Supplemental Users Manual Response to TC4252 and TC4253

Unknown
From: Bachler Andrew-WLAB00 [A.Bachler@motorola.com]
Sent: Thursday, July 29, 2004 11:08 AM
To: 'Gregory Czumak'
Cc:
PCTEST
-
Accounting; PCTEST
-
Al Cirwithian; PCTEST
-
Courtenay; PCTEST
-
Randy Ortanez
Subject:
RE: FCC ID: IHDT6EE1 (Portable PCS GSM Transceiver with Embedded Bluetooth)
Page
1
of
5
Message
7/29/2004
Hi Gregory,
Yes, Anna has the PO number, NP1325040 (financial aspects resolved).
I can not find the manual language either. We went through this same thing a little while ago. I'll contact our
manual publications group again. I expect the issue is due to the English translation of the manual going to China
(our first customer). It literally "got lost in the translation".
Response: Yes, the final user's manual will comply with the following:
§15.21 Information to user. The users manual or instruction manual for an intentional
or unintentional radiator shall caution the user that changes or modifications not
expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Typical language follows:
Caution: Changes or modifications made in the radio phone, not expressly approved by Motorola,
will void the user's authority to operate the equipment.
Andrew Bachler
Motorola PCS
847 523-6167
-----Original Message-----
From: Gregory Czumak [mailto:gregory@pctestlab.com]
Sent: Thursday, July 29, 2004 9:06 AM
To: Bachler Andrew-WLAB00
Cc: PCTEST - Accounting; PCTEST - Al Cirwithian; PCTEST - Courtenay; PCTEST - Randy Ortanez
Subject: RE: FCC ID: IHDT6EE1 (Portable PCS GSM Transceiver with Embedded Bluetooth)
Andy,
I've reviewed your response submittal- everything looks good EXCEPT I cannot find the
statement required by Section 15.21 in the manual supplement that you submitted. The
Bluetooth application (15.247) is required to have this statement in the manual. Once
you confirm that it will be included, we will be able to issue the grant (assuming all of
the financial aspects have been resolved- I am not involved with those).
Sincerely,
Gregory Czumak
Quality Manager
Senior Certification Engineer
PCTEST Engineering Laboratory, Inc.
6660-B Dobbin Road
Columbia, MD 21045
410-290-6652
410-290-6654 (Fax)
gregory@pctestlab.com
This communication and its attachments contain information from PCTEST Engineering
Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It
may contain information that is confidential and/or legally privileged. Any
unauthorized use that may compromise that confidentiality via distribution or disclosure
is prohibited. Please notify the sender immediately if you receive this communication in
error, and delete it from your computer system. Usage of PCTEST email addresses for
non-business related activities is strictly prohibited. No warranty is made that the e-mail
or attachment(s) are free from computer virus or other defect. Thank you.
-----Original Message-----
From: Bachler Andrew-WLAB00 [mailto:A.Bachler@motorola.com]
Sent: Wednesday, July 28, 2004 6:25 PM
To: 'Gregory Czumak'
Cc: PCTEST - Randy Ortanez; PCTEST - Courtenay; PCTEST - Al Cirwithian
Subject: RE: FCC ID: IHDT6EE1 (Portable PCS GSM Transceiver with Embedded Bluetooth)
Our response is attached.
Thanks,
Andy
Andrew Bachler
Motorola PCS
847 523-6167
-----Original Message-----
From: Gregory Czumak [mailto:gregory@pctestlab.com]
Sent: Tuesday, July 27, 2004 4:14 PM
To: Andrew Bachler
Cc: PCTEST - Randy Ortanez; PCTEST - Courtenay; PCTEST - Al Cirwithian
Subject: FCC ID: IHDT6EE1 (Portable PCS GSM Transceiver with Embedded Bluetooth)
To: Andrew Bachler/Motorola, Inc.
From: Gregory Czumak/PCTEST TCB
Re: FCC ID: IHDT6EE1 (Portable PCS GSM Transceiver with
Page
2
of
5
Message
7/29/2004
Embedded Bluetooth)
Applicant: Motorola, Inc.
Application Received: 07/16/2004
Correspondence Reference Number: 240727A.IHD
Confirmation Number: TC4252 and 4253
Date of Original Email: 07/27/04
Subject: Request for additional information
In regards to your recent response to our request for additional information
regarding your TCB application referenced above, we kindly request that you
provide the following additional information.
Bluetooth application:
1. There is no radiated emission data for emissions in the restricted band at
2483.5 - 2500 MHz, however, the spurious conducted emission plots show a
relatively strong strong spur (42 dBc) in this band. Please provide radiated
emission data for all emissions in the referenced restricted band.
2. What is the gain of the antenna used with the BT transmitter?
3. The statements listed in Sections 15.21 and 15.19(a)(3) are required to be in
the user's manual, however, they are not. Please include them in the manual.
PCS GSM application:
4. Page 3 of the SAR report lists the Bluetooth output power as 0 dBm,
however, the BT test report lists the measured level as 3.7 dBm. Please
correct the SAR report.
5. The left tilt, right touch and right tilt SAR plots list tissue parameters not
shown in the Table on p.5 of the SAR report. It appears that a line of tissue
parameter data is missing from the Table. Please address.
Proposed Grant Listings:
Portable PCS GSM Transceiver with Embedded Bluetooth
24E 1850.2 - 1909.8 MHz 0.971 W 0.1ppm 239KGXW
Page
3
of
5
Message
7/29/2004
Output power listed is EIRP. SAR compliance for body-worn operating
configuration is limited to the specific belt-clip/holsters tested for this filing.
End-users must be informed of the body-worn operating requirements for
satisfying RF exposure compliance. SAR compliance was evaluated with the
integral Bluetooth active. The highest reported SAR values are: Head: 1.16
W/kg; Body-worn: 0.27 W/kg.
This device contains 900/1800 MHz GSM functions that are not operational in
U.S. Territories. This filing is only applicable for 850/1900 MHz GSM
operations.
15C 2402 - 2480 MHz 0.0023 W
The items indicated above must be submitted before processing can continue
on the above referenced application. Failure to provide the requested
information within 60 days of the original e-mail date may result in
application dismissal and forfeiture of the filing fees.
