Murata Manufacturing Co., Ltd. Communication Module LBWA1ZZ1CA Installation Manual
Murata >
05 (Short-Term Confidential) User Manual_FCC
1
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 12 September 2017
1MW User Manual for FCC
*If it is difficult to describe this statement on the host product due to the size, please describe in the User's manual.
or
Contains Transmitter Module FCC ID:VPYLB1MW Contains FCC ID: VPYLB1MW
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Since this module is not sold to general end users directly, there is no user manual of
module.
For the details about this module, please refer to the specification sheet of module.
This module should be installed in the host device according to the interface specification
(installation procedure).
●The following information must be indicated on the host device of this module.
FCC ID:VPYLB1MW
2
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 12 September 2017
1MW User Manual for FCC
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the MAC, through the digital
and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are the
only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the
packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted. In
other words, this device automatically discontinue transmission in case of either absence of information to transmit
or operational failure.
Frequency Tolerance: ±20 ppm
●The following statements must be described on the user manual of the host device
of this module;
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
3
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 12 September 2017
1MW User Manual for FCC
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio
frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the radiator at least 20cm or mor
e
away from person’s body.
●When installing it in a mobile equipment. Please describe the following warning to the manual.
4
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 12 September 2017
1MW User Manual for FCC
Note)
Portable equipment : Equipment for which the spaces between human body and antenna are used within 20cm.
Mobile equipment : Equipment used at position in which the spaces between human body and antenna exceeded 20cm.
●When installing it in a portable equipment. Please describe the following warning to the manual.
It is necessary to take a SAR test with your set mounting this module (except to use only Bluetooth V4.2(BDR/EDR/LE)).
Class II permissive change application is necessary using the SAR report. Please contact Murata.
The available scientific evidence does not show that any health problems are associated with using low power wireless devices.
There is no proof, however, that these low power wireless devices are absolutely safe. Low power Wireless devices emit low
levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health
effects (by heating tissue), exposure of low-level RF that does not produce heating effects causes no known adverse health
effects. Many studies of low-level RF exposures have not found any biological effects. Some studies have suggested that some
biological effects might occur, but such findings have not been confirmed by additional research. 1MW has been tested and found
to comply with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF)
Exposure Guidelines.
