Exhibit 8b Users Manual

131
Video
Filming a video
You can record videos up to 5 MB.
An Options list is then available:
Note:
When the record mode is launched the shutter sound is
played.
1
Place yourself or the subject in front of the phone so that
the image is displayed on the screen.
2
Adjust the required settings (see "Adjusting the
preview", page 132).
3
Press
OK
to launch the recording.
4
Select
Stop
([Right] softkey) to stop the recording.
options description
Store
To store the video.
Play
To play the recorded video.
Send by...
To send the video by Mail, by MMS or by
Bluetooth.
Delete
To delete the current video.
Details
To display information about the file Name, the
Resolution (width*height in pixels), the
Duration of the video, the Size, the Storage
date, the File protection status. The empty
fields are not displayed.
Brit01_EN_User guide.book Page 131 Friday, March 3, 2006 3:02 PM
132
Video
Setting the video to Pause
This mode allows to record several sequences on a single file.
During the recording you can pause your video in the following
way:
Storing/erasing your video
When a video has just been recorded, the file name and the
«Keep this video?» message are displayed.
The video is automatically stored in the Video sub-folder of the
Fun & Media box menu (see "Video", page 138), except if
you
have previously chosen to have it stored on the
Memory
Card.
Adjusting the preview
You can adjust several setting types before making a video.
These settings can be accessed from the option menu.
To select the image size:
1
During the recording, press
OK
.
2
Press
OK
to restart the Recording.
1
Select
OK
to store the video or select
Discard
to erase it.
1
Press on the [Menu] key. Select
Settings
and
Resolution
.
2
Select the
Normal
or the
Small
mode.
3
Press
OK
to confirm your selection and then
Save
to
store your settings.
Brit01_EN_User guide.book Page 132 Friday, March 3, 2006 3:02 PM
133
Video
To select the image quality:
This setting allows you to choose a quality level for your video.
The better the quality, the bigger the file size. If you wish to
send your video by Mail or by MMS, we advise you choose the
Economic mode.
To select the brightness:
To select the zoom setting:
To access the video size limit setting:
You can determine the size limit you wish to set for your video
file. You can choose whether you allow the video to reach its
maximum allowed size (5 MB) - you can of course stop the
1
Press on the [Menu] key. Select
Settings
and
Quality
. Or
press the [Down arrow] key to access the Quality
feature.
2
Select the
Super fine
, the
Fine
or the
Economic
mode.
3
Press
OK
to confirm your selection and then
Save
to
store your settings.
1
Scroll up or down. Select
Brightness
. Or press the [Left
arrow] key to access the Brightness feature.
2
Select one of the seven brightness levels.
3
Press
OK
to confirm your selection.
1
Scroll up or down. Select
Zoom
. Or press the [Up arrow]
key to access the Zoom feature.
2
Select one of the zoom levels by scrolling left or right.
3
Press
OK
to confirm your selection.
Brit01_EN_User guide.book Page 133 Friday, March 3, 2006 3:02 PM
134
Video
video recording when you wish to - or if you prefer the phone
to automatically stop the recording when the available limit for
Mail or MMS sending is reached.
Note:
The Short mail and Long mail values depend on your
operator (min: 100 KB, max: 300 KB).
To access the microphone setting:
This setting allows you to activate or mute the microphone
during the recording.
To access the self timer:
The self timer offers the possibility of recording a delayed
video, thereby enabling you to be in the video.
1
Press on the [Menu] key. Select
Settings
and
Video size
limit
.
2
Select
Fit to mail
or
Maximum size
.
3
Press
OK
to confirm your selection and then
Save
to
store your settings.
1
Press on the [Menu] key. Select
Microphone
.
2
Select
On
or
Off
.
3
Press
OK
to confirm your selection.
1
Press on the [Menu] key. Select
Self timer
.
2
Select
On
.
3
Press
OK
to launch the countdown.
The 10 seconds countdown is displayed. The recording
is automatically launched when the countdown is over.
Please proceed as usual (to stop or pause the video).
4
Select
Stop
to stop the recording.
Brit01_EN_User guide.book Page 134 Friday, March 3, 2006 3:02 PM
135
Video
Note:
If an event occurs (Mail, MMS reception...) or the
phone’s behaviour is modified (any key pressed, ...) after the
countdown has started, the self timer is automatically
stopped and set to Off Once the event has been processed,
the phone returns to the preview screen.
To display/conceal information icons:
This option allows you to activate or conceal the phone
information status icons display on top of the screen
To adjust the shutter sound level:
This option allows you to adjust the shutter sound level.
Note:
You cannot deactivate or mute the shutter sound
Option on your phone
1
Press on the [Menu] key Select
Settings
and
Info
.
2
Select
On
(the icons are displayed) or
Off
(the icons are
not displayed).
3
Press
OK
to confirm your selection and then
Save
to
store your settings.
1
Press
Option
. Select
Settings
and
Shutter sound
.
2
Scroll up or down to adjust the shutter sound level.
3
Press
OK
to confirm your selection and then
Save
to
store your settings.
Brit01_EN_User guide.book Page 135 Friday, March 3, 2006 3:02 PM
136
Video
How to play your video
You can watch a video that has just been recorded before
storing it in the following way:
You can also watch a video that is stored in you phone in the
Fun & Media box.
Here is how to use the keypad while in the Play mode:
1
Press on the [Menu] key.
2
Select
Play
.
keys description
[0] to [7] keys To set the volume (if any audio
track on the video) from Mute to
level 7.
[8] & [9] keys To set the volume to its maximum
level (if any audio track on the
video).
[Up arrow] key To Play or Pause the video.
[Down arrow] key To Stop the video playing.
[Left arrow] key To open the previous video.
[Right arrow] key To open the next video.
[Up] side key To increase the audio volume.
[Down] side key To decrease the audio volume.
[Left] softkey To set the video to Full screen.
[OK] key To diplay the Details screen.
Brit01_EN_User guide.book Page 136 Friday, March 3, 2006 3:02 PM
137
Video
During the Play mode, during the Pause mode or when the
video is stopped, an Options menu is available (Press on the
[Menu] key):
options description
Volume
To increase or decrease the audio volume.
Full screen
To set the video playing to Full screen.
Loop mode
To play the video repeateadly.
Send by...
To send the video by Mail, by MMS or by
Bluetooth.
Set as...
To set the video as Idle screen, Incoming
call, Alarm, Message alert or New mail
alert.
Details
To display information about the file Name,
the Title, the Author, the Copyright, the
Resolution (width*height in pixels), the
Duration of the video, the Size, the Storage
date, the File protection status. The empty
fields are not displayed.
Brit01_EN_User guide.book Page 137 Friday, March 3, 2006 3:02 PM
138
Fun & media box
Fun & media box
This menu groups and manages all the images, melodies,
MP3, videos, speech notes, frames, Games and Java
applications contained in the phone as well as all the files
received via the i-mode browser, Bluetooth, Mail, MMS or
SMS.
Video
This sub-menu allows you to play videos that are stored on
your phone (see "Video", page 128). You can also send/receive
these videos by Mail, MMS or by Bluetooth. The video file
format supported by your phone is .3gp.
To access videos stored on your phone
1
Press the [Left arrow] key or Press the [Menu] key and
select
Fun & Media box
.
2
Select
Videos
.
3
Scroll up and down to select the required video or select
the required folder (press
OK
to view its content) then
the required video. An Options menu is then available
(Press on the [Menu] key):
Brit01_EN_User guide.book Page 138 Friday, March 3, 2006 3:02 PM
139
Fun & media box
options description
Play
To play the selected video.
Set as...
To set the video as Idle screen, Incoming
call Line 1 or Line 2, Alarm, Message alert
or New mail alert.
Send by...
To send the selected video by Mail, by
MMS or by Bluetooth.
Delete
To delete the current video.
Delete all
To delete all the videos in the current
folder.
Multiple selection
To select several videos (by pressing OK).
Press OK to unselect a ticked video. Press
on the [Menu] key to access Send by...
(Bluetooth), Delete, Move to (to one of the
Video sub-folders or to the memory card),
Copy to (a folder of Videos), Select all (to
select all the files of the current folder or to
the memory card), Unselect all (to unselect
all the ticked files).
Move to
To move the selected file to one of the
Videos sub-folders or to the memory card.
Copy to
To copy the selected file in one of the
Videos sub-folders or to the memory card.
New folder
To create a new folder in the Videos sub-
folder (available only if the selection is not
a folder already).
Brit01_EN_User guide.book Page 139 Friday, March 3, 2006 3:02 PM
140
Fun & media box
Note:
If the selection is a sub-folder, another Options list is
available (press on the [Menu] key).
To play a video
During the Play mode, during the Pause mode or when the
video is stopped you can access the following options list
(Press on the [Menu] key):
Rename
To rename the selected video.
Details
To view the current file name, copyright,
resolution, duration, size, storage date and
file protection status information.
My preferences
To sort the stored videos (by date, name,
size).
1
The video playing is automatically launched.
options description
Volume
To set the sound volume level (from 0 to 7).
Full screen
To play the video on full screen.
Loop mode
To play the video repeatedly.
Send by...
To send the current video by Bluetooth, by MMS
or by Mail.
Set as...
To set the current video as an idle screen, an
incoming call, an Alarm, a Message alert or a New
mail alert.
Details
To display information about the file Name, the
Copyright, the Resolution (width*height in pixels),
the Duration of the video, the Size, the Storage
date, the File protection status.
options description
Brit01_EN_User guide.book Page 140 Friday, March 3, 2006 3:02 PM
141
Fun & media box
Note:
When the video track cannot be played or if there is no
video track, the audio track only is played. The «Audio only»
message is displayed.
Note:
You cannot play a video while a communication is in
progress.
Note:
If an event (alarm, SMS receipt...) occurs while a video
is being played, the playback is stopped.
Note:
The sending of a video may not be allowed if it is
exportation (copyright) protected (the ’File protected’
message is then displayed).
Note:
To send a video via Bluetooth please see "Bluetooth",
page 48. To send a video via Mail or MMS, please see "Mail
system", page 196
.
To play the videos that you received by Mail or by MMS,
please see "To view the received iMails and iMMS list:", page
205.
While playing the video you can use several shortcuts (please
see "How to play your video", page 136).
Full screen option:
This option allows you to watch videos on full screen. Please
hold your phone horizontally to enjoy an optimised display of
the video. You can use the side keys to play, pause.
Brit01_EN_User guide.book Page 141 Friday, March 3, 2006 3:02 PM
142
Fun & media box
Restrictions:
Some of the videos you received by Mail, by MMS, via the i-
mode or Bluetooth may bear restrictions:
Note:
Each time a restricted video is launched, a warning
message is displayed before the Playing, thus informing on
the remaining span time, number of remaining allowed
playing times, etc.
To access videos stored on your Memory
Card
You can play videos that are stored on your Memory Card. The
Options lists are the same as in the Videos sub-menu.
restrictions description
Restricted number
of playable times
The video can be played a pre-determined
number of times.
Deadline
restriction
The video can be played until a pre-
determined date.
Playable span time
The video can be played during a pre-
determined duration from its downloading
date.
1
Press the [Menu] key. Select
Fun & Media box.
2
Select
Videos
, then
Memory card
(this item is only
displayed when a Memory Card is inserted).
3
Scroll up or down to select the required video or choose
a folder (press
OK
to view its content) then select a
video.
4
Press
OK
to play the selected video.
Brit01_EN_User guide.book Page 142 Friday, March 3, 2006 3:02 PM
143
Fun & media box
Pictures
The Pictures sub-menu allows you to view, set and stored (via
the Camera, Bluetooth, i-mode browser, Mail and MMS) still
and animated images (animated .gif) as an Idle screen, a
Welcome or a Goodbye screen in order to configure and
personalise your phone screen (see "Display", page 218). The
picture formats supported by your phone are .wbmp, .gif, .jpg,
.png, .swf (to download and store images, see the following
sections).
Pictures browser
The Pictures browser allows you to display the stored images
as a list or as a mosaic. When the pictures are displayed as a
list the screen is divided into two parts: the image names list
and the selected image. When they are displayed as a mosaic
(Thumbnails mode: see ’Options/My preferences’ below) the
screen contains a mosaic of pictures and the name of the
selected image.
Brit01_EN_User guide.book Page 143 Friday, March 3, 2006 3:02 PM
144
Fun & media box
Viewing an image:
Options:
The Pictures folder Options list contains the following items:
1
Press the [Menu] key. Select
Fun & Media box
.
2
Select
Pictures
.
3
Scroll down the images list or mosaic. Select the
required image or select a folder
to view its contents
(press
OK
).
4
Press
OK
or press the [Menu] key and select
View
to
view the selected image in full size.
options description
View
To view the full image and name.
Set as...
To set the image as an Idle screen, as a
Welcome screen on switching on your
phone or as a Goodbye screen on
switching it Off.
Send by...
To send the image via Bluetooth, by Mail
or by MMS.
Delete
To delete the current image.
Delete all
To delete all the pictures of the current
folder.
Brit01_EN_User guide.book Page 144 Friday, March 3, 2006 3:02 PM
145
Fun & media box
Note:
If the selection is a sub-folder, a different Options list is
available (Press on the [Menu] key).
Multiple selection
To select several images (by pressing OK).
Press OK to unselect a ticked image. Press
on the [Menu] key to access Send by...
(Bluetooth), Delete, Move to (a folder of
Pictures
or the Memory Card
), Copy to
(a folder of Pictures o
r the Memory
Card
), Select all (to select all the files of
the current folder), Unselect all (to
unselect all the ticked files).
Move to
To move the current image to the Pictures
folder, to one of the Pictures sub-folders
or
to the Memory Card
.
Copy to
To copy the current image to the Pictures
folder, in one of the Pictures sub-folders or
the Memory Card.
New folder
To create a sub-folder in the Pictures folder
(available only if the selection is not
a folder already).
Rename
To rename the current picture.
Details
To show the name, resolution, size,
storage date and protection status of the
current file.
My preferences
To sort the stored images (by date, name
or size) and select a view mode (List,
Thumbnails 4 - to display a 4 - picture
mosaic).
options description
Brit01_EN_User guide.book Page 145 Friday, March 3, 2006 3:02 PM
146
Fun & media box
Note:
The sending of an image may not be allowed if it is
exportation (copyright) protected (the ’File protected’
message is then displayed).
Note:
To send an image via Bluetooth please see "Bluetooth",
page 48. To send an image via Mail or MMS, please see "Mail
system", page 196
.
Note:
Error messages may be displayed when setting,
viewing or storing an image:’File too big’: Please see "Error
messages", page 251; ’Decoding failure’: the image cannot
be viewed by the phone.
Note:
You can only access the Memory Card storage space if
the Memory Card is inserted in the phone.
When viewing an image, an Options menu is available (Press
on the [Menu] key):
options description
Full view
To view the picture in full screen.
Set as...
To set the image as an Idle screen or as a
Welcome screen on switching on your
phone or as a Goodbye screen on
switching it Off.
Send by...
To send the picture via Bluetooth, by Mail
or by MMS.
Delete
To delete the current picture
.
Slide show
To display automatically all the pictures of a
folder one after another.
Brit01_EN_User guide.book Page 146 Friday, March 3, 2006 3:02 PM
147
Fun & media box
Setting a still or animated image as an Idle
screen as a Welcome screen or as a
Goodbye screen from the Pictures folder
This option allows you to set a picture as an Idle screen, as a
Welcome or a Goodbye screen.
Cropping:
If the image you want to set as an Idle screen is too large to be
inserted into the available space, your phone will propose a
cropped image.
Add frame...
To add a frame to the current picture.
Rotate...
To rotate the picture to the right (90°), to
the left (90°) or turnover (180°)
.
Once the
picture is rotated, an Options menu is
available to store the current picture, to
view it in Full screen, to Cancel the
rotation, to Add a frame to the current
picture or to Rotate it once again.
Details
To show the name, resolution, size,
storage date and protection status of the
current file.
1
Press the [Menu] key. Select
Fun & Media box
.
2
Select
Pictures
.
3
Use the [Up arrow] and [Down arrow] keys to scroll
through the image names list and select one. Press on
the [Menu] key and then
Set as...
4
Select
Idle screen,
Welcome screen
or
Goodbye screen
.
options description
Brit01_EN_User guide.book Page 147 Friday, March 3, 2006 3:02 PM
148
Fun & media box
This allows you to move the image left, right, up and down
(cursor key). The image you have cropped is then displayed as
such on the phone (as an Idle screen).
Downloading images via the i-mode
Please refer to "Quick access to i-mode basic features", page
212.
To access images stored on your Memory
Card
You can store or view pictures that are stored on your Memory
Card. The Options lists are the same as in the Pictures sub-
menu.
1
Select
Set as...
then select
Idle screen
. If the image is too
big, the crop
screen is displayed.
2
Use the cursor key to move the image up, down, left or
right (the availability of the four arrows depends on the
image size).
3
Select
OK
.
Stored
is then displayed.
1
Press the [Menu] key. Select
Fun & Media box.
2
Select
Pictures
, then
Memory card
(this item is only
displayed when a Memory Card is inserted).
3
Select the required picture or choose a folder (press
OK
to view its content) then select a picture.
4
Press
OK
or press the [Menu] key and select
Full view
to
view the selected image in full size.
Brit01_EN_User guide.book Page 148 Friday, March 3, 2006 3:02 PM
149
Fun & media box
Melodies
This sub-folder allows you to play/store pre-defined melodies
or melodies you downloaded via Bluetooth or via the i-mode
browser, or you received by SMS, by Mail or by MMS. You can
set these melodies as a ringtone for Line1 or Line2, an Alarm
melody, a Message alarm melody, a New mail alert, a
Welcome or Goodbye melody. The melody and audio file
formats supported by your phone are .mid, .smf, .midi, .mld,
.mfi and .nsm (except when a .nsm is received via Bluetooth).
Melodies
To display the Melodies file contents:
The following Options list is available while scrolling the
melodies list.
1
Press the [Menu] key.
Select
Fun & Media box
.
2
Select
Melodies
.
3
Use the [Up arrow] and [Down arrow] keys to scroll to
the required melody.
options description
Play
To play the selected melody.
Set as...
To set the selected melody as a Ringtone
for Line1 or Line2, as an Alarm melody, as
a Message alert melody, as a New mail
alert melody or as a Welcome melody or a
Goodbye melody.
Send by...
To send the selected melody by Mail, by
MMS or via Bluetooth.
Delete
To delete the current melody.
Brit01_EN_User guide.book Page 149 Friday, March 3, 2006 3:02 PM
150
Fun & media box
Note:
You can only access the Memory Card storage space if
the Memory Card is inserted in the phone.
Delete all
To delete all the melodies of the current
folder.
Multiple selection
To select several melodies (by pressing
OK). Press OK to unselect a ticked melody.
Press on the [Menu] key to access Send
by... (Bluetooth), Delete, Move to (a folder
of Melodies
or the Memory Card
), Copy
to (a folder of Melodies
or the Memory
Card
), Select all (to select all the files of
the current folder), Unselect all (to
unselect all the ticked files).
Move to
To move the selected file to the Memory
Card or to one of the Melodies sub-folders.
Copy to
To copy the selected file in the Memory
Card or to to one of the Melodies sub-
folders.
New folder
To create a new sub-folder in the Melodies
folder (available only if the selection is not
a folder already).
Rename
To rename the selected melody.
Details
To view the current file name, size, storage
date and file protection status information.
My preferences
To sort the stored melodies (by date,
name, size).
options description
Brit01_EN_User guide.book Page 150 Friday, March 3, 2006 3:02 PM
151
Fun & media box
Melody download
You can download melodies from the Internet (via your PC),
from interactive voice servers, from the i-mode browser and
mailer or via Bluetooth.
In addition to the usual SMS download of melodies, you can
download melodies by browsing internet web sites.
Motorola phones are compatible with the Nokia™ Smart
Messaging system.
The principle is the following:
You can also receive melodies or audio files via Bluetooth.
Formats managed by the phone are .mid, .smf, .midi, .mld,
.mfi and .nsm formats.
1
Melodies are stored on a Web server.
2
Select your Motorola phone type to access a choice of
melodies.
3
Select one or more melodies to be downloaded to your
phone.
4
All selected melodies are downloaded via SMS.
5
Once the melody is received, a reception screen is
displayed. Press
OK
or press on the [Menu] key then
select
Play
to play the received melody.
To set a melody as a ringtone, a message alert melody,
an alarm melody, a Welcome or a Goodbye, please see
"Tones", page 215.
Brit01_EN_User guide.book Page 151 Friday, March 3, 2006 3:02 PM
152
Fun & media box
To play a downloaded melody from the reception screen:
To store a downloaded melody:
To discard a downloaded melody:
To access melodies stored on your
Memory Card
You can store or play melodies on your Memory Card. The
Options lists are the same as in the Melodies sub-menu.
1
Select
OK
or Press on the [Menu] key then select
Play
.
2
Select
Exit
to stop the playback.
1
Press on the [Menu] key.
2
Select
Install
.
If the memory space is sufficient, the melody is
automatically stored in the Melodies file. If there is no
space left, you need to select one or several melody(ies)
to be replaced from the set of melodies (melodies
associated with a ring feature cannot be deleted).
Once stored, a message is displayed. The melody can
be played and selected via the
Fun & Media box
menu.
1
Select
Discard
. The melody is erased and is therefore lost
for further installation.
1
Press the [Menu] key. Select
Fun & Media box.
2
Select
Melodies
, then
Memory card
(this item is only
displayed when a Memory Card is inserted).
3
Scroll up or down to select the required melody or
choose a folder (press
OK
to view its content) then select
a melody.
Brit01_EN_User guide.book Page 152 Friday, March 3, 2006 3:02 PM
153
Fun & media box
MP3 player
This sub-menu allows you to play MP3 melodies that are
stored on your phone. You can also send/receive these MP3
files by Bluetooth.
To access MP3 files stored on your phone
Listening to personal stereo equipment at full volume for
long periods can damage the user’s hearing.
1
Press the [Menu] key. Select
Fun & Media box
.
2
Select
MP3
.
3
Scroll up and down to select the required MP3 file or
select the required folder (press
OK
to view its contents)
then the required MP3 file. An Options menu is then
available (Press on the [Menu] key):
options description
Play
To play the selected MP3 file.
Set as...
To associate the selected MP3 to an event
(Incoming call, Alarm, Message alert, New
mail alert) if it is not protected.
This option may not be available on your
phone.
Send by...
To send the selected MP3 file by
Bluetooth, Mail or MMS.
Delete
To delete the current MP3 file.
Delete all
To delete all the MP3 files of the current
folder.
Brit01_EN_User guide.book Page 153 Friday, March 3, 2006 3:02 PM
154
Fun & media box
Multiple selection
To select several MP3 files (by pressing
OK). Press OK to unselect a ticked MP3
file. Press on the [Menu] key to access
Send by... (Bluetooth), Delete, Move to (a
folder of MP3 files
or the Memory Card
),
Copy to (a folder of MP3 files
or the
Memory Card
), Select all (to select all the
files of the current folder), Unselect all (to
unselect all the ticked files).
Move to
To move the selected file to the Memory
Card or to one of the MP3 sub-folders.
Copy to
To copy the selected file in the Memory
Card or to to one of the MP3 sub-folders.
New folder
To create a new sub-folder in the MP3
folder (available only if the selection is not
a folder already).
Rename
To rename the selected MP3 file.
Details
To view the current file name, size, storage
date and file protection status information.
My preferences
To sort the stored MP3 files (by date,
name, size).
options description
Brit01_EN_User guide.book Page 154 Friday, March 3, 2006 3:02 PM
155
Fun & media box
To play an MP3 melody
While playing the MP3 file you can use the following shortcuts:
While playing the MP3 file an Options list is available:
1
The selected MP3 is automatically played.
Select
Mode
to change the play mode (Repeat one song,
Repeat all or Shuffle - see above)
keys description
To mute the sound volume.
From to
To set the sound volume level (from 1 to
7).
To display information related to the
current MP3 file.
To play the current MP3 file in Play mode
(after it was stopped).
To stop the file playing.
To play the previous MP3 file.
To play the following MP3 file.
To access the Options menu (see above).
To increase the volume level.
To decrease the volume level.
options description
Play
To play the selected MP3 file.
Play with keypad
locked
To play the current MP3 file and lock the
keypad (e.g.: to allow you to have your
phone in your pocket). This does not
prevent the phone from receiving calls.
Volume
To set the volume for the MP3 player.
Brit01_EN_User guide.book Page 155 Friday, March 3, 2006 3:02 PM
156
Fun & media box
Games & applications
This sub-menu allows you to activate games and various
applications that may be stored on your phone, download new
games and applications via the i-mode browser, upgrade or
delete the stored games and applications.
Your phone may contain pre-set games or applications
(operator dependent).
Play mode
To select one of the available play modes:
Repeat one song (to play the selected
song repeateadly), Repeat all (to play back
the whole current folder contents), and
Shuffle (to play the whole current folder
contents randomly).
The selected play mode is then the default
one until you change it again.
Send by Bluetooth
To send the selected MP3 file by
Bluetooth.
Set as...
To associate the selected MP3 to an event
(Incoming call, Alarm, Message alert, New
mail alert) if it is not protected.
This option may not be available on your
phone.
Player wallpaper
To select one of the available animations to
be played when the MP3 player is active.
Details
To view the current file name, size, storage
date and file protection status information.
options description
Brit01_EN_User guide.book Page 156 Friday, March 3, 2006 3:02 PM
157
Fun & media box
You can store/download up to 100 games and/or applications
on your phone.
To activate a game/application:
or:
Note:
Depending on the game/application stored on your
phone, you may need to activate a network connection via
the i-mode browser. Select Yes or No.
Note:
The downloaded games/applications can only be
activated if the phone contains the SIM card that was used
during the downloading process.
Press the
[Menu]
key when in the Games & Applications list:
1
Press the [Menu] key.
Select
Fun & Media box
.
2
Select
Games & applications
.
3
Select one of the available games/applications from
the list or from one of the available folders (if any).
1
Press and hold the
i-mode
softkey from the idle screen.
2
Select one of the available games/applications from
the list or from one of the available folders (if any).
options description
Create Folder
To create a new folder and name it.
Delete Folder
To delete the current folder.
Rename Folder
To rename the current folder.
Move to Folder
To move the current game or application to
a folder.
Upgrade
To download the latest version of the
game from the network.
Brit01_EN_User guide.book Page 157 Friday, March 3, 2006 3:02 PM
158
Fun & media box
Delete
To delete the current game or application
from your phone.
Selective Delete
To delete the selected games, applications
or folders from your phone.
Delete all
To delete all the games, applications or
folders from your phone.
Sort
To sort the games and applications list (by
name, by size, etc.). Select Enter to
choose one sorting type from the list.
Properties
To display detailed information about the
game or application (name, URL, size,
etc.).
Certificate
To display the certificate of the game/
application.
Network Setting
To enable/disable automatic connection to
the network or to confirm the activation of
the network connection prior to the game/
application start.
iAppli To Setting
To allow/forbid access to a game/
application from a phone application.
Icon Info Setting
To allow/forbid the use of information
contained in your phone if required by an
application.
Auto Start
Settings
To enable or disable the automatic
activation of the current game or
application.
Show Desc Setting
To enable/disable an Application
Description File (ADF) display before
downloading a new game/application.
options description
Brit01_EN_User guide.book Page 158 Friday, March 3, 2006 3:02 PM
159
Fun & media box
Note:
Some of these items are also available from the folders.
When in a folder, select Menu ([Left] softkey) to get to this
list.
Note:
The availability of these items depends on the games/
applications.
Speech notes
This feature allows you to record speech notes up to 25
minutes on your phone.
Auto Start Failure
To display the Auto Start failure date and
type information.
Trace Info
To display the errors that occurred in
executing the application.
System Info
To view the used memory information,
remaining memory space and the Games
& Applications software system details.
options description
Brit01_EN_User guide.book Page 159 Friday, March 3, 2006 3:02 PM
160
Fun & media box
To record a speech note:
To select a speech note:
1
Press the [Menu] key.
Select
Fun & Media box
.
2
Select
Speech notes
.
3
If no speech note has been recorded, select
New
.
If one/
several speech note(s) is/are stored in the phone, Press
on the [Menu] key then
Record new
.
4
Select
Stop
to end the recording.
5
Enter the note name and press
OK
.
1
Press the [Menu] key.
Select
Fun & Media box
.
2
Select
Speech notes
.
3
Scroll up or down to select the required speech note or
the required folder.
options description
Play
To play the selected speech note(s).
New
To record a new speech note.
Set as...
To set the selected speech note as a ring
tone for Line1 or Line2, as an alarm
melody, as a message alert melody, as a
new mail alert or as a Welcome or a
Goodbye melody.
Send by...
To send the speech note via Bluetooth, by
MMS or Mail.
Delete
To delete the current speech note.
Delete all
To delete all the speech notes of the
current folder.
Brit01_EN_User guide.book Page 160 Friday, March 3, 2006 3:02 PM
161
Fun & media box
Note:
You can only access the Memory Card storage space if
the microSD™ Card is inserted in the phone.
If the selection is a sub-folder, an Options list is available.
Multiple selection
To access the Multiple selection screen
and select several speech notes. You can
then press on the [Menu] key to Send the
selected file(s) via Bluetooth, to Delete the
selected file(s), to Move them to a Speech
notes sub-folder or to the Memory Card, to
Copy them to a Speech notes sub-folder or
to the Memory Card, to Select all the
speech notes or to Unselect all the ticked
speech notes.
Move to
To move the selected speech note to the
Memory Card or to a Speech notes sub-
folder.
Copy to
To copy the selected speech note to the
Memory Card or to a Speech notes sub-
folder.
New folder
To create a new folder in the Speech note
sub-folder (only available if the selection is
not a folder already).
Rename
To change the name of the current speech
note.
Details
To view information about the name, file
size and recording date, and file protection
status
.
My preferences
To sort the stored speech notes (by date,
name, size).
options description
Brit01_EN_User guide.book Page 161 Friday, March 3, 2006 3:02 PM
162
Fun & media box
To play a speech note:
To access speech notes stored on your Memory
Card
You can store (see "To record a speech note:", page 160 ) or
play speech notes that are stored on your Memory Card. The
Options lists are the same as in the Speech notes sub-menu.
Frames
The frame border feature allows you to illustrate your pictures
and give them a more personal and fun touch. You can add
frames, speech balloons, etc. to the pictures stored in the
Pictures folder or while doing your picture preview.
1
Press the [Menu] key.
Select
Fun & Media box
.
2
Select
Speech notes
.
3
Scroll up or down to the required speech note. Press
OK
or press on the [Menu] key then select
Play
.
1
Press the [Menu] key. Select
Fun & Media box.
2
Select
Speech notes
, then
Memory card
(this item is only
displayed when a microSD™ Card is inserted).
3
Scroll up or down to select the required speech notes or
choose a folder (press
OK
to view its content) then select
speech note.
4
Press
OK
or press the [Menu] key then select
Play
.
Brit01_EN_User guide.book Page 162 Friday, March 3, 2006 3:02 PM
163
Fun & media box
The frame folder contains all files that can be used as frame
borders on the phone and may contain pre-embedded frames
and sub-folders. The frame file type supported by your phone
is .ifm. When adding a frame to a picture, the new image is
stored as .jpg file.
Note:
It is not possible to add a frame to a video, to an
animated gif and to a Flash file.
Frames browser
The Frames browser allows you to display the stored frames
as a list or as a mosaic of frames. When the frames are
displayed as a list the screen is divided into two parts: the
frames names list and the selected frame. When they are
displayed as a mosaic (Thumbnails mode: see ’Options/My
preferences’ below) the screen contains a mosaic of frames
and the name of the selected frame.
While browsing the Frames folder the following Options list is
available (Press on the [Menu] key):
options description
View
To view the frame and its name.
Delete
To delete the current frame.
Delete all
To delete all the frames of the current
folder.
Brit01_EN_User guide.book Page 163 Friday, March 3, 2006 3:02 PM
164
Fun & media box
Note:
If the selection is a sub-folder, another Options list is
available (press on the [Menu] key).
Note:
You cannot transfer a frame out of the Frames folder
(e.g. via Bluetooth).
Note:
Error messages may be displayed when setting,
viewing or storing an image: ’File too big’ (please see "Error
messages", page 251); ’Decoding failure’: the frame cannot
be viewed by the phone.
Multiple selection
To select several frames (by pressing OK).
Press OK to unselect a ticked frame. Press
on the [Menu] key to access Delete, Move
to (a Frames sub-folder), Copy to (a
Frames sub-folder), Select all (to select all
the files of the current folder), Unselect all
(to unselect all the ticked files).
Move to
To move the current image to one of the
Frames sub-folders.
Copy to
To copy the current image in one of the
Frames sub-folders.
New folder
To create a sub-folder in the Frames folder.
Rename
To rename the current frame.
Details
To show the name, resolution, size,
storage date and protection status of the
current file.
My preferences
To sort the stored frames (by date, name,
size) and select a view mode (List,
Thumbnails 4 to display a 4-frame mosaic)
to change the Frames browser mode.
options description
Brit01_EN_User guide.book Page 164 Friday, March 3, 2006 3:02 PM
165
Fun & media box
Viewing a frame:
An Options menu is available (press the [Menu] key).
1
Press the [Menu] key. Select
Fun & Media box
.
2
Select
Frames
.
3
Scroll the frames list or mosaic. Select the required frame
or select
a folder
to view its content (press
OK
).
4
Press
OK
or press on the [Menu] key then
View
to view
the selected frame in full size.
options description
Full view
To view the frame in full screen.
Delete
To delete the current picture
.
Slide show
To automatically display all the frames of
the selected folder one after another.
Details
To show the name, resolution, size,
storage date and protection status of the
current file.
Brit01_EN_User guide.book Page 165 Friday, March 3, 2006 3:02 PM
166
Fun & media box
Adding a frame to your picture
This feature allows you to add a frame to your preview before
capturing an image. According to the selected frame, you may
need to use your phone horizontally or vertically in order to
make the preview screen content fit your frame.
Note:
The new picture is stored in the Pictures folder as a .jpg
file.
Note:
When capturing a picture, the preview size is
automatically adapted to the selected frame size. Modifying
the preview size removes the frame.
1
From the idle screen, press the [Menu] key. Select
Camera & Video
and select
Capture a Photo
.
2
Press on the [Menu] key then select
Frames
. The frames
list or mosaic is displayed.
3
Scroll down the frames list or mosaic. Select the
required frame or select a folder then select the required
frame. A preview with the selected frame over your
preview is displayed so that you can define your picture
settings and view the final result.
4
Press
OK
to confirm your selection.
5
Press
OK
to capture your picture.
Brit01_EN_User guide.book Page 166 Friday, March 3, 2006 3:02 PM
167
Fun & media box
Adding a frame to a stored picture
This feature allows your to add a frame to a stored image.
Note:
The new picture is stored in the Pictures folder as a .jpg
file. In case of format conversion the quality of the new
picture is not guaranteed.
Note:
The picture size is adapted to the frame size.
Note:
If the source picture is protected by a copyright, you
may not be allowed to add a frame to this picture.
1
Press the [Menu] key. Select
Fun & Media box
.
2
Select
Pictures
.
3
Scroll down the Pictures list or mosaic. Select the
required picture or select a folder
then select the
required picture.
4
Press on the [Menu] key then select
Add frame
. The
frames list or mosaic is displayed.
5
Scroll down the frames list or mosaic. Select the
required frame or select a folder then select the required
frame. A preview screen with the selected frame over
the current picture is displayed so that you can view the
final result.
6
Press
OK
to confirm your selection. The new picture and
its name are displayed.
7
Press on the [Menu] key then select
Store
to save the
new picture.
Brit01_EN_User guide.book Page 167 Friday, March 3, 2006 3:02 PM
168
Fun & media box
Frames receiving
You can receive frames via the i-mode browser (please see
"Quick access to i-mode basic features", page 212). But it is not
possible to send or to transfer a frame to a folder other than
the Frames folder or to another device (a PC, etc.). The frames
you received via the i-mode browser are automatically stored
in the Frames folder. If you receive frames by Bluetooth, the
files are stored in the Fun & Media Box Others folder, but you
will not be able to read them as your phone does not support
any other Frame downloading than via the i-mode.
Note:
When you download frames whose format is not
accepted by the phone, these frames are not stored in
the phone
Others
This menu allows you to store/view/play vCard files (Phone
book), vCalendar files (Diary cards), vbookmarks (Web
bookmarks), text files and files with unknown/unsupported
format.
To display the others file contents:
Note:
The contents of this Options list may vary according to
the file type.
1
Press The [Menu] key.
Select
Fun & Media box
.
2
Select
Others
.
3
Use the [Up arrow] and [Down arrow] keys to select the
required file.
Brit01_EN_User guide.book Page 168 Friday, March 3, 2006 3:02 PM
169
Fun & media box
Note:
You cannot send any copyright protected file (the ’File
protected’ message is displayed on any attempt to send
copyright protected files).
The following Options list is available:
options description
View
To view the file contents.
Store
To store the selected file in the
corresponding application folder.
Send by...
To send the text, the vBookmark(s) and the
unknown file(s) via Bluetooth.
To send the current vCard or vCalendar via
Bluetooth, by SMS, by MMS or by Mail.
Delete
To delete the current file.
Delete all
To delete all the files of the current folder.
Multiple selection
To select several files (by pressing OK).
Press OK to unselect a ticked file. Press on
the [Menu] key to access Send by...
(Bluetooth), Delete, Move to (a folder of
Others or the Memory Card), Copy to (a
folder of Others or the Memory Card),
Select all (to select all the files of the
current folder), Unselect all (to unselect all
the selected files)
Move to
To move the selected file to the Memory
Card or to an Others sub-folder.
Copy to
To copy the selected file to the Memory
Card an Others sub-folder.
Brit01_EN_User guide.book Page 169 Friday, March 3, 2006 3:02 PM
170
Fun & media box
Note:
You can only access the Memory Card storage space if
the microSD™ Card is inserted in the phone.
Data exchange
The purpose of this feature is to allow the easy transfer of
vCards, vCalendars, Bookmarks... vCards and vCalendars are
Phone book cards and diary cards that are sent or received to/
from another device (phone, pc,...).
Storing a received vCard:
Note:
A received file may contain several vCards. Select the
one(s) you want to keep, then select Store.
New folder
To create a new folder in the Others folder
(only available if the selected file is not a
folder already).
Rename
To rename the selected file.
Details
To view the current file name, size, storage
date and file protection status information.
My preferences
To sort the stored files (by date, name,
size).
1
Press on the [Menu] key when you have received the
file.
2
Select
View
.
3
The received file is displayed. Select
Store
.
4
Select
Phone names
,
SIM names
,
SIM fixed
or
My card
. The
vCard is then stored.
options description
Brit01_EN_User guide.book Page 170 Friday, March 3, 2006 3:02 PM
171
Fun & media box
Storing a received vCalendar:
Note:
A received file may contain several vCalendars. Select
the one(s) you want to keep, then select Store.
Storing a received vBookmark:
Note:
A received file may contain several vBookmarks. Select
the one(s) you want to keep, then select Store.
Sending a vCard or a vCalendar by SMS:
1
Press on the [Menu] key when you have received the
file.
2
Select
View
.
3
The received file is displayed. Select
Store
. The
vCalendar is then stored in the diary.
1
Press on the [Menu] key when you have received the
file.
2
Select
View
.
3
The received file is displayed. Select
Store
. The
vCalendar is then stored in the bookmarks.
1
Select the vCard (please see "Export", page 115) or the
vCalendar (please see "Sending an event/a task", page
41) you wish to transfer.
2
Press on the [Menu] key.
3
Select
Send by...
then
SMS
. A warning may be displayed
regarding the number of required SMS to send the card
(where more than one SMS is required).
4
Select
OK
if you wish to continue.
5
Enter the number to which you want to send the vCard
or the vCalendar, or select a name from the
Names
list.
Brit01_EN_User guide.book Page 171 Friday, March 3, 2006 3:02 PM
172
Fun & media box
To access other files stored on your
Memory Card
You can store or view other file types that are stored on your
Memory Card. The Options lists are the same as in the Others
sub-menu.
Storage used
To consult the percentage of memory used for the Pictures,
Melodies, MP3, Videos, Frames, Speech note and Others
folders:
1
Press the [Menu] key. Select
Fun & Media box
.
2
Select
Others
, then
Memory card
(this item is only
displayed when a microSD™ Card is inserted).
3
Scroll up or down to select the required file or choose
the required folder (press
OK
to view its content) then
select a file.
4
Select press the [Menu] key then select
View
.
1
Press the [Menu] key.
Select
Fun & Media box
.
2
Select
Storage used
. The total memory used is displayed
(all file types). Select
Details
to view storage information
per file type.
3
Use the [Up arrow] and [Down arrow] keys to scroll to
the required information type (Pictures, Melodies, MP3,
Videos, Frames, Speech note, Others).
Brit01_EN_User guide.book Page 172 Friday, March 3, 2006 3:02 PM
173
Fun & media box
Note:
The Fun & Media box space is managed as a single
folder. The Pictures, Melodies, Videos, Frames, Others and
Speech note files therefore share the same space in the
phone.
Note:
You may not be able to store more files. You can
however remove pictures, for instance, to free some space
and create a new Speech note.
Note:
If the memory card is inserted, information about its
memory used is also displayed.
Brit01_EN_User guide.book Page 173 Friday, March 3, 2006 3:02 PM
174
Memory card
MEMORY CARD
The Memory Card is an accessory which allows you to store
files if you need extra storage space, if you do not wish to
store files on your phone, if you wish to exchange files with
other devices (e.g. a phone or a PC). You can also use it to
store files to be viewed or played on another device. Your
Memory Card is a storage space which can support all format
types.
You can therefore store files such as Phone book cards,
Pictures, Melodies, Videos, etc. The file types that can be
viewed from a Memory Card must be supported by your
phone (e.g: .3gp video files). If your Memory Card contains
files whose formats are not recognized by the phone you will
not be allowed to read them.
The Memory Card to be used with your phone is of microSD™
Card type.
The Memory Card may not be supplied with your phone.
Please contact your retailer.
The XXXX mobile phone was designed to be used with a
microSD™ card or a Transflash card type. Any attempt to
use another Memory Card type may damage the phone and
be hazardous. Damage resulting from such use shall not be
covered by our guarantee.
Brit01_EN_User guide.book Page 174 Friday, March 3, 2006 3:02 PM
175
Memory card
Handling and storage precautions
•
Keep out of reach of children. If swallowed, seek
medical advice immediately.
•
This card is formatted to the SD memory card standard.
If reformatting is ever necessary, format it using SD
compatible equipment or SD formatting software.
Formatting the card with any other software will make
the card nonstandard and cause problems with
compatibility and performance.
•
After removing the card from equipment, immediately
store it in its case.
•
Do not disassemble or remodel.
•
Do not impact, bend, drop, or wet.
•
Do not touch the metal terminals with your hands or
metal objects.
•
Do not attach other labels or stickers.
•
Do not use or store in locations that may be affected by
static electricity or electrical noise.
•
Do not use or store in locations directly exposed to
sunlight, a heat vent, or a heating appliance.
•
Do not use or store in humid or dusty locations or in
locations exposed to corrosive gases.
Protecting your data
•
Use an oil-based felt pen to write on the card. Do not use
pencils or ballpoint pens as these can damage the card
Brit01_EN_User guide.book Page 175 Friday, March 3, 2006 3:02 PM
176
Memory card
or data on the card. Take care to keep the metal
terminals free from ink.
•
While data is being read or written, do not remove the
card or turn off any equipment using the card. Do not
remove the batteries from battery-operated equipment.
These actions can cause data to be destroyed.
•
Make backup copies of your data wherever possible.
How to insert/extract your
Memory Card
The Memory Card must be formatted in your phone before
its first use (please see "How to configure your Memory
Card", page 178). If the formatting is done via another
device (e.g. a PC) you may not be able to use your Memory
Card on your XXXXXXX.
2
1
Brit01_EN_User guide.book Page 176 Friday, March 3, 2006 3:02 PM
177
Memory card
How to access the Memory Card
contents
You can access the files that are stored on your Memory Card
via the sub-folders of the Fun & Media box application
(Pictures, Melodies, MP3, Videos, Speech notes, Others).
To view the files that are stored on a Memory Card, please
follow the standard process described for each of the
corresponding sub-folders.
Note:
The Memory Card item is only available in the Fun &
Media box sub-folders if it is inserted in the phone.
To access pictures
See "To access images stored on your Memory Card", page
148
To access melodies
See "To access melodies stored on your Memory Card", page
152
To access videos
See "To access images stored on your Memory Card", page
148
To access speech notes
See "To access speech notes stored on your Memory Card",
page 162
Brit01_EN_User guide.book Page 177 Friday, March 3, 2006 3:02 PM
178
Memory card
To access other files
See "To access other files stored on your Memory Card", page
172
Note:
You cannot view the contents of the Memory Card if
the card is locked. A warning message is displayed (’Memory
card is locked’).
Note:
When using your Memory Card with your PC, you can
access a folder list corresponding to the Fun & Media box
sub-folders (Pictures, Melodies, MP3, Videos, Speech notes,
Others). We advise you put each file in the corresponding
folder otherwise it may not be read by the phone.
Note:
Some files you created on your Memory Card
via other
devices may not be accessible by the phone.
Note:
You are not allowed to transfer or to copy protected
files from your phone to your Memory Card or other devices.
How to configure your Memory
Card
The Memory Card must be formatted in your phone before its
first use
1
Insert the Memory Card in the phone.
2
The ’Format card’ screen is displayed. Select
Yes
to
format your Memory Card. If you select
No
, your
Memory Card is not formatted and cannot be used with
your phone.
Brit01_EN_User guide.book Page 178 Friday, March 3, 2006 3:02 PM
179
Memory card
Note:
The first time you use your Memory Card, do not format
it via another device (e.g. your PC).
Note:
Formatting your Memory Card deletes all the files on it.
Note:
Removing your Memory Card during the formatting
process can damage it.
You can also format your Memory Card via the Settings menu.
Formatting your Memory Card deletes all the files on it. Do not
forget to back up or transfer your files on your internal phone
memory or on another device before going over the formatting
process.
Note:
Removing your Memory Card during the formatting
process could damage it.
1
Insert the Memory Card in the phone.
2
From the idle screen, press the [Menu] key.
Select
Settings
.
3
Select
Memory card
.
4
Select
Format card
.
5
Select
Yes
then press
OK
to launch the Memory Card
formatting. An information screen is displayed during the
process.
Brit01_EN_User guide.book Page 179 Friday, March 3, 2006 3:02 PM
180
Memory card
Storage used
To check the remaining storage space on a Memory Card:
1
Insert the Memory Card.
2
From the idle screen, press the [Menu] key.
Select
Fun &
Mediabox
.
3
Select
Storage used
. The total phone memory used is
displayed (all file types).
4
Use the [Up] and [Down arrow] keys to scroll to the
required information type (
Memory card
).
Brit01_EN_User guide.book Page 180 Friday, March 3, 2006 3:02 PM
181
Calendar
Calendar
The availability of this menu is network dependent. If your
SIM card does not contain an access to the Network services,
the Calendar menu is accessible from the Menu icons.
Please see "Calendar", page 35 for full details.
Network services
The availability of this menu is network dependent (it may not
be available or be named Network services, Network,...).
Your network operator may provide value added services,
information and contact phone numbers. These services
and phone numbers are stored in your SIM card and
appear on the phone menu as they are accessible from
the
Network serv.
menu. Please contact your service
provider for further details.
Some operators may provide up to two services on the same
SIM card.
The displayed sub-menus in the
Network serv.
menu may then
be named
Applications, Services
or
Information
.
Three kinds of services can be registered in this menu:
Brit01_EN_User guide.book Page 181 Friday, March 3, 2006 3:02 PM
182
Network services
SIM application tool kit
An automatic way to provide services related to your
network. These services are SIM card dependent.
SND numbers stored in the SIM card
Up to 32 numbers may be stored in the SIM. These numbers
cannot be modified or deleted.
Information numbers
A list or a menu allowing calls to network or information
services offered by the network.
Brit01_EN_User guide.book Page 182 Friday, March 3, 2006 3:02 PM
183
i-mode™
i-mode™
NetFront is a trademark and registered trademark of Access Co. Ltd.
in Japan and other countries.
Copyright © 1996-2004 ACCESS CO. LTD.
i-mode and the i-mode logo are registered trademarks of NTT DoComo inc. in Japan
and other countries.
Your phone allows you to access dedicated i-mode web sites
and webpages thanks to the i-mode standards. You can for
instance send and receive e-mails and MMS, connect to i-
mode sites and download images, videos, frames and 64 tone
melodies for your phone (see "Fun & media box", page 138).
Access to the i-mode is network dependent. Please contact
your service provider for full details about subscription
conditions. To be able to use the i-mode features on your
phone, you must have a GPRS subscription.
User interface
Whilst navigating the i-mode menu, please note that the [Up
arrow], [Down arrow], [Left arrow] and [Right arrow] keys allow
you to access further settings or fields to be filled in, as well as
validation and cancellation options (OK, Cancel, Send, Save,
etc.).
Scroll up or down to highlight (blue highlighting) the correct
field, select an option or enter text. Depending on the menu
you are in, you may have to scroll down many times until you
reach the correct option.
Brit01_EN_User guide.book Page 183 Friday, March 3, 2006 3:02 PM
184
i-mode™
While browsing i-mode features, you can access Options
menus by pressing the [Menu] key. These Options menus
are operator dependent
i-mode menu
This section describes access to the i-mode lock, i-mode
profiles and New mail alert.
To access these features:
1
Press the [Menu] key.
Select
i-mode
.
[ Right] soft key
To Ex it the cu rrent m enu.
Navigation key
To scroll Up, Down, Right or
Left according to the context.
[Menu] key
To access the Options menu
when is shown on the display.
Alphanumeric keys
Press the 1 to 9 keys to access
the requiered menu.
Brit01_EN_User guide.book Page 184 Friday, March 3, 2006 3:02 PM
185
i-mode™
i-mode lock
The purpose of this feature is to lock access to all i-mode
features, thereby protecting your phone from any unauthorised
operation.
Note:
The default i-mode lock code is 0000. To change the
code, select
Change lock code
instead of
Lock
and follow the
instructions displayed.
Note:
Mail and MMS reception is not affected by the i-mode
lock. However it does not allow you to read the e-mails and
MMS received.
i-mode profiles
To use the i-mode and connect to i-mode webpage, you must
first define and store the profile details, then select the
required i-mode profile (a default profile is generally provided
by your operator).
Note:
Select
View
to view the profile details, or select
Delete
to erase the current profile.
1
Press the [Menu] key.
Select
i-mode
.
2
Select
i-mode lock
.
3
Select
Lock
.
4
Enter your 4 digit i-mode lock code and select
OK
.
1
Press the [Menu] key.
Select
i-mode
.
2
Select
i-mode profiles
.
3
Select one of the available profiles and press on the
[Menu] key.
4
Choose
Select
.
Brit01_EN_User guide.book Page 185 Friday, March 3, 2006 3:02 PM
186
i-mode™
New mail alert
This sub-menu allows you to define and activate the alert
melody that is played on new incoming mail or MMS.
To select a melody:
Note:
The Alert field must be set to On to allow access to the
melodies list.
Note:
If Alert is set to Off, the New mail icon only is displayed
on receipt of a new mail.
i-mode applications
The i-mode applications menu allows access to the main i-
mode features. To access it:
i-Menu
You can access i-mode services via this sub-menu. The
content of this sub-menu is operator dependent
1
Press the [Menu] key.
Select
i-mode
.
2
Select
New mail alert
.
3
Select
Alert
and select
On
.
4
Select
Melody
and select one of the available files from
the
Melodies
,
MP3
,
Video
or
Speech notes
folders.
5
Select
Save
to store the settings.
1
From the idle screen,
select
i-mode
([Right] softkey).
Brit01_EN_User guide.book Page 186 Friday, March 3, 2006 3:02 PM
187
i-mode™
Whilst browsing an i-mode site (see "Go to Webpage", page
189, "Saved Pages", page 190), press the [Menu] key to access
the following options:
options description
Browser 1/3
1. Add Bookmark
To select the current page as a bookmark.
2. Save Page
To store the current page.
3. Save Image
To store the displayed image in the
Pictures folder.
4. Show Properties
To display information menus.
5. Bookmark List
To display the registered bookmarks list.
6. Go to Webpage
To enter a webpage address or select one
from a list (see "Go to Webpage", page 189
).
7. Saved Page List
To browse registered i-mode pages
without connecting to the Web.
Browser 2/3
1. Browser
Settings
To optimise the use of i-mode and the way
information is displayed (please see
"Setting your i-mode features", page 191).
2. i-Menu
To display the i-mode site.
3. Home
To display the Home page.
4. Reload
To refresh the page displayed.
5. Compose Mail
To send the current page via Mail or MMS.
6. Save in
Phonebook
To save the address in the phone book.
7. Play Animation
To play back the Flash file animation.
Browser 3/3
1. Sound Effect
To set sound effects for Flash files.
Brit01_EN_User guide.book Page 187 Friday, March 3, 2006 3:02 PM
188
i-mode™
Note:
The items on this options list may not all be availabe
according to the contents of the page displayed.
Mail
This sub-menu allows you to edit and send mail/MMS. Please
see "Mail system", page 196.
Java
This sub-menu allows you to launch Java™ applications.
Please see "Games & applications", page 156.
SMS
This sub-menu allows you access SMS menu. Please see
"Messages/Text editing", page 56.
Bookmarks
You can view the list of the saved bookmarks without having
to connect to the i-mode.
Scroll down to the required page name, then press the [Menu]
key to access the following options:
1
From the idle screen
select
i-mode
.
2
Select
Bookmark
or press .
options description
Bookmarks 1/2
1. Go To
To go to the selected web site address.
2. Title
To modify the selected URL address.
3. Delete
To delete the current bookmark.
Brit01_EN_User guide.book Page 188 Friday, March 3, 2006 3:02 PM
189
i-mode™
Go to Webpage
You can go to a specific webpage by entering the page
address or selecting it from the Address history list.
To go to a specific page:
To go back to the latest browsed page:
4. Selective Delete
To make a multiple selection and delete
several bookmarks.
5. Delete all
To delete all the bookmarks from the list.
6. Show Address
To display the current bookmark URL
address.
7. Copy Address
To copy the current bookmark URL
address.
Bookmards 2/2
1. Compose Mail
To write a mail or an MMS and attach the
current bookmark.
2. Send by
Bluetooth
To send the current bookmark URL
address by Bluetooth.
1
From the idle screen
select
i-mode
.
2
Select
Go to webpage
or press .
3
Select
Input address
and press
OK
or press then enter
the required webpage address.
4
Press
OK
to confirm connection.
1
From the idle screen
select
i-mode
.
2
Select
Go to webpage
or press .
3
Select
Last address
and press
OK
or press . The
contents of the latest browsed page is displayed.
options description
Brit01_EN_User guide.book Page 189 Friday, March 3, 2006 3:02 PM
190
i-mode™
To go back to a page you have previously visited:
Saved Pages
You can view pages that you have previously saved without
having to connect to the i-mode.
Scroll down to the required page name, then press the [Menu]
key to access the following options:
Browser Settings
Please see "Setting your i-mode features", page 191.
1
From the idle screen
select
i-mode
.
2
Select
Go to webpage
or press .
3
Select
Past input
or press .
4
Scroll to the required page address and select
OK
to
display it.
1
From the idle screen
select
i-mode
.
2
Select
Saved pages
or press .
options description
1. Show
To display the selected saved page.
2. Edit Title
To modify the selected page name.
3. Delete
To delete the selected saved page.
4. Selective Delete
To make a multiple selection and delete
several saved pages.
5. Delete all
To delete all the saved pages.
6. Show Address
To display the URL address of the saved
page.
7. Protect On/Off
To protect/unprotect the selected saved
page from deletion.
Brit01_EN_User guide.book Page 190 Friday, March 3, 2006 3:02 PM
191
i-mode™
This sub-menu allows you to customise your connection
settings.
Setting your i-mode features
To optimise use of the i-mode and the way information is
displayed on your phone whilst in connection you may wish to
adjust a few settings.
For each of the following settings:
Select the required setting type, then go through the following
instructions. When you have validated your setting the phone
automatically reverts to the Settings menu.
Home
To activate/deactivate the home page display:
To change the home page URL address:
1
From the idle screen
select
i-mode
.
2
Select
Browser Settings
or press .
1
Select
Home
or press .
2
Select
Enable
or
Disable
.
3
Scroll down as many times as necessary until is
highlighted and press
OK
to validate.
1
Select
Home
or press .
2
Scroll to the edition area and press
OK
. Type in the
required URL address.
3
Scroll down as many times as necessary until is
highlighted and press
OK
to validate.
Brit01_EN_User guide.book Page 191 Friday, March 3, 2006 3:02 PM
192
i-mode™
View
To define the way the information (text, images, web page
contents) is displayed on the phone screen.
Font size:
To define the characters size.
Images:
This allows you to choose whether or not your phone can
download and therefore display the images contained on the
webpages.
1
Select
View
or press .
2
Select
Font size
, then select
Normal
or
Large
.
3
Scroll down as many times as necessary until is
highlighted and press
OK
to validate.
1
Select
View
or press .
2
Select
Images
, then select
On
or
Off
.
3
Scroll down as many times as necessary until is
highlighted and press
OK
to validate.
Brit01_EN_User guide.book Page 192 Friday, March 3, 2006 3:02 PM
193
i-mode™
Table layout:
To set the way tables and their contents should be
displayed.
Wrap text:
The text on webpages may not automatically fit the size
of your phone display. This setting allows you to wrap
the text and adjust it so that it fits the screen of your
phone
.
CSS
To allow/forbid CSS (Cascading Style Sheets) if required by the
i-mode content provider.
1
Select
View
or press .
2
Select
Table layout
.
3
Select
Just fit
(to reduce the table width so that it can be
displayed within the screen width) or
Smart fit
(to display
the full table width on several lines if the table is larger
than allowed on your phone).
4
Scroll down as many times as necessary until is
highlighted and press
OK
to validate.
1
Select
View
or press .
2
Select
Wrap text
, then select
On
or
Off
.
3
Scroll down as many times as necessary until is
highlighted and press
OK
to validate.
1
Select
View
or press .
2
Select
CSS
, then select
On
or
Off
.
3
Scroll down as many times as necessary until is
highlighted and press
OK
to validate.
Brit01_EN_User guide.book Page 193 Friday, March 3, 2006 3:02 PM
194
i-mode™
Screen Scroll:
To display the number of lines to be scrolled on each [Down
arrow] key press when reading a page.
Certificates
Certificates are used for network security exchange (e.g. for
secure payment transactions).
Scroll down to the required certificates, then press the [Menu]
key to access the following options:
Others
To set the Response timeout, allow or forbid the sending of
terminal information and activate or deactivate the melody/
video autoplay or the automatic display of an image.
1
Select
View
or press .
2
Select Screen Scroll, then select
1 line
,
3 lines
or
5 lines
.
3
Scroll down as many times as necessary until is
highlighted and press
OK
to validate.
1
Select
Certificates
or press .
2
Select one of the displayed certificates to view its
contents.
3
Press
Exit
to return to the certificates list.
options description
1. Certificate Info
To display the certificate details.
2. Valid/Invalid
To enable/disable the selected certificate.
1
Select
Others
or press .
Brit01_EN_User guide.book Page 194 Friday, March 3, 2006 3:02 PM
195
i-mode™
Check settings
You can check the status or values of all your settings via this
menu.
items description
1. Response
timeout
To set the time limit for i-mode
disconnection when there is no response
from the network.
Select
60 seconds
,
90 seconds
or
Disabled
(if
you do not want automatic disconnection).
2. Send term. info
To display or not a confirmation screen
before sending of phone-related
information (linked to the i-mode) to the
server.
Select
On
or
Off
.
3. Auto Play
You can choose whether or not a melody
or a video should be automatically played
or an image should be automatically
shown after downloading.
Select
On
or
Off
.
4. Sound effect
To set sound effects for Flash files.
Select
On
or
Off
.
2
Scroll down as many times as necessary until is
highlighted and press
OK
to validate.
1
Select
Check Settings
or press to view the contents of
each parameter.
Brit01_EN_User guide.book Page 195 Friday, March 3, 2006 3:02 PM
196
i-mode™
Reset settings
You can reset all the settings and get back to the default
configuration.
Whilst adjusting or modifying one of the above features,
selecting allows you to go back to the Settings sub-
menu and selecting i-mode allows you to go back to the i-
mode main menu.
Whilst in the Settings menu, select Exit to return to the i-mode
main menu.
Reset data
You can reset the Bookmarks list, the Saved pages list, the
Last address, Input address and Past input lists.
Mail system
Your phone allows you to send and receive mails and MMS.
However the availability of these features is operator
dependent. Please read the following instructions to
configure your mail system and use the Mail menu.
You can access the i-mode Mail sub-menu in two ways:
1
Select
Reset Settings
or press then confirm by
selecting
Yes
.
1
Select
Reset Data
or press then confirm by selecting
Yes
.
1
From the idle screen select
Mail
.
Brit01_EN_User guide.book Page 196 Friday, March 3, 2006 3:02 PM
197
i-mode™
or:
Note:
The contents of the Mail menu may vary according to
your service provider.
Note:
The total attachment size cannot exceed 300KB.
However this value may vary according to your operator.
Once in the Mail sub-menu:
Composing an iMail
1
From the idle screen
select
i-mode
.
2
Select
Mail
or press .
1
Select
Compose imail
or press .
2
Highlight the first field (Address field). Press
OK
, select
the required name or press
New
to enter ithe required
address. You can also press the [Menu] key to enter a
new address or access another folder. Press
OK
.
3
Highlight the second
field (Subject field). Press
OK
to enter
in the edition screen and type the required text in or press
on the [Menu] key to get to the usual edition options list.
Press
OK
.
Brit01_EN_User guide.book Page 197 Friday, March 3, 2006 3:02 PM
198
i-mode™
Note:
The content of this page and the information to be
entered is operator dependent.
Note:
The maximum content of the mail is 300 KB provided
there is no header, no signature and no attached file. Each
additional text or file uses the available memory space and
reduces the maximum content of the message text.
Whilst writing your mail, you can access the Options menu at any
time by pressing the [Menu] key.
4
Highlight the attachment field if you want to add a file
(picture, melody, video, etc.) to your message. Press
OK
then select
Attach File
. Select
Pictures
,
Melodies
,
Speech
notes
,
Videos
,
Phonebook card
or
Diary
and select one of
the available files. You can also select
Attach Melody
or
Attach Bookmark
and select the required melody or
bookmark.
Press
OK
.
5
Highlight the text field. Press
OK
and type in the mail text
(maximum 10KB). Press
OK
.
6
Scroll down as many times as necessary to highlight
(to send your message) or
(to store your
message in the
Draft
folder) and select
OK
to validate
your choice.
options description
Composer Menu 1/2
1. Send
To send your mail.
2. Save
To store your mail in the Draft folder.
3. Add address
To add (an) addressee(s).
Brit01_EN_User guide.book Page 198 Friday, March 3, 2006 3:02 PM
199
i-mode™
Note:
The items on this options list may vary according to the
contents of the page displayed.
Note:
You can send your mail to a maximum of 5 people (To +
Cc + Bcc).
4. Address menu
To display the Address operation
submenu. This sub-menu bears the
following options: Open Phonebook,
Change to To (to change the selected
addressee to Main addressee), Change to
CC (to change the selected addressee to
Secondary addressee), Change to Bcc (to
change the selected addressee to Hidden
addressee)
,
Delete address.
5. Attach file menu
To display the file attachment submenu, if
the maximum attachment size was not
reached. This sub-menu bears the
following options: Attach File, Attach
Melody, Attach Bookmard, Delete Attach
File and Play/Display File.
6. Attach
Signature
To attach a pre-entered signature (please
make sure you have previously written and
stored one. See "Communication", page
211).
7. Delete Body
To delete the contents of the message
field.
Composer Menu 2/2
1. Delete Mail
To delete the contents of the whole mail.
options description
Brit01_EN_User guide.book Page 199 Friday, March 3, 2006 3:02 PM
200
i-mode™
Composing an iMMS
The Multimedia Messaging Service (MMS) is a service that
allows you to send and receive messages to and from other
MMS enabled mobile phones. An MMS contain several slides
composed of text + image and/or melody/speech note/video.
Whilst in the three first fields, you can access an Options
menu by pressing the [Menu] key.
1
Select
Compose iMMS
or press .
2
Highlight the first field (Address field). Press
OK
, select
the required name or press
New
to enter ithe required
address. You can also press the [Menu] key to enter a
new address or access another folder. Press
OK
.
3
Highlight the second field
(Subject field). Press
OK
to
enter in the edition screen and type the required text in
or Press on the [Menu] key to get to the usual edition
options list. Press
OK
.
4
Highlight the third field (Attachment field). Press
OK
then
select
Attach file
.
5
If required, select the type of file to be attached, then
select the required file.
options description
1. Send
To send your mail.
2. Save
To store your mail in the Draft folder.
3. Add address
To add (an) addressee(s).
Brit01_EN_User guide.book Page 200 Friday, March 3, 2006 3:02 PM
201
i-mode™
Note:
The items on this options list may vary according to the
contents of the page displayed.
Note:
You can send your MMS to a maximum of 5 people (To
+ Cc + Bcc)
4. Address menu
To display the Address operation
submenu. This sub-menu bears the
following options: Open Phonebook,
Change to To (to change the selected
addressee to Main addressee), Change to
CC (to change the selected addressee to
Secondary addressee), Change to Bcc (to
change the selected addressee to Hidden
addressee)
,
Delete address.
5. Attach file menu
To display the file attachment submenu, if
the maximum attachment size was not
reached. This sub-menu bears the
following options: Attach File, Attach
Melody, Attach Bookmard, Delete Attach
File and Play/Display File.
6. Delete Mail
To delete the contents of the whole mail.
6
Select
SMIL (0KB)
and press OK to reach the following
Options list:
option description
Compose menu 1/2
1. Send
To send your MMS.
2. Save
To return to the MMS edition screen and
save your MMS.
3. Preview
To preview the MMS.
options description
Brit01_EN_User guide.book Page 201 Friday, March 3, 2006 3:02 PM
202
i-mode™
Note:
The items on this options list may vary according to the
contents of the page displayed.
Media submenu:
4. Media
To display the Media sub-menu (please
see below).
5. Fit mode
To display the Fit mode sub-menu (please
see below).
6. Options
To display the Slide options list: the Slide
Timing, Text Timing, ImageTiming or Audio
Timing option is available, allowing you to
select the time each text, image or audio
file is displayed/played before switching to
the next one.
7. Arrange slide
To display the slide arrangement submenu
(please see below).
Compose menu 2/2
1. Slide
To display the slide operation submenu
(please see "Slide operation submenu:",
page 204.)
option description
Media 1/2
1. Edit Text
To write or edit text.
2. Delete Text
To delete text. This option is only available
if some text was previously written.
3. Add Image
To add an image to the slide. This is only
available if an image or a video was not
already set to the slide.
4. Delete Image
To erase the set image.
option description
Brit01_EN_User guide.book Page 202 Friday, March 3, 2006 3:02 PM
203
i-mode™
Fit mode submenu:
Slide arrangement submenu:
5. Add Audio
To add a sound file to the slide. This is only
available if a sound or a video was not
already set to the slide.
6. Delete Audio
To erase the set melody or ringtone.
7. Add Video
To add a video to the slide. This is only
available if an image or a sound file was
not already set to the slide.
Media 2/2
1. Delete Video
To delete the set video.
option description
1. Hidden
To display the image in its current size.
2. Fill
To adapt the image size to the available
image-dedicated space.
3. Meet
To adapt the longest side of the image to
the available image-dedicated space.
4. Slice
To adapt the shortest side of the image to
the available image-dedicated space.
option description
1. Text Color
To select one of the available colours for
the page text.
option description
Brit01_EN_User guide.book Page 203 Friday, March 3, 2006 3:02 PM
204
i-mode™
Slide operation submenu:
Inbox
The Inbox bears all received iMails and iMMS. These received
iMails and iMMS are displayed as a list. Folders can be created
to store these messages.
Whilst in the Inbox list, pressing the [Menu] key displays the
following Options list:
2. Background
Color
To select one of the available colours for
the page(s) background (one colour only
per message).
3. Change Region
Size
To modify the borderline location between
the text and the image area by using the
[Up arrow] and [Down arrow] keys.
4. Swap Position
To swap the text and the image locations
on the slide.
option description
1. Add
To add a new slide after the current one.
2. Insert
To add a new slide before the current one.
3. Delete
To erase the current slide. The next one is
then displayed.
4. Clear
To erase the current slide contents. The
slide is then blank.
option description
1. Create Folder
To create and name a folder.
2. Rename Folder
To change the name of the selected folder.
3. Delete Folder
To delete the selected folder
option description
Brit01_EN_User guide.book Page 204 Friday, March 3, 2006 3:02 PM
205
i-mode™
Note:
The protected and unread mails cannot be deleted.
To view the received iMails and iMMS list:
When viewing an iMail or a iMMS, pressing the [Menu] key
allows you to:
1
Select
Inbox
or press .
2
Select one of the files and scroll to the required imail or
iMMS and select
OK
to view it.
option description
1. Reply
To display the following options list: Reply,
Reply quoted (to reply and attach the text
contents of the received mail), Reply all (to
reply to the current message and send it to
all To and Cc addresses), Reply quoted all
(to reply to all the origin message To an Cc
addresses and attach the current message
contents).
2. Forward
To forward the current message.
3. Move
To move the selected message to one of
the available folders.
4. Delete
To delete the current message.
5. Protect On/Off
To protect/unprotect the current message
(this feature allows you to protect the mail
from unauthorised deletion).
6. Save in
Phonebook
To store the sender’s address in the phone
book.
7. Copy
To copy the message body, subject or
sender content.
8. Play SMIL
To play the SMIL contents (image, melody,
video, etc.) of the current iMMS.
Brit01_EN_User guide.book Page 205 Friday, March 3, 2006 3:02 PM
206
i-mode™
Note:
The items on this options list may vary according to the
contents of the page displayed.
Sent
This sub-menu allows you to view and edit sent iMails and
iMMS.
You must have saved your messages before sending them to
be able to find them in the Sent messages sub-menu.
When on the sent messages list, pressing the [Menu] key
allows you to reach:
9. Browse SMIL
To manually browse the SMIL contents of
the current iMMS.
10. Save melody
To save the melody contained in the
current imail and store it in the Melodies
folder (Fun & Media box).
11. Save attached
file
To save the attached file and store it in the
required location (Others folder if the
extension type is not recognised by the
phone).
option description
1. Edit
To edit the selected message.
2. Delete
To delete the selected message from the
list.
3. Selective delete
To make a multiple selection and delete
several messages.
4. Delete all
To delete all the selected messages
provided they are not protected.
option description
Brit01_EN_User guide.book Page 206 Friday, March 3, 2006 3:02 PM
207
i-mode™
Note:
The availability of these options may vary according to
the list contents.
To read a sent iMail or iMMS:
5. Protect On/Off
To protect/unprotect the selected
message (this feature allows you to
protect the mail from unauthorised
deletion).
6. Sort
To sort the files according to the following
criteria: Subject ascending, Subject
descending, Address ascending, Address
descending, Date ascending, Date
descending.
7. Filter
To select criteria for files display. The
following options are available: All (to
display all the folder messages in a list),
Pasted (to display only the mails that
contain pasted data), Attached (to display
only the mails that bear attached files),
iMail (to display only the mails), iMMS (to
display only the MMS), SMS (to display
only the SMS).
1
Select
Sent mail
or press .
2
Scroll to the required message and select
OK
to view it.
option description
Brit01_EN_User guide.book Page 207 Friday, March 3, 2006 3:02 PM
208
i-mode™
Whilst reading an iMail or an iMMS, pressing the [Menu] key
allows you to:
Note:
The availability of these options may vary according to
the message contents type.
Draft
The mails you have stored (see "Composing an iMail", page
197 and "Quick access to i-mode basic features", page 212) are
filed in the Draft folder.
To edit the stored mails:
option description
1. Edit
To edit the selected sent message
contents in order to re-send it.
2. Delete
To delete the current message.
3. Protect On/Off
To protect/unprotect the current message
(this feature allows you to protect the mail
from unauthorised deletion).
4. Save in
Phonebook
To save the message sender’s address.
5. Copy
To copy the message subject or body.
6. Play SMIL
To play the SMIL contents (image, melody,
video, etc.) of the current iMMS
7. Browse SMIL
To manually browse the SMIL contents of
the current iMMS.
1
Select
Draft
or press .
2
Scroll to the required mail and select
OK
to view and edit
it.
Brit01_EN_User guide.book Page 208 Friday, March 3, 2006 3:02 PM
209
i-mode™
Whilst in the Draft folder, pressing the [Menu] key allows you
to:
Check New Mail
This allows you to view new incoming mails and MMS.
Note:
Depending on your operator you may be allowed to
select whether you want All, mails only or MMS only to be
checked.
option description
1. Send
To send the selected mail.
2. Delete
To delete the selected mail.
3. Delete all
To delete all the draft mails.
4. Protect On/Off
To protect/unprotect the selected
message (this feature allows you to
protect the mail from unauthorised
deletion).
5. Sort
To sort the files by Subject, Address or by
Date.
6. Filter
To select criteria for files display. The
following options are available: All, Pasted,
Attached, iMail, iMMS, SMS (please see
the Options description above).
1
Select
Check new mail
or press .
2
The phone connects to the network and opens any new
mail(s) or MMS if any. Select
OK
to view it/them.
Brit01_EN_User guide.book Page 209 Friday, March 3, 2006 3:02 PM
210
i-mode™
Selective mail retrieval
You can retrieve pending mails and MMS from the server:
Note:
The availability of this option depends on your service
provider.
Mail Settings
Please see the "Options" section (below) for full details.
Options
This section explains how to personalize your messaging
service when sending and receiving mail.
All of these settings are accessible from the Mail settings sub-
menu
.
or:
1
Select
Selective retrieval
or press .
2
The screen is divided into 2 parts (Select retrieval and
Select delete): Select the
Display only title
or
Display detail
in the required part then select
Enter
.
Select the message(s) to be retrieved or deleted
according to its/their title or detailed contents.
1
From the idle screen, select
Mail.
2
Select
Mail Settings
or press .
1
From the idle screen
select
i-mode
.
2
Select
Mail
or press .
3
Select
Mail Settings
or press .
Brit01_EN_User guide.book Page 210 Friday, March 3, 2006 3:02 PM
211
i-mode™
Communication
This allows you to set the way you wish to receive your mails.
Edit
This allows you to edit a signature or a quotation for your e-
mails.
The signature is a text that is added (once each time
mail is sent) at the end of your message.
A quotation is a
reply symbol that is automatically added to your message body
when you reply (Reply quoted/Reply quoted all) to a received
mail. You can change this symbol and replace it by another
symbol or text.
Note:
The > symbol is the default reply marker. It is
automatically added to your reply mails.
1
Select
Communication
or press .
2
Select
Auto Receive
,
Selected Retrieval
or
Receive Attached
File
and follow the displayed instruction.
3
Scroll down until is highlighted and select
OK
to
store your settings.
1
Select
Edit
or press .
2
Select
Edit Signature
then select
Auto Attach
. Scroll to the
second field then enter the text you wish to add as your
signature.
2’
Select
Edit Quotation
then press
OK
to enter the reply
marker text or symbol(s).
3
Scroll down until is highlighted and select
OK
to
save the reply marker.
Brit01_EN_User guide.book Page 211 Friday, March 3, 2006 3:02 PM
212
i-mode™
View
You can define settings that are related to the way mails are
displayed:
Check settings
You can check the status of all your mail settings via this
menu.
Reset settings
Quick access to i-mode basic
features
This section shows you how to quickly access a few i-mode
features.
1
Select
View
or press .
2
Select one of the available settings from the list.
3
Modify the required item then scroll down as many times
as necessary until is highlighted and press
OK
to
validate.
1
Select
Check Settings
or press to view the contents of
each parameter.
1
Select
Reset Settings
or press to go back to the
Mail
main menu.
Brit01_EN_User guide.book Page 212 Friday, March 3, 2006 3:02 PM
213
i-mode™
To connect to a new i-mode site:
To access a stored address:
To bookmark a page:
To go to a bookmarked page:
1
Select
i-mode
from the idle screen.
2
Press and then .
3
Enter the site address.
4
Press
OK
. The connection is then automatically
activated.
1
Select
i-mode
from the idle screen.
2
Press .
3
Select or .
4
Select the required address.
Press
OK
. The connection is then automatically
activated.
1
Whilst visiting a webpage, press the [Menu] key to go to
the options menu.
2
Press then scroll down until is highlighted and
press
OK
to validate.The selected page URL address is
now stored in your Bookmarks list.
1
Select
i-mode
from the idle screen.
2
Press .
3
Select the required bookmark and press
OK
. The
connection is then automatically activated.
Brit01_EN_User guide.book Page 213 Friday, March 3, 2006 3:02 PM
214
i-mode™
To save a webpage:
To display a saved page:
To download a melody, a video, an image or a
frame:
You can download melodies, videos, images or frames via the
i-mode. The downloaded items are automatically stored in the
corresponding sub-folder of the Fun & Media box menu.
Note:
The maximum size for i-mode downloadable melodies,
videos, images or frames is operator dependent.
1
Whilst visiting a webpage, press the [Menu] key to go to
the options menu.
2
Press . The selected page is now stored in your Page
memo list.
1
Select
i-mode
from the idle screen.
2
Press .
3
Select the required page name and press
OK
.
1
Once on a page bearing a melody, a video, an image, or a
frame, select the required item and press
OK
to
download it.
Brit01_EN_User guide.book Page 214 Friday, March 3, 2006 3:02 PM
215
Settings
Settings
This menu allows you to adjust the features on your phone to
your own convenience and to ensure the security of the
phone.
Tones
Alert mode
You can set the ring, alert and alarm tone types via the
Mode
menu.
Note:
If you select the 'Vibrate' or 'Vibrate then ring' option, the
vibrating option replaces all the alert and alarm tones.
To modify the alert mode:
or:
Note:
If the Alert mode is set to Silent, the icon is displayed
on the idle screen.
Note:
If the Alert mode is set to Vibrate, Vibrate & ring or
Vibrate then ring, the icon is displayed on the idle screen.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Tones
.
3
Select
Mode
.
4
Select one of the available settings (
Ring
,
Silent
,
Vibrate
,
Vibrate & ring
or
Vibrate then ring
) and press
OK
to
validate.
Brit01_EN_User guide.book Page 215 Friday, March 3, 2006 3:02 PM
216
Settings
Note:
When the phone is connected to either the Desk Top
Charger, HF kit, CLA or AC adaptor, the vibrator mode
selection is temporarily inhibited and the phone rings instead
of vibrating.
Ringtone selection
You can select a melody, an MP3, a speech note or a video file
(provided it bears a sound track) from the available ring tones
stored in the phone.
Note:
When scrolling up or down in the Melodies list, wait for
a few seconds for the selected melody to be played (except
when on Silent mode).
Note:
The ‘No sound’ item may be selected to deactivate the
Welcome and Goodbye melodies.
1
From the idle screen, press the [Left arrow] key.
2
Select one of the available settings (
Ring
,
Silent
,
Vibrate
,
Vibrate & ring
or
Vibrate then ring
) and press
OK
to
validate.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Tones
.
3
Select
Ringtones
.
4
Select
Incoming call
,
Incoming call L2
,
Alarm
,
Welcome
melody
or
Goodbye melody
then
select Melodies,
Speech notes, MP3 or Videos
.
5
Scroll up or down to listen to the different ringtones.
Select one by pressing
OK
.
6
Select
Save
to store your settings.
Brit01_EN_User guide.book Page 216 Friday, March 3, 2006 3:02 PM
217
Settings
Note:
You can set a ringtone for each of your phone book
cards (please see "Setting a melody, a MP3 file, a video or a
speech note as a ringtone", page 101). This ringtone is played
on reception of an incoming call.
Volume adjustments
The ring tone, key tones, conversation, alarm tones (alarm
clock, diary alarm and low battery alarm), multimedia and Main
screen audio levels can all be individually set via the
Settings
menu:
During a call and while playing an MP3 or a video you can
adjust the conversation volume level by using the [Up] side key
and the [Down] side key.
Note:
If the ringtone volume level is set to 0, the icon is
displayed on the idle screen.
Note:
Setting the key tones to 0 deactivates the key tones.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Tones
.
3
Select
Volume
.
4
Select
Ring
,
Ramping
,
Conversation
,
Alarm
,
Multimedia
,
Keys
or
Main screen
.
5
Scroll up or down to adjust the settings. You can also use
the numeric keys to set the required audio level:
pressing sets the volume to
2
, pressing or sets
the volume to
6
or
7
, pressing sets the volume to the
minimum value (
1
for speech and
0
for all others).
6
Press
OK
to validate the setting.
7
Select
Save
to store your setting.
Brit01_EN_User guide.book Page 217 Friday, March 3, 2006 3:02 PM
218
Settings
Ramping
When activated, this feature gradually increases the incoming
ringtone to the maximum volume level if the call is not
answered after the first ring.
Display
Idle screen
You can set an image or a video as an idle screen. To select
a background image or a background video for your idle
screen:
1
Press the [Menu] key.
Select
Settings
.
2
Select
Tones
.
3
Select
Volume
.
4
Select
Ramping
.
5
Select
On
.
6
Select
Save
to store your setting.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Display
.
3
Select
Idle screen
.
4
Select
My picture
(see "Pictures", page 143) or
Videos
(see
"Video", page 138) to select one of the stored images or
videos or select one of the five available background
images.
5
Select
Save
to store your setting.
Brit01_EN_User guide.book Page 218 Friday, March 3, 2006 3:02 PM
219
Settings
Note:
You can also set your idle screen image from the
Pictures menu, via the Options menu. You can set your idle
screen video from the Videos list, via the Options menu.
Welcome screen
On switching on your phone, a Welcome screen is displayed
prior to the idle screen. This screen is a default one but it can
be customised by selecting any of the Pictures folder images
(see "Pictures", page 143).
Note:
You can also set the Welcome screen from the Pictures
and the Video menu (see "Setting a still or animated image as
an Idle screen as a Welcome screen or as a Goodbye screen
from the Pictures folder", page 147).
1
Press the [Menu] key.
Select
Settings
.
2
Select
Display
.
3
Select
Welcome screen
.
4
Select
Default
to set the default image as a Welcome
screen or select
My picture
(see "Pictures", page 143) to
select one of the stored pictures.
5
Select
Save
to store your setting.
Brit01_EN_User guide.book Page 219 Friday, March 3, 2006 3:02 PM
220
Settings
Goodbye screen
On switching off your phone, a Goodbye screen is displayed.
This screen is a default one but it can be customised by
selecting any of the Pictures folder images (see "Pictures",
page 143).
Note:
You can also set the Goodbye screen from the Pictures
menu (see "Setting a still or animated image as an Idle screen
as a Welcome screen or as a Goodbye screen from the
Pictures folder", page 147).
Backlight
To adjust the backlight for your screen:
1
Press the [Menu] key.
Select
Settings
.
2
Select
Display
.
3
Select
Goodbye screen
.
4
Select
Default
to set the default image as a Goodbye
screen or select
My picture
(see "Pictures", page 143) to
select one of the stored pictures.
5
Select
Save
to store your setting.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Display
.
3
Select
Backlight
.
4
Adjust the backlight with the [Up arrow] or [Down arrow]
keys (select a value from 1 to 3) and select
OK
.
5
Select
Save
to store the setting.
Brit01_EN_User guide.book Page 220 Friday, March 3, 2006 3:02 PM
221
Settings
Status light
To adjust your phone status light:
Keypad
Keypad lock
When the keypad lock is activated, this prevents the accidental
operation of the keys. The key tones are muted.
The keypad lock is suspended when an incoming call is
received and resumed once the call is over. Emergency calls
(112 or other official emergency number) can however be
made. If a key is pressed, a reminder message is displayed.
To activate and deactivate the automatic keypad lock:
1
Press the [Menu] key.
Select
Settings
.
2
Select
Display
.
3
Select
Status light
.
4
Select
On
or
Off
.
5
Select
Save
to store the setting.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Keypad
.
3
Select
Keypad lock
and select
Yes
.
4
When the phone is on idle state, the keypad is
automatically locked 5 seconds after the screen saver is
activated if the phone remains unused. To unlock the
keypad, press
Unlock
then the key.
Brit01_EN_User guide.book Page 221 Friday, March 3, 2006 3:02 PM
222
Settings
To activate and deactivate the manual keypad lock:
Any key answer
This feature allows you to answer a call by pressing any key
(except from the Off, No ring and Side keys)
.
Speed dial
Phone book numbers can be assigned to keys to . The
key cannot be assigned a Phone book number as it is already
assigned by default to the Voice Mail number (see "Calling the
voice mail centre to check your messages", page 228).
Numbers stored in both the SIM card and the phone
(except fixed dialling numbers) can be selected.
To assign Phone book numbers to the speed dialling keys:
1
From the idle screen, press and hold the key to
activate the keypad lock.
2
Press and hold the key to de-activate the keypad lock.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Keypad
.
3
Select
Any key answer
and select
On
.
1
Press
the [Menu] key.
Select
Settings
.
2
Select
Keypad
.
3
Select
Speed dial
.
Brit01_EN_User guide.book Page 222 Friday, March 3, 2006 3:02 PM
223
Settings
Note:
If a number which has been assigned to a speed dial
key is deleted from the Phone book, the corresponding
number is automatically deleted from the speed dial key.
To call a number using the Speed dial feature:
Phone settings
Language selection
You can change the language on your phone:
4
The Key number and the attached name (if any) are
displayed. Select
Names
(or press on the [Menu] key
then
select
Names
if a number has already been attached to
the key) to select a name from the names list.
4’
If the card bears several numbers, choose one.
5
Select
OK
to validate.
1
From the idle screen, press and hold the required to
key to launch a call.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Phone settings
.
3
Select
Language
.
4
Select a language from the list displayed and press
OK
to
validate.
Brit01_EN_User guide.book Page 223 Friday, March 3, 2006 3:02 PM
224
Settings
Auto features
Auto-answer:
This feature is only operational when the phone is connected
to a headset. The phone answers the call automatically after
about 5 seconds without the need to press a key.
Note:
This feature is inhibited if the silent mode is activated or
if the ringtone is set to 0.
Auto-retry:
This feature allows the phone to redial a number
automatically if call has failed due to an engaged line or
an unavailable signal from the network. The number is
re-dialled 10 times maximum until connection is
established.
When activated,
Retrying
and a countdown timer are displayed
prior to each new attempt. An auto-retry warning tone beeps
each time a new call attempt is made.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Phone settings
.
3
Select
Auto features
.
4
Select
Auto-answer
and select
On
.
5
Select
Save
to store your setting.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Phone settings
.
3
Select
Auto features
.
4
Select
Auto-retry
and select
On
.
5
Select
Save
to store your setting.
Brit01_EN_User guide.book Page 224 Friday, March 3, 2006 3:02 PM
225
Settings
Selecting
Exit
or pressing any key during the retry process
cancels the operation.
Auto-switch-on/off:
This feature allows the phone to switch on or off automatically
at a pre-determined time.
If the phone is already on at automatic switch-on time, it
remains on.
When the phone is about to automatically switch off, a
warning message and a countdown timer are displayed.
Selecting
Exit
cancels the switch off process.
If the phone is already off at switch-off time, it remains off.
Note:
If a call is in progress at switch-off time, the switch-off
process is postponed until the call has ended.
Time & date
This feature allows you to set the phone time according to the
world time zone map, based on Greenwich Mean Time (Origin
clock). A Secondary clock is also available. This feature is
useful for the Diary. To import or export calendar cards, events
1
Press the [Menu] key.
Select
Settings
.
2
Select
Phone settings
.
3
Select
Auto features
.
4
Select
Auto-switch-on
or
Auto-switch-off
and select
On
to
activate the feature.
5
Enter the time you want your phone to switch on and/or
to switch off and press
OK
.
6
Select
Save
to store your setting.
Brit01_EN_User guide.book Page 225 Friday, March 3, 2006 3:02 PM
226
Settings
and tasks, schedules must be set according to Time zones.
Both clocks are displayed on the screen. The date and time
and the city name are displayed for both clocks.
Clock setting:
To set the clocks:
Press on the [Menu] key to get to the following features:
1
Press the [Menu] key.
Select
Settings
.
2
Select
Phone settings
.
3
Select
Time & date
.
4
Select the
Origin clock
or press on the [Menu] key, then
choose
Edit origin
. Scroll through the panels and fill in the
required information.
5
Select
Save
to store the data.
6
Select the
Secondary clock
or press on the [Menu] key,
then choose
Edit secondary
. Scroll through the panels and
enter the required information.
7
Select
Save
to store the data.
options action
Swap clocks
To swap the Origin clock and the
Secondary clock. This feature is useful
when travelling: the secondary clock
becomes the origin/phone clock and the
origin clock becomes the secondary one.
Edit origin
To edit the origin clock panel in order to
modify its contents.
Edit secondary
To edit the secondary clock panel in order
to modify its contents.
Time format
To select a time format (12Hrs or 24Hrs).
Brit01_EN_User guide.book Page 226 Friday, March 3, 2006 3:02 PM
227
Settings
Default settings
You can reset your phone and return to your phone default
settings via the
Settings
menu. This has no effect on the Phone
book entries, the phone lock code or the i-mode lock code.
Voice mail
Your network provider may offer a Voice Mail service
which operates like an answering machine. You may be
able to access it directly by pressing and holding the .
Contact your service provider for further details.
Storing a voice mail centre number
If your SIM card does not contain the Voice Mail centre
number, you must store it manually:
Note:
The Voice Mail number is automatically assigned to speed
dial location number 1 (see "Speed dial" on page 222).
1
Press the [Menu] key.
Select
Settings
.
2
Select
Phone settings
3
Select
Default settings
.
4
Select
Yes
(The «Set default?» message is displayed)
1
Press the [Menu] key.
Select
Settings
.
2
Select
Voice Mail
.
3
Select
Number
. Enter the number (either by keying it or
pressing on the [Menu] key then selecting
Names
list).
4
Press
OK
to validate.
Brit01_EN_User guide.book Page 227 Friday, March 3, 2006 3:02 PM
228
Settings
Note:
If you subscribe to the 'Line 2' service, an additional
Voice Mail centre number must be stored separately.
Activating/deactivating the voice mail alert
tone
If you wish to be advised by a tone when receiving a new
Voice Mail message:
Note:
The availability of this feature is operator dependent.
Calling the voice mail centre to check your
messages
You can either:
•
Dial the Voice Mail centre number directly after receiving
a message:
•
or:
1
Press the [Menu] key.
Select
Settings
.
2
Select
Voice Mail
.
3
Select
Alert
. Select
On
.
1
From the idle screenidle screen, press and hold .
1Press
the [Menu] key
. Select
Settings
.
2Select
Voice Mail
.
3Select
Call
.
Brit01_EN_User guide.book Page 228 Friday, March 3, 2006 3:02 PM
229
Settings
GSM services
Call diverting
This Network dependent service allows you to divert incoming
calls (voice, fax or data calls) to another number
To divert a call:
1
Press the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Call diverting
. The following sub-menu is displayed
(the contents of this menu may vary according to your
service provider).
divert options action
Always
To divert all incoming voice calls.
When not
reachable
To divert all voice calls when the phone
cannot be reached (out of service).
On no reply
To divert all voice calls when the call is not
answered.
When busy
To divert all voice calls when the line is
engaged.
All conditions
To divert all voice calls when Not
Reachable, No Reply and When Busy.
Cancel all
To cancel all diverting options.
All FAX calls
To divert incoming fax calls unconditionally.
All DATA calls
To divert incoming data calls
unconditionally.
Brit01_EN_User guide.book Page 229 Friday, March 3, 2006 3:02 PM
230
Settings
Note:
If the 'On no reply' option is selected, please enter the
time limit (5, 15 or 30 seconds; this also depends on your
network) after which the feature will operate.
Note:
Call diverting must to be set for both Line1 and Line2.
Only the selected line is affected by the call divert.
To check the call divert status or deactivate it:
To cancel all call diverts:
Note:
This action cancels all call diverts (voice, faxes and data
calls) for the current line.
Note:
To cancel call diverts for the other line, you must select
this line first (menu Calls & Times - Line selection).
4
Select one of these options and select
OK
.
5
Select
Activate
.
6
Select
Voice Mail
(if you want the calls to be diverted to
your voice mailbox),
Names
(select one of the Phone
book entries) or
Number
(Enter the number to which the
calls are to be diverted) and select
OK
. A validation
message containing the selected number is displayed.
1
Press the [Menu] key.
Select
Settings
.
2
Select
GSM Services
. Select
Call diverting.
3
Select the call diverting type to be checked or cancelled.
4
Select
Status
or
Cancel
.
1
Press the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Call diverting
.
4
Select
Cancel all
.
Brit01_EN_User guide.book Page 230 Friday, March 3, 2006 3:02 PM
231
Settings
Call waiting
This network dependent feature allows you to receive a new
call while a call is already in progress. To activate the call
waiting feature:
Note:
You can also cancel or check the service status.
To put a call on hold and switch from Call 1 to Call 2:
1
Press
the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Call waiting
.
4
Select
Activate
.
Activated
or
Check your request
is then
displayed.
1
Whilst a call is in progress, a beep sounds to indicate a
second incoming call.
Select
Replace
to take Call 2 and end Call 1, select
Reject
to refuse Call 2 or press the Call/[Send] key to put Call 1
on hold and take Call 2.
Press the [On/Off] key to end Call 1 and press the [Call/
Send] key to take Call 2.
2
Press the [Menu] key
then select
Swap
to get back to
Call 1 and put Call 2 on hold.
Brit01_EN_User guide.book Page 231 Friday, March 3, 2006 3:02 PM
232
Settings
To set up a conference-call
You can set up a conference-call with up to 5 participants. This
option is network/subscription dependent.
During the conference-call, the following Options menu is
available:
Note:
You can set up and receive a new call during the
conference-call. In these cases the conference-call is put
on hold.
1
Whilst two calls are in progress and a new call is
received, press on the [Menu] key
then select
Join
then
press the [Call/Send] key to set up the conference-call.
Repeat the action each time a new call is received.
In compliance with European regulations, you are obliged to
inform your correspondents before recording a phone
conversation.
options description
Route to phone
To get the call back to the phone, if a
Bluetooth headset is connected.
Speaker On/Off
To activate/deactivate the hands free
mode.
Auto-DTMF
To type a new phone number and add this
new correspondent to the conference-call.
If the Auto-DTMF option is deactivated,
you cannot type in a new phone number.
Brit01_EN_User guide.book Page 232 Friday, March 3, 2006 3:02 PM
233
Settings
To end a conference-call:
Caller line identity - showing/hiding your
phone number (network dependent)
Most networks have Caller Line Identity feature (CLI). This
feature allows the phone number or the identity of the caller to
be displayed on incoming calls.
You can disable the sending of your own number on a call by
call basis by adding #31# before the number you are dialling.
You can also ask your service operator to hide your phone
phone number by default. Once hidden by your operator, you
can show your number, on a call by call basis, by entering *31#
before the number you are calling.
Private with
To have a private conversation with one of
the participants. During a private
conversation, the conference-call is put on
hold.
Hold
To put the conference-call on hold.
Retrieve
To retrieve the conference-call if it is put on
hold.
Mute/Unmute
To mute/unmute the microphone.
End one
To end one call.
End all
To end the conference-call.
Record
To record the conference-call up to 11 min.
1
Press the [On/Off] key or press on the [Menu] key then
select
End all
to end the conference-call.
options description
Brit01_EN_User guide.book Page 233 Friday, March 3, 2006 3:02 PM
234
Settings
Standard network setting:
To reset the standard network setting and send your phone ID:
Hiding or showing your number:
Viewing your current ID status:
Please contact your service provider for more information.
1
Press the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Sending my ID
.
4
Select
My settings
.
5
Select
Preset
. The phone resets and reverts to its original
network setting.
1
Press the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Sending my ID
.
4
Select
My settings
.
5
Select
Hide my ID
to prevent the phone from sending
your ID when making a call, select
Show my ID
to allow
the phone to send your ID or select
Preset
to get back to
the default factory/operator setting.
1
Press
the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Sending my ID
.
4
Select
Status
. The request is launched and an
information message displays the Sending my ID status.
Brit01_EN_User guide.book Page 234 Friday, March 3, 2006 3:02 PM
235
Settings
Receiving caller ID
Most networks have the Caller Line Identity feature (CLI). This
feature allows the phone number or the identity of the caller to
be displayed on incoming calls.
You can check the availability of this feature on your network
or subscription.
Network automatic search
When the phone is on, it automatically searches the last
network to which it was registered (usually the home
network). If it is not available, the phone automatically
searches and selects one of the networks registered in the
preferred network list (located in the SIM card).
Editing the preferred list:
Your phone contains a list of networks which can be selected
(e.g.: to suit your travel arrangements). You can also transfer
items from this list to the preferred networks list.
1
Press the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Receiving caller ID
.
The network then either returns
Presentation available
or
Presentation unavailable
information.
Brit01_EN_User guide.book Page 235 Friday, March 3, 2006 3:02 PM
236
Settings
The order and names of the networks in the preferred
networks list can be edited and amended.
Your SIM card may contain a forbidden list of networks which
cannot be used. To view this or show your home network:
1
Press the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Network
.
4
Select
Preferred list
. A list of networks is displayed.
5
Use the [Up arrow] and the [Down arrow] to select the
required network. Press
OK
to select one of the
following Options if you want to amend the list:
option description
Modify by list
To display the list of all networks stored in
the phone.
Modify by code
To edit or enter the identification operator
number if you have the information.
Delete
To delete an entry
1
Press the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Network
.
4
Select either
Forbidden
to view the list of forbidden
networks, or select
Home network
to view the name of
your usual network.
Brit01_EN_User guide.book Page 236 Friday, March 3, 2006 3:02 PM
237
Settings
Selecting manual search:
You may need to select a specific network (e.g. better
coverage than your own in the current location).
Note:
You cannot select a network for manual change if it is on
the forbidden list (even if it is still listed as a choice).
Note:
You cannot delete a network from the forbidden list.
This list is automatically updated when the manual
network selection is performed.
Note:
If the Manual search has been selected before turning
the phone off and if the manually selected network cannot be
found when the phone is next turned on, you must select
another network manually for your phone to lock on.
1
Press
the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Network
.
4
Select
Search
.
5
Select
Manual
. The
Scanning for networks...
message is
displayed.
6
Use the [Up arrow] or [Down arrow] keys to select a
network from the list.
7
Press
OK
to confirm your choice.
The
Requesting...
message is displayed, after which the
phone will return to the idle screen.
Brit01_EN_User guide.book Page 237 Friday, March 3, 2006 3:02 PM
238
Settings
Selecting automatic search:
To perform an automatic search from the preferred list,
proceed as follows:
Call barring
This network dependent service forbids certain outgoing or
incoming call types. It requires a call barring password.
To bar a call:
To remove call barring or check its status:
1
Press the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Network
.
4
Select
Search
.
5
Select
Automatic
.
1
Press the [Menu] key.
Select
Settings
.
2
Select
GSM Services
.
3
Select
Call barring
.
4
Select
Outgoing calls
(to bar All outgoing calls,
International calls or International calls excluding your
Home network) or
Incoming calls
(to bar All incoming calls
or all incoming calls while Roaming only).
5
Select
Activate
. Enter the password and press
OK
.
The network then confirms the selection.
1
Press the [Menu] key.
Select
Settings
.
Brit01_EN_User guide.book Page 238 Friday, March 3, 2006 3:02 PM
239
Settings
Call barring password:
The call barring password is used to select the call barring
levels. It is supplied via your service provider.
To change the password:
Security features
The security features described in this section protect your
phone from unauthorised use.
When prompted, enter the code and press
OK
. Codes are
displayed as asterisks (*).
Select Clear if you need to amend your entry.
Note:
Avoid using codes similar to emergency numbers
such as 112 to prevent the accidental dialling of these
numbers.
KEEP A RECORD OF YOUR CODES IN A SAFE PLACE.
2
Select
GSM Services
.
3
Select
Call barring
.
4
Scroll up or down to select the barring type to be
deactivated (
Cancel
) or checked (
Status
) and follow the
instructions displayed.
1
Press
the [Menu] key.
Select
Settings.
2
Select
GSM Services
.
3
Select
Call barring
.
4
Select
Change password
.
First enter the former password then enter the new
password twice. A Confirmation message is displayed.
Brit01_EN_User guide.book Page 239 Friday, March 3, 2006 3:02 PM
240
Settings
Phone lock code
A phone lock code is supplied with the phone for security
purposes. It prevents unauthorised access to the phone and
some of its features.
The default code is
0000
. We suggest that you change this
code and keep the new one in a safe place.
Once this feature is activated, the code is requested each time
the phone is turned on.
To change the phone lock code:
To activate/deactivate the phone lock code:
Note:
Emergency calls can still be made when phone lock is
activated.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Security
.
3
Select
Phone lock
change
and follow the instructions
displayed.
4
Press
OK
to validate the new code.
1
Press
OK
.
Select
Settings
.
2
Select
Security
.
3
Select
Phone lock enable
(if the code has been disabled)
or
Phone lock disable
(if the code has been enabled) and
enter your
Phone lock code
.
Brit01_EN_User guide.book Page 240 Friday, March 3, 2006 3:02 PM
241
Settings
PIN code
Your SIM card was provided with a 4 to 8 digit PIN code for
protection against unauthorised use. When enabled, the PIN
code is required each time you turn your phone on. If an
incorrect PIN code is entered three times in succession, your
SIM card will be blocked. The 8 digit PUK code is then required
to unblock your phone. Please contact your service provider for
this code.
To activate the PIN protection:
To change the PIN code (PIN must first be enabled):
PIN2 code
PIN2 code prevents unauthorised access to some of the
phone features (e.g. activating/deactivating FDN operations,
modifying the FDN Phone book, setting calls costs to zero,
modifying the costs display features). This code can be
changed but not be activated or deactivated.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Security
.
3
Select
PIN enable
(if the code has been disabled)
or
PIN
disable
(if the code has been enabled) and enter your
PIN
code
.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Security
.
3
Select
PIN change
and follow the information displayed.
4
Press
OK
to validate your new PIN code.
Brit01_EN_User guide.book Page 241 Friday, March 3, 2006 3:02 PM
242
Settings
Please contact your service provider for your PIN2 code. To
change the PIN2 code:
PUK code
The PUK ( ing key) is an 8 digit code supplied by your service
provider. It is used to unblock the phone when an incorrect PIN
code has been entered three times in succession. A PUK code
cannot be changed.
When prompted, enter the PUK code and select
OK
. You are
then requested to enter a new PIN code. Follow the prompts
displayed to reset the PIN code.
Note:
If you have entered an incorrect PUK code 10 times in
succession your SIM card will be permanently blocked.
Contact your service provider for a new card.
PUK2 code
The PUK2 is an 8 digit code supplied by your service provider.
It is used to unblock the phone when an incorrect PIN2 code
has been entered three times in succession. A PUK2 code
cannot be changed. When prompted, enter the PUK2 code.
Note:
If you have entered an incorrect PUK2 code 10 times in
succession for use of the features requiring the PIN2 code,
your phone will be permanently blocked. Contact your
service provider for a new card.
1
Press the [Menu] key.
Select
Settings
.
2
Select
Security
.
3
Select
PIN2 change
and follow the information displayed.
4
Press
OK
to validate your new PIN2 code.
Brit01_EN_User guide.book Page 242 Friday, March 3, 2006 3:02 PM
243
Settings
Summary of code/password entry chart:
password length number of
attempts allowed
if blocked or
forgotten
Phone lock
code
4 digits Unlimited Return phone to
manufacturer
PIN 4-8 digits 3Unblock with
PUK code
PIN2 4-8 digits 3Unblock with
PUK2 code
PUK 8 digits 10 Contact your
service provider
PUK2 8 digits 10 Contact your
service provider
Call barring
password
4 digits Defined by service
provider
Contact your
service provider
i-mode lock
code
4 digits Unlimited Return phone to
manufacturer
Brit01_EN_User guide.book Page 243 Friday, March 3, 2006 3:02 PM
244
SAR Data
Specific Absorption Rate Data
SAR Data
This model meets international guidelines for exposure
to radio waves.
Your mobile device is a radio transmitter and receiver. It is designed not to
exceed the limits for exposure to radio waves recommended by
international guidelines. These guidelines were developed by the
independent scientific organization ICNIRP and include safety margins
designed to assure the protection of all persons, regardless of age and
health.
The guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The ICNIRP SAR limit for mobiles devices used by
the general public is 2 W/kg and the highest SAR value for this device
when tested at the ear was X,XX W/kg.
1
As mobile devices offer a range of
functions, they can be used in other positions, such as on the body as
described in this user guide.
2
In this case, the highest tested SAR value is
Y,Y Y W/kg.
1
As SAR is measured utilizing the device’s highest transmitting power, the
actual SAR of this device while operating is typically below that indicated
above. This is due to automatic changes to the power level of the device to
ensure it only uses the minimum level required to reach the network.
While there may be differences between the SAR levels of various phones
and at various positions, they all meet the governmental requirements for
safe exposure. Please note that improvements to this product model could
cause differences in the SAR value for later products; in all cases, products
are designed to be within the guidelines.
The World Health Organization has stated that present scientific
information does not indicate the need for any special precautions for the
use of mobile devices. They note that if you want to reduce your exposure
Brit01_EN_User guide.book Page 244 Friday, March 3, 2006 3:02 PM
245
SAR Data
then you can do so by limiting the length of calls or using a “hands-free”
device to keep the mobile phone away from the head and body.
Additional Information can be found on the websites of the World Health
Organization (
http://www.who.int/emf
) or Motorola, Inc.
(
http://www.motorola.com/rfhealth
).
1. The tests are carried out in accordance with international guidelines for
testing. The limit incorporates a substantial margin for safety to give additional
protection for the public and to account for any variations in measurements.
Additional related information includes the Motorola testing protocol,
assessment procedure, and measurement uncertainty range for this product.
2. Please see the Safety and General Information section about body worn
operation.
Brit01_EN_User guide.book Page 245 Friday, March 3, 2006 3:02 PM
246
WHO Information
Information from the World Health
Organisation
WHO Inf ormatio n
Present scientific information does not indicate the need for any special
precautions for the use of mobile phones. If you are concerned, you may
want to limit your own or your children’s RF exposure by limiting the length
of calls or by using handsfree devices to keep mobile phones away from
your head and body.
Source: WHO Fact Sheet 193
Further information: http://www.who.int./peh-emf
Brit01_EN_User guide.book Page 246 Friday, March 3, 2006 3:02 PM
247
Appendix
Appendix
Glossary
expression meaning
AC/DC charger
Alternating Current/Direct Current charger.
Active call
The call currently in progress.
ALS
Alternate Line (Line 2) Service.
AoC
Advise of Charge - subscription service.
CB
Cell Broadcast.
CLI
Caller Line Identity - displays caller’s
telephone number.
DES
Data Encryption Standard.
Diverting
Diverts incoming calls to another number.
DTC
Desk Top Charger.
DTMF
Dual Tone Multifrequency Tones.
FDN
Fixed Dialling Number.
GSM
Global System for Mobile
communications.
http
Hyper Text Transfer Protocol
IN
Information Numbers of your operator.
IP
Internet Protocol.
LCD
Liquid Crystal Display.
MMI
Man Machine Interface.
MMS
Multimedia Messaging Service.
PIN/PIN2
Personal Identification Number. Supplied
by your network/service provider.
PPP
Point to Point Protocol.
Brit01_EN_User guide.book Page 247 Friday, March 3, 2006 3:02 PM
248
Appendix
PUK/PUK2
PIN Unblocking Key. Used to unlock PIN
and PIN2. Supplied by your network/
service provider.
QQVGA
Quarter Quarter Video Graphics Array.
Roaming (Rm)
The ability to use your telephone on
networks other than your home network.
SDN
Service Dialling Number of your operator
or service provider.
SIM
Subscriber Identity Module. Supplied by
your network/service provider.
SMS
Short Message Service.
SPN
Service Provider Name.
SR
Status Report - relates to SMS messages.
Standby mode
When the phone is on but not receiving/
making a call or menu navigating.
URL
Uniform Resource Locator.
VGA
Video Graphics Array.
Brit01_EN_User guide.book Page 248 Friday, March 3, 2006 3:02 PM
249
Appendix
Troubleshooting
problem possible cause and solution
Phone does not
switch on
Check that the battery is fully charged and
correctly connected to the phone.
Short standby and
talk times
Cell broadcast is permanently on, using
more battery power.
Phone is in a poor signal area and therefore
always on full power.
Incorrect charging and discharging. Always
charge and discharge your battery fully.
The battery is wearing out. Contact your
dealer and replace the battery.
Impossible to dial
numbers
Keypad lock is on ( appears). Press
Unlock
then select Clear to turn the keypad lock
off.
Impossible to
make or receive a
call
Check that at least one signal strength bar
( ) is displayed. Try a stronger signal
strength area.
If no network name is displayed, check
registration and area coverage with your
service/network provider and check that
the SIM is correctly inserted.
Call barring option is on. Deactivate it (see
page 238). Call cost limit is reached (see
page 88).
Stored telephone
numbers cannot
be recalled
Fixed Dialled Number or Call Barring
features are activated. Deactivate feature.
(see page 238).
Brit01_EN_User guide.book Page 249 Friday, March 3, 2006 3:02 PM
250
Appendix
The phone is on
but nothing is
displayed.
Display contrast is too low. Reset contrast
(see page 221).
No flashing
battery icon whilst
charging
There may be no mains supply. Try a
different electrical socket.
The AC/DC charger may be faulty. Return
to your dealer and try substitution with
another Motorola adaptor.
Battery icon not
flashing 1-2-3
during charging
May indicate a charge or battery problem.
Disconnect the charger. Reconnect and try
again.
May also indicate that the battery is fully
recharged and does not require any further
charging.
No charge symbol
when connecting
the charger
If the battery is totally empty the battery
level symbol may not be displayed at once
when connecting the battery charger.
Moreover the phone cannot be turned on.
Up to 15 minutes may be necessary to
reach the required 4% battery charge
to turn your phone on and allow the
battery charge symbol to be displayed.
symbol
displayed
There is not enough memory to store
another mail or another MMS. Delete one
or more of the existing stored messages.
Flashing
There is not enough memory to store
another SMS message. Delete one or
more of the existing stored messages.
Brit01_EN_User guide.book Page 250 Friday, March 3, 2006 3:02 PM
251
Appendix
Error messages
problem possible cause and solution
Allowed credit
reached!
You are trying to place an outgoing call and
the allowed credit is already reached.
The allowed credit limit is reached during
an outgoing call (the call is then aborted).
An internal error
has occurred
An error occurred in a game execution.
Busy
You are trying to make a call and the call
fails because the destination number is
already engaged in conversation.
Call failed
The user is unreachable.
The outgoing call fails due to:
the network cannot take the call because
the system is busy or
the number is out of order or
the number is unreachable or
the network does not answer or
the option to hide your phone number
when calling is not supported by the
network.
Control the ability to hide your ID when
making a call (service availability in
network).
Cancelled.
No type selected
Cell broadcast activation has been
requested but no message type has been
selected.
Brit01_EN_User guide.book Page 251 Friday, March 3, 2006 3:02 PM
252
Appendix
Cannot execute
command
You have made a request which is
impossible to execute in the current call
situation.
Can't display
message
The short message text cannot be
displayed (characters not recognised,
incorrect format etc.).
Charge error
A problem occurred during phone battery
charge process.
Check battery!
A battery problem has been detected.
Check SIM!
There is no SIM present or the SIM is
incorrectly inserted.
Check your
password
You changed the call barring password or
You changed the call barring service status.
The entered password seems to be wrong
or incorrect.
Check your
request
You made a request for a service that
seems to be unavailable.
Check your
subscription
You tried to activate a GSM service. You
are requested to check your subscription
regarding the related service rights of use/
access.
Brit01_EN_User guide.book Page 252 Friday, March 3, 2006 3:02 PM
253
Appendix
Connection failed
Connection with the server cannot be
established for one of the following
reasons:
The server is busy. Try to connect later.
The server is down. Try to connect later.
The network is not reachable. Check the
GPRS service icon is displayed in standby
mode.
Connection failure
The connection data failed.
Error!
The network cannot perform your request
and generates an error.
Failed
An SMS sending process failed (the short
message cannot be sent).
File protected
The file cannot be exported (copyright).
File too big
The file dimensions (pixels) and/or weight
(KB) are not adapted to your phone. Resize
the file (The maximum allowed file size
depends on your service provider).
Incorrect entry
You entered a character string with a
syntax error.
Invalid data
received
The received file bears invalid information
or the melody format cannot be
recognised by the phone.
Brit01_EN_User guide.book Page 253 Friday, March 3, 2006 3:02 PM
254
Appendix
Invalid number
You tried to make a call and the call is
rejected by the network because the
network does not recognise the phone
number structure.
You tried to store a phone number that
is too long to be stored in the selected
location.
You tried to move a phone entry to a
location that is unable to receive the
phone number (phone number too
long).
Low battery!
The battery is low and the phone will soon
be switched off automatically.
Network busy
You tried to make a call. The call is rejected
by the network due to congestion
problems.
Network not
allowed
When selecting network manual search,
you have selected a network that rejects
the connection.
New PIN2
incorrect.
Try again
Changing PIN2: the new PIN2 code values
differ (value control).
New PIN incorrect.
Try again
Changing PIN: the new PIN code values
differ (value control).
No connection
No connection is defined in the connection
profile.
Brit01_EN_User guide.book Page 254 Friday, March 3, 2006 3:02 PM
255
Appendix
No match!
No matching pattern has been found
between the pronounced sentence and
the recorded sentences from the voice
dialling database.
No response
You made a call to a remote user and no
response has been received.
Not allowed
Your number/character entry is not
allowed.
Not allowed fixed
dialling
A call is tried, but cancelled due to fixed
dialling control (the number dialled does
not match with one of the fixed dialling
numbers in memory).
Not enough place
in the phone
memory
Not enough place
in the SIM memory
The corresponding memory is full.
Number changed
The called number has changed.
Page has no
content
Your request was accepted by the network
but the required server page is empty.
Phone
permanently
blocked
A wrong PUK code has been entered 10
times. The phone is now permanently
blocked.
PIN blocked
A wrong PIN code has been entered 3
times.
PIN2 blocked
A wrong PIN2 code has been entered 3
times.
Brit01_EN_User guide.book Page 255 Friday, March 3, 2006 3:02 PM
256
Appendix
PUK2 blocked
A wrong PUK2 code has been entered 10
times.
The SIM services protected by the PIN2
code have now been permanently
disabled.
Reaching allowed
credit!
The cost limit is about to be reached. The
connected call ends automatically when
the limit is reached.
Ring volume Off
The ring volume is set to 0 (no volume).
Service not
available
Activating some GSM services that are not
available on the network.
SIM blocked.
Contact provider
A wrong PUK has been entered 10 times.
The SIM card has been permanently
disabled and needs to be replaced by a
new one.
SIM names Phone
book full
Phone names
Phone book full
The corresponding memory is full.
Undeletable file
The file cannot be deleted (copyright
protected).
Wrong code. Try
again
A wrong phone lock code has been
entered.
Wrong new code.
Try again
The new phone lock codes do not match
(value control).
Brit01_EN_User guide.book Page 256 Friday, March 3, 2006 3:02 PM
257
Appendix
Wrong PIN, try
again
Wrong PIN2, try
again
Wrong PUK, try
again
Wrong PUK2, try
again
The wrong code has been entered.
Wrong SIM
inserted:
phone locked
Invalid SIM
A SIM card, different from the SIM to
which the phone is usually locked, has
been inserted in the phone.
Not enough space
The corresponding memory is full or nearly
full.
Too many
applications
The number of applications in the phone
has already reached the maximum (50).
Brit01_EN_User guide.book Page 257 Friday, March 3, 2006 3:02 PM
258
Index
INDEX
A
Adjusting the preview 132
Alarm clocks 46
Alert mode 215
Answering a call 31
Any key answer 222
Audio/Video 152
Auto Switch On/Off 225
Automatic search 238
Auto-Retry 224
B
Backlight 220
Balance information 87
Battery
Charging the battery 21
Fitting the battery 20
Fitting the battery cover
21
Bluetooth
Paired devices 51
Bluetooth®
Bluetooth activation 48
Bookmark 213
Brightness 124, 133
Broadcast
Language 83
Message types 83
C
Calculator 43
Calendar 35, 181
Call
Duration 88
Recorded 91
Reminder 88
Times 86
Call barring 239
Password 238, 239, 243
Call cost
Reset 90
Call diverting 229
Call hold 231
Call management
Call costs 88
Call timer
Reset 88
Call waiting 231
Caller line identity 233
Calls & Times 85
Call costs 89, 90
Call logs 85
Call timers 86, 87, 88
Line selection 91
Camera
Adjusting a picture 122
Application 117, 126
Brightness 118, 124
Contrast 118, 124
Icons 117
Mode 123
Picture erasing 120
Picture quality 122
Picture size 122
Picture storing 120
Quality 117
Resolution 117, 122
Self timer 117, 124
Shortcuts 119
Zoom 117, 118, 123
CB 81
CB messages
Reading 82
Cell broadcast 81
Certificates 194
CLI 233
Clocks
Format 226
Origin clock 226
Secondary clock 226
Setting 226
Swap 226
Code
PIN 241
PIN2 241
PUK 242
PUK2 242
Composing an iMail 197
Contrast 124
Credit limit 89
Cropping 147
Currency converter 45
D
Data exchange 170
Diary
Calendar 36, 37
Exporting an event 41
Sending an event 41
Storage used 42
Tasks list 40
Display 32, 218
Downloaded melody 152
E
Edit quotation 211
Editing a phone book card
102
Editing a SIM name card
102
Editing a text model 75
Edition mode 63
Ending a call 32
Entering text 63
Erasing a video 132
Error messages 251
Export 115
Exporting an event/task
41
Extracting the memory
card 176
F
Figures on Menu list 28
Fixed dialling numbers
113
Frame 162
Adding 166, 167
Browser 163
Downloading 168
Viewing 165
Full screen 140
Fun & Media box 138, 143
Frame 162
Games & applications
156
Memory card 142, 148,
152
Others 168
Pictures 143
Playing a MP3 melody
155
Playing a video 140,
155
Speech notes 159
Storage used 172
Stored videos 138, 153
Video 138
G
Games & applications 156
Glossary 247
Goodbye screen 220
GPRS 25, 32
Graphic display icons 25,
28
GSM Services 229
Call diverting 229
Network 237
H
How to use your XXXX 18
I
Icons 25, 125, 135
i-mode pictographs 69
Idle screen
Welcome screen ani-
mation 143
Download 214
Quality 133
Size 132
i-mode 183
Brit01_EN_User guide.book Page 258 Friday, March 3, 2006 3:02 PM
259
Index
Applications 186
Bookmark 213
Bookmarks 188
Browser Settings 190
Certificates 194
Composing an iMail 197
Composing an iMMS
200
Draft 208
Features 191, 212
Go to webpage 189
Home 191
Icons 69
Inbox 204
Mail display 212
Menu 184
New mail alert 186
Pictographs 69
profiles 185
Reset 196
Saved page 214
Saved Pages 190
Site 213
Stored address 213
User interface 183
View 212
Webpage 214
i-mode lock 185
Information numbers 182
Infrared port
Opening 48
Inserting the memory card
176
K
Key mapping 18
Keypad 221
Keypad lock 33, 221
Keys 22
Actions 22
L
Line 1 85, 86, 87, 92, 111,
230
Line 2 85, 86, 87, 91, 111,
228, 230
Loop mode 140
M
Mail
Check new mail 209
Edit 211
Selective mail retrieval
210
Settings check 212
Mail system 196
Making a call 30
Melodies
Memory card 177
Melody 149
Download 151, 214
Memory card 152
Memory
Storage used 180
Memory card 174
Accessing 177
Configuring 178
Extracting 176
Inserting 176
Melodies 152, 177
Other files 178
Pictures 148, 177
Speech notes 177
Video 142, 177
Messages
Edition mode 63
Menu 56
Outbox 78
Reception Alert 61
Settings 62
SMS 58
Storage used 81
Text models 74, 75
Text symbols 68
Write new 75, 77
Microphone 134
Mobile number
Hiding 233
Showing 233
Modem 54
Multipress text entry 65
Multitap 66
Multitap text entry 65
My card 110
My number 111
N
Navigation key 19
Network 235
Network serv. 181
O
Outbox 78
P
Page Memo List 190
Pausing a video 132
Phone book 93
Adding a name 94, 95,
99, 100, 101, 102
Calling numbers 103
Copy 97
Copy all 97
Deleting images 100
Export 115
Fixed dialling 113, 114
Folder selection 106
Free space 108
Group 108
My numbers 111
Read 104, 105
SIM names card 95
Sorting 106
Storage used 108
Storing 94, 96
Storing phone numbers
94
Viewing & calling 103
Voice dialling 106, 107
Phone book card
Image 95
Phone card
Update 95
Phone lock 240
Code 240
Phone names card 94
Phone numbers
Storing 94
Phone settings 215
Memory card 148
Pictures 143, 218, 219
Album 144, 167
Album 2 144
Browser 143
Erasing 120
Quality 122
Size 122
Storing 120
Viewer 143
Viewer options 144
Viewing 126
Pictures list 95
PIN code 241
PIN2 code 241
Playing a video 136, 140,
155
Power saver 34
Preliminary operations 20
PUK code 242
PUK2 code 242
Q
Quick access 19
R
Ramping 218
Receiving caller ID 235
Recorded call 91
Rejecting a call 31
Reminder - call duration
88
Ring 216
Ring tone 216
Stop 32
Brit01_EN_User guide.book Page 259 Friday, March 3, 2006 3:02 PM
260
Index
S
Screen 22, 32
Goodbye screen 220
Welcome screen 219
Security 239
Features 239
Selective mail retrieval
210
Self timer 117, 124, 134
Sending an event/task 41
Sending my ID 233
Sent mail
Selective mail retrieval
210
Setting an image
Goodbye screen 147
Idle screen 147
Welcome screen 147
Settings
Any key answer 222
Auto features 224, 225
Backlight 220
Broadcast 82, 83
Contrast 221
Default settings 227
GSM Services 229
Keypad 221
Language selection 223
My picture 218, 219,
220
Phone settings 223
Screen 218
Security 240, 241, 242
Time and date 226
Tones 215, 216, 217,
218
Voice Mail 227, 228
Welcome screen 219
Shortcuts 119, 130
Show costs 90
Silent 215, 216
SIM card
Inserting 20
Update 96
SMS messages
Draft 79
Edition language 73
Forward 60
Insert 69
Move to SIM 59
Reading 58
Sending 75
Writing 63
Solutions 249, 251
Sound level 125, 135
Special characters 69
Speech notes 159
Memory card 177
Record new 160
Speed dial 222
Storage consumption 80
Storage used 42, 81, 108,
172
Storing 94
Storing a video 132
T
T9 67
T9 mode 67
Taking a picture 119
Text edition
i-mode pictographs 69
Special characters 69
Special characters, pic-
tographs 69
Text models 71
Text entry
Multipress mode 65
Multitap mode 65
T9 mode 67
Text model
Editing 75
Text writing 63
Time & date 225
Tones 215
Tools 35
Alarm clocks 46, 47
Calculator 43
Currency converter 45
Diary 36
Turning the phone Off 33
Turning the phone On 29
U
User interface 183
V
vCalendar
Sending 171
Storing 171
vCard
Sending 171
Storing 170
Vibrate 215, 216
& ring 215, 216
Then ring 215, 216
Video 128, 138
Adjusting the preview
132
Application 128
Brightness 133
Display 129
Erasing 132
Full screen 140
Image Size 132
Loop mode 140
Memory card 142, 177
Microphone 134
Pausing 132
Playback 136, 140, 155
Quality 133
Self timer 134
Shortcuts 130
Size 128
Size limit 133
Stored 138, 153
Storing 132
Zoom 133
Viewing an image 144,
165
Voice dialling
Creating a voice pattern
106
Making a call 108
Voice Mail
Activating 228
Alert 228
Alert tone 228
Call 228
Deactivating 228
Number 227
Volume
Alarm 217
Conversation 217
Key tones 217
Ramping 218
Ring 217
Volume adjustments 217
W
Webpage 189
Welcome screen 143
Writing text
Edition mode 63
Z
Zoom 117, 118, 123, 133
XXXXXXXXXX
Brit01_EN_User guide.book Page 260 Friday, March 3, 2006 3:02 PM

Navigation menu
