350 East Plumeria Drive
San Jose, CA 95134
USA
December 2013
202-11333-01
N300 WiFi Range Extender
WN2000RPT
User Manual
2
N300 WiFi Range Extender WN2000RPT
Support
Thank you for selecting NETGEAR products.
After installing your device, locate the serial number on the label of your product and use it to register your product at
https://my.netgear.com. You must register your product before you can use NETGEAR telephone support. NETGEAR
recommends registering your product through the NETGEAR website. For product updates and web support, visit
http://support.netgear.com.
Phone (US & Canada only): 1-888-NETGEAR.
Phone (Other Countries): Check the list of phone numbers at http://support.netgear.com/general/contact/default.aspx.
Contact your Internet service provider for technical support.
Compliance
For regulatory compliance information, visit http://www.netgear.com/about/regulatory.
See the regulatory compliance document before connecting the power supply.
Trademarks
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of NETGEAR, Inc.
and/or its subsidiaries in the United States and/or other countries. Information is subject to change without notice.
© NETGEAR, Inc. All rights reserved.
3
Table of Contents
Chapter 1 Overview
Unpack Your Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Front Panel LEDs and Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Rear Panel Ports, Buttons, and Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
When to Use Your Extender. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
How the Extender Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 2 Get Started
How to Position the Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Connect the Extender to Your WiFi Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Connect the Extender with WPS to a WiFi Network . . . . . . . . . . . . . . . . . . . . . . 12
Access the Extender over WiFi and Use the Setup Wizard . . . . . . . . . . . . . . . . . 14
Access the Extender over Ethernet and Use the Setup Wizard . . . . . . . . . . . . . 19
Chapter 3 Manage the Extender Network and Security Settings
Log In to the Extender After Initial Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Change the Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Connect the Extender to a WiFi Network Without
Using the NETGEAR genie Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Connect the Extender to a Hidden WiFi Network . . . . . . . . . . . . . . . . . . . . . . . . 31
Use WPS to Add a WiFi Device to the Extender’s WiFi Network . . . . . . . . . . . . 33
Use WPS with the Push Button Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Use WPS with the PIN Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Manage the Extender WiFi Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Configure WPA, WPA2, or WPA + WPA2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Configure WEP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Change the Extender IP Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Manage Advanced WiFi Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Manage a WiFi Access List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Set Up and Enable the Access List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Disable the Access List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Change a Device on the Access List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Remove a Device from the Access List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Run the Setup Wizard Again After Initial Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Connect Ethernet-Enabled Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4
N300 WiFi Range Extender WN2000RPT
Chapter 4 Maintain and Monitor the Extender
Back Up the Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Restore the Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Return the Extender to Its Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . 55
Use the Factory Reset Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Erase the Extender Configuration Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Upgrade the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
View the Status and Traffic Statistics of the Extender . . . . . . . . . . . . . . . . . . . . 58
View the Wired and WiFi Network Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Chapter 5 FAQs and Troubleshooting
FAQs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
You Cannot Connect to the Extender. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
You Cannot Join a WiFi Network and Receive an Error Message . . . . . . . . . . . . 65
Improve the Connection Between the Extender and the WiFi Router . . . . . . . 66
Appendix A Factory Settings and Technical Specifications
Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Technical and Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5
1
1. Overview
This user manual is for the NETGEAR® N300 WiFi Range Extender WN2000RPT, which is
referred to as the extender.
This chapter covers the following topics:
•Unpack Your Extender
•Front Panel LEDs and Button
•Rear Panel Ports, Buttons, and Connector
•When to Use Your Extender
•How the Extender Works
Note: For more information about the topics covered in this manual, visit the
support website at support.netgear.com.
Note: Firmware updates with new features and bug fixes are made
available from time to time on downloadcenter.netgear.com. Some
products can regularly check the site and download new firmware, or
you can check for and download new firmware manually. If the
features or behavior of your product do not match what is described in
this guide, you might need to update your firmware.
Note: In this manual, the terms wireless and WiFi are interchangeable.
Overview
6
N300 WiFi Range Extender WN2000RPT
Unpack Your Extender
Your box contains the following items:
•N300 WiFi Range Extender WN2000RPT
•Power adapter
•Installation guide
Front Panel LEDs and Button
Use the LEDs during installation to find the best location for the extender or to monitor the
extender performance.
Figure 1. Front panel LEDs and Button
The LEDs and button are described in the following table.
Link Rate LED
Extender Status LED
Device to Extender Connection LED
WPS button and LED
Overview
7
N300 WiFi Range Extender WN2000RPT
Table 1. Front panel LEDs and button
LEDs and Button Description
Link Rate LED
Green. The WiFi connection between the extender and the WiFi router is
optimum.
Amber. The WiFi connection between the extender and the WiFi router is good.
Red. The WiFi connection between the extender and the WiFi router is poor.
Off. The extender and the WiFi router do not have a WiFi connection.
Extender Status LED Green. The extender is on.
Amber. The extender starts. After about one minute, the LED lights green.
Off. The extender is off.
Device to Extender
Connection LED Green. The extender is connected to a computer or WiFi device.
Off. The extender is not connected to a computer or WiFi device.
WPS button and
LED The WPS button lets you make the following connections:
• Connect the extender to a WiFi router or access point.
• If the extender is already connected to a WiFi network, connect a WiFi
device to the WiFi network of the extender.
Solid Green. WiFi security is enabled (WPS or WPA2) for the WiFi network of
the extender.
Blinking Green. A WPS connection is in progress.
Off. WiFi security is not enabled for the WiFi network of the extender.
Overview
8
N300 WiFi Range Extender WN2000RPT
Rear Panel Ports, Buttons, and Connector
The following figure shows the ports, buttons, and connector on the rear panel of the
extender. The rear panel also shows the default access information, MAC address, and serial
number of the extender.
Figure 2. Rear panel
When to Use Your Extender
NETGEAR recommends that you connect to the extender only when your existing home
network connection is poor. Data traffic routed through the extender is inherently slower than
traffic routed directly from the network.
NETGEAR recommends that you connect through the extender network only when the WiFi
device is in a “dead zone” where connection from the existing network is poor or nonexistent.
Restore Factory Settings button
Ethernet LAN ports
Power connector
On/Off button
Overview
9
N300 WiFi Range Extender WN2000RPT
How the Extender Works
The extender works like a bridge between a WiFi router (or a WiFi access point) and a WiFi
device outside the range of the WiFi router. The extender has two main jobs:
1. The extender connects to a WiFi network.
When the extender connects over WiFi to an existing network, it functions as a network
client, similar to how a WiFi device connects to a network.
2. The extender acts as an access point for WiFi devices.
The extender has its own WiFi network that WiFi devices can join. In its role as an access
point, the extender performs tasks that WiFi routers do, such as broadcasting its network
name (SSID).
The extender must do each of these jobs so that both ends of the bridge are in place.
Figure 3. Range extender in a home
Extender
WiFi router
WiFi router
The extender is halfway
between the WiFi router
and the WiFi device
WiFi device
outside the
range of the
WiFi router
10
2
2. Get Started
This chapter covers the following topics:
•How to Position the Extender
•Connect the Extender to Your WiFi Router
•Connect the Extender with WPS to a WiFi Network
•Access the Extender over WiFi and Use the Setup Wizard
•Access the Extender over Ethernet and Use the Setup Wizard
Get Started
11
N300 WiFi Range Extender WN2000RPT
How to Position the Extender
The ideal location to place the extender is halfway between your WiFi router and your WiFi
device.
Figure 4. Range extender location
The best connection is established with a clear line of sight between the extender and the
WiFi router and a clear line of sight between the extender and the WiFi device that you are
using. If a thick wall or other materials block this straight path, move the extender to a
different location halfway between the WiFi device and the WiFi router.
When you make the initial connection between the extender and the WiFi router, place the
extender close to the WiFi router. After you have established a connection between the
extender and the WiFi router, move the extender to the location where you intend to use it.
(You might need to unplug the extender, replug it at its new location, and restart it.) Use the
Link Rate LEDs on the extender to choose the location where the connection between the
extender and the WiFi router is optimal. These steps are described in detail in the following
sections.
Connect the Extender to Your WiFi Router
To connect the extender to your WiFi router and find the best location, use one of the
following methods:
•WPS. Use the extender’s WPS button to establish a WiFi connection between the
extender and the WiFi router (see Connect the Extender with WPS to a WiFi Network).
Use this method if your WiFi router supports Wi-Fi Protected Setup (WPS).
•WiFi. Use a computer or WiFi device to join the extender’s default WiFi network, then
launch a web browser to set up the connection between the extender and a WiFi network
(see Access the Extender over WiFi and Use the Setup Wizard). Use this method if your
WiFi router does not support WPS.
•Ethernet. Use an Ethernet cable to connect a computer to the extender, then launch a
web browser to set up the connection between the extender and a WiFi network (see
Access the Extender over Ethernet and Use the Setup Wizard). Use this method if you
have difficulty establishing a WiFi connection to the extender.
Get Started
12
N300 WiFi Range Extender WN2000RPT
Connect the Extender with WPS to a WiFi Network
The easiest way to connect the extender to a WiFi network is by using Wi-Fi Protected Setup
(WPS). For this method to be successful, your WiFi router must support WPS.
If your WiFi router does not support WPS, see one of the following sections:
•Access the Extender over WiFi and Use the Setup Wizard on page 14
•Access the Extender over Ethernet and Use the Setup Wizard on page 19
WPS lets you join a secure WiFi network without typing the network name and password.
The WPS button is a physical button on the front panel of the extender. For more information
about the WPS button and LED of the extender, see Front Panel LEDs and Button on page 6.
Your WiFi router might have a physical WPS button, a software WPS button, or both.
WPS does not support WEP network security. If you are using WEP security, follow the
instructions in Access the Extender over WiFi and Use the Setup Wizard on page 14.
To connect the extender with WPS to a WiFi router:
1. Place the extender close to the WiFi router.
Note: In a later step in this procedure, after you have established a connection
to the WiFi router, you can place the extender at its permanent location.
2. Plug the extender into an electrical outlet.
3. If necessary, press the Power button.
The Status LED lights green.
You are now ready to connect the extender to your WiFi router.
4. Press the WPS button on the extender.
5. Within two minutes, press the WPS button on your WiFi router.
After a few seconds, the extender connects to your existing WiFi network. Because you
placed the extender close to the WiFi router, the Link Rate LED on the extender
lights green, indicating a good connection between the WiFi router and the extender.
If the Link Rate LED does not light green, try Step 4 and Step 5 again. If it still does not
light green, see Access the Extender over WiFi and Use the Setup Wizard.
6. Now that the extender is connected to the WiFi router, move it to a location where you can
boost your WiFi range.
The location you choose must be within the range of your existing WiFi router network.
7. Plug the extender into an electrical outlet at the new location and restart the extender.
Unless the extender is outside the range of your WiFi router, the extender connects
automatically to the WiFi router.
Get Started
13
N300 WiFi Range Extender WN2000RPT
The Link Rate LED help you choose a spot where the extender-to-router connection is
optimal. The following tables describe how the LEDs show the quality of the connection.
If the Link Rate LED is off, the extender cannot connect to the WiFi router. If the Link Rate
LED is red, the extender has a poor connection to the WiFi router.
8. If the extender has no connection or a poor connection, move the extender closer to your
WiFi router and try again until the Link Rate LED is green, or at least amber.
9. Use a WiFi network manager on the computer or mobile device to connect to the extender’s
newly created WiFi network. The extender’s default NETGEAR_EXT WiFi network name
(SSID) changes to the name of your existing WiFi network, with _EXT at the end of the
name, for example:
•Existing network name. MyNetworkName
•New extender network name. MyNetworkName_EXT
10. Select the new network and use your WiFi router password to connect.
You are now using your extended WiFi network.
Note: If your computer or mobile device cannot join the new WiFi network of
the extender, see You Cannot Join a WiFi Network and Receive an
Error Message on page 65.
LED Status LED Color Performance
Both the Link Rate LED and the Device
to Extender Connection LED are green. and The extender provides the best performance.
The Link Rate LED is amber and the
Device to Extender Connection LED is
green.
and The extender provides a workable performance.
The Link Rate LED is red. The extender provides a poor performance.
The Link Rate LED is off. The extender cannot function.
Get Started
14
N300 WiFi Range Extender WN2000RPT
Access the Extender over WiFi and Use the Setup Wizard
If your WiFi router does not support WPS, access the extender over WiFi and use the
browser-based NETGEAR genie® Setup Wizard to connect the extender to an existing WiFi
network.
The extender has a default NETGEAR_EXT WiFi network name (SSID) so you can access it
over WiFi. After you have used the Setup Wizard to connect the extender to an existing WiFi
network, the extender changes its default NETGEAR_EXT network name to the name of the
existing WiFi network and adds _EXT at the end of the name, for example:
•Existing network name. MyNetworkName
•New extender network name. MyNetworkName_EXT
Access the extender over WiFi and use the Setup Wizard to connect the extender to an
existing WiFi network:
1. Place the extender close to the WiFi router.
Note: In a later step in this procedure, after you have established a connection
to the WiFi router, you can place the extender at its permanent location.
2. Plug the extender into an electrical outlet.
3. If necessary, press the Power button.
The Status LED lights green.
4. Make sure that your computer or mobile device is not connected to a WiFi network or
Ethernet network.
If the computer or mobile device is already connected to a network, you might not be able
to connect to the extender.
5. Open a WiFi network manager on your computer or mobile device to find and connect to the
NETGEAR_EXT WiFi network of the extender.
You can use any WiFi network utility on a computer, tablet, or smartphone to find and
connect to the NETGEAR_EXT WiFi network of the extender. The following figure shows
an example of a WiFi network utility.
Get Started
15
N300 WiFi Range Extender WN2000RPT
After the connection with the computer or mobile device is established, the Device to
Extender Connection LED lights solid green.
6. Open a web browser window from the same computer or mobile device.
The browser takes you directly to the NETGEAR genie Setup Wizard start screen.
Note: If you are not automatically directed to NETGEAR genie Setup Wizard
start screen, go to www.mywifiext.net, and enter admin for the user
name and password for the password.
7. Under Do you want NETGEAR Genie to help?, select the Yes radio button, and click the
Next button.
NETGEAR genie searches for WiFi networks automatically.
Get Started
16
N300 WiFi Range Extender WN2000RPT
8. Select a WiFi network to extend, and click the Continue button.
9. Type the network passphrase (also called a password or network key) in the PassPhrase
field, and click the Continue button.
10. Use the default extension name, or, in the 2.4GHz Network Name (SSID) field, enter a new
network name for your extender WiFi network, and click the Continue button.
Get Started
17
N300 WiFi Range Extender WN2000RPT
The extender applies the settings.
11. Wait about two minutes while the extender creates the WiFi network.
12. Use a WiFi network manager on the computer or mobile device to connect to the extender’s
newly created WiFi network.
Note: Unless you entered a new network name in Step 10, the extender
changes its default NETGEAR_EXT network name to the name of the
WiFi network to which you connected the extender and adds _EXT at
the end of the name.
Note: If your computer or mobile device cannot join the new WiFi network of
the extender, see You Cannot Join a WiFi Network and Receive an
Error Message on page 65.
13. Select the My wireless devices are connected to the Extender network check box, and
click the Continue button.
Get Started
18
N300 WiFi Range Extender WN2000RPT
The next screen that displays describes the color of the Link Rate LED, which
corresponds to the color of the LED on the front of the extender. Because you placed the
extender close the WiFi router, the Link Rate LED is green.
14. Click the Finish button.
A pop-up screen displays.
15. To bookmark the URL of the extender, click the OK button.
A NETGEAR website displays. You are now online.
16. Now that the extender is connected to the WiFi router and you can connect a computer or
mobile device to the extender’s WiFi network, move it to a location where you can boost
your WiFi range.
The location you choose must be within the range of your existing WiFi router network.
17. Plug the extender into an electrical outlet at the new location and restart the extender.
Unless the extender is outside the range of your WiFi router, the extender connects
automatically to the WiFi router.
The Link Rate LEDs help you choose a spot where the extender-to-router connection is
optimal. The following tables describe how the LEDs show the quality of the connection.
If the Link Rate LED is off, the extender cannot connect to the WiFi router. If the Link Rate
LED is red, the extender has a poor connection to the WiFi router.
18. If the extender has no connection or a poor connection, move the extender closer to your
WiFi router and try again until the Link Rate LED is green, or at least amber.
LED Status LED Color Performance
Both the Link Rate LED and the Device
to Extender Connection LED are green. and The extender provides the best performance.
The Link Rate LED is amber and the
Device to Extender Connection LED is
green.
and The extender provides a workable performance.
The Link Rate LED is red. The extender provides a poor performance.
The Link Rate LED is off. The extender cannot function.
Get Started
19
N300 WiFi Range Extender WN2000RPT
19. Use a WiFi network manager on the computer or mobile device to reconnect to the
extender’s WiFi network.
Note: Unless you entered a new network name in Step 10, the extender
changes its default NETGEAR_EXT network name to the name of the
WiFi network to which you connected the extender and adds _EXT at
the end of the name.
20. Select the new network and use your WiFi router password to connect.
You are now using your extended WiFi network.
Access the Extender over Ethernet and Use the Setup
Wizard
If your WiFi router does not support WPS, you can use an Ethernet cable to connect your
computer to one of the LAN ports of the extender. Then use the browser-based NETGEAR
genie® Setup Wizard to connect the extender to an existing WiFi network.
After you have used the Setup Wizard to connect the extender to an existing WiFi network,
the extender changes its default NETGEAR_EXT WiFi network name (SSID) to the name of
the existing WiFi network and adds _EXT at the end of the name, for example:
•Existing network name. MyNetworkName
•New extender network name. MyNetworkName_EXT
Note: After you have set up the extender, you can also connect
Ethernet-enabled devices such as gaming consoles and printers to
the Ethernet LAN ports of the extender. For more information, see
Connect Ethernet-Enabled Devices on page 51.
Access the extender over Ethernet and use the Setup Wizard to connect the extender
to an existing WiFi network:
1. Place the extender close to the WiFi router.
Note: In a later step in this procedure, after you have established a connection
to the WiFi router, you can place the extender at its permanent location.
2. Plug the extender into an electrical outlet.
3. If necessary, press the Power button.
The Status LED lights green.
4. Make sure that your computer or mobile device is not connected to a WiFi network or
Ethernet network.
Get Started
20
N300 WiFi Range Extender WN2000RPT
If the computer or mobile device is already connected to a network, you might not be able
to connect to the extender.
5. Connect your computer to the extender with an Ethernet cable. You can use any of the four
Ethernet LAN ports of the extender.
CAUTION:
Do not use Ethernet cable to connect the extender to a WiFi router. If you
do so, the extender does not work because it is designed to use only a
WiFi connection to a WiFi router.
6. If you have trouble connecting, try the following:
•Wait a couple of minutes.
If you start your computer, connect the Ethernet cable to the extender, and launch
your browser quickly, the computer might still need a couple of minutes to recognize
the Ethernet LAN connection before you can connect.
•Make sure that your Ethernet cable is securely connected to the extender and the
computer, and that the extender Device to Extender Connection LED lights.
If the LED is not lit, reconnect the Ethernet cable, and relaunch your Internet browser.
7. Open a web browser window from the same computer or mobile device.
The browser takes you directly to the NETGEAR genie Setup Wizard start screen.
Note: If you are not automatically directed to NETGEAR genie Setup Wizard
start screen, go to www.mywifiext.net, and enter admin for the user
name and password for the password.
Get Started
21
N300 WiFi Range Extender WN2000RPT
8. Under Do you want NETGEAR Genie to help?, select the Yes radio button, and click the
Next button.
NETGEAR genie searches for WiFi networks automatically.
9. Select a WiFi network to extend, and click the Continue button.
10. Type the network passphrase (also called a password or network key) in the PassPhrase
field, and click the Continue button.
Get Started
22
N300 WiFi Range Extender WN2000RPT
11. Use the default extension name, or, in the 2.4GHz Network Name (SSID) field, enter a new
network name for your extender WiFi network, and click the Continue button.
The extender applies the settings.
12. Wait about two minutes while the extender creates the WiFi network.
13. Use a WiFi network manager on the computer or mobile device to connect to the extender’s
newly created WiFi network.
Note: Unless you entered a new network name in Step 11, the extender
changes its default NETGEAR_EXT network name to the name of the
WiFi network to which you connected the extender and adds _EXT at
the end of the name.
Note: If your computer or mobile device cannot join the new WiFi network of
the extender, see You Cannot Join a WiFi Network and Receive an
Error Message on page 65.
14. Select the My wireless devices are connected to the Extender network check box, and
click the Continue button.
Get Started
23
N300 WiFi Range Extender WN2000RPT
The next screen that displays describes the color of the Link Rate LED, which
corresponds to the color of the LED on the front of the extender. Because you placed the
extender close the WiFi router, the Link Rate LED is green.
15. Click the Finish button.
A pop-up screen displays.
16. To bookmark the URL of the extender, click the OK button.
A NETGEAR website displays. You are now online.
17. Disconnect the Ethernet cable from the computer and the extender.
18. Now that the extender is connected to the WiFi router and you can connect a computer or
mobile device to the extender’s WiFi network, move it to a location where you can boost
your WiFi range.
The location you choose must be within the range of your existing WiFi router network.
19. Plug the extender into an electrical outlet at the new location and restart the extender.
Unless the extender is outside the range of your WiFi router, the extender connects
automatically to the WiFi router.
Get Started
24
N300 WiFi Range Extender WN2000RPT
The Link Rate LEDs help you choose a spot where the extender-to-router connection is
optimal. The following tables describe how the LEDs show the quality of the connection.
If the Link Rate LED is off, the extender cannot connect to the WiFi router. If the Link Rate
LED is red, the extender has a poor connection to the WiFi router.
20. If the extender has no connection or a poor connection, move the extender closer to your
WiFi router and try again until the Link Rate LED is green, or at least amber.
21. Use a WiFi network manager on the computer or mobile device to reconnect to the
extender’s WiFi network.
Note: Unless you entered a new network name in Step 11, the extender
changes its default NETGEAR_EXT network name to the name of the
WiFi network to which you connected the extender and adds _EXT at
the end of the name.
22. Select the new network and use your WiFi router password to connect.
You are now using your extended WiFi network.
LED Status LED Color Performance
Both the Link Rate LED and the Device
to Extender Connection LED are green. and The extender provides the best performance.
The Link Rate LED is amber and the
Device to Extender Connection LED is
green.
and The extender provides a workable performance.
The Link Rate LED is red. The extender provides a poor performance.
The Link Rate LED is off. The extender cannot function.
25
3
3. Manage the Extender Network and
Security Settings
This chapter covers the following topics:
•Log In to the Extender After Initial Setup
•Change the Password
•Connect the Extender to a WiFi Network Without Using the NETGEAR genie Setup
Wizard
•Connect the Extender to a Hidden WiFi Network
•Use WPS to Add a WiFi Device to the Extender’s WiFi Network
•Manage the Extender WiFi Settings
•Change the Extender IP Address
•Manage Advanced WiFi Settings
•Manage a WiFi Access List
•Run the Setup Wizard Again After Initial Setup
•Connect Ethernet-Enabled Devices
Manage the Extender Network and Security Settings
26
N300 WiFi Range Extender WN2000RPT
Log In to the Extender After Initial Setup
You can log in to the extender to view or change the extender’s settings.
If you connect to the extender before it has been set up, the browser automatically goes to
www.mywifiext.net and displays the NETGEAR genie screens that step you through the
setup process. For more information, see Access the Extender over WiFi and Use the Setup
Wizard on page 14 or Access the Extender over Ethernet and Use the Setup Wizard on
page 19.
To log in to the extender after initial setup:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and password for the password.
Note: NETGEAR recommends that you set a more secure password after
you log in. For more information, see Change the Password on
page 27.
If your extender has an Internet connection, the following screen displays and the
extender automatically checks for new firmware at the NETGEAR website.
For more information about upgrading firmware, see Upgrade the Firmware on page 56.
The Status screen displays. Menu selections display on the left. The Status screen shows
the current settings for the extender.
Manage the Extender Network and Security Settings
27
N300 WiFi Range Extender WN2000RPT
For more information about the Status screen, see View the Status and Traffic Statistics
of the Extender on page 58.
4. To change your language, select a language from the menu in the top right of the screen.
By default, the language selection is Auto, which means that the extender uses the
language that it detects from the browser that you use.
Change the Password
The user name to access the extender is admin, and its default password is password.
NETGEAR strongly recommends that you set a more secure password.
To change the password for the extender:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
Manage the Extender Network and Security Settings
28
N300 WiFi Range Extender WN2000RPT
3. Type admin for the user name and password for the password.
If you already changed the password and want to change it again, type your personalized
password.
4. Select Maintenance > Set Password.
5. Type the old password.
6. Type the new password twice.
7. Click the Apply button.
Your settings are saved.
Connect the Extender to a WiFi Network Without
Using the NETGEAR genie Setup Wizard
If the extender is not yet connected to a WiFi network or you want to change the connection
to another WiFi network, you can connect the extender to a WiFi network without using the
NETGEAR genie Setup Wizard.
To connect the extender to a WiFi network without using the NETGEAR genie Setup
Wizard:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Setup > Connect to an Existing Network.
The extender scans for WiFi networks and displays a list.
Manage the Extender Network and Security Settings
29
N300 WiFi Range Extender WN2000RPT
If your WiFi network is functioning but not on the list, your WiFi network might be hidden,
or the connection between the WiFi router and the extender might be poor. For more
information, see the following sections:
•Connect the Extender to a Hidden WiFi Network on page 31
•Improve the Connection Between the Extender and the WiFi Router on page 66
5. Select the radio button for the network to which you want to connect the extender, and click
the Continue button.
6. In the Passphrase field, enter the passphrase or key for the WiFi network, or, if your WiFi
network uses WEP, enter the key in the Security Encryption (WEP) Key field, and click the
Continue button.
7. Use the default extension name, or, in the 2.4GHz Network Name (SSID) field, enter a new
network name for your extender WiFi network.
Manage the Extender Network and Security Settings
30
N300 WiFi Range Extender WN2000RPT
8. To specify security settings for the extender WiFi network that are different from the WiFi
network of the WiFi router, clear the check box.
The screen adjusts and lets you select security settings. For more information about WiFi
security options, see Manage the Extender WiFi Settings on page 36.
9. Click the Continue button.
10. Wait about two minutes while the extender creates the WiFi network.
11. Use a WiFi network manager on the computer or on a mobile device to connect to the
extender’s newly created WiFi network.
Note: Unless you entered a new network name in Step 7, the extender uses
the network name of the WiFi network to which you connected the
extender and adds _EXT at the end of the name.
Note: If your computer or mobile device cannot join the new WiFi network of
the extender, see You Cannot Join a WiFi Network and Receive an
Error Message on page 65.
12. Select the My wireless devices are connected to the Extender network check box, and
click the Continue button.
The new WiFi network settings for the extender are saved and the Status screen displays.
Manage the Extender Network and Security Settings
31
N300 WiFi Range Extender WN2000RPT
Connect the Extender to a Hidden WiFi Network
You can manually connect the extender to a hidden WiFi network without using the
NETGEAR genie Setup Wizard.
Before you start the following procedure, you must know the name of the hidden WiFi
network, the type of security that the network uses, and the key or passphrase to connect to
the network.
To connect the extender to a hidden WiFi network without using the NETGEAR genie
Setup Wizard:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Setup > Connect to an Existing Network.
The extender scans for WiFi networks and displays a list.
5. Select the Manually input my wireless SSID radio button, and click the Continue button.
The screen adjusts.
Manage the Extender Network and Security Settings
32
N300 WiFi Range Extender WN2000RPT
6. In the Name (SSID) field, enter the name of the WiFi network to which you want to connect
the extender.
7. From the Security menu, select the security settings for the WiFi network.
The screen adjusts.
8. Enter the passphrase or key for the WiFi network, and click the Continue button.
9. Use the default extension name, or, in the 2.4GHz Network Name (SSID) field, enter a new
network name for your extender WiFi network.
10. To specify security settings for the extender WiFi network that are different from the WiFi
network of the WiFi router, clear the check box.
The screen adjusts and lets you select security settings. For more information about WiFi
security options, see Manage the Extender WiFi Settings on page 36.
11. Click the Continue button.
12. Wait about two minutes while the extender creates the WiFi network.
Manage the Extender Network and Security Settings
33
N300 WiFi Range Extender WN2000RPT
13. Use a WiFi network manager on the computer or on a mobile device to connect to the
extender’s newly created WiFi network.
Note: Unless you entered a new network name in Step 9, the extender uses
the name of the WiFi network to which you connected the extender and
adds _EXT at the end of the name.
Note: If your computer or mobile device cannot join the new WiFi network of
the extender, see You Cannot Join a WiFi Network and Receive an
Error Message on page 65.
14. Select the My wireless devices are connected to the Extender network check box, and
click the Continue button.
The new WiFi network settings for the extender are saved and the Status screen
displays.
Use WPS to Add a WiFi Device to the Extender’s WiFi
Network
WPS (Wi-Fi Protected Setup) lets you connect a computer or WiFi device to the extender’s
network without entering the WiFi network passphrase or key. Instead, you use a WPS button
or enter a PIN to connect.
If you use the Push button method, the WiFi device that you are trying to connect must have
a physical Push button or a software Push button. If you use the PIN method, you must know
the PIN of the WiFi device that you are trying to connect.
WPS supports WPA and WPA2 WiFi security. If your extender network is open (no WiFi
security is set), connecting with WPS automatically sets WPA + WPA2 WiFi security on the
extender network and generates a random passphrase.
Manage the Extender Network and Security Settings
34
N300 WiFi Range Extender WN2000RPT
You can view this passphrase on the Wireless Settings screen (for more information, see
Manage the Extender WiFi Settings on page 36).
Note: For information about using WPS to connect the extender to a WiFi
network during setup, see Connect the Extender with WPS to a WiFi
Network on page 12.
Use WPS with the Push Button Method
To use the Push button method to connect a WiFi device to the extender’s WiFi network, the
WiFi device that you are trying to connect must have a physical Push button or a software
Push button.
To let a WiFi device join the extender’s WiFi network using WPS with the Push button
method:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Add WPS Client.
The screen displays a description of the WPS method.
5. Click the Next button.
By default, the Push Button (recommended) radio button is selected.
6. Either click the button onscreen or press the WPS button on the front panel of the
extender.
For two minutes, the extender attempts to find the WiFi device (that is, the client) that you
want to join the extender’s WiFi network.
Manage the Extender Network and Security Settings
35
N300 WiFi Range Extender WN2000RPT
7. Within two minutes, go to the WiFi device and press its WPS button (to join the extender’s
WiFi network without entering a password.
8. To verify that the WiFi device is connected to the extender’s WiFi network, select
Maintenance > Network Devices.
The WiFi device displays onscreen.
Use WPS with the PIN Method
To use the PIN method to connect a WiFi device to the extender’s WiFi network, you must
know the PIN of the WiFi device that you are trying to connect.
To let a WiFi device join the extender’s WiFi network using WPS with the PIN method:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Add WPS Client.
The screen displays a description of the WPS method.
5. Click the Next button.
On the screen that displays, the Push Button (recommended) radio button is selected
by default.
6. Select the PIN Number radio button.
7. In the Enter Client's PIN field, enter the PIN number of the WiFi device.
8. Click the Continue button.
For four minutes, the extender attempts to find the WiFi device (that is, the client) that you
want to join the extender’s WiFi network.
9. Within four minutes, go to the WiFi device and use its WPS software to join the network
without entering a password.
Manage the Extender Network and Security Settings
36
N300 WiFi Range Extender WN2000RPT
10. To verify that the WiFi device is connected to the extender’s WiFi network, select
Maintenance > Network Devices.
The WiFi device displays onscreen.
Manage the Extender WiFi Settings
You can change the WiFi network name (SSID) for the extender’s network and set up WiFi
security. If you did not change these settings already during initial setup, the network name is
NETGEAR_EXT, and the network is open (no WiFi security is set up).
Note: Although the WiFi security of the extender’s network can be different
from the WiFi security of the network that the extender is connected
to, you typically would select the same type of WiFi security for both
networks.
To change the WiFi settings for the extender’s network:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Setup > Wireless Settings.
5. In the Name (SSID) field, type a new name.
If more than one extender operates in your neighborhood, changing the SSID makes it
easier to identify the extenders.
Manage the Extender Network and Security Settings
37
N300 WiFi Range Extender WN2000RPT
6. From the Region menu, select the region in which you operate the extender.
Note: If you purchased the extender in the United States or Canada, the
selection from the Region menu is North America. You cannot
change this selection.
7. In the Security Options section of the screen, select the type of WiFi security that you want
to use for the extender’s WiFi network:
•None. An open WiFi network that does not provide any security. Any WiFi device can
join the network.
•WEP. WEP is an older standard, and is less secure than WPA or WPA2. WEP uses
encryption keys and data encryption for data security. Select 64-bit or 128-bit
encryption and enter a key. To join the extender’s WiFi network, a user must enter the
key. For more information, see Configure WEP on page 39.
•WPA-PSK [TKIP]. WPA is more secure than WEP. Enter a passphrase. For more
information, see Configure WPA, WPA2, or WPA + WPA2 on page 38.
•WPA2-PSK [AES]. WPA2 is even more secure than WEP, but some older WiFi
devices do not detect WPA2. Enter a passphrase. To join the extender’s WiFi
network, a user must enter the passphrase. For more information, see Configure
WPA, WPA2, or WPA + WPA2 on page 38.
•WPA-PSK [TKIP] + WPA2-PASK [AES]. When your network includes WiFi devices
that support either WPA or WPA2, select WPA-PSK [TKIP] + WPA2-PASK [AES]
security. Enter a passphrase. To join the extender’s WiFi network, a user must enter
the passphrase. For more information, see Configure WPA, WPA2, or WPA + WPA2
on page 38.
CAUTION:
If you use a WiFi device to change the extender’s WiFi settings, you are
disconnected when you click the Apply button. To reconnect, you must
select the new network name that you created, and enter the passphrase
or WiFi security key that you set up.
8. Click the Apply button.
Your settings are saved.
9. If you are disconnected, reconnect your WiFi device to the extender’s network with its new
settings.
The Setup Wizard can guide you through this process. For more information, see Run the
Setup Wizard Again After Initial Setup on page 47.
Manage the Extender Network and Security Settings
38
N300 WiFi Range Extender WN2000RPT
Configure WPA, WPA2, or WPA + WPA2
Both WPA and WPA2 provide strong data security. WPA2 with AES is a hardware
implementation. If you want to use WPA2 security, make sure that all devices in your WiFi
network support WPA2 security. If you are not sure, use WPA + WPA2 security.
To configure WPA, WPA2, or WPA + WPA2 in the extender:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Setup > Wireless Settings.
5. In the Security Options section, select the WPA-PSK [TKIP], WPA2-PSK [AES], or
WPA-PSK + WPA2-PSK radio button.
6. In the PassPhrase field, enter the passphrase.
7. Click the Apply button.
Your settings are saved.
8. If you are disconnected, reconnect your WiFi device to the extender’s network with its new
settings.
The Setup Wizard can guide you through this process. For more information, see Run the
Setup Wizard Again After Initial Setup on page 47.
Manage the Extender Network and Security Settings
39
N300 WiFi Range Extender WN2000RPT
Configure WEP
WEP is legacy WiFi security. Unless your WiFi network includes devices that do not support
WPA2 or WPA security, NETGEAR recommends that you use WPA2, WPA, or WPA + WPA
security.
Note: WEP security does not support WPS. If you change the security to
WEP, you can no longer let WiFi devices join the extender’s WiFi
network by using WPS.
To set up WEP:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Setup > Wireless Settings.
5. In the Security Options section, select the WEP radio button.
6. From the Encryption Strength menu, select the encryption strength setting:
•64 bit. Requires an encryption key of 10 hexadecimal digits (any combination of 0–9,
a–f, or A–F) or a string of five characters.
•128 bit. Requires an encryption key of 26 hexadecimal digits (any combination of
0–9, a–f, or A–F) or a string of 13 characters.
7. Specify the active key by selecting the Key 1, Key2, Key3, or Key 4 radio button.
Manage the Extender Network and Security Settings
40
N300 WiFi Range Extender WN2000RPT
Only one key can be the active key.
8. Enter a key next to the selected radio button.
The size of the key depends on your selection from the Encryption Strength menu (64
bit or 128 bit.) The key values that are not case-sensitive.
9. Click the Apply button.
Your settings are saved.
10. If you are disconnected, reconnect your WiFi device to the extender’s network with its new
settings.
The Setup Wizard can guide you through this process. For more information, see Run the
Setup Wizard Again After Initial Setup on page 47.
Change the Extender IP Address
By default, the extender receives its IP address automatically from the WiFi router to which it
connects. If the WiFi router does not have a DHCP server or its DHCP server is disabled, you
can assign a static IP address to the extender.
Before you assign a static IP address, you must know the IP address range, subnet mask,
gateway IP address, and primary DNS server of your network.
CAUTION:
NETGEAR recommends that you change the IP address of the extender
only if you are technically experienced or have a technically experienced
person to help you. Incorrect configuration can prevent you from
connecting to the extender and might require you to reset the extender to
factory default settings.
To change the IP address of the extender to a static IP address:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Setup > IP Address Setup.
Manage the Extender Network and Security Settings
41
N300 WiFi Range Extender WN2000RPT
5. Select the Use Static IP Address radio button.
6. Specify the static IP address settings:
•IP Address. The static IP address to be assigned to the extender.
•IP Subnet Mask. The subnet mask associated with the IP address.
•Gateway IP Address. The IP address for the gateway for your WiFi network.
•Primary DNS. The primary domain name server (DNS) for your WiFi network.
7. Click the Apply button.
Your settings are saved, and you are disconnected from the extender.
8. To continue to configure the extender, reconnect to the extender using the new IP address.
Manage Advanced WiFi Settings
The extender is already configured with the optimum settings. Do not change the advanced
settings unless directed by NETGEAR support. Incorrect settings might disable the extender
unexpectedly.
To view or change the advanced WiFi settings:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Advanced > Wireless Settings.
Manage the Extender Network and Security Settings
42
N300 WiFi Range Extender WN2000RPT
5. View or change the following settings:
•Enable Wireless Access Point. By default, the extender functions as a WiFi access
point. Clear the Enable Wireless Access Point check box only if you want to prevent
WiFi devices from connecting to the extender. LAN devices can still connect to the
extender over an Ethernet cable.
•Enable SSID Broadcast. By default, the extender broadcasts its WiFi network name
(SSID). Clear the Enable SSID Broadcast check box only to hide the network name
of the extender. In such a situation, the network name of the extender does not
display in a WiFi network manager. A user who wants to join the hidden WiFi network
of the extender must know its network name.
•Keep Existing Wireless Settings. By default, the settings on the Wireless Settings
screen remain the same when you use WPS to establish a WiFi connection. Clear the
Keep Existing Wireless Settings check box only if you want to allow the WPS
process to change the SSID and passphrase on the Wireless Settings screen.
If you clear the Keep Existing Wireless Settings check box and use WPS to add a
computer or WiFi device to the extender’s network, the SSID and passphrase are
automatically generated and other devices that are already connected to the
extender’s network might be disconnected. You can view the SSID and passphrase
on the Wireless Settings screen (see Manage the Extender WiFi Settings on
page 36).
NETGEAR recommends that you keep the Keep Existing Wireless Settings check
box selected.
6. Click the Apply button.
Your changes are saved.
Manage a WiFi Access List
By default, any WiFi device that is configured with the correct network name (SSID) can
access the WiFi network of the extender. For increased security, you can restrict access to
the WiFi network of the extender to allow only specific WiFi devices based on their MAC
addresses. Devices that are not on the access list cannot join the WiFi network of the
extender.
Each network device has a MAC address, which is a unique 12-character physical address,
containing the hexadecimal characters 0–9, a–f, or A–F only, and separated by colons (for
Manage the Extender Network and Security Settings
43
N300 WiFi Range Extender WN2000RPT
example, 00:09:AB:CD:EF:01). Typically, the MAC address is on the label of the WiFi device.
If you do not have access to the label, you can display the MAC address using the network
configuration utilities of the computer. You might also find the MAC addresses on the Network
Devices screen (see View the Wired and WiFi Network Devices on page 61).
CAUTION:
If you use a WiFi device to set up the access list, add your WiFi device to
the access list. Otherwise, you are disconnected when you click the Apply
button. To avoid this situation, use a computer with a wired connection to
access the extender.
Set Up and Enable the Access List
Before you can enable the access list, you must add the MAC addresses of the WiFi devices
that you want to grant access to the WiFi network of the extender.
To set up and enable the access list:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Advanced > Wireless Settings.
5. Click the Setup Access List button.
Manage the Extender Network and Security Settings
44
N300 WiFi Range Extender WN2000RPT
If you have not yet added any WiFi devices, the Wireless Card Access List is empty.
6. Click the Add button.
7. In the Device Name field, type a name for the WiFi device.
8. In the MAC Address field, type the MAC address of the WiFi device.
9. Click the Apply button.
The WiFi device is added to the Wireless Card Access List.
10. To add more WiFi devices, repeat Step 6 through Step 9.
11. Above the Wireless Card Access List, select the Turn Access Control On check box.
CAUTION:
If you use a WiFi device to set up the access list, add your WiFi device to
the access list. Otherwise, you are disconnected when you click the Apply
button.
12. Click the Apply button.
Now only WiFi devices that are in the Wireless Card Access List can access the WiFi
network of the extender.
Disable the Access List
After you have enabled the access list on the extender, you can disable the access list again.
To disable the access list:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
Manage the Extender Network and Security Settings
45
N300 WiFi Range Extender WN2000RPT
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Advanced > Wireless Settings.
5. Click the Setup Access List button.
6. Above the Wireless Card Access List, clear the Turn Access Control On check box.
7. Click the Apply button.
Now any WiFi device can access the WiFi network of the extender.
Change a Device on the Access List
You can change the name or MAC address of a device on the access list.
To change a WiFi device on the access list:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Advanced > Wireless Settings.
Manage the Extender Network and Security Settings
46
N300 WiFi Range Extender WN2000RPT
5. Click the Setup Access List button.
6. Select the radio button to the left of the device that you want to change.
7. Click the Edit button.
8. Change the name of the device or the MAC address.
9. Click the Apply button.
The changed settings display in Wireless Card Access List.
Remove a Device from the Access List
If you no longer want to grant a device access to the WiFi network of the extender, you can
remove the device from the access list.
To remove a WiFi device from the access list:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
Manage the Extender Network and Security Settings
47
N300 WiFi Range Extender WN2000RPT
If you have not yet personalized your password, type password for the password.
4. Select Advanced > Wireless Settings.
5. Click the Setup Access List button.
6. Select the radio button to the left of the device that you want to remove.
7. Click the Delete button.
The device is removed from the Wireless Card Access List.
Run the Setup Wizard Again After Initial Setup
There might be situations in which you want to run the Setup Wizard again after the initial
setup.
To run the Setup Wizard again:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Setup Wizard.
Manage the Extender Network and Security Settings
48
N300 WiFi Range Extender WN2000RPT
5. Click the Yes button.
6. NETGEAR genie searches for WiFi networks automatically.
7. Select a WiFi network to extend, and click the Continue button.
8. Type the network passphrase (also called a password or network key) in the PassPhrase
field, and click the Continue button.
Manage the Extender Network and Security Settings
49
N300 WiFi Range Extender WN2000RPT
9. Use the default extension name, or, in the 2.4GHz Network Name (SSID) field, enter a new
network name for your extender WiFi network, and click the Continue button.
The extender applies the settings.
10. Wait about two minutes while the extender creates the WiFi network.
11. Use a WiFi network manager on the computer or mobile device to connect to the extender’s
newly created WiFi network.
Note: Unless you entered a new network name in Step 9, the extender the
extender uses the network name of the WiFi network to which you
connected the extender and adds _EXT at the end of the name.
Note: If your computer or mobile device cannot join the new WiFi network of
the extender, see You Cannot Join a WiFi Network and Receive an
Error Message on page 65.
12. Select the My wireless devices are connected to the Extender network check box, and
click the Continue button.
Manage the Extender Network and Security Settings
50
N300 WiFi Range Extender WN2000RPT
The next screen that displays describes the color of the Link Rate LED, which
corresponds to the color of the LED on the front of the extender.
If the link rate LED is not green, see Improve the Connection Between the Extender and
the WiFi Router on page 66.
13. Click the Finish button.
A pop-up screen displays.
14. To bookmark the URL of the extender, click the OK button.
A NETGEAR website displays. You are now online.
Manage the Extender Network and Security Settings
51
N300 WiFi Range Extender WN2000RPT
Connect Ethernet-Enabled Devices
You can use the extender to connect as many as four Ethernet-enabled devices, such as
smart TVs, game consoles, and Blu-ray players, to the WiFi network.
After you have set up the extender, plug the Ethernet cable from a device that you want to
connect directly into one of the extender’s Ethernet LAN ports.
Figure 5. Ethernet LAN port on the rear panel
Ethernet LAN ports
52
4
4. Maintain and Monitor the Extender
This chapter covers the following topics:
•Back Up the Configuration Settings
•Restore the Configuration Settings
•Return the Extender to Its Factory Default Settings
•Upgrade the Firmware
•View the Status and Traffic Statistics of the Extender
•View the Wired and WiFi Network Devices
Maintain and Monitor the Extender
53
N300 WiFi Range Extender WN2000RPT
Back Up the Configuration Settings
When the extender works correctly after initial setup, NETGEAR recommends that you back
up the extender configuration settings. After you have backed up the settings, if you have
changed the extender configuration settings but are not content with the new settings, you can
restore the extender configuration to the backed-up settings.
To back up the extender configuration settings:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select extender Maintenance > Backup Settings.
5. Click the Backup button.
Your browser extracts the configuration file from the extender. By default, the name of the
backup file is NETGEAR_WN2000RPTv2.cfg.
6. If you do not have your browser set up to save downloaded files automatically, locate where
you want to save the file.
Maintain and Monitor the Extender
54
N300 WiFi Range Extender WN2000RPT
Restore the Configuration Settings
You can restore the configuration file of the extender to a previously saved configuration file.
CAUTION:
This process erases any settings that you have configured in the extender.
To restore the extender configuration settings:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select extender Maintenance > Backup Settings.
5. Click the Browse button.
6. Locate and select the previously saved backup file.
By default, the name of the backup file is NETGEAR_WN2000RPTv2.cfg.
CAUTION:
After you click the Restore button, do not try to go online, turn off the
extender, shut down the computer, or do anything else to the extender
until it finishes restarting!
7. Click the Restore button.
A confirmation pop-up screen displays.
8. Confirm your decision.
The extender restarts. This process takes about one minute.
Maintain and Monitor the Extender
55
N300 WiFi Range Extender WN2000RPT
Return the Extender to Its Factory Default Settings
Under some circumstances (for example, if you have lost track of the changes that you made
to the extender settings), you might want to erase the configuration and reset it to factory
default settings.
To reset the extender to factory default settings, you can use either the Restore Factory
Settings button on the rear panel or the Erase function. However, if you have lost the
password to access the extender, you must use the Restore Factory Settings button.
For a list of factory default settings, see Factory Default Settings on page 68.
Use the Factory Reset Button
CAUTION:
This process erases any settings that you have configured in the extender.
To reset the extender to factory default settings:
1. Insert a straightened paper clip into the hole of the Restore Factory Settings button
and hold it for about seven seconds.
2. Release the button.
The extender resets and restarts. This process takes about one minute.
Erase the Extender Configuration Settings
CAUTION:
This process erases any settings that you have configured in the extender.
To erase the extender’s settings:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Maintenance > Backup Settings.
Maintain and Monitor the Extender
56
N300 WiFi Range Extender WN2000RPT
CAUTION:
After you click the Erase button, do not try to go online, turn off the
extender, shut down the computer, or do anything else to the extender
until it finishes restarting!
5. Click the Erase button.
A confirmation pop-up screen displays.
6. Confirm your decision.
The extender resets and restarts. This process takes about one minute.
Upgrade the Firmware
Unless you changed the settings in the Firmware Upgrade screen previously, the extender is
set up to check for new firmware automatically at login.
To check manually for new firmware and, if available, upgrade the firmware:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Maintenance > Firmware Upgrade.
Maintain and Monitor the Extender
57
N300 WiFi Range Extender WN2000RPT
5. Click the Check button.
6. If new firmware is available, follow the onscreen prompts to download it onto your computer.
Note: You might need to unzip the firmware file.
7. Click the Browse button.
8. Locate and select the new firmware file.
The firmware file has a .img extension.
CAUTION:
After you click the Upload button, do not try to go online, turn off the
extender, shut down the computer, or do anything else to the extender
until it finishes restarting!
9. Click the Upload button.
The firmware upgrade starts and the extender restarts. The firmware upgrade process
takes a couple of minutes.
To disable the automatic new firmware check:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Maintenance > Firmware Upgrade.
Maintain and Monitor the Extender
58
N300 WiFi Range Extender WN2000RPT
5. Clear the Check for New Version Upon Log-in check box.
A confirmation pop-up screen displays.
6. Confirm your decision.
View the Status and Traffic Statistics of the Extender
The Status screen displays when you log in to the extender after initial setup. The Status
screen shows the current settings for the extender and provides access to the traffic statistics,
such as the number of packets sent and number of packets received for each port.
To view the status of the extender and the traffic statistics and to change the poll
interval:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Maintenance > Status.
Maintain and Monitor the Extender
59
N300 WiFi Range Extender WN2000RPT
The following table describes the fields on the Status screen.
Field Description
Hardware Version The hardware version of the extender.
Firmware Version The current firmware version of the extender. If you upgrade the firmware, this field
changes.
GUI Language Version The language version that is set on the extender. If you upgrade the firmware, this
field might change.
Connection Status to Existing Network
Name (SSID) The name (SSID) of the WiFi network to which the extender is connected.
Connection Status Shows whether the extender is connected to a WiFi network.
Link Rate The combined transmission (Tx) and receive (Rx) link rate in Mbps of the current
WiFi connection.
Extender IP Info
MAC Address The physical address of the extender.
IP Address The IP address of the extender. The default is 192.168.1.250.
DHCP Client Shows whether the DHCP client of the extender is on.
IP Subnet Mask The IP subnet mask that is associated with the IP address of the extender. The
default is 255.255.255.0.
Gateway IP Address The IP address of the WiFi network gateway.
Domain Name Server The IP address of the Domain Name Server (DNS) of the WiFi network.
Maintain and Monitor the Extender
60
N300 WiFi Range Extender WN2000RPT
5. Click the Show Statistics button.
The following table describes the traffic statistics fields that display for each of the four
LAN ports and for the WLAN port.
6. To change the poll interval:
a. Click the Stop button.
b. In the Poll Interval field, enter a new value in seconds.
c. Click the Set Interval button.
Extender Wireless Settings
Name (SSID) The name (SSID) of the WiFi network of the extender.
Region The location in which the extender is operating.
Channel The active channel of the WiFi network.
Wireless AP Shows whether the WiFi access point of the extender is on.
Broadcast Name Shows whether broadcasting of the network name (SSID) of the extender is on.
Wi-Fi Protected Setup Shows whether Wi-Fi Protected Setup (WPS) is configured.
Field Description
Status The link status of the port.
TxPkts The number of packets transmitted on the port since the extender was restarted.
RxPkts The number of packets received on the port since the extender was restarted.
Collisions The number of collisions on the port since the extender was restarted.
Tx B/s The packet transmission rate in bytes per second on the port.
Rx B/s The packet reception rate in bytes per second on the port.
Up Time The time elapsed since the extender was restarted.
Field Description
Maintain and Monitor the Extender
61
N300 WiFi Range Extender WN2000RPT
View the Wired and WiFi Network Devices
You can view the active wired and WiFi devices in both the network to which the extender is
connected and the extender network. If you do not recognize a WiFi device, it might be an
intruder.
To display the wired and WiFi devices:
1. On your computer, launch an Internet browser such as Mozilla Firefox or Microsoft
Internet Explorer.
2. In the address field of your browser, enter http://www.mywifiext.net.
You are prompted to enter a user name and password. If you do not see the login prompt,
make sure to include http:// when you type http://www.mywifiext.net in your browser.
3. Type admin for the user name and type your password.
If you have not yet personalized your password, type password for the password.
4. Select Maintenance > Network Devices.
For each wired and WiFi device, the IP address, MAC address, and device name display.
5. (Optional) Click the Refresh button.
The information onscreen is updated.
62
5
5. FAQs and Troubleshooting
This chapter covers the following topics:
•FAQs
•You Cannot Connect to the Extender
•You Cannot Join a WiFi Network and Receive an Error Message
•Improve the Connection Between the Extender and the WiFi Router
FAQs and Troubleshooting
63
N300 WiFi Range Extender WN2000RPT
FAQs
This section provides answers for difficulties you might experience with the extender.
1. Question. Does the extender work if I connect it to my WiFi router with an Ethernet
cable?
Answer. No, the extender is designed only to connect over WiFi to a WiFi router.
2. Question. What are the default user name and password to log in to the extender?
Answer. If you are online at http://www.mywifiext.net, you can use the following user
name and password to log in:
•User name. admin
•Password. password
3. Question. When I try to connect to the network, the Setup Wizard keeps asking me for my
passphrase, and I am sure I’ve entered the correct passphrase. What can I do?
Answer. It is likely that the extender is placed at the borderline of the range that the WiFi
router covers. For more information, see How to Position the Extender on page 11 and
Improve the Connection Between the Extender and the WiFi Router on page 66.
4. Question. I receive an error message on the Review Settings screen on the Setup Wizard.
What can I do?
Answer. Make sure that your computer is connected to the extender by using the SSID
and the passphrase that you have set up, and clicking the Refresh button in your
browser. You should be returned to the Setup Wizard.
5. Question. I connected to NETGEAR_EXT and launched a browser, but why can I not see
the Setup Wizard?
Answer. First, make sure that your device is set up to use DHCP. Second, make sure
that the Device to Extender Connection LED is green. Finally, relaunch the browser and
enter www.mywifiext.net.
6. Question. I have enabled a WiFi MAC filter (WiFi access control or ACL) on my WiFi router.
What should I do when installing the extender?
Answer. When the WiFi device connects through the extender to your router, the MAC
address of the WiFi device shown on the router is translated to another MAC address. If
your router's MAC filter is enabled, the WiFi device connects to the extender but cannot
get an IP address from the extender and cannot access the Internet. To allow the WiFi
device to receive an IP address from the extender and access the Internet, you must
provide the translated MAC address to the router.
To get the translated MAC address:
a. Disable the MAC filter on your router.
b. Turn on the extender and connect all of your WiFi devices to the extender.
c. Make sure that the Link Rate LED remains lit.
FAQs and Troubleshooting
64
N300 WiFi Range Extender WN2000RPT
d. Log in to the router and check the attached devices on the Attached Devices or
similar screen.
e. Add any MAC addresses that begin with 02:0F:B5 to your router’s MAC filter table.
7. Question. My router security is WEP, and I entered the wrong passphrase or security key
on the extender. I cannot access the extender anymore. What can I do?
Answer. The extender cannot detect whether the WEP passphrase is correct. If you
entered the wrong passphrase, your WiFi device cannot get the IP address from the
extender. You must reset the extender to the factory defaults to get the IP address back.
8. Question. Is seamless roaming supported? During a VoIP call, when I move to a different
location the call is dropped. What should I do?
Answer. No, the extender does not support seamless roaming. You might notice
performance issues if your WiFi device (laptop, smartphone, or tablet) connects to a
different WiFi network. For example, you might connect to the extender WiFi network,
begin a call, and then move to the location of your existing WiFi network. Your WiFi
device automatically connects to the network in your current location, which takes a few
seconds and might cause your call to be dropped. To prevent this situation, decide which
WiFi network you want to use for your VoIP call, and stay within the range of that network.
You Cannot Connect to the Extender
If you have trouble connecting to the extender, determine what prevents you from
connecting:
•Make sure that you use the correct user name and password to log in:
-User name. admin
-Password. password
•If your browser displays an error page, make sure that you include http:// when you type
http://www.mywifiext.net in the address field of your Internet browser. If you leave it out,
you might not be able to connect.
•If you already set up the extender but can no longer connect to it over WiFi, check if the
Link Rate LED is off or red. For more information, see Improve the Connection Between
the Extender and the WiFi Router on page 66.
•If you cannot get a WiFi connection working, you can use an Ethernet cable to connect
your computer to the extender. For more information, see Access the Extender over
Ethernet and Use the Setup Wizard on page 19.
FAQs and Troubleshooting
65
N300 WiFi Range Extender WN2000RPT
You Cannot Join a WiFi Network and Receive an Error
Message
To join a WiFi network, you must know its network name (also called the SSID) so that you
can select it. If the network is secure, you must know the passphrase or key. If the extender
does not connect to the network that you select, the following message displays:
Connection was not established to the selected network.
If this situation occurs, the cause might be one of the following:
•You might have typed the network name, passphrase, or key incorrectly. Use the Setup
Wizard to select a WiFi network from the list with detected networks, and retype the
passphrase or key. The passphrase or key is case-sensitive. For example,
PASSWORD25 is not the same as Password25 or password25.
•If the extender cannot detect your WiFi network, check to see if your WiFi network is still
up. Make sure that the WiFi router is turned on. If possible, move the extender closer to
the WiFi router. For more information, see Improve the Connection Between the Extender
and the WiFi Router on page 66.
•If the extender Link Rate LED is red, a poor WiFi connection exists between the WiFi
router and the extender. You can establish the best connection with a clear line of sight
between the extender and the WiFi router. Make sure that no physical obstacles exist
between the extender and the WiFi router, and try to move the extender closer to the WiFi
router. For more information, see Improve the Connection Between the Extender and the
WiFi Router on page 66.
If you use the Setup Wizard, and the extender cannot connect to the WiFi router or cannot
get an IP address from the WiFi router, or the WiFi router is not connected to the Internet, the
Setup Wizard displays the following message:
You are not able to connect to the Internet. Click Continue to run through setup again to
connect to your network.
Either run the Setup Wizard again or exit the Setup Wizard and try again later (see Log In to
the Extender After Initial Setup on page 26 and Run the Setup Wizard Again After Initial
Setup on page 47).
FAQs and Troubleshooting
66
N300 WiFi Range Extender WN2000RPT
Improve the Connection Between the Extender and the
WiFi Router
The extender LEDs can help you tell whether the extender is correctly set up and working as
it should.
To improve the connection between the extender and the WiFi router:
1. Move the extender closer to the WiFi router or to a different spot where it provides a
better line of sight.
You might need to unplug the extender, replug it at its new location, and restart it. Unless
the extender is outside the range of your WiFi router, the extender connects automatically
to the WiFi router.
2. As you move the extender, continue to check the Link Rate LED and the Device to Extender
LED on the top panel until you find a location where the Link Rate LED is green or amber,
and the Device to Extender LED is green.
The following table describes how the LEDs show the quality of the connection.
LED Status LED Color Performance
Both the Link Rate LED and the Device
to Extender Connection LED are green. and The extender provides the best performance.
The Link Rate LED is amber and the
Device to Extender Connection LED is
green.
and The extender provides a workable performance.
The Link Rate LED is red. The extender provides a poor performance.
The Link Rate LED is off. The extender cannot function.
67
A
A. Factory Settings and Technical
Specifications
This appendix covers the following topics:
•Factory Default Settings
•Technical and Environmental Specifications
Factory Settings and Technical Specifications
68
N300 WiFi Range Extender WN2000RPT
Factory Default Settings
To reset the extender to factory default settings, you can use either the Restore Factory
Settings button on the rear panel or the Erase function. For more information, see Return the
Extender to Its Factory Default Settings on page 55.
The following table lists the factory default settings.
Table 2. Factory default settings
Factory Settings
Setup Wizard Enabled
WiFi WiFi communication Enabled
WiFi network name (SSID) NETGEAR_EXT
Security Disabled
Transmission speed Auto1
1. Maximum WiFi signal rate (IEEE Standard 802.11). Actual throughput can vary. Network conditions and environmental factors,
including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput
rate.
Country/region Varies by region
Operating mode 802.11n, 802.11g, 802.11b
Data rate Up to 300 Mbps
DHCP Client enabled
Factory Settings and Technical Specifications
69
N300 WiFi Range Extender WN2000RPT
Technical and Environmental Specifications
The following table shows the technical and environmental specifications.
Table 3. Technical specifications
Technical Specifications
Network protocol and
standards compatibility Data and routing protocols: TCP/IP, DHCP client, DNS relay, NAT (many-to-one),
VPN pass-through (IPSec, PPTP)
Power adapter • North America (input): 120V, 60 Hz, input
• All regions (output): 12 VDC @ 1A output 15W maximum
Physical specifications • Dimensions: 7 by 5.1 by 2.1 in. (178 by 130 by 54 mm)
• Weight: 0.63 lb (0.28 kg)
Environmental • Operating temperature: 32° to 140°F (0° to 40°C)
• Operating humidity: 90% maximum relative humidity, noncondensing
• Electromagnetic emissions: Meets requirements of FCC Part 15 Class B.
Interface • 10BASE-T, 100BASE-TX, RJ-45
• 802.11n, 802.11g, 802.11b

Navigation menu
