice Tag
Deleted.
Using Voice Activation with Quick Access Features
To activate a Quick Access feature using Voice Activation:
1Press .
If there is a Quick Access feature with a Voice Tag, the following prompt appears:
2Say Name After Tone...
Wait for the tone to finish and then say the name. For best results, use in an area with
minimal wind or background noise.
AAt this point, you can press to return to the idle screen; press a numeric key or
to activate the appropriate Quick Access feature; press (NavDisc) to display the
Quick Access menu list.
If the phone does not find a matching Voice Tag, No Match Found appears and you
return to the Quick Access menu.
3If the name you say matches a Voice Tag, the phone repeats the name and displays the
entry for the Quick Access feature.
4Do one of the following:
• Wait for two seconds and the phone activates the feature.
•Press to activate the feature or to return to the idle screen.
•Press
(NavDisc) to display the next entry in the Quick Access menu.
When you scroll to a Quick Access feature that has a Voice Tag, your phone replays the Voice Tag
through the speaker.
(A5) Book_8J51.book Page 39 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 40
PRELIMINARY
Using the Options Menu
Restrict My Phone Number
NavDisc
Icons
(A5) Book_8J51.book Page 40 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
41
PRELIMINARY
Access Internet
Access Internet is a network and subscription-dependent feature. Contact your service
provider for details about the mobile internet services based on the WAP (Wireless Application
Protocol) technology that they provide.
Your phone has mobile internet access. This allows you to use the mobile internet services
available from your service provider, for example, financial, sport, travel and entertainment
information services.
This section explains:
• some of the common display features
• how to set up your phone for mobile internet access
• how to start a mobile internet session
• how to use and end the mobile internet session.
Common Display Features
Your service provider determines the layout and information that appears on the display. This
example display illustrates a typical mobile internet screen and the soft keys you use to select and
navigate through options.
Using the Main Menu
To display the Main Menu, press and hold until the Main Menu appears. You can access
the Main Menu only during a mobile internet session. Then scroll up or down to highlight the
appropriate menu option and press to select it. The Main Menu includes special
commands, for example:
Help: provides help, if available, for the previously-highlighted option.
Home: returns you to your home page.
Mark site: allows you to add a site to your Bookmarks folder.
Setup: contains the options to set up your mobile internet access.
Using Bookmarks
Select Mark site from the Main Menu. When your phone prompts you for a Bookmark?,
press any key from to . A Stored XXX message confirms that the bookmark key is
set. To return to the bookmark during a mobile internet session, press and hold the appropriate
key.
Using the Soft Keys
To select a soft key from the display during a mobile internet session, press or . The
soft keys change so that they are appropriate for the current display, for example, Quit, OK,
Back or View. In the example display, selects the softkey1 and selects the
softkey2.
(A5) Book_8J51.book Page 41 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 42
PRELIMINARY
Mobile Internet Icons and Messages
The internet service you receive determines the icons and messages that appear on
the display.
Setting Up for Mobile Internet Access
Your service provider may set up your mobile internet access automatically.
To set up your mobile internet access manually, you will need the following information:
• Primary Data Gateway: this is the IP address of the gateway through which you will
access the mobile internet. The IP address is in the format 123.456.789.123.
• Phone Number: this is the number that your phone will call to access the internet; your
Internet Service Provider (ISP) issues this number.
• User Name: this is your user name, provided by your ISP.
• User Password: this is your password, provided by your ISP.
• Baud Rate: this is likely to be 9600, the standard data rate for GSM phones.
• Idle Time Out: this is the time the phone will wait before hanging up if it detects no
internet activity; usually 600 seconds; maximum 1000 seconds.
• Line type: this is the type of call you make to your ISP, either modem or ISDN.
• Connection Type: this is either Non-Transparent or Transparent, depending on your
service provider.
Also ensure that your mobile phone number shows when you select the menu option My
Phone Number(s), under the Phone Book Main Menu. This is used as your account
number by the Primary Data Gateway. If your number is not shown, add it by following the
instructions in My Phone Number(s) on page 50.
Select the menu option Access Internet and press the key. Press and hold the
key until the Main Menu appears. Scroll down through the options to 6> Setup and press
key. Enter the information listed above at the appropriate menu item by first selecting the
item and choosing the softkey to edit it as necessary.
When you have entered all the appropriate information, exit the Main Menu by pressing the
key. Turn your phone off and then on again to make sure you register all changes. You
will then be ready to start a mobile internet session.
Icon or Message Description
Sending)))))) Sending data to the internet.
Receiving (((((( Receiving data from the internet.
Connecting..... Connecting to the internet.
Working..... Performing an internet activity.
[struck out key symbol] Non secure internet connection.
(A5) Book_8J51.book Page 42 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
43
PRELIMINARY
Starting a Mobile Internet Session
iPress . Select the Quick Access feature ( Access Internet).
The menu option Access Internet starts a mobile internet session.
When you start a mobile internet session, you will see the messages Connecting....,
Sending)))) and Receiving ((((before your home page appears. Typically, an ISDN
connection will take approximately 10 seconds and a modem connection will take 30 seconds.
Using the Mobile Internet Session
Selecting Options Within a Mobile Internet Session
If the Internet page has a list of menu options, scroll up or down to highlight the appropriate
menu option and then press to select it. Press to return to the previous screen.
When the text for a menu option is too wide for the screen, the phone uses two screens and
repeats each half of the menu list until you make a selection.
Editing Text Within a Mobile Internet Session
You edit text in a mobile internet session in a similar way to editing text in all other phone
functions. See Entering Text on Your Phone on page 46.
Making and Receiving Calls During a Mobile Internet Session
To make a call, you must end the mobile internet session and make your call in the normal way.
If you receive a call during a mobile internet session, your phone prompts you to Answer
Call? Press to accept the call or press to reject it.
If you answer the call, Session Paused - Resume? appears when you end the call. Press
to resume your mobile internet session or press to return to the idle phone display.
Internet Service Alerts
You do not need to be using the mobile internet to receive an internet service alert. If you receive
an alert, your phone:
• emits an alert tone (depending on the ‘Ringer On or Off’ setting)
• displays a pop up screen with appropriate alert details.
Press to display the contents of the alert or press to reject it.
Ending a Mobile Internet Session
If you press and hold ,the Internet home page appears. Press again to end the mobile
internet session.
You can also press the smart key to end the mobile internet session. This immediately returns you
to the idle phone display.
(A5) Book_8J51.book Page 43 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 44
PRELIMINARY
Summary of Keys Within a Mobile Internet Session
Key action Effect in mobile internet Effect in text editora
a. For full details, see Entering Text on Your Phone on page 46..
Press Selects the first soft key (Softkey1
in the example).
Press Selects the second soft key
(Softkey2 in the example).
Press and hold Displays the mobile internet menu.
Press Ends the mobile internet session.
Press Takes you back to the previous
screen.
Deletes the character in front of
the cursor.
Press and hold
Press again
Takes you back to the Internet
home page.
Ends the mobile internet session.
Deletes all the characters in the
edit area.
Press ... Selects a menu option in a list Inserts an alphanumeric
character.
Press and hold
...
Takes you to a bookmarked page. Inserts an alphanumeric
character.
Press (NavDisc Icons) Takes you up or down through a
list of menu options.
Moves the cursor one position to
the left or one position to the
right.
(A5) Book_8J51.book Page 44 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
45
PRELIMINARY
The Phone Book Menu
Nav Disc
(A5) Book_8J51.book Page 45 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 46
PRELIMINARY
What is the Phone Book?
You can store names and telephone numbers as entries in an electronic 'Phone Book'. These
entries are stored in the Personal Numbers list in your phone or SIM card's memory, and in the
Fixed Dial list# on your SIM card. Once stored, a number can be quickly retrieved and dialled.
Your phone can store 100 entries and the SIM card can store up to 155 entries in the Personal
Numbers list. The number of SIM card entries will vary depending upon the type of SIM card
issued by your Cellular Service Provider.
You can also store up to 40 entries in a Fixed Dialling list if you have this feature. Fixed Dialling
allows you to limit use of your phone to particular numbers, or, if you wish, to country codes,
area codes, or other prefixes of your choosing.
Each Phone Book entry comprises:
• A telephone number. Up to 32 digits can be stored, but this is reduced to 20 digits for
SIM card locations.
• A name. Up to 16 characters for phone locations. Up to 50 characters for SIM card
locations, but typically 10 or less.
• A location label - from 1 to 255 in your Personal Numbers list, or 1 to 40 in your Fixed
Dial list.
Postscripting
This allows you to make use of area codes and other prefixes previously stored in your Phone
Book when making a call.
To use postscripting, select the Phone Book entry containing the prefix and then simply enter the
rest of the number and press to make the call.
You can also use postscripting if you want to call a number similar to one you have stored in your
Phone Book. Retrieve the number from the Phone Book, delete the relevant digits and then enter
the new number.
Postscripting a number does not overwrite the entry in the Phone Book.
Postscripting is not available when accessing the Phone Book using the Smart button.
Entering Text on Your Phone
See Sending and Receiving SMS Messages on page 21.
Correcting Text
In Numeric Mode, you can delete one character at a time or you can delete all the text.
To move the cursor (Ú), press (NavDisc)
To delete the character before the cursor, press . You can then insert any new characters
you require.
To delete all the text, press and hold .
#Availability of the Fixed Dialling feature depends on the type of SIM card you have.
(A5) Book_8J51.book Page 46 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
47
PRELIMINARY
Voice Dialling
Select this option to call any phone number that has a Voice Tag. The phone prompts you to
press the smart button ( ). See Using Voice Activation on page 36.
Personal Numbers
The Personal Numbers sub-menu is used for creating and managing your list of personal
numbers.
Find Entry By Name
Press and say the Voice Tag name after the tone.
Press and use the volume button to scroll to the stored number, or press the
appropriate digit key to skip to a particular letter. To make the call, either hold down
for 1.5 seconds or press .
This option is used to select a telephone number from a list of alphabetically sorted Phone Book
names.
Once selected, this option will display the message Enter Name. You can enter a maximum of
three characters from a name but you do not need to enter all three characters to begin a search.
The Phone Book entries will be searched and the first alphabetically matching entry will be
displayed.
If there isn’t a name matching your entry, the nearest alphabetically matching entry will be
displayed.
If you do not enter any name information, the first alphabetical entry will be displayed.
If there are no names stored, No Names Stored will be displayed.
To display adjacent Phone Book entries use the (NavDisc) keys. When the desired name is
displayed press the key to select it. The phone then enters the options sub-menu for Find
Entry By Name. See The Options for ‘Find Entry By...’ on page 48.
Find Entry By Location
Press and say the Voice Tag name after the tone.
This option is used to select a telephone number from a list of numerically sorted Phone Book
locations.
Once selected, this option will display the message Enter Location. You can now enter a
location number. If the entered location is not valid, a timed message Range 1-XXX will be
displayed and the phone will return to the Enter Location menu item.
The Phone Book entries will be searched and an entry will be displayed.
If you enter a location number for which there is no entry, Location Empty will be displayed
and the nearest non-empty location will be selected instead.
If you did not enter a location, the first numerical entry will be displayed.
If there are no numbers stored, No Numbers Stored will be displayed.
To display adjacent Phone Book entries use the (NavDisc) keys. When the desired name is
displayed press the key to select it. The phone then enters the options sub-menu for Find
Entry By Location. See The Options for ‘Find Entry By...’ on page 48.
(A5) Book_8J51.book Page 47 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 48
PRELIMINARY
The Options for ‘Find Entry By...’
Once a Phone Book entry has been selected, it can be called, modified or deleted.
If the Phone Book entry is in phone memory, you can also add, edit or delete the Voice Tag.
Call Number
This option is used to call the selected Phone Book telephone number.
Modify Name or Number
This option is used to change the selected Phone Book entry.
The entry’s current telephone number and name will be presented, in turn, for modification. You
can accept the current settings or modify as required.
Erase Name and Number
This option is used to erase the selected Phone Book entry.
Simply press the key when the phone displays the message Erase Name And
Number. The option will display the timed message Erased XXX and then return to the
Find Entry menu item.
Add or Edit Voice Tag and Delete Voice Tag
Use these options to add, edit or delete the Voice Tag for the Phone Book entry. See Using
Voice Activation on page 36.
Add Entry
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
This option is used to add (store) entries to the Phone Book. You can choose to add the new
entry to either the phone or SIM card memory locations.
Add To Phone Memory, Add To SIM Card Memory
Once you have selected the destination of the new entry, you will be asked to enter the
telephone number, name and location number of the new entry.
The last telephone number displayed will be presented by default; it can be used or discarded as
required.
If the entered location is not valid, a timed message Range YYY-ZZZ will be displayed and the
phone will return to the Enter Location prompt. If the chosen location is currently used by
another entry, you will be asked for confirmation that the location can be overwritten.
If you do not supply a location number, the next available location will be used.
When the new entry has been entered, a timed message
Stored XXX will be displayed.
Add Voice Tag
If you add a Phone Book entry to the phone memory, the Add Voice Tag? prompt appears
after Stored XXX . Press to add a Voice Tag. See Using Voice Activation on page 36.
Check Capacity
This option is used to check the number of free Phone Book entries in the phone or SIM card
memory areas.
Check Phone Capacity, Check SIM Capacity
Once selected, a timed message XX Unused Locations displays the requested
information.
(A5) Book_8J51.book Page 48 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
49
PRELIMINARY
Prevent Access
This option enables you to prevent access to the Personal Numbers list.
You cannot record a Voice Tag if you have set Prevent Access To Phone Memory.
To SIM Card Memory, To Phone Memory, To Phone & SIM Memory, No
Memory Restrictions
You can prevent access to all entries in the SIM card memory, the phone memory or both the
phone and SIM card memory. To cancel all access restrictions use the No Memory Restrictions
option.
When you change the restrictions, you will be requested to enter the Security Code before the
change is made.
Show Services
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
This option displays a list of phone numbers and services provided by your Cellular Service
Provider.
Availability depends on the type and settings of the SIM card, and/or your subscription to this
feature.
Last Ten Calls
These options allow you to review your last 10 most recently missed, answered and called phone
numbers and the time and date information associated with the call. Depending on the option
you choose, you can then redial a phone number, store a phone number in your phone book, or
erase all of the phone numbers.
After you select an option, use the keys to scroll through
the list of phone numbers. Press the key to proceed.
You can use post scripting to modify a number once you have retrieved it from either of the
Last Ten Calls lists.
Last Calls Missed
Press . Select the Last Calls Missed or after the tone, say the Voice Tag name.
This option displays the last 10 calls which were unanswered by the user along with the time and
date. Select this list item to call the number, add it to phone or SIM card memory. If the number
matches an entry on your phone or SIM card memory, the name attached to the number will be
displayed in the Missed Call list.
You will only see the incoming phone numbers in the Last Calls Missed and Answered Calls
lists if you have Caller Line Identification.
When you scroll through your last ten calls, each call appears with a call position number.
Press the key to select a phone number. You can then scroll through and select one of the
following options:
Call Number
Select this option to call the phone number.
Switch View
Select this option to see more details of the selected item. The details include the name, number,
(A5) Book_8J51.book Page 49 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 50
PRELIMINARY
time and date. Select Switch View again to return to the previous screen.
Add to Phone Memory
Select this option to add all the phone number details (including any details you have added) to
your phone memory. If the name in the received call does not appear in your phone book, the
phone prompts you to Enter Name and Enter Location. For further details, see 'Add
Entry' in this section.
Add to SIM Card Memory
Select this option to add the phone number details (including any details you have added) to your
SIM card memory. If the name in the received call does not appear in your phone book, the
phone prompts you to Enter Name and Enter Location. For further details, see 'Add
Entry' in this section.
Answered Calls
This option displays the last 10 answered calls and the time and date on which the call was
received. Select this number to call the number, add it to phone or SIM card memory. If the
number matches an entry in your phone or SIM card memory, the name attached to the number
will be displayed in your Answered Calls list.
Made Calls
This option displays the last 10 calls made and the time and date on which the call was made. If
the call was made from the phone or SIM card memory, the name associated will be displayed,
otherwise only the number dialled will be shown.
Erase All Numbers
This option erases all the numbers stored in your Last 10 Calls Missed, Answered and Made lists.
The Last Ten Calls lists will be erased when a new SIM is inserted in the phone.
My Phone Number(s)
This option allows you to access your cellular phone, fax and data numbers so that you can
retrieve or modify them when required. For example, if you have difficulty remembering your
cellular phone number, store it with the name My Phone and then you will be able to retrieve
the number as required.
The My Phone Number(s) list is stored on your SIM card.
When you select this item, the first location will be displayed. Use the
keys to scroll through the phone numbers stored.
To enter or change a number, scroll to the location and press . You will be prompted to
enter a phone number and then a name. Press to store the information.
Depending on your Cellular Service Provider, you may find that one or more of the entries in
the My Phone Number(s) list will have been defined. You may not be able to change these
predefined entries.
Fixed Dialling
Availability of the Fixed Dialling menu depends on the type of SIM card.
This feature allows you to limit use (typically third-party use) of your phone to a predefined list of
telephone numbers or, if you wish, to a list of country codes, area codes, or other prefixes of your
choosing.
When Fixed Dialling is switched on, the only numbers that can be dialled from your phone are
(A5) Book_8J51.book Page 50 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
51
PRELIMINARY
those stored (or whose prefix is stored) in the Fixed Dial list. If you attempt to dial any other
number (apart from an emergency number), the message Restricted will be displayed. You
will not be able to make fax or data calls.
To make a call when Fixed Dialling is switched on, either dial the number manually, or select it
from the Fixed Dial list and press .
Up to 40 entries can be stored in the Fixed Dial list. The list is stored on your SIM card.
This option may be affected by the Call Barring setting.
View Fixed Dial List
This option allows you to scroll through the numbers in the Fixed Dial list. When you find the
number you want, press to make the call.
Setup Fixed Dialling
This option allows you to switch Fixed Dialling on or off and to enter or change entries in the
Fixed Dial list.
You will be prompted to enter your PIN2 security code when you select this option.
On
Switches fixed dialling on.
Off
Switches fixed dialling off.
Edit Entry
Modifies or clears an entry in the Fixed Dial list. When you select this option, the first non-empty
location in the list will be displayed. Scroll to the entry you want to change and press . You
will be prompted to edit the phone number and the name. To erase the entry, press .
Add Entry
Adds a phone number and name to the Fixed Dial list. When you select this option you will be
prompted to enter the phone number, name and a location number. If you do not specify a
location number, it will be stored in the next available location.
When setting up your Fixed Dial list, you may want to reserve the first nine locations for
phone numbers you wish to One-Touch Dial. See One-Touch Dial Setting on page 51.
Erase Entry
Erases a phone number and name from the Fixed Dial list. The first entry in the Fixed Dial list will
be displayed. Scroll to the entry you wish to delete and press .
One-Touch Dial Setting
This option allows you to specify which Phone Book list can be One-Touch Dialled.
To Phone Memory
Switches One-Touch Dialling to your Personal Numbers list stored in phone memory (locations 1
to 9).
To SIM Card Memory
Switches One-Touch Dialling to your Personal Numbers list stored on your SIM card (locations
101 to 109).
To Fixed Dial list
This option is only available if you have Fixed Dialling.
Switches One-Touch Dialling to your Fixed Dial list (locations 1 to 9).
(A5) Book_8J51.book Page 51 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 52
PRELIMINARY
The Alarm Clock
About Alarm Clock
Your phone can support up to 5 alarms. You can also attach a 40-character memo to each alarm
to remind you of a specific event linked to the alarm.
Set Alarm
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
This option allows you to set the frequency of the alarm, the time at which it will expire and
attach the 40-character message to the alarm. The alarms can be set to expire on a specific day
and time (One-Time), daily, weekly, every Monday to Friday or every Monday to Saturday.
Show Alarm Status
This option allows you to review the status of your various alarms. You can check if the alarm(s)
are set, expired or disabled.
You can also attach alarms to a maximum of 5 VoiceNotes. See Using Voice Features for more
details.
Switch View
This option allows you to see the full setting details for the selected alarm. Select Switch
View again to return to the previous screen.
Edit Alarm
This option allows you to change the time, date and attached memo for all of the set alarms
(expired and unexpired).
Disable Alarm
This option allows you to disable the alarm.
Nav Disc
Icon
(A5) Book_8J51.book Page 52 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
53
PRELIMINARY
Call Related Features Menu
Show Battery Meter
This option displays the approximate amount of battery capacity remaining, for example:
Number of
Segments
Approximate Charge Level
1 less than 5% (recharging needed)
3 less than 20%
5 less than 60%
7 greater than 60%
(NavDisc)
(A5) Book_8J51.book Page 53 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 54
PRELIMINARY
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
Restrict My Phone Number
'Restrict My Phone Number' is a network feature. You will need to subscribe to one of the two
Caller Line Identification restriction features with your Cellular Service Provider.
Show ID on Next Call
Your phone number is sent with the next attempted call, after this your phone number will not
be sent until you re-select this option.
Restrict ID on Next Call
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
Your phone number will not be sent with the next attempted call, after this your phone number
will be sent with calls until you re-select this option.
Call Diverting
Call diverting is a network feature. If your phone is unavailable, or you do not wish to receive
calls, incoming calls can be diverted to other phone numbers.
This option can be used to:
• Divert all incoming Voice calls unconditionally.
• Divert all incoming Voice calls at user scheduled times.
• Divert incoming Voice calls whenever your phone is unavailable, busy, not reachable or
not answered.
• Divert incoming Fax calls.
• Divert incoming Data calls.
• Reset all diversion options to off.
(NavDisc)
(A5) Book_8J51.book Page 54 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
55
PRELIMINARY
You cannot change the call divert settings when you are out of network coverage.
After selecting any of the call divert options there will be a short delay while the phone asks the
network for the current setting.
Divert Voice Calls
This option will allow you to set your phone to Divert When Unavailable, Divert All Voice Calls or
Detailed Diverting.
Divert When Unavailable
This option will enable you to divert all incoming Voice calls to a single number, whenever your
phone is unavailable.
The option has two settings, On or Off.
If you change the setting to On, you will be asked to enter a diversion phone number using the
digit keys.
Setting “Divert When Unavailable” to On will have the same effect as setting all “Detailed
Diverting” options to On.
When On, Divert When Unavailable takes priority over detailed diversion settings.
Divert All Voice Calls
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
This option will enable you to unconditionally divert all incoming Voice calls to a single number.
The option has two settings, On or Off.
If you change the setting to On, you will be asked to enter a diversion phone number using the
digit keys.
To use the Quick Access option, you must have a diversion phone number set up.
When On, Divert All Voice Calls takes priority over all other Voice call diversion settings.
Scheduled Diverting
This option will allow you to select the days and times during which all voice calls will be diverted
to a single number. This option has 2 settings: On or Off. If you change the setting to “on”, you
will be asked to select when you want your calls diverted.
Your call can be diverted daily, on a specific day every week, every Monday to Friday, every
Monday to Saturday. You then specify the exact times during which you want all your calls
diverted, using the digit keys.
Complete the setting by entering the diversion phone number using the digit keys.
If you attempt to set another voice divert feature (e.g. Divert when Unavailable, Divert All
Voice calls, Detailed Diverting) when Scheduled Diverting is active, the Scheduled Diverting
settings will be overwritten by your new settings.
When you perform manual call divert while scheduled call divert is selected, the scheduled
call divert is turned off. The same also happens when you change the time settings for the phone
while scheduled call divert is active.
(A5) Book_8J51.book Page 55 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 56
PRELIMINARY
Detailed Diverting
These options will enable you to divert Voice calls to different numbers, depending upon the
current status of your phone.
Each of the following detailed diverting options operate in the same way.
Each option has two settings, On or Off.
If you change the setting to On, you will be asked to enter a diversion phone number using the
digit keys.
Detailed diversion settings are ignored while Divert All Voice Calls or Divert When Unavailable
are On.
If Busy
This option will divert incoming calls if your phone is busy.
If Not Reachable
This option will divert incoming calls if your phone cannot be contacted by the network.
If No Answer
This option will divert incoming calls if you do not answer the call.
Divert Fax Calls
This option will enable you to divert all Fax calls to a single number.
The option has two settings, On or Off.
If you change the setting to On, you will be asked to enter a diversion phone number using the
digit keys.
Divert Data Calls
This option will enable you to divert all Data calls to a single number.
The option has two settings, On or Off.
If you change the setting to On, you will be asked to enter a diversion phone number using the
digit keys.
Cancel All Diverting
This option will enable you to cancel the diversion of incoming calls.
This option resets all diversion settings to Off and removes all diversion
numbers.
Talk and Fax
(FIND OUT IF THIS IS SUPPORTED!!)
TOn
Switches Talk and Fax mode on for the next and all subsequent calls.
Off
Switches Talk and Fax mode off for the next and all subsequent calls.
Call Waiting
The Call Waiting menu item has two settings On or Off. If you select Off, you will be not be
notified of waiting calls. The person trying to contact you will either receive the busy tone, or be
diverted by the ‘Detailed Diverting - If Busy’ option.
If Call Waiting is On, you will be notified of a waiting call by an audible alert and by the message
Call Waiting - Answer?. You can press the key to accept the waiting call, or use
the and then the
(A5) Book_8J51.book Page 56 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
57
PRELIMINARY
If you have Caller Line Identification, the caller’s number or name is displayed instead of the
Call Waiting message.
Availability of this feature depends on your service provider.
Call Barring
Call barring is a network feature which can be used to selectively bar outgoing and incoming
calls.
If you change the barring setting, you may be asked to enter your barring password. There will
be a short delay while the phone notifies the network of the new setting. When the change has
been made by the network, the phone will display a confirmation message.
The initial password will be supplied to you by your Cellular Service Provider when you subscribe
to this service.
This option may be affected by the Fixed Dialling setting.
Bar Outgoing Calls
After selecting this option, there will be a short delay while the phone asks the network for the
current setting.
Int'l Calls
When selected, this option will bar outgoing international calls.
Int'l Calls Except Home
When selected, this option will bar outgoing international calls, except those to your home
country.
All Calls
When selected, this option will bar all outgoing calls, except emergency calls.
Off
When selected, this option will disable all call barring for outgoing calls.
Bar Incoming Calls
After selecting this option, there will be a short delay while the phone asks the network for the
current setting.
When Roaming
When selected, this option will bar incoming calls when you are roaming.
You may wish to select this option, as some Cellular Service Providers charge an additional fee for
receiving calls when you are roaming.
All Calls
When selected, this option will bar all incoming calls.
Off
When selected, this option will disable all call barring for incoming calls.
Cancel All Barring
This option can be used to set all Call Barring options to Off.
Change Bar Password
This option can be used to change the call barring password.
After selecting this option, you will be asked to enter the current password.
You will then be asked to enter, and then re-enter, your new, 4 digit, barring password. When
the change has been made by the network, the phone will display a confirmation message.
(A5) Book_8J51.book Page 57 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 58
PRELIMINARY
Messages Menu
Your phone supports the two GSM message features: Short Message Services (SMS) and Cell
Broadcast.
SMS Messages
These are text messages that are sent specifically to and from your phone number.
When an SMS message is received, your phone:
1Makes three short alert tones (depending on the ‘Ring or Vibrate’ setting).
2Displays the (messages) icon.
3Stores the message for later viewing, if there is space. If there is not enough space,
the icon will flash. One or more messages must be removed before the
Cell Broadcast
MT SMS
MO SMS
NavDisc
Icon
(A5) Book_8J51.book Page 58 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
59
PRELIMINARY
message can be stored.
Your Cellular Service Provider will transmit a message for a limited amount of time. If a memory
location is not made available before the message is removed from the network, then you will
not be able to receive or read it.
4Displays the received message animation together with the word Message and the
prompt; Read Now?
•Press to display the open envelope animation and the contents of the new
message.
•Press to return to the screen that was present before you received the message.
• Press any other key to perform the function linked to that key.
If you do not press a key, then after 1 minute the display returns to the screen that was present
before you received the message.
Cell Broadcast Messages
These are general messages that your service provider broadcasts to all phones in a geographic
area. Your phone can only receive a cell broadcast message when it is in idle mode.
The messages are broadcast in numbered 'channels'. For example, channel 050 might be for
local weather, traffic reports or stock market prices. Please contact your service provider for a list
of available channels and the information they provide.
While a broadcast message is scrolling across the display, you can stop and start it by pressing
to restart the message from the beginning. If you want to
remove the message from the display, press .
If you need to use the (NavDisc) keys for their normal functions while you are receiving a cell
broadcast message, you must first remove the message.
When the message has scrolled across the display, the beginning of the message remains until
one of the following occurs: you remove it; a new message arrives; or you leave the geographic
area. For set up details, see Cell Broadcast on page 62.
Call Voicemail
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
This option will make a call to the current voicemail number. The voicemail number is entered
using the ‘Voicemail Number’ option in the Message Settings menu.
Received Messages
Press . Select the Quick Access feature or after the tone, say the
Voice Tag name.
This option is used to view and manage any SMS messages that have been sent to your phone
number.
When selected, this option will display a message indicating the total number of messages and
how many of these are new. If there are no messages No Messages will be displayed.
If there are messages, the phone then displays the open envelope animation and the contents of
the first message.
The new messages appear first.
Press (NavDisc) to display the whole message; when it was sent; and the phone number that sent
(A5) Book_8J51.book Page 59 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 60
PRELIMINARY
it (if available). The open envelope animation repeats for each new page.
Once you have read a new message it will automatically become old.
See Sending and Receiving SMS Messages on page 21, for more information on
navigating through the messages.
Press the key, when viewing any message, to enter the sub-menu.
Switch View
This option allows you to see the full setting details for the selected alarm. Select Switch
View again to return to the previous screen.
Delete Message
This option will delete the currently viewed message
Retrieve Numbers
This option allows you to retrieve all numbers embedded inside a SMS message. You can perform
one of the following: call the number or store it into your phone or SIM card memory.
If the number is more than 20 characters long (32 characters, if GSM1900), the remainder digits
will be automatically removed. Any non-numeric characters in the number will be treated as
delimiters. A space character or a ‘-’ character occurring in the number string will be ignored. If
there is no number found to retrieve within the SMS message, you will see No Number
available message.
Reply to Message
This option allows you to reply with a message.
Return Call
This option can be used to call the person who sent you the message, if their number has been
included by the network, or a number that has been included in quotes “” in the message.
Edit Message
This option allows you to use the Message Editor to edit the selected message and then to either
send the modified message and/or store it in your Outgoing Messages list. See Entering a Text
Message on page 22, for more information on using the Message Editor.
Go to Next Message
This option will display the next received message.
If you are currently reading the last message in your list then this option will take you back to the
top of the list.
Delete All Messages
This option allows you to delete all received messages whether they have been read or not.
Once deleted, messages are NOT retrievable.
Received Ringer Tone SMS Message
You can exchange (send and receive) user composed ringer tones via SMS messages between
compatible Motorola phones. When a ring tone is received via SMS, you can play the tune, save
it to the phone memory or delete it.
Save
This option allows you to save the incoming rung tone to your phone memory.
The newly saved tune will replace the existing user composed tune (Music Tone) in your
phone memory.
Play
(A5) Book_8J51.book Page 60 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
61
PRELIMINARY
This option allows you to play and listen to the received ringer tone.
Delete
This option will delete the current selected ringer tone SMS message.
Outgoing Messages
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
This option is used to view and manage any outgoing messages. These messages will be stored
on your SIM card. When you select this option, the total number of messages will be displayed
followed by the first message in the list.
You cannot send an outgoing message until the Message Service Centre number has been
set. See Message Settings on page 62.
Press the key, when viewing any message, to enter the
sub-menu. See Reading a SMS Message on page 22, for more information on navigating
through the messages.
Switch View
This option allows you to see the full setting details for the selected alarm. Select Switch
View again to return to the previous screen.
Send Message
This option allows you to add the destination phone number using
a sub-menu.
Using the scroll keys you can select:
Enter Number - this allows you to manually enter the phone
number using the keypad and send the message.
Find Entry by Name - this allows you to recall a phone number
from the Phone Book by name and send the message (see ‘Find Entry by Name’ in the ‘Phone
Book’ section).
Find Entry by Location - this allows you to recall a phone number from the Phone Book by
location and send the message (see ‘Find Entry by Location’ in the ‘Phone Book’ section).
When you have set up a destination phone number, select to send the message. The phone
displays the sending a message animation until you press to confirm that you are
Sending Message.
Edit Message
This option allows you to use the Message Editor to edit the selected message and then to either
send the modified message or store it in your Outgoing Messages list. See Sending and
Receiving SMS Messages on page 21, for more information on using the Message Editor.
Delete Message
This option will delete the currently viewed message.
Go to Next Message
This option will display the next outgoing message.
Message Editor
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
(A5) Book_8J51.book Page 61 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 62
PRELIMINARY
The Message Editor is used to edit the currently selected message and then to either send the
modified message or store it in your Outgoing Messages list. See Sending and Receiving
SMS Messages on page 21, for more information on using the Message Editor.
VoiceNotes
The VoiceNotes feature allows you to record a number of personal voice messages or to record
conversations during a phone call. You can selectively delete your VoiceNotes or erase them all at
once. You can also tag an alarm to a VoiceNote and have it play back to remind you when the
alarm expires. See See Using VoiceNotes on page 34, for more information.
Cell Broadcast
This option determines the cell broadcast settings. See also see Cell Broadcast Messages on
page 59.
On
Select On to receive cell broadcast messages. You must then use Channel List to specify the
appropriate channels.
Off
When you select Off, you do not receive any cell broadcast messages and you automatically
delete all existing cell broadcast messages.
Channel List
Select either Channel Index or Delete All Channels.
Channel Index
This option allows you to select up to five different channels for receiving cell broadcast
messages. If you modify a channel, you also remove any message associated with it.
Use , to highlight the channel index you require (1-5) and then press . The
phone prompts you to Enter Channel.
Type in the channel number and press . The phone stores the channel details and returns
you to the channel index list.
Please contact your service provider for a list of available channels and the information they
provide.
Delete All Channels
This option deletes all the channels and all the existing messages.
Language List
Availability depends on the type and settings of the SIM card, and/or your subscription to this
feature where available.
This option allows you to select different languages for Cell Broadcast messages. See also
Language Selection in the Phone Setup Menu on page 70.
Message Settings
Voicemail Number
This option is used to enter a phone number which will be used by the ‘Call Voicemail’ option.
If there is already a Voicemail Number, this will be shown in the display. This can be used,
modified or deleted as desired.
Remember to add the + symbol and the appropriate country code prefix to the phone
number.
(A5) Book_8J51.book Page 62 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
63
PRELIMINARY
Service Centre
Before you can send any messages you must use this option to enter your Message Service
Centre number. This number is obtained from your Cellular Service Provider.
If there is already a Message Service Centre number, this will be shown in the display. This can be
used, modified or deleted as desired.
Remember to add the + symbol and the appropriate country code prefix to the phone
number.
Expiry Period
You can use this option to specify the maximum time, in hours, that your unforwarded messages
are to remain with the Message Service Centre before being deleted. When you select this
option, the current expiry period will be displayed (the default is 24 hours).
The maximum value you can enter is 10584, though the real limit will depend on your Message
Service Centre.
Outgoing Message Type
This option is network dependent and can be used to specify the format of your outgoing
messages. You can select from the following message types: Text (default), Fax, X400,
Paging, E-Mail, ERMES or Voice.
You do not need to select Voice to send messages to Voicemail boxes.
(A5) Book_8J51.book Page 63 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 64
PRELIMINARY
Phone Setup Menu
Nav
Disc
Icon
(A5) Book_8J51.book Page 64 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
65
PRELIMINARY
Select Phone Line
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
This option allows you to switch between Line 1 and Line 2.
Availability depends on the type and settings of the SIM card, and/or your subscription to this
feature.
Adjust Ring Volume
This option is used to set the incoming call ring tone volume.
The volume will be displayed as follows:
Adjust the volume by pressing the volume buttons on the side of
your phone.
Press followed by the volume button to either increase or decrease the ringer
volume.
Ring or Vibrate
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
This option sets the way your phone alerts you to an incoming call. The options are:
•Ring Only - the phone will ring with the tone specified by the Set Ringer Tone option.
•Vibrate Only - the phone will vibrate using VibraCall™.
•Vibrate Then Ring - the phone will vibrate twice and then ring.
•No Ring or Vibrate - the phone will just display the Call message.
The setting you choose also defines the type of alert for an incoming SMS message and an
Internet service alert (except that if you select Vibrate Then Ring, your phone will just vibrate).
Set Ringer Tone
This option sets the tone your phone will make when an incoming call is received on Line 1.
Standard Tone
Your phone makes a standard ringing tone.
Music Tones
There are different music tones like ‘Hollywood, Jack n Jill, Buzz etc. When selected, your phone
will produce one of these alternative ringer tones.
Set Ringer Tone 2
This option sets the tone your phone will make when an incoming call is received on Line 2.
This option will not appear if you do not subscribe to Line 2.
Set Alarm Ringer Tone
This option allows you to turn the alarm ringer tone on or off.
(A5) Book_8J51.book Page 65 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 66
PRELIMINARY
Set Message Alert Tone
This option sets the tone your phone makes when it receives an SMS message.
Standard Tone
Your phone makes a standard SMS alert tone.
Music Tones
There are different music tones like ‘Hollywood, Jack n Jill, Buzz etc. When selected, your phone
will produce one of these alternative SMS alert tones.
Edit Music
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
This option allows you to compose your own ringer tone, adjust its tempo (speed) and send it via
SMS to another compatible Motorola phone. The tune can contain a maximum of 35 notes,
spanning a maximum 3 octaves. You can also adjust the duration of each individual notes.
The screen depicting a tune is as follows:
Moving the Cursor
Move the on screen cursor using the (NavDisc) keys to shift the key forwards and backwards
respectively. Keep pressing (NavDisc) to reach at the right edge of the screen. While you are at the
beginning of the screen at 1st note, press to come back to the previous menu. Press and
hold of brings you to the idle screen.
Creating or Changing a Music Note
The music notes are selected via the QWERTY keyboard. The keys and musical notes correspond
as follows:
Music Notes - Table
Keyboard Musical Note
AA
BB
CC
DD
EE
FF
GG
(A5) Book_8J51.book Page 66 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
67
PRELIMINARY
Changing the Duration of a Note
The duration of the note or rest can last from 1 to 6 with 1 being the shortest
duration and 6 the longest. The longest duration corresponds to 1 sec. Before
changing the duration of the note, move the cursor using the (NavDisc left
right arrow) keys and ensure it is placed between the note and its duration
indicator. Enter the duration from 1 to 6.
Changing the Octave of the Note
Ensure the cursor is placed on the selected note before changing the octave of the
note using the volume keys on the side of the phone. Press the Volume Up key to
shift the current note higher one octave and the Volume Down key to shift it lower
one octave.
Play Music
This option will play back the current user composed ringer tone.
Save Music
This option will save the latest user composed ringer tone and override the tune that was
previously stored in the phone memory.
Erase Music
This option will erase the latest user composed ringer tone and replace it with the standard pre-
programmed musical tune.
Change Tempo
This option will change the tempo of the current user composed ringer tone. The tempo can be
adjusted between the values of 1 (slowest) and 4 (fastest). The default tempo setting is 2. To
change the tempo, say from 2 to 4, erase 2 by pressing and then enter .
Send as SMS
This option will allows you to send the current composed ringer tone stored in your phone to
other compatible Motorola phones.
Quick Access Setup
This option allows you to do the following:
• Customise your Quick Access menu.
• Set up and change the Voice Tag allocation for the Quick Access features.
For more information, see Using Voice Activation on page 36.
R Rest - similar to a pause i.e. no music will be heard for a short
adjustable duration. This is shown on the display as a ‘R’.
Press and hold to fill the notes with 0.
P Toggles pitch of the note. Two pitches are available: Flat and Sharp.
To change the pitch of an individual note, keep the cursor between
the note and its duration and press . If the cursor is elsewhere
it changes the mode there by changes pitch for all notes.
Music Notes - Table (Contd.)
Keyboard Musical Note
Up
Down
(A5) Book_8J51.book Page 67 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 68
PRELIMINARY
Phone Lock
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
This option is used to set, and change, the unlock code.
The unlock code can be set to protect your phone from unauthorised use. It can be set to
automatically lock your phone each time it is switched on.
The unlock code is a four digit number which is set at manufacture to 1234. This can be changed
at any time by using the 'change unlock code' option.
Automatic Lock
This option can be used to automatically lock your phone each time it is switched on. The option
has two settings, On or Off.
Lock Now
This option can be used to immediately lock your phone. Once selected, your phone will be
unusable until the unlock code is entered.
Change Unlock Code
This option is used to change the unlock code.
After selecting this option, you will be asked to enter the current security code before you can
proceed.
You can now enter a four digit code to replace the old code.
By pressing the key, you can access this option even when the phone is locked.
Adjust Contrast
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
This option is used to adjust the screen contrast.
The contrast is displayed as follows:
Adjust the contrast by pressing (NavDisc) on the keypad.
Pressing or on the keypad will end the contrast
adjustment.
Require SIM Card PIN
This option is used to set, and change, the PIN code.
The PIN code can be set to protect your SIM card from unauthorised use. If set to On, access to
your SIM card will be restricted each time it is inserted or the phone is turned on.
The option has two settings, On or Off.
If the SIM card does not support PIN code disabling, these items will not appear.
Change SIM PIN Code
This option is used to change the SIM card PIN code.
The 'Require SIM Card PIN' option must be set to On and you must enter the old PIN code before
you can proceed.
You will be asked to enter a new, four to eight digit code to replace the old PIN code. The new
PIN code must be entered again as confirmation.
(A5) Book_8J51.book Page 68 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
69
PRELIMINARY
If the PIN number is entered incorrectly three times in a row, your SIM card
will automatically lock-up and the Blocked message will be displayed.
Unblocking Your Phone
If you receive the Blocked message you will need to enter an unblock code and key sequence
before you can use the phone.
The 8 digit PIN unblocking code will have been provided with your SIM card by your Cellular
Service Provider.
Enter the following key sequence to unblock your phone:
The new PIN code must contain four to eight digits.
If this operation is performed incorrectly 10 times in a row, your SIM card
will become permanently blocked.
Change SIM PIN2 Code
This option is used to change your PIN2 security code.
When you select this option you must enter the old PIN2 security code before you can proceed.
You will be asked to enter a new, four to eight digit code to replace the old PIN2 security code.
The new PIN2 security code must be entered again as confirmation.
If the PIN2 security code is entered incorrectly three times in a row, the
Blocked message will be displayed.
When the Blocked message is displayed, you are not allowed access to menu items that
require you to enter the PIN2 code, for example ‘Setup Fixed Dialling’ and ‘Call Charge Settings’.
If you receive the Blocked message when you try to enter your PIN2 code, you will need to
unblock and change the code using the following key sequence:
If the PIN2 unblocking operation is performed incorrectly 10 times in a row,
your PIN2 code will become permanently blocked.
New Security Code
The security code is used to control access to security and other options within the menus.
This option is used to change the security code, which is set at manufacture to 000000.
Once selected, you will be asked to enter the current security code before you can proceed.
You will then be asked to enter a new, six digit code to replace the old security code.
In order to safeguard your phone, you should change your security code from the
factory setting as soon as possible.
Extended Menus
Press and hold . Extended Menus will be temporarily activated until you exit the
Options menu.
This option is used to switch the extended menus on or off.
If the extended menu option is switched off, you will not be able to access any of the extended
features.
The option has two settings, On or Off.
(A5) Book_8J51.book Page 69 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 70
PRELIMINARY
Show Time and Date
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
When selected, this option displays the time and date until any key is pressed.
Set Time and Date
This option is used to set the time and date. You will be prompted to Enter Time - the time
must be entered in 24-hour format. You will then be prompted to Enter Date.
Set Time Format
This option is used to set the clock to either 12-hour or 24-hour format.
Language Selection
This option is used to change the language for display messages.
The option has multiple settings.
When you select a language, all further display prompts and help messages will be in the
selected language.
Entry Method Selection
This option allows you to select the default entry method for editing text on your phone. Press
to display each of the available options. Then press to select the entry method you
require.
If TAP does not support the current language set up for your phone, then only Tap is available.
Your phone displays Not Available when you press .
See Entering Text on Your Phone in The Phone Book Menu on page 46.
Battery Saving Mode
This option can help you to conserve battery power by activating DTX (Discontinuous
Transmission), turning the status indicator off, and deactivating the backlight for incoming Cell
Broadcast messages.
The option has two settings, On or Off.
Set Animation
This option allows you to choose between still and animated menu icons.
This option has two settings, On or Off.
Select Keypad Tones
This option allows you to change or disable tones you hear when you press a key.
The option has three settings, Normal Tones, Single Tone or No Tones.
Phone Status
Status Review
This option can be used to view the current setting of menu options.
When selected, your phone will display a list of menu items which have been changed from the
default setting. Press the key to view the next item.
Master Reset
This option should be used with caution.
This option is used to restore certain phone options to their original settings.
(A5) Book_8J51.book Page 70 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
71
PRELIMINARY
When selected, you will be asked to enter the security code. Once entered, the master reset
option will perform the following operations:
• Cancel Automatic Answer, Audible Call Timers, In-Call Display Meter, Battery Save
(DTX), Auxiliary Alert, Automatic Handsfree, Automatic Lock, Cell Broadcast and Talk
and Fax Mode.
• Return Language Selection and Entry Method Selection to Original.
• Restore Keypad Tones to Normal, Ringer Tones to Standard, SMS Alert Tones to
Standard, Volume Level to Medium and Network Search frequency to Medium.
• Restore Extended Menus to their default settings.
• Return the band selection to the default setting.
Master Clear
This option should be used with extreme caution, for example it will clear
all the Phone Book entries from your phone memory.
This option is used to restore certain phone options to their original settings.
When selected, you will be asked to enter the security code. Once entered, the master clear
option will perform the same operations as 'Master Reset', plus the following operations:
• Clear the Phone Book entries from phone memory (not from SIM memory)
• Clear the Last Calls Made and Last Calls received list
• Clear the Message Editor
• Reset the Resettable Call Timers.
• Erase all recorded VoiceNotes.
• Erase all recorded Voice Tags.
Master Clear does not clear the:
•Fixed Dial list
• My Number(s) list
• Charge Meters
• Received and Outgoing Messages list
• Voicemail number
• SMS Service Centre number
• Lifetime timer.
(A5) Book_8J51.book Page 71 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 72
PRELIMINARY
Network Selection Menu
Network Selection
In order for the phone to make and receive phone calls, it must register with one of the available
networks. These can be either GSM900, GSM1800 or combined GSM900/ 1800 types of
network.
Your phone automatically searches for the last network used. If, for any reason, this network is
unavailable, your phone will attempt to register with a new network.
When your phone needs to register with a new network, it will generate a sorted list of
networks. The network list is sorted in the following order:
• The Home network.
• Networks from a preferred list.
• A random list of other networks found above a certain signal strength.
• All remaining networks in descending order of signal strength.
Any forbidden networks, stored in the SIM card, will not be included in the sorted list.
NavDisc
Icon
(A5) Book_8J51.book Page 72 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
73
PRELIMINARY
Change Band
This option allows you to choose the band you prefer. If your phone is not able to connect to a
network after changing band, use Available Networks.
Available Networks
When selected, this option will scan to see which networks are operating in your current
location. When the scan is complete, press the key to scroll through the list. When you see
a network you wish to register with or store in your preferred list, press the key. You will
now enter the 'Register Now' and 'Make Preferred' sub- menu.
Register Now
Once selected, your phone will try to register with the selected network. If the registration fails,
your phone will try to register in the normal way.
Make Preferred
Once selected, you will be asked where the selected network is to be located in the preferred list.
Network Search
These options determine how often your phone tries to register with a network and how the
attempt is made.
Registration Preferences
This option determines how the phone tries to register with a network.
The option has two settings, Automatic Search or ManualSearch
Automatic Search Mode
In the automatic mode, the phone will try to register with the first network in the sorted list. If
this is successful, your phone will display the network name and then enter the standby mode.
If registration is unsuccessful with one network in the list, your phone will try the next listed
network. If your phone fails to register with any of the listed networks, it will start at the
beginning of the list after a preset period. The preset period is determined by the 'Frequency Of
Search' option.
Manual Search Mode
In the manual mode, the phone will present you with the sorted list of networks. Use the
keys to select one network from the list. Your phone will
try to register with the selected network. If this is successful, the phone will display the network
name and then enter the standby mode.
If registration is unsuccessful, your phone will present the list again after a preset period. The
preset period is determined by the 'Frequency Of Search' option.
Frequency of Search
This option is used to determine how long your phone waits before attempting to re- register
after a registration attempt has failed.
The option has the following settings: Slow Search , Medium Search , Fast Search
or Continuous Search
Fast and Continuous Search may use up a significant amount of battery
power.
(A5) Book_8J51.book Page 73 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 74
PRELIMINARY
Preferred Networks
Add Network to List
This option enables you to add networks to your preferred list. When selected, the 'Choose From
Available' option will scan to see which networks are operating in your current location. When
the scan is complete, press the key to scroll through the list. When you see a network you
wish to store in your preferred list, press the key. You will be asked where the selected
network is to be located in the preferred list.
The 'Choose From Known' option will, when selected, present you with a preset list of networks.
Press the key to scroll through the list. When you see a network you wish to store in your
preferred list, press the key. You will be asked where the selected network is to be located
in the preferred list.
Select the 'Add New Network Code' option to enter network codes directly. Once entered, you
will be asked where the network is to be located in the preferred list.
Show List of Networks
This option is used to display the networks you have stored in your preferred list. In addition,
pressing the key will select the currently displayed entry and enter a move/ delete sub-
menu.
When 'Move to New Location' is selected you will be asked to enter a new location for the
selected network. When selected, 'Delete Selection' will remove the selected network from the
preferred list.
Find New Network
When selected, the phone will try to register with a network in the normal manner, with one
exception. When the registration attempt is made, your current network will be excluded from
the list of those available. If the attempt fails, your phone will then try to re- register with the
previous network.
(A5) Book_8J51.book Page 74 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
75
PRELIMINARY
Call Meters Menu
Call Metering
Your phone has an internal metering system which can be used to provide you with individual
and total call times or costs.
Call cost information is only available if you receive the Advice of Charge service. If you do not
receive this service, then only time meters are available.
The meter can be displayed during a phone call and audible tones can be generated to indicate
the passage of call time.
Your phone can handle values up to 21 digits long, although during calls it can only display the
last 12 digits. If the value exceeds 21 digits, then Too Large is displayed.
In addition, you can set a maximum charge limit so that your phone will monitor either the
number of units used or the call cost, and then not allow the limit to be exceeded.
Nav Disc
Icon
(A5) Book_8J51.book Page 75 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 76
PRELIMINARY
Show Call Charges
This feature allows you to display the cost of your calls or the amount of credit remaining. The
figures are in phone units or currency depending on the setting of the Set Charge Type
option.
Show Call Charges is only available if you receive the Advice of Charge service.
Show Last Call
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
Displays the cost of your last chargeable call.
Total For All Calls
Displays the cost of all your chargeable calls since the charge meters were reset to zero using the
‘Reset Call Charges’ option.
Credit Remaining
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
Displays the difference between your total call costs and the limit specified by the ‘Set Total
Charge Limit’ option. If there is no limit, No Charge Limit Set will be displayed.
Show Call Timers
This feature allows you to display the duration of your calls and to reset your time meters to zero.
If you receive the Advice of Charge service then all calls are timed. If you do not receive the
Advice of Charge service then, depending on the model, either all calls or only outgoing calls are
timed.
Show Last Call
Press . Select the Quick Access feature or after the tone, say the Voice Tag
name.
Displays the duration of your last call.
Total For All Calls
Displays the duration of all your calls since the time meter was reset to zero using the ‘Reset All
Timers’ option.
Reset All Timers
Sets the resettable time meters to zero. The Lifetime Meter is not resettable.
Set Audible Call Timers
Your phone provides two programmable audible call timers:
• The 'Single Alert Timer' will sound a beep just once during a call, after a preset time has
elapsed.
• The 'Repetitive Timer' will sound regular beeps during a call, at preset intervals.
In both cases, the timers will sound their beeps ten seconds before the end of the programmed
time.
(A5) Book_8J51.book Page 76 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
77
PRELIMINARY
Set In-Call Display
This feature allows you to specify whether the time or charge meters are displayed during a call.
If you do not have the Advice of Charge service, then only the time meter is available.
If a total charge limit has been set, then the in-call display always shows your remaining
credit.
Show Time Per Call
This option is used to display the time meter during calls. If you receive the Advice of Charge
service, only the chargeable calls will be displayed.
Show Charge Per Call, Show Total Call Charges
These menu items are only available if you receive the Advice of Charge service.
These options are used to display the call charges meter during and after chargeable calls. The
meter shows phone units or currency depending on the setting of the ‘Set Charge Type’ option.
No In-Call Display
This option switches off in-call display of the charge/time meter.
Call Charge Settings
This feature allows you to customise your Advice of Charge settings. You will be prompted to
enter your PIN2 security code before you can access the options.
This menu item is only available if you receive the Advice of Charge service.
Reset Call Charges
This option resets your charge meters to zero.
Set Total Charge Limit
This option sets the maximum limit for call charges; once this limit has been reached, the
network will refuse any further chargeable calls.
If you switch the charge limit On, you will be prompted to enter a new limit. Enter the amount as
either units or currency depending on the setting of the Set Charge Type option. Units
must be entered as whole numbers.
When the charge limit is On, you will not be able to make fax or data calls.
Once a limit is set, the in-call display will show the remaining credit. When you reach your last
two minutes, the warning message Approaching Charge Limit will be displayed and a
warning alert will sound. The sound will be repeated when one minute remains. When the limit
is reached the message Charge Limit Reached will be displayed and you will not be able
to make any more chargeable calls.
Once the limit is reached the Total Charge Limit will need to be reset or switched off before any
chargeable calls can be made.
Select Off to switch off the charge limit.
Set Charge Type
This option defines whether charge information is displayed as either phone units or currency.
Units
Sets the charge type to phone units.
Currency
Sets the charge type to currency. You will be prompted to enter the Currency Name. Enter a
3-character notation, for example GBP for the UK, DEM for Germany or FFR for France. You will
then be prompted for the Charge Per Unit. Enter the amount and press .
(A5) Book_8J51.book Page 77 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 78
PRELIMINARY
Lifetime Timer
This option is used to display the total time of all calls made on your phone.
This meter can not be reset, the Reset All Timers, Master Reset or Master
Clear options have no effect.
(A5) Book_8J51.book Page 78 Thursday, May 4, 2000 3:32 PM
Using the Options Menu
79
PRELIMINARY
Accessory Setup Menu
† Only this option will be displayed when the headset accessory is attached.
‡ Availability depends on the type of car kit installed.
You will only be able to access this menu when your phone is mounted in a car kit or when a
headset accessory is attached.
Car kits can provide charging facilities and some provide connection to an external antenna for
better reception.
Your phone can also be linked to external microphones and speakers for hands free operation,
and provides several options to complement the use of car kits.
Mute Car Radio
This option can be used to mute your car radio when you make, or receive, a call when your
phone is attached to the car kit. It must be enabled by your local dealer.
This option has two settings, On or Off.
This option will have no effect if your car radio does not have a mute feature, or if the
car kit installation does not support this option.
Automatic Answer
This option allows your phone to automatically answer an incoming call after two rings.
This option has two settings, On or Off.
If this option is On, we recommend that the 'Ring or Vibrate' option be set to Ring Only.
Nav
Disc
Icon
(A5) Book_8J51.book Page 79 Thursday, May 4, 2000 3:32 PM
Using the Options Menu 80
PRELIMINARY
Safety Timer
This option can be used to keep the phone on for a set period after the vehicle ignition has been
turned off. This prevents the vehicle's battery from becoming drained and saves you from having
to re-enter PIN and Unlock codes after every short stop.
As standard the 'Safety Timer' is set to 60 minutes. Once selected, this option can be adjusted to
any value between zero and 999 minutes. When set to zero, this option is effectively switched
off.
Automatic Handsfree
This option is used in conjunction with the 'Automatic Answer' option and a car kit, to transfer
call conversation to external microphones and speakers. It is available only with selected car kits.
Contact your Motorola representative for further details.
This option has two settings, On or Off.
Safety Timer
This option can be used to keep the phone on for a set period after the vehicle ignition has been
turned off. This prevents the vehicle's battery from becoming drained and saves you from having
to re-enter PIN and Unlock codes after every short stop.
As standard the 'Safety Timer' is set to 60 minutes. Once selected, this option can be adjusted to
any value between zero and 999 minutes. When set to zero, this option is effectively switched
off.
Auxiliary Alert
This option allows your phone to alert you of an incoming call by flashing your vehicle lights, or
by sounding the horn. It must be enabled by your local dealer.
Some local regulations prevent the use of this option and, accordingly, this option
may not be present on your phone.
(A5) Book_8J51.book Page 80 Thursday, May 4, 2000 3:32 PM
Using the Quick Access Menu 81
PRELIMINARY
Using the Quick Access Menu
AThe menu shown above represents the default setting supplied with your phone.
Although the features in your phone are available through easy access menus, some of the most
commonly used features are also available in the Quick Access menu. Each feature in the menu is
allocated a number from 1 to 9.
To use a Quick Access feature, you can use any of the following methods:
•Press the quick access key ( ) and say the Voice Tag name after the tone. For best
results, use in an area with minimal wind or background noise. See Using Voice
Activation on page 36.
•Press followed by the number of the feature.
•Press . Use (NavDisc) to highlight the appropriate menu option and then press
to select it.
You can change the features, and the positions of the features, available in the Quick Access
menu - see Quick Reference Card.
Each Quick Access feature is represented by an icon as well as the feature name. The currently
selected icon is shown with a dark background.
Find Name?
You will be prompted to Enter Name. Enter the first three characters of the name and press
. The first matching entry in the Phone Book will be displayed. Press to call the
number.
Nav Disc
Icon
(A5) Book_8J51.book Page 81 Thursday, May 4, 2000 3:32 PM
Using the Quick Access Menu
82
PRELIMINARY
Add to SIM?
You will be prompted to enter a phone number and then a name.
AIf you already had a number displayed, it will automatically be re-displayed when you
select this feature.
The number will be stored in the next available SIM card location. See Add Entry on page 48,
for more information.
Battery Meter?
A bar graph indicating the approximate battery charge level will be displayed. The more bars
displayed, the greater the charge level.
See Show Battery Meter on page 53, for more information.
Play VoiceNotes?
Plays the recorded VoiceNotes™. See Using VoiceNotes on page 34, for more information.
Mute Phone?
Temporarily turns the microphone off during a phone call. Reselect this option to resume your
conversation.
Read Messages?
Your newest message will be displayed; you can then read, delete and edit messages as normal.
See ‘Received Messages’ for more information.
Vibrate On/Off?
VibraCall™ will be switched either on or off depending on the current setting. If VibraCall™ is
switched on, the ‘Ring or Vibrate’ setting changes to Vibrate Only. If VibraCall is switched
off, the ‘Ring or Vibrate’ setting changes to Ringer Only. See ‘Ring or Voibrate’ for more
information.
Divert On/Off?
Unconditional voice call diversion will be switched either on or off depending on the current
setting. This will allow Fax and Data diversion to remain enabled independent of the Voice Call
Diversion setting.
AYou must have defined a diversion number using the ‘Divert All Voice Calls’ option in the
Call Diverting menu in order to use this feature.
AYou cannot switch call diverting on or off if you are outside network coverage.
Find Location?
You will be prompted to Enter Location. Enter the location number and press . The
first matching entry in the Phone Book will be displayed. Press to call the number.
Add to Phone?
You will be prompted to enter a phone number and then a name.
AIf you already had a number displayed, it will automatically be re-displayed when you
select this feature.
The number will be stored in the next available phone memory location. See Add Entry on
page 48, for more information.
Call Voicemail?
Your phone will make a call to your voicemail number.
AYou must have defined a Voicemail number in order to use this feature.
See ‘Call Voicemail’ for more information.
(A5) Book_8J51.book Page 82 Thursday, May 4, 2000 3:32 PM
Using the Quick Access Menu 83
PRELIMINARY
Lock Now?
Immediately locks your phone, you will not be able to use your phone until the unlock code is
entered. See ‘Phone Lock’ for more information.
Adjust Ring?
This option is used to display and to set the incoming call ring tone volume.
Switch Memory?
Switches one-touch dialling between the phone and SIM memories depending on the current
setting.
Outgoing SMS?
Your newest message will be displayed; you can then read, send, delete and edit messages as
normal. See Outgoing Messages on page 61, for more information.
Message Editor?
The last message that was edited will be displayed. Press and hold to clear the message
and start a new one, or modify the message displayed. See Sending and Receiving SMS
Messages on page 21, for more information.
Received Calls?
Displays the first entry in the Last Calls Received list. You can scroll through the list and call the
numbers as normal. See Last Calls Missed on page 49, for more information.
Call Charge?
Displays the cost of your last chargeable call. See Show Call Charges on page 76, for more
information.
Call Timer?
Displays the duration of your last chargeable call. See Show Call Timers on page 76, for more
information.
Restrict My ID?
Your phone number will not be sent with the next attempted call; after this your phone number
will be sent until you reselect this option.
Show Time/Date?
Displays the current time and date.
Show Credit?
Allows you to quickly display the Credit Remaining.
AThis will only show the credit remaining if you receive the Advice of Charge service.
Find New Network?
Allows you to quickly search for a new network.
Adjust Contrast?
Allows you to adjust the screen contrast.
Change Band?
Use this option to change the band of operation for your phone. See Network Selection
Menu on page 72, for more information.
Set Alarm?
Use this option to set on alarm.
(A5) Book_8J51.book Page 83 Thursday, May 4, 2000 3:32 PM
Using the Quick Access Menu
84
PRELIMINARY
Edit Music?
Use this option to set on alarm.
Access Internet?
AThis is a network and subscription dependent feature. Contact your service provider for
details about the mobile internet services based on the WAP (Wireless Application
Protocol) technology that they provide.
Use this option to start your mobile internet session. See Access Internet on page 41, for
more information.
(A5) Book_8J51.book Page 84 Thursday, May 4, 2000 3:32 PM
Accessories 85
PRELIMINARY
Accessories
The following accessories have been designed to work with your phone. Additional accessories
may be available and are packaged separately. Please refer to your local service provider or retail
outlet for more information.
Power Adapter
The Power Adapter (charger) connects to the Desktop Charger or directly to the phone. When
connected directly to the phone, it charges the battery and also provides dead battery operation.
The Power Adapter requires an appropriate Adapter Plug.
UK Adapter Plug
The UK Adapter Plug connects the Power Adapter to a UK-style mains power outlet.
European Adapter Plug
The European Adapter Plug connects the Power Adapter to a Continental European-style mains
power outlet.
Aust/NZ Adapter Plug
The Australia/New Zealand Adapter Plug connects the power adapter to a Australian/New
Zealand mains power outlet.
Indian Adapter Plug
The Indian Adapter Plug connects the power adapter to an Indian mains power outlet. This plug
can also be used in Pakistan and Bangladesh.
Cigarette Lighter Adapter
The Cigarette Lighter Adapter connects to your phone and allows you to charge your phone's
battery while driving. When the phone is in use, the adapter overrides the battery therefore
preserving battery life. The adapter also provides dead battery operation.
Personal Handsfree System
The Personal Handsfree System allows you to use your phone handsfreeand is required for
telephone operation.
Holster
The Holster holds the phone while being worn on your belt.
(A5) Book_8J51.book Page 85 Thursday, May 4, 2000 3:32 PM
Accessories
86
PRELIMINARY
(A5) Book_8J51.book Page 86 Thursday, May 4, 2000 3:32 PM
What to do if... 86
PRELIMINARY
What to do if...
You can’t switch your
phone on
Check the battery. Is it charged, properly fitted and are the
contacts clean and dry? See Important Battery
Information on page 17.
You can’t make calls Check the signal strength meter in the display. If the signal is
weak, move to an open space or, if you are in a building, move
closer to a window.
Check the Network Selection settings. Try Manual Selection, or
try another network. See Network Search on page 73.
Check your Operator coverage map.
Is Restricted displayed? Check the Call Barring and Fixed
Dialling settings.
Has the call charge limit been reached? Use your PIN2 code to
reset the limit or contact your Service Provider. See Set Total
Charge Limit on page 77.
Has a new SIM card been inserted? Check that no new
restrictions have been imposed.
You can’t receive calls Check the signal strength meter in the display. If the signal is
weak, move to an open space or, if you are in a building, move
closer to a window.
Check the Call Diversion and Call Barring settings.
Check the Ringer and VibraCall™ settings. If both are off, there
is no audible alert. See ‘ Ring or Vibrate’.
Your phone won’t
unlock
Have you inserted a new SIM card? Enter the new PIN code.
See Entering Your SIM Card PIN Code on page 24.
Do you have a replacement phone? Enter the default phone
unlock code - 1234.
Have you forgotten the unlock code? Press to change the
unlock code (you will need your security code).
Your PIN is blocked Enter the PIN unblocking code supplied with your SIM card (see
Unblocking Your Phone on page 69.)
Your PIN2 is blocked Enter the PIN2 unblocking code supplied with your SIM card
(see Change SIM PIN2 Code on page 69.)
Your SIM card won’t
work
Is the card inserted the right way round? See SIM Card
Insertion/Removal on page 20.
Is the gold chip visibly damaged or scratched? Return the card
to your Service Provider.
Check the SIM contacts. If they are dirty, clean them with an
antistatic cloth.
(A5) Book_8J51.book Page 86 Thursday, May 4, 2000 3:32 PM
What to do if...
87
PRELIMINARY
The battery won’t
charge
Check the charger. Is it properly connected? Are its contacts
clean and dry? See Your Battery on page 17.
Check the battery contacts. Are they clean and dry?
Check the battery temperature. If it is warm, let it cool before
recharging.
Is it an old battery? Battery performance will decline after
several years use. Replace the battery.
Are you using a Motorola original battery? Your charging
system may not be able to communicate with your battery. See
‘Your Battery’.
The battery icon and
meter are missing
Are you using a Motorola original battery? Your charging
system may not be able to communicate with your battery. See
‘Your Battery’.
The battery drains
faster than normal
Are you in an area of variable coverage? This uses extra battery
power.
Is it a new battery? A new battery will need two to three
charge/discharge cycles to attain normal performance. See
Your Battery on page 17.
Is it an old battery? Battery performance will decline after
several years use. Replace the battery.
Is it a battery that hasn’t been completely discharged? Allow
the battery to fully discharge (until the phone turns itself off)
and then charge the battery overnight.
Check that the Frequency Of Search feature in the Network
Selection menu has not been set to Fast or Continuous.
See Network Search on page 73.
Check that the Battery Saving Mode feature has not been set
to Off.
Are you using your phone in extreme temperatures? At
extreme hot or cold temperatures, battery performance is
significantly reduced.
You can’t cancel Call
Diverting or Call
Barring
Wait until you are in an area with good network coverage and
try again.
The symbol is
flashing
There is not enough memory available to store another SMS
message. Use the Messages menu to delete one or more
existing messages.
I can’t make
international calls
Some Service Providers automatically bar the ability to make
international calls. Contact your Service Provider.
Have you included the relevant codes? Press and hold the
key to display the international dialling prefix (+) and then
enter the appropriate country code followed by the phone
number.
(A5) Book_8J51.book Page 87 Thursday, May 4, 2000 3:32 PM
Index 88
PRELIMINARY
Index
A
Access Internet .......................................38,86
Accessories ....................................................87
Accessory setup menu ..................................81
Add entry
To phone memory ............................48,84
To SIM card memory ........................48,84
Adjust Contrast ......................................70,85
Adjust ring volume ........................................67
Alarm Clock ...................................................53
Disable Alarm ...........................................53
Edit Alarm ................................................53
Switch View .............................................53
Alarm Status ..................................................53
Alert tones ..............................................67,68
Animated Icons .............................................15
Animation ......................................................72
Assign Key to Feature ...................................35
Automatic answer .........................................81
Automatic Handsfree ....................................82
Automatic lock ..............................................70
Automatic redial ............................................22
Auxiliary alert .................................................82
B
Bar incoming calls .........................................59
Bar outgoing calls .........................................58
Batteries
Charging ..................................................17
Desktop charging ....................................18
Fitting .......................................................18
Low battery warning ...............................17
Maintaining ..............................................17
Removing .................................................18
Battery charge indicator ...............................15
Battery meter ..........................................54,84
Battery saving mode .....................................72
Blocked message ....................................21,71
Buttons
Smart button ...........................................13
Start/Stop Record ....................................14
Volume .....................................................14
C
Call charge settings ......................................79
Call diverting ..........................................55,84
Call holding ...................................................27
Call metering .................................................77
Call meters menu ..........................................77
Call related features menu ..........................54
Call timers ......................................................78
Call Transfer ..................................................30
Call Voicemail ................................................62
Call waiting ...................................................27
Calls Answered .............................................50
Calls Made .....................................................50
Cancel all diverting ................................57,84
Capacity
Checking battery capacity ......................54
Checking Phone Book capacity .............48
Cell broadcast ...............................................64
Battery saving mode ...............................72
Channel List .............................................64
Messages .................................................61
Change band ................................................85
From the default (900/1800) .................85
Change bar password ..................................59
Change SIM PIN2 code ................................71
Change unlock code ....................................70
Characters .....................................................44
Charge meters
Resetting ..................................................79
Check capacity (of the Phone Book) ...........48
Communications
RS-232 Serial Data ..................................16
Conference Call ............................................25
Call Waiting .............................................30
End Active And Held ...............................25
Hold Call ..................................................25
Make a New Call .....................................25
Reconnect ................................................26
Reconnect Held Call ................................26
Restrict My Number ................................25
Split Call ...................................................26
Switch Calls .............................................25
Contrast
Adjust Contrast ................................70,85
Creating music notes ....................................68
D
Delete
Last ten calls ............................................50
Message ............................................62,64
Phone book entries .................................48
Desktop charging of your battery ...............18
Detailed diverting ..........................................57
Dialling phone book numbers .....................23
Display ............................................................14
(A5) Book_8J51.book Page 88 Thursday, May 4, 2000 3:32 PM
Index
89
PRELIMINARY
Adjusting the contrast .....................70,85
Display characters .........................................44
Display features .............................................38
Displaying your own phone number ...........50
Divert
Cancelling ................................................57
Data calls ..................................................57
Fax calls ....................................................57
Diverting
Scheduled ................................................56
DTX .................................................................72
Duration of note ...........................................69
Dynamic Dictionary .......................................46
E
Earpiece connector .......................................15
Edit .................................................................68
Edit Alarm ......................................................53
Edit Music ........................................68,69,86
Change Tempo ........................................69
Editing messages ...........................................61
Emergency calls .............................................23
Ending a phone call ......................................24
Entering characters .......................................43
Entry Method Selection .........................44,72
Erase music ....................................................69
Erase name and number ..............................48
Extended menus .......................................4,71
F
Fault finding ..................................................89
Find entry by location ............................47,84
Find entry by name ................................47,83
Fitting your battery .......................................18
Fixed dialling ..................................................50
Calling numbers ......................................51
Setting ......................................................51
Flip ..................................................................13
H
Handsfree On/Off ..........................................25
Headset
Making and receiving calls .....................13
Hold Call ........................................................25
I
In use symbol .................................................14
Initiating Transfer Call ..................................30
International phone calls ..............................23
Internet
Accessing .................................................38
Internet service alerts ....................................40
iTAP Mode .....................................................45
Dynamic Dictionary .................................46
Locking a word ........................................45
L
Language List ................................................65
Language selection .......................................72
Last 10 Calls
Switch View .............................................50
Last Calls Missed
Add to Phone Memory ...........................50
Add to SIM Card Memory ......................50
Last ten calls ..................................................49
Lifetime timer ................................................80
Lock now ................................................70,85
Low battery warning ....................................17
M
Master clear ...................................................73
Master reset ..................................................73
Menu
Access Internet ........................................38
Menus
Accessory setup menu ............................81
Call Diverting menu ................................55
Call meters menu ....................................77
Call related features menu .....................54
Extended menu .........................................4
Messages menu .......................................60
Network selection menu ........................74
Options menu ..........................................37
Personalised menus ...................................4
Phone Book menu ...................................42
Phone setup menu ..................................66
Quick Access menu .................................83
Send Messages menu .............................64
Short menu ................................................4
Message editor .......................................64,85
Message settings ..........................................65
Messages
Call holding/call waiting messages ........27
Cell broadcast messages ........................61
Creating and editing ...............................61
Reading SMS messages ..........................61
Sending SMS messages ..........................63
Switch View ......................................62,63
Messages menu ............................................60
Mobile Internet .............................................38
Editing Text ..............................................40
Ending the session ..................................40
Icons and messages ................................39
Internet service alerts ..............................40
(A5) Book_8J51.book Page 89 Thursday, May 4, 2000 3:32 PM
Index 90
PRELIMINARY
Making and Receiving Calls ...................40
Setting Up ................................................39
Soft Keys ..................................................38
Starting the session .................................40
Summary of keys .....................................41
Moving the cursor .........................................68
Music ..............................................................68
My phone number(s) ....................................50
N
Names
Entering ....................................................43
Network selection menu ..............................74
Networks
Change band ...........................................85
New security code .........................................71
Numeric Mode ..............................................46
O
One-touch dial setting ..................................51
One-touch dialling .................................22,85
Options menu ................................................37
Outgoing messages ...............................63,85
P
Pauses
Inserting into phone numbers ................23
Personal numbers ..........................................47
Personalised menu ..........................................4
Phone book
Call number .............................................48
Capacity ...................................................43
Deleting/erasing entries ..........................48
Dialling phone book numbers ................23
Modify name or number ........................48
Preventing access to ................................49
Storing numbers - see Add Entry .........48
Phone calls
Automatic redial ......................................22
Dialling phone book numbers ................23
Emergency calls .......................................23
Ending ......................................................24
International .............................................23
One-touch dialling ..................................22
Receiving ..................................................24
Phone setup menu ........................................66
Phone status ..................................................73
Phonebook ....................................................52
Groups ......................................................52
Phonebook Groups .......................................52
Creating ...................................................52
Modifying .................................................52
PIN code
Entering ....................................................21
Setting and changing .............................70
PIN2 code ......................................................71
Pitch ...............................................................69
Play music ......................................................69
Postscripting ..................................................43
Prevent access (to Phone Book) ...................49
Q
Quick Access features
Assign key ................................................35
Setup ........................................................35
Quick access menu .......................................83
Quick Access Setup ......................................35
R
Reading SMS messages ................................61
Received calls ................................................85
Received messages .......................................62
Receiving a phone call ..................................24
Recording VoiceNotes ...........................31,64
Redialling the last number called ................22
Removing your battery .................................18
Require SIM card PIN ....................................70
Restrict My Number ......................................25
Restrict my phone number ...................55,85
Retrieve Numbers ..........................................62
Return call ......................................................62
Ring or vibrate ...............................................67
Ring tones ......................................................67
S
Safety timer ...................................................82
Save music .....................................................69
Scheduled Diverting, Diverting
Scheduled ................................................56
Screen
Adjusting the contrast ............................85
Security code
Changing .................................................71
Select Phone Line ..........................................67
Send as SMS ..................................................69
Sending SMS messages ................................63
Service centre ................................................65
Set Alarm ................................................85,86
Set Animation ...............................................72
Set in-call display ..........................................79
Set Message Alert Tone ........................67,68
Set Ringer Tone .............................................67
Set Ringer Tone 2 .........................................67
Set Time and Date ........................................72
(A5) Book_8J51.book Page 90 Thursday, May 4, 2000 3:32 PM
Index
91
PRELIMINARY
Set Time Format ............................................72
Setup fixed dialling .......................................51
Short menu ......................................................4
Short message service symbol .....................15
Show Alarm Status .......................................53
Show battery meter ...............................54,84
Show call charges ..................................78,85
Show call timers .....................................78,85
Show Services ................................................49
Show Time and Date ....................................72
Signal strength symbol .................................14
SIM card
Insertion/removal .....................................20
PIN code ............................................21,70
PIN2 code .................................................71
Smart button .................................................13
SMS Messages ........................................60,63
Received Tone SMS .................................63
Tone SMS Messages ...............................63
Special keys ....................................................13
Split Call .........................................................26
Start/Stop Record button .............................14
Status indicator .............................................16
Battery saving mode ...............................72
Status review .................................................73
Switch Calls ...................................................25
Switch View .......................25,50,53,62,63
Symbols ..........................................................14
T
Talk and fax ...................................................57
Tap Mode ......................................................46
Text Entry Method
iTAP Mode ...............................................45
Numeric Mode .........................................46
Selecting ............................................44,72
Tap Mode .................................................46
Timers .............................................................78
Tone SMS Messages .....................................63
Tones
Setting alert tones ............................67,68
Setting ringer tones ................................67
Transfer Call ..................................................30
Transmission rate ..........................................57
Troubleshooting ............................................89
Turn Mute On or Off ....................................26
U
Unblocking your phone ................................71
Unconditional call diversion .........................84
Unlock code
Setting and changing ..............................70
V
VibraCall .................................................67,84
Visual Alert ....................................................72
Visual Indicator ..............................................16
Voice Activation
Phone Book entries .................................34
Quick Access features .............................36
Voice Dialling .........................................35,47
Voice Features ...............................................31
Voice Activation ......................................33
VoiceNotes ...............................................31
Voice Tag (Phone Book)
Adding or editing when entry
exists ......................................................34
Adding when entry is new .....................33
Deleting ....................................................34
Voice Tag (Quick Access)
Adding or editing ....................................35
Deleting ....................................................36
Voicemail
Number ....................................................65
VoiceNotes .............................................31,64
Recording ..........................................14,31
Volume
Adjusting the earpiece and
keypad volume .....................................14
Adjusting the ringer volume ..................67
Automatic volume control .....................14
Buttons .....................................................14
W
What to do if... .............................................89
(A5) Book_8J51.book Page 91 Thursday, May 4, 2000 3:32 PM
