National Electronics and Watch M16-470DBSG Smart Wristband with Optical Heart Rate User Manual Print
National Electronics & Watch Co., Ltd Smart Wristband with Optical Heart Rate Print
Users Manual
User Manual
National Electronics & Watch Co, Ltd.
WARNING
Thank you for purchasing the Healthy Life Style™ Smart Watch
Activity Tracker using OLED display. Healthy Life Style™ Smart
Watch Activity Tracker tracks your Exercise, Calories, Heart Rate,
Sleep, Steps, Distance, and Time. It can also send an alert to
your phone to locate the phone and noties you of new messag-
es and calls.
Please read these instructions in full before you start operating
the Healthy Life Style™ Smart Watch Activity Tracker.
Charging battery to PC
1. Plug your USB cable to your PC.
2. Align the charging clip with the contacts on the back of your device.
3. Connect the charging clip securely to the device.
Important notice
Charge the Healthy Life Style™ Smart Watch Activity Tracker for
at least 3-4 hours before rst use and immediately charge when
the battery level is at 20% to maximize the battery life. It is also
recommended to regularly re-charge your Healthy Life Style™
Smart Watch Activity Tracker once a month even if it is not used
to maintain good battery condition. Please thoroughly dry the
charging contacts and surrounding area to ensure proper elec-
trical contact and prevent corrosion.
This is NOT a medical device. Consult your doctor before you
begin any new exercise program. This is important for those
with pre-existing health problems or those who are taking
medication regularly. This Healthy Life Style™ Smart Watch
Activity Tracker may aect pacemakers. If you have any con-
cerns, consult your doctor before use. Over exercising may
result in serious injury or death. If you feel faint or become
short of breath, or if you experience pain while exercising,
stop immediately and call your doctor.
Introduction
Unwanted scenario
Pairing
How to operate with Healthy Life Style™ Smart Watch
Activity Tracker
Healthy Life Style™ Smart Watch Activity Tracker basics
Note:
Holding the S button for more than 10 sec. will reset the watch
and will cause you to lose your previously stored exercise data.
Unpairing
10:0012-1280%
SUN
10:00 12-1280%
SUN 115A
S button
Interactive display
3”
10:00 12-12
SUN
10:0012-1280%
SUN
PAIR
HOLD TO
PAIR 115A
PAIR 115A
PAIR OK
On starting mode press S button and hold
10:00 12-1280%
SUN 115A
PAIR
HOLD TO
Release S button once
PAIR starts blinking
Your device is
successfully paired
10:00 12-12
SUN 115A
OFF
HOLD TO
OFF 115A
On starting mode press S button and hold
On HRM mode wait
for the HEART icon
Release S button once
PAIR starts blinking
Your device is
successfully unpaired
Release S button once
PAIR starts blinking
10:00 12-1280%
SUN
10:00 12-1280%
SUN
PAIR X
Your device is not
paired yet so try again
Make sure Bluetooth on your phone is turned on
On starting mode press S button and hold
All modes on interactive display
10:00 12-1280%
SUN
Start mode Auto modes
(rotates automatically)
Browsing modes
(use S button for
switching)
FIND mode is visible
only when devices
are paired.
14550 STEPS
1550 KCAL
10.20 KM
80%
0
CALLS
INCOMING
0
MESSAGE
INCOMING
HRM
WORKOUT
SLEEP
FIND
Heart Rate Monitor
BPM
--%
Continue waiting until
you see the result
How to properly wear the device:
1. Fasten the device snugly so that the optical sensor is in contact
with your skin.
2. Wear the device above your wrist bone.
3. If the Heart rate data displayed in the band is not stable or erratic,
move the device along your forearm to the best wearing position
as shown.
Before starting your exercise:
• While measuring HR, minimize wrist movement.
• Make sure the heart rate data is stable.
• You may need to tighten the strap, especially after sweating for
a more accurate measurement.
Water Resistance
This device is an IPX7 standard.
Battery Charge
The device is powered by a built-in lithium-ion battery. It can be
charged using the USB port and it takes approx. 2 hours to fully
charge the battery. Please charge the device before using and
never allow it to reach empty.
Press S button from OFF screen to show the battery power level
during charging period.
Battery Life
Battery power will last for 7 days on a single charge this will
vary depending on on the customer's frequent use of the vibration
alert, such as incoming phone calls and text messages.
The battery on this device is not User replaceable.
HRM --- 72 BPM
32%
On SLEEP mode just
wait for a moment
This function will locate your Smartphone that it is paired via
Bluetooth. To nd your device, please note that Healthy Life Style™
App must be open in the background
Sleep
To bed
Hold S button to
turn on this mode
TO BED mode is ON
SLEEP TO BED z
z
Workout
Start
Stop
On WORKOUT mode
wait for the timer
Press S button and
hold for 2 sec. to start
Timer started
WORKOUT 00:00:00 00:00:01
On WORKOUT mode
wait for the timer
Press S button and
hold for 2 sec. to stop
Timer stopped
WORKOUT 00:01:19 00:01:20
Save
On WORKOUT mode
wait forthe timer
Press S button and
hold for 2 sec. to save
Result saved
(start mode is open)
WORKOUT 00:01:20
On SLEEP mode just
wait for a moment
On FIND mode just
wait for a moment
Open the Healthy Life Style™ App
Press the button LINK DEVICE to link your phone with the app
Choose the Healthy Life Style™ Smart Watch Activity Tracker from
the list and press Done. Check the status in top bar of your app.
If the symbol in right top corner appears in green the Bluetooth
connection is successfully established.
Once the WAKE UP is on device will walk you through your sleep
details
Wake up
Hold S button to
turn on this mode
WAKE UP is ON
SLEEP WAKE UP
06:58 01:04 05:54
TOTAL
SLEEP
LIGHT
SLEEP
DEEP
SLEEP
Find the phone
Hold the S button for
2 sec. and release
You will hear the alert
on your phone
10:00 12-12
SUN
Important notice
Don't forget to turn o the timer once you have nished your
workout to preserve battery
FIND
In order to use the Healthy Life Style™ Smart Watch Activity Tracker
you have to have Apple or Android smart phone. Please go to the
App Store or Google Play and search for Healthy Life Style™ App
and install it on your Apple or Android device.
Linking with the App
Green - The Bluetooth connection is established
Red – The Bluetooth connection is not established
Dashed circle – The Bluetooth is connecting
LINK DEVICE
John Doe
GO! 115 A
Speaker
Speaker DoneChoose your device
Please see printed materials for additional information
Desired scenario
See the app to track and monitor your progress
See the app to track and monitor your progress
See the app to track and monitor your sleep
The device has been evaluated to meet general RF exposure requirement, The device can be used
in portable exposure condition without restriction
FCC statements:
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused
by unauthorized modifications or changes to this equipment. Such modifications or
changes could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
‐ Reorient or relocate the receiving antenna.
‐ Increase the separation between the equipment and receiver.
‐Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
‐Consult the dealer or an experienced radio/TV technician for help.
Caution the user that changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
