Users Manual
N500i_BT_v1.0_English_master
Software version: None
Personalization version: None
i
Emergency Services and Safety Precautions
Emergency Services and Safety
Precautions
Emergency Services
To make an emergency call in any country
☛Press 1 1 2 .
Ask the operator for the service which you require: Police, Ambulance, Fire Brigade,
Coastguard or Mountain Rescue Services. Give your position and, if possible, remain
stationary to maintain phone contact.
The 112 emergency number service is available on every digital network service. The
number 999 is an alternative emergency number for the UK only, and can only be used
with a valid SIM card.
2Due to the nature of the cellular system, the success of emergency calls
cannot be guaranteed.
General Care
A cellphone contains delicate electronic circuitry, magnets, and battery systems. You
should treat it with care and give particular attention to the following points.
•Do not allow the phone or its accessories to come into contact with liquid or moisture
at any time.
•Do not place anything in the folded phone.
•Do not expose your phone to extreme high or low temperatures.
•Do not expose your phone to naked flame, cigars or cigarettes.
•Do not paint your phone.
•Do not drop or subject your phone to rough treatment.
•Do not place the phone alongside computer disks, credit cards, travel cards and other
magnetic media. The information contained on disks or cards may be affected by the
phone.
•Do not leave the phone or the battery in places where the temperature could exceed
60°C; e.g. on a car dashboard or on a window sill, behind glass in direct sunlight, etc.
•Do not remove the phone’s battery while the phone is switched on.
•Take care not to allow metal objects, such as coins or key rings, to contact or short-
circuit the battery terminals.
•Do not dispose of battery packs in a fire. Your phone's Li-ion batteries may be safely
disposed of at Li-ion recycling points. For more specific battery and power supply
information, see page 3.
•Do not put your phone's battery in your mouth as battery electrolytes may be toxic if
swallowed.
•Do not attempt to dismantle the phone or any of its accessories.
•This equipment is fitted with an internal battery that can only be replaced by a qualified
service engineer. There is a risk of explosion if the battery is replaced by an incorrect
type. Dispose of the used battery in accordance with the manufacturer's instructions.
•Using any battery pack, AC adapter or Vehicle power adapter (option) not specified by
the manufacturer for use with this phone creates a potential safety hazard.
•The earpiece may become warm during normal use and the unit itself may become
warm during charging.
•Use a damp or anti-static cloth to clean the phone. Do NOT use a dry cloth or
electrostatically charged cloth. Do not use chemical or abrasive cleaners as these
could damage the case.
•Remember to recycle: the cardboard packaging supplied with this phone is ideal for
recycling.
•Do not leave the battery pack empty or disconnected for a long time, otherwise some
data may be initialized.
•Your phone contains metal which may cause you an itch, a rash or eczema depending
on your constitution or physical condition.
•Take care not to put your phone in the back pocket of your trousers or skirt and then
sit on it. Also, do not put your phone at the bottom of bag where it may subject to
excessive weight or pressure.
Doing so may damage the LCD and camera lens and cause them malfunction.
•Take care not to hold the Light too close to your or other people’s eyes when the Light
is lit.
•Do not aim or direct the InfraRed (IR) data port towards your or other people’s eyes
when using the IR data exchange.
•The foam covers the earpiece of the headset. Do not put any other part of the headset
in your ears.
Aircraft Safety
•Switch off your phone and remove its battery when inside or near aircraft. The use of
cellphones in aircraft is illegal. It may be dangerous to the operation of the aircraft and
it may disrupt the cellular network. Failure to observe this instruction may lead to
suspension or denial of cellphone service to the offender, or legal action, or both.
•Do not use your phone on the ground without the permission of the ground crew.
Hospital Safety
•Switch off your phone in areas where the use of cellphones is prohibited. Follow the
instructions given by the respective medical facility regarding the use of cellphones on
their premises.
General Safety
•Observe ‘Turn off 2-way radio’ signs, such as those near stores of fuel, chemicals or
explosives.
•Do not allow children to play with the phone, charger or batteries.
•Small parts are included in your phone. Keep them out of reach of small children, for
whom it could be a choking hazard.
•The operation of some medical electronic devices, such as hearing aids and
pacemakers, may be affected if a cellphone is used next to them. Observe any warning
signs and manufacturer's recommendations.
•If you have a weak heart, you should take extra precautions when setting functions
such as the Vibrator and Ringer volume functions for incoming calls.
•If you set the Vibrator setting to anything other than OFF, be careful that the phone is
not near a source of heat (e.g. a heater) and that it does not fall from a desk due to the
vibration.
Road Safety
•You MUST exercise proper control of your vehicle at all times. Give full attention to
driving.
•Observe all the recommendations contained in your local traffic safety documentation.
•Pull off the road and park before making or answering a call if driving conditions so
require.
ii Emergency Services and Safety Precautions
•You MUST NOT stop on the hard shoulder of a motorway to answer or make a call,
except in an emergency.
•Switch off your phone at a refuelling point, such as a petrol station, even if you are not
refuelling your own car.
•Do not store or carry flammable or explosive materials in the same compartment where
a radio transmitter, such as a cellphone, is placed.
•Electronic vehicle systems, such as anti-lock brakes, speed control and fuel injection
systems are not normally affected by radio transmissions. The manufacturer of such
equipment can advise if it is adequately shielded from radio transmissions. If you
suspect vehicle problems caused by radio transmissions, consult your dealer and do
not switch on your phone until it has been checked by qualified approved installers.
Vehicles Equipped with an Air Bag
An air bag inflates with great force. Do not place objects, including either installed or
portable wireless equipment, in the area over the air bag or in the air bag deployment
area. If in-vehicle wireless equipment is improperly installed and the air bag inflates,
serious injury could result.
Third Party Equipment
The use of third party equipment, cables or accessories, not made or authorized by NEC,
may invalidate the warranty of your cellphone and also adversely affect the phone’s
operation. For example use only the NEC mains cable supplied with the AC charger.
Service
The cellphone, batteries and charger contain no user-serviceable parts. We recommend
that your NEC cellphone is serviced or repaired by an NEC authorized service centre.
Please contact your Service Provider or NEC for advice.
Non-Ionizing Radiations
The radio equipment shall be connected to the antenna via a non-radiating cable (e.g.
coax).
The antenna shall be mounted in a position such that no part of the human body will
normally rest close to any part of the antenna unless there is an intervening metallic
screen, for example, the metallic roof.
Use only an antenna that has been specifically designed for your phone. Use of
unauthorized antennas, modifications or attachments could damage your phone and
may violate the appropriate regulations, causing loss of performance and radio
frequency (RF) energy above the recommended limits.
Efficient Use
For optimum performance with minimum power consumption, note the following:
•Your phone has the internal antenna. Do not cover part of the internal antenna of the
phone with your hands. This affects call quality, may cause the phone to operate at a
higher power level than needed and may shorten talk and standby times.
Radio Frequency Energy
Your phone is a low-power radio transmitter and receiver. When it is turned on, it
intermittently receives and transmits radio frequency (RF) energy (radio waves). The
system that handles the call controls the power level at which the phone transmits.
Exposure to Radio Frequency Energy
Your phone is designed not to exceed the limits for exposure to RF energy set by
national authorities and international health agencies. * These limits are part of
comprehensive guidelines and establish permitted levels of radio wave exposure for the
general population. The guidelines were developed by independent scientific
organizations such as ICNIRP (International Commission on Non-Ionizing Radiation
Protection) through periodic and thorough evaluation of scientific studies. The limits
include a substantial safety margin designed to assure the safety of all persons,
regardless of age and health, and to account for any variations in measurements.
*Examples of radio frequency exposure guidelines and standards that your phone is
designed to conform to:
•ICNIRP, “Guidelines for limiting exposure to time-varying electric, magnetic, and
electromagnetic fields (up to 300 G Hz)-International Commission on Non-Ionizing
Radiation Protection (ICNIRP)”.
Health Physics, vol. 74. pp, 494-522, April 1998.
•99/519/EC Council Recommendation on the limitation of exposure to the general
public to electromagnetic fields 0 Hz-300 GHz, Official Journal of the European
Communities, July 12,1999.
•ANSI/IEEE C95.1-1992. “Safety levels with respect to human exposure to radio
frequency electromagnetic fields, 3kHz to 300 GHz”. The Institute of Electrical and
Electronics Engineers Inc., New York, 1991.
•FCC Report and Order, ET Docket 93-62, FCC 96-326, Federal Communications
Commission (FCC), August 1996.
•Radio communications (Electromagnetic Radiation Human Exposure) Standard 1999,
Australian Communications Authority (ACA), May 1999.
Declaration of Conformity
•This product complies with the requirements of the R&TTE Directive 1999/5/EC. The
‘Declaration of Conformity’ leaflet can be found within this box.
Disposing of your used NEC product
•In the European Union
EU-wide legislation as implemented in each Member State requires
that used electrical and electronic products carrying the mark (left)
must be disposed of separately from normal household waste. This
includes mobile telephones or electrical accessories, such as
chargers or headsets. When you dispose of such products, please
follow the guidance of your local authority and/or ask the shop where
you purchased the product. The mark on the electrical and electronic
products only applies to the current European Union Member States.
•Outside the European Union
If you wish to dispose of used electrical and electronic products
outside the European Union, please contact your local authority and
ask for the correct method of disposal.
Licenses
•T9® Text Input and the T9 logo are registered trademarks of Tegic Communication.
“T9 Text Input is licensed under one or more of the following:
U.S. Pat. Nos. 5,187,480, 5,818,437, 5,945,928, 5,953,541, 6,011,554, 6,286,064,
6,307,548, 6,307,549, and 6,636,162, 6,646,573; Australian Pat. Nos. 727539,
746674, and 747901; Canadian Pat. Nos. 1,331,057, 2,302,595, and 2,227,904; Japan
Pat. No. 3532780, 3492981; United Kingdom Pat. No. 2238414B; Hong Kong
Standard Pat. No. HK1010924; Republic of Singapore Pat. No. 51383, 66959, and
71979; European. Pat. Nos. 0 842 463 (96927260.8), 1 010 057 (98903671.0), 1 018
069 (98950708.2); Republic of Korea Pat. Nos. KR201211B1 and KR226206B1.
People’s Republic of China Pat. Application Nos. 98802801.8, 98809472.X and
96196739.0; Mexico Pat. No. 208141; Russian Federation Pat. No. 2206118; and
additional patents are pending worldwide”
iii
Emergency Services and Safety Precautions
•USE OF THIS PRODUCT IN ANY MANNER THAT COMPLIES WITH THE MPEG-4
VISUAL STANDARD IS PROHIBITED, EXCEPT FOR USE DIRECTLY RELATED TO
(A) DATA OR INFORMATION ENCODED BY A CONSUMER FOR PERSONAL AND
NON-COMMERCIAL USE WITHOUT REMUNERATION; (B) DATA OR
INFORMATION (i) GENERATED BY AND OBTAINED WITHOUT CHARGE FROM A
CONSUMER NOT THEREBY ENGAGED IN A BUSINESS ENTERPRISE, AND (ii)
FOR PERSONAL USE ONLY; AND (C) OTHER USES SPECIFICALLY AND
SEPARATELY LICENSED BY MPEG LA, L.L.C.
•Helvetica is a registered Trademark of Heidelberger Druckmaschinen AG which may
be registered in certain jurisdictions.
•©2002 Music Airport Inc., http://www.music-airport.com/
•Java and all Java-based trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc in the U.S. and other countries.
•This product contains ACCESS Co., LTD’s Compact NetFront™ Plus internet browser
software.
Copyright © 1998-2005 ACCESS CO., LTD.
Compact NetFront™ is a registered trademark or trademark of ACCESS CO., LTD in
Japan and selected countries worldwide.
•This product contains ACCESS CO., LTD’s JV-Lite2™ Java virtual machine software.
Copyright © 2000-2005 ACCESS CO., LTD.
JV-Lite2™ is a registered trade mark or trademark of ACCESS COl, LTD, in Japan and
selected countries world wide.
•Copyright 2005 Aplix Corporation and eSOL Co., Ltd. All Rights Reserved.
•This Mobile Printing Ready product is designed to provide easy printing from mobile
phones. This product follows Mobile Imaging and Printing Consortium (MIPC)
guidelines version 1.0 for PictBridge.
•The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by NEC is under license. Other trademarks and trade names are
those of their respective owners.
•This product contains ACCESS CO., LTD's IrFront® Infrared communication software.
Copyright ©1996-2005 ACCESS CO.,LTD.
•i-mode and i-mode logos are trademarks or registered trademarks of NTT DoCoMo.
For the purpose of improvement, the specifications for this product and its accessories
are subject to complete or partial change without prior notice.
KMP6J1BJ1 SAR/DoC
Radio Frequency (RF) Signals(900/1800MHz)
THIS NEC PHONE (MODEL KMP6J1BJ1) COMPLIES WITH THE EU REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transceiver, designed and manufactured not to exceed the SAR* limits** for
exposure to radio-frequency (RF) energy, which SAR* value , when tested for compliance against the
standard was (TBD)W/kg. While there may be differences between the SAR* levels of various phones and
at various positions, they all meet*** the EU requirements for RF exposure.
*The exposure standard for mobile phones employs a unit of measurement known as the Specific
Absorption Rate, or SAR.
**The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/kg) averaged over ten
grams of tissue, recommended by The Council of the European Union. The limit incorporates a substantial
margin of safety to give additional protection for the public and to account for any variations in
measurements.
*** Tests for SAR have been conducted using standard operating positions with the phone transmitting at its
highest certified power level in all tested frequency bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone while operating can be well below the maximum
value. This is because the phone is designed to operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are to a base station antenna, the lower the power
output.
Radio Frequency (RF) Signals(1900MHz)
THIS NEC PHONE (MODEL KMP6J1BJ1) COMPLIES WITH THE USA REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your wireless phone contains a radio transmitter and receiver. Your NEC phone is designed and
manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the
Federal Communications Commission of the U. S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the general population. The guidelines are based
on standards that were developed by independent scientific organizations through periodic and thorough
evaluation of scientific studies.
The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific
Absorption Rate (SAR). The SAR limit set by the FCC is 1.6W/kg.* Tests for SAR are conducted using
standard operating positions accepted by the FCC with the phone transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the
actual SAR level of the phone while operating can be well below the maximum value. This is because the
phone is designed to operate at multiple power levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base station antenna, the lower the output.
Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it
does not exceed the limit established by the government- adopted requirement for safe exposure. The tests
are performed on position and locations (for example, at the ear and worn on the body) as required by FCC
for each model. The highest SAR value for this model phone as reported to the FCC when tested for use at
the ear is (TBD) W/ kg, and when worn on the body, is (TBD) W/ kg. (Body- worn measurements differ
among phone models, depending upon available accessories and FCC requirements). While there may be
differences between the SAR levels of various phones and at various positions, they all meet the government
requirement.
* In the United States, the SAR limit for wireless mobile phones used by the public is 1.6 watts/ kg (W/ kg)
averaged over one gram of tissue. SAR values may vary depending upon national reporting requirements
and the network band.
Body- worn Operation
The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is
on file with the FCC and can be found under the Display Grant section at http:// www. fcc. gov/ oet/ fccid
after search on A98-KMP6J1BJ.
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used
with a NEC accessory designated for this product or when used with an accessory that contains no metal and
that positions the handset a minimum of 1.5 cm from the body.
iv Before You Start
Before You Start
User’s manual conventions
The instructions in this user’s manual make use of the shortcuts selection except special cases.
The following markers are used throughout the user’s manual to attract your attention:
/This type of paragraph will contain details of where to find information related to the topic in question.
2This type of paragraph will contain information worth noting.
,This type of paragraph will contain important information.
☛This type of description will contain procedures to operate your phone.
Menu shortcuts selection
The alternative shortcuts method of selection lets you jump straight to a menu or function without highlighting an icon and scrolling through the
intermediate menu options. The selection is made by pressing numbers which relate to the displayed menu options.
2The instructions in this user’s manual make use of the shortcuts selection, except in special cases.
Reading the titles
Some titles in this manual contain information on how to access the functions. In these titles, M stands for , the numbers indicate the menu shortcut
numbers (see “Overview of menu function” on page xi for details) and ... (three periods) indicate that there are more operations described in the
paragraph.
Reading the procedures
“Highlight” means to use the four way navigation keys (▲▼ ) to move the area emphasized with different colouring.
“Select” means to highlight an item and then press .
Procedures are written omitting the verb “press”, except in some special cases.
For example, 1 2 means to:
☛Start from the standby screen ➔ Press to display the Main menu screen
☛Press 1 to display the Settings screen ➔ Press 2 to display the Phone modes screen
Simple procedures are connected by arrows (➔).
Check box/Radio button
A check box enables/disables an option out of a set of options, and multiple check boxes can be selected at the same time. On the other hand, selecting
a radio button automatically cancels the previous selection, so only one radio button can be selected at one time.
A check box/radio button option can be selected/cancelled by highlighting it and pressing .
▼
▼
v
Before You Start
Display information
,The Liquid Crystal Displays (LCD) on your phone are manufactured using high-precision technology. Even so, the LCD may contain pixels
(dots) that fail to light or that remain permanently lit. Note that this is normal and does not indicate a problem with your display.
Status bar area
This area contains icons
which indicate the battery
strength, new SMS/MMS
message(s), signal
strength, etc. (see page viii).
On screens other than the
standby screen, the clock
display is placed in this
area.
SK1/SK2
This area contains context
sensitive descriptions of the
Softkeys’ functions appropriate
for the current screen.
Shortcut number
Press the appropriate number to
jump straight to a next menu.
The row colour is changed when
selected (e.g. to activate/
deactivate a facility). Help icons
Displayed when you can use the
key represented by these icons
(see page viii).
Next menu icon
Displayed when
you can press
or the shortcut
number to show
the next menu.
▼
Page scroll bar
Displayed when
you can press ▼
to scroll to the
next page.
Shortcut
menu number
The current
menu number
is displayed.
Menu title
Desktop icon area
This area contains the
automatically displayed
and the manually created
desktop icons. They
provide shortcuts to
certain items/functions.
Help area
This area contains help
information appropriate
for the current screen
(e.g. key presses
remaining when
composing a message).
vi Before You Start
Parts and functions
,Be careful not to put your finger or foreign objects in the hinge of the phone when your phone is opened.
Main-LCD
Send ( ) key
Softkey2(SK2)
Phonebook ( )key
End/on-off ( ) key
Alphanumeric keys
Mouthpiece
2nd-LCD
LED & light
Camera
Rear cover
Speaker
Clear (CLR)/Back key
Softkey1(SK1)
Menu ( ) key
Earphone
4 way navigation key
(
▲▼
)
Select key
( )
Charger connector cover
Internal antenna
Side down key
Side up key
Earpiece
jack cover
for battery
Through-hole
for straps
vii
Before You Start
Keypad shortcuts
The following operations are available from the standby screen.
Key Operation that involves pressing a key See
page Operation that involves pressing and holding a key See
page
Accessing the Main menu screen xi Setting/Cancelling the Side key lock 20
SK1 Accessing the Mail screen 43 Accessing the Inbox screen 43
SK2 Accessing the i-mode menu screen 39 Accessing the Java™ applications screen 67
Accessing the Phonebook list screen 48 Accessing the Message screen 27
▲Accessing the Phone modes screen 21 Setting the phone to Meeting mode/Returning to the previous mode 21
▼Accessing the My data screen 60 Accessing the voice recall 8
Accessing the received calls list 11 – –
Accessing the missed calls list 11 – –
Accessing the dialled calls list 11 – –
Highlighting a desktop icon 19 Accessing the homepage 40
Ending a call or returning to the standby screen – Powering off 5
CLR Cancelling the Cell Broadcast message display 33 Deleting all the automatically displayed desktop icons 18
Deleting character or returning to the previous screen – Deleting all characters when you enter text –
1Entering phone numbers 5 Calling the Voice mail centre 54
2 to 9Entering phone numbers 5 One-touch dial to the corresponding number in the phonebook(SIM) 7
0Entering phone numbers 5 Entering + when you make an international call 14
#Entering #5 Entering a pause –
Entering 5 Switching the ALS line 1/2 (if the SIM card supports ALS) 20
Side up
Accessing the volume control screen when your phone is open
(Use ▲ ▼, Side keys or 0 to 9 keys to adjust the volume.) 20 Accessing the camera view finder screen 55
Activating the ring silencer function when you receive a call 20
Side down
Accessing the volume control screen when your phone is open
(Use ▲ ▼, Side keys or 0 to 9 keys to adjust the volume.) 20 Turning on the light
(To turn it off, press any key or open/close your phone.) –
Activating the ring silencer function when you receive a call 20
▼
▼
viii Before You Start
LCD and displayed icons
Main-LCD
Indicates the battery level.
Indicates the battery charging status (fast, slow,
stop).
Indicates that there is a new SMS in your phone.
Indicates that there is a new SMS on the
network.
Indicates that the SIM memory is full.
Indicates that the Inbox in your phone is full.
(pink)
Indicates that there are mail and MMS on the server.
(yellow)
Indicates that there is a new mail/MMS in your
phone.
2This yellow icon blinks while a mail/MMS is being
downloaded.
Indicates that the memory for mail/MMS is full.
(red, green/red, green)
Indicates that new voice mail messages are on
the network (No ALS or ALS Line 1/ALS Line 1
and 2/ALS Line 2).
Indicates secured communication on WTLS in i-
mode browsing.
Indicates that your phone is connected to a
GPRS/EDGE modem such as PC.
(gray)
Indicates that the phone is in the GSM (Global
System for Mobile communication) network
service area and GPRS/EDGE is active.
(yellow)
Indicates that the GPRS/EDGE is available and
i-mode (PDP Context) is active.
Indicates that the i-mode connection is carried
out.
Indicates that the i-mode lock is on.
2No icon appears when the phone is outside the
GSM network service area, or when the phone is
in the GSM network service area and GPRS/
EDGE is not attached.
Indicates that Bluetooth is set to on, Bluetooth is
in operation.
Indicates the line status (No ALS or ALS Line 1/
ALS Line 2). The icon with displayed in red
indicates that the ALS line 1 or 2 is unencrypted/
no ALS.
Indicates the signal strength level.
Appears when you are outside the service area.
Network name (indicated in orange when using
roaming service)
Desktop icons
See “Desktop icons” on page 18 for details
Indicates the call diversion is set.
Indicates the Meeting mode, Pocket mode, Car
mode.
2No icon appears for the Normal mode.
Indicates sound-off, vibrator-on, sound-off/
vibrator-on.
Indicates alarm-on.
Indicates the auto start of a Java™ application
has failed.
Date
Day of week
Remote time
Local time
Indicates that you can use the options menu by
pressing .
Indicates that you can use the phonebook list by
pressing .
3
4
2
5
1
6
7
8 9
10
11
12
13
14
15
17
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
ix
Before You Start
Indicates the usable keys in black, while using i-
mode or a Java™ application is in operation.
Indicates that the help display is available by
pressing when using SIM toolkit.
Indicates that a Java™ application is in
operation.
<When the camera/video view finder is in
operation>
Indicates single/burst mode (camera).
Indicates the video mode is on or the video is
recording.
Indicates that the self timer is on.
Indicates the quality of the picture (super fine,
fine, normal, economy or super economy).
Indicates the quality of the video.
Indicates the photo/video screen size.
Indicates the shooting environment.
Indicates the brightness setting. The “+2” setting
is the brightest.
Indicates the zoom level.
<When the video player is in operation>
Indicates the video is playing, on pause, stopped.
Indicates the progressive download.
2The progressive download icon blinks while
buffering, pausing, or stopping the download.
Indicates that your phone is connected to a
GPRS/EDGE modem such as PC.
(gray)
Indicates that the phone is in the GSM (Global
System for Mobile communication) network
service area and GPRS/EDGE is active.
(yellow)
Indicates that the GPRS/EDGE is available and
i-mode (PDP Context) is active.
Indicates the video is played in normal/enlarged
screen size.
Displays the current volume level. The 0 is mute
and 9 is the maximum.
<When the streaming video player is in
operation>
Indicates the video is playing, on pause, stopped.
Indicates the video type is On-demand or Live
(green, yellow, red)
Indicates the amount of buffered data. (Green
indicates more than 70 % of data is buffered,
yellow indicates less than 70 %, red indicates
less than 30 %.)
Indicates that your phone is connected to a
GPRS/EDGE modem such as PC.
(gray)
Indicates that the phone is in the GSM (Global
System for Mobile communication) network
service area and GPRS/EDGE is active.
(yellow)
Indicates that the GPRS/EDGE is available and
i-mode (PDP Context) is active.
Indicates the video is played in normal/enlarged
screen size.
Displays the current volume level. The 0 is mute
and 9 is the maximum.
<When the Music player/MP3 player is in
operation>
Indicates the repeat mode is Repeat all, Repeat
one.
Indicates the Equalizer mode is Rock, Jazz, Pop.
Displays the current volume level. The 0 is mute
and 9 is the maximum.
2nd-LCD
Indicates the battery level.
Indicates
the battery charging status (fast, slow,
stop).
Indicates that there is a new SMS in your phone.
Indicates
that there is a new SMS on the network.
2
3
4
5
6
7
8
3
4
6
7
8
3
4
5
6
7
8
4
5
8
46
1
2
7
5
3
1
2
xBefore You Start
Indicates that the SIM memory is full.
Indicates that the Inbox in your phone is full.
(pink)
Indicates that there are mail and MMS on the server.
(yellow)
Indicates that there is a new mail/MMS in your
phone.
2This yellow icon blinks while a mail/MMS is being
downloaded.
Indicates that the memory for a mail/MMS is full
(red, green/red, green)
Indicates that a new voice mail message is on
the network (No ALS or ALS Line 1/ALS Line 1
and 2/ALS Line 2).
Indicates the Bluetooth is on, Bluetooth is in
active.
Indicates the signal strength level.
Appears when you are outside the service area.
Indicates that the phone is in the Meeting/Pocket/
Car mode.
2No icon appears for the Normal mode.
<When 2nd-LCD is used as the camera
view finder screen>
Indicates the battery level.
Indicates
the battery charging status (fast, slow,
stop).
Indicates single or burst mode of the camera.
(blue, red)
Indicates that the video mode is on or the video
is recording.
Indicates the photo/video screen size.
Indicates that the self timer is on.
<When the Music player/MP3 player is in
operation>
Indicates the player is playing, stopped.
Indicates the repeat mode is Normal, Repeat all,
Repeat one.
3
4
5
6
7
9
10
11
8
8
9
10
11
2
3
xi
Before You Start
Overview of menu function
➡➡
➡
➡
Standby screen Main menu screen
CLR
The Main menu has a set of icons for its top levels of options which can be selected either
using a combination of the 4-way navigation key (▲ ▼ ) and (menu selection),
or just the keypad (shortcuts selection).
2The title of the selected option will be displayed in the Help area.
2SIM toolkit icon is displayed only when your SIM card supports this function.
2With the Main menu screen displayed, press 0 to display your own number.
▼
▼
Key Main menu Second level menu
1 Settings Phone
Phone modes
Main-LCD
2nd-LCD
Power saving
Calls
Security
Network
Reset settings
2 Message Inbox
Drafts
Outbox
Sent
CB
Folder1
Folder2
Key Main menu Second level menu
7 Java Programs
Prog backlight
8 Accessory Music player
MP3 player
Calculator
Clock alarm
Scheduler
ToDo list
Notepad
Voice memo
Currency
Bluetooth
Synchronization
9 SIM toolkit
Key Main menu Second level menu
3 i-mode i-mode
Settings
4 Phonebook Lists
Information #
Call options
5 Camera Camera
Video recorder
6 My data Videos
Sounds
Pictures
MP3
xiii
Contents
Emergency Services and Safety Precautions i
Before You Start iv
User’s manual conventions............................................. iv
Display information .......................................................... v
Parts and functions ......................................................... vi
LCD and displayed icons ...............................................viii
Overview of menu function ............................................. xi
Getting Started 1
Preparing the phone ........................................................1
Standby and talk times.....................................................4
Checking the battery ........................................................4
Low battery alarm ............................................................4
Other battery alarms ........................................................4
Start-up ............................................................................4
Basic Calls & Phone Use 5
Making basic calls............................................................5
Ending a call ....................................................................6
Receiving an incoming call ..............................................6
Unsuccessful calls ...........................................................7
Emergency calls...............................................................7
Last number redial ...........................................................7
One-touch dial..................................................................7
Fast dialling......................................................................7
Displaying your own phone number (M0/M416) ..............8
Voice recall ......................................................................8
Options menu (during a call) ............................................8
Putting a call on hold........................................................9
Mute .................................................................................9
Call transfer...................................................................... 9
Multi-party calls ................................................................9
Recording a call ............................................................. 10
Scratchpad number........................................................10
Call options (M43).......................................................... 10
Call settings (M16) ......................................................... 12
International dialling codes ............................................ 14
Roaming......................................................................... 14
Text Entry 15
Mode change ................................................................. 15
T9® English text input .................................................... 15
Normal text input............................................................ 16
Numeric input.................................................................17
Key allocations............................................................... 17
Desktop icons 18
Settings (M1) 20
Phone (M11) ..................................................................20
Phone modes (M12) ......................................................21
Main-LCD (M13) ............................................................ 23
2nd-LCD (M14) .............................................................. 23
Power saving (M15) ....................................................... 23
Calls (M16)..................................................................... 24
Security (M17)................................................................ 24
Network (M18) ...............................................................25
Reset settings (M19)......................................................25
Message (M2) 27
Message overview ......................................................... 27
xiv Contents
Reading a message (M21) ............................................ 28
Creating a message....................................................... 31
Cell broadcast (M25) ..................................................... 33
i-mode (M3) 33
i-mode operation guide .................................................. 33
i-mode screen ................................................................ 39
i-mode menu screen ...................................................... 39
iMenu screen ................................................................. 42
Browser Options menu .................................................. 42
Mail screen .................................................................... 43
i-mode glossary ............................................................. 47
Phonebook (M4) 48
Phonebook types ........................................................... 48
Accessing your phonebook (M4) ................................... 49
Phonebook list Options menu........................................ 49
Personal data Options menu ......................................... 53
Voice mail (M417).......................................................... 54
Camera (M5) 55
Notes on using the camera............................................ 55
Taking a picture (M51)................................................... 56
Recording a video (M52) ............................................... 58
My data (M6) 60
Videos (M61) ................................................................. 61
Sounds (M62) ................................................................ 61
Pictures (M63) ............................................................... 62
MP3 (M64) ..................................................................... 64
File selector Options menu ............................................ 64
Java™ (M7) 67
Programs (M71)............................................................. 67
Prog backlight (M72)...................................................... 68
Accessory (M8) 68
Music player (M81) ........................................................ 68
MP3 player (M82) .......................................................... 69
Calculator (M83) ............................................................ 70
Clock alarm (M84) ......................................................... 71
Scheduler (M85) ............................................................ 72
ToDo list (M86) .............................................................. 73
Notepad (M87)............................................................... 75
Voice memo (M88) ........................................................ 76
Currency (M89).............................................................. 76
Bluetooth (M80) ............................................................. 77
Synchronization (M8*) ................................................... 77
Bluetooth (M80) 78
Pairing a Bluetooth device and your phone ................... 79
Using Bluetooth for voice/modem.................................. 80
Bluetooth data exchange ............................................... 80
FTP server ..................................................................... 81
Index 83
1
Getting Started
Getting Started
Preparing the phone
Before trying to use your phone, make sure that a valid Subscriber Identity Module (SIM) card is inserted and the battery is charged.
SIM card
Before using your phone, you must sign-up with one of the digital network service providers. In addition to your subscription details you will receive a
personal SIM (Subscriber Identity Module) card which is inserted into your phone.
If the SIM card is removed, the phone becomes unusable until a valid SIM card is fitted. It is possible to transfer your SIM card to another compatible
phone and resume your network subscription. The screen on your phone will display appropriate messages if no SIM card is fitted.
,If the phone, or the SIM card, is lost or stolen then you should contact your service provider immediately in order to bar it from use.
2The phone supports a number of languages and the keyboard symbols have been chosen for world-wide operation.
2The digital technology of your phone helps to ensure that your conversations are kept secure.
2The SIM card contains personal data such as your electronic phonebook, messages (see “Message (M2)” on page 27) and also details of the network
services you have subscribed to. The phone will not work (except for emergency calls on some networks) unless a valid SIM card is fitted.
,Be sure to turn the phone off before inserting and removing a SIM card. Otherwise damage to the SIM card can occur.
Inserting a SIM card
,Be sure to turn the phone off before removing the battery pack.
☛While pressing down the areas marked with of the rear cover as indicated by arrow ➀, slide the rear cover about 3 mm in the direction of
arrow ➁ with your finger tip. Then, lift the cover up in the direction of arrow ➂ to remove it.
☛Lift the finger tab of the battery pack up in the direction of arrow ➃. Then lift the battery pack out in the direction of arrow ➄.
☛With the metal part facing down, insert the straight end of the SIM card under the holder in the direction of arrow ➅. Slide the SIM card all the way
until it reaches the end.
,Be careful not to damage electric parts of the SIM holder when inserting a SIM card.
☛Insert the two tabs on the battery pack into the slots on the phone in the direction of arrow ➇, making sure that the tabs on the battery pack fit
properly into the slots on the phone. Then, press the battery pack down in the direction of arrow ➈ to clip it into the phone.
,Make sure that the battery pack is securely attached to the phone and align the rear cover with the grooves on the phone so that there is a gap
of about 3 mm at the end of the cover. After making sure that there is no gap between the rear cover and the phone body, slide the rear cover in
the direction of arrow ➉ until you hear a click.
2Getting Started
.
,If the SIM card is not fully inserted when the battery is replaced, damage to the SIM card can occur.
/If the SIM card is already fitted, see “Start-up” on page 4.
Removing a SIM card
☛With the battery removed, push the short and straight end of the SIM card with your thumb to slide it gently in the direction of arrow ➆ ➔ Lift the
SIM card after it is completely removed from the holder.
,Be careful not to damage electric parts of the SIM holder when removing a SIM card.
Rear cover
bout 3 mm
Battery
Finger tab
Holde
r
SIM card
About 3 mm
Check that there is no gap
between the rear cover
and the phone body.
Tabs
Slots
3
Getting Started
Charging the battery
Before trying to use your phone, insert the phone’s battery, and connect the NEC battery charger (AC adapter) supplied with your phone to a suitable
mains power socket.
☛Pull open the charger connector cover gently.
,Be careful when handling the charger connector cover. Do not pull strongly.
☛With the arrow marks of the charger plug facing up, hold the buttons on both sides of
the charger plug with your thumb and index finger.
☛Press the buttons as indicated by the arrow marks on the charger plug and insert the
plug into the charger connector.
,Make sure to insert the charger plug with the arrow marks facing up. Otherwise,
damage to the charger connector can occur when disconnecting the charger plug.
2If your phone is turned on and charging starts, the battery charging icon will be
displayed. LED will turn on in red while charging. When charging is complete, the LED
will turn off.
2You are recommended to switch off the phone while charging. If you need to receive
calls, your phone can be switched on and left in standby while being charged,
although the total time taken to charge is then increased.
☛After the charging is complete, press the buttons of the charger plug as indicated by
the arrow marks on the charger plug (➀) and gently pull straight out of the charger
connector (➁).
,Make sure to press both buttons when disconnecting the charger plug from the
charger connector. If you pull the charger plug forcibly without pressing the
buttons, damage to the charger connector can occur.
The icons show the charging status of battery.
Fast battery charging Slow battery charging while the phone is in use Battery charging stopped due to overheat
,Using any battery pack, AC adapter, vehicle power adapter (option) not specified by NEC for use with this phone can be dangerous and
may invalidate any warranty and approval given to the cellphone. Do not leave the charger connected to the mains supply when it is not
in use.
,Do not try to charge the battery if the ambient temperature is below 5°C (41°F) or above 35°C (95°F).
,DO NOT connect a charger or any other external DC source until the phone’s battery is inserted.
2If the phone does not respond, please wait for a few minutes. The charging will then start.
2If you use the phone while charging, handle the phone carefully since the cable or adapter is connected.
2If you make/receive a call while charging, the charging may temporarily be interrupted.
2Charging takes approximately 3 hours with your phone turned off.
2Even if the phone remains connected to the charger, battery residual capacity may decrease when the phone is used for video recording, playing or
other battery consuming operation.
Charger connector
Charger plug
Arrow marks
Press
Press
Make sure to hold the charger plug with the arrow
marks facing up and press both buttons.
Charger connector
Charger plug
Press
Press
Pull straight
Make sure to press both buttons and gently pull
the charger plug straight.
4Getting Started
,IMPORTANT BATTERY CHARGING INFORMATION
Charging a very low battery
The battery’s charge continues to drop after the low battery warning is displayed. In extreme cases where the battery is left uncharged for some
considerable time after this warning, a trickle charge is used to slowly top-up the battery to the safe level at which the fast charging can begin. The
phone can be in trickle charge for a few minutes before the fast charging starts.
Standby and talk times
Your phone works closely with the network you are using to provide the services you need, and the standby and talk times achieved will depend on how
you use the phone and choices made by the network operator.
In particular, factors such as your location within the network, the frequency at which this location is updated, the type of SIM card you have, your
reception of area messages or cell broadcast messages and the use of full rate or enhanced full rate speech, will affect both standby and talk times.
Checking the battery
☛Check icon at the top of the standby screen.
The number of blocks on the icon shows the charge of your battery pack.
Full battery power Partial battery power Low battery power Battery empty
Low battery alarm
When the battery voltage falls below the working level, a low battery warning is displayed on the screen accompanied by LED illumination and a short
tone along with an empty battery icon. The phone will automatically power down shortly afterwards.
2Please charge the battery as much as possible when the battery is very low.
Other battery alarms
Your phone may display warnings when the battery temperature is too high, or the voltage of the battery or the charger is over the appropriate level.
Follow the instruction given by these warnings immediately.
Start-up
Switching the phone on
☛Hold down for about a second to switch on. The screen will display the selected greeting (if set, see page 23) and the phone is then in standby.
2You may need to charge the battery before using your phone.
2When your phone is turned on, the specified ringer may sound.
5
Basic Calls & Phone Use
2If your phone is accidentally turned off while downloading or deleting Java™ application, it will take longer than usual to start up the phone the next
time you turn on the power.
Switching the phone off
☛Hold down until the display shows the switch off message.
PIN code
The SIM card issued by your service provider has a security feature called PIN code protection. The Personal Identification Number (PIN) is a number
put on to the card by your service provider, and is 4 to 8 digits long. Some service providers supply SIM cards which will cause your phone to prompt for
a PIN code when it is turned on. If this is the case, enter your code with the phone’s keypad. If you insert a SIM card other than your own, information
such as call logs may be lost (see “Security (M17)” on page 24 for details).
Basic Calls & Phone Use
Making basic calls
You make a simple call in the same way as you would with a normal phone, except that you need to press after entering the area Subscriber Trunk
Dialling (STD) code and the phone number. To make international calls, you must first enter the international dialling code (see page 14).
2Use the full STD area code even if you are calling to a person in the same town. If the numbers are too long to be displayed within one line, after
pressing , excess part is deleted and ‘...’ is added at its end.
2The main-LCD display shows the strength of the radio signal that links your phone to the network. The maximum signal strength is shown by 4 shaded
blocks and the minimum signal strength by 1 block.
Starting a call
☛Key in the phone number. Check the number on the display ➔ or SK1 to send the input number to start the call
☛Before the other party answers the call, you can end the call by pressing briefly, pressing SK2 or closing your phone. When you use the
headset, you can also end the call by pressing and holding the button on it.
2When connecting a wired headset and Bluetooth headset at the same time, the wired headset will not work.
When the call is sent, the screen displays the number called, the name stored in the phonebook and a connection graphic or a Calling Line Identification
(CLI) picture that has been allocated to the number called (see page 52).
Correcting mistakes
Use the and to move the cursor and then press CLR to clear individual digits, or hold down CLR to completely clear a phone number.
▼
▼
6Basic Calls & Phone Use
Ending a call
☛While talking, press SK2 or briefly, or close your phone. The phone returns to the standby screen.
2If is held down, your phone will turn off.
2When you use the headset, you can also end a call by pressing and holding the button on it.
2When connecting a wired headset and Bluetooth headset, the wired headset will not work.
2You cannot end a call by closing your phone when the headset is connected.
Receiving an incoming call
When someone calls your number, the ringer will play (if set - see page 22), the LED glows in the specified colour, and the phone number of the caller
may be displayed if the calling line identification facility is available and the caller has activated the feature. If the caller’s phone number has been related
and stored in your phonebook with a name and a CLI picture (see page 52), that name and picture will be displayed. If the caller has withheld their identity,
the screen will give a message that the caller’s number is being withheld. If the origin of the call cannot be determined, no information is displayed on
the screen.
2You also have options for holding and forwarding calls. These options depend on your network and your subscription arrangements.
Accepting an incoming call
☛While receiving an incoming call, press or SK1
2When you use the headset, you can also accept an incoming call by pressing the button on it.
2When connecting a wired headset and Bluetooth headset, the wired headset will not work.
2When Auto answer function (see page 22) is set to on and a headset is connected to the phone, the incoming call is automatically accepted after
several rings.
2You can accept an incoming call by opening your phone, when Fold answer function (see page 20) is set to on.
2You can set your phone to answer a call when any key is pressed (see “Any key answer” on page 20).
Rejecting an incoming call
☛While receiving an incoming call, press or SK2 briefly or close your phone.
2When you use the headset, you can also reject an incoming call by pressing and holding the button on it.
2You cannot reject a call by closing your phone when the headset is connected.
2When connecting a wired headset and Bluetooth headset, the wired headset will not work.
If your phone receives a call and you do not answer it, the main-LCD will display a desktop icon of the phone number (or the name if stored) of the caller
(if available).If your phone is closed, the 2nd-LCD will also display a missed call icon, and you can display the details by pressing Side up. This
information is stored in the missed calls list. Up to 20 missed calls are stored in this list.
2If you are making a call, the phone gives priority to receiving a call unless you have already pressed .
7
Basic Calls & Phone Use
/See also: “Call diversion (M161)” on page 12 and “Call waiting and holding (M162)” on page 13.
/See also: “Call options (M43)” on page 10.
Unsuccessful calls
If dialled call is not successfully connected, the display will give an appropriate message.
If your phone has the auto redial function activated, the number will be automatically called again after a short delay (see page 13).
Emergency calls
The standard emergency number of 112 can be used.
☛Key in 1 1 2 ➔ or SK1 to connect the call to the local emergency services.
2On some networks, emergency calls can be made using the 112 number without a SIM card inserted.
Last number redial
You can redial the last number you called.
☛Ensure that the standby screen is displayed and no phone number is shown ➔ twice to dial the last number you called.
/See also: “Call options (M43)” on page 10.
One-touch dial
One-touch dial for the phonebook (SIM) is available by pressing and holding the number keys between 2 and 9.
2A number for the One-touch dial corresponds to the location number in the phonebook (SIM).
2One-touch dial is available only for the phone numbers with the location number 2 to 9 stored in the phonebook (SIM).
Fast dialling
You can make a call to the phone number in the phonebook (Phone/SIM) with just a few press of button.
To fast-dial the phone number in the phonebook (SIM), use the following procedure:
☛From the standby screen, key in the Location number of a personal data in the phonebook (SIM). Then, press #. The corresponding personal data
is displayed.
☛ to dial the phone number.
To fast-dial the phone number in the phonebook (Phone), use the following procedure:
8Basic Calls & Phone Use
☛From the standby screen, key in the Abbreviated Dialing Number (ADN) of a personal data in the phonebook (Phone). Then press . The
corresponding personal data is displayed.
☛Use the and keys to choose the phone number (if there are more than one), then to dial the phone number.
Displaying your own phone number (M0/M416)
☛ 0 or 4 1 6
Voice recall
You can store up to 10 voice recall recordings which can be allocated to a personal data stored in the phonebook (Phone). To store the voice recall
sound, see page 52. To use the voice recall function, use the following procedure:
☛Press and hold ▼
2When you use the headset, you can also activate the voice recall function by pressing and holding the button on it from the standby screen.
☛Within 4 seconds, say the word or words you have recorded to identify the record you wish to recall. If the word or words were recognized, the
first phone number of the personal data stored in the phonebook (Phone) will be called automatically.
Options menu (during a call)
☛During a call, to display the options menu
No. Options menu (during a call)
1 Main menu Displays the Main menu screen. See “Overview of menu function” on page xi for details.
2 Hold/Retrieve Puts the call(s) on hold or retrieves the call(s).
3Mute/Unmute Mutes or unmutes your voice to all active calls.
4 Transfer call Enables to transfer the call and connect other parties.
2After transferring the call, your call will be dropped.
5 Add to conference Merges calls and makes a multi-party call.
6 Private call Make a private call to the highlighted party within the multi-party call.
7 Record call Records the call while talking.
8 Disconnect party Disconnects the highlighted party.
9 Switch call to Bluetooth/
Switch call to phone
Switches the audio path state of the call.
2You can also switch call to Bluetooth or phone by pressing and holding #.
2This option is available only when the Bluetooth device is connected to the phone.
▼
▼
9
Basic Calls & Phone Use
2Depending on the conditions, some options may be displayed in gray and not be available.
Putting a call on hold
☛To put the received or dialled call on hold, SK1 or 2. To retrieve the call, SK1 or 2 again.
Mute
You can mute the sound from the mouthpiece during a call. When your call is muted, the other party cannot hear any sound from your phone, but you
can still hear the sound from the other party.
☛To mute the sound during a call, press 3. To retrieve the sound, press 3 again.
2The mute function is automatically released after the call ends.
Call transfer
When you have an active call and a held call, you can transfer the call and connect the two parties, then you can drop from the line while leaving those
two calls active.
☛To transfer the call, 4.
2After dropping from the call with the other two parties, if you have a call waiting, you can proceed the call with it.
,Call transfer facility is SIM dependent.
Multi-party calls
If your SIM card is multi-party enabled, you can make a conference call to more than one caller. To create the multi-party calls, at least 3 parties, including
the host, are needed.
Receiving the second call
☛SK1 or to accept the second call ➔ SK2 or 5 to merge both calls to initiate a multi-party call.
2When you accept the second call, the first call will be put on hold.
Making the second call
☛SK1 to put the first call on hold ➔ Key in the phone number ➔ SK1 or to make the second call ➔ After the second participant answers, SK2
or 5 to merge both calls to initiate a multi-party call.
0 Bluetooth On Activates the Bluetooth device.
No. Options menu (during a call)
10 Basic Calls & Phone Use
Putting the multi-party calls on hold
☛SK1 or 2 to put all calls on hold ➔ To retrieve the call, press SK1 or 2 again.
2You can put the multi-party calls on hold only when you are a host of the multi-party calls.
Making a private call
While on the multi-party call, you can make a private call to a specific party.
☛To make a private call, highlight the desired party you want to make a private call to ➔ 6
☛To end a private call and return to the normal multi-party call ➔ 5
2While you are on a private call, other parties can continue with their conversation.
2You can make a private call only when you are a host of the multi-party calls.
Ending the multi-party calls
☛To end the multi-party calls, or SK2.
☛To disconnect a specific party on a multi-party call, highlight the party you wish to disconnect ➔ 8
2You can disconnect a specific party on the multi-party calls only when you are a host of the multi-party calls.
,Multi-party call facilities are network dependent.
Recording a call
You can record the conversation during the call.
☛During a call, press and hold ▼ or 7 to display the Voice memo screen ➔ SK1 to start the recording ➔ SK1 to pause and SK2 to stop the
recording ➔ To play the recording, see “Recording/playing voice memo or setting speaker” on page 76.
Scratchpad number
Your phone has a scratchpad facility that enables you to take down a phone number during a call and then make a call to it when you have finished. This
scratchpad number can be stored in memory for future use.
Noting & calling a scratchpad number
☛During a call, key in the number to be placed in the scratchpad. It will be shown on your phone’s screen ➔ when the call is finished. The number
will still be displayed. Press to dial the displayed number.
Call options (M43)
From Call options, you can display the list of missed, received and dialled calls, the duration of the last call made and all calls, charge information and
the redial blacklist.
11
Basic Calls & Phone Use
☛ 4 3 to display the Call options screen.
2Depending on the conditions, some options may be displayed in gray and not be available.
Display missed/received/dialled calls Options menu (M431M/M432M/M433M)
☛ or 4 3 1 for missed calls, or 4 3 2 for received calls, or or 4 3 3 for dialled calls.
☛Highlight a number in the list ➔
No. Call options
1 Missed calls Displays the list of missed calls. You can also access this function by pressing from the standby screen.
2 Received calls Displays the list of received calls. You can also access this function by pressing from the standby screen.
3 Dialled calls Displays the list of dialled calls. You can also access this function by pressing from the standby screen.
4 Last call duration Displays the duration of the last call made on your phone.
☛SK1 to reset the display to zero.
5 Total calls duration Displays the duration of the total calls made on your phone.
☛ SK1 ➔ 1 to reset the duration of the total dialled calls, 2 to reset the duration of the total received calls,
or 3 to reset the duration of all calls.
6Charge info Displays the charge information (Advice of Charge - AoC).
,The AoC facility is SIM card and network dependent.
2To reset the display to zero, set the maximum charges or edit the unit price, you may be prompted to
enter the PIN2 code.
1 Total charge Displays the total charge.
☛SK1 to reset the display to zero.
2 Maximum
charge
Displays the maximum charge.
☛Key in the maximum number of units allowed ➔ SK1
3 Unit price Displays the unit price.
☛Highlight the whole number (integer), the decimal number or the currency field
➔ Key in the required value for the whole number and decimal number fields.
For the currency field, key in the currency type using a maximum of three
characters ➔ SK1
7 Redial blacklist Accesses the numbers in the blacklist.
2If dialled call is not successfully connected (e.g. number busy), the auto redial facility will be offered (see
page 13). If you have set auto redial and the call still fails, the number called will be added to the blacklist.
▼
▼
▼
▼
12 Basic Calls & Phone Use
2Depending on the conditions, some options may be displayed in gray and not be available.
Call settings (M16)
From the Calls screen, you can change various call settings: the call diversion, call waiting and holding, auto redial and line identification.
Call diversion (M161)
Setting Call diversion
☛ 1 6 1 ➔ Highlight the type of call you wish to divert.
2 There will be a delay while your phone checks its divert status with your network.
☛Highlight one of the conditions ➔ When the phone number field of a divert condition is highlighted, either enter the phone number to divert to, or
delete any existing phone number.
☛If you have made any mistake, highlight the appropriate field ➔ SK1 to clear any mistakes.
☛If the settings are correct,
,There will be a short delay while the network sends the divert status of your phone.
,There may be an additional charge for this service depending on your network.
,There may be unavailable settings depending on your network.
No. Missed calls/Received calls/Dialled calls Options menu
1 Call Calls the current number.
2 Create message Creates a new message to the highlighted phone number.
3 Add to phonebook Adds the current number to the phonebook.
☛1 to add it as a new personal data, 2 to add it to an existing personal data ➔ Press the appropriate
number for the storage destination ➔ Press the appropriate number for the phonebook data field to
copy the current number to.
4 Delete one Deletes the current number.
5 Delete all Deletes all the numbers in the list.
6Info Displays information on the current number.
7 Add desktop icon Creates a desktop icon of the selected number.
8Items/Page Selects either to display 4 or 8 phone numbers in one screen.
13
Basic Calls & Phone Use
Call diversion edit options menu
☛Highlight the required edit field ➔
2Depending on the conditions, some options may be displayed in gray and not be available.
Call waiting and holding (M162)
This facility informs you that another call is being made to your phone while an existing call is in progress.
Setting up call waiting
☛ 1 6 2 ➔ 1 1 to activate, 1 2 to deactivate the call waiting, or 2 to check the status of call waiting.
Using call waiting
☛If you are on a call and another comes in, you will be alerted by a beep in the earpiece ➔ SK1 to accept the incoming call.
☛To switch the calls, SK1
☛To merge the calls, SK2 (see “Multi-party calls” on page 9).
☛To end the current call,
☛To retrieve the held call SK1
Auto redial (M163)
With the auto redial facility, your phone will redial a number up to 10 times if the first attempt fails. A tone will be heard at each redial attempt. Your phone
cannot connect a call if the other party is busy or if there are network problems. Pressing SK2 during a redial attempt will abort it.
☛ 1 6 3 ➔ 1 to activate or 2 to deactivate the auto redial facility.
No. Call diversion edit options menu
1Copy Copies the number in the edit field.
2Paste Pastes the previously copied number.
3 Disable all Disables the numbers from all the fields.
4 Phonebook Displays the phonebook to insert a number in the edit field.
5 Add to phonebook Adds the number to the phonebook as a new personal data or saves the number in an existing personal data.
14 Basic Calls & Phone Use
Line ID (M164)
,The line ID (identification) facility is network dependent.
The line ID facility enables you to choose whether or not to send your own phone number when you make a call
and also whether or not to display a caller’s phone number when you receive a call.
☛ 1 6 4 to display the Line ID screen with a ✔ over an activated line and a ✘ over a deactivated line.
☛To set the status of each line (see the table on the right), highlight a line (the line will flash when selected).
☛SK1 to set the line identification on or off ➔ to save the current settings.
International dialling codes
When you make an international call from any country, you must start by dialling a special international access code. Your phone has the facility to prefix
a + symbol to the numbers, so that you need not enter the access code for the country that you are calling from.
Entering international dialling codes
☛Hold down 0. The 0 character displayed will change to a + character ➔ Key in the country code, area code, and phone number that you wish to call.
The UK country code is always 44, no matter what country you are dialling from. For example, a typical UK number of 0131 1234567 is entered as:
Roaming
,You will be charged for calls forwarded to you while roaming.
The roaming facility enables you to use your phone in many parts of the world and pay all charges through your normal service provider. Your network
operator usually has agreements with named networks in other countries so that automatic roaming can take place with these named networks. The
phone also allows you to set network preferences of your own.
When dialling, you will need to add the international access codes if required. So, storing all numbers with the codes (such as +44 for UK) is helpful (see
“Entering international dialling codes”).
2Before leaving your home country, you should select any preferences such as bar calls or call diversion.
Setting Automatic or Manual network selection (M181)
☛ 1 8 1 ➔ 1 to select the automatic mode or 2 to select the manual mode.
,Before you manually select a network, ensure it is covered under the agreement you have with your service provider.
New search (M182)
☛ 1 8 2 to search the available networks➔ Highlight the desired network ➔ to connect to it.
International access country code area code phone number
+ 44 131 1234567
Line type Setting
Outgoing Send own #
Show connected #
Incoming Show Incoming #
Return own #
15
Text Entry
Viewing/editing network list (M183)
,Before editing your network list, please consult with your service provider.
☛ 1 8 3 to read the network list in the SIM memory ➔ Highlight the required network ➔
2Depending on the conditions, some options may be displayed in gray and not be available.
Selecting the frequency band (M184)
You have to select the frequency band to suit the location.
☛ 1 8 4 ➔ Select the required frequency band.
2Frequency bands must be adjusted to suit the location when roaming (Europe, US, etc.), for the phone to work properly.
Text Entry
This section describes how you enter text.
Mode change
☛With a text entry screen displayed, press SK1 to change the text entry mode: T9® English text, Normal text (ABC), Numeric input
T9® English text input
Your phone incorporates T9® Text Input, enabling fast, easy and intuitive text input. For each letter to be keyed in, you only need to press the
alphanumeric key once. The screen will display the word you may require based on the internal English dictionary of your phone.
☛With a text entry screen displayed, press SK1 until the entry mode is T9® English input.
i) For example, to enter “Good”:
☛ Press 4 6 6 3, and then press 0 to confirm the word.
ii) To enter “Peter is good”:
☛Press to shift to upper case (for one letter). You will see a green arrow in the Help area.
☛Press 7 3 8 3 7 to display “Peter”, and then press 0 to confirm.
☛Press 4 7 to display “is”, and then press 0 to confirm.
No. SIM list Options menu
1Add Adds a new network to the list.
2Move Moves the highlighted network within the list.
☛Use ▲ and ▼ to move the network ➔ SK1
3Remove Deletes the highlighted network.
16 Text Entry
☛Press 4 6 6 3 to display “good”, and then press 0 to confirm and the sentence is completed.
Normal text input
☛With a text entry screen displayed, press SK1 until the entry mode is Normal text (ABC) input.
☛Use alphanumeric keys to enter letters. For example, to enter “e,” press 3 twice; to enter “f,” press 3 three times. For other functions, see the table
below.
2When you are in the Normal text (ABC) input, any word entered that is not in the T9® dictionary will be added automatically.
Key Function
0Confirms a word and inserts a space.
1Inserts a period or a single quote as in “Let’s”, “we’re”, “it’s”, etc.
SK1(List) Displays the list of other matching words.
SK1(Spell?) Activates the spell mode which temporarily deactivates T9® for you to spell the word in Normal text input. The
spell mode ends when you key in 0 to enter a space, or SK1(T9).
SK2(Dismiss) Cancels the T9® matching word list.
SK2(Next) or #Displays the next candidate.
or Places the cursor.
0 to 9 (press and hold) Inserts the number.
CLR Deletes any character.
Toggles between lower case, shift (upper case for one letter) and caps lock (permanent upper case).
(press and hold) Press and hold to activate the highlight mode (see “Highlight mode” on page 32 for details).
#Activates symbol mode when no word is highlighted.
Key Function
Toggles between lower case, shift (upper case for one letter) and caps lock (permanent upper case).
(press and hold) Press and hold to activate the highlight mode (see “Highlight mode” on page 32 for details).
0Inserts a space.
0 to 9 (press and hold) Inserts the number.
CLR Deletes any character.
or Places the cursor.
#Activates symbol mode.
▼
▼
▼
▼
17
Text Entry
2If you have made a mistake, use ▲ ▼ to place the cursor to the left or the right of the incorrect character (depending on the Clear mode setting,
see page 33 for details) and then press CLR.
2When entering normal (ABC) text, and the character you require is displayed, use to move to the next character position (if you wait for more than
1 second, the cursor will move one character to the right automatically).
Numeric input
☛With a text entry screen displayed, press SK1 until the entry mode is Numeric input.
2You can also press and hold the number key to insert the number in T9®/Normal text input mode.
☛Use alphanumeric keys to enter numbers.
Key allocations
Whenever you need to enter text (for messages, storing names with numbers, etc.), successive presses of an alphanumeric key will display different
characters. Pressing in T9® English text input or Normal text (ABC) input toggles between lower case, shift (upper case for one letter) and caps lock
(permanent upper case). When a text entry screen is displayed, pressing SK1 enables you to select Normal text input (ABC), T9® Text input (T9) or
Numeric input (123).
2Depending on the types of text entry screens, not all types of text entry modes are available.
Symbol mode
In the symbol mode, pressing each key will input a symbol according to its position on the Symbols screen. By pressing # in a text entry mode, the
Symbols screen will be displayed. Use ▲ and ▼ to select the row, and then press the appropriate number on the column of the required symbol.
▼
▼
▼
18 Desktop icons
Desktop icons
Desktop icons are shortcuts to functions or items. You can activate a desktop icon on the standby screen (desktop) in stead of following the menu and
pressing the shortcut numbers.
The desktop icons are displayed in two rows on the standby screen. See “LCD and displayed icons” on page viii for the actual location of the desktop
icon area.
There are two types of desktop icons: the automatically displayed and the manually created.
Automatically displayed desktop icons
The following automatically displayed icons are displayed on the upper row of the desktop icon area:
2You can delete all the automatically displayed icons by pressing and holding CLR on the standby screen.
2If you turn the phone off, all the automatically displayed desktop icons are deleted.
Manually created desktop icons
The following manually created icons are displayed on the lower row of the desktop icon area
Icon name Image Description
Missed call Displayed when there is a new entry in the Missed calls list.
Missed message Displayed when there is a new message you have not acknowledged.
Missed Mail Displayed when there is a new Mail you have not acknowledged.
Icon name Image Description Icon name Image Description
Phone number Displays a dialer screen with the
registered phone number displayed.
Calculator Displays the Calculator screen.
Message Creates a new message to the registered
phone number or Email address.
Clock alarm Displays the Set alarm screen.
URL Activates the browser and accesses the
registered URL.
Scheduler Displays the Monthly/Weekly calendar
screen.
Picture Displays the image file. ToDo list Displays the ToDo list screen.
Note Displays the note. Notepad Displays the Add new screen for Notepad.
Camera Displays the camera view finder screen. Voice memo
recorder
Displays the New record screen for Voice
memo.
Video Displays the video view finder screen. Currency Displays the Currency screen.
19
Desktop icons
Creating a desktop icon manually
☛Highlight the required function (Camera, Video, Music player, MP3 player, Calculator, Clock alarm, Scheduler, ToDo list, Notepad, Voice memo,
Currency, Bluetooth Voice/Modem, or Bluetooth data exchange) or display the item (image file, note file, phone number, Email address, or URL).
☛For functions, SK1
☛For items, to display the Options menu and select Add desktop icon (for an image/note file, this menu is under Use item)
2For Camera/Video/Music player/MP3 player, you can also display the Options menu and select Add desktop icon (for Camera/Video, this
menu is under Other settings).
2You can create up to 10 desktop icons.
2If you have more than 5 desktop icons, an arrow will be displayed to indicate that you can scroll for more icons.
2The phone number, Email address or URL desktop icon data will not be updated when the original data is modified. Delete the old desktop icon
and create a new one in such a case.
2When you create a desktop icon of an image file or notepad file, the file will be automatically protected. The default title will be the file name. Even
if this title is changed, the original file name will remain the same.
2Each manually created desktop icon has a title that you can edit.
Activating a desktop icon
☛ ➔ Highlight the required desktop icon ➔
2If you do not press any key for three minutes after highlighting a desktop icon, the highlight is cancelled and the screen goes back to the normal
standby screen.
2If you activate an automatically displayed desktop icon, it will be deleted automatically.
Desktop icon Options menu
☛Highlight a desktop icon ➔
Music player Displays the Music player screen. Bluetooth Voice/
Modem
Displays the Bluetooth Voice/Modem
screen.
MP3 player Displays the MP3 player screen. Bluetooth data
exchange
Displays the Bluetooth data exchange
screen.
No. Desktop icon Options menu
1 Edit title Edits the title of the highlighted desktop icon.
2 Delete one Deletes the highlighted desktop icon.
3 Delete all Deletes all the manually created desktop icons.
Icon name Image Description Icon name Image Description
20 Settings (M1)
Settings (M1)
Phone (M11)
☛ 1 1
No. Phone
1 Voice volume Adjusts the sound volume output from the earpiece.
☛Use ▲ ▼, Side keys or alphanumeric keys (0 to 9) to adjust the volume.
2You can also press the Side keys to display the volume control screen and to adjust the volume setting.
2During a call, you can press the Side keys to adjust the setting of the volume as required.
2When you change this setting while a headset is connected, the changed volume will be valid only when you have a
headset connected.
2While using a Bluetooth headset, you cannot change the volume.
2 Answer options 1 Any key answer On: Any key (except , SK2, the Side keys) is valid to answer a call.
Off: Only and SK1 are valid to answer a call.
2 Ring silencer On: Pressing one of the Side keys stops the ringer sound and the vibrator while receiving a call
with the phone closed.
2This function cannot be used if the Side keys are locked.
3 Fold answer On: You can answer an incoming call by opening your phone.
3 Side key Disable: Side keys are locked while your phone is folded.
2You can also lock/unlock the Side keys by pressing and holding on the standby screen.
4 ALS setup ,The Alternate Line Service (ALS) facility is SIM card and network dependent.
If your SIM card supports ALS, you can setup which line to use for Outgoing call or Voice mail.
21
Settings (M1)
Phone modes (M12)
Your phone can be set to one of the following modes: Normal mode, Meeting mode, Pocket mode or Car mode.
,Any changes made to the settings while in a particular mode will be stored and used when that mode is selected again.
Selecting your phone mode
☛▲ or 1 2 ➔ Press the appropriate key for the required mode.
2You can also set the Meeting mode or return to the previous mode by pressing and holding ▲ on the standby screen.
Editing the mode settings
☛▲ or 1 2 ➔ Highlight the required mode ➔ SK1 ➔ Press the appropriate number for the required setting in the following table.
2For any volume setting, use ▲ ▼, Side keys or alphanumeric keys (0 to 9).
5Clock 1 Show clock Sets to display the local time, both the local and remote times or no time on the main-LCD.
2Set time Sets the time for the local or remote time.
3Set date Sets the date.
4 Set date format Selects the date display format.
5 Set time format Selects the time display format from 12 hour or 24 hour.
6Set timezone Sets the timezone. (A ✔ is placed on the currently selected timezone.)
☛Highlight the required timezone ➔ Press SK1 to save the change.
2If the highlighted timezone has Daylight Saving, a check box will be displayed at the bottom
of the screen. Press to activate (✔)/deactivate the setting.
7 Set start day Selects whether to start the week on Sunday or Monday.
2This setting affects the functions related to the day of the week, such as Scheduler. (See
“Scheduler (M85)” on page 72 for details.)
6 Language Selects the language the phone displays.
2When you have switched the language to be displayed, please wait until the new setting becomes active.
7LED Selects the Light Emitting Diode (LED) colour for incoming calls/SMS/Mail or during a call.
2If the personal setting or the Group setting for the LED colour is also set in the phonebook, it has priority over this LED
setting. (See “Allocating a LED colour” on page 52 for details.)
8 Earphone type Selects the earphone type from Stereo or Monaural, depending on your earphones (headset).
No. Phone
22 Settings (M1)
2When you change this setting while a headset is connected, the changed volume will be valid only when you have a headset connected.
2If the selected mode is Car mode, the backlight will always be turned on. This will accelerate the battery consumption.
No. Phone mode setting
1 Ringer Selects the Sound or Video for incoming calls. (See “Sounds (M62)” on page 61 or “Videos (M61)” on page 61 for
details.)
2If the Video is set, it will sound and will be displayed regardless of the CLI picture setting for the personal data
in Phonebook. (See “Allocating a picture as a CLI” on page 52.)
2 Ringer volume Sets the sound volume for incoming calls.
2While receiving a call with your phone open, the ringer volume can also be adjusted by pressing the Side keys.
2While using a wired headset, you can set the volume for the wired headset. The volume settings for the wired
headset and the speaker of the phone are saved individually.
2While using a Bluetooth headset and a Bluetooth hands-free kit, however, the volume setting for the speaker
of the phone is used.
3 SMS tone Selects the ringtone for incoming SMS messages. (See “Sounds (M62)” on page 61 for details.)
4 SMS tone volume Sets the sound volume for incoming SMS messages.
5 Mail tone Selects the ringtone for incoming Mail or MMS messages. (See “Sounds (M62)” on page 61 for details.)
6 Mail tone volume Sets the sound volume for incoming Mail or MMS messages.
7 Key tone Turns on/off the key tone.
8 Service tone Turns on/off the service tone.
9 Alarm volume Sets the sound volume for Clock alarm and Schedule alarm.
0Vibrator Turns on/off the vibrator function.
Earphone setting Selects the sound output from Earphone & Speaker or Earphone.
2This option affects the headset.
# Auto answer Selects whether to answer an incoming call automatically.
2To use the Auto answer function, connect the headset to your phone and set the earphone volume to 1 or
higher. If the earphone volume is set to 0, you must turn the vibrator ON to use the Auto answer.
2The Auto answer function only applies to the first incoming call. When you have another incoming call, you
have to answer it manually.
23
Settings (M1)
Main-LCD (M13)
☛ 1 3
2nd-LCD (M14)
☛ 1 4
Power saving (M15)
☛ 1 5
2If the selected mode is Car mode, this function is displayed in gray and is not available.
No. Main-LCD
1 Greetings Selects the greeting which is displayed on the main-LCD during phone start-up from No greeting, Text or Animation.
☛If you select Text greeting, press SK1 to edit the greeting text. Key in a greeting text and press .
2 Wallpaper Selects a picture or video file to use as the background for the main-LCD.
3 Colour style Selects the phone’s colour theme.
No. 2nd-LCD
1 Clock/Event display Selects which items to display on the 2nd-LCD from Clock & Event, Clock only, Event only or Off.
2 Wallpaper Selects a picture file to use as the background for the 2nd-LCD.
3 Clock selection Selects the type of clock to be displayed on the 2nd-LCD.
2When selecting Digital 2 clock, no icon will be displayed in the standby screen of the 2nd-LCD.
4 Incoming call No. Turns on/off the function to display the incoming call number on 2nd-LCD.
5 Contrast Sets the contrast level of the 2nd-LCD.
☛Use ▲, ▼ or Side keys to adjust the contrast. The contrast gauge is displayed on the 2nd-LCD.
No. Power saving
1 Level setting Selects the power saving level from Level 1 (minimum power save setting), Level 2 (moderate) or Level 3 (maximum).
2The main-LCD backlight will turn dim and then turn off after a given amount of time with no operation.
2When the phone is folded, Power saving level also applies to the 2nd-LCD.
24 Settings (M1)
Calls (M16)
☛ 1 6
/For settings provided on the Calls screen, see “Call settings (M16)” on page 12.
Security (M17)
☛ 1 7
The security settings will help to protect your phone from improper and unauthorized use. You may be required to enter one of the five codes (shown
below). When the phone prompts you for one of these codes, key in the appropriate number.
•PIN code (provided by your network service provider to protect your SIM card if it is stolen)
•PIN2 code (provided by your network service provider for charge information and Fixed dialling services protection)
•PUK code (personal unblocking key in case you forget PIN code)
•PUK2 code (personal unblocking key in case you forget PIN2 code)
•Security code
,If you forget any of these codes, ALWAYS contact your service provider as they are the ONLY source for your codes.
PIN code
Your phone can be set up so that your PIN code must be entered at power up before the phone can be used at all. If the PIN code is not entered, not
even incoming calls can be answered. Entering your PIN code incorrectly 3 times (not necessarily in the same session) will invalidate the correct PIN
code. In such a case you will have to contact your service provider for a PUK code to unblock your SIM card.
2Some SIM cards are set up so that PIN number entry cannot be turned off.
2When SIM PIN lock is enabled, you can change the PIN code.
PIN2 code
Your phone supports advanced feature that may require a PIN2 code to be entered before they can be accessed or modified. Entering your PIN2 code
incorrectly 3 times (not necessarily in the same session) will invalidate the correct PIN2 code. In this case you will have to contact your service provider
for a PUK2 code.
,The PIN2 code is SIM card related and may only be available from your service provider.
2 Function key LED Selects whether to flash the LED of SK1 and SK2 when the main-LCD and its backlight are turned off.
2If the selected mode is Car mode or the camera view finder screen is displayed, the main-LCD backlight will always
be on.
No. Power saving
25
Settings (M1)
Network (M18)
☛ 1 8
/For settings provided on the Network screen, see “Roaming” on page 14.
Reset settings (M19)
☛ 1 9
This function will reset your phone to its factory settings.
No. Security
1Change PINsChanges the PIN or PIN2 code (PIN activate setting must be turned on to change the PIN code).
2 PIN activate Turns on/off the PIN code entry required at starting up the phone.
3Change
security code
Changes the security code which is used to set some of functions and unlock the Personal Information Manager (PIM)
features.
2The default setting of the security code is “0000”.
4 Phone lock Turns on/off the Phone lock function which will lock the phone: you can only make emergency calls or enter the security
code. After entering the correct security code, you can use the phone normally.
2Upon power-up, you are prompted to enter the security code if the Phone lock was active when the phone was
powered down.
5 Bar calls You can bar the following calls made/received on your phone: all outgoing (dialled) calls, international outgoing (dialled)
calls, international outgoing (dialled) calls except to home, all incoming (received) calls or Incoming (received) calls
when roaming.
,Bar calls facilities are network services and may require a password.
5 Bar calls
(Continued)
1 Change settings ☛Highlight the type of restriction and the call type, and then ➔ to save changes.
☛Key in your bar calls password to verify user identification to the network ➔ SK1 to
confirm and save changes to the network.
2The selected settings have red bars over their icons.
2 Set password Changes the bar calls password.
6 Fixed dialling Turns on/off the fixed dialling which restricts the use of dialled number to only the Fixed Dialling Numbers (FDN).
,The FDN facility is network dependent.
/See also: “Fixed dialling numbers (FDN)” on page 48.
26 Settings (M1)
,By restoring the factory settings, any changes you have made to your phone EXCEPT the following will return to the factory settings (the
following data/settings will not be reset):
•Settings: Set time for Local time, Set date, Language, all settings in Calls other than Auto redial, all Security settings other than Change security
code, SIM list settings in Network.
•Call options: Information in Charge info.
•Phonebook: All Phonebook entries. The settings for Groups.
•Accessory: All Schedule, ToDo, Notepad and Voice memo entries. All the settings other than Clock alarm, Play list for MP3 player, View events for
Scheduler, Sort for ToDo, and Timer setting and My phone settings for Bluetooth.
•i-mode: All Bookmarks, Saved pages, Go to webpage, and Mail settings. All the i-mode related settings.
•Java™: All the Java™ applications.
•Message: All the stored messages. The settings for SMS centre, Validity period for SMS and Language for Cell Broadcast.
•My data: All stored files.
27
Message (M2)
Message (M2)
Message overview
Message services
Your phone supports the following messaging services:
•Short Messaging Service (SMS) allows you to send short messages (160 half-pitch characters max.) to one or more phone numbers. To send an
SMS message, the destination phone number must be a mobile phone with an SMS service subscription. SMS service also supports Enhanced
Messaging Service (EMS) for which the maximum length of the message you can send depends on the number of linked messages (maximum of
10 linked messages are available).
•Mail (i-mode messaging service) allows you to send a message to not only other cellphones but also to PCs and other devices that uses Email
addresses. You can attach files from Pictures, Videos and Sounds in My data (see page 60). Mail facility is available from the Mail screen under
the i-mode facility. For details on the mail service, see “i-mode (M3)” on page 33.
•Multimedia Messaging Service (MMS) is a service that allows you to send messages of a slideshow of text and multimedia files. When you receive
an MMS message, you will be notified by a message from the MMS centre. You can either automatically or manually receive the contents of an
MMS message. MMS facility is available from the Mail screen under the i-mode facility. For details on the mail service, see “i-mode (M3)” on
page 33.
,The Message Services are network dependent.
Sending/Receiving messages
While an SMS message is being sent or received, a name or a number will be displayed (if a name has been stored with the number in your phonebook).
The received messages are stored on the SIM card or in your phone memory. When you receive a message, your phone will ring or beep during a call,
a new message icon will be shown on your phone’s display and its LED will glow.
2Please delete the unnecessary messages in the folders from time to time. The phone cannot receive any messages when the Inbox folder is full.
Message screen
☛To display the Message screen, 2 or press and hold ➔ Press the appropriate key for the required option.
No. Message screen menu
1 Inbox The received messages are stored here.
2Drafts The messages currently being edited are stored here.
3 Outbox The messages that failed to be sent are stored here.
4Sent The sent messages are stored here.
28 Message (M2)
2If there is no message in a message list, the list will be displayed in gray and you cannot select it.
Reading a message (M21)
☛To display the Message view screen of a new message, 2 1 or press and hold and press 1 ➔ Highlight the new message ➔
☛The new (unread) messages are displayed in bold.If the message cannot be displayed in one page, use ▲ and ▼ to scroll through the message.
The following icons will be displayed.
Message Options menu (M2M)
☛ 2 or press and hold and press
5CB The received broadcast messages are saved. See “Cell broadcast (M25)” on page 33 for details.
6, 7 Folder1/Folder2 The messages moved by Move msg (see “Message list Options menu” on page 29) are stored here.
Icon type Icons Descriptions Icon type Icons Descriptions
Message
type icons
SMS message Read / Unread
status icons
New / Unread message(s)
Incomplete SMS message Read message(s)
Storing
location
icons
Highlighted message stored in SIM Filtering
status icons
SMS messages filtered by status (incomplete)
Highlighted message stored in the phone
memory SMS messages filtered by location (SIM)
Sorting
status icons Messages sorted by Date SMS messages filtered by location (the phone
memory)
Messages sorted by Name Filtered SMS messages
Messages sorted by Read/Unread status Sent message
status icons
Sent but failed message
Messages sorted by Size Sent message
Messages sorted by Ascending order
Messages sorted by Descending order
No. Message screen menu (Continued)
29
Message (M2)
,The receipt request and linking of SMS messages are network dependant.
2Depending on the selected folder, some options may be displayed in gray and not be available.
Message list Options menu
☛Display the message list in the Inbox, Drafts, Outbox, Sent, CB, Folder1 or Folder2 ➔
No. Message Options menu
1 SMS settings 1 SMS centre Edits the SMS centre number (this number is saved in the SIM card).
2Auto display Turns on/off the automatic display function that displays the received SMS messages
automatically.
3 Receipt request Selects whether to request a receipt of the sent SMS messages.
4 Max linked msgs Sets the maximum number of linked SMS messages. This function divides an SMS with
the message text exceeding the maximum number of characters allowed into multiple
messages.
5 Validity period Selects the period of time an SMS message is stored at the SMS centre, while trying to
deliver the message.
2 CB settings 1Enable 1 to receive none, 2 to receive all, or 3 to specify a list or Cell Broadcast Message
Identifier (CBMI) to receive broadcast from.
2 Languages Selects which language to receive the cell broadcast messages in.
3 View msg status Displays the information on the number of messages in the phone, the size of free/used memories, SMS units in the
phone/SIM, and complete/incomplete SMS units.
4 Rename folder Renames Folder1 and Folder2.
5View all Displays all the messages in all folders on the same list.
6 Msg filter Sets the type(s) of messages to be displayed by selecting the desired filter option.
No. Message list Options menu
1Reply Replies to the sender of the highlighted message.
2 Reply all Replies to the sender and all other recipients of the highlighted message.
3Delete Deletes the highlighted message.
4 Delete all Deletes all the messages in the current folder.
5Forward Forwards the message text of the highlighted message.
6 Msgs/page Selects either to display 3 or 7 messages in one screen.
30 Message (M2)
2Depending on the selected folder, the menu number and available options may vary.
2Depending on the selected folder, some options may be displayed in gray and not be available.
Message view Options menu
☛Display the message list in the Inbox, Drafts, Outbox, Sent, CB, Folder1 or Folder2 ➔ Highlight a message ➔ ➔
2Depending on the conditions, some options may be displayed in gray and not be available.
2The reply facility uses the phone number of the person who sent the message.
2The Save object Options menu will be displayed only if an object is highlighted.
7Move msg Moves the highlighted message to Inbox or Folder1/2, or copies to SIM or Phone.
8Sort msg By: Sorts the messages by date, name, read/unread status or size.
Order: Sorts the messages in ascending or descending order.
9Search Searches messages by alphabets.
0View details Displays the detailed information on the highlighted message.
– Add desktop icon Creates a desktop icon of the sender or recipient of the highlighted message (Inbox, Sent, Folder1, Folder2,
and Drafts only).
–Edit Edits the highlighted message (Drafts and Outbox only).
– Resend Resends the highlighted message in the folder (Outbox only).
The entire message or only the packets that failed to reach the recipient(s) can be sent.
No. Message view Options menu
1Reply Replies to the sender of the highlighted message.
2 Reply all Replies to the sender and all other recipients of the highlighted message.
3 Delete Deletes the highlighted message.
4View details Displays detailed information on the highlighted message.
5 Forward Forwards the message text of the highlighted message.
6 Save object Saves the highlighted object to a folder in My data.
7Move msg Moves the highlighted message to Inbox or Folder1/2, or copies to SIM or Phone.
8 Highlight mode Activates the Highlight mode (see “Highlight mode” on page 32 for details).
9 Option mode Activates the Option mode to highlight the phone number, Email address, URL or attached file.
0 Add desktop icon Creates a desktop icon of the sender or recipient of the highlighted message.
No. Message list Options menu (Continued)
31
Message (M2)
Option mode Options menu
☛Display the message list in the Inbox, Drafts, Outbox, Sent, CB, Folder1 or Folder2 ➔ Highlight a message ➔ ➔ 9 / / to highlight
a phone number, Email address or URL in the message ➔
The columns show the menu numbers for P: Phone number highlighted, E: Email address highlighted and U: URL highlighted.
Creating a message
☛To display the Message composer screen, press 2 and SK1, or press and
hold and press SK1
☛To address the message, highlight the To field ➔ ➔ Input the required phone
number ➔
2To scroll the phone numbers in the To field, or
☛To key in the message, highlight the Message field ➔ ➔ Key in the message
➔
2Pressing while keying in the To/Message field displays the Message edit
Options menu screen.
☛Press SK1 to send the message.
2When you are in the ABC (normal text) mode, any word entered that is not in the
T9® dictionary will be added automatically.
2When you are keying in your message, press SK1 to change the text entry mode.
2If you display another screen or receive a call while you are editing a message more
than 1 character, the message will be saved automatically in Drafts.
P E U Option mode Options menu
1 1 – Add to phonebook Adds the highlighted phone number or Email address to a phonebook.
2 – – Dial phone number Dials the selected phone number.
– – 1 Add to bookmark Adds the highlighted URL to the bookmarks.
– – 2 Go to URL Activates the web browser to access the highlighted URL.
3 2 3 Create message Creates a new message with the highlighted phone number/Email address/URL in the To
field, the message text, or the slide text.
4 3 – Add desktop icon Creates a desktop icon of the highlighted phone number/Email address.
5 4 4 View mode Deactivates the Option mode.
▼
▼
Help area
This area contains the
information on the message.
S indicates the size of the
message equivalent to the
number of SMS messages, and
R indicates the remaining
number of characters
available.
(green) Indicates that an upper case letter will be input next.
(red) Indicates the capital lock.
(no arrow) Indicates that a lower case letter will be input next.
▼
▼
32 Message (M2)
Message composer Options menu
☛ 2 SK1 or press and hold and press SK1 ➔ Highlight To or Message field ➔
2Depending on the selected field, some options may be displayed in gray and not be available.
Message edit Options menu
☛ 2 SK1 or press and hold and press SK1 ➔ Highlight To or Message field ➔ ➔
No. Message composer Options menu
1 Add/Edit Adds or edits a recipient phone number or a message.
2Preview msg Displays a message preview screen.
3 Delete Deletes the highlighted recipient, message, or object.
4 Delete all Deletes all the recipients.
5 Save Saves the message in Drafts folder.
6 Phonebook Displays the phonebook list to insert a recipient phone number.
7 Resend list Inserts a phone number from the resend list.
2You can delete the highlighted phone number from the resend list or the entire resend list by pressing
1 or 2 respectively.
8 Insert Inserts a new recipient phone number (To field only).
9 Address list Displays the recipients of the message (To field only).
No. Message edit Options menu
1Text colour Selects the colour of text and background.
2 Text format Selects the font size (small, normal or large) and font style (bold, italics, underline or strikethrough).
3 Text alignment Sets the text alignment (left, centred or right).
4Paste Pastes the text which has been copied onto the clipboard in the Highlight mode.
2This function can be used only when text has been copied or cut in the Highlight mode.
5 Highlight mode Activates the Highlight mode at the cursor position.
2You can also activates the Highlight mode by pressing and holding .
2This function can only be used when text has been entered.
2To toggle the Highlight mode on/off, SK1 and to go back to the normal mode, CLR
☛To display the following Highlight mode Options menu, .
1 Text colour Selects the colour of text and background.
2 Text format Selects the font size (small, normal or large) and font style (bold, italics, underline or
strikethrough).
3 Copy Copies the highlighted part of text onto the clipboard.
4Cut Cuts the highlighted part of text.
33
i-mode (M3)
2Depending on the conditions, some options may be displayed in gray and not be available.
Cell broadcast (M25)
Cell broadcast (CB) messages (e.g. weather reports, news) are sent by the network to all phones in a certain area.
☛ 2 5
2The Cell broadcast message display on the standby screen is erased by pressing CLR.
,Broadcast messages service is network dependent. Please contact your service provider for details.
i-mode (M3)
Using your phone’s browser facility, you can enjoy i-mode services such as browsing information on i-mode sites (programs) and other Internet web
pages, and sending/receiving i-mode messages which include the mail and MMS (including attachment).
2You can download melody files, images, animations, Flash, videos and Java™ applications and save them in My data. Some files with restrictions
cannot be saved even though they can be downloaded and played or displayed.
/For the definitions of the icons related to i-mode, see “LCD and displayed icons” on page viii.
i-mode operation guide
You can access various i-mode functions by selecting the menus on the main four i-mode related screens: i-mode screen, i-mode menu screen, iMenu
screen (i-mode operator portal site) and Mail screen. The following table gives an outline of the procedures related to the i-mode services.
5 Highlight mode 5 Delete Deletes the highlighted part of text.
6 Select word Selects (highlights) the nearest word to the current cursor position.
7 Select paragraph Selects (highlights) the nearest paragraph to the current cursor position.
8 Select all Selects (highlights) the entire text.
9 Save to text file Saves the highlighted part of text as a text file.
6 Insert object Inserts Text, Sound, Still image, Animation, Emoticon, or Pictograph into the message at the cursor position.
7 T9 Language Selects the language for T9® text input.
8 Edit settings Sets the Write mode (Insert or Overwrite) and Clear mode (Backspace or Delete).
Action Procedure
Browsing the i-mode sites/Internet web pages
Display the homepage ☛Press and hold or SK2 ➔ 6 ➔ 3
2You need to set the homepage URL in Home page beforehand (see “Set homepage” on page 41).
No. Message edit Options menu
34 i-mode (M3)
Display a web page ☛SK2 ➔ 6 ➔ 1 to key in the address, or 2 to select an address in the history.
Reload the current page ☛While browsing a webpage, ➔ ➔ 1
Display the URL of the current page ☛While browsing a webpage, ➔ ➔ 2
Bookmark a web page ☛With the web page you want to bookmark displayed, 1
Display a bookmarked web page ☛SK2 ➔ 5 or 2 while displaying another page ➔ highlight a bookmark ➔
Save a web page ☛With the page to save displayed, 4
Display a saved page ☛SK2 ➔ 7 ➔ highlight a saved page ➔
Save an image ☛With the page including the image to save displayed, 3 ➔
Save a phone number ☛With the phone number to save highlighted, 5
Display the certificate information
of the current page
☛With a page displayed, 6
2You can also refer to a saved page’s certificate information by displaying the page and 3.
Download a file ☛Highlight the link to the file to download ➔ ➔ When the download is completed, save the file and
check that the downloaded file is stored in My data (see page 60) or the Applications screen of Java™
(see page 67).
Play a video by streaming ☛Highlight the link to the video to stream➔ (for details, see “Streaming/downloading a video” )
Download a video ☛Highlight the link to the video to download➔ (for details, see “Streaming/downloading a video” )
Returning to the previous screen/
moving forward to the next screen
☛ While connecting to i-mode, to return to the previous screen (if any), or to move forward to the
next screen (if any).
Mail/MMS
Create a mail ☛SK1 ➔ 1 (for details, see “Creating a new mail” on page 35)
Create an MMS ☛SK1 ➔ 2 (for details, see “Creating a new MMS” on page 36)
Read a mail /MMS ☛SK1 ➔ 3 ➔ Highlight a message ➔
Check for new mail/MMS ☛SK1 ➔ 6
Settings for i-mode
Change the mail settings ☛SK1 ➔ 7 (for details, see “Mail settings” on page 46)
Change the browser settings ☛SK2 ➔ 8 (for details, see “Settings” on page 41)
Change the phone settings related
to i-mode
☛ 3 2 (for details, see page 39)
Action Procedure
▼
▼
▼
▼
35
i-mode (M3)
Streaming/downloading a video
There are three types of video depending on the download site or data type: the video that can be played after downloading, the video that can be played
while downloading, and the streaming video that can be played while downloading but cannot be saved to your phone.
2The maximum size of a video that you can download is 1 MB.
2The replay volume depends on the ringer volume of your phone. If the ringer volume is set to 6 or above, however, the replay volume is adjusted to
level 5. You can change the volume while replaying a video. This change only applies to the currently replayed video.
2For the operation while playing a video, see “Operations while replaying video” on page 61).
Streaming a video
☛While browsing a webpage, highlight the link to the video to stream ➔
2If you are not in the EDGE service area but in GPRS service area, you cannot activate the streaming video.
2Streaming has priority over the incoming call/message/Clock alarm/Scheduler reminder.
Playing a video while downloading
☛While browsing a webpage, highlight the link to the video to download ➔
☛After download is completed, 1 to play again, 2 to save or 3 to display detailed information on the video
☛To cancel the download before downloading is complete, SK2 or CLR
2If the download is interrupted, you can resume downloading the same video from where it was interrupted. The download may start from the
beginning for some files depending on the sever, file type, and other conditions.
2Even if the download continues from where it was interrupted, the replay starts from the beginning.
2To play while downloading, Video auto play must be activated in advance (see “Video auto play” on page 41).
Options menu (during pause/stop)
☛ while the video is paused or stopped
2Pause is not available for live streaming video.
Mail/MMS operations
Creating a new mail
☛SK1 ➔ 1
No. Options menu (during pause/stop)
1 Full screen Turns the Full screen on/off for Sub-QCIF.
2You can also turn the Full screen on/off by pressing #.
2 View detail Displays detailed information on the video.
3 Input URL Enters a URL to connect to the streaming server (only available for streaming video).
36 i-mode (M3)
☛Set the addressee.
Highlight the To field ➔ ➔ key in the destination ➔
To refer to the phonebook, ➔ Open phonebk. to retrieve the destination
To send the mail to more than one addressee, ➔ Add To/Cc/Bcc
To change the To/Cc/Bcc status of an already set addressee, highlight the destination ➔ ➔ Change to To/Cc/Bcc
To delete an already set addressee, highlight the To field ➔ ➔ Del. address
☛Key in the subject.
Highlight the Subject field ➔ ➔ key in the subject ➔
☛Key in the message.
Highlight the Message field ➔ ➔ key in the message ➔
To attach a header, ➔ Attach header
To attach a signature, ➔ Attach sign.
☛Attach a file if necessary.
Highlight the Attachment field ➔ ➔ select a file to attach from the My data screen
To delete an already attached file, highlight the attachment field ➔ ➔ Delete attachment
To preview the attached file, highlight the attachment field ➔ ➔ Play/View file
2You can attach files up to 299 KB in total, or 10 files.
☛To send the mail, highlight Send ➔
☛To save the mail, highlight Save ➔
To delete the currently edited mail, ➔ Del. mail
Creating a new MMS
☛SK1 ➔ 2 ➔ The Compose menu screen is displayed
☛Using Compose menu, create an MMS (for details, see the table “Compose menu” ) ➔ SK2 ➔ The Compose MMS screen is displayed
☛Set the addressee and key in the subject (see “Creating a new mail” for details).
☛To send the MMS, highlight Send ➔
☛To save the MMS, highlight Save ➔
37
i-mode (M3)
Compose menu
☛From the Compose MMS or Edit MMS screen, highlight Attachment ➔ ➔ The slide is displayed ➔
No. Compose menu
– Add/Delete/Overwrite
media
1 Add/Delete/
Overwrite text
Adds, deletes or overwrites the text data in the text field on the slide.
2 Add/Delete/
Overwrite image
Adds, deletes or overwrites the image file in the image field on the slide.
3 Add/Delete/
Overwrite audio
Adds, deletes or overwrites the sound file in the sound field on the slide.
4 Add/Delete/
Overwrite video
Adds, deletes or overwrites the video file on the slide.
–Exit Shifts to the Compose MMS screen.
–Save Saves the currently created MMS.
– Preview Displays the created slides in order from the beginning at the preset playback time for each.
–Add slide 1 Add slide Adds a new slide after the currently displayed slide.
2 Insert slide Inserts a new slide just before the currently displayed slide.
– Delete slide Deletes the currently displayed slide.
–Text colour Selects the Text colour from the 16 different colours.
– Background colour Selects the Background colour from the 16 different colours.
– Set Fit mode Selects the size in which the image/video is displayed.
2This setting will be applied to all the slides.
1Hidden Displays the image/video in the actual size.
2Fill Displays the image/video in the reduced size so that the height and width fit into
the image/video display area.
3 Meet Displays the image/video in the reduced size so that the longer side of the height
or width fits the corresponding side of the image/video display area.
4Slice Displays the image/video in the reduced size so that the shorter side of the height
or width fits the corresponding side of the image/video display area.
– Options Sets the length of time a slide is displayed, and sets the beginning and end times for text, image or sound
within that slide display time.
2You cannot set the beginning and end time for video files.
38 i-mode (M3)
2Depending on the conditions, some options may be displayed in gray and not be available.
☛When you finish editing attachment, SK2 or select Exit from Compose menu to return to the Compose MMS screen.
☛If necessary, edit the composed MMS using the Edit menu options menu (see “Using the Edit menu options” for details).
Using the Edit menu options
☛From the Compose mail/Compose MMS/Edit mail/Edit MMS screen, to display the Edit menu options.
2Depending on the conditions, some options may be displayed in gray and not be available.
Reading a received mail/MMS
☛SK1 ➔ 3 ➔ The list of mail/MMS in the Inbox folder will be displayed.
☛Highlight the message to read ➔ ➔ The message content will be displayed. Scroll the message content.
☛ To view the previous message , to view the next message,
– Resize region Changes the region size of the image/video field and the text field, using the ▲ and ▼ keys.
– Switch positions Switches positioning of the image/video field and text field on the slide.
– Previous slide Displays the previous slide.
– Next slide Displays the next slide.
No. Edit menu options
–Send Sends the mail.
– Save Saves the mail being edited to the draft folder.
–Attach file Attaches a file to the mail.
– Delete attachment Deletes the attached file(s).
– Play/View file Plays or displays the attached file.
– Open phonebk. Adds the destination directly from the phonebook.
– Add To/Cc/Bcc Adds a To/Cc/Bcc field.
–Change to To/Cc/BccChanges the highlighted Cc/Bcc/To field to a To/Cc/Bcc field.
– Del. address Deletes a destination field.
– Attach header/sign. Attaches a stored opening sentence at the start or a stored signature at the end of the text.
– Del. message Deletes the message of the mail being edited.
–Del. mail Deletes the new message currently edited.
No. Compose menu
▼
▼
39
i-mode (M3)
2While reading a received mail/MMS in the Inbox folder, you can use various functions. See “Inbox” on page 43.
2If Auto play is on (see “Auto play” on page 46), the MMS/attachment will be automatically played/displayed. if not, press SK1 to start playing.
2You can change the font size by pressing and holding the and . enlarges the font size, while reduces it.
i-mode screen
From the i-mode screen you can change the i-mode related settings of your phone.
☛ 3 ➔ The i-mode screen will be displayed.
i-mode menu screen
From the i-mode menu screen you can access to the iMenu(i/Mail/Message screen, your bookmarks, the entry screen for a URL to be displayed, the
access history, the saved pages, the list of Java™ applications and the browser settings.
No. i-mode screen menus
1i-mode Displays the i-mode menu screen (For details, see “i-mode menu screen menus” on page 40).
2 Settings 1Ringer time Sets the ringtone/vibration duration to 3-10 seconds for incoming mail/MMS.
2 Connection No. Selects the connection number settings to use. The following settings are
available:
1 Factory setting Uses the default connection numbers.
2, 3 User setting 1/2 Uses and changes the following settings.
1 Access point
2 i-mode server IP address
HTTP Port No.
SSL Port No.
3 Portal server (i-mode server URL)
4Mail
5User data User name
Password
6 Streaming Proxy IP address
Port No.
3 i-mode lock Locks the i-mode function, including mail/MMS.
▼
▼
▼
▼
40 i-mode (M3)
☛SK2 or 3 1 to display the i-mode menu screen.
No. i-mode menu screen menus (Sheet 1 of 3)
1iMenu Accesses the iMenu screen. (see “iMenu screen” on page 42.)
2Mail Displays the Mail screen, on which you can display received mail/MMS, saved draft messages and sent messages,
and also create new mail/MMS (see “Mail screen” on page 43).
3 Java application Displays the list of Java™ applications (see “Java™ (M7)” on page 67 for details).
4SMS Displays the Message screen, on which you can read received SMS and create new SMS (see “Message (M2)” on
page 27).
5 Bookmarks Displays the list of bookmarked web pages.
Bookmarks options menu
1Open Displays the highlighted bookmark.
2 Copy address Copies the highlighted bookmark URL.
3 Edit title Edits the title of the highlighted bookmark.
4 Add desktop icon Creates a desktop icon of the URL of the selected bookmark.
5 Create message Creates a new message with the highlighted bookmark address in the message text.
6 Delete one Deletes the highlighted bookmark.
7 Delete all Deletes all the bookmarks.
6 Go to webpage Displays the URL you key in, the URL in the address history, or the homepage.
1 Enter address Prompts you to key in a web page address.
2 Address history Displays the list of addresses in the access history for you to select from.
Address history Options menu
Add desktop icon: Creates a desktop icon of the URL of the selected history.
Create message: Creates a message with the URL of the selected history in the text.
Delete one: Deletes the highlighted address.
Delete all: Deletes all the addresses in the list.
3Go to home Displays the homepage set in Home page of Settings (See page 41).
2This menu is not available, if Set homepage of i-mode menu screen is not set.
0Back Returns to the i-mode menu screen.
7 Saved pages Displays the list of saved pages. Saved pages are stored in your phone memory so you can see them offline.
41
i-mode (M3)
7 Saved pages Saved pages list Options menu
1Open Displays the current saved page.
2 Edit title Edits the title of the current saved page.
3 Protect On/Off Protects or unprotects the current page.
4 Delete one Deletes the current saved page.
5 Delete all Deletes all the saved pages excluding the protected.
6 Delete all + Pr. Deletes all the saved pages including the protected.
Saved pages details Options menu
1 Save image Saves an image as a file on the current saved page.
2 Edit title Edits the title of the current saved page.
3 Certificate info Displays the certificate information on the current saved page.
4Page info Displays the URL on the current saved page.
5 Protect On/Off Protects or unprotects the current page.
6 Delete Deletes the current saved page.
8 Settings Changes the settings of your browser.
1 Set time out Disconnects the connection after the set time. You can set 60 seconds or 90 seconds,
or disable this function.
2 Load images Sets whether to display images contained in web pages.
3Wrap text Sets whether to display text as is on web pages and mail/attachment text, or wrap it to
fit your phone’s screen.
4 Certificates Displays the certificate information and validates/invalidates a certificate.
5 Send terminal info Sets whether to display a confirmation message before sending the terminal
information to the Information Providers (IPs).
,If you agree to send private information (e.g. production serial No. and SIM
No.) to the IPs via the Internet, it may be obtained by others.
6 Set homepage Validates the homepage and sets the URL.
2You can display the homepage by pressing and holding from the standby
screen.
7 Video auto play Sets whether to play a video file automatically after or during download.
No. i-mode menu screen menus (Sheet 2 of 3)
42 i-mode (M3)
2Depending on the conditions, some options may be displayed in gray and not be available.
iMenu screen
From the iMenu screen you can access the various services provided by your i-mode service operator.
☛SK2 or 3 1 to display the i-mode menu screen ➔ 1 to display the iMenu screen
Browser Options menu
You can use the function menus of your browser such as adding a bookmark, saving a web page and creating a message.
☛From the iMenu screen or while downloading, to display the browser options menu.
8 Settings 8 Check settings Displays all the options set for the settings (browser).
0Back Returns to the i-mode menu screen (see “i-mode menu screen” on page 39).
No. Browser options menu
– Add bookmark Bookmarks the current page.
– Bookmarks Displays the Bookmark list.
2This option is displayed only when one or more bookmarks are registered.
– Save image Saves an image on the current page.
2This option is displayed only when one or more images are displayed on the current screen.
– Save page Saves the current page.
– Add to phonebook Saves the phone number displayed in the current page in the phonebook.
2This option is displayed only when one or more phone numbers are displayed on the current screen.
– Certificate info Displays the server certificate of the current page.
2This option is displayed only when the current page is a SSL page.
– Go to webpage Displays a page by keying in the URL or using the access history (see “Go to webpage” on page 40).
–Reload Updates the data on the current page.
– Page info Displays the URL of the current page.
– Add desktop icon Creates a desktop icon of the URL of the current page.
– Create message Creates a new message with the highlighted phone number or Email address in the message text.
No. i-mode menu screen menus (Sheet 3 of 3)
43
i-mode (M3)
,If you agree to send private information (e.g. production serial No. and SIM No.) to the IPs via the Internet, it may be obtained by others.
2Pressing CLR or may not bring back the previous screen. Screen operations depend on the current screen content.
Mail screen
From the Mail screen you can use the i-mode message services.
☛SK1 or 3 1 2 to display the Mail screen.
2The available options differ depending on the operators.
2If an error occurs while sending mail, it will be saved in the Draft folder as an unsent mail.
2The same mail can be sent to up to five addresses.
2If you save a mail while editing, it will be saved in the Draft folder.
No. Mail screen menus (Sheet 1 of 4)
1 Compose mail Displays the Compose mail screen (see “Creating a new mail” on page 35).
2 Compose MMS Displays the Compose MMS screen (see “Creating a new MMS” on page 36).
3 Inbox Displays the list of received mail/MMS.
Inbox list Options menu
– Show all Displays all the received mail/MMS.
– Show unread Displays only the unread mail/MMS.
– Show read Displays only the read mail/MMS.
– Show protect. Displays only the protected mails/MMS.
– Delete one Deletes the currently selected mail/MMS.
– Delete read mail Deletes all the read mails except protected mails/MMS.
– Delete all Deletes all the mails/MMS.
– Title sort Sorts the received mails/MMS by title.
– Address sort Sorts the received mails/MMS by address.
– Date sort Sorts the received mails/MMS by date.
Inbox details Options menu
–Reply Replies to the received mail/MMS.
– Reply quoted Replies to the received mail quoted.
44 i-mode (M3)
3 Inbox – Reply all Replies to the sender and all the recipients of a mail/MMS.
– Reply quoted all Replies to the sender and all the recipients of a mail quoted.
– Forward Forwards the received mail/MMS.
–Delete Deletes the received mail/MMS you are viewing.
– Add desktop icon Creates a desktop icon that creates a new message to the sender.
– Save address Saves the address of the sender into the phonebook.
– Add to phonebook Saves the highlighted phone number into the phonebook.
– Create message Creates a new message with the highlighted Email address or phone number.
– Save melody Saves the melody attached to the received mail.
– Save attachment Saves the attached file.
– Copy message Copies the message text.
– Copy subject Copies the desired subject text.
– Copy address Copies the desired address.
– Play attachment Plays the attachment content based on the content setting.
Play attachment Options menu
1 Copy text Copies the text data on the slide.
2 Save image Saves the image file on the slide.
3 Save audio Saves the audio file on the slide.
4 Save video Saves the video file on the slide.
–Browse
attachment Plays the attachment content manually.
Browse attachment Options menu
1 Copy text Copies the text data on the slide.
2 Save image Saves the image file on the slide.
3 Save audio Saves the audio file on the slide.
4 Save video Saves the video file on the slide.
5 Save selection Saves the highlighted phone number, Email address
or URL to the phonebook or bookmarks.
No. Mail screen menus (Sheet 2 of 4)
45
i-mode (M3)
3 Inbox -Browse
attachment 6 Create message Creates a message to the destination in the slide text.
7 Play slide Plays the highlighted slide.
– Protect On/Off Protects or unprotects the received mail/MMS.
4Sent mail Displays the list of sent mail/MMS.
Sent mail list Options menu
– Title sort Sorts the sent mail/MMS by their titles.
– Address sort Sorts the sent mail/MMS by their first destination addresses.
– Date sort Sorts the sent mail/MMS by the date they were sent.
– Delete one Deletes the selected mail/MMS.
– Delete all Deletes all the sent mail/MMS.
– Delete all + Pr. Deletes all the sent mail/MMS including the protected.
Sent mail details Options menu
– Re-edit Displays the composer to edit the sent mail/MMS again.
– Delete Deletes the sent mail.
– Add desktop icon Creates a desktop icon that creates a new message to the addressee.
– Save address Saves the destination address to the phonebook.
– Add to phonebook Saves the phone number and mail address contained in the message part.
– Create message Creates a new message to the highlighted Email address or phone number.
– Copy message Starts the copy mode in the message part.
– Copy subject Starts the copy mode in the subject part.
–Play attachment Plays the attachment content based on the content setting (see “Play attachment” on
page 44).
–Browse
attachment
Plays the attachment content manually (see “Browse attachment” on page 44).
– Protect On/Off Protects or unprotects the received mail/MMS.
5Draft Displays the unsent and the saved draft mail/MMS.
Draft Options menu
No. Mail screen menus (Sheet 3 of 4)
46 i-mode (M3)
2Depending on the conditions, some options may be displayed in gray and not be available.
5Draft 1 Delete one Deletes the selected mail/MMS.
2 Delete all Deletes all mail/MMS.
6 Check new mail Checks if there is any new i-mode messages (mail/MMS) for you stored at the mail server.
7 Mail settings Changes the mail settings.
1 Edit header Edits the header to be added at the beginning of a mail, and sets whether to add it
automatically.
☛Highlight the checkbox ➔ to place a check, to automatically add a header.
☛Highlight the text box ➔ to edit the header ➔ Edit the text ➔
2 Edit signature Edits the signature to be added at the end of a mail, and sets whether to add it
automatically.
☛Highlight the checkbox ➔ to place a check, to automatically add the signature.
☛Highlight the text box ➔ to edit the signature ➔ Edit the text ➔
3 Reply marker Edits the reply markers to be added when replying to a mail with quotations from the
original.
☛Highlight the text box ➔ to edit the reply marker ➔ Edit the text ➔
4 Auto play Sets whether to automatically play or display the sound, image or video file attached,
when you open the mail.
5 Auto reception Sets whether to automatically retrieve a mail after receiving the incoming mail
notification.
2When set to on, your phone will automatically receive mail. If set to off, you will
have to manually retrieve from your i-mode service provider using the Check new
mail of Mail screen menus (see “Check new mail” on page 46).
6 Receive
attachment
Sets the attachment file type that can be received.
☛Highlight the file type ➔ to place a check.
7 Attachment data Selects whether to receive Melody For i-mode (MFi) files attached to a mail.
8 Font size Sets the font size to display the mail.
9 Check settings Displays the values set to the above mail settings.
0 Back Returns to the Mail screen.
0Back Returns to the i-mode menu screen.
No. Mail screen menus (Sheet 4 of 4)
47
i-mode (M3)
i-mode glossary
The following defines the basic terms used in this section.
Term Definition
Site (program) An Internet contents page especially designed for i-mode users, which can be accessed from your i-mode top screen of
your IP.
Mail Mail is the messaging service of i-mode. You can not only exchange messages with other cellphones, but also with PCs,
PDAs, etc.
MMS Multimedia Messaging Service lets you send messages with image/video/sound files attached. The MMS type message is
also referred to as an MMS.
Access history Your phone stores up to 10 URLs you have accessed. You can refer to this list when you want to go to a web page you have
accessed recently.
Web page An Internet contents page compatible to i-mode services, which can be browsed using your phone, including the sites
(programs).
Bookmark A bookmark contains the URL of a web page. You can save up to 50 bookmarks and use them for easier accesses.
Certificate
information
If you are displaying a Secure Sockets Layer (SSL) page designed to enable safe data transmission, you will be able to see
its certificate information.
IP Information Provider. Your IP provides you the i-mode sites (programs).
Home page A web page that is set in your profile as the page to connect to when you press and hold from the standby screen.
Saved pages You can save up to 20 web pages in your phone memory, for quick off-line access.
Streaming Streaming video is received in a continuous stream and is played as it arrives. This type of video cannot be saved to your
phone.
48 Phonebook (M4)
Phonebook (M4)
Phonebook types
Your phone can have up to 7 directories stored on your SIM card and in your phone memory: Complete (a list of all the numbers stored in the ADN and
FDN), personal directories (ADN) in the SIM card, personal directories (ADN) in the phone memory, Service Dialling Numbers (SDN), Fixed Dialling
Numbers (FDN), Own number and Voice mail number.
2When viewing any of the directories described, you can switch to the other directories (if your SIM card supports them) by pressing .
2The maximum number of phone numbers that can be stored on a SIM card is the total of the ADN, FDN and SDN directories.
2When you activate the phonebook, the directory which you were referring to the last time will open.
Personal directory (ADN)
These numbers are known as abbreviated dialling numbers (ADN). There are two types of ADN, one is the phonebook stored in the phone memory
(the phonebook (Phone)) and the other is the phonebook stored on the SIM card (the phonebook (SIM)).
Phonebook (SIM)
Up to 255 personal data can be stored in the SIM card. Each personal data contains a phone number, a name and a location number.
2The number of phone numbers that can be stored on a SIM card depends on the SIM card capability.
Phonebook (Phone)
Up to 500 personal data can be stored in your phone memory. Each personal data is given a location number (1 to 500), and it can be allocated to a
group. To each personal data, you can set the following: 7 phone numbers (Home, Mobile, Work, Data, Fax, Other phone x 2), 2 Email addresses, 2
descriptive information, Group, Voice tag, LED colour, Picture/Video, Ringer and Location number.
2Up to 10 phone numbers can have a voice recognition recording allocated to them.
Fixed dialling numbers (FDN)
Fixed dialling numbers are a means of limiting which numbers can be called from your phone. With the FDN feature switched on (see page 25), you can
call with your phone the numbers you have stored in this phonebook and the emergency number only.
,Although FDN is supported by your phone, it must be present on your SIM card - check with your service provider.
Service dialling numbers (SDN)
The numbers stored in the SDN directory are pre-installed by your service provider. They will call numbers and services as agreed with your supplier
(e.g. customer enquiries, billing information, sportslines, weatherlines, etc.) and cannot be edited by you.
,Although SDN is supported by your phone, it must be present on your SIM card - check with your service provider.
49
Phonebook (M4)
Accessing your phonebook (M4)
You can store personal information in the phonebook of your phone or your SIM card.
Displaying a personal data (M41)
☛ 4 1 and the appropriate key for the desired directory or until the required directory is displayed ➔ Highlight the required personal data
➔
Displaying information about your phonebook (M42)
☛ 4 2 to display the information about your phonebook.
2This function is SIM dependent.
Call options (M43)
☛ 4 3 to display the Call options screen.
2For details on the Call options screen, see “Call options (M43)” on page 10.
Phonebook list Options menu
☛ 4 1 and the appropriate key for the desired directory or until the required directory is displayed ➔ Highlight the required personal data
➔
No. Phonebook list Options menu
1 Add new Adds a new personal data to Phone/SIM/FDN.
2Edit Displays the data edit screen to edit the currently highlighted personal data.
2When editing the data in FDN, you will be prompted to enter PIN2 code.
Phonebook list screen Personal data screen
SK2
Abbreviated dialing number (ADN)
Abbreviated dialing number (ADN)
50 Phonebook (M4)
3 Copy Copies personal data to another phonebook (see “Copying and moving personal data” on page 53 for details).
1 Current copy Copies the currently highlighted personal data.
2 Package copy Copies the selected data in the list.
4Move Moves the currently highlighted personal data to SIM, Phone, FDN, Own number or Voice mail number.
5Delete Deletes personal data.
1 Delete current Deletes the currently highlighted personal data.
2 Delete all Deletes all the data in the list.
6 Groups Editing the group information
☛Highlight the group you wish to edit ➔ SK1 and highlight the required field
☛To rename the group name, select Group name field ➔ Key in the name of the group ➔
☛To set information on the selected group, select Info field ➔ Key in the info ➔
☛To select the LED colour, select LED field ➔ 1 ➔ Highlight the desired colour ➔
☛To select the CLI picture, select Picture field ➔ 1 for Picture ➔ Highlight the desired picture ➔
☛To select the ringer, select Ringer field ➔ 1 for Sound or 2 for Video ➔ Highlight the desired ringtone
or video ➔
☛SK1 to set the change
2If the personal settings for the LED colour, CLI picture, or the ringer are also set, they have priority over
those of the Group settings.
Group member list screen Options menu
☛Highlight the group you wish to edit ➔ to display the list of group members ➔ Highlight the member
➔
1Call Calls the highlighted member.
2 Create message Creates a new message to the highlighted member.
3 Add new Creates a new phonebook entry to join the group.
4 Add to group Adds a phonebook entry to the group.
5 Remove from
group
Removes the highlighted member from the group.
6 Remove and delete Removes the highlighted member from the group and delete the phonebook
entry at the same time.
No. Phonebook list Options menu
51
Phonebook (M4)
2Depending on the conditions, some options may be displayed in gray and not be available.
Making a call or creating a message from the phonebook list
☛Highlight a desired personal data to display the stored numbers or Email addresses in the help area ➔ Use and to display the other stored
phone numbers or Email addresses, if any, in the help area
☛Press to make a phone call to the displayed phone number, or press SK1 to send a new message to the phone number or Email address
Adding a new personal data
☛ 4 1 and the appropriate key for the desired directory, or until the required directory is displayed ➔ SK2 ➔ Select the directory to which
you wish to store the personal data ➔ Enter the name and other necessary information ➔ SK1 (see “Editing an existing personal data” on
page 52).
2You can also input phone numbers on the standby screen and press to add a new personal data.
2It is best to store numbers using the international number format.
6Groups 7 Add desktop icon Creates a desktop icon of the phone number/Email address of the highlighted
member.
7Sort Sorts the personal data in the order of alphabets or location number.
2Sorting may take time depending on the number of personal data entries, the number of characters
contained in each entry and the type of language.
1 Alphabetic Sorts the personal data alphabetically.
2You can jump directly to a name beginning with specific characters by
pressing the appropriate key (e.g. press 5 once to jump to names beginning
with J, or twice to jump to names beginning with K).
2 Location Sorts the personal data in memory location number.
8 Location Searches for the personal data by the location number.
☛Key in the desired location number ➔ SK1 to display the Phonebook list screen with the selected
personal data highlighted.
9 Show Displays phonebook information.
1 Summary Displays the summary of phonebook contents.
2 Voice tag list Displays the phonebook entry names with the voice recognition tags recorded.
0Send via Bluetooth Sends the currently highlighted personal data to another device via Bluetooth.
/See also: “Bluetooth data exchange” on page 80.
Add desktop icon Creates a desktop icon of the highlighted personal data.
No. Phonebook list Options menu
▼
▼
52 Phonebook (M4)
Editing an existing personal data
☛ 4 1 and the appropriate key for the desired directory or until the required directory is displayed ➔ Highlight the required personal data
➔ 2
2For the phonebook (SIM) and FDN, only the name, phone number and the location number can be added or edited in the following procedures.
2For the own number and voice mail number settings, only the name and phone number can be added or edited in the following procedures.
Adding/editing phone numbers, Email addresses & personal information
☛Highlight the field you wish to edit or add information to ➔
☛Add the required number or information or make necessary changes to the selected field ➔
☛Highlight another field to make further changes, if required
2You can edit the Name, Phone number, Email address and Info fields by the above method.
Allocating a group
☛Highlight the Group field ➔ ➔ Highlight the group you wish to add the current personal data to ➔
Voice recall functions
Adding a Voice recall recording
☛Highlight the Voice tag field ➔ ➔ 1
☛Say the name you wish to record as a voice tag ➔ Say the name again for confirmation according to the displayed message
Playing a Voice recall recording
☛Highlight the Voice tag field ➔ ➔ 2
Deleting a Voice recall recording
☛Highlight the Voice tag field ➔ ➔ 3
2Up to 10 voice tags can be stored.
2You can check the number of stored voice tag and list of those tags (see “Summary” and “Voice tag list” on page 51).
Allocating a LED colour
☛Highlight the LED colour field ➔ ➔ 1 ➔ Highlight the desired colour ➔
2The personal setting for the LED colour has priority over the Group setting and phone setting for the LED colour.
Allocating a picture as a CLI
You can set a picture to be displayed on the screen as a Calling Line Identification (CLI) for an incoming call.
☛Highlight the Picture field ➔ ➔ 1 to display the picture list screen
☛Highlight the desired picture ➔ SK1 to preview the picture or to select the highlighted picture
2A ✔ is displayed on the icon for which the item is currently selected.
53
Phonebook (M4)
2See also: “Pictures (M63)” on page 62.
Allocating sound/video as a ringer
You can set a sound or video as a ringer for an incoming call. When a video is set, a movie is displayed on the screen with the sound.
☛Highlight the Ringer field ➔ ➔ 1 to display the sound list screen or 2 to display the video list screen
☛Highlight the desired sound or video ➔ SK1 to preview the file or to select the highlighted file
2A ✔ is displayed on the icon for which the item is currently selected.
2If the video as a ringer is set, it will sound and will be displayed on the screen regardless of the CLI picture setting.
2See also: “Sounds (M62)” on page 61.
Allocating a location number
☛Highlight the Location number field ➔ ➔ Key in the desired location number ➔
Saving the edited personal data
☛ After editing the required fields, SK1 to save the edited data and return to the previous screen.
Copying and moving personal data
☛ 4 1 and the appropriate key for the desired directory or until the required directory is displayed ➔ Highlight the required personal data/
list of data ➔ 3 to copy or 4 to move
☛For copying, 1 to copy the highlighted personal data or 2 to copy all the personal data in the current list
☛Press the appropriate key for the desired destination (SIM, Phone, FDN, Own number or Voice mail number)
2If you copy or move from phonebook (Phone), the Origin number screen will be displayed to choose which phone number to copy.
☛Key in the desired location number ➔
2If you copy or move to phonebook (Phone), the Number type screen will be displayed to choose which phone number type to copy to.
Personal data Options menu
☛ 4 1 and the appropriate key for the desired directory or until the required directory is displayed
☛Highlight the required data ➔ ➔ Highlight the required field ➔
No. Personal data Options menu
1Call Calls the highlighted phone number.
2 Create message Creates a new message to the highlighted phone number or Email address.
3 Send via Bluetooth Sends the selected personal data to another device via Bluetooth.
4Edit Edits the selected personal data.
54 Phonebook (M4)
/See also: “Phonebook list Options menu” on page 49 for the operation of 4 (Edit), 5 (Copy), 6 (Move) and 7 (Delete current).
Voice mail (M417)
Voice mail function enables you to forward received calls to the Voice mail centre, and the caller can leave voice messages in your voice mail mailbox.
You may be notified by an icon on the standby screen if the caller leaves a voice message.
,The voice mail service is network dependent. Contact your service provider for details on your voice mail number.
Setting the Voice mail number
2This function is available when the Voice mail number has not been set.
☛ 4 1 7 ➔ Highlight the required line ➔ twice ➔ ➔ key in the voice mail number ➔ ➔ SK1 to save the change.
Forwarding a call to the Voice mail centre
☛Set the voice mail centre number (see “Setting the Voice mail number” for details) ➔ Set up Call diversion (see “Call diversion (M161)” on page 12
for details). When you receive a call set to be diverted, the call will be diverted to the voice mail centre.
Retrieving a Voice mail
2This function is available when the Voice mail number has been set.
☛ 4 1 7 ➔ Highlight the required line ➔
2You can also retrieve a voice mail by pressing and holding 1 from the standby screen.
2To set up the line to call the voice mail centre, see “ALS setup” on page 20 for details.
5Copy Copies the selected phone number(s)/Email address(es).
☛Press the appropriate key for the desired destination (SIM, Phone, FDN, Own number or Voice mail
number) ➔ Key in the desired location number ➔
6Move Moves the currently highlighted personal data.
☛Press the appropriate key for the desired destination (SIM, Phone, FDN, Own number or Voice mail
number) ➔ Key in the desired location number ➔
7 Delete current Deletes the selected personal data.
8 Add desktop icon Creates a desktop icon of the selected personal data.
No. Personal data Options menu (Continued)
55
Camera (M5)
Camera (M5)
Camera function enables you to take pictures or record videos and save them as Joint Photographic Expert Group (JPEG) files and 3rd Generation
Partnership Project (3GPP) files respectively. You can enjoy the picture and video files in many ways: send them attached to an MMS or Email, set a
picture file as the wallpaper for your phone, etc.
Notes on using the camera
Handling the Camera
,The camera of your phone is manufactured using high-precision technology. However, there may be dots or lines on the screen that
appear darker or brighter than the others. Note also that when you are shooting or recording in dimly-lit places, the amount of noise
(such as red and blue dots or horizontal lines) may increase noticeably.
,Be careful not to apply force to the lens when closing your phone. This could damage the lens.
2Fingerprints or grease on the lens can result in focusing problems or dark images. Wipe the lens clean with a soft cloth before use.
2The image quality may be degraded after your phone has been left for a long period in a warm place.
2Exposing the camera to direct sunlight for a long period could discolour the camera’s internal colour filter and cause discoloured images.
2Camera mode is automatically cancelled if none of the phone’s keys are pressed for 3 minutes or longer.
Precautions when taking pictures/recording videos
2You cannot switch the camera’s shutter sound off. The shutter makes a clicking sound when you take a picture or start/end a video recording,
even when the phone is in Meeting mode.
2Avoid camera shake. Moving the phone when you take a picture will result in a blurred image. Hold the camera firmly to keep it still when you take
a picture, or use the auto timer to take the shot.
2As there is a slight delay from the time you press or Side up until the picture is actually taken, do not move the camera until you hear the shutter
sound.
2If taking a picture with not enough light, try to hold the phone still as much as possible, and for a longer period of time after the shutter sound: the
shutter speed may be slower in a darker environment.
2Note that if you attempt to shoot directly into a strong light source, such as the sun, another bright light or the high reflecting target with strong
light, the image may contain washed-out white highlights or be disrupted.
2While recording, be careful not to cover the mouthpiece of your phone as it is used as the microphone to record sound along with the video.
Copyright information
2Images and videos shot or recorded on your phone cannot be used in ways that infringe copyright laws without the consent of the copyright holder,
unless intended only for personal use. Note that some restrictions apply to the photographing of stage performances, entertainments and exhibits,
even when intended purely for personal use.
56 Camera (M5)
2Users are also asked to note that the transfer of images protected under copyright laws is only permissible within the restrictions imposed by those
copyright laws.
,Be considerate of other people’s privacy when you take a picture or record a video using the camera of your phone and send it to others.
Taking a picture (M51)
☛To activate the camera function, press and hold Side up or press 5 1
2When you highlight Camera on the Camera screen, pressing SK1 creates a desktop icon of the camera function on the standby screen.
☛Look into the camera view finder screen and adjust the camera position to place the target on the screen.
2You can switch the camera view finder screen between the main-LCD and the 2nd-LCD by pressing .
2You can take a picture while the phone is closed.
☛Hold the phone still ➔ To use the shutter, or Side up ➔ Check the picture ➔ If successfully taken, ➔ Saved as a JPEG file in a folder in
Pictures
2After taking a picture, press SK1 to send the taken picture attached to a message, and press SK2 to discard the picture.
2The default file name for the picture saved in the folder is the date, month, year and sequence number. When you take pictures in burst mode,
the saved files will be named by the default file names plus a consecutive two-digit number at the end.
2If a call comes in while you are checking or saving a photographed image, image storage is cancelled. When this occurs, the next time you select
camera function a message appears to say that you have an image that was not stored, allowing you to check and store the image.
2Before taking a picture, you can switch to the video camera function by pressing SK2. This use of SK2, however, is invalid if the self-timer function
is activated.
Operations when taking a picture
☛To turn the light on or off, SK1 or Side down
2Take care not to hold the light too close to your or other people’s eyes when the light is lit.
☛To zoom in and out, ▲ or ▼
2You can also select 1x, 2x, 3x, 4x or 5x magnification from the Zoom setting on the Camera Options menu.
☛To turn on/off the camera view finder on the full screen, press #.
2Depending on the photo size, there may be parts not seen on the full screen view finder display in the saved picture.
☛To control the brightness level of the picture, or
Camera Options menu (before taking a picture)
No. Camera Options menu (before taking a picture)
1 Single mode/Burst mode Switches the shooting mode to Single/Burst mode (serial shooting).
2 Shoot environment Changes the camera settings to suit the environment. Select from Standard, Person, Room or Darkness.
▼
▼
57
Camera (M5)
2Depending on the conditions, some options may be displayed in gray and not be available.
3 Effect Applies special effect to the picture. Select from Off, Sepia, Monochrome, or Negative film.
4Photo size Sets the picture size to T1 : 128x96 pixels, T2 : 176x144 pixels, T3 :176x220 pixels, T4 : 352x288 pixels,
T5 : 640x480 pixels or T6 : 1280x1024 pixels.
2You cannot use the Zoom function for T5 and T6, and you can select 1x to 2x magnification for T3 and
T4, 1x to 4x magnification for T2 and 1x to 5x magnification for T1.
2You can use the Frame and Burst mode functions for T1, T2 and T3.
2You cannot use the Full screen function for T1 and T2.
2If you select T3, T4, T5 or T6, the picture on the camera view finder screen will be displayed as a
smaller picture than the actual size. Also on the camera view finder screen, the picture size before
shooting differs from the size after shooting.
5 Image quality Sets the image quality to Super fine, Fine, Normal, Economy or Super economy.
6Frame Selects whether to use a frame when taking pictures, and sets the desired frame with which a picture will
be taken.
7 Self timer/Self timer cancel Activates or deactivates the self-timer function.
8 Sound settings Selects the Shutter sound and Self timer sound.
9Pictures Opens Pictures in My data.
0 Other settings Add desktop icon: Creates a desktop icon of the camera function on the standby screen.
Automatic save: Selects whether to save taken pictures automatically or not.
Save in: Selects the folder (preset or created) where the taken picture will be saved.
Light: Turns the light on or off.
Brightness: Changes the brightness level of the picture between -2 and +2.
Zoom: Changes the zoom magnification from 1x, 2x, 3x, 4x or 5x.
Thumbnail view: Selects whether to display the pictures taken in the Burst mode as thumbnails
or slides.
Video recorder: Activates the video function.
Flicker control: Selects 50Hz, 60Hz or Auto to prevent flickers when taking a picture under a
fluorescent light.
Switch finder Selects whether to display the camera view finder on the main-LCD or the 2nd-LCD.
2On the 2nd-LCD view finder, the object appears as a mirrored image.
# Full screen Turns the Full screen on or off.
No. Camera Options menu (before taking a picture) (Continued)
58 Camera (M5)
Camera Options menu (after taking a picture)
2Depending on the conditions, some options may be displayed in gray and not be available.
Recording a video (M52)
Recording a video
,To record a video, keep your phone open at all time. Unlike taking a picture, you cannot record a video while the phone is closed.
☛Press and hold Side up then SK2, or press 5 2 ➔ Look into the view finder screen and adjust the camera position.
2When you highlight Video on the Camera screen, pressing SK1 creates a desktop icon of the video function on the standby screen.
2You can switch the camera view finder screen between the main-LCD and the 2nd-LCD by pressing .
☛To start recording, or Side up ➔ The progress bar will show the ratio of how much you have recorded already.
2While recording, be careful not to cover the mouthpiece of your phone as it is used as the microphone to record sound along with the video.
2While recording, the key tones are deactivated.
☛Move the camera to capture the scenes you want ➔ To stop recording, press or the Side up.
2After the set video file size is reached, the recording automatically stops.
2After recording, press SK1 to replay the recorded video, and press SK2 to send the video file attached to a message.
2While replaying, you can fast forward by pressing or rewind by pressing . Pressing SK1 or will stop the fast forwarding/rewinding. Then,
pressing SK1 will restart and continue the replay.
No. Camera Options menu (after taking a picture)
1 Save current Saves the currently displayed picture in the folder selected as Save in setting.
2 Save all Saves all pictures taken in Burst mode.
3 Create message Creates a new message with the file attached.
4 Set as wallpaper Sets the picture to be the main-LCD or 2nd-LCD wallpaper.
5 Display as normal image/
Display as mirror image
Selects whether to display the taken picture as a normal or mirror image on the main-LCD
preview screen when you select the 2nd-LCD as a camera view finder in Single mode.
6 Save as mirror image Saves the picture as a mirror image when you select the 2nd-LCD as a camera view finder in
Single mode.
7 Thumbnail view Selects whether to display the pictures taken in the Burst mode as thumbnails or slides.
8 Automatic save Selects whether to save taken pictures automatically or not.
9 Save in Selects the folder (preset or created) where the taken picture will be saved.
0Pictures Opens Pictures in My data.
▼
▼
59
Camera (M5)
2You can discard the recorded video by pressing or CLR.
☛To save the recorded video, . The recorded video is saved as a 3GPP file in the Videos - My movies folder in My data (see page 61).
2Pressing # before/while playing a video file will enlarge the replay screen size, and pressing # will return the screen size to normal for T1 : 128x96
pixels only.
2The default file name for the recorded video saved in the folder is the date, month, year and sequence number.
/For the operations while replaying the video, see “Videos (M61)” on page 61.
/For the operations while recording a video, see “Operations when taking a picture” on page 56.
2If a call comes in while you are checking or saving a video, video storage is cancelled. If this occurs, the next time you select camera function a
message appears to say that you have a video that was not stored, allowing you to check and store the video.
2Before recording a video, you can switch to the camera function by pressing SK2. This use of SK2, however, is invalid if the self-timer function is
activated.
Operations when recording a video
☛To turn the light on or off, SK1 or Side down
2Take care not to hold the light too close to your or other people’s eyes when the light is lit.
☛To zoom in and out, ▲ or ▼
☛To control the brightness level of the picture, or
Camera Options menu (before recording a video)
No. Camera Options menu (before recording a video)
1 Shoot environment Changes the camera settings to suit the conditions. Select from Standard, Person, Room or Darkness.
2 Effect Applies special effect to the video. Select from Off, Sepia, Monochrome, or Negative film.
3 Screen size Sets the video screen size to T1 : 128x96 pixels or T2 : 176x144 pixels.
4 Video file size Sets the video file size to Mail size or Normal size.
5Quality Sets the video quality to High or Standard.
6 Self timer/Self timer cancel Activates or deactivates the self-timer function.
7Self timer sound Selects the self timer sound from Sound1, Sound2 or Sound3.
8Videos Opens Videos in My data.
▼
▼
60 My data (M6)
2Depending on the conditions, some options may be displayed in gray and not be available.
Camera Options menu (after recording a video)
2Depending on the conditions, some options may be displayed in gray and not be available.
My data (M6)
Using My data, you can playback sound and MP3 files, or display pictures and videos downloaded from the Internet or captured with the camera function
of your phone.
9 Other settings Add desktop icon: Creates a desktop icon of the video function on the standby screen.
Save in: Selects the folder (preset or created) where the recorded video will be saved.
Light: Turns the light on or off.
Brightness: Changes the brightness level of the video between -2 and +2.
Zoom: Changes the zoom magnification from 1x to 5x for T1 and from 1x to 4x for T2.
Camera: Activates the camera function.
Flicker control: Selects 50Hz, 60Hz or Auto to prevent flickers when taking a picture under a
fluorescent light.
0 Switch finder Selects whether to display the viewfinder on the Main-LCD or the 2nd-LCD.
No. Camera Options menu (after recording a video)
1 Save Saves the currently displayed video.
2 Create message Creates a new message with the file attached.
3 Set as ring tone Sets the video as the ringtone.
4 Set as wallpaper Sets the video to be the main-LCD wallpaper.
5 Full screen Selects whether to enlarge the replay screen size.
2You cannot use the Full screen function for T2 : 176x144 pixels.
6 View detail Displays detailed information on the selected video.
7 Save in Selects the folder (preset or created) where the recorded video will be saved.
8Videos Opens Videos in My data.
No. Camera Options menu (before recording a video)
61
My data (M6)
Videos (M61)
In the following section, how to playback video files (videos) stored in your phone is described. You can either record videos using your phone, download
them from the Internet, receive them attached to messages. There are two pre-set folders: My Movies and Download.
Replaying the video files
☛▼ 1 or 6 1 ➔ Highlight a folder ➔ or ➔ Highlight a video file you wish to replay ➔ or ➔ The video file will be replayed.
2When the flat view function is activated, the list of folders is not displayed. The list of all the stored video files is displayed.
2If you wish to move to another hierarchy folder, use and
2Pressing # on the video preview screen will enlarge the replay screen size, and pressing # again will return the screen size to normal for T1 :
128x96 pixels only.
2For the definitions of the icons displayed while replaying, see “LCD and displayed icons” on page viii.
2To create your own playlist, see “Music player (M81)” on page 68.
Operations while replaying video
☛To stop, SK2
☛To pause, SK1 ➔ While pausing, SK1 again to restart and continue the replay.
☛To fast forward/rewind, or ➔ SK1 or will stop the fast forwarding/rewinding.
☛To enlarge the replay screen size, # for T1 : 128x96 pixels only
☛To adjust the volume, Side keys
☛To display the previous/next file, ▲ or ▼
2You cannot fast forward, rewind or enlarge the screen for video files with only sound but no image.
Sounds (M62)
In the following section, how to playback sound files stored in your phone is described. There are three pre-set folders: Download, Preset and Voice
memo.
Selecting and playing sound
☛▼ 2 or 6 2 ➔ Highlight a folder ➔ or ➔ Highlight a sound file you wish to replay ➔ or
2When the flat view function is activated, the list of folders is not displayed. The list of all the stored sounds files is displayed.
2If you wish to move to another hierarchy folder, use and
Operations while playing sound
☛To stop, SK2
☛To adjust the volume, Side keys.
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
62 My data (M6)
☛To replay the previous/next file, ▲ or ▼
Pictures (M63)
The Pictures function allows you to display images and animations, which were obtained with the camera function of your phone, received as a file
attached to MMS messages, or downloaded from the Internet. The images can also be edited using this function. From the Pictures function you can
also attach images and animations to messages you compose. There are five pre-set folders: Photo, Download, Preset, Frame, and Stamp.
Displaying the Pictures view screen
☛▼ 3 or 6 3 ➔ Highlight a folder ➔ or ➔ Highlight an image file you wish to display ➔ or
☛To display the previous/next image file, ▲ or ▼
2When the flat view function is activated, the list of folders is not displayed. The list of all the stored image file is displayed.
2If you wish to move to another hierarchy folder while the Thumbnail view is turned off, use and
Cutting the image
☛Highlight or display the image file you wish to edit ➔ 1 3 ➔ Select the image size ➔ A frame indicating the cut area appears on the preview
screen.
☛Move the frame position ➔ ➔ SK1 if the image is favorable
2When you select Free, a cross indicator appears on the preview screen. Move it to the point to start a frame and to confirm the position. Then,
expand the frame into the required size and to confirm.
Reducing the image size
☛Highlight or display the image file you wish to edit ➔ 1 4 ➔ Select the image size ➔ SK1 if the image is favorable
Rotating the image
☛Highlight or display the image file you wish to edit ➔ 1 5 ➔ SK1 to rotate the image 90 degrees clockwise.
☛Keep pressing SK1 until the image is at the required angle ➔ to confirm
Decorating the image with stamps
☛Highlight or display the image file you wish to edit ➔ 1 6
☛To apply a marker stamp, 1 ➔ Highlight the required stamp ➔ ➔ The marker stamp position is displayed in centre
2If you wish to preview the highlighted stamp, press SK1. To display the previous/next stamp, ▲ or ▼.
☛To apply a text stamp, 2 ➔ Key in the text ➔ ➔ The text stamp position is displayed in centre
☛Move the stamp position ➔ to confirm ➔ The stamp preview is displayed again. Repeat applying if necessary, or to select another
stamp.
☛SK1 when finished applying the stamp (the stamp preview will not be applied this time)
▼
▼
▼
▼
63
My data (M6)
Adding a frame to the image
☛Highlight or display the image file you wish to edit ➔ 1 7 ➔ Highlight a frame ➔ to preview the resulting image ➔ Scroll through the
various frames by ▲ and ▼ ➔ to confirm.
Saving the edited image
☛After any edition, SK1 or to save the edited image ➔ Select the Save Quality
2SK1 to check the expected size of the image.
☛Edit the name (if required) ➔
Printing an image using a printer
You can print an Exif format image file by connecting your phone to a PictBridge compatible printer using a USB cable (option).
2There may be PictBridge compatible printers that cannot be connected to your phone.
2Refer to the operation manual of the printer for details on the printing.
☛▼ 3 or 2 3 ➔ Highlight a folder ➔ or ➔ Highlight an image file you wish to print ➔ 2 4
2“Print via USB” may be displayed in gray and unavailable, depending on the image file.
☛Connect your phone and the printer with the USB cable ➔ Prepare the printer ready for printing, referring to its manual
☛Check the print detail screen displayed
☛To print as seen on the detail screen, SK1
☛To edit the print detail and then print, on the print detail screen to display the Options menu ➔ Edit the detail using the Options menu
➔ SK1
2The Options menu may change depending on the connected printer.
2If any interruption or error occurs, or the printing is not completed normally, pull out the USB cable and start again from the first step.
2If you want to print multiple images on one sheet, set both the settings for Number of prints and N-up on Layout screen under Layout detail. For
example, 4 for Number of prints and 2 for N-up will print 2 sheets with 2 half-sized images per sheet.
No. Print via USB Options menu
1 Number of prints Sets the number of prints to output.
2 Layout detail Selects the paper size, paper type and layout to print the image file.
3 Print quality Selects the required quality of printing.
4 File name Selects whether or not to print the file name on the paper.
5Date Selects whether or not to print the date on the paper.
▼
64 My data (M6)
MP3 (M64)
In the following section, the procedures to display and play your MP3 files are described. There is one pre-set folder: Download.
Selecting and playing an MP3 file
☛▼ 4 or 6 4 ➔ Highlight the MP3 file you want to play ➔ or
2When the flat view function is activated, the list of folders is not displayed. The list of all the stored MP3 files is displayed.
2To create your own playlist, see “MP3 player (M82)” on page 69.
Operations while playing an MP3 file
☛To stop, SK2
☛To adjust the volume, Side keys.
☛To replay the previous/next file, ▲ or ▼
File selector Options menu
☛Display the Videos/Sounds/Pictures/MP3 list screen ➔
No. File Selector Options menu
1 Edit item Rename item: Edits the user title or name of the selected folder or file.
Set protection: Sets the protection settings of the selected folder or file on/off.
Cut: Cuts the selected picture into T1 : 128x96 pixels, T2 : 176x144 pixels, Main-LCD
(176x220), 2nd-LCD (128x128) or Free.
Reduce: Reduces the selected picture to fit within T1 : 128x96 pixels, T2 : 176x144 pixels, Main-
LCD (176x220) or 2nd-LCD (128x128).
Rotate: Rotates the selected picture.
Stamp tool: Adds a marker or text stamp on the selected picture.
Frame: Sets a frame to the selected picture.
2You cannot use the Cut and Rotate functions for T6.
2You can only use the Stamp tool and Frame functions for T1, T2 and T3.
2 Use item (Videos) Set as ring tone: Sets the selected video to be the ringer tone.
Set as wallpaper: Sets the selected video to be the main-LCD wallpaper.
Send via Bluetooth: Sends the selected video via Bluetooth to other devices or a cellphone.
▼
65
My data (M6)
2 Use item (Sounds) Set as ring tone: Sets the selected sound to be the ring tone.
Set as SMS tone: Sets the selected sound to be the SMS tone.
Set as Mail tone: Sets the selected sound to be the Mail tone.
Send via Bluetooth: Sends the selected sound via Bluetooth to other devices or a cellphone.
2 Use item (Pictures) Set as wallpaper: Sets the selected image to be the main-LCD or 2nd-LCD wallpaper.
Add desktop icon: Creates a desktop icon for the selected image on the standby screen.
Send via Bluetooth: Sends the selected image via Bluetooth to other devices or a cellphone.
Print via USB: Prints the selected image file using a PictBridge printer via USB cable (see
page 63).
2 Use item (MP3) Send via Bluetooth: Sends the selected MP3 through Bluetooth to other devices or a cellphone.
3 Create message Creates a new message with the file attached.
2This function is not available for the MP3 files.
4 Delete item Deletes the selected file and folder.
5 Delete all Deletes all the files in the current list.
6 Copy item Copies the selected file or folder to the selected folder.
7Copy all Copies all the files in the current list to the selected folder.
8Move Moves the selected file/folder or all the files in the current list to the selected folder.
9 Create folder Creates a new folder under the current folder.
0 Storage detail Displays the current storage information of your phone memory.
View detail Displays the details of the selected folder or file.
2You can also display the details on the highlighted folder or file by pressing without displaying the
Options menu.
No. File Selector Options menu
66 My data (M6)
2Depending on the conditions, some options may be displayed in gray and not be available.
2Depending on the size of the data, file selector operation may take a long time.
2Neither protected data nor preset data and folders can be deleted or moved.
# Options Sorting order: Sorts the files by date or alphabetically.
Info column: Sets whether to display the column on the list screen, and the information to be
shown there.
None: No column showing
Size: Approximate size of the file
Type: File type
2 You can also change the information on the column by pressing # without
displaying the Options menu.
Thumbnail view: Displays the files as thumbnails.
Flat view: Displays the list of all the stored files regardless of the folder hierarchy.
Save options: Saves the current option settings.
Reset options: Resets the option settings.
No. File Selector Options menu
67
Java™ (M7)
Java™ (M7)
You can download Java™ applications (games etc.) from i-mode sites and run them on your phone.
Programs (M71)
How to run software
To run a software (Java™ application), perform the following.
☛ 7 1 or press and hold SK2 ➔ Highlight an application containing the software you want to run ➔
2When you display the Java™ applications list screen for the first time after downloading a program(s), it may take a while for your phone to verify
the program(s). A message will be displayed during this process, and you may activate the program(s) after it is completed.
,After downloading the software, always make sure that you check the downloaded program is displayed in the Applications screen.
,Do not remove the battery while the software is running as data to that point may not be saved.
2While the software is active, the Java™ operation icon is displayed (see page viii).
Java™ System menu
☛ 7 1 ➔ Highlight an application ➔
2Depending on the conditions, some options may be displayed in gray and not be available.
Application menu
☛ 7 1 ➔ Highlight an application you want to run ➔ SK1
No. System menu
1 Description setting Selects whether to display the information of the selected application.
2 Delete all Deletes all the applications.
3 Storage status Displays the status of Java™ applications currently stored in your phone.
4 Trace info. Displays the trace information.
5 About Displays the information of the Java™ system.
No. Application menu
1 Properties Displays the information of the selected software.
2Upgrade Makes an enquiry on whether the selected software has an upgrade. If there is, starts downloading the
data.
3 Delete Deletes the selected software.
68 Accessory (M8)
2Depending on the conditions, some options may be displayed in gray and not be available.
Prog backlight (M72)
You can set the backlight mode of your phone.
☛ 7 2 ➔ 1 to set your phone to follow the normal backlight setting, or press 2 to let the backlight be controlled by the Java™ application.
2If you set your phone to follow the normal backlight setting, the current power save settings will be active (see “Power saving (M15)” on page 23).
2When the software is not running, the backlight operation depends on your phone’s backlight settings.
Accessory (M8)
Music player (M81)
This feature allows you to create a Playlist to play music files in the order you desire. You can add AAC files saved in your phone to the Playlist (see
“Videos (M61)” on page 61) or change the order of the AAC files within the Playlist.
☛ 8 1 ➔ SK1 to play ➔ After playing, SK2 to stop.
☛To change the volume, Side keys.
☛To play the previous file, ▲
☛To play the next file, or ▼
☛To play from the beginning of the music being played,
2When there are no AAC files saved in the Playlist, the Playlist screen will be displayed in stead of the Music player screen.
2When you use a headset, you can start or stop playing by pressing the button on it, and play the next file by pressing and holding it.
4 Network connection Permits/prohibits the selected software to connect to the network or displays the confirmation message
every time you start the selected software.
5 Auto start setting Enables or disables the automatic start of a complying Java™ application.
No. Application menu
▼
▼
69
Accessory (M8)
Music player Options menu
☛ 8 1
2Depending on the conditions, some options may be displayed in gray and not be available.
MP3 player (M82)
This feature allows you to create a Playlist to play MP3 files in the order you desire. You can add MP3 files saved in your phone to the Playlist (see “MP3
(M64)” on page 64) or change the order of the MP3 files within the Playlist.
☛ 8 2 ➔ SK1 to play ➔ After playing, SK2 to stop.
☛To change the volume, Side keys.
☛To play the previous file, ▲
☛To play the next file, or ▼
☛To play from the beginning of the music being played,
2When there are no MP3 files saved in the Playlist, the Playlist screen will be displayed in stead of the MP3 player screen.
No. Music player Options menu
1 Playlist Displays a list of AAC files in the order in which they are played.
2You can save up to 30 AAC files in the Playlist depending on the size of each file.
2The AAC files that are deleted from Video of My data or erroneous AAC files are displayed in gray and cannot be
played.
☛ to display the Playlist Options menu below, or SK1 to add an AAC file.
1Add item Adds an AAC file in your phone to the Playlist.
2Move item Moves the highlighted AAC file in the Playlist.
3 Delete item Deletes the highlighted AAC file from the Playlist.
4 Delete all Deletes all the AAC files from the Playlist.
5View detail Displays the properties (folder title and status) of the highlighted AAC file.
2 Play mode Normal: Plays all the AAC files in order from top to bottom of the Playlist once.
Repeat all: Plays all the AAC files in the Playlist repeatedly.
Repeat one: Plays the selected AAC file repeatedly.
3 Add desktop
icon
Creates a desktop icon of the Music player function on the standby screen.
4Notify
message
Selects whether or not to stop playing AAC files and notify you of the receipt of a new message.
▼
▼
70 Accessory (M8)
2When you use a headset, you can start or stop playing by pressing the button on it, and play the next file by pressing and holding it.
MP3 player Options menu
☛ 8 2
2Depending on the conditions, some options may be displayed in gray and not be available.
Calculator (M83)
You can perform addition, subtraction, multiplication and division with the calculator. It also has a memory function.
☛ 8 3
2The calculator can display a result of up to 9 digits. If a calculation results in a number exceeding the maximum, the screen displays error in the
calculation field.
No. MP3 player Options menu
1 Playlist Displays a list of MP3 files in the order in which they are played.
2You can save up to 30 MP3 files in the Playlist depending on the size of each file.
2The MP3 files that are deleted from MP3 of My data or erroneous MP3 files are displayed in gray and cannot
be played.
☛ to display the Playlist Options menu below, or SK1 to add an MP3 file.
1Add item Adds an MP3 file in your phone to the Playlist.
2 Move item Moves the highlighted MP3 file in the Playlist.
3 Delete item Deletes the highlighted MP3 file from the Playlist.
4 Delete all Deletes all the MP3 files from the Playlist.
5 View detail Displays the properties (file name, title, artist name and recording time) of the highlighted
MP3 file.
2 Play mode Normal: Plays all the MP3 files in order from top to bottom of the Playlist once.
Repeat all: Plays all the MP3 files in the Playlist repeatedly.
Repeat one: Plays the selected MP3 file repeatedly.
3 Equalizer Selects from Rock, Jazz, Pop and Off to obtain the desired tone.
2The selected Equalizer setting applies to all the MP3 files in the Playlist.
4 Add desktop icon Creates a desktop icon of the MP3 player function on the standby screen.
71
Accessory (M8)
Calculator Key Assignment
For calculator function, the keys are assigned different functions. The following shows the key assignment:
2Using the % function, you can calculate (100 + x) % of a figure (e.g. 200 + 5% = 210) and (100 - x) % of a figure (e.g. 200 - 5% = 190).
Clock alarm (M84)
This feature enables you to switch the clock alarm function on/off and to set the time, repetition and alarm tone.
Turning the alarm on/off
☛ 8 4
☛When all settings are done, SK1 to save the setting.
2The selected melody will be played when the alarm occurs if the ringer is turned on based on the current phone mode. If vibration is turned on, you
will be notified of the alarm by vibration.
2Even if the phone has been switched off, the phone automatically switches itself on and sounds the alarm or vibrates at the specified time.
2You can stop the alarm tone or vibration by pressing any key.
Key Operation Key Operation
Addition (+) Subtraction (–)
▲Multiplication (×)▼Division (÷)
Equals to (=) SK2 Memory Store/Memory Addition
SK1 Memory Recall/Memory Cancel (Press twice) Percent (%)
Inversion (±) Exit calculator
Decimal Point (.) CLR Delete digit (if held, all clear)
Clock alarm setting
On/Off Turns on or off the alarm.
Set time Sets the time and am/pm (for 12 hour format) at which the alarm will sound.
Set alarm tone Sets the melody to be played when the alarm occurs (see “Sounds (M62)” on page 61).
Alarm repeat Selects alarm repeat for once, daily or day of the week.
2You can select more than one day of the week at the same time.
2You can remove the check by highlighting and pressing again.
Enter alarm text Sets the message (e.g. Wake up!) which is displayed when the alarm occurs (optional).
▼
▼
72 Accessory (M8)
Scheduler (M85)
Scheduler enables you to enter reminders and appointments for particular time and date.
Adding a new event
☛ 8 5 ➔ Highlight the day ➔ to display the day’s schedule list screen (if any) ➔ SK1
☛When all settings are done, SK1 to save the setting.
2The selected melody will be played when the scheduled event occurs if the ringer is turned on based on the current phone mode. If vibration is turned
on, you will be notified of the event by vibration.
2If the phone has been switched off, the phone does not switch itself on to sound the reminder or vibrate at the specified time.
2You can stop the reminder tone or vibration by pressing any key.
2If the event is a private event, the reminder will sound at the specified time but the entered description will not be displayed. You are prompted to
enter the security code to view the details of the private event.
Viewing the scheduled events
☛ 8 5 ➔ Highlight a day (SK1 to display the previous monthly/weekly view screen or SK2 to display the next monthly/weekly view screen)
☛ to display the day’s schedule list screen (To display the previous/next day’s schedule list screen, or ).
☛ to display the detail screen of the highlighted schedule.
Setting the reminder again
☛When the scheduler reminder is set off, or and SK2 to select the time to remind again.
Scheduler setting
Event date/time Sets the day, month, year, time and am/pm (for 12 hour format) of the event.
Event end date/time Sets the day, month, year, time and am/pm (for 12 hour format) of the end of event.
Description Sets the event description (optional).
Repeat Selects repeat for One time only, Daily, Weekly or Monthly.
Reminder Turns on or off the reminder.
Reminder time Selects the time to set off the reminder prior to the event start time.
Reminder tone Associates a reminder tone with an event.
2You can set the reminder tone only when the Reminder is turned on.
Private Sets the event as a private event.
☛Place a check mark to set the event as a private event. To set the event as a public event, do
not place a check mark.
▼
▼
▼
▼
73
Accessory (M8)
Scheduler Options menu
☛ 8 5 ➔ Highlight the day ➔ to display the day’s schedule list screen (if any) ➔ Highlight the required scheduled event ➔
2Depending on the conditions, some options may be displayed in gray and not be available.
ToDo list (M86)
This feature allows you to set up to 100 ToDo tasks that should be finished by a certain date. You can choose to display either all ToDo tasks, or those
just finished or unfinished. Each task is identified by a description (of up to 256 characters) and its start/due date.
Adding a new ToDo task
☛ 8 6 ➔ Highlight the list ➔ ➔ SK1
No. Scheduler Options menu
1 Add new Adds a new entry.
2Edit Edits the highlighted event.
3Copy Copies the highlighted event.
4 Delete Deletes event(s). Press the appropriate keys for the event category (the currently selected event, all the public/
private events on the day, all the past public/private events, all the public/private events or all the events) to
delete.
5 Go to date Displays the selected date.
6 Monthly calendar/
Weekly calendar
Switches the weekly view screen to the monthly view screen, or the monthly view screen to the weekly view
screen.
2You can select Sunday or Monday to start the week from “Set start day” on page 21.
7 View summary Displays a summary of all the events.
8 View events Displays the events. Press the appropriate keys for the event category (Public only, Private only or All) to display.
2You are required to key in the security code to display the private events or all events.
9 Send via Bluetooth Sends the selected schedule via Bluetooth to other devices or a cellphone.
ToDo list setting
Start date Sets the day, month and year to start the ToDo task.
Due date Sets the date to end the ToDo task. Key in the date or press the appropriate key for the date.
2If you select to key in the date yourself, input the day, month and year of the date to end the ToDo task, then SK1.
Description Sets the ToDo task description (e.g. Pay the rent).
Category Sets the category (Business, Personal or Other).
74 Accessory (M8)
☛When all settings are done, SK1 to save the setting.
When a ToDo task is completed
☛ 8 6 ➔ Highlight the list ➔ ➔ Highlight the required ToDo task ➔ ➔ 1 and 1, or SK2 to save the task as completed.
Viewing ToDo task details
☛ 8 6 ➔ Highlight the list ➔ ➔ Highlight the required ToDo task ➔ ➔ To view the details of the previous or next ToDo task in the list,
or
☛To edit the currently displayed task, SK1
ToDo Options menu
☛To display the ToDo Options menu, 8 6 ➔ Highlight the list ➔ ➔ Highlight the required ToDo task ➔
☛To display the ToDo detail Options menu, 8 6 ➔ Highlight the list ➔ ➔ Highlight the required ToDo task ➔ ➔
Column L shows the ToDo options menu, and column D shows the ToDo detail Options menu.
2Depending on the conditions, some options may be displayed in gray and not be available.
Priority Sets the priority (Normal, Low or High).
Private Sets the ToDo task as private.
L D ToDo Options menu
14 Add new Adds a ToDo task (see “Adding a new ToDo task” on page 73, from the second step).
–1Status Changes the completion status of the highlighted ToDo task.
22Edit Edits the highlighted ToDo task (see “Adding a new ToDo task” on page 73, from the second step).
3– Delete Deletes ToDo task(s). Press the appropriate keys for the ToDo task category (the currently selected ToDo
task, all the public/private ToDo tasks, all the completed public/private ToDo tasks or all the ToDo tasks) to
delete.
–3 Delete current Deletes the current ToDo task.
4– Display filter Sets the type(s) of ToDo tasks to be displayed by selecting the desired filter option (None, Incomplete or
Completed).
5–Sort list Displays a list of ToDo tasks rearranged according to the selected sort key (Due date, Category, Priority,
or Status).
6–View summary Displays the number of Incomplete and Completed tasks and how many more tasks can be created.
75 Send via Bluetooth Sends the selected ToDo task via Bluetooth to other devices or a cellphone.
ToDo list setting (Continued)
▼
▼
75
Accessory (M8)
Notepad (M87)
Notepad function allows you to record and store a note as a text file.
Creating a new memo (M871)
☛ 8 7 1 ➔ Key in text ➔ to save the entry as a text file. The first few words are displayed on the text list screen.
Displaying a memo (M872)
☛ 8 7 2 ➔ Highlight a file ➔ SK1 to preview, or to edit
Notepad Options menu
☛ 8 7 2 ➔ Highlight a file ➔
No. Notepad Options menu
1Edit item Sets the protection settings of the selected file on/off.
Rename item: Edits the user title or name of the selected folder or file.
Set protection: Sets the protection settings of the selected folder or file on/off.
2 Use item Add desktop icon: Creates a desktop icon of the selected file on the standby screen.
Send via Bluetooth: Sends the selected file via Bluetooth to other devices or a cellphone.
3 Create message Creates a new message with the highlighted text (note).
4 Delete item Deletes the selected file or folder if it is unprotected.
5 Delete all Deletes all the notes unprotected from the list.
6 Copy item Copies the selected note.
7Copy all Copies all the notes.
8Move Moves the selected note or all the notes in the current folder to a folder.
9 Create folder Creates a new folder under the current folder.
0 Storage detail Displays the current storage information of your phone memory.
View detail Displays the detail of the selected file.
2You can also display the details on the highlighted folder or file by pressing without displaying the
Options menu.
76 Accessory (M8)
2Depending on the conditions, some options may be displayed in gray and not be available.
Voice memo (M88)
Voice memo function allows you to record up to 60 seconds of sound/voice, using your phone’s microphone.
Recording/playing voice memo or setting speaker
☛ 8 8
/See also: “Sounds (M62)” on page 61.
Currency (M89)
Currency function allows you to convert an amount of money in one currency to another.
# Options Sorting order: Sorts the files by date or alphabetically.
Info column: Sets whether to display the column on the list screen, and the information to be
shown there.
None: No column showing
Size: Approximate size of the file
Type: File type
2You can also change the information on the column by pressing # without displaying the Options menu.
Flat view: Displays the list of all the stored files regardless of the folder hierarchy.
Save options: Saves the current option settings.
Reset options: Resets the option settings.
No. Voice memo setting
1Record Records a voice memo.
☛SK1 to start recording.
2You can finish recording and save the data as a file by pressing SK2 even before the recording is completed.
/To record the conversation during a call, see “Recording a call” on page 10.
2Play Plays a voice memo or recorded call.
☛Highlight a voice memo ➔ to start playing and SK2 to stop playing.
3 Speaker setting Selects between speaker and earpiece to play the voice memo.
☛1 for the Speaker, or 2 for the Earpiece.
No. Notepad Options menu (Continued)
77
Accessory (M8)
Converting currency
☛ 8 9
2If you have made a mistake in entering the exchange rate or amount, CLR to delete individual number or SK2 to cancel the entry and return to
the previous screen, and then start again.
Resetting the currencies
☛ 8 9 and SK1
Bluetooth (M80)
Bluetooth function allows you to use your phone as a modem and to talk by using a Bluetooth headset.
☛ 8 0
/For details, see “Bluetooth (M80)” on page 78.
Synchronization (M8*)
Synchronization function allows you to synchronize the data (phonebook, scheduler, ToDo list data) with PC application via the USB cable.
This function can update such data between your phone and PC.
2Data should comply with vCard 2.1/vCalendar 1.0 specification.
2You cannot synchronize the phonebook data stored in the SIM card.
☛Connect your phone with your PC via a USB cable ➔ Activate the software on PC side and prepare for synchronization (for details, refer to the
manuals of the software)
☛ 8 ➔ Select the data type (Phonebook, Scheduler or ToDo list) ➔ SK1 or 1 to start synchronization
Currency setting
From Sets the source currency code.
To Sets the destination currency code.
Exchange rate Sets the exchange rate.
☛If you wish to change the exchange rate, CLR to delete the displayed exchange rate and key in the required number
(for decimal point, SK1) ➔
Amount Sets the amount of money you wish to convert (for decimal point, SK1).
78 Bluetooth (M80)
Bluetooth (M80)
Bluetooth function allows you to communicate with the external devices (PC, PDA, headset, hands-free kit, etc.).
This function provides the following service:
•Dial-up service - You can use your phone as a modem.
•Headset/hands-free service - You can make/receive a call using a Bluetooth headset or hands-free kit.
•Data transfer - You can exchange the data (from Phonebook/Scheduler/ToDo lost/Notepad/My data(Videos/Sounds/Pictures/MP3)) between your
phone and other Bluetooth devices.
•FTP server - You can use your phone as a server while other Bluetooth devices function as a client. This enables the user to browse your phone
from other Bluetooth devices.
2The list of the Bluetooth accessories recommended for N500i is available on NEC France’s website: http://www.nec.fr
2When using Bluetooth devices, always refer to their operation manual.
2Depending on the connection status, a Bluetooth device may not function correctly. In such a case, retry operation from the device side, or switch
your phone off and on.
2There may be Bluetooth devices that cannot be connected to your phone.
Bluetooth setting
☛ 8 0 1
No. Bluetooth setting
1 Bluetooth On/
Bluetooth Off
Activates or deactivates Bluetooth function.
2If you switch the phone off while Bluetooth On is set, the next time you switch on, the phone will be in
Bluetooth On status again.
2 Pair new device Registers the external Bluetooth devices.
1 Search device Searches for the nearby active Bluetooth devices.
2 Wait for connect Standby your phone to wait for other devices to search for it.
2Other Bluetooth devices can only detect your phone while your phone is displaying
Wait for connect screen.
3 Device list Displays and edits the list of paired devices.
4 My phone Displays the terminal information of your phone.
☛ to display the Options menu
Rename: Edits the terminal name of your phone.
2You cannot edit the information during Bluetooth communication.
79
Bluetooth (M80)
2Depending on the conditions, some options may be displayed in gray and not be available.
Device list Option menu
☛ 8 0 1 ➔ 3
Device list icons
The following icons will be displayed in the device list screen.
Pairing a Bluetooth device and your phone
☛ 8 0 1 ➔ 2 ➔ 1 to be searched by other Bluetooth devices or 2 to search other Bluetooth devices
☛If the device is found, the list of found Bluetooth devices will be displayed
☛Highlight the device from the list➔ ➔ Input passcode on each device
2When pairing, enter a passcode specified by the Bluetooth device to your phone and the device. If no passcode is specified by the device, enter
the same arbitrary number to your phone and the device. A passcode is a number from 4 to 16 digits.
5 Active device Displays the information on the device in connection.
6 Disconnect Ends the Bluetooth connection in progress.
No. Device list Option menu
1Rename Edits the name of the highlighted device.
2 Protect/Unprotect Protects or unprotects the highlighted device.
3 Delete device Deletes the highlighted device.
4 Delete all devices Deletes all the devices listed.
5 View detail Displays detailed information on the highlighted device.
Indicates the device is not registered. Indicates the device is an audio (a headset
or handsfree device).
Indicates the device is a PC.
Indicates the device is a phone Indicates the device is other than an audio,
PC, or phone.
Indicates the device is protected.
TBD Indicates the device is connected with
your phone.
No. Bluetooth setting
80 Bluetooth (M80)
Using Bluetooth for voice/modem
2To use the Bluetooth headset/hands-free kit or Bluetooth modem, you must perform the Bluetooth pairing with your external device beforehand. For
details, refer to the operation manual of the device.
,While using the Bluetooth device, the following icons will be displayed in the status bar area of your phone.
Connecting Bluetooth headset/hands-free kit
2When connecting a wired headset and Bluetooth headset at the same time, the wired headset will not work.
2For some Bluetooth devices, the voice recall function may be activated when a paired headset/hands-free kit is turned on (see “Voice recall” on
page 8).
☛Pair the Bluetooth device and your phone beforehand. See “Pairing a Bluetooth device and your phone” on page 79 for details.
☛ 8 0 1 ➔ 1 to toggle to Bluetooth On to activate Bluetooth ➔ 3 ➔ Highlight the headset/hands-free kit in the list ➔ SK1 or
☛Press the button on the headset/hands-free kit
☛To switch the headset/hands-free kit call to your handset call, 9
2You cannot deactivate Bluetooth during a call.
☛To end the call, press or end from the headset/hands-free kit
Using your phone as Bluetooth modem
2For details of dial-up connection settings, consult your Internet service provider.
☛Pair the Bluetooth device and your phone beforehand. See “Pairing a Bluetooth device and your phone” on page 79 for details.
☛ 8 0 1 ➔ 1 to toggle to Bluetooth On to activate Bluetooth ➔ Perform dial-up connection by your PC
☛Activate Bluetooth function ➔ Perform dial-up connection by your PC.
☛To end the dial-up connection, disconnect from the PC application
Bluetooth data exchange
2The maximum size for exchanging data is 1 MB. If the data you are sending is larger than that, a message will be displayed indicating the error has
occurred.
2You can only transfer one item per exchange.
Sending data
You can send the data from Phonebook/Scheduler/ToDo lost/Notepad/My data(Videos/Sounds/Pictures/MP3) between other Bluetooth devices.
Indicates that Bluetooth is set to on. Indicates that Bluetooth is in operation.
81
Bluetooth (M80)
Phonebook entry (M413...)
2You can only send Name, Home, Mobile, Work, Fax, 2 Email addresses and 2 pieces of descriptive information.
2Your phone sends data according to the vCard 2.1 specification.
☛To display the phonebook (Phone), (for required number of times) or 4 1 3 ➔ Highlight a phonebook entry.
☛ 0 or 3 ➔ The phonebook entry will be sent through the IR port.
Video/Sound/Picture/MP3 (M6...)
☛ 6 1 for Videos, 6 2 for Sounds, 6 3 for Pictures or 6 4 for MP3 ➔ Highlight a folder ➔ ➔ Highlight a file.
☛ 2 3 for Videos/Pictures, 2 4 for Sounds or 2 1 for MP3 ➔ The file will be sent through the IR port (see “My data (M6)” on
page 60 for details).
Schedule entry (M85...)
☛ 8 5 ➔ Highlight a date ➔ ➔ Highlight a schedule entry ➔ ➔ 9 ➔ The schedule entry will be sent through the IR port.
ToDo entry (M86...)
☛ 8 6 ➔ Highlight Public, Private or All ➔ ➔ Highlight a ToDo entry ➔ 7 ➔ The ToDo entry will be sent through the IR port.
Note (M872...)
☛ 8 7 2 ➔ Highlight a note ➔ 2 and 2 ➔ The note entry will be sent through the IR port.
Receiving data
You can standby your phone to receive data for Phonebook/Scheduler/ToDo lost/Notepad/My data(Videos/Sounds/Pictures/MP3) between other
Bluetooth devices.
☛ 8 0 2 ➔ Start sending data from the other end.
2Once the transmission completes, your phone automatically judges the type of received data and stores the data accordingly.
2If your phone does not have enough space to store the received data, a message will be displayed indicating lack of space. In such a case, delete
unnecessary data and try the data exchange again.
FTP server
Using Bluetooth connection, you can browse your phone from other Bluetooth devices and transfer data.
This function provides the following services:
•See the file/folder list in your phone.
•Send/receive the file/folder to/from your phone.
•Delete the file/folder from your phone.
•Create a folder in your phone.
82 Bluetooth (M80)
☛ 8 0 2 ➔ the waiting data screen is displayed.
☛Browse your phone from other Bluetooth device.
2While using FTP server to receive the data from other Bluetooth devices, your phone can only accept the data for Notepad or My data (Videos,
Sounds, Pictures, MP3).
2The connection from other Bluetooth devices is accepted only when the waiting data screen is displayed.
2Depending on the security settings, the operations when the connection from other Bluetooth devices is accepted differs.
83
Index
Index
Numerics
2nd-LCD 23
3GPP 55
4 way navigation key vi
A
AC adapter 3
Accepting an incoming call 6
Access history 47
Accessory 68
ADN 48
Alarm volume 22
ALS 20
Animation 62
Any key answer 20
AoC 11
Auto answer 22
Auto redial 13
B
Bar calls 25
Basic calls & phone use 5
Battery charging 3
Battery level icons viii, 4
Battery pack 1
Bluetooth 78
Bookmark 47
C
Calculator 70
Call diversion 12
Call lists 11
Call options 10
Call transfer 9
Call waiting and holding 13
Camera 55
Recording a video 58
Taking a picture 56
Car mode 21
CB 33
Certificate information 47
CLI 5, 52
Clock 21
Clock alarm 71
Clock selection 23
Clock/Event display 23
Colour style 23
Contrast 23
Correcting mistakes 5
Currency 76
D
Date 21
Date format 21
Desktop icons 18
Dialled calls list 11
Download 34
E
Earphone setting 22
Earphone type 21
Emergency calls 7
Ending a call 6
F
Fast dialling 7
FDN 25, 48
Flicker control 57, 60
Fold answer 20
Frame 63
Frequency band 15
FTP server 81
Function key LED 24
G
General care i
Greetings 23
Groups 50
GSM viii, ix
H
Hands-free kit 78
Headset 21, 78
Highlight mode 32
Holding a call 9
Homepage 47
I
Icons viii, 79, 80
i-mode 33
Certificate information 47
i-mode menu screen 39
i-mode operations 33
i-mode screen 39
IP 47
Mail 47
MMS 47
Site (program) 47
Web page 47
i-mode menu screen 39
i-mode operations 33
i-mode screen 39
Inbox 27
Incoming call No. 23
International dialling codes 14
IP 47
J
Java™ 67
JPEG 55
K
Key allocations 17
Key tone 22
Keypad shortcuts vii
L
Language 21
Last call duration 11
Last number redial 7
LCD v
LED 21
Line ID 14
Low battery alarm 4
M
Mail 47
Mail screen 43
Mail server 39
Main menu xi
Main-LCD 23
Making basic calls 5
Meeting mode 21
84 Index
Menu functions xi
Menu shortcuts selection iv
Message 27
MFi 46
Missed calls list 11
MMS 47
MMS messages 27
MMS tone 22
MMS tone volume 22
MP3 player 69
Multi-party calls 9
Music player 68
Mute 9
My data 60
MP3 64
Pictures 62
Sounds 61
Videos 61
N
Network selection 14
Normal mode 21
Normal text (ABC) input 16
Notepad 75
Number type 53
Numeric input 17
O
One-touch dial 7
Option mode 30
Origin number 53
Own phone number display 8
P
Parts and functions vi
Phone lock 25
Phone modes 21
Phonebook 48
PIM 25
PIN activate 25
PIN code 5, 24
PIN2 code 24
Pocket mode 21
Power saving 23
Preparing the phone 1
PUK 24
R
Reading a message 28
Received calls list 11
Receiving an incoming call 6
Recording a call 10
Redial blacklist 11
Rejecting an incoming call 6
Reset settings 25
Ring silencer 20
Ringer 22
Ringer volume 22
Roaming 14
S
Saved pages 47
Scheduler 72
Scratchpad number 10
SDN 48
Security 24
Security code 24
Service tone 22
Settings 20
Shortcuts selection xi
Side key lock 20
SIM card 1
SIM card insertion 1
SIM card removal 2
Site (program) 47
SMS messages 27
SMS tone 22
SMS tone volume 22
Stamp 62
Standby and talk times 4
Standby screen v
Starting a call 5
Start-up 4
STD 5
Streaming Proxy 39
Switching the phone off 5
Switching the phone on 4
Synchronization 77
T
T9 English text input 15
Text entry 15
Mode change 15
Time 21
Time format 21
Timezone 21
ToDo list 73
Total calls duration 11
U
Unsuccessful calls 7
User’s manual conventions iv
V
Vibrator 22
Video 55
Recording a video 58
View mode 31
Voice mail 54
Voice memo 76
Voice recall 8
Voice volume 20
W
Wallpaper 23
Web page 47
Z
Zoom 57, 60
1_00505
