Motorola Mobility T6ZC1 PCS Deskset User Manual ZC EX08
Motorola Mobility LLC PCS Deskset ZC EX08
Exhibit 8 Users Manual
APPLICANT: MOTOROLA, INC. FCC ID: IHDT6ZC1
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:
FX5000 Digital
Fixed Wireless Telephone
Cover to be Designed
FX5000.book Page 1 Monday, February 14, 2000 1:24 PM
Welcome
Thank you for selecting Motorola —
a world leader in communications technology
.
All Motorola wireless phones are designed and manufactured to meet Motorola’s exacting specifications and
world class quality standards. The
FX5000 Digital
fixed wireless phone is no exception. This personal phone
withstands our rigorous durability tests including temperature, humidity, and a drop test.
• For any information about your wireless service, please call your service provider (Carrier).
Carrier’s Name
Carrier’s Phone Number
• You will need to have the following information when you inquire about your phone or service.
ESN Number
MSN Number
Model Number
Wireless Phone Number
Warranty Expiration Date
Date of Purchase
Product Quality is yours with Motorola!
FX5000.book Page 2 Monday, February 14, 2000 1:24 PM
iii
General Safety Information
Wireless Operation Safety Information
IMPORTANT! Read This Information Before Using Your Wireless Telephone.
Exposure to Radio Frequency Signals
Your fixed wireless telephone is a radio transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
European and International Agencies have set standards and recommendations for the protection of public
exposure to RF electromagnetic energy.
•International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996
•Verband Deutscher Electringenieure (VDE) DIN-0848
•Directives of the European Community, Directorate General V in Matters of Radio Frequency Electromagnetic Energy
•National Radiological Protection Board of the United Kingdom, GS 11, 1998
•American National Standards Institute (ANSI) IEEE. C95.1-1992
•National Council on Radiation Protection and Measurements (NCRP). Report 86
•Department of Health and Welfare Canada. Safety Code 6
These standards are based on extensive scientific review. For example, over 120 scientists, engineers, and
physicians from universities, government health agencies, and industry reviewed the available body of research to
develop the updated ANSI Standard.
The design of your phone complies with these standards when used normally. During operation the user must be
at least 20 centimeters away from the antenna.
FX5000.book Page iii Monday, February 14, 2000 1:24 PM
iv
General Safety Information
Antenna Care
Use only the supplied or approved replacement antenna. Unauthorized antennas, modifications, or attachments
could damage the phone and may violate FCC regulations.
Electronic Devices
Most modern electronic equipment is shielded from RF signals. However, certain electronic equipment may not be
shielded against the RF signals from your fixed wireless phone.
Pacemakers —
The Health Industry Manufacturers Association recommends that a minimum separation of six
inches (fifteen centimeters) be maintained between a fixed wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations are consistent with the independent research by and
recommendations of Wireless Technology Research.
Persons with pacemakers:
•
Should
always
keep the phone more than six inches (fifteen centimeters) from their pacemaker when the phone is
turned ON.
•If you have any reason to suspect that interference is taking place, turn your phone OFF immediately.
Hearing Aids —
Some digital wireless phones may interfere with some hearing aids. In the event of such
interference, you may want to consult your hearing aid manufacturer to discuss alternatives.
Other Medical Devices —
If you use any other personal medical device, consult the manufacturer of your device
to determine if they are adequately shielded from external RF energy. Your physician may be able to assist you in
obtaining this information.
Blasting Areas
Do not use your fixed wireless phone in an area where blasting operations are being performed.
v
General Safety Information
Potentially Explosive Atmospheres
Do not operate your phone when in any area with a potentially explosive atmosphere and obey all signs and
instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include: fueling
areas such as gasoline stations, below deck on boats, fuel or chemical transfer or storage facilities, vehicles using
liquefied petroleum gas (such as propane or butane), areas where the air contains chemicals or particles, such as
grain, dust, or metal powders.
Using External Antennas
Your
FX5000 Digital
telephone is equipped with an antenna which screws onto the transceiver. This antenna is
intended for internal use, and will provide adequate operation under normal circumstances. If you elect to install
an external antenna (not supplied by Motorola), you must take precautions to provide adequate lightning
protection for the external antenna. Motorola assumes no liability if you elect to install an external antenna.
Please Save These Instructions
FX5000.book Pages iv - v Monday, February 14, 2000 1:24 PM
vi
General Safety Information
Notes…
FX5000.book Page vi Monday, February 14, 2000 1:24 PM
1
Introduction
About Your New
FX5000 Digital
Telephone
The
FX5000 Digital
fixed wireless phone is a convenient and efficient solution for providing
residential telephone service in geographical areas where normal landline telephone service is
either inadequate or not available.
The
FX5000 Digital
telephone consists of a base (containing a keypad and an internal wireless
radio transceiver), a handset, and a power supply. After your Wireless Service Provider registers
your phone for wireless service, simply plug the cord into any wall outlet and you are ready to
place and receive calls. Since your
FX5000 Digital
telephone operates like a radio and uses the
wireless telephone system, there is no need to have telephone wiring or jacks in your home.
About This Manual
In this manual, we’ll tell you how to assemble and install your
FX5000 Digital
telephone. We’ll
also provide easy step-by-step instructions on using your phone to make and receive calls,
storing numbers in memory, and using the other features offered by your
FX5000 Digital
telephone.
Some photos representing AC plugs and antennas may differ from your actual unit. They are for
illustrative purposes only.
FX5000.book Page 1 Monday, February 14, 2000 1:24 PM
2
Introduction
FX5000 Digital
Telephone Major Components
The major components of your
FX5000 Digital
telephone are shown in the photo on the next
page.
•
Handset
— Hold the handset to your ear like any normal telephone to carry on
conversations.
•
Base
— Provides the dialing keypad and other function buttons, as well as a hang-up
cradle for the handset.
•
Antenna
— Allows your
FX5000 Digital
telephone to send and receive radio signals to/
from the wireless telephone system.
•
Power Supply
— When plugged into an AC wall outlet, the power supply provides the DC
electricity needed for your
FX5000 Digital
telephone to operate.
3
Introduction
Base
Antenna
Handset
Hang-Up
Cup
FX5000.book Pages 2 - 3 Monday, February 14, 2000 1:24 PM
4
Introduction
Things You Should Know
Before assembling, installing, and using your
FX5000 Digital
telephone, here are a few things
you should be aware of:
• Your
FX5000 Digital
telephone operates on the wireless telephone system. Before you can
use your phone, make sure that your local Wireless Service Provider has registered your
phone for wireless service. This includes programming your phone and providing you
with a phone number.
• Your
FX5000 Digital
telephone must be installed in an area where it can adequately
communicate with the wireless telephone system (by radio communications). This means
that the location in which you wish to use your phone must be within the coverage area
of the wireless telephone system. Your Wireless Service Provider can advise you as to
whether you are in the coverage area.
• The Power Supply in your
FX5000 Digital
telephone is designed to withstand AC input
power variations of up to 10%. If you suspect that your AC power varies more than this,
you may choose to use an external surge protection device.
• To clean your phone, use a soft rag.
Do not
use alcohol or any other solvent.
• Please read
General Safety Information
before operating your phone.
FX5000.book Page 4 Monday, February 14, 2000 1:24 PM
5
Assembly
Unpacking and Taking Inventory
Open the packaging and remove the contents. Your
FX5000 Digital
telephone package should
contain the following items. If it does not, return the entire package to the dealer and exchange
it for a new package.
Handset
Antenna
Power
Supply
Base
Coil Cord
FX5000.book Page 5 Monday, February 14, 2000 1:24 PM
6
Assembly
Installing the Handset
Plug one end of the coil cord into the handset and the other end into the base, as shown below.
Then place the handset into the cradle on the base.
Connect coil cord to handset and base.
Push each connector into receptacle until it "clicks"
into place. Note that the connectors are keyed and
can be plugged in only one way.
Place handset into cradle in base.
7
Assembly
Attaching the Antenna
Locate the black rubber-coated antenna and attach it to the
base as shown. Note that the antenna can be left straight or
bent at a 90º angle, depending on whether you are using
the phone on a horizontal surface (like a desk) or are going
to wall mount the phone. For now, leave the antenna bent
at a 90º angle as shown.
NOTE
You may elect to purchase and install an external
antenna (not available from Motorola). In this case, be sure
to observe all manufacturer’s recommendations regarding
installation and lightning protection. In fact, you may wish
to hire a professional to help you with the installation. Additionally, you may have to purchase
an RF adapter to allow the antenna cable to connect to the transceiver
. Be sure to read your
Motorola warranty to determine the limits and liabilities imposed if you elect to use any
hardware not approved by Motorola. Doing so may void your warranty.
FX5000.book Pages 6 - 7 Monday, February 14, 2000 1:24 PM
8
Assembly
Installing the Power Supply
Connect the Power Supply cord as shown below.
Do not
connect the wall transformer to AC
power at this time.
FX5000.book Page 8 Monday, February 14, 2000 1:24 PM
9
Installation
Overview
In this section, we will tell you how to mount your
FX5000 Digital
telephone (desktop or wall
mounted) and how to plug your telephone into the AC outlet. Keep the following in mind when
deciding where to position your telephone.
• Do not place the phone or power supply near water.
• Do not place the phone in direct sunlight to avoid possibly overheating the handset and
transceiver.
• Be sure to keep children and pets away from the phone and power supply.
• Do not position the phone in close proximity to other electrical or electronic appliances
(such as computers, microwave ovens, televisions, radios, etc.) to avoid possible
electrical interference between the phone and the appliances.
• Installing the phone inside a metal building is not recommended, since it may reduce the
signal quality of your phone.
• Do not dangle the phone by the DC power cord. Rest the phone on a table or other flat
surface, or secure it to a wall as described in “Wall Mounting” on page 11.
FX5000.book Page 9 Monday, February 14, 2000 1:24 PM
10
Installation
Mounting Locations
Overview
Your
FX5000 Digital
telephone has been designed for use on a horizontal surface (like a desk) or
a vertical surface (mounted to a wall). Both mounting methods are described below.
Desktop Mounting
You may place your phone on any horizontal
surface, such as a desktop or counter top. Be sure
to position your phone so that the DC power cord
will reach a nearby electrical outlet. Note that the
antenna should be positioned vertically as shown
at right.
11
Installation
Wall Mounting
You may mount your phone on any vertical surface, such as a
wall. Be sure to position your phone so that the DC power
cord will reach a nearby electrical outlet. Note that the
antenna should be positioned vertically as shown. Install two
3 mm or 1/8" screws (not supplied) per template and adjust
them until the phone has been firmly attached to the wall.
NOTE
Before drilling holes to wall mount your phone, it is a
good idea to plug in your phone (described in “Plugging into
AC Power” on page 12) and verify that you are receiving a
strong signal (as indicated by the LED on the base turning
green) and you are able to place and receive calls.
8.3 cm
(3 1/4 ")
Install two screws (not supplied)
per template, then attach phone
as shown.
Attach phone as shown.
Route the DC power cord to the
back of the base and thread it
through the cable retaining track
as shown. The DC power cord
should hang down from the bot-
tom of the base.
Route the DC power cord to
the back of the base and
thread it through the cable
retaining track as shown.
The DC power cord should
hang down from the bottom
of the base.
FX5000.book Pages 10 - 11 Monday, February 14, 2000 1:24 PM
12
Installation
Plugging into AC Power
Your
FX5000 Digital
telephone is equipped with an AC-to-DC transformer that you plug into an
AC electrical outlet with voltage according to transformer. Check transformer label.
Connect your telephone to AC power by plugging in the transformer to a nearby AC receptacle.
13
Installation
Notes…
FX5000.book Pages 12 - 13 Monday, February 14, 2000 1:24 PM
14
Controls and Indicators
➊
Numeric Keypad
Used to enter call information.
➋
Flash Button
This button is used to send a switch hook flash when a call is in progress.
➌
Function Buttons
and Adjusts earpiece and ringer volume.
Places a call to the last number called.
Stores numbers into any of nine available memory locations.
❹
LED Indicator
When GREEN, indicates that telephone is receiving wireless service and is operating normally.
You may place and receive calls when the LED is GREEN and the signal strength is sufficient. If
the signal strength is insufficient, move the base closer to a window.
When ORANGE, indicates that wireless service is available but you may experience noise
during conversation and even have a call dropped.
When RED, indicates that telephone is not receiving wireless service and cannot place or
receive calls. LED indicator also blinks in other situations, for example, when storing a
telephone number or programming the phone.
VOL VOL
RDL
STO
15
Controls and Indicators
FX5000.book Pages 14 - 15 Monday, February 14, 2000 1:24 PM
16
Operating Your Telephone
Overview
This section provides step-by-step instructions for operating your
FX5000 Digital
telephone,
including how to turn your phone on and off, place calls, receive calls, and end calls. Also
described are memory dialing, volume adjustments, and last number redial.
Whenever using your phone, keep the following in mind:
• Like a normal landline telephone, you will hear a dial tone when lifting your handset.
• To place a call, pick up the handset, enter the phone number and the call will be placed
a few seconds after the last key is pressed.
• When finished with a call, you must either hang up the handset in the base, or use your
finger to depress the hang-up button in the handset.
• Before using your phone, the AC transformer must be plugged in and the LED on the base
must be GREEN. The base must also be placed in an area where the signal will be strong.
• If you lose AC electrical power, your
FX5000 Digital
phone will not operate. However,
any phone numbers and other information you have stored in memory will be preserved.
17
Operating Your Telephone
Basic Operation
Turning Your Phone On and Off
Your
FX5000 Digital
telephone is on whenever the transformer is plugged into a powered AC
electrical outlet and the DC power cord is plugged into the base. You can tell if your telephone
is on (and operational) if the LED on the base is GREEN. (It may take a few seconds after first
applying power for the LED to turn GREEN.)
How to Place a Call
1. With power on, lift the handset and enter the number you wish to call by
pressing the keypad buttons. As you press each button, make sure you hear a tone
in the handset earpiece to confirm your entry.
2. The call will be placed a few seconds after the last key is pressed.
3. Begin the conversation when the called party answers.
Note
If you are dialing a number and an incoming call is received, you will hear the incoming
call ringer in the handset earpiece. To answer the call, press .
Flash
FX5000.book Pages 16 - 17 Monday, February 14, 2000 1:24 PM
18
Operating Your Telephone
How to Receive a Call
When you hear the ring tone indicating an incoming call, lift the handset to your ear
and begin the conversation.
How to End a Call
When you are finished with your conversation, hang up the handset in the base.
Note
If you wish to place another call right away, you may simply press and release the hang-
up button in the handset. You will hear the dial tone and you may dial a new number for the
next call.
Redialing Last Number Called
This feature allows you to press a single button to automatically place a call to the last phone
number you called (either placed by entering the number from the keypad or recalled from
memory).
1. With power on, lift the handset, then press and release .
2. You will hear the ring tone in the handset earpiece.
3. Begin the conversation when the called party answers.
RDL
19
Operating Your Telephone
Using Memory Dialing
Storing Numbers in Memory
Your phone provides nine memory locations (designated by location numbers 1, 2, through 9)
in which to store frequently called phone numbers. Each memory location accepts up to
20 digits.
1.
Press . LED indicator will blink red and green.
2. Enter the phone number you wish to store (up to 20 digits).
3. Press .
4.
Enter a location number (e.g.,
, ,
etc.).
Note
If you store a phone number in a memory location where a number is already stored,
the new number will permanently overwrite the old number.
You can abort the store process by pressing the Flash key
STO
STO
1 2
FX5000.book Pages 18 - 19 Monday, February 14, 2000 1:24 PM
20
Operating Your Telephone
Placing Calls from Memory
1. With power on, lift the handset.
2. Press and hold the associated digit key ( through ). You will hear the tone
associated with the key and the call will be placed a few seconds after the sound
changes to a distinctive tone.
3. You will hear the ring tone in the handset earpiece.
4. Begin the conversation when the called party answers.
1 9
21
Operating Your Telephone
Making Volume Adjustments
Adjusting the Earpiece Volume
The loudness of the audio you hear from the handset earpiece while in a conversation can be
adjusted to seven volume levels.
To increase the volume level — While in a call, press and release the button to
increase the volume level one step.
To decrease the volume level — While in a call, press and release the button to
decrease the volume level one step.
Note
You may also adjust the transceiver audio tones when not in a call. Simply lift the
handset and press or (as described above).
VOL
VOL
VOL VOL
FX5000.book Pages 20 - 21 Monday, February 14, 2000 1:24 PM
22
Operating Your Telephone
Adjusting the Ringer Volume
The loudness of the ringer tone you hear from the base to alert you of an incoming call can be
adjusted to seven volume levels.
To increase the volume level — With the handset in the base, press and release the
button to increase the volume level one step. You will hear a tone to indicate
the volume level.
To decrease the volume level — With the handset in the base, press and release the
button to decrease the volume level one step. You will hear a tone to indicate
the volume level.
VOL
VOL
23
Operating Your Telephone
Advanced Call Features
Your phone supports the advanced call features: call waiting, call forwarding and 3-way call.
These features are dependent on your Service Provider. Please contact your Service Provider for
details on how to use these features.
FX5000.book Pages 22 - 23 Monday, February 14, 2000 1:24 PM
24
Troubleshooting
Overview
If you have problems placing or receiving calls, try to locate your difficulty in the following
troubleshooting table and follow the instructions to remedy the problem. If you still are having
problems, contact your Wireless Service Provider.
Troubleshooting Table
Symptom Remedy
You cannot make or receive calls
•Make sure that your phone’s power supply is
plugged into an AC outlet.
•Make sure that the AC power in your house or
office is on.
•Have you obtained wireless service?
You hear static or intermittent voice
during conversations •Try moving the location of your phone.
•Be sure the antenna is in a vertical position.
FX5000.book Page 24 Monday, February 14, 2000 1:24 PM
25
Technical Specifications
Technical Specifications
The following table lists the technical specifications for your
FX5000 Digital
telephone.
General
Dimensions 19.3 cm x 19.1 cm x 6.6 cm (excluding
antenna)
Weight 1.1 Kg
Operating Temperature 0º C to +40º C
RF Connection TNC
Input/Output Impedance 50 ohms nominal
Power Supply
Input Voltage 90 to 240 VAC
Input Frequency 50 to 60 Hz
Output Voltage 7.5 VDC
Output Current 900 mA
Protection Output are short-circuit protected and
isolated from input until 3000 V
FX5000.book Page 25 Monday, February 14, 2000 1:24 PM
American Wireless Subscriber Group
600 North U.S. Highway 45
Libertyville, Illinois 60048-5343
U.S.A.
Visit us on the web:
www.mot.com
, and all other trademarks indicated as such
herein are trademarks of Motorola, Inc.
Reg. U.S. Pat. & TM off.
2000 Motorola, Inc. All rights reserved
Printed in the U.S.A.
,
68P09425A76-O
x/xx/99-xxx
FX5000.book Page 26 Monday, February 14, 2000 1:24 PM
