LOBTC User Manual HTML Version

Users Guide

Cordless Terminal Users Guide

DTL-12BT-1(BK) TEL

ITL-12BT-1(BK) TEL

BCH-L(BK) UNIT

- Before using your product, read this Users Guide thoroughly to ensure

correct handling.

- After reading the Users Guide, keep it in a place that is accessible for

read reference.

LIABILITY DISCLAIMER

NEC Infrontia Corporation reserves the right to change the specifications, functions, or fea-

tures, at any time, without notice.

NEC Infrontia Corporation has prepared this document for use by its employees and custom-

ers. The information contained herein is the property of NEC Infrontia Corporation and shall

not be reproduced without prior written approval from NEC Infrontia Corporation. All brand

names and product names on this document are trademarks or registered trademarks of their

respective companies.

NEC Infrontia Corporation

Warning

◆Do not use the unit when you notice smoke, strange smell or other unusual happenings. It

may cause fire if you continuously use them. Turn off the power switch of the phone sys-

tem immediately. For the recharger, disconnect the power plug immediately. Confirm that

smoke is ceased, and then contact the nearest NEC service office.

Never attempt to repair those units by yourself.

◆If you had an accident such as dropping the phone and broke the unit, turn off the power of

the phone system immediately. For the recharger, disconnect the power plug immediately.

Contact the nearest NEC service office.

If you keep using those units, they may cause fire or electrical shock.

◆If water smeared into the unit, turn off the power of the phone system immediately. For the

recharger, disconnect the power plug immediately. Contact with the nearest NEC service

office. If you keep using those units, they may cause fire or electrical shock.

◆Do not insert flammable or metal objects into the units. If a foreign object were acciden-

tally placed into the units, turn off the power of the phone system and plug out the power

adapter. Contact the nearest NEC service office. If you keep using those units, they may

cause fire or electrical shock. Pay special attention to children to prevent from similar

accidents.

◆Do not attempt to disassemble nor modify the units. It may cause fire, electrical shock, or

system malfunciton.

Modification by a user is prohibited by law.

◆Do not open the units intentionally. It may cause electrical shock or system malfunction.

Ask test adjustment, and repair of the units for the nearest NEC service office.

◆Do not twist, put a heavy object, and push the phone system. Such actions may cause dam-

age, fire, or injuries.

◆Do not place a container with water such as a vase, a plant pot, a cup, cosmetics, chemi-

cals, nor a small metal object. Splashing water over the units and foreign metal object

inserted into the units may cause fire or electrical shock.

◆Do not use the unit in a high humid area such as a bathroom or near a humidifier. They

may cause fire, electrical shock, or system malfunction.

◆Use the specified power adapter, which is attached to the unit. Other adapters may cause

fire or system malfunction.

◆Do not damage, or modify the power adapter cord. Do not kink, pull, twist, or bundle it.

Do not put a heavy object or heat it. They may cause fire, electrical shock, or system mal-

function. Contact the nearest NEC service office for a damaged adapter cord.

◆Do not touch the power plug with a wet hand. It may cause electrical shock or system mal-

function.

◆Do not touch the units or replace a battery with a wet hand. It may cause electrical shock

or system malfunction.

◆When you hear thunder during using the phone system outside, immediately stop using it

and move to a safe place.

◆Do not use multiple plugs to a single outlet. It may cause fire or electrical shock.

◆Follow the instruction below when you use a battery pack. They may cause heating, explo-

sion, and fire;

・Do not put the battery pack into a microwave oven or a pressure chamber.

・Do not use other batteries with this battery pack.

◆If the internal battery liquid clung to your skin or clothes, immediately rinse it with clean

water to prevent chemical damage to your skin and clothes.

◆Do not use the phone or recharge the battery in a place where fire or explosion may occur.

・This phone system does not have explosion protection. Do not use it where a flamma-

ble gas such as propane and gasoline are stored. Turn off the power of the phone imme-

diately. Do not recharge the battery in such a place.

◆Do not use near microwave ovens, medical equipment and industrial equipment.

iii

User Safety Protocol

Important:Read this information before using your DTL-12BT-1(BK) TEL, ITL-12BT-

1(BK) TEL and BCH-L(BK) UNIT Handset.

Observe the following instructions to use this product safely, prevent you and other people

from possible injury, and protect properties. Improper handling may cause heat, explosion,

and fire.

Danger

◆Recharge the battery with the matching battery charger (see battery label description).

◆Use the battery only for this DTL-12BT-1(BK) TEL, ITL-12BT-1(BK) TEL and BCH-

L(BK) UNIT handset system. Do not use it with other electrical devices.

◆Keep the following warnings to prevent the battery pack from heating, explosion, and fire.

・Do not throw the battery pack into fire.

・Do not solder the battery pack directly.

・Do not short the positive (+) and negative (-) terminal of the battery pack with metal.

・Do not poke the battery nor smash it with hammer.

◆Do not disassemble nor modify the battery pack. It has a safety circuit and a damaged cir-

cuit may cause heat, explosion, and fire.

◆The internal liquid of the battery pack has strong acid. If the battery liquid gets into your

eye, rinse your eye well with water and consult with a doctor.

◆Do not use, leave, nor recharge the battery pack near fire or under the direct sunlight. High

temperature may damage the internal safety circuit and may cause malfunction of the

recharge, heat, explosion, or fire.

FCC portion

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

・Reorient or relocate the receiving antenna.

・Increase the separation between the equipment and receiver.

・Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

・Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) This device must

accept any interference received, including interference that may cause undesired operation.

Caution:

Any changes or modifications not expressly approved by the party responsible for product

compliance could void the user’s authority to operate the equipment.

To comply with FCC RF exposure compliance requirements, this device must not be co-

located or operating in conjunction with any other antenna or transmitter.

LO(BTC)B / LO(BTC)U

To comply with FCC RF exposure compliance requirements, a separation distance of at least

20 cm must be maintained between the antenna of this device and all persons. This device

must not be co-located or operating in conjunction with any other antenna or transmitter.

LO(BTH)B / LO(BTH)U

To comply with FCC RF exposure compliance requirements, this device must not be

colocated or operating in conjunction with any other antenna or transmitter.

LO(BTH)B or LO(BTH)U was tested with BELTCLIP(BTH)(BK).Use only

this beltclip to ensure FCC Compliance. The use of third-party beltclips may not comply with

FCC RF exposure compliance requirements, and should be avoided.

RF Exposure Guidelines

Industry Canada Portion

Canada Regulatory Compliance Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numériqué de la classe B est conformé à la norme NMB-003 du Canada.

For Customers in Canada

This device complies with RSS 210 of Industry Canada (IC).

Operation is subject to the following two conditions:

・this device may not cause interference, and

・this device must accept any interference, including interference that may cause undes-

ired operation of this device.

L’utilisation de ce dispositif est autorisée seulement aux conditions suivantes:

・il ne doit pas produire de brouillage et

・I'utilisateur du dispositif doit étre prêt a accepter tout brouillage radioélectrique reçu,

même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.

Exposure to radio frequency radiation

The installer of this radio equipment must ensure that the antenna is located or pointed such

that it does not emit RF field in excess of Health Canada limits for the general population;

consult Safety Code 6, obtainable from Health Canada’s website at www.hc-sc.gc.ca/rpb.

Introduction

Thank you very much for purchasing our cordless terminal.

< Devices covered >

・DtermX Cordless Terminal DTL-12BT-1(BK) TEL

・IPtermX Cordless Terminal ITL-12BT-1(BK) TEL

・Bluetooth® Handset Cradle BCH-L(BK) UNIT

A cordless terminal is a multifunctional telephone with a portable handset that lets you origi-

nate calls and answer terminating calls from within a certain talking range.

A standard multifunctional telephone may have its handset replaced with a BCH-L UNIT to

transform into a cordless terminal.

Each cordless terminal consists of the following devices:

・Bluetooth® Cradle : A multifunctional telephone unit to which a BTC is connected.

・Bluetooth® Handset : BTH

Instructions in this User’s Guide focus on Bluetooth® handset operations. For instructions

about handling the Bluetooth® cradle, refer to the user documentation that comes with your

system.

How This Guide Is Organized

Before Using the

Product

Provides tips and hints on using the product safely and properly,

and topics of prerequisite importance to using the cordless termi-

nal.

Bluetooth® Handset

Operations

Explains operating tips and the handset functions of the cordless

terminal.

Troubleshooting Explains how to deal with troubles that may occur while you use

the cordless terminal and interpret the error messages that may be

displayed in the Bluetooth® handset LCD.

vii

Table of Contents

Introduction ..................................................................................... vi

How This Guide Is Organized .............................................................................. vi

Table of Contents ........................................................................... vii

Before Using the Product ............................................... 1-1

About Cordless Terminals ............................................................ 1-2

Bluetooth® Cradle and Bluetooth® Handset ..................................................... 1-2

Key Functions ................................................................................................... 1-2

Talking Range ................................................................................................... 1-4

Charging ........................................................................................................... 1-5

Replacing the Battery ....................................................................................... 1-6

In the Event of a Power Failure ........................................................................ 1-7

If Security Features Are Used ........................................................................... 1-7

Primary Specifications ...................................................................................... 1-8

Safety Precautions ..................................................................... 1-10

Operating Instructions and Maintenance ................................... 1-14

Locating the Bluetooth® Cradle ...................................................................... 1-14

Antenna .......................................................................................................... 1-15

Radio Transmission ........................................................................................ 1-15

Radio Interference .......................................................................................... 1-16

Maintenance ................................................................................................... 1-16

Charging Terminals ........................................................................................ 1-17

Operation Following Power Feeding to the Bluetooth® Cradle ....................... 1-17

Component Names and Functions ............................................ 1-18

Bluetooth® Cradle (BTC) ................................................................................ 1-18

Bluetooth® Handset (BTH) ............................................................................. 1-19

Bluetooth® Handset LCD Screen ............................................... 1-20

Displayed Information ..................................................................................... 1-20

Explanations of Icons ...................................................................................... 1-22

Table of Contents

viii

Table of Contents

Adjusting the Bluetooth® Handset .............................................. 1-24

Configuring the Cordless Terminal ............................................ 1-25

Configuring the Bluetooth® Cradle (BTC) ....................................................... 1-25

Configuring the Bluetooth® Handset (BTH) .................................................... 1-27

Transforming the Standard Handset into a BCH-L(BK) UNIT .... 1-29

Wall-Mounting the Bluetooth® Cradle ........................................ 1-35

Connecting a Headset ............................................................... 1-38

Pairing with a Bluetooth® Headset ................................................................. 1-38

Connecting a Wire Headset ............................................................................ 1-40

Bluetooth® Handset Operations ..................................... 2-1

Caution ......................................................................................... 2-2

Bluetooth® Handset Functions ..................................................... 2-3

Key Lock ........................................................................................................... 2-3

Troubleshooting ............................................................. 3-1

Troubleshooting Tips ................................................................... 3-2

1 - 1

Before Using the Product

About Cordless Terminals ............................................... 1-2

Safety Precautions ......................................................... 1-10

Operating Instructions and Maintenance ....................... 1-14

Component Names and Functions ................................. 1-18

Bluetooth® Handset LCD Screen .................................. 1-20

Adjusting the Bluetooth® Handset ................................ 1-24

Configuring the Cordless Terminal ............................... 1-25

Transforming the Standard Handset into

a BCH-L(BK) UNIT ................................................ 1-29

Wall-Mounting the Bluetooth® Cradle ......................... 1-35

Connecting a Headset .................................................... 1-38

1 - 2

About Cordless Terminals

A cordless terminal is a multifunctional telephone that interconnects its Bluetooth® cradle

and Bluetooth® handset with each other using Bluetooth® wireless technology to maintain

calls or perform other operations between them.

・The Bluetooth® cradle of a cordless terminal can be handled the same way as a telephone.

Its Bluetooth® handset can be handled likewise, except for some of its features. If a partic-

ular feature of a Bluetooth® cordless terminal does not work, use the Bluetooth® cradle to

enable it.

・If the Bluetooth® handset of a cordless terminal is out of service, return it to the Blue-

tooth® cradle to keep it charged at all times.

・Ere multiple cordless terminals are set up, be careful to retain the pairing between the

Bluetooth® cradle and Bluetooth® handset.

The table below summarizes the key functions of a cordless terminal. For information about

the functions of the multifunctional telephone itself, refer to the user documentation that

comes with your system.

About Cordless Terminals

Bluetooth® Cradle and Bluetooth® Handset

Key Functions

The ways you originate calls from the Bluetooth® headset and answer terminat-

ing calls may vary depending on the type of device you use.

Function Description

Blue-

tooth®

Cradle

(BTC)

Bluetooth® headset

call You can register a Bluetooth® headset with the Bluetooth®

cradle and use it.

• Originating calls to an extension or central office line

Press the headset call (call control) key twice briefly and

perform a dialing operation from the telephone.

• Answering terminating calls

Press the headset call (call control) key while a call ter-

minates with a ring tone.

Caution

1 - 3

About Cordless Terminals

Function Description

Blue-

tooth®

Cradle

(BTC)

Bluetooth® headset

call * For latest recommended product information, browse

the following Web site:

http://www.necinfrontia.co.jp/

* Try to use a headset of the recommended type to ensure

that it connects to the cradle successfully and with the

correctly matched sound volume.

* The Bluetooth® handset cannot be used while you are

talking with the Bluetooth® headset on. You cannot

switch to the Bluetooth® headset to use while you are

using the Bluetooth® handset, either.

* The headset call control key allows you to only origi-

nate calls from the headset and answer terminating

calls.

Any other headset-specific functions are not supported.

Blue-

tooth®

Handset

(BTH)

LCD display A 20-position-by-2-line LCD screen displays the date,

time, phone number and more.

Icons, such as those designating the status of radio and the

remaining battery voltage, appear on the first line.

* LCD displays may not be produced depending on your

system.

Line keys Allow the functions preprogrammed on line keys 1 to 8 in

the Bluetooth® cradle to be used.

* For the functions that are available with the Bluetooth®

handset, refer to the user documentation that comes

with your system.

Incoming call/

charging lamp Lights or blinks en calls terminate or the handset is

charged.

Key touch tone Provides an audible verification of each click on a dial key.

Tone type En calls terminate, a ring tone sounds from the speaker in

the cordless terminal. The ring tone sounds in different

ways depending on the status of the Bluetooth® handset:

• Charging (handset returned to the cradle)

Sounding from the speaker in the cradle only

• Standby (handset removed from the cradle)

Sounding from both the cradle and handset speakers

Volume/density

control Allows you to use the cursor keys and to adjust the

receiver and ring tone volumes and the LCD contrast.

1 - 4

About Cordless Terminals

The Bluetooth® cradle and Bluetooth® handset can be separated from each other about 50m at

the remotest as a line-of-sight distance. This talking range, however, may shorten depending

on the office environment in which the cradle and handset are used; for example, they are

used near a metal or concrete wall.

If the handset gets too remote from the Bluetooth® cradle, the antenna mark will disappear

accompanied by an alarm tone.

Blue-

tooth®

Handset

(BTH)

Telephone func-

tion Allows you to originate calls to an extension or central

office line, answer terminating calls and more, all in Blue-

tooth® handset operations.

Hold/Transfer Places calls on hold and forward them to another tele-

phone.

Histories of origi-

nating and termi-

nating calls

Displays up to 10 originating and up to 10 terminating

calls (up to 20 calls in total), including the latest calls.

* This function may be inoperable or the number of calls

that can be displayed may vary depending on your sys-

tem.

Talking Range

• You may have difficulty originating a call by dialing from the Bluetooth® hand-

set. In this case, wait for a while and retry the dialing operation.

• Consult your dealer if you wish to use a cordless terminal together with an

office cordless telephone in the same environment.

Function Description

About 50m in

radius as a

line-of-sight distance

No antenna mark

appearing in

the LCD screen

Alarm Tone

About 2m

Bluetooth headset

Bluetooth

Handset

Bluetooth

Cradle

Caution

1 - 5

About Cordless Terminals

Before you use the Bluetooth® handset for the first time or reuse the handset after it has been

left out of service for a long time, charge it for at least 5 hours. (Full charging takes about 16

hours to complete.) A fully charged handset will allow you to talk for about 8 hours continu-

ously and stand by for about 30 hours if low-power mode is enabled or for about 24 hours if

low-power mode is disabled.

The remaining battery voltage icon appearing in the LCD screen, coupled by the incoming

call/charging lamp and an alarm tone, alerts you to the remaining battery voltage of the Blue-

tooth® handset. The table below describes how these indications appear depending on the

remaining battery voltage of the handset.

Charging

Remaining

battery

voltage

State indications

Remarks

Icon Incoming call/charging

lamp Alarm

Tone

High - -

Medium - -

Low - ×

Charging

required Blinking red ×The handset can be

used as long as the

beep sounds.

Charging in

progress - Fully charged: Lit green

Charging : Lit red -

Charging

error - Blinking orange -

1 - 6

About Cordless Terminals

The battery loaded in the Bluetooth® handset has a useful life of about 2 years, though it is a

parameter of on how the handset has been used. If the battery voltage diminishes quickly

after the battery has been charged for a long time, replace with a new battery (Li-ion BAT-

TERY - option). For more details, ask your dealer.

Replacing the Battery

This product is powered by a lithium-ion battery.

Lithium-ion battery : 3.7V 1100mAh

The lithium-ion battery is a recyclable resource.

In recycling batteries that have been replaced or that have been unloaded from a used prod-

uct, take notice of this precaution to avoid smoking and firing:

• Bring batteries to our repair counter with the contacts being taped to prevent shorts or

enclosed individually in plastic bags.

<Our repair counter> For more details, visit the NEC Infrontia Environment Website.

URL http://www.necinfrontia.co.jp/company/kankyo/index.htm

Do not disassemble, tamper or damage the battery pack.

Please send your queries to:

• Dealer from whom your product or lithium-ion battery was purchased

• Our repair counter

Unload

the battery

Remove the cover

1 - 7

About Cordless Terminals

Your cordless terminal will behave in the following manners:

・The charging function is shut down to keep the system battery from draining depending on

your system.

・The cordless terminal may be disabled depending on the system battery voltage.

・The cordless terminal is disabled if the system battery is exhausted.

・Calls in progress will be cleared if the system battery is exhausted in the meantime.

・If an optional AC adapter (AC-2RD UNIT) is used, the cordless terminal cannot be

charged while the power failure persists.

< On an IP multifunctional telephone only >

If security features are programmed on the system or on an IP multifunctional telephone, a

security mode icon appears in the LCD screen of the Bluetooth® handset (BTH), with the fol-

lowing functions being locked:

・Logging of originating/terminating calls

・Setup menu

The security features can be canceled from the system or the Bluetooth® cradle only. Calls

and other performance may be restricted depending on the security features. For more details,

refer to the user documentation that comes with your system.

In the Event of a Power Failure

If Security Features Are Used

1 - 8

About Cordless Terminals

Primary Specifications

Item Dimension Remarks

Bluetooth® version Bluetooth® version 2.0

Radio interface Bluetooth® Class1

Installed profiles Bluetooth® Handset (BTH)

・GAP : Generic Access Profile

・SPP : Serial Port Profile

・HSP : Headset Profile

Bluetooth® Cradle (BTC)

・GAP : Generic Access Profile

・SPP : Serial Port Profile

・HSP : Headset Profile

・HFP : Hands Free Profile

* For latest recommended prod-

uct information, browse the

following Web site:

http://www.necinfrontia.co.jp/

* Try to use a headset of the

recommended type to ensure

that it connects to the cradle

successfully and with the cor-

rectly matched sound volume.

Operating range About 50m (line-of-sight distance) Dependent on the environment.

Power consumption Bluetooth® Handset (BTH):About

0.5W

Bluetooth® Cradle (BTC) : About

1.5W Including the power used to charge

the handset.

Power feeding

method Power feeding from the multifunc-

tional telephone

Option AC-2RD UNIT Used only if the distance from the

main unit exceeds 400m.

Dimensions

(L × W × H) Bluetooth® Handset (BTH):

180mm × 51mm × 33mm Excluding the antenna.

Bluetooth® Cradle (BTC):

175mm × 226mm × 92mm

Weight Bluetooth® Handset (BTH):

About 200g Including the battery.

Bluetooth® Cradle (BTC):

About 300g Excluding the line cord, LAN cable.

Operating environ-

ment Temperature : 0 to 40℃

Relative humidity : 10 to 90% No dew condensing

1 - 9

About Cordless Terminals

* Bluetooth® is a registered trademark owned by Bluetooth SIG, Inc. and is licensed to NEC

Infrontia Corporation.

Restrictions Keep the cordless terminal at least 1m apart from other cordless terminals and

at least 3m apart from other radio equipment

Cordless terminals operate on a digital radio principle and are made less suscepti-

ble to interception by third parties. Radio waves used by the cordless terminals,

however, threaten the chances of intentional interception. To dismiss concerns

over possible interception by third parties, use a fixed-line telephone.

Item Dimension Remarks

Caution

1 - 10

Safety Precautions

This User’s Guide uses various pictorial markings to alert you to the precautions you need to

observe to safeguard you and others and prevent property damage.

The meanings of such pictorial markings and graphic symbols are defined below. Understand

these definitions fully before proceeding to read the main text.

Examples of Pictorial Markings

Safety Precautions

DANGER :Indicates a situation in which an impending risk of human

death or severe physical injury is anticipated.

WARNING :Indicates a situation in which a possibility of human death or

severe physical injury is anticipated.

CAUTION :Indicates a situation in which a possibility of physical injury

or property damage is anticipated.

NOTICE :Indicates a situation that could result in a failure to demon-

strate the intended performance of this system or in a func-

tional shutdown.

The symbol alerts you to a caution (including a danger or warning), which is

depicted within the marking (in this example, an electrical shock).

The symbol alerts you to a prohibited action, which is depicted within the mark-

ing (in this example, no wetting).

The symbol alerts you to a required or suggested, which is depicted within the

marking.

1 - 11

Safety Precautions

DANGER

●Observe these precautions en using a lithium-ion battery pack:

・Never charge the pack from other than the main unit.

・The lithium-ion battery pack has a specified connector orientation. In inserting the

pack into the unit, observe the correct connector orientation.

・Do not charge it with the lithium-ion battery pack unit.

・Use a specified type of lithium-ion battery pack. Do not use the specified type of lith-

ium-ion battery pack for any other device.

・Do not dispose of the lithium-ion battery pack in fires or heat it.

・Do not make direct soldering connections to the lithium-ion battery pack.

・Do not disassembly or tamper the lithium-ion battery pack.

・Do not carry or store the lithium-ion battery pack together with metallic products,

which could cause the pack to leak, heat or blast.

●If the internal fluid in the lithium-ion battery pack should contact the eyes, it

could threaten vision. Flush the eyes with plenty of fresh water immediately,

without rubbing them, and obtain medical attention promptly.

WARNING

●Do not remove the armor of the lithium-ion battery pack or scratch it, which

could cause the pack to leak, heat or blast.

●If the internal fluid in the lithium-ion battery pack should contact the skin or

clothes, it could cause physical harm to the skin. Flush with plenty of fresh water

immediately.

●Do not soak the lithium-ion battery pack in water or seawater or moisten it,

which could cause the pack to heat or rust.

●Discontinue using the lithium-ion battery pack whenever any signs of abnormal-

ity, such as leakage, discoloration or deformation, are noticed.

●Do not use the lithium-ion battery pack in bathrooms or shower rooms, which

could cause the pack to short-circuit, resulting in fires or electrical shock haz-

ards.

●Do not use the lithium-ion battery pack ere it may be splashed or wetted with

water, which could cause the pack to short-circuit, resulting in fires or electrical

shock hazards.

1 - 12

Safety Precautions

●Do not disassemble or tamper the unit, which could result in fires or electrical

shock hazards.

●Do not allow water inside the lithium-ion battery pack or wet it with water,

which could cause the pack to short-circuit, resulting in fires or electrical shock

hazards.

●Do not operate or make connections to this unit with wet hands, which could re-

sult in electrical shock hazards.

●Do not put flower vases, plant pots, cups, cosmetics, containers filled with

chemicals or water or small metallic objects on top of the unit, which could re-

sult in fires or electrical shock hazards if they spill or penetrate the interiors of

the unit.

●Do not insert metallic objects or put metallic objects into the interiors of the unit

through openings, which could result in fires, electrical shock hazards or fail-

ures.

●If it is necessary to use an AC adapter, use one of the specified type; otherwise,

fires, electrical shock hazards or failures could result.

CAUTION

●Do not give violent shocks to the lithium-ion battery pack or throw it.

●Keep the lithium-ion battery pack out of reach of infants and children.

●Do not leave the lithium-ion battery pack in a place exposed to direct sunlight or

in a hot place. A heightened internal temperature could result in fires.

●Do not place the unit in a place ere it could be splashed with heated oils or ex-

posed to steam, such as near a cooking table, or in a dusty place, which could

result in fires or electrical shock hazards.

●Do not mount the unit on a rickety table or in an inclined or unstable place,

which could cause the unit to tumble down out of balance or fall to cause phys-

ical injury.

WARNING

1 - 13

Safety Precautions

●Do not block ventilation holes in the unit, which could cause heat to build up in-

side the unit, resulting in fires.

●Do not place the unit in a place that is liable to frequent vibration or impact,

which could cause the unit to fall or tumble down, resulting in physical injury.

●Be careful not to let the antenna of a cordless telephone or the like stick into your

eyes by mistake.

●Do not shot-circuit the charging terminals.

●Do not charge the handset seated in the cradle while the charging terminals are

wet with water drops.

●If foreign matter or water should penetrate the interiors of the telephone, discon-

nect the line cord, LAN cable and AC adapter immediately and contact your

dealer.

NOTICE

●To use the unit safely and properly, avoid installing it in these places:

・Places there is much dust or vibration.

・Places that are filled vaporized chemicals or the unit may be exposed to chemicals.

・Places close to radios or TV receivers or sources of intense magnetic fields.

・Places in which there are sources of high-frequency interference nearby, such as high-frequency

sewing machines or electric welders.

CAUTION

1 - 14

Operating Instructions and Maintenance

In using cordless terminals, take notice of these

instructions in particular.

・If multiple cordless terminals are installed, keep

their Bluetooth® cradles at least 1m apart from

one another.

・If the Bluetooth® cradle is installed near a metal,

concrete wall or any other structure that could

affect radio transmission, a communication fail-

ure might occur.

・Keep the Bluetooth® cradle at least 3m apart from

any of the devices listed below. Be also careful

not to get within 3m of these devices en using the

Bluetooth® handset. Before locating the cradle,

ask your dealer for a safety validation.

- Microwave ovens

- Wireless LAN access points (AP)

- Medical apparatus

- RFID (apparatus operating in the 2.4 GHz band)

- Manufacturing equipment, such as plasma strippers (LSI manufacturing)

- Speedway electronic toll gates

- Bluetooth® devices

Operating Instructions and

Maintenance

Locating the Bluetooth® Cradle

Maintenance

Environment

At least 1m apart

Concrete Wall

Metal

1 - 15

Operating Instructions and Maintenance

Use the antenna of the Bluetooth® cradle in an

upright position.

The antenna would be broken or bent if it is given

undue force.

Cordless terminals may not work or may be

affected by interference if they are used near a

broadcasting station or near sources of intense radio

transmission, such as ham radio and CB radio.

Because radio equipment might be disabled in the

presence of radio interference, ask your dealer for

preliminary environmental measurement. In install-

ing new radio equipment after the system has been

installed as well, request a preliminary verification

of freedom from radio interference. If interference

is detected after the system is installed, they may

not be corrected.

・This product features built-in radio equipment

that operates on the entire band of 2.4 to 2.4835

GHz. Bands in which mobile stations are identi-

fied can be avoided. The product supports the

FH-SS modulation method and an interfering dis-

tance of 80m. It is labeled with a mark to desig-

nate these characteristics as shown at right.

Antenna

Radio Transmission

2.4 FH 8

1 - 16

Operating Instructions and Maintenance

Cordless terminals are designed to heighten radio output automatically as the separation

between the Bluetooth® cradle and Bluetooth® handset widens, thereby maintaining a satis-

factory state of communication.

Heightened radio output could cause radio interference to neighboring equipment. In this

occurs, keep the Bluetooth® cradle farther apart from the neighboring equipment.

If the Bluetooth® cradle and Bluetooth® handset get

dirty, wipe their surfaces with a soft, dry cloth.

If they are heavily soiled, wipe them with a diluted

solution of a kitchen detergent and then wipe them

off with a dry cloth.

Never use organic solvents, such as alcohol, ben-

zine and thinner, for cleaning; these chemicals

could damage the surfaces of the telephone.

Also, avoid using a chemical duster.

Tips on Radio Transmission

The working frequency band of this device is shared by industrial, scientific and medical

equipment, such as microwave ovens, premises radio stations that are typically used in

manufacturing lines at plants for mobile identification (radio stations that require licensing)

and specified low-power radio stations (license-free radio stations).

• Before using this device, check that premises radio stations for mobile identification and

specified low-power radio stations are not used nearby.

• If any case of radio interference arises from a premises radio station used for mobile

identification, discontinue radio transmission from this device immediately and contact

your dealer for advice on how to take action for avoiding the interference.

• Further, if any case of radio interference arises from a specified low-power radio station

used for mobile identification or any troubles develop, contact your dealer.

Radio Interference

Maintenance

Dry cloth

1 - 17

Operating Instructions and Maintenance

Keep the charging terminals of the Bluetooth® cra-

dle and Bluetooth® handset always clean. Wipe dust

off the charging terminals with a dry cotton swab or

the like at least once a month or rub them with a

cotton swab or the like impregnated with alcohol.

Because cordless terminals use radio transmission between their Bluetooth® cradle and Blue-

tooth® handset, they may take about 15 seconds after the line cord/LAN cable is instead into

the Bluetooth® cradle before calls can be made between the Bluetooth® cradle and Bluetooth®

handset.

If the Bluetooth® handset goes off- hook or the FNC/Conference or TALK key is pressed in

the meantime, the error tone “pi-pi-pi-pi” may sound without a wireless (line) connection

being established, but this is not a fault.

Charging Terminals

In cleaning the charging terminals, be sure not to:

• Touch the terminals with hands directly

• Short-circuit the terminals.

Operation Following Power Feeding to the Bluetooth®

Cradle

Charging

terminals

Caution

1 - 18

Component Names and Functions

The names and functions of the components of a cordless terminal are shown below.

Component Names and Functions

Bluetooth® Cradle (BTC)

Speaker

Answer

ABC 3

DEF

JKL

GHI 6

MNO

TUV

PQRS 9

WXYZ

Recall

%NGCT /GPW

Transfer

Hold

Feature

Mic

Exit Help

4GFKCN

Large lamp

Indicates the status

of a terminating call.

Security key

Use to enable the security features.

* The security key is not available on

some types of telephone.

Antenna

Charging

terminals

1 - 19

Component Names and Functions

Bluetooth® Handset (BTH)

Back Right

side

HOLDTRF

CONF Recall

@ ABC DEF

GHI JKL MNO

PQRS TUV WXYZ

HOLD

Recall

CONF

FNC

TRF

FNC

㨇 ޓޓ㨪ޓޓ 㨉

㨇ޓޓ㨉

㨇ޓ 㨉

㨇ޓޓ 㨪ޓ ޓ㨉

[ ޓ ] 㨪[ ޓ ]

[ޓ ]

㨇ޓޓ㨉

[ ޓ ]

Incoming call/

charging lamp

Headset jack

Corsur key

Use to accept the terminating or

originating call history displayed

in the LCD screen or and make

a call.

Use to adjust tone volumes or

display densities.

Volume Up/Down key:

Received History key:

Use to view a history of

terminating calls.

Enter key:

Call History key:

Use to view a history of originating

calls.

Transfer key

Use to forward a call to an

extension or central office line.

FNC/Conference key

(with lamp)

Use to call an extention or answer

a call. This key can also be used to

on the man unit as a FNC (function

key) key. A setting on the man unit

is required to use this key as a FNC

key. For more details, refer to the

user dcocumentation that comes

with your system.

TALK key

(with lamp)

Use to originate a call to an

extension or central office line or

answer a terminating call.

Indicates the sutatus

of a terminating call

and in progress, and

the status of charging.

Accepts a wire

headset.

㨇ޓޓ㨉

LCD screen (with backlight)

Displays various information

according to the status of the

telephone, such as a clock,

remote party information,

originating and terminating call

histories and menues.

Line keys 1 to 8 (with lamp)

Access the functions

preporgrammed on function

buttons 1 to 8 on the cradle.

Also display the status of the

functions preprogrammed on

the buttons.

HOLD key

Use to place extention or

central office line calls on hold.

Recall key

Use to forward calls on a

private exchange (PBX) or

receive the call waiting service

feature.

END key (Disconect)

Use to clear a call.

Dial keys 1 to # (with backlight)

Charging terminals

1 - 20

Bluetooth® Handset LCD Screen

The Bluetooth® handset LCD screen displays certain information as described below accord-

ing to the status of the telephone. For information about the Bluetooth® cradle LCD screen,

refer to the user documentation that comes with your system.

▼Standby Sample Display

The information shown below is displayed en the telephone is not used.

For explanations of the icons, see “Explanations of Icons” (P.1-22).

Bluetooth® Handset LCD Screen

Displayed Information

・First line : Icon

・Second line : Date and time

・Third line : Extension number and line

・Fourth line : Active line key number

9'&2/



First line

Second line

Third line

Fourth line

Ĵ ĻĺĹĸķĶĵ

1 - 21

Bluetooth® Handset LCD Screen

▼If an Originating or Terminating Call History Is Displayed

If an originating or terminating call history is displayed, the history number of a call and date

and time are displayed, along with the remote party’s name or telephone number.

▼If the Setup Screen Is Displayed

If the Setup Screen is displayed, the title of a setup item and its setting are displayed. For

more details, see “Configuring the Bluetooth® Handset (BTH)” (P.1-27).

The display may differ depending on your system.









Caution

=4KPI8QNWOG?

4KPI8QNWOG

=

ĀĀĀĀĀ

=.QY2QYGT/QFG?

e&KUCDNG

e'PCDNG

1 - 22

Bluetooth® Handset LCD Screen

The table below summarizes the explanations of the icons that appear on the first and fourth

lines in the LCD screen.

Explanations of Icons

Icon Explanation

Antenna

marks High Indicates the strength of radio transmission between

the Bluetooth® cradle and Bluetooth® handset.

* If no service occurs while a call is in progress, the

call is cleared after about 20 seconds expire. The

call can last if it recovers from no service before

it is cleared.

* No service (no display) indicates that the tele-

phone is out of reach of radio transmission. Move

to a place ere an antenna mark lights.

Low

ser-

vice

Security mode Displayed en the telephone is locked in security key.

* Available only if the Bluetooth® cradle is an IP

multifunctional telephone.

Ring tone OFF Displayed en the telephone is configured to suppress

the ring tone. For more details, see “Ring Volume”

in “Configuring the Bluetooth® Handset (BTH)”

(P.1-27).

Unread instant

message notification Displayed en there are instant messages (IM) yet to

be read.

* Available only if the Bluetooth® cradle is an IP

multifunctional telephone.

Unheard voice

mail notification Displayed en there are voice mails in the mailbox

yet to be heard.

Key lock Displayed en a key lock has been set.

For more details, see “Key Lock” (P.2-3)

Unanswered call

history yet to be

confirmed

Displayed en there is a history of unanswered termi-

nating messages yet to be confirmed.

Remaining battery

voltage Indicates the remaining voltage of the battery. For

more details, see “Charging” (P.1-5).

1 - 23

Bluetooth® Handset LCD Screen

Available cursor

display Indicates the directions of the cursor keys available.

Line key status dis-

play Indicates the numbers of active line keys.

Icon Explanation

ĴĻ

1 - 24

Adjusting the Bluetooth® Handset

You can adjust the volumes of various tones and the display density of the Bluetooth® hand-

set using the up and down cursor keys.

▼Adjusting the Receiver Volume

You can adjust the volume of the voice that is heard from

the handset.

Press the up and down cursor keys (up: high, down: low)

while you are talking on the handset.

▼Adjusting the Ring tone Volume

You can adjust the volume of the ring tone of the Blue-

tooth® handset.

Press the up and down cursor keys (up: high, down: low)

while the ring tone sounds.

If you want to adjust the ring tone volume while the ring

tone does not sound, do as instructed in “Ring Volume” in

“Configuring the Bluetooth® Handset (BTH)” (P.1-27).

The ring tone OFF icon appears in the LCD screen if the

ring tone volume is turned off.

▼Adjusting the LCD Density

You can adjust the contrast of the LCD screen.

Press the up and down cursor keys (up: dark, down: light)

while the standby panel is on display.

Adjusting the Bluetooth® Handset

9'&2/

=?ć=A?

*0&

ĀĀĀĀĀĀ

9'&2/

40)

ĀĀĀĀĀĀĀĀ

9'&2/



.%&

ĀĀĀĀĀ

1 - 25

Configuring the Cordless Terminal

Start configuring Bluetooth® from the cradle setup menu.

The table below lists the setting of each setup item.

Configuring the Cordless Terminal

Configuring the Bluetooth® Cradle (BTC)

Menu display Setting

([ ] default) Explanation

Pairing

Mode Pairing - Up to 8 Bluetooth® devices located around the

Bluetooth® cradle (BTC) are located, among

which select a headset want to pair with the multi-

functional telephone.

For more details, see “Pairing with a Bluetooth®

Headset” (P.1-38).

PIN Code 4 to 16

digits

[0000]

Before pairing, you need to adjust the PIN Code

of the Bluetooth® cradle (BTC) and the Blue-

tooth® headset.

In pairing with a Bluetooth® headset having a PIN

Code other than 0000, enter a string of 4 to 16

digits to suit that device.

For more details, see “Pairing with a Bluetooth®

Headset” (P.1-38).

* The PIN Code is a password that is exchanged

between Bluetooth® devices preparatory to

launching a session of communication between

them.

Visibility 1. Disable

[2. Enable] Set ether to make information about the Blue-

tooth® cradle (BTC) visible to other Bluetooth®

devices or not.

• Disable : Invisible

• Enable : Visible

1 - 26

Configuring the Cordless Terminal

▼Key Operations at Menu Setup (Bluetooth® Cradle)

BT Information - You can view the following kinds of information

about the Bluetooth® cradle (BTC):

• Firmware version

• Hardware version

• BT module

• BT profile (Bluetooth® standard)

• SPP (SPP profile version)

• HSP (HSP profile version)

• HFP (HFP profile version)

• Device address

•Device name

Key Description

Cursor

keys Up • Moves up the highlighted item.

• Raises the volume or density.

Down • Moves down the highlighted item.

• Lowers the volume or density.

Left • Returns to the last page.

Right • Accepts the highlighted item and displays the next page.

Enter • Accepts the highlighted item and displays the next page.

• Saves the change and returns to the last page.

Dial keys • Accept the item of a number pressed and display the next page.

• Save the change to a number pressed and return to the last page.

• Enter numerals.

Clear key • Returns to the last page.

• Deletes one numeral.

* The clear key is not available on some types of telephone.

Exit key • Cancels an operation and returns to the standby panel.

You cannot originate calls or answer terminating calls while the Bluetooth®

menu setup is in progress. Exit the menu before originating calls or answering

terminating calls.

Menu display Setting

([ ] default) Explanation

Caution

1 - 27

Configuring the Cordless Terminal

On the Bluetooth® handset in standby mode, press the [HOLD] > [Transfer] keys and then

press dial keys (1) to (6) to see a Setup Screen associated with the dial key pressed.

The table below lists the setting of each item.

Configuring the Bluetooth® Handset (BTH)

The handset will return to the standby panel automatically if 4 minutes pass with

the no action being launched from the menu.

Dial key Item Setting

([ ] default) Explanation

(1) Base Call - Allows you to call up the paired Bluetooth®

cradle and identify it en it is unknown.

(2) Key Touch

Tone •Disable

•[Enable] Set ether to sound a confirmation tone each

time a key is pressed or not.

(3) Ring Volume Off (0),

1 to [8] to 13 Adjusts the ring tone volume.

The ring tone OFF icon appears in the LCD

screen if the ring tone volume is turned off.

(4) No Service

Tone •Disable

•[Enable] Set ether to sound a no service tone en no

service occurs.

(5) Low Power

Mode •Disable

•[Enable] Set ether to transition to low-power mode

automatically en no call or key operation

has been launched for a long time.

(6) Font Size • Double

Height

•[Normal]

Set ether to display the characters on the

two lines in the middle in the LCD screen

in double or normal height.

* Characters display in normal height

while a setup item is on display.

You cannot originate calls or answer terminating calls while the Bluetooth®

menu setup is in progress. Exit the menu before originating calls or answering

terminating calls.

Caution

1 - 28

Configuring the Cordless Terminal

▼Key Operations at Setup (Bluetooth® Handset)

Key Description

Cursor

keys Up • Moves up the highlighted item.

• Raises the volume or density.

Down • Moves down the highlighted item.

• Lowers the volume or density.

Left • Returns to the last page.

Right • Accepts the highlighted item and displays the next page.

Enter • Accepts the highlighted item and returns to the standby panel.

END key • Cancels an operation and returns to the standby panel.

1 - 29

Transforming the Standard Handset into a BCH-L(BK) UNIT

The BCH-L(BK) UNIT is an optional device that transforms the standard multifunctional

telephone into a cordless terminal. This section explains how to transform the standard hand-

set into a BCH-L(BK) UNIT.

▼Supported Telephone Type

The BCH-L(BK) UNIT can be connected to the following types of telephone:

▼Replacement Procedure

1Turn over the telephone.

2Remove the standard handset.

Release the coiled cord from the groove and out its modular plug from the HANDSET connector

on the back of the telephone.

3Lower the tilt legs to the first level.

Transforming the Standard Handset into

a BCH-L(BK) UNIT

Telephone type Description Remarks

Digital multifunctional

telephone • DTL-12/24/32D-1

• DTL-32DLK-1

• DTL-8LD-1

Not connectable to the DTL-

2E-1 and DTL-6DE-1.

IP multifunctional tele-

phone • ITL-12/24/32D-1

• ITL-32DLK-1

• ITL-8LD-1

• ITL-320C-1

Not connectable to the DTL-

2E-1 and DTL-6DE-1.

If the BCH-L(BK) UNIT is connected to a telephone, the following optional

devices cannot be connected at the same time:

• APR-L UNIT

• ADA-L UNIT

• BHA-L UNIT

• PSD-L(WH) UNIT

• PSA-L(WH) UNIT

Caution

1 - 30

Transforming the Standard Handset into a BCH-L(BK) UNIT

4Release lugs a and b on the stopper from grooves A and B in the

tilt legs and widen the tilt legs.

5Slide the tilt legs to front out of position while pushing claws c and

Tilt leg

Stoppe

1 - 31

Transforming the Standard Handset into a BCH-L(BK) UNIT

6Tilt the handset cradle stopper towards the cradle until it is

released with a click.

7Slide the handset cradle farther away to remove.

8Remove the cradle connecting cable from the telephone unit con-

nector.

9Insert the cradle connecting cable of the Bluetooth® cradle (BTC)

into the telephone unit connector.

10 Insert the lug on the telephone unit into the hole in the Bluetooth®

cradle (BTC).

Have the cradle connecting cable passed in the groove to keep it from being pinched.

Multifunctional

telephone unit

Handset cradle

Unit connector

Cradle connecting cable

Stopper

1 - 32

Transforming the Standard Handset into a BCH-L(BK) UNIT

11 Slide the Bluetooth® cradle (BTC).

12 Push the Bluetooth® cradle (BTC) until the stopper clicks into

position.

13 Fit the cradle connecting cable in the groove to clamp.

Multifunctional

telephone unit

Bluetooth

cradle (BTC)

Unit connector

Cradle connecting cable

Stopper

Cradle connecting cable

Bluetooth

cradle (BTC)

Groove

1 - 33

Transforming the Standard Handset into a BCH-L(BK) UNIT

14 Cut out the notched section of the bottom unit connector on the

multifunctional telephone with nippers or the like.

15 Attach the bottom unit mounted in the Bluetooth® cradle (BTC) to

the telephone connector while pushing the claws on both sides of

the unit.

16 Uncover the bottom unit mounted in the Bluetooth® cradle (BTC)

while holding its knob.

Cut out the notched section at its base to leave no legs.

Notched section

Multifunction telephone

Caution

Multifunctional

telephone

Bottom unit

Claw

1 - 34

Transforming the Standard Handset into a BCH-L(BK) UNIT

17 Stow the extra length of the bottom unit connecting cable at the

bottom unit connector and close the bottom unit.

18 Widen the tilt legs until a click sounds.

19 The tilt legs in original position.

20 Place the Bluetooth® handset (BTH) in the Bluetooth® cradle

(BTC).

21 Erect the antenna of the Bluetooth® cradle (BTC).

The transformation of the standard handset into a BCH-L(BK) UNIT is

complete.

Cover

Knob

Bottom unit connecting cable

Bluetooth

cladle㧔BTC㧕

Antenna

Bluetooth

handset㧔BTH㧕

Bluetooth

cradle㧔BTC㧕

1 - 35

Wall-Mounting the Bluetooth® Cradle

▼Selecting a Mounting Position

Clearances required for installing the Bluetooth® cradle are shown below. Avoid mounting

the cradle on a plaster-board wall, but before mounting the cradle on a wall, fully check that

the wall withstands the weight of the telephone and the load from pulling the telephone dur-

ing operation.

<< Wall-mounting dimension diagram >>

Wall-Mounting the Bluetooth

Cradle

CAUTION

●When the cradle is wall-mounted, watch for its fall.

- Physical injury could result.

●In wall-mounting the cradle, install it in firm position so it will not fall due its

own weight.

- Physical injury could result.

1 - 36

Wall-Mounting the Bluetooth® Cradle

▼Installation Procedure

Finish cabling to the Bluetooth® cradle before mounting it.

1Attach two wood screws to the wall.

See “<< Wall-mounting dimension diagram >>” (P.1-35). Keep a clearance of about 2mm between

each wood screw and the wall.

2Remove the Bluetooth® handset hanger from the cradle.

Insert a rod in the hollow below and lift it up.

3Insert the handset hanger in a different direction and slide it down

to secure until it clicks into position.

Wood screw

Ǿ4.1mm

length 16 to 20mm

Wall

Surface

Wood screw Wall

Surface

Keep a clearance

of about 2mm.

Handset hanger

Rod

Hollow

Click

Multifunctional

telephone

Handset hanger

1 - 37

Wall-Mounting the Bluetooth® Cradle

4Turn over the telephone and lower the tilt legs to the first level.

5Release lugs a and b on the stopper from grooves A and B in the

tilt legs and widen the tilt legs.

6Hook wall-mount holes C and D on the back of the telephone on

wood screws c and d attached in Step 1.

The installation of the Bluetooth® cradle is completed.

To return the Bluetooth® handset to a wall-mounted cradle, push it fully into

position until its contacts touch the rear.

Wood screw c

Wood screw d

Wall-mount hole C

Wall-mount hole D

Wall

Surface

Bluetooth cradle

Caution

1 - 38

Connecting a Headset

The following kinds of headsets can be used with a cordless terminal:

・Bluetooth® Cradle (BTC) side : Bluetooth® head set, wire head set

・Bluetooth® Handset (BTH) side : Wire head set

The method of connecting each headset is as follows.

A Bluetooth® headset can be connected to the Bluetooth® cradle (BTC) by pairing in a cradle

menu operation. To perform pairing, follow these steps:

1Invoke the Bluetooth® device setup screen in the Bluetooth® cra-

dle LCD screen.

For instructions on how to invoke the setup screen, see “Configuring the Bluetooth® Cradle

(BTC)” (P.1-25).

If the Bluetooth® headset has a PIN code of ‘0000’, go to Step 3; else, go to Step 2.

2In the Bluetooth® screen, select [1. Pairing Mode] > [2. PIN Code]

in this order. Enter a PIN Code (4 to 16 digits) to suit the Bluetooth®

device and press the OK key.

Connecting a Headset

Pairing with a Bluetooth

Headset

=$NWGVQQVJ?

2CKTKPI/QFG

8KUKDKNKV[

ĉĊ$CEM1-

=2CKTKPI/QFG?

2CKTKPI

2+0%QFG

ĉĊ$CEM1-

=2+0%QFG?

2+0%QFG!



$-$CEM1-

1 - 39

Connecting a Headset

3In the Bluetooth® screen, select [1. Pairing Mode] > [1. Pairing] >

[1. -- Bluetooth Headset --] in this order and select a headset to pair

with from a list of Bluetooth® devices located.

4Select [1. Paired Head Set] > [2. Connect] > [2. Enable] in the pair-

ing screen in this order and press the OK key.

Pairing between the Bluetooth® headset and the Bluetooth® cradle

(BTC) is completed.

After pairing, be sure to configure the cradle connection with the Bluetooth®

headset in Step 4 to enable it. If connected setting is not done, the Bluetooth®

headset that does the pairing cannot be used.

To unpair a paired Bluetooth® headset

Select [1. Delete] in the Bluetooth® Headset screen in Step 4 above to switch to a Delete

screen. Press the OK key to unpair the paired Bluetooth® headset.

=2CKTKPI?

$NWGVQQVJ*GCFUGV

ĉĊ$CEM1-

=2CKTKPI?



ĉĊ$CEM1-

ĴĴ

=$NWGVQQVJ*GCFUGV?

CCDDEEFFGGHH



ĉĊ$CEM1-

Ĵ Ĵ Ĵ

=$NWGVQQVJ?

2CKTKPI/QFG

8KUKDKNKV[

ĉĊ$CEM1-

=2CKTKPI/QFG?

2CKTKPI

2+0%QFG

ĉĊ$CEM1-

=2CKTKPI?



ĉĊ$CEM1-

ĴĴ

=$NWGVQQVJ*GCFUGV?

&GNGVG

%QPPGEV

ĉĊ$CEM1-

=%QPPGEV?

&KUCDNG

'PCDNG

ĉĊ$CEM1-

ĵ ĵ

Caution

1 - 40

Connecting a Headset

▼Visibility Setting

Set whether to make information about the Bluetooth® cradle (BTC) visible to other Blue-

tooth® devices. The example below assumes that the cradle information is not made visible.

1Invoke the Bluetooth® device setup screen in the Bluetooth® cra-

dle LCD screen.

For instructions on how to invoke the setup screen, see “Configuring the Bluetooth® Cradle

(BTC)” (P.1-25).

2In the Bluetooth® screen, select [2. Visibility] > [1. Disable] and

press the OK key.

The visibility setting is completed.

You can connect a headset to the Bluetooth® handset (BTH).

For latest recommended product information, browse the following Web site:

http://www.necinfrontia.co.jp/

Insert the headset plug firmly into the headset jack (bearing the mark in the cover) on the

right side of the Bluetooth® handset (BTH).

Connecting a Wire Headset

=$NWGVQQVJ?

2CKTKPI/QFG

8KUKDKNKV[

ĉĊ$CEM1-

=8KUKDKNKV[?

&KUCDNG

'PCDNG

ĉĊ$CEM1-

Bluetooth Handset (BTH)

Headset jack

Bluetooth cradle 㧔BTC㧕

2 - 1

Bluetooth

Handset Operations

Caution ............................................................................ 2-2

Bluetooth® Handset Functions ........................................ 2-3

2 - 2

Caution

Take notice of these instructions when operating a cordless terminal:

・Cordless terminals take a certain length of time before they enable you to talk. Cordless

terminals also take some time before switching a call originated by on-hook dialing to the

Bluetooth® handset after you confirm the called party’s response to it.

・The TALK lamp on the Bluetooth® handset may light green while it stands by off-hook

after a dialing operation performed from the Bluetooth® cradle. Press the handset key to

switch the call to the Bluetooth® handset.

・When making a phone call from the Bluetooth® handset after pressing the TALK or FNC/

Conference key, make sure you hear a dial tone before pressing dial keys. Dial keys

pressed before a dial tone is heard will be ignored.

・For operating instructions that use line keys, refer to the user documentation that comes

with your system.

Caution

2 - 3

Bluetooth® Handset Functions

You can lock the Bluetooth® handset keys to disable them from being tampered.

▼How To Enable the Key Lock

1Press the Transfer key for 2 seconds.

2A key lock icon appears in the LCD

screen.

▼How to disable

1Press the Transfer key for 2 seconds.

2The key lock icon disappears from the

LCD screen.

Bluetooth® Handset Functions

Key Lock

If a call terminates while the key lock is enabled

Press the TALK key, blinking line key or FNC/Conference key to answer the terminating

call. While the call is in progress, the key lock is temporarily overridden to make all keys

functional. Hang up to return to the key lock enabled state.

9'&2/



9'&2/



3 - 1

Troubleshooting

Troubleshooting Tips ....................................................... 3-2

3 - 2

Troubleshooting Tips

If you suspect a failure, try the actions recommended in the table below first. If the problem

persists or the symptom you are experiencing is not listed here, call your dealer and request

service.

Troubleshooting Tips

Symptom Point to check Action

Shut down completely • Isn’t the Bluetooth® cradle

cord out of position?

• Is the battery correctly

loaded?

• Is the battery charged?

• Isn’t the handset too

remote from the Blue-

tooth® cradle? (Does the

antenna mark in the Blue-

tooth® handset LCD screen

show “Antenna” or isn’t it

off?)

• Inset the Bluetooth® cra-

dle cord firmly into posi-

tion.

• Reload the battery cor-

rectly.

• The battery may have been

exhausted aged if the hand-

set still fails when the bat-

tery is fully charged.

Replace the battery.

• Get closer to the Blue-

tooth® cradle to operate.

Ring back tone does

not sound • Isn’t the ring tone volume

turned OFF? (Doesn’t the

ring tone OFF appear in

the Bluetooth® handset

LCD screen?)

• Is the battery correctly

loaded?

• Adjust the ring tone vol-

ume.

• Reload the battery cor-

rectly.

Voice is disrupted while

talking • Does the antenna mark in

the handset LCD screen

show “Antenna” or isn’t it

off?

• Isn’t there an obstacle,

such as a concrete wall,

between the Bluetooth®

cradle and Bluetooth®

handset?

• Get closer to the Blue-

tooth® cradle to operate.

• Move to a location clear of

intervening obstacles.

3 - 3

Troubleshooting Tips

Noise heard while talk-

ing • Isn’t there any home appli-

ance or OA equipment

nearby?

• Electrical equipment can

be a source of radio inter-

ference. Keep apart from

electrical equipment.

Calls do not last long

than 10 minutes even

though the battery has

been charged for 8

hours or longer

• Is the Bluetooth® handset

correctly seated in the

Bluetooth® cradle?

• Aren’t the charging termi-

nals soiled?

• Hasn’t the handset been

used for nearly two years?

• Keep the Bluetooth® hand-

set properly seated in the

Bluetooth® cradle.

• Wipe off dirt from the

charging terminals of the

Bluetooth® cradle and

Bluetooth® handset with a

dry cloth.

• The battery may have been

exhausted if two years

have passed since the

handset was first used.

Replace the battery.

Remote party’s voice

hard to hear • Isn’t the Bluetooth® hand-

set receiver volume set

low?

• Press the up cursor key

while talking to adjust the

receiver volume.

It sometimes happens

that, when the TALK or

FNC/Conference key is

pressed, their respec-

tive lamps blink but do

not stay continuously lit

and the call is not

established, with an

error tone “pi-pi-pi-pi”

sounding from the

Bluetooth® handset.

• Radio interference may be

at fault.

• Isn’t there any source of

radio interference nearby?

• Is the cradle at least 3m

apart from the equipment

mentioned in “Locating the

Bluetooth® Cradle” (P.1-

14) ?

• Isn’t there any device near

the Bluetooth® handset that

is mentioned in “Locating

the Bluetooth® Cradle”

(P.1-14) ?

• Press the TALK or FNC/

Conference key one again.

• Keep the Bluetooth® cradle

and Bluetooth® handset at

least 3m apart from

sources of possible radio

interference.

Symptom Point to check Action

Store name

A50-012514-001 Issue 1.0

2007.12

Cordless Terminal User



s Guide

Please cooperate with recycling of a lithium ion battery.

NEC Infrontia Corporation

NEC of America LOBTC Bluetooth Cradle User Manual BT TEL E

NEC Corporation of America Bluetooth Cradle BT TEL E

Users Guide

Navigation menu

Namespaces

Views

Navigation
