Netgear Incorporated Home Security Lifestyle Gateway with Zigbee ASG1100

User Manual

Installation Guide
ASG1100 Lifestyle Gateway with ZigBee
Package Contents
Gateway
Ethernet cablePower adapter
Connect the Gateway
1. Verify the package contents.
2. Decide where to place the gateway.
Note: For best WiFi coverage, identify a relatively central location within the
premises. Ensure that the gateway can be conveniently wired to the broadband
router and is close to an AC outlet.
3. Install the gateway in the proper orientation:
Mount vertically if most devices are on the same floor as the gateway.
Place horizontally (after removing the stand) if the devices and gateway
occupy multiple floors.
4. Connect the cables:
a. Connect an Ethernet cable from one of the open ports of the broadband
router to the WAN Ethernet port of the gateway.
b. Pull wires gently to verify that gateway connections are secure.
c. Plug the power cord into the gateway and then plug the power adapter into
an AC outlet.
5. Wait until the Power and Devices LEDs on the gateway become solid green
(this could take a few minutes).
6. To begin the installation process, visit http://www.example.com and use
installer credentials to log in to the Example system.
Horizontal mount
Vertical mount
Broadband routerGateway
March 2013
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of NETGEAR, Inc. and/or its
subsidiaries in the United States and/or other countries. Information is subject to change without notice. © NETGEAR, Inc. All rights reserved.
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134 USA
Technical Specifications
Support
Thank you for selecting NETGEAR products.
After installing your device, locate the serial number on the label of your product and
use it to register your product at https://my.netgear.com.
You must register your product before you can use NETGEAR telephone support.
NETGEAR recommends registering your product through the NETGEAR website.
For product updates and web support, visit http://support.netgear.com.
NETGEAR recommends that you use only the official NETGEAR support resources.
Power adapter • North America (input): 120V, 60 Hz, input
• All regions (output): 12V DC @ 1A output 15W maximum
Physical specifications • Dimensions: 8.5 by 5.75 by 1.3 in. (216 by 146 by 33 mm)
• Weight: 0.95 lb (0.42 kg)
Environmental • Operating temperature: 32° to 104°F (0° to 40°C)
• Operating humidity: 90% maximum relative humidity,
noncondensing
• Electromagnetic emissions:
Meets requirements of FCC Part 15 Class B.
Troubleshooting
Use the LEDs on the front of the gateway to determine its status and to troubleshoot
its operation.
To return the gateway to its factory settings, use the end of a paper clip or some other
similar object to press and hold the Reset button on the back of the gateway for at
least 15 seconds. All four LEDs simultaneously flash amber three times. The gateway
resets and returns to the factory settings.
LED Description
Devices • Solid green: ZigBee sensors are paired with the gateway. No trouble
detected.
Blinking green: The gateway is looking for ZigBee sensors to pair with the
gateway.
•Amber: One or more ZigBee sensors report a trouble condition.
•Off: No ZigBee sensor is paired with the gateway.
WiFi • Solid green: WiFi cameras are connected to the gateway, but are not
currently being viewed.
• Blinking green: WiFi cameras are connected to the gateway and are
currently being viewed.
•Off: No WiFi camera is paired with gateway.
Connection Solid green: The gateway is activated and connected to the service
provider.
• Blinking amber: The gateway is not activated with the service provider
and is not connected to the server, but is connected to the router.
• Solid amber: The gateway is activated with the service provider and is
connected to the router, but is not connected to the server.
•Solid red: The gateway is not connected to the router.
Power Solid green: The gateway is powered on.
Blinking green: A firmware update is in progress. Do not unplug the
gateway.
Off: The gateway is powered off.
FCC Requirements for Operation in the United States
FCC Information to User
This product does not contain any user serviceable components and is to be used with approved antennas only. Any product changes or
modifications will invalidate all applicable regulatory certifications and approvals.
FCC Guidelines for Human Exposure
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance of 20 cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
FCC Declaration of Conformity
We, NETGEAR, Inc., 350 East Plumeria Drive, San Jose, CA 95134, declare under our sole responsibility that the ASG1100 Lifestyle
Gateway with ZigBee complies with Part 15 Subpart B of FCC CFR47 Rules. Operation is subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received, including interference that may cause undesired operation.
FCC Radio Frequency Interference Warnings & Instructions
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. This certification does not guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following methods:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an electrical outlet on a circuit different from that which the radio receiver is connected.
FCC Caution
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
For product available in the USA and Canada market, only channel 1~11 can be operated. Selection of other channels is not
possible. Pour les produits disponibles aux États-Unis / Canada du marché, seul le canal 1 à 11 peuvent être exploités. Sélection
d'autres canaux n'est pas possible.
This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter. Cet
appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une autre antenne ou
transmetteur.
Canadian Department of Communications Radio Interference Regulations
This digital apparatus (ASG1100 Lifestyle Gateway with ZigBee) does not exceed the Class B limits for radio-noise emissions from digital
apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.
This Class [B] digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
Industry Canada
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
IMPORTANT NOTE: Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and
operated with minimum distance 20cm between the radiator & your body.
Caution:
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement
est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout
brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.
NOTE IMPORTANTE: Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement
doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps.
