Motorola Solutions 89FT5818 iDEN i30sx User Manual i30sx
Motorola Solutions, Inc. iDEN i30sx i30sx
Users Manual
Motorola
iDEN®
Digital Multi-Service Data-Capable Phone
i30sx Phone User’s Guide
Preliminary
@NNTN4196A@
NNTN4196A
www.motorola.com/iden
i
Table of Contents
Introduction .......................................................................................... 5
Driving Safety Tips .........................................................................................6
Getting Started...................................................................................... 9
i30sx Phone Features.....................................................................................10
Battery ...........................................................................................................10
Turning Your i30sx Phone On/Off ...............................................................14
Security Features of the i30sx Phone ............................................................15
Keypad Lock .................................................................................................21
Status of Your i30sx Phone...........................................................................24
My Information .............................................................................................25
Using T9® Text Input ...................................................................................26
Display Essentials ............................................................................... 31
Display Screen Elements...............................................................................31
Call Information Icons...................................................................................34
Navigating Menus and Lists..........................................................................35
Main Menu Options.......................................................................................36
Phonebook ........................................................................................... 39
Accessing Phonebook with an i2000, i2000plus, or GSM Phone.................40
Phonebook Entries and Speed Dial Numbers................................................40
Phonebook Icons ...........................................................................................40
Voice Names .................................................................................................41
Accessing Your Phonebook ..........................................................................41
About Phonebook Entries..............................................................................42
Pause Digit Entry...........................................................................................49
Plus Dialing ...................................................................................................51
Digital Cellular.................................................................................... 53
Making Phone Calls ......................................................................................53
Emergency Calling........................................................................................58
ii
www.motorola.com/iden
Receiving a Phone Call .................................................................................58
Ending a Phone Call ......................................................................................58
Recent Calls...................................................................................................58
Call Timers....................................................................................................62
Call Waiting ..................................................................................................63
Call Hold .......................................................................................................65
Three-Way Calling........................................................................................66
Call Forwarding.............................................................................................68
Messages .............................................................................................. 73
Message Center .............................................................................................73
Voice Mail.....................................................................................................74
Using Voice Mail ..........................................................................................75
Text and Numeric Messaging........................................................................76
Net Mail.........................................................................................................78
Using Your Phone as a Modem.....................................................................79
Private Calls........................................................................................ 81
Private Call....................................................................................................81
Call Alerts......................................................................................................83
Group Call .....................................................................................................87
Memo ...................................................................................................91
Adding a New Memo ....................................................................................91
Viewing a Memo...........................................................................................91
Editing a Memo .............................................................................................92
Deleting a Memo...........................................................................................92
Customizing the i30sx phone ............................................................. 93
Settings..........................................................................................................93
Accessories......................................................................................... 111
Carrying Solutions.......................................................................................111
Batteries.......................................................................................................114
Travel Chargers ...........................................................................................115
iii
Data Accessories .........................................................................................117
Other Important Information ......................................................... 123
Understanding Status Messages ..................................................................123
Safety and General Information ..................................................... 125
RF Operational Characteristics ...................................................................125
Accessory Safety Information .....................................................................133
Limited Warranty Motorola Communication Products...............................135
Limited Warranty Motorola Communication Products (International) ......139
Patent and Trademark Information..............................................................143
iv
www.motorola.com/iden
DECLARATION OF CONFORMITY
Per FCC CFR 47 part 2 Section 2.1077(a)
Hereby declares that the product:
Conforms to the following regulation:
FCC Part 15, subpart B
Class B Computer peripheral
Date: December 17, 2001
Responsible party name: Motorola Inc.
Address: 8000 West Sunrise Boulevard,
Plantation, FL 33328 USA
Phone number: 1 (800) 453-0920
Product name: i30sx
Model Number: H56XAH6RR5AN
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
5
Introduction
ongratulations on purchasing your Motorola iDEN i30sx Phone
multi-service, data-capable, digital, portable phone. Your i30sx
phone offers:
•Phonebook — Your consolidated Phonebook holds up to 250 entries and
allows you to store multiple contact numbers for each person, offering you
various ways to communicate with your business and personal contacts.
•SIM Card — Your phone’s SIM card holds all entries stored in your
Phonebook. In addition, you have a PIN (Personal Identification Number)
to keep your information safe and secure.
•Messages — The Message Center allows you to manage and access your
Voice Mail, Text Messages and Net Mail all from the same inbox.
•Private and Group Calls — You can use your phone as a two-way radio
to communicate directly with business and personal contacts in your iDEN
service area.
•Fax and Data Transfer — for circuit data faxes and file transfers..
•Speakerphone — You can enjoy hands-free communication at the touch of
a button. And Speakerphone is especially great for conference calls.
For more information on these and other features of the i30sx phone, review this
User’s Guide. There is a Table of Contents in the front of the guide and an Index
in the back of the guide to assist you in finding the specific information you
want.
NOTE: Some features of your i30sx phone are available only in the
iDEN service area, and are indicated as such in this guide.
NOTE: This guide describes the features of the i30sx phone as they
were set up by Motorola. However, your carrier or your
organization may have changed or added features. For more
information, check with your carrier or your organization.
C
6
www.motorola.com/iden
Driving Safety Tips
“Safety is your most important call!”
Your Motorola wireless telephone gives you the powerful ability to
communicate by voice — almost anywhere, anytime, wherever wireless phone
service is available and safe conditions allow. But an important responsibility
accompanies that benefits of wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility. If you find it necessary to
use your wireless phone while behind the wheel of a car, practice good common
sense and remember the following tips:
1. Get to know your Motorola wireless phone and its features such as speed
dial and redial. If available, these features help you to place your call with-
out taking your attention off the road.
2. When available, use a hands-free device. If possible, add an additional
layer of convenience to your wireless phone with one of the many Motor-
ola Original hands-free accessories available today.
3. Position your wireless phone within easy reach. Be able to access your
wireless phone without removing your eyes from the road. If you receive
an incoming call at an inconvenient time, if possible, let your voice mail
answer it for you.
4. Let the person you are speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous weather conditions. Rain,
sleet, snow, ice, and even heavy traffic can be hazardous.
5. If you receive an incoming call at an inconvenient time do not take notes or
look up phone numbers while driving. Jotting down a “to do” list or going
through your address book takes attention away from your primary respon-
sibility — driving safely.
6. Dial sensibly and assess the traffic; if possible, place calls when you are not
moving or before pulling into traffic. Try to plan calls when your car will
be stationary. If you need to make a call while moving, dial only a few
numbers, check the road and your mirrors, then continue.
7. Do not engage in stressful or emotional conversations that may be distract-
ing. Make people you are talking with aware you are driving and suspend
conversations which have the potential to divert your attention away from
the road.
8. Use your wireless phone to call for help. Dial 9-1-1 or other local emer-
gency number in the case of fire, traffic accident or medical emergencies.1
7
Driving Safety Tips
9. Use your wireless phone to help others in emergencies. If you see an auto
accident, crime in progress or other serious emergency where lives are in
danger, call 9-1-1 or other local emergency number, as you would want
others to do for you.*
10. Call roadside assistance or a special non-emergency wireless assistance
number when necessary. If you see a broken-down vehicle posing no seri-
oushazard,abrokentrafficsignal,aminortrafficaccidentwherenoone
appears injured, or a vehicle you know to be stolen, call roadside assistance
or other special non-emergency wireless number.1
1. Wherever wireless phone service is available.
8
www.motorola.com/iden
10
www.motorola.com/iden
i30sx Phone Features
Battery
Your i30sx phone comes with a Lithium Ion battery. After attaching the battery,
you must charge it before you use it for the first time. See “Charging Lithium
Ion Batteries” on page 114 for the charging times for your phone’s battery. The
first time you charge your phone’s battery, charge for 30 minutes more than the
time shown on page 114. After the initial charging, the battery can be charged in
thetimeshownonpage114.
Instructions for Attaching and Detaching the battery may be found on page 15.
Antenna
Earpiece
Display
Menu Key
Option Key
Photosensor Send Key
AlphaNumeric
Keypad
Microphone
Option Key
4-Way Navigation Key
Punctuation Key
Headset Jack
Back Key/Pause Dialing
Next Word Key/International
Plus Dialing
Accessory Connector
Speaker Key
Volume Control Buttons
Push-To-Talk Button (PTT)
Status Light
End/Home Key
SIDE VIEW FRONT VIEW
TOP VIEW
Battery
BOTTOM VIEW
Power On/Off
Lanyard Hook
11
Battery
Attaching the Battery
Detaching the Battery
1
Holding the phone face down, insert the battery into the phone in a
forward and downward motion. A securing click will be heard.
1
Ensure the phone is powered off before attempting to detach the battery.
2
Press the battery release button and slide the battery away from the
antenna.
3
Remove the battery by pushing the battery toward the antenna and
lifting it out of the phone.
12
www.motorola.com/iden
Charging the Battery
NOTE: Your phone’s screen backlight will remain lit while the battery is
charging.
1
With your phone’s keypad facing up, plug the charger’s
accessory connector into the left side of the accessory
connector on the bottom of the phone.
2
Plug the charger into an electrical outlet.
In Process
13
Battery
Battery Charging Status
The battery strength indicator icon found on your phone’s display screen shows
the charge amount remaining in the battery. Refer to Battery Charging, Table 1.
Table 1: Battery Charging
When Using Phone
NOTE: A short, chirp-like sound indicates a low battery. This indicates
that you have approximately five minutes of talk time remaining.
When Charging Battery
NOTE: During the charging process, the battery icon will be flashing. In
addition, when the battery is fully charged, the battery icon will
show a fully charged battery.
Icon
Display abcd
Battery
Strength Low
Battery 11% - 40% 41% - 70% Fully Charged
(90% -100%)
Icon
Display efgh
1flashingbar 1flashingbar,
1 continuous bar 1 flashing bar,
2 continuous bars 3 continuous bars
Battery
Strength Low
Battery 31% - 60% 61% - 90% FullyCharged
(90% -100%)
14
www.motorola.com/iden
Turning Your i30sx Phone On/Off
To power the phone on:
To power the phone off:
1
For optimal signal strength, extend the antenna.
2
Press and hold pnear the bottom of the phone until the status light
glows red and a tone briefly sounds.
3
If the Enter SIM PIN Code screen displays, enter your SIM PIN. (For
more information see “SIM Card Personal Identification Number
(PIN)” on page 15.)
NOTE:The default SIM card PIN is 0000. It is recommended that you
change your PIN to prevent fraudulent use of the SIM card
(see “Changing the PIN” on page 16).
4
Press Bunder OK.
As your phone connects to the network,
youwillseeawelcomemessageanda
connecting message. When the Ready
screen appears on the display, you are
readytouseyouri30sx phone!
1
Press and hold pnear the bottom of the phone until you see the message
Powering Off.
2
Push down the antenna.
A
15
Security Features of the i30sx Phone
Security Features of the i30sx Phone
SIM Card
Your phone comes with a built-in level of security protection through the use of
the SIM (Subscriber Identity Module) card. The SIM card stores all your
Phonebook information. Since this information is stored on the SIM card, not in
your phone itself, you can remove the information by removing the SIM card.
The SIM card is located in the SIM Card Holder on the back of the phone,
underneath the battery. You can verify that the SIM card is in place by removing
the battery and viewing the SIM card through the SIM card cover.
See “Removing/Inserting the SIM Card”on page 20 for information on locating
the SIM card. If there is no SIM card in your phone, notify your sales
representative.
NOTE:Except for making emergency calls, your phone will not
function without the SIM card.
SIM Card Personal Identification Number (PIN)
To prevent unauthorized use of your phone, your SIM card is protected by a
PIN. Each time the phone is powered on, you must enter your PIN. You can
change or disable your PIN if desired.
NOTE: Disabling your PIN enables anyone to use your phone. If you
disable your PIN, you must still keep the SIM card in the phone
to make calls.
Entering the PIN
Depending on your service provider, your phone
may or may not require you to enter a SIM PIN
whenyou first use your phone.
If your phone is set to require you to enter a PIN,
your default SIM card PIN is: 0000. It is
recommended that you change your PIN to
prevent fraudulent use of the SIM card (see
“Changing the PIN”on page 16).
P
16
www.motorola.com/iden
If you enter an incorrect PIN, the message SIM PIN incorrect: Try again
appears on your phone’s screen. After three consecutive incorrect attempts, the
SIM card is blocked. The phone does not allow you to attempt to enter your PIN
again, even after powering the phone off and back on. If this happens, see
“Unblocking the PIN”on page 17.
Changing the PIN
Incorrectly entering your PIN three times
causes the SIM card to be blocked. To
unblock your SIM card, you must contact
your service provider. For more
information, see “Unblocking the PIN”on
page 17.
1
From the Enter SIM PIN screen, enter your four- to eight-digit PIN.
An asterisk appears for each character entered.
NOTE:Other than emergency dialing, you will be unable to use any
of the phone functions, including receiving phone calls, until
you enter the PIN.
2
Press Bunder OK.
1
At the Ready screen, press mand then
press Rto scroll to Settings.
2
Press Bunder SELECT. The Settings screen displays.
!
C a u t i o n
B
17
Security Features of the i30sx Phone
Unblocking the PIN
If you forget your PIN and unsuccessfully enter it three times, access to your
phone will be blocked.
NOTE: Before you begin, obtain the PIN Unblocking Key (PUK) code
from your service provider, then read and understand the PIN
unblocking sequence. When entering the key press sequence,
each key press must occur within 5 seconds of the prior key
press.
3
Press Rto scroll to Security.PressB
under SELECT to access the Security
screen.
4
At the Security screen, press Rto scroll to New Passwords.PressB
under SELECT to access the New Passwords screen.
5
At the New Passwords screen, press Rto scroll to SIM PIN and press
Bunder SELECT.
6
At the Enter Old SIM PIN Code screen, enter the current SIM PIN
and press Bunder OK.
NOTE:The default SIM is 0000.
7
At the Enter New SIM PIN Code screen, enter the new 4- to 8-digit
SIM PIN and press Bunder OK.
8
At the Re-enter New SIM PIN Code screen, re-enter the new SIM PIN
to confirm, and press Bunder OK.
C
18
www.motorola.com/iden
To unblock the PIN:
Disabling/Enabling the PIN Requirement
When the PIN requirement is enabled, you are
prompted to enter your PIN each time you turn
on your phone. Until a valid PIN is entered, you
can use the phone only to make emergency calls.
After the PIN is accepted, the phone registers on
the network and the Ready screen displays.
When the PIN requirement is disabled, the phone
can be used without entering a PIN.
If you unsuccessfully enter the PUK code
ten times, the SIM card is permanently
blocked and must be replaced. If this
happens, all data will be lost. You will get a
message to contact your service provider. If
the SIM card is blocked, the i30sx phone
only allows outgoing Emergency calls.
1
Press **05e.
2
Enter the PUK code.
3
Press e.
4
Enter a new 4- to 8-digit SIM PIN and press e.
5
Re-enter your SIM PIN and press e.
If you entered the codes properly, the SIM Unlocked screen displays.
!
C a u t i o n
P
19
Security Features of the i30sx Phone
If you disable the PIN requirement, you
remove protection of personal data on your
SIM card. Anyone can then use your phone
and access your personal data.
1
At the Ready screen, press mand then
press Rto scroll to Settings.
2
Press Bunder SELECT. The Settings screen displays.
3
Press Rto scroll to Security.PressB
under SELECT to access the Security
screen.
4
At the Security screen, press Rto scroll to SIM PIN.PressBunder
SELECT to access the SIM PIN screen.
5
Press Rto scroll to On or Off.On enables the SIM PIN requirement;
Off disables the SIM PIN requirement. Press Bunder SELECT.
6
At the Verify SIM PIN Code screen, enter the current SIM PIN and
press Bunder OK.
!
C a u t i o n
B
C
20
www.motorola.com/iden
Removing/Inserting the SIM Card
Do not touch the gold-colored areas of the
SIM card.
To avoid loss or damage, do not remove
your SIM card from your phone unless
absolutely necessary.
1
With phone powered off, remove the battery cover. See “Detaching the
Battery”on page 11.
2
With the back of the phone exposed and facing
up, locate the SIM cover and gently push it to
the right. Lift the cover up.
3
To insert the SIM card, very carefully place it in its holder with the gold
contact side facing down.
To close the SIM card cover, push it down and slide
forward.
!
C a u t i o n
21
Keypad Lock
Keypad Lock
The i30sx phone includes a Keypad Lock feature that enables you to quickly
lock the phone’s keypad to avoid inadvertently pressing keys or placing calls.
Once Keypad Lock is activated, you can only perform the following tasks:
•turn your phone on and off
•unlock the keypad
•receive incoming calls, messages, and alerts.
NOTE: Emergency calls cannot be placed while Keypad Lock is
activated.
Before locking your phone’s keypad, you may want to read this entire section to
learnhowtorespondtoincomingcalls,messages,andalerts.
Activating Keypad Lock
Whenever a key is pressed while in Keypad Lock mode, the unlock instructions
display briefly.
4
To remove the SIM card, slide the SIM card cover back and lift up (as
in step 2). Very carefully lift the SIM out of its holder. Do not touch the
gold-colored areas of the SIM card.
NOTE: Protect the SIM card as you would any delicate object. When
the SIM card is not in the phone, you should store it in
something protective, such as a mailing envelope.
From the Ready screen, press m*.The
message Keypad Locked displays on your
phone. D
22
www.motorola.com/iden
Receiving Incoming Calls
When you receive an incoming phone call (see “Receiving a Phone Call”on
page 58), Keypad Lock is temporarily disabled.
Receiving Private Calls
When you receive an incoming Private call, Talkgroup call, or call alert (see
“Private Call”on page 81), Keypad Lock is temporarily disabled.
Receiving New Voice Mail
When you receive new Voice Mail (see “Voice Mail”on page 74), Keypad
Lock is temporarily disabled.
1
Press Bunder YES or press eto answer the call. When you end the
call, the Recent Calls list appears. Press sor press Aunder EXIT to
reactivate Keypad Lock and return to the Ready screen.
Or,
Press AunderNOorpresssto send the call to Voice Mail and
reactivate Keypad Lock.
1
Press and hold the Push-To-Talk (PTT) button on the side of the phone.
Begin talking after the phone emits a chirping sound. Release the PTT
button to listen.
2
When you end the call, the Recent Calls list appears. Press eor press
Aunder EXIT to reactivate Keypad Lock and return to the Ready
screen.
1
When New VoiceMail Message displays, press Aunder EXIT to
return to the Ready screen and reactivate Keypad Lock.
Or,
Press Bunder CALL to access Voice Mail.
2
Once you have finished, press sto exit Voice Mail. The Recent Calls
list displays. Press sto reactivate Keypad Lock and return to the
Ready screen.
23
Keypad Lock
Receiving New Text Messages
When you receive new Text Messages (see “Text and Numeric Messaging”on
page 76), Keypad Lock is temporarily disabled.
Receiving New Net Mail
When you receive new Net Mail, Keypad Lock is temporarily disabled.
1
When New Text Message displays, press Aunder EXIT to return to
the Ready screen and reactivate Keypad Lock.
Or,
Press Bunder READ to read the message. Press Bunder SAVE or
DELETE. Once you have finished, press sor press Aunder EXIT to
reactivateKeypadLockreturntotheReady screen.
1
When New Browser Message displays, press Aunder EXIT to return
to the Ready screen and reactivate Keypad Lock.
Or,
Press Bunder GOTO. Press Aunder View. Press Aunder OK or
Reply. Once you have finished, press suntil you reactivate Keypad
Lock return to the Ready screen.
24
www.motorola.com/iden
Deactivating Keypad Lock
Status of Your i30sx Phone
Your i30sx phone has a status light that displays at the top of the phone. The
status light indicates the status of your connection.
From the Ready screen, press m*.
The message Keypad Unlocked
displays briefly.
Status Light
Indicator i30sx Phone Status
Solid Red Signing on to the network. Please wait.
Flashing Red No service or out of coverage area.
Flashing
Green Inservice/Readytouse.
Solid Green In use.
E
25
My Information
My Information
You can select My Info from the main menu to display or edit the following:
•Name —enter your name in this field.
•Private ID —your Private ID is displayed in this field. Your Private ID is
the number that others use to contact you using Private calls.
•Phone Numbers of Lines 1 and 2 —your phone’s numbers are displayed in
these fields. You can edit the phone numbers displayed on the My
Information screen, but this does not change your phone numbers.
•IP Addresses —these fields display the IP addresses you use to access the
Internet with your phone.
•Circuit Data Number (Ckt)—your circuit data number is in this field.
Viewing/Editing My Information
1
From the Ready screen, press m.
2
Press Sto scroll to My Info.PressBunder SELECT. The My
Information screen displays.
3
Use Sto scroll through the fields.
4
To edit the displayed information, press Bunder CHANGE. Edit
information as desired, and press Bunder OK to save the changes.
To return to the Ready screen, press Aunder EXIT.
26
www.motorola.com/iden
Using T9®Text Input
Your i30sx phone has embedded software, called T9®Text Input, that makes
typing on a phone keypad much like typing on a computer keyboard: it
eliminates the traditional “multi-tap”method of text entry. As you type, you
press only one key per letter. T9 Text Input matches your keystrokes to words in
its linguistic database of approximately 60,000 words and proper names. You
may also store additional words you frequently use in your own user database,
which is incorporated into the T9 database.
T9 Text Input is available when you are typing information into your
Phonebook and Datebook.
T9 Text Input Entry Modes
Four text entry modes are available in T9 Text Input: Alpha, Word, Symbols,
and Numeric. When you are using T9 Text Input, an icon in the top right corner
of your phone’s display screen (next to the battery strength indicator icon)
indicates the T9 Text Input entry mode you are using:
When you are using Phonebook or Datebook, you select your text entry mode
from a menu available whenever the phone is displaying a screen that requires
you to enter text (for example, the Name: screen or Title: screen).
Icon T9 Entry Mode
Name Used For...
wAlpha Standard “multi-tap”keypad
text entry.
#Word Entering words and
punctuation with one key-
press per character.
!Symbols Entering punctuation and
symbols such as “@”or “?”.
,Numeric Entering keypad numbers.
27
Using T9® Text Input
To choose a text entry mode:
Choosing a Language
To change the language of the T9 Text Input database:
Using Alpha Mode
To enter text while in Alpha text entry mode to enter letters, numbers, and
symbols:
•Press any button on the alphanumeric keypad to enter the letters, numbers,
and symbols on that key.
•Press and hold a key to capitalize a letter, or press #to activate and
deactivate Caps Lock.
1
From any screen that requires text input, press mto access the Entry
Method menu.
A check mark appears next to the current text entry mode. When you
access a screen that requires text input, the default text entry mode is
Alpha.
2
Press Sto scroll to the T9 Text Input text entry mode you want to use.
3
Press Bunder SELECT.
The phone returns to the text entry screen. The text entry mode you
selected is now active.
1
From any screen that requires text input, press mto access the Entry
Method menu.
2
Press Sto scroll to Languages.
3
Press Bunder SELECT.
4
Press Sto scroll to the language you want T9 Text Input to use.
5
Press Bunder SELECT.
28
www.motorola.com/iden
•Pause briefly to leave the currently displayed character in place and move
on to the next place in the text entry field.
•Press Pto create a space in the text entry field.
•Press Aunder DELETE to delete one character. Press and hold Aunder
DELETE to delete an entire entry.
Using Word Mode
In Word mode, T9 Text Input analyzes the letters on the keypad button you
press and arranges them to create words. As you type, T9 Text Input matches
your keystrokes to words in its database and will display the most commonly
used matching word.
Special Key Functions
Some of your phone’s keys assume different functions while in T9 Text Input
Word mode.
Backspace and Erase
Press Aunder DELETE once to backspace or to erase a single character. Press
and hold Aunder DELETE to erase the entire text entry field.
Space
Press Ronce to accept a word and insert a space when entering text.
Next Word in Database
Press 0to display more words in the database that match the keystroke
sequence you entered.
Shift and Caps Lock
Press #to make the next letter typed uppercase (Shift), to make all subsequent
letters types uppercase (Caps Lock), or to go back to lowercase letters.
These icons appear in the top row of your display screen:
•$for Shift to uppercase
•xfor Caps Lock
When neither of these icons appear, letters typed are lowercase.
NOTE:T9 Text Input automatically makes the first letter of a sentence
uppercase.
29
Using T9®Text Input
Punctuation
In Word mode, T9 Text Input uses Smart Punctuation to quickly apply basic
rules of grammar to insert the correct punctuation within a word and at the end
of a sentence.
Press 1to insert punctuation. One of eight basic punctuation symbols will be
inserted(.,-’@:?;).
Press 0to change the inserted punctuation symbol to another of the eight basic
punctuation symbols.
Press Rto accept the punctuation and continue typing.
NOTE: Additional punctuation symbols are available in Symbols mode.
EnteringaWord
To enter a word using Word mode:
1
Choose Word as your text entry mode.
2
Type a word by using one key-press per desired letter.
For example, to type “test”press 8378.
NOTE: The displayed word may change as you type it. Do not try to
correct the word as you go. Type to the end of the word
before editing.
3
If the word that appears is not the desired word, press 0to change the
word on the display to the next most likely word in the database.
Repeat until the desired word appears.
If the desired word does not appear, you can add it to the database of
words using the instructions in “Adding Words to the User Database”
on page 30.
30
www.motorola.com/iden
Adding Words to the User Database
To add words to the T9 database:
NOTE: You cannot store alphanumeric combinations, such as Y2K.
Using Numeric Mode
To use Numeric text entry mode, choose Numeric as your text entry mode and
press the number buttons on your keypad to enter numbers.
Using Symbols Mode
To use Symbols text entry mode:
1
Change from Word text entry mode to Alpha text entry mode.
2
Type the word using Alpha text entry mode.
3
Return to Word text entry mode.
4
Press Rto add a space.
The word you typed in Alpha text entry mode is now in the database.
1
Choose Symbols as your text entry mode.
A row of 32 symbols appears along the bottom of your phone’sdisplay
screen, just above the display option and menu icon. (Press Tto view
the complete row.)
2
Press Tto highlight the symbol you want to enter into the text entry
field.
3
Press Bunder SELECT to enter the symbol.
31
Display Essentials
Your i30sx phone’s display screen tells you what you need to know as you use
your phone.
This section includes:
Display Screen Elements
Any time your phone is powered on, the display screen provides you with
information and options.
The Ready Screen
The Ready screen displays any time the
phone is powered on, but not engaged in
some activity.
The Ready screen consist of elements
commontomanyofthescreensyour
phone displays:
•status icons
•text display area
•menu icon
•display options
USER TIP:You can always access the Ready screen by pressing e.
Status Icons
Status icons provide you with information about your phone and its functions.
These icons are context sensitive; meaning, the icons that appear depend on the
task you are performing.
Display Screen Elements Page 31
Navigating Menus and Lists Page 35
Main Menu Options Page 36
\
Status
icon
rows
Text
display
area
Menu
icon
Display
options
Status
icon
rows
Tex t
display
area
Menu
icon
Display
options
Status
icon
rows
Tex t
display
area
Menu
icon
Display
options
32
www.motorola.com/iden
Status icons appear in the two rows at the top of the display screen. Some appear
at all times. Others appear only when your phone is engaged in certain activities
or when you have activated certain features.
Icon Indicates...
abcd
efgd
Battery Strength icons —remaining
battery charge. More bars on the battery
indicate a greater charge. See the table on
page 13 for detailed information about the
meaning of each battery strength icon.
opqr
sSignal Strength icons —strength of the
network signal. More bars next to the
antenna indicate a stronger signal.
01 Active Line icons —currently active
phone line; 0indicates Line 1 is active; 1
indicates Line 2 is active.
GHI
JKL Call Forward icons —phone is set to
forward calls. See “Call Forwarding”on
page 68 for more information.
cPhone In Use —phone is connected on an
active call.
hPrivate In Use —number being called is a
Private ID.
%Talkgroup In Use —phone is active on a
talkgroup call.
YPacket Data Ready —phone is ready to
receive data through a data cable.
ZPacket Data Activity —phone is
transmitting data.
]Mobile IP —phone is ready to access the
Internet.
33
Display Screen Elements
The icon of the main menu feature currently in use always appears in the top left
of the status icon rows. For a list of the main menu icons, see “Main Menu
Options”on page 36.
Text Display Area
The text display area shows menu options, messages, names, phone numbers,
and other information.
{Secure Data —phone is accessing the
Internet using a secure connection.
}Non-secure Data —phone is accessing
the Internet using a non-secure connection.
lRoaming —phone is searching for
network connections outside your local
area.
.Text Message —you have one or more
Text Messages or Net Mail messages.
yVoice Mail —you have one or more Voice
Mail messages.
BFaxMail —you have one or more FaxMail
messages.
uSpeaker Off —phone’s speaker is off.
-[\* Ring/Vibe icons —you have customized
the way in which the phone is set to notify
you when you receive calls and other types
of messages. See “Ring Style and
Notification Type”on page 95 for more
information.
w#,!
$x
T9 Text Input icons —youareusingT9
Text Input to enter text. See “Using T9®
Text Input”on page 26 for more
information.
34
www.motorola.com/iden
Call Information Icons
Each of the following icons appear on the left side of the text display area of the
one-line screen or the full-sized screen, providing you with information about
your phones line or lines.
Menu Icon
This menu icon mappears on any screen from which a menu can be accessed.
To access a menu, press the menu key on your keypad. This key has the menu
icon printed on it.
Menus are context sensitive. The menu that appears depends on the screen you
access it from and the items on the menu apply to the task you are currently
performing.
Pressing mor Qfrom the Ready screen accesses the main menu.
Display Options
Two display options appear at the bottom of most screens. These options enable
you to perform a wide variety of actions, including changing, saving and
viewing information, running programs, and canceling previous actions. You
activate a display option by pressing the Abelow it.
NOTE: Throughout the User’s Guide, the option keys Cand Dwill
be represented by A.
Icon Indicates...
DIn Call - phone is in an active call.
EIncoming Call - phone is receiving an
incoming all (not active).
XOutgoing Call - phone is placing an
outgoing (not active).
zOn Hold - phone has a call on hold.
?End Call - phone has ended the active call.
35
Navigating Menus and Lists
The Ready screen display options provide quick access to two main menu
features. By default, the Phonebook (PHBK)andMessages(MESG)display
options appear on the Ready screen. You can control which display options
appear on the Ready screen using the phone’s Personalize feature in the Settings
menu (see “Changing Ready Screen Options”on page 100).
The display options on screens other than the Ready screen cannot be
customized.
Navigating Menus and Lists
The i30sx phone is menu driven. By navigating menus, you access submenus
which lead to all of the functions and features that are built into your phone. Use
the menus to store calls, manage your Phonebook and Datebook, change your
phone settings, browse the Internet, and more.
Some features include lists of names, numbers, or other information. These list
items can be accessed the same way menu options are.
To access the items in a menu or list, scroll through using the four-way
navigation key near the center of your keypad. Scroll down by pressing the
lower portion of the navigation key R. Scroll up by pressing the upper portion
of the navigation key Q. Holding down the appropriate part of the navigation
key speeds up scrolling. If you continue scrolling after you have reached the
bottom or top of a menu or list, you “wrap-around”to the opposite end.
If more items appear in a menu or list than can be displayed in the text area, a
down arrow or up arrow appears in the left side of the screen indicating that
more options may be accessed by scrolling up or down.
Down arrow Up arrow
BS
36
www.motorola.com/iden
Main Menu Options
By default, the main menu options appear in the order determined by your
service provider. You can change the order in which they appear by using the
Personalize feature (see “Reordering Main Menu”on page 99)
To access the main menu, press mor Qfrom the Ready screen:
Menu Item Use to ...
7Browser Browse the Web.
mSettings Customize your phone: Ring/Vibe, In Call
Setup, Security, Initial Setup, Phone Setup,
Voice Volume, and Talkgroup Settings.
bPhonebook Store and retrieve a list of stored entries for
calling, editing, viewing, and deleting.
RMessages Receive, store, access and manage Voice
Mail, FaxMail, Text Messages, and Net
Mail.
;Call Forward Settings for forwarding calls in various
situations.
OMemo Input and store numbers to access later.
zCall Timers Display the duration of phone calls, private
or group calls, circuit data use, and
Kilobytes sent and received.
jRecent Calls Access a list of the last 20 sent, received, or
missed calls. Calls can be made from this
list.
UMy Info View the name, Private ID, phone numbers
for lines 1 and 2, IP address, and circuit
data number of your phone.
:Call Alert Store received call alerts to respond to at
your convenience.
37
Main Menu Options
To choose the highlighted Main Menu selection, press Bunder SELECT. To
exit the Main Menu and return to the Ready screen, press Aunder EXIT or
press s.
38
www.motorola.com/iden
39
Phonebook
The Phonebook allows you to store up to 250 frequently used names and
numbers.
When you store information in your Phonebook, it is saved on your SIM card. If
you move your SIM card to another i30sx phone, i85sphone or i50sx phone, you
can access information in your Phonebook from that phone.
NOTE: If you use a different SIM card in your phone, some information
stored in the phone will be lost. See “Removing/Inserting the
SIM Card”on page 20.
This section includes:
Accessing Phonebook with an i2000, i2000plus, or
GSM Phone Page 40
Phonebook Entries and Speed Dial Numbers Page 40
Phonebook Icons Page 40
Voic e Names Page 41
Accessing Your Phonebook Page 41
About Phonebook Entries Page 42
Viewing Phonebook Entries Page 42
Sorting Phonebook Entries Page 43
Adding Phonebook Entries Page 44
Editing Phonebook Entries Page 49
Deleting Phonebook Entries Page 49
Pause Digit Entry Page 49
Plus Dialing Page 51
40
www.motorola.com/iden
Accessing Phonebook with an i2000, i2000plus,
or GSM Phone
If you plan to use the information stored in your Phonebook with an i2000,
i2000plus, or any other GSM phone, you must purchase CompanionPro. Go to
www.motorola.com\iden or your service provider’swebsiteformore
information.
You can use CompanionPro to make the Phonebook information saved to your
i30sx phone’s SIM card accessible in this type of phone.
Phonebook Entries and Speed Dial Numbers
Your Phonebook can store multiple phone numbers to a single name. For
example, you can enter someone’s name into your Phonebook once and then
add that person’s home, office, mobile phone and fax numbers to the name.
Each number stored in your Phonebook is automatically assigned a Speed Dial
number that corresponds to its location in your Phonebook. Each phone number
uses one Speed Dial location, even if it is assigned to the same name as other
phone numbers. The phone number stored in location 1 is assigned Speed Dial
number 1, the phone number stored in location 2 is assigned Speed Dial number
2, and so forth, to location 250.
Phonebook Icons
Icons that appear to the right of entries in your Phonebook convey information
about those entries.
When you enter a phone number in your Phonebook, you can designate the
phone number’s type using any of the following icons:
WMobile
hPrivate
+Work
QMain
LHome
bPager
41
Voice Names
NOTE: The Mobile icon automatically appears to the right of the first
number assigned to a name unless you choose another icon.
For more information on entering numbers into your Phonebook, see “Adding
Phonebook Entries”on page 44.
The “picker”arrows appearing around the number type icon indicates multiple
phone numbers stored under one name:
The Voice Name icon appearing to the left of one of the phone number type
icons indicates that a voice name is associated with the Phonebook entry:
Voice Names
A voice name is an audio recording you make by speaking into your i30sx phone
that you assign to a number in your Phonebook. You can then dial the number
by speaking the words you recorded into the phone. See step 6 of “Adding
Phonebook Entries”on page 44 for more information on creating a voice name.
Accessing Your Phonebook
If PHBK is one of your display options:
KFax
nTalkgroup
|IP (Internet
Protocol
Address)
ZOther
ef pickers
pVoic e Name
From the Ready screen, press Aunder PHBK.
42
www.motorola.com/iden
If PHBK is not one of your display options:
USER TIP:You can also access the Phonebook by pressing mwhile
your phone is on a phone call or private call.
This brings you to the Phonebook screen. From this screen, you can view, sort,
add, edit, and delete Phonebook entries, check Phonebook capacity, or make
calls.
About Phonebook Entries
Each Phonebook entry may contain the following information:
•The name associated with the entry. Typically, this is the name of the
person whose number you are storing in the Phonebook.
•The type of number to be stored: Mobile, Private, Work, Main, Home,
Pager, Fax, Other, or Talkgroup. If you don’t choose a type, the number is
assigned type Mobile, unless a Mobile number has already been assigned
to the name.
•The number to be stored. Every Phonebook entry must contain a phone
number. This number may be any type of phone number, Private ID, or
Talkgroup number.
•A Speed Dial number. You may accept the default Speed Dial number or
assign a different one.
•A voice name audio recording for voice-activated dialing.
Viewing Phonebook Entries
Names with more than one number assigned to them appear with ef
surrounding the icon to the right of the name. For example, if you had stored a
home and work number for Joe Smith, the entry for Joe Smith’s home phone
number would look like this:
Joe Smith eLf
Whenthenameishighlighted,pressTto scroll to the icons representing each
of the numbers assigned to that name.
1
From the Ready screen, press m.
2
Press Rto scroll to Phonebook.
3
Press Bunder SELECT.
43
About Phonebook Entries
To view any of the phone numbers assigned to a name:
Sorting Phonebook Entries
You can sort your Phonebook entries by:
•Name —thenameyouenteredfortheentry.
•Speed No. —the Speed Dial location of the entry.
•Voic e Nam e —all entries with voice names appear at the top of the list.
NOTE: Private and group calls cannot be made from the Phonebook
when sorted by Speed Dial location.
To sort your Phonebook list:
1
From the Phonebook screen, press Sto scroll to the name associated
with the phone number you want to see.
2
Press Tto view the icons representing the phone numbers assigned to
that name.
3
When the icon representing the number you want to view is displayed,
press Bunder VIEW.
If there is a Private ID or a Talkgroup number stored for the person,
press m.ThenpressRto scroll to View and press Bunder SELECT.
4
Press Sto view the other numbers stored for this name.
1
From the Main Screen screen, press m
and scroll down Rto view the
Phonebook Menu screen.
2
Press Rto scroll to Sort By.
}
44
www.motorola.com/iden
Checking Phonebook Capacity
Your Phonebook can store up to 250 separate numbers. To see how many
entries are stored in your Phonebook:
Adding Phonebook Entries
Using the following instructions, you will enter the information in the order the
items appear on the Phonebook Entry Details screen. However, you can enter
this information in any order by pressing Sto scroll through the items on the
Entry Details screen.
YoucanleaveanyitemblankorunchangedbypressingSto scroll past it on
the Entry Details screen. Only a number is required for a valid Phonebook
entry.
After you have entered a phone number and any other information you wish to
include, you can press Aunder DONE to save the Phonebook entry.
3
Press Bunder SELECT.
4
Press Rto scroll to the desired sorting method: Name,Speed No.,or
Voice Name.
5
Press Bunder SELECT.
1
From the Phonebook screen, press mto view the Phonebook Menu
screen.
2
Press Rto scroll to Capacity.
3
Press Bunder SELECT.
The Capacity screen shows how many storage spaces in you
Phonebook are in use and how many are empty.
45
About Phonebook Entries
To cancel a Phonebook entry at any time, press sto return to the Ready
screen.To add a Phonebook entry:
1
Access the Entry Details screen:
From the Main Screen screen, press m.
Then press Rto scroll to Phonebook.
Press Bunder SELECT
To add a [New Entry],pressBunder
SELECT.
2
If you want to assign a name to your
Phonebook entry:
With the Name: field highlighted, press
Bunder CHANGE.
From the Name: screen, enter the name
using the alphanumeric keypad.
See “Using T9®Text Input”on page 26
for information about entering text into
this field.
When you are finished, press Bunder OK.
The Entry Details screen returns with the Type: field highlighted.
3
If you want to assign a number type other
than Mobile to your Phonebook entry:
With the Type: field highlighted, press B
under CHANGE.
From the Type Editor screen, press Rto
scroll to the type of number you want to
assign to the Phonebook entry.
Press Bunder SELECT.
The Entry Details screen returns with the No.: field highlighted.
H
I
J
46
www.motorola.com/iden
4
Assign a number to your Phonebook
entry:
With the No.: field highlighted, press B
under CHANGE.
Type the number using the alphanumeric
keypad. For phone numbers, use the
10-digit format.
To delete a digit, press Aunder
DELETE.
See “Pause Digit Entry”on page 49 and “Plus Dialing”on page 51 for
information on using these features when storing phone numbers in
your Phonebook.
NOTE: The number can be up to 20 characters long.
When you are finished, press Bunder OK.
The Entry Details screen returns with the Speed No. field highlighted.
5
The default Speed Dial number assigned
to the Phonebook entry is displayed in the
Speed No.: field. This is always the next
available Speed Dial location.
If you want to assign the phone number to
a different Speed Dial location:
With the Speed No.: field highlighted,
press Bunder CHANGE.
Press Aunder DELETE to delete the
current Speed Dial number.
Type the new Speed Dial number using the alphanumeric keypad.
When you are finished, press Bunder OK.
K
L
47
About Phonebook Entries
6
If you want to assign a voice name to the
number:
With the Voice Name: field highlighted,
press Bunder RECORD.
As directed by the screen prompts, say and
repeat the name you want to assign to the
number. Speak clearly into the
microphone.
An )icon appears in the Voice Name:
field indicating that the voice name has
been recorded.
USER TIP:For best results, record in a quiet environment.
7
If you want to store more numbers to the
name associated with this Phonebook
entry:
Press Rto scroll to MORE at the bottom
of the Entry Details screen and then press
Bunder SELECT.
AnewType: field appears for the
additional number.
Enter the information for the additional
number using step 3 through step 7.
NOTE:Each name in your Phonebook may have up to seven phone
numbers one Private ID associated with it.
8
When you have entered all the information
you wanted in this Phonebook entry, press
Aunder DONE.
M
U
N
48
www.motorola.com/iden
Storing Numbers Fast
Your phone gives you two ways to store numbers quickly: from the Ready
screen and from the Recent Calls list.
To store a number from the Ready screen:
To store a number from the Recent Calls list:
1
From the Ready screen, use the alphanumeric keypad to enter the
number you want to store.
2
Press mto access the Dialing Menu screen.
3
With Store Number highlighted, press Bunder SELECT.
This displays the Entry Details screen with the No: fieldfilledinwith
the number you typed.
4
If you want to add more information to the Phonebook entry, follow the
applicable instructions in “Adding Phonebook Entries”on page 44.
5
Press Aunder DONE.
1
From the Recent Calls screen, press Rto scroll to the number you
want to store.
2
Press Bunder STORE.
Or, press mto access the Rec. Calls Menu.PressSto scroll to
Store.PressBunder SELECT.
This displays the Entry Details screen with the No: fieldfilledinwith
thenumberoftherecentcall.
3
If you want to add more information to the Phonebook entry, follow the
applicable instructions in “Adding Phonebook Entries”on page 44.
4
Press Aunder DONE.
49
Pause Digit Entry
Editing Phonebook Entries
Deleting Phonebook Entries
Pause Digit Entry
When storing a number, you can program your phone so that it will not only dial
a number but also pause before entering another series of numbers such as a
personal identification number (PIN) or password. This feature is particularly
useful for accessing automated services such as voice mail and banking systems
from your i30sx phone.
1
From the Phonebook screen, press Rto scroll to the entry you want to
edit.
2
Press mto view the Phonebook Menu.
3
Press Rto scroll to Edit.
4
Press Bunder SELECT. The Entry Details screen displays.
5
Follow the applicable instructions in “Adding Phonebook Entries”on
page 44 to edit the various fields.
1
From the Phonebook screen, press Rto scroll to the entry you want to
delete.
2
Press mto view the Phonebook Menu.
3
Press Rto scroll to Delete Record or Delete Number.
Delete Record deletes the name and all numbers associated with that
name.
Delete Number deletes the number associated with the icon that is
currently displayed in the Phonebook list for the name. The name and
all the other numbers will remain.
4
Press Bunder SELECT. A warning screen displays requiring you to
confirm the deletion.
50
www.motorola.com/iden
Here’s how it works. Let’s say you have a company voice mail account that you
frequently check while traveling. And, to access that account you must do the
following:
•Dial your work number
•Press # while the voice mail greeting is being played
•Enter your PIN to access your messages
You can program your phone to enter all of the above information for you. All
you have to do is separate each entry with a pause. If you were to program your
phone to automatically input the above information, the stored data would look
like this 17035551234P#P1234. In this example, the first eleven digits represent
the number that must be dialed to access your voice mail. The P represents a 3
second pause. The # interrupts your greeting. The second P represents another 3
second pause. The last four digits represent your PIN.
You can use this feature not only to enter PINs and passwords but also to have
the phone automatically select menu options (i.e., press 1 to hear messages).
To create a three-second pause, follow the steps below:
NOTE:You can enter up to 20 characters in a single entry, stored or
dialed.
NOTE: If you use a system that will not let you enter an option until the
automated message has played in its entirety, you can program
your phone to pause for more than 3 seconds. For example,
performing the above step twice will program two pauses and
cause your phone to wait 6 seconds before entering the next set
of numbers.
Press and hold *for two seconds. The pause symbol (P) will appear on
the display screen.
51
Plus Dialing
Plus Dialing
This feature enables you to place an international call from most countries —
without entering the local international access code. Use Plus Dialing for all
Phonebook entries if you plan to travel outside the United States. Begin by
following the instructions for “Adding Phonebook Entries”on page 44. Before
you type the phone number to be stored:
1
Press and hold 0for two seconds. A “0”appears, then changes to a
“+”.
NOTE: The network translates the “+”into the appropriate
international access code needed to place the call.
2
Enter the country code, city code, or area code, and phone number.
3
Follow the rest of the instructions for “Adding Phonebook Entries”on
page 44.
52
www.motorola.com/iden
53
Digital Cellular
The i30sx phone enables you to make and receive domestic and international
phone calls, make emergency calls, and be notified of a missed call.
This section includes:
Making Phone Calls
Your i30sx phone provides the following features for making phone calls:
•Direct Dial
•Phonebook
•Recent Calls
•Speed Dial
•Turbo Dial®
•Last Number Redial
•TTY - your phone supports TTY devices and communications.
Making Phone Calls Page 53
Emergency Calling Page 58
Receiving a Phone Call Page 58
Ending a Phone Call Page 58
Recent Calls Page 58
Call Waiting Page 63
Hands-Free SpeakerPhone Page 61
Call Timers Page 63
Call Hold Page 65
Three-Way Calling Page 66
Call Forwarding Page 68
54
www.motorola.com/iden
Using Direct Dial
NOTE:See “Plus Dialing”on page 51 for information on making
international calls.
If you make a mistake:
•To clear one digit, press Aunder DELETE.
•To clear all digits, press and hold Aunder DELETE.
•To cancel, press s.
Making Calls from the Phonebook
After you have entered phone numbers into your Phonebook, you can use these
numbers to make phone calls. For information on entering numbers into your
Phonebook, see “Adding Phonebook Entries”on page 44.
To make calls from the Phonebook:
1
From the Ready screen, use the keypad to enter the 10-digit phone
number you want to call.
2
Press eto place the call.
3
Press sto end the call.
1
From the Ready screen, if PHBK is one of your display options, press
Aunder PHBK.
Or,
From the Ready screen, press m,thenpressRto scroll to
Phonebook.PressBunder SELECT.
2
Press Rto scroll through the names in your Phonebook.
Or,
Use the alphanumeric keypad to enter the first letter of the name and
press Rto scroll through the names beginning with that letter.
Stop when the name of the person you want to call is highlighted.
55
Making Phone Calls
Making Calls from the Recent Calls List
Your phone stores the numbers of the last 20 calls you received or sent in the
Recent Calls list.
3
If more than one number is stored for the person you want to call, ef
appears around the icon to the right of the person’sname.
Press Tto scroll through the icons representing the numbers stored for
that person.
Or,
Press Bunder VIEW to view all the numbers stored for this person.
Then press Rto scroll to the number you want to call.
Or,
If there is a Private ID or a Talkgroup number stored for this person,
press m. When the Phonebook Menu appears, press Sto scroll to
View and press Bunder SELECT. Then press Rto scroll to the
number you want to call.
For more information on assigning multiple numbers to one person, see
“Adding Phonebook Entries”on page 44.
4
Press eto place the call.
5
Press sto end the call.
1
From the Ready screen, press R.
Or,
From the Ready screen, press Sto Recent Calls is not the first item
on the list, press Sto scroll to it. Press Bunder SELECT.
2
Press Sto scroll the list received or sent recent calls until you reach
the desired call.
56
www.motorola.com/iden
Using Speed Dial
Each phone number stored in your Phonebook is assigned a Speed Dial number.
You can use the Speed Dial number to quickly place a call.
Using Turbo Dial
Turbo Dial allows you to call the numbers in your Phonebook associated with
Speed Dial numbers 1 through 9 by pressing and holding the corresponding
numerickeyonthekeypad.
NOTE: Turbo Dial cannot be accessed while the browser is active, nor
while Keypad Lock or SIM Lock is active.
3
To view additional information about the call:
Press Bunder VIEW.
Or,
Press mto access the Rec. Calls Menu.ThenpressRto scroll to
View and press Bunder SELECT.
4
Press eto place the call.
5
Press sto end the call.
1
From the Ready screen, enter the Speed Dial number assigned to the
phone number you want to call.
2
Press #.
3
Press eto place the call.
4
Press sto end the call.
Press and hold a number key (1 through 9).
57
Making Phone Calls
Last Number Redial
Placing International Phone Calls
When making an international call, you can either enter the international access
code directly (011 in the United States) or use Plus Dialing.
You can make international calls from your Phonebook if you have stored the
numbers with Plus Dialing. See “Adding Phonebook Entries”on page 44 and
“Plus Dialing”on page 51 for more information.
NOTE: Your service default is “International Calls Restricted.”
Therefore, you must call Customer Care to obtain international
dialing access.
To make an international call using Plus Dialing:
Making TTY Calls
NOTE: This feature may not be offered by your service provider.
You can use your phone to make calls using a TTY device.
When you make TTY call, the call begins in the TTY mode you last selected.
You can change the TTY mode during a call. For more information on choosing
a TTY mode, see “Setting TTY Mode”on page 105.
To make a call using a TTY device:
Press and hold eto redial the last number you called.
1
Press and hold 0for two seconds. A “0”appears, then changes to a
“+”.
NOTE: The network translates the “+”into the appropriate
international access code needed to place the call.
2
Enter the country code, city code, or area code, and phone number.
3
Press eto place the call.
4
Press sto end the call.
58
www.motorola.com/iden
Emergency Calling
Your phone supports emergency calling. Emergency calls can be made even
when the SIM card is blocked or not in the phone.
To place a call in an emergency, dial 911e. You will be connected to the
nearest emergency dispatch center. If you are on an active call, you must end it
before calling 911.
NOTE: If you have enabled the Keypad Lock feature, you must unlock
the phone’s keypad before any call can be made, including 911
emergency calls.
Receiving a Phone Call
Ending a Phone Call
Recent Calls
The Recent Calls feature stores the numbers of the 20 most recent calls you have
made and received, including private and talkgroup calls. You can access
Recent Calls to:
•view your recent calls
•store numbers to the Phonebook
•delete recent calls
•call numbers on the Recent Calls list
1
Connect one end of a 2.5mm cable into the jack on the phone. (To
locate the jack, see page 10.) Connect the other end of the cord into
your TTY device.
2
Enter the phone number you wish to call and press e.
Incoming calls are indicated by a ring, vibration or backlight
illumination. Press eor any key on the keypad or press Bunder YES
to answer the call.
Press sto hang up.
59
Recent Calls
NOTE: The Recent Calls list displays briefly after you end a call.
Recent Calls Icons
If the number of the recent call is stored in your Phonebook, the name associated
with the phone number appears on the Recent Calls list.
For private calls, group calls, and numbers stored in your Phonebook, an icon
appears to the right of the name of number indicating the Phonebook type of the
number used in the call. See “Phonebook Icons”on page 40 for more
information about Phonebook types.
For phone calls, an icon appears to the left of the name or number indicating the
type of call:
•Nindicates an incoming call
•aindicates an outgoing call
•Vindicates a missed call. (Missed calls appear on your Recent Calls list
only if you have Caller ID.)
For private calls, an icon appears to the left of the name or number indicating the
type of call:
•hindicates a Private Call
•nindicates a Group Call
Viewing Recent Calls
To view your Recent Calls list:
1
From the Ready screen, press R.
Or,
From the Ready screen, press Sto scroll to Recent Calls.PressB
under SELECT.
2
Press Sto scroll the list of recent calls.
60
www.motorola.com/iden
Getting Detailed Information About Recent Calls
To get more information about a recent call:
The screen that appears displays information such as the name associated with
the number of the recent call, the number, the date, time, and duration of the
call.
Storing a Recent Call Number to the Phonebook
To store a number from the Recent Calls list to the Phonebook:
Calling From the Recent Calls List
See “Making Calls from the Recent Calls List”on page 55.
1
From the Recent Calls screen, press Sto scroll to the call you want
more information on.
2
Press Bunder VIEW.
Or,
Press mto access the Rec. Calls Menu.ThenpressRto scroll to
View and press Bunder SELECT.
1
From the Recent Calls screen, press Sto scroll to the number you
want to store.
2
Press Bunder STORE.
This displays the Phonebook Entry Details screen with the No: field
filled in with the number of the recent call.
3
If you want to add more information to the Phonebook entry, follow
applicable the instructions in “Adding Phonebook Entries”on page 44.
61
Recent Calls
Deleting Recent Calls
To delete a recent call:
To delete all calls on the Recent Calls list:
Hands-Free Speakerphone
This feature provides the convenience of a hands-free solution, allowing you to
hold impromptu meetings and place safer phone calls. The speakerphone option
(SPKR) is available whenever you are on an active phone.
NOTE: During speakerphone operation, you may either speak or listen,
but you cannot do both at the same time.
To turn the speakerphone on:
While speakerphone is on, Spkrphone On appears in the text display area.
1
From the Recent Calls screen, press Sto scroll to the call you want to
delete.
2
Press mto access the Rec. Calls Menu.
3
Press Rto scroll to Delete.
4
Press Bunder SELECT.
5
Press Aunder YES to confirm the deletion.
1
From the Recent Calls screen, press mto access the Rec. Calls
Menu.
2
Press Rto scroll to Delete All.
3
Press Bunder SELECT.
4
Press Aunder YES to confirm the deletion.
While on an active call, press Bunder SPEAKER.
62
www.motorola.com/iden
To turn the speakerphone off:
Use the Mute feature to listen to incoming audio without allowing sound from
your phone’s microphone to be transmitted over the phone line.
To turn mute on:
While mute is on, UNMUTE appears as a display option.
To turn mute off:
Call Timers
Call Timers measure the duration of your phone calls, Private or Group calls,
and circuit data use, as well as the number of Kilobytes sent and received by
your phone.
The Call Timers menu displays the following options:
•Last Call —displays the duration of your most recent phone call.
•Phone Reset —keeps a running total of your phone call minutes, until you
reset it.
•Phone Lifetime —displays the total minutes of all your phone calls.
•Prvt/Grp Reset —keeps a running total of all of your Private and Group
call minutes, until you reset it.
•Prvt/Grp Lifetime —displays the total minutes of all your Private and
Groups calls.
•Circuit Reset —keeps a running total of all of your circuit data use, until
you reset it.
•Circuit Lifetime —displays the total minutes of all of your circuit data
use.
Press Bunder SPEAKER.
Press Bunder MUTE.
Press Bunder UNMUTE.
63
Call Waiting
•Kbytes Reset —keeps a running total of the number of Kilobytes sent and
received by your phone, until you reset it.
To view the Call Timers menu:
To view or reset a Call Timers option:
NOTE: The values displayed by Call Timers are not intended for billing
purposes.
Call Waiting
Call Waiting allows you to receive a second call while you are talking on the
phone. You can switch between calls so you never have to miss a call. By
default, Call Waiting is always on unless you turn it off for a specific call.
1
From the Ready screen, press m.
2
Press Rto scroll to Call Timers.
3
Press Bunder SELECT.
1
From the Call Timers menu, press Sto scroll to the Call Timers
option you want to view or reset.
2
Press Bunder SELECT.
3
If the feature does not include an option to reset or you do not wish to
reset the option, press Aunder DONE when you are finished viewing.
To reset a feature, press Bunder RESET. When the confirmation
screen appears, press Aunder YES to confirm the reset.
64
www.motorola.com/iden
If you’re on a call and you receive a second call,
you will:
•Hear a tone; and
•See a message on your display informing
you of another incoming call.
Accepting Calls
Switching Between Calls
When you accept a second call while you are talking on the phone, your display
shows the name or number of each call. An icon appears to the left of each name
or number indicating that the call is on hold zor active D.
Declining Calls
Press Bunder YES. The first call is placed on hold.
Press Bunder SWITCH to switch
between calls.
Press Aunder NO. If you subscribe to Voice Mail, the call will be
forwarded to your Voice Mail box.
e
Z
65
Call Hold
Ending the Active Call
Turning Off Call Waiting
If you do not want to be interrupted during a call, you can turn Call Waiting off
prior to making/receiving a call.
Call Hold
When you are on an active call, you can place the call on hold and make a
second call.
To place an active call on hold:
Press s.
1
From the Ready screen, press m.PressRto scroll to Settings,and
press Bunder SELECT.
2
Press Rto scroll to In Call Setup and press Bunder SELECT.
3
Press Rto scroll to Call Waiting and press Bunder CHANGE.
4
Press Rto scroll to Off and press Bunder SELECT.
Call Waiting is now disabled for the next call. It will automatically reset
to On when you hang up.
1
Press mto access the Calls Menu.
2
Press Rto scroll to Hold.
3
Press Bunder SELECT.
4
If you have not placed a second call, you can resume this call by
pressing Bunder RESUME.
66
www.motorola.com/iden
To place a second call while the first call is on hold:
To toggle between the two calls:
To end the active call:
Three-Way Calling
Using Three-Way Calling, you can combine two ongoing phone calls into one
conversation. While on an active call, you can make a second call and combine
the two calls. When you place or receive a phone call, the 3-WAY option
appears in the bottom right-hand corner of the display screen.
To make a three-way call:
1
Enter the second phone number you want to call. Or select the number
from your Phonebook by pressing mand selecting Phonebook.
2
Press eto place the second call.
Press Bunder SWITCH.
Press s. The call on hold becomes active.
1
Place or receive a phone call.
2
While on the call, press mto access the Call Menu.
3
Press Rto scroll to 3Way.
4
Press Bunder SELECT. The first call will be placed on hold.
67
Three-Way Calling
5
Enter the second phone number you want to call and press eto place
the second call.
Or, access the number from your Phonebook:
Press mandthenpressRto scroll to Phonebook.
Press Bunder SELECT.
To place the call, see “Making Calls from the Phonebook”on page 54.
6
After you reach the second individual, press m.
7
Press Sto scroll to 3Way.
8
Press Bunder SELECT. Both calls will appear on your display.
68
www.motorola.com/iden
Call Forwarding
Call Forwarding forwards calls to the number you designate. The following Call
Forwarding options are available:
•Off —No calls are forwarded.
•All Calls —When this option is turned on, all calls will be sent
automatically to a number you specify.
•Detailed —Choosing this option enables you to forward calls you missed
to different numbers, or to Voice Mail, depending on why you missed each
call:
•Busy —your phone is engaged in other activities.
•No Answer —you do not answer. The phone will ring 4 times before
forwarding the call.
•Unreachable —your phone is out of coverage or powered off.
You can forward Line 1 and Line 2 independently.
When your phone is set to forward all calls, one of the following icons appears
on the top row of your display screen to indicate the call forwarding option you
have chosen:
Icon Indicates...
GLine 1 is active; calls from Line 1 are being
forwarded.
HLine 1 is active; calls from Line 2 are being
forwarded.
ILine 1 is active; calls from Line 1 and Line
2 are being forwarded.
JLine 2 is active; calls from Line 1 are being
forwarded.
KLine 1 is active; calls from Line 2 are being
forwarded.
LLine 2 is active; calls from Line 1 and Line
2 are being forwarded.
69
Call Forwarding
NOTE:Call Forwarding must be set to Detailed with the Voice Mail
access number to receive Voice Mail messages. This is the
default setting.
TurningOnCallForwarding
1
Press mthen press Rto scroll to Call Forward.
2
Press Bunder SELECT.
3
At the Call Forward screen, the Forward
field is highlighted. Press Bunder
CHANGE.
4
Press Sto scroll to All Calls.
5
Press Bunder SELECT.
6
Press Rto scroll to the To field and press Bunder CHANGE.
W
70
www.motorola.com/iden
Your calls will now be forwarded to the number that you selected.
Turning Off Call Forwarding
7
To activate a call forwarding number:
If you have never used Call Forwarding before, the Forward screen
appears. To enter a call forwarding number, type the number on your
phone’skeypadorpressBunder SEARCH to select from numbers
stored in your phone. Press Bunder OK.
Or,
If you have used Call Forwarding before, the call forwarding number
youlastusedisdisplayed.PressBunder CHANGE to access the
Forward screen.
To forward your calls to this number, press Bunder OK.
To forward your calls to a different number, press and hold Aunder
DELETE to erase the displayed number. Type the new number on your
phone’skeypadorpressBunder SEARCH to select from numbers
stored in your phone. Press Bunder OK.
1
Press mthen press Rto scroll to Call Forward.
2
Press Bunder SELECT.
The Call Forward screen displays with the Forward field highlighted.
71
Call Forwarding
NOTE: You can use the Detailed setting to forward calls to other
numbers if desired. However, it is recommended that you leave
Detailed set to the Voice Mail access number and use the All
Calls setting if you wish to forward your calls to another
number.
SettingCallForwardingtoVoiceMail
In most cases, turning off Call Forwarding restores your ability to receive Voice
Mail messages when you are unavailable (see “Turning Off Call Forwarding”
on page 70). If you have completed those steps but are still not able to receive
Voice Mail messages, you can reset Call Forwarding to Voice Mail.
For you to receive Voice Mail messages, Call Forwarding must be set to
Detailed with your Voice Mail access number:
3
Press Rto scroll to the To field and press Bunder CHANGE.
4
Press Sto scroll to Off and press B
under SELECT.
1
Press mthen press Rto scroll to Call Forward.
2
Press Bunder SELECT.
The Call Forward screen displays with the Forward field set to
Detailed.
3
Press Rto scroll to the If Busy field and press Bunder CHANGE.
72
www.motorola.com/iden
NOTE: You can use the Detailed setting to forward calls to other
numbers if desired. However, it is recommended that you leave
Detailed set to the Voice Mail access number and use the All
Calls setting if you wish to forward your calls to another
number.
4
The call forwarding number you last used is displayed. Press Bunder
CHANGE. If this is your Voice Mail access number (the first six digits
of your 10-digit phone number followed by 6245), go to step 7.
5
Press and hold Aunder DELETE to erase the displayed number.
6
Enter your Voice Mail access number.
Your Voice Mail access number is the first six digits of your 10-digit
phone number, followed by 6245. (For example 7035556245.)
7
Press Bunder OK.
8
Repeat step 3 through step 7 for the If No Answer field and the If
Unreachable field.
9
When finished, press Aunder EXIT.
73
Messages
The main topics covered in this section are listed below:
Message Center
The Message Center enables you to access all messaging services through one
screen.
To access the Message Center:
If MESG is one of your display options:
If MESG is not one of your display options:
The Message Center screen displays the number of messages you have in each
message service —Voicemail (Voice Mail), Text Msgs (Text and Numeric
Messages), and NetMail (Net Mail).
Message Center Page 73
Voic e Mail Page 74
Text and Numeric Messaging Page 76
Alert Flag Notification Page 74
Net Mail Page 78
Using Your Phone as a Modem Page 79
From the Ready screen, press Bunder MESG.
1
From the Ready screen, press m.
2
Press Rto scroll to Messages.
3
Press Bunder SELECT.
74
www.motorola.com/iden
To access any message service:
Voice Mail
New Message Indicators
When you receive a new message:
•New VoiceMail Message will display on the screen.
•Your phone will alert you every 30 seconds until you press Bunder CALL
or Aunder EXIT. (If you are on a call, your phone will alert you once
during the call.)
Transferring Calls to Voice Mail
1
From the Message Center screen, press Rto scroll to the message
service you want to access.
2
Press Bunder the display option on the right. This option varies
depending on the message service selected.
Press Aunder NO while your phone is ringing to transfer incoming
calls directly to Voice Mail.
f
75
Using Voice Mail
Using Voice Mail
Logging Into Voice Mail
1
From the Ready screen, press Bunder
MESG to open up the Message Center
screen.
2
Voicemail should be highlighted to
indicate that it is selected. If it isn’t
highlighted, press Sto scroll to the
Voicemail field.
The number of new messages and the total
number of messages are displayed.
3
Press Bunder CALL to log into your Carrier’s Voice Mail System.
Calling displays as you are connected to the network.
A
g
76
www.motorola.com/iden
Text and Numeric Messaging
With Text and Numeric Messaging, your phone will:
•Allow numeric messages up to 20 characters in length and text (alpha)
messagesupto140charactersinlength.
•Accept your messages even if you are unavailable, if your phone is turned
off, or if you are busy on another call.
•Alert you of a new text or numeric message, even if you are on another call.
•Store a message if you are making a Private or Group call and deliver it
upon completion of the call.
•Store the message if you are outside of the coverage area and deliver it as
soon as you are back in a coverage area.
•Attempt continuous delivery of messages until successful, for up to 7 days.
With Text and Numeric Messaging, your phone will:
•Refer to text and numeric messages as Text Messages.
•Stamp the message with the time and date the message was left.
•Storeupto16messagesatatime,thatwillremainuntilyoudeletethem.
NOTE:“Mail Waiting, Memory Full”displays when 16 message
registers are full. (Messages must be erased before you can
receive others.)
•Allow for “Auto Call Back”of a phone number that is included within a
message, by pressing e. If the message contains two phone numbers, Auto
Call Back will dial the last number.
77
Text and Numeric Messaging
New Messages Indicators
When you receive a new message:
•New Text Message willdisplayonthescreen.
•Your phone will alert you every 30 seconds until you press Bunder
READ or Aunder EXIT. (If you are on a call, your phone will alert you
once during the call.)
Accessing New Messages
When you receive a message, you can view it immediately or later:
View a Message Immediately
Viewing a Message Later
1
Press Bunder READ. The message displays.
2
If the message fills more than one screen, use Sto scroll through the
rest of the message.
3
Press Aunder SAVE to save the message.
Or,
Press Bunder DELETE to delete the message.
Press Aunder EXIT. The .icon will appear on the second line of the
Ready screen to remind you that you have a stored message.
i
78
www.motorola.com/iden
Viewing Stored Messages
Net Mail
With Net Mail, you can send text and numeric messages in any of three ways:
•from your i30sx phone
•from a web site provided by your service provider
•from any email application
When you receive a new message:
•Words will display on your phone’s display screen indicating that you have
a Net Mail message. (The exact words displayed are determined by your
service provider.)
•Your phone will alert you every 30 seconds until your press Bto access
the message or press Ato exit the screen.
If you choose to exit the screen and view the message later, the .icon will
appear on the second line of the Ready screen to remind you that you have a
stored message.
You can view new or stored Net Mail messages at any time by access the
Message Center. For more information, see “Message Center”on page 73.
1
In the Message Center screen, press Sto scroll down to Text Msgs.
The number of new messages and the total number of messages are
displayed.
2
Press Bunder SELECT. The Text Msg Inbox screen appears.
3
Press Sto scroll to the message you want to read and press Bunder
READ.
4
If the message fills more than one screen, use Sto scroll through the
rest of the message.
5
Press Aunder SAVE to save the message.
Or,
Press Bunder DELETE to delete the message.
79
Using Your Phone as a Modem
Using Your Phone as a Modem
NOTE: Some features may be network dependent or subscription only,
and may not be available in all areas. Contact your service
provider for more information.
You can use your i30sx phone as a modem for data transfer from your laptop,
handheld device, or desktop computer. This is particularly useful when there is
no wired phone line (wall jack) available.
You simply attach a data cable (available separately) to your phone and your
computer. From that point, your phone is your modem. This allows you to send
or receive time-critical information such as email, a field service report, or files.
In addition, you can also send or receive faxes.
This type of wireless connection uses one of two types of data connection:
circuit-switched data and packet data.
•Circuit-switched data is typically used for sending and receiving faxes and
for transferring large files.
•Packet data is used for small file transfers such as email.
To use these services, you must install the iDEN Wireless Data Services
software (available separately). For more information on setting up your
computer and your i30sx phone for Packet and Circuit Data calls, see the
Wireless Data Services User’s Guide and contact your carrier.
80
www.motorola.com/iden
81
Private Calls
The main topics covered in this section are listed below:
Private Call
There are several ways to reach an individual using Private calls. Whether you
dial the person’s Private ID directly or store it in your Phonebook or Recent
Calls list, you must have the individual’s Private ID to use Private calls. To learn
how to store names and numbers, see “Phonebook”on page 39.
USER TIP:To find out your own Private ID number, see “My
Information”on page 25.
Making a Private Call from the Keypad
Making a Private Call from the Phonebook
If you have stored a person’s Private ID in your Phonebook, you can use your
Phonebook to make a Private call to that person:
Private Call Page 81
Call Alerts Page 83
Group Call Page 87
1
Enter the Private ID of the person you are trying to call.
2
Press and hold the Push-To-Talk button (PTT) button on the side of the
phone. Begin talking after the phone emits a chirping sound.
3
Release the PTT button to listen.
1
From the Ready screen, press m.
2
Press Rto scroll to the Phonebook.PressBunder SELECT.
82
www.motorola.com/iden
Making a Private Call from the Recent Call List
Receiving a Private Call
When you receive a Private call, your phone emits a chirping sound and Private
in Use appears on the screen. The Private ID or the name of the caller (if stored
in your Phonebook) displays on the screen.
To respond to a Private Call:
3
From the Phonebook screen, press Sto scroll through the names until
the desired name is highlighted.
4
Press and hold the PTT button on the side of the phone. Begin talking
after the phone emits a chirping sound.
5
Release the PTT button to listen.
1
From the Ready screen, press m.
2
Press Rto scroll to the Recent Calls.PressBunder SELECT.
3
From the Recent Calls screen, press Sto scroll through the names and
numbers until the desired name or Private ID number is highlighted.
4
Press and hold the PTT button on the side of the phone. Begin talking
after the phone emits a chirping sound.
5
Release the PTT button to listen.
1
Wait for the caller to stop speaking.
2
Press and hold the PTT button. Begin talking after the phone emits a
chirping sound.
3
Release the PTT button to listen.
83
Call Alerts
Storing Private IDs
For information store Private ID numbers to your Phonebook, see “Adding
Phonebook Entries”on page 44.
For information on how to quickly store Private ID numbers, see “Storing
Numbers Fast”on page 48.
Call Alerts
You can send a call alert, which lets recipients know that you would like to talk
with them. When you send an alert, the recipient will receive a series of beeps
and your name or Private ID will appear on the display.
Placing a Call Alert from the Keypad
Placing a Call Alert from the Phonebook
1
Enter the Private ID of the person you want to call.
2
Press Bunder ALERT. The ReadytoAlertscreen displays.
3
Press and hold the PTT button until Alert Successful displays. The alert
sounds intermittently until the user of the phone answers, queues, or
clears the alert.
1
From the Ready screen, press m.
2
Press Rto scroll down to Phonebook.PressBunder SELECT.
3
From the Phonebook screen, press Sto scroll to the Phonebook entry
for the person you want to alert.
84
www.motorola.com/iden
Ready to Alert Screen
ReadytoAlertis used to confirm your request for the alert and to prompt you
to push the PTT button:
•If you press the PTT button, the call alert is sent, and the phone displays the
Recent Calls screen.
•For call alerts placed from the keypad, pressing Aunder CANCEL causes
the phone to return to the Dial screen with the previously entered number
displayed.
•For call alerts placed from the Phonebook, pressing Aunder CANCEL
causes the phone to return to the Phonebook screen.
•If you do nothing, the phone will revert to the Ready screen.
Receiving Call Alerts
When you receive a call alert, your phone emits a chirp and displays the name or
number of the caller. You can answer, queue, or clear the call alert:
•To answer a call alert, press the PTT button.
•To queue a call alert, press Bunder QUEUE.
•To clear the call alert, press Aunder CLEAR.
4
Press Bunder ALERT. The Ready to
Alert screen appears.
5
Press and hold the PTT button until Alert Successful displays. The alert
sounds intermittently until the user of the phone answers, queues, or
clears the alert.
V
85
Call Alerts
Call Alert Queue
Call alert queuing enables you to save call alerts in a list, or queue. To store a
call alert in the call alert queue, press Bunder QUEUE when you have received
an incoming call alert.
Accessing the Call Alert Queue
Viewing Call Alert Date and Time
Tofindoutthedateandtimeacallalertwasreceived:
Sorting Call Alerts
To sort your call alerts by the order they were received:
1
From the Ready screen, press m.
2
Press Rto scroll to Call Alert.
3
Press Bunder SELECT. The Call Alert Queue screen displays.
1
From the Call Alert Queue screen, press Sto scroll to the desired call
alert.
2
Press mto access Call Alert Menu.
3
Press Rto scroll to View.
4
Press Bunder SELECT.
1
From the Call Alert Queue screen, press mto access Call Alert
Menu.
2
Press Sto scroll to Sort By.
3
Press Bunder SELECT.
86
www.motorola.com/iden
Responding to a Call Alert From the Queue
Deleting a Call Alert From the Queue
To delete a call alert from the queue:
4
Press Sto scroll to First on Top or Last on Top.
5
Press Bunder SELECT.
1
From the Call Alert Queue screen, press Sto scroll to the call alert
you want to respond to. You can respond by sending a call alert or
placing a Private call.
2
To send a call alert, press Bunder ALERT and then press the PTT
button.
Or,
To place a Private call, press the PTT button.
The call alert will be removed from the queue.
1
From the Call Alert Queue screen, press Sto scroll to the entry you
want to delete.
2
Press mto access Call Alert Menu.
3
Press Rto scroll to Delete.
4
Press Bto SELECT.
5
When the confirmation screen appears, press Bunder YES to delete all
call alerts.
87
Group Call
To delete all call alerts from the queue:
Group Call
In a Group call, you can communicate instantly with a group of people that you
have previously set up as a Talkgroup. Your sales representative must set up
your Talkgroups by providing you with a Talkgroup number for each
Talkgroup. After you have the number, you can assign each Talkgroup number a
name and store it in your phone (see “Storing a Talkgroup”on page 87).
Talkgroups appear on your display as numbers or programmed names such as
SALES TEAM or Talkgrp 5. Your phone can store up to 30 Talkgroups. You
can initiate or participate in Group calls for Talkgroups that have been created
for you and that are stored in your Phonebook.
Storing a Talkgroup
1
From the Call Alert Queue screen, press mto access Call Alert
Menu.
2
Press Rto scroll to Delete All.
3
Press Bto SELECT.
4
When the confirmation screen appears, press Bunder YES to delete
the entry.
1
From the Ready screen, press m.
2
Press Rto scroll to Phonebook.
3
Press Bunder SELECT.
4
Press Sto scroll to New Entry.
5
Press Bunder SELECT. The Entry Details screen displays.
6
Enter the information as you would any other Phonebook entry. (See
“Adding Phonebook Entries”on page 44.) When you get to Type,make
sure that you select Talkgroup.
88
www.motorola.com/iden
Making a Group Call from the Keypad
Making a Group Call from the Phonebook
Making a Group Call from the Recent Calls List
7
Enter the Talkgroup name or number.
8
When you have completed the Entry Details,pressAunder DONE.
1
Press #and then enter the Talkgroup number of the group that you
want to call.
2
Press and hold the PTT button on the side of the phone or press B
under ALERT, and speak. The phones of individuals in the Talkgroup
will emit a chirping sound to alert them that someone is calling.
3
Release the PTT button to listen.
1
From the Phonebook screen, press Rto scroll to the name of the
Talkgroup you want to call.
2
Press and hold the PTT button on the side of the phone or press B
under ALERT, and speak. The phones of the people in the Talkgroup
will emit a chirping sound to alert them that someone is calling.
3
Release the PTT button to listen.
1
From the Recent Calls screen, press Rto scroll to the name of the
Talkgroup you want to call.
2
Press and hold the PTT button on the side of the phone or press B
under ALERT, and speak. The phones of individuals in the Talkgroup
will emit a chirping sound to alert them that someone is calling.
3
Release the PTT button to listen.
89
Group Call
Receiving a Group Call
When you receive an incoming Group call, your phone emits a chirp.
To respond to a Group call:
Group-Silent Programming
Group-Silent programming enables you to silence incoming Group alerts and
communication.
Turning Group-Silent On or Off
1
Wait for the caller to finish speaking.
2
Press and hold the PTT button to talk. Release the PTT button to listen.
1
From the Ready screen, press m.
2
Press Rto scroll to Settings.PressBunder SELECT.
3
Press Rto scroll to Tkgrp Settings.PressBunder SELECT.
4
With the Silent field highlighted, press Bunder CHANGE.
5
Press Sto scroll to On or Off.
6
Press Bunder SELECT.
90
www.motorola.com/iden
91
Memo
The Memo application provides you with a place to store a numeric note (for
example a phone number) in your i30sx phone.
This section includes:
Adding a New Memo
Viewing a Memo
Adding a New Memo Page 91
Viewing a Memo Page 91
Editing a Memo Page 92
Deleting a Memo Page 92
1
From the Ready screen, press m.
2
Press Rto scroll to Memo.
3
Press Bunder SELECT. The Memo screen displays.
4
Type your numeric memo using the phone’s keypad.
5
Press Bunder STORE.
1
From the Ready screen, press m.
2
Press Rto scroll to Memo.
3
Press Bunder SELECT.
4
To call this number, press e.
92
www.motorola.com/iden
Editing a Memo
Deleting a Memo
1
From the Ready screen, press m.
2
Press Rto scroll to Memo.
3
Press Bunder SELECT.
4
Type the new number.
You can delete a digit by pressing Aunder DELETE. To all the digits,
press and hold Aunder DELETE.
5
Press Bunder STORE.
1
From the Ready screen, press m.
2
Press Rto scroll to Memo.
3
Press Bunder SELECT.
4
Press and hold Aunder DELETE.
5
Press Bunder STORE.
93
Customizing the i30sx phone
You can customize your i30sx phonetofitthewayyouwanttouseit.
This section includes:
Settings
The phone’s Settings menu enables you to control many of the phone’sfeatures
and functions, including display properties, message handling, and security
features.
To access the Settings menu:
From the Settings screen, you can access these Settings options:
•Ring/Vibe —controls how your phone rings or vibrates (VibraCallTM)
when you receive calls and messages.
•Phone Setup —sets call-answering features, turns off non-telephone
features, chooses which phone line is used, and sets your network ID.
•In Call Setup —sets call timer, message notification, and call waiting
features.
•Security —sets security features including phone lock, keypad lock, and
SIM PIN.
•Personalize —controls which features are most accessible when you turn
on your phone.
•Initial Setup —sets a variety of display features including the language
displayed, the screen contrast, time and date formats, current year,
backlight, status light, and scrolling. Also turns auto redial on or off and
sets baud rate.
•VoiceVolume —sets the volume of your phone’s earpiece and speaker.
Settings Page 93
1
From the Ready screen, press m.
2
Press Sto scroll to Settings.
3
Press Bunder SELECT.
94
www.motorola.com/iden
•Tkgrp —sets certain Talkgroup options.
•Service Status —shows the status of your phone’sservices.
To access any of these options:
Many of these options have other options within them. Press Sto scroll
through the lists of options, and press Ato select and modify options and the
features, according to the instructions on your phone’s screen. For some options,
you can also press Tto select sub-options.
In screens that show lists of options for a setting, a check mark to the left of the
option indicates the current option for the setting.
Ring/Vibe
Ring/Vibe enables you to control how your phone rings and vibrates
VibraCall®*when you receive calls and messages. You can set ring volume,
choose ring styles, and use the vibrate alert feature which enables you to set
your phone to alert you to calls and messages by vibrating.
Main Options
Ring/Vibe provides these main options:
•Ringer Vol —sets ring volume.
•Keypad Vol —sets volume of sounds associated with keypad actions.
•Mail Vol —sets volume of Text Message, Voice Mail, and Net Mail
notifications.
•Headset —choosing the HdsetOnly option prevents sound from being
emitted from the phone’s speaker when the headset is being used.
•VibeAll (VibraCallTM)—choosing On sets the phone to vibrate for all
calls, messages, and alerts; choosing Off enables you set the type of
notification for each these features.
1
From the Settings screen, press Rto scroll to the option you want to
access.
2
Press Bunder SELECT.
95
Settings
Ring Style and Notification Type
When you set VibeAll to On, your phone vibrates to notify you of all types of
calls, messages, and alerts.
When you set VibeAll to Off, the following features display after VibeAll on
the Ring/Vibrate screen, enabling you to set notification options for each:
•Line 1 —sets the ring style and type of notification for calls on Line 1.
•Line 2 —sets the ring style and type of notification for calls on Line 2.
•Pvt/Grp —sets type of notification for private and group calls.
•Call Alert —sets the ring style and type of notification for call alerts.
•Text Msgs —sets type of notification for Text Messages.
•Reminder —sets type of notification for Datebook reminder alarms.
•Voicemail —sets type of notification for Voice Mail messages.
•Netmail —sets type of notification for Net Mail messages.
To set VibeAll to Off or On:
The following icons appear on your display screen to indicate the options you
have chosen:
1
From the Ring/Vibrate screen, press Sto scroll to the VibeAll:.
2
Press Bunder CHANGE.
3
Press Sto scroll to Off or On.
4
Press Bunder SELECT.
Icon Indicates...
-Vibrate All - phone is set to vibrate when
you receive all types of calls, messages,
and alerts; the VibeAll option is On.
[Vibrate On - phone is set to vibrate when
you receive phone calls.
96
www.motorola.com/iden
Ring Styles
When you set a ring style, you can choose from any of nine pre-set ring styles.
To set a ring style:
USER TIP:To hear the ring style you have selected, press the volume
button on the side of your phone.
Notification Types
When you set a notification type, you have these options:
•Ring —the phone rings to notify you.
•Vibe —the phone vibrates to notify you.
•Vibe/Ring —the phone vibrates and then rings to notify you. This option
is only available for calls on Line 1 and Line 2.
•Silent —the phone does not ring to notify you.
\Vibrate Then Ring - phone is set to
vibrate and then ring when you receive
phone calls.
*Silent - phone is set not to ring.
1
From the Ring/Vibrate screen, ensure that VibeAll is set to Off.Then
press Sto scroll to any of the features that allow you to set a ringer
style: Line1,Line2,orCall Alert.
2
Press Bunder SELECT.
3
With the Style: field highlight, press Bunder CHANGE.
4
Press Rto scroll to the ring style you want to assign to the feature.
5
To assign the ring style, press Bunder SELECT.
97
Settings
To set a notification type:
Phone Setup
Phone Setup sets some basic phone features. Access Phone Setup to set the
following options:
•Line —enables you to choose Line 1 or Line 2 as the active line for
outgoing calls.
•AutoAns —sets your phone to automatically answer an incoming call
after a specified number of rings. When this feature is turned on, the phone
answers by connecting you to the caller; it does not send the call to Voice
Mail, unless you are out of coverage or on the line.
•Any Key —when turned on, enables you to answer calls by pressing any
key on the alphanumeric keypad.
•Phone Only —when turned on, prevents your phone from making or
receiving Private calls or Group calls.
•Network ID —enables you to set the phone’snetworkIDsandtheir
roaming options.
In Call Setup
In Call Setup sets the in-call timer, message notification, and call-waiting
features.
•The In Call Timer option turns the following features on and off:
•Display —the duration of each call displays on the phone’s screen.
1
From the Ring/Vibrate screen, ensure that VibeAll is set to Off.Then
press Sto scroll to any of the features on the Ring/Vibrate screen
after VibeAll.
2
Press Bunder SELECT.
3
With the Type: field highlighted, press Bunder CHANGE.
4
Press Rto scroll to the notification type you want to assign to the
feature.
5
To assign the notification type, press Bunder SELECT.
98
www.motorola.com/iden
•Minute Beep —an audible beep occurs every minute of an active
call.
•The Notifications option controls message notification during calls:
•Receive All —notifies you of all types of messages during calls.
•Msg Mail Only —notifies you of mail messages only; all other types
of message notifications are delayed until the call has ended.
•Delay All —delays notification of all messages until the call has
ended.
•Call Waiting —enables you to turn off call waiting for the next call. After
you hang up, call waiting is turned back on.
Security
Security allows you to set security features:
•Phone Lock —sets an optional code that locks your phone.
•Keypad Lock —displays instructions for locking and unlocking your
phone’skeypad.
•SIM PIN —enables and disables your phone’s SIM PIN requirement.
•New Passwords —enables you to change your phone’s security code,
phone unlock code, and SIM PIN.
•Master Reset —allows your service provider to reset your service in the
event of a security or provisioning problem.
Using Phone Lock
The Phone Lock feature enables you to prevent your phone from being used
unless an Unlock code is typed into the keypad.
The Unlock code is required to enable the phone lock feature, to unlock the
phone, and to set a new Unlock code. Contact your service provider for your
default Unlock code.
Phone lock provides two options for locking the phone:
•Lock Now locks the phone immediately after you set the option.
•Auto Lock locks the phone the next time the phone is powered on.
99
Settings
Setting Keypad Lock
Choosing the Keypad Lock option displays instructions for locking and
unlocking your phone’s keypad. See “Keypad Lock”on page 21 for more
information on locking the keypad.
Enabling and Disabling SIM PIN
The SIM PIN option enables and disables the feature that requires a SIM PIN
code to be typed into the phone to access the information on the SIM card and to
make or receive calls. See “SIM Card Personal Identification Number (PIN)”on
page 15 for more information.
Setting New Passwords
The New Passwords option enables you to set three types of passwords that
control access to your phone:
•Unlock Code —this code is used to control access to the phone using
Phone Lock. It is also required to access the Master Clear and Feature
Reset features. If you want to use any of these features, contact your
service provider for your default Unlock code.
•Security Code —this code is used to access the Master Reset feature
under the direction of your service provider. It can also be used to override
your Unlock code under the direction of your service provider.
•SIM PIN —this code is used to access the information on your SIM card
and to make or receive calls. Using Master Reset
The Master Reset option is provided for use only under the direction of your
service provider. It resets your service..
Reordering Main Menu
1
From the Personalize screen with Main Menu highlighted, press B
under SELECT to access the Reorder Menu screen.
2
Press Sto scroll to the main menu option you want to move.
3
Press Bunder GRAB.
4
Press Sto move the option up or down in the list.
100
www.motorola.com/iden
Changing Ready Screen Options
TwooptionsfromthemainmenualwaysappearonyourReady screen above
the left and right option keys. Each option can be accessed by pressing the
corresponding option key.
Your phone arrives with Phonebook (PHBK) assigned to the left option key and
Messages (MESG) assigned to the right option key (B). You can assign any
Main Menu option you want to the option keys.
5
When the item is where you would like it to appear in the main menu,
press Bunder INSERT.
6
Repeat step 2 through step 5 for all main menu items you want to move.
7
Press Aunder DONE.
1
From the Personalize screen, press Rto scroll to Keys.
2
Press Bunder SELECT. The Keys screen shows the option assigned to
each option key (Left and Right).
3
To change the option assigned to the left option key, press Bunder
CHANGE while Left is highlighted.
4
Press Rto scroll to the option you want to assign to the left option key.
5
Press Bunder SELECT.
6
To change the option assigned to the right option key, press Rto
highlight Right and press Bunder CHANGE. Repeat steps 4 and 5 for
the right option key.
101
Settings
Changing Power-Up Program
Your phone is set to display the Ready screen when it is powered on. You can
set the phone to display the main screen of any main menu option when it is
powered on.
Initial Setup
Initial Setup enables you to control a variety of your phone’sfeaturesthatyou
may want to modify when you first get your phone:
•Time/Date Format —sets the format in which the time and date display
on your phone.
•Year —sets the current year.
NOTE: Changing the current year may affect stored Datebook events.
Datebook stores events 12 months ahead and one month before
the current date. Events outside this range will be deleted. See
“Datebook”on page 91 for more information.
•Auto Redial —turns the automatic redial feature on and off.
•Backlight —controls how long your phone’s backlight stays on.
•Status Light —controls whether the status light is on when the phone is
on.
•Scroll —sets how you can scroll lists and menus.
•Language —sets the language that your phone displays.
•Master Clear —returns all settings to their original defaults and erases all
stored lists. Use only under the direction of your service provider.
1
From the Personalize screen, press Rto scroll to Power Up App.
2
Press Bunder SELECT. The Power Up App screen shows the name
of the program or screen that currently appears when the phone is
powered on.
3
Press Bunder CHANGE.
4
Press Rto scroll to the option you want to appear when the phone is
powered on.
5
Press Bunder SELECT.
102
www.motorola.com/iden
•Feature Reset —returns all settings to their original defaults. Use only
under the direction of your service provider.
•Baud Rate —sets the baud rate at which your phone communicates when
connected to a laptop computer, PC, or similar device.
•TTY Setup —sets TTY options. By default, your phone is set to function
with a TTY device.
•TTY Baud Rate —sets the baud rate at which your phone communicates
when connected to a TTY device.
Changing Time and Date Format
Your phone displays times in 12-hour-clock format (12:00 am through 11:59
pm) or 24-hour-clock format (0:00 through 23:59). It displays dates in month/
day format or day/month format.
NOTE: If you turn the time and date display off, no times are associated
with calls on your Recent Calls list, and the alarm feature of
your Datebook is disabled.
To set the time and date format, or turn time and date display on or off:
1
From the Initial Setup screen with Time/Date Format highlighted,
press Bunder SELECT to access the Time/Date Format screen.
2
To change the time format:
With Time Format: highlighted, press Bunder CHANGE to access
the Time Format screen.
Press Sto highlight the time format you want.
Press Bunder SELECT.
103
Settings
SettingAutoRedial
When Auto Redial is set to On, if you receive a System Busy, Try Later
message while making a call, the phone will redial the number automatically.
You will hear a ring-back tone when a successful call is placed.
When Auto Redial is set to Off, you must press and hold eto redial the last
number dialed.
Setting Backlight Timer
The backlight illuminates the display when you receive or make calls. You can
set the amount of time that the backlight stays on to 5, 10, 20, or 30 seconds, or
set it to stay on continuously or stay off at all times.
3
To change the date format:
Press Sto highlight Date Format:, and press Bunder CHANGE to
access the Date Format screen.
Press Sto highlight the date format you want.
Press Bunder SELECT.
4
To turn the time and date format on or off:
Press Rto highlight Display:,andpressBunder CHANGE to access
the Display screen.
Press Sto choose Off or On.
Press Bunder SELECT.
1
From the Initial Setup screen, press Rto scroll to Backlight.
2
Press Bunder CHANGE.
3
Press Sto scroll to the desired backlight option.
4
Press Bunder SELECT.
104
www.motorola.com/iden
NOTE: Setting the backlight to stay on continuously will decrease the
amount of time you can use the phone before recharging the
battery.
Adjusting Status Light
The status light is located on the top of the phone. It illuminates when the phone
is on. See “Status of Your i30sx Phone”on page 24. You can turn the status
light feature on or off from the Initial Setup screen.
Setting Scrolling
You can set your phone to scroll through menus and lists in either of two ways:
•Up/Down —when you reach the bottom or top of list or menu scrolling
stops until you scroll in the other direction.
•Wrap Around —when you reach the bottom or top of a list or menu
scrolling “wraps”around and continues at the other end of the list or menu.
You can set the scrolling style from the Initial Setup screen using the Scroll
option.
Changing Display Language
You can customize the i30sx phone to display menus in English, French,
Spanish, or Portuguese. The default language is English.
To change the display language:
Master Clear
Master Clear returns all your phone’s settings to their original defaults and
erases all stored lists. To use this feature, you must contact your service provider
to receive your phone’s Unlock code.
1
From the Initial Setup screen, press Rto scroll to Language.
2
Press Bunder CHANGE.
3
Press Rto scroll to the language you want your phone to display.
4
Press Bunder SELECT.
105
Settings
Feature Reset
Feature Reset returns all your phone’s settings to their original defaults. To use
this feature, you must contact your service provider to receive your phone’s
Unlock code.
Setting Baud Rate
You can set your phone’s baud rate from the Initial Setup screen. Scroll to the
Baud Rate option and then choose the baud rate you want, or choose Auto to
set your phone to automatically choose the appropriate baud rate.
Setting TTY Mode
TTY Setup enables you to set your options for using your phone with a
teletypewriter (TTY) device. By default, your phone is set to function with a
TTY device in TTY mode.
Your phone supports the following TTY modes:
•TTY —for calls in which you type and read text on your TTY device.
•VCO (Voice-Carry-Over) —for calls in which you speak into your phone
and read text replies on your TTY device.
•HCO (Hearing-Carry-Over) —for calls in which you type text on your
TTY device on listen to voice replies on your phone’s speaker.
You can set your TTY mode using your phone’sSettings menu at any time, or
by issuing commands from your TTY device while on an active call.
To set your phone’s TTY mode using your phone’sSettings menu:
To set your phone’s TTY mode from your TTY device, issue one of the
following commands while on an active call:
•“VCO please”—to select VCO mode.
1
From the Initial Setup screen, press Rto scroll to TTY Setup.
2
Press Bunder CHANGE.
3
Press Sto scroll to the desired TTY mode; Off,TTY,VCO,orHCO.
4
Press Bunder SELECT.
106
www.motorola.com/iden
•“HCO please”—to select HCO mode.
•“HCO off please”—to turn off HCO mode.
NOTE: TTY device manufacturer’s proprietary feature such as Turbo-
Code, High-Speed, and Interruption are not supported by your
phone. These features must be turned off or disabled to use
your TTY device with your phone.
Setting TTY Baud Rate
By default, your phone’s TTY baud rate is set to 45.45, the baud rate required
for TTY calls within the US. To make calls outside the US, set your TTY baud
rate to 50.0.
To change the TTY baud rate:
VoiceVolume
VoiceVolume sets the volume of the sound coming from your phone’searpiece
or speaker:
When you are using HCO, the sound coming from
your phone speaker may be uncomfortably loud.
Use caution when putting the phone to your ear.
(For information on setting your phone’s speaker
volume, see “VoiceVolume”on page 106.)
1
From the Initial Setup screen, press Rto scroll to TTY Baud.
2
Press Bunder CHANGE.
3
Press Sto scroll to the baud rate for your location.
4
Press Bunder SELECT.
1
From the VoiceVolume screen, highlight Earpiece Vol: to set the
earpiece volume, or press Rto scroll to Speaker Vol: to set the
speaker volume.
2
Press Bunder CHANGE.
!
W A R N I N G
!
107
Settings
Tkgrp (Talkgroup) Settings
Tkgrp Settings enables you to set certain Talkgroup options. See “Group Call”
on page 87 for more information.
Service Status
The Service Status screen shows the status of your phone’s services. This screen
is for information only; no options can be set.
Setting Call Filtering
The Call Filter feature enables you to control which calls, messages, and alerts
your phone responds to, and which it ignores.
From the Call Filter screen, you set separate filtering options for phone calls,
private and group calls, alerts, and messages:
•Phone —sets filtering options for phone calls.
•Prvt/Grp —sets filtering options for Private and Group calls.
•Alerts —sets filtering options for call alerts.
•Notifications —sets filtering options for messages.
Setting Phone Call Filtering
Call Filter enables you to set your phone to respond to all calls, no calls, or only
calls from some or all numbers in your Phonebook:
•Off sets your phone notify you of all calls.
•All sets your phone to ignore all calls.
3
Toselectavolumelevel:
Press Tto raise of lower the volume setting.
Or,
Press the Volume Control buttons on the side of your phone.
4
Press Bunder OK.
108
www.motorola.com/iden
•All Phonebook sets your phone to notify you only of calls from the
numbers stored in your Phonebook.
•Some Phonebook sets your phone to notify you only of calls from
numbers you select from your Phonebook. You may choose up to five
Phonebook entries.
To choose Phonebook entries that you want your phone to respond to calls from:
Setting Private and Group Call Filtering
Setting Prvt/Grp to On sets your phone to ignore all Private and Group calls.
Setting Prvt/Grp to Off sets your phone to respond to all Private and Group
calls.
Setting Alert Filtering
Setting Alerts to On sets your phone to ignore all call alerts. Setting Alerts to
Off sets your phone to respond to all call alerts.
1
From the Call Filter screen, press Rto scroll Phone:.
2
Press Bunder CHANGE.
3
Press Rto scroll to Some Phonebook.
4
Press Bunder SELECT. The entries stored in your Phonebook appear.
5
To select a Phonebook entry as one you want to your phone to respond
to, press Sto scroll to the Phonebook entry and press Bunder
SELECT.
A check mark appears next to each selected Phonebook entry. You may
select up to five Phonebook entries.
6
To remove a selected Phonebook entry from the list, press Sto scroll
tothenameandpressBunder SELECT.
7
When you have selected the Phonebook entries you want, press A
under DONE.
109
Setting Message Notification Filtering
Call Filter enables you to set your phone to notify you of some types of
messages, all types of messages, or no messages:
•Off allows your phone to notify you of all messages.
•Voice Messages allows your phone to notify you of Voice Mail messages.
•Text Messages allows your phone to notify you of Text Messages
messages.
•All prevents your phone from notifying you of all messages.
Call Filter can prevent your phone from ringing or vibrating when you receive a
message. Your display screen will still indicate that you have messages.
110
www.motorola.com/iden
111
Accessories
To order additional accessories, log on to our Web site at: www.motorola.com/
store/iden or contact your Motorola Authorized Retailer.
This section includes the following topics:
Carrying Solutions
Swivel Carry Clip
The Swivel Carry Clip provides a convenient means by which to carry your
i30sx phone with you. It consists of the Phone Clip and the Belt Clip.
Carrying Solutions Page 111
Batteries Page 114
Travel Chargers Page 115
Data Accessories Page 117
Phone Clip
Belt Clip
112
www.motorola.com/iden
Using the Swivel Carry Clip
1
Ensure that the phone is powered off before attempting to detach the
battery.
2
Attach the Phone Clip to the phone by removing the battery.
Holding the phone face down, remove the battery by sliding the battery
release button backwards, while lifting in an upward and outward
motion.
3
Slide the Phone Clip under the slotted lip
and reattach the battery.
4
Slide the Phone clip into the belt clip until a secure click is heard.
Battery Release
Button
113
Carrying Solutions
Removing the Swivel Carry Clip
1
Ensure that the phone is powered off before attempting to detach the
battery.
2
Holding the phone face down, remove the battery by sliding the battery
release button backwards, while lifting in an upward and outward
motion.
3
Slide the Phone clip in a downward motion.
This will unclip the assembly from the phone..
Battery Release
Button
114
www.motorola.com/iden
Batteries
For best results, charge the batteries within the temperature range of 10oCto
40oC(50
oF to 104oF).
Prolonged charging is not recommended. For battery charging guidelines, see
Table below.
Charging Lithium Ion Batteries
Table 2 provides the approximate time to fully charge a battery using a
Motorola iDEN Approved Lithium Ion battery charger. Check the kit number on
your battery and charger to determine the appropriate charging time.
Table 2: Battery Charging Times
NOTE:Charging times are based on a fully discharged battery.
For optimal battery life, use a Motorola iDEN Approved Lithium Ion battery
charger with your Motorola iDEN Lithium Ion battery. Other chargers may not
fully charge your Lithium Ion battery.
Battery Operating Instructions
•Extreme temperatures will degrade battery performance. Do not store your
battery where temperatures exceed 60°C(140°F) or fall below -20°C(4°F).
•Lithium Ion batteries have a self discharge rate and without use, will lose
about 1% of its charge per day.
MOTOROLA BATTERIES Charging Time to 100%
Item
Number Description/
Chemistry Economy
Charger
(SPN4808)
Rapid
Charger
(NTN4716)
Mid-Rate
Charger
(SPN4940)
SNN5716 Slim Li Ion
Battery 4 hours 2 hrs 30 min 4 hours
SNN5705 High
Performance Li
Ion Battery
5 hours 2hrs 30min 5 hours
115
Travel Chargers
•The battery capacity will be degraded if stored for long periods while fully
charged. If long term storage is required, store at half capacity.
•The Motorola iDEN Approved Lithium Ion chargers will provide optimum
performance. Other chargers may not fully charge your iDEN Lithium Ion
battery or may yield reduced number of lifetime charge cycles.
•If the battery appears inoperative, the internal protection circuitry may
have been activated. Remove the battery from the phone and put it into the
charger for several minutes to reset the circuitry.
•When batteries are not in use, always store them in the plastic safety tray.
Travel Chargers
Using one of the Travel Chargers listed below, you can charge a battery from an
AC outlet. On one end of the Travel Charger, an accessory connector attaches to
the bottom of the phone. At the other (AC outlet) end of the device, there is a
compact housing that contains the plug-in power supply.
NOTE: Additional adaptor plugs to accommodate various International
power outlets can be purchased separately for the multi-voltage
Travel Chargers.
TRAVEL CHARGERS
Item
Number Description
SPN4940 Multi-Voltage Travel Charger
SPN4716 Rapid Multi-Voltage Travel Charger
SPN4808 Mid-Rate Economy Travel Charger
116
www.motorola.com/iden
Using the Travel Charger
1
While holding the phone with its keypad facing up, insert the accessory
connector (with the Motorola logo facing you) into the bottom of the
phone until you hear a click.
2
If you have either the Mid-Rate Multi-Voltage Travel Charger or the
Rapid Multi-Voltage Travel Charger, flip open the prongs, and plug the
Travel Charger transformer into an AC wall outlet.
Or
If you have the Mid-Rate Economy Travel Charger, plug the Travel
Charger transformer into an AC wall outlet.
Accessory
Connector
Rapid Travel Charger Economy Travel Charger
Accessory
Connector
117
Data Accessories
Data Accessories
The RS232 Data Cable facilitates quick and easy data synchronization between
your i30sx phone and a PC. This cable accommodates both circuit and packet
data applications. The cable also features a charging port. Any applicable phone
charger may be used to charge the phone simultaneously.
Using the Data Cable
1
While holding the phone with its keypad facing up, insert the accessory
connector (with the Motorola logo facing you) into the bottom of the
phone until you hear a click.
2
Insert the data plug directly into your PC or one of the many other data
compatible iDEN accessories.
Port for charging source
118
www.motorola.com/iden
Dual Port Adapter Cable
The Dual Port Adapter Cable enables in-vehicle communications and charging
of the i30sx phone via the Hands-Free Car kit, while being simultaneously
connected for data operations.
Using the Dual Port Adapter Cable
1
Insert the flat end of the Dual Port Adapter Cable cord into the bottom
connector of the i30sx phone. Make sure the Motorola logo is facing
upward.
2
Insert the round end of the RS232 Data Cable into the receptacle on the
Dual Port Adapter Cable labeled “Data”.
3
Insert the Hands-Free Car Kit into the receptacle on the Dual Port
Adapter Cable labeled “Car Kit”.
DATA
CAR KIT
119
Data Accessories
PDA Converter Plugs
The PDA (Pocket Digital Assistant) plug is a convenient way to connect your
i30sx phone to many types of PDA devices, both PC and Windows CE
compatible.
Below is the list of adapters which can be used with your i30sx phone:
Using the PDA Converter Plug
Item Number Description
NTN6546 Palm IIITM/VIITM Cable Adapter
NKN6547 Palm VTM Cable Adapter
NTN8993 Generic Pocket Digital Assistant (PDA) -Male-
Female Serial Adapter (Not Shown)
1
While holding the phone with its keypad facing up, insert the accessory
connector (with the Motorola logo facing you) into the bottom of the
phone until you hear a click.
2
Connect the opposite end of the data cable to the PDA converter.
NTN6546 and
NTN6547 Type Plug
120
www.motorola.com/iden
NOTE:Please see the label on the bottom of your Dual-Pocket Desktop
Charger for more information regarding battery charging status.
Universal Serial Bus (USB)
Your user will be able communicate with USB capable laptop and desktop
computers.
USB capable i30sx phone supports both RS232 communications and USB
communications (with USB mother devices). The i30sx phone will
automatically detect whether an RS232 or USB cable has been connected to it
and will utilize the appropriate protocol accordingly. No other action is required
by the user in order to select between USB or RS232 serial communications.
iDEN PC applications will support USB drivers for the following operating
systems only:
•Windows 98 Second Edition (SE)
•Windows 2000
3
Connect other end of PDA converter to the mating connector of the
PDA device.
4
If you are using the NTN8993 PDA adapter, connect the other end of
the adapter to the PDA’s supplied data synchronization cradle and place
the PDA into the cradle.
USB Cable End
Phone Cable End
121
Data Accessories
PC Applications Supported
•RSS
•Tethered Circuit Data
•iDEN CompanionPro
•SDK (Windows only, Palm SDK not supported)
•iDEN Update ~ after first upgrade
•iDEN Applet for Data Services
122
www.motorola.com/iden
123
Other Important Information
This section includes the following topics:
Understanding Status Messages
The following table lists and describes the status messages.
Understanding Status Messages Page 123
Safety and General Information Page 125
Limited Warranty Information Page 135
Patent and Trademark Information Page 143
Status Messages Message Description
Number Not in Service The number that you entered is not valid.
User Not Available The phone that you called is either busy, out-
of-coverage, or turned off. Please try again
later.
User Not Authorized The person that you called has not purchased
this service.
Please Try Later This service is temporarily not available.
Please try again later.
User Busy in Private The phone that you called is busy in a Private
call.
User Busy in Data The phone that you called is busy in a Dial-Up
call.
Service Restricted This service was restricted by your service
provider, or this service was not purchased.
Service Not Available This feature is not available on the current
network.
124
www.motorola.com/iden
System Busy Try
Later
The system is experiencing heavy traffic.
Please try again later.
Service Conflict This service cannot be enabled because an
incompatible service has already been turned
on.
Please Try Again An error occurred. Please try again.
Self Check Error A fault was detected with your phone. If this
error recurs, note the error code and contact
Customer Care.
Self Check Fail An operational fault was detected with your
phone. Note the numeric code, turn your phone
off, and contact Customer Care.
PIN Blocked
Call Your Provider
The incorrect PIN was entered three
consecutive times. You will be unable to place
or receive calls on your i30sx phone. Call your
service provider to have them obtain the PIN
Unblocking Key (PUK) code.
Insert SIM Your SIM Card is not being detected. Please
check to ensure that you have inserted the SIM
Card.
Check SIM Card Please check your SIM Card to make sure it
has been inserted properly.
Wrong PIN You have entered an incorrect PIN number.
Wrong Code Your phone will not accept a SIM card that is
not from your carrier.
Status Messages Message Description
125
RF Operational Characteristics
Safety and General Information
RF Operational Characteristics
Your radio product contains a radio frequency transmitter to convey the
information you wish to send as well as occasional automatic signals used to
sustain connection to the wireless network, and a receiver which enables you to
receive communication and connection information from the network.
PORTABLE RADIO PRODUCT OPERATION AND
EME EXPOSURE
Your Motorola radio product is designed to comply with the following national
and international standards and guidelines regarding exposure of human beings
to radio frequency electromagnetic energy (EME):
•United States Federal Communications Commission, Code of Federal
Regulations; 47 CFR part 2 sub-part J
•American National Standards Institute (ANSI) / Institute of Electrical and
Electronics Engineers (IEEE). C95. 1-1992
•Institute of Electrical and Electronics Engineers (IEEE). C95. 1-1999
Edition
•National Council on Radiation Protection and Measurements (NCRP) of
the United States, Report 86, 1986
•International Commission on Non-Ionizing Radiation Protection (ICNIRP)
1998
•Ministry of Health (Canada). Safety Code 6. Limits of Human Exposure to
Radiofrequency Electromagnetic Fields in the Frequency Range from 3
kHz to 300 GHz, 1999.
•Australian Communications Authority Radiocommunications
(Electromagnetic Radiation - Human Exposure) Standard 1999 (applicable
to wireless phones only)
IMPORTANT INFORMATION ON SAFE AND
EFFICIENT OPERATION.
READ THIS INFORMATION BEFORE USING
YOUR INTEGRATED MULTI-SERVICE
PORTABLE RADIO.
126
www.motorola.com/iden
To assure optimal radio product performance and make sure human
exposure to radio frequency electromagnetic energy is within the guidelines
set forth in the above standards, always adhere to the following procedures:
Phone Operation
When placing or receiving a phone call, hold your radio product as you would a
wireline telephone. Speak directly into the microphone.
Two-way radio operation
When using your radio product as a traditional two-way
radio, hold the radio product in a vertical position with
themicrophoneonetotwoinches(2.5to5cm)away
from the lips.
Body-worn operation
To maintain compliance with FCC RF exposure guidelines, if you wear a radio
product on your body when transmitting, always place the radio product in a
Motorola approved clip, holder, holster, case or body harness for this
product. Use of non-Motorola-approved accessories may exceed FCC RF
exposure guidelines. If you do not use a Motorola approved body-worn
accessory and are not using the radio product in the intended use positions
along side of the head in the phone mode or in front of the face in the two-
way radio mode, then ensure the antenna and the radio product is kept the
following minimum distances from the body when transmitting:
•Phone or Two-way radio mode: one inch (2.5 cm)
•Data operation using any data feature with or without an accessory
cable: one inch (2.5 cm)
Antenna Care
Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the radio product and
may violate FCC regulations.
DO NOT hold the antenna when the radio product is “IN USE”.Holding the
antenna affects call quality and may cause the radio product to operate at a
higher power level than needed.
127
PORTABLE RADIO PRODUCT OPERATION AND EME EXPOSURE
Approved Accessories
For a list of approved Motorola accessories call 1-800-453-0920, or visit our
website at www.mot.com/iden, or look in the accessory section of this manual.
ALL MODELS WITH FCC ID AZ489FT5818 MEET THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal
Communications Commission of the U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the general population. The guidelines
are based on standards that were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.*Tests for SAR are
conducted using standard operating positions reviewed by the FCC with the phone transmitting at
its highest certified power level in all tested frequency bands. Although the SAR is determined at
the highest certified power level, the actual SAR level of the phone while operating can be well
below the maximum value. This is because the phone is designed to operate at multiple power
levels so as to use only the power required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be tested and certified to the FCC
that is does not exceed the limit established by the government-adopted requirement for safe
exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body)
as required by the FCC for each model. The highest SAR value for this model phone when tested
for use at the ear is 1.4 W/kg and when tested on the body, as described in this user guide, is 0.419
W/kg during voice transmission using Phone Mode and 0.776 W/kg during packet data
transmission. (Body-worn measurements differ among phone models, depending upon available
accessories and FCC requirements.) While there may be differences between the SAR levels of
various phones and at various positions, they all meet the government requirement for safe
exposure.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR
levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this
model phone is on file with the FCC and can be found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID: AZ489FT5818.
Additional information on Specific Absorption Rates (SAR) can be found on the Cellular
Telecommunications Industry Association (CTIA) web-site at http://www.wow-com.com.
______________________________________
* In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6
watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin
of safety to give additional protection for the public and to account for any variations in
measurements.
128
www.motorola.com/iden
Electro Magnetic Interference/Compatibility
NOTE: Nearly every electronic device is susceptible to electromagnetic
interference (EMI) if inadequately shielded, designed or
otherwise configured for electromagnetic compatibility.
Facilities
To avoid electromagnetic interference and/or compatibility conflicts, turn off
your radio product in any facility where posted notices instruct you to do so.
Hospitals or health care facilities may be using equipment that is sensitive to
external RF energy.
Aircraft
When instructed to do so, turn off your radio product when on board an aircraft.
Any use of a radio product must be in accordance with applicable regulations
per airline crew instructions.
Medical Devices
Pacemakers
The Health Industry Manufacturers Association recommends that a minimum
separation of 6 inches (15 cm) be maintained between a handheld wireless radio
product and a pacemaker. These recommendations are consistent with those of
the U.S. Food and Drug Administration.
Persons with pacemakers should:
•ALWAYS keep the radio product more than 6 inches (15 cm) from their
pacemaker when the radio product is turned ON.
•Not carry the radio product in a breast pocket.
•Use the ear opposite the pacemaker to minimize the potential for
interference.
•Turn the radio product OFF immediately if you have any reason to suspect
that interference is taking place.
Hearing Aids
Some digital wireless radio products may interfere with some hearing aids. In
the event of such interference, you may want to consult your hearing aid
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of your
device to determine if it is adequately shielded from RF energy. Your physician
may be able to assist you in obtaining this information.
129
Medical Devices
Use While Driving
Check the laws and regulations on the use of radio products in the area where
you drive. Always obey them.
When using the radio product while driving, please:
•Give full attention to driving and to the road.
•Use hands-free operation, if available.
•Pull off the road and park before making or answering a call if driving
conditions so require.
130
www.motorola.com/iden
Operational Warnings
For Vehicles with an Air Bag
Do not place a portable radio product in the area over the air bag or in the
air bag deployment area. Air bags inflate with great force. If a portable
radio is placed in the air bag deployment area and the air bag inflates, the
radio product may be propelled with great force and cause serious injury to
occupants of the vehicle.
Potentially Explosive Atmospheres
Turn off your radio product prior to entering any area with a potentially
explosive atmosphere, unless it is a radio product type especially qualified
for use in such areas as “Intrinsically Safe”(for example, Factory Mutual,
CSA, or UL approved). Do not remove, install, or charge batteries in such
areas. Sparks in a potentially explosive atmosphere can cause an explosion
or fire resulting in bodily injury or even death.
NOTE: The areas with potentially explosive atmospheres referred to
above include fueling areas such as below decks on boats, fuel or
chemical transfer or storage facilities, areas where the air
contains chemicals or particles, such as grain, dust or metal
powders, and any other area where you would normally be
advised to turn off your vehicle engine. Areas with potentially
explosive atmospheres are often but not always posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn off your radio
product when you are near electrical blasting caps, in a blasting area, or in
areas posted: “Turn off two-way radio”. Obey all signs and instructions.
!
W A R N I N G
!
131
Operational Cautions
Cleaning and Drying Considerations
Using a leather carry case may help protect the surfaces and help prevent liquids
(e.g., rain) from entering into the interior of the radio product. This product is
not water proof, and exposing the unit to liquids may result in permanent
damage to the unit.
Ifyourradioproductinteriorgetswet,thendonottrytoacceleratedryingwith
the use of an oven or a dryer as this will damage the radio product and void the
warranty. Instead, do the following:
1. Immediately power off the radio product.
2. Remove Battery and SIM card (if so equipped) from radio product.
3. Shake excess liquid from radio product.
4. Place the radio product and battery in an area that is at room temperature
and has good air flow.
Operational Cautions
Antennas
Do not use any portable radio product that has a damaged antenna. If
a damaged antenna comes into contact with your skin, a minor burn can
result.
Batteries
All batteries can cause property damage and/or bodily injury, such as burns
if a conductive material such as jewelry, keys, or beaded chains touches
exposed terminals. The conductive material may complete an electrical
circuit (short circuit) and become quite hot. Exercise care in handling any
charged battery, particularly when placing it inside a pocket, purse, or other
container with metal objects.
!
C a u t i o n
132
www.motorola.com/iden
5. Let the radio product, battery dry, and SIM card for 72 hours before
reconnecting the battery and/or powering on the radio product.
If the radio product does not work after following the steps listed above, contact
your dealer for servicing information.
Clean the external surfaces of the radio product with a damp cloth, using a mild
solution of dishwashing detergent and water. Some household cleaners may
contain chemicals that could seriously damage the radio product. Avoid the use
of any petroleum-based solvent cleaners. Also, avoid applying liquids directly
on the radio product.
133
Accessory Safety Information
Accessory Safety Information
IMPORTANT:
SAVE THESE ACCESSORY SAFETY INSTRUCTIONS
•Before using any battery or battery charger, read all the instructions for and
cautionary markings on (1) the battery, (2) the battery charger, which may
include a separate wall-mounted power supply or transformer, and (3) the
radio product using the battery.
•Do not expose any battery charger to water, rain, or snow as they are
designed for indoor or in-vehicle use only.
•To reduce the risk of damage to the cord or plug, pull by the plug rather
than the cord when you disconnect the battery charger from the power
source outlet.
•Do not operate any battery charger with a damaged cord or plug —replace
them immediately.
•Battery chargers may become warm during operation, but not hot. If it
becomes hot to the touch, unplug it from the power outlet immediately and
discontinue its use.
•Use of a non-recommended attachment to a battery charger may result in a
risk of fire, electric shock, or injury to persons.
•Make sure the battery charger power cord is located so that it will not be
stepped on, tripped over, or subjected to damage or stress.
•An extension cord should not be used with any battery charger unless
absolutely necessary. Use of an improper extension cord could result in a
risk of fire and electric shock. If an extension cord must be used, make sure
that:
•The pins on the plug of the extension cord are the same number, size,
and shape as those on the plug of the charger.
•The extension cord is properly wired and in good electrical condition.
•The cord size is 18AWG for lengths up to 100 feet and 16AWG for
lengthsupto150feet.
To reduce the risk of injury, charge only the
rechargeable batteries listed in the Accessories
section of this manual. Other types of batteries
may burst, causing personal injury and damage.
!
W A R N I N G
!
134
www.motorola.com/iden
•Do not operate any battery charger if it has received a sharp blow, has been
dropped, or has been damaged in any way; take it to a qualified service
technician.
•Do not disassemble a battery charger; take it to a qualified service
technician when service or repair is required. Incorrect reassembly may
result in a risk of electric shock or fire.
•Maximum ambient temperature around the power supply or transformer of
any battery charger should not exceed 40°C (104°F).
•The output power from the power supply or transformer must not exceed
the rating given on the Desktop Dual-Pocket Charger.
•The disconnection from the line voltage is made by unplugging the power
supply from the AC receptacle.
•To reduce risk of electric shock, unplug any battery charger from the outlet
before attempting any maintenance or cleaning.
For optimum charging performance, turn off the radio product while charging it
in any battery charger.
135
Limited Warranty Motorola Communication Products
Limited Warranty Motorola Communication
Products
I. WHAT THIS WARRANTY COVERS AND FOR
HOW LONG:
MOTOROLA, INC. (“MOTOROLA”) warrants the MOTOROLA
manufactured iDEN Communication Products listed below (“Product”)against
defects in material and workmanship under normal use and service for a period
of time from the date of purchase as scheduled below:
Rechargeable Batteries will be replaced during the applicable warranty period
if:
a. the battery capacity falls below 80% of rated capacity, or
b. the battery develops leakage.
MOTOROLA, at its option, will at no charge either repair the Product (with new
or reconditioned parts), replace it (with a new or reconditioned Product), or
refund the purchase price of the Product during the warranty period provided it
is returned in accordance with the terms of this warranty. Replaced parts or
boards are warranted for the balance of the original applicable warranty period.
All replaced parts of Product shall become the property of MOTOROLA.
This express limited warranty is extended by MOTOROLA to the original end
user purchaser only and is not assignable or transferable to any other party. This
is the complete warranty for the Product manufactured by MOTOROLA.
MOTOROLA assumes no obligations or liability for additions or modifications
NOTE: This Warranty applies within the fifty (50) united
states and the District of Columbia
iDEN Subscriber Digital Mobile and
Portable Units One (1) Year
Product Accessories One (1) Year
Batteries One (1) Year
136
www.motorola.com/iden
tothiswarrantyunlessmadeinwritingandsignedbyanofficerof
MOTOROLA. Unless made in a separate agreement between MOTOROLA
and the original end user purchaser, MOTOROLA does not warrant the
installation, maintenance or service of the Product.
MOTOROLA cannot be responsible in any way for any ancillary equipment not
furnished by MOTOROLA which is attached to or used in connection with the
Product, or for operation of the Product with any ancillary equipment, and all
such equipment if expressly excluded from this warranty. Because each system
which may use the Product is unique, MOTOROLA disclaims liability for
range, coverage, or operation of the system as a whole under this warranty.
II. GENERAL PROVISIONS:
This warranty sets forth the full extent of MOTOROLA’S responsibilities
regarding the Product, Repair, replacement or refund of the purchase price, at
MOTOROLA’S options, is the exclusive remedy. THIS WARRANTY IS
GIVEN IN LIEU OF ALL OTHER EXPRESS WARRANTIES. IMPLIED
WARRANTIES, INLCUDING WITHOUT LIMITATION, IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL MOTOROLA BE LIABLE
FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT, FOR ANY LOSS OF USE, LOSS OF TIME, INCONVENIENCE,
COMMERCIAL LOSS, LOST PROFITS OR SAVINGS OR OTHER
INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING
OUT OF THE USE OR INABILITY TO USE SUCH PRODUCT, TO THE
FULL EXTENT SUCH MAY BE DISCLAIMED BY LAW.
III. STATE LAW RIGHTS:
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR LIMITATION ON
HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY.
This warranty gives specific legal rights, and there may be other rights which
may vary from state to state.
137
Limited Warranty Motorola Communication Products
IV. HOW TO GET WARRANTY SERVICE:
You must provide proof of purchase (bearing the date of purchase and Product
item serial number) in order to receive warranty service and, also, deliver or
send the Product item, transportation and insurance prepaid, to an authorized
warranty service location. Warranty service will be provided by MOTOROLA
through one of its authorized warranty service locations. If you first contact the
company which sold you the Product (e.g., dealer or communication service
provider), it can facilitate your obtaining warranty service. You can also call
MOTOROLA at 1-800-453-0920 for warranty service location information.
V. WHAT THIS WARRANTY DOES NOT COVER:
a. Defects or damage resulting from use of the Product in other than its
normal and customary manner.
b. Defects or damage from misuse, accident, water, or neglect.
c. Defects or damage from improper testing, operation, maintenance,
installation, alteration, modification, or adjustment.
d. Breakage or damage to antennas unless caused directly by defects in
material workmanship.
e. A Product subjected to unauthorized Product modifications,
disassemblies or repairs (including, without limitation, the audition to
the Product of non-MOTOROLA supplied equipment) which
adversely affect performance of the Product or interfere with
MOTOROLA’S normal warranty inspection and testing of the
Product to verify any warranty claim.
f. Product which has had the serial number removed or made illegible.
g. Rechargeable batteries if:
1. Any of the seals on the battery enclosure of cells are broken or show
evidence of tampering.
2. The damage or defect is caused by charging or using the battery in
equipment or service other than the Product for which it is specified.
h. Freight costs to the repair depot.
i. A Product which, due to illegal or unauthorized alteration of the
software/firmware in the Product, does not function in accordance
with MOTOROLA’S published specifications or the FCC type
acceptance labeling in effect for the Product at the time the Product
was initially distributed from MOTOROLA.
j. Scratches or other cosmetic damage to Product surfaces that does not
effect the operation of the Product.
k. Normal and customary wear and tear.
138
www.motorola.com/iden
VI. PATENT AND SOFTWARE PROVISIONS:
MOTOROLA will defend, at its own expense, any suit brought against the end
user purchaser to the extent that it is based on a claim that the Product or parts
infringe a United States patent, and Motorola will pay those costs and damages
finally awarded against the end user purchaser in any such suit which are
attributable to any such claim, but such defense and payments are conditioned
on the following:
a. That MOTOROLA will be notified promptly in writing by such
purchaser of any notice of such claim;
b. That MOTOROLA will have sole control of the defense of such suit
and all negotiations for its settlement or compromise; and
c. Should the Product or parts become, or in MOTOROLA’S opinion be
likely to become, the subject of a claim of infringement of a patent,
that such purchaser will permit MOTOROLA, at its option and
expense, either to procure for such purchaser the right to continue
using the Product or parts or to replace or modify the same so that it
becomes non-infringing or to grant such purchaser a credit for the
Product or parts as depreciated and accept its return. The
depreciation will be an equal amount per year over the lifetime of the
Product or parts as established by MOTOROLA.
MOTOROLA will have no liability with respect to any claim of patent
infringement which is based upon the combination of the Product or parts
furnished hereunder with software, apparatus or devices not furnished by
MOTOROLA, nor will MOTOROLA have any liability for the use of ancillary
equipment or software not furnished by MOTOROLA which is attached to or
used in connection with the Product or any parts thereof.
Laws in the United States and other countries preserve for MOTOROLA certain
exclusive rights for copyrighted MOTOROLA software, such as the exclusive
rights to reproduce in copies and distribute copies of such MOTOROLA
software. MOTOROLA software may be used in only the Product in which the
software was originally embodied and such software in such Product may not be
replaced, copied, distributed, modified in any way, or used to produce any
derivative thereof. No other use including, without limitation, alteration,
modification, reproduction, distribution, or reverse engineering of such
MOTOROLA software or exercise or rights in such MOTOROLA software is
permitted. No license is granted by implication, estoppel or otherwise under
MOTOROLA patent rights or copyrights.
139
Limited Warranty Motorola Communication Products (International)
Limited Warranty Motorola Communication
Products (International)
I. WHAT THIS WARRANTY COVERS AND FOR
HOW LONG:
MOTOROLA warrants the MOTOROLA manufactured iDEN Communication
Products listed below (“Product”) against defects in material and workmanship
under normal use and service for a period of time from the date of purchase as
scheduled below:
Rechargeable Batteries will be replaced during the applicable warranty period
if:
a. the battery capacity falls below 80% of rated capacity, or
b. the battery develops leakage.
MOTOROLA, at its option, will at no charge either repair the Product (with new
or reconditioned parts), replace it (with a new or reconditioned Product), or
refund the purchase price of the Product during the warranty period provided it
is returned in accordance with the terms of this warranty. Replaced parts or
boards are warranted for the balance of the original applicable warranty period.
All replaced parts of Product shall become the property of MOTOROLA.
This express limited warranty is extended by MOTOROLA to the original end
user purchaser only and is not assignable or transferable to any other party. This
is the complete warranty for the Product manufactured by MOTOROLA.
MOTOROLA assumes no obligations or liability for additions or modifications
NOTE: This Warranty applies in Singapore and the
Philippines.
iDEN Subscriber Digital Mobile and
Portable Units One (1) Year
Product Accessories (manufactured by
or under license from MOTOROLA) One (1) Year
Batteries One (1) Year
140
www.motorola.com/iden
tothiswarrantyunlessmadeinwritingandsignedbyanofficerof
MOTOROLA. Unless made in a separate agreement between MOTOROLA
and the original end user purchaser, MOTOROLA does not warrant the
installation, maintenance or service of the Product.
MOTOROLA cannot be responsible in any way for any ancillary equipment not
furnished by MOTOROLA which is attached to or used in connection with the
Product, or for operation of the Product with any ancillary equipment, and all
such equipment if expressly excluded from this warranty. Because each system
which may use the Product is unique, MOTOROLA disclaims liability for
range, coverage, or operation of the system as a whole under this warranty.
II. GENERAL PROVISIONS:
This warranty sets forth the full extent of MOTOROLA’S responsibilities
regarding the Product, Repair, replacement or refund of the purchase price, at
MOTOROLA’S options, is the exclusive remedy. THIS WARRANTY IS
GIVEN IN LIEU OF ALL OTHER EXPRESS WARRANTIES. IMPLIED
WARRANTIES, INLCUDING WITHOUT LIMITATION, IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY TO THE FULL EXTENT SUCH MAY BE
DISCLAIMED BY LAW. IN NO EVENT SHALL MOTOROLA BE LIABLE
FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT, FOR ANY LOSS OF USE, LOSS OF TIME, INCONVENIENCE,
COMMERCIAL LOSS, LOST PROFITS OR SAVINGS OR OTHER
INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING
OUT OF THE USE OR INABILITY TO USE SUCH PRODUCT, TO THE
FULL EXTENT SUCH MAY BE DISCLAIMED BY LAW.
III. HOW TO GET WARRANTY SERVICE:
You must provide proof of purchase (bearing the date of purchase and Product
item serial number) in order to receive warranty service and, also, deliver or
send the Product item, transportation and insurance prepaid, to an authorized
warranty service location. Warranty service will be provided by MOTOROLA
through one of its authorized warranty service locations. If you first contact the
company which sold you the Product (e.g., dealer or communication service
provider), it can facilitate your obtaining warranty service.
IV. WHAT THIS WARRANTY DOES NOT COVER:
a. Defects or damage resulting from use of the Product in other than its
normal and customary manner.
141
Limited Warranty Motorola Communication Products (International)
b. Defects or damage from misuse, accident, water, or neglect.
c. Defects or damage from improper testing, operation, maintenance,
installation, alteration, modification, or adjustment.
d. Breakage or damage to antennas unless caused directly by defects in
material workmanship.
e. A Product subjected to unauthorized Product modifications,
disassemblies or repairs (including, without limitation, the audition to
the Product of non-MOTOROLA supplied equipment).
f. Product which has had the serial number removed or made illegible.
g. Rechargeable batteries if:
1. Any of the seals on the battery enclosure of cells are broken or
show evidence of tampering.
2. The damage or defect is caused by charging or using the battery in
equipment or service other than the Product for which it is
specified.
h. Freight costs to the repair depot.
i. A Product which, due to illegal or unauthorized alteration of the
software/firmware in the Product, does not function in accordance
with MOTOROLA’S published specifications or the local type
acceptance labeling in effect for the Product at the time the Product
was initially distributed from MOTOROLA.
j. Scratches or other cosmetic damage to Product surfaces that does not
effect the operation of the Product.
k. Normal and customary wear and tear.
l. Exclusion for defects or damage arising from use of the products in
connection with non-MOTOROLA equipment.
V. PATENT AND SOFTWARE PROVISIONS:
MOTOROLA will defend, at its own expense, any suit brought against the end
user purchaser to the extent that it is based on a claim that the Product or parts
infringe a patent, and Motorola will pay those costs and damages finally
awarded against the end user purchaser in any such suit which are attributable to
any such claim, but such defense and payments are conditioned on the
following:
a. That MOTOROLA will be notified promptly in writing by such
purchaser of any notice of such claim;
b. That MOTOROLA will have sole control of the defense of such suit
and all negotiations for its settlement or compromise; and
c. Should the Product or parts become, or in MOTOROLA’S opinion be
likely to become, the subject of a claim of infringement of a patent,
142
www.motorola.com/iden
that such purchaser will permit MOTOROLA, at its option and
expense, either to procure for such purchaser the right to continue
using the Product or parts or to replace or modify the same so that it
becomes non-infringing or to grant such purchaser a credit for the
Product or parts as depreciated and accept its return. The
depreciation will be an equal amount per year over the lifetime of the
Product or parts as established by MOTOROLA.
MOTOROLA will have no liability with respect to any claim of patent
infringement which is based upon the combination of the Product or parts
furnished hereunder with software, apparatus or devices not furnished by
MOTOROLA, nor will MOTOROLA have any liability for the use of ancillary
equipment or software not furnished by MOTOROLA which is attached to or
sued in connection with the Product or any parts thereof. In no event shall
MOTOROLA be liable for any incidental, special or consequential damages
arising from any claim of patent infringement or alleged infringement.
Laws in the United States and other countries preserve for MOTOROLA certain
exclusive rights for copyrighted MOTOROLA software, such as the exclusive
rights to reproduce in copies and distribute copies of such MOTOROLA
software. MOTOROLA software may be used in only the Product in which the
software was originally embodied and such software in such Product may not be
replaced, copied, distributed, modified in any way, or used to produce any
derivative thereof. No other use including, without limitation, alteration,
modification, reproduction, distribution, or reverse engineering of such
MOTOROLA software or exercise or rights in such MOTOROLA software is
permitted. No license is granted by implication, estoppel or otherwise under
MOTOROLA patent rights or copyrights.
143
Patent and Trademark Information
Patent and Trademark Information
MOTOROLA, the Stylized M Logo and all other trademarks indicated as such herein are
trademarks of Motorola, Inc. ®Reg. U.S. Pat. & Tm. Off. ©2001 Motorola, Inc. All
rights reserved. Manufactured under one or more of the U.S. patents listed in the User’s
Guide.
Microsoft and, Microsoft WEB Explorer, are registered trademarks of Microsoft
Corporation.
Netscape Navigator is a registered trademark of Netscape Communications Corporation.
T9 is a trademark owned by Tegic Communications.
T9®Text Input Patent and Trademark Information
This product is covered by U.S. Pat. 5,818,437, U.S. Pat. 5,953,541, U.S. Pat. 6,011,554
and other patents pending.
Java and all other Java-based marks are trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
Direct Protect is a trademark of Signal Insurance Company.
All other product or service names mentioned in this manual are the property of their
respective trademark owners.
144
www.motorola.com/iden
145
Index
A
Accessories 111
batteries 114
Data cable 79,117,118
Dual Port Adapter Cable 118
Swivel Carry Clip 111
Travel Charger 115
Accessory safety information 133
Adapter cable 118
Alpha mode, text entry 27
Auto Redial 103
B
Backlight timer 103
Battery 114
attaching 11
charge strength 13
charging 12
detaching 11
operating 114
Battery Charging 13
Baud rate 105
C
Call Alert Queue 85
Call alerts 83
from Phonebook 83
receiving 84
Call Filtering 107
Call Forwarding 68
turning off 70
turning on 69
Call Hold 65
Call Timers 62,63
Call Waiting 63,98
accepting calls 64
declining calls 64
ending active calls 65
switching between calls 64
turning off 65
Charge strength 13
Circuit data 79
Circuit data number 25
CompanionPro 40
Connection status 24
Customizing phone 93
D
Data cable 79,117,118
Dialing menu 48
Digital cellular 53
Direct dial 54
Display options 34
changing 100
Driving safety vi
E
email 79
sending and receiving 78
Entering text, see Text entry
F
Faxes
sending and receiving 79
G
Getting started 9
Group calls 87
I
Icons
146
www.motorola.com/iden
context sensitive 31
main menu 36
Phonebook 40
status 31
In Call Setup 97
Initial Setup 101
Initial SIM PIN number 15
International calls 51,57
IP Address 25
K
Keypad Lock 99
L
Language 27,104
M
Main menu 37
icons 36
options 36
reordering 99
Making call alerts 83
Making phone calls 53
Making Private calls 81
Master Reset 99
Memo 91
adding 91
deleting 92
editing 92
viewing 91
Menu icon 34
Menus 34,35,48
main menu 37
Message Center 73
Messages 73
Net Mail 78
text and numeric 76
voice mail 74
Messages, Net Mail
receiving 78
Messages, text and numeric
receiving 77
viewing 77
Missed call 59
Modem, phone as 79
Motorola v
Mute 62
My Information 25
N
Net Mail 78
Notifications 98
setting 96
Numeric mode, text entry 30
P
Packet data 79
Password
security code 99
SIM PIN 99
unlock code 99
Patent information 143
Pause digit entry 49
Phone
modem 79
off 14
on 14
status 24
Phone calls 53
ending 58
from Phonebook 54
from Recent Calls list 55
international calls 57
receiving 58
speed dial 56
Turbo Dial 56
147
Phone Lock 98
Phone Setup 97
Phonebook 39
capacity 44
CompanionPro 40
making call alerts 83
making calls 54
Private calls 81
storing Recent Calls 60
with non-i85s phones 40
with other i85s phones 39
Phonebook entries 42
adding 44
deleting 49
editing 49
sorting 43
viewing 42
Plus dialing 51
Power button 14
Powering phone on or off 14
Private calls 81
from Phonebook 81
from Recent Calls list 82
making 81
receiving 82
PUK code 18
R
Radio frequency 125
Ready screen 31
Recent Calls 48,55,58
deleting 61
details 60
Private calls 82
storing to Phonebook 60
viewing 59
Ring styles 96
Ring/Vibe 94
S
Safety 125
accessory 133
electromagnetic interference
128
medical devices 128
radio frequency 125
Scrolling 104
Security 15,98
Settings
In Call Setup 97
Initial Setup 101
Phone Setup 97
Ring/Vibe 94
Security 98
VoiceVolume 106
Shortcuts 109
SIM card 15,39
blocked 16
inserting and removing 20
unblocking 17,18
with non-i85s phones 40
with other i85s phones 39
SIM PIN 15,99
changing 16
default 15
disabling 18
enabling 18
entering 15
Speed Dial numbers 40,46,56
Status light 24,104
Status messages 123
Status of connection 24
Swivel Carry Clip 111
Symbols mode, text entry 30
148
www.motorola.com/iden
T
T9 Text Input 26
also see Text entry
Talkgroups 87
naming 87
Text and numeric messages 76
Text display
area 33
Text entry
Alpha mode 27
Numeric mode 30
Symbols mode 30
Word mode 28
Three-Way Calling 66
Time and date format 102
Trademark information 143
Travel Charger 115
TTY devices
making calls 57
setting baud rate 106
setting mode 105
Turbo Dial 56
Turning phone on or off 14
Two-way radio, see Private calls
Typing text, see Text entry
U
Unblocking SIM PIN 18
V
Voice Mail 74
logging in 75
receiving messages 74
transferring calls to 74
Voice names 41
creating 47
Phonebook 47
W
Warranty 139
Word mode, text entry 28
