Contents

User Manual-3

Product External Specifications
For
802.11ac PCI Express Card
Model Number : 11AC-AR9880
Revision: 1.0
ii
Contents
1.0 SCOPE........................................................................................................................................................................... 3
1.1 DOCUMENT................................................................................................................................................................. 3
1.2 PRODUCT FEATURES.................................................................................................................................................. 3
2.0 REQUIREMENTS ....................................................................................................................................................... 3
2.1 GENERAL REQUIREMENTS ........................................................................................................................................ 4
2.2.1 IEEE 802.11a Section.......................................................................................................................................... 4
2.2.2 IEEE 802.11n Section.......................................................................................................................................... 4
2.2.3 IEEE 802.11ac Section........................................................................................................................................ 4
2.2.4 General Section ................................................................................................................................................... 4
2.3 SOFTWARE REQUIREMENTS...................................................................................................................................... 5
2.4 MECHANICAL REQUIREMENTS ................................................................................................................................. 5
2.7 ENVIRONMENTAL REQUIREMENTS ........................................................................................................................... 5
3
1.0 Scope
1.1 Document
This document is to specify the product requirements for 802.11ac PCI Express. This PCI Express card is based on
Qualcomm chip that complied with IEEE 802.11ac from 5GHz, and it is also backward compatible to comply with
IEEE 802.11a and IEEE 802.11n standard.
1.2 Product Features
 3x3 802.11ac or 802.11n 5 GHz Wi-Fi PCIe module
 3x3 MIMO configuration
 20 MHz, 260Mbps peak PHY rate
 40 MHz, 600Mbps peak PHY rate
 80 MHz, 1.3Gbps peak PHY rate in 802.11ac
 Supports WEP, 802.1x, WPA and WPA2 enhanced security
 Friendly user configuration and diagnostic utilities
 Supports PCIe interface .

2.0 Requirements
The following sections identify the detailed requirements of the 802.11ac PCI Express.
4
2.1 General Requirements
2.2.1 IEEE 802.11a Section
Feature Detailed Description
2.2.1.1 Standard  IEEE 802.11a
2.2.1.2 Radio and Modulation
Schemes
 BPSK, QPSK, 16QAM, 64QAM, with OFDM
2.2.1.3 Data Rate  54, 48, 36, 24, 18, 12, 9, and 6 Mbps
2.2.1.4 Media Access Protocol  CSMA/CA with ACK
2.2.2 IEEE 802.11n Section
Feature Detailed Description
2.2.2.1 Standard
IEEE 802.11n
2.2.2.2 Radio and Modulation
Schemes
 BPSK, QPSK, 16QAM, 64QAM with OFDM
2.2.2.3 Data Rate
6.5~300 Mb
p
s
2.2.2.4 Media Access Protocol
CSMA/CA with ACK
2.2.3 IEEE 802.11ac Section
# Feature Detailed Description
2.2.3.1 Standard  IEEE 802.11ac
2.2.3.2 Radio and Modulation
Schemes
 BPSK, QPSK, 16QAM, 64QAM , up to 256QAM with OFDM
2.2. 3.3 Data Rate  6.5~1300 Mbps
2.2. 3.4 Media Access Protocol  CSMA/CA with ACK
2.2.4 General Section
# Feature Detailed Description
2.2.4.1 Antenna Connector
 Three antenna connectors
2.2.4.2 Operating Voltage
 3.3VDC for SOC 4.2VDC for PA
2.2.4.3 Current
Consumption
 4.5W is use on continue TX
2.2.4.4 Form Factor and
Interface
 Mini-card form factor with signal of PCI-e Gen1 X1 lane
5
2.3 Software Requirements
The Configuration Software supports Linux driver. This configuration software includes the following functions:
 Information
Information allows you to monitor network status.
 Configuration
Configuration allows you to configure parameters for wireless networking.
 Security
Supports WEP, WPA-PSK, WPA2-PSK, WPA/WPA2, AES, TKIP and WPS(Wi-Fi Protected Setup)
2.4 Mechanical Requirements
# Feature Detailed Description
2.4.1 Length  50.76 mm (PCB)
2.4.2 Width  50.05mm (PCB)
2.4.3 Height  3.3mm (PCB)
2.7 Environmental Requirements
# Feature Detailed Description
2.7.1 Operating
Temperature
Conditions
 0 ℃ to +40℃.
