Contents
Latest Safety Booklet
Please retain for future use
6802965C93-B
July, 2003
@6802965C93@
Commercial, Government and Industrial Solutions Sector
1301 E. Algonquin Road, Schaumburg, IL 60196
Copyright © 2003 Motorola All Rights Reserved.
Safety and General Information
RF Operational Characteristics
Your data terminal contains a radio frequency transmitter to convey the information
you wish to send as well as occasional automatic signals used to sustain connection
to the wireless network, and a receiver which enables you to receive communication
and connection information from the network.
For data radio terminals that have been approved as intrinsically safe, read the in-
structions and information on intrinsic safety in this booklet.
PORTABLE RADIO PRODUCT OPERATION AND EME EXPOSURE
Your Motorola radio product is designed to comply with the following national and
international standards and guidelines regarding exposure of human beings to radio
frequency electromagnetic energy (EME):
• United States Federal Communications Commission, Code of Federal Regula-
tions; 47CFR part 2 sub-part J
• American National Standards Institute (ANSI) / Institute of Electrical and Elec-
tronic Engineers (IEEE) C95. 1-1992
• Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition
• International Commission on Non-Ionizing Radiation Protection (ICNIRP)
1998
• Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to
Radio frequency Electromagnetic Fields in the Frequency Range from 3 kHz
to 300 GHz, 1999
• Australian Communications Authority Radio communications (Electromagnetic
Radiation - Human Exposure) Standard 2003.
• ANATEL, Brasil Regulatory Authority, Resolution 256 (April 11, 2001) "addi-
tional requirements for SMR, cellular and PCS product certification."
To assure optimal radio product performance and make sure human exposure
to radio frequency electromagnetic energy is within the guidelines set forth in
the above standards, always adhere to the following procedures:
Body-worn operation
To maintain compliance with FCC RF exposure guidelines, if you wear a radio prod-
uct on your body when transmitting, always place the radio product in a Motorola
approved holster or carry case for this product. When placing your data ter-
minal in a carry case approved for body-worn applications for this device, it
must be inserted with the display facing away from the user's body. Use of
non-Motorola-approved accessories may exceed FCC RF exposure guidelines.
For additional information on RF exposure awareness information, visit the following
Motorola website: www.mot.com/rfhealth.
Electro Magnetic Interference/Compatibility
NOTE: Nearly every electronic device is susceptible to electromag-
netic interference (EMI) if inadequately shielded, designed or
otherwise configured for electromagnetic compatibility.
Facilities
To avoid electromagnetic interference and/or compatibility conflicts, turn off your ra-
dio data terminal in any facility where posted notices instruct you to do so. Hospitals
or health care facilities may be using equipment that is sensitive to external RF en-
ergy.
Aircraft
When instructed to do so, turn off your radio data terminal when on board an aircraft.
Any use of a radio data terminal must be in accordance with applicable regulations
per airline crew instructions.
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION.
READ THIS INFORMATION BEFORE USING YOUR HANDHELD DATA
TERMINAL.
HANDHELD DATA
TERMINAL
HDT 600
ab
Medical Devices
Pacemakers
The Advanced Medical Technology Association (AdvaMed) recommends that a
minimum separation of 6 inches (15 centimeters) be maintained between a hand-
held wireless radio data terminal and a pacemaker. These recommendations are
consistent with those of the U.S. Food and Drug Administration.
Persons with pacemakers should:
• ALWAYS keep the radio data terminal more than 6 inches (15 centimeters)
from their pacemaker when the radio data terminal is turned ON.
• Do not carry the radio data terminal in the breast pocket.
• Turn the radio data terminal OFF immediately if you have any reason to sus-
pect that interference is taking place.
Hearing Aids
Some digital wireless radio data terminals may interfere with some hearing aids. In
the event of such interference, you may want to consult your hearing aid manufac-
turer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of your de-
vice to determine if it is adequately shielded from RF energy. Your physician may
be able to assist you in obtaining this information.
Use While Driving
Check the laws and regulations on the use of radio products in the area where you
drive. Always obey them.
When using the radio product while driving, please:
• Give full attention to driving and to the road.
• Use hands-free operation, if available.
• Pull off the road and park before making or answering a call if driving condi-
tions so require.
Operational Warnings
For Vehicles With an Air Bag
Do not place a portable radio product in the area over the air bag
or in the air bag deployment area. Air bags inflate with great force.
If a portable radio is placed in the air bag deployment area and the
air bag inflates, the radio product may be propelled with great force
and cause serious injury to occupants of the vehicle.
Potentially Explosive Atmospheres
Turn off your radio data terminal prior to entering any area with a
potentially explosive atmosphere, unless it is a radio data terminal
type especially qualified for use in such areas as "Intrinsically
Safe" (for example, Factory Mutual, CSA, UL, or CENELEC). Do
not remove, install, or charge batteries in such areas. Sparks in a
potentially explosive atmosphere can cause an explosion or fire
resulting in bodily injury or even death.
NOTE: The areas with potentially explosive atmospheres
referred to above include fueling areas such as
below decks on boats, fuel or chemical transfer
or storage facilities, areas where the air contains
chemicals or particles, such as grain, dust or
metal powders. Areas with potentially explosive
atmospheres are often but not always posted.
Blasting Caps and Blasting Areas
To avoid possible interference with blasting operations, turn off
your data radio terminals when you are near electrical blasting
caps, in a blasting area, or in areas posted: "Turn off two-way ra-
dio" Obey all signs and instructions.
Operational Cautions
Batteries
All batteries can cause property damage and/or bodily injury, such
as burns if a conductive material such as jewelry, keys, or beaded
chains touches exposed terminals. The conductive material may
complete an electrical circuit (short circuit) and become quite hot.
Exercise care in handling any charged battery, particularly when
placing it inside a pocket, purse, or other container with metal ob-
jects.
Accessory Safety Information
IMPORTANT:
SAVE THESE ACCESSORY SAFETY INSTRUCTIONS
• Before using any battery or battery charger, read all the instructions for and
cautionary markings on (1) the battery, (2) the battery charger, which may
include a separate wall-mounted power supply or transformer, and (3) the
radio product using the battery.
• Do not expose any battery charger to water, rain, or snow as they are
designed for indoor or in-vehicle use only.
• To reduce the risk of damage to the cord or plug, pull by the plug rather than
the cord when you disconnect the battery charger from the power source out-
let.
• Do not operate any battery charger with a damaged cord or plug - replace
them immediately.
• Battery chargers may become warm during operation, but not hot. If it
becomes hot to the touch, unplug it from the power outlet immediately and dis-
continue its use.
• Use of a non-recommended attachment to a battery charger may result in a
risk of fire, electric shock, or injury to persons.
• Make sure the battery charger power cord is located so that it will not be
stepped on, tripped over, or subjected to damage or stress.
• An extension cord should not be used with any battery charger unless abso-
lutely necessary. Use of an improper extension cord could result in a risk of fire
and electric shock. If an extension cord must be used, make sure that:
• The pins on the plug of the extension cord are the same number, size,
and shape as those on the plug of the charger.
• The extension cord is properly wired and in good electrical condition.
• The cord size is 18AWG for lengths up to 100 feet and 16AWG for
lengths up to 150 feet.
• To reduce the risk of injury, charge only the rechargeable batteries
listed in the Accessories section of this manual. Other types of batter-
ies may burst, causing personal injury and damage.
To reduce the risk of injury, charge only the
rechargeable batteries listed in the Accessories
section of this manual. Other types of batteries
may burst, causing personal injury and damage.
