NINGBO CSTAR IMP and EXP 0044 Wireless charger speaker User Manual SL249 7198 64 instruction 7 3
NINGBO CSTAR IMP&EXP; CO., LTD Wireless charger speaker SL249 7198 64 instruction 7 3
User Manual
Metal Bluetooth Speaker
and Wireless Charging Pad
Instruction Manual
1 x Metal Speaker
1 x USB to Micro-USB Charging Cable
1 x Instruction Manual
Playing time: up to 2hrs at max volume
Charging time: up to 1.5hrs
Pairing Name: “Metal Wireless”
(Be sure to fully charge the speaker before
Charging the Speaker
Connect the provided charging cable to a
power source and to the micro USB port on
the speaker (6).
The LED indicator light will glow red when
charging and turn off when fully charged.
Wireless Charging:
Connect speaker to a 2A output with the
provided cable, Wireless Charging LED(4)
will glow red once connected.
Place wireless charging supported mobile
device on top charging pad, LED will glow
green when device is charging.
Phone will begin to charge automatically.
Bluetooth® Setup:
Press and hold Power Button(1) to turn ON
the speaker, Bluetooth LED Indicator(2) will
Turn on the Bluetooth function on
mobile device, Select “Metal Wireless”
pairing name. LED will turn solid BLUE if
successfully paired.
Speaker will automatically pair if the mobile
device has been paired before.
Press and hold Power Button(1) to turn off
the device.
Playing Music:
Short press “Play/Pause” key to pause
music. A second short press will resume
playing music again.
“Vol+/Next track”:
Short press - next track.
Long press - increase volume.
“Vol-/Previous track”:
Short press - previous track
Long press - reduce volume
1.
•
2.
•
•
•
3.
•
•
•
•
4.
•
•
•
1.
2.
3.
4.
5.
6.
7.
8.
•
•
•
Play/Pause/ON/OFF
Bluetooth LED Indicator
Vol +/Next Track
Wireless Charging LED Indicator
Vol-/Previous Track
Micro-USB charging port
Charging LED Indicator
Wireless Charging Pad
What’s included:
Functions:
Instructions:
WARNING-When using this product, basic
precautions should always be followed:
Read all the instructions before use.
Never store or use this product in
temperatures below 32°F(0°C) or above
115°F(45°C).
Do not overcharge Phone. Unit may get
hot with excessive use. Remove Phone
when it is fully charged. Never charge for
more than 7 hours at a time.
The unit’s full performance is achieved
only after 2 or 3 completed charge and
discharge cycles.
To reduce the risk of injury, close
supervision is necessary when the product
is used near children.
Do not expose the device to moisture.
Do not use the device in excess of its
output rating. Overload outputs above
Do not use the device if damaged or
explosion or risk of injury.
Do not disassemble the device. For
professional. Incorrect reassembly may
or temperatures above 104°F may cause
explosion.
use only identical replacement parts to
ensure product safety
•
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
SAFETY PRECAUTIONS:
MADE IN CHINA
SL240
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Note:This equipment has been tested and found to comply with the limits for a class B
digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequence energy and,if not
installed and used in accordance with the instructions,may cause harmful interference to
radio communications.However,there is no guarantee that interference will not accor in a
particular installation.if this equipmemt does cause harmful interference to radio or
television reception,which can be determined by turning the equipment off and on,the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an autlet on a circuit different from that to which the
receiver is connectec.
• Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The devicecan
be used in portable exposure condition without restriction.
