Sales leaflet
TLA 852/853
• Small and convenient
• Two-line display
• 32 Memories
• Personal and Group
RICs
• 8 Special Services
(mailboxes)
• Vibrate as standard
• Runs on one AAA
battery
• Alarm clock
• Delete All feature
• Battery saver
Two-Line
Alphanumeric
Pagers
The new Multitone™ TLA 850 range
is small, attractive and easy to use.
Two-line display
The large LCD shows two rows,
each of 14 easily visible
alphanumeric characters. New
messages appear instantly on the
display - their time stamp appears
last.
Using the TLA
In standby mode the display shows
time, date and status information.
Simply press the right button to view
stored messages, the middle button
to access the archive (Special
Services instead if enabled) or the
left button to set your user options.
These include choosing the alert
type, setting the clock, selecting the
battery saver times and deleting all
messages - all done via easily
understood icons:
Archive
Alarm Backlight
Battery
Saver
Delete All
Alert Off
Multitone Electronics plc
Head Office
Multitone House
Beggarwood Lane
Kempshott Hill
Basingstoke
Hampshire
RG23 7LL
Tel: +44 (0) 1256 320292
Fax: +44 (0) 1256 462643
E-Mail: Info@multitone.co.uk
Web Site: www.multitone.com
Northern/Scottish Office
Unit 33, Geddes House
Kirkton North
Livingston
West Lothian
EH54 6GU
Tel: 01506 418198
Fax: 01506 411711
Multiton Elektronik GmbH
Dusseldorf, GERMANY
Multiton Elektronik GmbH
Vienna, AUSTRIA
PL0319/1
The Multitone policy is one of continual improvement, so
equipment may vary in detail from the description and
specification in this publication.
© Multitone Electronics plc 1998
Designed and manufactured in accordance
with Quality System ISO 9000.
Certificate Nos. FM20122 and Q10379.
SPECIFICATION
RADIO PERFORMANCE TLA 852 (VHF) TLA 853 (UHF)
Frequency range 137.5-174MHz 439-470MHz
Channel spacing 25kHz 25kHz
Sensitivity (typical for 40 character message)
Best position
512 Baud 5µV/m 5µV/m
1200 Baud 7µV/m 8µV/m
2400 Baud 10µV/m 12µV/m
8 Position average
512 Baud 8µV/m 9µV/m
1200 Baud 11µV/m 12µV/m
2400 Baud 15µV/m 17µV/m
Intermodulation rejection 60dB 55dB
Adjacent channel sensitivity 70dB 60dB
Spurious response 60dB 60dB
Image response 65dB 50dB
Spurious emission <1GHz (max.) 2nW 2nW
DISPLAY STN LCD
Illumination Bulb backlighting to LCD
Display area 48mm x 13.5mm
Capacity 2 Rows of 14 characters
Time and date 12 or 24 Hour selectable
Alarm time function Single alarm, daily alert
Also battery saving “Timed Off” function
ALERTS
Audible (typical) 76dB SPL @ 30cm
Alert tones 7 Plus vibrate and silent
Max. number of messages 32 Personal messages
Max. number of characters
per message 1024
Message archive capacity 6 Archive locations
Total Number of RICs 4
Personal Paging RICs 2
Information Service RICs 2 Permitting a total of 8 services
Message time stamp Standard
Languages Country specific ASCII characters
Accessories Holster, lanyard, battery and guide
Code format CCIR RPC No. 1 (POCSAG)
CE Approved
ENVIRONMENTAL
Operating temperature -10°C to +55°C
Storage temperature -20°C to +70°C
PHYSICAL
Width x Height 75mm x 49mm
Thickness 16.5mm
Volume 60cm3
Weight (including AAA battery) 65g
