USERS MANUAL 3

Features
19
Locking the Keypad
You can lock the keypad buttons to avoid accidentally changing your radio settings.
1. To lock the keypad, press and hold for 3 seconds.
Note: The f icon will display.
2. To unlock, press and hold for 3 seconds.
End-of-Transmission Tone
If enabled, your two-way radio transmits a tone when you finish transmitting. It is like
saying Roger or Over.
1. To enable, press and hold as you turn the radio ON.
2. To disable, simply turn your radio OFF and press and hold as you turn the
radio ON.
Time-Out Timer
The radio will emit a warning tone and will stop transmitting if the Push to Talk
button is pressed for more than 60 seconds continuously.
MENU
MENU
operation.fm Page 19 Tuesday, August 30, 2005 1:16 PM
Frequency and Code Charts
20
Frequency and Code Charts
The charts on the following pages provide Frequency and Code information. These
charts are useful when using Motorola AU Series two-way radios with other
business radios. Frequency position is identical to Spirit M, GT, S, and XTN Series
Frequencies (where applicable).
VHF Frequencies
Frequency (MHz) Bandwidth Frequency (MHz) Bandwidth
1 151.6250 25.0 16 151.8650 25.0
2 151.9550 25.0 17 151.8950 25.0
3 154.5700 25.0 18 151.9250 25.0
4 154.6000 25.0 19 152.7000 25.0
5 151.7000 12.5/25.0 20 154.4900 25.0
6 151.7600 12.5/25.0 21 154.5150 25.0
7 151.8200 12.5/25.0 22 154.5275 25.0
8 151.8800 12.5/25.0 23 154.5400 25.0
9 151.9400 25.0 24 154.6000 25.0
10 151.5125 25.0 25 154.6550 25.0
11 151.6550 25.0 26 158.4000 25.0
12 151.6850 125.0 27 158.4075 25.0
13 151.7150 25.0
14 151.7450 25.0
15 151.7750 25.0
operation.fm Page 20 Tuesday, August 30, 2005 1:16 PM
Frequency and Code Charts
21
UHF Frequencies
Frequency (MHz) Bandwidth Frequency (MHz) Bandwidth
1 464.5000 12.5/25.0 20 461.3125 12.5
2 464.5500 12.5/25.0 21 461.3375 12.5
3 467.7625 12.5 22 461.3625 12.5
4 467.8125 12.5 23 462.7625 12.5
5 467.8500 12.5/25.0 24 462.7875 12.5
6 467.8750 12.5/25.0 25 462.8125 12.5
7 467.9000 12.5/25.0 26 462.8375 12.5
8 467.9250 12.5/25.0 27 462.8625 12.5
9 461.0375 12.5 28 462.8875 12.5
10 461.0625 12.5 29 462.9125 12.5
11 461.0875 12.5 30 464.4875 12.5
12 461.1125 12.5 31 464.5125 12.5
13 461.1375 12.5 32 464.5375 12.5
14 461.1625 12.5 33 464.5625 12.5
15 461.1875 12.5 34 466.0375 12.5
16 461.2125 12.5 35 466.0625 12.5
17 461.2375 12.5 36 466.0875 12.5
18 461.2625 12.5 37 466.1125 12.5
19 461.2875 12.5 38 466.1375 12.5
operation.fm Page 21 Tuesday, August 30, 2005 1:16 PM
Frequency and Code Charts
22
39 466.1625 12.5 48 467.7875 12.5
40 466.1875 12.5 49 467.8375 12.5
41 466.2125 12.5 50 467.8625 12.5
42 466.2375 12.5 51 467.8875 12.5
43 466.2625 12.5 52 467.9125 12.5
44 466.2875 12.5 53 469.4875 12.5
45 466.3125 12.5 54 469.5125 12.5
46 466.3375 12.5 55 469.5375 12.5
47 466.3625 12.5 56 469.5625 12.5
UHF Frequencies (Continued)
Frequency (MHz) Bandwidth Frequency (MHz) Bandwidth
operation.fm Page 22 Tuesday, August 30, 2005 1:16 PM
Frequency and Code Charts
23
Interference Eliminator Codes
Code Hz Code Hz Code Hz
1 67.0 14 107.2 27 167.9
2 71.9 15 110.9 28 173.8
3 74.4 16 114.8 29 179.9
4 77.0 17 118.8 30 186.2
5 79.7 18 123.0 31 192.8
6 82.5 19 127.3 32 203.5
7 85.4 20 131.8 33 210.7
8 88.5 21 136.5 34 218.1
9 91.5 22 141.3 35 225.7
10 94.8 23 146.2 36 233.6
11 97.4 24 151.4 37 241.8
12 100.0 25 156.7 38 250.3
13 103.5 26 162.2
operation.fm Page 23 Tuesday, August 30, 2005 1:16 PM
Frequency and Code Charts
24
Digital Interference Eliminator Codes
Code Hz Code Hz Code Hz
39 023 58 132 77 265
40 025 59 134 78 271
41 026 60 143 79 306
42 031 61 152 80 311
43 032 62 155 81 315
44 043 63 156 82 331
45 047 64 162 83 343
46 051 65 165 84 346
47 054 66 172 85 351
48 065 67 174 86 364
49 071 68 205 87 365
50 072 69 223 88 371
51 073 70 226 89 411
52 074 71 243 90 412
53 114 72 244 91 413
54 115 73 245 92 423
55 116 74 251 93 431
56 125 75 261 94 432
57 131 76 263 95 445
operation.fm Page 24 Tuesday, August 30, 2005 1:16 PM
Frequency and Code Charts
25
96 464 105 606 114 703
97 465 106 612 115 712
98 466 107 624 116 723
99 503 108 627 117 731
100 506 109 631 118 732
101 516 110 632 119 734
102 532 111 654 120 743
103 546 112 662 121 754
104 565 113 664
Digital Interference Eliminator Codes (Continued)
Code Hz Code Hz Code Hz
operation.fm Page 25 Tuesday, August 30, 2005 1:16 PM
Troubleshooting
26
Troubleshooting
Symptom Try This:
No Power
Reposition, recharge or replace NiMH battery pack.
Message not
transmitting
Make sure the
Push to Talk
button is completely pressed while
transmitting.
Reposition, recharge, replace the NiMH battery pack.
Message not
received
Confirm that all radios have the same channel, frequency, and
interference eliminator code settings.
Make sure that the Push to Talk button is not inadvertently
being pressed. Reposition, recharge, or replace the NiMH
battery pack.
Obstructions and operating indoors or in vehicles may interfere -
change location.
Hearing
conversation or
noise on a
channel
Check that the Interference Eliminator Code setting is not set to
0. A shared channel may be in use, try another.
operation.fm Page 26 Tuesday, August 30, 2005 1:16 PM
Troubleshooting
27
Limited talk
range
Steel and/or concrete structures, heavy foliage, buildings, or
vehicles decrease range. Check for a clear line of sight to
improve transmission.
Wearing the radio close to the body such as in a pocket or on a
belt decreases range. Change location of the radio.
Heavy static or
interference
Radios are too close to one another. They must be at least
5 feet apart.
Obstacles are interfering with transmission.
Keypad locked
Make sure menu us unlocked. Unlock by holding for
3 seconds.
Low batteries
Recharge or replace NiMH battery pack. Extreme operating
temperatures affect battery life.
Charger light
does not come
on
Check that radio/battery is properly inserted and check battery/
charger contacts to be sure they are clean.
Verify that the charging pin is inserted correctly.
Symptom Try This:
MENU
operation.fm Page 27 Tuesday, August 30, 2005 1:16 PM
Troubleshooting
28
operation.fm Page 28 Tuesday, August 30, 2005 1:16 PM
