NINGBO DOOYA MECHANIC and ELECTRONIC TECHNOLOGY DC908B DC908B User Manual eDD1520 DD1522 A 00
NINGBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. DC908B eDD1520 DD1522 A 00
Manual
Step 1 To pair a remote to a shade
1. Press and hold the learning buon on the motor unl it jogs and beeps 1 me
2. Press P2 on the remote (shade will jog and beep)
3. Press P2 on the remote (shade will beep)
4. Press the up or down arrow (shade will jog and beep 6 mes)
The remote is now linked to the shade/motor
(NOTE: If shade travels in opposite direcon, PRESS and HOLD learning buon for 2 jogs and 2 beeps
then release. This will reverse motor direcon).
(
2 Channel
Up
Down
Stop
Up + Stop
Together = P2
LESS than 2 sec)
UP DOWN
P2
Channel selecon
15 Channel
1.
2.
3.
Step 2 Limit seng Mode
Press P2 on the remote (shade will jog and beep)
Press the up arrow on the remote (shade will jog and beep)
Press P2 on the remote (shade will jog and beep 4 mes to confirm you are in the limit seng
mode) You can now set the limits
Step 3 Seng Limits
1. Using the up or down buons move the shade to the desired upper or lower posion (for fine
adjustment press P2 while shade is in moon, this will send shade into incremental jogging) press
stop buon when desired limit is reached. Aer correct limit posion is reached, press the stop
buon 5 mes (shade will jog and beep 1 me) indicang that the limit is set.
2. Using the up or down buons move the shade to the desired upper or lower posion (for fine
adjustment press P2 while shade is in moon, this will send shade into incremental jogging) press
stop buon when desired limit is reached). Aer correct limit posion is reached, press the stop
buon 5 mes (shade will jog and beep 1 me) indicang that the limit is set.
3. If limits need to be adjusted aer seng, go back to “limit seng Mode” and follow “seng Limits”
Adding a remote
Start with the remote that currently works with the shade
1. Press P2 on working remote (shade will jog and beep)
2. Press P2 on working remote (shade will jog and beep)
3. Press P2 on remote to add (shade will jog and beep 7 mes)
Controlling mulple shades on a single channel (All day/All night)
1. Locate shade number on controller, press P2 ( shade will jog and beep)
2. Press P2 again (shade will jog and beep)
3. Scroll through channels unl desired “ALL” channel number is reached
4. Press P2 to add control of that shade to the specific channel number (shade will jog and beep 7 mes)
5. Now that shade is controlled with the original channel number and the second “All” channel buon
6. Repeat 1 - 4 above with up to 20 individual motors per channel.
Removing a remote
1. Start with the remote that currently works the shade
2. Press P2 on working remote
3. Press P2 on working remote
4. Press P2 on the remote to delete
Replacing a lost remote
If a shade has been previously programmed but the remote has been lost
1. Press the learning buon on the motor for 1 jog and beep
2. Press the up and down buons on the new remote (shade will jog and beep)
3. The new remote has been added to the shade. The shade will have the same sengs as with the
previous remote.
Adjusng Motor Speed Slow - Standard - Fast
To raise speed, press UP + STOP together, (for 2 channel remote you must press buons for MORE
than 2 sec), motor will jog to confirm
To reduce speed, press DOWN + STOP together, motor will jog to confirm
What Motor Jogs Mean
1. A single jog = To “pair” a remote to a new motor
2. Two jogs = Reverse motor direcon
3. Three jogs = Factory reset
