Users Manual
Please read this user’s guide before
installing, setting up and using your new product
www.radioshack.com
Your boat is not designed for use in oceans, rivers, lakes or streams. Use in a swimming pool,
pond or small body of water.
Attach the antenna to your transmitter.
Slide the boat’s antenna wire through the supplied tube. Then, insert
the tube into the antenna tube holder.
Turn your boat and transmitter on.
Place your boat in the water and use the transmitter’s controls to
operate it. Your transmitter’s LED lights when you move the controls.
in your transmitter
Your transmitter requires one 9V
alkaline battery (not supplied,
available at your local RadioShack
store or online at
www.radioshack.com).
Press OPEN and pull
the battery cover
downward.
Insert your 9V battery,
matching the polarity
(+ and -) symbols
marked inside.
Replace the cover.
When your transmitter’s range decreases, replace
its battery.
in your boat
Your boat requires one 9.6V
rechargeable nickel-metal hydride
(Ni-MH) battery pack (not supplied,
available at your local RadioShack
store or online at
www.radioshack.com). You must
charge it before use. Follow the
manufacturer’s instructions for charging your
battery pack.
Turn your boat off.
Turn the right and left latches toward the
OPEN arrow and remove the cover.
Attach the battery pack’s
connector to the boat’s
connector. Do not force
them; they fi t only one
way.
Carefully insert the
wires into the battery
compartment and replace the cover.
60-4411
caliente RC boat
RC Boat & Stand Transmitter Antenna
Boat Antenna Tube User’s Guide
Transmitter
Thank you for purchasing your RadioShack
Caliente RC Boat from RadioShack. Your boat
comes in two frequencies (27 MHz and 49
MHz), so you and your friends can have fun
driving together.
Note: Actual product may vary from the
images found in this document.
WARNING!
Do not submerge your transmitter or leave it in water.
Store your boat on the included stand when not in use.
Connector
Release to Stop
LED
Forward
Reverse
Left
Release to go Straight
Right
Antenna tube
©2005. RadioShack Corporation.
All rights reserved. RadioShack and
RadioShack.com are trademarks
used by RadioShack Corporation.
60-4411
02A05
Printed in Malaysia
The FCC Wants You to Know
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult your local RadioShack store or an
experienced radio/TV technician for help.
• If you cannot eliminate the interference, the
FCC requires that you stop using your mini
boat.
Changes or modifi cations not expressly
approved by RadioShack may cause
interference and void the user’s authority to
operate the equipment.
This product is warranted by RadioShack against manufacturing defects
in material and workmanship under normal use for ninety (90) days
from the date of purchase from RadioShack company-owned stores
and authorized RadioShack franchisees and dealers. For complete war-
ranty details and exclusions, check with your local RadioShack store.
RadioShack Customer Relations
300 RadioShack Circle, Fort Worth, TX 76102
04/04
• Dry your boat thoroughly after use.
• Two boats with the same frequency cannot run together. Both frequencies (27 MHz and 49 MHz)
are available from your local RadioShack store.
• Running your boat continuously for long periods generates high heat levels, which cause wear
and tear on the motor. To help keep heat levels down, let the boat cool at least 10 minutes
before installing a fresh battery pack.
• Keep your boat away from grass and debris that could cause propeller damage.
• If your boat does not respond, drives slowly, or the range reduces, recharge your battery pack.
• If your boat fails to respond after recharging, replace the battery in the transmitter and check the
propellers for debris.
• When your boat slows down from loss of battery power, guide it shore immediately so you
won’t lose it.
• When your boat goes outside the transmitter’s range, it stops. Hold your transmitter high above
your head to try to re-establish contact. If this doesn’t work, move closer and try again. Be
careful not to wade in deep water.
• Never touch the propellers while they are spinning, and avoid the propellers while the boat
is on.
• Children must be supervised by adults when playing with toys around water.
• Dispose of old batteries promptly and
properly. Do not burn or bury batteries.
• Use only fresh batteries of the required size
and recommended type.
• Do not mix old and new batteries, or
batteries with different capacities or different
chemistries.
• Never leave a dead or weak battery in your
transmitter.
• If you do not plan to use your RC boat for
a few weeks, remove the battery from your
transmitter. Batteries can leak chemicals that
may damage electronic parts.
• Do not charge or recharge your battery pack
when it is in the boat.
• Do not overcharge your battery pack.
• Do not recharge your battery pack
immediately after use. Allow it to cool fi rst.
• Make sure your battery pack is securely
fastened to your boat before playing.
• Batteries purchased for use in this toy may
be hazardous to children. Check the safety
notice before use.
Drain holes
On/Off Propeller
• When you fi nish playing, remove your boat
from the water.
• Remove the rubber caps on the three drain
holes and shake excess water from your
boat.
• Use and store your boat and transmitter only in room temperature environments.
• Handle them carefully. Do not drop them.
• Keep your boat and transmitter away from dust and dirt, and wipe them with a damp cloth
occasionally to keep them looking new.
• Leave its battery cover off while in storage to allow moisture to evaporate.
The EPA certifi ed RBRC®
Battery Recycling Seal on
the nickel-cadmium (Ni-Cd)
battery indicates RadioShack
is voluntarily participating in
an industry program to collect
and recycle these batteries
at the end of their useful life, when taken out of
service in the United States or Canada. The RBRC
program provides a convenient alternative to
placing used Ni-Cd batteries into the trash or the
municipal waste stream, which may be illegal
in your area. Please call 1-800-THE-SHACK (1-
800-843-7422) for information on Ni-Cd battery
recycling and disposal bans/restrictions in your
area. RadioShack’s involvement in this program is
part of the company’s commitment to preserving
our environment and conserving our natural
resources.
