User Manual

7004 Wireless Speaker Clock with Pen

INSTRUCTIONS



Features:

z WirelessSpeaker

z Hands‐freeMicrophonefunction

z AuxiliaryLine‐inPlayFunction

z ChargingCable

z RechargeableLithiumBattery

z AnalogClock

z MetalInkPen



Specifications:

z SpeakerPower: 5Watts

z BatteryCapacity: 800mAh

z Wirelessversion: 4.1

z OperatingDistance: 30Feet

z ChargingTime:  Approximately2hours

z PlaybackTime: Upto3hours(mediumvolume)



ControlButtons

O MULTIFUNCTIONBUTTON

PowerOn:PresstheMULTIFUNCTIONbuttonandholdfor2‐3secondsuntila

toneisheardandthebluelightflasheswaitingtopair.

PowerOff:PressandholdtheMULTIFUNCTIONbuttonfor3‐4secondsuntila

doubletoneisheardandthelightflashesgoesout.

Pause/Play:Pressandreleasetopausethemusicandrepeattoresume

playing.

AUXLine‐InJack

Multifunction

Microphone

Previous/DownNext/U

MicroUSBPort

Answer/EndCall:Pressandreleasetoanswerorendacall.

‐ PREVIOUS/DOWN:Pressandholdtodecreasethevolume/Pressandrelease

forprevioussong.

+ NEXT/UP:Pressandholdtoincreasevolume/Pressandreleasefornextsong.



ControlsNext/Previous,VolumeUp/Down,Pause/Play,Answer/EndCall:Youmay

alsousethefunctionsonyoursmartphoneormusicplayertocontrolthesefunctions.



MICROPHONE

Foruseasahands‐freespeaker.Itisasmallholelocatedtotheleftofthe

MULTIFUNCTIONbutton.



PleaseNote:Itisstronglyrecommendedthatyouturnoffthespeakerwhilenotinuse.



Charging

PlugthechargingcableintotheChargingportofthespeakerandthenconnecttheUSB

endofthechargingcabletotheUSBportofyourPCorotherUSBpowersource.Thered

LEDlightwilllightupduringcharging.Thelightwillgooffwhenchargingiscomplete.It

isstronglyrecommendedthatthespeakerbefullychargedbeforefirstuseandafter

longperiodsofinactivity.Donotoverchargethebattery.



WirelessPairing

Pleasechecktomakesurethedevicetowhichyouarepairinghaswirelesscapabilities.

ThiscanshowupundertheBluetooth®settingonyoursmartphoneormusicplayer.

Thisinformationshouldbeincludedinyourphoneordevice’sinstructionsorpackaging.



1. Makesurethatthespeakeristurnedoff.

2. Placethespeakerandthedeviceinproximitysothatbothdevicesareinview.

3. PressandholdtheMULTIFUNCTIONbuttonfor2‐3secondsuntilspeaker

powerison.BlueLEDlightswillflash.Whenpaired,atonewillsoundandthe

lightwillturnsolid.

4. Ifyourmusicplayerasksforapasscode,enterthepasscode0000andpress

OKtopairyourspeakerwiththedevice.Thespeakerisnowreadyforlistening

tomusicoransweringcalls.

Note:Somemobilephonesorotherdevicesmaypairautomaticallywhenre‐started.



AuxiliaryLine‐InMode(Plugginginaphoneormusicplayer)

Plugoneendoftheprovided3.5mmAUXcableintothesmartphoneofmusicplayer’s

headphoneorspeakerjackandplugtheotherendintothespeaker.Operatethesong

selectionsandvolumefromthesmartphoneorotherdevice.

• Next/PreviousandPause/Playsongfunctionbuttonsarenotavailablein

AUXLine‐inMode.(Usethephone’scontrols.)

• Speakervolumeisavailableinthismode,butonlycontrolsthespeakervolume,

notthevolumeonthephone/musicplayer.



PhoneSpeakerFunctions



Whenacallcomesin,theringandvoiceindicationwillbeheardthroughthespeaker.

1. Answer:PressandreleasetheMULTIFUNCTIONbuttontoanswerthecall.You

mayalsoanswerthroughyourphone.

2. RejectaCall:PressandholdtheMULTIFUNCTIONbuttonfor2secondsuntil

youhear“callrejected”.Youmayalsodeclineacallusingyourphone’s

functions.

3. EndaCall:PressandreleasetheMULTIFUNCTIONbuttonduringthecall.You

mayalsoendthecallusingyourphone’sfunctions.

Precautions

• PleaseonlyusethecomputerUSBortheDC5Vpoweradaptormatchingthe

MicroUSBinterfacetocharge.Onlyusequalitycordsandadaptors.

• Pleasekeepanduseinnormalenvironments.Exposuretoextremeelements

suchasextremeheatandcold,fire,dust,excessivedirectsunlight,orother

extremeelementsmaydamagetheunit.Keepdebrisorotheritemsfrom

enteringanyoftheports.Donotcleanwithharshchemicals.

• Donotattempttoopen,repair,ortakeapartthespeaker.Thespeakermaybe

damagedduringthatprocess.

• Ifthespeakerqualityseemslessened,oraslightpoppingnoiseisheard,it

maybeduetolowbattery.(Recharge)

• Thisitemisnotmeantforchildren.

• Donotoverchargethebattery.

TROUBLESHOOTING

NoSound

• Makesurethatthemusicplayerisworkingandthatthespeakerischarged.

• Makesurethewirelessispairedtothisspecificspeakerandthatthemusic

playerandspeakerarewithinoperatingdistance.(30feet)



Notcharging

• Checktomakesurethatyouareusingthecorrectcableandthatitisfully

pluggedintoboththedeviceandtheUSBportthatyouarechargingfrom.

AlsochecktomakesurethePCorotherUSBchargeristurnedon.

FCC Statement

ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe

followingtwoconditions:

(1)Thisdevicemaynotcauseharmfulinterference.

(2)Thisdevicemustacceptanyinterferencereceived,includinginterference

thatmaycauseundesiredoperation.

2.Changesormodificationsnotexpresslyapprovedbythepartyresponsible

forcompliancecouldvoidtheuser’sauthoritytooperatetheequipment.

Note:Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfor

aclassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsare

designedtoprovidereasonableprotectionagainstharmfulinterferenceina

residentialinstallation.

Thisequipmentgeneratesusesandcanradiateradiofrequenceenergy

and,ifnotinstalledandusedinaccordancewiththeinstructions,maycause

harmfulinterferencetoradiocommunications.However,thereisnoguarantee

thatinterferencewillnotaccorinaparticularinstallation.ifthisequipmemt

doescauseharmfulinterferencetoradioortelevisionreception,whichcanbe

determinedbyturningtheequipmentoffandon,theuserisencouragedtotry

tocorrecttheinterferencebyoneormoreofthefollowingmeasures:



•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanautletonacircuitdifferentfromthatto

whichthereceiverisconnectec.

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.The

devicecanbeusedinportableexposureconditionwithoutrestriction.


