NINGBO FOREVER ELECTRONIC APPLIANCE AMAS-2618 Remote Control for Mattress Inflation Air Pump User Manual
NINGBO FOREVER ELECTRONIC APPLIANCE CO., LTD. Remote Control for Mattress Inflation Air Pump
user manual
AMAS-2618 Mattress Inflation Air Pump Instruction
一、Brief Introduction
Amas-2618 air mattress pump can adjust hardness degree with the two ways
mattress, so as to achieve the best sleep state. Our product uses the newest wireless remote
control technology, and MCU control technology, easy and convenient operation,
beautiful and lavish in product, it’s an ideal mattress pump.
二、Technical Parameters:
Model: AMAS-2618
Voltage: DC12V /Remote Control:DC 3V
Pressure: 5-60mbar
Flow: 20LPM
Power: 25W
Standby Power：2.5W
Weight：2.3Kg
Contour Dimension：;Length260*Wide155*High105mm
三、Remote Control Diagram:
LCD Display
Inflation
Memory Value
L/R Channel
Deflation
四、Operation Instruction:
1. Pump connected with mattress: Remove dust cover of one corresponding outlet
and connect the mattress.
2.
Power on: Light shows r ed for 30s af ter power is on (Time fo r RC calibrating) .
Pump is in holding state and gets ready when light turns to g reen. Using the RC w hile
LED flashes with green, it means pump is working or transforming data with RC.
3.
Remote control lighted by pr essing any button, LCD shows to work and it g ets
dormancy without any operating in 10s.
4.
Inflation and deflation: Press L/R button to choose the wanted mattress, press
Inflation button, it starts inflating and th e data of LC D shows increasing, when
reaches to t he appropriate pressure, it will stop inflating with pressi ng any key; press
the Deflation button, it starts deflating and the data of LCD shows de creasing, when
reaches to the ap propriate pressure, it will stop deflation when pr ess any butt on; Users
can do the same method to inflate or deflate another mattress by pressing L/R button.
5.
Memory value: press Memory button afte r choosing the wanted mattress, LCD
shows Memory and starts inflating or de flating, once it gets th e memory data it will
stop(reset 25mbar, cut the power of RC it returns to the reset data)
6. Memory save: Press Memory button for 3s in the data showing state when the RC
flashes or stops working, LCD shows “Memory” and flas h to “Save”, d ata will be
memorized and saved as a new one. Use the same method to another.
五、Pay attention:
1.This RC can control 5 to 10 meters, it shows
“
Er
”
when out of the distance, please
use
it in its range.
2. Restart the remote co ntrol coding: This remote control and pump ar e coded be fore
leaving the factory, when RC needs a replacem ent that requires use r to calib rate the
code. Method as follows: Connect the pow er and during the 30s w hen light shows red,
please press any button the RC lighted. Next st ep is pres s Memory button first then
press L/R button for 3S, and LCD will show SU, it means coded successfully.
3. Two AAA-LR03-1.5V batteries are fitted for this RC; LCD will show the signal of i ts
low power and please change the batteries in time to avoid damage. Without any using in
the long time please remove out the batteries.
FCC Statement:
This equipment has been tested and found to comply with the lim its for Part 15 of the
FCC rules. These lim its are designed to pr ovide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) This device m ay not cause harmful interference, and (2) this devic e
must accept any interference received, including interference that m ay cause undesired
operation.
Note: Modifications to this product will vo id the u ser’s authority to oper ate this
equipment.
