Multitone Electronics PLC EKOFOB 2 way alarm and alerting device User Manual Layout 1

Multitone Electronics PLC 2 way alarm and alerting device Layout 1

Handy guide

Buttons
(from top to bottom):
Grey button: on/off and alarm
cancel
Blue button: assist alarm
Red button: emergency alarm
1.
Turning on the device
To turn the fob on for the first time, place the device in the
charger and remove after the recommended 12 hours.
The pager may take a few minutes to charge before
turning on. Otherwise, to turn the device on press the
grey button for up to 3 seconds, the device will beep to
acknowledge the action
Turning off the device
To turn the device off, press and hold the grey button for
up to 3 seconds, the device will beep to acknowledge the
action
Charging the battery
lThe fob is fitted with a AAA Ni-Mh rechargeable battery
lTo charge the battery, place the device in the charger,
the LED will flash to acknowledge charging:
1 flash every 3 seconds – charging
2 flashes every 3 seconds – charged
Do NOT attempt to remove the battery.
Opening the device will invalidate any warranty. Please give
the device to your administrator for return to a Multitone
Agent for service.
2. 3.
Emergency Alarm (red button): (if enabled)
lSend Emergency Assist call (1 or 2 pushes as
configured by supervisor)
lWhen the Emergency Alert button pressed you will see
the following:
Alarm being sent: Slow flash
Alarm delivered: 2 Fast flashes
Alarm accepted: 3 Fast flashes (only when
accepted by another user)
lTo clear a raised alarm press the grey button (short
press)
4. Assist Alarm (blue button): (if enabled)
l1 push raises assist alarm (alarm automatically
cleared)
lWhen pressed you will see the following:
Alarm being sent: Slow flash
Alarm delivered: 2 Fast flashes
Wander Alarm: Upon entering a restricted zone, the fob
activates an alert.
Man-Down Alarm: If unit is tilted more than 45 degrees
for longer than the configured trigger period
Dead-Man Alarm: If a response is not entered to the
periodic prompt
Status Indicators
lTo check if the device is on the network press grey
button (short press)
(LED : one flash = off network, two flashes = on network)
lA low battery status alarm will be activated when the
battery reaches less than 25% (audible and vibrate)
lWhen the fob is out of range of the EkoTek network,
an alarm will be activated to notify the user
5. 6.
Welcome to your
EkoTek Fob Quick
Guide
Further instructions are
available from the
multitone support site
www.multitone.com
For further information or
troubleshooting, please refer to your
system administrator.
EU Declaration of Conformity In Accordance With Article 6.3 of the EU Radio &
Telecommunication Terminal Equipment R & TTE Directive 99/5/EC.
As the manufacturer, we declare under our sole responsibility that the EKOFOB equipment conforms
to all the applicable essential requirements of the EU Directive 99/5/EC, in accordance with the
procedures of Annex II of the Directive and the following technical standards:-
ETSI EN 300 328 (Directive article 3.2);
ETSI EN 301 489-1; ETSI EN 301 489-3 (Directive article 3.1{b});
EN 60950 (Directive article 3.1{a}).
These equipments are designated as Class 1, Sub Class 21 (non-specific short range device) under
the terms of the Directive and TCAM (Telecommunication Conformity Assessment and Market
Surveillance Committee) classification scheme.
A full copy of the Declaration of Conformity may be obtained from www.multitone.com , or upon
application to Multitone.
FCC & Industry Canada Statement of Compliance
This device complies with Part 15 of the FCC Rules and Industry Canada Standards RSS GEN &
RSS210.
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference that may cause undesired operation.
Unauthorised modification to this equipment will void the user's authority to continue to operate the
device within the scope of the Industry Canada and FCC Part 15 Rules.
WEEE Directive & Product Disposal
At the end of its serviceable life, this product should not be treated
as household or general waste. It should be handed over to the
applicable collection point for the recycling of electrical and
electronic equipment, or returned to Multitone or their agent,
for disposal.
Literature No: EkoTek Fob/cc/issue 1 Product No.: FOB-9261-9167
