NVIDIA Corporation WLAN 2x2 MIMO 802.11a/b/g/n/ac with Bluetooth P3310 Integration Notes

Contents

P3310_Integration_Notes

Regulatory Module Integration Instructions
This module has been granted modular approval for mobile applications. OEM integrators for host
products may use the module in their final products without additional FCC / ISED (Innovation,
Science and Economic Development Canada) certification if they meet the following conditions.
Otherwise, additional FCC / ISED approvals must be obtained.
• The host product with the module installed must be evaluated for simultaneous
transmission requirements.
• The users manual for the host product must clearly indicate the operating requirements
and conditions that must be observed to ensure compliance with current FCC / ISED RF
exposure guidelines.
• To comply with FCC / ISED regulations limiting both maximum RF output power and
human exposure to RF radiation, the maximum antenna gain including cable loss in a
mobile-only exposure condition must not exceed the following:
Peak Antenna Gain
Frequency(GHz) 2.4 2.44 2.48 5.2 5.3 5.5 5.6 5.8
Gain(dBi) 2.41 2.81 2.86 5.49 5.57 4.81 4.84 1.99
Antenna Manufacturer: Pulse, Part Number: CW1043, Type: Dipole
Antenna Cable Loss
Frequency(GHz) 2.4 2.44 2.48 5.2 5.3 5.5 5.6 5.8
Cable Loss (dBm) 0.9 0.9 0.9 2 2 2 2 2
Cable Manufacturer : Pulse, part number: CW9009
• Any device incorporating this module must include an external, visible, permanent
marking or label which states:
Contains FCC ID: VOB-P3310
Contains IC: 7361A-P3310
The final host / module combination may also need to be evaluated against the FCC Part 15B
criteria for unintentional radiators in order to be properly authorized for operation as a Part 15
digital device.
If the final host / module combination is intended for use as a portable device (see classifications
below) the host manufacturer is responsible for separate approvals for the SAR requirements
from FCC Part 2.1093 and RSS-102.
Note: In the case where the Host / Module combination has been re-certified the FCC ID shall
appear in the product manual.
NVIDIA Module Integration Instructions
Rev. 04 January 2017
Page 2 of 6
Device Classifications
Since host devices vary widely with design features and configurations module integrators shall
follow the guidelines below regarding device classification and simultaneous transmission, and
seek guidance from their preferred regulatory test lab to determine how regulatory guidelines will
impact the device compliance. Proactive management of the regulatory process will minimize
unexpected schedule delays and costs due to unplanned testing activities.
The module integrator must determine the minimum distance required between their host device
and the user’s body. The FCC provides device classification definitions to assist in making the
correct determination. Note that these classifications are guidelines only; strict adherence to a
device classification may not satisfy the regulatory requirement as near-body device design
details may vary widely. Your preferred test lab will be able to assist in determining the
appropriate device category for your host product and if a KDB or PBA must be submitted to the
FCC.
Note, the module you are using has been granted modular approval for mobile applications.
Portable applications may require further RF exposure (SAR) evaluations. It is also likely that the
host / module combination will need to undergo testing for FCC Part 15 regardless of the device
classification. Your preferred test lab will be able to assist in determining the exact tests which
are required on the host / module combination.
It is the responsibility of the manufacturer of the final product to verify whether or not further
standards, recommendations or directives are in force
FCC Definitions
Portable: (§2.1093) — A portable device is defined as a transmitting device designed to be used
so that the radiating structure(s) of the device is / are within 20 centimeters of the body of the
user.
Mobile: (§2.1091) (b) — A mobile device is defined as a transmitting device designed to be used
in other than fixed locations and to generally be used in such a way that a separation distance of
at least 20 centimeters is normally maintained between the transmitter’s radiating structure(s) and
the body of the user or nearby persons. Per §2.1091d(d)(4) In some cases (for example, modular
or desktop transmitters), the potential conditions of use of a device may not allow easy
classification of that device as either Mobile or Portable. In these cases, applicants are
responsible for determining minimum distances for compliance for the intended use and
installation of the device based on evaluation of either specific absorption rate (SAR), field
strength, or power density, whichever is most appropriate.
NVIDIA Module Integration Instructions
Rev. 04 January 2017
Page 3 of 6
Simultaneous Transmission Evaluation
Any simultaneous transmission condition established through module integration into a host
product must be evaluated per the requirements in KDB447498 and KDB616217 (for laptop,
notebook, netbook, and tablet applications).
These requirements include, but are not limited to:
• Transmitters and modules certified for mobile or portable exposure conditions can be
incorporated in mobile host devices without further testing or certification when:
• The closest separation among all simultaneous transmitting antennas is >20 cm,
Or
• Antenna separation distance and MPE compliance requirements for ALL simultaneous
transmitting antennas have been specified in the application filing of at least one of the
certified transmitters within the host device. In addition, when transmitters certified for
portable use are incorporated in a mobile host device, the antenna(s) must be >5 cm
from all other simultaneous transmitting antennas.
• All antennas in the final product must be at least 20 cm from users and nearby persons.
NVIDIA Module Integration Instructions
Rev. 04 January 2017
Page 4 of 6
OEM Instruction Manual Content
Consistent with §2.909(a), the following text must be included within the user’s manual or
operator instruction guide for the final commercial product. OEM-specific content is displayed in
bold-italics.
Operating Requirements and Conditions:
The design of (Product Name) complies with U.S. Federal Communications Commission (FCC)
guidelines respecting safety levels of radio frequency (RF) exposure for (OEM manufacturer to
insert device classification: Mobile or Portable) devices.
FCC ID:
This product contains FCC ID: (Include FCCID of the Module)
Note: In the case where the Host / Module combination has been re-certified the FCCID shall
appear in the product manual as follows:
FCC ID: (Include Standalone FCC ID)
Mobile Device RF Exposure Statement (If Applicable):
RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
Only those antennas with same type and lesser/equal gain filed under this FCC ID number can
be used with this device.
Portable Device RF Exposure Statement (If Applicable):
RF Exposure - This device has been tested for compliance with FCC RF exposure limits in a
portable configuration. At least (Insert Required Separation Distance from RF Exposure
Evaluation) cm of separation distance between the (Product Name) device and the user's body
must be maintained at all times. This device must not be used with any other antenna or
transmitter that has not been approved to operate in conjunction with this device.
Caution Statement for Modifications:
CAUTION: Any changes or modifications not expressly approved by (Company Name) could
void the user’s authority to operate the equipment.
FCC Part 15 Statement (Only Include if FCC Part 15 is Required on the End Product):
Note: This equipment has been tested and found to comply with the limits for a (OEM to insert
device type: Class A or Class B) digital device, pursuant to Part 15 of the FCC Rules.
OEM must follow Part 15 guidelines (§15.105 and §15.19) to determine additional statements
required in this section for their device class.
NVIDIA Module Integration Instructions
Rev. 04 January 2017
Page 5 of 6
Consistent with Innovation, Science and Economic Development Canada RSS_GEN and RSS-
247, the following text must be included within the user’s manual or operator instruction guide for
the final commercial product. The content must be provided in both English and French OEM-
specific content is displayed in bold-italics. The content below does NOT contain certified
translations.
Operating Requirements and Conditions:
This radio transmitter (identify the device by certification number or model number if
Category II) has been approved by Innovation, Science and Economic Development Canada to
operate with the antenna types listed below with the maximum permissible gain indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for
that type, are strictly prohibited for use with this device.
Le présent émetteur radio (identifier le dispositif par son numéro de certification) a été
approuvé par Innovation, Sciences et Développement économique Canada pour fonctionner avec
les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal. Les types
d'antenne non inclus dans cette liste, et dont le gain est supérieur au gain maximal indiqué, sont
strictement interdits pour l'exploitation de l'émetteur.
list of all antenna types approved for use with the transmitter, indicating the maximum
permissible antenna gain (in dBi).
the device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential
for harmful interference to co-channel mobile satellite systems.
les dispositifs fonctionnant dans la bande de 5 150 à 5 250 MHz sont réservés uniquement pour
une utilisation à l'intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux;
Note: high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-
5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to
LE-LAN devices.
Remarque: les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-
à-d., qu'ils ont la priorité) des bandes de 5 250 à 5 350 MHz et de 5 650 à 5 850 MHz et ces
radars pourraient causer du brouillage et/ou des dommages aux dispositifs de RL-EL.
ISED ID:
This product Contains IC: (Include IC ID of the Module)
Note: In the case where the Host / Module combination has been re-certified the ID shall appear
in the product manual as follows:
IC: (Include Standalone IC ID)
NVIDIA Module Integration Instructions
Rev. 04 January 2017
Page 6 of 6
Mobile Device RF Exposure Statement (If Applicable):
RF Radiation Exposure Statement
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
Déclaration d'exposition aux radiations:
Cet appareil est conforme aux limites d'exposition aux rayonnements définies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé à une distance minimale
de 20 centimètres entre le radiateur et votre corps.
Portable Device RF Exposure Statement (If Applicable):
RF Radiation Exposure Statement
This device has been tested for compliance with ISED RSS 102 RF exposure limits in a portable
configuration. At least (Insert Required Separation Distance from RF Exposure Evaluation)
cm of separation distance between the radiating elements and the user's body must be
maintained at all times. This device must not be used with any other antenna or transmitter that
has not been approved to operate in conjunction with this device.
Déclaration d'exposition aux radiations:
Ce dispositif a été testé pour la conformité avec ISED RSS 102 limites d'exposition aux RF dans
une configuration portable. Au moins (Insérer requis Séparation Distance de RF évaluation de
l'exposition) cm de distance de séparation entre les éléments rayonnants et le corps de
l'utilisateur doit être maintenu en tout temps. Ce dispositif ne doit pas être utilisé avec une autre
antenne ou émetteur qui n'a pas été approuvé pour fonctionner en combinaison avec cet
appareil.
ISED RSS-Gen Statement:
This device complies with Innovation, Science and Economic Development Canada license-
exempt RSSs.. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR Innovation, Sciences et Développement économique
Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
