Product Data Sheet

MULTITONE PAGING SYSTEMS
RPT503 UHF - PAGING TRANSMITTER
SALES DATA SHEET
The new RPT503 UHF Series Transmitter has been designed specifically to interface with the Multitone paging
systems. With up to 5 watts of output power and supporting master and slave line synchronization it meets the
requirements of even the largest paging systems.
Connected by a Single Twisted Pair
A single pair line cable is all that is required to connect the encoder to the transmitter. This allows local operation via a
twisted cable pair, or remote operation via a PTT line. DTMF tones switch the transmitter into different modes, allowing
both analogue and digital data and speech to share the same pair.
Multiple Code Formats Supported
The RPT503 Series Transmitters can be used for Multitone analogue and digital formats, transmitting any analogue,
digital or FM (Frequency Modulation) code formats. The RPT 503 transmitters are also able to transmit FSK (Frequency
Shift Keyed) formats such as POCSAG (CCIR Radio Paging Code No. 1).
Integral Line Synchronisation
The RPT503 Series Transmitter can be synchronised to other transmitters on the same frequency, without the
requirement for a separate synchronization unit. The RPT 503 transmitters are linked via an audio-pair line and use low
frequency tone signaling to synchronise the transmitter frequencies.
Status Indication & Fault Monitoring
LED’s provide visual indication of the transmitter status. These include; Tx keyed, power and fault. Internal fault
conditions are also monitored, such as High Reverse Power and Oscillator Fail. Further features include a failsafe timer,
to key down the transmitter automatically after 256 seconds and a phase locked local loop oscillator for consistent
performance and reliability.
Easier Installation & Support
Transmitter set-up is configured via a standard PC or Laptop, making the RPT503 UHF Transmitter easy to install and
configure on-site. With a small footprint and extremely lightweight design this product is much easier to handle. Supplied
with both mounting brackets and feet, it can be easily wall or desktop mounted.
••Easy selectable power output from 1 to 5 watts
••Fully synthesized transmitter from 430MHz to 470MHz
••Up to 100 percent duty cycle
••Multiple code formats: Multitone Mk6, Mk7 and POCSAG
••Easy to install and configure using a standard PC or Laptop
••Small footprint
MULTITONE PAGING SYSTEMS
Radio Performance RPT 503 UHF (PLL Synthesized Radio)
Frequency Range 430-470MHz
Frequency Stability +/- 2.5 ppm -20°C to +60°C
Output Power Up to 5W
Duty Cycle Up to 100%
Normal Load Impedance 50Ω
Channel Spacing 12.5/20/25kHz
VSWR Protection Protection against short-term removal of the antenna
(maximum of 5 calls with the antenna disconnected)
Antenna Options End-fed dipole or standalone UHF whip with 4m cable
Inputs
Line Input -33 to -13dBm, 600Ωbalanced line
AC Mains Input 100 to 240V 50/60Hz (Separate Power Supply Unit)
DC Input 13.6V at 2.1A
Ancillary Connections
Line Input 8-Way RJ45 connector, -33 to 13dBm 600Ωbalanced line
RF Output 50W N-type connector
Auxiliary Transmitter Control 15-Way High Density D-type connector
-13dBm into 600Ω(speech and data)
Line Synchronisation 8-Way RJ45 connector
-13dBm into 600Ω
Line Synchronisation Frequency 20kHz
Displays & Alarms
LED Indicators Standby, transmitter keyed and transmitter failed
Alarm Outputs Open collector logic fault indication
Environmental
Operating Temperature -20°C to +60°C
Storage Temperature -20°C to +70°C
Code Format Multitone Mk6, Mk7 & POCSAG (CCIR No.1)
Dimensions
Length x Height x Depth 168mm x 60mm x 104mm
Weight 650 grams
Multitone Electronics PLC
Geddes House Tel: 01506 418198
Kirkton North Fax: 01506 411711
Livingston
West Livingston www.multitone.com
EH54 6GU PLO732 Issue No: 3
Multitone Electronics plc reserves the right to change or amend this Sales and Technical Specification
TECHNICAL SPECIFICATION
RPT503 UHF - PAGING TRANSMITTER
